Technical Information Manual PC 300GL Types 6563, 6564, 6574 PC 300PL Type 6565

IBM

Technical Information Manual PC 300GL Types 6563, 6564, 6574 PC 300PL Type 6565

Before using this information and the product it supports, be sure to read the general infromation

Note:

under “Appendix E. Notices and Trademarks,” on page 57.

Technical Information Manual IBM PC 300GL Types 6563, 6564, 6574 and PC300PL Type 6565

Second Edition (Marc h 2000)

Note to U.S. Government Users — Documentation related to restricted rights — Use, duplication or disclosure is subject to restrictions set forth in GSA ADP Schedule Contract with IBM Corp.

Preface . . . . . . . . . . . . . . . . . . . . . . . . . . . vii

Related publications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vii

Terminology . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . viii

Chapter 1.System Overview . . . . . . . . . . . . 1

Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

CD-RW . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

DVD-ROM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

ADSL modems. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Wake on LAN. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Wake on Ring. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Chapter 2.System board features . . . . . . . 5

Intel Pentium III microprocessor with MMX technology 5

Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

L2 Cache . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Chip set control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

System memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

PCI Bus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

IDE bus master interface. . . . . . . . . . . . . . . . . . . . . . . . 7

USB interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Video Subsystem . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Audio Subsystem . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Integrated peripheral controller . . . . . . . . . . . . . . . . . . . 11

Diskette Drive Interface . . . . . . . . . . . . . . . . . . . . . . . 11

Serial ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Parallel port. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Keyboard and mouse ports . . . . . . . . . . . . . . . . . . . . 12

Network connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Real-time clock and CMOS . . . . . . . . . . . . . . . . . . . . . . . 13

Flash EEPROM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Expansion adapters. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Physical layout. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Rocker switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Cable connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Connector panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Chapter 3.Physical specifications . . . . . . 21

PC 300 GL and PL desktop . . . . . . . . . . . . . . . . . . . . . . . 21

PC300 PL and GL tower . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Chapter 4.Power supply . . . . . . . . . . . . . . 25

Power input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Power output. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Component outputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Output protection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Connector description . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Plug and Play. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

POST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Configuration/Setup Utility program . . . . . . . . . . . . . . 30

Advanced Power Management (APM) . . . . . . . . . . . . . 30

Advanced Configuration and Power Interface (ACPI) 30

Flash update utility program. . . . . . . . . . . . . . . . . . . . . . 30

Diagnostic program. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Chapter 6.System compatibility. . . . . . . . 31

Hardware compatibility . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Hardware interrupts . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Software compatibility . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Software interrupts . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Machine-sensitive programs. . . . . . . . . . . . . . . . . . . . 32

Appendix A. Connector pin assignments 33

SVGA monitor connec tor . . . . . . . . . . . . . . . . . . . . . . . . . 33

DVI-I monitor connector . . . . . . . . . . . . . . . . . . . . . . . . . 34

System memory conn ector. . . . . . . . . . . . . . . . . . . . . . . . 34

PCI connectors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

IDE connectors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Diskette drive connector. . . . . . . . . . . . . . . . . . . . . . . . . . 43

Power supply connector. . . . . . . . . . . . . . . . . . . . . . . . . . 44

Wake on LAN connectors. . . . . . . . . . . . . . . . . . . . . . . . . 44

USB port connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Mouse and keyboard port connectors . . . . . . . . . . . . . . 45

Serial port connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

Parallel port connector . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

Appendix B. System address maps. . . . . 47

System memory map . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Input/output address map . . . . . . . . . . . . . . . . . . . . . . . 48

DMA I/O address map. . . . . . . . . . . . . . . . . . . . . . . . . . . 50

PCI configuration space map. . . . . . . . . . . . . . . . . . . . . . 51

Appendix C. IRQ and DMA channel

assignments. . . . . . . . . . . . . . . . . . . . . . . 53

Appendix D. Error codes . . . . . . . . . . . . . 55

POST error codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

Beep codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

Appendix E. Notices and Trademarks . . . 57

Bibliography. . . . . . . . . . . . . . . . . . . . . . . . 59

Chapter 5.System software. . . . . . . . . . . . 29

BIOS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

Preface

This Technical Information Manual provides information for the IBM PC 300GL personal computer types 65 63, 6564, 657 4 and PC 300 PL personal co mputer type 6565. The Manual is intended for developers who want to provide hardware and software products to operate with these IBM computer s an d provides an in-depth view of how these IBM computers work. Users of this publication should have an understanding of computer architecture and programming concepts.

Related publications

In addition to this Manual, the following IBM publications provide information related to the operation of the IBM PC 300GL and PC 300PL personal computer. Several publications mentioned in this book are available from the IBM Web site. In some cases, you will have to follow further instructions on the Web site to find the document for your particular computer and model. To order printed publications in the U.S. and Puerto Rico, call 1-800-879-2755. In other countries, contact an IBM reseller or an IBM marketing representative.

• PC 300GL and PC 300PL User Guide This publication contains information about configuring, operating, and

maintaining the PC 300GL and the PC 300PL personal computer, as well as installing new options in the PC 300GL and PC 300PL personal computer. Also included are warranty information, instructions for diagnosing and solving problems, and information on how to obtain help and service.

• Understanding Yo ur P ersonal Computer This online document includes general information a bout using computers and

detailed information about the features of the PC 300GL and the PC 300PL personal computer. This publ ication is available on the World Wide Web at http://www.ibm.com/pc/support.

• About Your Software This publication (provided only with computers that have IBM-preinstalled

software) contains information about the preinstalled software package.

• Hardware Maintenance Manual This publication contains information for trained service technicians. It is

available at http://www.ibm.com/pc/support on the World Wide Web, and it can also be ordered from IBM. To purchase a copy, see the "Getting Help, Service, and Information" section in the PC 300GL and PC 300PL User Guide.

• Compatibility Report This publication contains information about compatible hardware and software

for the PC 300GL and PC 300PL personal computer. It is available at http://www.ibm.com/pc/us/cdt on the World Wide Web.

• Network Administrator’s Guide

This publication contains information for network administrators who configure and service local area networks (LANs). Look for this publication at http://www.ibm.com/pc/us/cdt on the World Wide Web.

Terminology

Attention: The term reserved describes certain signals, bits, and registers that should not be changed. Use of reserved areas can cause compatibility problems, loss of data, or permanent damage to the hardware. If you change the contents of a register, preserve the state of the reserved bits. When possible, read the register first and change only the bits that must be changed.

In this manual, some signals are represented in an all-capital-letter format (-ACK). A minus sign in front of the signal indicates that the signal is active low. No sign in front of the signal indicates tha t the signal is active high.

The term hex indicates a hexidecimal number. When numerical modifiers such as K, M, and G are used, they typically indicate

powers of 2, not powers of 10. For example, 1 KB equals 1 0 24 bytes (2

1 048 576 bytes (2

), and 1 GB, equals 1 073 741 824 bytes (230).

), 1 MB equals

When expressing storage capacity, MB equals 1 000 KB (1 024 000). The value is determned by counting the number of sectors and assuming thatevery two sectors equals 1 KB.

Note: Depending on the operating system and other requirements, the storage

capacity available to you might vary.

viii PC 300 GL and 300 PL

Chapter 1. System Overview

IBM® PC 300® GL personal computer types 6563, 6564, and 6574 and PC 300PL personal computer type 6565 are computer systems that provide state-of-the-art computer power with room for future growth.

Features

Your computer has:

• An Intel® Pentium® III microprocessor with MMX™ technology, streaming single instruction multiple date (SMID) extensions, a nd 51 2 KB L2 cache

Your computer may have all, or some, of the following major features:

• Room for up to 1 GB of system memory total

• Integrated IDE bus master controller, Ultra DMA-66 capable

• EIDE hard disk drive

• System management — Remote Program Load (RPL) and Dynam ic Host Configuration Protocol

(DHCP) — Wake on LAN® support — Desktop Management Interface (DMI) BIOS and DMI software — Integrated network protocols — Enablement for Remote Administration — Ability to update POST and BIOS over the netw ork — Wake on Ring support — Automatic power-on startup — System Management (SM) BIOS and software — Ability to store POST hardware test results — Selectable startup sequence — Selectable Automatic Power ON Startup Sequence — CMOS Save/Restore utility program — CMOS setup over LAN

• IDE CD-ROM

• CD-RW (Rewritable) drive, standard on some models

• DVD-ROM drive, standard on some models

• Asynchronous Digital Subscriber Line (ADSL) modem, standard on some models

• Asset security — Security settings provided by the Configuration/Setup Utilit y program:

– Power-on and administrator password protection – Startup sequence control – Hard disk drive and diskette drive access control

– I/O port control — Cover lock loop (PC 300GL models only) — Cover key lock (PC 300PL models only) — U-bolt and security cabling (optional)

drive, standard on some models

1. Variable read rate. Actual playback speed will vary and is often less than the maximum possible.

— Diskette write-protection™ — Alert on LAN

• Accelerated graphics port (AGP) video adapter with up to 16 MB of Synchronous Graphics Random Access Memory (SGRAM)

• Integrated 16-bit audio controller and built-in high-quality speaker (supports SoundBlaster, Adlib, and Microsoft® Windows® Sound System applications)

• Networking — IBM 10/100 megabits-per-second (Mbps) PCI Ethernet adapter with Wake

on LAN in some models

— IBM PCI token-ring adapter with Wake on LAN support (optional)

• Expansion: four drive bays, three PCI expansion slots

• PCI I/O bus compatibility

• EnergyStar compliance (some models only)

• 3.5-inch, 1.44 MB diskette drive

• Input/Output features — One 25-pin, ECP/EPP parallel port

— Two 9-pin, 16550 universal asynchronous receiver/transmitter (UART)

serial ports — Two 4-pin, Universal Serial Bus (USB) ports — One 6-pin, keyboard port — One 6-pin, mouse port — One 15-pin, DDC2B-compliant monitor port or — One 24-pin, DVI-I port on the AGP adapter (on some models) — Three 3.5-mm audio jacks (in/headphone out, line in, microphone)

CD-RW

DVD-ROM

CD-Rewritable (CD-RW ) drives, standard on some models, enable the recording and reuse of CD recor dable media. The laser used in CD-R W has variable temperatur es to provide the three functions of CD-RW drives: playing CDs or CD-RWs, erasing CD-RWs, and recording CD-RWs.

CD-RW drives can read traditional CDs, but many older CD players cannot read CD-RWs. Their light reflective properties are about one-thir d that of traditional CDs. CD-RW drives cannot read DVDs.

To learn more about CD-RW drives, see the Understanding Your Personal Computer publication for your personal computer model and type number. This publication is available on the World Wide Web at http://www.ibm.com/pc/support.

