Product Catalog
February 2021
Contents
VHF Handhelds ..................................................................................................................................... 5
M25 .................................................................................................................................................... 6
M37 .................................................................................................................................................... 8
M73 .................................................................................................................................................. 10
M85 .................................................................................................................................................. 12
M85IS .............................................................................................................................................. 15
M94D ............................................................................................................................................... 17
VHF Fixed Mount ................................................................................................................................. 19
M200 EXPORT ONLY ...................................................................................................................... 20
M220 EXPORT ONLY ...................................................................................................................... 22
M400BB ........................................................................................................................................... 24
M330 – M330G ................................................................................................................................ 26
M424G ............................................................................................................................................. 28
M506 ................................................................................................................................................ 30
M605 ................................................................................................................................................ 33
HM195/G .......................................................................................................................................... 36
SSB ..................................................................................................................................................... 37
M802 EXPORT ONLY ...................................................................................................................... 38
M803 ................................................................................................................................................ 40
M700PRO EXPORT ONLY .............................................................................................................. 42
GMDSS ............................................................................................................................................... 44
GM1600 ........................................................................................................................................... 45
GM600 EXPORT ONLY ................................................................................................................... 48
GM800 EXPORT ONLY ................................................................................................................... 50
AIS/Radar ............................................................................................................................................ 52
MA510TR ......................................................................................................................................... 53
MR-1010R2 ...................................................................................................................................... 55
Discontinued Radios ............................................................................................................................ 57
M93D ............................................................................................................................................... 58
MA500TR ......................................................................................................................................... 59
M36 .................................................................................................................................................. 60
M24 .................................................................................................................................................. 61
M72 .................................................................................................................................................. 62
3
3026.02.21
M92D ............................................................................................................................................... 63
M412 ................................................................................................................................................ 64
M504 ................................................................................................................................................ 65
M604 ................................................................................................................................................ 66
3026.02.21
4
VHF Handhelds
3026.02.21
5
M25
SPECS _______________________
Output Power: 5W, 1W
Waterproof Rating: IPX7 (submersible protection)
Frequencies: Tx: 156.025–157.425MHz
Rx: 156.050–163.275MHz
Usable Channel Groups: INT, USA, CAN and WX
Type of Emission: FM (16K0G3E)
Current Drain (at 3.7V DC):Tx (High): 2.3A
Rx (at AF max):
300mA/200mA
Weight: 7.8oz
Versions: Marine blue, metallic gray,
pearl white
FEATURES ___________________
Float 'n flash
USB charging
11 hours battery life
Large LCD with simple user interface (30% larger than M24)
550mW audio output
4-step battery life indicator
Dual/Tri-watch functions
Weather channel with weather alert
Instant access to Ch. 16 or programmable call channel
Auto scan function
Tag scan
Favorite channel functions
Monitor function opens noise squelch
LCD auto backlighting
AquaQuake draining function
COMES WITH ___________
Battery charger (BC217SA)
Belt clip (MB133)
Antenna (FASC59V)
Hand strap
Owner’s manual
Warranty: 3 years
VHF Marine Transceiver
6
3026.02.21
M25
Configurations
Model
Description
M25 GRAY
5W floating marine VHF handheld in metallic gray
M25 WHITE
5W floating marine VHF handheld in pearl white
M25 BLUE
5W floating marine VHF handheld in marine blue
Accessories
Model
Description
Antennas
FASC59V
Standard antenna M25/M37/M93D/M92D
Batteries
BP282
1500mAh Li-ion battery for the M25
Belt Clips
MB133
Alligator type belt clip
Chargers
BC217SA
USB charger; 100-240V with a US style plug
Microphones
HM213
Waterproof floating speaker mic for M25
Software & Cables
CSM25
M25 programming software (requires OPC478UC+OPC1655)
OPC1655
Cloning cable adapter for M25/M36/M93D
OPC478UC
USB programming cable (2-pin connectors handhelds)
VHF Marine Transceiver
7
3026.02.21
M37
SPECS _______________________
Output Power: 6W, 1W
Waterproof Rating: IP57 rating
Frequencies: Tx: 156.025-157.425MHz
Rx: 156.050-163.275MHz
Usable Channel Groups: INT, USA, CAN, WX
Type of Emission: 16K0G3E
Current Drain: Tx (at 6.0W/1.0W output):
2.5A/1.0A
Rx (Max audio. Inter SP/Exter
SP): 0.4A/0.2A
Weight: 10.3oz (with BP296)
FEATURES ___________________
700mW audio output
Channel history function stores the last five channels used for easy recall
Float’n Flash function
Low Battery Alert function
Voice Loud and Mute function enables to temporary maximize/mute the
volume
AquaQuake™ function prevents audio degradation from a water-logged
speaker
Dualwatch and Tri-Watch functions
Favorite Channel function
Instant access to channel 16 and the Call channel
Weather channels with Weather Alert function
COMES WITH ___________
Battery pack (BP296)
Trickle charger (BC235)
AC adapter (BC217SA)
Belt clip (MB133)
Antenna (FASC59V)
Hand strap
Owner’s manual
Warranty: 3 years
VHF Marine Handheld
8
3026.02.21
M37
Configurations
Model
Description
M37
6W marine VHF floating handheld with battery, charger included
Accessories
Model
Description
Antennas
FASC59V
Standard antenna M25/M37/M93D/M92D
Batteries
BP296
3.6V 2350mAh Li-Ion battery (M37)
BP297
Alkaline case for M37 (3 x AAA)
Belt Clips
MB133
Alligator type belt clip
Carrying Cases
NCP1
Nylon chest pack
Chargers
BC217SA
USB charger; 100-240V with a US style plug
BC235
Desktop trickle charger (requires BC217SA)
BC238
6-unit gang charger for the M37
Microphones
HM213
Waterproof floating speaker mic for M25
VHF Marine Handheld
9
3026.02.21
M73
SPECS _______________________
Output Power: 6W, 3W, 1W
Waterproof Rating: IPX8 (submersible)
Frequencies: Tx: 156.025-157.425MHz
Rx: 156.050-163.275MHz
Usable Channel Groups: INT, USA, CAN, WX
Type of Emission: FM (16K0G3E)
Current Drain: Tx (at 6W output): 1.5A
Rx (Max.audio):
450mA/250mA
Weight: 11.3oz (with BP245N)
FEATURES ___________________
Both Versions:
• Slim, hourglass body and wide viewing angle LCD
• IPX8 Submersible Plus™
• 700mW loud audio
• 6W RF output power
• AquaQuake™ water draining function
• Dual/Tri-Watch function for monitoring Channel 16 and/or call
