Icom 2200H User Manual

INSTRUCTION MANUAL

i2200H

VHF TRANSCEIVER

This device complies with Part 15 of the FCC rules. Operation is sub­ject to the following two conditions: (1) This device may not cause
harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.

i

FOREWORD

Thank you for purchasing this Icom product. The IC-2200H

VHF TRANSCEIVER

is designed and built with Icom’s superior
technology and craftsmanship. With proper care, this product
should provide you with years of trouble-free operation.

We want to take a couple of moments of your time to thank
you for making your IC-2200H your radio of choice, and hope
you agree with Icom’s philosophy of “technology first.” Many
hours of research and development went into the design of
your IC-2200H.

DD

FEATURES

❍ 65 W* of high transmit output power

(except Korea/Taiwan versions)

❍ Tone squelch, DTCS squelch standard

❍ Dual color (amber & green) LCD backlight

❍ Remote control microphone available

(optional for some versions)

❍ Optional Digital modulator/demodulator

❍ Optional DTMF decoder

IMPORTANT

READ ALL INSTRUCTIONS carefully and completely

before using the transceiver.

SAVE THIS INSTRUCTION MANUAL— This in-

struction manual contains important operating instructions for
the IC-2200H.

EXPLICIT DEFINITIONS

WORD DEFINITION

R WARNING!

CAUTION

NOTE

Personal injury, fire hazard or electric shock
may occur.

Equipment damage may occur.

Recommended for optimum use. No risk of
personal injury, fire or electric shock.

Icom, Icom Inc. and the logo are registered trademarks of Icom
Incorporated (Japan) in the United States, the United Kingdom, Ger­many, France, Spain, Russia and/or other countries.

ii

RWARNING RF EXPOSURE! This device emits

Radio Frequency (RF) energy. Extreme caution should be ob­served when operating this device. If you have any questions re­garding RF exposure and safety standards please refer to the
Federal Communications Commission Office of Engineering and
Technology’s report on Evaluating Compliance with FCC Guide­lines for Human Radio frequency Electromagnetic Fields (OET
Bulletin 65)

RWARNING! NEVER connect the transceiver to an AC

outlet. This may pose a fire hazard or result in an electric shock.

RWARNING! NEVER operate the transceiver while dri-

ving a vehicle. Safe driving requires your full attention—anything
less may result in an accident.

NEVER connect the transceiver to a power source of more

than 16 V DC. This will ruin the transceiver.

NEVER connect the transceiver to a power source using re-

verse polarity. This will ruin the transceiver.

NEVER cut the DC power cable between the DC plug and

fuse holder. If an incorrect connection is made after cutting, the
transceiver may be damaged.

NEVER expose the transceiver to rain, snow or any liquids.

The transceiver may be damaged.

NEVER operate or touch the transceiver with wet hands. This

may result in an electric shock or ruin the transceiver.

NEVER place the transceiver where normal operation of the

vehicle may be hindered or where it could cause bodily injury.

DO NOT

push the PTT when not actually desiring to transmit.

DO NOT allow children to play with any radio equipment con-

taining a transmitter.

During mobile operation,

DO NOT operate the transceiver

without running the vehicle’s engine. When the transceiver’s
power is ON and your vehicle’s engine is OFF, the vehicle’s bat­tery will soon become exhausted.

BE CAREFUL! The transceiver will become hot when op-

erating it continuously for long periods.

AVOID placing the transceiver against walls or putting any-

thing on the top of the transceiver. This will obstruct heat dissi­pation.

AVOID using or placing the transceiver in direct sunlight or in

areas with temperatures below –10°C (+14˚F) or above +60°C
(+140˚F).

AVOID the use of chemical agents such as benzine or alcohol

when cleaning, as they can damage the transceiver’s surfaces.

USE Icom microphones only (supplied or optional). Other man-

ufacturer’s microphones have different pin assignments and may
damage the transceiver if attached.

PRECAUTION

iii

SUPPLIED ACCESSORIES AND OPTIONS

■ Supplied Accessories

q Microphone (HM-133V)* . . . . . . . . . . . . . . . . . . . . . . . . . 1

w Fuse (20 A) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

e DC power cable (3 m) . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

r Mobile mounting bracket . . . . . . . . . . . . . . . . . . . . . . . . 1

t Mounting screws, nuts and washers . . . . . . . . . . . . 1 set

y Microphone hanger

†

. . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

u Insulation sheet

‡

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

*HM-118TN

DTMF MICROPHONE

supplied versions are also available.

†

Depending on version.

‡

Used for optional unit installation, see p.91 for details.

■ Options

UT-108

DTMF DECODER UNIT

UT-115

DIGITAL UNIT

HM-118TAN/TN

DTMF MICROPHONES

HM-118N

HAND MICROPHONE

HM-133V

REMOTE-CONTROL MICROPHONE

SP-10

EXTERNAL SPEAKER

OPC-440/OPC-647

MIC EXTENSION CABLES

OPC-441

SPEAKER EXTENSION CABLE

OPC-1132/OPC-347

DC POWER CABLES

OPC-589

ADAPTER CABLE

CS-2200H

CLONING SOFTWARE

+ OPC-478/OPC-478U

CLONING CABLE

OPC-474

CLONING CABLE

qwe

rtyu

iv

TABLE OF CONTENTS

FOREWORD ........................................................................................... i

IMPORTANT ............................................................................................ i

EXPLICIT DEFINITIONS ......................................................................... i

PRECAUTION ........................................................................................ ii

SUPPLIED ACCESSORIES AND OPTIONS ......................................... iii

TABLE OF CONTENTS ......................................................................... iv

QUICK REFERENCE GUIDE ............................................................ I–VI

■ Installation ....................................................................................... I

■ Your first contact ........................................................................... IV

■ Repeater operation ........................................................................ V

■ Programming memory .................................................................. VI

1 PANEL DESCRIPTION ................................................................. 1–8

■ Front panel ..................................................................................... 1

■ Function display ............................................................................. 3

■ Rear panel ..................................................................................... 5

■ Microphone (HM-133V) .................................................................. 6

■ Microphone keypad ........................................................................ 7

2 SETTING A FREQUENCY .......................................................... 9–12

■ Preparation .................................................................................... 9

