IBM ThinkPad iSeries 1300 Service Manual

򔻐򗗠򙳰

ThinkPad i Series 1200/1300
Hardware Maintenance Manual

Before using this information and the product it supports,
be sure to read the general information under
“Introduction” on page 2, and “Read this first” on page 19.

First Edition (October 2001)

The following paragraph does not apply to the United
Kingdom or any country where such provisions are
inconsistent with local law:

INTERNATIONAL BUSINESS MACHINES CORPORATION
PROVIDES THIS PUBLICATION ″AS IS″ WITHOUT ANY
WARRANTY OF ANY KIND, EITHER EXPRESS OR
IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE
LIMITED WARRANTIES OF MERCHANTABILITY OR
FITNESS FOR A PARTICULAR PURPOSE. Some states
do not allow disclaimers or express or implied warranties in
certain transactions; therefore, this statement may not
apply to you.

This publication could include technical inaccuracies or
typographical errors. Changes are periodically made to the
information herein; these changes will be incorporated in
new editions of the publication. IBM may make
improvements or changes in the products or the programs
described in this publication at any time.

Requests for technical information about IBM products
should be made to your IBM Authorized Dealer or your
IBM Marketing Representative.

© Copyright International Business Machines
Corporation 2001. All rights reserved. NotetoUS

Government Users — Documentation related to restricted
rights — Use, duplication, or disclosure is subject to
restrictions set forth in GSA ADP Schedule Contract with
IBM Corp.

Preface

About this manual

This manual contains service and reference information for
IBM ThinkPad i Series 1200/1300 products. Use this
manual along with the advanced diagnostic tests to
troubleshoot problems effectively.

The manual is divided into sections as follows:

v Common sections provide general information,

guidelines, and safety information required to service
computers.

v Product-specific sections include service, reference, and

product-specific parts information.

– Part I includes information on the following models:

1161-210, 1161-230, 1161-260, 1161-25N, 1161-45N,
1161-55N, 1161-65N, 1161–267, 1161–26M,
1161–26A, 1161–26T, 1161–26C, 1161–26H,
1161–26K, 1161–26Y, 1161–26F, 1161–26S,
1161–26P, 1161–26X, 1161–264, 1161–257,
1161–BB7, 1161–25M, 1161–25A, 1161–25T,
1161–25C, 1161–25H, 1161–25K, 1161–25Y,
1161–25F, 1161–25S, 1161–25P, 1161–25X,
1161–254, 1161–234, 1161–23N, 1161–237,
1161–23M, 1161–23A, 1161–23T, 1161–23C,
1161–23H, 1161–23K, 1161–23Y, 1161–23F,
1161–23S, 1161–23P, 1161–23X, 1161–214,
1161–217, 1161–21M, 1161–21A, 1161–21T,
1161–21C, 1161–21H, 1161–21K, 1161–21Y,
1161–21F, 1161–21S, 1161–21P, 1161–21X,
1161–2MS, 1171–337, 1171–BB7, 1171–33F,
1171–37F, 1171–34F, 1171-310, 1171-320, 1171-340,
1171-350, 1171-330, 1171-370, 1171-334, 1171-335,
1171-374, 1171-375

– Part II includes information on the following models:

1161-11U, 1161-41U, 1161-51U, 1161-51J, 1161-71U,
1161-71J, 1161-91J, 1161-46N, 1161-56N, 1161-66N,
1161–91M, 1161–91A, 1161–91T, 1161–91C,
1161–91H, 1161–91K, 1161–91Y, 1161–71G,
1161–BB6, 1161–71M, 1161–71A, 1161–71T,
1161–71C, 1161–71H, 1161–71K, 1161–71Y,
1161–71F, 1161–61M, 1161–61A, 1161–61T,
1161–61C, 1161–61H, 1161–61K, 1161–61Y,
1161–51G, 1161–51F, 1161–51S, 1161–51P,
1161–51X, 1161–41J, 1161–41G, 1161–41M,
1161–41A, 1161–41T, 1161–41C, 1161–41H,
1161–41K, 1161–41Y, 1161–41F, 1161–41S,
1161–41P, 1161–41X, 1161–4JJ, 1161–36N,
1161–11G, 1161–11M, 1161–11A, 1161–11T,
1161–11C, 1161–11H, 1161–11K, 1161–11Y,

iii

1161–11F, 116 1–11S, 1161–11P, 1161 –11X,
1161–3MS, 1171–i1U, 1171–i1G, 1171–81G,
1171–BB6, 1171–81M, 1171–61G, 1171–61M,
1171–61F, 1171–91F, 1171-61U, 1171-91U,
1171-51J, 1171-61J, 1171-71J, 1171-81J

– Part III includes information on the following models:

1171-21U, 1171-71U

– Part IV includes information on the following models:

1161-42J, 1161-72J, 1161-92J, 1161-47N, 1161-57N,
1161-67N, 1161–92T, 1161–92H, 1161–92U,
1161–92G, 1161–A2G, 1161–92M, 1161–92A,
1161–92C, 1161–92Y, 1161–92K, 1161–67N,
1161–62U, 1161–62G, 1161–52K, 1161–62S,
1161–62P, 1161–62X, 1161–52F, 1161–52U,
1161–62M, 1161–62A, 1161–62T, 1161–62C,
1161–62H, 1161–62K, 1161–62Y, 1161–72A,
1161–42U, 1161–42G, 1161–42M, 1161–52M,
1161–42A, 1161–42T, 1161–42C, 1161–42H,
1161–42K, 1161–42Y, 1161–42S, 1161–42P,
1161–42X, 1161–37N, 1171–9LU, 1171–9KU,
1171–9AU, 1171–9LM, 1171–9AG, 1171–82J,
1171–6LM, 1171–7WG, 1171–7YU, 1171–9WU,
1171–7GJ, 1171–9WF, 1171–5YU, 1171–6WU,
1171-5WU, 1171-7WU, 1171-5BU, 1171-5WJ,
1171-6LU, 1171-52J, 1171-62J, 1171-7WJ