channel
• 4 level battery indicator
• Favorite channel and tag scan functions
• Auto power save function
Plus Version:
• Last call voice recording
• Bidirectional active noise cancelling
COMES WITH ___________
Antenna (FAS64V)
Battery pack (BP245N)
Belt clip (MB103)
Cigarette lighter cable (CP25H)
Rapid charger (BC210)
Hand strap
Owner’s manual
Warranty: 3 years
VHF Marine Transceiver
10
3026.02.21
M73
Configurations
Model
Description
M73
6W IPX8 submersible handheld
M73 PLUS
6W IPX8 submersible handheld with built-in active noise cancelling and voice recording
Accessories
Model
Description
Antennas
AD92SMA
Antenna connector adapter to connect a BNC-type antenna
FAS64V
Standard antenna for the M72/M73 (4 17/32" or 115mm)
Batteries
BP245H
7.4V 2000mAh Li-Ion battery for M72/M73
Belt Clips
MB103
Alligator belt clip
MB86
Swivel belt clip that screws into back of radio
MB96N
Swivel belt hanger to use with standard belt clip
Cables
OPC515L
DC power cable for single unit rapid chargers
OPC656
DC power cable for gang charger
Chargers
AD129
Adapter cup for BC197 gang charger for M73
BC123SA
AC adapter for rapid chargers; 100-240V with US style plug
BC123SE
AC adapter for rapid chargers; 100-240V with Euro style plug
BC157S
AC adapter for gang chargers; 100-240V with US style plug
BC157SE
AC adapter for gang chargers; 100-240V with Euro style plug
BC197 32
Six unit charger for radios with the BP245N Li-Ion battery (includes AC adapter and cups
installed); 100-240V with US style plug
BC210
Rapid charger for the BP-245 includes AC adapter with US plug
CP23L
12V cigarette lighter cable for use with rapid chargers
Headsets
HS94
Earpiece headset; use with VS/OPC2004/OPC2006/OPC1392
HS95
Headset with boom mic; use with VS/OPC2004/OPC2006/OPC1392
HS97
Earphone with throat mic headset; use with VS/OPC2004/OPC2006/OPC1392
OPC1392
Headset adapter to use with HS94/95/97 for the M73/M72/GM1600/M90
Microphones
HM167
Lightweight IPX8 waterproof speaker mic M73/GM1600/M92/M72
HM202
Compact IPX7 waterproof speaker mic M73/M72
Software & Cables
CSM73
Programming software for the M73
OPC478UC
USB programming cable (2-pin connectors handhelds)
OPC922
Cloning cable adapter for M72/M73/M92D
VHF Marine Transceiver
11
3026.02.21
M85
SPECS _______________________
Output Power:
Marine: 5W, 3W, 1W
Land mobile: 2W, 1W
Waterproof Rating: IP67
Frequencies:
Marine Tx: 156.025-157.425MHz
Marine Rx: 156.050-163.275MHz
LMR Tx/Rx: 136.000-174.000MHz
Usable Channel Groups: USA, INT,CAN, WX
100 LMR
Type of Emission:
Marine 16K0G3E
LMR 16K0F3E
11K0F3E
Current Drain: Tx (at 5W output): 1.5A
Rx (at AF max): 0.45A
Weight: 8.7oz
FEATURES ___________________
Compact and lightweight
Covers 136-174MHz land mobile frequency
Up to 100 programmable land mobile channels
700mW loud audio
Three emergency functions: MOB alarm, Man Down, and Lone Worker
Multi-function button allows user to change from marine to land mobile
channels or use the scrambler function
Buil-in voice scrambler (32-code)
AquaQuake™
Internal VOX capability
Weather channel receiving
Priority scan
Dual/Tri-watch function for monitoring CH16 and/or call channels
COMES WITH __________
Battery pack (BP290)
Battery charger (BC227)
AC adapter (BC123SA)
Antenna (FAS58V)
Belt clip (MBB3)
Hand strap
Owner’s manual
Warranty: 3 years
VHF Marine Transceiver
12
3026.02.21
M85
Configurations
Model
Description
M85
Marine VHF 5W handheld; 100 land mobile programmable channels (2W)
Accessories
Model
Description
Antennas
FASC58V
Standard antenna M24/M34/M36/M85
Batteries
BP290
2010mAh li-ion battery
BP291
Battery case 5 x AA
BP294
3150mAh li-ion battery for the F52D/F62D/M85
Belt Clips
MB136
Swivel belt clip for F1000/F3400/F7010/F52D/M85 series
MB96N
Swivel belt hanger to use with standard belt clip
MBB3
Standard belt clip
Cables
OPC515L
DC power cable for single unit rapid chargers
OPC656
DC power cable for gang charger
Carrying Cases
LCF1052S
Leather case with swivel belt loop and D-ring for the F52D
NCF1052C
Nylon case for the F52D with a clip
Chargers
BC123SA
AC adapter for rapid chargers; 100-240V with US style plug
BC123SE
AC adapter for rapid chargers; 100-240V with Euro style plug
BC157S
AC adapter for gang chargers; 100-240V with US style plug
BC157SE
AC adapter for gang chargers; 100-240V with Euro style plug
BC214-1
Six gang charger (includes AC adapter with US plug)
BC214-1E
Six gang charger (includes AC adapter with Euro plug)
BC225
Smart rapid charger; 100-240V with a US style plug
BC226
Connectable rapid charger (connect up to 6) and requires the BC228 AC adapter
BC227
Rapid charger that goes into trickle mode at a 80% charge (US Plug)
BC228
AC adapter for BC226
CP23L
12V cigarette lighter cable for use with rapid chargers
Headsets
HS94
Earpiece headset; use with VS/OPC2004/OPC2006/OPC1392
HS95
Headset with boom mic; use with VS/OPC2004/OPC2006/OPC1392
HS97
Earphone with throat mic headset; use with VS/OPC2004/OPC2006/OPC1392
VS5MC
VOX/PTT switch cable to use with headset (HS94/95/97)
Microphones
HM184H
14-pin loud waterproof speaker mic (no accessory jack)
HM222
IP68 waterproof speaker microphone w/3.5mm accessory jack (14-pin connector)
VHF Marine Transceiver
13
3026.02.21
M85
Accessories
Model
Description
HM222H
IP68 waterproof speaker microphone w/3.5mm accessory jack (14-pin connector)
HM236
Compact waterproof speaker microphone
HM-HD7I6WP
Large waterproof, high gain speaker microphone with 3.5mm accessory jack (14-pin
connector)
SP27
Acoustic tube earphone with a clip (3.5mm)
SP29
Earhook type earphone with 3.5mm plug
SP40
Earphone with 3.5mm plug
SP-AT1
Single pin listen only w/QD acoustic tube (9", 3.5mm L-shape)
Miscellaneous
AD118
14-pin ACC adapter to use with Hirose plug accessories
AD135
3.5mm earphone jack adapter that plugs into a 14-pin connector
Software & Cables
CSM85
M85 programming software
OPC1862
USB programming cloning cable for radios with 14-pin connector
RSBC225
Battery management software for the BP-283/284/BP290. Can connect up to 30 BC-225
chargers to it.
Wire Kits
EH15B
Earphone with 2.5mm plug to use with HM-163MC
HM163MC
Lapel mic with 2.5mm earphone jack
SP26
Tube earphone with 2.5mm plug to use with HM-163MC/HM-153LS
SP28
Earhook type earphone with 2.5mm plug to use with HM-163MC/HM-153LS
SP32
Tube adapter for use with the EH-15B
VHF Marine Transceiver
14
3026.02.21
M85IS
SPECS _______________________
Output Power:
Marine: 5W, 3W, 1W
Land mobile: 2W, 1W
Waterproof Rating: IP67
Frequencies:
Marine Tx: 156.025-157.425MHz
Marine Rx: 156.050-163.275MHz
LMR Tx/Rx: 136.000-174.000MHz
Usable Channel Groups: USA, INT,CAN, WX
100 LMR
Type of Emission:
Marine 16K0G3E
LMR 16K0F3E
11K0F3E
Current Drain: Tx (at 5W output): 1.5A
Rx (at AF max): 0.45A
Weight: 8.7oz
FEATURES ___________________
Compact and lightweight
Covers 136-174MHz land mobile frequency
Up to 100 programmable land mobile channels
700mW loud audio
Three emergency functions: MOB alarm, Man Down, and Lone Worker
Multi-function button allows user to change from marine to land mobile
channels or use the scrambler function
Buil-in voice scrambler (32-code)
AquaQuake™
Internal VOX capability
Weather channel receiving
Priority scan
Dual/Tri-watch function for monitoring CH16 and/or call channels
Intrinsically Safe: meets ANSI/TIA-4950-A, ANSI/UL 121201 requirements
for:
o Intrinsically safe: Class I, Division 1, Groups C, D:
o Class II, Division 1, Groups E, F, G;
o Class III. T3C.
o Non-incendive: Class I, Division 2, Groups A, B, C, D
COMES WITH __________
Battery pack (BP292IS)
Battery charger (BC227)
AC adapter (BC123SA)
Antenna (FAS58V)
Belt clip (MBB3)
Hand strap
Owner’s manual
Warranty: 3 years
Note: The M85IS should only be used with the specified Intrinsically Safe options. UL certified the M85IS and accessories under
the official names on the boxes and UL stickers M85UL, BP292UL, and HM184UL.
VHF Intrinsically Safe Marine Transceiver
15
3026.02.21
M85IS
Configurations
Model
Description
M85UL
Intrinsically safe marine VHF 5W handheld; 100 land mobile programmable channels (2W)
Accessories
Model
Description
Antennas
FASC58V
Standard antenna M24/M34/M36/M85
Batteries
BP292IS
2010mAh li-ion intrinsically safe battery
Belt Clips
MB136
Swivel belt clip for F1000/F3400/F7010/F52D/M85 series
MB96N
Swivel belt hanger to use with standard belt clip
MBB3
Standard belt clip
Cables
OPC515L
DC power cable for single unit rapid chargers
OPC656
DC power cable for gang charger
Carrying Cases
LCF1052S
Leather case with swivel belt loop and D-ring for the F52D
NCF1052C
Nylon case for the F52D with a clip
Chargers
BC123SA
AC adapter for rapid chargers; 100-240V with US style plug
BC123SE
AC adapter for rapid chargers; 100-240V with Euro style plug
BC157S
AC adapter for gang chargers; 100-240V with US style plug
BC157SE
AC adapter for gang chargers; 100-240V with Euro style plug
BC214-1
Six gang charger (includes AC adapter with US plug)
BC214-1E
Six gang charger (includes AC adapter with Euro plug)
BC226
Connectable rapid charger (connect up to 6) and requires the BC228 AC adapter
BC227
Rapid charger that goes into trickle mode at a 80% charge (US Plug)
BC228
AC adapter for BC226
CP23L
12V cigarette lighter cable for use with rapid chargers
Microphones
HM184IS
14-pin intrinsically safe approved waterproof speaker mic (no accessory jack)
Software & Cables
CSM85
M85 programming software
OPC1862
USB programming cloning cable for radios with 14-pin connector
RSBC225
Battery management software for the BP-283/284/BP290. Can connect up to 30 BC-225
chargers to it.