DVD-ROM drives, standard on some models, differ from CD-ROM and CD-RW drives as the result of refinements in laser technology.

The recording tracks on DVD media are not as deep and are more condensed than on CDs or CD-RWs, therefore DVDs provide more storage space. DVD media also use both sides of the disk, as opposed to just one side for CDs and CD-RWs.

DVD-ROM drives read traditional CDs, CD-RWs, and DVDs. To learn more about DVD-ROM drives, see the Understanding Your Personal Computer

publication for your personal computer model and type number. This publication is available on the World Wide Web at http://www.ibm.com/pc/support.

2 PC 300 GL and 300 PL

ADSL modems

Wake on LAN

ADSL modems, available on some models, enable simultaneous internet connectivity and telephone service. Contact your local telephone service provider and ask if your premises need any additional telephony equipment, such as a splitter or a filter. Also contact your Internet service provider (ISP) to determine if they provide service to customers with ADSL.

ADSL modems work by using separately the individual four or six wires in the standard RJ-11 telephone jack. The inner wires, or pairs of wires if there are six, carry voice transmissions. The outer wires on either side carry data between your computer and the Internet. One channel is data download; the other is data upload.

To learn more about ADSL modems, see the Understanding Your Personal Computer publication for your personal computer model and type number. This publication is available on the World Wide Web at http://www.ibm.com/pc/support.

The power supply of the computer supports the Wake on LAN feature. With the Wake on LAN feature, the computer can be turned on when a specific LAN frame is passed to the computer over the LAN.

To use the Wake on LAN featu re, your computer must be equipped with a network adapter that supports Wake on LAN.

Wake on Ring

T o find out if the Wake on LAN feature is set, refer to the menu item for Wake on LAN in the Configuration/Setup Utility program. See the PC 300GL and PC 300PL User Guide for help with using the Configura tion/Setup Utility program.

All models can be configured to turn on the computer after a ring is detected from an external or internal modem. Use the menu for setting the Wake on Ring feature in the Configuration/Setup Utility Program. Two options control this feature:

• Serial Ring Detect: Use this option if the computer has an external modem

connected to the serial port.

• Modem Ring Detect: Use this option if the computer has an internal modem.

Chapter 1. System Overview 3

4 PC 300 GL and 300 PL

Chapter 2. System board features

This section includes information about system board features. For an illustration of the system board, see “Physical layout” on page 14.

Intel Pentium III microprocessor with MMX technology

PC 300 GL personal computer types 6563, 6564, and 6574 and PC 300 PL personal computer type 6565 come with an Intel Pentium III microprocessor. The microprocessor has an attached heat sink which plugs directly into a connector on the system board.

More information on this microprocessor is available at http://www.intel.com on the World Wide Web.

Features

The features of the Pentium III microprocessor are as follows:

• Optimization for 32-bit software

• Operation at a low voltage level

• Intel microprocess or serial number

• 64-bit microprocessor data bus

• 100-133 MHz front-side bus (FSB)

•Math coprocessor

• Internet Streaming SIMD extensions

• MMX technology, which boosts the processing of graphic, video, and audio data

L2 Cache

Chip set control

System memory

The Pentium III microprocessor provides up to 512 KB L2 cache. The L2 cache error corrected code (ECC) function is automatically enabled if ECC memory is installed. If nonparity memory is installed, the L2 cache is non-ECC.

The chip set design is the interface between the microprocessor and the following:

• Memory subsystem

•PCI bus

• IDE bus master connection

• High performance, PCI-to-ISA bridge

•USB ports

•SMBus

• Enhanced DMA controller

• Real-time clock (RTC)

The maximum amount of system memory the computer can physically accommodate is 1 GB total. The amount of system memory factory-preinstalled varies by model.

For memory expansion, the system board provides two dual inline m emo ry module (DIMM) connectors and supports 1 33 MHz DI MMs in s izes of 64 MB, 125 M B, and 512 MB. 100 MHz DIMMs may be used in systems with a 100 MHz FSB.

The following information applies to system memory:

• Synchronous dynamic random access memory (SDRAM) is standard.

• The maximum height of memory modules is 6.35 cm (2.5 in.).

• Only PC 100 and PC 133 industry-standard, gold-lead DIMMs are supported.

• DIMM connectors do not support RAMBUS Inline Memory Modules (RIMMs).

• The PC 300GL supports error-corrected code (ECC). A mix of nonparity types configures as nonparity.

• BIOS sepcific auto-configure, auto-detect maximum system memory.

For information on the pin assignments for the memory modules connectors, see “System memory connector” on page 34.

The following table shows some possible configurations for the supported DIMMs.

Table. 1. Memory Configuration (MB)

Total Memory Mem O Mem 1

64 64 0

96 64 32 128 64 64 128 128 0 160 128 32 192 128 64 256 128 128 384 256 128 512 256 256 512 512 0 578 512 64 640 512 128

1024 512 512

6 PC 300 GL and 300 PL

PCI Bus

The PCI bus originates in the chip set. Features of the PCI bus are:

• Integrated arbiter with multitransaction PCI arbitration acceleration hooks

• Zero-wait-state, microprocessor-to-PCI write interface for high-performance graphics

• Built-in PCI bus arbiter

• Microprocessor-to-PCI memory write posting

• Conversion of back-to-back, sequential, microprocessor-to- PCI memory write to PCI burst write

• Delayed transaction

• PCI parity checking and generation support

IDE bus master interface

The system board incorporates a PCI-to-IDE interface that complies with the AT Attachment Interface with Extensions.

The bus master for the IDE interface is integrated into the I/O hub of the chip set. The chip set is PCI 2.2 compliant. It connects directly to the PCI bus and is designed to allow concurrent operations on the PCI bus and IDE bus. The chip set is capable of supporting PIO mode 0–4 devices and IDE DMA mode 0–3 devices. Ultra DMA 66 transfers up to 66 Mbps using an ATA 66 cable.

The IDE devices receive their power through a four-position power cable containing +5 V dc, +12 V dc, and ground voltage. As devices are added to the IDE interface, designate one device as the master, or primary, device and another as the slave, or subordinate, device. These designations are determined by switches or jumpers on each device. There are two IDE ports, one designated Primary and the other Secondary, allowing for up to four devices to be attached. The total number of physical IDE devices is determined by available space on the system board.

For the IDE interface, no resource assignments are given in the system memory or the direct memory access (DMA) channels. For information on the resource assignments, see “Input/output address map” on page 48 and “Appendix C. IRQ and DMA channel assignments ,” on page 53.

For information on the connector pin assignments, see “IDE connectors” on page 42.

USB interface

Universal Serial Bus (USB) technology is a standard feature of your personal computer. The system board provides the USB interface with two connectors integrated into the chip set. A USB-enabled device can attach to a connector and, if that device is a hub, multiple peripheral devices can attach to the hub and be used by the system. The USB connectors use Plug and Play technology for installed devices. The speed of the USB is up to 12 MBps with a maximum of 127 peripheral devices. The USB is compliant with Universal Host Controller Interface Guide 1.0.

Features of USB technology include:

• Plug and Play devices

• Concurrent operation of multiple devices

• Suitability for different device bandwidths

Chapter 2. System board features 7

• Support for up to five-meter cable length from host to hub or hub to hub

• Guaranteed bandwidth and low latencies appropriate for specific devices

• Wide range of packet sizes

• Limited power to hubs For information on the connector pin assignment for the USB interface, see “USB port

connectors” on page 44.

Video Subsystem

The PC 300GL personal computer types 6563, 6564, and 6574 ad PC 300PL personal computer type 6565 come with one of the following graphic solutions:

1. S3 Savage4 Accelerated Graphics Port (AGP) 4X adapter with 8 MB 125 MHz

2. S3 Savage4 Extreme AGP4X adapter with 16 MB 166 MHz SGRAM, a

3. S3 Diamond AGP 4X adapter with 32 MB 143 MHz SDRAM with a DVI-I

SDRAM and a 15-pin VGA connector

DVI-connector, and a 15-pin VGA converter. The Savage4 graphics accelerator supports the following features:

• 128-bit 2D graphics engine

• High-performance 2D/3D video accelerator

• 3D rendering

• Motion video architecture

• High-speed memory bus

• Flat-panel monitor support

• ACPI and PCI power management

• PCI 2.2 bus support, including bus mastering

• 300 MHz RAMDAC with gamma correction

• Serial bus and flash ROM support

• Hardware and BIOS support for VESA timing and DDC monitor communications

• 2.5 V core with 3.3V/5V to lerant I/O

connector and, on some models, TV outlet on a daughter card. The S3 Diamond graphics accelerator supports the following features:

• 128-bit 3D graphics engine

• Two texture-mapped, lit pixels-per-clock cycle

• Single-pass multi-texturing

• 32-bit Z/stencil buffer

• Anti-aliasing: full scene, order independent

• Up to 2048 x 1536 resolution

• 30 frames per second (fps) full screen DVD playback

• National Television Systems Committee (NTSC) digital output (optional)

• Phase Alternate Line (PAL) digital output (optional)

• DVI-I interface

• Bidirectional Media Port and CCIR-656 video capture port (optional)

8 PC 300 GL and 300 PL

The integrated video subsystem supports all video graphics array (VGA) modes and is compliant with super video graphics array (SVGA) modes and Video Electronics Standards Association (VESA) 1.2. Some enhanced features include:

• Integrated video subsystem on chip, including 2D, 3D, and video port

• 66 MHz AGP system bus interface with 2X and 4X

• Sideband signaling (some models only)

• Command list bus mastering support for fast 2D and 3D performance

• 64-bit, 125 MHz SDRAM or 166 MHz SGRAM interface

• Plug and Play support

• 4 MB dynamic display cache memory

• Advanced Power Management (APM) support

• Color space conversion

• Hardware scaling The integrated graphics memory controller subsystem complys with the VESA

Display Data Channel (DDC) 1.1 standard and uses DDC1 and DDC2B to determine optimal values during automatic minor detection.

The video subsystem has the following resource assignm ents.

Table 2. Video subsystem resources Resource Assignment

ROM Hex C0000-C7FFF (32KB) RAM Hex A0000-BFFFF (standard VGA frame buffer) I/O VGA, sequencer , CR T controller, graphics controller , attribute, RAMDAC,

extended sequencer , extended CRTC registers

IRQ PCI interrupt 1 (enabled by default in the Configuration/Setup Utility

program. Normally assigned to IRQ 0B when nothing else is installed in the system. 3D systems use this interrupt.)

DMA None, N/A for AGP bus

For further information on resource assignments, see “Appendix B. System address maps,” on page 47 and “Appendix C. IRQ and DMA channel assignments,” on page

53.

Chapter 2. System board features 9

The PC 300GL personal computer types 6563, 6564, and 6574 and the PC 300PL type 6565 support the following video subsystem modes.

