Chapter 1: Introduction
This manual describes the IBM® Tivoli® Netcool®/Proviso® Cisco IP Telephony Technology Pack. Specifically, the manual describes the reports that display information about the devices and technologies that operate in the Cisco IP Telephony environment.
Note: This technology pack supports the Cisco CallManager (CCM) environment and its new implementation,
the Cisco Unified Communications Manager (CUCM) environment. Where this guide refers to CCM, the text also applies to CUCM, unless an explicit distinction is made.
Audience
The audiences for this manual are the network administration engineers at IBM customer sites who will install, configure, and use the Cisco IP Telephony Technology Pack as part of their Tivoli Netcool/Proviso installation. IBM Professional Services engineers may also find this manual useful.
To install and use the Cisco IP Telephony Technology Pack, you should have a working knowledge of the following subjects:
Tivoli Netcool/Proviso DataMart
TCP/IP networks
Telecommunications network management
Administration of the operating system
The audiences should also be familiar with the specific technology that the Cisco IP Telephony Technology Pack deals with, in this case Cisco IP Telephony.
Organization
This guide is organized as follows:
Chapter 1, Introduction
Provides a general introduction to the Tivoli Netcool/Proviso product suite.
Chapter 2, Devices and Services
Provides an overview of the device technology supported by the technology pack.
Chapter 3, Supported Reports and KPIs
Provides information about the reporter sets and key performance indicators (KPIs) that the Cisco IP Telephony Technology Pack provides for each device operating in the Cisco IP Telephony environment.
Chapter 4, Configuring the technology pack
Describes how to configure the Cisco IP Telephony Technology Pack.
Appendix A, UBA parameters (Tivoli Netcool/Proviso v4.4.3 and later)
Provides UNIX® reference pages for each of the pack-specific UBA parameters supplied with the XSD file for the Cisco IP Telephony Technology Pack.
IBM Tivoli Netcool/Proviso Cisco IP Telephony 2.4.0.0 Technology Pack 1
Chapter 1: Introduction
Appendix B, Template file (Tivoli Netcool/Proviso pre-v4.4.3 only)
Explains the edits that must be made to the pack-specific UBA parameters delivered in the pack template file.
The Tivoli Netcool/Proviso product suite
Tivoli Netcool/Proviso is made up of the following components:
Tivoli Netcool/Proviso DataMart is a set of management, configuration and troubleshooting GUIs that the Tivoli Netcool/Proviso system administrator uses to define policies and configuration, as well as to verify and troubleshoot operations.
Tivoli Netcool/Proviso DataLoad provides flexible, distributed data collection and data import of SNMP and non-SNMP data to a centralized database.
Tivoli Netcool/Proviso DataChannel aggregates the data collected through Tivoli Netcool/Proviso DataLoad for use by the Tivoli Netcool/Proviso DataView reporting functions. It also processes on-line calculations and detects real-time threshold violations.
Tivoli Netcool/Proviso DataView is a reliable application server for on-demand, web-based network reports.
Tivoli Netcool/Proviso Technology Packs extend the Tivoli Netcool/Proviso system with service-ready reports for network operations, business development, and customer viewing.
Figure 1 shows the different Tivoli Netcool/Proviso modules.
Figure 1: Tivoli Netcool/Proviso modules
DataLoad collects network data.
DataChannel computes aggregations and stores data in DataMart.
DataMart provides data management and applications.
DataView produces and manages reports.
Tivoli Netcool/Proviso documentation
IBM provides the following Tivoli Netcool/Proviso documentation:
Release notes
Configuration recommendations
•User guides
References
Technical notes
Online help
2 IBM Tivoli Netcool/Proviso Cisco IP Telephony 2.4.0.0 Technology Pack
Chapter 2: Devices and Services
This chapter discusses the following topics:
Topic Pa g e
Overview 3
Summary of Device Technology 3
Sources of Collected Data 5
Prerequisites 8
Supported MIBs 9
Overview
This chapter provides a summary of Cisco IP Telephony device technology that the Cisco IP Telephony Technology Pack is designed to support.
Note: This technology pack supports the Cisco CallManager (CCM) environment and its new implementation,
the Cisco Unified Communications Manager (CUCM) environment. Where this guide refers to CCM, the text also applies to CUCM, unless an explicit distinction is made.
Summary of Device Technology
The Tivoli Netcool/Proviso Cisco IP Telephony Technology Pack collects and reports performance metrics in an Architecture for Voice, Video and Integrated Data (AVVID) environment where Cisco CallManager (CCM) IP-PBXs are deployed.
The technology pack manages the IP telephony application by focusing on an end-to-end voice path. It uses advanced data consolidation, with data coming from the end user (the phone extension itself), as well as data coming from network infrastructure devices.
The Cisco IP Telephony Technology Pack operates with the following Cisco versions:
Cisco CallManager version 4
Cisco Unified Communications Manager version 5
Cisco Unified Communications Manager version 6
Cisco Unified Communications Manager version 7
IBM Tivoli Netcool/Proviso Cisco IP Telephony 2.4.0.0 Technology Pack 3
Chapter 2: Devices and Services
Categories of Service Reporting
The technology pack provides the following categories of service reporting:
•Voice Quality Management — Latency, jitter, packet loss, network bandwidth, Class-Based QoS, and element availability.
Call Signaling Management — Call setup and termination metrics, based on data from Call Detail Records (CDRs).
Converged Network Infrastructure Management — Network and system devices in charge of the Service and Voice Data Packets Delivery.
Services and Devices Monitored
The Tivoli Netcool/Proviso Cisco IP Telephony Technology Pack creates automatic, on-demand, historical, and real-time reports showing performance and trend analysis for the following services and devices:
Voice Quality — Jitter, latency, packet drops, mean opinion score, per cluster, per location, per business department, and even for each extension number.
CallManager System & Application — Server availability, performance, CPU load, memory, service availability, disk usage, and registered devices.
PSTN Gateway Devices — Catalyst6500, Cisco AS5x00 series, Cisco 2600 & 3600 series, E1 & T1 Serial Links, DS0 Channel availability and utilization, DSP availability and utilization, capacity planning, bandwidth, errors. Also, total number of calls per gateway, total duration per gateway.
Gatekeeper Devices — Number of successful / unsuccessful requests (routing, location, admission), registered endpoints, errors.
Telephony Usage — Total number of calls, total duration of calls, total number of packets, per location, per business department, per extension number, top10 clusters (or sites, offices, extensions, departments). Number of outbound and inbound calls. Total accumulated hours of traffic per hour, day, week, month.
Call Completion — Percentage of outgoing and incoming successful/unsuccessful calls, what are the main errors (phones, LAN, WAN, PSTN network, congestions, no resource available).
Call Distribution — On-net vs. off-net ratio (number of IP routed calls vs. calls routed toward PSTN), number of internal (private extension to private extension) calls, local calls, long distance calls, international calls. Capability to provide statistics on number of calls to mobile networks (supported in some countries only).
Site to Site Path Analysis — End-to-end measurement between customer offices. Voice quality, call distribution, call completion, IP telephony usage, TopN sites for errors, number of calls, duration and voice quality.
4 IBM Tivoli Netcool/Proviso Cisco IP Telephony 2.4.0.0 Technology Pack
Chapter 2: Devices and Services
Sources of Collected Data
The Tivoli Netcool/Proviso Cisco IP Telephony Technology Pack uses both SNMP and bulk data collection. The technology pack collects performance data from the following sources:
Source of Collected Data Collection Type
PSTN gateway, media gateway SNMP
Gatekeeper SNMP
Cisco CallManager Server Each server in the cluster has an SNMP agent
Call Detail Records (CDR) Accounting data
Call Maintenance Records (CMR) Voice quality data
Microsoft® performance counter metrics (Perfmon) Bulk
SNMP
Bulk
Bulk
CDR and CMR data is collected in Cisco CallManager (CCM) environments and Cisco Unified Communications Manager (CUCM) environments. The technology pack accesses CDR and CMR data differently in each environment.
The following sections provide an overview of how the technology pack accesses CDR and CMR data in these different environments. A basic understanding of the different access methods will help you when you configure the technology pack.
Note: Perfmon is not supported for Cisco CallManager version 4.x.
Collecting CDR and CMR Data with Cisco CallManager
With Cisco CallManager (CCM), the technology pack collects CDR and CMR data through SQL requests to the CallManager Publisher SQL database.
IBM Tivoli Netcool/Proviso Cisco IP Telephony 2.4.0.0 Technology Pack 5
Chapter 2: Devices and Services
The following figure illustrates the technology pack’s data collection architecture in a CCM environment:
Port for SQL Access
CallManager Publisher runs on a Microsoft SQL Server 2000 server. To collect SQL data from the CallManager Publisher, an SQL bridge must be set up on the machine where Tivoli Netcool/Proviso DataLoad resides. This bridge is provided as part of the Tivoli Netcool/Proviso Cisco IP Telephony Technology Pack.
The connection between the Data Direct SQL server bridge and the SQL Server 2000 server is made through TCP port number 1433 or 1370, according to the Cisco CallManager Publisher configuration.
Troubleshooting Note for SQL Requests
If you have problems issuing SQL queries to the Cisco CallManager (CCM) Publisher, check the following list:
•Ensure that tempdb has been set to an adequate size (at least 100Mb) in order to correctly receive the SQL result set, as recommended in the Cisco CallManager Installation Guide.
Check the log file (proviso.log by default) for any SQL error messages. By default, the log file is in the
$DC_HOME/log directory — for example, /opt/datachannel/log.
6 IBM Tivoli Netcool/Proviso Cisco IP Telephony 2.4.0.0 Technology Pack
Chapter 2: Devices and Services
With pre-4.4.3 Tivoli Netcool/Proviso versions, ensure that the dc.cfg file contains a URI for each CCM Publisher bulk adaptor, and that the URI matches the URI of the associated data source in the file.
odbc.ini
Collecting CDR, CMR, and Perfmon Data with Cisco Unified Communications Manager
With Cisco Unified Communications Manager (CUCM), the technology pack collects CDR, CMR, and Perfmon data files in either of the following ways:
Through SOAP requests to the CUCM server and PerfmonPorts API.
Through a schedule for pushing the data files back to the DataChannel server. The schedule is specified by CUCM Web administration configuration settings.
In both cases, the CUCM pushes the data back to the technology pack via FTP.
The technology pack includes a Java™ application called ProvisoCUCM. This application is responsible for sending the SOAP requests to the CUCM, and for producing the CSV files for the UBA from the data files pushed back to the DataChannel server by the CUCM server.
The ProvisoCUCM finds the address of the CUCM server, authentication information, and other configuration details in the file described in Chapter 4, Configuring the technology pack.
The following figure illustrates the technology pack’s data collection architecture in a CUCM environment:
cucm.properties. You install and edit this file when you configure the technology pack, as
IBM Tivoli Netcool/Proviso Cisco IP Telephony 2.4.0.0 Technology Pack 7
Chapter 2: Devices and Services
Prerequisites
This section describes the prerequisites for the Tivoli Netcool/Proviso Cisco IP Telephony Technology Pack.
SNMP Access
The Tivoli Netcool/Proviso Cisco IP Telephony Technology Pack needs read access to SNMP agents of PSTN gateway, gatekeeper, and CallManager Server devices. Customers must provide a valid IP address and community name to access these devices.
UDP Port number 161 needs to be open in the remote firewalls.
CallManager servers, as well as Unity servers and other Cisco media servers running under the Microsoft SQL Server 2000 environment, can be configured with the following standard SNMP Extensions:
•HOST-MIB
PERFMON-MIB (optional – perfmon counters)
SQL-MIB (optional – SQL Server and Database metrics)
EXCHANGE-MIB (optional – MS Exchange metrics)
DHCP-MIB (optional – Dhcp server metrics)
HTTP-MIB (optional – Http server metrics)
Cisco CallManager Configuration
To enable CDR and CMR collection from CCM and CUCM environments, some configuration parameters must be set using the CCM System Administrator. Configuration settings must be defined separately on every server in a cluster.
The following configuration service parameters control the generation of CDR records:
cdrEnabled Determines whether CDR records are generated. Default value: false.
CdrLogCallsWithZeroDurationFlag — Enables logging of CDR records for calls that were never
connected, or which lasted less than one second. This parameter must be enabled to allow data to be collected on short connections.
CallDiagnosticsEnabled — Determines whether CMR records are generated. Only IP phones and MGCP
gateways support CMR records. Default value:
MaxCdrRecords — Controls the maximum number of CDRs on the system. When this limit is exceeded,
the oldest CDRs are automatically removed once a day, along with the related CMR records. Default value:
1.5 million records.
The Tivoli Netcool/Proviso Cisco IP Telephony Technology Pack never deletes records. IBM recommends retrieving CDRs every hour or every four hours. This polling interval permits the system administrator to decrease the maximum number of CDRs on the CallManager and to improve performance.
false.
8 IBM Tivoli Netcool/Proviso Cisco IP Telephony 2.4.0.0 Technology Pack
Chapter 2: Devices and Services
In addition, the following enterprise parameters must be set:
LocalCDRPath — A directory for local CDR files written by Cisco CallManager. If this value is empty or invalid, the CDR files will not be moved.
PrimaryCDRUNCPath — A central collection point for CDR files. If this value is empty or invalid, the CDR files will not be moved. The installation procedure sets this parameter.
CDRFormat — A parameter that determines whether the files are written to the database. The value specifies either
For performance reasons, the Tivoli Netcool/Proviso Cisco IP Telephony Technology Pack collects CDRs using SQL requests, not flat files. Tivoli Netcool/Proviso does not support
PrimaryCDRDSN — An optional parameter that references the primary CDR server on which to insert CDRs. The referenced system does not need Cisco CallManager installed, but does need SQL server and a CDR database.
This parameter allows movement of the CDRs off of the Cisco CallManager cluster. If this parameter is missing, CDRs are written locally to the
CDRFlatFileInterval — A parameter that determines the amount of time, in minutes, that a CDR file can be written to before Cisco CallManager closes the CDR file and opens a new one.
FLAT or DB. Default value: DB.
FLAT for CDR collection.
PrimaryCDRUNCPath.
Supported MIBs
This technology pack uses the following MIB files:
cisco-10-mib
CISCO-CCM-MIB.my
CISCO-CDP-MIB.my
•CISCO-DSP-MGMT-MIB.my
•CISCO-GATEKEEPER-MIB.my
CISCO-POP-MGMT-MIB.my
•MSSQL-MIB.my
rfc1213-MIB-II
rfc1514-HOSTRESOURCES
rfc1907-SNMPv2-MIB
rfc2127-ISDN-MIB
rfc2233-IF-MIB
Bulk input file formats
The Cisco IP Telephony devices gather performance data and other statistics from multiple network elements. This data is referred to collectively as network health metrics. Each Cisco IP Telephony device produces, on an hourly basis, a bulk input file that contains the network health metrics and other information.
The Cisco IP Telephony Technology Pack supports multiple input files, where each input file contains data for one polling period only.
The syntax for these bulk input files is discussed in Bulk input file name on page 10.
IBM Tivoli Netcool/Proviso Cisco IP Telephony 2.4.0.0 Technology Pack 9
Chapter 2: Devices and Services
The Cisco IP Telephony Technology Pack provides a file that interprets these bulk input files. See Bulk adaptor design files on page 11 for more information.
Bulk input file name
Cisco IP Telephony devices produce Comma-Separated Values (CSV) files that are named using the following syntax:
DataType_ClusterName_Date_SerialNumber.csv
where:
DataType specifies the type of data collected: cdr, cmr, cdrcmr, or perfmon.
ClusterName specifies the name of the cluster from which the data was collected.
Date specifies the date on which the data was collected. The date format is as follows:
yyyyMMddHHmm
where:
yyyy specifies a four-digit integer (for example, 2010) that identifies the year in which the Cisco IP
Telephony produced the CSV file.
MM specifies a two-digit integer (for example, 05) that identifies the month in which the Cisco IP
Telephony produced the CSV file.
dd specifies a two-digit integer (for example, 15) that identifies the day in which the Cisco IP Telephony
produced the CSV file.
HH specifies a two-digit integer (for example, 08) that identifies the metric hour in which the Cisco IP
Telephony produced the CSV file.
mm specifies a two-digit integer (for example, 35) that identifies the minutes after the metric hour in which
the Cisco IP Telephony produced the CSV file.
SerialNumber specifies the serial number of the file, in case there are multiple files for a single period.
Example:
cdrcmr_cluster_01_201005150835_10001.csv
Bulk input file schema
For Cisco CallManager version 4.x, CDR data is stored in a Microsoft SQL Server 2000 database. The Cisco IP Telephony Technology Pack connects directly to the database and uses an SQL query to retrieve the data. Perfmon is not supported for Cisco CallManager version 4.x.
For Cisco Unified Communications Manager versions 5.x and higher, the ProvisoCUCM Java application uses the AXL/SOAP API delivered by the device to collect both CDR and Perfmon data. For CDR, a SOAP query to the CUCM server requests all CDR data for a certain time period. The CUCM server uses FTP to send the data back to a specified host. The data is delivered in two formats, CDR and CMR, which are concatenated to produce a CSV format for the UBA. Perfmon data is delivered in-band as a response to the SOAP request, and is also written into a CSV format for the UBA.
Example CDR CSV file:
1,1,6177065,5362499,1273883641,1,0,760260612,"6076","termine",0,1,4,0,0,57,0,0,0 ,0,0,0,0,"0","0",19835742,0,0,0,"6096","6096","",0,0,4,0,0,0,0,0,0,0,0,0,0,"0"," 0",0,1273883673,"6001","593fa05e-bc1d-4dc5-9cca­6c25184e7e98","","Phones","","",69,"SEP00155832DDD1","",13,0,0,0,0,0,0,"StandAlo
10 IBM Tivoli Netcool/Proviso Cisco IP Telephony 2.4.0.0 Technology Pack
Chapter 2: Devices and Services
neCluster",0,"","",0,"",3,0,0,1,"6076",5362499,1273883641,541,2954,487,2849,6,96 ,144,"03d4df7b-78ff-460e-a0bb­43ccee36cc5f","Phones","StandAloneCluster","SEP00155832DDD5","MLQK=3.2000;MLQKav =3.3000;MLQKmn=1.4000;MLQKmx=3.9000;ICR=0.8200;CCR=0.7600;ICRmx=0.9800;CS=9;SCS= 2;MLQKvr=;z="
1,1,8590499,10263919,1273883642,1,0,760260611,"6058","termine",0,1,4,0,0,51,0,0, 0,0,0,0,0,"0","0",19835742,0,0,0,"6017","6017","",0,0,4,0,0,0,0,0,0,0,0,0,0,"0", "0",0,1273883642,"6001","593fa05e-bc1d-4dc5-9cca­6c25184e7e98","","Phones","","",197,"SEP00155832DDD6","",13,0,0,0,0,0,0,"StandAl oneCluster",0,"","",0,"",3,0,0,1,"6058",10263919,1273883642,128,313,1784,1107,11 ,176,62,"03d4df7b-78ff-460e-a0bb­43ccee36cc5f","Phones","StandAloneCluster","SEP00155832DDD5","MLQK=3.2000;MLQKav =3.3000;MLQKmn=1.4000;MLQKmx=3.9000;ICR=0.8200;CCR=0.7600;ICRmx=0.9800;CS=9;SCS= 2;MLQKvr=;z="
This example contains both the CDR and CMR data, with the CMR data concatenated to the end of the CDR line. This example is taken from the output file after the Cisco IP Telephony Technology Pack has processed the two inputs and created the CSV file for the UBA.