– Part V includes information on the following models:

1161-95G, 1161-95M, 1161-94T, 1161-94H,
1161-94G, 1161-94M, 1161-94A, 1161-94K,
1161-93U, 1161-93G, 1161-93F, 1161-93M,
1161-93C, 1161-93H, 1161-93K, 1161-93Y, 1161-93T,
1161-73J, 1161-53M, 1161-43U, 1161-43G,
1161-43M, 1161-43A, 1161-43T, 1161-43C,
1161-43K, 1161-43Y, 1161-43S, 1161-43P, 1161-43X,
1161-43H, 1161–96A, 1161–97A, 1161–96C,
1161–96Y, 1161–86C, 1161–96K, 1161–44F,
1161–4JU, 1161–45U, 1161–43A, 1161–45F,
1161–53U, 1161–83G, 1171–9BU, 1171–8MU,
1171-9MU, 1171-6MU, 1171-6NU, 1171-7XG,
1171-9XU, 1171-9XF, 1171-9XA, 1171-9XT,
1171-9XC, 1171-9XH, 1171-9XK, 1171-5XU,
1171-5XM, 1171-5CU, 1171-4MU, 1171-6XU

iv ThinkPad i Series 1200/1300 HMM

Important

This manual is intended for trained servicers who
are familiar with ThinkPad products. Use this
manual along with the advanced diagnostic tests to
troubleshoot problems effectively. Before servicing
an IBM ThinkPad product, be sure to review the
safety information under “Safety Notices
(Multi-lingual Translations)” on page 3 and “Safety
Information” on page 11.

Related publications

The following product publications are available through
IBM or your IBM Authorized Dealer.

Publication Part, Form Number

Mobile Systems HMM Volume 1:
Laptop, Notebook, Portable, and
ThinkPad Computers (Models L40,
CL57, N45, N51, P70/P75,
ThinkPad 300, 350, 500, 510,
710T, Expansion Unit, Dock I,
Dock II)

Mobile Systems HMM Volume 2:
ThinkPad Computers (Models 340,
355, 360, 370, 700, 701, 720, 750,

755)

Mobile Systems HMM Volume 3:
ThinkPad Computers (Models 365,
380, 385, 560, 760, SelectaDock)

Mobile Systems HMM Volume 4:
ThinkPad Computers (Models 380,
385, 560, 760, 765)

30H2356, S82G-1501-01

30H2357, S82G-1502-03

84H8099, S82G-1503-05

05L1271, S05L-1270-01

Related diskettes

The following diskettes are available through IBM or your
IBM Authorized Dealer.

Diskette Part, Form Number

ThinkPad 300 (2615) Advanced
Diagnostics Diskette

ThinkPad 350, 350C, 425, 425C
(2618) Advanced Diagnostics
Diskette

ThinkPad 365 (2625) Advanced
Diagnostics Diskette

ThinkPad 380/385 (2635)
Maintenance Diskette

33G9361, S33G-9361

A211000, GA21-1000

76H7578, S30H-2498

06J0333, S06J-0333

Preface v

Diskette Part, Form Number

ThinkPad 500 (2603) Advanced
Diagnostics Diskette

ThinkPad 510 (2604) Advanced
Diagnostics Diskette

ThinkPad 700 (9552) Reference
Diskette

ThinkPad 700C (9552) Reference
Diskette

ThinkPad 720/720C (9552)
Reference Diskette

ThinkPad i Series 1400 (2611)
Diagnostic and Utilities diskettes

ThinkPad Hardware Maintenance
Diskette (for all Models 355, 360,
560, 750, 755, 760)