■ Using the tuning dial ...................................................................... 9

■ Using the keypad ......................................................................... 10

■ Using the [Y]/[Z] keys ................................................................. 10

■ Tuning step selection ................................................................... 11

■ Lock functions .............................................................................. 12

3 BASIC OPERATION ................................................................. 13–16

■ Receiving ..................................................................................... 13

■ Monitor function ........................................................................... 13

■ Audio mute function ..................................................................... 14

■ Squelch attenuator ....................................................................... 14

■ S-meter squelch ........................................................................... 15

■ Transmitting ................................................................................. 15

■ Selecting output power ................................................................ 16

■ One-touch PTT function ............................................................... 16

4 REPEATER OPERATION ......................................................... 17–23

■ Accessing a repeater ................................................................... 17

■ Subaudible tones ......................................................................... 19

■ Offset frequency .......................................................................... 21

■ Repeater lockout .......................................................................... 21

■ Reversed duplex mode ................................................................ 22

■ Auto repeater ............................................................................... 23

5 MEMORY OPERATION ............................................................ 24–34

■ General description ...................................................................... 24

■ Memory channel selection ........................................................... 24

■ Programming a memory channel ................................................. 25

■ Transferring memory contents ..................................................... 27

■ Programming channel names....................................................... 29

■ Memory clearing .......................................................................... 31

■ Memory bank selection ................................................................ 32

■ Memory bank setting .................................................................... 33

■ Transferring bank contents .......................................................... 34

6 CALL CHANNEL OPERATION ................................................ 35–36

■ Call channel selection .................................................................. 35

■ Call channel transferring .............................................................. 35

■ Programming a call channel ........................................................ 36

7 SCAN OPERATION .................................................................. 37–42

■ Scan types ................................................................................... 37

■ Scan start/stop ............................................................................. 38

■ Scan edges programming ............................................................ 39

■ Skip channel setting ..................................................................... 41

■ Scan resume condition ................................................................ 42

v

8 PRIORITY WATCH .................................................................... 43–44

■ Priority watch types ...................................................................... 43

■ Priority watch operation ............................................................... 44

9 DTMF MEMORY ENCODER ..................................................... 45–47

■ Programming a DTMF code ......................................................... 45

■ Transmitting a DTMF code .......................................................... 46

■ DTMF speed ................................................................................ 47

10 POCKET BEEP AND TONE SQUELCH ................................... 48–51

■ Pocket beep operation ................................................................. 48

■ Tone/DTCS squelch operation ..................................................... 50

■ Tone scan ..................................................................................... 51

11 PAGER/CODE SQUELCH (Required Optional UT-108).......... 52–57

■ Pager function .............................................................................. 52

■ Code programming ...................................................................... 52

■ Pager operation ........................................................................... 55

■ Code squelch ............................................................................... 57

12 DIGITAL MODE OPERATION (Required Optional UT-115) .... 58–73

■ Digital mode operation ................................................................. 58

■ Call sign programming ................................................................. 58

■ Digital voice mode operation ........................................................ 61

■ When receiving a Digital call ........................................................ 63

■ Break-in communication .............................................................. 65

■ Emergency communication .......................................................... 66

■ Digital code/Call sign squelch operation ...................................... 67

■ Slow data communication ............................................................ 68

■ Other setting items ....................................................................... 69

■ GPS operation ............................................................................. 72

13 OTHER FUNCTIONS ................................................................ 74–87

■ Set mode ...................................................................................... 74

■ Initial set mode ............................................................................. 79

■ Weather channel operation .......................................................... 83

■ Microphone keys .......................................................................... 84

■ Partial reset .................................................................................. 85

■ All reset ........................................................................................ 85

■ Data cloning ................................................................................. 86

14 SPECIFICATIONS ........................................................................... 88

15 MAINTENANCE ........................................................................ 89–91

■ Troubleshooting ........................................................................... 89

■ Fuse replacement ........................................................................ 90

■ Optional unit installation ............................................................... 91

16 CE .................................................................................................... 92

17 MODE ARRANGEMENT ........................................................... 93–94

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17

I

QUICK REFERENCE GUIDE

■ Installation

D Location

Select a location which can support the weight of the trans­ceiver and does not interfere with driving in any way. We rec­ommend the locations shown in the diagram below.

NEVER place the transceiver where normal operation of the
vehicle may be hindered or where it could cause bodily injury.

NEVER place the transceiver where air bag deployment may
be obstructed.

DO NOT place the transceiver where hot or cold air blows di­rectly onto it.

AVOID placing the transceiver in direct sunlight.

D Using the mounting bracket

➀ Drill 4 holes where the mounting bracket is to be installed.

• Approx. 5.5–6 mm (1⁄4″) when using nuts; approx. 2–3 mm (1⁄8″)
when using self-tapping screws.

➁ Insert the supplied screws, nuts and washers through the

mounting bracket and tighten.

➂ Adjust the angle for the clearest view of the function dis-

play.

IMPORTANT!

Detailed installation notes for Icom mobile transceivers to
be fitted into vehicles are available. Contact your Icom
dealer or distributor.

Nut

Spring washer

Flat washer

When using
self-tapping
screws

Spring
washer

Mounting
nut

Mounting
bracket

II

QUICK REFERENCE GUIDE

D Battery connection

☞ NEVER connect the transceiver directly to a 24 V battery.
☞ DO NOT use the cigarette lighter socket for power con-

nections. (See p. 5 for details)
Attach a rubber grommet when passing the DC power cable
through a metal plate to prevent short circuiting.

• CONNECTING TO A DC POWER SOURCE

• See p. 90 for fuse replacement.

D DC power supply connection

Use a 13.8 V DC power supply with at least 15 A capacity.

Make sure the ground terminal of the DC power supply is
grounded.

• CONNECTING TO A DC POWER SUPPLY

• See p. 90 for fuse replacement.

DC power
supply 13.8 V

to an
AC
outlet

Fuses
20 A

black
red⊕

−

⊕

−

IC-2200H

Fuses
20 A

Crimp Solder

black

red⊕

Grommet

IC-2200H

−

12 V

12 V
battery

Supplied
DC power cable

NOTE:

Use terminals for the
cable connections.