Table 3. Supported VGA video modes

Mode

(Hex)

00 Text 40 x 25 characters 2 B8000 28.322 31.5 70 01 Text 40 x 25 characters 16 B8000 28.322 31.5 70 02 Text 80 x 25 characters Black/white B8000 28.322 31.5 70 03 Text 80 x 25 characters 16 B8000 28.322 31.5 70 04 Graphics 320 x 200 pixels 4 B8000 25.175 31.5 70 05 Graphics 320 x 200 pixels 4 B8000 25.175 31.5 70 06 Text 640 x 200 pixels 2 B8000 25.175 31.5 70 07 Text 80 x 25 characters Mono B8000 28.322 31.5 70 0D Graphi cs 320 x 200 pixels 16 A0000 25.175 31.5 70 0E Graphics 640 x 200 pixels 16 A0000 25.175 31.5 70 0F Graphics 640 x 350 pixels Mono A0000 25.175 31.5 70 10 Graphics 640 x 350 pixels 16 A0000 25.175 31.5 70 11 Graphics 640 x 480 pixels 2 A0000 25.175 31.5 60 12 Graphics 640 x 480 pixels 16 A0000 25.175 31.5 60

Display

mode

Screen resolution Colors

Buffer

start (hex)

Dot

clock

(MHz)

Sweep

rate

(kHz)

Refresh

rate

(Hz)

13 Graphics 320 x 200 pixels 256 A0000 25.175 31.5 70

The video subsystem provides a 15-pin monitor connector on the system board. On some models, an optional 24-pin DVI-I monitor connector is provided on the AGP board. For information on monitor connector pin assignments see “Appendix A.

Connector pin assignments,” on page 33 for SVGA and DVI.

Audio Subsystem

PC 300GL and PC 300PL personal computers come with an integrated audio controller . These models, which are capable of playing and reco rding sounds, support SoundBlaster, Adlib, and Microsoft Windows Sound System applications.

The device drivers for the preinstalled audio adapter ar e on the ha rd disk. The device drivers are also available on the D evice Drivers and Diagnostics CD provided with models that come with preinstalled software.

If you connect an optional device to the audio adapter, follow the instructions provided by the manufacturer.

Note: Additional device drivers might be required. If necessary, contact the

The following connectors are available on the audio adapter or integrated audio controller:

• Line Out port for connecting powered speakers or headphones. You must

manufacturer for information on these device drivers.

connect a set of speakers to the Line Out port to hear audio from the adapter.

10 PC 300 GL and 300 PL

These speakers must be powered with a built in amplifier. In general, any powered speakers designed for use with personal computers can be used with the audio adapter. These speakers are available with a wide range of features and power outputs.

• Line In port for connecting musical devices, such as a portable CD-ROM player or stereo.

• Microphone for connecting a microp hone.

Integrated peripheral controller

Control of the integrated input/output (I/O) and diskette drive controllers is provided by a single module, the integrated peripheral contr oller (SMC FDC 87B813). This module, which supports Plug and Play technology, controls the following features:

• Diskette drive interface

•Serial port

• Parallel port

• Keyboard and mouse ports

Diskette Drive Interface

PC 300GL and PC 300PL personal computers have four drive bays for installing internal devices. The following is a list of devices that the diskette drive subsystem supports:

• 1.44 MB, 3.5 inch diskette drive

• 1.44 MB, 3.5 inch, 3-mode drive for Japan (no BIOS support for 3-mode drive)

• 1.2 MB, 5.25 inch diskette

• 1 Mbps, 500 Kbps, or 250 Kbps internal tape drive

One connector is provided on the system board for diskette drive support. For information on the connector pin assignments, see “Diskette drive connector” on page

43.

Serial ports

Two universal asynchronous receiver/transmitter (UART) serial ports are integrated into the system board. The two serial ports include 16-byte data, first-in first-out (FIFO) buffers and have programmable baud rate generators. The serial ports are NS16450 and PC16550A compatible.

For information on the connector pin assignments, see “Serial port connector” on page 45.

Note: Current loop interface is not supported.

Chapter 2. System board features 11

The following figure shows the serial port assignments in the configuration.

Table 4. Serial port assignments Port assignment Address range (hex) IRQ level

Serial 1 03F8–03FF IRQ4 Serial 2 02F8–02FF IRQ3 Serial 3 03E8–03FF IRQ 4 Serial 4 O2E8–027F IRQ13

The default setting for the serial port is COM1.

Parallel port

Integrated in the system board is support for extended capabilities port (ECP), enhanced parallel port (EPP), and standard parallel port (SPP) modes. The modes of operation are selected through the Configuration/Setup Utility program with the default mode set to SPP.

The following figure shows the parallel port ass ignments used in the configuration.

Table 5. Parallel port assignments Port assignment Address range (hex) IRQ level

Parallel 1 03BC–03BE IRQ7 Parallel 2 0378–037F IRQ5 Parallel 3 0278–03FF IRQ5

The default setting for the parallel port is Parallel 1. The system board has one connector for the parallel port. For information on the

connector pin assignments, see “Parallel port connector” on page 46.

Keyboard and mouse ports

A general purpose 8-bit microcontroller, 8042AH compatible, controls the mouse and keyboard subsystem. The controller consists of 256 bytes of data memory and 2 KB of read-only memory (ROM).

The controller has two logical devices: one controls the keyboard and the other controls the mouse. The keyboard has two fixed I/O addresses, a fixed IRQ line, and can operate without the mouse. The mouse cannot operate without the keyboard because, although it has a fixed IRQ line, the mouse relies on the addresses of the keyboard for operation. For the keyboard and mouse interfaces, no resource assignments are given in the system memory addresses or DMA channels. For information on the resource assignments, see “Input/output address map” on page 48 and “Appendix C. IRQ and DMA channel a ssignments,” on page 53.

The system board has one connector for the keyboard port and one connector for the mouse port. For information on the connector pin assignments, see “Mouse and keyboard port connectors” on page 45.

12 PC 300 GL and 300 PL

Network connection

Some PC 300 GL and PC 300 PL models are equipped with an Ethernet or token-ring adapter that supports the Wake on LAN feature.

Features of the optional Wake on LAN Ethernet adapter are:

• Operates in shared 10BASE-T or 100BASE-TX environment

• Transmits and receives data at 10 Mbps or 100 Mbps

• Has an RJ-45 connector for LAN attachment

• Operates on symmetrical multiprocessing ( SMP) environments

• Supports Wake on LAN

• Supports Remote Program Load (RPL) and Dynamic Host Configuration Protocol (DHCP)

Features of the optional token-ring adapter are:

• Transmits and receives data at 4 Mbps or 16 Mbps

• Has RJ-45 and D-shell connectors for LAN attachment

• Supports Wake on LAN

• Supports Remote Program Load (RPL) and Dynamic Host Configuration Protocol (DHCP)

The PC 300GL personal computer has a 3-pin header on the system board that provides the AUX5 (auxiliary 5 volts) and wake-up signal connections.

Real-time clock and CMOS

The real-time clock is low-power and provides a time-of-day clock and a calend ar. An external battery source of 3 V dc maintains the settings.

The system uses 242 bytes of complementary metal-oxide semiconductor (CMOS) memory to store data. To erase or reset CMOS memory to the default, use the small rocker switch on the system board.

Note: Refer to the instructions in the PC 300PL and PC 300GL User Guide before

To locate the battery and the rocker switches, see “Physical layout” on page 14.

Flash EEPROM

The system board uses two megabits (Mb) of flash electrically erasable programmable, read-only memory (EEPROM) to store the basic input/output system (BIOS), IBM logo, Configuration/Setup Utility, and Plug and Play data.

If necessary, you can update the EEPROM by downloading a stand-alone utility program available from the IBM Web site: http://www.ibm.com/pc.

Expansion adapters

Each PCI-expansion connector is a 32-bit slot. PCI-expansion connectors support the 32-bit, 5 V dc, local-bus signalling environment defined in PCI Local Bus Speci fication

2.2.

attempting to reset CMOS.

PC 300GL personal computer types 6563, 6564, and 6574 and PC 300PL personal computer type 6565 personal computers have three PCI slots to support the addition of adapters. For information on installing adapters, see the PC 300GL and PC 300PL

User Guide.

Chapter 2. System board features 13

Physical layout

For information on the connector pin assignments, see “PCI connectors” on page 40.

Note: PC 300GL computers do not support ISA expansion adapters or the IBM

PCMCIA adapter for PCI.

The system board might look slightly different from the one shown. Note: A diagram of the system board, including switch and jumper settings, is

attached to the underside of the computer cover.

14 PC 300 GL and 300 PL

Þ1ÝMicroprocessor Þ13ÝSmall rocker switch Þ2ÝDIMM 0 Þ14ÝBattery Þ3ÝDIMM 1 Þ15ÝChassis intrusion detection connector Þ4ÝFan connector Þ16ÝWake on LAN connector Þ5ÝPower connector Þ17ÝAlert on LA N connector Þ6ÝSwitch/LED connector Þ18ÝCD-ROM, CD-RW, or DVD drive connector Þ7ÝRFID connector (some models) Þ19ÝPCI adapter slot 1 Þ8ÝPrimary EIDE connector Þ20ÝPCI adapter slot 2 Þ9ÝSecondary EIDE connector Þ21ÝPCI adapter slot 3 (for Alert on LAN adapter) Þ10ÝDiskette drive connec tor Þ22ÝChassis speaker connector Þ11ÝFan connector Þ23ÝAGP adapter slot Þ12ÝLarge rocker switch (some models)

Rocker switches

The two rocker switches on the system board are used for custom configuration. For the location of the small and large rocker switches, see items 12 and 13 above.

The large rocker switch has eight switches for setting microprocessor speeds for compatibility with the system board. The following table shows the rocker switch settings for compatibility with the corresponding microprocessor speeds.

Chapter 2. System board features 15

Table 6. Large rocker switch settings

Microprocessor

speed

100 150 200

133 200 266

166 250 333

200 300 400

233 350 466

12345678

Off Off On Off Off Off Off Off

On On On On Off Off Off Off

OffOffOffOffOff OffOffOff

On On On Off Off Off Off Off

On On Off On Off Off Off Off

On On Off Off Off Off Off Off

266 400 533

300 450 600

333 500 666

366 500 733

400 600 800

433 650 866

On Off On On Off Off Off Off

On Off On Off Off Off Off Off

On Off Off On Off Off Off Off

On Off Off Off Off Off Off Off

Off On On On Off Off Off Off

Off On On Off Off Off Off Off

16 PC 300 GL and 300 PL

Table 6. Large rocker switch settings

Microprocessor

speed

466 700 933

500 750 1000

533 800 1066

Reserved Off Off Off On Off Off Off Off

The small rocker switch has three functions. By moving switch 1 to the On position, you activate the diskette write-protect feature. By moving switch 2 to the On position , you clear the CMOS. This rocker switch is also used for flash recovery. See the PC 300GL and PC 300PL User Guide for instruction.

