IBM CP-X445 User Manual
Projector
CP-X445
User Manual – Operating Guide
Thank you for purchasing this projector.
WARNING ►Before using, read the "User's Manual - Safety Guide" and
these manuals to ensure correct usage through understanding. After reading,
store them in a safe place for future reference.
About this manual
Various symbols are used in this manual. The meanings of these symbols are
described below.
WARNING This symbol indicates information that , if ignored, could possibly
result in personal injury or even death due to incorrect handling.
CAUTION This symbol indicates information that , if ignored, could result
possibly in personal injury or physical damage due to incorrect
handling.
Please refer to the pages written following this symbol.
NOTE • The information in this manual is subject to change without notice.
• The manufacturer assumes no responsibility for any errors that may appear in this manual.
• The reproduction, transmission or use of this document or contents is not permitted without
express written authority.
Trademark acknowledgment
• VGA and XGA are registered trademarks of the International Business Machines
Corporation.
• Apple and Mac are registered trademarks of the Apple Computer, Inc.
• VESA and SVGA are trademarks of the Video Electronics Standard Association.
• Windows is a registered trademark of the Microsoft Corporation.
• Internet Explorer is a trademark of the Microsoft Corporation.
• Netscape is a registered trademark of the Netscape Communications Corporation.
All other trademarks are the property of their respective owners.
1
2
About this manual . . . . . . . . . . 1
Contents . . . . . . . . . . . . . . . . . 2
Projector features . . . . . . . . . .
3
Preparations . . . . . . . . . . . . . .
3
About contents of package . . . . . . . 3
Fastening the lens cap . . . . . . . . . . 3
Part names
. . . . . . . . . . . . . . . 4
Projector . . . . . . . . . . . . . . . . . . . . . 4
Control buttons . . . . . . . . . . . . . . . . 5
Remote control . . . . . . . . . . . . . . . . 5
Setting up . . . . . . . . . . . . . . . . 6
Arrangement . . . . . . . . . . . . . . . . . . 7
Adjusting the projector's elevator . . 8
About the filter cover for bottom-up use
. . 9
Connecting your devices . . . . . . . . 10
Connecting power supply . . . . . . . 13
Remote control . . . . . . . . . . .
14
Laser pointer . . . . . . . . . . . . . . . . . 14
Putting batteries . . . . . . . . . . . . . . 14
Using the remote control . . . . . . . . 15
Power on/off
. . . . . . . . . . . . . 16
Turning on the power . . . . . . . . . . .
16
Turning off the power . . . . . . . . . . .
16
Operating
. . . . . . . . . . . . . . . 17
Adjusting the volume . . . . . . . . . . . 17
Temporarily muting the sound . . . .
17
Selecting an input signal . . . . . . . . 17
Adjusting screen with ONE-TOUCH
. . 18
Selecting an aspect ratio . . . . . . . . 18
Adjusting the zoom and focus . . . . 18
Using the automatic adjustment feature
. 19
Adjusting the position . . . . . . . . . . 19
Correcting the keystone distortions 20
Using the magnify feature . . . . . . . 20
Freezing the screen . . . . . . . . . . . . 21
Temporarily blanking the screen
. . 21
Operating the computer screen . . . 22
Multifunctional settings . . . . 23
Using the menu function . . . . . . . . 23
Contents
Contents
EASY Menu . . . . . . . . . . . . . . . . . . 24
Aspect, Mode, Bright, Contrast, Color,
Tint, Sharpness, Whisper, Mirror, Reset,
Filter time, Language, Go to advanced
menu
PICTURE Menu . . . . . . . . . . . . . . . 26
Bright, Contrast, Gamma, Color temp,
Color, Tint, Sharpness, My memory
IMAGE Menu . . . . . . . . . . . . . . . . . 29
