IBM p Series User Manual

IBM ~ pSeries
High Performance Switch
Tuning and Debug Guide
April 2005
IBM Systems and Technology Group
Cluster Performance Department
Poughkeepsie, NY
Contents
1.0 Introduction.....................................................................................................4
2.0 Tunables and settings for switch software...................................................... 5
2.1 MPI tunables for Parallel Environment........................................................5
2.1.1 MP_EAGER_LIMIT..............................................................................5
2.1.2 MP_POLLING_INTERVAL and MP_RETRANSMIT_INTERVAL......... 5
2.1.3 MP_REXMIT_BUF_SIZE and MP_REXMIT_BUF_CNT......................6
2.1.4 MEMORY_AFFINITY...........................................................................6
2.1.5 MP_TASK_AFFINITY........................................................................... 7
2.1.6 MP_CSS_INTERRUPT........................................................................ 7
2.2 MPI-IO ........................................................................................................ 7
2.3 chgsni command.........................................................................................8
3.0 Tunables and settings for AIX 5L ................................................................... 9
3.1 IP tunables.................................................................................................. 9
3.2 File cache ................................................................................................... 9
3.3 svmon and vmstat commands..................................................................10
3.3.1 svmon.................................................................................................11
3.3.2 vmstat.................................................................................................12
3.4 Large page sizing......................................................................................13
3.5 Large pages and IP support......................................................................15
3.6 Memory affinity for a single LPAR............................................................. 15
3.7 Amount of memory available....................................................................15
3.8 Debug settings in the AIX 5L kernel.......................................................... 16
4.0 Daemon configuration..................................................................................16
4.1 RSCT daemons........................................................................................16
4.2 LoadLeveler daemons..............................................................................17
4.2.1 Reducing the number of daemons running ........................................17
4.2.2 Reducing daemon communication and placing daemons on a switch17
4.2.3 Reducing logging................................................................................17
4.3 Settings for AIX 5L threads....................................................................... 18
4.4 AIX 5L mail, spool, and sync daemons..................................................... 18
4.5 Placement of POE managers and LoadLeveler scheduler.......................18
5.0 Debug settings and data collection tools......................................................19
5.1 lsattr tuning...............................................................................................19
5.1.1 driver_debug setting...........................................................................19
5.1.2 ip_trc_lvl setting..................................................................................19
5.2 CPUs and frequency................................................................................. 19
5.3 Affinity LPARs...........................................................................................20
5.4 Small Real Mode Address Region on HMC GUI....................................... 20
5.5 Deconfigured L3 cache............................................................................. 20
5.6 Service focal point.....................................................................................20
5.7 errpt command.......................................................................................... 21
5.8 HMC error logging.....................................................................................21
5.9 Multiple versions of MPI libraries..............................................................21
pshpstuningguidewp040105.doc Page 2
5.10 MP_PRINTENV......................................................................................22
5.11 MP_STATISTICS.................................................................................... 23
5.12 Dropped switch packets.......................................................................... 24
5.12.1 Packets dropped because of a software problem on an endpoint....24
5.12.2 Packets dropped in the ML0 interface.............................................. 26
5.12.3 Packets dropped because of a hardware problem on an endpoint...27
5.12.4 Packets dropped in the switch hardware.......................................... 28
5.13 MP_INFOLEVEL.....................................................................................28
5.14 LAPI_DEBUG_COMM_TIMEOUT.......................................................... 29
5.15 LAPI_DEBUG_PERF..............................................................................29
5.16 AIX 5L trace for daemon activity.............................................................30
6.0 Conclusions and summary........................................................................... 30
7.0 Additional reading.........................................................................................30
7.1 HPS documentation..................................................................................30
7.2 MPI documentation................................................................................... 31
7.3 AIX 5L performance guides...................................................................... 31
7.4 IBM Redbooks.......................................................................................... 31
7.5 POWER4.................................................................................................. 31
pshpstuningguidewp040105.doc Page 3
1.0 Introduction
This paper is intended to help you tune and debug the performance of the IBM pSeries® High Performance Switch (HPS) on IBM Cluster 1600 systems. It is not intended to be a comprehensive guide, but rather to help in initial tuning and debugging of performance issues. Additional detailed information on the materials presented here can be found in sources noted in the text and listed in section 7.0.
This paper assumes an understanding of MPI and AIX 5L™, and that you are familiar with and have access to the Hardware Management Console (HMC) for pSeries systems.
This paper is divided into four sections. The first deals with HPS-specific tunables for tuning the HPS subsystems. The second section deals with tuning AIX 5L and its components for optimal performance of the HPS system. The third section deals with tuning various system daemons in both AIX 5L and cluster environments to prevent impact on high-performance parallel applications. The final section deals with debugging performance problems on the HPS.
Before debugging a performance problem in the HPS, review the HPS and AIX 5L tuning as well as daemon controls. Many pr oblems are s p ecifically related to t hese su b systems. I f a performance problem persists after you follow the instructions in the debugging section, call IBM service for additional tools and help.
We want to thank the following people in the IBM Poughkeepsie development organization for their help in writing this paper:
Robert Blackmore George Chochi a Frank Johnston Bernard King-Smith John Lewars Steve M ar tin Fernando Pizzano Bill Tuel Richard Treumann
~
®
pshpstuningguidewp040105.doc Page 4
2.0 Tunables and settings for switch software
To optimiz e the HPS, you c an set s hell va riab les for Parallel En v i ronment MPI-based workloads and for IP-based workloads. This section reviews the shell variables that are most often used for performance tuning. For a complete list of tunables and their usage, see the documentation listed in section 7 of this paper.
2.1 MPI tunables for Parallel Environment
The following sections list the most common MPI tunables for applications that use the HPS. Along with each tunable is a description of the variable, what it is used for, and how to set it appropriately.
2.1.1 MP_EAGER_LIMIT
The MP_EAGER_LIMIT variable tells the MPI transport protocol to use the "eager" mode for messages less than or equal to the specified size. Under the "eager" mode, the sender sends the message without knowing if the matching receive has actually been posted by the destination task. For messages larger than the EAGER_LIMIT, a rendezvous must be used to confirm that the matching receive has been posted
The sending task does not have to wait for an okay from the receiver before sending the data, so the effective start-up cost for a small message is lower in “eager” mode. As a result, any messages that are smaller than the EAGER_LIMIT are typically faster, especially if the corresponding receive has already been posted. If the receive has not been posted, the transport incurs an extra copy cost on the target, because data is staged through the early-arrival buffers. However, the overall time to send a small message might still be less in "eager" mode. Well­designed MPI applications often try to post each MPI_RECV before the message is expected, but because tasks of a parallel job are not in lock step, most applications have occasional early arrivals.
The maximum message size for the “eager” protocol is currently 65536 bytes, although the default value is lower. An application for which a significant fraction of the MPI messages are less than 65536 bytes might see a performance benefit from setting MP_EAGER_LIMIT. If MP_EAGER_LIMIT is increased above the default value, it might also be necessary to increase MP_BUFF E R_MEM, which determines the amount of memory availab le for early arrival buffers. Higher “eager” limits or larger task counts either demand more buffer memory or reduce the number of unl imite d “eager” mes sages that can b e ou tstandi n g, and ther efor e can also impact performance.
2.1.2 MP_POLLING_INTERVAL and MP_RETRANSMIT_INTERVAL
The MP_POL LING_INTER VAL and MP_RETRANSMIT_INTERVAL va ria bles control h ow oft e n the protocol co de checks wheth er dat a that was pr e viously s ent is assumed to be lost and needs to be retransmitted. When the values are larger, this checking is done less often. There are two different environment variables because the check can be done by an MPI/LAPI service
pshpstuningguidewp040105.doc Page 5
thread, and from within the MPI/LAPI polling code that is invoked when the application makes blocking MPI calls.
MP_POLLING_INTERVAL specifies the number of microseconds an MPI/LAPI service thread should wait (sleep) before it checks whether any data previously sent by the MPI task needs to be retransmitted. MP_RETRANSMIT_INTERVAL specifies the number of passes through the internal MPI/LAPI polling routine between calls before checking whether any data needs to be resent. When the switch fabric, adapters, and nodes are operating properly, data that is sent arrives intact, and the receiver sends the source task an acknowledgment for the data. If the sending task does not receive such an acknowledgment within a reasonable amount of time (determined by the variable MP_RETRANSMIT_INTERVAL), it assumes the data has been lost and tries to resend it.