VHF Intrinsically Safe Marine Transceiver
16
3026.02.21
M94D
SPECS _______________________
Output Power: 6W
Waterproof Rating: IPX7
Frequencies: Tx: 156.025-157.425 MHz
Rx: 156.050-163.275 MHz
Usable Channel Groups: INT, USA, CAN, WX
Type of Emission: FM (16K0G3E)
DSC (16K0G2B)
AIS (16K0GXW)
Current Drain: Tx (6W/1W output):
1500mA/700mA
Rx (Inter SP/Exter SP Max
audio): 700mA/350mA
Weight: 12.6 oz (with BP306 and
antenna)
FEATURES ___________________
Built-in AIS and DSC
Simplified navigation system
Up to 50 plottable waypoints
Up to 10 hours of battery life
Active noise cancelling technology
Float’n Flash
Aquaquake™ draining function
Dualwatch and Tri-watch functions
Supports 4-digit channels
Weather channel receive
Favorite 4-digit channels
COMES WITH __________
Antenna (FASC59V)
Battery pack (BP306)
Battery charger (BC251)
AC adapter (BC242)
Belt Clip (MB-133)
Hand strap
VHF Marine Transceiver
17
3026.02.21
M94D
Configurations
Model
Description
M94D
6 Watt VHF transceiver with built-in AIS & DSC.
Accessories
Model
Description
Antennas
FASC59V
Standard antenna M25/M37/M93D/M92D
Belt Clips
MB133
Alligator type belt clip
Chargers
BC123SA
AC adapter for rapid chargers; 100-240V with US style plug
BC242
AC adapter
CP23L
12V cigarette lighter cable for use with rapid chargers
Microphones
HM165
Waterproof speaker mic for M34/M36/M93D
HM228
Compact IPX7 speaker mic for M93D
VHF Marine Transceiver
18
3026.02.21
VHF Fixed Mount
19
3026.02.21
M200 EXPORT ONLY
SPECS _______________________
Output Power: 25W, 1W (High, low)
Waterproof Rating: IPX7 (submersible protection)
Frequencies: Tx: 156.025–162.000MHz
Rx: 156.025–162.025MHz
Usable Channel Groups: USA, INT, CAN
Type of Emission: FM (16K0G3E)
Current Drain: Tx (at 25W output): 5.5A
Rx (Max audio): 200mA
Weight: 1.7lb
FEATURES ___________________
Dualwatch and tri-watch function
Favorite channel function
Built-in ultra-stable TCXO for reliable frequency stability
Channel operation with the hand microphone
Instant-access button for Channel 16 and call channel
Priority scan and normal scan
Built-in low voltage indicator
Keypad backlighting
COMES WITH ___________
Hand microphone (HM164B)
DC Power cable (OPC891A)
Mounting bracket kit
Owner’s manual
Warranty: 3 years
VHF Marine Transceiver
20
3026.02.21
M200 EXPORT ONLY
Configurations
Model
Description
M200
VHF fixed mount marine radio - EXPORT ONLY NOT FCC APPROVED
Accessories
Model
Description
Microphones
HM164B
Standard black hand mic M200/M304/M412
Miscellaneous
MB92
Dust cover M200/M304/402 series
Mounting Hardware
MB69
Flush mount kit for mounting controller or speaker to a panel
M200/M412/M302/M402/M45/M304/M422
VHF Marine Transceiver
21
3026.02.21
M220 EXPORT ONLY
SPECS ______________________
Output Power: 25W, 1W (High, low)
Waterproof Rating: IPX7
Frequencies: Tx: 156.025–157.425MHz
Rx: 156.025–163.275MHz
Usable Channel Groups: USA, INT, CAN
Type of Emission: FM (16K0G3E), DSC (16k0G2B)
Current Drain: Tx (at 25W output): 5A
Rx (Max audio) 1.2A
Weight: 1.5lb
FEATURES ___________________
Built-in Class D DSC with a CH70 dedicated receiver
Tag scan and favorite channel functions
Dual and tri watch function
Priority scan
Display and keypad backlight
Weather channel alert
Built-In GPS
AquaQuake™
COMES WITH __________
Hand microphone (HM237B)
SC Power cable
Mounting bracket kit
VHF Marine Transceiver
22
3026.02.21
M220 EXPORT ONLY
Configurations
Model
Description
M220
VHF fixed mount marine radio - EXPORT ONLY NOT FCC APPROVED
Accessories
Model
Description
External Speakers
SP37
40W hailer/speaker for fixed mounts; 4 ohm, extra UV protecting, all stainless steel hardware, heavy
duty mounting bracket
Microphones
HM237B
Hand microphone for the M220
Mounting Hardware
MBF5
Flush mount kit for M330 series
VHF Marine Transceiver
23
3026.02.21
M400BB
SPECS _______________________
Output Power: 25W, 1W
Waterproof Rating: IPX7 (submersible)
Frequencies: Tx: 156.025–157.425MHz
Rx: 156.050–163.275MHz
Ch. 70: 156.525MHz
Usable Channel Groups: USA, INT, CAN, WX
Type of Emission: FM (16K0G3E)
DSC (16K0G2B)
Current Drain: Tx (at 25W output): 5.5A
Rx (Max audio): 3.5A
Weight: 1.83lb (M400BB)
14.1oz (HM195B/SW)
FEATURES ___________________
Space-saving, two-piece configuration
New intuitive user interface
Active noise cancelling
10W loud audio, public address and foghorn
Built-in class D DSC
Common NMEA interface
AIS target call with MA-500TR
MarineCommander™ compatible
AquaQuake™ water draining function
Dual/tri-watch function for monitoring Ch.16 and/or call channel
COMES WITH ___________
Commandmic (HM195B/SW)
DC Power cable
Owner’s manual
Warranty: 3 years
VHF Marine Transceiver
24
3026.02.21
M400BB
Configurations
Model
Description
M400BB
Black box marine VHF fixed mount with black Command Mic
M400BB SW
Black box marine VHF fixed mount with white Command Mic
Accessories
Model
Description
External Speakers
SP37
40W hailer/speaker for fixed mounts; 4 ohm, extra UV protecting, all stainless steel hardware,
heavy duty mounting bracket
Microphones
HM195B
CommandMic IV with yellow backlit LCD in black
HM195GB
CommandMic IV with white backlit LCD in black
HM195GW
CommandMic IV with white backlit LCD in super white
HM195SW
Command Mic IV with yellow backlit LCD in super white
OPC1541
6.1m/20ft extension cable to use with the COMMANDMIC III/IV with the OPC1540. Up to 2
OPC-1541 can be connected.
Miscellaneous
IUK2CMA
Dual COMMANDMIC adapter
Navigation
MA510TR
AIS transponder with GPS navigation function, and NMEA 2000 connectivity.
Software & Cables
CSM400BB
M400BB programming software. Requires OPC-478UC + OPC-980 cables.
OPC478UC
USB programming cable (2-pin connectors handhelds)
OPC980
Cloning cable adapter for M424/M504/M604
VHF Marine Transceiver
25
3026.02.21
M330 – M330G
SPECS _______________________
Output Power: 25W, 1W (High, low)
Waterproof Rating: IPX7 (Waterproof protection)
Frequencies: Tx: 156.025–161.600MHz
Rx: 156.050–163.275MHz
Ch70: 156.525MHz
Usable Channel Groups: USA, CAN, INT and WX
Type of Emission: FM (16K0G3E)
DSC (16K0G2B)
Current Drain: Tx (at 25W output): 5A
Rx (AF max): 1A
Weight: 730g; 1.6lb
Versions: Black or super white
GPS or non GPS
FEATURES ___________________
Built-in GPS receiver with a supplied GPS antenna (G version)
Built-in Class D DSC with CH70 dedicated receiver
Intuitive user interface
Common NMEA interface for external GPS/NAV connection
MA-500TR Class B AIS transponder compatible
Tag scan and favorite channel functions
Dual/tri-watch function for monitoring CH16 and/or call channel
Priority scan function
Display and keypad backlighting
External speaker connection
AquaQuake™ draining function
COMES WITH ___________
Hand microphone (HM235B/W)
DC power cable
Mounting bracket kit
Owner’s manual
Warranty: 3 years
VHF Marine Transceiver
26
3026.02.21
M330 – M330G
Configurations
Model
Description
M330 11
Black marine compact VHF fixed mount
M330 21
White marine compact VHF fixed mount
M330G 31
Black marine compact VHF fixed mount with built-in GPS receiver and supplied GPS antenna
M330G 41
Super white marine compact VHF fixed mount with built-in GPS receiver and supplied GPS
antenna
Accessories
Model
Description
Microphones
HM235B
Black microphone for M330
HM235W
White microphone for M330
Mounting Hardware
MBF5
Flush mount kit for M330 series
Navigation
MA510TR
AIS transponder with GPS navigation function, and NMEA 2000 connectivity.
