Estimado Digital 2000,
Los códigos de errores 163 y 173 para los IBM ThinkPads significan que el reloj en tiempo real no
está funcionando y la memoria CMOS/NVRAM tiene problema. Esto indica que la batería de la
CMOS está mal, sin carga. Hay que cambiarla y reiniciar los datos de la CMOS (día, hora, etc) en
el setup de la máquina..
No sé cual es el modelo de su ThinkPad, pero algunos de los modelos necesitan que usted, ao
prenderlo, mantenga la tecla F1 presionada para entrar al setup (claro está, después de cambiar la
batería interna de la CMOS…)
Véase una relación de los códigos de errores de IBM en las páginas siguientes:
163 CMOS error; Clock is not updating
173 Bad CMOS/NVRAM checksum
BIOS
PostCodes:
Acer BIOS Post
Codes
ALR BIOS Post
Codes
AMIT/AMI
BIOS Post Codes
Arche Legacy
BIOS Post Codes
AST BIOS Post
Codes
AT&T BIOS
Post Codes
Award BIOS
Post Codes
Chips &
Technologies
BIOS Post Codes
Compaq BIOS
Post Codes
Dell BIOS Post
Codes
DTK BIOS Post
Codes
Eurosoft/Mylex
BIOS Post Codes
Faraday A-Tease
BIOS Post Codes
HP BIOS Post
Codes
IBM BIOS Post
Codes
Landmark BIOS
Post Codes
Home · Forums · About Us · Awards · Contact Us
For their PS/2 systems, IBM used a system of diagnostic codes to diagnose
trouble spots in a given computer. The problem was, these diagnostic
codes were never really documented all that well. The codes that I am
presenting here are from documents I have read through, found on the web,
found in old books, documents and technical papers. As a computer
technician, I rely on documentation to guide me through these types of
messages. Therefore, I hope to provide this to all those other technicians
out there who get the opportunity to work on one of these. And, yes,
people still use them and some refuse to give them up.
The method for reading these codes is pretty straight forward. The first
part of the error code indicates the device that is causing the trouble. The
second part gives the meaning of the error. You can think of the first part
as the test code and the second part as the fault code. A fault code of 00
indicates that no problem was found. Thus 200 means the system memory
was tested. The 00 means that no fault was found. 201 would mean a
memory error. 202 would mean memory address error; lines 00-15.
This page is rather extensive and will be updated on a regular basis. Like
all the other codes out there. If you know of any error codes that I am
displaying incorrectly or that aren't here.
Let me know and I'll get it
corrected as soon as I can.
Thanks to Mike Rose for erors 129 and 229!
System Board Errors:
Code
Description
101 System board interrupt failure (unexpected interrupt)
102 BIOS ROM checksum error (PC, XT); timer error (AT, MCA)
103
104
105
BASIC ROM checksum error (PC, XT); timer interrupt error
(AT, MCA)
Interrupt controller error (PC, XT); protected mode error (AT,
MCA)
Timer failure (PC, XT); 8042 keyboard controller failure
(MCA)
BIOS Beep Codes:
AMI BIOS Beep
Codes
AST BIOS Beep
Codes
Award BIOS Beep
Codes
Compaq BIOS
Beep Codes
IBM BIOS Beep
Codes
Mylex BIOS Beep
Codes
Phoenix BIOS
Beep Codes
Quadtel BIOS
Beep Codes
System Specific
Diagnostic and
POST Error
Messages:
IBM Diagnostic
Error Codes
Compaq Desktop
Systems
Diagnostic and
POST Errors
BIOS Related
Pages:
Bios Data Area
BiosCentral Forums
BIOS Basics
Microid
Research/Mr
BIOS Post Codes
NCR BIOS Post
Codes
Olivetti BIOS
Post Codes
Phillips BIOS
Post Codes
Phoenix BIOS
Post Codes
Quadtel BIOS
Post Codes
Supersoft BIOS
Post Codes
Tandon BIOS
Post Codes
Zenith BIOS Post
Codes
Intel
Motherboards:
CA810E
CC820
SE440BX-2
D810E2CB
D810EMO
D815BN
D815EEA
D815EPEA
106 System board converting logic test failure
107
System board non-maskable interrupt (NMI) test failure; Hot
NMI test failure (MCA)
108 System board timer bus test failure
109 DMA test memory select failure
110
111
PS/2 system board parity check error (MCA); PS/2 system
board memory error (ISA)
PS/2 adapter memory problem (ISA); PS/2 I/O channel parity
check error (MCA)
112 PS/2 watchdog timeout error (NMI)
113 PS/2 DMA arbitration time out error (NMI)
114 PS/2 external ROM checksum error
115 BIOS ROM checksum error, cache parity error, or DMA error
116 System board read/write error
118 System Board parity or L2 cache error
119
2.88MB floppy installed but not supported by the floppy
controller
120 CPU self test error
121
Unexpected hardware interrupt occurred; 256KB ROM
checksum error (second 128KB bank)
129 System Board Failure
131 Cassette wrap test; DMA compatibility registers error
132 DMA extended registers error
133 DMA verify logic error
134 DMA arbitration error
151 Battery, real time clock, or CMOS RAM failure
152 Real time clock, or CMOS RAM failure
160 PS/2 system board ID not recognized
161 CMOS configuration lost (battery has died)
162 CMOS checksum error, CRC error, or adapter ID mismatch
BIOS and
Computer Links
BIOS Int 13 Error
Codes
BIOS Services
CMOS Memory
Map
Debug Routines
Interrupts
My Other Pages:
Images
My Systems
Site Comments
Utility Downloads
Best viewed at
1024x768x16
D820LP
SE440BX
SR440BX
JN440BX
LB440GX/
L440GX
N440BX/
NA440BX
OR840
T440BX
RC440BX
163 CMOS error; Clock is not updating
164
CMOS error; CMOS setting does not match memory on
system board
165 PS/2 adapter ID mismatch
166 PS/2 adapter time out; card busy
167 PS/2 system clock not updating
168 Math coprocessor error in the CMOS configuration
169 System board and processor card configuration mismatch
170 ASCII setup conflict error
171 Rolling bit test failure on CMOS shutdown byte
172 Rolling bit test failure on NVRAM diagnostic byte
173 Bad CMOS/NVRAM checksum
VC820
174 Bad system configuration
175 Bad EEPROM CRC
177 Bad password CRC
178 Bad EEPROM
179 NVRAM error log full
180x Sub address date error in slot x
181 Unsupported configuration
182 Password switch is not in the writing position
183 System halted; password is required
184 Bad power on password
185 Bad startup sequence
186 Password protection hardware error
187 Serial number error
188 Bad EEPROM checksum
189 Too many incorrect password attempts
191 Cache controller test failed
194 System board memory error
195
Configuration read from hibernation area of HDD doesn't
match actual configuration
196 Read error occurred in hibernation area of HDD
199 User indicated device list not correct
Return to Top
Memory Errors:
Code
Description
20x Memory error
201 Memory test failure; error location might be displayed
202 Memory address error; lines 00-15
203 Memory address error; lines 16-23 (ISA) or 16-31 (MCA)