Aspect, Over scan, V. position, H. phase,
H. position, H. size, Auto adjust execute
VIDEO Qlty. Menu . . . . . . . . . . . . . 31
Progressive, 3D-YCS, Video NR
INPUT Menu . . . . . . . . . . . . . . . . . 32
Color space, Component, Video format,
DVI, Information
SETUP Menu . . . . . . . . . . . . . . . . . 34
Whisper, Mirror, Volume, Stereo, IR remote
SCREEN Menu . . . . . . . . . . . . . . . 35
Language, Menu position, OSD bright,
Blank, Start up, MyScreen,
MyScreen lock, Message
OPTION Menu . . . . . . . . . . . . . . . . 38
One touch, Auto
search, Auto off, Lamp
time, Filter time, Service
NETWORK Menu . . . . . . . . . . . . . 40
DHCP, IP address, Subnet mask, Default
gateway, Information
Maintenance . . . . . . . . . . . . . 44
Lamp . . . . . . . . . . . . . . . . . . . . . . . 44
Air filter
. . . . . . . . . . . . . . . . . . . . . 46
Other care . . . . . . . . . . . . . . . . . . . 47
Troubleshooting
. . . . . . . . . . 48
Related messages . . . . . . . . . . . . . 48
Regarding the indicator lamps . . . . 50
Phenomena that may easily be
mistaken for machine defects . . . . 52
Warranty and after-service
. . . 54
Specifications . . . . . . . . . . . .
54
Technical (English only)
(Please see the end of this book, although only in English.)
3
Projector features / Preparations
Projector features
This projector is used to project various computer signals as well as NTSC/PAL/
SECAM video signals onto a screen. It requires just a little space for installation
and gets a large image from short distance.
High Brightness
Newly developed 230W UHB (Ultra High Brightness) lamp gives you a higher
brightness image on a screen. The image can be still kept as bright and clean
enough for use in bright rooms.
Low Noise
WHISPER mode is equipped for reducing acoustic noise to realize quieter
operation. It is perfect for use in low luminance rooms where low noise is more
important than brightness.
Rich Connectivity
This projector has a variety of I/O ports. It can be easily connected to many
signal sources like PC, DVD and so on. The rich connectivity provides you
more options to make your presentation impressive.
Compact Body
Even with its many features, this projector is extremely compact and slim,
which gives you more flexibility and usability to use it where you want.
Preparations
About contents of package
Please see the "Contents of package" of the "User's Manual - Quick Guide". Your
projector should come with the items shown there. Contact immediately your
dealer if anything is missing.
NOTE
• Keep the original packing materials for future reshipment. For
moving the projector, be sure to use the original packing material. Use special
caution for the lens part.
Fastening the lens cap
To avoid losing, please fasten the lens cap to the projector using the strap.
1.
Fix the strap to the strap ring of lens cap.
2.
Put the strap into the groove on rivet.
3.
Push the rivet into the strap hole.
Strap ring
Strap
Strap hole
Bottom side
4
Y
VIDEO
RGB IN1 RGB IN2
DVI-
D
RGB OUT CONTROL
AUDIO-IN
REMOTE
CONTRO
L
US
B
DC OU
T
S-VIDE
O
LA
N
COMPONENT VIDE
O
CB/P
B
CR/P
R
R-AUDIO IN-L
AUDIO-OU
T
Part names
Lens (16)
Filter cover (46)
(Air filter and intake vent
are inside.)
Elevator button (8)
Elevator foot (8)
Remote sensor (15)
Zoom knob (18)
Focus ring (18)
Vent (
6)
AC inlet (13)
Power switch (16)
Elevator button (8)
COMPONENT
VIDEO ports (12)
Y
CB/P
B
CR/P
R
S-VIDEO port (12)
VIDEO port (12)
CONTROL port (
11
)
Part names
Projector
Lamp cover (45)
(Lamp unit is inside.)
Elevator foot (8)
Bottom side
Speaker
Front-Right side
Rear-Left side
Control buttons (5)
(See the following page.)
Ports (See below.)