Software & Cables
CSM330
M330 programming software
VHF Marine Transceiver
27
3026.02.21
M424G
SPECS _______________________
Output Power: 25W, 1W
Waterproof Rating: IPX7 (submersible protection)
Frequencies: Tx: 156.025–157.425MHz
Rx: 156.050–163.275MHz
Usable Channel Groups: USA, CAN, INT, WX
Type of Emission: FM (16K0G3E)
DSC (16K0G2B)
Current Drain: Tx 25W output: 5.5A
Rx AF Max External SP:
5.0A
Internal SP: 1.5A
Weight: 2.65lb
FEATURES ___________________
Built-in GPS
Active noise canceling
10W loud audio, public address and foghorn
Built-in class D DSC
Optional COMMANDMICIV™ HM195B/SW or HM195GB/GSW
Common GPS/NAV interface
MarineCommander™ compatible
MA-500TR AIS transponder compatible
AquaQuake™ water draining function
Weather channel with alert function
Dualwatch and Tri-watch functions for monitoring Ch.16 and/or call channel
Priority and normal scan
Built-in attenuator for local communication
COMES WITH ___________
Hand microphone (HM-205)
DC power cable
Mounting bracket kit
Owner’s manual
Warranty: 3 years
VHF Marine Transceiver
28
3026.02.21
M424G
Configurations
Model
Description
M424G BLACK
Black fixed mount
M424G WHITE
Super white fixed mount
Accessories
Model
Description
External Speakers
SP24
External speaker (4x4") for marine fixed mount radios (7W)
SP35
5W external speaker with 3.5mm speaker jack and 2m cable
SP37
40W hailer/speaker for fixed mounts; 4 ohm, extra UV protecting, all stainless steel hardware,
heavy duty mounting bracket
Microphones
HM195B
CommandMic IV with yellow backlit LCD in black
HM195GB
CommandMic IV with white backlit LCD in black
HM195GW
CommandMic IV with white backlit LCD in super white
HM195SW
Command Mic IV with yellow backlit LCD in super white
HM196B
Standard hand microphone for M424 and works with the M424G
HM196SW
Standard hand microphone for M424 and works with the M424G
HM205B
Speaker microphone M424G/M506
OPC1540
6.1m/20ft connection cable to use with the COMMANDMIC III/IV (mounting hardware
required)
OPC1541
6.1m/20ft extension cable to use with the COMMANDMIC III/IV with the OPC1540. Up to 2
OPC-1541 can be connected.
Miscellaneous
IUK2CMA
Dual COMMANDMIC adapter
Mounting Hardware
MB132
Flush mount kit for M324/M424G/MA510TR
Navigation
MA510TR
AIS transponder with GPS navigation function, and NMEA 2000 connectivity.
Software & Cables
CSM92D/M424
Programming software for M92D & M424
OPC478UC
USB programming cable (2-pin connectors handhelds)
OPC980
Cloning cable adapter for M424/M504/M604
VHF Marine Transceiver
29
3026.02.21
M506
SPECS ______________________
Output Power: 25W or 1W (at 13.8V DC)
Waterproof Rating: IPX8
Frequencies: Tx: 156.025–157.425MHz
Rx: 156.050–163.275MHz
CH70: 156.525MHz
AIS1, 2
Usable Channels: USA, INT, CAN, and WX
Type of Emission: 16K0G3E (FM),
16K0G2B (DSC)
Current Drain: Tx 25W output: 5.5A
Rx AF Max External SP: 5.0A
Internal SP: 1.5A
Weight 3.09lb
FEATURES ___________________
Integrated AIS Receiver on specific versions
NMEA 2000® and NMEA 0183 connectivity on specific versions
Last call voice recording
Active noise cancelling
25W two-way hailer
Large LCD and intuitive user interface
80dB (typical) IMD and channel selectivity
MA-500TR AIS transponder and Marine-Commander™ compatible
Compatible with COMMANDMICIV™
COMES WITH __________
Hand microphone (HM205B/RB)
DC power cable
Mounting bracket kit
Owner’s manual
Warranty: 3 years
VHF Marine Transceiver
30
3026.02.21
M506
Configurations
Model
Description
M506 01
Class D DSC marine VHF radio
M506 11
Class D DSC marine VHF radio with NMEA2000
M506 21
Class D DSC marine VHF radio with NMEA2000 and AIS receiver
M506 31
Class D DSC marine VHF radio with rear mic and NMEA2000
M506 41
Class D DSC marine VHF radio with rear mic, NMEA2000 and AIS receiver
Accessories
Model
Description
INSTALLATION MARINE
Encryption & Internal Modules
UT112
Digital voice scrambling unit - 32 Codes
External Speakers
SP24
External speaker (4x4") for marine fixed mount radios (7W)
SP35
5W external speaker with 3.5mm speaker jack and 2m cable
SP37
40W hailer/speaker for fixed mounts; 4 ohm, extra UV protecting, all stainless steel hardware, heavy
duty mounting bracket
Microphones
HM195B
CommandMic IV with yellow backlit LCD in black
HM195GB
CommandMic IV with white backlit LCD in black
HM195GW
CommandMic IV with white backlit LCD in super white
HM195SW
Command Mic IV with yellow backlit LCD in super white
HM205B
Speaker microphone M424G/M506
HM205RB
Speaker microphone for M506 rear connector & M605
OPC1000
6.1m/20ft connection cable to use with the HM126RB/RG/HM205RB/HM157 (mounting hardware
req.)
OPC1540
6.1m/20ft connection cable to use with the COMMANDMIC III/IV (mounting hardware required)
OPC1541
6.1m/20ft extension cable to use with the COMMANDMIC III/IV with the OPC1540. Up to 2 OPC1541 can be connected.
OPC999
20ft extension cable to connect COMMANDMIC II or HM-205RB to the OPC1000 and radio. Connect
up to two HM205RB with M506 or one with M605.
Miscellaneous
UX231
AIS receive board for M506
Mounting Hardware
MB132
Flush mount kit for M324/M424G/MA510TR
MB75
Flush mount kit for mounting controller or speaker to a panel for
M506/M605/M802/M504/M604/MA510TR/M502/M602
Navigation
MA510TR
AIS transponder with GPS navigation function, and NMEA 2000 connectivity.
Software & Cables
CSM506
M506 programming software. Requires OPC-478UC + OPC-980 cables.
OPC478UC
USB programming cable (2-pin connectors handhelds)
VHF Marine Transceiver
31
3026.02.21
M506
Accessories
Model
Description
OPC980
Cloning cable adapter for M424/M504/M604
VHF Marine Transceiver
32
3026.02.21
M605
SPECS _______________________
Output Power: 25W, 1W
Waterproof Rating: IPX8
Frequencies: Tx: 156.025–161.600 MHz
Rx: 156.025–162.000 MHz
CH70: 156.525 MHz
Ais1, 2: 161.975, 162.025 MHz
Usable Channel Groups: USA, CAN, INT and WX
Type of Emission: 16K0G3E (FM), 16K0G2B
(DSC)
Current drain: Tx (at 25W output): 6.0A
Rx (Maximum audio): 8.0A
Weight: 3.30lb
Versions: Radio without AIS receiver
Radio with AIS receiver
FEATURES ___________________
30W listen back hailer
Built-in horn/foghorn
GNSS antenna included
Configuration flexibility
o M605 + three COMMANDMICS
o M605 + two COMMANDMICS + one Command Head
o M605 + two Command Heads + one COMMANDMIC
4.3” wide color TFT LCD
Night mode ensures readability in dark places
Intuitive user interface
NMEA2000™ and NMEA0183 connectivity
Class D DSC
Active noise cancelling
Last call voice recording
COMES WITH ___________
Radio
Hand microphone (HM-205RB)
GNSS antenna (UX-241)
PC power cable
Mounting bracket kit
Warranty: 3 years
VHF Marine Transceiver
33
3026.02.21
M605
Configurations
Model
Description
M605 11
VHF fixed mount with color display and rear mic connector
M605 21
VHF fixed mount with AIS, color display, and rear mic connector
Accessories
Model
Description
Antennas
UX241
GPS antenna
Command Head
OPC2377
32.8ft extension cable for RC-M600
OPC2383
32.8ft connection cable for RC-M600
RCM600
Command head for M605. Comes with OPC-2383 & HM-205RB.
