Flexible functionality in a 1U server at a compact price
IBM System x3250 M3
The IBM® System x3250 M3 is a
Highlights
■
Maximize performance with the
latest Intel technology in a
robust, flexible platform
■
Achieve energy savings with
built-in power management
tools
■
Minimize risks with easy serv-
iceability and maintenance
single-socket server that offers new lev-
els of performance and flexibility to help
you respond quickly to changing busi-
ness demands. Cost-effective and
compact, it is well-suited for small to
mid-sized businesses as well as large
enterprises, whether for general-
purpose workloads or specialized
applications.
Amplify your performance
Built with the latest Intel® Xeon® 3400
Series processors, the x3250 M3 has
industry-leading computing capabilities
in a small, 1U footprint. It also offers
substantial memory and storage
capacity to help you manage your data
efficiently.
Save on energy costs
The x3250 M3 features support for
IBM Systems Director Active Energy
Manager™ to help you monitor and
control power consumption in your IT
environment. An option to upgrade to a
high-efficiency power supply is also
available.
Easy serviceability
To help you stay focused on your core
business, the x3250 M3 offers easy
deployment, update management and
much more with its built-in IBM Tool
Center. It delivers leadership reliability,
management and flexibility while helping
you protect your IT investments and
lower your operating costs.
Select configurations of the x3250 M3
are part of the IBM Express
Advantage™ Portfolio, designed to
meet the needs of mid-sized busi-
nesses. Easy to manage, Express™
models/configurations vary by country.
System x3250 M3 at a glance
Form factor/height
Rack/1U
Processor (CPU GHz/L3
Intel Xeon 3400 Series (quad-core) up to 2.93 GHz/8 MB/
cache/front-side bus MHz max)
1333 MHz
Number of processors (std/max)
1/1
Cache (max)
8 MB L3
Memory1(max)
Up to 32 GB DDR-3 ECC memory, up to 1333 MHz; 1 GB,
2 GB and 4 GB UDIMMs2; 1 GB, 2 GB, 4 GB and 8 GB
RDIMMs
2
Expansion slots
2 PCIe x8 Gen2, dedicated PCIe x4 for RAID-0, -1, optional
PCI-X
Disk bays (total/hot-swap)
Two 3.5" simple-swap SATA or 3.5" hot-swap SAS/SATA, or
four 2.5" hot-swap SAS HDDs
Maximum internal storage
1, 3
2.0 TB SATA or SAS
Network interface
Dual Gigabit Ethernet
Power supply (std/max)
351 W 1/1; optional high-efficiency power supply
Hot-swap components
Two 3.5" hot-swap SAS/SATA or four 2.5" hot-swap SAS HDDs
RAID support
Hot-swap hardware RAID-0, -1 (standard), simple swap
hardware RAID-0, -1 (optional); optional RAID-5 and
encryption RAID
Ports
Seven USB (2 front/4 rear/1 internal), two Ethernet, one serial
and video
Systems management
Integrated Management Module (IMM) with IPMI 2.0 and
Serial over LAN (SOL), IBM Systems Director, Alert Standard
Format 2.0, IBM ServerGuide, Virtual Media Key (hardware key
for optional remote presence), Trusted Platform Module
(TPM) 1.2
Operating systems supported
Microsoft® Windows Server 2008 Enterprise Edition,
Enterprise x64 Edition, Standard Edition, Standard x64 Edition,
Datacenter Edition, Datacenter x64 Edition, Windows® Small
Business Server 2008, Red Hat Linux®, SUSE Linux
Limited warranty
4
1-year or 3-year customer replaceable unit and onsite limited
warranty
World Wide Web
U.S. ibm.com/systems/x
Canada ibm.com/ca/en/systems/x
4
IBM hardware products are made from new
parts, or new and serviceable used parts.
Regardless, our warranty terms apply. For a
copy of applicable product warranties, write to:
Warranty Information, P.O. Box 12195, RTP,
NC 27709, Attn: Dept. JDJA/B203. IBM makes
no representation or warranty regarding thirdparty products or services including those
designated as ServerProven®.
© Copyright IBM Corporation 2009
IBM Systems and Technology Group
Route 100
Somers, New York 10589
September 2009
All Rights Reserved
This publication could include technical
inaccuracies or typographical errors. This
publication was produced in the United States.
IBM may not offer the products, services or
features discussed in this document in other
countries, and the information may be subject
to change without notice. References herein to
IBM products and services do not imply that
IBM intends to make them available in other
countries. Consult your local IBM business
contact for more information.
IBM, the IBM logo, ibm.com and System x are
trademarks or registered trademarks of
IBM Corporation in the United States, other
countries or both. If these and other
IBM trademarked terms are marked on their first
occurrence in this information with a trademark
symbol (® or ™), these symbols indicate U.S.
registered or common law trademarks owned
by IBM at the time this information was
published. Such trademarks may also be
registered or common law trademarks in other
countries. A current list of IBM trademarks is
available on the Web at ibm.com/legal/
copytrade.shtml.
Intel and Intel Xeon are trademarks or registered
trademarks of Intel Corporation or its
subsidiaries in the United States and other
countries.
Linux is a registered trademark of Linus Torvalds
in the United States, other countries or both.
Microsoft and Windows are registered
trademarks of Microsoft Corporation in the
United States, other countries or both.
Other company, product and service names
may be trademarks or service marks of others.
1
Maximum internal hard disk and memory
capacities may require the replacement of any
standard hard drives and/or memory and the
population of all hard disk bays and memory
slots with the largest currently supported drives
available. When referring to variable speed
CD-ROMs, CD-Rs, CD-RWs and DVDs, actual
playback speed will vary and is often less than
the maximum possible.
2
Maximum UDIMM support for 16 GB when
4 GB DIMMs are available 1Q 2010, and
maximum RDIMM support for 32 GB when
8 GB DIMMs are available 1Q 2010.
3
When referring to storage capacity,
GB = 1,000,000,000 bytes, and
TB = 1,000,000,000,000 bytes. Accessible
capacity is less.