+ red

_ black

III

QUICK REFERENCE GUIDE

D Antenna installation

• Antenna location
To obtain maximum performance from the transceiver, select
a high-quality antenna and mount it in a good location. A non­radial antenna should be used when using a magnetic mount.

• Antenna connector
The antenna uses a PL-259 connector.

• PL-259 CONNECTOR

q Slide the coupling ring

down. Strip the cable
jacket and soft solder.

w Strip the cable as shown

at left. Soft solder the cen­ter conductor.

e Slide the connector body

on and solder it.

r Screw the coupling ring

onto the connector body.

(10 mm ≈3⁄8 in)

NOTE: There are many publications covering proper an­tennas and their installation. Check with your local dealer
for more information and recommendations.

D Connecting a microphone

Connect a microphone to the eight-pin modular socket on the
front panel of the transceiver.

*HM-133V; A different microphone may be

supplied with some versions of the IC-2200H.

30 mm

10 mm (soft solder)

10 mm

1–2 mm

solder solder

Soft
solder

Coupling ring

to antenna

Roof-mount antenna
(Drill a hole or use a magnetic mount.)

Gutter-mount antenna

Trunk-mount
antenna

IV

QUICK REFERENCE GUIDE

■ Your first contact

Now that you have your IC-2200H installed in your car or
shack, you are probably excited to get on the air. We would
like to take you through a few basic operation steps to make
your first “On The Air” an enjoyable experience.

1. Turning ON the transceiver

Before powering up your IC-2200H, you may want to make
sure the audio volume and squelch level controls are set in
9–10 o’clock positions.

Although you have purchased a brand new transceiver, some
settings may be changed from the factory defaults because
of the QC process. Resetting the CPU is necessary to start
from factory default.

➥ While pushing [SET ] and [S.MW ], push

[PWR] for 1 sec. to reset the CPU.

2. Tune the desired frequency

[DIAL] will allow you to dial in the frequency you want to op-

erate. Pages 9 and 11 will instruct you on how to set the tun­ing speed.

Using the HM-133V

You can directly enter the frequency with the HM-133V keypad.

We hope these pointers have been helpful. Now you
are ready to call CQ.

LOCK

S

E

T

ANM

MONI

DUP

LOW

T-SCAN

TONE

PRIO

M/CALL

SCAN

V/MHz

DIGITAL

PRIOAOBUSY
MUTE
NAR
MID
LOW

LOCK

S

E

T

ANM

MONI

DUP

LOW

T-SCAN

TONE

PRIO

M/CALL

SCAN

V/MHz

DIGITAL

PRIOAOBUSY
MUTE
NAR
MID
LOW

LOCK

S

E

T

ANM

MONI

DUP

LOW

T-SCAN

TONE

PRIO

M/CALL

SCAN

V/MHz

DIGITAL

PRIOAOBUSY
MUTE
NAR
MID
LOW

LOCK

S

E

T

ANM

MONI

DUP

LOW

T-SCAN

TONE

PRIO

M/CALL

SCAN

V/MHz

DIGITAL

PRIOAOBUSY
MUTE
NAR
MID
LOW

[EXAMPLE]: Setting frequency to 145.3625 MHz.

Push

Push

Push

Push

[DIAL]

MWLOCK

[PWR] [SET LOCK] [S.MW MW]

Set both [VOL] and [SQL] controls to
9–10 o’clock positions.

[VOL]

[SQL]

V

QUICK REFERENCE GUIDE

■ Repeater operation

1. Setting duplex

Push [LOW ] for 1 sec. once or twice to select minus
duplex or plus duplex.

• The USA version has an auto repeater function, therefore, setting
duplex is not required.

2. Repeater tone

Push [TONE ] several times until “ ” appears, if the
repeater requires a subaudible to be accessed.

Using the HM-133V

Plus or minus duplex selection and the repeater tone setting
can be made easily via HM-133V.
Push [

DUP

– 7(TONE)] for minus duplex; [

DUP

+ 8(TSQL

SS

)]

for plus duplex selection, push [FUNC] then [

DUP

– 7(TONE)]

to turn the repeater tone ON.

LOCK

S

E

T

ANM

MONI

DUP

LOW

T-SCAN

TONE

PRIO

M/CALL

SCAN

V/MHz

DIGITAL

PRIOAOBUSY
MUTE
NAR
MID
LOW

LOCK

S

E

T

ANM

MONI

DUP

LOW

T-SCAN

TONE

PRIO

M/CALL

SCAN

V/MHz

DIGITAL

PRIOAOBUSY
MUTE
NAR
MID
LOW

LOCK

S

E

T

ANM

MONI

DUP

LOW

T-SCAN

TONE

PRIO

M/CALL

SCAN

V/MHz

DIGITAL

PRIOAOBUSY
MUTE
NAR
MID
LOW

Push

Push , then

Push

LOCK

S

E

T

ANM

MONI

DUP

LOW

T-SCAN

TONE

PRIO

M/CALL

SCAN

V/MHz

DIGITAL

PRIOAOBUSY
MUTE
NAR
MID
LOW

T-SCAN

LOCK

S

E

T

ANM

MONI

DUP

LOW

T-SCAN

TONE

PRIO

M/CALL

SCAN

V/MHz

DIGITAL

PRIOAOBUSY
MUTE
NAR
MID
LOW

DUP

The IC-2200H has a total of 207 memory channels (including
6 scan edges and 1 call channel) for storing often used oper­ating frequency, repeater settings, etc.

1. Setting a frequency

In VFO mode, set the desired operating frequency with re­peater, tone and tuning steps, etc.

2. Selecting a memory channel

Momentarily push [S.MW ], then rotate [DIAL] to select
the desired memory channel.

•“M” indicator and memory channel number blink.

3. Writing a memory channel

Push and hold [S.MW ] for 1 sec. to program.

• 3 beeps sound

• Memory channel number automatically increases when continuing
to push [S.MW ] after programming.

Using the HM-133V

q In VFO mode, set the desired operating frequency, includ-

ing offset direction, tone settings, etc.

w Push [FUNC] then [

CLR

A(MW)].