Encryption & Internal Modules
UT112
Digital voice scrambling unit - 32 Codes
External Speakers
SP24
External speaker (4x4") for marine fixed mount radios (7W)
SP35
5W external speaker with 3.5mm speaker jack and 2m cable
SP37
40W hailer/speaker for fixed mounts; 4 ohm, extra UV protecting, all stainless steel hardware,
heavy duty mounting bracket
GPS
MXG5000S
GPS receiver
Microphones
HM195B
CommandMic IV with yellow backlit LCD in black
HM195GB
CommandMic IV with white backlit LCD in black
HM195GW
CommandMic IV with white backlit LCD in super white
HM195SW
Command Mic IV with yellow backlit LCD in super white
HM205RB
Speaker microphone for M506 rear connector & M605
OPC1000
6.1m/20ft connection cable to use with the HM126RB/RG/HM205RB/HM157 (mounting
hardware req.)
OPC1540
6.1m/20ft connection cable to use with the COMMANDMIC III/IV (mounting hardware
required)
OPC1541
6.1m/20ft extension cable to use with the COMMANDMIC III/IV with the OPC1540. Up to 2
OPC-1541 can be connected.
OPC2384
12-pin to 8-pin conversion cable to connect HM195 to M605 (1 cable required per HM195)
OPC999
20ft extension cable to connect COMMANDMIC II or HM-205RB to the OPC1000 and radio.
Connect up to two HM205RB with M506 or one with M605.
Miscellaneous
UX231
AIS receive board for M506
UX251
AIS receiver unit for the M605
VHF Marine Transceiver
34
3026.02.21
M605
Accessories
Model
Description
Mounting Hardware
MB75
Flush mount kit for mounting controller or speaker to a panel for
M506/M605/M802/M504/M604/MA510TR/M502/M602
Navigation
MA510TR
AIS transponder with GPS navigation function, and NMEA 2000 connectivity.
Software & Cables
CSM605
Programming software for the M605. Includes MMSI reset dongle. Requires OPC2382 +
OPC478UC for programming.
OPC2382
Conversion cable to program M605 (links OPC478UC to M605)
OPC478UC
USB programming cable (2-pin connectors handhelds)
VHF Marine Transceiver
35
3026.02.21
HM195/G
HM195B/SW – Orange backlighting
HM195GB/GW – White backlighting
Total control of all communications and Class D DSC
functions.
Menu system provides easy and intuitive operation.
The bottom line of the dot-matrix display shows the
software key functions, which can be toggled with the
left and right buttons.
The directional keypad allows you to perform various
operations and settings
IPX7 Submersible rating
Superior audio performance
AquaQuake™
Size (W × H × D): 2.66 × 5.69 × 1.46 in.
Weight (approx.; except cables): 14.1 oz
Supplied accessories:
• 20ft connection cable (OPC-1540)
• Mounting hardware for OPC-1540
o Connector cap (part#8930069360)
o Five screws (part#8810010710)
o C-plate (part#8930069220)
o Mic hanger (part#8950006870)
Configurations
Model
Description
HM195GB
CommandMic IV with white backlit LCD in black
HM195GW
CommandMic IV with white backlit LCD in super white
HM195B
CommandMic IV with yellow backlit LCD in black
HM195SW
Command Mic IV with yellow backlit LCD in super white
Accessories
Model
Description
Microphones
OPC1540
6.1m/20ft connection cable to use with the COMMANDMIC III/IV (mounting hardware
required)
OPC1541
6.1m/20ft extension cable to use with the COMMANDMIC III/IV with the OPC1540. Up to 2
OPC-1541 can be connected.
OPC2384
12-pin to 8-pin conversion cable to connect HM195 to M605 (1 cable required per HM195)
Miscellaneous
IUK2CMA
Dual COMMANDMIC adapter
COMMANDMIC™ IV Remote-Control Microphone
36
3026.02.21
SSB
37
3026.02.21
M802 EXPORT ONLY
SPECS _______________________
Output Power: 150W, 60W, 20W PEP (Selectable)
Frequencies: Tx: 1.6–2.9999, 4.0–4.9999, 6.0–
6.9999, 8.0–8.9999, 12.0–13.9999,
16.0–17.9999, 18.0–19.9999, 22.0–
22.9999, 25.0– 27.5000MHz
Rx: 0.5–29.9999MHz (continuous)
Channels: 1335 (max.) (160 programmable;
249 ITU SSB duplex; 721 ITU SSB
simplex; 662 ITU FSK duplex; 160
e-mail; 21ITU 4MHz simplex; 31
ITU 8MHz simplex)
Type of Emission: J3E (SSB), J2B (AFSK), F1B
(FSK), A1A (CW), H3E (AM*)
*Rx only
Current Drain: Tx (Max power): 30A
Rx (Max audio): 3.0A
Weight:
Main unit 10.36lb
Controller 1.26lb
Speaker 0.81lb
FEATURES ___________________
Standard 4x8 remote controller
Large LCD with dot-matrix characters
Easy to use in all conditions
Built-in digital selective calling
Digital signal processor advantage
150W (PEP) of powerful output
One-touch e-mail access
Automatic antenna tuner, AT140
Wide band receive coverage
Remote control mic allows you to select channels directly
Accessory RS232C port allows connection of modem, etc.
GPS input, NMEA 0183 version 3.01
A headphone jack in front of the controller
COMES WITH __________
Remote controller (RC25)
Separation cable (16.4ft) (OPC1106)
Hand microphone (HM135)
External speaker (SP24)
DC power cables (OPC1107A)
Owner’s manual
Warranty: 2 years
HF Marine Transceiver
38
3026.02.21
M802 EXPORT ONLY
Configurations
Model
Description
M802 11
150W marine VHF SSB with DSC (Export/Fed government only)
Accessories
Model
Description
Antenna Tuners
AT140
HF automatic antenna tuner
MN100
Antenna matcher. Matches the transceiver to a dipole antenna. Covers all HF bands from 1.5
to 30MHz. Two 8m antenna wires come standard.
MN100L
Antenna matcher. Matches the transceiver to a long wire antenna. Covers all HF bands from
1.5 to 30mhz. One 15m antenna comes standard.
OPC1147N
Shielded control cable to connect the M802 to the AT140 (10m)
Antennas
AH710
Folded dipole antenna with an SO-239 connector. Covers 1.9 to 30MHz band. Length is
approx 80.3ft.
Cables
OPC1107A
M802 Main Unit DC PC
External Speakers
SP24
External speaker (4x4") for marine fixed mount radios (7W)
Manuals
94414860
M802 USB Drive service manual
Microphones
HM135
Hand microphone; water resistant, remote function for M802
Mounting Hardware
M802 MMB
Mounting Bracket M802
MB75
Flush mount kit for mounting controller or speaker to a panel for
M506/M605/M802/M504/M604/MA510TR/M502/M602
Remote Mounting
OPC1106
Seperation cable between controller and main unit (16.4ft) for M802
Software & Cables
CSM802
M802 Program Software
OPC478UC
USB programming cable (2-pin connectors handhelds)
HF Marine Transceiver
39
3026.02.21
M803
SPECS _______________________
Frequencies:
Tx: 1.6–2.9999, 4.0–4.9999,
6.0–6.9999, 8.0–8.9999,
12.0–13.9999, 16.0–17.9999,
18.0–19.9999, 22.0–22.9999,
25.0– 27.5000MHz
Rx: 0.5–29.9999MHz (continuous)
DSC: 2.1875, 4.2075, 6.3120,
8.4145, 12.5770, 16.8045MHz
Mode:
Tx/Rx: J3E (USB, LSB), J2B (AFSK),
F1B (FSK), A1A (CW), H3Eʹ
(AM) (ʹ H3E receive only)
DSC: J2B
Current drain (at 13.6 V DC):
Receive: Less than 3.0 A (Maximum
audio output)
Transmit: 30 A (Maximum output power)
Weight:
Main unit 9.7lb
Controller 1.7lb
FEATURES ___________________
Emergency distress button
Intuitive user interface
Large main dial and software keys at the bottom of the display, provide
simple operation and easy access to often used functions
4.3” wide color TFT display
Night mode display
Integrated GPS receiver includes GPS, GLONASS, and SBAS function
Two minute instant replay function
Advance RF direct sampling system
HF e-mail ready
IPX7 waterproof remote controller
NMEA 0183 version 4.10 data input/output (4800-38400bps)
COMES WITH ___________
Remote controller
PC power cable
Remote control cable
GPS antenna (16.4ft)
Microphone (HM214H)
Mounting bracket kits
ACC plugs & spare fuses
Owner’s manual
Warranty: 2 years
HF Marine SSB
40
3026.02.21
M803
Configurations
Model
Description
M803
150W advanced SSB with Class E DSC MF/HF certification
Accessories
Model
Description
Antenna Tuners
AT140
HF automatic antenna tuner
MN100
Antenna matcher. Matches the transceiver to a dipole antenna. Covers all HF bands from 1.5
to 30MHz. Two 8m antenna wires come standard.
