Technical Information Manual

PC 300PL (Types 6562 and 6592)

IBM

Technical Information Manual

PC 300PL (Types 6562 and 6592)

Note

Before using this information and the product it supports, be sure to read the general information under Appendix E, “Notices and Trademarks” on page 59.

First Edition (August 1997)

The following paragraph does not apply to the United Kingdom or any country where such provisions are inconsistent with local law: INTERNATIONAL BUSINESS MACHINES CORPORATION PROVIDES THIS PUBLICATION “AS IS” WITHOUT

WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. Some states do not allow disclaimer of express or implied warranties in certain transactions, therefore, this statement may not apply to you.

This publication could include technical inaccuracies or typographical errors. Changes are periodically made to the information herein; these changes will be incorporated in new editions of the publication. IBM may make improvements and/or changes in the product(s) and/or the program(s) described in this publication at any time.

This publication was developed for products and services offered in the United States of America. IBM may not offer the products, services, or features discussed in this document in other countries, and the information is subject to change without notice. Consult your local IBM representative for information on the products, services, and features available in your area.

Requests for technical information about IBM products should be made to your IBM reseller or IBM marketing representative.

Note to U.S. Government Users — Documentation related to restricted rights — Use, duplication or disclosure is subject to restrictions set forth in GSA ADP Schedule Contract with IBM Corp.

Contents

Preface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . v

Manual Style . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . v

Related Publications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vi

Chapter 1. System Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Hardware Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Software Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

System Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

BIOS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Plug and Play ................................................. 3

POST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Configuration/Setup Utility Program .................................... 4

Advanced Power Management ....................................... 4

Flash Update Utility Program ........................................ 4

Diagnostic Programs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Device Drivers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Operating System Support ........................................... 5

Chapter 2. System Board Features ...................................... 6

Microprocessor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Chip Set Control .................................................. 6

L2 Cache . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

System Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

PCI-to-ISA Bridge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

System I/O and Power Management ..................................... 8

IDE Bus Master Interface ........................................... 9

USB Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Super Input/Output Controller ........................................... 11

Diskette Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Parallel Port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Serial Ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Infrared Port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Keyboard and Mouse Ports .......................................... 13

General-Purpose I/O Ports ........................................... 14

Real-Time Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Audio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Video . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Video Device Drivers .............................................. 17

Video Upgrade Options ............................................. 17

Memory Upgrade . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Multimedia Upgrade . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Video Adapters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Special Function Video Adapters ....................................... 17

Ethernet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

System Management Controller ......................................... 19

Riser Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

System Board Switches .............................................. 22

System Board Jumper ............................................... 23

Physical Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

 Copyright IBM Corp. 1997 iii

Chapter 3. Adapters and Internal Drives .................................. 25

Adapters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

SCSI Adapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Cabling Requirements for Wake on LAN Adapters ............................. 25

Internal Drives . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Chapter 4. Power Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Power Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Power Output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Output Protection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Power Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Chapter 5. Physical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Chapter 6. System Compatibility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Hardware Compatibility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Hardware Interrupts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Diskette Drives and Controller ......................................... 35

Hard Disk Drives and Controller ........................................ 35

Software Compatibility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Software Interrupts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Machine-Sensitive Programs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Appendix A. Connector Pin Assignments .................................. 37

ISA Bus Connectors ................................................ 37

PCI Bus Connectors ................................................ 39

IDE Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Diskette Drive Connector ............................................. 42

System Memory Connectors ........................................... 43

USB Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

Parallel Port Connector .............................................. 46

Serial Port Connectors ............................................... 47

Infrared Port Connector (Optional) ........................................ 47

Keyboard and Mouse Port Connectors ..................................... 48

Monitor Port Connector .............................................. 48

Ethernet Connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

Appendix B. System Address Maps ..................................... 50

System Memory Map ............................................... 50

Input/Output Address Map ............................................ 51

DMA I/O Address Map ............................................... 53

Appendix C. IRQ and DMA Channel Assignments ............................ 55

Appendix D. Error Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

POST Error Codes ................................................. 56

Beep Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

Appendix E. Notices and Trademarks .................................... 59

References . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60

General Sources . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60

World Wide Web Sources ........................................... 60

iv Technical Information Manual

Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

Contents v

Tables

1. System Resource Assignments for the IDE Interface .......................... 9

2. System Resource Assignments for the Diskette Interface ....................... 11

3. System Resource Assignments for the Parallel Port .......................... 12

4. System Resource Assignments for the Serial Ports ........................... 12

5. System Resource Assignments for the Keyboard and Mouse ..................... 13

6. System Resource Assignments for the Real-Time Clock ........................ 14

7. System Resource Assignments for the Audio Controller ........................ 15

8. System Resource Assignments for the Video Controller ........................ 16

9. System Resource Assignments for the Ethernet Controller ...................... 18

10. System Resource Assignments for the System Management Controller ............... 19

11. Riser Card Expansion Characteristics ................................... 21

12. Microprocessor Speed (Switches 1-4) .................................. 22

13. Reserved (Switch 5) ............................................. 22

14. System Board Ethernet Control (Switch 6) ................................ 22

15. Privileged Access Password Control (Switch 7) ............................. 22

16. Floppy Device Access (Switch 8) ..................................... 23

17. CMOS Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

18. Diskette Drives . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

19. IDE and SCSI Devices ........................................... 26

20. Power Output for 145-Watt Power Supply (PC 300PL, Type 6562) .................. 28

21. Power Output for 200-Watt Power Supply (PC 300PL, Type 6592) .................. 28

22. System Board Power Connectors ..................................... 28

23. ISA-Bus Adapters (Per Slot) ........................................ 29

24. PCI-Bus Adapters (Per Slot) ........................................ 29

25. Internal Devices (DASD) .......................................... 29

26. Keyboard Port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

27. Auxiliary Device Port ............................................ 29

28. USB Port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

29. Pin Assignments for the 4-Pin Power Connectors (PC 300PL, Type 6562) ............. 30

30. Pin Assignments for the 4-Pin Power Connectors (PC 300PL, Type 6592) ............. 30

31. Size . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

32. Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

33. Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

34. Air Temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

35. Humidity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

36. Electrical Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

37. Heat Output (Approximate) ......................................... 32

38. 3.5-Inch Diskette Drive Reading, Writing, and Formatting Capabilities ................ 35

39. Pin Assignments for the ISA Bus Connectors .............................. 37

40. Pin Assignments for the PCI Bus Connectors .............................. 39

41. Pin Assignments for the IDE Connectors ................................. 41

42. Pin Assignments for the Diskette Drive Connector ........................... 42

43. Pin Assignments for the DIMM Connectors ............................... 43

44. Pin Assignments for the USB Connectors ................................ 46

45. Pin Assignments for the Parallel Port Connector ............................ 46

46. Pin Assignments for the Serial Port Connectors ............................. 47

47. Pin Assignments for the Infrared Connector ............................... 47

48. Pin Assignments for the Keyboard and Mouse Connectors ...................... 48

49. Pin Assignments for the Monitor Connector ............................... 48

50. Pin Assignments for the Ethernet Connector ............................... 49

vi  Copyright IBM Corp. 1997

51. System Memory Map (Fixed Address Ranges) ............................. 50

52. System Memory Map (Flexible Address Ranges) ............................ 50

53. Input/Output Address Map ......................................... 51

54. DMA I/O Addresses ............................................. 53

55. IRQ Channel Assignments ......................................... 55

56. DMA Channel Assignments ........................................ 55

57. POST Error Codes ............................................. 56

58. Beep Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

Figures

1. Riser Card for PC 300PL (Type 6562) .................................. 20

2. Riser Card for PC 300PL (Type 6592) .................................. 20

3. System Board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

4. ISA Bus Connector ............................................. 37

5. PCI Bus Connector ............................................. 39

6. IDE Connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

7. Diskette Drive Connector .......................................... 42

8. System Memory (DIMM) Connector .................................... 43

9. USB Connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

10. Parallel Port Connector ........................................... 46

11. Serial Port Connector ............................................ 47

12. Infrared Port Connector ........................................... 47

13. Keyboard and Mouse Port Connector ................................... 48

14. Monitor Connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

15. Ethernet Connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

Tables vii

Preface

This

Technical Information Manual

The manual, which is intended for developers who want to provide hardware and software products to operate with these computers, provides in-depth information on how the computers work. Users of this publication should have an understanding of computer architecture and programming concepts.

Manual Style

Because the PC 300PL (Type 6562) and (Type 6592) are similar, they will be referred to collectively as

PC 300PL computers

computer types must be described. In this manual, the use of the letter “h” indicates a hexadecimal number. Also, when numerical modifiers

such as “K”, “M” and “G” are used, they typically indicate powers of 2, not powers of 10. For example, 1 KB equals 1024 bytes (2 (230).

throughout this manual, except in cases where differences between the two

), 1 MB equals 1 048576 bytes (220), and 1 GB equals 1073741824 bytes

provides information on the IBM PC 300PL (Types 6562 and 6592).

When expressing storage capacity, MB equals 1000 KB (1024000). The value is determined by counting the number of sectors and assuming that every two sectors equals 1 KB. Depending on the operating system and other system requirements, the storage capacity available to the user might vary.

Warning: The term Use of reserved areas can cause compatibility problems, loss of data, or permanent damage to the hardware. When the contents of a register are changed, the state of the reserved bits must be preserved. When possible, read the register first and change only the bits that must be changed.

Some signals are abbreviated. A minus sign in front of a signal indicates that the signal is active low. No sign in front of a signal indicates that the signal is active high.

reserved

describes certain signals, bits, and registers that should not be changed.

viii  Copyright IBM Corp. 1997

Related Publications

In addition to this manual, the following IBM publications provide information about the operation of PC 300PL computers. To order these publications, call 1-800-879-2755 in the U.S. and Puerto Rico. In other countries, contact an IBM reseller or IBM marketing representative.

Setting Up Your PC 300PL (Type 6562)



Setting Up Your PC 300PL (Type 6592)

These publications contain instructions on preparing the computer for operation.



Using Your PC 300PL (Type 6562) Using Your PC 300PL (Type 6592)

These publications contain information on configuring, operating, and maintaining the computer. Also included are warranty information, instructions for diagnosing and solving problems, and information on how to obtain help and service.



Installing Options in Your PC 300PL (Type 6562) Installing Options in Your PC 300PL (Type 6592)

These publications contain instructions for installing options in the computer.



Understanding Your PC 300PL

This publication includes general information about using computers and detailed information about the features of PC 300PL computers.



About Your Software

This publication (provided only with computers that have IBM-preinstalled software) contains information about the preinstalled software package.



Your Ready-to-Configure CD

This publication contains information about the computers. The publication also contains instructions for starting the CD.



Adaptec SCSI Documentation

This documentation, which is provided with computer models that have an IBM-installed SCSI adapter, includes information on configuring the adapter and instructions for installing and configuring SCSI devices.



Hardware Maintenance Manual

This publication contains information on PC 300PL computers for trained service technicians. It can be found on the World Wide Web (http://www.us.pc.ibm.com/cdt/hmm.html), and it can also be ordered from IBM. To purchase a copy, refer to the "Getting Help, Service, and Information" section in

Your PC 300PL (Type 6562)



Compatibility Report

This publication contains information about compatible hardware and software for PC 300PL computers. The publication is available on the World Wide Web (http://www.us.pc.ibm.com/cdt).

Using Your PC 300PL (Type 6592)

Ready-to-Configure CD

that comes with PC 300PL

Using

Preface ix

x Technical Information Manual

Chapter 1. System Overview

The PC 300PL (Type 6562) and (Type 6592) are versatile products designed to provide state-of-the-art computing power with room for future growth. The two computers utilize the same system board. They differ in frame assembly design, power supply capacity, and riser card design. (Type 6562 has four drive bays, four expansion slots, and a 145-watt power supply. Type 6592 has six drive bays, six expansion slots, and a 200-watt power supply. Refer to “Riser Card” on page 20 for an illustration of the riser card in each computer.)

Note: Because the two computer types (6562 and 6592) are similar, they will be referred to collectively

PC 300PL computers

two types must be described.

Hardware Features

The major features of PC 300PL computers are:

 Intel  Single bank, pipeline burst, synchronous L2 cache soldered on the system board  Support for up to 384 MB of system memory  Busmaster IDE controller  EIDE or Ultra Wide SCSI hard disk drive  CD-ROM drive (some models only)  3.5-inch, 1.44 MB diskette drive  Integrated Matrox MGA-1164SG1 3D video controller with 2 MB SGRAM soldered to the system board

 Integrated 16-bit, stereo audio controller (supports Sound Blaster Pro applications)

 Integrated Intel 10/100 Mbit, PCI Ethernet controller

 System Management

 Input/Output Features



Pentium processor with MMX technology

– Support for additional 2 MB of SGRAM

– Upgrade connectors for VESA interface and Matrox multimedia options

– Built-in, high-quality speaker

– RPL (Remote Program Load) and DHCP (Dynamic Host Configuration Protocol)

– Integrated Wake on LAN controller

– Automatic power-on startup sequence

– POST/BIOS update from network

– DMI (Desktop Management Interface) BIOS and DMI software

– Integrated system management controller

– Two serial ports

– One ECP/EPP parallel port

– One monitor port

– Four 3.5 mm audio jacks (line out, line in, headphone, and microphone)

– One Ethernet RJ-45 port

– Two USB (universal serial bus) ports

– One keyboard port (Windows 95-compatible)

– One mouse port

– One infrared port (optional)

– One multimedia port (optional)

throughout this manual, except in cases where differences between the

The 1164SG controller is equivalent to the 1064SG controller (which is installed in some PC 300PL computers models).