Vent (
6)
AUDIO OUT port (
11
)
Ports
AUDIO IN port (
11
)
AUDIO IN L/R port (
12
)
USB port (11)
RGB IN1 port (
11
)
RGB IN2 port (
11
)
DVI-D port (
11
)
NOTE (*) About Restart switch: This Projector is controlled by an internal
microprocessor. Under certain exceptional circumstances, the projector may not
operate correctly and the microprocessor will need to be reset. In such a case,
please push the Restart switch by using a cocktail stick or similar, and before
turning on again, make the projector cool down at least 10 minutes without
operating. Only push the Restart switch in these exceptional instances.
Speaker
Restart switch (*) (52)
RGB OUT port (
11
)
WIRED REMOTE port
DC OUT port
LAN port (
12
)
5
STANDBY/ON
VIDEO
UP
DOWN
BLANK
ASPECT
PUSH
LASER
INDICATOR
LASER
RGB
ENTER
ON
OFF
ESC
POSITION
MAGNIFY
MUTE
KEYSTONE
FREEZE
ONE TOUCH
AUTO
PA
GE
MENU
RESET
VOLUME
STAND BY/O N
INP U
T
KEY STONE
RES E
T
MEN U
POW ER
TE MP
LA MP
Part names
RGB button (17)
PAGE buttons (
22)
LASER button (14)
Disk pad(22)
Right mouse button (22)
CURSOR buttons (23)
RESET button (
23)
MENU button (23)
AUTO butotn (
19)
VOLUME button (17)
MUTE button (17)
ONE TOUCH button (
18)
Control buttons
STANDBY/ON button (
16)
VIDEO button (17)
BLANK button (21)
ASPECT button (
18)
Lever switch (23)
ESC button (22)
POSITION button (19)
MAGNIFY buttons (
20)
FREEZE button (21)
KEYSTONE button (
20)
REMOTE CONTROL port
(15)
STANDBY/ON
button (16)
INPUT button (
17)
KEYSTONE button (
20)
RESET button (
23)
LAMP incicator (
50)
TEMP indicator (
50)
POWER indicator (16)
Remote control
Cursor buttons
▲,▼,◄,►(23)
Battery cover (14)
(on the back)
Laser switch (Inside of the battery cover)
1: enables the laser function
2: disables the laser function
Flip toward disk pad: UP key
F
lip toward MENU button: DOWN key
Press in center: ENTER
LASER INDICATOR (14)
6
Setting up
Setting up
WARNING ►Place the projector in a stable position horizontally. A fall or
a turnover could cause an injury and/or damage to the projector. Then using
damaged projector could result in a fire and/or an electric shock.
• Don’t place the projector on an unstable, slant or vibrant surface such as a
wobbly or inclined stand.
• Do not place the projector in the side/front/rear-up position, except care of the
air filter.
• For the projector installed bottom-up, use the accessory filter cover for bottom-
up use. And in the case of a ceiling installation or the like, contact your dealer
before installation.
►Place the projection in a cool place, and pay attention enough to ventilation.
The high temperature of the projector could cause a fire, a burn and/or
malfunction to the projector.
• Don’t stop up, block and cover the projector's vents.
• Keep a space of 30 cm or more between the sides and other objects such as
walls.
• Don’t place the projector on a metallic thing or anything weak in heat.
• Don’t place the projector on a carpet, cushion or bedding.
• Don’t place the projector in direct sunlight or near a hot object such as heater.
• Put nothing about lens and vents of the projector. Put nothing on the projector.
• Put nothing that is sucked or sticks to the bottom of projector. This projector
has some intake vents also on the bottom.
►Do not place the projector on the place that gets wet. Damping the projector
or inserting liquid in the projector could cause a fire, an electric shock and/or
malfunction to the projector.
• Don’t place the projector in a bathroom or the outdoors.
• Put nothing containing the liquid near the projector.
CAUTION ►Avoid a smoky, humid or dusty place. Placing the projector
in such place could cause a fire, an electric shock and/or malfunction to the
projector.
• Don’t place the projector near a humidifier, a smoking space or a kitchen.
• Put nothing containing the liquid near the projector.
►Adjist the direction of the projector to keep light from directly hitting the
projector's remote sensor.