204 Memory remapped due to error (run diagnostics again)
205 Base 128KB memory error; memory remapped
207 ROM failure
210 System board memory parity error
211 Error in first 64KB of RAM
212 Watchdog timer error
213 DMA bus arbitration time out
215 Memory address error; 64KB on daughter/SIP 2 failed
216 Memory address error; 64KB on daughter/SIP 1 failed
221 ROM to RAM copy failed
225 Wrong speed memory on system board
229 Memory Error
230 Overlapping adapter and planar memory
231 Non continuous adapter memory installed
235 Stuck data line on memory module
241 Memory module 2 failed
251 Memory module 3 failed
Return to Top
Keyboard Errors:
Code
Description
301 Keyboard did not respond correctly
302 Keyboard locked
303
304 Keyboard or system unit error
305 Keyboard fuse failed on system board
306 Unsupported keyboard attached
341 Keyboard error
342 Keyboard cable error
343 Enhancement card or cable error
365 Keyboard failure
366 Interface cable failure
367 Enhancement card or cable failure
Return to Top
Monochrome Display Adapter Errors:
Code
Keyboard and/or system board interface error; keyboard
controller fault
Description
401 Memory, horizontal sync frequency or vertical sync failure
408 User indicated display attribute failure
416 User indicated character set failure
424 User indicated 80 x 25 mode failure
432 MDA card parallel port test failure
Return to Top
Color Graphics Adapter Errors:
Code Description
501
503 CGA adapter controller failed
508 User display attribute failure
516 User indicated character set failure
524 User indicated 80 x 25 mode failure
532 User indicated 40 x 25 mode failure
540 User indicated 320 x 200 graphics mode failure
548 User indicated 640 x 200 graphics mode failure
556 User indicated light pen test failed
564 User indicated paging test failure
Return to Top
Floppy Drive/Controller Errors:
Code
CRT error; CGA memory, horizontal sync frequency or video
test failure
Description
601 General diskette or adapter failure
602 Diskette boot sector is not valid
603 Diskette size error
604 Media sense error
605 Diskette drive locked
606 Diskette verify test failed
607 Write protect error
608 Drive command error
610 Diskette initialization failure
611 Drive time out error
612 NEC drive controller IC error
613 Floppy system DMA error
614 Floppy system DMA boundary overrun error
615 Drive index timing error
616 Drive speed error
621 Drive seek error
622 Drive cyclic redundancy check (CRC) error
625 Controller chip (NEC) seek error
626 Diskette data compare error
627 Diskette data compare error
628 Diskette removed
630 Index stuck high; drive A:
631 Index stuck low; drive A:
632 Track 0 stuck off; drive A:
632 Track 0 stuck on; drive A:
640 Index stuck high; drive B:
641 Index stuck low; drive B:
642 Track 0 stuck off; drive B:
643 Track 0 stuck on; drive B:
645 No index pulse
646 Drive track 0 detection failed
647 No transitions on read data line
648 Format test failed
649 Incorrect media type in drive
650 Drive speed error
651 Format failure
652 Verify failure
653 Read failure
654 Write failure
655 Controller error
656 Drive failure
657 Write protect stuck protected
658 Changeline stuck unprotected
659 Write protected stuck unprotected
660 Changeline stuck unchanged
Return to Top
Math Coprocessor Errors:
Code
Description
701 Math coprocessor presence/initialization error
702 Exception errors test failure
703 Rounding test failure
704 Arithmetic test 1 failure
705 Arithmetic test 2 failure
706 Arithmetic test 3 failure; Test is performed on 80387 only
707 Combination test failure
708 Integer load/store test failure
709 Equivalent expressions errors
710 Interrupt errors
711 Save state errors
712 Protected mode test failure
713 Voltage test failure
Return to Top
Parallel Printer Adapter Errors:
Code
Description
901 Data register latch error
902 Control register latch error
903 Register address decode error
904 Address decode error
910 Status line wrap connector error
911 Status line bit 8 wrap error
912 Status line bit 7 wrap error
913 Status line bit 6 wrap error
914 Status line bit 5 wrap error
915 Status line bit 4 wrap error
916 Printer adapter interrupt wrap error
917 Unexpected printer adapter interrupt
92x Feature register error
Return to Top
Alternate Printer Adapter Errors
:
Code Description
1001 Printer adapter data register latch error
1002 Printer adapter control register latch error
1003 Printer adapter register address decode error
1004 Printer adapter address decode error
1010 Status line wrap connector error
1011 Status line bit 8 wrap error
1012 Status line bit 7 wrap error
1013 Status line bit 6 wrap error
1014 Status line bit 5 wrap error
1015 Status line bit 4 wrap error
1016 Printer adapter interrupt wrap error
1017 Unexpected printer adapter interrupt
102x Feature register error
Return to Top
Primary Async Communications Errors:
Code
Description
1101 16450/16550 chip error; serial port A error
1102
1103
1104 PC convertible internal modem dial tine test 2 failed
1106 Serial option cannot be put to sleep
1107 Cable error
1108 Interrupt request (IRQ) 3 error
1109 Interrupt request (IRQ) 4 error
1110 16450/16550 chip register failure
1111
1112
1113 16450/16550 chip transmit error
1114 16450/16550 chip receive error
1115 16450/16550 chip receive error; data not equal to transmit data
1116 16450/16550 chip interrupt function error
Card selected feedback error; PC convertible internal modem
test failed
Port 102h register test failure; PC convertible internal modem
dial tone test 1 failed
Internal wrap test of 16450/16550 chip modem control line
failure
External wrap test of 16450/16550 chip modem control line
failure
1117 16450/16550 chip baud rate test failure
1118 16450/16550 chip receive external data wrap test failure
1119 16550 chip first-in/first-out (FIFO) buffer failure
1120 Interrupt enable register error; all bits cannot be set
1121 Interrupt enable register error; all bits cannot be reset
1122 Interrupt pending; stuck on
1123 Interrupt ID register; stuck on
1124 Modem cannot register error; all bits cannot be set
1125 Modem cannot register error; all bits cannot be reset
1126 Modem status register error; all bits cannot be set
1127 Modem status register error; all bits cannot be reset
1128 Interrupt ID error
1129 Cannot force overrun error
1130 No modem status interrupt
1131 Invalid interrupt pending
1132 No data ready
1133 No data available interrupt
1134 No transmit holding interrupt
1135 No interrupts
1136 No received line status interrupt