Sometimes w hen many MPI tasks s hare the s witch adapter s, swit ch fab ric, or both, t he time it takes to send a message and receive an acknowledgment is longer than the library expects. In this case, data might be retransmitted unnecessarily. Increasing the values of MP_POLLING_INTERVAL and MP_RETRANSMIT_INTERVAL decrease the likelihood of unnecessary retransmission but increase the time a job is delayed when a packet is actually dropped.
2.1.3 MP_REXMIT_BUF_SIZE and MP_REXMIT_BUF_CNT
You can improve application performance by allowing a task that is sending a message shorter than the “eager” limit to return the send buffer to the application before the message has reached its destination, rather than forcing the sending task to wait until the data has actually reached the receiving task and the acknowledgement has been returned. To allow immediate return of the send buffer to the application, LAPI attempts to make a copy of the data in case it must be retransmitted later (unlikely but not impossible). LAPI copies the data into a retransmit buffer (REXMIT_BUF) if one is available. The MP_REXMIT_BUF_SIZE and MP_REXMIT_B UF_CNT environment va riab les control the size and number of the retransmit buffers allocated by each task.
2.1.4 MEMORY_AFFINITY
The POWER4™ and POWER4+™ models of the pSeries 690 have more than one multi-chip modu le (MCM). An MCM c ontai ns eig ht CPUs and frequ entl y has t wo loca l memory cards. On these systems, applicat ion per formance can improve when ea ch CPU and the memory it accesses are on the same MCM.
Setting the AIX MEMORY_AFFINITY environment variable to MCM tells the operating system to attempt to allocate the memory from within the MCM containing the processor that made the request. If memory is a vailab le on the MCM c ontai ning th e C PU, the request is usually granted. If memory is n ot available o n t he loca l MCM, b ut is available on a re mote MCM, the memo ry is taken from the remote MCM. (Lack of local memory does not cause the job to fail.)
pshpstuningguidewp040105.doc Page 6
2.1.5 MP_TASK_AFFINITY
Setting MP_TASK_AFFINITY to SNI tells parallel operating environment (POE) to bind each task to the MCM containing the HPS adapter it will use, so that the adapter, CPU, and memory used by any task are all local to the same MCM. To prevent multiple tasks from sharing the same CPU, do not set MP_TASK_AFFINITY to SNI if more than four tasks share any HPS adapter. If more than four tasks share any HPS adapter, set MP_TASK_AFFINITY to MCM, whic h allows each M PI task to us e C PUs and memor y f rom the same MCM, e ven if the adapter is on a remote MCM. If MP_TASK_AFFINITY is set to either MCM or SNI, MEMORY_AFFINITY should be set to MCM.
2.1.6 MP_CSS_INTERRUPT
The MP_CSS_INTERRUPT variable allows you to control interrupts triggered by packet arrivals. Setting this variable to no implies that the application should run in polling mode. This setting is appropriate for applications that have mostly synchronous communication. Even applications that make heavy use of MPI_ISEND/MPI_IRECV should be considered synchronous unless there is significant computation between the ISEND/IRECV postings and the MPI_WAITALL. The default value for MP_CSS_INTERRUPT is no.
For applications with an asynchronous communication pattern (one that uses non-blocking MPI calls), it might be more appropriate to set this variable to yes. Setting MP_CSS_INTERRUPT to yes can cause your application to be interrupted when new packets arrive, which could be helpful if a receiving MPI tas k is likely to be in t he midd le of a long numerica l comput ation at the time when data from a remote-blocking send arrives.
2.2 MPI-IO
The most effectiv e us e of MP I-IO is wh en an a p plicat i o n takes advantage of fil e views an d collective operations to read or write a file in which data for each task is dispersed across the file. To simplify we focus on read, but write is similar.
An example is reading a matrix with application-wide scope from a single file, with each task needing a different fragment of that matrix. To bring in the fragment needed for each task, several disjoint chunks must be read. If every task were to do POSIX read of each chunk, the GPFS file system handle it correctly. However, because each read() is independent, there is little chance to apply an effective strategy.
When the same set of reads is done with collective MPI-IO, every task specifies all the chunks it needs to one MPI-IO call. Because the call is co l l ect i v e, t h e requirements of a ll th e ta s ks are known at one time. As a result, MPI can use a broad strategy for doing the I/O.
When MPI-IO is us ed but eac h call to read or write a file is local or s p ecif i es o nly a s ing l e chunk of data, there is much less chance for MPI-IO t o do anything more than a simple POSIX read() would do. Also, when the file is organized by task rather than globall y, t here is less MP I-IO can do to help. This is the case when each task's fragment of the matrix is stored contiguously in the file rather than having the matrix organized as a whole.
pshpstuningguidewp040105.doc Page 7
Sometimes MP I-IO is u s ed in an a pp licat i o n as if it were bas ic P OSIX read/write, eit h er b ecause there is no need for more complex read/write patterns or because the application was previously hand-optimized to use POSIX read/write. In such cases, it is often better to use the IBM_largeblock_io hint on MPI_FILE_OPEN. By default, the PE/MPI implementation of MPI­IO tries to take advantage of the information the MPI-IO interface can provide to do file I/O more efficiently. If t h e MPI-IO calls do not use MPI_data types and file views or collective I/O, there might not be enough information to do any optimization. The hint shuts off the attempt to optimize and makes MPI-IO ca l ls beha ve muc h li k e the P O S IX I/O ca lls that GP FS a lr eady handles well.
2.3 chgsni command
The chgsni command is used to tune the HPS drivers by changing a list of settings. The basic syntax for chgsni is:
chgsni -l <HPS device name > -a <variable>=<new value>
Multiple variables can be set in a single command. The key variables to set for TCP/IP are spoolsize and rpoolsize. To change the send IP pools for
HPS, change the spoolsize parameter. To change the receive IP pool, change the rpoolsize parameter.
The IP buffer pools are allocated in partitions of up to 16MB each. Each increase in the buffer that crosses a 16 MB boundary allocates an additional partition. If you are running a pSeries 655 system wit h two HP S links, a lloc ate t wo partit ions (32MB) of b uffer space. If you ar e runnin g a p690+ system with eight HPS links, set the buffer size to 128MB. If you are running in an LPAR and have a different number of links, sca l e t he buffer size a c c ordi ngly.
IP buffer settings are global across all HPS links in an AIX 5L partition. This means you only need to change the setting on one interface. All other interfaces get the new setting. In other words, if you run the chgsni command against sn0, the new setting takes effect under sn1, sn2, and so on, up to the number of links in a node or partition. The following command sets the IP buffer pools for either a p655 with two HPS links or a p690 LPAR:
chgsni -l sni0 -a spoolsize=33554432 -a rpoolsize=33554432
To see the values for the current chgsni settings, use the lsattr co m man d . The fo llowi ng example shows the settings on the HPS sni0 link.
lsattr -E -l sni0
> lsattr -E -l sni0 base_laddr 0x3fff9c00000 base address False driver_debug 0x0 Device driver trace level True int_level 1040 interrupt level False ip_kthread 0x1 IP kthread flag True ip_trc_lvl 0x00001111 IP trace level True num_windows 16 Number of windows False perf_level 0x00000000 Device driver perf level True rdma_xlat_limit 0x8000000000000000 RDMA translation limit True
pshpstuningguidewp040105.doc Page 8
rfifosize 0x1000000 receive fifo size False rpoolsize 0x02000000 IP receive pool size True spoolsize 0x02000000 IP send pool size True
3.0 Tunables and settings for AIX 5L
Several settings in AIX 5L impact the performance of the HPS. These include the IP and memory subsystems. The following sections provide a brief overview of the most commonly used tunables. For more information about these subjects, see the AIX 5L tuning manuals listed in section 7.0.
3.1 IP tunables
When defining subnets for HPS links, it is easier to debug performance problems if there is only one HPS interface for each IP subnet. When running with multiple interfaces for each subnet, applications do not typically control which interface is used to send or receive packets. This can make connectivity problems more difficult to debug. For example, the RSCT cthats subsystem that polls interfaces to assert connectivity might have problems identifying which interfaces are down w h e n mult ip le interfa c es are on the same IP su bnet.