 Copyright IBM Corp. 1997

Chapter 1. System Overview

 Expansion

– PC 300PL (Type 6562): Four drive bays, four expansion slots (one ISA, two PCI, and one shared

ISA/PCI) – PC 300PL (Type 6592): Six drive bays, six expansion slots (three ISA and three PCI)

Several model variations are available for PC 300PL computers. The following list describes some of the ways in which the models vary:

 Microprocessor speed

 Hard disk type and capacity  Amount of system memory preinstalled  Type of operating system software preinstalled

Note also that models are available with or without a CD-ROM drive preinstalled.

2 Technical Information Manual

Chapter 1. System Overview

Software Features

This section describes the system software, device drivers, and operating system support provided with PC 300PL computers.

System Software

System software refers to the following:

 Basic input/output system (BIOS)  Plug and Play  Power-on self-test (POST)  Configuration/Setup Utility program  Advanced Power Management (APM)  Flash update utility program

 Diagnostic programs

BIOS

PC 300PL computers have an IBM BIOS. Support is provided for the following features:

 PCI bus, according to the PCI BIOS Specification (Version 2.1)  Plug and Play, according to the ISA Plug and Play BIOS Specification (Version 1.2)  Advanced Power Management, according to the APM BIOS Interface Specification (Version 1.2)  Desktop Management BIOS, according to DMI Specification 2.0a  IDE LBA to allow access to hard disks with a capacity greater than 527 MB  Intel 82430HX core chipset  Matrox MGA-1164SG 3D video BIOS  Intel Ethernet BIOS  Crystal audio setup BIOS  National System Management BIOS  Initialization of National Semiconductor N87307 I/O chip, with Plug and Play support

 Manufacturing hooks  Bootable CD-ROM

 DBCS code (for Japanese systems only)  Wake on LAN  RPL (Remote Program Load) and DHCP (Dynamic Host Configuration Protocol)  Flash over LAN  Alternate boot sequence

 CMOS cloning

 Enable/disable of system board Ethernet controller

Plug and Play

PC 300PL computers conform to the following:



ISA Plug and Play BIOS Specification (Version 1.2)



ISA Plug and Play BIOS Specification, Errata and Clarifications (Version 1.0)

Chapter 1. System Overview 3

, as released by Microsoft

Chapter 1. System Overview

PC 300PL computers also conform to the guidelines described in the following:



Plug and Play BIOS Extension Design Guide (Version 1.0)



Guide to Integrating the Plug and Play BIOS Extensions with System BIOS (Version 1.1)



Plug and Play Kit for DOS and Windows

POST

PC 300PL computers use IBM power-on self-test (POST) software with initialization code added for the Intel Pentium processor with MMX technology, the Intel 82430HX core chipset, the National Semiconductor PC87307 I/O chip, the Intel Ethernet chip, and the Matrox MGA-1164SG 3D video chip.

POST software locates any hardware problems or configuration changes. If an error occurs while POST is running, an error code in the form of a text message displays on the screen. For a description of POST error codes, see “POST Error Codes” on page 56. For further information on POST, refer to

PC 300PL (Type 6562)

Using Your PC 300PL (Type 6592)

Using Your

Configuration/Setup Utility Program

The Configuration/Setup Utility program provides menus for viewing and changing selections for devices and I/O ports, current date and time, start options, system security, advanced setup, ISA legacy resources, and advanced power management. The Configuration/Setup Utility program also provides system summary and product data screens which contain information specific to the computer model being used. Refer to on the Configuration/Setup Utility program.

Using Your PC 300PL (Type 6562)

Using Your PC 300PL (Type 6592)

for further information

Advanced Power Management

PC 300PL computers come with energy-saving software that meets Energy Star requirements. Advanced Power Management (APM) is a feature that reduces power consumption when components of the computer (or the entire computer system) are not in use. When enabled, APM initiates reduced-power modes for the microprocessor, monitor, hard disk drive, or entire system after a specified period of inactivity is reached.

APM is implemented in PC 300PL computers according to the APM BIOS Interface Specification (Version

1.2). For more information on APM, refer to

(Type 6562)

Using Your PC 300PL (Type 6592)

Understanding Your PC 300PL

and

Using Your PC 300PL

Flash Update Utility Program

A stand-alone utility program is available to support user-initiated flash code updates. This utility program updates the BIOS code in flash memory. PC 300PL computers also support BIOS updating over the LAN (Flash-over-LAN). The Flash-over-LAN function requires the use of the integrated system board Ethernet.

The flash update utility program is available on the World Wide Web (http://www.us.pc.ibm.com/files.html) or through the PC Company Bulletin Board Service in files that can be downloaded onto a diskette. Instructions for using the flash update utility program will be available in a README file included in the downloaded files. Refer to further information.

Using Your PC 300PL (Type 6562)

Using Your PC 300PL (Type 6592)

for

SCSI hard disk drives do not support APM.

4 Technical Information Manual

Chapter 1. System Overview

Diagnostic Programs

A diagnostic program (QAPlus/WIN for IBM or QAPlus/PRO for DOS) is provided with each PC 300PL computer. The diagnostic program provided depends on the type of software preinstalled. For more information on diagnostic programs, refer to

(Type 6592)

Using Your PC 300PL (Type 6562)

Using Your PC 300PL

Device Drivers

PC 300PL computers come with device drivers to support built-in features and several operating systems. The device drivers are preinstalled in models that come with IBM-preinstalled software. In addition, the device drivers are included on the Ready-to-Configure (RTC) CD-ROM that is provided with all PC 300PL models.

Operating System Support

Although a variety of operating systems can be used with PC 300PL computers, full function is provided only with Windows 95 and Windows NT 4.0. When operating systems other than Windows 95 and Windows NT 4.0 are used, PC 300PL computers will work, but without all of the advanced functions (for instance, the USB function is not supported with OS/2.) For a list of operating systems that are compatible with PC 300PL computers, refer to

(Type 6592)

http://www.us.pc.ibm.com/cdt.

, and the IBM online compatibility report on the World Wide Web at

Using Your PC 300PL (Type 6562), Using Your PC 300PL

Note: An operating system and various support programs are preinstalled in some PC 300PL computers.

Refer to Ready-to-Configure (RTC) CD-ROM is included with all models. The RTC CD-ROM contains applications and device driver support for the preinstalled operating system (if applicable), and several other operating systems.

About Your Software

for a detailed description of the preinstallation package. Also, a

Chapter 1. System Overview 5

Chapter 2. System Board Features

This section provides information about system board features. For an illustration of the PC 300PL system board, refer to “Physical Layout” on page 24.

For a list of features provided with PC 300PL computers, refer to “Hardware Features” on page 1.

Microprocessor

PC 300PL computers have an Intel Pentium processor with MMX technology. This microprocessor has separate core supply (2.8 V) and I/O supply (3.52 V) voltages. A voltage regulator on the system board converts the 3.52 V provided by the power supply to the core voltage (2.8 V) required by the microprocessor.

The Pentium processor with MMX technology features the following:

 Optimization for 32-bit software  Operation at a lower voltage level than previous microprocessors  64-bit data bus  32-bit I/O bus  32 KB L1 cache (split into 16 KB write-through code cache and 16 KB write-back data cache)  Fractional bus speed (selectable at 2/7, 2/5, 1/3, or 1/2 bus/core frequency ratio)  Power management features (stop clock, I/O trap restart, autohalt, system management mode)

 Math coprocessor

 Support for MMX technology (boosts the processing of graphic, video, and audio data)

Chapter 2. System Board Features

More information on the Pentium processor with MMX technology can be found on the World Wide Web at http://www.intel.com.

The microprocessor plugs into a 321-pin PGA processor ZIF socket (Socket 7) located on the system board. This socket will accommodate the 320-pin Pentium processor with MMX technology. The ZIF socket defines approximately half of the Vcc pins for core supply and the other half for I/O supply.

For information on replacing a microprocessor or installing an upgrade, refer to

PC 300PL (Type 6562)

Installing Options in Your PC 300PL (Type 6592)

Installing Options in Your

Chip Set Control

PC 300PL computers use the second-generation Intel 82430HX chip set, which consists of two modules. The 324-pin TXC module provides a bridge between the PCI bus and the microprocessor bus. (For information on the PCI bus, see “PCI-to-ISA Bridge” on page 8.) The TXC module also controls the cache and system memory interfaces.

The 208-pin, PIIX3 module provides a bridge between the PCI and ISA buses. The module, which is fully compliant with

PCI Local Bus Specification (Version 2.1)

, also contains the IDE and USB controllers.

6  Copyright IBM Corp. 1997

Chapter 2. System Board Features

L2 Cache

The L2 cache installed in PC 300PL computers consists of synchronous, pipeline burst, SRAMs installed in a single bank on the system board. There is one 32K x 8 bit, 15 ns, 5 V SRAM tag module and two 64K x 32 bit, 8ns, 3.3 V SRAM modules installed. Features of the L2 cache are as follows:

 Look-aside architecture

 Direct-mapped (one-way associativity) organization  Operates in write-back mode  Follows MESI (modified, exclusive, shared, invalid) protocol  Implemented as a unified cache (cache code and data)

System Memory

The system memory interface in PC 300PL computers is controlled by the Intel TXC chip set module. (Refer to “Chip Set Control” on page 6 for information on the TXC module.) There are three dual inline memory module (DIMM) sockets on the system board. The DIMM sockets are powered by +3.3 volts. This voltage allows for low-power operation and supports 64-Mbit technology. For DIMM socket pin assignments, refer to “System Memory Connectors” on page 43.

The system board supports:

 A total of 384 MB of system memory  A maximum of 128 MB of system memory in each DIMM socket

Any configuration of DIMMs is acceptable. However, DIMMs must have the following characteristics:

 Must be EDO nonparity (NP) or EDO error correcting code (ECC) DRAMs  Must be 16, 32, 64, or 128 MB in size  Must be 168-pin, unbuffered, +3 V, serial PD type  Must have gold-lead tabs  Must have 60 ns access speed only

Also, note the following:

 EDO NP modules and EDO ECC modules can be mixed, but they will configure as NP.  To enable ECC, all installed memory must be of the EDO ECC type.

Note: Single inline memory modules (SIMMs) are not supported in PC 300PL computers.

Chapter 2. System Board Features 7

Chapter 2. System Board Features

PCI-to-ISA Bridge

The PIIX3 chipset module provides the bridge between the peripheral component interconnect (PCI) and industry standard architecture (ISA) buses. The chip is used to convert PCI bus cycles to ISA bus cycles.

The PCI bus is compliant with host bus and is driven at a frequency of 33 MHz (half the speed of the 66 MHz microprocessor bus). The ISA bus is permanently set to the PCI bus speed divided by four.

The PCI bus shares interrupts with the ISA bus. Free interrupts are automatically assigned to PCI devices during POST. If no interrupts are available for the PCI devices, an 18XX POST error message is generated.

For information on PCI and ISA bus expansion connectors, see “Riser Card” on page 20.

PCI Local Bus Specification 2.1

. The PCI bus runs synchronously to the

System I/O and Power Management

The Intel PIIX3 chipset module that provides the PCI-to-ISA bridge also provides all the subsystems of the ISA bus. These subsystems are:

 An ISA-compatible interrupt controller that provides the function of two cascaded 82C59 interrupt

controllers

 Three counters, equivalent to an 82C54 programmable interval timer  The function of two 82C37 DMA controllers with seven independent DMA channels (four 8-bit

channels and three 16-bit channels)

 Power management features

For further information on the PIIX3 chipset module, refer to “Chip Set Control” on page 6.

8 Technical Information Manual

Chapter 2. System Board Features

IDE Bus Master Interface

The system board incorporates a PCI-to-IDE interface that complies with the

Extensions

. The Intel PIIX3 chipset module contains the controller for the PCI Bus Master IDE interface.

AT Attachment Interface with

The PIIX3 module allows concurrent operations on the PCI and IDE buses. (Refer to “Chip Set Control” on page 6 for further information on the PIIX3 module.)

The primary and secondary IDE busses are routed to two connectors on the riser card. A total of four IDE devices can be attached to the two IDE riser card connectors using ribbon cables. Note that a total of three IDE devices can be attached to the riser card connectors in the PC 300PL (Type 6562) due to bay limitations. The IDE devices receive their power through separate, four-position power cables containing +5 V, +12 V, and ground (GND) voltage.

On each IDE connector, one IDE device is designated as the primary (master) device, and the other device is designated as the secondary (subordinate) device. These designations are determined by switch or jumper settings on each IDE device. A functional primary device must be present on each IDE connector for a secondary device to be recognized on that same IDE connector. Care must be taken to ensure that the jumpers on the IDE devices installed in the system correctly identify them as either primary or secondary devices. Otherwise, some of the devices might not be recognized by the system. There is no performance impact between a primary device and a secondary device of the same type on the same IDE connector.

A bootable IDE hard disk drive can be installed on either IDE connector. A bootable hard disk is one which has an active partition with an operating system installed on it.

PCI or ISA IDE expansion adapters are not supported. For a list of devices that can be installed in PC 300PL computers, refer to “Internal Drives” on page 26. The following table shows the typical system resource assignments for the IDE interface.

Table 1. System Resource Assignments for the IDE Interface

Configuration ROM RAM I/O Address (Hex) IRQ DMA

IDE 1 None None 01F0-01F7, 03F6, 03F7 bits 6:0 14 None IDE 2 None None 0170-0177, 0376-0377 15 None

Notes:

1. IDE 1 is the default for the primary channel.

2. IDE 2 is the default for the secondary channel. When the computer is started, the resource assignments are subject to change during POST. Two 40-pin connectors are provided on the riser card for the IDE interface. For information on connector

pin assignments, see “IDE Connectors” on page 41.

Chapter 2. System Board Features 9

Chapter 2. System Board Features

USB Interface

The Intel PIIX3 chipset module contains the controller for the USB interface in PC 300PL computers. (Refer to “Chip Set Control” on page 6 for information on the PIIX3 module.) Two USB ports are provided on the rear connector panel of the computers. A USB-enabled device can be attached to each port, and if that device is a hub, multiple peripheral devices can be attached to the hub and be used by the system. Plug and Play technology is used to recognize installed devices. The USB port functions at speeds of up to 1.5 Mbits per second or 12 Mbits per second. Data is transferred in either asynchronous or isochronous mode. The system does not support a keyboard attached to either of the USB ports as a boot device.