ThinkPad Dock I (3545) 71G4140, S71G-4140

Docking Station (3550) 42G2428, S42G-2428

Data/Fax Modem 61G1556, S61G-1556

FaxConcentrator/A 84F8540, S84F-8540

71G3702, S71G-3702

83G8095, S83G-8095

42G2017, S42G-2017

42G2023, S42G-2023

61G1194, S61G-1194

01K4841, S01K-4841-00

78H5384, S78H-5384

vi ThinkPad i Series 1200/1300 HMM

Contents

Preface ...............iii

ThinkPad i Series 1200/1300 Hardware Maintenance

Manual ..............1

General Descriptions ...........1

Introduction ..............2

ImportantServiceInformation........2

Drive and Diskette Compatibility Matrix .....3

Safety Notices (Multi-lingual Translations) ....3

SafetyInformation...........11

Laser Compliance Statement .......16

Read this first .............19

What to do first ...........19

FRU replacement notices .........21

LCD replacement notice .........21

Screwnotices............21

System board/LCD/Inverter replacement notice 22

Relatedserviceinformation.........26

Power button as reset switch .......26

Running a low-level format ........26

ServiceWebsite...........26

Passwords .............26

Power management features .......28

Fn key combinations ..........29

Product recovery program ........31

Checkout guide ............34

Testing the computer ..........34

Relatedserviceinformation........36

Power systems checkout.........36

Symptom-to-FRU Index ..........40

Numeric Error Codes and Messages .....40

Beep Symptoms ...........41

LCD-Related Symptoms .........42

Keyboard/TrackPoint-Related Symptoms ....43

Indicator-Related Symptoms........43

Power-Related Symptoms ........43

Memory-Related Symptom ........44

Audio-Related Symptoms ........44

PC Card (PCMCIA)-Related Symptoms ....44

Power Management-Related Symptoms ....45

Peripheral-Device-Related Symptoms .....45

Modem-Related Symptom ........46

Operating System-Related Symptom .....46

IntermittentProblems..........46

Undetermined Problems .........47

FRU removals and replacements .......48

1010 External Diskette Drive .......50

1020 Battery assembly .........50

1030 Memory cover and memory card.....51

1040 Hard disk drive assembly .......52

vii

1050 Hard disk drive kitting pack ......54

1060 CD-ROM assembly ........54

1070 EZ key cover ..........56

1080 Keyboard ...........56

1090 Backup battery ..........57

1100 PCMCIA holder ..........58

1110 Modem and Ethernet card cover .....60

1120 Modem card ...........60

1130 Ethernet card (Optional) .......61

1140 IEEE 1394 card (Optional) ......61

1150 Middle cover ..........62

1160 LCD assembly ..........63

1170 Keyboard bezel ..........65

1180 Hard disk drive connection board ....67

1190 System board ..........67

1200 Fan assembly ..........68

1210 LCD bezel assembly (12.1″)......69

1220 LCD Inveter (12.1″) ........71

1230 LED board (12.1″).........72

1240 LCD panel assembly (12.1″), speaker

assembly and LCD bracket hinge assembly . . 73

1250 LCD FPC assembly (12.1″)......74

1260 LCD bezel assembly (12.1″/Hitachi) ....75

1270 LED/Inverter board (12.1″/Hitachi) ....76

1280 LCD panel assembly (12.1″/Hitachi), speaker

assembly and LCD bracket hinge assembly . . 77

1290 LCD FPC assembly (12.1″/Hitachi) ....79

1300 LCD bezel assembly (13.0″)......80

1310 LED/Inverter board (13.0″)......81

1320 LCD panel assembly (13.0″), speaker

assembly and LCD bracket hinge assembly . . 82

1330 LCD FPC assembly (13.0″)......83

1340 LCD bezel assembly (13.3″)......84

1350 LED/Inverter board (13.3″)......85

1360 LCD panel assembly (13.3″), speaker

assembly and LCD bracket hinge assembly . . 86

1370 LCD FPC assembly (13.3″)......89

Locations ..............90

FrontView.............90

Rear View .............91

BottomView............92

Switch Locations ...........93

ThinkPad i Series 1200/1300 (Part I) ......94

Product overview ...........95

Parts list (ThinkPad i Series 1200/1300) ....100

ThinkPad i Series 1200/1300 (Part II) .....113

Product overview ..........114

Parts list (ThinkPad i Series 1200/1300) ....119

ThinkPad i Series 1200/1300 (Part III) .....131

Product overview ..........132

FRU removals and replacements ......137

Parts list (ThinkPad i Series 1200/1300) ....176

ThinkPad i Series 1200/1300 (Part IV) .....185

viii ThinkPad i Series 1200/1300 HMM

Product overview ..........186

Parts list (ThinkPad i Series 1200/1300) ....191

ThinkPad i Series 1200/1300 (Part V) .....203

Product overview ..........204

Parts list (ThinkPad i Series 1200/1300) ....209

Notices..............222

Trademarks .............223

Contents

ix

x ThinkPad i Series 1200/1300 HMM

ThinkPad i Series 1200/1300 Hardware Maintenance Manual

General Descriptions

This chapter includes descriptions for any ThinkPad model
that has the PC-Doctor DOS diagnostics program. Some
descriptions might not apply to your particular computer.

1

Introduction

Important Service Information

Important

Diskette fixes are customer-installable. The diskette
fixes are posted on the IBM support site
(http://www.pc.ibm.com/support/).

Advise customers to contact the PC Company
HelpCenter at 800-772-2227 if they need assistance
in obtaining or installing any diskette fixes.

FRU Replacement Strategy

Before Replacing Parts

Ensure that all diskette fixes are installed prior to
replacing any FRUs listed in this manual.

Use the following strategy to prevent unnecessary FRU
replacement and service expense:

v If you are instructed to replace a FRU and that does

not correct the problem, reinstall the original FRU
before you continue.

v Some computers have both a processor board and a

system board. If you are instructed to replace either the
processor board or the system board, and the first board
that you replaced does not correct the problem, reinstall
the original board, then replace the other (processor or
system) board.

v If an adapter or device consists of more than one FRU,

an error code may be caused by any of the FRUs.
Before replacing the adapter or device, remove the
FRUs, one by one, to see if the symptoms change.
Replace only the FRU that changed the symptoms.

Attention: A customized setup configuration (other than
default settings) may exist on the computer you are
servicing. Running Automatic Configuration may alter those
settings. Note the current configuration settings (using the
View Configuration option) and verify that the settings are
in place when service is complete.

Hard Disk Drive Replacement Strategy

Always try to run a low-level format before replacing a hard
disk drive.

2 ThinkPad i Series 1200/1300 HMM

Attention: The drive startup sequence in the computer

you are servicing might have been changed. Be extremely
careful during write operations such as copying, saving, or
formatting. Data or programs can be over-written if you
select an incorrect drive.

How to Use Error Messages

Use the error codes displayed on the screen to diagnose
failures. If more than one error code is displayed, begin the
diagnosis with the first error code. The cause of the first
error code can result in false error codes being displayed.
If no error code is displayed, see if the error symptom is
listed in the Symptom-to-FRU Index for the computer you
are servicing.

How to Read POST Error Messages

POST error messages are displayed on the screen as
three, four, five, or eight digits. The error messages that
can be displayed as shorter POST messages are
highlighted in this index. Some digits will represent
different information for SCSI errors versus non-SCSI
errors.

All SCSI devices are set to a different SCSI ID. Duplicate
SCSI ID settings can generate a false error message. Use
the SCSI ID to determine whether the error message is
coming from an internal or an external device.