Table 7. Small rocker switch settings

12345678

Off On Off On Off Off Off Off

Off On Off Off Off Off Off Off

Off Off On On Off Off Off Off

Function On

Diskette write-protect Switch 1 Clear CMOS Switch 2

Cable connectors

Connections for attaching devices are provided on the back of the computer. Each connection has a corresponding device symbol. The connect ors are:

•USB (2)

•Mouse

•Keyboard

•Serial (2)

•Parallel

• Monitor

• Ethernet adapter with RJ-45 connector (s ome models only)

• Integrated audio controller with line in, line out, and microphone connectors

Connector panel

On the following connector panel illustrations, note the device connection symbols. A connector provided by an adapter might not have an identifying symbol.

For pin-out details on connectors, see “Appendix A. Connector pin assignme nts, ” on page 33.

Chapter 2. System board features 17

The following illustration shows the connector panel for the desktop model.

Serial 2

Mouse

Serial 1

Keyboard

USB 2

USB 1

Line In

Headphone/ Line Out

DVI Monitor

SVGA Monitor

Parallel

Microphone

18 PC 300 GL and 300 PL

The following illustration shows the connector panel for the tower model.

Serial 1

Mouse

Keyboard

USB 2

USB 1

Line In

Headphone/

Line Out

Microphone

Parallel

Serial 2

SVGA Monitor

DVI Monitor

Chapter 2. System board features 19

20 PC 300 GL and 300 PL

Chapter 3. Physical specifications

This chapter lists the physical specificati on s for the PC 300GL personal computer types 6563, 6564, an d 6574 and PC 300 PL personal computer type 6565. The PC 300GL ad PC300PL have four expansion slots and four drive bays.

Note: The PC 300GL and PC 300PL computers comply with FCC Class B

specifications.

PC 300 GL and PL desktop

Dimensions

• Height: 138 mm (5.4 in.)

• Width: 400 mm (15.75 in.)

• Depth: 429 mm (16.9 in.)

Weight

• Minimum configuration as shipped: 9.53 kg (21 lb)

• Maximum configuration : 10.4 kg (23 lb)

Environment

• Air temperature: — System on: 10° to 35° C (50° to 95° F)

— System off: 10° to 43° C (50° to 110° F)

• Humidity — System on: 8% to 80%

— System off: 8% to 80%

• Maximum altitude: 2134 m (7000 ft), the maximum altitude at which the specified air temperatures apply. At higher altitudes, the maximum air temperatures are lower than those specified.

Electrical input

•Input voltage: — Low range:

– Minimum: 90 V ac – Maximum: 137 V ac – Input frequency range: 57 – 63 Hz – Voltage switch setting: 115 V ac

—High Range:

– Minimum: 180 V ac – Maximum: 265 V ac – Input frequency range: 47 – 53 Hz – Voltage switch setting: 230 V ac

— Input kilovolt-amperes (kVA) (approximately) :

– Minimum configuration as shipped: 0.08 kVA – Maximum configuration: 0.51 kVA

Note: Power consumption and heat output vary depending on the number and

type of optional features installed and the power-management optional features in use.

Heat output

• Approximate heat output in British thermal units (Btu) per hour: — Minimum configuration: 256 Btu/hr (75 w atts )

— Maximum configuration: 70 6 Btu/ hr (207 watts)

Airflow

• Approximately 0.5 cubic meter per minute (18 cubic feet per minute)

Acoustical noise-emission values

• Average sound-pressure levels: — At operator position:

– Idle: 33 dBA – Operating: 39 dBA

— At bystander position-1 meter (3.3 ft):

– Idle: 4.4 bels – Operating: 4.9 bels

Note: These levels were measures in controlled acoustical environments according

to procedures specified by the American National Standards Institute (ANSI) S12.10 and ISO 7779, and are reported in accordance with ISO 9296. Actual sound-pressure levels in your location might exceed the average values stated because of room reflections and other nearby noise sources. The declared sound power levels indicate an upper limit, below which a large num ber of computers will operate.

PC300 PL and GL tower

Dimensions

• Height: 378 mm (14.9 in.)

• Width: 192 mm (7.6 in.)

• Depth: 383 mm (15.1 in.)

Weight

• Minimum configuration as shipped: 8.3 kg (18.3 lb)

• Maximum configuration: 10.2 kg (22.5 lb)

Environment

• Air temperature: — System on: 10° to 35°C (50° to 95° F)

— System off: 10° to 43°C (50° to 110° F)

• Humidity — System on: 8% to 80% — System off: 8% to 80%

• Maximum altitude: 2134 m (7000 ft), the maximum altitude at which the specified air temperatures apply. At higher altitudes, the maximum air temperatures are lower than those specified.

Electrical input

• Input voltage: — Low range:

22 PC 300 GL and 300 PL

– Minimum: 90 V ac – Maximum: 137 V ac – Input frequency range: 57 – 63 Hz – Voltage switch setting: 115 V ac

—High Range:

– Minimum: 180 V ac – Maximum: 265 V ac – Input frequency range: 47 – 53 Hz – Voltage switch setting: 230 V ac

— Input kilovolt-amperes (kVA) (approximately) :

– Minimum configuration as shipped: 0.08 kVA – Maximum configuration: 0.51 kVA

Note: Power consumption and heat output vary depending on the number and

type of optional features installed and the power-management optional features in use.

Heat output

• Approximate heat output in British thermal units (Btu) per hour: — Minimum configuration: 25 6 Btu/hr (75 watts)

— Maximum configuration: 70 6 Btu/ hr (207 watts)

Airflow

• Approximately 0.5 cubic meter per minute (18 cubic feet per minute)

Acoustical noise-emission values

• Average sound-pressure levels: — At operator position:

– Idle: 33 dBA – Operating: 40 dBA

— At bystander position-1 meter (3.3 ft):

– Idle: 4.4 bels – Operating: 4.9 bels

Note: These levels were measures in controlled acoustical environments according

Chapter 3. Physical specifications 23

24 PC 300 GL and 300 PL

Chapter 4. Power supply

A 145-watt power supply drives your computer. The power supply provides 3.3-volt power for the Pentium III microprocessor, core chip set, and 5-volt power for PCI adapters. Also included is an auxiliary 5-volt (AUX 5) power supply to provide power to power-management circuit ry and a Wake on LAN adapter. The power supply converts the ac input voltage into four dc output voltages and provides power for the following:

• System board

• Adapters

• Internal drives

• Keyboard and auxiliary devices

• USB devices

A logic signal on the power connector controls the power supply; the front panel switch is not directly connected to the power supply.

The power supply connects to the system board with a 2 x 10 pin connector.

Power input

The following table shows the power input specifications. The power supply has a manual switch to select the correct input voltage.

Power output

Table 8. Power input requirements Specification Measurements

Input voltage, low range 100 (min) to 127 (max) V ac Input voltage, high range 200 (min) to 240 (max) V ac Input frequency 50 Hz ± 3 Hz or 60 Hz ± 3 Hz

The following figures show the power supply output of all the connectors, including the system board, DASD, PCI, and auxiliary outputs.

Table 9. Power output (145 watts) Output voltage Tolerance Minimum current Maximum current

+5 V dc +5% to -5% 1.5 A 18.0 A +12 V dc +5% to -5% 0.02 A 4.2 A

-12 V dc +10% to -10% 0.0 A 0.4 A +3.3 V dc +5% to -5% 0.0 A 10.0 A +5 V ac (auxiliary) +5% to -5% 0.0 A 0.720 A

The total combined 3.3 V and 5 V power must not exceed 100 watts.

Component outputs

The power supply provides separate voltage sources for the system board and internal storage devices. The following figures show the approximate power that is provided for specific system components. Many components draw less current than the maximum shown.

Table 10. System board Supply voltage Maximum current Tolerance

+3.3 V dc 5000 mA +5.0% to -5.0% +5.0 V dc 6000 mA +5.0 to -4.0% +12.0 V dc 25.0 mA +5.0% to -5.0%

-12.0 V dc 25.0 mA +10.0% to -9.0%

Table 11. Keyboard port Supply voltage Maximum current Tolerance

+5.0 V dc 275 mA +5.0% to -4.0%

Table 12. Auxiliary device port Supply voltage Maximum current Tolerance

+5.0 V dc 300 mA +5.0% to -4.0%

Table 13. PCI-bus adapters (per slot) Supply voltage Maximum current Tolerance

+5.0 V dc 1000 mA +5.0% to -4.0% +3.3 V dc 1500 mA +5.0% to -4.0%

Note: For each PCI connector, the maximum power consumption is rated at 5 watts

for +5 V dc and +3.3 V dc combined. If maximum power is used, the overall system configuration will be limited in performance.

Table 14. USB port Supply voltage Maximum current Tolerance

+5.0 V dc 500 mA +5.0%to -4.0%

Table 15. Internal DASD Supply voltage Maximum current Tolerance

+5.0 V dc 1400 mA +5.0% to -5.0%

26 PC 300 GL and 300 PL

Table 15. Internal DASD Supply voltage Maximum current Tolerance

+12.0 V dc 1500 mA at startup, 400 mA

Table 16. Video port pin 9 Supply voltage Maximum current Tolerance

+5.0 V dc 1100 mA +5.0% to -5.0%

Note: Some adapters and hard disk drives draw more current than the rated

Output protection

The power supply protects against output overcurrent, overvoltage, and short circuits. See the power supply specifications on the previous pages for details.

A short circuit that is placed on any dc output (between outputs or between an output and a dc return) latches all dc outputs into a shutdown state, with no damage to the power supply. If this shutdown state occurs, the power supply returns to normal operation only after the fault has been removed and the power switch has been turned off for at least one second.

+5.0% to -5.0%

when active

maximums. These adapters and drives can be installed in the system; however , the power supply will shut down if the total power used exceeds the maximum power that is available.

If an overvoltage fault occurs (in the power supply), the power supply latches all dc outputs into a shutdown state before any output exceeds 130% of the power supply value.

Connector description

The power supply for PC 300GL and PC 300PL personal computers has four, 4-pin connectors for internal devices. The total power used by the connectors must not exceed the amount shown in “Component outputs” on page 26. For connector pin

assignments, see “Appendix A. Connector pin assignments,” on page 33.

Chapter 4. Power supply 27

28 PC 300 GL and 300 PL

Chapter 5. System software

This section briefly describes some of the system software included with your computer.