1137 No receive data available
1138 Transmit holding register not empty
1139 No modem status interrupt
1140 Transmit holding register not empty
1141 No interrupts
1142 No interrupt 4
1143 No interrupt 3
1144 No data transferred
1145 Maximum baud rate error
1146 Minimum baud rate error
1148 Time out error
1149 Invalid data returned
1150 Modem status register error
1151 No data set ready and delta data set ready
1152 No data set ready
1153 No delta data set ready
1154 Modem status register not clear
1155 No clear to send and delta clear to send
1156 No clear to send
1157 No delta clear to send
Return to Top
Alternate Async Communications Errors:
Code
Description
1201 16450/16550 chip error
1202 Card selected feedback error
1203 Port 02h register test failure
1206 Serial option cannot be put to sleep
1207 Cable error
1208 Interrupt request (IRQ) 3 error
1209 Interrupt request (IRQ) 4 error
1210 16450/16550 chip register failure
1211
1212
1213 16450/16550 chip transmit error
Internal wrap test of 16450/16550 chip modem control line
failure
External wrap test of 16450/16550 chip modem control line
failure
1214 16450/16550 chip receive error
1215 16450/16550 chip receive error; data not equal to transmit data
1216 16450/16550 chip interrupt function error
1217 16450/16550 chip baud rate test failure
1218 16450/16550 chip receive external data wrap test failure
1219 16550 chip first-in/first-out (FIFO) buffer failure
1220 Interrupt enable register error; all bits cannot be set
1221 Interrupt enable register error; all bits cannot be reset
1222 Interrupt pending; stuck on
1223 Interrupt ID register; stuck on
1224 Modem cannot register error; all bits cannot be set
1225 Modem cannot register error; all bits cannot be reset
1226 Modem status register error; all bits cannot be set
1227 Modem status register error; all bits cannot be reset
1228 Interrupt ID error
1229 Cannot force overrun error
1230 No modem status interrupt
1231 Invalid interrupt pending
1232 No data ready
1233 No data available interrupt
1234 No transmit holding interrupt
1235 No interrupts
1236 No received line status interrupt
1237 No receive data available
1238 Transmit holding register not empty
1239 No modem status interrupt
1240 Transmit holding register not empty
1241 No interrupts
1242 No interrupt 4
1243 No interrupt 3
1244 No data transferred
1245 Maximum baud rate error
1246 Minimum baud rate error
1248 Time out error
1249 Invalid data returned
1250 Modem status register error
1251 No data set ready and delta data set ready
1252 No data set ready
1253 No delta data set ready
1254 Modem status register not clear
1255 No clear to send and delta clear to send
1256 No clear to send
1257 No delta clear to send
Return to Top
Game Control Adapter Errors:
Code
Description
1301 Game control adapter test failure
1302 Joystick test failure
Return to Top
Matrix Printer Errors:
Code
Description
1401 Printer test failure
1402 Printer not ready, not on line, or out of paper
1403 Printer no paper error
1404 Matrix printer test failure; system board time out
1405 Parallel adapter failure
1406 Printer presence test failed
Return to Top
Synchronous Data Link Control Communications (SDLC) Adapter
Errors:
Code
Description
1501 SDLC adapter test failure
1510 8255 port B failure
1511 8255 port A failure
1512 8255 port C failure
1513 8253 timer #1 did not reach terminal count
1514 8253 timer #1 stuck on
1515 8253 timer #0 did not reach terminal count
1516 8253 timer #0 stuck on
1517 8253 timer #2 did not reach terminal count
1518 8253 timer #2 stuck on
1519 8273 port B error
1520 8273 port A error
1521 8273 command/read time out
1522 Interrupt level 4 failure
1523 Ring indicate stuck on
1524 Receive clock stuck on
1525 Transmit clock stuck on
1526 Test indicate stuck on
1527 Ring indicate stuck on
1528 Receive clock stuck on
1529 Transmit clock stuck on
1530 Test indicate not on
1531 Data set ready not on
1532 Carrier detect not on
1533 Clear to send not on
1534 Data set ready stuck on
1535 Carrier detect stuck on
1536 Clear to send stuck on
1537 Interrupt level 3 failure
1538 Receive interrupt results error
1539 Wrap data compare error
1540 Direct memory access channel 1 error
1541 Direct memory access channel 1 error
1542 8273 error checking or status reporting error
1547 Stray interrupt level 4
1548 Stray interrupt level 3
1549 Interrupt presentation sequence time out
Return to Top
Display Station Emulation Adapter (DSEA) Errors:
Code
Description
1604 DSEA or twinaxial network error
1608 DSEA or twinaxial network error
1624 DSEA error
1634 DSEA error
1644 DSEA error
1652 DSEA error
1654 DSEA error
1658 DSEA error
1662 DSEA interrupt level error
1664 DSEA error
1668 DSEA interrupt level error
1669 DSEA diagnostics error; use 3.0 or higher
1674
1684 DSEA device address error
1688 DSEA device address error
Return to Top
Hard Drive and Controller Errors:
Code
1701 Fixed disk or adapter general error
1702 Drive and controller time out error
1703 Drive seek error
1704 Drive controller failed
1705 Drive sector not found error
1706 Write fault error
1707 Drive track 00 error
DSEA diagnostics error; use 3.0 or higher; DSEA station
address error
Description
1708 Head select error
1709 Bad ECC returned
1710 Sector buffer overrun
1711 Bad address mark
1712 Internal controller diagnostics failure
1713 Data compare error
1714 Drive not ready
1715 Track 00 indicator error
1716 Diagnostics cylinder errors
1717 Surface read errors
1718 Hard drive error
1720 Bad diagnostics cylinder
1726 Data compare error
1730 Drive controller error
1731 Drive controller error
1732 Drive controller error
1733 BIOS undefined error return
1735 Bad command error
1736 Data corrected error
1737 Bad drive track error
1738 Bad sector error
1739 Bad initialization error
1740 Bad sense error
1750 Drive verify error
1751 Drive read error
1752 Drive write error
1753 Drive random read test failure
1754 Drive seek test failure
1755 Drive controller failure
1756 Controller ECC test failure
1757 Controller head select failure
1780 Drive seek failure (drive 0)
1781 Drive seek failure (drive 1)
1782 Hard disk controller failure
1790 Diagnostic cylinder read error (drive 0)
1791 Diagnostic cylinder read error (drive 1)
Return to Top
I/O Expansion Unit Errors:
Code
Description
1801 Expansion unit POST error
1810 Enable/Disable failure
1811 Extender card wrap test failure while disabled
1812 High order address lines failure while disabled
1813 Wait state failure while disabled