Bulk adaptor design files
Tivoli Netcool/Proviso supports several data formats for bulk input files, including CSV, XML, and binary. Each UBA technology pack provides a Bulk Adaptor Design File to define the data format supported by that technology pack. The Bulk Adaptor Design File, which is a JavaScript file, processes both inventory and statistics data from the same bulk input file. The Bulk Adaptor Design File provides a function that creates the bulk collection formula names. Some technology packs provide several Bulk Adaptor Design Files, each of which handles a specific bulk input file format.
The Cisco IP Telephony Technology Pack provides the following Bulk Adaptor Design Files:
CCMAdaptor.js
CCMConfig.js
CCMSupport.js
CUCMAdaptor.js
CUCMConfig.js
CUCMPerfmonAdaptor.js
CUCMSupport.js
IBM Tivoli Netcool/Proviso Cisco IP Telephony 2.4.0.0 Technology Pack 11
Chapter 2: Devices and Services
NOTES
12 IBM Tivoli Netcool/Proviso Cisco IP Telephony 2.4.0.0 Technology Pack
Chapter 3: Supported Reports and KPIs
This chapter discusses the following topics:
Topic Pa g e
Overview 13
Reporter sets 13
Reporter set tree 15
Reporter set contents 16
Key performance indicators 33
Overview
The Cisco IP Telephony Technology Pack supplies a set of reports to display information about the devices and activity associated with the Cisco IP Telephony environment.
The reports contain metrics that are generated by the formulas that this technology pack provides. The metric names are the same as the names of the formulas that generate them. For information about a metric that is listed for a particular report, see the description of the associated formula in the Collection Formulas section of the IBM Tivoli Netcool/Proviso Cisco IP Telephony 2.4.0.0 Technology Pack Reference.
For information about how to navigate to a particular report on the DataView portal, see the NOC Reporting tree in the Subelement Groups section of the IBM Tivoli Netcool/Proviso Cisco IP Telephony 2.4.0.0 Technology Pack Reference. This chapter provides information about deployed reports only.
For information about understanding report types, creating reports, configuring reports, viewing and working with reports, and deploying reports, see the Netcool/Proviso DataView User’s Guide. This Technology Pack User Guide assumes an understanding of the report-related topics discussed in the Netcool/Proviso DataView User’s Guide.
Reporter sets
A reporter set contains a group of reporters that together provide information about a specific technology or vendor device. Technology pack developers use the Reporter Set Wizard to choose the type of template on which to base the reporter set. Technology packs use reporter sets as the framework for defining reports.
The Cisco IP Telephony Technology Pack reports display, on a Web portal, the collected information about the devices and technologies that operate in the Cisco IP Telephony environment.
IBM Tivoli Netcool/Proviso Cisco IP Telephony 2.4.0.0 Technology Pack 13
Chapter 3: Supported Reports and KPIs
Table 1 shows a summary of the reports in each reporter set provided by the Cisco IP Telephony Technology Pack.
Table 1: Reporter set summary
Reporter set Dashboard Group Resource Detail Threshold
CallManager Server 0 1 2 0 0
Cluster 1 4 5 0 0
Codec 0 0 1 0 0
DSP Card 0 0 1 0 0
Device 0 0 2 0 0
Device 2 0 2 0 0
Extension 0 3 4 0 0
Global Customer Reports 0 0 1 0 0
Interface 0 0 2 0 0
Interface 2 0 2 0 0
K-Factor 0 1 1 0 0
Media Devices 0 1 1 0 0
Perfmon 0 4 4 0 0
TOTALS 5 14 28 0 0
See the Netcool/Proviso DataView User’s Guide for more information about reporter sets and the Reporter Set Wizard.
14 IBM Tivoli Netcool/Proviso Cisco IP Telephony 2.4.0.0 Technology Pack
Chapter 3: Supported Reports and KPIs
Reporter set tree
The Cisco IP Telephony Technology Pack provides the following reporter sets, which are listed as they appear in the DataView Navigator tree structure:
AP Cisco VOIP Pack
Global Customer Reports Call Detail Record
Cluster Extension K-Factor Codec
Infrastructure
CallManager Server PSTN Gateway
Interface Device
DSP Card Media Devices Gatekeeper
Device
Interface Perfmon
IBM Tivoli Netcool/Proviso Cisco IP Telephony 2.4.0.0 Technology Pack 15
Chapter 3: Supported Reports and KPIs
Reporter set contents
This section describes the contents of the reporter sets provided in the Cisco IP Telephony Technology Pack, including the key performance indicators (KPIs) for each report.
Note: If any fields are omitted from the CDR or CMR data, the corresponding metric fields in the reports have
dashes instead of zeroes.
Global Customer Reports
Global VOIP
KPIs
• ClusterOffNetCall
• PSTN Gateway Active DS0 Channels (Nb)
• Cluster Total Number of Normal Call Clearing
• ClusterJitter
• CCM CPU Utilization (percent) (avg last 5 mn)
• ClusterDropCall
• ClusterOnNetCall
• Cluster Percentage of Packet Lost (percent)
• ClusterSuccessfulCall
• PSTN Gateway Network Errors (percent)
• ClusterUnsuccessfulCall
• Interface Bandwidth Utilization Out (percent)
• PSTN Gateway Active DS0 Channels (Nb) (Gauge)
Charts
Call Detail Record
Cluster
Cluster Utilization Resource
KPIs
• Cluster Total Number of Outgoing External Calls (Nb)
• ClusterTollBypassCall
• Cluster Total Number of External Calls (Nb)
• Cluster Total Number of Company Calls (Nb)
• Cluster Erlang
• ClusterNbPacketsReceived
16 IBM Tivoli Netcool/Proviso Cisco IP Telephony 2.4.0.0 Technology Pack
• Cluster Total Hours of Traffic
• ClusterNbPacketsSent
• ClusterTotalCall
Charts
• TollBypass vs Normal Ougoing PSTN Calls
• Company vs External Calls
Cluster Quality Resource
KPIs
• ClusterNbPacketsLost
• MLQK
• ClusterLatency
• ClusterJitter
• Cluster Total Number of Normal Call Clearing
• ClusterDropCall
Chapter 3: Supported Reports and KPIs
• ClusterSuccessfulCall
• ClusterUnsuccessfulCall
Charts
• Successful vs Unsuccessful Calls
• Drop calls vs Normal call clearing
Cluster Call Distribution Resource
KPIs
• Cluster Total Number of Outgoing External Calls (Nb)
• ClusterLongDistanceCall
• ClusterInternationalCall
• ClusterLocalCall
• Cluster Total Number of External Calls (Nb)
• ClusterInternalCall
• ClusterIncomingCall
Charts
• Types of Calls Distribution
• Incoming vs Outgoing Calls Ratio
Cluster Call Distribution Group
KPIs
• Cluster Total Number of Outgoing External Calls (Nb)
• ClusterLongDistanceCall
IBM Tivoli Netcool/Proviso Cisco IP Telephony 2.4.0.0 Technology Pack 17
Chapter 3: Supported Reports and KPIs
• ClusterInternationalCall
• ClusterLocalCall
• ClusterInternalCall
• ClusterIncomingCall
Charts
• Incoming vs Outgoing Calls Ratio
• Types of Calls Distribution
Top 10 Cluster Call Completion
KPIs
• Cluster Percentage of Successful Calls (percent)
• Cluster Percentage of Drop Calls (percent)
• Cluster Percentage of Normal Call Clearing (percent)
Cluster Quality Group
KPIs
• ClusterMOS
• Cluster Percentage of Drop Calls (percent)
• MLQK
• ClusterLatency
• ClusterJitter
• Cluster Percentage of Packet Lost (percent)
• Cluster Percentage of Successful Calls (percent)
Charts
• Successful Calls Percent Distribution Chart
• Mean Opinion Score
Cluster Utilization Group
KPIs
• Cluster Percentage of Company Calls (percent)
• ClusterIntersiteIPCall
• Cluster Percentage of TollBypass Calls (percent)
• Cluster Erlang
• ClusterNbPacketsReceived
• Cluster Total Hours of Traffic
• ClusterNbPacketsSent
• ClusterTotalCall
18 IBM Tivoli Netcool/Proviso Cisco IP Telephony 2.4.0.0 Technology Pack
Charts
• TollBypass Calls Distribution Chart
• Comapny Calls Percent Distribution Chart
Top 10 Cluster Number of Calls
KPIs
• ClusterTotalCall
• ClusterOnNetCall
• ClusterIncomingCall
• Cluster Total Number of Outgoing External Calls (Nb)
• ClusterOffNetCall
Top 10 Cluster Number of Errors
KPIs
• Cluster Percentage of Successful Calls (percent)
• ClusterShortCall
• Cluster Percentage of Packet Lost (percent)
Chapter 3: Supported Reports and KPIs
• Cluster Percentage of Drop Calls (percent)
Cluster VoiceMail Usage Resource
KPIs
• ClusterVoicemailPackets
• ClusterForwardToVoiceMail
• ClusterVoicemailCallDuration
• ClusterVoiceMailCall
• Cluster Number of Direct VoiceMail Calls (Nb)
Charts
• Direct vs Forward Calls ratio
Cluster IP vs Legacy Resource
KPIs
• ClusterTollBypassCall
• Cluster Total Number of External Calls (Nb)
• Cluster Total Number of Company Calls (Nb)
• Cluster Total Number of Company LegacyPBX Calls (Nb)
• Cluster Total Number of Company IP Calls (Nb)
Charts
• External vs Company Calls Ratio
• IP vs LegacyPBX Calls Ratio
IBM Tivoli Netcool/Proviso Cisco IP Telephony 2.4.0.0 Technology Pack 19
Chapter 3: Supported Reports and KPIs
Cluster Utilization MLH Resource
KPIs
• ClusterTollBypassCall
• ClusterNbPacketsLost
• Cluster Total Number of Company Calls (Nb)
• Cluster Total Hours of Traffic
• ClusterNbPacketsReceived
• ClusterSuccessfulCall
• ClusterTotalCall
• ClusterNbPacketsSent
• ClusterUnsuccessfulCall
Charts
Cluster Erlang-B Group
KPIs
• Cluster Erlang
Extension
CDR Utilization Resource
• Cluster Total Hours of Traffic
• ClusterBlocking
• ClusterLines
• ClusterErlangB
KPIs
• Percentage of Drop Calls (percent) CME(Bulk) VOIP Cisco
• Total Number of Calls (Nb) CME(Bulk) VOIP Cisco
• NbPacketsReceived
• NbPacketsLost
• CallDuration
• Percentage of Successful Calls (Nb) CME(Bulk) VOIP Cisco
• NbPacketsSent
Charts
• Percentage of Successful calls Distribution Chart
• Drop Calls Distribution Chart
CDR Quality Resource
KPIs
• UnsuccessfulCall
20 IBM Tivoli Netcool/Proviso Cisco IP Telephony 2.4.0.0 Technology Pack
• Percentage of Drop Calls (percent) CME(Bulk) VOIP Cisco
• SuccessfulCall
• Latency
• MOS
• Jitter
• Percentage of Packet Lost (percent) CME(Bulk) VOIP Cisco
• Percentage of Successful Calls (Nb) CME(Bulk) VOIP Cisco
Charts
• Drop Calls Distribution Chart
• Percentage of Successful calls Distribution Chart
CDR Call Distribution Resource
KPIs
• Local
• Incoming
Chapter 3: Supported Reports and KPIs
• LongDistance
• International
• Total Number of Outgoing External Calls (Nb)
• Internal
Charts
• Incoming vs Outgoing Calls Ratio
• Types of Calls Distribution
Top 10 CDR Number of Calls
KPIs
• Total Number of Outgoing External Calls (Nb)
• Total Number of Calls (Nb) CME(Bulk) VOIP Cisco
• TollBypassCall
• Incoming
Top 10 CDR Number of Errors
KPIs
• Percentage of Packet Lost (percent) CME(Bulk) VOIP Cisco
• Percentage of Successful Calls (Nb) CME(Bulk) VOIP Cisco
• Percentage of Drop Calls (percent) CME(Bulk) VOIP Cisco
• ShortCall
IBM Tivoli Netcool/Proviso Cisco IP Telephony 2.4.0.0 Technology Pack 21
Chapter 3: Supported Reports and KPIs
CDR VoiceMail Usage Resource
KPIs
• VoicemailPackets
• VoicemailCallDuration
• VoiceMailCall
• Total Number of VoiceMail Direct Calls (Nb) CME(Bulk) VOIP Cisco
• ForwardToVoiceMail
Charts
• Direct vs Forward Calls ratio
Top 10 CDR Call Completion
KPIs
• Percentage of Successful Calls (Nb) CME(Bulk) VOIP Cisco
• Percentage of Drop Calls (percent) CME(Bulk) VOIP Cisco
Top 10 CDR Call Duration
KPIs
• TollbypassCallDuration
• CallDuration
CDR Quality Group
KPIs
• Percentage of Drop Calls (percent) CME(Bulk) VOIP Cisco
• MOS
• Latency
• Jitter
• Percentage of Packet Lost (percent) CME(Bulk) VOIP Cisco
• Percentage of Successful Calls (Nb) CME(Bulk) VOIP Cisco
Charts
• Mean Opinion Score
• Successful Calls Percent Distribution Chart
CDR Utilization Group
KPIs
• Total Number of Calls (Nb) CME(Bulk) VOIP Cisco
• Percentage of TollBypass Calls (percent) CME(Bulk) VOIP Cisco
• NbPacketsReceived
• Percentage of Company Calls (percent) CME(Bulk) VOIP Cisco
• NbPacketsLost
22 IBM Tivoli Netcool/Proviso Cisco IP Telephony 2.4.0.0 Technology Pack
• CallDuration
• NbPacketsSent
Charts
• Company Calls Percent Distribution Chart
• TollBypass Calls Distribution Chart
CDR Call Distribution Group
KPIs
• Local
• Incoming
• LongDistance
• International
• Total Number of Outgoing External Calls (Nb)
• Internal
Charts
• Incoming vs Outgoing Calls Ratio
Chapter 3: Supported Reports and KPIs
K-Factor
• Types of Calls Distribution
K-Factor Resource
KPIs
• MLQKmx
• MLQKmn
• MLQK
• MLQKav
• ICRmx
• ICR
• SCS
• CS
• CCR
K-Factor Group
KPIs
• MLQKmn
• MLQK
• MLQKav
• ICRmx
• ICR
IBM Tivoli Netcool/Proviso Cisco IP Telephony 2.4.0.0 Technology Pack 23
Chapter 3: Supported Reports and KPIs
• SCS
• CS
• CCR
Charts
• Mean Opinion Score
Top 10 CDR K-Factor
KPIs
• CCR
• ICR
• CS
• SCS
• MLQK
Codec
Errors on Cluster by Codec
KPIs
• CauseTemporaryFailure
• CauseNetworkOutOfOrder
• CauseChannelUnacceptable
• CauseUserBusy
• CauseDestinationOutOfOrder
• CauseNoRouteTransitNetwork
• CauseUnassignedNumber
• CauseNumberChanged
• CauseNoChannelAvailable
• CauseMisdialedTrunkPrefix
• CauseNoRouteToDestination
• CauseInvalidNumberFormat
• CauseNoAnswerFromUser
• CauseOther
• CauseNoUserResponding
• CauseResourceUnavailable
• CauseCallRejected
• CauseSubscriberAbsent
• CauseSwitchCongestion
24 IBM Tivoli Netcool/Proviso Cisco IP Telephony 2.4.0.0 Technology Pack
Infrastructure
CallManager Server
CCM Server Quality Resource
CCM Sql Server Resource
Chapter 3: Supported Reports and KPIs
KPIs
• CCM Rejected Devices (Nb) (Gauge)
• CCM Physical Memory Utilization (percent)
• CCM Registered Devices (Nb) (Gauge)
• CCM CPU Utilization (percent) (avg last 5 mn)
Charts
• Managed Devices
• CPU Utilization Distribution Chart
KPIs
• CCM SQL Server number of locks
• CCM SQL Server free buffers (Nb)
• CCM SQL Server Cache Hit ratio (percent)
• CCM SQL Server number active user connections
• CCM SQL Server Availability percentage
• CCM SQL Server number of pending rw
• CCM SQL Server Total number of Pages
• CCM SQL Server number of blocked users
Charts
• Cache Hit Ratio percentage
• Server Availability
CCM Sql Server Group
KPIs
• CCM SQL Server number of locks
• CCM SQL Server free buffers (Nb)
• CCM SQL Server number active user connections
• CCM CPU Utilization (percent) (avg last 5 mn)
• CCM SQL Server number of pending rw
• CCM SQL Server Total number of Pages
• CCM SQL Server number of blocked users
IBM Tivoli Netcool/Proviso Cisco IP Telephony 2.4.0.0 Technology Pack 25
Chapter 3: Supported Reports and KPIs
Charts
• CPU Utilization Distribution Chart
• SQL Server Number of Locks Distribution Chart
PSTN Gateway
Interface
Top 10 E1/T1 Utilization Resource
KPIs
• PSTN Gateway DS1 Active DS0 Channels (Nb)
• Interface Bandwidth Utilization In (percent)
• Interface Bandwidth Utilization Out (percent)
• Interface Throughput In (kbps)
• Interface Throughput Out (kbps)
PSTN Gateway E1/T1Availability Resource
Device
KPIs
• Interface Availability (percent)
• Interface Packet Loss (percent)
Charts
• Availability Distribution Chart
PSTN Gateway E1/T1 Interface Utilization Resource
KPIs
• Interface Throughput Out (kbps)
• Interface Bandwidth Utilization In (percent)
• PSTN Gateway DS1 Active DS0 Channels (Nb)
• Interface Throughput In (kbps)
• Interface Bandwidth Utilization Out (percent)
Charts
• Inbound Utilization Distribution Chart
• Outbound Utilization Distribution Chart
PSTN Gateway Device Quality Resource
KPIs
26 IBM Tivoli Netcool/Proviso Cisco IP Telephony 2.4.0.0 Technology Pack
• PSTN Gateway Packet Discards
• PSTN Gateway Active DS0 Channels (Nb)
• SNMP Response Time (ms) (avg last hour)
• PSTN Gateway Network Errors (percent)
• PSTN Gateway Total Packets per Second
Charts
• Network Errors percentage
• Number of Active DS0 Channels
PSTN Gateway Availability Resource
KPIs
• PSTN Gateway ICMP Outbound Errors (percent)
• PSTN Gateway ICMP Inbound Errors (percent)
• SNMP Response Time (ms) (avg last hour)
• SNMP Availability (percent) (avg last hour)
Charts
• SNMP Responce Time Distribution Chart
• SNMP Availability Distribution Chart
Chapter 3: Supported Reports and KPIs
DSP Card
PSTN Gateway DSP Card Resource
KPIs
Charts
Media Devices
Media Device Resource
KPIs
Charts
Media Device Group
• DSP Card Resource Utilization (percent)
• DSP Card Availability (percent)
• AP.global.Availability
• DSP Card Utilization
• CCM Media Device Registration Availability (percent)
• Registration Availability Distribution Chart
KPIs
• CCM Media Device Registration Availability (percent)
IBM Tivoli Netcool/Proviso Cisco IP Telephony 2.4.0.0 Technology Pack 27
Chapter 3: Supported Reports and KPIs
Charts
• Media Device Registration Distribution Chart
Gatekeeper
Device
Gatekeeper Device Quality Resource Detail Chart
KPIs
• Gatekeeper Total Number of Concurrent Calls (Nb) (Gauge)
• Gatekeeper Packet Errors (Nb)
• Gatekeeper Total Number of Admission Requests (Nb)
• Gatekeeper Buffer Utilization (percent)
• Gatekeeper Total Number of Location Rejects (Nb)
• Gatekeeper Total Number of Admission Rejects (Nb)
• Gatekeeper Total Packets (Nb)
• Gatekeeper Call Setup Quality (percent)
• Gatekeeper Total Number of Location Requests (Nb)
• Gatekeeper CPU Utilization (percent) (avg last 5 mn)
Charts
• Total Number of Packets
• Admission vs Location Rejects (avg)
• CPU Utilization (percent)
• Call Setup Quality (percent)
• Buffer Utilization (percent)
• Packet Errors (Nb)
• Admission vs Location Requests (avg)
• Active Calls (Nb)
Gatekeeper Device Quality Resource
KPIs
• Gatekeeper Total Number of Concurrent Calls (Nb) (Gauge)
• Gatekeeper Packet Errors (Nb)
• Gatekeeper Total Packets (Nb)
• Gatekeeper Call Setup Quality (percent)
• Gatekeeper CPU Utilization (percent) (avg last 5 mn)
Charts
28 IBM Tivoli Netcool/Proviso Cisco IP Telephony 2.4.0.0 Technology Pack
• Gatekeeper Total Number of Registered EndPoints (Nb)
• CPU Utilization (percent)
• Call Setup Quality
Gatekeeper Availability Resource Detail Chart
KPIs
• Gatekeeper ICMP Inbound Errors (percent)
• SNMP Unavailable (percent) (avg last hour)
• SNMP Availability (percent) (avg last hour)
• Gatekeeper ICMP Outbound Errors (percent)
• SNMP Response Time (ms) (avg last hour)
• SNMP Availability (percent) (avg last hour)