MN100L
Antenna matcher. Matches the transceiver to a long wire antenna. Covers all HF bands from
1.5 to 30mhz. One 15m antenna comes standard.
OPC1465
32.8ft shielded control cable from AT140 to M803
Antennas
AH710
Folded dipole antenna with an SO-239 connector. Covers 1.9 to 30MHz band. Length is
approx 80.3ft.
External Speakers
SP24
External speaker (4x4") for marine fixed mount radios (7W)
Microphones
HM214H
Hand microphone for GM800 & M803
Mounting Hardware
MB75
Flush mount kit for mounting controller or speaker to a panel for
M506/M605/M802/M504/M604/MA510TR/M502/M602
Software & Cables
OPC478UC
USB programming cable (2-pin connectors handhelds)
HF Marine SSB
41
3026.02.21
M700PRO EXPORT ONLY
SPECS _______________________
Output Power: 150W, 60W, 20W PEP
(Selectable)
Frequencies:
Receive 500kHz-29.99MHz
Transmit 1.6–2.9999, 4.0–4.9999,
6.0–6.9999, 8.0–8.9999,
12.0–13.9999, 16.0–17.9999,
18.0–19.9999, 22.0–22.9999,
25.0– 27.5000MHz
Channels: 150 (max.; 3 groups of 50
channels each)
Type of Emission: J3E (USB), LSB, H3T (AM),
J2B (AFKSK), F1B (FSK),
R3E, A1A (CW)
Weight: 17.2lb
FEATURES ___________________
Rugged 150 watt transceiver
150 memory channels
Selectable dual/tri watch
PC Programmable
Large LCD display
COMES WITH ___________
Hand microphone (HM180)
Mounting bracket (SP24)
DC power cables (OPC568)
Owner’s manual
Warranty: 2 years
SSB Radio Telephone
42
3026.02.21
M700PRO EXPORT ONLY
Configurations
Model
Description
M700PROE
150W SSB transceiver - EXPORT ONLY
Accessories
Model
Description
Antenna Tuners
AT130
Auto antenna tuner M710/IC-78
AT140
HF automatic antenna tuner
MN100
Antenna matcher. Matches the transceiver to a dipole antenna. Covers all HF bands from 1.5
to 30MHz. Two 8m antenna wires come standard.
MN100L
Antenna matcher. Matches the transceiver to a long wire antenna. Covers all HF bands from
1.5 to 30mhz. One 15m antenna comes standard.
OPC566
Cable to connect the AT130 to the M710 (30 ft.)
Antennas
AH710
Folded dipole antenna with an SO-239 connector. Covers 1.9 to 30MHz band. Length is
approx 80.3ft.
Cables
OPC568
M710/M700PRO Power Cord
Microphones
HM180
Microphone for M710/M700PRO
SSB Radio Telephone
43
3026.02.21
GMDSS
44
3026.02.21
GM1600
SPECS _______________________
Output Power: 2W, 1W
Frequencies: 156.300-156.875MHz
Rx: 156.050-163.275MHz
Type of Emission: FM (16K0G3E)
Current Drain: Tx 2W output: 1.0A
1W output: 0.7A
Rx AF max: 200mA
Weight: 13.6oz (with BP234)
wide)/
FEATURES ___________________
Meets the strict environmental requirements for survival craft radio
High capacity Lithium battery, BP234, has superior low temperature
Large keypad with positive button action
Wide viewing angle LCD display
One touch access to Channel 16 and call channel
Highly visible yellow colored body
Bright LED indicator on the top of panel
Optional VOX headset for on-board use
COMES WITH ___________
GM1600 21K:
Battery pack (BP252)
Battery pack (BP234)
Battery charger (BC173)
AC adapter (BC147SA)
Belt clip (MB103Y)
Antenna (FAS61V)
Neck strap
Owner’s manual
Warranty: 3 years
GM1600:
Battery pack (BP234)
Belt clip (MB103Y)
Antenna (FAS61V)
Neck strap
Owner’s manual
Warranty: 3 years
Survival Craft 2-Way VHF Radio
45
3026.02.21
GM1600
Configurations
Model
Description
GM1600
GMDSS VHF handheld for survival crafts; radio plus BP-234 lithium battery
GM1600 21K
GMDSS VHF handheld for survival crafts; includes li-ion battery/charger plus the BP-234
battery. Surface shipping only.
Accessories
Model
Description
Antennas
FAS61V
Standard antenna for GM1600
Batteries
BP224
7.2V 750mAh NiCd battery - GM1600/M32/M2A/M90
BP234
9.0V 3300mAh lithium battery pack GM1600. FedEx ground shipping only. No shipments to HI
or AK.
BP252
7.4V 980mAh Li-Ion battery (M36/M34/GM1600)
Belt Clips
MB103Y
Yellow alligator belt clip for the GM1600
MB86
Swivel belt clip that screws into back of radio
MB96N
Swivel belt hanger to use with standard belt clip
Cables
OPC515L
DC power cable for single unit rapid chargers
OPC656
DC power cable for gang charger
Carrying Cases
NCP1
Nylon chest pack
Chargers
AD109
Adapter cup fits the BC119N/BC121N and charges the BP224 (M90/GM1600)
BC123SE
AC adapter for rapid chargers; 100-240V with Euro style plug
BC147SA
AC adapter for trickle chargers; 100-240V with a US style plug
BC147SE 15
AC adapter for trickle chargers; 230V with a Euro style plug
BC157S
AC adapter for gang chargers; 100-240V with US style plug
BC173 01
Desktop trickle charger (M34/M36/GM1600/BP224) requires BC-147S
CP23L
12V cigarette lighter cable for use with rapid chargers
Headsets
HS94
Earpiece headset; use with VS/OPC2004/OPC2006/OPC1392
HS95
Headset with boom mic; use with VS/OPC2004/OPC2006/OPC1392
HS97
Earphone with throat mic headset; use with VS/OPC2004/OPC2006/OPC1392
OPC1392
Headset adapter to use with HS94/95/97 for the M73/M72/GM1600/M90
Manuals
94414927
GM1600 USB drive service manual
Microphones
HM167
Lightweight IPX8 waterproof speaker mic M73/GM1600/M92/M72
Survival Craft 2-Way VHF Radio
46
3026.02.21
GM1600
Accessories
Model
Description
Software & Cables
CSGM1600
GM1600 programming software
OPC478UC
USB programming cable (2-pin connectors handhelds)
Survival Craft 2-Way VHF Radio
47
3026.02.21
GM600 EXPORT ONLY
SPECS _______________________
Output Power: 25W 1W
Waterproof Rating: IPX7 (submersible
construction)
Frequencies: Tx: 156.025–161.600MHz
Rx: 156.025–162.000MHz
DSC 156.525MHz
Usable Channel: INT channels
Type of Emissions: 16K0G3E(FM) 16K0G2B(DSC)
Current Drain: Tx (at 25W output): 3.3A
Rx (Max audio): 2.0A
Weight (approx): 3.5lb
FEATURES ___________________
Class A DSC
Dedicated distress button
Meets MED “wheel mark” requirements
Meets ITU-R M.493-13 DSC
4.3” wide color TFT LCD
Night mode ensures readability in dark places
Intuitive user interface
10W audio when plugged into an external speaker
Optional DC-DC converter
COMES WITH ___________
Radio
Hand Microphone (HM-214V)
DC power cable
Mounting bracket kit
Warranty: 3 years
VHF GMDSS Marine Transceiver
48
3026.02.21
GM600 EXPORT ONLY
Configurations
Model
Description
GM600
VHF GMDSS fixed mount
Accessories
Model
Description
Power Supplies
PS310 01
24V DC-DC converter
PS310 02
12V DC-DC converter
VHF GMDSS Marine Transceiver
49
3026.02.21
GM800 EXPORT ONLY
SPECS _______________________
Output Power: RF: 125W 85W
Audio: 4W 2W
Waterproof Rating: IPX7 (waterproofing for
controller)
Frequencies: Tx: 0.5–29.9999MHz (ITU
marine channels)
Rx: 156.025–162.000MHz
(continuously)
DSC 2.1875, 4.2075, 6.3120,
8.4145, 12.5770, 16.8045MHz
Type of Emissions: Tx/Rx: J3E(USB/LSB*), H3E*
(AM), J2B* (AFSK), F1B
(FSK), A1A* (CW) *Receive
only.