7
(a) Screen size
[inch (m)]
(b) Projection distance [m (inch)] (c) Screen height [cm (inch)]
min. max. down up
30 (0.8) 0.9 (35) 1.1 (42)
5 (2) 41 (16)
40 (1.0) 1.2 (47) 1.4 (57) 6 (2) 55 (22)
50 (1.3) 1.5 (59) 1.8 (71) 8 (3) 69 (27)
60 (1.5) 1.8 (71) 2.2 (86) 9 (4) 82 (32)
70 (1.8) 2.1 (83) 2.6 (100) 11 (4) 96 (38)
80 (2.0) 2.4 (96) 2.9 (115) 12 (5) 110 (43)
90 (2.3) 2.7 (108) 3.3 (130) 14 (5) 123 (49)
100 (2.5) 3.0 (120) 3.7 (144) 15 (6) 137 (54)
120 (3.0) 3.7 (144) 4.4 (174) 18 (7) 165 (65)
150 (3.8) 4.6 (181) 5.5 (217) 23 (9) 206 (81)
200 (5.1) 6.1 (241) 7.4 (291) 30 (12) 274 (108)
250 (6.4) 7.7 (302) 9.2 (364) 38 (15) 343 (135)
300 (7.6) 9.2 (363) 11.1 (437) 46 (18) 411 (162)
(a) Screen size
[inch (m)]
(b) Projection distance [m (inch)] (c) Screen height [cm (inch)]
min. max. down up
30 (0.8) 1.0 (38) 1.2 (46)
-1 (0) 39 (15)
40 (1.0) 1.3 (51) 1.6 (62) -2 (-1) 51 (20)
50 (1.3) 1.6 (65) 2.0 (78) -2 (-1) 64 (25)
60 (1.5) 2.0 (78) 2.4 (94) -2 (-1) 77 (30)
70 (1.8) 2.3 (91) 2.8 (110) -3 (-1) 90 (35)
80 (2.0) 2.6 (104) 3.2 (126) -3 (-1) 103 (41)
90 (2.3) 3.0 (117) 3.6 (141) -4 (-1) 116 (46)
100 (2.5) 3.3 (131) 4.0 (157) -4 (-2) 129 (51)
120 (3.0) 4.0 (157) 4.8 (189) -5 (-2) 154 (61)
150 (3.8) 5.0 (197) 6.0 (237) -6 (-2) 193 (76)
200 (5.1) 6.7 (263) 8.0 (317) -8 (-3) 257 (101)
250 (6.4) 8.4 (329) 10.1 (396) -10 (-4) 322 (127)
300 (7.6) 10.0 (395) 12.1 (476) -12 (-5) 386 (152)
Arrangement
Refer to the illustrations and tables below to determine the screen size and projection
distance.
The values shown in the table are calculated for a full size screen: 1024 x 768
(a) The screen size (diagonal)
(b) Distance from the projector to the screen (±10%)
(c) The height of the screen (±10%)
Setting up
4:3
(a)
16:9
(a)
At 16:9 screen
At 4:3 screen
(c) up
(b)
(c) down
8
Adjusting the projector's elevator
WARNING ►Do not adjust the projector’s elevator during use or
immediately after use. Handling while the projector is in a high temperature
could cause a burn and/or malfunction to the projector.
CAUTION ►If you press the elevator button without holding the projector,
the projector might crash down, overturn, smash your fingers and possibly
result in malfunction. To prevent damaging the projector and injuring yourself,
always hold the projector whenever using the elevator buttons to adjust the
elevator feet.
►Except for inclining by the elevator feet adjustment, place the projector
horizontally.
You can use the elevator feet to make adjustments if the surface on which you
need to set the projector is uneven or if you otherwise need to adjust the angle of
projection. The adjustment range of the elevator feet is 0 to 9 degrees.
1.
After making sure that the projector is cool adequately, press and hold in the
elevator buttons while holding the projector.
The elevator buttons and the elevator feet are on the both sides.