The IP subsystem has several variables that impact IP performance over HPS. The following table contains recommended initial settings used for TCP/IP. For more information about these variables, see the AIX 5L manuals listed in section 7.0.
Parameter Setting sb_max 1310720 tcp_sendspace 655360 tcp_recvspace 655360 rfc1323 1 tcp_mssdflt 1448 ipforwarding 1
3.2 File cache
AIX 5L defines all virtual memory pages allocated for most file systems as permanent storage pages. Files mapped from the GPFS file cache are an exception. A subset of permanent storage pages are further defined as client pages (such as NFS and JFS2 mapped files). All permanent storage pages can be referred to as the file cache. The size of the file cache tends to grow unless an increase in computational page allocations (for example, application data stored in memory) ca uses the o perating system to run low o n availabl e virtual memory f ra m es, o r t he fi les being memory mapped become unavailable (for example, a file system becomes unmounted).
pshpstuningguidewp040105.doc Page 9
The overhead in maintaining the file cache can impact the performance of large parallel applications. Much of the overhead is associated with the sync() system call (by defa u lt, run every minu te fro m the syncd daemon). The sync() system call scans all of the pages in the file cache to determine if any pages have been modified since the last sync(), an d therefore ne ed t o be written to disk. This type of d elay af fects larg er parallel a pplica tions more s e verely, and those with f requent sync hroni zing c ollecti ve cal ls (su c h as MP I_ALL TOALL or MPI_BAR RIER) ar e aff e c ted the most. A s ynchroniz ing op eration like MPI_ALLT O ALL ca n be completed only a f ter the slowest task involved has reached it. Unless an effort is made to synchronize the sync daemons across a cluster, t he sync() system call runs at different times across all of the LPARs. Unless the time between synchronizing operations for the application is large compared to the time required for a sync(), the random delays from sync() oper ations on many LPARs c an slo w the entire application. To address this problem, tune the file cache to reduce the amount of work each sync() must do..
To determine if the system is impacted by an increasing file cache, run the vmstat -v command and c heck the numperm and numclient percentages. Here is an example:
vmstat -v [. . .]
0.6 numperm percentage 10737 file pages
0.0 compressed percentage 0 compressed pages
0.0 numclient percentage
[. . .]
If the system tends to move towards a high numperm level, here are a couple of approaches to address performance concer ns:
Use vmo tunables to tune page replacement. By decreasing the maxperm percentage
and maxclient percentage, you can try to force page replacement to steal permanent and client pages before computational pages. Read the vmo man page before changing these tunables , and test any vmo changes incrementally . Always consult IBM serv ic e before changing the vmo tunables strict_maxperm and strict_maxclient.
If most of the permanent file pages allocated are listed as being client pages, these might
be NFS pages. If NFS accesses are driving the file cache up, consider periodically unmounting the NFS file systems (for example, use automount to mount file systems as th ey are requ i red).
3.3 svmon and vmstat commands
The svmon and vmstat comma nds are very he lpful in analyzing problems w ith virtual memor y. To find an optimal problem size, it helps to understand how much memory is available for an HPS application before paging starts. In addition, if an application uses large pages, it must know how much of t hat r es ourc e is availa ble. B ecause processes compete for the memory, and memory allocation changes over time, you need to understand the process requirements. The following sections introduce how to use the svmon and vmstat commands for debugging. For more information, see the AIX 5L performance and tuning guide and the related man pages.
pshpstuningguidewp040105.doc Page 10
3.3.1 svmon
The svmon command provides information about the virtual memory usage by the kernel and us er processes in the system at a ny given time. Fo r examp le, to see sy stem-wi de info rmation about the segments (256MB chunk of virtual memory), type the following command as root:
svmon -S
The command prints out segment information sorted according to values in the Inuse field, which shows the number of virtual pages in the segment that are mapped into the process address space. Segments of type work with a blank description field belong to user processes. If the LPage is set to Y, the segment contains large pages. These segments always have 65536 in the Inuse, Pin, and Virtual fields because this is the number of 4KB pages in the 256MB segment. In other words, large pages are mapped into the process address space with a granularity of 256MB even if a process is using a small fraction of it. A segment can have either large pages or small pages, but not both.
Vsid Esid Type Description LPage Inuse Pin Pgsp Virtual
101810 - work Y 65536 65536 0 65536 161836 - work Y 65536 65536 0 65536 1e09de - work kernel heap - 30392 92 0 30392 9e0 - work kernel heap - 26628 20173 0 26628 190899 - work mbuf pool - 15793 15793 0 15793 20002 - work page table area - 7858 168 7690 7858 0 - work kernel segment - 6394 3327 953 6394 70b07 - work other kernel segments Y 4096 4096 0 4096 c0b0c - work other kernel segments Y 4096 4096 0 4096 1b00bb - work vmm software hat - 4096 4096 0 4096 a09aa - work loader segment - 3074 0 0 3074
Memory overhead associated with HPS communication buffers allocated in support of MPI processes and IP is shown in the map as other ke rnel segments. Unlike user segments with large pages, these segments have just one large page or 4096 4KB pages. The segment named mbuf pool indicates a system-wide pool of pinned memory allocated for mbufs mostly used in support of IP. The Pin field shows the number of pinned 4KB pages in a segment (for example, pages that cannot be paged out). Large pages are always pinned.
To s e e a segmen t all oc ati on map organized by pr ocess, type the follow ing comman d as r oot:
svmon -P
The outpu t is sor ted acc o rdi ng to the aggr egate In us e value for each process. T h i s is usef ul in finding virtual memory demands for all processes on the node. The virtual segment ID (Vsid) is a unique segment ID that is listed in more than one process when processes share data (for exa mple, if multiple MPI ta sks us e s hared memory or program t ex t).
Pid Command Inuse Pin Pgsp Virtual 64-bit Mthrd LPage
381118 sppm 448221 3687 2675 449797 Y Y N
pshpstuningguidewp040105.doc Page 11
PageSize Inuse Pin Pgsp Virtual
4KB 448221 3687 2675 449797 16MB 0 0 0 0
Vsid Esid Type Description LPage Inuse Pin Pgsp Virtual
1f187f 11 work text data BSS heap - 56789 0 0 56789 218a2 70000000 work default shmat/mmap - 33680 0 0 33680 131893 17 work text data BSS heap - 21840 324 0 21840 0 0 work kernel segment - 4902 3327 2563 6419 1118b1 8001000a work private load - 1405 0 0 1405 d09ad 90000000 work loader segment - 1039 0 42 1226 1611b6 90020014 work shared library text - 169 0 65 194 31823 10 clnt text data BSS heap - 145 0 - ­ 1a187a ffffffff work application stack - 50 0 0 50 c17ec f00000002 work process private - 31 22 0 31 b11ab 9fffffff pers shared libra ry text, - 10 0 - -
3.3.2 vmstat
The vmstat command can show how many large pages are available for an application. It also reports paging activity, which can indicate if thrashing is taking place. It can also be used to find the me mory f o otpr int of a n application. Unli ke svmon, it does not require you to run as root.
To s e e a one-l ine summar y of the vmstat statistics, enter the following command:
vmstat -l
The f irst part of the output reports the number of CPUs and the amount of u sable phys ical memory.
System Configuration: lcpu=32 mem=157696MB
kthr memory page faults cpu large-page
----- ---------- ----------- ----------- --------------- -- ------------------ -------- ---------- -----------­r b avm fre re pi po fr sr cy in sy cs us sy id wa alp flp
3 1 35953577 5188383 0 0 0 0 0 0 3334 2080 176 1 0 99 0 213 7787
The ou tput is grouped into five ca tegor ies. T he last one, th e large - page group , has t wo members: allocated large pages (alp) and free large pages (flp). Because large pages are mapped into the process address space in 256MB segments, the maximum number of segments an application can get is flp * 16 / 256 . alp. This includes HPS buffers allocated in support of MPI processes on the adapters and buffers for IP. If only one application is running on a node or LPAR, the memory footprint of the application is the number of Active Virtual Memory (avm) pages. This can also be measured as the difference in avm before the application was started and when it is running. The avm is given in 4K units.