DSC: F1B
Current Drain: Tx Maximum power: Less than
20A (at 1.1kHz and 1.7kHz two
tones)
Rx Maximum audio: Less than
3A
Weight (approx): Main unit 8.6kg, Controller
FEATURES ___________________
Class A DSC
Dedicated distress button
Meets MED “wheel mark” requirements
Meets ITU-R M.493-13 DSC
Dedicated DSC watch-keeping receiver continuously scans and six distress
channels in rotation
Store up to 100 MMSI members for DSC calls with a 10=character ID name
4.3” wide viewing color display
Almost 180 degree wide viewing angle with high resolution characters
function icons
Night display mode
Remote distress alarm
Printer connector (IEEE-1284)
Built-in 24V DC-DC converter
COMES WITH ___________
Radio
Handset (HS-98)
Mounting bracket kit
Warranty: 3 years
VHF GMDSS Marine Transceiver
50
3026.02.21
GM800 EXPORT ONLY
Configurations
Model
Description
GM800
GMDSS MF/HF radio with Class A DSC - Export only
Accessories
Model
Description
Antenna Tuners
AT141
Export HC automatic antenna tuner - special order
VHF GMDSS Marine Transceiver
51
3026.02.21
AIS/Radar
52
3026.02.21
MA510TR
SPECS _______________________
Output Power: 2W
Waterproof Rating: IPX7
Frequencies: 161.500-162.025MHz
Type of Emission: 16K0G2B
Weight: 1.5lb
DATA Interface:
USB (Type-B Mini): GGA, GNS, GLL, GSA, GSV, RMC,
VTG, VDM, VDO, ACA, ACS, ALR,
TXT
NMEA 2000™
Input: 059392 /904, 060160 /416 /928,
065240, 126208 /996, 129026 /029
/545
Output: 059392 /904,060416 /928,126208
/464 /993 /996 /998, 129026 /029
/038 /039 /040 /041 /539 /540 /545
/792 /793 /794 /797 /798 /801 /802
/803 /805 /806 /807 /809 /810 /811
NMEA 0183
Input/Output 4800–38400 bps; Sentence Format:
GGA, GNS, GLL, GSA*1, GSV*1,
RMC, VTG, GBS, DTM, DSC
External GPS Input: 4800–38400 bps, Sentence format:
GGA, GNS, GLL, RMC, VTG,
GBS*2, DTM
AIS Output: 38400 bps, Sentence format: VDM,
VDO, ACA, ACS, ALR, TXT
*1 Only 38400 bps. *2 When a received GPS signal does not
include a GBS sentence, the transponder will not receive the signal from the
external GPS receiver
FEATURES ___________________
Class B AIS transponder, receives both A & B signals
Large 4.3” Color TFT LCD Display
Night Screen mode
Wide angle viewing
NMEA 2000™, 0183/-HS connectivity
Built-in simple navigation function
100 waypoint memory
Friend/danger nav function
Silent mode
Individual DSC call
USB connectivity
Multi-lingual user interface
12V and 24V
Collison alarm function
Anchor watch alarm
Man over board (MOB) function, assignable MOB waypoint
COMES WITH __________
Speaker Microphone
GPS Antenna Unit
Class B AIS Transponder
53
3026.02.21
MA510TR
Configurations
Model
Description
MA510TR
AIS transponder with GPS navigation function, and NMEA 2000 connectivity.
Accessories
Model
Description
Antennas
0800017330
GPS Antenna for the MA-510TR
Mounting Hardware
MB132
Flush mount kit for M324/M424G/MA510TR
MB75
Flush mount kit for mounting controller or speaker to a panel for
M506/M605/M802/M504/M604/MA510TR/M502/M602
Class B AIS Transponder
54
3026.02.21
MR-1010R2
SPECS _______________________
Display Type: 10.4-inch Color TFT LCD
Resolution: 480 x 640 dots
Type of Emission: 16K0G3E (FM)
Minimum Range: 25m; 82ft (at 1/8 NM range)
Maximum Range: 36 NM
FEATURES ___________________
Connect to a DSC radio to use the DSC information function
Connect to an external AIS device to use the AIS overlay function
Large color display with an approximate 176° viewing angle
Color RFT LCD (480x640 dots) display offers bright vivid echos with 16
steps gradient intensity
Easily adjust the screen color (day, night and user settings) with the
“BRILL” button
Language setting is selectable from English, Indonesian, Korean, Spanish,
Thai and Vietnamese
Simplified ARPA function helps prevent collision risk with other vessels or
objects
TLL (Target Latitude Longitude) function
True trail function
10.2-42V wide DC input to prevent over voltage damage
Two user programmable alarm zones
Optional video output unit
Marine Radar
55
3026.02.21
MR-1010R2
Configurations
Model
Description
MR1010R2
Marine radar, 4kW, color LCD
Accessories
Model
Description
Miscellaneous
UX252
Analog TCG output for the MR1010RII
Marine Radar
56
3026.02.21
Discontinued Radios
57
3026.02.21
M93D
Accessories
Model
Description
Antennas
FASC59V
Standard antenna M25/M37/M93D/M92D
Batteries
BP285
Li-ion 7.2V 1570mAh (typical), 1485mAh (minimum) battery for M93D
Belt Clips
MB133
Alligator type belt clip
Cables
OPC515L
DC power cable for single unit rapid chargers
OPC656
DC power cable for gang charger
Chargers
BC123SA
AC adapter for rapid chargers; 100-240V with US style plug
BC123SE
AC adapter for rapid chargers; 100-240V with Euro style plug
BC157S
AC adapter for gang chargers; 100-240V with US style plug
BC157SE
AC adapter for gang chargers; 100-240V with Euro style plug
BC214 14
Gang charger for the M93D. Includes the BC157.
BC220
Rapid charger for the M93D
CP23L
12V cigarette lighter cable for use with rapid chargers
Microphones
HM165
Waterproof speaker mic for M34/M36/M93D
HM228
Compact IPX7 speaker mic for M93D
Software & Cables
OPC1655
Cloning cable adapter for M25/M36/M93D
OPC478UC
USB programming cable (2-pin connectors handhelds)
VHF Marine Transceiver are discontinued and no longer available from Icom. Icom does still
sell the below compatible accessories.
58
3026.02.21
MA500TR
Accessories
Model
Description
GPS
MXG5000S
GPS receiver
Manuals
94415578
MA500TR USB Drive service manual
Mounting Hardware
MB75
Flush mount kit for mounting controller or speaker to a panel for
M506/M605/M802/M504/M604/MA510TR/M502/M602
The MA500TR Class B AIS Transponders are discontinued and no longer available from Icom.
Icom does still sell the below compatible accessories
59
3026.02.21
M36
Accessories
Model
Description
Antennas
FASC58V
Standard antenna M24/M34/M36/M85
Batteries
BP251
Alkaline case for M34/M36 (5 x AAA)
BP252
7.4V 980mAh Li-Ion battery (M36/M34/GM1600)
Belt Clips
MB109
Belt clip for the M34/M36/M92D
Cables
OPC515L
DC power cable for single unit rapid chargers
Carrying Cases
NCF30G LOOP
Nylon carrying case with a loop for the F30G/40G & M36 radios
NCP1
Nylon chest pack
Chargers
BC123SE
AC adapter for rapid chargers; 100-240V with Euro style plug
BC147SA
AC adapter for trickle chargers; 100-240V with a US style plug
BC147SE 15
AC adapter for trickle chargers; 230V with a Euro style plug
BC162 01
Rapid charger for M34/M36. Includes BC123SA with US plug.
BC173 01
Desktop trickle charger (M34/M36/GM1600/BP224) requires BC-147S
CP23L
12V cigarette lighter cable for use with rapid chargers
Microphones
HM165
Waterproof speaker mic for M34/M36/M93D
Software & Cables
OPC1655
Cloning cable adapter for M25/M36/M93D
OPC478UC
USB programming cable (2-pin connectors handhelds)
The M36 VHF Marine Transceivers are discontinued and no longer available from Icom. Icom
does still sell the below compatible accessories
60
3026.02.21
M24
Accessories
Model
Description
Antennas
FASC58V
Standard antenna M24/M34/M36/M85
Batteries
BP266
Li-ion 1500mAh battery for the M24
Belt Clips
MB124
Alligator type belt clip
Cables
OPC515L
DC power cable for single unit rapid chargers
Chargers
AD123 02
Adapter cup for BC119N for M24
BC157S
AC adapter for gang chargers; 100-240V with US style plug
BC157SE
AC adapter for gang chargers; 100-240V with Euro style plug
BC199SE 13
Wall charger for the M24; 100-240V with a Euro style plug
CP24
Cigarette lighter cable that charges the charger in a vehicle
Software & Cables
CSM24
M24 programming software
OPC2091
Cloning cable adapter for M24
OPC478UC
USB programming cable (2-pin connectors handhelds)
The M24 VHF Marine Transceivers are discontinued and no longer available from Icom. Icom
does still sell the below compatible accessories.