Drive and Diskette Compatibility Matrix

The following table provides identification information for

3.5-inch drives.

Diskette Drive Identifying Mark

3.5-Inch - 1.44MB 1.44 on the eject button

3.5-Inch - 2.88MB 2.88 on the eject button

The following table provides compatibility information for

3.5-inch diskettes and 3.5-inch diskette drives.

Diskette Capacity 1.44MB Drive 2.88MB Drive

1.0MB Read/Write Read/Write

2.0MB Read/Write Read/Write

4.0MB Not Compatible Read/Write

Safety Notices (Multi-lingual Translations)

In this manual, safety notices appear in English with a
page number reference to the appropriate multi-lingual,
translated safety notice found in this section.

ThinkPad i Series 1200/1300

3

The following safety notices are provided in English,
French, German, Italian, and Spanish languages.

Safety Notice 1

Before the computer is powered-on after FRU
replacement, make sure all screws, springs, or other
small parts are in place and are not left loose inside
the computer. Verify this by shaking the computer
and listening for rattling sounds. Metallic parts or
metal flakes can cause electrical shorts.

Avant de remettre l’ordinateur sous tension après
remplacement d’une unité en clientèle, vérifiez que
tous les ressorts, vis et autres pièces sont bien en
place et bien fixées. Pour ce faire, secouez l’unité et
assurez-vous qu’aucun bruit suspect ne se produit.
Des pièces métalliques ou des copeaux de métal
pourraient causer un court-circuit.

Bevor nach einem FRU-Austausch der Computer
wieder angeschlossen wird, muβ sichergestellt
werden, daβ keine Schrauben, Federn oder andere
Kleinteile fehlen oder im Gehäuse vergessen
wurden. Der Computer muβ geschüttelt und auf
Klappergeräusche geprüft werden. Metallteile oder

-splitter können Kurzschlüsse erzeugen.

Prima di accendere l’elaboratore dopo che é stata
effettuata la sostituzione di una FRU, accertarsi che
tutte le viti, le molle e tutte le altri parti di piccole
dimensioni siano nella corretta posizione e non
siano sparse all’interno dell’elaboratore. Verificare
ciò scuotendo l’elaboratore e prestando attenzione
ad eventuali rumori; eventuali parti o pezzetti
metallici possono provocare cortocircuiti pericolosi.

Antes de encender el sistema despues de sustituir
una FRU, compruebe que todos los tornillos,
muelles y demás piezas pequeñas se encuentran
en su sitio y no se encuentran sueltas dentro del
sistema. Compruébelo agitando el sistema y
escuchando los posibles ruidos que provocarían.
Las piezas metálicas pueden causar cortocircuitos
eléctricos.

4 ThinkPad i Series 1200/1300 HMM

Safety Notice 2

Some standby batteries contain a small amount of

nickel and cadmium. Do not disassemble it,

recharge it, throw it into fire or water, or short-circuit

it. Dispose of the battery as required by local

ordinances or regulations. Use only the battery in

the appropriate parts listing. Use of an incorrect

battery can result in ignition or explosion of the

battery.

Certaines batteries de secours contiennent du nickel

et du cadmium. Ne les démontez pas, ne les

rechargez pas, ne les exposez ni au feu ni à l’eau.

Ne les mettez pas en court-circuit. Pour les mettre

au rebut, conformez-vous à la réglementation en

vigueur. Lorsque vous remplacez la pile de

sauvegarde ou celle de l’horloge temps réel, veillez

à n’utiliser que les modèles cités dans la liste de

pièces détachées adéquate. Une batterie ou une

pile inappropriée risque de prendre feu ou

d’exploser.

Die Bereitschaftsbatterie, die sich unter dem

Diskettenlaufwerk befindet, kann geringe Mengen

Nickel und Cadmium enthalten. Sie darf nur durch

die Verkaufsstelle oder den IBM Kundendienst

ausgetauscht werden. Sie darf nicht zerlegt,

wiederaufgeladen, kurzgeschlossen, oder Feuer

oder Wasser ausgesetzt werden. Die Batterie kann

schwere Verbrennungen oder Verätzungen

verursachen. Bei der Entsorgung die örtlichen

Bestimmungen für Sondermüll beachten. Beim

Ersetzen der Bereitschafts- oder Systembatterie nur

Batterien des Typs verwenden, der in der

Ersatzteilliste aufgeführt ist. Der Einsatz falscher

Batterien kann zu Entzündung oder Explosion

führen.

Alcune batterie di riserva contengono una piccola

quantità di nichel e cadmio. Non smontarle,

ricaricarle, gettarle nel fuoco o nell’acqua né

cortocircuitarle. Smaltirle secondo la normativa in

vigore (DPR 915/82, successive disposizioni e

disposizioni locali). Quando si sostituisce la batteria

dell’RTC (real time clock) o la batteria di supporto,

utilizzare soltanto i tipi inseriti nell’appropriato

Catalogo parti. L’impiego di una batteria non adatta

potrebbe determinare l’incendio o l’esplosione della

batteria stessa.

Algunas baterías de reserva contienen una pequeña

ThinkPad i Series 1200/1300

5

cantidad de níquel y cadmio. No las desmonte, ni
recargue, ni las eche al fuego o al agua ni las
cortocircuite. Deséchelas tal como dispone la
normativa local. Utilice sólo baterías que se
encuentren en la lista de piezas. La utilizaciónde
una batería no apropiada puede provocar la ignición
o explosión de la misma.

6 ThinkPad i Series 1200/1300 HMM

Safety Notice 3

The battery pack contains small amounts of nickel.

Do not disassemble it, throw it into fire or water, or

short-circuit it. Dispose of the battery pack as

required by local ordinances or regulations. Use

only the battery in the appropriate parts listing when

replacing the battery pack. Use of an incorrect

battery can result in ignition or explosion of the

battery.

