Cisco MDS 9506, 9509, 9513, 9216i, 9222i, 9134, and 9124 for IBM
System Storage™ Directors and Switches
Interoperability Matrix
Last update: February 24, 2010
© Copyright International Business Machines Corporation 1999, 2002, 2003, 2004, 2005. All rights reserved.
The information provided in this document is provide "AS IS" without warranty of any kind, including any warranty of
merchantability, fitness for a particular purpose, interoperability or compatibility. IBM's products are warranted in
accordance with the agreements under which they are provided.
Unless otherwise specified, the product manufacturer, supplier, or publisher of non-IBM products provides warranty,
service, and support directly to you. IBM makes no representations or warranties regarding non-IBM products.
The inclusion of an IBM or non-IBM product on an interoperability list is not a guarantee that it will work with the
designated IBM storage product. In addition, not all software and hardware combinations created from compatible
components will necessarily function properly together. The following list includes products developed or distributed by
companies other than IBM. IBM does not provide service or support for the non-IBM products listed, but does not prohibit
them from being used together with IBM's storage products. During problem debug and resolution, IBM may require that
hardware or software additions be removed from the IBM product to provide problem determination and resolution on the
IBM-supplied hardware/ software. For support issues regarding non-IBM products, please contact the manufacturer of the
product directly. IBM does not warrant either functionality or problem resolution of any non-IBM products.
This information could include technical inaccuracies or typographical errors. IBM does not assume any liability for
damages caused by such errors as this information is provided for convenience only; the reader should confirm any
information contained herein with the associated vendor.
Changes are periodically made to the content of the document. These changes will be incorporated in new editions of the
document. IBM may make improvements and/or changes in the product(s) and/or the program(s) described in this
document at anytime without notice.
Any references in this information to non-IBM Web sites are provided for convenience only and do not in any manner
serve as an endorsement of those Web sites. The materials at those Web sites are not part of the materials for this IBM
product and use of those Web sites is at your own risk.
Information concerning non-IBM products was obtained from the suppliers of those products, their published
announcements or other publicly available sources. IBM has not tested those products and cannot confirm the accuracy
of performance, compatibility or any other claims related to non-IBM products. Questions on the capabilities of non-IBM
products should be addressed to the suppliers of those products.
All statements regarding IBM’s future direction or intent are subject to change or withdrawal without notice, and represent
goals and objectives only.
This information is for planning purposes only. The information herein is subject to change before the products described
become available.
The following terms are trademarks of the International Business Machines Corporation in the United States, other
countries, or both:
AIX
BladeCenter
e (logo)
eServer
ESCON
ES/9000
FICON
FlashCopy
IBM
IBM logo
I5/OS
Micro Channel
Multiprise
Netfinity
OS/390
OS/400
Redbooks
RS/6000
S/390
S/390 Parallel Enterprise Server
SP
System i
System p
System Storage
System x
System z
TotalStorage
VSE/ESA
xSeries
z/OS
z/VM
Microsoft and Windows are trademarks of Microsoft Corporation in the United States, other countries, or both.
Java and all Java-based trademarks are trademarks of Sun Microsystems, Inc. in the United States, other countries, or
both.
UNIX is a registered trademark of The Open Group in the United States and other countries.
Other company, product, or service names may be trademarks or service marks of others.
Table of Contents
ESS
…………………………………………………………………………………………..……Page 3
DS8000
DS6000
DS4000
Tape
NAS
What has changed?
Notes:
…………………………………………………………………………………………….Page 8
…………………………………………………………………………………………….Page 13
…………………………………………………………………………………………….Page 18
………………………………………………………………………………………………..Page 23
………………………………………………………………………………………………...Page 30
1. Updated NX-OS support with 4.2(3)
2. Updated Fabric Manager support with 4.2(3a)
3. Updated BladeCenter Cisco FCSM support with 3.3(4a)
4. NX-OS support for 4.2(3) will include p6 support for both System i and p.
5. Support for I/O Acceleration
1. The MDS 9506/9509/9513 Multilayer Directors and MDS 9216i/9222i/9124/9134 Fabric Switches latest firmware
level is 4.2(3). The latest FICON or Intermix fabrics firmware level is 4.2(1b). SAN-OS Release notes are found
http://www.cisco.com/en/US/products/ps5989/prod_release_notes_list.html
2. Installation and upgrade information:
http://www.cisco.com/en/US/products/hw/ps4159/ps4358/prod_installation_guides_list.html
3. Product datasheets:
http://www.cisco.com/en/US/products/hw/ps4159/ps4358/products_data_sheets_list.html
4. Configuration Guides:
http://www.cisco.com/en/US/products/ps5989/products_installation_and_configuration_guides_list.html
5. Maximum ISLs (physical hops): 7 (maximum 1 Longwave ISL)
6. Blade module information: http://www.cisco.com/en/US/products/ps5991/prod_models_home.html
7. Technical support on SAN Volume Controller (SVC) can be found at: http://www-
03.ibm.com/systems/storage/software/virtualization/svc/index.html
8. This SAN product line can not attach to public telecom networks and is not intended to attach to public telecom
networks
9. Note - Customers that do not require an upgrade to NX-OS 4.2(3), but require field updates, may install SAN-OS
3.3(4a). FICON customers that do not require an upgrade to NX-OS 4.2(1b), but require field updates may install
SAN-OS 3.3(1c)
10. The MDS 9216, 9216A and Supervisor-1 are not NX-OS compatible. SAN-OS 3.3.4a must be used.
Cisco MDS 9000 for IBM System Storage Interoperability Matrix Page 2 of 37
ESS Connectivity
1. Please see IBM TotalStorage Enterprise Storage Server Interoperability Matrix
Internal Code (LIC) level.
2. For PPRC FC Direct, FC-CWDM and FCIP support see table 4 of ESS Interoperability Matrix.
for Licensed
IBM System z Models
Description Operating Systems Additional Information
IBM TotalStorage Enterprise
Storage Servers
IBM 2105 Model
• 750
• 800
• F10/F20
IBM z/OS level 1.4.1 or later
Available
Cascading: Maximum of 1
hop (Inter Switch Links) is
supported.
Taking the CUP off-line prior
to a concurrent software
update.
zSeries I/O Connectivity
1
IBM System z
Description Operating Systems Additional Information
IBM TotalStorage Enterprise
Storage Servers
IBM 2105 Model
• 750
• 800
• F10/F20
1
When the Cisco switch is to be used in a FICON/Open intermixed environment, the user should manage
the fabric from the Cisco Device and Fabric Managers. Disable host port control with the following
procedure.
From the switch Device Manager Window:
1. Go to FICON ->
2. Select VSANs ->
3. Find "Port Control by", then Uncheck the left hand side box labeled "Host"
The user still has the capability of using IBM's SA OS/390 application for viewing the FICON related
portions of the fabric.
It is recommended that network-admin privilege be strictly controlled.
UnitedLinux (FCP)
SLES (FCP)
RedHat EL (FCP)
Available.
Cisco MDS 9000 for IBM System Storage Interoperability Matrix Page 3 of 37
IBM System p Servers
Description Operating Systems Additional Information
IBM TotalStorage Enterprise
Storage Servers
IBM 2105 Model
• 750
• 800
• F10/F20
IBM System i Servers
Description Platform/Operating Systems Additional Information
IBM TotalStorage Enterprise
Storage Servers
IBM 2105 Model
• 750
• 800
• F10/F20
AIX 5L
HACMP
Linux
• SuSE Linux Enterprise Server
• Red Hat Enterprise Linux
OS/400
Linux
Available.
IBM TotalStorage Enterprise
Storage Server Interoperability
Matrix
Available.
Available.
IBM TotalStorage Enterprise
Storage Server
Interoperability Matrix
System i SAN information
Cisco MDS 9000 for IBM System Storage Interoperability Matrix Page 4 of 37
IBM System x and other Intel-based Servers
Description Operating Systems Additional Information
IBM TotalStorage Enterprise
Storage Servers
IBM 2105 Model
• 750
• 800
• F10/F20
Microsoft Windows
Novell Netware
Red Hat Enterprise Linux
SuSE Linux Enterprise Server
(SLES)
UnitedLinux
Available.
IBM TotalStorage Enterprise
Storage Server Interoperability
Matrix
IBM Server Proven
Interoperability matrix
Available.
Available.
Cisco MDS 9000 for IBM System Storage Interoperability Matrix Page 5 of 37
SUN Microsystems Servers
Description Operating Systems Additional Information
IBM TotalStorage Enterprise
Storage Servers
IBM 2105 Model
• 750
• 800
• F10/F20
Solaris
Hewlett-Packard Servers – HP- UX
Description Operating Systems Additional Information
IBM TotalStorage Enterprise
Storage Servers
IBM 2105 Model
• 750
• 800
• F10/F20
HP-UX
Available.