BIOS

Your personal computer uses the IBM basic input/output system (BIOS), which is stored in flash electrically erasable programmable read-only memory (EEPROM). Some features of the BIOS are:

• PCI support according to PCI BIOS Specification 2.2

• Microsoft PCI IRQ Routing Ta ble

• Plug and Play support according to Plug and Play BIOS Specification 1.1a

• Advanced Power Management (APM) support according to APM BIOS Interface

Specification 1.2

• Wake on LAN support

• Wake on Ring support

• Remote Initial Program Load (RIPL) and Dynamic Host Configuration Protocol (DHCP)

• Flash-over-LAN support

• Alternate startup sequence

• IBM Look and Feel - such as screen arrangements and user interface

• ACPI (Advanced Configuration and Power Interface)

• IDE Logical Block Addressing (LBA)

• LSA 2.0 support

• Digital optical disk support

• LS-120 disk drive support

• DM BIOS 2.1 (DMI 2.0 compliant)

• PC99 compliance

Plug and Play

Support for Plug and Play conforms to the following:

• Plug and Play BIOS Specification 1.1a and 1.0

• Plug and Play BIOS Extension Design Guide

• Plug and PLay BIOS Specification, Errata, and Clarifications 1.0

• Guide to Integrating the Plug and Play BIOS Extensions with system BIOS 1.2

• Plug and Play Kit for DOS and Windows

POST

IBM power-on self-test (POST) code is used. Also, initialization code is included for the on-board system devices and controllers.

POST error codes include text messages for determining the cause of an error. For more information, see “Appendix D. Erro r codes,” on page 55 and your PC 300GL and PC 300PL User Guide.

Configuration/Setup Utility program

The Configuration/Setup Utility program provides menu choices for devices, I/ O ports, date and time, system security, start options, advanced setup, and power management.

More detailed information on using the Configuration/Setup Utility program is in the PC 300GL and PC 300PL User Guide.

Advanced Power Management (APM)

The PC 300GL computers have built-in energy-saving capabilities. Advanced Power Management (APM) is a feature that reduces the power consumption of components when they are not in use. Whe n enabled, APM initiates red uced-power mod es for th e monitor, microprocessor, and hard disk drive after a specified period of inactivity.

The BIOS supports APM 1.2. This enables the system to enter a power-management state, reducing the power drawn from the AC electrical outlet. Advanced Power Management is enabled through the Configuration/Setup Utility program and is controlled by the individual operating system.

For more information on APM, see the PC 300GL and PC 300PL User Guide and Understanding Your Personal Computer.

Advanced Configuration and Power Interface (ACPI)

Advanced Configuration and Power Interface (ACPI) BIOS mode enables the operating system to control the power-management features of your computer. Not all operating systems support ACPI BIOS mode. Refer to your operating-system documentation to determine if ACPI is supported.

Flash update utility program

The flash update utility program is a stand-alone program to support flash updates. This utility program updates the BIOS code and the machine readable information (MRI) to different languages.

The latest version of the flash update utility program is available on the IBM Web site at http://www.ibm.com/pc/support and can be copied to a 3.5-inch diskette.

Diagnostic program

The diagnostic program that comes with PC 300PL and the PC 300GL personal computers is provided as a startable IBM Enhanced Diagnostic diskette ima ge on the IBM Product Recove ry CD or the Device Driver and IBM Enhanced D iagnostic CD. It runs independently of the operating system. The user interface is WaterGate Software PCDoctor. The diagnostic program can also be downloaded from the following World Wide Web page: http://www.ibm.com/pc/support/. For more information on the diagnostic program, see the PC 300GL and PC 300PL User Guide.

30 PC 300 GL and 300 PL

Chapter 6. System compatibility

This chapter discusses some of the hardware, software, and BIOS compatibility issues for the computer. See the Compatibility Report under, “Related publications” on page

vii for a list of compatible hardware and software options.

Hardware compatibility

This section discusses hardware, software, and BIOS compatibility that must be considered when designing application programs.

The functional interfaces are compatible with the following interfaces:

• Intel 8259 interrupt controllers (edge-triggered mode)

• National Semiconductor NS16450 and NS126550A serial communications controllers

• Motorola MC146818 Time of Day Clock command and status (CMOS reorganized)

• Intel 8254 timer, driven from a 1.193 MHz clock (channels 0, 1, and 2)

• Intel 8237 DMA controller, except for the Command and Request registers and the Rotate and Mask functions; the Mode register is partially supported

• Intel 8272 or 82077 diskette drive controllers

• Intel 8042 keyboard controller at address hex 0060 and hex 0064

• All video standards using VGA, EGA, CGA, MDA, and Hercules modes

• Parallel printer ports (Parallel 1, Parallel 2, and Parallel 3) in compatibility mode

Use this information to develop application programs. Whenever possible, use the BIOS as an interface to hardware to provide maximum compatibility and portability of applications among systems.

Hardware interrupts

Hardware interrupts are level-sensitive for PCI interrupts. The interrupt controller clears its in-service register bit when the interrupt routine sends and End-of-Interrupt (EOI) command to the controller. The EOI command is sent regar dless of wh ether the incoming interrupt request to the controller is active or inactive.

The interrupt-in-progress latch is readable at an I/O-address bit position. This latch is read during the interrupt service r outine and might be reset by the r ead opera tion or it might require an explicit reset.

Note: For performance and latency considerations, designers might want to limit

the number of devices sharing an interrupt level.

With level-sensitive interrupts, the interrupt controller requires that the interrupt request be inactive at the time the EOI command is sent; otherwise, a new interrupt request will be detected. To avoid this, a level-sensi tive interrupt handler must clear the interrupt condition (usually by a read or write operation to an I/O port on the device causing the interrupt). After processing the interrupt, the interrupt handler:

1. Clears the interrupt

2. Waits one I/O delay

3. Sends the EOI

4. Waits one I/O delay

5. Enables the interrupt through the Set Interrupt Enable Flag command

Hardware interrupt IRQ9 is defined as the replacement interrupt level for the cascade level IRQ2. Program interrupt sharing is implemented on IRQ2, interrupt hex 0A. The following processing occurs to maintain compatibility with the IRQ2 used by IBM Personal Computer products:

1. A device drives the interrupt request active on IRQ2 of the channel.

2. This interrupt request is mapped in hardware to IRQ9 input on the second interrupt controller.

3. When the interrupt occurs, the system microprocessor passes control to the IRQ9 (interrupt hex 71) interrupt handler.

4. This interrupt handler performs an EOI command to the second interrupt controller and passes control to the IRQ2 (interrupt hex 0A) interrupt handler.

5. This IRQ2 interrupt handler, when handling the interrupt, causes the device to reset the interrupt request before performing an EOI command to the master interrupt controller that finishes servicing the IRQ2 request.

Software compati bil ity

To maint ain software compatibility, the interrupt polling mechanism that is used by IBM Personal Computer products is retained. Software that interfaces wi th the reset port for the IBM Personal Computer positive-edge interrupt sharing (hex address 02Fx or 06Fx, where x is the interrupt level) does not create interference.

Software interrupts

With the advent of software interrupt sharing, software interrupt routines must daisy chain interrupts. Each routine must check the function value, and if the function value is not in the range of function calls, that routine must transfer control to the next routine in the chain. Because software interrupts are initially pointed to address 0:0 before daisy chaining, check for this case. If the next routine is pointed to address 0:0 and the function call is out of range, the appropriate action is to set the carry flag and initiate a RET 2 to indicate an error condition.

Machine-sensitive programs

Programs can select machine-specific features, but they must first identify the machine and model type. IBM has defined methods for uniquely determining the specific machine type. The machine model byte can be found through interrupt 15H, Return System Configuration Parameters function (AH)=(C0H).

32 PC 300 GL and 300 PL

Appendix A. Connector pin assignments

The following figures show the pin assignments for various system board connectors.

SVGA monitor connector

10 6

15 11

Table 17. SVGA monitor port connector pin assignments Pin Signal I/O Pin Signal I/O

1 Red O 9 +5 V, used by

2 Green O 10 Ground NA 3 Blue O 11 Monitor ID 0 -

4Monitor ID 2 -

Not used

5 Ground NA 13 Horizontal

6 Red ground NA 14 Vertical sync O 7 Green ground NA 15 DDC2B clock I/O 8 Blue ground NA

I 12 DDC2B serial

DDC2B

Not used

I/O

data

sync

DVI-I monitor connector

C1 C2

C3C5C4

Table 18. DVI-I monitor port connector pin assignments - main pin field Pin Signal Pin Signal

1 TMDS data 2+ 13 TMDS data 3+ 2 TMDS data 2- 14 +5V power 3 TMDS data 2/4 return 15 Ground 4 TMDS data 4- 16 Hot plug detect 5 TMDS data 4+ 17 TMDS data 06 DDC clock 18 TMDS data 0+ 7 DDC data 19 TMDS data 08 Analog vertical sync 2 0 TMDS data 0/5 shield 9 TMDS data 1- 21 TMDS data 5+ 10 TMDS data 1+ 22 TMDS clock shield 11 TMDS 1/3 shield 23 TMDS clock+ 12 TMDS data 3+ 24 TMDS clock-

Table 19. DVI connector pin assignments - micro cross section Pin Signal

C1 Red video out C2 Green video out C3 Analog blue C4 Analog horizontal sync C5 Video/pixel clock return

System memory connecto r

168

34 PC 300 GL and 300 PL

Table 20. System memory connector pin assignments Pin x64 nonparity x72 ECC Pin x64 nonparity x72 ECC

1 VSS VSS 85 VSS VSS 2 DQ0 DQ0 86 DQ32 DQ32 3 DQ1 DQ1 87 DQ33 DQ33 4 DQ2 DQ2 88 DQ34 DQ34 5 DQ3 DQ3 89 DQ35 DQ35 6 VCC VCC 90 VCC VCC 7 DQ4 DQ4 91 DQ36 DQ36 8 DQ5 DQ5 92 DQ37 DQ37 9 DQ6 DQ6 93 DQ38 DQ38 10 DQ7 DQ7 94 DQ39 DQ39 11 DQ8 DQ8 95 DQ40 DQ40 12 VSS VSS 96 VSS VSS 13 DQ9 DQ 97 DQ41 DQ41 14 DQ10 DQ10 98 DQ42 DQ42 15 DQ11 DQ11 99 DQ43 DQ43 16 DQ12 DQ12 100 DQ44 DQ44 17 DQ13 DQ13 101 DQ45 DQ45 18 VCC VCC 102 VCC VCC 19 DQ14 DQ14 103 DQ46 DQ46 20 DQ15 DQ15 104 DQ47 DQ47 21 NC CB0 105 NC CB4 22 NC CB1 106 NC CB5 23 VSS VSS 107 VSS VSS 24 NC NC 108 NC NC 25 NC NC 109 NC NC 26 VCC VCC 110 VCC VCC 27 /WE /WE0 111 /CAS /CAS 28 DQMB0 DQMB0 112 DQMB4 DQMB4 29 DQMB1 DQMB1 113 DQMB5 DQMB5 30 /S0 /S0 114 NC /S1 31 DU NC 115 /RAS /RAS 32 VSS VSS 116 VSS VSS 33 A0 A0 117 A1 A1 34 A2 A2 118 A3 A3 35 A4 A4 119 A5 A5