La batterie contient du nickel. Ne la démontez pas,

ne l’exposez ni au feu ni à l’eau. Ne la mettez pas

en court-circuit. Pour la mettre au rebut,

conformez-vous à la réglementation en vigueur.

Lorsque vous remplacez la batterie, veillez à

n’utiliser que les modèles cités dans la liste de

pièces détachées adéquate. En effet, une batterie

inappropriée risque de prendre feu ou d’exploser.

Akkus enthalten geringe Mengen von Nickel. Sie

dürfen nicht zerlegt, wiederaufgeladen,

kurzgeschlossen, oder Feuer oder Wasser

ausgesetzt werden. Bei der Entsorgung die örtlichen

Bestimmungen für Sondermüll beachten. Beim

Ersetzen der Batterie nur Batterien des Typs

verwenden, der in der Ersatzteilliste aufgeführt ist.

Der Einsatz falscher Batterien kann zu Entzündung

oder Explosion führen.

La batteria contiene piccole quantità di nichel. Non

smontarla, gettarla nel fuoco o nell’acqua né

cortocircuitarla. Smaltirla secondo la normativa in

vigore (DPR 915/82, successive disposizioni e

disposizioni locali). Quando si sostituisce la batteria,

utilizzare soltanto i tipi inseriti nell’appropriato

Catalogo parti. L’impiego di una batteria non adatta

potrebbe determinare l’incendio o l’esplosione della

batteria stessa.

Las baterías contienen pequeñas cantidades de

níquel. No las desmonte, ni recargue, ni las eche al

fuego o al agua ni las cortocircuite. Deséchelas tal

como dispone la normativa local. Utilice sólo

baterías que se encuentren en la lista de piezas al

sustituir la batería. La utilización de una bateríano

apropiada puede provocar la ignición o explosiónde

la misma.

ThinkPad i Series 1200/1300 7

Safety Notice 4

The lithium battery can cause a fire, explosion, or
severe burn. Do not recharge it, remove its
polarized connector, disassemble it, heat it above
100°C (212°F), incinerate it, or expose its cell
contents to water. Dispose of the battery as required
by local ordinances or regulations. Use only the
battery in the appropriate parts listing. Use of an
incorrect battery can result in ignition or explosion of
the battery.

La pile de sauvegarde contient du lithium. Elle
présente des risques d’incendie, d’explosion ou de
brûlures graves. Ne la rechargez pas, ne retirez pas
son connecteur polarisé et ne la démontez pas. Ne
l’exposez pas à une temperature supérieure à
100°C, ne la faites pas brûleretn’en exposez pas
le contenu à l’eau. Mettez la pile au rebut
conformément à la réglementation en vigueur. Une
pile inappropriée risque de prendre feu ou
d’exploser.

Die Systembatterie ist eine Lithiumbatterie. Sie kann
sich entzünden, explodieren oder schwere
Verbrennungen hervorrufen. Batterien dieses Typs
dürfen nicht aufgeladen, zerlegt, über 100 C erhitzt
oder verbrannt werden. Auch darf ihr Inhalt nicht mit
Wasser in Verbindung gebracht oder der zur
richtigen Polung angebrachte Verbindungsstecker
entfernt werden. Bei der Entsorgung die örtlichen
Bestimmungen für Sondermüll beachten. Beim
Ersetzen der Batterie nur Batterien des Typs
verwenden, der in der Ersatzteilliste aufgeführt ist.
Der Einsatz falscher Batterien kann zu Entzündung
oder Explosion führen.

La batteria di supporto e una batteria al litio e puo
incendiarsi, esplodere o procurare gravi ustioni.
Evitare di ricaricarla, smontarne il connettore
polarizzato, smontarla, riscaldarla ad una
temperatura superiore ai 100 gradi centigradi,
incendiarla o gettarla in acqua. Smaltirla secondo la
normativa in vigore (DPR 915/82, successive
disposizioni e disposizioni locali). L’impiego di una
batteria non adatta potrebbe determinare l’incendio
ol’esplosione della batteria stessa.

La bateria de repuesto es una bateria de litio y
puede provocar incendios, explosiones o
quemaduras graves. No la recargue, ni quite el
conector polarizado, ni la desmonte, ni caliente por

8 ThinkPad i Series 1200/1300 HMM

encima de los 100°C (212°F), ni la incinere ni

exponga el contenido de sus celdas al agua.

Deséchela tal como dispone la normativa local.

Safety Notice 5

If the LCD breaks and the fluid from inside the LCD

gets into your eyes or on your hands, immediately

wash the affected areas with water for at least 15

minutes. Seek medical care if any symptoms from

the fluid are present after washing.

Si le panneau d’affichage à cristaux liquides se

brise et que vous recevez dans les yeux ou sur les

mains une partie du fluide, rincez-les abondamment

pendant au moins quinze minutes. Consultez un

médecin si des symptômes persistent aprèsle

lavage.

Die Leuchtstoffröhre im LCD-Bildschirm enthält

Quecksilber. Bei der Entsorgung die örtlichen

Bestimmungen für Sondermüll beachten. Der

LCD-Bildschirm besteht aus Glas und kann

zerbrechen, wenn er unsachgemäβ behandelt wird

oder der Computer auf den Boden fällt. Wenn der

Bildschirm beschädigt ist und die darin befindliche

Flüssigkeit in Kontakt mit Haut und Augen gerät,

sollten die betroffenen Stellen mindestens 15

Minuten mit Wasser abgespült und bei

Beschwerden anschlieβend ein Arzt aufgesucht

werden.