IBM TotalStorage Enterprise
Storage Server Interoperability
Matrix
Available.
IBM TotalStorage Enterprise
Storage Server Interoperability
Matrix
.
Cisco MDS 9000 for IBM System Storage Interoperability Matrix Page 6 of 37
DS8000 Connectivity
Please see IBM TotalStorage DS 8000 Interoperability Matrix
1. For Licensed Internal Code (LIC) level.
2. For PPRC FC Direct, FC-CWDM and FCIP support see table 4 of DS8000 Interoperability Matrix.
IBM System z
Description Operating Systems Additional Information
IBM TotalStorage DS 8000
Series
IBM Model
• 8100 Model 921
• 8300 Model 922
• 8300 Model 9A2
IBM z/OS level 1.4.1 or later
Available
Cascading: Maximum of 1
hop (Inter Switch Links) is
supported.
Taking the CUP off-line prior
to a concurrent software
update.
zSeries I/O Connectivity
2
IBM System z
Description Operating Systems Additional Information
IBM TotalStorage DS 8000
Series
IBM Model
• 8100 Model 921
• 8300 Model 922
• 8300 Model 9A2
2
When the Cisco switch is to be used in a FICON/Open intermixed environment, the user should manage
the fabric from the Cisco Device and Fabric Managers. Disable host port control with the following
procedure.
From the switch Device Manager Window:
1. Go to FICON ->
2. Select VSANs ->
3. Find "Port Control by", then Uncheck the left hand side box labeled "Host"
The user still has the capability of using IBM's SA OS/390 application for viewing the FICON related
portions of the fabric.
It is recommended that network-admin privilege be strictly controlled.
UnitedLinux (FCP)
SLES (FCP)
RedHat EL (FCP)
Available.
Cisco MDS 9000 for IBM System Storage Interoperability Matrix Page 7 of 37
IBM System p Servers
Description Operating Systems Additional Information
IBM TotalStorage DS 8000
Series
IBM Model
• 8100 Model 921
• 8300 Model 922
• 8300 Model 9A2
AIX
HACMP
RHELppc
SUSEppc
Available.
IBM TotalStorage DS 8000
Interoperability Matrix
Available.
Cisco MDS 9000 for IBM System Storage Interoperability Matrix Page 8 of 37
IBM System i Servers
Description Platform/Operating Systems Additional Information
IBM TotalStorage DS 8000
Series
IBM Model
• 8100 Model 921
• 8300 Model 922
• 8300 Model 9A2
IBM System i Models
OS/400
I5/OS
Linux
Available.
IBM TotalStorage DS 8000
Interoperability Matrix
System i SAN information
Cisco MDS 9000 for IBM System Storage Interoperability Matrix Page 9 of 37
IBM System x, and other Intel-based Servers
Description Operating Systems Additional Information
IBM TotalStorage DS 8000
Series
IBM Model
• 8100 Model 921
• 8300 Model 922
• 8300 Model 9A2
Microsoft Windows
Novell Netware
Red Hat Enterprise Linux
SuSE Linux Enterprise Server
(SLES)
UnitedLinux
Available.
IBM TotalStorage DS 8000
Interoperability Matrix
IBM Server Proven
Interoperability matrix
Available.
Available.
Cisco MDS 9000 for IBM System Storage Interoperability Matrix Page 10 of 37
SUN Microsystems Servers
Description Operating Systems Additional Information
IBM TotalStorage DS 8000
Series
IBM Model
• 8100 Model 921
• 8300 Model 922
• 8300 Model 9A2
Solaris
Hewlett-Packard Servers – HP- UX
Description Operating Systems Additional Information
IBM TotalStorage DS 8000
Series
IBM Model
• 8100 Model 921
• 8300 Model 922
• 8300 Model 9A2
HP-UX
Available.
IBM TotalStorage DS 8000
Interoperability Matrix
Available.
IBM TotalStorage DS 8000
Interoperability Matrix
Cisco MDS 9000 for IBM System Storage Interoperability Matrix Page 11 of 37
DS6000 Connectivity
Please see IBM TotalStorage DS 6000 Interoperability Matrix
3. For Licensed Internal Code (LIC) level.
4. For PPRC FC Direct, FC-CWDM and FCIP support see table 4 of DS6000 Interoperability Matrix.
IBM System z Models
Description Operating Systems Additional Information
IBM TotalStorage DS 6000
Series
IBM 1750 Model
• DS 6800
IBM z/OS level 1.4.1 or later
Available
Cascading: Maximum of 1
hop (Inter Switch Links) is
supported.