The USB is compliant with USB technology include:

 Support for up to 127 physical devices  Connections of up to five meters in length from host to hub or hub to hub  Support for hot pluggable devices  Support for concurrent operation of multiple devices  Support for different device bandwidths  Guaranteed bandwidth and low latencies appropriate for telephony, audio, etc.  Wide range of packet sizes  Eight-signal USB cable

The external interface for the USB ports consists of two, 4-pin connectors. For information on connector pin assignments, see “USB Connectors” on page 46.

Universal Host Controller Interface Design Guide 1.0

. Features provided by

10 Technical Information Manual

Chapter 2. System Board Features

Super Input/Output Controller

Control of the integrated input/output (I/O) ports, diskette drive, and real-time clock is provided by the National Semiconductor PC87307 chip. This chip, which is compatible with

Specification 1.0a

, supports and implements the following features:

Plug and Play ISA

 Diskette interface  Parallel port  Serial ports  Infrared port

 Keyboard and mouse ports  General-purpose I/O ports

 Real-time clock

Diskette Interface

The PC 300PL (Type 6562) supports one diskette drive. The PC 300PL (Type 6592) supports a maximum of two diskette drives. (Refer to “Internal Drives” on page 26 for more information). The following is a list of devices that the diskette interface will support:

 1.44 MB, 3.5-inch diskette drive  1.44 MB, 3.5-inch, 3-mode drive for Japan  1.2 MB, 5.25-inch diskette drive (PC 300PL, Type 6592 only)  1 Mbps, 500 Kbps, or 250 Kbps internal tape drive (PC 300PL, Type 6592 only)

Note: A 2.88 MB, 3.5-inch diskette drive is not supported. The following table shows the typical system resource assignments for the diskette interface.

Table 2. System Resource Assignments for the Diskette Interface

Resource Resource Assignment

ROM None RAM None I/O Address (Hex) 03F0–03F5 (diskette channel 0)

03F7, bit 7 (diskette change) IRQ 6 DMA 2

When the computer is started, the resource assignments are subject to change during POST. One shrouded, 34-pin, berg-strip connector is provided on the PC 300PL riser card for the diskette drive.

For information on connector pin assignments, see “Diskette Drive Connector” on page 42.

Chapter 2. System Board Features 11

Chapter 2. System Board Features

Parallel Port

One parallel port is integrated into the system board. Support for extended capabilities port (ECP), enhanced parallel port (EPP), and standard parallel port (SPP) modes is provided. These modes are selected through the Configuration/Setup Utility program, with the default mode set to SPP. The ECP and EPP modes are compliant with IEEE 1284.

The following table shows the typical system resource assignments for the parallel port.

Table 3. System Resource Assignments for the Parallel Port

Configuration ROM RAM I/O Address (Hex) IRQ DMA

LPT1 None None 03BC–03BE 7 3 LPT2 None None 0378-037F 5 3 LPT3 None None 0278-027F 3

Note: The default setting for the parallel port is LPT1. When the computer is started, the resource

assignments are subject to change during POST.

The external interface for the parallel port is a 25-pin, female, D-shell connector. For information on connector pin assignments, see “Parallel Port Connector” on page 46.

3 3 3

Serial Ports

The serial port subsystem consists of two universal asynchronous receiver/transmitters (UARTs) that are PC16550A- and NS16450-compatible. The serial ports include a 16-byte data first-in first-out (FIFO) buffer and have programmable baud rate generators. The UARTs function independently of one another, and both can be used in normal mode, which is inclusive of modem control circuitry. UART2 can be used as an infrared serial interface. UART2 function is determined at boot time via the Configuration/Setup Utility program and can only be altered by changing setup and rebooting the computer. If UART2 is set to the infrared function, serial port 2 will be disabled.

The following table shows the typical system resource assignments for the serial ports.

Table 4. System Resource Assignments for the Serial Ports

Configuration ROM RAM I/O Address (Hex) IRQ DMA

COM1 None None 03F8-03FF 4 None COM2 None None 02F8-02FF 3 None COM3 None None 0220-0227, 02E8-02EF,

0338-033F, 03E8-03EF

COM4 None None 0220-0227, 02E8-02EF,

0338-033F, 03E8-03EF

The default setting for serial port 1 is COM1. For serial port 2, the default setting is COM2. When the computer is started, the resource assignments are subject to change during POST.

4 None

3 None

The external interface for the serial ports consists of two, 9-pin, male, D-shell connectors (in a stacked configuration). For information on connector pin assignments, see “Serial Port Connectors” on page 47.

ECP/EPP mode only.

12 Technical Information Manual

Chapter 2. System Board Features

Infrared Port

An optional infrared port can be added to PC 300PL computers. To do this, an internal cable/connector assembly must be attached to the infrared header provided on the system board. This assembly provides a female, 9-pin, D-shell connector to be located in the knockout area at the rear of the computer. An infrared module (which contains the infrared optics) attaches to the female connector via a shielded cable with a standard 9-pin, male, D-shell connector. The internal cable/connector assembly and the infrared module/shielded cable do not come standard with PC 300PL computers. They can be purchased from IBM or an IBM reseller as a single option package (referred to as the 4.0 MBit IR Transceiver Option).

Once the infrared option is installed, the infrared function must be enabled by configuring UART2 to

infrared mode, rather than normal mode. (Note that UART2 can be used as either an infrared port second serial port; it cannot be used for both purposes.) The infrared port uses any of the same four system resource assignments as the serial port.

The software required for infrared communication is available on the

Ready-to-Configure CD

that comes

with PC 300PL computers. Note: For Windows 95, an infrared device driver must be installed. The device driver can be

downloaded from the Microsoft Windows 95 Updates World Wide Web site.

The infrared module is capable of establishing a link of up to one meter (3.3 ft.) at a rate of 115 kilobits-per-second (Kbps). The infrared interface complies with HP-SIR, SHARP-IR and IrDA-2.

For information on connector pin assignments for the infrared port, refer to “Infrared Port Connector (Optional)” on page 47.

Keyboard and Mouse Ports

The keyboard-and-mouse subsystem is controlled by a general purpose, 8-bit microcontroller. The controller consists of 256 bytes of data memory and 2 KB of read-only memory (ROM).

The controller has two logical devices; one controls the keyboard, and the other controls the mouse. The keyboard has two fixed I/O addresses and a fixed IRQ line (IRQ1). The keyboard can operate without a companion mouse, but the mouse can only operate with its companion keyboard. The mouse has a fixed IRQ line (IRQ12), but it does not have its own I/O address; it relies on the addresses used by the keyboard.

The following table shows the typical system resource assignments for the keyboard and mouse.

Table 5. System Resource Assignments for the Keyboard and Mouse

Configuration ROM RAM I/O Address (Hex) IRQ DMA

Keyboard & mouse None None 0060, 0064 1 (keyboard)

Keyboard only None None 0060, 0064 1 None Mouse only None None 0060, 0064 12 None

Note: Keyboard & mouse is the default. When the computer is started, the resource assignments are subject to change during POST. For an external interface, the keyboard and mouse each have a 6-pin connector. For information on

connector pin assignments, see “Keyboard and Mouse Port Connectors” on page 48.

Chapter 2. System Board Features 13

None

12 (mouse)

Chapter 2. System Board Features

General-Purpose I/O Ports

The National Semiconductor PC87307 chip on the system board has up to 16 general-purpose input/output (GPIO) pins which are supported by 2 GPIO ports. The port pins are used for specific functions and are not configurable by the user.

The GPIO ports use I/O addresses 0078-007F. Each GPIO port occupies a 4-byte I/O address.

Real-Time Clock

The low-power, real-time clock provides a time-of-day clock and a calendar. The clock is accurate to +/− 12 minutes per year. The clock settings are maintained by an external battery source at +2.4 volts. The life expectancy of the battery is approximately 2.25 years.

An external crystal is used to drive the real-time clock, and the battery is used to maintain the state of the CMOS RAM when the power to the computer is turned off. (The system has 242 bytes of battery-backed CMOS RAM in two banks.) If the CMOS RAM becomes corrupted and the system will not boot, a jumper is included on the system board to clear CMOS RAM so that POST can set CMOS RAM to factory default values.

The following table shows the typical system resource assignments for the real-time clock.

Table 6. System Resource Assignments for the Real-Time Clock

Resource Resource Assignment

ROM None RAM None I/O Address (Hex) 0070, bits 6:0 (address)

0071 (data) IRQ 8 DMA None

When the computer is started, the resource assignments are subject to change during POST.

14 Technical Information Manual

Chapter 2. System Board Features

Audio

The system board has a Crystal 4236B, 16-bit, stereo audio subsystem that provides all the digital audio and analog mixing functions required for recording and playing high-quality sound from PC 300PL computers. The audio subsystem provides the following functions:

 ISA bus interface  Digital audio processor that supports Sound Blaster Pro, Adlib, and Microsoft Windows Sound System

applications

 MIDI UART

 Windows Sound System interface  FM synthesizer interface

 16-bit codec/mixer PC 300PL computers have a built-in, high-quality speaker and four audio jacks (ports). The jacks are

industry-standard, 3.5 mm (1/8") mini-jacks. A description of these jacks follows.

 Audio Line Out: This jack, which is located on the rear connector panel, is used to send audio signals

from the computer to external devices, such as stereo-powered speakers with built-in amplifiers, multimedia keyboards, or the Audio Line In jack on a stereo system.

 Audio Line In: This jack, which is located on the rear connector panel, is used to send audio signals

from an external device (such as a CD player or stereo) to the computer so that the signals can be recorded on the hard disk. (However, the input level must be reduced accordingly using the mixer provided in the computer operating system.)

 Microphone: This jack, which is located on the front panel, is used to connect a microphone to the

computer so that voice or other sounds can be recorded on the hard disk. This jack can also be used by speech-recognition software.

 Headphone: This jack, which is located on the front panel, is used to connect headphones or small

bookshelf speakers to the computer. The speakers must have built-in amplifiers. If headphones are inserted in the jack, the computer's built-in speaker is muted (except for system beeps).

PC 300PL computers also have a volume control knob on the front panel that adjusts the sound level for the headphone jack and built-in speaker.

The following table shows the system resource assignments for the audio controller.

Table 7. System Resource Assignments for the Audio Controller

Resource Resource Assignment

ROM None RAM None I/O Address (Hex) Required IRQ Required DMA Required

4 4 4

When the computer is started, the resource assignments are subject to change during POST.

Assigned by Plug and Play BIOS or operating system.

Chapter 2. System Board Features

Video

The video subsystem in PC 300PL computers consists of the following system board components:

 Matrox MGA-1164SG 3D video controller  2 MB of SGRAM (expandable to 4 MB SGRAM)  Upgrade connector for the VESA interface option  Upgrade connector for the Matrox multimedia option

The MGA-1164SG 3D video controller is a high-performance, next-generation 3D graphics, multimedia, and windows accelerator that provides the following:

 Superior Windows performance (+35 Winmarks)  Acceleration of 3D texture-mapped multimedia applications  Full DirectDraw compliance  Acceleration of digital video, including software MPEG  Integrated RAMDAC (190 MHz)  Fully-featured 3D rendering engine  Integrated digital video scaling, filtering, and color space conversion engine  Shared frame buffer and split frame buffer modes of operation  Support for all VGA modes; fully compatible superset of the VGA function  VESA (Version 1.2)-compliant for SVGA modes  Complete Plug and Play support  DDC2B and I

C support

 Local peripheral bus (LPB)

Chapter 2. System Board Features

In PC 300PL computers, the video subsystem connects to the monitor through a 15-pin, female, D-shell, DDC2B-compliant connector located on the rear connector panel of the computer. If a DDC2B/DDC1 monitor is attached to the computer, the monitor will automatically be detected during POST and the refresh rates will be set to the optimal values (in the Configuration/Setup Utility program) supported by the DDC2B/DDC1 monitor.

The following table shows the typical system resource assignments for the video controller.

Table 8. System Resource Assignments for the Video Controller

Resource Resource Assignment

ROM (Hex) C0000 to C7FFF (32 KB) RAM (Hex) A0000 to BFFFF

MGABASE1 to (MGABASE1+3FFF), (MGA control aperture)

MGABASE2 to (MGABASE2+7FFFFF) (8 MB linear frame buffer)

MGABASE3 to (MGABASE3+7FFFFF) (8 MB pseudo-DMA window)

MGABASE1 is specified in the Matrox PCI configuration register offsets 10h–13h (default =

41000000h).

MGABASE2 is specified in the Matrox PCI configuration register offsets 14h–17h (default =

40800000h – prefetchable).

MGABASE3 is specified in the Matrox PCI configuration register offsets 18h–1Bh (default =

40000000h). I/O Address (Hex) 3B4-3B5, 3BA, 3C0-3C2, 3C4–3CA, 3CC, 3CE–3CF, 3D4-3D5, 3DA, 3DE–3DF IRQ The video IRQ can be enabled or disabled in the Configuration/Setup Utility program. If

enabled, it is assigned PCI INT 2 and is automatically assigned an ISA IRQ by the Plug and

Play BIOS or operating system. DMA None

When the computer is started, the resource assignments are subject to change during POST.

16 Technical Information Manual

Chapter 2. System Board Features

Video Device Drivers

Video device drivers for the Matrox MGA-1164SG 3D controller are provided on the

that comes with PC 300PL computers. Instructions for installing the device drivers are provided on the

Ready-to-Configure CD

prompt appears requesting specification of Mystique or Millennium, specify Mystique.) Note: Video device drivers have already been installed in computers that come with IBM-preinstalled

software.

in Matrox README files that correspond to the operating system being used. (If a

Ready-to-Configure

Video Upgrade Options

The Matrox MGA-1164SG 3D video subsystem provides support for several types of upgrade options. These options are standard Matrox upgrades that can be purchased directly from Matrox Graphics Inc. Descriptions of the upgrades follow.