The vmstat command allows sampling at fixed intervals of time. This is done by adding an interval in seconds to the vmstat command. For example, the following command shows vmstat
pshpstuningguidewp040105.doc Page 12
statistics in 5-second intervals, with the first set of statistics being the statistics since the node or LPAR was last booted.
vmstat 5
The pi and po of the page group is the number of 4KB pages read from and written to the paging device between consecutive samplings. If place. In that case, it is a good idea to run the svmon command segment allocation.
po is high, it could indicate that thrashing is taking
to see the system-wide virtual
3.4 Large page sizing
Some HPC applications that use Technical Large Pages (TLPs) can benefit from a 5 - 20% increase in performance. There are two reasons wh y TLPs boos t performance :
Because the hardware prefetch streams cross fewer page boundaries, they are more
efficient.
Because missing the translation lookaside buffer is less likely, there is a better chance of
usin g a fast pat h f or address t ranslation.
TLP s must be conf igured by t he root user and require a s ystem rebo ot as d es c rib ed below. The oper ating syst e m limits the ma ximu m number of TLP to about 80% of the tot al phys ical storage on the system. The application can choose to use small pages only, large pages only, or both. Using both small and large pages is also known as an advisory mode recommended for high performance computing applications.
You can enable the application for TLPs by using the loader flag, by means of the ldedit command, or by using the environment variable at run time. The ldedit command enables the app lic ation for TLPs in the advisory mode:
ldedit –b lpdata <executable path name>
You can use –b nolpdata to turn TLPs off. The –b lpdata loader flag on the ld command does the same thing.
Setting the LDR_CNTRL environment variable enables TLPs in the advisory mode for all process es spawned from a shell p rocess and t heir children. Here is an example :
export LDR_CNTRL=LARGE_PAGE_DATA=Y
Setting the environment variable has a side effect for MPI jobs spawned by the MPI daemons from the shell process, because it also enables the daemons for TLPs. This takes away about 512MB of physical memory from an application. TLPs by their nature are pinned in memory (they cannot be paged out). In addition, TLPs are mapped into the process address space with segment granularity (256MB) even if the process uses only a few bytes in that segment. As a result, each of the two MPI daemons gets 256MB of pinned memory. For that reason, you should avoid using the LDR_CNTRL environment variable with MPI jobs.
Using TLPs boosts the performanc e of the MPI p rotocol stack. Some of the T LPs are res erved b y the HPS adapter code at boot time and are not available to an application as long as the HPS
pshpstuningguidewp040105.doc Page 13
adapter is configured. The volume of reservation is proportional to the number of user windows configured on the HPS adapter. A private window is required for each MPI task.
Here is a formula to calculate the number of TLPs needed by the HPS adapter. In the formula below, number_of_sni refers to the number of sniX logical interfaces present in the partition. To obtain the num_windows, send pool size, and receive pool size values for the AIX partition, run the following command:
lsat tr -El s niX (where X is the device minor number: 0, 1, 2, etc.)
total_num_windows = num_windows + 7
number of TLP required = A + B + C + D
where: A = 1 + (number_of_sni * 2) B = (number_of_sni * total_num_windows) C = (number_of_sni * total_num_windows * 262144) / 16777216 D = (send pool size + receive pool size) / 16777216
To change the number of windows, use the chgsni command. To set the Large Page option, use one of the following vmo commands:
vmo -r -o v_pinshm=1 -o lgpg_size=16777216 -o lgpg_regions= <number of TLP
required>
dsh -vn <node name> "echo y|vmo -r -o v_pinshm=1 -o lgpg_size=16777216 -o
lgpg_regions = <number of TLP required>"
If you use dsh co mman d, which is provi d e d by CS M, you must use the echo command, because vmo asks for verification to run bosboot.
Here is a sample of the information returned from the vmo command.
> Setting v_pinshm to 1 in nextboot file > Setting lgpg_size to 16777216 in nextboot file > Setting lgpg_regions to the required number of TLP in nextboot file > Warning: some changes will take effect only after a bosboot and a reboot > Run bosboot now? > A previous bosdebug command has changed characteristics of this boot image. Use bosdebug -L to display what these changes are. > bosboot: Boot image is 19877 512 byte blocks. > Warning: changes will take effect only at next reboot
pshpstuningguidewp040105.doc Page 14
3.5 Large pages and IP support
One of the most important ways to improve IP performance on the HPS is to ensure that large pages are enabled. Large pages are required to allocate a number of large pages which will used by the HPS IP driver a t boo t time.
Each snX needs one large page for the IP FIFO, plus the number of send pools and receive pools shared among all adapters. Here is the formula for the number of large pages, assuming that the send pool and receive pool each need two pages.
(N_adapters*(1 + 2send pools + 2receive pools))
To check whether the driver is using large pages, run the following command:
/usr/sbin/ifsn_dump -a | grep use_lg_pg
If large pages are being used, you should see this result:
use_lg_pg 0x00000001 If large pages are not used for the IP pools, the ifsn_dump -r traces (discussed later) report this
with the following messages:
[02] 1099351956s 0831707096ns 0x000c sn_setup_if_env: large page check failed! lgpg_size=0x1000000, lgpg_cnt=[. . .] [02] 1099351956s 0831708002ns 0x000d sn_setup_if_env: large page check failed! num_pages=0x4, lgpg_numfrb=[. . .]
3.6 Memory affinity for a single LPAR
If you are running with one big LPAR containing all processors on a p690 machine, you need to ensure that memory affinity is set correctly. To do this using vmo, set memory_affinity =
1.
This works with the AIX 5L shell variable MEMORY_AFFINITY and with the MPI variable MP_TASK_AFFINITY described earlier.
3.7 Amount of memory available
To pr o perly si ze t he number o f la rge pages on a system, or to determine t he largest pr oblem si ze that an MP I task c an run, you nee d to determine t he amount of conf igur e d memor y in you r LPAR. To do this, run the followi ng command:
lsattr -E -l sys0 -a real mem
To find the actual physical real memory installed on you CEC or LPAR, run the following command:
lscfg -vp | grep G B
pshpstuningguidewp040105.doc Page 15
If you have eight cards for p690 (or four cards for p655), this command also indicates whether you have full memory bandwidth.
3.8 Debug settings in the AIX 5L kernel
The AIX 5L kernel has several debug settings that affect the performance of an application. To make sure you are running with all the debug settings in the kernel turned off, run the following command:
bosdebug -L
The output will look something like this:
Memory debugger off Memory sizes 0 Netw ork memo ry sizes 0 Kernel debugger off Real Time Kernel off
Check the output to make sure that all the debug settings are off. To change any of these settings, run the following command:
bosdebug -o <variab l e>= off
After you make changes to the kernel settings, run the following command and then reboot:
bosboot -a
4.0 Daemon configuration
Several daemons on AIX 5L and the HPS can impact performance. These daemons run periodically to monitor the system, but can interfere with performance of parallel applications. If there are as many MPI tasks as CPUs, then when these demons run, they must temporarily take a CPU away from a task. This perturbs the performance of the application if one task takes a little longer to reach a synchronization point in its execution as compared to other tasks. Lowering the fre quenc y of these da e mons c an improv e performan ce or repeat ability of t he per for mance of a parallel application.
4.1 RSCT daemons
If you are using RSCT Peer Domain (such as VSD, GPFS, LAPI striping, or fail over), check the IBM.ConfigRMd daemon and the hats_nim daemon. If you see these daemons taking cycles, restart the daemons with AIXTHREAD_SCOPE=S.
pshpstuningguidewp040105.doc Page 16
4.2 LoadLeveler daemons
The LoadLeveler® daemons are needed for MPI applications using HPS. However, you can lower the impact on a parallel application by changing the default settings for these daemons. You can lower the impact of the LoadLeveler daemons by:
Reducing the number of daemons running
Reducing daemon communication or placing daemons on a switch
Reducing logging
4.2.1 Reducing the number of daemons running
Stop the keyboard daemon
On LoadL_config: # Specify whether to start the keyboard daemon X_RUNS_HERE = False
Allow o nly a fe w public schedd to run for submitting jobs o r PO E
On LoadL_config: LOCAL_CONFIG = $(tilde)/LoadL_config.local.$(hostname)
On LoadL_config.local.plainnode: SCHEDD_RUNS_HERE = False
On LoadL_config.local.scheddnode: SCHEDD_RUNS_HERE = True
On LoadL_admin for schedd node to make public: node_name.xxx.xxx.xxx: type = machine alias = node_name1.xxx.xxx.xxx node_name2.xxx.xxx.xxx schedd_host=true
4.2.2 Reducing daemon communication and placing daemons on a switch
On LoadL_config: # Set longer to reduce daemon messages. This will slow response to failures. POLLING_FREQUENCY = 600 POLLS_PER_UPDATE = 1 MACHINE_UPDATE_INTERVAL = 1200
Use the switch traffic for daemon communication.