61
3026.02.21
M72
Accessories
Model
Description
Antennas
FAS64V
Standard antenna for the M72/M73 (4 17/32" or 115mm)
Batteries
BP245H
7.4V 2000mAh Li-Ion battery for M72/M73
Belt Clips
MB103
Alligator belt clip
MB86
Swivel belt clip that screws into back of radio
MB96N
Swivel belt hanger to use with standard belt clip
Cables
OPC515L
DC power cable for single unit rapid chargers
OPC656
DC power cable for gang charger
Chargers
BC147SA
AC adapter for trickle chargers; 100-240V with a US style plug
BC147SE 15
AC adapter for trickle chargers; 230V with a Euro style plug
BC157S
AC adapter for gang chargers; 100-240V with US style plug
BC157SE
AC adapter for gang chargers; 100-240V with Euro style plug
BC197 32
Six unit charger for radios with the BP245N Li-Ion battery (includes AC adapter and cups
installed); 100-240V with US style plug
BC210
Rapid charger for the BP-245 includes AC adapter with US plug
CP23L
12V cigarette lighter cable for use with rapid chargers
Headsets
HS94
Earpiece headset; use with VS/OPC2004/OPC2006/OPC1392
HS95
Headset with boom mic; use with VS/OPC2004/OPC2006/OPC1392
HS97
Earphone with throat mic headset; use with VS/OPC2004/OPC2006/OPC1392
OPC1392
Headset adapter to use with HS94/95/97 for the M73/M72/GM1600/M90
Microphones
HM167
Lightweight IPX8 waterproof speaker mic M73/GM1600/M92/M72
HM202
Compact IPX7 waterproof speaker mic M73/M72
Software & Cables
CSM72
M72 Programming Software
OPC478UC
USB programming cable (2-pin connectors handhelds)
OPC922
Cloning cable adapter for M72/M73/M92D
The M72 VHF Marine Transceivers are discontinued and no longer available from Icom. Icom
does still sell the below compatible accessories
M92D
Accessories
Model
Description
Antennas
FASC59V
Standard antenna M25/M37/M93D/M92D
Batteries
BP275
7.4V 1500mAh Li-ion battery for M92D
Belt Clips
MB109
Belt clip for the M34/M36/M92D
Cables
OPC515L
DC power cable for single unit rapid chargers
OPC656
DC power cable for gang charger
Chargers
BC123SA
AC adapter for rapid chargers; 100-240V with US style plug
BC123SE
AC adapter for rapid chargers; 100-240V with Euro style plug
BC147SA
AC adapter for trickle chargers; 100-240V with a US style plug
BC147SE 15
AC adapter for trickle chargers; 230V with a Euro style plug
CP23L
12V cigarette lighter cable for use with rapid chargers
Microphones
HM167
Lightweight IPX8 waterproof speaker mic M73/GM1600/M92/M72
Software & Cables
CSM92D/M424
Programming software for M92D & M424
OPC478UC
USB programming cable (2-pin connectors handhelds)
OPC922
Cloning cable adapter for M72/M73/M92D
The M92D VHF Marine Transceivers are discontinued and no longer available from Icom.
Icom does still sell the below compatible accessories.
M412
Accessories
Model
Description
Cables
OPC891A
M504/M422 power cord
External Speakers
SP24
External speaker (4x4") for marine fixed mount radios (7W)
SP35
5W external speaker with 3.5mm speaker jack and 2m cable
Microphones
HM164B
Standard black hand mic M200/M304/M412
Mounting Hardware
M422 MMB
Black mounting bracket for M412/M422
M422SW MMB
Mounting bracket super white M412/M422
MB69
Flush mount kit for mounting controller or speaker to a panel
M200/M412/M302/M402/M45/M304/M422
Software & Cables
OPC478UC
USB programming cable (2-pin connectors handhelds)
The M412 VHF Marine Transceivers are discontinued and no longer available from Icom.
Icom does still sell the below compatible accessories.
M504
Accessories
Model
Description
Cables
OPC891A
M504/M422 power cord
Encryption & Internal Modules
UT112
Digital voice scrambling unit - 32 Codes
External Speakers
SP24
External speaker (4x4") for marine fixed mount radios (7W)
SP35
5W external speaker with 3.5mm speaker jack and 2m cable
Manuals
94415078
M504 USB Drive service manual
Microphones
HM126B
Standard black front mount mic for M504
HM126RB
Standard black rear mount mic for M504/M604
OPC1000
6.1m/20ft connection cable to use with the HM126RB/RG/HM205RB/HM157 (mounting
hardware req.)
OPC1540
6.1m/20ft connection cable to use with the COMMANDMIC III/IV (mounting hardware
required)
OPC1541
6.1m/20ft extension cable to use with the COMMANDMIC III/IV with the OPC1540. Up to 2
OPC-1541 can be connected.
OPC999
20ft extension cable to connect COMMANDMIC II or HM-205RB to the OPC1000 and radio.
Connect up to two HM205RB with M506 or one with M605.
Mounting Hardware
M504B MMB
Black mounting bracket for M504/M502
M504G MMB
Gray mounting bracket for M504/M502
MB75
Flush mount kit for mounting controller or speaker to a panel for
M506/M605/M802/M504/M604/MA510TR/M502/M602
Software & Cables
OPC478UC
USB programming cable (2-pin connectors handhelds)
OPC980
Cloning cable adapter for M424/M504/M604
The M504 VHF Marine Transceivers are discontinued and no longer available from Icom.
Icom does still sell the below compatible accessories.
M604
Configurations
Model
Description
M605 11
VHF fixed mount with color display and rear mic connector
M605 21
VHF fixed mount with AIS, color display, and rear mic connector
Accessories
Model
Description
Antennas
UX241
GPS antenna
Cables
OPC1174
M602/M604 DC power cord
Command Head
OPC2377
32.8ft extension cable for RC-M600
OPC2383
32.8ft connection cable for RC-M600
RCM600
Command head for M605. Comes with OPC-2383 & HM-205RB.
Encryption & Internal Modules
UT112
Digital voice scrambling unit - 32 Codes
External Speakers
SP24
External speaker (4x4") for marine fixed mount radios (7W)
SP35
5W external speaker with 3.5mm speaker jack and 2m cable
SP37
40W hailer/speaker for fixed mounts; 4 ohm, extra UV protecting, all stainless steel hardware,
heavy duty mounting bracket
GPS
MXG5000S
GPS receiver
Microphones
HM126RB
Standard black rear mount mic for M504/M604
HM195B
CommandMic IV with yellow backlit LCD in black
HM195GB
CommandMic IV with white backlit LCD in black
HM195GW
CommandMic IV with white backlit LCD in super white
HM195SW
Command Mic IV with yellow backlit LCD in super white
HM205RB
Speaker microphone for M506 rear connector & M605
OPC1000
6.1m/20ft connection cable to use with the HM126RB/RG/HM205RB/HM157 (mounting
hardware req.)
OPC1540
6.1m/20ft connection cable to use with the COMMANDMIC III/IV (mounting hardware
required)
OPC1541
6.1m/20ft extension cable to use with the COMMANDMIC III/IV with the OPC1540. Up to 2
OPC-1541 can be connected.
OPC2384
12-pin to 8-pin conversion cable to connect HM195 to M605 (1 cable required per HM195)
OPC999
20ft extension cable to connect COMMANDMIC II or HM-205RB to the OPC1000 and radio.
Connect up to two HM205RB with M506 or one with M605.
Miscellaneous
UX231
AIS receive board for M506
UX251
AIS receiver unit for the M605
The M604 VHF Marine Transceivers are discontinued and no longer available from Icom.
Icom does still sell the below compatible accessories.
Accessories
Model
Description
Mounting Hardware
M602 MMB
Black mounting bracket M602 01
MB75
Flush mount kit for mounting controller or speaker to a panel for
M506/M605/M802/M504/M604/MA510TR/M502/M602
Navigation
MA510TR
AIS transponder with GPS navigation function, and NMEA 2000 connectivity.
Software & Cables
CSM604A
M604A programming software
CSM605
Programming software for the M605. Includes MMSI reset dongle. Requires OPC2382 +
OPC478UC for programming.
OPC2382
Conversion cable to program M605 (links OPC478UC to M605)
OPC478UC
USB programming cable (2-pin connectors handhelds)
OPC980
Cloning cable adapter for M424/M504/M604
67
3026.02.21
U.S. Marine
Product Catalog
Loading...
