ISPLAY CAR SYSTEM l

(ATBB0G2AN_NOWIFI, ATBB0G7AN_NOWIFI, ADB41G2AN_NOWIFI)

미국/영어-English

USER'S MANUAL

Read the following safety cautions for your safety

Notations used within this User's Manual

Before using the product, read the contents of this user's manual

carefully and use this product safely.

※

The design and speciﬁ cations of this product may change without prior

notiﬁ cation for product and service improvement.

The actual features in the vehicle may differ from the illustrations.

For more accurate information about the vehicle, please refer to the

catalogue.

※

This Audio system contains open source software, including without

limitation, software distributed and/or modiﬁ ed under the GNU General

Public license, Version 2, June 1991, and the GNU lesser General Public

License, Version 2.1, February 1999.

For additional information and to obtain related materials including

without limitation, the previous referred to licenses and software, please

WARNING

• Failure to observe the instructions within this category could result in death

or serious injury or damage to the vehicle.

CAUTION

• Information on matters that could potentially lead to injury or vehicle

damage/malfunction Information that could lead to higher user safety

Information

• Information and tips that provide additional user convenience in using the

product

NOTICE

• Information on specific features that facilitate proper product use and

functional understanding

• Information on terminology used within this manual

Thank you for purchasing this multimedia system.

This user's manual explains how to use

the HYUNDAI Motor multimedia system. Before using the product, read the contents of this user's manual carefully and use this product safely.

•

The screens shown in this manual may differ with the actual screens of the product.

•

The design and specification of this product may change without prior notification for product improvement.

•

When transferring the vehicle to another individual, include this user's manual so that the next driver can continue its use.

Precaution for safe usage

•

Driving while distracted can result in a loss of vehicle control, that may lead to an accident, severe personal injury, and death. The driver’s primary responsibility is in the safe and legal operation of a vehicle, and use of any handheld devices, other equipment, or vehicle systems which take the driver’s eyes, attention and focus away from the safe operation of a vehicle or which are not permissible by law should never be used during operation of the vehicle.

•

Do not operate the while driving.

•

Do not disassemble, assemble, or modify the

multimedia system

•

Do not watch the screen for prolonged periods of time while driving.

•

Set the volume to a level which allows the driver to be aware of external conditions.

multimedia system

•

Do not operate the

multimedia system

prolonged periods of time with the vehicle ignition in ACC. Such operations may lead to battery discharge.

•

Be cautious not to spill water or introduce foreign objects into the device.

•

Do not cause severe shock to the device. Direct pressure onto the front side of the monitor may cause damage to the LCD or touch panel.

•

In case of product malfunction, please contact your place of purchase or service center.

•

When cleaning the touch screen, make sure to turn off the device and use a dry and smooth cloth. Never use tough materials, chemical cloths, or solvents (alcohol, ammonia, benzene, thinners, etc.) as such materials may damage the device panel or cause color and quality deterioration.

for

•

SiriusXM service requires a subscription, sold separately, after 3-month trial included with vehicle purchase. If you decide to continue your SiriusXM service at the end of your trial subscription, the plan you choose will automatically renew and bill at then-current rates until you call Sirius XM at 1-866-635-2349 to cancel. See our Customer Agreement for complete terms at www.siriusxm. com. Programming subject to change. Sirius satellite service is available only to those at least 18 and older in the 48 contiguous USA, D.C., and PR (with coverage limitations). Traffic information not available in all markets. See siriusxm.com/traffic for details. Sirius, XM and all related marks and logos are trademarks of Sirius XM Radio Inc.

WARNING

• Driving while distracted can result in a

loss of vehicle control that may lead to an accident, severe personal injury, and death. The driver’s primary responsibility is in the safe and legal operation of a vehicle, and use of any handheld devices, other equipment, or vehicle systems which take the driver’s eyes, attention and focus away from the safe operation of a vehicle or which are not permissible by law should never be used during operation of the vehicle.

iPod

iPod® is a registered trademark of Apple Inc.

Bluetooth®

The

Bluetooth

trademarks owned by

Wireless Technology

Wireless Technology word mark and logos are registered

Bluetooth

Wireless Technology SIG, Inc. and any

use of such marks by HYUNDAI is under license.

Bluetooth

Wireless Technology enabled cell phone is required to use

Wireless Technology.

Bluetooth

Wireless Technology phone

compatibility can be checked by visiting https://www.hyundaiusa.com/

luetooth.

HD Radio™ Technology

HD Radio™ Technology manufactured under license from iBiquity Digital

Corporation. U.S. and Foreign Patents.

HD Radio™ and the HD, HD Radio, and "Arc" logos are proprietary

trademarks of iBiquity Digital Corp.

Pandora

Pandora, the Pandora logo, and the Pandora trade dress are trademarks

or registered trademarks of Pandora Media, Inc. Used with permission.

Pandora is only available in certain countries. Please visit http://www.

pandora.com/legal for more information.

6 I Table of Contents

part.1

Component Names and Functions

Starting the System for the First Time

Basic

Warnings and Cautions

Key Product Features

Basic

Safety Warnings

•Do not stare at the screen while driving. Staring at the screen for prolonged periods of time could lead to traffic accidents.

•Do not disassemble, assemble, or modify the Multimedia system. Such acts could result in accidents, fire, or electric shock.

•Heed caution not to spill water or intro-

duce foreign objects into the device. Such acts could lead to smoke, fire, or product malfunction.

•If you use phone related functions while

driving, you will find it difficult to concentrate on operating the vehicle and the current traffic conditions, so the possibility of an accident may increase. Please use phone related functions only when parked.