Nel caso che caso l’LCD si dovesse rompere ed il

liquido in esso contenuto entrasse in contatto con gli

occhi o le mani, lavare immediatamente le parti

interessate con acqua corrente per almeno 15

minuti; poi consultare un medico se i sintomi

dovessero permanere.

Si la LCD se rompe y el fluido de su interior entra

en contacto con sus ojos o sus manos, lave

inmediatamente las áreas afectadas con agua

durante 15 minutos como mínimo. Obtenga atención

medica si se presenta algúnsíntoma del fluido

despues de lavarse.

ThinkPad i Series 1200/1300 9

Safety Notice 6

To avoid shock, do not remove the plastic cover that
surrounds the lower portion of the inverter card.

Afin d’éviter tout risque de choc électrique, ne
retirez pas le cache en plastique protégeant la
partie inférieure de la carte d’alimentation.

Aus Sicherheitsgründen die Kunststoffabdeckung,
die den unteren Teil der Spannungswandlerplatine
umgibt, nicht entfernen.

Per evitare scosse elettriche, non rimuovere la
copertura in plastica che avvolge la parte inferiore
della scheda invertitore.

Para evitar descargas, no quite la cubierta de
plástico que rodea la parte baja de la tarjeta
invertida.

Safety Notice 7

Though main batteries have low voltage, a shorted
or grounded battery can produce enough current to
burn combustible materials or personnel.

Bien que le voltage des batteries principales soit
peu élevé, le court-circuit ou la mise à la masse
d’une batterie peut produire suffisamment de
courant pour brûler des matériaux combustibles ou
causer des brûlures corporelles graves.

Obwohl Hauptbatterien eine niedrige Spannung
haben, können sie doch bei Kurzschluβ oder Erdung
genug Strom abgeben, um brennbare Materialien zu
entzünden oder Verletzungen bei Personen
hervorzurufen.

Sebbene le batterie di alimentazione siano a basso
voltaggio, una batteria in corto circuito o a massa
può fornire corrente sufficiente da bruciare materiali
combustibili o provocare ustioni ai tecnici di
manutenzione.

Aunque las baterías principales tienen un voltaje
bajo, una batería cortocircuitada o con contacto a
tierra puede producir la corriente suficiente como
para quemar material combustible o provocar
quemaduras en el personal.

10 ThinkPad i Series 1200/1300 HMM

Safety Notice 8

Before removing any FRU, power-off the computer,

unplug all power cords from electrical outlets,

remove the battery pack, then disconnect any

interconnecting cables.

Avant de retirer une unité remplaçable en clientèle,

mettez le système hors tension, débranchez tous

les cordons d’alimentation des socles de prise de

courant, retirez la batterie et déconnectez tous les

cordons d’interface.

Die Stromzufuhr muβ abgeschaltet, alle Stromkabel

aus der Steckdose gezogen, der Akku entfernt und

alle Verbindungskabel abgenommen sein, bevor

eine FRU entfernt wird.

Prima di rimuovere qualsiasi FRU, spegnere il

sistema, scollegare dalle prese elettriche tutti i cavi

di alimentazione, rimuovere la batteria e poi

scollegare i cavi di interconnessione.

Antes de quitar una FRU, apague el sistema,

desenchufe todos los cables de las tomas de

corriente eléctrica, quite la batería y, a continuación,

desconecte cualquier cable de conexión entre

dispositivos.

Safety Information

The following section contains the safety information that
you need to be familiar with before servicing an IBM
mobile computer.

General Safety

Follow these rules to ensure general safety:

v Observe good housekeeping in the area of the

machines during and after maintenance.

v When lifting any heavy object:

1. Ensure that you can stand safely without slipping.

2. Distribute the weight of the object equally between
your feet.

3. Use a slow lifting force. Never move suddenly or
twist when you attempt to lift.

4. Lift by standing or by pushing up with your leg
muscles; this action removes the strain from the
muscles in your back. Do not attempt to lift any

objects that weigh more than 16 kg (35 lb) or objects
that you think are too heavy for you.

ThinkPad i Series 1200/1300

11

v Do not perform any action that causes hazard to the

customer, or that makes the equipment unsafe.

v Before you start the machine, ensure that other service

representatives and the customer’s personnel are not in
a hazardous position.

v Place removed covers and other parts in a safe place,

away from all personnel, while you are servicing the
machine.

v Keep your tool case away from walk areas so that other

people will not trip over it.

v Do not wear loose clothing that can be trapped in the

moving parts of a machine. Ensure that your sleeves
are fastened or rolled up above your elbows. If your hair
is long, fasten it.

v Insert the ends of your necktie or scarf inside clothing or

fasten it with a nonconductive clip, approximately 8
centimeters (3 inches) from the end.

v Do not wear jewelry, chains, metal-frame eyeglasses, or

metal fasteners for your clothing.
Attention: Metal objects are good electrical

conductors.

v Wear safety glasses when you are: hammering, drilling

soldering, cutting wire, attaching springs, using solvents,
or working in any other conditions that might be
hazardous to your eyes.

v After service, reinstall all safety shields, guards, labels,

and ground wires. Replace any safety device that is
worn or defective.

v Reinstall all covers correctly before returning the

machine to the customer.

Electrical Safety

Observe the following rules when working on electrical
equipment.

Important

Use only approved tools and test equipment. Some
hand tools have handles covered with a soft
material that does not insulate you when working
with live electrical currents. Many customers have,
near their equipment, rubber floor mats that contain
small conductive fibers to decrease electrostatic
discharges. Do not use this type of mat to protect
yourself from electrical shock.

v Find the room emergency power-off (EPO) switch,

disconnecting switch, or electrical outlet. If an electrical
accident occurs, you can then operate the switch or
unplug the power cord quickly.