1814 Enable/disable could not be set on
1815 Wait state failure while enabled
1816 Extender card wrap test failure while enabled
1817 High order address lines failure while enabled
1818 Disable not functioning
1819 Wait request switch not set correctly
1820 Receiver card wrap test failed
1821 Receiver high order address lines failure
Return to Top
Binary Synchronous Communications (BSC) Adapter Errors:
Code
Description
2001 BSC adapter test failure
2010 8255 port A failure
2011 8255 port B failure
2012 8255 port C failure
2013 8253 timer #1 did not reach terminal count
2014 8253 timer #1 stuck on
2015 8253 timer #2 did not reach terminal count
2016 8253 timer #2 stuck on
2017 8251 data set ready failed to come on
2018 8251 clear to send not sensed
2019 8251 data set ready stuck on
2020 8151 clear to send stuck on
2021 8151 hardware reset failure
2022 8251 software reset failure
2023 8251 software "error reset" failure
2024 8251 transmit ready did not come on
2025 8251 receive ready did not come on
2026 8251 could not force "overrun" error status
2027 Interrupt failure; no timer interrupt
2028 Interrupt failure; transmit; replace card or planar
2029 Interrupt failure; transmit; replace card
2030 Interrupt failure; receive; replace card or planar
2031 Interrupt failure; receive; replace card
2033 Ring indicate stuck on
2034 Receive clock stuck on
2035 transmit clock stuck on
2036 Test indicate stuck on
2037 Ring indicate stuck on
2038 Receive clock not on
2039 Transmit clock not on
2040 Test indicate not on
2041 Data set ready not on
2042 Carrier detect not on
2043 Clear to send not on
2044 Data set ready stuck on
2045 Carrier detect stuck on
2046 Clear to send stuck on
2047 Unexpected transmit interrupt
2048 Unexpected receive interrupt
2050 8251 detected overrun error
2051 Lost data set ready during data wrap
2052 Receive time out during data wrap
Return to Top
Alternate Binary Synchronous Communications (BSC) Adapter
Errors:
Code
Description
2101 BSC adapter test failure
2110 8255 port A failure
2111 8255 port B failure
2112 8255 port C failure
2113 8253 timer #1 did not reach terminal count
2114 8253 timer #1 stuck on
2115 8253 timer #2 did not reach terminal count
2116 8253 timer #2 stuck on
2117 8251 data set ready failed to come on
2118 8251 clear to send not sensed
2119 8251 data set ready stuck on
2120 8151 clear to send stuck on
2121 8151 hardware reset failure
2122 8251 software reset failure
2123 8251 software "error reset" failure
2124 8251 transmit ready did not come on
2125 8251 receive ready did not come on
2126 8251 could not force "overrun" error status
2127 Interrupt failure; no timer interrupt
2128 Interrupt failure; transmit; replace card or planar
2129 Interrupt failure; transmit; replace card
2130 Interrupt failure; receive; replace card or planar
2131 Interrupt failure; receive; replace card
2133 Ring indicate stuck on
2134 Receive clock stuck on
2135 transmit clock stuck on
2136 Test indicate stuck on
2137 Ring indicate stuck on
2138 Receive clock not on
2139 Transmit clock not on
2140 Test indicate not on
2141 Data set ready not on
2142 Carrier detect not on
2143 Clear to send not on
2144 Data set ready stuck on
2145 Carrier detect stuck on
2146 Clear to send stuck on
2147 Unexpected transmit interrupt
2148 Unexpected receive interrupt
2150 8251 detected overrun error
2151 Lost data set ready during data wrap
2152 Receive time out during data wrap
Return to Top
Cluster Adapter Errors:
Code
Description
22xx
Return to Top
Plasma Monitor Adapter Errors:
Code
23xx
Return to Top
Enhanced Graphics Adapter or Video Graphics Adapter Errors:
Code
2401 Video adapter test failure
A cluster adapter error has occurred - replace the cluster
adapter
Description
A plasma adapter display error has occurred - replace the
plasma display monitor assembly
Description
2402 Video display error
2408 User indicated display attribute test failed
2409 Video display error
2410 Video adapter error; video port error
2416 User indicated character set test failed
2424 User indicated 80 x 25 mode failure
2432 User indicated 40 x 25 mode failure
2440 User indicated mode 320 x 200 mode failure
2448 User indicated 640 x 200 mode failure
2456 User indicated light pen test failure
2464 User indicated paging test failure
Return to Top
Alternate Enhanced Graphics Adapter Errors:
Code
Description
2501 Video adapter test failure
2502 Video display error
2508 User indicated display attribute test failed
2509 Video display error
2510 Video adapter error; video port error
2516 User indicated character set test failed
2524 User indicated 80 x 25 mode failure
2532 User indicated 40 x 25 mode failure
2540 User indicated mode 320 x 200 mode failure
2548 User indicated 640 x 200 mode failure
2556 User indicated light pen test failure
2564 User indicated paging test failure
Return to Top
XT or AT/370 370-M (Memory) and 370-P (Processor) Adapter
Errors:
Code
Description
2601 370-M adapter error
2655 370-M adapter error
2657 370-M adapter error
2668 370-M adapter error
2672 370-M adapter error
2673 370-P adapter error
2674 370-P adapter error
2677 370-P adapter error
2680 370-P adapter error
2681 370-M adapter error
2682 370-P adapter error
2694 370-P adapter error
2697 370-P adapter error
2698 XT or AT/370 diagnostic diskette error
Return to Top
XT or AT/370 3277-EM (Emulation) Adapter Error:
Code
2701 3277-EM adapter error
2702 3277-EM adapter error
2703 3277-EM adapter error
Return to Top
3728/3729 Emulation Adapter or 3270 Connection Adapter Errors:
Code
Description
28xx An emulation adapter fault has occurred - replace the adapter
Return to Top
Color/Graphics Printer Errors:
Description
Code
Description
29xx
Return to Top
Primary PC Network Adapter Errors:
Code
3001 Network adapter test failure
3002 ROM checksum test failure
3003 Unit ID PROM test failure
3004 RAM test failure
3005 Host interface controller 9HIC) test failure
3006 +/- 12Vdc test failure
3007 Digital loopback test failure
3008 Host detected HIC failure
A general fault has been detected with the printer or it's printer
port - replace the adapter
Description
3009 Sync signal failure and no go bit
3010 HIC test OK and no go bit
3011 Go bit OK, but no command 41
3012 Card not present
3013 Digital failure fall through
3015 Analog failure
3041 Hot carrier on other card
3042 Hot carrier on this card
Return to Top
Secondary PC Network Adapter Errors:
Code
Description
3101 Network adapter test failure
3102 ROM checksum test failure
3103 Unit ID PROM test failure