2.
Raise or lower the projector to the desired height and the release the elevator
buttons.
When you release the elevator buttons, the elevator feet will lock into position.
3.
As necessary, you can also finely adjust the height of the projector by twisting
the elevator feet by hand.
Setting up
Elevator feet
Elevator button
9
Setting up
About the filter cover for bottom-up use
WARNING ►Do not replace the filter cover during use or immediately
after use. While the projector connects with a power supply, or the projector is
in a high temperature state, handling could cause an electric shock, a fire, a
burn and/or malfunction to the projector.Before handling, make sure the power
switch is off and the power cord is not plugged in, then wait at least 45 minutes.
When the projector is installed bottom up, please use the accessory filter cover
for bottom-up use. It is higher than usual filter cover, to keep the space for intake
ventilation. Please change in the following procedure.
1.
After making sure that the projector is cool adequately, slowly turn the
projector so that the lens-side is facing up. Please be careful for a projector
not to fall. While the projector is placed lens-side up, hold the projector.
2.
Unhooking the filter cover’s claws, pull the filter cover in the direction of the
arrow to remove it.
3.
Replace the filter cover for bottom-up use and snap it back into place.
4.
Slowly turn the projector so that the top is facing up.
Filter cover’s claws
To set
Filter cover’s claws
Filter cover
To remove
Filter cover for bottom-up use
10
Setting up
Connecting your devices
CAUTION ►Turn off all devices prior to connecting them to the projector.
Attempting to connect a live device to the projector may generate extremely
loud noises or other abnormalities that may result in malfunction and/or damage
to the device and/or projector.
►Use the accessory cable or a designated-type cable for the connection.
Some cables have to be used with core set. A too long cable may cause a
certain picture degradation. Please consult with your dealer for details. For
cables that have a core only at one end, connect the core to the projector.
►Make sure that you connect devices to the correct port. Incorrect connection
may result in malfunction and/or damage to the device and/or projector.
NOTE • Whenever attempting to connect a laptop computer to the projector, be sure
to activate the laptop’s RGB external image output (set the laptop to CRT display or to
simultaneous LCD and CRT display). For details on how this is done, please refer
to the
instruction manual of the corresponding laptop computer.
• Secure the screws on the connectors and tighten.
• Some computers may have multiple display screen modes. Use of some of these
modes will not be possible with this projector.
• For some RGB signal modes, the optional Mac adapter is necessary.
• When the image resolution is changed on a computer, depending on an input,
automatic adjust function may take some time and may not be completed. In this case,
you may not be able to see a check box to select “Yes/No” for the new resolution on
Windows. Then the resolution will go back to the original. It might be recommended to
use other CRT or LCD monitors to change the resolution.
About Plug-and-Play capability
Plug-and-Play is a system composed of the computer, its operating system and
peripheral equipment (i.e. display devices). This projector is compatible with VESA DDC
2B. Plug-and-Play can be achieved by connecting this projector to computers that are
VESA DDC (display data channel) compatible.
• Please take advantage of this function by connecting the accessory RGB cable to the
RGB IN1 port (DDC 2B compatible) and/or the optional DVI cable to the DVI-D port (DDC
2B compatible). Plug-and-Play may not work properly if any other type of connection is
attempted.
• Please use the standard drivers in your computer as this projector is a Plug-and-Play
monitor.
• The CP-X445's DVI is compatible with HDCP (High-bandwidth Digital Content
Protection) and therefore capable of displaying video from HDCP compatible DVD
players, et al. However, if the HDCP standards are modified, the CP-X445's DVI might
not be able to display video from HDCP compatible device developed in conformance to
such modified HDCP standards.