12 ThinkPad i Series 1200/1300 HMM

v Do not work alone under hazardous conditions or near

equipment that has hazardous voltages.

v Disconnect all power before:

– Performing a mechanical inspection

– Working near power supplies

– Removing or installing main units

v Before you start to work on the machine, unplug the

power cord. If you cannot unplug it, ask the customer to
power-off the wall box that supplies power to the
machine and to lock the wall box in the off position.

v If you need to work on a machine that has exposed

electrical circuits, observe the following precautions:

– Ensure that another person, familiar with the

power-off controls, is near you.
Attention: Another person must be there to switch

off the power, if necessary.

– Use only one hand when working with powered-on

electrical equipment; keep the other hand in your
pocket or behind your back.

Attention: There must be a complete circuit to
cause electrical shock. By observing the above rule,
you may prevent a current from passing through your
body.

– When using testers, set the controls correctly and

use the approved probe leads and accessories for
that tester.

– Stand on suitable rubber mats (obtained locally, if

necessary) to insulate you from grounds such as
metal floor strips and machine frames.

Observe the special safety precautions when you work
with very high voltages; these instructions are in the
safety sections of maintenance information. Use
extreme care when measuring high voltages.

v Regularly inspect and maintain your electrical hand tools

for safe operational condition.

v Do not use worn or broken tools and testers.

v Never assume that power has been disconnected from

a circuit. First, check that it has been powered-off.

v Always look carefully for possible hazards in your work

area. Examples of these hazards are moist floors,
nongrounded power extension cables, power surges,
and missing safety grounds.

v Do not touch live electrical circuits with the reflective

surface of a plastic dental mirror. The surface is
conductive; such touching can cause personal injury and
machine damage.

ThinkPad i Series 1200/1300

13

v Do not service the following parts with the power on

when they are removed from their normal operating
places in a machine:

– Power supply units

– Pumps

– Blowers and fans

– Motor generators

and similar units. (This practice ensures correct
grounding of the units.)

v If an electrical accident occurs:

– Use caution; do not become a victim yourself.
– Switch off power.
– Send another person to get medical aid.

Safety Inspection Guide

The intent of this inspection guide is to assist you in
identifying potentially unsafe conditions on these products.
Each machine, as it was designed and built, had required
safety items installed to protect users and service
personnel from injury. This guide addresses only those
items. However, good judgment should be used to identify
potential safety hazards due to attachment of non-IBM
features or options not covered by this inspection guide.

If any unsafe conditions are present, you must determine
how serious the apparent hazard could be and whether
you can continue without first correcting the problem.
Consider these conditions and the safety hazards they
present:

v Electrical hazards, especially primary power (primary

voltage on the frame can cause serious or fatal
electrical shock).

v Explosive hazards, such as a damaged CRT face or

bulging capacitor.

v Mechanical hazards, such as loose or missing

hardware.

The guide consists of a series of steps presented in a
checklist. Begin the checks with the power off, and the
power cord disconnected.

Checklist:

1. Check exterior covers for damage (loose, broken, or
sharp edges).

2. Power-off the computer. Disconnect the power cord.

3. Check the power cord for:

a. A third-wire ground connector in good condition.

Use a meter to measure third-wire ground

14 ThinkPad i Series 1200/1300 HMM

continuity for 0.1 ohm or less between the external
ground pin and frame ground.

b. The power cord should be the appropriate type as

specified in the parts listings.

c. Insulation must not be frayed or worn.

4. Remove the cover.

5. Check for any obvious non-IBM alterations. Use good
judgment as to the safety of any non-IBM alterations.

6. Check inside the unit for any obvious unsafe
conditions, such as metal filings, contamination, water
or other liquids, or signs of fire or smoke damage.

7. Check for worn, frayed, or pinched cables.

8. Check that the power-supply cover fasteners (screws
or rivets) have not been removed or tampered with.

Handling Electrostatic Discharge-Sensitive Devices

Any computer part containing transistors or integrated
circuits ( ICs) should be considered sensitive to
electrostatic discharge (ESD). ESD damage can occur
when there is a difference in charge between objects.
Protect against ESD damage by equalizing the charge so
that the machine, the part, the work mat, and the person
handling the part are all at the same charge.

Notes:

1. Use product-specific ESD procedures when they
exceed the requirements noted here.

2. Make sure that the ESD protective devices you use
have been certified (ISO 9000) as fully effective.

When handling ESD-sensitive parts:

v Keep the parts in protective packages until they are

inserted into the product.

v Avoid contact with other people.

v Wear a grounded wrist strap against your skin to

eliminate static on your body.

v Prevent the part from touching your clothing. Most

clothing is insulative and retains a charge even when
you are wearing a wrist strap.

v Use the black side of a grounded work mat to provide a

static-free work surface. The mat is especially useful
when handling ESD-sensitive devices.

v Select a grounding system, such as those listed below,

to provide protection that meets the specific service
requirement.

Note: The use of a grounding system is desirable but

not required to protect against ESD damage.

ThinkPad i Series 1200/1300

15

– Attach the ESD ground clip to any frame ground,

ground braid, or green-wire ground.

– Use an ESD common ground or reference point

when working on a double-insulated or
battery-operated system.

– You can use coax or connector-outside shells on

these systems.

– Use the round ground-prong of the AC plug on

AC-operated computers.

Grounding Requirements

Electrical grounding of the computer is required for
operator safety and correct system function. Proper
grounding of the electrical outlet can be verified by a
certified electrician.

Laser Compliance Statement

Some IBM Personal Computer models are equipped from
the factory with a CD-ROM/DVD-ROM drive.
CD-ROM/DVD-ROM drives are also sold separately as
options. The CD-ROM/DVD-ROM drive is a laser product.
The CD-ROM/DVD-ROM drive is certified in the U.S. to
conform to the requirements of the Department of Health
and Human Services 21 Code of Federal Regulations
(DHHS 21 CFR) Subchapter J for Class 1 laser products.
Elsewhere, the drive is certified to conform to the
requirements of the International Electrotechnical
Commission (IEC) 825 and CENELEC EN 60 825 for
Class 1 laser products.