Taking the CUP off-line prior
to a concurrent software
update.
zSeries I/O Connectivity
3
IBM System z
Description Operating Systems Additional Information
IBM TotalStorage DS 6000
Series
IBM 1750 Model
• DS 6800
UnitedLinux (FCP)
4
Available.
3
When the Cisco switch is to be used in a FICON/Open intermixed environment, the user should manage
the fabric from the Cisco Device and Fabric Managers. Disable host port control with the following
procedure.
From the switch Device Manager Window:
1. Go to FICON ->
2. Select VSANs ->
3. Find "Port Control by", then Uncheck the left hand side box labelled "Host"
The user still has the capability of using IBM's SA OS/390 application for viewing the FICON related
portions of the fabric.
It is recommended that network-admin privilege be strictly controlled.
4
SLES 8 for IBM zSeries 32-bit and 64-bit Server
Cisco MDS 9000 for IBM System Storage Interoperability Matrix Page 12 of 37
IBM System p Servers
Description Operating Systems Additional Information
IBM TotalStorage DS 6000
Series
IBM 1750 Model
• DS 6800
AIX 5L
HACMP
Linux
Available.
IBM TotalStorage DS 6000
Interoperability Matrix
Available.
Cisco MDS 9000 for IBM System Storage Interoperability Matrix Page 13 of 37
IBM System i Servers
Description Platform/Operating Systems Additional Information
IBM TotalStorage DS 6000
Series
IBM 1750 Model
• DS 6800
OS/400
Linux
Available.
IBM TotalStorage DS 6000
Interoperability Matrix
System i SAN information
Cisco MDS 9000 for IBM System Storage Interoperability Matrix Page 14 of 37
IBM System x and other Intel-based Servers
Description Operating Systems Additional Information
IBM TotalStorage DS 6000
Series
IBM 1750 Model
• DS 6800
Microsoft Windows
Novell Netware
Red Hat Enterprise Linux
SuSE Linux Enterprise Server
(SLES)
UnitedLinux
Available.
IBM TotalStorage DS 6000
Interoperability Matrix
IBM Server Proven
Interoperability matrix
Available.
Available.
Cisco MDS 9000 for IBM System Storage Interoperability Matrix Page 15 of 37
SUN Microsystems Servers
Description Operating Systems Additional Information
IBM TotalStorage DS 6000
Series
IBM 1750 Model
• DS 6800
Solaris
Hewlett-Packard Servers – HP- UX
Description Operating Systems Additional Information
IBM TotalStorage DS 6000
Series
IBM 1750 Model
• DS 6800
HP-UX
Available.
IBM TotalStorage DS 6000
Interoperability Matrix
Available.
IBM TotalStorage DS 6000
Interoperability Matrix
Cisco MDS 9000 for IBM System Storage Interoperability Matrix Page 16 of 37
DS4000 Connectivity
For the most current supported HACMP, PSSP, GPFS/RVSD configurations see the important notices and
Readme files posted on each DS4000 product website.
IBM System p
Description Operating Systems Additional Information
IBM TotalStorage Storage
Servers
• DS4800
• DS4700
• DS4500
• DS4400
• DS4300
• Dual Controller
• Turbo
• DS4200
• DS4100
AIX 5L
HACMP, PSSP (see note #0
page 17)
Red Hat Enterprise Linux PPC
SuSE Linux Enterprise Server
(SLES) PPC
Available.
IBM TotalStorage DS 4000
Storage Interoperability matrix
IBM Server Proven
Interoperability matrix
Available.
Cisco MDS 9000 for IBM System Storage Interoperability Matrix Page 17 of 37
IBM System x and other Intel-based Servers
Description Operating Systems Additional Information
IBM TotalStorage Storage
Servers
• DS4800
• DS4700
• DS4500
• DS4400
• DS4300
• Dual Controller
• Turbo
• DS4200
• DS4100
Microsoft Windows
Novell Netware
Red Hat Enterprise Linux
SuSE Linux Enterprise Server
(SLES)
UnitedLinux
Available.