Charts
• SNMP Availability (percent) (avg last hour)
• Outbound ICMP Errors (percent)
• Availability vs Unavailable - SNMP
• Inbound ICMP Errors (percent)
Chapter 3: Supported Reports and KPIs
Gatekeeper Availability Resource
Interface
Gatekeeper Interface Availability Resource Detail Chart
• SNMP Response Time (ms) (avg last hour)
KPIs
• Gatekeeper ICMP Inbound Errors (percent)
• Gatekeeper ICMP Outbound Errors (percent)
• SNMP Availability (percent) (avg last hour)
• SNMP Response Time (ms) (avg last hour)
• SNMP Response Time (ms) (avg last hour)
Charts
• SNMP Responce Time Distribution Chart
• SNMP Availability Distribution Chart
KPIs
• Interface Packet Loss (percent)
• Interface Availability (percent)
Charts
• Availability vs Unavailable
• AP.global.Availability_(percent)
• Inbound and Outbound Packet Loss (percent)
IBM Tivoli Netcool/Proviso Cisco IP Telephony 2.4.0.0 Technology Pack 29
Chapter 3: Supported Reports and KPIs
Gatekeeper Interface Availability Resource
KPIs
• Interface Availability (percent)
• Inbound Loss (percent)
• Outbound Loss (percent)
Gatekeeper Interface Utilization Resource Detail Chart
KPIs
• Interface Bandwidth Utilization Out (percent)
• Interface Bandwidth Utilization In (percent)
• Interface Throughput Out (kbps)
• Interface Throughput In (kbps)
Charts
• Inbound vs Outbound Utilization (avg)
• AP.global.Outbound_Utilization_(percent)
• Inbound vs Outbound Throughput (avg)
• AP.global.Inbound_Utilization_(percent)
Perfmon
• Outbound Throughput (kbps)
• Inbound Throughput (kbps)
Gatekeeper Interface Utilization Resource
KPIs
• Interface Bandwidth Utilization Out (percent)
• Interface Bandwidth Utilization In (percent)
• Interface Throughput Out (kbps)
• Interface Throughput In (kbps)
Charts
• Inbound Utilization Distribution Chart
• Outbound Utilization Distribution Chart
Perfmon Active Calls Resource
KPIs
• CallsActive
• CallsInProgress
• HuntlistCallsInProgress
• HuntlistCallsActive
• SIPCallsInProgress
• H323CallsInProgress
30 IBM Tivoli Netcool/Proviso Cisco IP Telephony 2.4.0.0 Technology Pack
• GatewayCallsActive
• SIPCallsActive
• H323CallsActive
Perfmon Active Calls Group
KPIs
• CallsActive
• CallsInProgress
• HuntlistCallsInProgress
• HuntlistCallsActive
• SIPCallsInProgress
• H323CallsInProgress
• GatewayCallsActive
• SIPCallsActive
• H323CallsActive
Chapter 3: Supported Reports and KPIs
Perfmon Security Group
KPIs
• EncryptedCallsActive
• AuthenticatedPartiallyRegisteredPhone
• AuthenticatedCallsActive
• CallsActive
• AuthenticatedRegisteredPhones
• EncryptedRegisteredPhones
• EncryptedPartiallyRegisteredPhones
• AttendantConsoleClientsRegistered
• AttendantConsoleClientsOnline
Perfmon Security Resource
KPIs
• EncryptedCallsActive
• AuthenticatedPartiallyRegisteredPhone
• AuthenticatedCallsActive
• CallsActive
• AuthenticatedRegisteredPhones
• EncryptedRegisteredPhones
• EncryptedPartiallyRegisteredPhones
• AttendantConsoleClientsRegistered
• AttendantConsoleClientsOnline
IBM Tivoli Netcool/Proviso Cisco IP Telephony 2.4.0.0 Technology Pack 31
Chapter 3: Supported Reports and KPIs
Perfmon PSTN Resource
KPIs
• T1SpansInService
• T1ChannelsActive
• FXSPortsInService
• FXOPortsActive
• BRIChannelsActive
• FXSPortsActive
• FXOPortsInService
• BRISpansInService
Perfmon PSTN Group
KPIs
• T1SpansInService
• T1ChannelsActive
• FXSPortsInService
• FXOPortsActive
• BRIChannelsActive
• FXSPortsActive
• FXOPortsInService
• BRISpansInService
Perfmon MOH Resource
KPIs
• MOHUnicastResourceActive
• MOHTotalUnicastResources
• MOHUnicastResourceAvailable
• MOHMulticastResourceActive
• MOHTotalMulticastResources
• MOHMulticastResourceAvailable
Perfmon MOH Group
KPIs
• MOHUnicastResourceActive
• MOHTotalUnicastResources
• MOHUnicastResourceAvailable
• MOHMulticastResourceActive
• MOHTotalMulticastResources
• MOHMulticastResourceAvailable
32 IBM Tivoli Netcool/Proviso Cisco IP Telephony 2.4.0.0 Technology Pack
Chapter 3: Supported Reports and KPIs
Key performance indicators
Table 2 lists all of the key performance indicators (KPIs) supported by the Cisco IP Telephony Technology Pack.
Table 2: Key performance indicators
KPI Comment
AttendantConsoleClientsOnline Total number of attendant console clients currently online
AttendantConsoleClientsRegistered Total number of attendant console clients registered to the device
AuthenticatedCallsActive Total number of active authenticated calls
AuthenticatedPartiallyRegisteredPhone Total number of active authenticated extensions which have not completed
the registration process
AuthenticatedRegisteredPhones Total number of active authenticated and fully registered extensions
BRIChannelsActive Total number of BRI channels currently in use in the target device
BRISpansInService Total number of BRI spans available in the target device
CCM CPU Utilization (percent) (avg last 5 mn)
CCM Media Device Registration Availability (percent)
CCM Physical Memory Utilization (percent) In order to know the percentage of memory utilization, we have to sum the
CCM Registered CTI Devices (Nb) (Gauge) Total number of CTI devices which are registered to the CCM
CCM Registered Devices (Nb) (Gauge) Number of devices currently registered to the CCM device
CCM Registered Gateways (Nb) (Gauge) Total number of media gateways registered to a CCM device
CCM Registered Media Devices (Nb) (Gauge) Total number of media devices registered to a CCM server
CCM Registered Phones (Nb) (Gauge) Total number of IP phones registered to a CCM device
CCM Registered VoiceMail Devices (Nb) (Gauge)
CCM Rejected Devices (Nb) (Gauge) Total number of rejected devices
CCM SQL Server Availability percentage CCM SQL server availability percentage
CCM SQL Server Cache Hit ratio (percent) Buffer cache hit ratio. Percentage of time that a requested data page was
The average, over the last minute, of the percentage of time that this processor was not idle
Percentage availability that media devices could register with a CCM server
amount of real system memory allocated to each process, and then divide this value with the amount of physical memory contained by the host
Total number of registered voicemail devices
found in the data cache (instead of being read from disk).
CCM SQL Server Total number of Pages Total number of pages read and write
CCM SQL Server free buffers (Nb) Total number of data cache buffers currently in the free pool.
CCM SQL Server number active user connections
CCM SQL Server number of blocked users Total Number of users blocked by other users
CCM SQL Server number of locks Total number of locks being used by SQL Server
IBM Tivoli Netcool/Proviso Cisco IP Telephony 2.4.0.0 Technology Pack 33
Total number of open user connections
Chapter 3: Supported Reports and KPIs
Table 2: Key performance indicators
KPI Comment
CCM SQL Server number of locks blocking
Total number of locks blocking other processes.
processes
CCM SQL Server number of pending rw Total number of reads and writes pending
CCR Cumulative conceal ratio. Cumulative concealment ratio during a call
represented as concealment time / speech time
CS Conceal seconds. The number of seconds of concealment during a call
CallDuration Time value in seconds of the call duration.
CallsActive Total number of currently active calls for the resource or resources
specified
CallsInProgress Total number of calls being established at the time of sampling
CauseCallRejected Call was rejected by the far end
CauseChannelUnacceptable Call failure due to lack of acceptable TDM channel
CauseDestinationOutOfOrder Called destination is not in service
CauseInvalidNumberFormat Call failure due to invalid number format
CauseMisdialedTrunkPrefix Call failed due to a misdialed trunk prefix
CauseNetworkOutOfOrder Call failed because the network was out of order
CauseNoAnswerFromUser Call failed because there was no answer at the destination end
CauseNoChannelAvailable Call failed due to lack of available channel
CauseNoRouteToDestination Call failure due to lack of route to destination
CauseNoRouteTransitNetwork Call failued due to lack of available route in the transit network
CauseNoUserResponding Call failed because receiving end sent no RTP data
CauseNumberChanged Recipient number has changed
CauseOther Call failure code is 'other'
CauseResourceUnavailable Call failed due to lack of resources
CauseSubscriberAbsent Call failed because the subscriber called is tagged as absent
CauseSwitchCongestion Call failed due to switch congestion
CauseTemporaryFailure Generic temporary call failure
CauseUnassignedNumber Call failed due to unassigned destination number
CauseUserBusy Call failed due to busy received from destination
Cluster Erlang Cluster Erlang measured in minutes: ClusterCallDuration / 60
Cluster Number of Direct VoiceMail Calls (Nb)
Total number of VoiceMail Calls that are Direct call to VoiceMail. This is the case when a user dials directly his VoiceMail. This metric is the opposite of ForwardToVoiceMail.
34 IBM Tivoli Netcool/Proviso Cisco IP Telephony 2.4.0.0 Technology Pack
Table 2: Key performance indicators
KPI Comment
Chapter 3: Supported Reports and KPIs
Cluster Percentage of Company Calls
Ratio between Company calls and Total number of Calls
(percent)
Cluster Percentage of Drop Calls (percent) Ratio between DropCalls and Total number of Calls
Cluster Percentage of Normal Call Clearing (percent)
Ratio between Calls that have normal termination code and Total number of Calls. This metric is the opposite of the Percentage of Drop Calls metric.
Cluster Percentage of Packet Lost (percent) Ratio between Packets Lost and Total number of Packets sent and received.
Cluster Percentage of Successful Calls
Ratio between Successful Calls and Total number of Calls
(percent)
Cluster Percentage of TollBypass Calls
Ratio between Toll Bypass Calls and Total number of Calls
(percent)
Cluster Total Hours of Traffic This formula will be useful for future Erlang calculation. This is the Total
call duration in hours.
Cluster Total Number of Company Calls (Nb) Total number of Company Calls. A company call is define as: - An Intrasite
IP Call - An Intersite IP Call - An Intrasite Legacy PBX Call - An Intersite Legacy PBX Call Any call with caller and callee that is part of the Internal dial plan is a Company Call.
Cluster Total Number of Company IP Calls
Total number of internal VoIP company calls
(Nb)
Cluster Total Number of Company LegacyPBX Calls (Nb)
Total number of Company Legacy PBX Calls. A Legacy PBX Call is defined as: - An intrasite Legacy PBX Call - An intersite Legacy PBX Call
Cluster Total Number of External Calls (Nb) Any call FROM / TO the PSTN. This is the opposite of a Company Call.
An External Call is defined as: - A Local Call - A Long Distance Call - An International Call - An Incoming Call An External Call is like Outgoing External Call + Incoming Call
Cluster Total Number of Normal Call
Total number of calls which cleared normally for a given cluster
Clearing
Cluster Total Number of Outgoing External Calls (Nb)
Any Outbound call going to the PSTN. This metric is a subset of the Cluster Total Number of External Calls. An Outgoing External call is define as: - A Local Call - A Long Distance Call - An International Call
ClusterBlocking Total number of times call blocking occurred. This can be due to lack of
channel availability, or switch congestion. Error codes 34 and 42 are used in the calculation.
ClusterDropCall Identifies a call successfully established, but with a specific event during the
communication between the 2 parties: the call has been dropped accidentally during the communication. A Drop call is also: - A Successful call - Any Inbound, Outbound, or other type of call described above.
ClusterErlangB Probability that a new arriving call will be rejected because circuits are busy
ClusterForwardToVoiceMail Identifies a call forwarded to another destination by the original callee. In
this case, the destination is one of the VoiceMail extension number, defined in the VoiceMailExtensionRange variable from the UBA.xml adaptor configuration file.
IBM Tivoli Netcool/Proviso Cisco IP Telephony 2.4.0.0 Technology Pack 35
Chapter 3: Supported Reports and KPIs
Table 2: Key performance indicators
KPI Comment
ClusterIncomingCall Identifies a call where caller is not an internal extension. An Incoming call is
also: - An Inbound call - An Off-net call, coming from the PSTN
ClusterInternalCall An Internal Call is a call between 2 internal extensions, managed by one or
more CallManager Clusters, where the 2 Extension numbers (caller and callee) are short internal numbers. An Internal call, or Company call can be:
- An Outbound or Inbound call,
- A call between 2 IP phones from the same site,
- A call between 2 IP phones from different sites,
- A call between 1 IP phone and 1 legacy phone from the same site,
- A call between 1 IP phone and 1 legacy phone from different sites7 Internal = IntrasiteIP OR IntersiteIP OR IntrasiteLegacyPBX OR IntersiteLegacyPBX7
- An On-net call (pure IP Network transit)
- An Off-net call (IP to PSTN Gateway call). An Internal call can never be:
- A call between an Internal Extension and any External PSTN Number. Note: Internal extensions are managed through the UBA.xml adaptor configuration file, where the variable ExtensionRange has to be defined.
ClusterInternationalCall Identifies a call where the caller is an internal extension and where the callee
is an International External PSTN number, according to the Numbering Plan (NANP or Other prefixes). An International call is also: - An Outbound call- An Off-net call, routed towards the PSTN - Can be a TollBypassCall if a remote PSTN Gateway is involved in the Voice path
ClusterIntersiteIPCall Identifies a specific Internal Call where caller and callee are from different
location (site) and using a pure IP Network transit path (No PSTN Gateway is involved in the voice Path).
ClusterJitter Provides an estimate of the statistical variance of the RTP data packet
interarrival time; measured in milliseconds.This metric comes from the CMR table. Its set only once the call is established. This metric is only available for IP Phones.
ClusterLatency Designates value that is an estimate of the network latency, expressed in
milliseconds. This value represents the average value of the difference between the NTP timestamp indicated by the RTP Control Protocol (RTCP) messages and theNTP timestamp of the receivers, measured when these messages are received.Cisco CallManager obtains the average by summing all the estimates then dividing by the number of RTCP messages that have been received. Value of the Latency in milli-seconds. This metric comes from the CMR table. Its set only once the call is established. This metric is only available for IP Phones.
ClusterLines Total number of type 18 interfaces lines
36 IBM Tivoli Netcool/Proviso Cisco IP Telephony 2.4.0.0 Technology Pack
Chapter 3: Supported Reports and KPIs
Table 2: Key performance indicators
KPI Comment
ClusterLocalCall Identifies a call where the caller is an internal extension and where the callee
is a Local External PSTN number, according to the Numbering Plan (NANP or Other prefixes). A Local call is also:- An Outbound call - An Off-net call, routed towards the PSTN - Can be a TollBypassCall if a remote PSTN Gateway is involved in the Voice path Note: Internal extensions are managed through the UBA.xml adaptor configuration file, where the variable ExtensionRange is defined. In order to be able to know whether or not a call will be charged as a Local call, an additional variable needs to be set in the UBA.xml adaptor configuration file. If the first N digits match for this particular site with one of the number configured in this list, then the call is tagged as Local
ClusterLongDistanceCall Identifies a call where the caller is an internal extension and where the callee
is a LongDistance External PSTN number, according to the Numbering Plan (NANP or Other prefixes). A Long Distance cal call is also: - An Outbound call - An Off-net call, routed towards the PSTN - Can be a TollBypassCall if a remote PSTN Gateway is involved in the Voice path
ClusterMOS Mean Opinion Score. This is an high level metric. Note: There is no
algorithm for Mean Opinion Score calculations. This is a subjective metric from the end user point of view. In voice communications, particularly Internet telephony, the mean opinion score (MOS) provides a numerical measure of the quality of human speech at the destination end of the circuit. The scheme uses subjective tests (opinionated scores) that are mathematically averaged to obtain a quantitative indicator of the system performance. To determine MOS, a number of listeners rate the quality of test sentences read aloud over the communications circuit by male and female speakers. A listener gives each sentence a rating as follows: - 1 bad; ­2 poor; - 3 fair; - 4 good; - 5 excellent. The MOS is the arithmetic mean of all the individual scores, and can range from 1 (worst) to 5 (best). In our context, our MOS calculation is based on the consolidation of Jitter, Latency and Packets Lost values which give us a good overview of the real MOS value.
ClusterNbPacketsLost Number of Packets Lost by the subelement during a call. T his metric comes
from the CMR table. Its set only once the call is established. This metric is only available for IP Phones.
ClusterNbPacketsReceived Number of Packets Received by the subelement during a call. This metric
comes from the CMR table. Its set only once the call is established. This metric is only available for IP Phones.
ClusterNbPacketsSent Number of Packets Sent by the subelement during a call. This metric comes
from the CMR table. Its set only once the call is established. This metric is only available for IP Phones.