4.2.3 Reducing logging
On LoadL_config: # reduce LoadLeveler activity to minimum. Warning: You will not be notified of failures. NEGOTIATOR_DEBUG = -D_ALWAYS NEGOTIATOR_DEBUG = -D_ALWAYS STARTD_DEBUG = -D_ALWAYS
pshpstuningguidewp040105.doc Page 17
SCHEDD_DEBUG = -D_ALWAYS
4.3 Settings for AIX 5L threads
Several variables help you use AIX 5L threads to tune performance. These are the recommended initial settings for AIX 5L threads when using HPS. Set them in the /etc/environment file.
AIXTHREAD_SCOPE=S
AIXTHREAD_MNRATIO=1:1 AIXTHREAD_COND_DEBUG=OFF AIXTHREAD_GUARDPAGES=4 AIXTHREAD_MUTEX_DEBUG=OFF AIXTHREAD_RWLOCK_DEBUG=OFF To see the current settings on a running system, run the following command:
ps ewaux | grep -v grep | grep -v AIXTHREAD_SCOPE
4.4 AIX 5L mail, spool, and sync daemons
AIX 5L automatically starts daemons for print spooling and mail. Because these are usually not needed on HPS s yst ems, t h ey ca n b e turned off. To dynamically turn off these da emons on a running system, use the following commands:
stopsrc -s sendmail stop src - s qdea mon stopsrc -s writesrv
You can also change the frequency when the syncd daemon for the file system runs. In the /sbin/rc.boot file, change the number of seconds setting between syncd calls by increasing the default value of 60 to something higher. Here is an example:
nohup /usr/sbin/syncd 300 > /dev/null 2>&1 &
You also need to change the sync_release_ilock value to 1 by using the following command:
ioo -p -o sync_release_ilock=1
4.5 Placement of POE managers and LoadLeveler scheduler
Select one node to run POE managers for MPI jobs and to run the LoadLeveler scheduler. If possible, do not use a compute node. If you do use a compute node, make sure that the CPUs on it do not all try to run an MPI task. Otherwise, tasks assigned to that node will run slightly slower than tasks on other compute nodes. A single slow task in a parallel job is likely to slow the entire job.
pshpstuningguidewp040105.doc Page 18
5.0 Debug settings and data collection tools
Sev eral debug s et tings a nd data c ollec tion tools can he lp you d e bug a perf ormance pr oble m on systems using HPS. This section contains a subset of the most common setting changes and tools . If a performance proble m persists after you check the deb ug set tings an d the da ta that wa s collected, call IBM service for assista nce.
5.1 lsattr tuning
The lsattr command lists two trace and debug-level settings for the HPS links. The following settings are recommended for peak performance and are the defaults.
Parameter Setting driver_debug 0 ip_trc_lvl 0x1111
5.1.1 driver_debug setti ng
The driver_debug setting is used to increase the amount of information collected by the HPS device drivers. eave this setting set to default value unless you are directed to change it by IBM service.
5.1.2 ip_trc_lvl setti ng
The ip _t r c _l vl s et t i n g is u s e d t o c ha ng e t h e a mount of da ta c ol le ct e d by the I P dr i ver . Lea v e t his setting set to default value unless you are directed to change it by IBM service.
5.2 CPUs and frequency
Performance of parallel application can be impacted by the number of CPUs on an LPAR and by th e sp eed of th e pro cessors. To s ee how many CPUs are a v ai l able and the frequen cy t hey run at, run any of the fol lowing commands:
lsdev -Cc processor lsattr -E -l proc# bindprocessor -q prtconf
pmcycles –m
If you mix slow CPUs and fast CPUs within a parallel job, the slowest CPU determines the speed for the entire job.
pshpstuningguidewp040105.doc Page 19
5.3 Affinity LPARs
On p690 systems, if you are running with more than one LPAR for each CEC, make sure you are running affi nity LPARs. To ch eck aff inity between CPU, me mory, and HP S links, ru n the associativity scripts on the LPARs.
To check the memory affinity setting, run the vmo command.
5.4 Small Real Mode Address Region on HMC GUI
Because the HMC and hypervisor code on POWER4 systems uses up physical memory, some physical memory is unavailable to th e LPARs. To make su re that Small Real Mo de Addr es s Region on the HMC GUI is set on, make sure the ulimit –a output shows you all unlimited.
Here are so me examples of p hysical memory an d avail able memo ry. Act ual va lues d epend on your hardware configuration.
Physical Real Memory Maximum Memory Available
64GB 61.5GB 128GB 120GB 256GB 240GB 512GB 495GB
5.5 Deconfigured L3 cache
The p690 and p655 systems can continue running if parts of the hardware fail. However, this can lead to unexpectedly lower performance on a long-running job. One of the degradations observed has been the deconfiguration of the L3 cache. To check for this condition, run the following command on each LP AR t o make sure that no L3 cach e ha s been deco n fi gured:
/usr/lib/boot/bin/dmpdt_chrp > /tmp/dmpdt_chrp.out vi /tmp/dmpdt_chrp.out
Search for L3 and i-cache-size
08000000 [................]
d-cache-size
08000000 [................]
If you get a value other than the one above, then part or all of your L3 is deconfigured.
5.6 Service focal point
The Service Focal Point (SFP) application runs on the HMC and provides a user interface for viewing events and performing problem determination. SFP resource managers monitor the system and record information about serviceable events.
pshpstuningguidewp040105.doc Page 20
On the HMC GUI, select Service Applications -> Service Focal Point -> Select Serviceable Events.
5.7 errpt command
On AIX 5L, the errpt command list s a summary of syst e m error mes sag es . Some of the HPS subsystem errors are collected by errpt. To find out if you have hardware errors, you can either run the errpt command, or you ca n run t he dsh command from the CSM manager:
dsh errpt | grep “ 02 23” | grep sysplana r0 (The value 0223 is the mo nth and day. )
You can also look at /var/adm/sni/sni_errpt_capture on the LPAR that is reporting the error.
If you see any errors from sni in the errpt listing, check the sni logs for more specific information. The HPS logs are found in a set of directories under the /var/adm/sni directory.
5.8 HMC error logging
The HMC records errors in the /var/hsc/log directory. Her e is an example of a command to check for cyclical redundancy check (CRC) errors in the FNM_Recover.log:
grep -i evtsum FNM_Rec ov.log | gr ep -i crc
In general, if Service Focal Point is working properly, you should not need to check the low-level FNM logs such as the FNM_Recov file. However, for completeness, these are additional FNM logs on the HMC:
FNM_Comm.log FNM_Ice.log FNM_Init.log FNM_Route.log
Another debug command you can run on the HMC is lsswtopol -n 1 -p $PLANE_NUMBER. For example, run the following command to check the link status for plane 0:
lsswtopol -n 1 -p0
If the lsswtopol command calls out links as ”service required,” but these links do not show up in Service Focal Point, contact IBM service.
5.9 Multiple versions of MPI libraries
One common problem on clustered systems is having different MPI library levels on various nodes. This can occur when a node is down for service while an upgrade is made, or when there ar e mu ltiple versions of the libraries for ea c h node and the lin ks ar e b roken. To chec k the lib rary levels across a large system, use the following dsh comman ds:
For LAPI libraries: dsh sum /opt /rsct/lapi/l ib/ liblapi_r.a (or run with
MP_INFOLEVEL=2)
pshpstuningguidewp040105.doc Page 21
For HAL libraries: dsh sum /usr /sni/aix 52/lib/libhal_ r.a
For MPI libraries: dsh sum /usr/lpp/ppe .poe/lib /libmpi_r.a (or run
with MP_PRINTENV=yes)
To make sure you are running the correct c ombinati on of HAL , LAP I , and MPI, c heck the Service Pack Release Notes.