IBM TotalStorage DS 4000
Storage Interoperability matrix
IBM Server Proven
Interoperability matrix
Available.
Available.
Cisco MDS 9000 for IBM System Storage Interoperability Matrix Page 18 of 37
SUN Microsystems Servers
Description Operating Systems Additional Information
IBM TotalStorage Storage
Servers
• DS4800
• DS4700
• DS4500
• DS4400
• DS4300
• Dual Controller
• Turbo
• DS4200
• DS4100
Solaris
Hewlett-Packard Servers – HP- UX
Description Operating Systems Additional Information
IBM TotalStorage Storage
Servers
• DS4800
• DS4700
• DS4500
• DS4400
• DS4300
• Dual Controller
• Turbo
• DS4200
• DS4100
HP-UX
Available.
IBM TotalStorage DS 4000
Storage Interoperability matrix
IBM Server Proven
Interoperability matrix
Available.
IBM TotalStorage DS 4000
Storage Interoperability matrix
IBM Server Proven
Interoperability matrix
Cisco MDS 9000 for IBM System Storage Interoperability Matrix Page 19 of 37
DS5000 Connectivity
For the most current supported HACMP, PSSP, GPFS/RVSD configurations see the important notices and
Readme files posted on each DS4000 product website.
IBM System p
Description Operating Systems Additional Information
IBM TotalStorage Storage
Servers
• DS5100
• DS5300
AIX
HACMP, PSSP (see note #0
page 17)
Linux
RHELppc
SUSEppc
Available.
ADD DS5k Interop Matrix
Available.
Cisco MDS 9000 for IBM System Storage Interoperability Matrix Page 20 of 37
IBM System x and other Intel-based Servers
Description Operating Systems Additional Information
IBM TotalStorage Storage
Servers
• DS5100
• DS5300
Microsoft Windows
Novell Netware
Red Hat Enterprise Linux
United Linux
Available.
IBM TotalStorage DS 4000
Storage Interoperability matrix
IBM Server Proven
Interoperability matrix
Available.
Available.
Cisco MDS 9000 for IBM System Storage Interoperability Matrix Page 21 of 37
SUN Microsystems Servers
Description Operating Systems Additional Information
IBM TotalStorage Storage
Servers
• DS4800
• DS4700
• DS4500
• DS4400
• DS4300
• Dual Controller
• Turbo
• DS4200
Solaris
Hewlett-Packard Servers – HP- UX
Description Operating Systems Additional Information
IBM TotalStorage Storage
Servers
• DS4800
• DS4700
• DS4500
• DS4400
• DS4300
• Dual Controller
• Turbo
• DS4200
HP-UX
Available.
IBM TotalStorage DS 4000
Storage Interoperability matrix
IBM Server Proven
Interoperability matrix
Available.
IBM TotalStorage DS 4000
Storage Interoperability matrix
IBM Server Proven
Interoperability matrix
Cisco MDS 9000 for IBM System Storage Interoperability Matrix Page 22 of 37
IBM System p Servers
Description Operating Systems Additional Information
IBM TotalStorage Storage
Servers
• FAStT500
• FAStT200
IBM System x
and other Intel-based Servers
Description Operating Systems Additional Information
IBM TotalStorage Storage
Servers
• FAStT500
• FAStT200
AIX 5L
HACMP, PSSP (see note #0
page 17)
Linux
Microsoft Windows 2000
Microsoft Windows 2003
Red Hat Enterprise Linux
United Linux 1.0
Available.
IBM TotalStorage FAStT Storage
Interoperability matrix
Available.
Available.
IBM TotalStorage FAStT Storage
Interoperability matrix
IBM Server Proven
Interoperability matrix
Available.
Cisco MDS 9000 for IBM System Storage Interoperability Matrix Page 23 of 37
SUN microsystems Servers
Description Operating Systems Additional Information
IBM TotalStorage Storage
Servers
• FAStT500
• FAStT200
Solaris
Hewlett-Packard Servers – HP- UX
Description Operating Systems Additional Information
IBM TotalStorage Storage
Servers
• FAStT500
• FAStT200
HP-UX
Available.
IBM TotalStorage FAStT Storage
Interoperability matrix
IBM Server Proven
Interoperability matrix
Available.