ClusterOffNetCall Identifies a call where at least one PSTN Gateway is involved in the Voice
path, with the following criteria: - Inbound or Outbound call - Internal or call to/from PSTN number - Intersite or Intrasite Legacy PBX Call
ClusterOnNetCall Identifies a call where the caller is an internal extension and where the callee
is also an internal extension, from the same site or different sites, with the following criteria: - Outbound call - Internal call - Intersite or Intrasite IP Call - No PSTN Gateway is involved in the Voice path - This is a pure IP to IP call
IBM Tivoli Netcool/Proviso Cisco IP Telephony 2.4.0.0 Technology Pack 37
Chapter 3: Supported Reports and KPIs
Table 2: Key performance indicators
KPI Comment
ClusterShortCall Identifies a call successfully established, but with a call duration less than 1
second. In this case, the CallManager set the CallDuration value to 0 in the CDR table. A ShortCall call is also: - A Successful call - Any Inbound, Outbound, or other type of call described above.
ClusterSuccessfulCall Identifies a call successfully established. Once the call is established, the
communication starts between the 2 parties. A successful call can be an Inbound, Outbound, or any type of call described above.
ClusterTollBypassCall Identifies a call where the caller is an internal extension, managed by the
CallManager and where the callee can be an internal extension or any external PSTN Number, with one or more following criteria: - Outbound call - Off-net call - The call is going through a PSTN Gateway and caller site and PSTN Gateway site are different - An intersiteLegacyPBXCall can be also a TollBypassCall, if the PSTN Gateway site is different from the caller site. - TollBypass calls are interesting to save money for long distance or international calls using a remote PSTN Gateway with local fees7 Example: A caller in Boston makes a call to an external PSTN number base in London. Because there is an IP-VPN between the Boston office and the London office with a PSTN Gateway in London, the call goes through the IP network until the Londons PSTN Gateway.
ClusterTotalCall Total Number of Calls (including call attempts) for the complete Cluster.
ClusterUnsuccessfulCall Identifies a call which has not been successfully established. In this case, the
call setup has been rejected and the communication never started between the 2 parties. An Unsuccessful call can be an Inbound, Outbound, or any type of call described above.
ClusterVoiceMailCall Identifies a call where the final destination (callee) is a VoiceMail. The
VoiceMail application is managed through a specific range of extensions number, defined site by site, using the global variable VoiceMailExtensionRange.
ClusterVoicemailCallDuration Time value in Seconds of any call duration with the VoiceMail application.
ClusterVoicemailPackets Number of Packets Sent + Received by the subelement during a call with
the VoiceMail. This metric comes from the CMR table. Its set only once the call is established with one of the VoiceMail extension.
DSP Card Availability (percent) DSP card availability percentage
DSP Card Resource Utilization (percent) Total percentage of DSPs in used for a DSP card
EncryptedCallsActive Total number of currently active encrypted calls
EncryptedPartiallyRegisteredPhones Total number of encrypted extensions which have not completed the
registration process
EncryptedRegisteredPhones Total number of active authenticated calls
FXOPortsActive Total number of FXO ports currently in use in the target device
FXOPortsInService Total number of FXO ports available in the target device
FXSPortsActive Total number of FXS ports currently in use in the target device
FXSPortsInService Total number of FXS ports available in the target device
38 IBM Tivoli Netcool/Proviso Cisco IP Telephony 2.4.0.0 Technology Pack
Chapter 3: Supported Reports and KPIs
Table 2: Key performance indicators
KPI Comment
ForwardToVoiceMail Identifies a call forwarded to another destination by the original callee. In
this case, the destination is one of the VoiceMail extension number, defined in the VoiceMailExtensionRange variable from the UBA.xml adaptor configuration file.
Gatekeeper Buffer Utilization (percent) Percentage of a gatekeeper device's buffer space in use
Gatekeeper CPU Utilization (percent) (avg
CPU utilization percentage over the last 5 minutes measured
last 5 mn)
Gatekeeper Call Setup Quality (percent) Percentage of calls that have been set up successfully
Gatekeeper ICMP Inbound Errors (percent) Percentage of inbound ICMP packets which triggered errors
Gatekeeper ICMP Outbound Errors
Percentage of outbound ICMP packets which triggered errors
(percent)
Gatekeeper Packet Errors (Nb) Total number of packet errors for a gatekeeper device
Gatekeeper Total Number of Admission
Total number of admission rejections
Rejects (Nb)
Gatekeeper Total Number of Admission
Total number of gatekeeper admission requests
Requests (Nb)
Gatekeeper Total Number of Concurrent
Total number of concurrent calls for a gatekeeper device
Calls (Nb) (Gauge)
Gatekeeper Total Number of Location Rejects (Nb)
Gatekeeper Total Number of Location
Total number of location reject messages sent and received by a gatekeeper device
Total number of location requests sent and received by a gatekeeper device
Requests (Nb)
Gatekeeper Total Number of Registered
Total number of endpoints registered to a Cisco gatekeeper
EndPoints (Nb)
Gatekeeper Total Packets (Nb) Total number of packets sent and received by this gatekeeper device
GatewayCallsActive Total number of currently active calls for the gateway resource or resources
specified
H323CallsActive Total number of currently active H.323 calls for the resource or resources
specified
H323CallsInProgress Total number of H.323 calls being established at the time of sampling
HuntlistCallsActive Total number of currently active huntlist calls
HuntlistCallsInProgress Total number of currently active huntlist calls
ICR Interval Conceal Ratio. The average concealment rate measured during the
last three seconds of speech
ICRmx Maximum conceal ratio during a call
IBM Tivoli Netcool/Proviso Cisco IP Telephony 2.4.0.0 Technology Pack 39
Chapter 3: Supported Reports and KPIs
Table 2: Key performance indicators
KPI Comment
Inbound Loss (percent) Out of all inbound traffic received by this entity, the percentage of PDUs
that: (a) contained defects which prevented them from being deliverable to a higher-layer protocol (bad checksums, bad length, etc.), (b) were discarded even though no errors are detected (i.e. due to congestion, policing, or resource limitations), or (c) were discarded because they were of an unknown or unsupported protocol.
Incoming Identifies a call where caller is not an internal extension. An Incoming call is
also: - An Inbound call - An Off-net call, coming from the PSTN
Interface Availability (percent) Interface availability percentage for a Cisco gatekeeper
Interface Bandwidth Utilization In (percent) Inbound bandwidth utilization percentage for a PSTN gateway interface
Interface Bandwidth Utilization Out (percent) Outbound bandwidth utilization percentage for a PSTN gateway interface
Interface Packet Loss (percent) Total percentage of packets lost for a gatekeeper interface
Interface Throughput In (kbps) Inbound interface throughput measured in kilobits per second
Interface Throughput Out (kbps) Outbound interface throughput measured in kilobits per second
Internal An Internal Call is a call between 2 internal extensions, managed by one or
more CallManager Clusters, where the 2 Extension numbers (caller and callee) are short internal numbers. An Internal call, or Company call can be:
- An Outbound or Inbound call,
- A call between 2 IP phones from the same site,
- A call between 2 IP phones from different sites,
- A call between 1 IP phone and 1 legacy phone from the same site,
- A call between 1 IP phone and 1 legacy phone from different sites7 Internal = IntrasiteIP OR IntersiteIP OR IntrasiteLegacyPBX OR IntersiteLegacyPBX7
- An On-net call (pure IP Network transit)
- An Off-net call (IP to PSTN Gateway call). An Internal call can never be:
- A call between an Internal Extension and any External PSTN Number. Note: Internal extensions are managed through the UBA.xml adaptor configuration file, where the variable ExtensionRange has to be defined.
International Identifies a call where the caller is an internal extension and where the callee
is an International External PSTN number, according to the Numbering Plan (NANP or Other prefixes). An International call is also: - An Outbound call- An Off-net call, routed towards the PSTN - Can be a TollBypassCall if a remote PSTN Gateway is involved in the Voice path
Jitter Provides an estimate of the statistical variance of the RTP data packet
interarrival time; measured in milliseconds.This metric comes from the CMR table. Its set only once the call is established. This metric is only available for IP Phones.
40 IBM Tivoli Netcool/Proviso Cisco IP Telephony 2.4.0.0 Technology Pack
Chapter 3: Supported Reports and KPIs
Table 2: Key performance indicators
KPI Comment
Latency Designates value that is an estimate of the network latency, expressed in
milliseconds. This value represents the average value of the difference between the NTP timestamp indicated by the RTP Control Protocol (RTCP) messages and theNTP timestamp of the receivers, measured when these messages are received.Cisco CallManager obtains the average by summing all the estimates then dividing by the number of RTCP messages that have been received. Value of the Latency in milli-seconds. This metric comes from the CMR table. Its set only once the call is established. This metric is only available for IP Phones.
Local Identifies a call where the caller is an internal extension and where the callee
is a Local External PSTN number, according to the Numbering Plan (NANP or Other prefixes). A Local call is also:- An Outbound call - An Off-net call, routed towards the PSTN - Can be a TollBypassCall if a remote PSTN Gateway is involved in the Voice path Note: Internal extensions are managed through the UBA.xml adaptor configuration file, where the variable ExtensionRange is defined. In order to be able to know whether or not a call will be charged as a Local call, an additional variable needs to be set in the UBA.xml adaptor configuration file. If the first N digits match for this particular site with one of the number configured in this list, then the call is tagged as Local
LongDistance Identifies a call where the caller is an internal extension and where the callee
is a LongDistance External PSTN number, according to the Numbering Plan (NANP or Other prefixes). A Long Distance call is also: - An Outbound call - An Off-net call, routed towards the PSTN - Can be a TollBypassCall if a remote PSTN Gateway is involved in the Voice path
MLQK MOS Listening Quality K-factor. This is an estimate of the MOS score of
the last eight seconds of speech measured on the receiving end.
MLQKav Average MOS Listening Quality K-factor for a call
MLQKmn Minimum MOS Listening Quality K-factor for the worst sounding eight
seconds
MLQKmx Maximum MOS Listening Quality K-factor for the best sounding eight
seconds
MOHMulticastResourceActive Total number of currently active message-on-hold multicast resources
MOHMulticastResourceAvailable Total number of available message-on-hold multicast resources
MOHTotalMulticastResources Total number of active and inactive message-on-hold multicast resources
MOHTotalUnicastResources Total number of active and inactive message-on-hold unicast resources
MOHUnicastResourceActive Total number of currently active message-on-hold unicast resources
MOHUnicastResourceAvailable Total number of available message-on-hold unicast resources
IBM Tivoli Netcool/Proviso Cisco IP Telephony 2.4.0.0 Technology Pack 41
Chapter 3: Supported Reports and KPIs
Table 2: Key performance indicators
KPI Comment
MOS Mean Opinion Score. This is an high level metric. Note: There is no
algorithm for Mean Opinion Score calculations. This is a subjective metric from the end user point of view. In voice communications, particularly Internet telephony, the mean opinion score (MOS) provides a numerical measure of the quality of human speech at the destination end of the circuit. The scheme uses subjective tests (opinionated scores) that are mathematically averaged to obtain a quantitative indicator of the system performance. To determine MOS, a number of listeners rate the quality of test sentences read aloud over the communications circuit by male and female speakers. A listener gives each sentence a rating as follows: - 1 bad; ­2 poor; - 3 fair; - 4 good; - 5 excellent. The MOS is the arithmetic mean of all the individual scores, and can range from 1 (worst) to 5 (best). In our context, our MOS calculation is based on the consolidation of Jitter, Latency and Packets Lost values which give us a good overview of the real MOS value.
NbPacketsLost Number of Packets Lost by the subelement during a call. This metric comes
from the CMR table. Its set only once the call is established. This metric is only available for IP Phones.
NbPacketsReceived Number of Packets Received by the subelement during a call. This metric
comes from the CMR table. Its set only once the call is established. This metric is only available for IP Phones.
NbPacketsSent Number of Packets Sent by the subelement during a call. This metric comes
from the CMR table. Its set only once the call is established. This metric is only available for IP Phones.
OffNet Identifies a call where at least one PSTN Gateway is involved in the Voice
path, with the following criteria: - Inbound or Outbound call - Internal or call to/from PSTN number - Intersite or Intrasite Legacy PBX Call
OnNet Identifies a call where the caller is an internal extension and where the callee
is also an internal extension, from the same site or different sites, with the following criteria: - Outbound call - Internal call - Intersite or Intrasite IP Call - No PSTN Gateway is involved in the Voice path - This is a pure IP to IP call
Outbound Loss (percent) Out of all outbound traffic to be sent by this entity, the percentage of PDUs
that: (a) contained defects which prevented them from being transferable, or (b) were discarded even though no errors are detected (i.e. due to congestion or resource limitations).
PSTN Gateway Active DS0 Channels (Nb) Total number of active DS0 channels for all of the enabled PRIs in a PSTN
device
PSTN Gateway Active DS0 Channels (Nb)
Total number of currently active DS0 channels for a PSTN gateway
(Gauge)
PSTN Gateway Call Setup Quality (percent) (Successful / Total)
PSTN Gateway DS1 Active DS0 Channels (Nb)
42 IBM Tivoli Netcool/Proviso Cisco IP Telephony 2.4.0.0 Technology Pack
Percentage of successful call setups for a PSTN gateway device
Number of Active DS0s Channel that are active for a specific Serial E1/T1 Interface. Because there is no specific OID for thisin the MIB we assume that: 1 Call = 1 DS0 Channel = 64 kbpsThenThroughput (in or out) / 64000 = Active Channels
Table 2: Key performance indicators
KPI Comment
Chapter 3: Supported Reports and KPIs
PSTN Gateway ICMP Inbound Errors
Percentage of inbound ICMP errors
(percent)
PSTN Gateway ICMP Outbound Errors
Percentage of outbound SNMP errors
(percent)
PSTN Gateway Network Errors (percent) Percentage of network errors observed by a PSTN gateway
PSTN Gateway Packet Discards Percentage of PSTN gateway packets discarded
PSTN Gateway Total Number of Calls (Nb) Total number of calls for a PSTN device
PSTN Gateway Total Number of Calls per
Total number of calls per minute for a PSTN device
mn (Calls/mn)
PSTN Gateway Total Number of Successful
Total number of successful calls for a PSTN gateway device
Calls (Nb)
PSTN Gateway Total Number of
Total number of unsuccessful calls for a PSTN gateway device
Unsuccessful Calls (Nb)
PSTN Gateway Total Packets per Second Total number of packets per second for a PSTN gateway device
Percentage of Company Calls (percent)
Percentage of all calls which were intra-company calls
CME(Bulk) VOIP Cisco
Percentage of Drop Calls (percent)
Ratio between DropCalls and Total number of Calls
CME(Bulk) VOIP Cisco
Percentage of Packet Lost (percent)
Ratio between Packets Lost and Total number of Packets sent and received.
CME(Bulk) VOIP Cisco
Percentage of Successful Calls (Nb)
Percentage of calls which completed successfully
CME(Bulk) VOIP Cisco
Percentage of TollBypass Calls (percent)
Ratio between Toll Bypass Calls and Total number of Calls
CME(Bulk) VOIP Cisco
SCS Severely concealed seconds. Concealment lasting longer than fifty
milliseconds or five percent of the voice traffic
SIPCallsActive Total number of currently active SIP calls for the resource or resources
specified
SIPCallsInProgress Total number of SIP calls being established at the time of sampling
SNMP Availability (percent) (avg last hour) PROVISO Performance Metric; works with PVL 1.2 or better
SNMP Response Time (ms) (avg last hour) SNMP response time measured in milliseconds averaged over the last hour
SNMP Unavailable (percent) (avg last hour) Created by CME Formula Editor
ShortCall Identifies a call successfully established, but with a call duration less than 1
second. In this case, the CallManager set the CallDuration value to 0 in the CDR table. A ShortCall call is also: - A Successful call - Any Inbound, Outbound, or other type of call described above.
SuccessfulCall Identifies a call successfully established. Once the call is established, the
communication starts between the 2 parties. A successful call can be an Inbound, Outbound, or any type of call described above.
IBM Tivoli Netcool/Proviso Cisco IP Telephony 2.4.0.0 Technology Pack 43
Chapter 3: Supported Reports and KPIs
Table 2: Key performance indicators
KPI Comment
T1ChannelsActive Total number of T1 channels currently in use in the target device
T1SpansInService Total number of T1 spans available in the target device
TollBypassCall Identifies a call where the caller is an internal extension, managed by the
CallManager and where the callee can be an internal extension or any external PSTN Number, with one or more following criteria: - Outbound call - Off-net call - The call is going through a PSTN Gateway and caller site and PSTN Gateway site are different - An intersiteLegacyPBXCall can be also a TollBypassCall, if the PSTN Gateway site is different from the caller site. - TollBypass calls are interesting to save money for long distance or international calls using a remote PSTN Gateway with local fees7 Example: A caller in Boston makes a call to an external PSTN number base in London. Because there is an IP-VPN between the Boston office and the London office with a PSTN Gateway in London, the call goes through the IP network until the Londons PSTN Gateway.
TollbypassCallDuration Time value in seconds of the call duration, when the call is classified as a
TollBypass call.
Total Number of Calls (Nb) CME(Bulk)
Total number of inbound and outbound calls for this Call Manager device.
VOIP Cisco
Total Number of Outgoing External Calls (Nb)
Any Outbound call going to the PSTN. This metric is a subset of the Cluster Total Number of External Calls.An Outgoing External call is define as: - A Local Call - A Long Distance Call - An International Call
Total Number of VoiceMail Direct Calls (Nb) CME(Bulk) VOIP Cisco
Total number of VoiceMail Calls that are Direct call to VoiceMail. This is the case when a user dials directly his VoiceMail. This metric is the opposite of ForwardToVoiceMail.
UnsuccessfulCall Identifies a call which has not been successfully established. In this case, the
call setup has been rejected and the communication never started between the 2 parties. An Unsuccessful call can be an Inbound, Outbound, or any type of call described above.
VoiceMailCall Identifies a call where the final destination (callee) is a VoiceMail. The
VoiceMail application is managed through a specific range of extensions number, defined site by site, using the global variable VoiceMailExtensionRange.
VoicemailCallDuration Time value in Seconds of any call duration with the VoiceMail application.
VoicemailPackets Number of Packets Sent + Received by the subelement during a call with
the VoiceMail. This metric comes from the CMR table. Its set only once the call is established with one of the VoiceMail extension.
44 IBM Tivoli Netcool/Proviso Cisco IP Telephony 2.4.0.0 Technology Pack
Chapter 4: Configuring the technology pack
This chapter explains how to configure the Cisco IP Telephony Technology Pack and consists of the following topics:
Topic Pa g e
Overview 45
Before you begin 45
Configure the technology pack 46
Overview
Tivoli Netcool/Proviso supports the following two types of technology packs, based on the type of data that they collect:
•SNMP
SNMP packs are MIB-based, and their configuration is relatively straightforward.
•Bulk (or UBA)
Bulk technology packs collect data against non-SNMP devices, and rely on the UBA of the Tivoli Netcool/Proviso DataChannel to process the data. Prior to Tivoli Netcool/Proviso version 4.4.3, bulk packs could be very difficult to configure, and in many cases required extensive Tivoli Netcool/Proviso domain knowledge.
Tivoli Netcool/Proviso version 4.4.3 introduces a GUI to configure Tivoli Netcool/Proviso UBA technology packs on supported Tivoli Netcool/Proviso platforms.
The Cisco IP Telephony Technology Pack is an SNMP and UBA technology pack.
Before you begin
Before configuring the Cisco IP Telephony Technology Pack, ensure that you:
Have the following software and documentation for your version of Tivoli Netcool/Proviso:
— Release notes for the current technology pack release.
— IBM Tivoli Netcool/Proviso Installation Guide.
IBM Tivoli Netcool/Proviso Upgrade Guide (if performing an upgrade).
IBM Tivoli Netcool/Proviso DataMart Configuration Guide.