11
Y
VIDEO
RGB IN1 RGB IN2
DVI-
D
RGB OUT CONTROL
AUDIO-IN
REMOTE
CONTRO
L
US
B
DC OU
T
S-VIDEO
LA
N
COMPONENT VIDE
O
CB/P
B
CR/P
R
R-AUDIO IN-L
AUDIO-OU
T
Y
VIDEO
RGB IN1 RGB IN2
DVI-
D
RGB OUT CONTROL
AUDIO-IN
REMOTE
CONTRO
L
US
B
DC OU
T
S-VIDEO
LA
N
COMPONENT VIDE
O
CB/P
B
CR/P
R
R-AUDIO IN-L
AUDIO-OU
T
Y
VIDEO
RGB IN1 RGB IN2
DVI-
D
RGB OUT CONTROL
AUDIO-IN
REMOTE
CONTRO
L
USB
DC OUT
S-VIDE
O
LAN
COMPONENT VIDEO
CB/P
B
CR/P
R
R-AUDIO IN-L
AUDIO-OU
T
Y
VIDEO
RGB IN1 RGB IN2
DVI-
D
RGB OUT CONTROL
AUDIO-IN
REMOTE
CONTRO
L
US
B
DC OU
T
S-VIDEO
LAN
COMPONENT VIDE
O
CB/P
B
CR/P
R
R-AUDIO IN-L
AUDIO-OU
T
RGB IN2
RGB OUT
Setting up
Examples of connection with a computer
Audio out
USB(A)
RS-232C
DVI out
DVI cable
Stereo mini audio cable
* AUDIO IN is linked to RGB IN1/2
and
DVI-D.
RGB out Audio out
Stereo mini audio cable
RGB cable
RGB in
RGB cable
Audio in
Stereo mini audio cable
USB cable
RS-232C cable
Connecting to a monitor (output)
Connecting to a speaker with amplifier (output)
12
Y
VIDEO
RGB IN1 RGB IN2
DVI-D
RGB OUT CONTROL
AUDIO-IN
REMOTE
CONTRO
L
US
B
DC OU
T
S-VIDE
O
LAN
COMPONENT VIDE
O
CB/P
B
CR/P
R
R-AUDIO IN-L
AUDIO-OU
T
Y
VIDEO
RGB IN1 RGB IN2
DVI-D
RGB OUT CONTROL
AUDIO-IN
REMOTE
CONTRO
L
USB
DC OU
T
S-VIDE
O
LAN
COMPONENT VIDE
O
CB/P
B
CR/P
R
R-AUDIO IN-L
AUDIO-OU
T
Y
VIDEO
RGB IN1 RGB IN2
DVI-
D
RGB OUT CONTRO
L
AUDIO-IN
REMOTE
CONTRO
L
US
B
DC OU
T
S-VIDE
O
LAN
COMPONENT VIDE
O
CB/P
B
CR/P
R
R-AUDIO IN-L
AUDIO-OU
T
Y
VIDEO
RGB IN1 RGB IN2
DVI-
D
RGB OUT CONTRO
L
AUDIO-IN
REMOTE
CONTRO
L
US
B
DC OU
T
S-VIDE
O
LAN
COMPONENT VIDE
O
CB/P
B
CR/P
R
R-AUDIO IN-L
AUDIO-OU
T
Setting up
Examples of connection with a VCR/DVD player
Audio (L) out
Video out
Audio cable
Audio/Video cable
Audio (L) out
S-Video out
S-Video cable
RGB out
Audio (L) out
Component video out
RGB cable
Component video out
Component video cable
Y
CB/P
B
CR/P
R
Audio cable
Audio (R) out
Audio (R) out
LAN cable (CAT-5)
LAN port
Y
CB/P
B
CR/P
R
Audio (R) out
Component video cable
13
Setting up
Connecting power supply
WARNING ►Please use extra caution when connecting the power cord as
incorrect or faulty connections may result in fire and/or electrical shock.
• Only use the power cord that came with the projector. If it is damaged, contact
your dealer to newly get correct one.
• Only plug the power cord into an outlet rated for use with the power cord's
specified voltage range.
• Never modify the power cord. Never attempt to defeat the ground connection
of the three-pronged plug.
1.
Connect the connector of the power cord to the AC inlet of the projector.
2.
Firmly plug the power cord's plug into the outlet.