Appendix A. Connector pin assignments 35

Table 20. System memory connector pin assignments Pin x64 nonparity x72 ECC Pin x64 nonparity x72 ECC

36 A6 A6 120 A7 A7 37 A8 A8 121 A9 A9 38 A10/AP A10/AP 122 BA0 BA0 39 NC BA1 123 NC A11 40 VCC VCC 124 VCC VCC 41 VCC VCC 125 CK1 CK1 42 CK0 CK0 126 A12 A12 43 VSS VSS 127 VSS VSS 44 DU NC 128 CKE0 CKE0 45 /S2 /S2 129 NC /S3 46 DQMB2 DQMB2 130 DQMB6 DQMB6 47 DQMB3 DQMB3 131 DQMB7 DQMB7 48 DU NC 132 A13 A13 49 VCC VCC 133 VCC VCC 50 NC NC 134 NC NC 51 NC NC 135 NC NC 52 NC CB2 136 NC CB6 53 NC CB3 137 NC CB7 54 VSS VSS 138 VSS VSS 55 DQ16 DQ16 139 DQ48 DQ48 56 DQ17 DQ17 140 DQ49 DQ49 57 DQ18 DQ18 141 DQ50 DQ50 58 DQ19 DQ19 142 DQ51 DQ51 59 VCC VCC 143 VCC VCC 60 DQ20 DQ20 144 DQ52 DQ52 61 NC NC 145 NC NC 62 NC NC 146 NC NC 63 NC CKE1 147 NC NC 64 VSS VSS 148 VSS VSS 65 DQ21 DQ21 149 DQ53 DQ53 66 DQ22 DQ22 150 DQ54 DQ54 67 DQ23 DQ23 151 DQ55 DQ55 68 VSS VSS 152 VSS VSS 69 DQ24 DQ24 153 DQ56 DQ56 70 DQ25 DQ25 154 DQ57 DQ57

36 PC 300 GL and 300 PL

Table 20. System memory connector pin assignments Pin x64 nonparity x72 ECC Pin x64 nonparity x72 ECC

71 DQ26 DQ26 155 DQ58 DQ58 72 DQ27 DQ27 156 DQ59 DQ59 73 VCC VCC 157 VCC VCC 74 DQ28 DQ28 158 DQ60 DQ60 75 DQ29 DQ29 159 DQ61 DQ61 76 DQ30 DQ30 160 DQ62 DQ62 77 DQ31 DQ31 161 DQ63 DQ63 78 VSS VSS 162 VSS VSS 79 CK2 CK2 163 CK3 CK3 80 NC NC 164 NC NC 81 NC NC 165 SA0 SA0 82 SKA SDA 166 SA1 SA1 83 SCL SCL 167 SA2 SA2 84 VCC VCC 168 VCC VCC

Table 21. System memory connector pin input/output Pin Signal name I/O Pin Signal name I/O

1 GND N/A 85 GND N/A 2 MD0 I/O 86 MD32 I/O 3 MD1 I/O 87 MD33 I/O 4 MD2 I/O 88 MD34 I/O 5 MD3 I/O 89 MD35 I/O 6 VDD I/O 90 VDD N/A 7 MD4 I/O 91 MD36 N/A 8 MD5 I/O 92 MD37 I/O 9 MD6 I/O 93 MD38 I/O 10 MD7 I/O 94 MD39 I/O 11 MD8 (PAR0) I/O 95 MD40 I/O 12 GND N/A 96 GND N/A 13 MD9 I/O 97 MD41 I/O 14 MD10 I/O 98 MD42 I/O 15 MD11 I/O 99 MD43 I/O 16 MD12 I/O 100 MD44 I/O 17 MD13 I/O 101 MD45 I/O 18 VDD N/A 102 VDD N/A

Appendix A. Connector pin assignments 37

Table 21. System memory connector pin input/output Pin Signal name I/O Pin Signal name I /O

19 MD14 I/O 103 MD46 I/O 20 MD15 I/O 104 MD47 I/O 21 NC I/O 105 NC I/O 22 NC I/O 106 NC I/O 23 GND I/O 107 GND N/A 24 NC N/A 108 NC N/A 25 NC N/A 109 NC N/A 26 VDD N/A 110 VDD N/A 27 WE# I 111 CAS# N/A 28 DQMB0# I 112 DQMB4# I 29 DQMB1# I 113 DQMB4# I 30 S0# I 114 S1# I 31 OE0# I 115 RAS# N/A 32 GND N/A 116 GND N/A 33 A0 I 117 A1 I 34 A2 I 118 A3 I 35 A4 I 119 A5 I 36 A6 I 120 A7 I 37 A8 I 121 A9 I 38 A10/AP I 122 A11 I 39 NC 123 NC 40 VDD N/A 124 VDD N/A 41 NC N/A 125 CK1 N/A 42 CK0 N/A 126 A14 O 43 GND N/A 127 GND N/A 44 OE2# I 128 CKE0 N/A 45 S2# I 129 S3# I 46 DQMB2# I 130 DQMB6# I 47 DQMB3# I 131 DQMB7# I 48 WE2# I 132 A15 I 49 VDD N/A 133 VDD N/A 50 NC N/A 134 NC N/A 51 NC N/A 135 NC N/A 52 NC I/O 136 NC I/O 53 NC I/O 137 NC I/O

38 PC 300 GL and 300 PL

Table 21. System memory connector pin input/output Pin Signal name I/O Pin Signal name I /O

54 GND N/A 138 GND N/A 55 MD16 I/O 139 MD48 I/O 56 MD17 I/O 140 MD49 I/O 57 MD18 I/O 141 MD50 I/O 58 MD19 I/O 142 MD51 I/O 59 VDD N/A 143 VDD N/A 60 MD20 I/O 144 MD52 I/O 61 CKE1 N/A 145 NC N/A 62 VREF N/A 146 VREF N/A 63 (CKE1)* N/A 147 NC N/A 64 GND N/A 148 GND N/A 65 MD21 I/O 149 MD53 I/O 66 MD22 I/O 150 MD54 I/O 67 MD23 I/O 151 MD55 I/O 68 GND N/A 152 GND N/A 69 MD24 I/O 153 MD56 I/O 70 MD25 I/O 154 MD57 I/O 71 MD26 I/O 155 MD58 I/O 72 MD27 I/O 156 MD59 I/O 73 VDD N/A 157 VDD N/A 74 MD28 I/O 158 MD60 I/O 75 MD29 I/O 159 MD61 I/O 76 MD30 I/O 160 MD62 I/O 77 MD31 I/O 161 MD63 I/O 78 GND N/A 162 GND N/A 79 CK2 O 163 CK3 O 80 NC N/A 164 NC N/A 81 NC O 165 SA0 O 82 SDA O 166 SA1 O 83 SCL O 167 SA0 O 84 VDD N/A 168 VDD N/A

Appendix A. Connector pin assignments 39

PCI connectors

A62

B62

Table 22. PCI connector pin assignments Pin Signal I/O Pin Signal I/O

A1 TRST# O B1 -12 V dc N/A A2 +12 V dc N/A B2 TCK O A3 +12 V dc O B3 Ground N/A A4 TDI O B4 TDO I A5 +5 V dc N/A B5 +5 V dc N/A A6 INTA# I B6 +5 V dc N/A A7 INTC# I B7 INTB# I A8 +5 V dc N/A B8 INTD# I A9 Reserved N/A B9 PRSNT1# I A10 +5 V dc (I/O) N/A B10 Reserved N/A A11 Reserved N/A B11 PRNST2 I A12 Ground N/A B12 Ground N/A A13 Ground N/A B13 Ground N/A A14 Reserved N/A B14 Reserved N/A A15 RST# O B15 Ground N/A A16 +5 V dc (I/O) N/A B16 O O A17 GNT# O B17 Ground N/A A18 Ground N/A B18 REQ# I A19 PCIPME N/A B19 +5 V dc (I/O) N/A A20 Address/data 30 I/O B20 Address/data 31 I/O A21 +3.3 V dc N/A B21 Address/data 29 I/O A22 Address/data 28 I/O B22 Ground N/A A23 Address/data 26 I/O B23 Address/data 27 I/O A24 Ground I/O B24 Address/data 25 N/A A25 Address/data 24 I/O B25 +3.3 V dc N/A A26 IDSEL O B26 C/BE 3# I/O A27 +3.3 V dc N/A B27 Address/data 23 I/O

40 PC 300 GL and 300 PL

Table 22. PCI connector pin assignments Pin Signal I/O Pin Signal I/O

A28 Address/data 22 I/O B28 Ground N/A A29 Address/data 20 I/O B29 Address/data 21 I/O A30 Ground I/O B30 Address/data 19 N/A A31 Address/data 18 I/O B31 +3.3 V dc N/A A32 Address/data 16 I/O B32 Address/data 17 I/O A33 +3.3 V dc N/A B33 C/BE2# I/O A34 FRAME# I/O B34 Ground N/A A35 Ground N/A B35 IRDY# I/O A36 TRDY# I/O B36 +3.3 V dc N/A A37 Ground N/A B37 DEVSEL# I/O A38 STOP# I/O B38 Ground N/A A39 +3.3 V dc N/A B39 LOCK# I/O A40 SDO NE I/O B40 PERR# I/O A41 SBO# I/O B41 +3.3 V dc N/A A42 Ground N/A B42 SERR# I/O A43 +3.3 V dc N/A B43 +3.3 V dc N/A A44 C/BE(1)# I/O B44 C/BE 1# I/O A45 Address/data 14 I/O B45 Address/data 14 I/O A46 Ground N/A B46 Ground N/A A47 Address/data 12 I/O B47 Address/data 12 I/O A48 Address/data 10 I/O B48 Address/data 10 I/O A49 Ground N/A B49 Ground N/A A50 Key N/A B50 Key N/A A51 Key N/A B51 Key N/A A52 Address/data 8 I/O B52 Address/data 8 I/O A53 Address/data 7 I/O B53 Address/data 7 I/O A54 +3.3 V dc N/A B54 +3.3 V dc N/A A55 Address/data 5 I/O B55 Address/data 5 I/O A56 Address/data 3 I/O B56 Address/data 3 I/O A57 Ground N/A B57 Ground N/A A58 Address/data 1 I/O B58 Address/data 1 I/O A59 +5 V dc (I/O) N/A B59 +5 V dc (I/O) N/A A60 ACK64# I/O B60 ACK64# I/O A61 +5 V dc N/A B61 +5 V dc N/A A62 +5 V dc N/A A62 +5 V dc N/A