•“M” indicator and memory channel number blink.

e Push [YY]/[ZZ] to select the desired memory channel.
r Push [FUNC] then push [

CLR

A(MW)] for 1 sec. to pro-

gram.

• 3 beeps sound

• Memory channel number automatically increases when continu­ing to push [

CLR

A(MW)] after programming.

LOCK

S

E

T

ANM

MONI

DUP

LOW

T-SCAN

TONE

PRIO

M/CALL

SCAN

V/MHz

DIGITAL

PRIOAOBUSY
MUTE
NAR
MID
LOW

Push ,

then

MW

MW

LOCK

S

E

T

ANM

MONI

DUP

LOW

T-SCAN

TONE

PRIO

M/CALL

SCAN

V/MHz

DIGITAL

PRIOAOBUSY
MUTE
NAR
MID
LOW

[S.MW MW] [DIAL]

MW

■ Programming memory channels

VI

QUICK REFERENCE GUIDE

■ Front panel

q POWER KEY [PWR]

Turns power ON and OFF when pushed for 1 sec.

w MEMORY WRITE KEY [S.MW ] (p. 25)

➥ Selects a memory channel for programming.
➥ Programs the selected memory channel when pushed

for 1 sec.

• Continue to hold the key to increment the memory channel
automatically.

e MICROPHONE CONNECTOR

Connects the supplied microphone.

r VOLUME CONTROL [VOL] (p. 13)

Adjusts the audio level.

t SQUELCH CONTROL [SQL] (p. 13)

Varies the squelch level.

• The RF attenuator activates and increases the attenuation when
rotated clockwise to the center position and further.

MW

PWR

S.MW

MW

BANK

OPT

Function display (p. 3)

!0oiuy

q

w

e

rt

!3

!1 !2

1

PANEL DESCRIPTION

1

2

1

PANEL DESCRIPTION

1

y SET•LOCK KEY [SET ]

➥ Enters set mode when pushed. (p. 74)
➥ Keys the lock function ON and OFF when pushed for

1 sec. (p. 12)

u MONITOR•CHANNEL NAME KEY [MONI ]

➥ Push to switch the monitor function ON and OFF. (p. 13)
➥ In memory and call channel mode, switches the channel

names or number ON and OFF. (p. 29)

i OUTPUT POWER•DUPLEX KEY [LOW ]

➥ Each push changes the output power selection. (p. 16)
➥ Select DUP–, DUP+ and simplex operation when

pushed for 1 sec. (p. 17)

o TONE•TONE SCAN KEY [TONE ]

➥ Each push selects a tone function. (pgs. 17, 48)

• Tone encoder, pocket beep, tone squelch or tone function
OFF can be selected.

➥ Push for 1 sec. to start/stop the tone scan function.

(p. 51)

❍ While in the digital mode operation with the installing an

optional Digital unit UT-115.

➥ Each push select the digital code

(CSQL) squelch func-

tion, call sign

(DSQL) squelch, pocket beep function

(CSQL or DSQL). (p. 67)

!0 MEMORY/CALL•PRIORITY KEY [M/CALL ]

➥ Push to select and toggle memory, call and weather

channel* modes. (pgs. 24, 35, 83)

*Weather channels available for USA versions only.

➥ Starts priority watch when pushed for 1 sec. (p. 44)

!1 VFO/MHz TUNING•SCAN KEY [V/MHz ]

➥ Selects and toggles VFO mode and 1 MHz (or 10 MHz

for some versions) tuning when pushed. (p. 9)

➥ Starts scan when pushed for 1 sec. (p. 38)

• Cancels a scan when pushed during a scan.

!2 BANK•OPTION KEY [BANK ]

➥ Push to select memory bank condition during memory

mode. (p. 32)

➥ Push for 1 sec. to enter the DTMF or option set mode.

!3 TUNING DIAL [DIAL]

Selects the operating frequency (p. 9), memory channel
(p. 24), the setting of the set mode item and the scanning
direction (p. 38).

D Microphone connector (front panel view)

q +8 V DC output (Max. 10 mA)
w Channel up/down
e 8 V control IN
r PTT
t GND (microphone ground)
y MIC (microphone input)
u GND
i Data IN

q

i

OPT

SCAN

PRIO

T-SCAN

DUP

ANM

LOCK

3

1 PANEL DESCRIPTION

■ Function display

qFREQUENCY READOUT

Shows the operating frequency, channel names, set mode
contents, etc.

• Frequency decimal point flashes while scanning. (p. 38)

• “d” appears in place of the 1st digit while the DTMF memory
function is in use. (p. 45)

wTRANSMIT INDICATOR

➥ Appears while transmitting. (p. 15)
➥ Flashes while transmitting with the one-touch PTT func-

tion. (p. 16)

eAUDIO MUTE INDICATOR (p. 14)

Appears when the audio mute function is activated via mi­crophone control.

rNARROW MODE INDICATOR (p. 78)

Appears when the narrow mode is selected.
Narrow mode is not available with some versions.

tOUTPUT POWER INDICATORS (p. 16)

“LOW” appears when low output power; “MID” and “LOW”
appear when mid low output power; “MID” appears when
middle output power is selected.

• Mid. low power is not available with some versions.

LOCK

S

E

T

ANM

MONI

DUP

LOW

T-SCAN

TONE

PRIO

M/CALL

SCAN

V/MHz

DIGITAL

PRIO

AO

BUSY
MUTE
NAR
MID

LOW

!7 !3!4

i

!5!6

!0

!2 !1

u

o

w

y

t

e
r

q

4

1

PANEL DESCRIPTION

1

yKEY INDICATORS

Indicate the function(s) of the front panel keys directly
below the function display.

uSKIP INDICATOR (p. 41)

Appears when the selected memory channel is specified
as a skip channel.

iMEMORY CHANNEL NUMBER INDICATORS

➥ Shows the selected memory channel number. (p. 24)
➥ “C” appears when the call channel is selected. (p. 35)

oMEMORY INDICATOR (p. 24)

Appears when memory mode is selected.

!0S/RF INDICATORS

➥ Shows the relative signal strength while receiving sig-

nals. (p. 13)

➥ Shows the output power level while transmitting. (p. 16)

!1BUSY INDICATOR (p. 13)

➥ Appears when a signal is being received or the squelch

is open.