5.10 MP_PRINTENV
If you set MP_PRINTENV=YES or MP_PRINTENV=script_name, the outpu t includes the following information about environmental variables. The output for the user script is also printed, if it was s pecified.
Hostname Job ID (MP_PARTIT ION) Number of Tasks (MP_PROCS) Number of Nodes (MP_NODES) Number of Tasks per Node (MP_TASKS_PER_NODE) Library Specifier (MP _ EUILIB) Adapter Name IP Address Window ID Network ID Device Name (MP_EUIDEVICE) Window Instances (MP_INSTANCES) Striping Setup Pr otocols in Use (MP_M SG_API) Effective Libpath (LIBPAT H) Cur rent Directory 64 Bit Mode Threaded Library Requested T hread Scope (AIX THREAD_SCO PE) Thread Stack Allocation (MP_THREAD_STACKSIZE/Bytes) CP U Use (MP_CPU_US E) Ada pter Use (MP _ADAPT ER_ USE) Clock Source (MP_CLOCK_SOURCE) Priority Class (MP_PRIORITY) Connection Timeout (MP_TIMEOUT/sec) Adapter Interrupt s Enab led (MP_C SS_ INTE R R UPT) Polling Interval (MP_POLLING_INTERVAL/sec) Use Flow Control (MP_USE_FLOW_CONTROL) Buffer Memory (MP_BUFFER_MEM/Bytes) Message Eager Limit (MP_EAGER_LIMIT/Bytes) Message Wait Mode(MP_WAIT_MODE) Retransmit Interval (MP _R ET R ANSM IT_INTERVAL/count) Shared Memory Enabled (MP_SHARED_MEMORY) Shared Memory Collective (MP_SHM_CC) Collective Shared Memory Segment Page Size (KBytes) Large Pa ge Environmen t Large Page Memory Page Size (KBytes)
pshpstuningguidewp040105.doc Page 22
MEMORY_AFFINITY Single Thread Usage(MP_SINGLE_THREAD) Hints Filtered (MP_HINTS_FILTERED) MPI-I/O Buffer S ize (MP_IO_B UFF E R _SIZE) MPI-I/O Error Logging (MP_IO_ ER RLOG) MPI-I/O Node File (MP_IO_NODEFILE) MPI-I/O Task List (MP_IO_T ASKLIS T) System Checkpoi ntable (CHECKPOINT) LoadLeveler Gang Scheduler DMA Receive FIFO Size (Bytes) Max outstandi ng packets LAPI Max Packet Size (Bytes) LAPI Ack Threshold (MP_ACK_THRESH) LAPI Max retransmit buf size (MP_REXMIT_BUF_SIZE) LAPI Max retransmit buf count (MP_REXMIT_BUF_CNT) LAPI Maximum Atom Size LAPI use bulk transfer (MP_USE_BULK_XFER) LAPI bulk min message size (MP_BULK_MIN_MSG_SIZE) LAPI no debug timeout (MP_DEBUG_NOTIMEOUT) Develop Mode (MP_EUIDEVELOP) Standard Input Mode (MP_STDINMODE) Standard Output Mode (MP_STDOUTMODE) Statistics Collection Enabled (MP_STATISTICS) Number of Service Variables set (MP_S_*) Interrupt Delay (us) (MP_INTRDELAY) Sync on Connect Usage (MP_SYNC_ON_CONNECT) Internal Pipe Size (KBytes)(MP_PIPE_SIZE) Ack Interval (count)(MP _ACK_INTERVAL) LAPI Buffer Copy Size (MP_COPY_SEND_BUF_SIZE) User Script Name (MP_PRINTENV) Size of User Script Output
5.11 MP_STATISTICS
If MP_STATISTICS is set to yes, statistics are collect ed. Howev er, these statist ics are written only when a call is made to mp_statistics_write, which takes a pointer to a file descriptor as its sole argument. These statistics can be zeroed out with a call to mp_statistics_zero. This can be used with calls to mp_statistics_write to determine the communication statistics in different porti ons o f the user applic ation. Th ese s ta tistics are useful fo r determi ning if there are exc essive packet retransmits, in addition to giving the total number of packets, messages, and data sent or received. The late arrivals are useful in determining how often a receive was posted before the matching message arrived. Early arrivals indicate how often a message is received before the posting of the matching receive.
MP_STATISTICS take the values yes and print. If the value is set to print, the statistics are printed for each task in the job at MPI_FINALIZE. If you set MP_STATISTICS to print, you should also set MP_LABELIO to yes so you know which task each line of output came from.
The following is a sample output of the statistics.
pshpstuningguidewp040105.doc Page 23
MPCI: sends = 14 MPCI: sendsComplete = 14 MPCI: sendWaitsComplete = 17 MPCI: recvs = 17 MPCI: recvWaitsComplete = 13 MPCI: earlyArrivals = 5 MPCI: earlyArrivalsMatched = 5 MPCI : lateArrivals = 8 MPCI: shoves = 10 MPCI : p ulls = 13 MPCI: threadedLockYields = 0 MPCI: unorderedMsgs = 0 LAPI: Tot_dup_pkt_cnt=0 LAPI: Tot_retrans_pkt_cnt=0 LAPI: Tot_gho_pkt_cnt=0 LAPI: Tot_pkt_sent_cnt=14 LAPI: Tot_pkt_recv_cnt=15 LAPI: Tot_data_sent=4194 LAPI: Tot_data_recv=3511
5.12 Dropped switch packets
Lower than expected performance can be caused by dropped packets on the HPS switch. Packets sent over a switch interface can be dropp e d in several ways, as describ e d in the followi ng sections.
5.12.1 Packets dropped because of a software problem on an endpoint
Pa c ket s are somet imes dropp e d at one of the e ndpo ints of the pa cket transfer. In this c ase, you shou ld be able t o run AIX 5L comma nds to see so me evidence on the endpoint tha t dropped t he packet. For exampl e, r un /usr/sni /sni.snap -l {adapter_number} to get the correct e ndpoi nt dat a. T his is best ta ke n both before and after r e- c reating the pr oblem. The
sni.snap creates a new archive in /var/adm/sni/snaps. For example, /usr/sni/sni.snap - l 1 produces a hostname.adapter_no.timestamp file such as
/var/adm/sni/snaps/c704f2n01.1.041118122825.FEFE5.sni.snap.tar.Z. For IP traffic, lookin g at netsta t -D data is a good place to start:
netstat -D Source Ipkts Opkts Idrops Odrops [. . .] sn_dmx0 156495 N/A 0 N/A sn_dmx1 243602 N/A 0 N/A sn_if0 156495 140693 0 0 sn_if1 243602 241028 0 13 ml_if0 0 98 0 10
The ifsn_dump command provides interface-layer statistics for the sni interfaces. This tool helps you diagnose packet drops seen in netstat -D and also prints some drops that are not shown under netstat.
pshpstuningguidewp040105.doc Page 24
Run the following command:
/usr/sbin/ifsn_dump -a
The data is collected in sni.snap (sni_dump.out.Z), and provides useful information, such as the local mac address:
mac_addr 0:0:0:40:0:0
If you are seeing arpq drops, ensure the source has the correct mac_addr for its destination.
The ndd statistics listed in ifsn_dump are useful for me asur ing pac ket drop s in r e lati o n to the over all number of pack et s se nt and received. ifsn_dump provides 64-bit counters for drops, sends, and receives, using msw and lsw 32-bit words. These 64-bit counters can be more useful than the 32-bit counters listed in netstat, because these 32-bit counters (limited to 4GB) can be quickly wrapped under heavy traffic loads on the switch.