IBM TotalStorage FAStT Storage
Interoperability matrix
IBM Server Proven
Interoperability matrix
Cisco MDS 9000 for IBM System Storage Interoperability Matrix Page 24 of 37
IBM XIV System Storage Connectivity
Please see IBM XIV System Storage Interoperability Matrix
IBM System z
Description Operating Systems Additional Information
IBM System Storage XIV
IBM Model
• XIV 2810
• XIV 2812
IBM z/OS level 1.4.1 or later
IBM System z
Description Operating Systems Additional Information
IBM System Storage XIV
IBM Model
• XIV 2810
• XIV 2812
UnitedLinux (FCP)
SLES (FCP)
RedHat EL (FCP)
Cascading: Maximum of 1
hop (Inter Switch Links) is
supported.
Taking the CUP off-line prior
to a concurrent software
update.
zSeries I/O Connectivity
Available.
Cisco MDS 9000 for IBM System Storage Interoperability Matrix Page 25 of 37
IBM System p Servers
Description Operating Systems Additional Information
IBM System Storage XIV
IBM Model
• XIV 2810
• XIV 2812
AIX 6.1 ML2
AIX 5.3 ML 8
HACMP
Linux
Available.
IBM XIV System Storage
Interoperability Matrix
Available.
Cisco MDS 9000 for IBM System Storage Interoperability Matrix Page 26 of 37
Cisco MDS 9000 for IBM System Storage Interoperability Matrix Page 27 of 37
IBM System x, and other Intel-based Servers
Description Operating Systems Additional Information
IBM System Storage XIV
IBM Model
• XIV 2810
• XIV 2812
Microsoft Windows 2000
Microsoft Windows 2000 (64
bit)
Microsoft Windows 2003
Microsoft Windows 2003 (64
bit)
Novell Netware
Red Hat Enterprise Linux
SuSE Linux Enterprise Server
(SLES)
UnitedLinux
Available.
IBM XIV System Storage
Interoperability Matrix
IBM Server Proven
Interoperability matrix
Available.
Available.
Cisco MDS 9000 for IBM System Storage Interoperability Matrix Page 28 of 37
TAPE Connectivity
IBM 9672 Enterprise G5, G6 and System z
Description Operating Systems Additional Information
IBM TotalStorage Enterprise
Tape Controller 3592 Model
J70, E06
FICON Attachment Longwave:
• FC-3434 (2 Gb)
Shortwave:
FC-3435 (2 Gb)
IBM TotalStorage Enterprise
Automated Tape Library 3494
IBM TotalStorage Virtual Tape
Server 3494-B10/B20 in
Standalone or Peer to Peer
configurations
IBM 9672 Enterprise
G5 or G6 and zSeries Servers
5
Available.
Cascading: Maximum of 1 hop
(Inter Switch Links) is supported.
Taking the CUP off-line prior to a
concurrent software update.
IBM TotalStorage Enterprise
Tape Drive Frame 3590 Model
A14
IBM TotalStorage Silo
Compatible Tape Drive Frame
5
When the Cisco switch is to be used in a FICON/Open intermixed environment, the user should manage
the fabric from the Cisco Device and Fabric Managers. Disable host port control with the following
procedure.
From the switch Device Manager Window:
1. Go to FICON ->
2. Select VSANs ->
3. Find "Port Control by", then Uncheck the left hand side box labelled "Host"
The user still has the capability of using IBM's SA OS/390 application for viewing the FICON related
portions of the fabric.
It is recommended that network-admin privilege be strictly controlled.
Cisco MDS 9000 for IBM System Storage Interoperability Matrix Page 29 of 37
IBM System z
Description Operating Systems Additional Information
Enterprise Tape System
3592
J1A, E06 in a 3494 or
3584 Tape Library.
Enterprise Tape System
3590
E11/E1A and H11/H1A
with Native FC Tape Drives.
Standalone or in a 3494 Tape
Library.
Enterprise Tape System
TS1120
All 3494 rules apply.
i.e. ESCON/FICON owned
drives cannot co-exist in the
same frame as Open Systems
drives.
TS3310
Native Ultrium 3 drives
TS3400 Tape Library with
TS1120 tape drives
TS3500 Tape Library with LTO
4
Ultrium 3584
Tape Library with Native FC
Ultrium 2, 3, and 4 drives
Ultrium 3583
Library with Native FC Ultrium
2, 3, and 4 drives
Ultrium 3582
with Native FC Ultrium 2, 3,
and 4 drives
Ultrium 3581-2U
Tape Autoloader
Virtualization Engine TS
7510 and TS7520
(3952 E05) tape drive.