➥ Flashes while the monitor function is activated.

!2AUTO POWER-OFF INDICATOR (p. 81)

Appears while the auto power-off function is in use.

!3PRIORITY WATCH INDICATOR (p. 44)

Appears while the priority watch is activated; blinks while
the watch is paused.

!4DIGITAL INDICATOR (p. 61)

Appears when digital mode is selected.

!5LOCK INDICATOR (p. 12)

Appears when the lock function is activated.

!6TONE INDICATORS

➥ “ ” appears while the subaudible tone encoder is in

use. (p. 17)

➥ “ ” appears while the tone

(CTCSS) squelch function is

in use. (p. 48)

➥ “ ” appears while the tone

(DTCS) squelch function is

in use. (p. 48)

➥ “ ” appears with the “ ” or “ ” indicator while the

pocket beep function

(CTCSS or DTCS) is in use. (p. 48)

❍ While in the digital mode operation with the installing an

optional Digital unit UT-115.

➥ “ ” appears while the digital code

(CSQL) squelch func-

tion is in use. (p. 67)

➥ “ ” appears while the call sign

(DSQL) squelch function

is in use. (p. 67)

➥ “ ” appears with the “ ” or “ ” indicator while the

pocket beep function

(CSQL or DSQL) is in use. (p. 67)

!7DUPLEX INDICATORS (p. 17)

“+” appears when plus duplex, “–” appears when minus
duplex operation is selected.

5

1 PANEL DESCRIPTION

■ Rear panel

q SPEAKER JACK [SP]

Accepts an 8 Ω speaker.

• Audio output power is more than 2.4 W.

w DATA JACK [DATA]

Connects to a PC or GPS receiver via an RS-232C cable
(D-sub 9-pin) for data communication in the RS-232C for­mat.

e POWER RECEPTACLE [DC13.8V]

Accepts 13.8 V DC ±15% with the supplied DC power
cable.51

NOTE: DO NOT use a cigarette lighter socket as a
power source when operating in a vehicle. The plug
may cause voltage drops and ignition noise may be su­perimposed onto transmit or receive audio.

r ANTENNA CONNECTOR [ANT]

Connects a 50 Ω antenna with a PL-259 connector and a
50 Ω coaxial cable.

Pin 2 (RxD), Pin 3 (TxD), Pin 5 (GND)

to [DATA] jack

TxD

2.5(d) mm

GND

RxD

1

5

69

RS-232C (DB-9 female)

r

e

q

w

Make sure the connection between transceiver and PC, oth­erwise misreading may occur for data communication.

6

1

PANEL DESCRIPTION

1

■ Microphone (HM-133V*)

qVFO/LOCK KEY [VFO/LOCK]

➥ Push to select VFO mode. (p. 9)
➥ Push for 1 sec. to switch the lock function ON and OFF.

(p. 12)

wPTT SWITCH

➥ Push and hold to transmit; release to receive.
➥ Switches between transmitting and receiving while the

one-touch PTT function is in use. (p. 16)

eUP/DOWN KEYS [Y]/[Z]

➥ Push either key to change operating frequency, mem-

ory channel, set mode setting, etc. (pgs. 10, 24)

➥ Push either key for 1 sec. to start scanning. (p. 38)

rACTIVITY INDICATOR

➥ Lights red while any key, except [FUNC] and [DTMF-S],

is pushed, or while transmitting.

➥ Lights orange while the microphone keypad lock func-

tion is activated.

➥ Lights green while the one-touch PTT function is in use.

tKEYPAD (pgs. 7, 8)
yFUNCTION INDICATOR

➥ Lights orange while [FUNC] is activated—indicates the

secondary function of keys can be accessed.

➥ Lights green when [DTMF-S] is activated—DTMF sig-

nals can be transmitted with the keypad.

uFUNCTION KEY [FUNC] (pgs. 7, 8)
iDTMF MEMORY SELECT KEY [DTMF-S] (p. 46)
oFUNCTION KEYS [F-1]/[F-2] (p. 84)

Program and re-call your desired transceiver conditions.

!0BANK/OPTION KEY [BANK/OPTION]

➥ Push to selects memory bank condition during memory

mode. (p. 32)

➥ Push for 1 sec. to enter the DTMF or option set mode.

!1MEMORY/CALL KEY [MR/CALL]

➥ Push to select memory mode. (p. 24)
➥ Push for 1 sec. to select call channel. (p. 35)

q

e

r

t

Mic element

y

u

i

o

!0

!1

w

*

A different microphone
may be supplied de­pending on version.

7

1 PANEL DESCRIPTION

■ Microphone keypad

KEY FUNCTION SECONDARY FUNCTION ( +key) OTHER FUNCTIONS

Switches between opening and closing the
squelch. (p. 13)

Starts and stops scanning. (p. 38)

Starts and stops priority watch. (p. 44)

Selects high output power. (p. 16)

Selects mid. output power. (p. 16)

Selects low output power (p. 16)

Selects minus duplex operation. (p. 18)

Selects plus duplex operation. (p. 18)

Selects simplex operation. (p. 18)

No primary function.

In memory mode switches the channel names
or number indication ON and OFF. (p. 30)

Starts and stops tone scanning. (p. 51)

Turns the one-touch PTT function ON and
OFF. (p. 16)

Turns the DTCS squelch ON. (p. 50)
*Turns the DSQL function. (p. 67)

Turns the DTCS pocket beep function ON. (p. 49)
*Turns the DSQL pocket beep function.

Turns the DTMF memory encoder function
ON. (p. 45)

Turns the subaudible tone encoder ON.

(p. 18)

Turns the CTCSS pocket beep function ON.(p. 49)
*Turns the CSQL pocket beep function.

Turns the tone squelch function ON.

(p. 50)

*Turns the CSQL function. (p. 67)

Sends a 1750 Hz tone signal while pushing
and holding. (p. 20)

After pushing :
Transmits the appropriate
DTMF code. (pgs. 20, 46)
When the DTMF memory en­coder is activated, push [0] to
[9] to transmit the appropriate
DTMF memory contents.

(p. 46)

*While in the digital mode operation with the installing an optional Digital unit UT-115.