Here is an exa mple of n dd statist ic s list e d by th e ifsn_dump –a comma n d:
| ndd_ipackets_msw 0x00000000 [0] | ndd_ipackets_lsw 0x00026357 [156503] | ndd_ibytes_msw 0x00000000 [0] | ndd_ibytes_lsw 0x012756be [19355326] | ndd_recvintr_msw 0x00000000 [0] | ndd_recvintr_lsw 0x00000000 [0] | ndd_ierrors 0x00000000 [0] | ndd_opackets_msw 0x00000000 [0] | ndd_opackets_lsw 0x00022595 [140693] | ndd_obytes_msw 0x00000000 [0] | ndd_obytes_lsw 0x01172099 [18292889] | ndd_xmitintr_msw 0x00000000 [0] | ndd_xmitintr_lsw 0x00000000 [0] | ndd_oerrors 0x00000000 [0] | ndd_nobufs 0x00000000 [0] | ndd_xmitque_max 0x00000000 [0] | ndd_xmitque_ovf 0x00000000 [0] | ndd_recvintr_msw 0x00000000 [0] | ndd_recvintr_lsw 0x00000000 [0] | ndd_ierrors 0x00000000 [0] | ndd_opackets_msw 0x00000000 [0] | ndd_opackets_lsw 0x00022595 [140693] | ndd_obytes_msw 0x00000000 [0] | ndd_obytes_lsw 0x01172099 [18292889] | ndd_xmitintr_msw 0x00000000 [0] | ndd_xmitintr_lsw 0x00000000 [0] | ndd_oerrors 0x00000000 [0] | ndd_nobufs 0x00000000 [0] | ndd_xmitque_max 0x00000000 [0] | ndd_xmitque_ovf 0x00000000 [0] | ndd_ipackets_drop 0x00000000 [0] | ndd_ibadpackets 0x00000000 [0] | ndd_opackets_drop 0x00000000 [0] | ndd_xmitque_cur 0x00000000 [0] | ndd_ifOutUcastPkts_msw 0x00000000 [0] | ndd_ifOutUcastPkts_lsw 0x00020e67 [134759] | ndd_ifOutMcastPkts_msw 0x00000000 [0] | ndd_ifOutMcastPkts_lsw 0x00000000 [0] | ndd_ifOutBcastPkts_msw 0x00000000 [0] | ndd_ifOutBcastPkts_lsw 0x0000172e [5934]
pshpstuningguidewp040105.doc Page 25
To help you isolate the exact cause of packet drops, the ifsn_dump -a command also lists th e following debug statistics. If you isolate packet drops to these statistics, you will probably need to contact IBM support.
dbg: | sNet_drop 0x00000000 [0] | sRTF_drop 0x00000000 [0] | sMbuf_drop 0x00000000 [0] | sFifo_drop 0x00000000 [0] | sQueue_drop 0x00000000 [0] | rPool_drop 0x00000000 [0] | m_reject 0x00000000 [0] | rsvd_pool_used 0x00000000 [0] | recv_not_ready 0x00000000 [0] | recv_bad_flag 0x00000000 [0] | recv_bad_type 0x00000000 [0] | alloc_cntl_fail 0x00000000 [0] | spkt_timeout 0x00000000 [0] | bad_health_drop 0x00000000 [0] | phantom_recv_intr 0x00000000 [0] | same_thresh_cnt 0x00000000 [0] | last_recv_thresh 0x0000000000000000 [0]
To see some packet drops (such as arpq drops), you must use the kdb ifnet structure (which is common for many interfaces). Here is an example:
echo ifnet | kdb[ . . .] SLOT 2 ---- IFNET INFO ----(@ 075AF098)----
name........ sn0 unit........ 00000000 mtu......... 0000FFE0
flags....... 08800843
(UP|BROADCAST|RUNNING|SIMPLEX|NOECHO|BPF|IFBUFMGT|CANTCHANGE... [. . .]
init()...... 00000000 output().... 075AE498 start()..... 00000000
done()...... 00000000 ioctl()..... 075AE4B0 reset()..... 00000000
watchdog().. 00000000 ipackets.... 00026549 ierrors..... 00000000
opackets.... 00022778 oerrors..... 00000000 collisions.. 00000000
next........ 075AF2C8 type........ 00000038 addrlen..... 00000000
hdrlen...... 00000018 index....... 00000003
ibytes...... 0127BA9E obytes...... 0117B005 imcasts..... 00000000
omcasts..... 00000000 iqdrops..... 00000000 noproto..... 00000000
baudrate.... 00000000 arpdrops.... 00000002 ifbufminsize 00000200
devno....... 8000002300000000 chan........ 2FF38EB0 multiaddrs.. 00000000
tap()....... 00000000 tapctl...... FFFFFFFFFFFFFFFF arpres().... 00000000
arprev().... 00000000 arpinput().. 00000000 ifq_head.... 00000000
ifq_tail.... 00000000 ifq_len..... 00000000 ifq_maxlen.. 00000200
ifq_drops... 00000000 ifq_slock... 00000000 slock....... 00000000
5.12.2 Packets dropped in the ML0 interface
For ml0 drop s to a desti natio n, use t he mltdd_d u mp -k comma nd to d etermine if a valid ml0 route exists to destination:
/usr/sbin/mltdd_dump -k
The following example shows the route to ml0 destination 192.168.2.3, which is a valid and comp lete ml0 route. I f a route is incomplet e, it is n ot valid.
mlr_next = 0x0000000000000000 mlr.state = 160 (COMPLETE)
pshpstuningguidewp040105.doc Page 26
There ar e two routes. sending packet using route No. 1 ml ip address structure, starting:
ml flag (ml interface up or down) = 0x00000000 ml tick = 0
ml ip address = 0xc0a80203, 192.168.2.3
There are two prefer red rou te p airs: from local if 0 to remote if 0 from local if 1 to remote if 1
There are two act ual rou tes ( tw o preferre d ).
--------------------------------------­fro m lo c al if 0 t o remot e if 0 destination ip address structure: if flag (up or down) = 0x000000c1 if tick = 0 ipaddr = 0xc0a80003, 192.168.0.3
--------------------------------------­fro m lo c al if 1 t o remot e if 1 destination ip address structure: if flag (up or down) = 0x000000c1 if tick = 0 ipaddr = 0xc0a80103, 192.168.1.3
5.12.3 Packets dropped because of a hardware problem on an endpoint
To check f or dropped pack ets at the HM C, check /var/adm/sni/sni_errpt_capture. Each hardware event has an entry. If you don't have the register mappings for error bits, check whether the errors are recoverable (non-MP-Fatal) or MP-Fatal. (MP-Fatal errors take longer to recover from and could be associated with more dr ops.)
The fo l lowin g i s an example of Recoverable/Non Mp Fatal entry in /var/adm/sni/sni_errpt_capture:
Current time is: Mon Oct 4 05:08:51 2004 Errpt Sequence num is: 3229 Errpt Timestamp is: Mon Oct 4 05:08:51 2004 Event TOD is: 2004160209010410 Event TOD date: Oct 04 09:02:16 2004 Not MP Fatal DSS Log count = 07 1st Attn type = Recoverable 2nd Attn type = Recoverable 1st Alert type = Alert 02 - SMA Detected Error FNM handles callout SMA chip (GFW #) 3 SMA location U1.28-P1-H1/Q1 SMA logically defined in this LPAR sni1 Failure Signature 8073D001
pshpstuningguidewp040105.doc Page 27
MAC WOF (2F870): Bit: 1 [. . .]
5.12.4 Packets dropped in the switch hardware
If a packet is dropped withi n the switch hardware it self ( for example, whe n travers i ng the link betwe en t wo switch chips), evide nce of the p acket d rop is o n the HMC, w here the swi tc h Fed erat i on Network Manager ( FNM) runs. You can run /opt/hsc/bin/fnm.snap to create a snap archive in /var/hsc/log (for example, /var/hsc/log/c704hmc1.2004-11-19.12.50.33.snap.tar.gz).
The FNM code handles errors associated with packet drops in the switch. To run the fnm.snap command (/opt/hsc/bin/fnm.snap), you must have root a c c es s or s et up proper aut henticati on. In the snap data, check the FNM_Recov.* logs for switch errors. If a certain type of error reached a threshold in the hardware, reporting for that type of error might be disabled. As a result, packet loss might not be reported. Generally, when you are looking for packet loss, it's a good idea to restart the FNM code to ensure that error reporting is reset.