AC inlet
Connector
of the power cord
14
Putting batteries
WARNING ►Always handle the batteries with care and use them only as
directed. Improper use may result in battery explosion, cracking or leakage,
which could result in fire, injury and/or pollution of the surrounding environment.
• Be sure to use only the batteries specified. Do not use batteries of different
types at the same time. Do not mix a new battery with used one.
•
Make sure the plus and minus terminals are correctly aligned when loading a battery.
• Keep a battery away from children and pets.
• Do not recharge, short circuit, solder or disassemble a battery.
•
Do not allow a battery in a fire or water. Keep batteries in a dark, cool and dry place.
•
If you observe a leakage of a battery, wipe out the flower and then replace a battery.
If the flower adheres your body or clothes, rinse well with water immediately.
1.
Remove the battery cover.
Slide back and remove the battery cover in the direction of the arrow.
2.
I
nsert the batteries.
Align and insert the two AA batteries according to their plus and minus
terminals as indicated in the remote control.
3.
Close the battery cover.
Replace the battery cover in the direction of the arrow and snap it back into place.
Remote control
Laser pointer
This remote control has a laser pointer in place of a finger or rod. The laser beam works
and theLASER INDICATOR lights while the LASER button is pressed.
WARNING ►The laser pointer of the remote control is used in place of a
finger or rod. Never look directly into the laser beam outlet or point the laser
beam at other people. The laser beam can cause vision problems.
CAUTION ►Use of controls or adjustments or performance of procedures
other than those specified herein may result in hazardous radiation exposure.
Remote control
STANDBY/ON
V
ID
E
O
U
P
DO
W
N
B
L
A
N
K
ASPEC
T
PU
SH
L
A
S
E
R
IN
D
ICAT
O
R
L
A
S
E
R
R
G
B
E
N
T
E
R
O
N
O
F
F
E
SC
POSITION
M
A
G
N
IF
Y
MU
T
E
KEYST
ONE
FREEZ
E
ONE TOUCH
A
UT
O
PA
G
E
M
E
N
U
R
E
S
E
T
V
O
L
UM
E
15
Remote control
Using the remote control
CAUTION ►Be careful in handling the remote control.
• Do not drop or otherwise expose the remote control to physical impact.
• Do not get the remote control wet or place it on wet objects. Doing so may
result in malfunction.
• Remove the batteries from the remote control and store them in a safe place if
you won’t be using the remote control for an extended period.
• Replace the batteries whenever the remote control starts to malfunction.
• When strong lights, such as direct sunlight or light from an extremely close
range (such as from an inverter fluorescent lamp), hit the projector’s remote
sensor, the remote control may cause to function. Adjust the direction of the
projector to keep light from directly hitting the projector’s remote sensor.
The remote control works with the projector’s remote sensor.
• The range of the remote sensor is 3 meters with a 60- degree range (30 degrees
to the left and right of the remote sensor).
• Also a remote signal reflected in the screen etc. may be available. If it is difficult
to send a remote signal to the sensor directly, please try.
• Since the remote control uses infrared light to send signals to the projector
(Class1 LED), be sure to use the remote control in an area free from obstacles
that could block the remote control’s output signal to the projector.
• You can use the remote control as a wired remote control, by connecting the
REMOTE CONTROLports of the main unit and remote control via an audio cable
(3.5 dia. stereo mini cable with plugs).
30º
30º
approx. 3 meters
16
STANDBY/ON
VIDEO
UP
DOWN
BLANK
ASPECT
PUSH
LASER
INDICATOR
LASER
RGB
ENTER
ON
OFF
ESC
POSITION
MAGNIFY
MUTE
KEYSTONE
FREEZE
ONE TOUCH
AUTO
PA
GE
MENU
RESET
VOLUME
STANDBY /ON
INPU
T
KEYSTO NE
RESE
T
MENU
POWER
TEMP
LAMP
Power on/off
Power on/off
WARNING ►When the power is on, a strong light is emitted. Do not look
into the lens or vents of the projector.