3104 RAM test failure
3105 Host interface controller 9HIC) test failure
3106 +/- 12Vdc test failure
3107 Digital loopback test failure
3108 Host detected HIC failure
3109 Sync signal failure and no go bit
3110 HIC test OK and no go bit
3111 Go bit OK, but no command 41
3112 Card not present
3113 Digital failure fall through
3115 Analog failure
3141 Hot carrier on other card
3142 Hot carrier on this card
Return to Top
3270 PC/AT Display Errors:
Code
Description
32xx
A fault has been detected in the display system - replace the
display system
Return to Top
Compact Printer Errors:
Code Description
33xx
Return to Top
Enhanced Display Station Emulation Adapter (EDSEA) Errors:
Code
3504 Adapter connected to twinaxial cable during offline test
3508 Workstation address error
3509 Diagnostic program failure
3540 Workstation address invalid
3588 Adapter address switch error
3599 Diagnostic program failure
Return to Top
A fault has been detected in the printer or printer adapter replace the printer or printer adapter
Description
General Purpose Interface Bus (GPIB) Adapter Errors:
Code
Description
3601 Adapter test failure
3602 Serial poll mode register write error
3603 Adapter address error
3610 Adapter listen error
3611 Adapter talk error
3612 Adapter control error
3613 Adapter standby error
3614 Adapter asynchronous control error
3615 Adapter asynchronous control error
3616 Adapter error; cannot pass control
3617 Adapter error; cannot address to listen
3618 Adapter error; cannot unaddress to listen
3619 Adapter error; cannot address to talk
3620 Adapter error; cannot unaddress to talk
3621
3622
3623 Adapter error; cannot address to talk with extended addressing
Adapter error; cannot address to listen with extended
addressing
Adapter error; cannot unaddress to listen with extended
addressing
3624
Adapter error; cannot unaddress to talk with extended
addressing
3625 Write to self error
3626 Generate handshake error
3627 Cannot detect Device Clear message error
3628 Cannot detect Selected Device Clear message error
3629 Cannot detect end with end of identify
3630 Cannot detect end of transmission with end of identify
3631 Cannot detect end with 0 bot end of string
3632 Cannot detect end with 7 bit end of string
3633 Cannot detect group execute trigger
3634 Mode 3 addressing error
3635 Cannot recognize undefined command
3636
Cannot detect remote, remote changed, lockout, or lockout
changed
3639 Cannot conduct serial poll
3640 Cannot conduct parallel poll
3650 Adapter error; direct memory access (DMA) to 7210
3651 Data error; error on direct memory access (DMA) to 7210
3652 Adapter error; direct memory access (DMA) from 7210
3653 Data error on direct memory access (DMA) from 7210
3658 Uninvoked interrupt received
3659 Cannot interrupt on address status changed
3660 Cannot interrupt on address status changed
3661 Cannot interrupt on command output
3662 Cannot interrupt on data out
3663 Cannot interrupt on data in
3664 Cannot interrupt on error
3665 Cannot interrupt on device clear
3666 Cannot interrupt on end
3667 Cannot interrupt on device execute trigger
3668 Cannot interrupt on address pass through
3669 Cannot interrupt on command pass through
3670 Cannot interrupt on remote changed
3671 Cannot interrupt on lockout changed
3672 Cannot interrupt on service request in
3673
3674
Cannot interrupt on terminal count on direct memory access to
7210
Cannot interrupt on terminal count on direct memory access
from 7210
3675 Spurious direct memory access terminal count interrupt
3697 Illegal direct memory access configuration setting detected
3698 Illegal interrupt level setting detected
Return to Top
System Board SCSI Controller Errors:
Code
Description
37xx
Return to Top
Data Acquisition Adapter Errors:
Code
3801 Adapter test failure
3810 Timer read test failure
3811 Timer interrupt test failure
3812 Binary input 13 test failure
3813 Binary input 13 test failure
3814 Binary output 14 interrupt request test failure
3815 Binary output 0 count in test failure
3816 Binary input strobe (STB) count out test failure
3817 Binary output 0 clear to send (CTS) test failure
the system board SCSI controller has failed - replace the
motherboard
Description
3818 Binary output 1, binary input 0 test failure
3819 Binary output 2, binary input 1 test failure
3820 Binary output 3, binary input 2 test failure
3821 Binary output 4, binary input 3 test failure
3822 Binary output 5, binary input 4 test failure
3823 Binary output 6, binary input 5 test failure
3824 Binary output 7, binary input 6 test failure
3825 Binary output 8, binary input 7 test failure
3826 Binary output 9, binary input 8 test failure
3827 Binary output 10, binary input 9 test failure
3828 Binary output 11, binary input 10 test failure
3829 Binary output 12, binary input 11 test failure
3830 Binary output 13, binary input 12 test failure
3831 Binary output 15, analog input CE test failure
3832 Binary output strobe, binary output GATE test failure
3833 Binary input clear to send, binary output HOLD test failure
3834
3835 Counter interrupt test failure
3836 Counter read test failure
3837 Analog output 0 ranges test failure
3838 Analog output 1 ranges test failure
3839 Analog input 0 values test failure
3840 Analog input 1 values test failure
3841 Analog input 2 values test failure
3842 Analog input 3 values test failure
3843 Analog input interrupt test failure
3844 Analog input 23 address or value test failure
Return to Top
Professional Graphics Adapter (PGA) Errors:
Analog input command output (CO), binary input 15 test
failure
Code
Description
3901 PGA test failed
3902 ROM 1 self test failed
3903 ROM 2 self test failed
3904 RAM self test failed
3905 Cold start cycle power error
3906 Data error in communications RAM
3907 Address error in communications RAM
3908 Bad data reading/writing 6845 like register
3909 Bad data in lower E0h bytes reading/writing 6845 like registers
3910 Graphics controller display bank output latches error
3911 Basic clock error
3912 Command control error
3913 Vertical sync scanner error
3914 Horizontal sync scanner error
3915 Intech error
3916 Look up table address error
3917 Look up table red RAM chip error
3918 Look up table green RAM chip error
3919 Look up table blue RAM chip error
3920 Look up table data latch error
3921 Horizontal display error
3922 Vertical display error
3923 Light pen error
3924 Unexpected error
3925 Emulator addressing error
3926 Emulator data latch error
3927 Base for error codes 3928-3930
3928 Emulator RAM error