Note: The Matrox MGA-1164SG 3D video subsystem supports a maximum of one Matrox upgrade

module. This means that a memory upgrade module cannot be used in conjunction with a multimedia upgrade module.

Memory Upgrade

PC 300PL computers come standard with 2 MB (2 chips) of video memory. A memory upgrade that provides an additional 2 MB of SGRAM memory can be purchased from Matrox. The upgrade provides more flexibility in terms of resolution and 3D support.

The memory upgrade is a daughtercard that plugs into two parallel, 70-pin connectors on the system board. The system board connectors provide all of the control, address, data, and power signals required by the upgrade daughtercard. The connectors incorporate keying and protection features.

Multimedia Upgrade

The other supported upgrades are the Matrox Rainbow Runner Studio multimedia upgrade modules. These upgrades are available in several configurations. Refer to

Using Your PC 300PL (Type 6592)

Rainbow Runner Studio upgrade modules plug into the Matrox Rainbow Runner Studio system board connectors. An optional cable and connector (containing audio/video inputs for Rainbow Runner Studio) is cabled from the Rainbow Runner Studio upgrade module to the knockout area at the rear of the computer.

for a description of the upgrades available.

Using Your PC 300PL (Type 6562)

and

Video Adapters

The video subsystem supports video adapters that are installed in either a PCI or an ISA expansion slot. No jumpers need to be changed when an upgrade video adapter is installed, because the system BIOS automatically detects that the adapter has been added. If an ISA or PCI adapter is detected by the system BIOS, the adapter video is enabled, and the system board video is disabled. If no ISA or PCI video adapters are found, the system board video is then enabled.

Special Function Video Adapters

The system board has a VGA VESA feature connector that supports special function video adapters, such as the ReelMagic TV tuner and MPEG decoder adapters.

Chapter 2. System Board Features 17

Chapter 2. System Board Features

Ethernet

The system board of PC 300PL computers contains an Intel 82557 10/100 Mbit Ethernet controller that provides a high-performance network connection. The Ethernet controller, which is a Plug and Play device and a PCI 2.1 Bus Master, features the following:

 IEEE 802.3 compliance, 10 and 100 Mbps  Support for 100BaseTx and 10BaseT with PCI bus interface  Viewable media access control (MAC) address  Single RJ-45 port  3 Kbyte transmit FIFO and 3 Kbyte receive FIFO

 Auto-negotiation

 Full duplex capability  Full NOS support

The Ethernet controller interfaces directly with the ICS 1890 Tx physical layer on the system board, which contains all of the analog transmit and receive circuits.

The system board also includes a discrete Wake on LAN controller (MagPack). This controller can be disabled in the Configuration/Setup Utility program.

A switch is provided on the system board for disconnecting the Ethernet subsystem from AUX5 power. This disconnection is required if a Wake on LAN adapter is installed. (The power supply does not provide enough AUX5 current to power both the system board Ethernet and a Wake on LAN adapter simultaneously.)

Note: For compliance with FCC Class B radiation limits, all Ethernet cabling attached to PC 300PL

computers must be Class 5, regardless of the speed (10 Mbit or 100 Mbit).

The following table shows the system resource assignments for the Ethernet controller.

Table 9. System Resource Assignments for the Ethernet Controller

Resource Resource Assignment

ROM None RAM None I/O Address (Hex) Required IRQ Required DMA None

5 5

When the computer is started, the resource assignments are subject to change during POST. The external interface for the Ethernet feature is an 8-pin, RJ-45 connector. For information on connector

pin assignments, see “Ethernet Connector” on page 49.

Assigned by Plug and Play BIOS or operating system.

18 Technical Information Manual

Chapter 2. System Board Features

System Management Controller

The system board contains a National System Management chip (LM78) that monitors the computer at all times looking for potential hardware failures. The LM78 is programmed with predetermined threshold values for the following:

 System temperature  Fan speed

 Power supply voltages (+5, +12, −12, +3.52, Vcore)  Intrusion detect for security (detects when chassis lid has been removed, even if power is off)

During system operation, Desktop Management Interface (DMI) code polls the LM78 chip and generates an alert if the measured value is outside of the programmed minimum and maximum range. The alert can be provided to a network administrator across a LAN.

Note: DMI is software used to gather information about the hardware and software in a computer. It

allows network administrators to remotely monitor and control the computer. DMI can be used to remotely track many types of information about networked PCs. This information can be accessed using a DMI browser. DMI browsers are provided by all major operating system and all major LAN management packages.

The following table shows the typical system resource assignments for the system management controller.

Table 10. System Resource Assignments for the System Management Controller

Resource Resource Assignment

ROM None RAM None I/O Address (Hex) 0290, 0295, 0296 IRQ None DMA None

When the computer is started, the resource assignments are subject to change during POST.

Chapter 2. System Board Features 19

Riser Card

The riser card in PC 300PL computers contains all the cable connectors for the system. The following illustrations show the physical layout of the riser card in each computer:

Chapter 2. System Board Features

PCI

Shared

ISA ISA

Front Panel Audio

CD-ROM Audio

340-Pin Connector

Figure 1. Riser Card for PC 300PL (Type 6562)

ISA

Power (Back)

Modem Wakeup

Wake On LAN

Diskette Power

Secondary IDE Diskette Drive

SCSI Hard Disk LED

System Front Panel

Primary IDE (Back)

Diskette Drive (Back)

3.5 V Select (Back) Fan

ISA PCI

PCI

Front Panel Audio

CD-ROM Audio

340-Pin Connector

Power (Back)

Primary IDE (Back)

Secondary IDE (Back)

Modem Wakeup SCSI Hard Disk LED

Wake on LAN

Speaker

LED Panel (Back)

Figure 2. Riser Card for PC 300PL (Type 6592)

The riser card plugs into the system board via a 340-pin connector. Adapters plug into the ISA- or PCI-expansion connectors (slots) on the riser card. Signals from adapters are routed to the ISA or PCI buses. Each ISA-expansion connector provides a 16-bit-wide data path, and each PCI-expansion connector provides a 32-bit-wide data path.

The following table shows the number of ISA, PCI, and shared ISA/PCI expansion slots provided with each type of PC 300PL computer. Shared slots will accommodate either an ISA adapter installed in the

20 Technical Information Manual

Chapter 2. System Board Features

ISA connector, or a PCI adapter installed into the PCI connector. Shared slots cannot accommodate ISA and PCI adapters at the same time.

Table 11. Riser Card Expansion Characteristics

Expansion Slot Type Type 6562 Type 6592

Shared ISA/PCI 1 0 Dedicated ISA 1 3 Dedicated PCI 2 3

Each PCI-expansion connector is capable of driving one, low-power Schottky load. Each ISA-expansion connector is capable of driving two, low-power Schottky loads. The ISA bus is permanently set to the PCI bus speed divided by four.

The PCI bus shares interrupts with the ISA bus. Free interrupts are automatically assigned to PCI devices during POST. If no interrupts are available for the PCI devices, an 18xx POST error message is generated.

For information on connector pin assignments, see “ISA Bus Connectors” on page 37 and “PCI Bus Connectors” on page 39.

Chapter 2. System Board Features 21

Chapter 2. System Board Features

System Board Switches

Switches are provided on the system board to allow for custom configuration. The switches, which are contained in an eight-position switch block on the system board, are rocker switches. The side of the rocker that is pushed down is the active side.

Switches 1 through 4 determine the speed of the microprocessor (CPU) and local processor bus. Switch settings for the Intel microprocessors supported by PC 300PL computers are shown in the following table. Note that the two speeds shown for each microprocessor are the microprocessor core speed followed by the local processor bus speed (for example, 166/66 MHz).

Table 12. Microprocessor Speed (Switches 1-4)

Microprocessor Switch 1 (BF0) Switch 2 (BF1) Switch 3 (CLK0) Switch 4 (CLK1)

166/66 MHz On On On Off 200/66 MHz Off On On Off 233/66 MHz Off Off On Off

PC 300PL computers are designed to support other microprocessors. Switches 1 and 2 determine the local processor bus/microprocessor core ratio. (For instance, 166/66 is a 2/5 ratio.) Switches 3 and 4 control the local processor bus speed. (For instance, the 166/66 has a 66 MHz local processor bus speed.)

Note: Only the switch values shown in the preceding table are supported. Using unsupported switch

settings will cause unpredictable results.

Off

Switch 5 is reserved and should remain in the factory default

Table 13. Reserved (Switch 5)

Reserved Off (factory default)

Switch 6 enables or disables the system board Ethernet. When the Ethernet disable switch is

position.

, the system board Ethernet is disabled. This switch must be on when a Wake on LAN adapter is installed. (Note that only one Wake on LAN device can be used.)

Table 14. System Board Ethernet Control (Switch 6)

Disable On Enable (factory default) Off

Switch 7 enables or disables the privileged access password (PAP). Note that this password is also referred to as the

administrator password Options in Your PC 300PL (Type 6562) Your PC 300PL (Type 6592)

Table 15. Privileged Access Password Control (Switch 7)

Disable (factory default) Off Enable On

for important information on erasing lost or forgotten passwords.

. Refer to

Using Your PC 300PL (Type 6592)

Using Your PC 300PL (Type 6562)

and

Installing Options in

Installing

22 Technical Information Manual

Chapter 2. System Board Features

Switch 8 controls writes to the diskette drive.

Table 16. Floppy Device Access (Switch 8)

Write enabled (factory default) Off Write protected On

System Board Jumper

A jumper is provided on the system board for clearing CMOS memory. Refer to

PC 300PL (Type 6562) (Type 6592)

Table 17. CMOS Operation

Function Jumper Position

Normal operation (factory default) 1-2 Clear CMOS 2-3

and

Using Your PC 300PL (Type 6562)

Using Your PC 300PL (Type 6592)

Installing Options in Your PC 300PL

for important information on clearing CMOS.

Installing Options in Your

Chapter 2. System Board Features 23

Chapter 2. System Board Features

Physical Layout

PC 300PL computers incorporate a new system board and riser card design. There are no cables on the system board; all cables are on the riser card. The system board is on a sliding mechanism so that the board can be moved in and out of the computer without removing any cables. The new design eliminates cable clutter on the system board, allows for shorter cable lengths, simplifies peripheral upgrades, and provides better cooling for system components.

The system board has gold-edge tabs that contain all signals to the riser card. The gold-edge tabs insert into a 340-pin connector on the riser card.

The following is an illustration of the PC 300PL system board. Note that, in various PC 300PL computers, the system board might look slightly different from the one shown here. A diagram of the system board, including switch and jumper settings, is attached to the underside of the top cover of the computer.

Note: For other system connectors, refer to “Riser Card” on page 20.

.1/ Monitor connector .2/ Mouse/keyboard connectors

(top=mouse, bottom=keyboard)

.3/ Serial connectors

(top=serial port 2, bottom=serial port 1)

.4/ USB connectors (top=USB2, bottom=USB1) .5/ Parallel connector .6/ Ethernet RJ45 connector .7/ Audio line in jack .8/ Audio line out jack .9/ Matrox Rainbow Runner Studio upgrade connector .1ð/ VESA feature connector .11/ Infrared connector .12/ Video memory or

Rainbow Runner Studio upgrade connector

.13/ Battery .14/ SW1 (8-position rocker switch) .15/ Microprocessor socket .16/ DIMM socket 0 .17/ DIMM socket 1 .18/ DIMM socket 2 .19/ CMOS clear jumper .2ð/ System board latch .21/ Video memory or

Rainbow Runner Studio upgrade connector

OFF 1 ON

24 Technical Information Manual

Figure 3. System Board

Chapter 3. Adapters and Internal Drives

This chapter provides information on adapters and internal drives supported by PC 300PL computers.

Adapters

This section provides information on the adapters preinstalled in some PC 300PL computers, as well as cabling requirements for Wake on LAN adapters.

Note: PC 300PL computers do not support IDE expansion adapters or the IBM PCMCIA adapter for PCI.

SCSI Adapter

Some PC 300PL computers come with an Adaptec SCSI-II Ultra Wide adapter installed in one of the expansion slots. This adapter provides an interface between the PCI bus and SCSI devices. SCSI technology is useful with multitasking operating environments because instructions can be sent concurrently to every drive in the system, and the drives can then execute these instructions simultaneously.

An extra cable is provided with SCSI models. The cable included with the PC 300PL (Type 6562) has four connectors: one connector for attaching the cable to the SCSI adapter and three connectors for attaching optional SCSI devices. The cable included with the PC 300PL (Type 6592) has five connectors: one connector for attaching the cable to the SCSI adapter and four connectors for attaching optional SCSI devices.

For information on the adapter and connecting SCSI devices, refer to the SCSI documentation that comes with PC 300PL computers.

Cabling Requirements for Wake on LAN Adapters

Wake on LAN adapters have two headers: a 3-pin, right-angle header for providing AUX5 (Auxiliary 5 volts), and a 2-pin straight header for connecting the wakeup signal to the system board (or riser card). PC 300PL computers have a 3-pin header on the riser card that provides the AUX5 and wakeup signal connections. The Wake on LAN adapter option will provide a Y-cable that has the 3-pin riser card connector on one end and splits into the 3-pin and 2-pin connectors required to interface the card. When a Wake on LAN adapter is installed in the system and attached to the AUX5 power, the system board Ethernet function must be disabled via switch 6 on the system board (refer to “System Board Switches” on page 22 for switch information).

 Copyright IBM Corp. 1997 25

Chapter 3. Adapters and Internal Drives

Internal Drives

The IDE, SCSI (some models only), and diskette interfaces provide connectors for attaching internal drives.