8

1

PANEL DESCRIPTION

1

➥ Cancels frequency entry. (p. 10)
➥ Cancels the scan or priority watch.

(pgs. 38, 44)

➥ Exit set mode. (p. 74)

➥ Enters set mode (p. 74)
➥ Advances the set mode selection order

after entering set mode. (p. 74)

➥ Sets the keypad for numeral input.

(p. 10)

➥ Reverses the set mode selection order

after entering set mode. (p. 74)

Adjusts the squelch level increments.

(p. 13)

No primary function.

Adjusts the squelch level decrement.

(p. 13)

➥ Selects a memory channel for program-

ming. (p. 26)

➥ Advances the memory channel number

when continuously pushed after pro­gramming is completed. (p. 26)

DTMF memory OFF. (p. 46)

Turns the subaudible tone encoder, pocket
beep or CTCSS/DTCS tone squelch OFF.

(pgs. 18, 49, 50)

*Turns the pocket beep or CSQL/DSQL OFF. (p.63)

Mutes the audio. (p. 14)

• Mute function is released when any operation
is performed.

Sends a 1750 Hz tone signal for 0.5 sec.

(p. 20)

Locks the digit keys on the keypad (includ­ing the A to D, # and M keys. (p. 12)

• Lights orange while the microphone keypad
lock function is activated.

After pushing :
Transmits the appropriate
DTMF code. (pgs. 20, 46)

KEY FUNCTION SECONDARY FUNCTION ( +key) OTHER FUNCTIONS

*While in the digital mode operation with the installing an optional Digital unit UT-115.

9

SETTING A FREQUENCY

2

■ Preparation

D Turning power ON/OFF

➥ Push [PWR] for 1 sec. to

turn power ON and OFF.

D VFO mode selection

The transceiver has 2 basic operating modes: VFO mode and
memory mode.

➥ Push [V/MHz ] to

select VFO mode.

➥ Push [VFO/LOCK] to select VFO mode.

■ Using the tuning dial

qRotate [DIAL] to set the frequency.

• If VFO mode is not selected, push [V/MHz ] to select VFO
mode.

• The frequency changes according to the selected tuning steps.
(p. 11)

wTo change the frequency in 1 MHz (10 MHz for some ver-

sions) steps, push [V/MHz ], then rotate [DIAL].

• Pushing [V/MHz ] for
1 sec. starts scan function.
If scan starts, push [V/MHz

] again to cancel it.

SCAN

SCAN

LOCK

S

E

T

ANM

MONI

DUP

LOW

T-SCAN

TONE

PRIO

M/CALL

SCAN

V/MHz

DIGITAL

PRIOAOBUSY
MUTE
NAR
MID
LOW

The display shows that the
1 MHz tuning step is selected.

SCAN

SCAN

LOCK

S

E

T

ANM

MONI

DUP

LOW

T-SCAN

TONE

PRIO

M/CALL

SCAN

V/MHz

DIGITAL

PRIOAOBUSY
MUTE
NAR
MID
LOW

[DIAL]

VFO/LOCK

SCAN

LOCK

S

E

T

ANM

MONI

DUP

LOW

T-SCAN

TONE

PRIO

M/CALL

SCAN

V/MHz

DIGITAL

PRIOAOBUSY
MUTE
NAR
MID
LOW

Push [PWR] for 1 sec.

Note that in this manual, sections beginning with a micro­phone icon (as above), designate operation via the HM­133V microphone.

10

2

SETTING A FREQUENCY

2

■ Using the keypad

The frequency can be directly set via numeral keys on the mi­crophone.

z Push [VFO/LOCK] to VFO mode, if necessary.
x Push [

ENT

C(T-OFF)] to activate the keypad for

digit input.

c Push 6 keys to input a frequency.

• When a digit is mistakenly input, push [

ENT

C(T-OFF)]

to clear the input, then repeat input from the 1st digit.

• Pushing [

CLR

A(MW)] clears input digits and retrieves

the frequency.

■ Using the [Y]/[Z] keys

➥ Push [YY] or [ZZ] to select the desired frequency.

• Pushing [YY]/[ZZ] for 1 sec. activates a scan. If scan
starts, push [YY]/[ZZ] again or push [

CLR

A(MW)] to

cancel it.

YZ

LOCK

S

E

T

ANM

MONI

DUP

LOW

T-SCAN

TONE

PRIO

M/CALL

SCAN

V/MHz

DIGITAL

PRIOAOBUSY
MUTE
NAR
MID
LOW

LOCK

S

E

T

ANM

MONI

DUP

LOW

T-SCAN

TONE

PRIO

M/CALL

SCAN

V/MHz

DIGITAL

PRIOAOBUSY
MUTE
NAR
MID
LOW

LOCK

S

E

T

ANM

MONI

DUP

LOW

T-SCAN

TONE

PRIO

M/CALL

SCAN

V/MHz

DIGITAL

PRIOAOBUSY
MUTE
NAR
MID
LOW

LOCK

S

E

T

ANM

MONI

DUP

LOW

T-SCAN

TONE

PRIO

M/CALL

SCAN

V/MHz

DIGITAL

PRIOAOBUSY
MUTE
NAR
MID
LOW

[EXAMPLE]: Setting frequency to 145.3625 MHz.

Push

Push

Push

Push

ENT

C

11

2 SETTING A FREQUENCY

■ Tuning step selection

Tuning steps are the minimum frequency change increments
when you rotate [DIAL] or push [YY]/[ZZ] on the microphone.
The following tuning steps are available.

• 5 kHz • 10 kHz • 12.5 kHz • 15 kHz

• 20 kHz • 25 kHz • 30 kHz • 50 kHz

NOTE: For convenience, select a tuning step that matches
the frequency intervals of repeaters in your area.

q Push [V/MHz ] to se-

lect VFO mode, if neces­sary.

w Push [SET ] to enter

set mode.

e Push [SET] or [MONI] sev-

eral times until “TS” appears
as shown at left.

r Rotate [DIAL] to select the

desired tuning step.

t Push any key other than in-

dicated function keys to exit
set mode.

z Push [VFO/LOCK] to select VFO mode, if

necessary.

x Push [

SET

B(D-OFF)] to enter set mode.

c Push [

SET

B(D-OFF)] or [

ENT

C(T-OFF)]

several times until “TS” appears.

v Push [YY] or [ZZ] to select the desired tun-

ing step.

b Push [

CLR

A(MW)] to exit set mode.