When a CD-ROM/DVD-ROM drive is installed, note the
following.

16 ThinkPad i Series 1200/1300 HMM

CAUTION:
Use of controls or adjustments or performance of
procedures other than those specified herein might
result in hazardous radiation exposure.

O uso de controles, ajustes ou desempenho de
procedimentos diferentes daqueles aqui especificados
pode resultar em perigosa exposição à radiação.

Pour éviter tout risque d’exposition au rayon laser,
respectez les consignes de réglage et d’utilisation des
commandes, ainsi que les procédures décrites.

Werden Steuer- und Einstellelemente anders als hier
festgesetzt verwendet, kann gefährliche
Laserstrahlung auftreten.

L’utilizzo di controlli, regolazioni o l’esecuzione di
procedure diverse da quelle specificate possono
provocare l’esposizione a

El uso de controles o ajustes o la ejecución de
procedimientos distintos de los aquí especificados
puede provocar la exposición a radiaciones
peligrosas.

ThinkPad i Series 1200/1300

17

DANGER

Opening the CD-ROM/DVD-ROM drive could result
in exposure to hazardous laser radiation. There are
no serviceable parts inside the CD-ROM/DVD-ROM
drive. Do not open.

Some CD-ROM/DVD-ROM drives contain an
embedded Class 3A or Class 3B laser diode. Note
the following.

Laser radiation when open. Do not stare into the
beam, do not view directly with optical instruments,
and avoid direct exposure to the beam.

Radiação por raio laser ao abrir. Não olhe fixo no
feixe de luz, não olhe diretamente por meio de
instrumentos óticos e evite exposição direta com o
feixe de luz.

Rayonnement laser si carter ouvert. Évitez de fixer
le faisceau, de le regarder directement avec des
instruments optiques, ou de vous exposer au
rayon.

Laserstrahlung bei geöffnetem Gerät. Nicht direkt
oder über optische Instrumente in den Laserstrahl
sehen und den Strahlungsbereich meiden.

Kinyitáskor lézersugár!Nenézzen bele se szabad
szemmel, se optikai eszközökkel. Kerülje a
sugárnyalábbal valóérintkezést !

Aprendo l’unità vengono emesse radiazioni laser.
Non fissare il fascio, non guardarlo direttamente
con strumenti ottici e evitare l’esposizione diretta al
fascio.

Radiaciónláser al abrir. No mire fijamente ni
examine con instrumental óptico el haz de luz.
Evite la exposición directa al haz.

18 ThinkPad i Series 1200/1300 HMM

Read this first

Before you go to the checkout guide, be sure to read this
section first.

Important Notes:
v Only certified trained personnel should service the

computer.

v Read the entire FRU service procedures before

replacing any FRUs.

v Use new nylon-coated screws when you replace

FRUs.

v Be extremely careful during write operations such

as copying, saving, or formatting. Drives in the

computer that you are servicing might have been
rearranged or the drive startup sequence might have
been altered. If you select an incorrect drive, data or
programs could be overwritten.

v Replace FRUs only for the correct model. When you

replace a FRU, make sure that the model of the
machine and FRU part number are correct by referring
to the FRU parts list.

v A FRU should not be replaced because of a single,

unreproducible failure. Single failure can occur for a

variety of reasons that have nothing to do with a
hardware defect, such as: cosmic radiation, electrostatic
discharge, or software error. FRU replacement should
be considered only when a recurring problem exists. In
this case, clear the error log and run the test again. Do
not replace FRUs if log errors do not reappear.

v Be careful not to replace a non-defective FRU.

What to do first

The servicer must include the following in the parts
exchange form or parts return form that is attached to the
returned FRU:

1. Name and phone number of servicer

2. Date of service

3. Date when part failed

4. Date of purchase

5. Failure symptoms, error codes appearing on display,
and beep symptoms

6. Procedure index and page number in which failing FRU
was detected

7. Failing FRU name and part number

8. Machine type, model number and serial number

9. Customer’s name and address

ThinkPad i Series 1200/1300

19

Before checking problems with the computer, determine
whether the damage is covered under the warranty by
referring to the following:

Note for Warranty:

For Warranty:

During the warranty period, the customer may be
responsible for repair costs if the computer damage
was caused by misuse, accident, modification,
unsuitable physical or operating environment, or
improper maintenance by the customer. The
following list provides some common items that are
not covered under warranty and some symptoms
that may indicate the system was subjected to
stresses beyond normal use.

The following are not covered under warranty:

v LCD panel cracked by applying excessive force

or by being dropped.

v Scratched (cosmetic) parts.

v Cracked or broken plastic parts, broken latches,

broken pins, or broken connectors caused by
excessive force.

v Damage caused by liquid spilled into the system.

v Damage caused by improperly inserting a PC

Card or installation of an incompatible card.

v Damage caused by foreign material in the FDD.

v Diskette drive damage caused by pressing the

diskette drive cover or inserting diskettes with
multiple labels.

v Damaged or bent diskette drive eject button.

v CD-ROM/DVD-ROM drive damage caused by

excessive force, shock, or by being dropped.

v Fuses blown by attaching a nonsupported device.

v Forgotten computer password (making the

computer unusable).

The following symptoms might indicate damage
caused by non-warranted activities:

v Missing parts may be a symptom of unauthorized

service or modification.

v HDD spindles can become noisy if subjected to

excessive force or by being dropped.

v I9990303 errors can be caused by exposure to

strong magnetic fields.

20 ThinkPad i Series 1200/1300 HMM