PC 300PL computers come standard with an internal diskette drive and an internal EIDE or SCSI hard disk drive. Some models also have an internal CD-ROM drive.

The following tables show the characteristics of internal drives that come standard with or are available for PC 300PL computers.

Table 18. Diskette Drives

Characteristics Number/Size

Standard One 3.5-inch, 1.44 MB diskette drive Maximum One diskette drive

Table 19. IDE and SCSI Devices

Characteristics Number/Size or Speed

Standard One EIDE or Ultra Wide SCSI hard disk drive (size varies by model) Standard (some models only) One IDE CD/ROM drive Optional IDE or SCSI hard disk drives and tape backup drives Maximum IDE Devices Three total (Type 6562) Four total (Type 6592) Maximum SCSI Devices Refer to the SCSI documentation shipped with the computer.

Note: The actual number of internal devices that can be installed in PC 300PL computers is limited by

the number of available drive bays in the computers.

26 Technical Information Manual

Chapter 4. Power Supply

Power requirements are supplied by a 145-watt power supply in the PC 300PL (Type 6562), and a 200-watt supply in the PC 300PL (Type 6592). The power supply provides 3.52-volt power for the Pentium microprocessor and core chip sets, as well as 5-volt power for ISA and PCI adapters. Also included is an auxiliary 5-volt (AUX 5) supply to provide power to power management circuitry and the system board Ethernet function, or a Wake on LAN adapter.

The power supply, which has EnergyStar and Extended LAN Wakeup features, converts ac input voltages into dc output voltages. The power supply operates at either 115 V ac or 230 V ac. The voltage setting is manually selected with a switch on the rear of the computer.

The power supply provides power for the following components:  System board

 ISA and PCI adapters

 Internal drives

 Keyboard and auxiliary devices

 USB devices A logic signal on the power connector controls the power supply. (The front panel switch is not directly

connected to the power supply.) The power supply connects to the riser card with a 2 x 10 connector.

 Copyright IBM Corp. 1997 27

Power Input

For power input specifications, refer to Table 36 on page 32.

Power Output

The following tables show the power supply capacity per voltage for the PC 300PL (Type 6562) and PC 300PL (Type 6592). In the tables, amperes are designated with an A, and milliamperes with an mA.

Table 20. Power Output for 145-Watt Power Supply (PC 300PL, Type 6562)

Output Voltage Minimum to Maximum Regulation Limits

+5 V dc 1.5 to 18.0 A6 +5% to −4% +12 V dc 0.2 to 4.2 A +5% to −5%

−12 V dc 0.0 to 0.4 A +10% to −9%

−5 V dc 0.0 to 0.3 A +10% to −10% +3.52 V dc 0.0 to 10.0 A6 ±2% +5 V dc (auxiliary) 5 mA to 0.72 A ±5% to −10%

Chapter 4. Power Supply

Table 21. Power Output for 200-Watt Power Supply (PC 300PL, Type 6592)

Output Voltage Minimum to Maximum Regulation Limits

+5 V dc 1.5 to 20.0 A7 +5% to −4% +12 V dc 0.2 to 8.0 A +5% to −5%

−12 V dc 0.0 to 0.4 A +10% to −9%

−5 V dc 0.0 to 0.3 A +10% to −10% +3.52 V dc 0.0 to 20.0 A7 ±2% +5 V dc (auxiliary) 5 mA to 0.72 A ±5% to −10%

The power supply provides separate voltage sources for the system board and internal storage devices. The following tables show the maximum power that specific system components can draw. In normal operation, components draw less current than the maximum shown.

Table 22. System Board Power Connectors

Supply Voltage Maximum Current Regulation Limits

+3.52 V dc 8520 mA ±2% +5.0 V dc 2000 mA +5.0% to −4.0% +12.0 V dc 25.0 mA +5.0% to −5.0%

−12.0 V dc 25.0 mA +10.0% to −9.0%

Simultaneous loading of +3.52 V dc and +5 V dc must not exceed 90 watts.

Simultaneous loading of +3.52 V dc and +5 V dc must not exceed 120 watts.

28 Technical Information Manual

Chapter 4. Power Supply

Table 23. ISA-Bus Adapters (Per Slot)

Supply Voltage Maximum Current Regulation Limits

+5.0 V dc 2000 mA +5.0% to −4.0%

−5.0 V dc 100 mA ±10.0% +12.0 V dc 175 mA +5.0% to −5.0%

−12.0 V dc 100 mA +10.0% to −9.0%

Table 24. PCI-Bus Adapters (Per Slot)

Supply Voltage Maximum Current Regulation Limits

+5.0 V dc 5000 mA +5.0% to −4.0% +3.52 V dc 7600 mA ±2.0% +12 V dc 500 mA ±5.0%

−12 V dc 100 mA ±10.0%

Notes:

1. For each PCI connector, the maximum power consumption is rated at 25 watts for +5 V and +3.52 V combined.

2. Maximum current cannot be supplied to all components at all times. System power and cooling are designed to support the statistical RMS power load and typical combinations of adapters.

Table 25. Internal Devices (DASD)

Supply Voltage Maximum Current Regulation Limits

+5.0 V dc 900 mA +5.0% to −5.0% +12.0 V dc 1400 mA startup; 400 mA active +5.0% to −5.0%

Note: Some adapters and hard disk drives draw more current than the recommended limits. These

adapters and drives can be installed in the system; however, the power supply will shut down if the total power used exceeds the maximum power that is available.

Table 26. Keyboard Port

Supply Voltage Maximum Current Regulation Limits

+5.0 V dc 275 mA +5.0% to −4.0%

Table 27. Auxiliary Device Port

Supply Voltage Maximum Current Regulation Limits

+5.0 V dc 300 mA +5.0% to −4.0%

Table 28. USB Port

Supply Voltage Maximum Current Regulation Limits

+5.0 V dc 500 mA +5.0% to −4.0%

Chapter 4. Power Supply 29

Chapter 4. Power Supply

Output Protection

The power supply protects against output overcurrent, overvoltage, and short circuits. A short circuit that is placed on any dc output (between outputs or between an output and dc return)

latches all dc outputs into a shutdown state, with no damage to the power supply. If this shutdown state occurs, the power supply returns to normal operation only after the fault has been removed and the ac input voltage has been turned off for at least five seconds.

If an overvoltage fault occurs (in the power supply), the power supply latches all dc outputs into a shutdown state before any output exceeds 130% of the nominal value of the power supply.

Power Connectors

The power supply connects to the riser card via a single 2 x 10 connector. The power supply provides 4-pin connectors for attaching internal devices. The PC 300PL (Type 6562)

has three DASD connectors, and the PC 300PL (Type 6592) has one diskette and four DASD connectors. The following tables list the pin assignments for these connectors.

Note: The total power used by the any of following connectors must not exceed the amount shown in

Table 25 on page 29.

Table 29. Pin Assignments for the 4-Pin Power Connectors (PC 300PL, Type 6562)

Connector Location Pin 1 Pin 2 Pin 3 Pin 4

P2 DASD +12 V Ground Ground +5 V P3 DASD +12 V Ground Ground +5 V P4 DASD +12 V Ground Ground +5 V

Table 30. Pin Assignments for the 4-Pin Power Connectors (PC 300PL, Type 6592)

Connector Location Pin 1 Pin 2 Pin 3 Pin 4

P3 3.5-inch diskette drive +5 V Ground Ground +12 V P4 DASD +12 V Ground Ground +5 V P5 DASD +12 V Ground Ground +5 V P6 DASD +12 V Ground Ground +5 V P7 DASD +12 V Ground Ground +5 V

30 Technical Information Manual

Chapter 5. Physical Specifications

The tables in this chapter list the physical specifications for PC 300PL computers. Note: The computers are electromagnetically compatible with FCC Class B.

Table 31. Size

Description Measurement (Type 6562) Measurement (Type 6592)

Depth 450 mm (17.7 in.) 445 mm (17.5 in.) Height 128 mm (5.0 in.) 492 mm (19.4 in.) Width 450 mm (17.7 in.) 200 mm (7.9 in.)

Table 32. Weight

Description Measurement (Type 6562) Measurement (Type 6592)

Minimum configuration 9.9 kg (22 lb) 15 kg (33 lb) Maximum configuration 11.3 kg (25 lb) 17.3 kg (38 lb)

Table 33. Cables

Description Measurement

Power cable 1.63 m (5 ft 4 in.) Keyboard cable 1.83 m (6 ft) Ribbon cable (IDE interface) 0.51 m (1 ft 8 in.) SCSI cable (models with SCSI adapter only) 0.91 m (3 ft)

Table 34. Air Temperature

Description Measurement

System on 10 to 35°C (50 to 95°F) System off 10 to 43°C (50 to 110°F)

Note: The maximum altitude at which the specified air temperatures apply is 2134 m (7000 ft). At

higher altitudes, the maximum air temperatures are lower than those specified.

Table 35. Humidity

Description Measurement

System on 8% to 80% System off 8% to 80%

 Copyright IBM Corp. 1997 31

Chapter 5. Physical Specifications

In the following two tables, maximum power and heat specifications are based on the maximum capacity of the power supply (145-watt maximum for Type 6562 and 200-watt maximum for Type 6592).

Table 36. Electrical Input

Description Measurement

Low range 90 V ac (minimum)

137 V ac (maximum) 100 to 127 V ac (nominal)

High range 180 V ac (minimum)

265 V ac (maximum)

200 to 240 V ac (nominal) Sine-wave input 50 to 60 Hz is required Input kilovolt-amperes, minimum (approximate) 0.08 kVA (Types 6562 and 6592) Input kilovolt-amperes, maximum (approximate) 0.37 kVA (Type 6562) 0.52 kVA (Type 6592)

Table 37. Heat Output (Approximate)

Description Measurement (Type 6562) Measurement (Type 6592)

Minimum configuration 35 W (120 Btu per hour) 35 W (120 Btu per hour) Theoretical maximum configuration

207 W (704 Btu per hour) 285 W (970 Btu per hour)

Under typical maximum configurations, the heat output will be significantly below the theoretical maximum.

32 Technical Information Manual

Chapter 6. System Compatibility

This chapter provides information on some of the hardware, software, and BIOS compatibility issues for the PC 300PL (Type 6562) and (Type 6592). For a list of compatible hardware and software option packages available, refer to the http://www.us.pc.ibm.com/cdt.

Hardware Compatibility

This section discusses hardware and BIOS compatibility issues that must be considered when designing application programs.

Many of the interfaces are the same as those used by the IBM Personal Computer AT. In most cases, the command and status organization of these interfaces is maintained.

The functional interfaces are compatible with the following interfaces:

 The Intel 8259 interrupt controllers (edge-triggered mode)

Compatibility Report

for these computers on the World Wide Web at

 The National Semiconductor NS16450 and NS16550A serial communication controllers  The Motorola MC146818 Time of Day Clock command and status (CMOS reorganized)  The Intel 8254 timer, driven from a 1.193 MHz clock (channels 0, 1, and 2)  The Intel 8237 DMA controller, except for the Command and Request registers and the Rotate and

Mask functions; the Mode register is partially supported

 The Intel 8272 or 82077 diskette drive controllers  The Intel 8042 keyboard controller at addresses 0060h and 0064h  All video standards using VGA, EGA, CGA, MDA, and Hercules modes  The parallel printer ports (Parallel 1, Parallel 2, and Parallel 3) in compatibility mode

Use the following information to develop application programs. Whenever possible, use the BIOS as an interface to hardware to provide maximum compatibility and portability of applications among systems.

 Copyright IBM Corp. 1997 33

Chapter 6. System Compatibility

Hardware Interrupts

Hardware interrupts are level-sensitive for PCI interrupts and edge-sensitive for ISA interrupts. The interrupt controller clears its in-service register bit when the interrupt routine sends an End of Interrupt (EOI) command to the controller. The EOI command is sent regardless of whether the incoming interrupt request to the controller is active or inactive.

The interrupt-in-progress latch is readable at an I/O-address bit position. This latch is read during the interrupt service routine and might be reset by the read operation, or it might require an explicit reset.

Note: For performance and latency considerations, designers might want to limit the number of devices

sharing an interrupt level.

With level-sensitive interrupts, the interrupt controller requires that the interrupt request be inactive at the time the EOI command is sent; otherwise, a new interrupt request will be detected. To avoid this, a level-sensitive interrupt handler must clear the interrupt condition (usually by a read or write operation to an I/O port on the device causing the interrupt). After processing the interrupt, the interrupt handler:

1. Clears the interrupt

2. Waits one I/O delay

3. Sends the EOI

4. Waits one I/O delay

5. Enables the interrupt through the Set Interrupt Enable Flag command

Hardware interrupt IRQ9 is defined as the replacement interrupt level for the cascade level IRQ2. Program interrupt sharing is implemented on IRQ2, interrupt 0Ah. The following processing occurs to maintain compatibility with the IRQ2 used by IBM Personal Computer products:

1. A device drives the interrupt request active on IRQ2 of the channel.

2. This interrupt request is mapped in hardware to IRQ9 input on the second interrupt controller.

3. When the interrupt occurs, the system microprocessor passes control to the IRQ9 (interrupt 71h) interrupt handler.

4. This interrupt handler performs an EOI command to the second interrupt controller and passes control to the IRQ2 (interrupt 0Ah) interrupt handler.

5. This IRQ2 interrupt handler, when handling the interrupt, causes the device to reset the interrupt request before performing an EOI command to the master interrupt controller that finishes servicing the IRQ2 request.

34 Technical Information Manual

Chapter 6. System Compatibility

Diskette Drives and Controller

The following table shows the reading, writing, and formatting capabilities for the diskette drive type supported by PC 300PL computers.