Important: Refer to this guide to create an inventory profile and initiate a discovery.
— Access to the Tivoli Netcool/Proviso DataMart server.
IBM Tivoli Netcool/Proviso Cisco IP Telephony 2.4.0.0 Technology Pack 45
Chapter 4: Configuring the technology pack
— An X Window server on the DataMart server.
Note: (Tivoli Netcool/Proviso pre-v4.4.3) If there is no graphics card on the DataMart server, you can
install the Xvfb virtual frame buffer package to provide X Window services, as described in the IBM Tivoli
Netcool/Proviso Installation Guide.
— Access to the SilverStream server.
— Access to the DataChannel server.
Have completed the following tasks:
— Reviewed the release notes for the current technology pack.
Important: Release notes contain important information you need to consider before installing a technology pack.
They also contain information on specific patches that need to be installed before you configure a technology pack.
— Installed the current version of the Tivoli Netcool/Proviso components, as described in the IBM Tivoli
Netcool/Proviso Installation Guide.
— Installed the MIB-II Technology Pack.
Note: The MIB-II Technology Pack is a stand-alone technology pack that is contained in its own jar file.
— Installed the Cisco IP Telephony Technology Pack.
Note: Installation instructions for a technology pack can be found in the Appendices of the IBM Tivoli
Netcool/Proviso Installation Guide (covers core and technology packs).
Upgrade instructions for a technology pack can be found in Chapter 3 of the IBM Tivoli Netcool/Proviso
Upgrade Guide (covers core and technology packs).
Localization is done automatically during installation of the technology pack.
— Configured at least one DataChannel.
— Configured a UBA bulk collector subchannel.
— Configured an SNMP collector subchannel.
— Created a user account on the server where the ProvisoCUCM application is installed, so that the CUCM
can FTP the CDR/CMR data stream back to the ProvisoCUCM application.
Note: This technology pack contains a Java application, ProvisoCUCM, that sends data requests to CUCM
servers. The ProvisoCUCM application requires the Java 2 Enterprise Edition (JRE 1.5 J2EE). Starting with the Cisco IP Telephony 2.4.0.0 Technology Pack, the ProvisoCUCM application supports multiple Perfmon host collection for a single instance of the ProvisoCUCM application.
Configure the technology pack
To configure the Cisco IP Telephony Technology Pack, follow these steps:
1. Load the DataMart environment.
To load the shell with the DataMart environment, follow these steps:
1-a. Log in to the DataMart server as pvuser.
1-b. Change your working directory to the DataMart home directory (/opt/datamart, by default), using
the following command:
cd /opt/datamart
46 IBM Tivoli Netcool/Proviso Cisco IP Telephony 2.4.0.0 Technology Pack
Chapter 4: Configuring the technology pack
1-c. Load the shell with the DataMart environment, by sourcing the dataMart.env file, as follows:
. /opt/datamart/dataMart.env
Note: After you load the DataMart environment into the shell, the PVMHOME variable is set to the
DataMart home directory, /opt/datamart by default. These instructions assume that this variable has been set.
2. Copy technology-specific files from the DataMart server to the DataChannel server.
Technology-specific files are used to associate a UBA technology pack with a specific instance of the UBA.
Note: While it is possible to install DataMart and DataChannel on the same server, in a typical installation
these modules are installed on separate servers. If this is the case, use ftp to copy the technology-specific files. Otherwise, if DataMart and DataChannel are on the same server, use the cp command to copy the files to the appropriate DataChannel directory.
To copy technology-specific files to the DataChannel server, follow these steps:
2-a. Log in to the Tivoli Netcool/Proviso DataChannel server by entering the user name and password that
you specified when installing and configuring a DataChannel. The default user name and password are
pvuser and PV, respectively.
2-b. Change your working directory to the DATA_CHANNEL_HOME/scripts/voip_cisco_ipt
directory by entering the following command, replacing DataChannel home directory (
$ cd DATA_CHANNEL_HOME/scripts/voip_cisco_ipt
/opt/datachannel, by default):
DATA_CHANNEL_HOME with the
2-c. Using the ftp utility in text mode, log into the DataMart server using the appropriate user name and
password (
pvuser and PV, by default).
2-d. Using the cd subcommand, change your working directory to the
$PVMHOME/APFiles/voip_cisco_ipt/datachannel/scripts/voip_cisco_ipt
directory.
2-e. Using the get subcommand, copy the Bulk Adaptor Design Files (*.js), scripts (if any), and other
files (if any) from the DataMart server to the DataChannel server.
2-f. (Tivoli Netcool/Proviso pre-v4.4.3 only) Copy the voip_cisco_ipt_sample_dc.cfg template
file as follows:
• Using the cd subcommand, change your working directory to the
$PVMHOME/APFiles/voip_cisco_ipt/datachannel/conf directory.
• Using the get subcommand, copy the voip_cisco_ipt_sample_dc.cfg template file from the DataMart server to the DataChannel server.
2-g. Exit the ftp utility by entering the bye subcommand.
2-h. Verify that the technology-specific files are now located in the target directory as follows:
(Tivoli Netcool/Proviso v4.4.3 and later) Verify that the Bulk Adaptor Design Files (*.js), scripts (if any), other files (if any) are now located in the DATA_CHANNEL_HOME/scripts/voip_cisco_ipt directory.
(Tivoli Netcool/Proviso pre-v4.4.3 only) Verify that the Bulk Adaptor Design Files (*.js), scripts (if any), other files (if any), and voip_cisco_ipt_sample_dc.cfg template file are now located in the
DATA_CHANNEL_HOME/scripts/voip_cisco_ipt directory.
3. Activate data collection requests.
During installation of the technology pack, all predefined data collection requests are promoted to the database and set to inactive (that is, idle displays in the Active column of the Tivoli Netcool/Proviso DataMart Request Editor). You need to activate these predefined data collection requests using the Request Editor.
To set data collection requests to active, follow these steps:
IBM Tivoli Netcool/Proviso Cisco IP Telephony 2.4.0.0 Technology Pack 47
Chapter 4: Configuring the technology pack
3-a. Change your working directory to $PVMHOME/bin (/opt/datamart/bin, by default) on the
DataMart server.
3-b. Invoke the DataMart GUI by entering the following command and pressing Enter:
pvm
3-c. Click the Configuration tab, then click Request Editor to open the Request Editor.
3-d. Click the Collection tab.
3-e. Click Refresh.
The predefined data collection requests are loaded into the Request Editor from the database.
3-f. Click the Inactive button in the Filter group box to display only idle requests.
3-g. In the Sub-Element Groups pane, select all idle data collection requests in the following group or
groups:
Root->Sub-Element Collect->VOIP->Cisco
3-h. Click the Active box under Details. The Request Editor toggles the idle setting for these data collection
requests from
idle to active in the Active column.
3-i. Click Save.
4. Merge the technology pack subelement inventory text files.
Subelement inventory control rules for the Cisco IP Telephony Technology Pack are contained in the file
voip_cisco_ipt_inventory_subelements.txt, which is installed in the following directory on the
DataMart server:
$PVMHOME/APFiles/voip_cisco_ipt/datamart/conf
You must merge the contents of this file with the file inventory_subelements.txt located in $PVMHOME/conf (typically, /opt/datamart/conf) on the DataMart server:
To merge the subelement inventory control rules for the Cisco IP Telephony Technology Pack, follow these steps:
4-a. Change your working directory to $PVMHOME/conf by entering the following command:
cd $PVMHOME/conf
4-b. Copy voip_cisco_ipt_inventory_subelements.txt to the $PVMHOME/conf directory, by
entering the following command:
cp $PVMHOME/APFiles/voip_cisco_ipt/datamart/conf/voip_cisco_ipt_inventory_subelements.txt .
4-c. Make a backup copy of the inventory_subelements.txt file by entering the following
command:
cp inventory_subelements.txt inventory_subelements.txt.ORIG
4-d. Append the contents of voip_cisco_ipt_inventory_subelements.txt to
inventory_subelements.txt, by entering the following command:
cat voip_cisco_ipt_inventory_subelements.txt >> inventory_subelements.txt
Important: Ensure that you use two forward brackets (>>); otherwise, the original contents of
inventory_subelements.txt will be overwritten.
4-e. Perform a diff on the backed-up file and the appended file to ensure that the merge succeeded, as
shown in the following example:
diff inventory_subelements.txt inventory_subelements.txt.ORIG
Important: If you do not have a CCM environment, skip Step 5 and continue with Step 6.
48 IBM Tivoli Netcool/Proviso Cisco IP Telephony 2.4.0.0 Technology Pack
Chapter 4: Configuring the technology pack
5. CCM environment only: Configure the Data Direct SQL Server Bridge
The Tivoli Netcool/Proviso Cisco IP Telephony Technology Pack collects data from SNMP devices and, through SQL for Call Detail Records, from each CCM database.
The technology pack UBA is responsible for retrieving CCM data, using the Data Direct SQL server bridge to do so. This bridge is part of the UBA installation. No additional software is required.
You need to set up the Data Direct SQL server bridge to get Call Detail Records from each CallManager Publisher. The complete configuration is done by editing the
pvuser.
$DC_HOME/conf/odbc.ini file as user
[ODBC Data Sources]
Your_Data_Source1=DataDirect 4.20 SQL Server Wire Protocol Your_Data_Source2=DataDirect 4.20 SQL Server Wire Protocol Your_Data_SourceN=DataDirect 4.20 SQL Server Wire Protocol
[Your_Data_Source1] Driver=PVmsss20.so Description=DataDirect 4.20 SQL Server Wire Protocol Address=xx.xx.xx.xx,1433 AnsiNPW=Yes Database=CDR QuoteId=No
[Your_Data_Source2] Driver=PVmsss20.so Description=DataDirect 4.20 SQL Server Wire Protocol Address=xx.xx.xx.xx,1370 AnsiNPW=Yes Database=CDR QuoteId=No
[Your_Data_SourceN] Driver=PVmsss20.so Description=DataDirect 4.20 SQL Server Wire Protocol Address=xx.xx.xx.xx,1433 AnsiNPW=Yes Database=CDR QuoteId=No
[ODBC] IANAAppCodePage=4 InstallDir=/opt/datachannel/ Trace=0 TraceDll=/opt/datachannel/lib/odbctrac.so TraceFile=odbctrace.out UseCursorLib=0
All fields above which appear in italics must be configured according to your CallManager Publisher environment, as follows:
Field Description
[ODBC Data Sources]
One entry per CallManager Publisher.
Note:
The data source name must match the data source name specified in the corresponding URI (Uniform Resource Identifier) parameter in the dc.cfg file. Each line in this section should also be associated with a subsection that configures the data source.
IBM Tivoli Netcool/Proviso Cisco IP Telephony 2.4.0.0 Technology Pack 49
Chapter 4: Configuring the technology pack
Field Description
[Data Source Name] The configuration of the specified data source.
[Data Source Name]: for example, [SANFRANCISCO]
Address: the remote IP address and TCP port of the CallManager Publisher Database (for example, 192.168.1.1,1433). To verify the remote connection configuration, establish the connection manually from a shell window: telnet xx.xx.xx.xx 1433 or telnet xx.xx.xx.xx 1370. The remote TCP port can be 1433 or 1370 according to the SQL Server configuration.
[ODBC] A global section that defines the global environment for the bridge.
Important: If you do not have a CUCM environment, skip Step 6 through Step 9, and continue with Step 10.
6. CUCM environment only: On the DataChannel host, create a directory for each CUCM server from which CDR, CMR, and Perfmon data files will be requested. For example, if you will be requesting data files from two CUCM servers, you might create the following directories:
/opt/datachannel/cucm1 /opt/datachannel/cucm2
These directories will contain the ProvisoCUCM application and other files needed to send SOAP requests to each CUCM server.
Note: If you will be requesting CDR and CMR data files through a master CUCM server, you need to create
just one directory for those requests. However, if you will be requesting Perfmon data, you must create a separate directory for each CUCM server from which you will request Perfmon data.
7. CUCM environment only: Copy the following files into each one of the directories you just created in Step 6:
— ProvisoCUCM.jar
— cucm.properties
— startcucm.sh
— stopcucm.sh
These files were included in the technology-specific files you copied to DATA_CHANNEL_HOME/scripts/voip_cisco_ipt in step 2-e on page 47.
8. CUCM environment only: Configure each of the cucm.properties files you copied in Step 7.
Each cucm.properties file is associated with an instance of the ProvisoCUCM application that is located in the same directory as the file. The ProvisoCUCM instance reads the
cucm.properties file to find the
address and login credentials of the associated CUCM server, the address and login credentials of the DataChannel host for the CUCM server to use when pushing the requested files via FTP back to the DataChannel host, and other required configuration details.
The following table describes the fields in the cucm.properties files:
Field Description
cdr_output_dir
The location on the DataChannel host where the ProvisoCUCM instance generates output from a CDR file and its associated CMR file.
The output is a single CSV file that contains correlated data from the CDR file and CMR file.
Example: cdr_output_dir=/opt/uba/cdrcmr
50 IBM Tivoli Netcool/Proviso Cisco IP Telephony 2.4.0.0 Technology Pack
Field Description
Chapter 4: Configuring the technology pack
collect_cdr
collect_perfmon
cucm.host
cucm.pass
cucm.port
cucm.user
debug
If true, ProvisoCUCM requests CDR and CMR data from the CUCM server.
If
false, ProvisoCUCM will not poll the CUCM server for CDR and CMR
data.
Example: collect_cdr=true
If true, ProvisoCUCM requests Perfmon data from the CUCM server.
If
false, ProvisoCUCM will not poll the CUCM server for Perfmon data.
Example: collect_perfmon=true
The IP address of the CUCM server associated with this properties file.
Examples:
cucm.host=10.1.2.3 cucm.host=cucm.mycorp.com
User password required for login to the CUCM.
Example: cucm.pass=cucmpwd
The port number for SOAP requests sent to the CUCM server.
Example: cucm.port=443
User ID required for login to the CUCM.
Example: cucm.user=cucmuser
If true, enables debug mode for ProvisoCUCM operations. Error information pertaining to the SOAP interaction with the CUCM server is written to a log file. The log file is located in the same directory as the
ProvisoCUCM.jar and cucm.properties files.
If
false, debug mode is not enabled.
Example: debug=true
ftp.host
The IP address of the DataChannel host where the requested data files are to be returned through FTP.
The FTP server must be the host where the ProvisoCUCM instance for this
cucm.properties file is running.
Examples: ftp.host=10.4.5.6
ftp.host=proviso.mycorp.com
ftp.pass
User password required for login to the DataChannel host that issued the SOAP request.
Example: ftp.pass=provisopwd
ftp.remotedir
The location on the DataChannel host where the requested data files are to be copied.
Example: ftp.remotedir=/export/home/pvuser/CUCM/files
ftp.secure
If true, instructs the CUCM server to return the requested data files over a secure FTP connection.
If
false, the CUCM server will not use a secure FTP connection.
Example: ftp.secure=true
IBM Tivoli Netcool/Proviso Cisco IP Telephony 2.4.0.0 Technology Pack 51
Chapter 4: Configuring the technology pack
Field Description
ftp.user
grace_period
perfmon.hostN.hostname
perfmon.host
N.pass
User ID required for login to the DataChannel host that issued the SOAP request.
Example: ftp.user=provisouser
The time, in milliseconds, to subtract from the polling start time. The polling start time is the time that the ProvisoCUCM instance begins polling the CUCM server for data.
The grace period is intended to help you avoid missing data files that the CUCM has not yet written for the current time period.
ProvisoCUCM uses the polling start time specified in the field
start_time of the file cucm.TIMESTAMP. This file is located in the same
directory as the
cucm.properties file.
If the file does not exist when ProvisoCUCM is instantiated, it starts polling the CUCM server immediately, creates
cucm.TIMESTAMP, and writes the
current time to it.
Example grace period (100 seconds): grace_period=100000
Example start time (1/20/2009 at 12:00): start_time=1232470820931
The name of one of the multiple hosts on which Perfmon data is collected.
Example (host1): perfmon.host1.hostname = host1.example.zz Example (host2): perfmon.host2.hostname = host2.example.zz
The password to access one of the multiple hosts on which Perfmon data is collected.
Example (host1): perfmon.host1.pass = pass Example (host2): perfmon.host2.pass = pass
perfmon.host
perfmon.host
perfmon_interval
perfmon_output_dir
N.port
N.user
The port number on one of the multiple hosts on which Perfmon data is collected.
Example (host1): perfmon.host1.port = 443 Example (host2): perfmon.host2.port = 443
The user name to access one of the multiple hosts on which Perfmon data is collected.
Example (host1): perfmon.host1.user = admin Example (host2): perfmon.host2.user = admin
The interval, in milliseconds, at which ProvisoCUCM polls the CUCM server for Perfmon data files, and checks
perfmon_output_dir for data
files pushed there by the CUCM server.
Example (5 minutes): run_interval=300000
The location on the DataChannel host where the ProvisoCUCM instance generates output, in CSV format, from a Perfmon data file.
Example: perfmon_output_dir=/opt/uba/perfmon
52 IBM Tivoli Netcool/Proviso Cisco IP Telephony 2.4.0.0 Technology Pack
Field Description
Chapter 4: Configuring the technology pack
resend_sent_files
run_interval
If true, the CUCM server will re-send files that it has already successfully sent. Since the CUCM can be configured to send data files to any host specified by CUCM Web administration configuration settings, this field must be set to
true to ensure that data files are also sent to the
DataChannel host that requested them.
Use the
false setting in the following situations:
If you prefer to have the data files pushed back to the DataChannel host according to a schedule specified by CUCM Web administration configuration settings. Set the CUCM configuration to push the data files back to the DataChannel server where the ProvisoCUCM instance is running.
If data files are being pushed back to the DataChannel host too slowly for your needs.
If this field is false, the ProvisoCUCM instance will request the data files from the CUCM server and receive none. It will then check for the data files in the location specified by the CUCM Web administration configuration (at time intervals specified by
run_interval or perfmon_interval). If
the files are there, ProvisoCUCM retrieves the files and generates the CSV output to
cdr_output_dir (or perfmon_output_dir with Perfmon
data) on the DataChannel host that requested the data.
Example: resend_sent_files=true
The interval, in milliseconds, at which ProvisoCUCM polls the CUCM server for CDR and CMR data files, and checks
cdr_output_dir for data
files pushed there by the CUCM server.
Example (15 minutes): run_interval=900000
Note: Before proceeding to the next step, be sure you have configured each cucm.properties file in the directories
you created in
Step 6.
9. CUCM environment only: Start all ProvisoCUCM applications by running the startcucm.sh file in each directory that you created in Step 6.
ProvisoCUCM writes a log file in the same directory where its ProvisoCUCM.jar file is located. Monitor the log file to make sure that ProvisoCUCM is successfully communicating with the CUCM server. Also, verify that CSV files are being generated to the output directories (
perfmon_output_dir).
cdr_output_dir and/or
Note: Be sure that all ProvisoCUCM instances are operating successfully before proceeding to the next step.
10. Define global variables.
Global variables are specific to each CCM or CUCM cluster. You assign values to global variables in either of the following files:
CCMConfig.js. with CCM clusters
CUCMConfig.js with CUCM clusters
The Cisco IP Telephony Technology Pack includes the configuration files CCMConfig.js and
CUCMConfig.js. In Step 2-e, you copied these files to
DATA_CHANNEL_HOME/scripts/voip_cisco_ipt (typically,
/opt/datachannel/scripts/voip_cisco_ipt).