NOTE • Turn the power on/off in right order. Please power on the projector
before the connected devices. Power off the projector after the connected devices.
Power switch
STANDBY/ON
button
POWER
indicator
Turning on the power
1.
Make sure that the power cord is firmly and correctly
connected to the projector and outlet.
2.
Remove the lens cap, and set the power switch to the
ON position.
The power indicator will light to solid orange. Then wait
several seconds because buttons may not function for
these several seconds.
3.
Press the STANDBY/ON button on the projector or remote control.
The projector lamp will light up and the POWER indicator will begin blinking
green. When the power is completely on, the indicator will stop blinking light
green.
To display the picture, select an input signal according to the section "Selecting an
input signal"
(17)
.
Turning off the power
1.
Press the STANDBY/ON button on the projector or
remote control.
The message "Power off?" will appear on the screen for
approximately 5 seconds.
2.
Press the STANDBY/ON button on the projector or
remote control again while the message is visible.
The projector lamp will go off, and the POWER indicator
will begin blinking orange.
Then the POWER indicator will stop blinking and light to
solid orange when the lamp cooling is complete.
3.
Make sure that the power indicator lights to solid orange, set the power switch
to the OFF position. The POWER indicator will go off. Attach the lens cap.
Power off?
POWER
(Solid orange)
POWER
(Blinking green)
POWER
(Solid green)
POWER
(Blinking orange)
POWER
(Solid orange)
17
Operating
Operating
Adjusting the volume
1.
Press the VOLUME button on the remote control.
A dialog will appear on the screen to aid you in adjusting
the volume.
2.
Use the cursor buttons ▲/▼ to adjust the volume.
To close the dialog and complete the operation, press the VOLUME button
again. Even if you don’t do anything, the dialog will automatically disappear
after a few seconds.
Temporarily muting the sound
1.
Press the MUTE button on the remote control.
A dialog will appear on the screen indicating that you have
muted the sound.
To restore the sound, press the MUTE or VOLUME button.
Even if you don’t do anything, the dialog will automatically disappear after a few
seconds.
Selecting an input signal
1.
Press the INPUT button on the projector.
Each time you press the button, the projector switches its input
port as below.
RGB IN1 RGB IN2 DVI-D
VIDEO S-VIDEO COMPONENT VIDEO
1.
Press the RGB button on the remote control to select an
input port for RGB signal.
Each time you press the button, the projector switches its
RGB input port as below.
RGB IN1 RGB IN2 DVI-D
● When the TURN ON is selected to the item AUTO SEARCH of OPTION menu
(38)
, the projector checks the current selected port at first. If no input is
detected at the port, projector will check other ports in above order.
1.
Press the VIDEO button on the remote control to select an
input for video signal.
Each time you press the button, the projector switches its
video input port as below.
COMPONENT VIDEO
S-VIDEO VIDEO
● When the TURN ON is selected to the item AUTO SEARCH of OPTION menu
(38)
, the projector checks the current selected video port at first. If no input is
detected at the port, projector will begin to check other ports in above order.
STANDBY/ON
VIDEO
UP
DOWN
BLANK
ASPECT
PUSH
LASER
INDICATOR
LASER
RGB
ENTER
ON
OFF
ESC
POSITION
MAGNIFY
MUTE
KEYSTONE
FREEZE
ONE TOUCH
AUTO
PA
GE
MENU
RESET
VOLUME
STANDBY/ON
VIDEO
UP
DOWN
BLANK
ASPECT
PUSH
LASER
INDICATOR
LASER
RGB
ENTER
ON
OFF
ESC
POSITION
MAGNIFY
MUTE
KEYSTONE
FREEZE
ONE TOUCH
AUTO
PA
GE
MENU
RESET
VOLUME
STANDBY/ON
VIDEO
UP
LASER
INDICATOR
RGB
STANDBY/ON
VIDEO
UP
LASER
INDICATOR
RGB
INPU
T
KEYSTO NE
RESE
T
MENU
POWER
TEMP
LAMP
Loading...