Table 38. 3.5-Inch Diskette Drive Reading, Writing, and Formatting Capabilities

Diskette Drive Type 720 KB Mode 1.44 MB Mode 2.88 MB Mode

1.44 MB drive RWF RWF Not supported

Copy Protection

The following methods of copy protection might not work in systems using the 3.5-inch, 1.44 MB diskette drive.

 Bypassing BIOS routines:

– Data transfer rate: BIOS selects the proper data transfer rate for the media being used. – Diskette parameter table: Copy protection, which creates its own diskette parameter table, might

not work in these drives.

 Diskette drive controls:

– Rotational speed: The time between two events in a diskette drive is a function of the controller. – Access time: Diskette BIOS routines must set the track-to-track access time for the different types

of media that are used in the drives.

– ‘Diskette change’ signal: Copy protection might not be able to reset this signal.

 Write-current control: Copy protection that uses write-current control does not work, because the

controller selects the proper write current for the media that is being used.

Hard Disk Drives and Controller

Reading from and writing to the hard disk is initiated in the same way as in other IBM Personal Computer products; however, new functions are supported.

Software Compatibility

To maintain software compatibility, the interrupt polling mechanism that is used by IBM Personal Computer products is retained. Software that interfaces with the reset port for the IBM Personal Computer positive-edge interrupt sharing (hex address 02Fx or 06Fx, where x is the interrupt level) does not create interference.

Software Interrupts

With the advent of software interrupt sharing, software interrupt routines must daisy-chain interrupts. Each routine must check the function value, and if it is not in the range of function calls for that routine, it must transfer control to the next routine in the chain. Because software interrupts are initially pointed to address 0:0 before daisy chaining, check for this case. If the next routine is pointed to address 0:0 and the function call is out of range, the appropriate action is to set the carry flag and do a RET 2 to indicate an error condition.

Chapter 6. System Compatibility 35

Machine-Sensitive Programs

Programs can select machine-specific features, but they must first identify the machine and model type. IBM has defined methods for uniquely determining the specific machine type. The machine model byte can be found through Interrupt 15H, Return System Configuration Parameters function ((AH)=C0H).

Chapter 6. System Compatibility

36 Technical Information Manual

Appendix A. Connector Pin Assignments

The following tables show the pin assignments for various riser card and system board connectors.

ISA Bus Connectors

A31

B31C1D1

C18

D18

Figure 4. ISA Bus Connector

The ISA bus connectors are located on the riser card.

Table 39 (Page 1 of 2). Pin Assignments for the ISA Bus Connectors

Pin Signal Name I/O Pin Signal Name I/O

B1 Ground NA A1 IOCHCK# I B2 RESET DRV O A2 SD7 I/O B3 +5 V dc NA A3 SD6 I/O B4 IRQ2/9 I A4 SD5 I/O B5 −5 V dc NA A5 SD4 I/O B6 DRQ2 I A6 SD3 I/O B7 −12 V dc NA A7 SD2 I/O B8 0WS# I A8 SD1 I/O B9 +12 V dc NA A9 SD0 I/O B10 Ground NA A10 IOCHRDY I B11 SMEMW# O A11 AEN O B12 SMEMR# O A12 SA19 I/O B13 IOW# I/O A13 SA18 I/O B14 IOR# I/O A14 SA17 I/O B15 DACK3# O A15 SA16 I/O B16 DRQ3 I A16 SA15 I/O B17 DACK1# O A17 SA14 I/O B18 DRQ1 I A18 SA13 I/O B19 REFRESH# I/O A19 SA12 I/O B20 CLK O A20 SA11 I/O B21 IRQ7 I A21 SA10 I/O B22 IRQ6 I A22 SA9 I/O B23 IRQ5 I A23 SA8 I/O B24 IRQ4 I A24 SA7 I/O B25 IRQ3 I A25 SA6 I/O B26 DACK2# O A26 SA5 I/O B27 TC O A27 SA4 I/O B28 BALE O A28 SA3 I/O

 Copyright IBM Corp. 1997 37

Table 39 (Page 2 of 2). Pin Assignments for the ISA Bus Connectors

Pin Signal Name I/O Pin Signal Name I/O

B29 +5 V dc NA A29 SA2 I/O B30 OSC O A30 SA1 I/O B31 Ground NA A31 SA0 I/O

D1 MEMCS16# I C1 SBHE# I/O D2 IOCS16# I C2 LA23 I/O D3 IRQ10 I C3 LA22 I/O D4 IRQ11 I C4 LA21 I/O D5 IRQ12 I C5 LA20 I/O D6 IRQ15 I C6 LA19 I/O D7 IRQ14 I C7 LA18 I/O D8 DACK0# O C8 LA17 I/O D9 DRQ0 I C9 MEMR# I/O D10 DACK5# O C10 MEMW# I/O D11 DRQ5 I C11 SD8 I/O D12 DACK6# O C12 SD9 I/O D13 DRQ6 I C13 SD10 I/O D14 DACK7# O C14 SD11 I/O D15 DRQ7 I C15 SD12 I/O D16 +5 V dc NA C16 SD13 I/O D17 MASTER# I C17 SD14 I/O D18 Ground NA C18 SD15 I/O

Appendix A. Connector Pin Assignments

38 Technical Information Manual

Appendix A. Connector Pin Assignments

PCI Bus Connectors

A62

B62

Figure 5. PCI Bus Connector

Note: The PCI bus connectors are located on the riser card.

Table 40 (Page 1 of 2). Pin Assignments for the PCI Bus Connectors

Pin Signal Name I/O Pin Signal Name I/O

A1 TRST# O B1 −12 V dc NA A2 +12 V dc NA B2 TCK O A3 TMS O B3 Ground NA A4 TDI O B4 TDO I A5 +5 V dc NA B5 +5 V dc NA A6 INTA# I B6 +5 V dc NA A7 INTC# I B7 INTB# I A8 +5 V dc NA B8 INTD# I A9 Reserved NA B9 PRSNT1# I A10 +5 V dc NA B10 Reserved NA A11 Reserved NA B11 PRSNT2# I A12 Ground NA B12 Ground NA A13 Ground NA B13 Ground NA A14 Reserved NA B14 Reserved NA A15 RST# O B15 Ground NA A16 +5 V dc NA B16 CLK O A17 GNT# O B17 Ground NA A18 Ground NA B18 REQ# I A19 Reserved NA B19 +5 V dc NA A20 Address/Data 30 I/O B20 Address/Data 31 I/O A21 +3.52 V dc NA B21 Address/Data 29 I/O A22 Address/Data 28 I/O B22 Ground NA A23 Address/Data 26 I/O B23 Address/Data 27 I/O A24 Ground NA B24 Address/Data 25 I/O A25 Address/Data 24 I/O B25 +3.52 V dc NA A26 IDSEL O B26 C/BE3# I/O A27 +3.52 V dc NA B27 Address/Data 23 I/O A28 Address/Data 22 I/O B28 Ground NA A29 Address/Data 20 I/O B29 Address/Data 21 I/O A30 Ground NA B30 Address/Data 19 I/O A31 Address/Data 18 I/O B31 +3.52 V dc NA A32 Address/Data 16 I/O B32 Address/Data 17 I/O A33 +3.52 V dc NA B33 C/BE2# I/O

Appendix A. Connector Pin Assignments 39

Table 40 (Page 2 of 2). Pin Assignments for the PCI Bus Connectors

Pin Signal Name I/O Pin Signal Name I/O

A34 FRAME# I/O B34 Ground NA A35 Ground NA B35 IRDY# I/O A36 TRDY# I/O B36 +3.52 V dc NA A37 Ground NA B37 DEVSEL# I/O A38 STOP# I/O B38 Ground NA A39 +3.52 V dc NA B39 LOCK# I/O A40 SDONE I/O B40 PERR# I/O A41 SBO# I/O B41 +3.52 V dc NA A42 Ground NA B42 SERR# I/O A43 PCIPAR NA B43 +3.52 V dc NA A44 Address/Data 15 I/O B44 C/BE1# I/O A45 +3.52 V I/O B45 Address/Data 14 I/O A46 Address/Data 13 NA B46 Ground NA A47 Address/Data 11 I/O B47 Address/Data 12 I/O A48 Ground I/O B48 Address/Data 10 I/O A49 Address/Data 9 NA B49 Ground NA A50 ##Key## NA B50 ##Key## NA A51 ##Key## NA B51 ##Key## NA A52 C/BE0# I/O B52 Address/Data 8 I/O A53 +3.52 V dc I/O B53 Address/Data 7 I/O A54 Address/Data 6 NA B54 +3.52 V dc NA A55 Address/Data 4 I/O B55 Address/Data 5 I/O A56 Ground I/O B56 Address/Data 3 I/O A57 Address/Data 2 NA B57 Ground NA A58 Address/Data 0 I/O B58 Address/Data 1 I/O A59 +5 V dc NA B59 +5 V dc NA A60 REQ64# I/O B60 ACK64# I/O A61 +5 V dc NA B61 +5 V dc NA A62 +5 V dc NA B62 +5 V dc NA

Appendix A. Connector Pin Assignments

40 Technical Information Manual

Appendix A. Connector Pin Assignments

IDE Connectors

Figure 6. IDE Connector

The IDE connectors are 40-pin, shrouded berg strips located on the riser card.

Table 41. Pin Assignments for the IDE Connectors

Pin Signal Name I/O Pin Signal Name I/O

1 Reset O 2 Ground NA 3 D7 I/O 4 D8 I/O 5 D6 I/O 6 D9 I/O 7 D5 I/O 8 D10 I/O 9 D4 I/O 10 D11 I/O 11 D3 I/O 12 D12 I/O 13 D2 I/O 14 D13 I/O 15 D1 I/O 16 D14 I/O 17 D0 I/O 18 D15 I/O 19 Ground NA 20 Key NA 21 DMA REQ NA 22 Ground NA 23 IOW# O 24 Ground NA 25 IOR# O 26 Ground NA 27 IOCHRDY I 28 CSEL O 29 DMA ACK# NA 30 Ground NA 31 IRQ I 32 CS16# I 33 SA1 O 34 No connect I 35 SA0 O 36 SA2 O 37 CS0# O 38 CS1# O 39 Active# I 40 Ground NA

Appendix A. Connector Pin Assignments 41

Diskette Drive Connector

Appendix A. Connector Pin Assignments

Figure 7. Diskette Drive Connector

The diskette drive connector is a 34-pin, shrouded berg strip located on the riser card.

Table 42. Pin Assignments for the Diskette Drive Connector

Pin Signal Name I/O Pin Signal Name I/O

1 Drive 2 installed# I 2 High density select O 3 Not connected NA 4 Not connected NA 5 Ground NA 6 Data rate 0 NA 7 Ground NA 8 Index# I 9 Reserved NA 10 Motor enable 0# O 11 Ground NA 12 Drive select 1# O 13 Ground NA 14 Drive select 0# O 15 Ground NA 16 Motor enable 1# O 17 MSEN1 I 18 Direction in# O 19 Ground NA 20 Step# O 21 Ground NA 22 Write data# O 23 Ground NA 24 Write enable# O 25 Ground NA 26 Track 0# I 27 MSEN0 I 28 Write protect# I 29 Ground NA 30 Read data# I 31 Ground NA 32 Head 1 select# O 33 Ground NA 34 Diskette change# I

42 Technical Information Manual

Appendix A. Connector Pin Assignments

System Memory Connectors

168

Figure 8. System Memory (DIMM) Connector

Each DIMM connector is a 168-pin, gold-lead, unbuffered, 3.3 V, SDRAM connector.

Table 43 (Page 1 of 3). Pin Assignments for the DIMM Connectors

Pin Signal Name I/O Pin Signal Name I/O

1 Ground NA 85 Ground NA 2 DQ0 I/O 86 DQ32 I/O 3 DQ1 I/O 87 DQ33 I/O 4 DQ2 I/O 88 DQ34 I/O 5 DQ3 I/O 89 DQ35 I/O 6 Vcc I/O 90 Vcc NA 7 DQ4 I/O 91 DQ36 NA 8 DQ5 I/O 92 DQ37 I/O 9 DQ6 I/O 93 DQ38 I/O 10 DQ7 I/O 94 DQ39 I/O 11 DQ8 I/O 95 DQ40 I/O 12 Ground NA 96 Ground NA 13 DQ9 I/O 97 DQ41 I/O 14 DQ10 I/O 98 DQ42 I/O 15 DQ11 O 99 DQ43 I/O 16 DQ12 O 100 DQ44 I/O 17 DQ13 O 101 DQ45 I/O 18 Vcc O 102 Vcc NA 19 DQ14 O 103 DQ46 I/O 20 DQ15 I/O 104 DQ47 I/O 21 CB0 I/O 105 CB4 I/O 22 CB1 I/O 106 CB5 I/O 23 Ground I/O 107 Ground NA 24 NC NA 108 NC NA 25 NC NA 109 NC NA 26 Vcc I/O 110 Vcc NA 27 /WE0 O 111 NC NA 28 DQMB0 O 112 DQMB4 O 29 DQMB1 O 113 DQMB5 O 30 /S0 O 114 /S1 O 31 /OE0 O 115 NC NA 32 Ground O 116 Ground NA 33 A0 O 117 A1 O