VFO/LOCK

USING

SET MODE

LOCK

SCAN

LOCK

S

E

T

ANM

MONI

DUP

LOW

T-SCAN

TONE

PRIO

M/CALL

SCAN

V/MHz

DIGITAL

PRIOAOBUSY
MUTE
NAR
MID
LOW

15 kHz tuning step

[DIAL]

12

2

SETTING A FREQUENCY

2

■ Lock functions

To prevent accidental channel changes and unnecessary
function access, use the lock function. The transceiver has 2
different lock functions.

D Frequency lock

This function locks [DIAL] and keys electronically and can be
used together with the microphone lock function.

➥ Push [SET ] for

1 sec. to turn the lock func­tion ON and OFF.

• [PTT], [MONI ], [VOL]
and [SQL] can be used while
the channel lock function is in
use. Also, TONE-1, TONE-2,
DTMF tones or DTMF mem­ory contents can be transmit­ted from the microphone.

➥ Push [VFO/LOCK] for 1 sec. to switch the

lock function ON and OFF.

D Microphone keypad lock

This function locks the microphone keypad.

➥ Push [FUNC] then [

SQL

ZZ

#(16KEY-L)] to
switch the microphone keypad lock function
ON and OFF.

• Lights orange while the microphone keypad lock
function is activated.

• [PTT], [VFO/LOCK], [MR/CALL], [BANK/OP-

TION], [YY], [ZZ], [F-1], [F-2], [DTMF-S] and
[FUNC] on the microphone can be used.

• All keys on the transceiver can be used.

• The keypad lock function is released when the

power is turned OFF then ON again.

16KEY-L

VFO/LOCK

ANM

LOCK

LOCK

S

E

T

ANM

MONI

DUP

LOW

T-SCAN

TONE

PRIO

M/CALL

SCAN

V/MHz

DIGITAL

PRIOAOBUSY
MUTE
NAR
MID
LOW

Appears

13

BASIC OPERATION

3

■ Receiving

q Push [PWR] for 1 sec. to turn power ON.
w Set the audio level.

➥ Push [MONI ] to open the squelch.
➥ Rotate the [VOL] control to adjust the audio output

level.

➥ Push [MONI ] again to close the squelch.

e Set the squelch level.

➥ Rotate [SQL] fully counterclockwise in advance.
➥ Rotate [SQL] clockwise until the noise just disappears.
➥ When interference is received, rotate [SQL] clockwise

again for attenuator operation. (p. 14)

r Set the operating frequency. (pgs. 9, 10)
t When receiving a signal on the set frequency, squelch

opens and the transceiver emits audio.

• “BUSY” appears and the S/RF
indicator shows the relative
signal strength for the re­ceived signal.

✔

CONVENIENT!

The squelch level can also be adjusted with

[

SQL

YY

D(MUTE)] and [

SQL

ZZ

#(16KEY-L)].

■ Monitor function

This function is used to listen to weak signals without disturb­ing the squelch setting or to open the squelch manually even
when mute functions such as the tone squelch are in use.

➥ Push [MONI ] to open

the squelch.

• “BUSY” blinks.

• Push [MONI ] again to
cancel the function.

➥ Push [

MONI

1(ANM)] to open the squelch.

• Push [

MONI

1(ANM)] again to cancel the function.

NOTE: When [SQL] adjustment is set too far clockwise,

(12–17 o’clock position) the squelch attenuator is acti­vated. To monitor weak signals on the operating frequency,
deactivate the squelch attenuator function. See p. 82 for
details.

MONI

1

ANM

ANM

LOCK

S

E

T

ANM

MONI

DUP

LOW

T-SCAN

TONE

PRIO

M/CALL

SCAN

V/MHz

DIGITAL

PRIOAOBUSY
MUTE
NAR
MID
LOW

LOCK

S

E

T

ANM

MONI

DUP

LOW

T-SCAN

TONE

PRIO

M/CALL

SCAN

V/MHz

DIGITAL

PRIOAOBUSY
MUTE
NAR
MID
LOW

SQLY

D

SQLZ

#

LOCK

S

E

T

ANM

MONI

DUP

LOW

T-SCAN

TONE

PRIO

M/CALL

SCAN

V/MHz

DIGITAL

PRIOAOBUSY
MUTE
NAR
MID
LOW

Appears when receiving a signal.

ANM

ANM

14

3

BASIC OPERATION

3

■ Audio mute function

This function temporarily mutes the audio without disturbing
the volume setting.

➥ Push [FUNC] then [

SQL

YY

D(MUTE)] to mute

audio signals.

• “MUTE” appears.

• Push [

CLR

A(MW)] (or any other key) to cancel the

function.

■ Squelch attenuator

The transceiver has an RF attenuator related to the squelch
level setting. Approx. 10 dB attenuation is obtained at maxi­mum setting.

➥ Rotate [SQL] clockwise past the 12 o’clock position to ac-

tivate the squelch attenuator.

• Attenuation level can be adjusted up to 10 dB (approx.) between
12 o’clock and fully clockwise position.

• When setting the squelch from the microphone, a level greater
than ‘19’ activates the squelch attenuator.

NOTE: The squelch attenuator functions even when the
monitor function is in use. Thus set the [SQL] within 10 to
12 o’clock position (12 to 19 level when setting with the
HM-133V) is recommended when using the monitor func­tion.

Squelch is

open.

Squelch
attenuator

Squelch
threshold

Shallow Deep

Noise squelch

LOCK

S

E

T

ANM

MONI

DUP

LOW

T-SCAN

TONE

PRIO

M/CALL

SCAN

V/MHz

DIGITAL

PRIOAOBUSY

MUTE

NAR
MID
LOW

Appears

MUTE

15

3 BASIC OPERATION

■ S-meter squelch

The transceiver has an S-meter squelch. The S-meter
squelch allows you to set minimum signal level needed to
open the squelch.

qTurn the transceiver power OFF.
wWhile pushing [SET ]

,

push [PWR] for 1 sec. to

enter initial set mode.

ePush

[SET] or [MONI] to select “SSQ” (S-meter squelch)

item.

rRotate [DIAL] to set the S-meter level or OFF.

t Push [PWR] to exit initial set mode.