Tape Library with
UltraScalable
Scalable Tape
Tape Library
IBM LTO
SLES 8 for IBM zSeries 32bit and 64-bit Server
Available.
zSeries Support of Fibre
Channel FCP Channels
Cisco MDS 9000 for IBM System Storage Interoperability Matrix Page 30 of 37
IBM System p Servers
Description Operating Systems Additional Information
Enterprise Tape System 3592
J1A, E06 in a 3494 or 3584 Tape
Library, rack mounted or Silo
Compatible Frame.
Enterprise Tape System 3590
E11/E1A and H11/H1A with
Native FC Tape Drives.
Standalone or in a 3494 Tape
Library or Silo Compatible Frame.
Enterprise Tape System TS1120
(3952 E05) tape drive.
TS3310
Ultrium 3 drives
TS3400 Tape Library with
TS1120 tape drives
TS3500 Tape Library with LTO 4
Ultrium 3584
Library with Native FC Ultrium 2,
3, and 4 drives
Ultrium 3583
Library with Native FC Ultrium 2,
3, and 4 drives
Ultrium 3582
Native FC Ultrium 2, 3, and 4
drives
Ultrium 3581-2U
Autoloader
Tape Library with Native
UltraScalable Tape
Scalable Tape
Tape Library with
IBM LTO Tape
AIX
Red Hat Enterprise Linux PPC
SuSE Linux Enterprise Server
(SLES) PPC
Available.
Please review
RMSS Technical Support
Available.
Site.
Virtualization Engine TS 7510
and TS7520
Cisco MDS 9000 for IBM System Storage Interoperability Matrix Page 31 of 37
IBM System i Servers
Description Platform/Operating Systems Additional Information
Enterprise Tape System
3592
J1A, E06 in a 3494 or
3584 Tape Library or rack
mounted.
Enterprise Tape System
3590
E11/E1A and H11/H1A
with Native FC Tape Drives.
Standalone or in a 3494 Tape
Library.
Enterprise Tape System
TS1120
(3952 E05) tape drive.
OS/400
I5/OS
Linux
6
Available.
System i SAN information
.
Please review
RMSS Technical Support
Site.
TS3310
Tape Library with
Native Ultrium 3 drives
TS3400 Tape Library with
TS1120 tape drives
TS3500 Tape Library with LTO
4
Ultrium 3584
UltraScalable
Tape Library with Native FC
Ultrium 2, 3, and 4 drives
Ultrium 3583
Scalable Tape
Library with Native FC Ultrium
2, 3, and 4 drives
Ultrium 3582
Tape Library
with Native FC Ultrium 2, 3,
and 4 drives
Ultrium 3581-2U
IBM LTO
Tape Autoloader
Virtualization Engine TS
7510 and TS7520
6
Required PTF MF32002
Cisco MDS 9000 for IBM System Storage Interoperability Matrix Page 32 of 37
IBM System x and other Intel-based Servers
Description Operating Systems Additional Information
Enterprise Tape System 3592
J1A, E06 in a 3494 or 3584 Tape
Library, rack mounted or Silo
Compatible Frame.
Enterprise Tape System 3590
E11/E1A and H11/H1A with
Native FC Tape Drives.
Standalone or in a 3494 Tape
Library or Silo Compatible Frame.
Enterprise Tape System TS1120
(3952 E05) tape drive.
TS3310
Ultrium 3 drives
TS3400 Tape Library with
TS1120 tape drives
TS3500 Tape Library with LTO 4
Ultrium 3584
Library with Native FC Ultrium 2,
3, and 4 drives
Ultrium 3583
Library with Native FC Ultrium 2,
3, and 4 drives
Ultrium 3582
Native FC Ultrium 2, 3, and 4
drives
Ultrium 3581-2U
Autoloader
Tape Library with Native
UltraScalable Tape
Scalable Tape
Tape Library with
IBM LTO Tape
Microsoft Windows
Red Hat Enterprise Linux
SuSE Linux Enterprise Server
(SLES)
United Linux 1.0
Available.
IBM Server Proven
Interoperability matrix
Please review
RMSS Technical Support
Site.
Available.
Please review
RMSS Technical Support
Site.
Virtualization Engine TS 7510
and TS7520
Cisco MDS 9000 for IBM System Storage Interoperability Matrix Page 33 of 37
SUN Microsystems Servers
Description Operating Systems Additional Information
Enterprise Tape System 3592
J1A, C06 in a 3494 or 3584 Tape
Library, rack mounted or Silo
Compatible Frame.