3929 Emulator RAM error
3930 Emulator RAM error
3931 Emulator horizontal/vertical display problem
3932 Emulator cursor position error
3933 Emulator attribute display problem
3934 Emulator cursor display error
3935 Fundamental emulation RAM problem
3936 Emulation character set problem
3937 Emulation graphics display error
3938 Emulation character display problem
3939 Emulation bank select error
3940 Adapter RAM U2 error
3941 Adapter RAM U4 error
3942 Adapter RAM U6 error
3943 Adapter RAM U8 error
3944 Adapter RAM U10 error
3945 Adapter RAM U1 error
3946 Adapter RAM U3 error
3947 Adapter RAM U5 error
3948 Adapter RAM U7 error
3949 Adapter RAM U9 error
3950 Adapter RAM U12 error
3951 Adapter RAM U14 error
3952 Adapter RAM U16 error
3953 Adapter RAM U18 error
3954 Adapter RAM U20 error
3955 Adapter RAM U11 error
3956 Adapter RAM U13 error
3957 Adapter RAM U15 error
3958 Adapter RAM U17 error
3959 Adapter RAM U19 error
3960 Adapter RAM U22 error
3961 Adapter RAM U24 error
3962 Adapter RAM U26 error
3963 Adapter RAM U28 error
3964 Adapter RAM U30 error
3965 Adapter RAM U21 error
3966 Adapter RAM U23 error
3967 Adapter RAM U25 error
3968 Adapter RAM U27 error
3969 Adapter RAM U29 error
3970 Adapter RAM U32 error
3971 Adapter RAM U34 error
3972 Adapter RAM U36 error
3973 Adapter RAM U38 error
3974 Adapter RAM U40 error
3975 Adapter RAM U31 error
3976 Adapter RAM U33 error
3977 Adapter RAM U35 error
3978 Adapter RAM U37 error
3979 Adapter RAM U39 error
3980 Graphics controller RAM timing error
3981 Graphics controller read/write latch error
3982 Shift register bus output latches error
3983 Addressing error (vertical column of memory; U2 at top)
3984 Addressing error (vertical column of memory; U4 at top)
3985 Addressing error (vertical column of memory; U6 at top)
3986 Addressing error (vertical column of memory; U6 at top)
3987 Addressing error (vertical column of memory; U8 at top)
3988 Addressing error (vertical column of memory; U10 at top)
3989 Horizontal bank latch errors
3990 Horizontal bank latch errors
3991 Horizontal bank latch errors
3992 RAG/CAG graphics controller error
3993 Multiple write modes; nibble mask errors
3994 Row nibble (display RAM) error
3995 Graphics controller addressing error
Return to Top
Display Attachment Unit and 5279 Display Errors:
Code
Description
44xx
Return to Top
A fault has occurred with the display system - replace the
display system
IEEE 488 (GPIB) Interface Adapter Errors:
Code
Description
45xx A fault has occurred with the GPIB - replace the adapter
Return to Top
ARTIC Multiport/2 Interface Adapter Errors:
Code
Description
4611 ARTIC adapter error
4612/4613 Memory module error
4630 ARTIC adapter error
4640/4641 Memory module error
4650 ARTIC interface cable error
Return to Top
Internal Modem Errors:
Code
Description
48xx The internal modem has failed - replace the modem
Return to Top
Alternate Internal Modem Errors:
Code
Description
49xx
Return to Top
PC Convertible LCD Errors:
The alternate internal modem has failed - replace the alternate
internal modem
Code
5001 LCD buffer failure
5002 LCD font buffer failure
5003 LCD controller failure
Description
5004 User indicated PEL/drive test failure
5008 User indicated display attribute test failed
5016 User indicated character set test failed
5020 User indicated alternate character set test failure
5024 User indicated 80 x 25 mode test failure
5032 User indicated 40 x 25 mode test failure
5040 User indicated 320 x 200 graphics test failure
5048 User indicated 640 x 200 graphics test failure
5064 User indicated paging test failure
Return to Top
PC Convertible Portable Printer Errors:
Code
Description
5101 Portable printer interface failure
5102 Portable printer busy error
5103 Portable printer paper or ribbon error
5104 Portable printer time out
5105 User indicated print pattern test error
Return to Top
Financial Communication System Errors:
Code
Description
56xx
Return to Top
Phoenix BIOS/Chipset Specific Errors:
Code
A fault has been detected in the financial communication
system - replace the financial communication system
Description
7000 Chipset CMOS failure
7001 Shadow RAM failure (ROM not shadowed to RAM)
7002 Chipset CMOS configuration data error
Return to Top
Voice Communications Adapter (VCA) Errors:
Code
Description
7101 Adapter test failure
7102 Instruction or external data memory error
7103 PC to VCA interrupt error
7104 Internal data memory error
7105 DMA error
7106 Internal registers error
7107 Interactive shared memory error
7108 VCA to PC interrupt error
7109 DC wrap error
7111 External analog wrap and tone output error
7114 Telephone attachment test failure
Return to Top
3 1/2" Floppy Disk Drive Errors:
Code
Description
7301 Diskette drive/adapter test failure
7306 Diskette change line error
7307 Write protected diskette
7308 drive command error
7310 Diskette initialization failure track 00 error
7311 Drive time out error
7312 NEC drive controller IC error
7313 DMA error
7314 DMA boundary overrun error
7315 Drive index timing error
7316 Drive speed error
7321 Drive seek error
7322 Drive CRC check error
7323 Sector not found error
7324 Address mark error
7325 NEC controller IC seek error
Return to Top
8514/A Display Adapter Errors:
Code Description
7426 8514 display error
7440 8514/A memory module 31 error
7441 8514/A memory module 30 error
7442 8514/A memory module 29 error
7443 8514/A memory module 28 error
7444 8514/A memory module 22 error
7445 8514/A memory module 21 error
7446 8514/A memory module 18 error
7447 8514/A memory module 17 error
7448 8514/A memory module 32 error
7449 8514/A memory module 14 error
7450 8514/A memory module 13 error
7451 8514/A memory module 12 error
7452 8514/A memory module 06 error
7453 8514/A memory module 05 error
7454 8514/A memory module 02 error
7455 8514/A memory module 01 error
7460 8514/A memory module 16 error
7461 8514/A memory module 27 error
7462 8514/A memory module 26 error
7463 8514/A memory module 25 error
7464 8514/A memory module 24 error
7465 8514/A memory module 23 error
7466 8514/A memory module 20 error
7467 8514/A memory module 19 error
7468 8514/A memory module 15 error
7469 8514/A memory module 11 error
7470 8514/A memory module 10 error
7471 8514/A memory module 09 error
7472 8514/A memory module 08 error
7473 8514/A memory module 07 error
7474 8514/A memory module 04 error
7475 8514/A memory module 03 error
Return to Top
4216 Page Printer Adapter Errors:
Code
Description
7601 Adapter test failure
7602 Adapter card error
7603 Printer error