IBM Tivoli Netcool/Proviso Cisco IP Telephony 2.4.0.0 Technology Pack 53
Chapter 4: Configuring the technology pack
These configuration files contain sample values. Edit either or both files to assign values appropriate for locations in your Cisco IP Telephony CCM or CUCM environment. The following table describes the global variables to define:
Variable Description
CUSTOMERNAME
CMCLUSTER
OUTBOUNDPREFIX
String specifying the customer’s identifier. This value allows automatic grouping and report navigation by customer.
Example: var CUSTOMERNAME="TELINDUS";
String specifying the cluster’s identifier. This value allows automatic grouping and report navigation by cluster.
Example: var CMCLUSTER="SF";
Integer specifying the prefix to dial to call outside of the PBX (for example, 9 within the US, or
Example: var OUTBOUNDPREFIX=0;
0 within Europe.)
54 IBM Tivoli Netcool/Proviso Cisco IP Telephony 2.4.0.0 Technology Pack
Chapter 4: Configuring the technology pack
Variable Description
site A variable assigned to the JavaScript object Site. A Site object defines a set of
properties specific for a site, business department, location, remote office, or group of people. You can define multiple Site objects. Objects are distinguished through the site name you pass to the object.
Create a Site object as follows:
site = new Site("MySite");
In the example, MySite is the site name.
A site object contains the following methods:
addLocalCallPrefix(string prefix)
The prefix argument specifies n digits in a local call prefix, where n is the prefix length. If the first n digits in a phone number match the prefix, the phone number is determined to be a local number. Many local call prefixes can be defined for the same site through this method.
Example: site.addLocalCallPrefix("999");
addExtensionRange(int startNumber, int endNumber)
The two arguments specify the extension range for a site, beginning with the first extension in the range, and ending with the last extension.
Each number within the range is an internal extension for the named site. Many extension ranges can be defined for the site through this method. The values allow automatic grouping, report navigation by site, and path subelement definition.
Example: site.addExtensionRange(1000,1830);
addVoiceMailRange(int startNumber, int endNumber)
The two arguments specify the VoiceMail extension range for a site, beginning with the first VoiceMail extension in the range, and ending with the last extension.
Each number within the range is an internal VoiceMail extension for the named site. Many VoiceMail extension ranges can be defined for the site through this method. The values allow automatic grouping, report navigation by site, and specific reports on the VoiceMail application.
Example: site.addVoiceMailRange(9000,9050);
addPstnGatewayIpAddress(string ipAddress)
The argument specifies the IP address of a PSTN gateway. Many PSTN gateway addresses can be defined for the named site through this method. The values allow automatic grouping, report navigation by site, and path and gateway subelement definition.
Example: site.addPstnGatewayIpAddress("10.1.184.20");
addCucmAddress(string ipAddress)
IBM Tivoli Netcool/Proviso Cisco IP Telephony 2.4.0.0 Technology Pack 55
Note: Use the following method only in the CUCMConfig.js file.
The argument specifies the IP address of a CUCM server in the cluster.
Example: site.addCucmAddress("10.1.6.8");
Note: If you are collecting Perfmon data on multiple hosts, ensure that
you specify all of the Perfmon hosts in the CUCMConfig.js file, by adding more addCucmAddress lines to the appropriate cluster sections.
Chapter 4: Configuring the technology pack
11. Run the initial SNMP inventory and initiate a discovery.
An inventory collects data about the network resources that the technology pack monitors. After you install an SNMP technology pack, you must create an inventory profile using the initiate a discovery by executing the inventory profile using the
Inventory Tool.
Inventory Tool Wizard and then
Running the initial inventory against SNMP objects is an intricate task and unfortunately beyond the scope of this configuration chapter. For instructions on using the profile, and the
Inventory Tool to execute the inventory profile, see the IBM Tivoli Netcool/Proviso DataMart
Inventory Tool Wizard to create an inventory
Configuration Guide.
12. Edit pack-specific UBA parameters, based on the following Tivoli Netcool/Proviso platforms:
— Tivoli Netcool/Proviso v4.4.3 and later
— Tivoli Netcool/Proviso pre-v4.4.3
Tivoli Netcool/Proviso v4.4.3 and later
In this release of Tivoli Netcool/Proviso, you were instructed to modify the technology pack-specific UBA parameters when you installed the Cisco IP Telephony Technology Pack, using the Topology Editor. If you did not modify the UBA parameters with site-specific values or you want to make additional edits, you can do so now. Otherwise, you can go to the next step.
See the Installing Technology Packs chapter of the IBM Tivoli Netcool/Proviso Installation Guide for more information.
Tivoli Netcool/Proviso pre-v4.4.3
The Cisco IP Telephony Technology Pack requires specific UBA parameters that are not in the dc.cfg file. The DataChannel installer creates a (
/opt/datachannel/conf, by default). These pack-specific parameters were delivered in a template file
called
voip_cisco_ipt_sample_dc.cfg.
dc.cfg file in the DATA_CHANNEL_HOME/conf directory
The best practice on adding these pack-specific parameters to the dc.cfg file is to:
— Edit the pack-specific UBA parameters in the template file with site-specific values.
— Manually add them to the dc.cfg file.
To edit the pack-specific UBA parameters in the template file with site-specific values, follow these steps:
12-a. On the DataChannel server, change your working directory to the
DATA_CHANNEL_HOME/scripts/voip_cisco_ipt directory by entering the following command, replacing
DATA_CHANNEL_HOME with the DataChannel home directory
(/opt/datachannel, by default):
cd DATA_CHANNEL_HOME/scripts/voip_cisco_ipt
12-b. Make a backup copy of the voip_cisco_ipt_sample_dc.cfg template file, by entering the
following command:
cp voip_cisco_ipt_sample_dc.cfg voip_cisco_ipt_sample_dc.cfg.ORIG
12-c. In a text editor, open the voip_cisco_ipt_sample_dc.cfg template file for editing.
12-d. Edit the pack-specific UBA parameters according to the instructions provided in Appendix B, Template
file (Tivoli Netcool/Proviso pre-v4.4.3 only)
12-e. When you are satisfied with your edits, write (but do not quit) the
voip_cisco_ipt_sample_dc.cfg template file.
Important: Editing the dc.cfg file is a nontrivial task and prone to error. Take your time and check your work
carefully.
To manually add the pack-specific UBA parameters to the dc.cfg file, follow these steps:
56 IBM Tivoli Netcool/Proviso Cisco IP Telephony 2.4.0.0 Technology Pack
Chapter 4: Configuring the technology pack
12-f. Open a second terminal emulator.
12-g. On the DataChannel server, change your working directory to the DATA_CHANNEL_HOME/conf
directory (
cd DATA_CHANNEL_HOME/conf
/opt/datachannel/conf, by default), by entering the following command:
12-h. Make a backup copy of the dc.cfg file, by entering the following command:
cp dc.cfg dc.cfg.ORIG
12-i. In a text editor, open the dc.cfg file for editing.
12-j. Search for the UBA parameters, which begin with the string UBA. These parameters were written to the
dc.cfg file when you configured the UBA Bulk Collector and installed the DataChannel
configuration, as described in the IBM Tivoli Netcool/Proviso Installation Guide.
12-k. Copy the pack-specific UBA parameters from the voip_cisco_ipt_sample_dc.cfg template file
to the
dc.cfg file.
12-l. When you are satisfied with your edits, do the following tasks:
— Quit the voip_cisco_ipt_sample_dc.cfg template file.
— Write and quit the
dc.cfg file.
13. Load the DataChannel environment.
In subsequent steps, you will execute dccmd commands. To ensure that you can run these commands, load the shell with the DataChannel environment by following these steps:
13-a. Log in to the DataChannel server as pvuser.
13-b. Change your working directory to the DataChannel home directory (/opt/datachannel, by
default), using the following command:
cd /opt/datachannel
13-c. Load the shell with the DataChannel environment, by sourcing the dataChannel.env file, as
follows:
. /opt/datachannel/dataChannel.env
14. Restart the DataChannel to activate the UBA and read in changes to the deployed topology (v4.4.3 and later) or
dc.cfg (pre-v4.4.3 only).
14-a. Open a terminal emulator on the DataChannel server.
14-b. Use the dccmd command to stop all DataChannel applications:
dccmd -action stop all
14-c. Use the dccmd command to release all daemons running in the DataChannel:
dccmd -action forget all
14-d. Use the following command to find the process identifiers (pids) associated with the DataChannel
visual processes:
DATA_CHANNEL_HOME/bin/findvisual
where:
DATA_CHANNEL_HOME is /opt/datachannel, by default.
14-e. Use the following commands to stop each DataChannel visual process:
kill -9 <cnsw_pid>
kill -9 <logw_pid>
kill -9 <amgrw_pid>
kill -9 <cmgrw_pid>
IBM Tivoli Netcool/Proviso Cisco IP Telephony 2.4.0.0 Technology Pack 57
Chapter 4: Configuring the technology pack
14-f. Use the following commands to restart each DataChannel visual process:
cnsw
logw
amgrw
cmgrw
14-g. Use the dccmd command to start all DataChannel applications:
dccmd -action start all
14-h. Use the dccmd command to verify that all of the DataChannel applications started properly:
dccmd -action status all
More specifically, make sure that the UBA application associated with the DataChannel you configured for the Cisco IP Telephony Technology Pack is running.
14-i. Watch the output of the status switch to verify that all the necessary processes are running. If these
processes are running, run the to the following example:
tail -f DATA_CHANNEL_HOME/log/proviso.log | grep UBA.<channel>.<collector>- | more
where:
tail utility on the log file for the UBA by issuing a command similar
Variable Meaning
DATA_CHANNEL_HOME
<channel> Specifies the channel number (for example, 1) you
<collector> Specifies the collector number (for example, 100) you
The trailing dash (–) after <collector> Removes extraneous log messages from your view. That is,
Is /opt/datachannel, by default.
specified when configuring this DataChannel.
specified when configuring this UBA Bulk Collector.
the trailing dash guarantees that the command displays only those messages generated by your application. The first set of messages relate to syntax checks.
The following table identifies some events to watch for during the syntax check:
Event Meaning
The UBA application starts successfully, but then stops executing.
The Bulk Adaptor Design File might be corrupt. This event causes a syntax error before the UBA
The UBA application connects to the database. This event causes a message similar to the following
Typically, this event occurs because of a licensing issue.
application connects to the database.
example to display:
58 IBM Tivoli Netcool/Proviso Cisco IP Telephony 2.4.0.0 Technology Pack
DB_CONNECT Connecting to <sid> as <user>
If you see this database connection message without prior errors, the UBA application has passed the syntax check.
Chapter 4: Configuring the technology pack
15. Ensure that the bulk input files can be read.
To verify that the UBA application can read the bulk input files, follow these steps:
15-a. Place a bulk input file at the source input location.
(Tivoli Netcool/Proviso v4.4.3 and later) The source input location for bulk input files is specified
using the URI parameter from the pack XSD file, which you can view using the Topology Editor.
(Tivoli Netcool/Proviso pre-v4.4.3 only) The source input location for bulk input files is specified
using the URI parameter from the template file, which you added to the
dc.cfg file in a previous step.
Within the configured file retrieval interval (typically, five minutes), the UBA application retrieves the bulk input file and copies it to the following directory:
DATA_CHANNEL_HOME/UBA.<channel>.<collector>/<instance>/do/
where:
Variable Meaning
DATA_CHANNEL_HOME
<channel> Specifies the channel number (for example, 1) that you
<collector> Specifies the collector number (for example, 100) that you
<instance> (Tivoli Netcool/Proviso v4.4.3 and later) Specifies the string for the INSTANCES parameter in the
<instance> (Tivoli Netcool/Proviso
pre-v4.4.3 only) Specifies the string for the INSTANCES parameter in the
Is /opt/datachannel, by default.
specified when configuring this DataChannel.
specified when configuring this UBA bulk collector.
pack XSD file. Typically, this string represents the name of the pack and is read-only. You can view the string specified for INSTANCES by using the Topology Editor.
pack template file. You were instructed to copy this parameter to the dc.cfg file in a previous step.
The UBA application then processes the bulk input file according to the instructions in the Bulk Adaptor Design File.
Note: The first time that the UBA processes a bulk input file, it passes a metric to the CME. The CME rejects
this metric as a BAD_METRIC because the metric does not have an associated grouped subelement prior to the time this metric is recorded. This is expected behavior. The CME accepts metrics from the bulk input files after the inventory is run.
15-b. Ensure that the UBA application can successfully read the bulk input file that you copied into the
source input location, by issuing a tail command similar to the following example:
tail -f DAT A_ CH AN NE L_ HO ME /log/proviso.log | grep UBA.<channel>.<collector>- | more
The following table identifies the success messages that you should look for.
IBM Tivoli Netcool/Proviso Cisco IP Telephony 2.4.0.0 Technology Pack 59
Chapter 4: Configuring the technology pack
Success message Meaning
PERF_INPUT_PROCESSING Processed <integer> records in <float> seconds (<float> records/minute): <int> records
METRIC_STREAM_INFO Completed writing metric output: DATA_CHANNEL_HOME/UBA.<channel>.<collector>/streaming/
state/temp/output/<time>.<instance>.NRAW.BOF; wrote <int> metrics; <int> bad resource IDs; <int> bad formula names (#())
PERF_INVFLUSH Inserted/updated <int> inventory objects in <float> seconds
Specifies a Bulk Adaptor Design File completion message. A Bulk Adaptor Design File successfully completes when an informational message similar to this one displays in the log file.
Success occurs when <int> records equals 0.
Specifies a metric creation success message. The UBA application successfully creates metrics when a debug 2 message similar to this one displays in the log file.
For some technology packs, the metric creation may be done across different instances of UBA applications. Success occurs when <int> metrics is greater than one, <int> bad resource IDs equals 0, and <int> bad formula names equals 0.
Specifies an inventory success message. The inventory successfully completes when an informational message similar to this one displays in the log file.
If <int> is greater than one, the UBA application created or updated at least one subelement, and the inventory process is successful. The log file might record further details (if necessary) in the messages associated with the PERF_INVFLUSHPV subelement message category.
16. Run the bulk inventory profile.
The UBA application handles the inventory and metrics according to the instructions provided in the technology pack design file or files. The UBA application inserts the created elements, subelements, and metrics into the database. However, the UBA application does not handle the grouping of these elements and subelements.
To handle the grouping of the elements and subelements that were inserted into the database, UBA technology packs supply a bulk inventory profile. This bulk inventory profile is automatically created when the pack is installed. Bulk inventory profiles use the following name syntax:
bulk_N
60 IBM Tivoli Netcool/Proviso Cisco IP Telephony 2.4.0.0 Technology Pack
Chapter 4: Configuring the technology pack
where:
Syntax item Meaning
bulk_
Identifies this as a bulk inventory profile for a UBA
technology pack.
N Specifies the collector number (for example, 100) the user
specified when configuring this UBA Bulk Collector.
You must use the Inventory Tool to run a bulk inventory profile.
To run the bulk inventory profile for this technology pack, perform the following steps:
16-a. In the command window where you loaded the DataMart environment, change your working directory
to
$PVMHOME/bin (/opt/datamart/bin, by default) on the DataMart server.
16-b. Invoke the DataMart GUI by entering the following command and pressing Enter:
pvm
16-c. Click Inventory Tool in the Resource tab. The Inventory Tool window appears.
This window displays a list of the existing inventory profiles on the Configuration tab. The name of the inventory profile to run is
bulk_N, where N is the collector number configured for this pack.
16-d. On the Configuration tab, click on the bulk inventory profile for this technology pack and then select
Run Profile from the Action menu.
The Live Information tab displays messages about the status of the profile. See the IBM Tivoli Netcool/Proviso DataMart Configuration Guide for more information about running an inventory profile.
16-e. (Optional) Every time the UBA technology pack design file creates new elements, subelements, and
metrics, you must perform the previous steps to group the elements and subelements. One way to accomplish this task on a regular basis is to create a command. The following example shows a operation for a bulk inventory profile called
0 * * * * . /opt/datamart/dataMart.env && inventory -name bulk_100 -action pregrouping -reload
-noX
0 * * * * . /opt/datamart/dataMart.env && inventory -name bulk_100 -action grouping -reload -noX
cron entry that makes use of the inventory CLI
cron entry that periodically performs the grouping
bulk_100:
See the ÌBM Tivoli Netcool/Proviso Command Line Interface Guide for more information about the inventory command.
17. Deploy reports.
After the technology pack installation completes, the rules for the new device are automatically loaded into the database. The inventory process uses those rules to group elements and subelements. You must manually deploy (auto-group) the reports by associating them with groups in the NOC Reporting tree in the DataMart Resource Editor.
To deploy the Cisco IP Telephony Technology Pack reports, follow these steps:
17-a. Open the Tivoli Netcool/Proviso DataMart Resource Editor.
17-b. Click the ReportSEGroup tab.
17-c. Move the cursor to the left pane and scroll up to select any group under the SUB-ELEMENTS->NOC
Reporting tree.
17-d. Right-click and select the AutoGrouping option from the menu. The AutoGrouping option places the
reports in dynamically generated groups created during inventory.
17-e. Click Ye s to continue.
IBM Tivoli Netcool/Proviso Cisco IP Telephony 2.4.0.0 Technology Pack 61
Chapter 4: Configuring the technology pack
17-f. Click Close to exit the message box, or click Details to view a description of any errors.
17-g. Optional: You can also deploy reports on a regular basis by creating a cron entry that makes use of the
inventory CLI command and the -reportGrouping option. This option instructs the inventory
command to run the report grouping rules and update the deployed reports stored in the database. Report grouping rules must first have been created before this option can be used. For information on creating report grouping rules, see the IBM Tivoli Netcool/Proviso DataMart Configuration Guide.
The following example shows a cron entry that periodically performs the deploy report operation:
0 * * * * . /opt/datamart/dataMart.env && inventory -noX -reportGrouping
See the ÌBM Tivoli Netcool/Proviso Command Line Interface Guide for more information about the
inventory command.
Verifying resources
Use the Tivoli Netcool/Proviso DataMart Resource Editor to determine whether the technology pack resources (elements, subelements, properties, and so on) were successfully discovered and created in the database during inventory.
See the IBM Tivoli Netcool/Proviso DataMart Configuration Guide for information about using the Tivoli Netcool/Proviso DataMart Resource Editor.
62 IBM Tivoli Netcool/Proviso Cisco IP Telephony 2.4.0.0 Technology Pack
Appendix A: UBA parameters (Tivoli Netcool/Proviso v4.4.3 and later)
This appendix provides UNIX reference pages for each of the pack-specific UBA parameters supplied with the XSD file for the Cisco IP Telephony Technology Pack. The descriptions are the same as those that display in the Topology Editor Help. These reference pages are provided for convenience.
Overview
The following pages provide a reference for the UBA parameters that this technology pack provides. The reference pages have the following sections:
Parameter name. Each reference page begins with the parameter name, using the following syntax:
[device.][instance.][schema.]parameter_name
where:
device specifies the name of the device.
instance specifies the group alias, typically a string that represents the name of the technology pack.
schema specifies the string passed to the input schema object referenced in the bulk adaptor design file.
parameter_name specifies the name of the parameter.
In the Detail sections of the reference pages, parameter names in the descriptions are typically referenced as schema.parameter_name or simply parameter_name. The descriptions do not reference the device or instance part of the parameter name.
Description. A short description that identifies the purpose of the parameter.