Appendix A. Connector Pin Assignments 43

Table 43 (Page 2 of 3). Pin Assignments for the DIMM Connectors

Pin Signal Name I/O Pin Signal Name I/O

34 A2 O 118 A3 O 35 A4 O 119 A5 O 36 A6 O 120 A7 O 37 A8 O 121 A9 O 38 A10 O 122 A11 O 39 NC O 123 NC O 40 Vcc NA 124 Vcc NA 41 Vcc NA 125 NC NA 42 NC NA 126 NC NA 43 Ground NA 127 Ground NA 44 /OE2 O 128 NC NA 45 /S2 O 129 /S3 O 46 DQMB2 O 130 DQMB6 O 47 DQMB3 O 131 DQMB7 O 48 /WE2 O 132 NC NA 49 Vcc O 133 Vcc NA 50 NC NA 134 NC NA 51 NC NA 135 NC NA 52 CB2 I/O 136 CB6 I/O 53 CB3 I/O 137 CB7 I/O 54 Ground NA 138 Ground NA 55 DQ16 I/O 139 DQ48 I/O 56 DQ17 I/O 140 DQ49 I/O 57 DQ18 I/O 141 DQ50 I/O 58 DQ19 I/O 142 DQ51 I/O 59 Vcc NA 143 Vcc NA 60 DQ20 I/O 144 DQ52 I/O 61 NC NA 145 NC NA 62 NC NA 146 NC NA 63 NC NA 147 NC NA 64 Ground NA 148 Ground NA 65 DQ21 I/O 149 DQ53 I/O 66 DQ22 I/O 150 DQ54 I/O 67 DQ23 I/O 151 DQ55 I/O 68 Ground NA 152 Ground NA 69 DQ24 I/O 153 DQ56 I/O 70 DQ25 I/O 154 DQ57 I/O 71 DQ26 I/O 155 DQ58 I/O 72 DQ27 I/O 156 DQ59 I/O 73 Vcc NA 157 Vcc NA 74 DQ28 I/O 158 DQ60 I/O 75 DQ29 I/O 159 DQ61 I/O 76 DQ30 I/O 160 DQ62 I/O

Appendix A. Connector Pin Assignments

44 Technical Information Manual

Appendix A. Connector Pin Assignments

Table 43 (Page 3 of 3). Pin Assignments for the DIMM Connectors

Pin Signal Name I/O Pin Signal Name I/O

77 DQ31 I/O 161 DQ63 I/O 78 Ground NA 162 Ground NA 79 NC I/O 163 NC NA 80 NC I/O 164 NC NA 81 NC I/O 165 SA0 I/O 82 SDA I/O 166 SA1 I/O 83 SCL I/O 167 SA2 I/O 84 Vcc NA 168 Vcc I/O

Notes:

1. DU = Don't use

2. NC = Not connected

Appendix A. Connector Pin Assignments 45

USB Connectors

Appendix A. Connector Pin Assignments

Figure 9. USB Connector

The external interface for the USB ports consists of two, 4-pin connectors.

Table 44. Pin Assignments for the USB Connectors

Pin Signal Name I/O

1 VCC NA 2 -Data I/O 3 +Data I/O 4 Ground NA

Parallel Port Connector

Figure 10. Parallel Port Connector

The external interface for the parallel port is a 25-pin, female, D-shell connector.

Table 45. Pin Assignments for the Parallel Port Connector

Pin Signal Name I/O Pin Signal Name I/O

1 STROBE# I/O 2 D0 I/O 3 D1 I/O 4 D2 I/O 5 D3 I/O 6 D4 I/O 7 D5 I/O 8 D6 I/O 9 D7 I/O 10 ACK# I 11 BUSY I 12 PE I 13 SLCT I 14 AUTO FD XT# O 15 ERROR# I 16 INIT# O 17 SLCT IN# O 18 Ground NA 19 Ground NA 20 Ground NA 21 Ground NA 22 Ground NA 23 Ground NA 24 Ground NA 25 Ground NA

46 Technical Information Manual

Appendix A. Connector Pin Assignments

Serial Port Connectors

Figure 11. Serial Port Connector

The external interface for the serial ports consists of two, 9-pin, male, D-shell connectors (in a stacked configuration).

Table 46. Pin Assignments for the Serial Port Connectors

Pin Signal Name I/O Pin Signal Name I/O

1 Data carrier detect I 2 Receive data# I 3 Transmit data# O 4 Data terminal read O 5 Ground NA 6 Data set ready I 7 Request to send O 8 Clear to send I 9 Ring indicator I

Infrared Port Connector (Optional)

Figure 12. Infrared Port Connector

The external interface for the optional infrared port is a 9-pin, female, D-shell connector.

Table 47. Pin Assignments for the Infrared Connector

Pin Signal Name Signal Definition I/O

1 IRTX Infrared transmitted data (output) O 2 Ground NA 3 Reserved NA 4 IRSL2 Infrared module select 2 O 5 IRSL1 Infrared module select 1 O 6 IRRX Infrared received data (input) I 7 VCC Input voltage (5 V) from system board NA 8 IRSL0 Infrared module select 0 O 9 NC No connect NA

Appendix A. Connector Pin Assignments 47

Keyboard and Mouse Port Connectors

Appendix A. Connector Pin Assignments

6 4

5 3

Figure 13. Keyboard and Mouse Port Connector

The keyboard and mouse ports each have a 6-pin, mini-DIN external connector.

Table 48. Pin Assignments for the Keyboard and Mouse Connectors

Pin Signal Name I/O Pin Signal Name I/O

1 Data I/O 2 Reserved NA 3 Ground NA 4 +5 V dc NA 5 Clock I/O 6 Reserved NA

Monitor Port Connector

10 6

15 11

Figure 14. Monitor Connector

The external interface for the integrated Matrox MGA-1164SG 3D video subsystem is a 15-pin, female, D-shell, DDC2B-compliant connector located on the rear connector panel.

Table 49. Pin Assignments for the Monitor Connector

Pin Signal Name I/O

1 Red O 2 Green O 3 Blue O 4 Monitor ID2 - not used I 5 Ground NA 6 Red ground NA 7 Green ground NA 8 Blue ground NA 9 +5 V, used by DDC2B NA 10 Ground NA 11 Monitor ID 0 - not used I 12 DDC2B serial data I/O 13 Horizontal sync. O 14 Vertical sync. O 15 DDC2B clock I/O

Note: All inputs and outputs are with respect to the system board.

48 Technical Information Manual

Appendix A. Connector Pin Assignments

Ethernet Connector

Figure 15. Ethernet Connector

The external interface for the Ethernet port is an 8-pin, RJ-45 connector.

Table 50. Pin Assignments for the Ethernet Connector

Pin Signal Name I/O

1 TxD+ O 2 TxD− O 3 RxD+ I 4 Ground NA 5 Ground NA 6 RxD− I 7 Ground NA 8 Ground NA

Appendix A. Connector Pin Assignments 49

Appendix B. System Address Maps

System Memory Map

Memory can be mapped differently if POST detects an error.

Table 51. System Memory Map (Fixed Address Ranges)

Address Range (Dec) Address Range (Hex) Size Description

0–511 KB 00000–7FFFF 512 KB Conventional 512 KB–638 KB 80000–9FBFF 127 KB Extended conventional 639 KB 9FC00–9FFFF 1 KB Extended BIOS data (moveable

by HIMEM, QEMM, 386MAX) 640 KB–767 KB A0000–BFFF 128 KB Matrox video RAM 768 KB–799 KB C0000–C7FFF 32 KB Matrox video ROM BIOS

(shadowed) 800 KB–895 KB C8000–DFFFF 96 KB PCI/ISA space – available to ISA

adapter ROMs 896 KB–1 MB E0000–FFFFF 128 KB System ROM BIOS (ISA bus,

main memory shadowed) 1 MB–16 MB 100000–FFFFFF 15 MB PCI/ISA space 16 MB–4095.872 MB 1000000–FFFDFFFF 4079.9 MB PCI space (positive decode)

4095.872 MB–4096 (4 GB) FFFE0000–FFFFFFFF 128 KB System ROM BIOS (ISA bus)

Appendix B. System Address Maps

Table 52. System Memory Map (Flexible Address Ranges)

Range Name Range Size

(Hex)

ROMBASE FFFF 64 KB Matrox ROM address (ROMBASE to ROMBASE+FFFF) MGABASE1 3FFF 16 KB Matrox MGA control aperture MGABASE2 7FFFFF 8 MB Matrox direct frame buffer access aperture MGABASE3 7FFFFF 8 MB Matrox 8 MB pseudo DMA window

Range Size Description

50  Copyright IBM Corp. 1997

Appendix B. System Address Maps

Input/Output Address Map

The following table lists resource assignments for the I/O address map. Any addresses that are not shown are reserved.

Table 53 (Page 1 of 2). Input/Output Address Map

Address (Hex) Size (Dec) Description

0000–001F 32 bytes DMA 1 0020–002D

0030–003F 002E–002F 2 bytes Super I/O controller system board Plug-and-Play index/data registers

0040–0043 0050–0053

0044–004F 0054–005F

0060 1 byte Keyboard controller, data byte (on ISA data bus) 0061 1 byte System port B 0064 1 byte Keyboard controller, command and status byte (on ISA data bus) 0062, 0063,

0065–006F 0070, bit 7 write

only 0070, bits 6:0 7 bits Real-time clock, address (on ISA bus) 0071 1 byte Real-time clock, data (on ISA bus) 0072–0077 6 bytes General I/O locations—available to XD/ISA bus 0078 4 bytes General purpose I/O (GPIO) 007C 4 bytes General purpose I/O (GPIO) 0080 1 byte POST checkpoint register during POST only 0080–008F 16 bytes DMA page registers 0090–009F 16 bytes General I/O locations—available to ISA bus 00A0–00B1

00B4–00BF 00B2 1 byte Advanced power management control 00B3 1 byte Advanced power management status 00C0–00DF 32 bytes DMA 2 00E0–00EF 16 bytes General I/O locations—availabe to ISA bus 00F0 1 byte Coprocessor error register 00F1–00FF 15 bytes General I/O locations—available to ISA bus 0170–0177 8 bytes IDE channel 1 01F0–01F7 8 bytes IDE channel 0 0220–0227 8 bytes COM3 or COM4 0278–027F 8 bytes LPT3 0290, 0295, 0296 3 bytes System management chip 02E8–02EF 8 bytes COM3 or COM4 02F8–02FF 8 bytes COM2 (system board) 0338–033F 8 bytes COM3 or COM4 0376–0377 2 bytes IDE channel 1

30 bytes Interrupt controller 1

(index=002E, data=002F)

8 bytes Counter/timer 1

24 bytes General I/O locations—available to ISA bus

13 bytes General I/O locations—available to ISA bus

1 bit Enable/disable NMI

30 bytes Interrupt controller 2

Appendix B. System Address Maps 51

Table 53 (Page 2 of 2). Input/Output Address Map

Address (Hex) Size (Dec) Description

0378–037F 8 bytes LPT2 03B4–03B7

03BA 03BC–03BE 4 bytes LPT1 (system board) 03C0–03CF

03D4–03D7 03DA

03E8–03EF 8 bytes COM3 or COM4 03F0–03F5 6 bytes Floppy channel 0 03F6 1 byte IDE channel 0 03F7, bit 7 1 bit Floppy disk change 03F7, bits 6:0 7 bits IDE status channel 0 03F8–03FF 8 bytes COM1 (system board) 04D0 1 byte Interrupt edge/level control 1 04D1 1 byte Interrupt edge/level control 2 0CF8–0CFB 4 bytes PCI configuration address register 0CF9 1 byte Reset control register 0CFC–0CFF 4 bytes PCI configuration data register

5 bytes Matrox MGA-1164SG 3D video

20 bytes Matrox MGA-1164SG 3D video

Appendix B. System Address Maps

52 Technical Information Manual

Appendix B. System Address Maps

DMA I/O Address Map

The following table lists resource assignments for the DMA address map. Any addresses that are not shown are reserved.

Table 54 (Page 1 of 2). DMA I/O Addresses

Address (Hex) Description Bits Byte Pointer

0000 Channel 0, Memory Address register 00–15 Yes 0001 Channel 0, Transfer Count register 00–15 Yes 0002 Channel 1, Memory Address register 00–15 Yes 0003 Channel 1, Transfer Count register 00–15 Yes 0004 Channel 2, Memory Address register 00–15 Yes 0005 Channel 2, Transfer Count register 00–15 Yes 0006 Channel 3, Memory Address register 00–15 Yes 0007 Channel 3, Transfer Count register 00–15 Yes 0008 Channels 0–3, Read Status/Write Command register 00–07 0009 Channels 0–3, Write Request register 00–02 000A Channels 0–3, Write Single Mask register bits 00–02 000B Channels 0–3, Mode register (write) 00–07 000C Channels 0–3, Clear byte pointer (write) NA 000D Channels 0–3, Master clear (write)/temp (read) 00–07 000E Channels 0–3, Clear Mask register (write) 00–03 000F Channels 0–3, Write All Mask register bits 00–03 0081 Channel 2, Page Table Address register 0082 Channel 3, Page Table Address register 0083 Channel 1, Page Table Address register 0087 Channel 0, Page Table Address register 0089 Channel 6, Page Table Address register 008A Channel 7, Page Table Address register 008B Channel 5, Page Table Address register 008F Channel 4, Page Table Address/Refresh register 00–07 00C0 Channel 4, Memory Address register 00–15 Yes 00C2 Channel 4, Transfer Count register 00–15 Yes 00C4 Channel 5, Memory Address register 00–15 Yes 00C6 Channel 5, Transfer Count register 00–15 Yes 00C8 Channel 6, Memory Address register 00–15 Yes 00CA Channel 6, Transfer Count register 00–15 Yes 00CC Channel 7, Memory Address register 00–15 Yes 00CE Channel 7, Transfer Count register 00–15 Yes 00D0 Channels 4–7, Read Status/Write Command register 00–07 00D2 Channels 4–7, Write Request register 00–02 00D4 Channels 4–7, Write Single Mask register bit 00–02

9 9 9 9 9 9 9

00–07 00–07 00–07 00–07 00–07 00–07 00–07

Upper byte of memory address register.

Appendix B. System Address Maps

Table 54 (Page 2 of 2). DMA I/O Addresses

Address (Hex) Description Bits Byte Pointer

00D6 Channels 4–7, Mode register (write) 00–07 00D8 Channels 4–7, Clear byte pointer (write) NA 00DA Channels 4–7, Master clear (write)/temp (read) 00–07 00DC Channels 4–7, Clear Mask register (write) 00–03 00DE Channels 4–7, Write All Mask register bits 00–03 00DF Channels 5–7, 8- or 16-bit mode select 00–07

Appendix B. System Address Maps

54 Technical Information Manual

Appendix C. IRQ and DMA Channel Assignments

The following tables list the IRQ (interrupt request) and DMA (direct memory access) channel assignments for PC 300PL computers.