7604 Printer cable error
Return to Top
PCMCIA Adapter Errors:
Code Description
8081
Presence test failure (PCMCIA revision number also
checksum)
8082 PCMCIA register test failure
Return to Top
PS/2 Speech Adapter Errors:
Code
Description
84xx
A fault has occurred with the speech adapter - replace the
speech adapter
Return to Top
2MB XMA Memory Adapter Errors:
Code
Description
85xx
A fault has occurred with the memory module - replace the
memory module
Return to Top
PS/2 Pointing Device Errors:
Code
Description
8601 Pointing device: mouse time out error
8602 Pointing device: mouse interface error
8603 System board: mouse interrupt error
8604 Pointing device or system board error
8611 System bus error
8612 TrackPoint II error
8613 System bus or TrackPoint II error
Return to Top
MIDI Interface Errors:
Code
Description
89xx
Return to Top
3363 Worm Optical Drive/Adapter Errors:
Code
91xx
Return to Top
SCSI Adapter (W/32 bit Cache):
Code
96xx
A fault has occurred with the MIDI adapter - replace the MIDI
adapter
Description
A fault has occurred in the drive or adapter - replace the
adapter or the drive
Description
A fault has occurred with the SCSI adapter - replace the SCSI
adapter
Return to Top
Multiprotocol Adapter Errors:
Code
Description
10001 Presence test failure
10002 Card selected feedback error
10003 Port 102h register test failure
10004 Port 103h register test failure
10006 Serial option cannot be disabled
10007 Cable error
10008 IRQ 3 error
10009 IRQ 4 error
10010 UART register failure
10011 Internal wrap test of UART control line failed
10012 External wrap test of UART control line failed
10013 UART transmit error
10014 UART receive error
10015 UART receive error - data not equal to transmit data
10016 UART interrupt error
10017 UART baud rate test failure
10018 UART receive external wrap test failure
10019 UART FIFO buffer failure
10026 8255 port A error
10027 8255 port B error
10028 8255 port C error
10029 8254 timer 0 error
10030 8254 timer 1 error
10031 8254 timer 2 error
10032 Bi-sync data set ready (DSR) response error
10033 Bi-sync clear to send(CTS) error
10034 8251 hardware reset test failed
10035 8251 function generator
10036 8251 status error
10037 Bi-sync timer interrupt error
10038 Bi-sync transmit interrupt error
10039 Bi-sync receive interrupt error
10040 Stray IRQ 3 error
10041 Stray IRQ 4 error
10042 Bi-sync external wrap error
10044 Bi-sync data wrap error
10045 Bi-sync line status error
10046 Bi-sync time out error during wrap test
10050 8273 command acceptance or time out error
10051 8273 port A error
10052 8273 port B error
10053 SDLC modem status logic error
10054 SDLC timer IRQ 4 error
10055 SDLC IRQ 4 error
10056 SDLC external wrap error
10057 SDLC interrupt results error
10058 SDLC data wrap error
10059 SDLC transmit interrupt error
10060 SDLC receive interrupt error
10061 DMA channel 1 transmit error
10062 DMA channel 1 receive error
10063 8273 status detect failure
10064 8273 error detect failure
Return to Top
Internal 300/1200Bps Modem Errors:
Code
Description
10101 Presence detect failure
10102 Card selected feedback error
10103 Port 102h register test error
10106 Serial option cannot be disabled
10108 IRQ 3 error
10109 IRQ 4 error
10110 UART chip register failure
10111 UART control line internal wrap test failure
10113 UART transmit error
10114 UART receive error
10115 UART error - transmit and receive data not equal
10116 UART interrupt function error
10117 UART baud rate test failure
10118 UART interrupt driven receive external data wrap test failure
10125 Modem reset result code error
10126 Modem general result code error
10127 Modem S registers read/write error
10128 Modem echo on/off error
10129 Modem enable/disable result codes error
10130 Modem enable number/word result codes error
10133 Connect results for 300 baud not received
10134 Connect results for 1200 baud not received
10135 Modem fails local analog loopback 300 baud test
10136 Modem fails local analog loopback 1200 baud test
10137 Modem does not respond to escape/reset sequence
10138 S register 13 shows incorrect parity or number of data bits
10139 S register 15 shows incorrect bit rate
Return to Top
ESDI or MCA IDE Fixed Disk or Adapter Errors:
Code
Description
10450 Read/write test failed
10451 read verify test failed
10452 Seek test failed
10453 Wrong drive type indicated
10454 Controller sector buffer test failure
10455 Controller invalid failure
10456 Controller diagnostic command failure
10461 Drive format error
10462 Controller head select error
10463 Drive read/write sector error
10464 Drive primary detect map unreadable
10465 Controller: error-correction code (ECC) 8 bit error
10466 Controller: error correction code (ECC) 9 bit error
10467 Drive soft seek error
10468 Drive head seek error
10469 Drive soft error count exceeded
10470 Controller attachment diagnostic error
10471 Controller wrap mode interface error
10472 Controller wrap mode drive select error
10473 Read verify test errors
10480 Seek failure: drive 0
10481 Seek failure: drive 1
10482 Controller transfer acknowledge error
10483 Controller reset failure
10484 Controller: head select 3 error
10485 Controller: head select 2 error
10486 Controller: head select 1 error
10487 Controller: head select 0 error
10488 Controller: read gate - command complete 2 error
10489 Controller: write gate - command complete 1 error
10490 Diagnostic area read error: drive 0
10491 Diagnostic area read error: drive 1
10492 Controller error, drive 1
10493 Reset error, drive 1
10499 Controller failure
Return to Top
5 1/4 External Disk Drive or Adapter Errors:
Code
Description
107xx
Return to Top
SCSI Adapter (16 bit without Cache) Errors:
Code
A fault has occurred with the external disk drive or adapter replace the disk drive or adapter
Description
112xx
Return to Top
System Board SCSI Adapter Errors:
Code
113xx
Return to Top
Processor Complex Errors:
Code
129005 DMA error
A fault has occurred with the SCSI adapter - replace the SCSI
adapter
Description
A fault has occurred with the system board SCSI adapter replace the motherboard
Description
12901 Processor board: processor test failure
12902 Processor board: cache test failure
12904 Second level cache failure
12905 Cache enable/disable errors
12907 Cache fatal error
12908 Cache POST program error
12912x Hardware failure
12913x Micro channel bus time out
12914x Software failure
12915x Processor complex error
12916x Processor complex error
12917x Processor complex error
12918x Processor complex error