Component. The DataChannel application or component to which the parameter applies. The value specified for this parameter controls the behavior of this DataChannel application. This section can contain the following values:
BLB specifies the DataChannel BLB (Bulk Load Balancer) application.
IF specifies the DataChannel Inventory File (IF) application. Examples of IF applications include:
SAMIF specifies the IF application for the Alcatel-Lucent 5620 SAM Technology Pack.
QCIF specifies the IF application for the Alcatel-Lucent 5620 NM Technology Pack.
CWMIF specifies the IF application for the Cisco CWM Technology Pack.
UBA specifies the DataChannel UBA application.
Most UBA technology packs operate with only the UBA application.
Val ue . Specifies the following information:
Default identifies the default value, if one is specified, for the parameter.
Attribute specifies whether the parameter is writable.
Location specifies the location of the parameter in the Topology Editor.
Detail. Provides details about the parameter, including possible values.
IBM Tivoli Netcool/Proviso Cisco IP Telephony 2.4.0.0 Technology Pack 63
Appendix A: UBA parameters (Tivoli Netcool/Proviso v4.4.3 and later)
INSTANCES
Description
Group alias.
Component
UBA
Value
Default: VOIP_CISCO_IPT_PERFMON
Attribute: Read-only
Location: Advanced Properties tab
Detail
The DataChannel supports multiple instances of technology packs running in a single channel component. Therefore, there must be a way to guarantee that the DataChannel applications that handle inventory and metrics parse the correct design files and read the appropriate Bulk input files. The that the DataChannel applications that handle inventory and metrics perform the correct operation for a specific technology pack.
The value of
VOIP_CISCO_IPT with CCM or CUCM metrics.
VOIP_CISCO_IPT_PERFMON with CUCM Perfmon metrics.
This is a read-only parameter whose value you cannot change. Typically, the value for INSTANCES is a string that represents the name of the technology pack.
INSTANCES is one of the following:
INSTANCES parameter helps ensure
64 IBM Tivoli Netcool/Proviso Cisco IP Telephony 2.4.0.0 Technology Pack
INSTANCES
Description
Group alias.
Component
UBA
Value
Default: VOIP_CISCO_IPT
Attribute: Read-only
Location: Advanced Properties tab
Detail
Appendix A: UBA parameters (Tivoli Netcool/Proviso v4.4.3 and later)
The DataChannel supports multiple instances of technology packs running in a single channel component. Therefore, there must be a way to guarantee that the DataChannel applications that handle inventory and metrics parse the correct design files and read the appropriate Bulk input files. The that the DataChannel applications that handle inventory and metrics perform the correct operation for a specific technology pack.
The value of
VOIP_CISCO_IPT with CCM or CUCM metrics.
VOIP_CISCO_IPT_PERFMON with CUCM Perfmon metrics.
This is a read-only parameter whose value you cannot change. Typically, the value for INSTANCES is a string that represents the name of the technology pack.
INSTANCES is one of the following:
INSTANCES parameter helps ensure
IBM Tivoli Netcool/Proviso Cisco IP Telephony 2.4.0.0 Technology Pack 65
Appendix A: UBA parameters (Tivoli Netcool/Proviso v4.4.3 and later)
INSTANCES
Description
Group alias.
Component
UBA
Value
Default: VOIP_CISCO_IPT
Attribute: Read-only
Location: Advanced Properties tab
Detail
The DataChannel supports multiple instances of technology packs running in a single channel component. Therefore, there must be a way to guarantee that the DataChannel applications that handle inventory and metrics parse the correct design files and read the appropriate Bulk input files. The that the DataChannel applications that handle inventory and metrics perform the correct operation for a specific technology pack.
The value of
VOIP_CISCO_IPT with CCM or CUCM metrics.
VOIP_CISCO_IPT_PERFMON with CUCM Perfmon metrics.
This is a read-only parameter whose value you cannot change. Typically, the value for INSTANCES is a string that represents the name of the technology pack.
INSTANCES is one of the following:
INSTANCES parameter helps ensure
66 IBM Tivoli Netcool/Proviso Cisco IP Telephony 2.4.0.0 Technology Pack
Appendix A: UBA parameters (Tivoli Netcool/Proviso v4.4.3 and later)
VOIP_CISCO_IPT.CCMINPUT.DELETEONACQUIRE
Description
Deletes CCM Bulk input files after acquisition.
Component
UBA
Value
Default: false
Attribute: Writable
Location: Advanced Properties tab
Detail
The CCMINPUT.DELETEONACQUIRE parameter specifies whether the Bulk input files should be preserved after the UBA acquires them. A related parameter -
Set this parameter to the value acquires them. Otherwise, set this parameter to files after it acquires them.
true to instruct this UBA application to delete the CCM Bulk input files after it
CCMINPUT.URI - specifies the location of the Bulk input files.
false to instruct this UBA application to preserve the Bulk input
IBM Tivoli Netcool/Proviso Cisco IP Telephony 2.4.0.0 Technology Pack 67
Appendix A: UBA parameters (Tivoli Netcool/Proviso v4.4.3 and later)
VOIP_CISCO_IPT.CCMINPUT.URI
Description
CCM Bulk input files location.
Component
UBA
Value
Default: No default value
Attribute: Read-only
Location: Properties tab
Detail
The DataChannel applications that handle inventory and metrics must be directed to the location of the Bulk input files generated by the devices associated with the technology on which the application operates. The
CCMINPUT.URI parameter specifies the location for the specified DataChannel applications to retrieve these Bulk
input files. A related parameter ­delete the Bulk input files after it acquires them.
The syntax for the URI is as follows:
sqldb:odbc*threaded/username=userName;password=password;environment=dataSourceName
For example: sqldb:odbc*threaded/username=sa;password=netcool;environment=SANFRANCISCO
Note: The URIs you specify must match the URIs of each CCM Publisher data source defined in the
odbc.ini file.
CCMINPUT.DELETEONACQUIRE - specifies whether the UBA application should
68 IBM Tivoli Netcool/Proviso Cisco IP Telephony 2.4.0.0 Technology Pack
Appendix A: UBA parameters (Tivoli Netcool/Proviso v4.4.3 and later)
VOIP_CISCO_IPT.CDRINPUT.DELETEONACQUIRE
Description
Deletes CUCM Bulk input files after acquisition.
Component
UBA
Value
Default: false
Attribute: Writable
Location: Advanced Properties tab
Detail
The CDRINPUT.DELETEONACQUIRE parameter specifies whether the Bulk input files should be preserved after the UBA acquires them. A related parameter -
Set this parameter to the value it acquires them. Otherwise, set this parameter to input files after it acquires them.
true to instruct this UBA application to delete the CUCM Bulk input files after
CDRINPUT.URI - specifies the location of these Bulk input files.
false to instruct this UBA application to preserve the Bulk
IBM Tivoli Netcool/Proviso Cisco IP Telephony 2.4.0.0 Technology Pack 69
Appendix A: UBA parameters (Tivoli Netcool/Proviso v4.4.3 and later)
VOIP_CISCO_IPT.CDRINPUT.URI
Description
CUCM Bulk input files location.
Component
UBA
Value
Default: No default value
Attribute: Read-only
Location: Properties tab
Detail
The DataChannel applications that handle inventory and metrics must be directed to the location of the Bulk input files generated by the devices associated with the technology on which the application operates. The
CDRINPUT.URI parameter specifies the location, in Universal Resource Identifier (URI) format, for the specified
DataChannel applications to retrieve Bulk input files for CDR data.
A related parameter ­Bulk input files after it acquires them.
CDRINPUT.DELETEONACQUIRE - specifies whether the UBA application should delete these
70 IBM Tivoli Netcool/Proviso Cisco IP Telephony 2.4.0.0 Technology Pack
VOIP_CISCO_IPT.DESIGNFILE
Description
JavaScript file that controls UBA for CCM or CUCM metrics.
Component
UBA
Value
Default: CUCMAdaptor.js
Attribute: Read-only
Location: Properties tab
Detail
Appendix A: UBA parameters (Tivoli Netcool/Proviso v4.4.3 and later)
Netcool/Proviso technology packs control the behavior of the DataChannel UBA application through instructions contained in Bulk Adaptor design (JavaScript) files. The of a technology pack’s design file.
CCM metrics require the
This is a read-only parameter.
CCMAdaptor.js design file. CUCM metrics require the CUCMAdaptor.js design file.
DESIGNFILE parameter identifies the name
IBM Tivoli Netcool/Proviso Cisco IP Telephony 2.4.0.0 Technology Pack 71
Appendix A: UBA parameters (Tivoli Netcool/Proviso v4.4.3 and later)
VOIP_CISCO_IPT.DESIGNFILE
Description
JavaScript file that controls UBA for CCM or CUCM metrics.
Component
UBA
Value
Default: CCMAdaptor.js
Attribute: Read-only
Location: Properties tab
Detail
Netcool/Proviso technology packs control the behavior of the DataChannel UBA application through instructions contained in Bulk Adaptor design (JavaScript) files. The of a technology pack’s design file.
CCM metrics require the
This is a read-only parameter.
CCMAdaptor.js design file. CUCM metrics require the CUCMAdaptor.js design file.
DESIGNFILE parameter identifies the name
72 IBM Tivoli Netcool/Proviso Cisco IP Telephony 2.4.0.0 Technology Pack
Appendix A: UBA parameters (Tivoli Netcool/Proviso v4.4.3 and later)
VOIP_CISCO_IPT.INPUT_DIRECTORY
Description
Path to Bulk input files directory for CCM or CUCM metrics.
Component
UBA
Value
Default: sqldb:odbc*threaded/username=user&password=passwd&environment=EXAMPLE
Attribute: Writable
Location: Properties tab
Detail
The INPUT_DIRECTORY parameter specifies the path to the directory where the generated Bulk input files should be stored.
Do not enter any subdirectories and the actual wildcards used to specify the Bulk input files to be acquired. Any subdirectories and wildcards are automatically specified in the directory specification is
CCM metrics are accessed through ODBC to a SQL database. CUCM metrics are accessed through SOAP requests.
opt/uba.
URI-related parameters. An example of an input
IBM Tivoli Netcool/Proviso Cisco IP Telephony 2.4.0.0 Technology Pack 73
Appendix A: UBA parameters (Tivoli Netcool/Proviso v4.4.3 and later)
VOIP_CISCO_IPT.INPUT_DIRECTORY
Description
Path to Bulk input files directory for CCM or CUCM metrics.
Component
UBA
Value
Default: No default value
Attribute: Writable
Location: Properties tab
Detail
The INPUT_DIRECTORY parameter specifies the path to the directory where the generated Bulk input files should be stored.
Do not enter any subdirectories and the actual wildcards used to specify the Bulk input files to be acquired. Any subdirectories and wildcards are automatically specified in the directory specification is
CCM metrics are accessed through ODBC to a SQL database. CUCM metrics are accessed through SOAP requests.
opt/uba.
URI-related parameters. An example of an input
74 IBM Tivoli Netcool/Proviso Cisco IP Telephony 2.4.0.0 Technology Pack
Appendix A: UBA parameters (Tivoli Netcool/Proviso v4.4.3 and later)
VOIP_CISCO_IPT.INPUT_FTP_PASSWORD
Description
FTP or SFTP password for Bulk input files used in CCM or CUCM environments.
Component
UBA
Value
Default: No default value
Attribute: Writable
Location: Properties tab
Detail
The INPUT_FTP_PASSWORD parameter specifies the password that the server administrator assigned (using the ftp or sftp utility) to the FTP or SFTP user. The FTP or SFTP user specifies this password to gain access to the server on which the Bulk input files reside.
Likewise, the UBA uses this same password to gain access to the server on which the Bulk input files reside.
IBM Tivoli Netcool/Proviso Cisco IP Telephony 2.4.0.0 Technology Pack 75
Appendix A: UBA parameters (Tivoli Netcool/Proviso v4.4.3 and later)
VOIP_CISCO_IPT.INPUT_FTP_USERNAME
Description
FTP or SFTP username for Bulk input files used in CCM or CUCM environments.
Component
UBA
Value
Default: No default value
Attribute: Writable
Location: Properties tab
Detail
The INPUT_FTP_USERNAME parameter specifies the username that the server administrator assigned (using the ftp or sftp utility) to the FTP or SFTP user. The FTP or SFTP user specifies this username to gain access to the server on which the Bulk input files reside.
Likewise, the UBA uses this same username to gain access to the server on which the Bulk input files reside.
76 IBM Tivoli Netcool/Proviso Cisco IP Telephony 2.4.0.0 Technology Pack
Appendix A: UBA parameters (Tivoli Netcool/Proviso v4.4.3 and later)
VOIP_CISCO_IPT.INPUT_HOST
Description
Hostname for Bulk input files in CCM or CUCM environments.
Component
UBA
Value
Default: No default value
Attribute: Writable
Location: Properties tab
Detail
The INPUT_HOST parameter specifies the hostname of the server on which the Bulk input files reside. These are the files that the UBA parses.
IBM Tivoli Netcool/Proviso Cisco IP Telephony 2.4.0.0 Technology Pack 77
Appendix A: UBA parameters (Tivoli Netcool/Proviso v4.4.3 and later)
VOIP_CISCO_IPT.INPUT_HOST
Description
Hostname for Bulk input files in CCM or CUCM environments.
Component
UBA
Value
Default: No default value
Attribute: Writable
Location: Properties tab
Detail
The INPUT_HOST parameter specifies the hostname of the server on which the Bulk input files reside. These are the files that the UBA parses.
78 IBM Tivoli Netcool/Proviso Cisco IP Telephony 2.4.0.0 Technology Pack
Appendix A: UBA parameters (Tivoli Netcool/Proviso v4.4.3 and later)
VOIP_CISCO_IPT.INPUT_USE_SECURE_FTP
Description
Acquire CCM or CUCM Bulk input files using secure FTP.
Component
UBA
Value
Default: false
Attribute: Writable
Location: Properties tab
Detail
The INPUT_USE_SECURE_FTP parameter specifies whether FTP (File Transfer Protocol) or SFTP (secure FTP) is used. To use FTP, specify the value is
false.
To use the and where the DataChannel is running. Typically, an SSH client is installed by default on most Unix systems. For more information, see your operating system documentation or the
Use an FTP client to connect to an SFTP server
Connect to an FTP server with a client that supports only SFTP
sftp command, you must have an SSH client installed on the servers where the Bulk input files reside
Note: You cannot do the following:
false. Otherwise, to use SFTP, specify the value true. The default value
sftp manpage.
IBM Tivoli Netcool/Proviso Cisco IP Telephony 2.4.0.0 Technology Pack 79
Appendix A: UBA parameters (Tivoli Netcool/Proviso v4.4.3 and later)
VOIP_CISCO_IPT.INPUT_USE_SECURE_FTP
Description
Acquire CCM or CUCM Bulk input files using secure FTP.
Component
UBA
Value
Default: false
Attribute: Writable
Location: Properties tab
Detail
The INPUT_USE_SECURE_FTP parameter specifies whether FTP (File Transfer Protocol) or SFTP (secure FTP) is used. To use FTP, specify the value is
false.
To use the and where the DataChannel is running. Typically, an SSH client is installed by default on most Unix systems. For more information, see your operating system documentation or the
Use an FTP client to connect to an SFTP server
Connect to an FTP server with a client that supports only SFTP
sftp command, you must have an SSH client installed on the servers where the Bulk input files reside
Note: You cannot do the following:
false. Otherwise, to use SFTP, specify the value true. The default value
sftp manpage.
80 IBM Tivoli Netcool/Proviso Cisco IP Telephony 2.4.0.0 Technology Pack
Appendix A: UBA parameters (Tivoli Netcool/Proviso v4.4.3 and later)
VOIP_CISCO_IPT_PERFMON.DESIGNFILE
Description
JavaScript file that controls UBA for CUCM Perfmon metrics.
Component
UBA
Value
Default: CUCMPerfmonAdaptor.js
Attribute: Read-only
Location: Properties tab
Detail
Netcool/Proviso technology packs control the behavior of the DataChannel UBA application through instructions contained in Bulk Adaptor design (JavaScript) files. The of a technology pack’s design file.
This is a read-only parameter. You cannot change the name of the technology pack’s Bulk Adaptor design file.
DESIGNFILE parameter identifies the name
IBM Tivoli Netcool/Proviso Cisco IP Telephony 2.4.0.0 Technology Pack 81
Appendix A: UBA parameters (Tivoli Netcool/Proviso v4.4.3 and later)
VOIP_CISCO_IPT_PERFMON.INPUT_DIRECTORY
Description
Path to Bulk input files directory for CUCM Perfmon metrics.
Component
UBA
Value
Default: No default value
Attribute: Writable
Location: Properties tab
Detail
The INPUT_DIRECTORY parameter specifies the path to the directory where the generated Bulk input files should be stored.
Do not enter any subdirectories and the actual wildcards used to specify the Bulk input files to be acquired. Any subdirectories and wildcards are automatically specified in the directory specification is
CUCM Perfmon metrics are accessed through SOAP requests.
opt/uba.
URI-related parameters. An example of an input
82 IBM Tivoli Netcool/Proviso Cisco IP Telephony 2.4.0.0 Technology Pack
Appendix A: UBA parameters (Tivoli Netcool/Proviso v4.4.3 and later)
VOIP_CISCO_IPT_PERFMON.INPUT_FTP_PASSWORD
Description
FTP or SFTP password for Bulk input files used for collecting Perfmon metrics in CUCM environments.
Component
UBA
Value
Default: No default value
Attribute: Writable
Location: Properties tab
Detail
The INPUT_FTP_PASSWORD parameter specifies the password that the server administrator assigned (using the ftp or sftp utility) to the FTP or SFTP user. The FTP or SFTP user specifies this password to gain access to the server on which the Bulk input files reside.
Likewise, the UBA uses this same password to gain access to the server on which the Bulk input files reside.
IBM Tivoli Netcool/Proviso Cisco IP Telephony 2.4.0.0 Technology Pack 83
Appendix A: UBA parameters (Tivoli Netcool/Proviso v4.4.3 and later)
VOIP_CISCO_IPT_PERFMON.INPUT_FTP_USERNAME
Description
FTP or SFTP username for Bulk input files used for collecting Perfmon metrics in CUCM environments.
Component
UBA
Value
Default: No default value
Attribute: Writable
Location: Properties tab
Detail
The INPUT_FTP_USERNAME parameter specifies the username that the server administrator assigned (using the ftp or sftp utility) to the FTP or SFTP user. The FTP or SFTP user specifies this username to gain access to the server on which the Bulk input files reside.
Likewise, the UBA uses this same username to gain access to the server on which the Bulk input files reside.
84 IBM Tivoli Netcool/Proviso Cisco IP Telephony 2.4.0.0 Technology Pack
Appendix A: UBA parameters (Tivoli Netcool/Proviso v4.4.3 and later)
VOIP_CISCO_IPT_PERFMON.INPUT_HOST
Description
Hostname for Bulk input files containing Perfmon metrics in CUCM environments.
Component
UBA
Value
Default: No default value
Attribute: Writable
Location: Properties tab
Detail
The INPUT_HOST parameter specifies the hostname of the server on which the Bulk input files reside. These are the files that the UBA parses.
IBM Tivoli Netcool/Proviso Cisco IP Telephony 2.4.0.0 Technology Pack 85
Appendix A: UBA parameters (Tivoli Netcool/Proviso v4.4.3 and later)
VOIP_CISCO_IPT_PERFMON.INPUT_USE_SECURE_FTP
Description
Acquire CUCM Perfmon Bulk input files using secure FTP.