Appendix A. Connector pin assignments 41

IDE connectors

Table 23. IDE connector pin assignments Pin Signal I/O Pin Signal I/O

1 RESET O 21 NC N/A 2 Ground N/A 22 Ground N/A 3 Data bus bit 7 I/O 23 I/O write O 4 Data bus bit 8 I/O 24 NC N/A 5 Data bus bit 6 I/O 25 I/O read O 6 Data bus bit 9 I/O 26 Ground I 7 Data bus bit 5 I/O 27 I/O channel ready I 8 Data bus bit 10 I/O 28 ALE O 9 Data bus bit 4 I/O 29 NC N/A 10 Data bus bit 11 I/O 30 Ground N/A 11 Data bus bit 3 I/O 31 IRQ I 12 Data bus bit 12 I/O 32 CS16# I 13 Data bus bit 2 I/O 33 SA1 O 14 Data bus bit 13 I/O 34 PDIAG# I 15 Data bus bit 1 I/O 35 SA0 O 16 Data bus bit 14 I/O 36 SA2 O 17 Data bus bit 0 I/O 37 CS0# O 18 Data bus bit 15 I/O 38 CS1 O 19 Ground N/A 39 Active# I 20 Key (Reserved) N/A 40 Ground N/A

42 PC 300 GL and 300 PL

Diskette drive connector

Table 24. Diskette drive connector pin assignments Pin Signal I/O Pin Signal I/O

1 Drive 2 installed # I 18 Direction in# O 2 High density

O19GroundN/A

select 3 Not connected N/A 20 Step# O 4 Not connected N/A 21 Ground N/A 5 Ground N/A 22 Write data # O 6 Data rate 0 N/A 23 Ground N/A 7 Ground N/A 24 Write enable# O 8 Index# I 25 Ground N/A 9 Reserved N/A 26 Track0# I 10 Motor enable 0# O 27 MSEN0 I 11 Ground N/A 28 Write pr o t ect # I 12 Drive select 1# O 29 Ground N/A 13 Ground N/A 30 Read data# I 14 Drive select 0# O 31 Ground N/A 15 Ground N/A 32 Head 1 select# O 16 Motor enable 1# O 33 Data rate 1 N/A 17 MSEN1 I 34 Diskette change# I

Appendix A. Connector pin assignments 43

Power supply connector

Table 25. Power supply connector pin assignments Pin Signal Function Pin Signal Function

1 3.3 V dc +3.3 V dc 11 3.3 V dc +3.3 V dc 2 3.3 V dc +3.3 V dc 12 -12 V dc -12 V dc 3 COM Ground 13 COM Ground 4 5 V dc +5 V dc 14 PS-ON DC Remote

Enable 5 COM Ground 15 COM Ground 6 5 V dc +5 V dc 16 COM Ground 7 COM Ground 17 COM Ground 8 POK PWR GOOD 18 Reserved Reserved 9 5 VSB Standby Voltage 19 5 V dc +5 V dc 10 12 V dc +12 V dc 20 5 V dc +5 V dc

Wake on LAN connectors

Table 26. J14 Wake on LAN connector pin assignments Pin Description

1 +5 V AUX 2Ground 3 Internal Wake on LAN

USB port connectors

Table 27. USB port connector pin assignments Pin Signal

1VCC 2-Data

3+Data 4Ground

44 PC 300 GL and 300 PL

Mouse and keyboard port connectors

6 4

5 3

Table 28. Mouse port connector pin assignments Pin Signal I/O Pin Signal I/O

1DataI/O4+5 V dcN/A 2 Reserved I/O 5 Clock I/O 3 Ground N/A 6 Reserved N/A

Table 29. Keyboard port connector pin assignments Pin Signal I/O Pin Signal I/O

1 Keyboard data I/O 4 +5 V dc N/A 2 Mouse data I/O 5 Keyboard

I/O

Clock

3GroundN/A6Mouse clockN/A

Serial port connector

Table 30. Serial port connector pin assignments Pin Signal I/O Pin Signal I/O

1 Data carrier detect I 5 Ground N/A 2 Receiv e data# I 6 Data set ready I 3 Transmit data# O 7 Request to send O 4 Data terminal read O 8 Clear to send I 9 Ring indicator

Appendix A. Connector pin assignments 45

Parallel port connector

Table 31. Parallel port connector pin assignments Pin Signal I/O Pin Signal I/O

1 STROBE# I/O 14 AUTO FD XT# O 2 Data bit 0 I/O 15 ERROR# I 3 Data bit 1 I/O 16 INIT# O 4 Data bit 2 I/O 17 SLCT IN# O 5 Data bit 3 I/O 18 Ground N/A 6 Data bit 4 I/O 19 Ground N/A 7 Data bit 5 I/O 20 Ground N/A 8 Data bit 6 I/O 21 Ground N/A 9 Data bit 7 I/O 22 Ground N/A 10 ACK# I 23 Ground N/A 11 BUSY I 24 Ground N/A 12 PE I 25 Ground N/A 13 SLCT I

46 PC 300 GL and 300 PL

Appendix B. System address maps

The following charts represent how the hard disk stores different types of information. Address ranges and byte sizes are approximate.

System memory map

The first 640 KB of system board RAM is mapped starting at address hex 0000000. A 256 byte area and a 1 KB area of this RAM are reserved for BIOS data areas. Memory can be mapped differentl y if POST detects an error.

Table 32. System memory map Address range

(decimal)

0–512 KB 00000–7FFFF 512 KB Conventional 512–639 KB 80000–9FBFF 127 KB Extended conventional 639–640 KB 9FC00–9FFFF 1 KB Extended BIOS data 640–767 KB A0000–BFFFF 128 KB Dynamic video memory display

768–800 KB C0000–C7FFFF 32 KB Video ROM BIOS (shadowed) 800–896 KB C8000–DFFFF 96 KB PCI space, available to adapter

896 KB–1 MB E0000–FFFF F 128 KB System ROM BIOS (main memory

1–16 MB 100000–FFFFFF 15 MB PCI space 16–4096 MB 1000000–FFDFFFF 4080 MB PCI space (positive decode) 4096–4120 MB FFFE0000–FFFFFFFF 128 KB System ROM BIOS

Address range (hex) Size Description

cache

ROMs

shadowed)

Input/output address map

The following lists resource assignments for the I/O address map. Any addresses that are not shown are reserved.

Table 33. I/O address map Address (hex) Size Description

0000–000F 16 bytes DMA 1 0010–001F 16 bytes General I/O locations - available to PCI bus 0020–0021 2 bytes Interrupt controller 1 0023–003F 30 bytes General I/O locations - available to PCI bus 0040–0043 4 bytes Counter/timer 1 0044–00FF 28 bytes General I/O locations - available to PCI bus 0060 1 byte Keyboard controller byte - reset IRQ 0061 1 byte System port B 0064 1 byte Keyboard controller, CMB/STAT byte 0070, bit 7 1 bit Enable NMI 0070, bits 6:0 1 bit Real-time clock, address 0071 1 byte Real-time clock, data 0072–007F 14 bytes General I/O locations - available to PCI bus 0080 1 byte POST checkpoint register during POST only 008F 1 byte Refresh page register 0080–008F 16 bytes ICH1, DMA page registers 0090–0091 15 bytes General I/O locations - available to PCI bus 0092 1 byte PS/2 keyboard controller registers 0093–009F 15 bytes General I/O locations 00A0–00A1 2 bytes Interrupt controller 2 00A2–00BF 30 bytes APM control 00C0–00DF 31 bytes DMA 2 00E0–00EF 16 bytes General I/O locations - available to PCI bus 00F0 1 byte Coprocessor error register 00F1–016F 127 bytes General I/O locations - available to PCI bus 0170–0177 8 bytes Secondary IDE channel 01F0–01F7 8 bytes Primary IDE channel 0200–0207 8 bytes Available 0220–0227 8 bytes Serial port 3 or 4 0228–0277 80 bytes General I/O locations - available to PCI bus 0278–027F 8 bytes LPT3

48 PC 300 GL and 300 PL

Table 33. I/O address map Address (hex) Size Description

0280–02E7 102 bytes Available 02E8–02EF 8 bytes Serial port 3 or 4 02F8–02FF 8 bytes COM2 0338–033F 8 bytes Serial port 3 or 4 0340–036F 48 bytes Available 0370–0371 2 bytes SIO planar Plug and Play index/data registers 0372–0375 4 bytes Available 0376–0377 2 bytes IDE channel 1 command 0378–037F 8 bytes LPT2 0380–03B3 52 bytes Available 03B4–03B7 4 bytes Video 03BA 1 byte Video 03BC–03BE 16 bytes LPT1 03C0–03CF 16 bytes Video 0334–03D7 4 bytes Video 03DA 1 byte Video 03D0–03DF 11 bytes Available 03E0–03E7 8 bytes Available 03E8–03EF 8 bytes COM3 or COM4 03F0–03F5 6 bytes Diskette channel 1 03F6 1 byte Primary IDE channel command port 03F7 (Write) 1 byte Diskette channel command 03F7, bit 7 1 bit Diskette disk change channel 03F7, bits 6:0 7 bits Primary IDE channel status port 03F8–03FF 8 bytes COM1 0400–047F 128 bytes Available 0480–048F 16 bytes DMA channel high page registers 0490–0CF7 1912 bytes Available 0CF8–0CFB 4 bytes PCI configuration address register 0CFC–0CFF 4 bytes PCI configuration date register OPTn–400h 8 bytes ECP port, LPTn base address + hex 400 0CF9 1 byte Turbo and reset control register 0D00–FFFF 62207 bytes Available

Appendix B. System address maps 49

DMA I/O address map

Table 34. DMA I/O address map Address (hex) Description Bits Byte pointer

0000 Channel 0, Memory Address register 00–15 Y es 0001 Channel 0, Transfer Count register 00–15 Yes 0002 Channel 1, Memory Address register 00–15 Yes 0003 Channel 1, Transfer Count register 00–15 Yes 0004 Channel 2, Memory Address register 00–15 Yes 0005 Channel 2, Transfer Count register 00–15 Yes 0006 Channel 3, Memory Address register 00–15 Yes 0007 Channel 3, Transfer Count register 00–15 Yes 0008 Channels 0–3, Read Status/Write Comm and

register 0009 Channels 0–3, Write Request register 00–02 000A Channels 0–3, Write Single Mask register bits 00–02 000B Channels, 0–3, Mode register (write) 00–07 000C Channels 0–3, Clear byte pointer (write) N/A 000D Channels, 0–3, Master clear (writer)/temp (read) 00–07 000E Channels 0–3, Clear Mask register (write) 00–03 000F Channels 0–3, Write All Mask register bits 00–03 0081 Channel 2, Page Table Address register 00–07 0082 Channel 3, Page Table Address register 00–07 0083 Channel 1, Page Table Address register 00–07 0087 Channel 0, Page Table Address register 00–07 0089 Channel 6, Page Table Address register 00–07 008A Channel 7, Page Table Address register 00–07 008B Channel 5, Page Table Address register 00–07 008F Cha nnel 4, Page Table Address/Refresh register 00–07