■ Transmitting

NOTE: To prevent interference, listen on the channel be-
fore transmitting by pushing [MONI ], or
[

MONI

1(ANM)] on the microphone.

q Set the operating frequency. (pgs. 9, 10)

• Select output power if desired. See section at right for details.

w Push and hold [PTT] to transmit.

•“$” appears.

• The S/RF indicator shows the output power selection.

• A one-touch PTT function is available. See p. 16 for details.

e Speak into the microphone using your normal voice level.

• DO NOT hold the microphone too close to your mouth or speak
too loudly. This may distort the signal.

r Release [PTT] to return to receive.

IMPORTANT! (for 65 W transmission):

The IC-2200H is equipped with current detector circuit to
protect the power amplifier circuit from high current flowing.
When a high SWR (Standing Wave Ratio) antenna or no
antenna is connected, or when the connected power sup­ply’s voltage includes, the transceiver reduces transmit out­put power to 10–20 W (approx.) automatically.

ANM

CAUTION: Transmitting without an antenna will damage

the transceiver.

LOCK

USING

INITIAL SET MODE

[SET LOCK ]

[PWR]

DIGITAL

T-SCAN

TONE

PRIOAOBUSY

PRIO

M/CALL

MUTE
NAR
MID
LOW

LOCK

ANM

DUP

MONI

LOW

S

E

T

S-meter squelch OFF (default) S2 level (2 indicator level)

SCAN

V/MHz

DIGITAL

T-SCAN

TONE

PRIOAOBUSY

PRIO

M/CALL

MUTE
NAR
MID
LOW

LOCK

ANM

DUP

MONI

LOW

S

E

T

SCAN

V/MHz

16

3

BASIC OPERATION

3

■ Selecting output power

The transceiver has 4* output power levels to suit your oper­ating requirements. Low output powers during short-distance
communications may reduce the possibility of interference to
other stations and will reduce current consumption.

*The Taiwan version has only 3 levels.

Push [LOW ] several times to select the output power.

*approx., †Korea version

• The output power can be changed while transmitting.

The microphone can also be used to select output power.

➥ Push [

HIGH

4(DTCS)] for high output power;

[

MID

5(DTCSSS)] for middle output power

(push again for mid. low output power); and

[

LOW

6(DTMF)] for low output power.

• The output power can be changed via the microphone
during receive only.

■ One-touch PTT function

The PTT switch can be operated as a one-touch PTT switch
(each push switches between transmit/receive). Using this
function you can transmit without pushing and holding the
PTT switch.

To prevent accidental, continuous transmissions with this
function, the transceiver has a time-out timer. See p. 80 for
details.

z Push [FUNC] then [

PRIO

3(PTT-M)] to turn the

one-touch PTT function ON.

• The activity indicator lights green.

x Push [PTT] to transmit and push again to re-

ceive.

• Two beeps sound when transmission is started and a
long beep sounds when returning to receive.

•“$” flashes when transmitting with the one-touch
PTT function.

c Push [FUNC] then [

PRIO

3(PTT-M)] to turn the

one-touch PTT function OFF.

• The activity indicator goes out.

LOCK

S

E

T

ANM

MONI

DUP

LOW

T-SCAN

TONE

PRIO

M/CALL

SCAN

V/MHz

DIGITAL

PRIOAOBUSY
MUTE
NAR
MID
LOW

PTT-M

HIGH

4

MID

5

LOW

6

DUP

S/RF INDICATOR

POWER OUTPUT

Taiwan

65 W (50 W

†

)24W

25 W* 10 W*

10 W* N/A

5W* 5W*

High:

Mid.:

Mid. Low:

Low:

17

REPEATER OPERATION

4

■ Accessing a repeater

q Set the receive frequency (repeater output frequency).

(pgs. 9, 10)

w Push [LOW ] for 1 sec., once or twice, to select

minus duplex or plus duplex.

• “–” or “+” appears to indicate the transmit frequency for minus
shift or plus shift, respectively.

• When the auto repeater function is turned ON (available for the
USA version only), steps w and e are not necessary. (p. 23)

e Push [TONE ] several times to turn ON the sub-

audible tone encoder, according to repeater requirements.

•

“ ” appears

• 88.5 Hz is set as the default; refer to p. 19 for tone frequency set­tings.

• When the repeater requires a different tone system, see p. 20.

r Push and hold [PTT] to transmit.

• The displayed frequency automatically changes to the transmit
frequency (repeater input frequency).

• If

“OFF” appears, confirm that the offset frequency (p. 21) is set

correctly.

t Release [PTT] to receive.

yPush [MONI ] to check whether the other station’s

transmit signal can be received directly.

uTo return to simplex operation, push [LOW ] for

1 sec., once or twice, to clear the “–” or “+” indicator.

iTo turn OFF the subaudible tone encoder, push

[TONE ] several times until no tone indicators ap­pear.

T-SCAN

DUP

ANM

LOCK

S

E

T

ANM

MONI

DUP

LOW

T-SCAN

TONE

PRIO

M/CALL

SCAN

V/MHz

DIGITAL

PRIOAOBUSY
MUTE
NAR
MID
LOW

LOCK

S

E

T

ANM

MONI

DUP

LOW

T-SCAN

TONE

PRIO

M/CALL

SCAN

V/MHz

DIGITAL

PRIOAOBUSY
MUTE
NAR
MID
LOW

While transmittingWhile receiving

LOCK

S

E

T

ANM

MONI

DUP

LOW

T-SCAN

TONE

PRIO

M/CALL

SCAN

V/MHz

DIGITAL

PRIOAOBUSY
MUTE
NAR
MID
LOW

Appears

T-SCAN

LOCK

S

E

T

ANM

MONI

DUP

LOW

T-SCAN

TONE

PRIO

M/CALL

SCAN

V/MHz

DIGITAL

PRIOAOBUSY
MUTE
NAR
MID
LOW

Either “–” or “+” appears.

DUP