Component
UBA
Value
Default: false
Attribute: Writable
Location: Properties tab
Detail
The INPUT_USE_SECURE_FTP parameter specifies whether FTP (File Transfer Protocol) or SFTP (secure FTP) is used. To use FTP, specify the value is
false.
To use the and where the DataChannel is running. Typically, an SSH client is installed by default on most Unix systems. For more information, see your operating system documentation or the
Use an FTP client to connect to an SFTP server
Connect to an FTP server with a client that supports only SFTP
sftp command, you must have an SSH client installed on the servers where the Bulk input files reside
Note: You cannot do the following:
false. Otherwise, to use SFTP, specify the value true. The default value
sftp manpage.
86 IBM Tivoli Netcool/Proviso Cisco IP Telephony 2.4.0.0 Technology Pack
Appendix A: UBA parameters (Tivoli Netcool/Proviso v4.4.3 and later)
VOIP_CISCO_IPT_PERFMON.PERFMON.DELETEONACQUIRE
Description
Deletes CUCM Perfmon Bulk input files after acquisition.
Component
UBA
Value
Default: false
Attribute: Writable
Location: Advanced Properties tab
Detail
The PERFMON.DELETEONACQUIRE parameter specifies whether the Bulk input files should be preserved after the UBA acquires them. A related parameter -
Set this parameter to the value files after it acquires them. Otherwise, set this parameter to the Bulk input files after it acquires them.
true to instruct this UBA application to delete the CUCM Perfmon Bulk input
PERFMON.URI - specifies the location of these Bulk input files.
false to instruct this UBA application to preserve
IBM Tivoli Netcool/Proviso Cisco IP Telephony 2.4.0.0 Technology Pack 87
Appendix A: UBA parameters (Tivoli Netcool/Proviso v4.4.3 and later)
VOIP_CISCO_IPT_PERFMON.PERFMON.URI
Description
CUCM Perfmon Bulk input files location.
Component
UBA
Value
Default: No default value
Attribute: Read-only
Location: Properties tab
Detail
The DataChannel applications that handle inventory and metrics must be directed to the location of the Bulk input files generated by the devices associated with the technology on which the application operates. The
PERFMON.URI parameter specifies the location, in Universal Resource Identifier (URI) format, for the specified
DataChannel applications to retrieve Bulk input files for CDR data.
A related parameter ­Bulk input files after it acquires them.
PERFMON.DELETEONACQUIRE - specifies whether the UBA application should delete these
88 IBM Tivoli Netcool/Proviso Cisco IP Telephony 2.4.0.0 Technology Pack
Appendix B: Template file (Tivoli Netcool/Proviso pre-v4.4.3 only)
You should read this appendix after you open the voip_cisco_ipt_sample_dc.cfg template file for editing, as instructed in Chapter 4, Configuring the technology pack.
This appendix describes the pack-specific UBA parameters that you need to add to the dc.cfg file, and explains how to tailor the values to your specific deployment.
Template file name and location
The voip_cisco_ipt_sample_dc.cfg template file is located in the following directory on the DataChannel server:
DATA_CHANNEL_HOME/scripts/voip_cisco_ipt (
/opt/datachannel/scripts/voip_cisco_ipt, by default)
You were instructed to copy the voip_cisco_ipt_sample_dc.cfg template file in a configuration step (step 2 on page 47) described in Chapter 4.
Pack-specific UBA parameters
The voip_cisco_ipt_sample_dc.cfg template file provides the following pack-specific UBA parameters:
UBA.<channel_number>.<collector_number1>.INSTANCES=<instance> UBA.<channel_number>.<collector_number1>.<instance>.TIMEZONE=GMT UBA.<channel_number>.<collector_number1>.<instance>.DESIGNFILE=CCMAdaptor.js UBA.<channel_number>.<collector_number1>.<instance>.CCMINPUT.URI=<input_files_location1> UBA.<channel_number>.<collector_number1>.<instance>.CCMINPUT.DELETEONACQUIRE=true
UBA.<channel_number>.<collector_number2>.INSTANCES=<instance> UBA.<channel_number>.<collector_number2>.<instance>.TIMEZONE=GMT UBA.<channel_number>.<collector_number2>.<instance>.DESIGNFILE=CUCMAdaptor.js UBA.<channel_number>.<collector_number2>.<instance>.CDRINPUT.URI=<input_files_location2> UBA.<channel_number>.<collector_number2>.<instance>.CDRINPUT.DELETEONACQUIRE=false
UBA.<channel_number>.<collector_number3>.INSTANCES=<instance> UBA.<channel_number>.<collector_number3>.<instance>.TIMEZONE=GMT UBA.<channel_number>.<collector_number3>.<instance>.DESIGNFILE=CUCMPerfmonAdaptor.js UBA.<channel_number>.<collector_number3>.<instance>.PERFMON.URI=<input_files_location1> UBA.<channel_number>.<collector_number3>.<instance>.PERFMON.DELETEONACQUIRE=false
IBM Tivoli Netcool/Proviso Cisco IP Telephony 2.4.0.0 Technology Pack 89
Appendix B: Template file (Tivoli Netcool/Proviso pre-v4.4.3 only)
The following table describes the values that you must provide for these UBA parameters.
UBA Parameter Value Meaning
<channel_number>
<collector_number> Replace with the UBA Bulk Collector number that was configured for this technology
<instance> Replace with an arbitrary string that identifies a group alias to be associated with
<timezone> Replace with the correct time zone, as specified in the /etc/default/init file
<input_files_location> Specify the location of the bulk input files that the device generates, and the URIs of
Replace with the channel number that was configured for this technology pack. This
channel number appears in the dc.cfg file.
pack. This collector number appears in the dc.cfg file.
subsequent lines in this section of the dc.cfg file. See Additional information about UBA parameters on page 90 for more information on this UBA parameter value.
The template file specifies VOIP_CISCO_IPT as an example. If you replace this string with one of your own, make sure that you replace it in the other parameters where it is specified.
on the source host.
For example:
UBA.1.1.VOIP_CISCO_IPT.TIMEZONE=GMT
The time zone must be set correctly. Otherwise, the pack will not deploy.
each CCM Publisher data source defined in the odbc.ini file.
See Additional information about UBA parameters on page 90 for more information about this UBA parameter value.
Additional information about UBA parameters
This section provides more information about the INSTANCES, URI, and DB_USERNAME parameters.
INSTANCES
The DataChannel UBA application supports multiple instances of technology packs running in a single channel component. Therefore, there must be a way to guarantee that the UBA parses the correct design file and reads the appropriate bulk input files. The performs the correct operation for a specific technology pack.
The Cisco IP Telephony Technology Pack provides an
voip_cisco_ipt_sample_dc.cfg template file. You supply an arbitrary string — referred to as a group alias
— to the
INSTANCES parameter. After you define the INSTANCES parameter with a specific string, make sure
you specify this string wherever <instance> appears in the template file.
You can associate this group alias with any arbitrary string. For example, you might associate this group alias with the location (for example,
BOSTON, LOWELL, BERLIN, PARIS, and so forth) of the data source.
INSTANCES parameter helps ensure that the DataChannel UBA application
INSTANCES parameter in its
90 IBM Tivoli Netcool/Proviso Cisco IP Telephony 2.4.0.0 Technology Pack
Appendix B: Template file (Tivoli Netcool/Proviso pre-v4.4.3 only)
URI
The DataChannel UBA application needs to know where to find the bulk input files that the supported device generates. Therefore, you must specify a Universal Resource Identifier (URI) for the location of the bulk input files. To define this location, the Cisco IP Telephony Technology Pack provides a
voip_cisco_ipt_sample_dc.cfg template file.
You must specify the URI for each CCM Publisher bulk adaptor configured in the
Note: The URIs that you specify in the dc.cfg file must match the URIs of each CCM Publisher data source
defined in the odbc.ini file.
Follow these guidelines when specifying a URI in the template or dc.cfg file:
Use Internet-standard URIs.
Specify the file protocol, FTP (File Transfer Protocol), or SFTP (secure FTP).
The file protocol is appropriate only when specifying a path on the same host computer.
When using the file protocol, specify a full absolute path after the initial file://. This results in three slashes after the word
file, because the full path must begin with a slash.
When using FTP or SFTP, use the following syntax:
ftp://<username>:<encrypted_password>@<hostname>//full/path/to/directory/specific_string
sftp://
<username>:<encrypted_password>@<hostname>//full/path/to/directory/specific_string
where:
URI parameter in its
dc.cfg file.
<username> specifies the user name that the server administrator assigned (using the ftp or sftp utility)
to the FTP or SFTP user. The FTP or SFTP user specifies this user name to gain access to the server on which the technology pack is installed.
<encrypted_password> specifies the password that the server administrator assigned (using the ftp or sftp
utility) to the FTP or SFTP user. The FTP or SFTP user specifies this password to gain access to the server on which the technology pack is installed. The password specified here should be the encrypted password.
<hostname> specifies the host name of the server on which the bulk input files are located. These are the
files that the UBA parses.
specific_string refers to the string that ends an entry for the URI line.
Example:
UBA.1.1.VOIP_CISCO_IPT.CDRINPUT.URI=ftp://pvuser:CACCDHDBCCCJHCGL@KLPRO02Z7//opt/uba/cdrcmr/*
To use the sftp command, you must have an SSH client installed on the servers where the bulk input files are located and where the DataChannel is running. Typically, an SSH client is installed by default on most UNIX systems. For more information, see your operating system documentation or the
sftp reference page.
Note that you cannot do the following:
Use an FTP client to connect to an SFTP server
Connect to an FTP server with a client that supports only SFTP
DB_USERNAME
Use the following guidelines to determine whether you have the correct value for the
UBA.<channel_number>.<collector_number>.DB_USERNAME parameter in the dc.cfg file:
IBM Tivoli Netcool/Proviso Cisco IP Telephony 2.4.0.0 Technology Pack 91
Appendix B: Template file (Tivoli Netcool/Proviso pre-v4.4.3 only)
The UBA technology pack requires the DataChannel UBA application to process metrics only. In this
scenario, the UBA technology pack provides a metrics schema in its design file. In this case, must be set to
PV_COLL.
DB_USERNAME
The UBA technology pack requires the DataChannel UBA application to process both inventory and
metrics. In this scenario, the UBA technology pack provides metrics and inventory schemas in its design file. In this case,
DB_USERNAME must be set to PV_GUI.
For the Cisco IP Telephony Technology Pack, DB_USERNAME should be set to PV_GUI.
Example
The following example shows the UBA parameter settings for the Cisco IP Telephony Technology Pack:
UBA.1.98.ROOT_DIRECTORY=/opt/datachannel UBA.1.98.INSTANCES=VOIP_CISCO_IPT UBA.1.98.RUNINTERVAL=900 UBA.1.98.VOIP_CISCO_IPT.TIMEZONE=GMT UBA.1.98.VOIP_CISCO_IPT.DESIGNFILE=CUCMPerfmonAdaptor.js UBA.1.98.VOIP_CISCO_IPT.PERFMON.URI=ftp://user:cryptedpass@examplehost//opt/uba/ perfmon/*.csv UBA.1.98.VOIP_CISCO_IPT.PERFMON.DELETEONACQUIRE=false UBA.1.98.METRIC_STREAM_TYPE=BOF UBA.1.98.DEBUG_WALKBACK_ON_ADAPTOR_ERROR=TRUE UBA.1.98.DUAL_LOGGING=true UBA.1.98.LOG_FILTER=FEWI 12345 UBA.1.98.SERVICE_INSTANCE=GLOBAL UBA.1.98.COLLECTOR_LIST=98 UBA.1.98.DB_USERNAME=PV_GUI UBA.1.98.DB_PASSWORD=AAAC UBA.1.98.INVENTORY_SUBELEMENT_FLUSH_THRESHOLD=1
UBA.1.99.ROOT_DIRECTORY=/opt/datachannel UBA.1.99.INSTANCES=VOIP_CISCO_IPT UBA.1.99.RUNINTERVAL=900 UBA.1.99.VOIP_CISCO_IPT.TIMEZONE=GMT UBA.1.99.VOIP_CISCO_IPT.DESIGNFILE=CUCMAdaptor.js UBA.1.99.VOIP_CISCO_IPT.CDRINPUT.URI=ftp://user:cryptedpass@examplehost//opt/uba /cdrcmr/*.csv UBA.1.99.VOIP_CISCO_IPT.CDRINPUT.DELETEONACQUIRE=false UBA.1.99.METRIC_STREAM_TYPE=BOF UBA.1.99.DEBUG_WALKBACK_ON_ADAPTOR_ERROR=TRUE UBA.1.99.DUAL_LOGGING=true UBA.1.99.LOG_FILTER=FEWI 12345 UBA.1.99.SERVICE_INSTANCE=GLOBAL UBA.1.99.COLLECTOR_LIST=99 UBA.1.99.DB_USERNAME=PV_GUI UBA.1.99.DB_PASSWORD=AAAC UBA.1.99.INVENTORY_SUBELEMENT_FLUSH_THRESHOLD=1
UBA.1.101.ROOT_DIRECTORY=/opt/datachannel UBA.1.101.INSTANCES=VOIP_CISCO_IPT UBA.1.101.RUNINTERVAL=900 UBA.1.101.VOIP_CISCO_IPT.TIMEZONE=EST UBA.1.101.VOIP_CISCO_IPT.DESIGNFILE=CCMAdaptor.js UBA.1.101.VOIP_CISCO_IPT.CCMINPUT.URI=sqldb:odbc*threaded/username=sa&password=n etcool&environment=SF
92 IBM Tivoli Netcool/Proviso Cisco IP Telephony 2.4.0.0 Technology Pack
Appendix B: Template file (Tivoli Netcool/Proviso pre-v4.4.3 only)
UBA.1.101.VOIP_CISCO_IPT.CCMINPUT.DELETEONACQUIRE=false UBA.1.101.METRIC_STREAM_TYPE=BOF UBA.1.101.DEBUG_WALKBACK_ON_ADAPTOR_ERROR=TRUE UBA.1.101.DUAL_LOGGING=true UBA.1.101.LOG_FILTER=FEWI 12345 UBA.1.101.SERVICE_INSTANCE=GLOBAL UBA.1.101.COLLECTOR_LIST=101 UBA.1.101.DB_USERNAME=PV_GUI UBA.1.101.DB_PASSWORD=AAAC UBA.1.101.INVENTORY_SUBELEMENT_FLUSH_THRESHOLD=10
IBM Tivoli Netcool/Proviso Cisco IP Telephony 2.4.0.0 Technology Pack 93
Appendix B: Template file (Tivoli Netcool/Proviso pre-v4.4.3 only)
NOTES
94 IBM Tivoli Netcool/Proviso Cisco IP Telephony 2.4.0.0 Technology Pack
Notices
This information was developed for products and services offered in the U.S.A.
IBM may not offer the products, services, or features discussed in this document in other countries. Consult your local IBM representative for information about the products and services currently available in your area. Any reference to an IBM product, program, or service is not intended to state or imply that only that IBM product, program, or service may be used. Any functionally equivalent product, program, or service that does not infringe any IBM intellectual property right may be used instead. However, it is the user’s responsibility to evaluate and verify the operation of any non-IBM product, program, or service.
IBM may have patents or pending patent applications covering subject matter described in this document. The furnishing of this document does not grant you any license to these patents. You can send license inquiries, in writing, to:
IBM Director of Licensing IBM Corporation North Castle Drive Armonk, NY 10504-1785 U. S. A.
For license inquiries regarding double-byte character set (DBCS) information, contact the IBM Intellectual Property Department in your country or send inquiries, in writing, to:
Intellectual Property Licensing Legal and Intellectual Property Law IBM Japan Ltd. 1623-14, Shimotsuruma, Yamato-shi Kanagawa 242-8502 Japan
The following paragraph does not apply to the United Kingdom or any other country where such provisions are inconsistent with local law:
INTERNATIONAL BUSINESS MACHINES CORPORATION PROVIDES THIS PUBLICATION "AS IS" WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF NON-INFRINGEMENT, MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.
Some states do not allow disclaimer of express or implied warranties in certain transactions, therefore, this statement might not apply to you.
This information could include technical inaccuracies or typographical errors. Changes are periodically made to the information herein; these changes will be incorporated in new editions of the publication. IBM may make improvements and/or changes in the product(s) and/or the program(s) described in this publication at any time without notice.
Any references in this information to non-IBM Web sites are provided for convenience only and do not in any manner serve as an endorsement of those Web sites. The materials at those Web sites are not part of the materials for this IBM product and use of those Web sites is at your own risk.
IBM may use or distribute any of the information you supply in any way it believes appropriate without incurring any obligation to you.
IBM Tivoli Netcool/Proviso Cisco IP Telephony 2.4.0.0 Technology Pack 95
Notices
Licensees of this program who wish to have information about it for the purpose of enabling: (i) the exchange of information between independently created programs and other programs (including this one) and (ii) the mutual use of the information which has been exchanged, should contact:
IBM Corporation 2Z4A/101 11400 Burnet Road Austin, TX 78758 U. S. A.
Such information may be available, subject to appropriate terms and conditions, including in some cases payment of a fee.
The licensed program described in this document and all licensed material available for it are provided by IBM under terms of the IBM Customer Agreement, IBM International Program License Agreement or any equivalent agreement between us.
Any performance data contained herein was determined in a controlled environment. Therefore, the results obtained in other operating environments may vary significantly. Some measurements may have been made on development­level systems and there is no guarantee that these measurements will be the same on generally available systems. Furthermore, some measurements may have been estimated through extrapolation. Actual results may vary. Users of this document should verify the applicable data for their specific environment.
Information concerning non-IBM products was obtained from the suppliers of those products, their published announcements or other publicly available sources. IBM has not tested those products and cannot confirm the accuracy of performance, compatibility or any other claims related to non-IBM products. Questions on the capabilities of non-IBM products should be addressed to the suppliers of those products.
All statements regarding IBM’s future direction or intent are subject to change or withdrawal without notice, and represent goals and objectives only.
This information is for planning purposes only. The information herein is subject to change before the products described become available.
This information contains examples of data and reports used in daily business operations. To illustrate them as completely as possible, the examples include the names of individuals, companies, brands, and products. All of these names are fictitious and any similarity to the names and addresses used by an actual business enterprise is entirely coincidental.
COPYRIGHT LICENSE:
This information contains sample application programs in source language, which illustrate programming techniques on various operating platforms. You may copy, modify, and distribute these sample programs in any form without payment to IBM, for the purposes of developing, using, marketing or distributing application programs conforming to the application programming interface for the operating platform for which the sample programs are written. These examples have not been thoroughly tested under all conditions. IBM, therefore, cannot guarantee or imply reliability, serviceability, or function of these programs. The sample programs are provided "AS IS", without warranty of any kind. IBM shall not be liable for any damages arising out of your use of the sample programs.
If you are viewing this information in softcopy form, the photographs and color illustrations might not appear.
Trademarks
IBM, the IBM logo, and ibm.com are trademarks or registered trademarks of International Business Machines Corp., registered in many jurisdictions worldwide. Other product and service names might be trademarks of IBM or other companies. A current list of IBM trademarks is available on the Web at “Copyright and trademark information” at www.ibm.com/legal/copytrade.shtml.
UNIX is a registered trademark of The Open Group in the United States and other countries.
96 IBM Tivoli Netcool/Proviso Cisco IP Telephony 2.4.0.0 Technology Pack
Loading...
