IBM System x3200
Entry server for retail, file and print or network infrastructure
applications
Get it now
go to ibm.com/systems/uk/x/ or call
IBM at 0870 010 2508
to buy direct or to locate an IBM reseller
Highlights
■
Affordable uni-processor tower
server for medium-sized
businesses or distributed large
enterprises
■
More availability and
management features than
other systems in its class
■
Quad-core and dual-core Intel
®
Xeon®processors deliver high
performance.
The IBM System x3200 can help lower
your IT costs throughout its business
lifecycle. The x3200 is not only
affordable to purchase, but it’s also
easy to manage and keep up to date.
Keep your business in business
With unprecedented system availability,
the x3200 can help you maximise
uptime for your file and print or network
infrastructure applications. Select Serial
Advanced Technology Attachment
(SATA), near-line SATA or Serial
Attached SCSI (SAS) hard disk drives
(HDDs) depending on your reliability
requirements. If a HDD or power supply
fails, the x3200 can stay up and
running with redundant power supplies
and hot-swap SATA and SAS HDDs.
Protect your data, your investment
Standard on select models, integrated
hardware RAID-0 or -1 provides
protection for your business-critical
data. Optional upgrades to RAID-5 or
tape backup solutions are also
available.
Manage your growth
The x3200 helps minimise management
costs for distributed or remote
applications. It supports industry-
standard, IPMI-based systems
management and the IBM Remote
Supervisor Adapter (RSA) II for
advanced hardware management –
enabling your IT staff to do more
with less.
IBM System x3200 at a glance
Form factor/height
Tower/5U
Processor (level 2
(L2) cache/CPU GHz/front-side
bus MHz max)
Quad-Core Intel Xeon (2x4MB/2.13 GHz/1066 MHZ), Dual-Core
Intel Xeon (4MB/up to 2.4 GHz/1066 MHz), Intel Pentium®D
(dual-core) (2x2MB/up to 3.4 GHz/800 MHz) or Intel
Pentium 4 (1MB/3.2 GHz/800 MHz)
Number of processors (std/max)
1/1
Memory1(max)
Up to 8GB double data rate (DDR) II 667 MHz
Expansion slots
3 PCI and 2 PCI-Express (x8, x1)
Dedicated RSA II slot
Slotless hardware RAID-0, -1
Disk bays (total/hot-swap)
Four 3.5" simple-swap or hot-swap SATA HDDs or four 2.5" or
3.5" hot-swap SAS HDDs
Maximum internal storage
1,2
Up to 1.2TB SAS HDDs or up to 3.0TB SATA HDDs
Network interface
Integrated Gigabit Ethernet (GbE)
Power supply (std/max)
400W 1/1 or 430W hot-swap redundant 2/2 (model
dependent)
Hot-swap components
HDDs, power supplies (model dependent)
RAID support
Integrated hardware RAID-0, -1 (model dependent)
Optional upgrade to RAID-5 and RAID-6
Ports
Front: Two USB
Rear: Four USB; one Ethernet; two serial; one parallel; keyboard
and mouse
Systems management
IPMI 1.5-compliant mini-BMC, IBM Director, Alert Standard
Format 2.0, IBM ServerGuide, optional RSA II and optional
Remote Deployment Manager
Operating systems supported
Microsoft®Windows®Server 2003 Standard Edition/Enterprise
Edition, Windows Small Business Server 2003, Red Hat
Enterprise Linux®, SUSE Linux Enterprise Server, Novell
NetWare, IBM OS 4690
Limited warranty
3
One year or three year on-site limited warranty (model
dependent)