Enterprise Tape System 3590
E11/E1A and H11/H1A with
Native FC Tape Drives.
Standalone or in a 3494 Tape
Library or Silo Compatible Frame.
Enterprise Tape System TS1120
(3952 E05) tape drive.
TS3310
Ultrium 3 drives
TS3400 Tape Library with
TS1120 tape drives
TS3500 Tape Library with LTO 4
Ultrium 3584
Library with Native FC Ultrium 2,
3, and 4 drives
Ultrium 3583
Library with Native FC Ultrium 2,
3, and 4 drives
Ultrium 3582
Native FC Ultrium 2, 3, and 4
drives
Ultrium 3581-2U
Autoloader
Tape Library with Native
UltraScalable Tape
Scalable Tape
Tape Library with
IBM LTO Tape
Solaris
Available.
Please review
RMSS Technical Support
Site.
Virtualization Engine TS 7510
and TS7520
Cisco MDS 9000 for IBM System Storage Interoperability Matrix Page 34 of 37
Hewlett-Packard Servers – HP- UX
Description Operating Systems Additional Information
Enterprise Tape System 3592
J1A, C06 in a 3494 or 3584 Tape
Library, rack mounted or Silo
Compatible Frame.
Enterprise Tape System 3590
E11/E1A and H11/H1A with
Native FC Tape Drives.
Standalone or in a 3494 Tape
Library or Silo Compatible Frame.
Enterprise Tape System TS1120
(3952 E05) tape drive.
TS3310
Ultrium 3 drives
TS3400 Tape Library with
TS1120 tape drives
TS3500 Tape Library with LTO 4
Ultrium 3584
Library with Native FC Ultrium 2,
3, and 4 drives
Ultrium 3583
Library with Native FC Ultrium 2,
3, and 4 drives
Ultrium 3582
Native FC Ultrium 2, 3, and 4
drives
Ultrium 3581-2U
Autoloader
Tape Library with Native
UltraScalable Tape
Scalable Tape
Tape Library with
IBM LTO Tape
HP-UX
Available.
Please see the readme
any restrictions.
Please review
RMSS Technical Support
Site.
file for
Virtualization Engine TS 7510
and TS7520
Cisco MDS 9000 for IBM System Storage Interoperability Matrix Page 35 of 37
NETWORK ATTACHED STORAGE (NAS)
Cisco MDS 9506, 9509, 9513, 9216i, 9216i, 9222i*, and 9134* for IBM System Storage
Directors and Switches are interoperable with:
N series models – Supported with SAN-OS 2.1(2b) and above
NAS and N series Gateways – Supported with SAN-OS 2.1(2b) and above
*Denotes products must run SAN-OS 3.x or above
IBM eServer Blade Center (BC)
Information on interoperability and Technical Support can be found at IBM eServer Blade Center.
Description Blade Switch
Module Firmware
Cisco 10/20 port FCSM* 4.2 (1b) 4.2(3)
4GB Qlogic Intelligent
6.5.0.21.0 4.2(3)
Pass-Thru
Optical Pass-Thru Module N/A 4.2(3)
*Notes
NPV and NPIV is supported with fw 3.2 and above
Cisco MDS 9000
SAN Family
Heterogeneous SAN support
For information regarding heterogeneous SAN support please use the following:
http://www.cisco.com/en/US/docs/switches/datacenter/mds9000/interoperability/matrix/Matrix4.html#wp299
210
Supported Distance / Extension Methods
Traffic / Application
regular FICON traffic FC ISLs with DWDM 300km
regular FICON traffic CWDM FC ISLs 100km
regular FICON traffic FCIP ISLs 300km
IBM VTS (host to VTC connection) FC ISLs with DWDM 250km
IBM VTS (VTC to VTS connection) FC ISLs with DWDM 250km
IBM Enterprise and LTO Tape all 300km*
IBM XRC FICON FC ISLs with DWDM 200km
IBM XRC FICON CWDM FC ISLs 200km
IBM XRC FICON FCIP ISLs 200km
* IBM 3592 drives with Control Units C06 and J70 supported up to 3000km when Cisco FICON Tape
Acceleration is enabled
Extension Method Supported Distance
Cisco MDS 9000 for IBM System Storage Interoperability Matrix Page 36 of 37
Loading...