5.13 MP_INFOLEVEL
You can get additional information from an MPI job by setting the MPI_INFOLEVEL variable to
2. In addition, if you set the MP_LABELIO variable to yes, you can get information for each task. Here is an example of the output using these settings:
INFO: 0031-364 Contacting LoadLeveler to set and query information for interactive job INFO: 0031-380 LoadLeveler step ID is test_mach1.customer.com.2507.0 INFO: 0031-118 Host test_mach1.customer.com requested for task 0 INFO: 0031-118 Host test_mach2.customer.com requested for task 1 INFO: 0031-119 Host test_mach1.customer.com allocated for task 0 INFO: 0031-120 Host address 10.10.10.1 allocated for task 0 INFO: 0031-377 Using sn1 for MPI euidevice for task 0 INFO: 0031-119 Host test_mach2.customer.com allocated for task 1 INFO: 0031-120 Host address 10.10.10.2 allocated for task 1 INFO: 0031-377 Using sn1 for MPI euidevice for task 1 1:INFO: 0031-724 Executing program: <spark-thread-bind.lp> 0:INFO: 0031-724 Executing program: <spark-thread-bind.lp> 1:LAPI version #7.9 2004/11/05 1.144 src/rsct/lapi/lapi.c, lapi, rsct_rir2, rir20446a 32bit(us) library compiled on Wed Nov 10 06:44:38 2004 1:LAPI is using lightweight lock. 1:Bulk Transfer is enabled. 1:Shared memory not used on this node due to sole task running. 1:The LAPI lock is used for the job 0:INFO: 0031-619 32bit(us) MPCI shared object was compiled at Tue Nov 9 12:36:54 2004 0:LAPI version #7.9 2004/11/05 1.144 src/rsct/lapi/lapi.c, lapi, rsct_rir2, rir20446a 32bit(us) library compiled on Wed Nov 10 06:44:38 2004 0:LAPI is using lightweight lock. 0:Bulk Transfer is enabled. 0:Shared memory not used on this node due to sole task running. 0:The LAPI lock is used for the job
pshpstuningguidewp040105.doc Page 28
5.14 LAPI_DEBUG_COMM_TIMEOUT
If the LAPI protocol experiences communication timeouts, set the environment variable LAPI_DEBUG_COMM_TIMEOUT to PAUSE. This causes the application to issue a pause() call w hen encountering a time out, which stops the ap plication i nstead of cl osin g it.
5.15 LAPI_DEBUG_PERF
The LAPI_DEBUG_PERF flag is not supported and should not be used in production. However, it ca n prov ide use ful i nformatio n about pac ket los s. If you sus pect packet drops are reduc ing performance, set the LAPI_DEBUG_PERF flag to yes (export LAPI_DEBUG_PERF=yes). The f o llowi ng additional infor mation is sent to standard error in t h e job out p ut:
_retransmit_pkt_cnt Tot_retrans_pkt_cnt LAPI Tot_retrans_pkt_cnt Shared Tot_retrans_pkt_cnt
Be aware that some retransmissions in the initialization stage are normal.
Here is a simple Perl script (count_drops) to count the number of lost packets. When LAPI_DEBUG_PERF is set to yes, this script is run against the STDERR of an LAPI job.
============================================= #!/usr/bin/perl $retrans=0; $dup=0; $ftbl_drop=0; $diff=0; while ( <STDIN> ) { if( /(.*)Shared Tot_dup_pkt_cnt(.*)= (.*)/) { $dup += $3; } if( /(.*)Shared Tot_retrans_pkt_cnt(.*)= (.*)/) { $retrans += $3; } if( /(.*)_drop_due_to_usr_ftbl_not_setup(.*)= (.*)/) { $ftbl_drop += $3; } } $diff=$retrans-$dup-$ftbl_drop; printf "retrans=$retrans dup=$dup ftbl_drop=$ftbl_drop lost=$diff\n";
==============================================
pshpstuningguidewp040105.doc Page 29
5.16 AIX 5L trace for daemon activity
If you suspect that a system daemon is causing a performance problem on your system, run AIX 5L trace to ch e ck for daemo n activity. For ex ample, to f ind out which dae mons are t aking up CPU time, use the following process:
trace -j 001,002,106,200,10c,134,139,465 -a -o /tmp/trace.aux -L 40000000 -T 20000000 sleep XX (XX is the time for your trace) trcstop trcrpt -O 'cpuid=on exec=on pid=on tid=on' /tmp/trace.aux > /tmp/trace.out Look at /tmp/trace.out
pprof XX (XX is the time for your trace) Look at: pprof.cpu pprof.famcpu pprof.famind pprof.flow pprof.namecpu pprof.start pprof.cpu
You will find all these files on the $PWD at the time you run it.
tprof -c -A all -x sleep XX (XX is the time for your trace) Look at: sleep.prof (you will find this file on the $PWD at the time you run it)
6.0 Conclusions and summary
Peak performance of HPS systems depends on properly tuning the HPS, and on correctly setting applicat ion shell varia bles and AIX 5L tu nables.
Because there are many sources of performance data, correct tuning takes time. As has been demonstrated, the HPS performs very well. If tuning is needed, there are several good tools to use to determine performance prob lems.
7.0 Additional reading
This section lists documents that contain additional information about the topics in this white paper.
7.1 HPS documentation
pSeries High Performance Switch - Planning, Installation and Service, GA22-7951-02
pshpstuningguidewp040105.doc Page 30
7.2 MPI documentation
Parallel Environment for AIX 5L V4.1.1 Hitchhiker's Guide, SA22-7947-01
Parallel Environment for AIX 5L V4.1.1 Operation and Use, Volume 1, SA22-7948-01
Parallel Environment for AIX 5L V4.1.1 Operation and Use, Volume 2, SA22-7949-01
Parallel Environment for AIX 5L V4.1.1 Installation, GA22-7943-01
Parallel Environment for AIX 5L V4.1.1 Messages, GA22-7944-01
Parallel Environment for AIX 5L V4.1.1 MPI Programming Guide, SA22-7945-01
Parallel Environment for AIX 5L V4.1.1 MPI Subroutine Reference, SA22-7946-01
7.3 AIX 5L performance guides
AIX 5L Version 5.2 Performance Management Guide, SC23-4876-00
AIX 5L Version 5.2 Performance Tools Guide and Reference, SC23-4859-03
7.4 IBM Redbooks™
AIX 5L Performance Tools Handbook, SG24-6039-01
7.5 POWER4
POWER4 Processor Introduction and Tuning Guide, SG24-7041-00
How to Control Resource Affinity on Multiple MCM or SCM pSeries Architecture in an HPC Environment
http://www.redbooks.ibm.com/redpapers/abstracts/redp3932.html
:
pshpstuningguidewp040105.doc Page 31
© IBM Corporation 2005 IBM Corporation
Marketing Communications Systems Group Route 100 Somers, New York 10589
Produced in the United States of America April 2005 All Rights Reserved
This document was developed for products and/or services offered in the United States. IBM may not offer the products, features, or services discussed in this document in other countries.
The information may be subject to change without notice. Consult your local IBM business contact for information on the products, features and services available in your area.
All statements regarding IBM’s future directions and intent are subject to change or withdrawal without notice and represent goals and objectives only.
IBM, the IBM logo, LoadLeveler, POWER4, POWER4+, pSeries and Redbooks are trademarks or registered trademarks of International Business Machines Corporation in the United States or other countries or both. A full list of U.S. trademarks owned by IBM may be found at
http://www.ibm.com/legal/copytrade.shtml
Other company, product, and service names may be trademarks or service marks of others.
IBM hardware products are manufactured from new parts, or new and used parts. Regardless, our warranty terms apply.
Copying or downloading the images contained in this document is expressly prohibited without the written consent of IBM.
This equipment is subject to FCC rules. It will comply with the appropriate FCC rules before final delivery to the buyer.
Information concerning non-IBM products was obtained from the suppliers of these products or other public sources. Questions on the capabilities of the non-IBM products should be addressed with the suppliers.
All performance information was determined in a controlled environment. Actual results may vary. Performance information is provided “AS IS” and no warranties or guarantees are expressed or implied by IBM.
The IBM home page on the Internet can be found at http://www.ibm.com
The pSeries home page on the Internet can be found at
http://www.ibm.com/servers/eserver/pseries
~
, AIX 5L,
.
.
.
pshpstuningguidewp040105.doc Page 32
Loading...