00–07

00C0 Channel 4, Memory Address register 00–15 Yes 00C2 C ha nnel 4, Transfer Count register 00–15 Yes 00C4 Channel 5, Memory Address register 00–15 Yes 00C6 C ha nnel 5, Transfer Count register 00–15 Yes 00C8 Channel 6, Memory Address register 00–15 Yes 00CA Channel 6, Transfer Count register 00–1 5 Yes 00CC Channel 7, Memory Address register 00–15 Yes

50 PC 300 GL and 300 PL

Table 34. DMA I/O address map Address (hex) Description Bits Byte pointer

00CE Channel 7, Transfer Count register 00–15 Y es 00D0 Channels 4–7, Read Status/Write Command

register 00D2 Channels 4–7, Write Request register 00–02 00D4 Channels 4–7, Write Single Mask register bit 00–02 00D6 Channels 4–7, Mode register (write) 00–07 00D8 Channels 4–7, Clear byte pointer (write) N/A 00DA Channels 4–7, Master clear (write)/temp (read) 00–07 00DC Channels 4–7, Clear Mask register (write) 00–03 00DE Channels 4–7, Write All Mask register bits 00–03 00DF Channels 507, 8- or 16-bit mode select 00–07

00–07

PCI configuration space map

Table 35. PCI configuration space map Bus number (hex) Device number (hex) Function number (hex) Description

00 00 00 VIA VT 82C694X (north bridge) 00 01 00 VIA VT 82C694X (north bridge) 00 02 00 VIA VT 82C596B (south bridge) 00 02 01 VIA VT 82C596B (south bridge) 00 02 02 VIA VT 82C596B (south bridge) 00 02 03 Intel 82371AB power management 00 0 x 12 00 ESS 1930 audio controller 01 00 00 S3Tio3D AGP video 00 0 x 10 N/A Slot 1 00 0 x 0F N/A Slot 2 00 0 x 0E N/A Slot 3

Appendix B. System address maps 51

52 PC 300 GL and 300 PL

Appendix C. IRQ and DMA channel assignments

The following tables list the inte rrupt request (IR Q) and direct memory access (DMA channel assignments .

Table 36. IRQ channel assignments IRQ System resource

NMI Critical system error SMI System management interrupt - power management 0 Reserved (interval timer) 1 Reserved (keyboard) 2 Reserved, cascade interrupt from slave PIC 3COM2 4COM1 5 LPT2/audio (if present) 6 Diskette controller 7LPT1 8 Real-time clock 9ACPI 10 Available to user 11 Available to user 12 Mouse port 13 Reserved (math coprocessor) 14 Primary IDE (if present) 15 Secondary IDE (if present)

Table 37. DMA channel assignments DMA channel Data width System resource

0 8 bits Open 1 8 bits Open 2 8 bits Diskette drive 3 8 bits Parallel port (for ECP or EPP) 4 -- Reserved (cascade channel) 516 bitsOpen 616 bitsOpen 716 bitsOpen

54 PC 300 GL and 300 PL

Appendix D. Error codes

Complete lists of POST and beep error codes are provided in the PC300GL and PC 300PL User Guide and in the Hardware Maintenance Manual.

POST error codes

POST error messages appear when, during startup, POST finds problems with the hardware or a change in the hardware configuration. POST error messages are 3-, 4-, 5-, 8-, or 12-character alphanumeric messages.

Beep codes

Beep codes are a series of tones in sets of two or three that sound when there are POST errors. The beep pattern repr esents numeric values and provides further information about the location of a potential problem.

The Hardware Maintenance Manual provides a complete list of beep codes.

56 PC 300 GL and 300 PL

Appendix E. Notices and Trademarks

This publication was developed for produ cts and services offered in the U.S.A. IBM may not offer the products, services, or features discussed in this document in

other countries. Consult your local IBM representative for information on the products and services currently available in your area. Any reference to an IBM product, program, or service is not intended to s tate or imply that only that IBM product, program, or service may be used. Any functionally equivalent product, program, or service that does not infringe any IBM intellectual property right may be

used instead. However, it is the user’s responsibility to evaluate and verify the operation of any non-IBM product, program, or service.

IBM may have patents or pending patent applications covering subject matter described in this document. The furnishing of this document does not give you any license to these patents. You can send license inquiries, in writing, to:

IBM Director of Licensing IBM Corporation North Castle Drive Armonk, NY 10504-1785 U.S.A.

The following paragraph does not apply to the United Kingdom or any country where such provisions are inconsistent with local law: INTERNATIONAL

BUSINESS MACHINES CORPORATION PROVIDES THIS PUBLICATION "AS IS" WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF NONINFRINGEMENT, MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. Some states do not allow disclaimer of express or implied warranties in certain transactions, therefore, this statement may not apply to you.

This information could include technical inaccuracies or typographical errors. Changes are periodically made to the information herein; these changes will be incorporated in new editions of the publication. IBM may make improvem ents and/or changes in the product(s) and/or the program(s) described in this publication at any time. without notice.

Any references in this publication to non-IBM Web sites are provided for convenience only and do not in any manner serve as an endorsement of those Web sites. The materials at those W eb sites ar e not part of the materials for this IBM product, an d use of those Web sites is at your own risk.

The following terms are trademarks of the IBM Corporation in the United States or other countries or both:

Alert on LAN IBM PC300 Wake on LAN

Pentium, Intel, and MMX are trademarks of Intel Corporation in the United States, other countries, or both.

Microsoft and W indo ws are tradem arks of Microso ft Corporation in the U nited States, other countries, or both.

Other company, product, and service names may be trademarks or service marks of others.

58 PC 300 GL and 300 PL

Bibliography

The following publications were reference materials for IBM staff in developing the PC300 PL and 300 GL. This list of reference materials is provided for convenience only. For further information on these materials, contact the source corporation.

• Advanced Power Management (APM) BIOS Interface Specification 1.2, Source: Intel

Corporation

• AT Attachment Interface with Extensions, Source: American National Standard of Accredited Standards Committee

• Extended Capabilities Port: Specification Kit, Source: Microsoft Corporation

• Intel Microprocessor and Peripheral Component Literature, Source: Intel Corporation

• PCI BIOS Specification 2.0, Source: PCI Special Interest Grou p

• Plug and Play BIOS Specification 1.1, Source: Microsoft Corporation; http://www.microsoft.com/hwdev/

• Plug and Play BIOS Specification for Windows 2000, Source: Microsoft Corporation

• Plug and Play BIOS Specification, Errata and Clarifications 1.0, Source: Microsoft Corporation

• Universal Serial Bus Specifications, Source: http://www.usb.org

• Video Electronics Standards Association 1.2, Source: http://www.vesa.org

60 PC 300 GL and 300 PL

Index A

Accelerated Grap hi cs P o rt 8 ACPI 30 address maps

DMA I/O 50 input/output 48 PCI configuration 51

system memory 47 Adlib 10 ADSL modems 3 Advanced Configuration and Power

Interface 30 Advanced Power Management 30 AGP 8 APM 30 audio

connectors 10 controller 10 device drivers 10 subsystem 10

basic input/output system 29 beep error 55 bibliography 59 BIOS 29 bus

PCI 7 universal serial 7

CD-RW(Rewritable) 2 channel assignments

DMA 54

IRQ 53 chip set 5 clock 13 CMOS 13 compatibility

hardware 31

software 32 component current 26 Configuration/Setup Utility 30 connector

cables 17

diskette drive 43

DVI-I 34

IDE 42

keyboard 45

mouse port 45

parallel port 46

PCI 40

power supply 44

serial port 45

SVGA 33

system memory 34

USB 44

Wake on LAN 44 Connector Panel

desktop, tower 17 connector panel

desktop 18

tower 19

DDC 9 DIMM 6 direct memory access 7 diskette drive

connector 43

interface 11 DMA 7 DMA I/O address map 50 dual inline memory module 6 DVD-ROM 2 DVI-I

connector 34

interface 8

ECP 12 EEPROM 13 end-of-interrupt (EOI) 31 enhanced parallel port 12 EOI (end-of-interrupt) 31 EPP 12 error codes

alphanumeric 55

beep 55

complete lists 55

POST 55 Ethernet 13 expansion

adapters 13

PCI 13

slots 13 extended capabilities port 12

flash

EEPROM 13

update utility 30 frames per second 8

GB viii gigabyte viii

hardware interru pts 31 hex viii

IDE

connector 42 input/output address map 48 integrated peripheral controller 11 interrupts

hardware 31

PCI 31

software 32

keyboard port connector 45 kilobytes viii

machine model byte 32 machine-sensitive programs 32 major features 1 megabyte viii memory

connectors 34

system 5 microprocessor 5 MMX 5 mouse 12 mouse port connector 45

network

Eathernet 13

token ring 13

overview 1 overvoltage 27

PAL 8 parallel port 12 parallel port connector 46 PCI

connectors 40

interrupts 31 PCI configuration space map 51 PCI connector 40 pin assignments 33 Plug and Play 29 port

keyboard 12

mouse 12

parallel 12 ports

serial 11 POST 29

errors 55 Power

input, output 25 power

supply 27

supply connector 44 Power Supply 25 power-on self-test 29 publications, related vii

real-time clock 13 related publications vii Remote Program Local 13 reserved viii

Rocker Switches 15

serial port connector 45 Serial ports 11 shutdown 27 SMID 1 software

CDs 30 compatibility 32 diagnostic program 30 system 29

SoundBlaster 10 specifications

desktop 21

tower 22 SPP 12 standard parallel port 12 SVGA monitor connec t or 33 system board 5, 14 system memory map 47

terminology viii token ring 13

UART 11 Universal Serial Bus 7 USB

interface 7

port connectors 44

VGA 9 video

DVI-I 34

frames per second 8

graphic solutions 8

graphics arra y 9

modes 10

SVGA 33 Video Electronics Standards Associ-

ation 9

Wake on LAN 3 Wake on LAN connector 44 Wake on Ring 3

62 PC 300 GL and 300 PL

IBM PC 300GL User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Contents

Preface

Chapter 1. System Overview

Chapter 2. System board features

Chapter 3. Physical specifications

Chapter 4. Power supply

Chapter 5. System software

Chapter 6. System compatibility

Appendix A. Connector pin assignments

Appendix B. System address maps

Appendix C. IRQ and DMA channel assignments

Appendix D. Error codes

Appendix E. Notices and Trademarks

Bibliography