12919x Processor complex error
12940x Processor complex failure
12950x Processor complex failure
129900 Processor complex serial number mismatch
Return to Top
P70/P75 Plasma Display and Adapter Errors:
Code
Description
14901 Plasma display adapter failure
14902 Plasma display adapter failure
14922 Plasma display failure
14932 External display device failure
Return to Top
XGA Display Adapter Errors:
Code
Description
152xx
Return to Top
120MB Internal Tape Drive Errors:
Code
164xx
Return to Top
6157 Streaming Tape Drive Errors:
Code
A fault has occurred with the XGA display adapter - replace
the display adapter
A fault has occurred with the internal tape drive - replace the
tape drive
Description
Description
16520 Streaming tape drive failure
16540 Tape attachment adapter failure
Return to Top
Primary Token Ring Network Adapter Errors:
Code Description
166xx
Return to Top
Alternate Token Ring Network Adapter Errors:
Code
167xx
Return to Top
PS/2 Wizard Adapter Errors:
Code
18001 Interrupt controller failure
A fault has occurred with the network adapter - replace the
network adapter
Description
A fault has occurred with the network adapter - replace the
network adapter
Description
18002 Incorrect timer count
18003 Timer interrupt failure
18004 Sync check interrupt failure
18005 Parity check interrupt failure
18006 Access error interrupt failure
18012 Bad checksum error
18013 Micro Channel interface error
18021 Wizard memory compare or parity error
18022 Wizard memory address line error
18023 Dynamic RAM controller error
18029 Wizard memory byte enable error
18031
18032 Wizard memory expansion module byte enable error
19039 Wizard memory expansion module byte enable error
Return to Top
Wizard memory expansion module memory compare or parity
error
DBCS Japanese Display Adapter Errors:
Code
Description
185xx
A fault has occurred with the display adapter - replace the
display adapter
Return to Top
80286 Memory Expansion Option Module Errors:
Code
Description
194xx
Return to Top
Image Adapter Errors:
Code
200xx
Return to Top
Unknown SCSI Device Errors:
Code
208xx
A fault has occurred with the memory module - replace the
memory module
Description
A fault has occurred with the image adapter - replace the
image adapter
Description
A fault has occurred in an unknown SCSI adapter - replace the
unknown SCSI adapter
Return to Top
SCSI Removable Media Errors:
Code
Description
209xx
Return to Top
SCSI Fixed Disk Errors:
Code
210PLSC "PLSC" codes indicate errors
P = SCSI ID number (Physical Unit Number or PUN)
A fault has occurred in the SCSI removable disk - replace the
removable disk
Description
L = Logical unit number (LUN, usually 0)
S = Host adapter slot number
C = SCSI drive capacity
A = 60MB
B = 80MB
C = 120MB
D = 160MB
E = 320MB
F = 400MB
H = 1.02MB (1GB)
I = 104MB
J = 212MB
U = Undetermined or non IBM OEM drive
Return to Top
SCSI Tape Drive Errors:
Code
Description
211xx
Return to Top
SCSI Printer Errors:
Code
212xx
Return to Top
SCSI Processor Errors:
Code
A fault has occurred with the SCSI tape drive - replace the
SCSI tape drive
Description
A fault has occurred with the SCSI printer - replace the SCSI
printer
Description
213xx
Return to Top
SCSI Write Once Read Multiple (WORM) Drive Errors:
A fault has occurred with the SCSI adapter processor - replace
the SCSI adapter
Code Description
214xx
Return to Top
SCSI CD-ROM Drive Errors:
Code
215xx
Return to Top
SCSI Scanner Errors:
Code
216xx
A fault has occurred with the SCSI WORM drive - replace the
SCSI WORM drive
A fault has occurred with the SCSI CD-ROM drive - replace
the SCSI CD-ROM drive
Description
A fault has occurred with the SCSI Scanner - replace the SCSI
Scanner
Description
Return to Top
SCSI Magneto Optical Drive Errors:
Code
Description
217xx
Return to Top
SCSI Jukebox Changer Errors:
Code
218xx
Return to Top
A fault has occurred with the SCSI Magneto Optical Drive replace the drive
Description
A fault has occurred with the SCSI Jukebox Changer - replace
the device
SCSI Communications Errors:
Code Description
219xx
Return to Top
XGA-2 Adapter Errors:
Code
243xxxx
Return to Top
Dynamic Configuration Select (DCS) Information Codes:
Code
I998001x Bad integrity of DCS master boot record
A fault has occurred with the SCSI Communications device replace the device
Description
A fault has occurred with the XGA-2 adapter - replace the
adapter
Description
I988002x Read failure of DCS master boot record
I988003x DCS master boot record is not compatible with the planar ID
I988004x
I988005x Bad integrity of CMOS/NVRAM or internal process error
I988006x Read failure of header/mask/configuration record
I988007x Bad integrity of header/mask/configuration record
I988008x
I988009x DCS master boot record is older than system ROM
I9880402
I9880403
Return to Top
DCS master boot record is not compatible with the model/
submodel byte
Hard disk does not support the command to set the maximum
RBA
Copyright notice in E000 segment does not match the one in
DCS MBR
DCS MBR is not compatible with the system board ID or
model/submodel byte
Initial Microcode Load (IML) Errors:
Code
Description
I999001x Invalid disk IML error
I999002x Disk IML record load error
I999003x Disk IML record incompatible with system board
I999004x Disk IML record incompatible with processor/processor card
I999005x Disk IML not attempted
I999006x Disk stage II system image load error
I999007x Disk stage II image checksum error
I999008x IML not supported on primary disk drive
I999009x Disk IML record is older than ROM
I99900x1 Invalid diskette IML record
I99900x2 Diskette IML record load error
I99900x3 Diskette IML record incompatible with system board
I99900x4 Diskette IML record incompatible with processor board
I99900x5
I99900x6 Diskette stage II image load error
I99900x7 Diskette stage II image checksum error
I99900x9 Diskette IML record older then ROM
Return to Top
No Bootable Device, Initial Program Load (IPL) Errors:
Code
I9990301 Hard disk error
I9990302
I9990303 IML system partition boot failure
I9990304 No bootable device with ASCII console
I9990305 No bootable device
Diskette IML recovery prevented (valid password and CE
override not set)
Description
Invalid disk boot record, unable to read IPL boot record from
disk
I9990306 Invalid SCSI Device boot record
I9990401
I9990402 Missing ROM IBM copyright notice
I9990403
Return to Top
Unauthorized access (manufacturing boot request with valid
password)
IML Boot record incompatible with system board/processor
card
Loading...