Table 55. IRQ Channel Assignments

IRQ System Resource

NMI Critical system error SMI System management interrupt – power management 0 Reserved, internal timer 1 Reserved, keyboard buffer full 2 Reserved, cascade interrupt from slave PIC 3 Serial port 2 if enabled; otherwise, user available for ISA or PCI bus 4 Serial port 1 if enabled; otherwise, user available for ISA bus 5 Parallel port 2 if enabled; otherwise, user available for ISA or PCI bus 6 Diskette drive controller 7 Parallel port 1 if enabled; otherwise, user available for ISA bus 8 Reserved, real-time clock 9 User available for ISA or PCI bus 10 User available for ISA or PCI bus 11 User available for ISA or PCI bus 12 System board mouse port if enabled; otherwise, user available for ISA or PCI bus 13 Reserved, math coprocessor 14 IDE channel 1 if enabled; otherwise user available for ISA or PCI bus 15 IDE channel 2 if enabled; otherwise user available for ISA or PCI bus

Note: Audio IRQ and DMA resources are required and are assigned by the Plug and Play BIOS or

operating system.

Table 56. DMA Channel Assignments

DMA Channel Data Width System Resource

0 8 bits only User available for ISA bus 1 8 bits only User available for ISA bus 2 8 bits only Reserved, floppy 3 8 bits only Parallel port if ECP; otherwise user available for ISA bus 4 Reserved–cascade channel 5 16 bits only User available for ISA bus 6 16 bits only User available for ISA bus 7 16 bits only User available for ISA bus

Note: Channels 0–3 can transfer data in 64 KB pages; channels 5–7 can transfer data in 128 KB pages.

Appendix D. Error Codes

The following tables list the POST error codes and beep error codes for the PC 300PL (Type 6562) and PC 300PL (Type 6592).

POST Error Codes

POST error messages appear when POST finds problems with the hardware during power-on or when a change in the hardware configuration is found. POST error messages are 3-, 4-, 5-, 8-, or 12-character alphanumeric messages. An x in an error message can represent any number.

Table 57 (Page 1 of 2). POST Error Codes

Code Description

101 Interrupt failure 102 Timer failure 103 Timer-interrupt failure 104 Protected mode failure 105 Last 8042 command not accepted – keyboard failure 106 System board failure 108 Timer bus failure 109 Low MB chip select test 110 System board parity error 1 (system board parity latch set) 111 I/O parity error 2 (I/O channel check latch set) 112 I/O channel check error 113 I/O channel check error 114 External ROM checksum error 115 DMA error 116 System board port read/write error 120 Microprocessor test error 121 Hardware error 151 Real time clock failure 161 Bad CMOS Battery 162 CMOS RAM checksum/configuration error 163 Clock not updating 164 CMOS RAM memory size does not match 167 Clock not updating 175 Riser card or system board error 176 System cover has been removed 177 Corrupted administrator password 178 Riser card or system board error 183 Administrator password has been set and must be entered 184 Password removed due to checksum error 185 Corrupted boot sequence 186 System board or hardware security error 189 More than three password attempts were made to access system

56 Technical Information Manual

Appendix D. Error Codes

Table 57 (Page 2 of 2). POST Error Codes

Code Description

201 Memory data error 202 Memory address line error 00-15 203 Memory address line error 16-23 221 ROM to RAM remapping error 225 Unsupported memory type installed or memory pair mismatch 301 Keyboard error 302 Keyboard error 303 Keyboard to system board interface error 304 Keyboard clock high 305 No keyboard +5Vdc 601 Diskette drive or controller error 602 Diskette IPL boot record not valid 604 Unsupported diskette drive installed 605 POST cannot unlock diskette drive 662 Diskette drive configuration error 762 Math coprocessor configuration error 11xx Serial port error (xx = serial port number) 1762 Hard disk configuration error 1780 Hard disk 0 failed 1781 Hard disk 1 failed 1782 Hard disk 2 failed 1783 Hard disk 3 failed 1800 PCI adapter has requested an unavailable hardware interrupt 1801 PCI adapter has requested an unavailable memory resource 1802 PCI adapter has requested an unavailable I/O address space, or the adapter is defective 1803 PCI adapter has requested an unavailable memory address space, or the adapter is defective 1804 PCI adapter has requested unavailable memory addresses 1805 PCI adapter ROM error 1962 Boot sequence error 2401 System board video error 8601 System board - keyboard/pointing device error 8602 Pointing device error 8603 Pointing device or system board error 12092 Level 1 cache error (Processor chip) 12094 Level 2 cache error I9990301 Hard disk failure I9990305 No operating system found

Appendix D. Error Codes 57

Appendix D. Error Codes

Beep Codes

For the following beep codes, the numbers indicate the sequence and number of beeps. For example, a “2-3-2” error symptom (a burst of two beeps, three beeps, then two beeps) indicates a memory module problem. An x in an error message can represent any number.

Table 58. Beep Codes

Beep Code Probable Cause

1-1-3 CMOS write/read failure 1-1-4 BIOS ROM checksum failure 1-2-1 Programmable interval timer test failure 1-2-2 DMA initialization failure 1-2-3 DMA page register write/read test failure 1-2-4 RAM refresh verification failure 1-3-1 1st 64 K RAM test failure 1-3-2 1st 64 K RAM parity test failure 2-1-1 Slave DMA register test in progress or failure 2-1-2 Master DMA register test in progress or failure 2-1-3 Master interrupt mask register test failure 2-1-4 Slave interrupt mask register test failure 2-2-2 Keyboard controller test failure 2-3-2 Screen memory test in progress or failure 2-3-3 Screen retrace tests in progress or failure 3-1-1 Timer tick interrupt test failure 3-1-2 Interval timer channel 2 test failure 3-1-4 Time-of-Day clock test failure 3-2-4 Comparing CMOS memory size against actual 3-3-1 Memory size mismatch occurred

58 Technical Information Manual

Appendix E. Notices and Trademarks

References in this publication to IBM products, programs, or services do not imply that IBM intends to make these available in all countries in which IBM operates. Any reference to an IBM product, program, or service is not intended to state or imply that only that IBM product, program, or service may be used. Subject to IBM’s valid intellectual property or other legally protectable rights, any functionally equivalent product, program, or service may be used instead of the IBM product, program, or service. The evaluation and verification of operation in conjunction with other products, except those expressly designated by IBM, are the responsibility of the user.

IBM may have patents or pending patent applications covering subject matter in this document. The furnishing of this document does not give you any license to these patents. You can send license inquiries, in writing, to:

IBM Director of Licensing

IBM Corporation

500 Columbus Avenue Thornwood, NY 10594 U.S.A.

The following terms are trademarks of the IBM Corporation in the United States or other countries or both: AT IBM IntelliStation

OS/2 Personal Computer AT SurePath Wake on LAN XT

Intel, MMX, and Pentium are trademarks or registered trademarks of Intel Corporation. Microsoft, Windows, and Windows NT are trademarks or registered trademarks of Microsoft Corporation. Other company, product, and service names may be trademarks or service marks of others.

References

General Sources

Advanced Power Management (APM) BIOS Interface Specification 1.2

Source: Intel Corporation

AT Attachment Interface with Extensions

Source: American National Standard of Accredited Standards Committee

Extended Capabilities Port: Specification Kit

Source: Microsoft Corporation

Intel Microprocessor and Peripheral Component Literature

Source: Intel Corporation

PCI BIOS Specification 2.1

Source: PCI Special Interest Group

PCI Local Bus Specification 2.1

Source: PCI Special Interest Group

Plug and Play BIOS Specification, Errata and Clarifications

Source: Microsoft Corporation

World Wide Web Sources

82439HX PCI and Memory Controller (TXC)

Source: Intel Corporation; available at

http://www.intel.com/design/pcisets/datashts

82371SB PCI ISA IDE Xcelerator (PIIX3)

Source: Intel Corporation; available at

http://www.intel.com/design/pcisets/datashts

Plug and Play BIOS Specification 1.1

Source: Microsoft Corporation; available at

http://www.microsoft.com/hwdev

Universal Serial Bus Specifications

Source:

Video Electronics Standards Association 1.2

Source:

http://www.teleport.com/˜usb

http://www.vesa.org

60  Copyright IBM Corp. 1997

Index

Index A

adapters

SCSI 25 supported 25 video 17 Wake on LAN 22, 25

address map

DMA 53 I/O 51

system memory 50 advanced power management 4 altitude 31 APM 4 audio

features 15

jacks 15

battery 14 beep codes 58 BIOS

bypassing 35

data areas 50

features 3

updates 4 bus

IDE 9

ISA 8, 20

PCI 8, 20

universal serial bus 10 bus master interface 9

cables 31 cache, L2 7 CD-ROM drive 26 chip set control 6 clock, real-time 14 CMOS RAM 14 CMOS-clear jumper 14, 23 compatibility

hardware 33

software 35 configuration/setup utility program 4 connectors

audio 15

DIMM 7

diskette drive 11, 42

Ethernet 18, 49

IDE 9, 41

connectors

infrared 13, 47 ISA 37 keyboard/mouse 13, 48 memory 7 monitor 16, 48 parallel port 12, 46 PCI 39 power supply 30 riser card 20 serial ports 12, 47 system board 24 system memory (DIMM) 43 USB 10, 46

video 16, 48 controller, super input/output 11 copy protection 35 current, electrical 32

(continued)

depth, system unit 31 Desktop Management Interface (DMI) 19 device drivers

for built-in features 5

operating system 5

video 17 diagnostic programs 5 DIMM connectors 7 diskette drive

change signal 35

characteristics 26, 35

compatibility 35

connector 42

controller 35

interface 11

write current 35

write protect switch 23 DMA

channel assignments 55

I/O address map 53 DRAM (dynamic random access memory) 7 drives, internal 26 dual inline memory modules (DIMMs) 7

electrical input 32 electromagnetic compatibility 31 environment, operating 31 error codes, POST 56

Index

Ethernet

enable/disable switch 22 features 18 port 18, 49

expansion 20

fault, overvoltage 30 features

hardware 1 operating system support 5

software 3 flash update 4 floppy devices 11, 26, 35 frequency, input power 27, 32

GPIO ports 14

hard disk drive

characteristics 26

compatibility 35

IDE interface 9

reading/writing 35 hardware

compatibility 33

features 1

interrupts 34 heat output 32 height, system unit 31 humidity 31

IDE

connectors 41

hard disk drive 26

interface 9 information, related ix infrared port 13, 47 input/output (I/O)

address map 51

controller 11

system 8 internal drives 26 interrupts

hardware 34

software 35 IRQ (interrupt request) assignments 55 ISA

bus 8, 20

connectors 20, 37

jumper, system board 23

keyboard

cable 31 port 13, 48

L2 cache 7 level-sensitive interrupts 34

machine-sensitive programs 36 measurements, system unit 31 mechanical specifications 31 memory

connectors 43 DIMMs 7 L2 cache 7 map, system 50 RAM 50 system 7

video 16 messages, POST error 56 microprocessor

features 6

socket 6

switch settings 22 modes, power management 4 monitor port 16, 48 mouse port 13, 48 multimedia upgrade 17

operating system support 5 overvoltage fault 30

parallel port 12, 46 password enable/disable switch 22 PCI

bus 8, 20

connectors 20, 39 PCI-to-ISA bridge 8 physical specifications 31 pin assignments

diskette drive connector 42

Ethernet connector 49

IDE connectors 41

infrared connector 47

62 Technical Information Manual

Index

pin assignments

ISA connectors 37 keyboard/mouse connectors 48 monitor connector 48 parallel port connector 46 PCI connectors 39 serial port connectors 47 system memory (DIMM) 43 USB connectors 46

video connector 48 Plug and Play 3 polling mechanism 35 ports

audio 15

Ethernet 18, 49

GPIO 14

infrared 13, 47

keyboard/mouse 13, 48

monitor 16, 48

parallel 12, 46

serial 12, 47

USB 10, 46

video 16, 48 POST

description 4

error codes 56 power

advanced power management 4

cable 31

input 28

output capacity 28

output protection 30

specifications 32

supply 27 power management 8 protection, power supply 30 publications, related ix

(continued)

QAPlus/PRO for DOS 5 QAPlus/WIN for IBM 5

RAM (random access memory) 50 random access memory (RAM) 50 real-time clock 14 references 60 related information ix reserved areas viii riser card 20

SCSI

adapters 25 cable 31

hard disk drive 26 serial ports 12, 47 short circuit 30 size, system unit 31 socket, microprocessor 6 software

compatibility 35

features 3

interrupts 35

operating system support 5

system 3 specifications, physical 31 switches, system board 22 system board

features 6

jumper 23

layout 24

switches 22 system management controller 19 system resource assignments

audio 15

diskette interface 11

Ethernet 18

IDE interface 9

keyboard/mouse 13

parallel port 12

real-time clock 14

serial ports 12

system management controller 19

video 16

temperature 31

universal serial bus (USB)

ports 10, 46

technology 10 updates, BIOS 4

video

adapters 17

device drivers 17

features 16

memory 16

port 16, 48

upgrades 17

Index 63

voltage

input power 28 output power 28

Wake on LAN

adapters 22, 25

controller 18 warning, reserved areas viii weight, system unit 31 width, system unit 31 write current, diskette 35 write-protect switch, diskette drive 23

Index

64 Technical Information Manual

IBM

Part Number: xxxxxxx

Printed in U.S.A.

XXXXXXX

IBM PC 300PL, PC 300PL Type 6562, PC 300PL Type 6592 Technical Information Manual