•Please refrain from use if the screen is blank or no sound can be heard as these signs may indicate product malfunction. Continued use in such conditions could lead to accidents (fires, electric shock) or product malfunctions.

•Do not touch the antenna during thunder or lightening as such acts may lead to lightning induced electric shock.

•Do not stop or park in parking-restricted

areas to operate the product. Such acts could lead to traffic accidents.

•For most Audio and multimedia modes,

the display will not operate when the vehicle is in motion. For your safety, first park the vehicle to watch or view the screen.(The screen will only operate when the parking brake is ON for manual transmission vehicles and when the parking brake is ON or the gearshift is in the P (PARK) position for automatic.)

•Some functions other than the one mentioned above cannot be used while driving. These functions operate only when the vehicle is parked.

1-2 I Basic

Safety Cautions

Pay attention to traffic conditions while driving.

•Operating the device while driving could lead to accidents due to a lack of attention to external surroundings. First park the vehicle before operating the device. In addition, the touch screen may not work for some functions when the vehicle is in motion. The touch screen feature will be supported once the vehicle has stopped.

•Adjust the volume to levels that allow the driver to hear sounds from outside of the vehicle. Driving in a state where external sounds cannot be heard may lead to accidents.

•Pay attention to the volume setting when turning the device on. A sudden output of extreme volume upon turning the device on could lead to hearing impairment. (Adjust the volume to a suitable levels before turning off the device.)

•If you want to change the position of device installation, please inquire with your place of purchase or service maintenance center. Technical expertise is required to install or disassemble the device.

•Turn on the car ignition before using this device. Do not operate the Multimedia system for long periods of time with the ignition turned off as such operations may lead to battery discharge.

•Upon using the Multimedia system for more than 10 minutes with the car engine turned off, the following warning will be displayed. After 10 minutes, the warning will be displayed for 5 seconds every 1 minute.

•Do not subject the device to severe shock or impact. Direct pressure onto the front side of the monitor may cause damage to the LCD or touch screen.

•When cleaning the device, make sure to turn off the device and use a dry and smooth cloth. Never use tough materials, chemical cloths, or solvents(alcohol, benzene, thinners, etc.) as such materials may damage the device panel or cause color/quality deterioration. When experiencing product with y

our place of purchase or service

maintenance center.

•Prevent caustic solutions such as perfume and cosmetic oil from contacting the dashboard because they may cause damage or discoloration.

concerns, inquire

Warnings and Cautions I 1-3

Key Product Features

This device is a Multimedia system equipped with a multifunctional disc player that supports Radio (FM, AM), HD Radio™ technology, SiriusXM™, Audio CD, MP3, USB, iPod, AUX, Bluetooth Audio and My Music features. The WIDE VGA LCD provides a high quality resolution while the powerful and rich sound system adds to the driving enjoyment.

Wide TFT-LCD Display

Display

Radio

Multimedia

Player

•Provides high quality video through a Wide TFTLCD Display using an LED Back Light.

•Touch screen for maximum user convenience.

Digital Tuner Feature

•Digital Tuner using PPL method that supports memory of 12 broadcast stations for each AM and FM modes.

Radio broadcast station name

•Displays broadcast station names.

HD Radio™/Satellite Radio feature

•Supports HD Radio™ reception and Satellite Radio (SiriusXM™).

Support for various Media Formats

•Support for various media formats, including Radio, Audio CD, MP3, USB, iPod, AUX and Bluetooth

Audio Streaming modes

My Music

•Supports copying of music stored within USB devices into My Music (internal memory) mode

Miscellaneous

Bluetooth

Wireless Technology

•Convenient use of Bluetooth

Handsfree by

using buttons within the steering wheel control

Digital Screen Control Features

•Easy control of features through touch screen options

Steering Wheel Control

•Control over audio features, voice recognition and Bluetooth

through the steering wheel con-

trol for maximum convenience

1-4 I Basic

Component Names and Functions

Head Unit

Name Description

•When power is off, press to turn power on.

POWER/

VOL

TUNE

•When power is on, press and hold for over 0.8 seconds to turn the power off.

•When power is on, press shortly for less than

0.8 seconds to turn Audio off.

•Turn left/right to adjust the volume.

•FM/AM mode: Changes the frequency.

•SiriusXM™ mode: Changes the channel.

•MEDIA (Disc/USB/iPod/My Music) mode: Changes the track, file or title (except USB Image, Bluetooth Audio, and AUX).

Name Description

Converts to FM/AM/SiriusXM™ mode

RADIO

MEDIA

PHONE

•Each time the key is pressed, the mode is changed in the following order: FM → AM FM.

Moves to MEDIA mode.

•If the media is not connected or the CD player is not available for this model, the MEDIA mode will not be activated.

Displays the Bluetooth phone mode.

Component Names and Functions I 1-5

→

SiriusXM™

→

Head Unit

Name Description

When the key is pressed shortly (for less than 0.8 seconds),

•FM/AM mode:

Plays the previous/next frequency.

•SiriusXM™ mode: Changes the channel.

•MEDIA (Disc/USB/iPod/My Music) mode: Changes

SEEK

TRACK

the track, file or title (except for USB Image and

AUX). When the key is pressed and held down (for over 0.8 seconds),

•FM/AM mode:

Continuously changes the fre-

quency until the key is released.

•MEDIA (Disc/USB/iPod/My Music) mode: Rewinds or fast forwards the track or file (except for USB Image, Bluetooth Audio, and AUX).

1-6 I Basic

Name Description

APPS/

BLUELINK

SETUP

Moves to the Apps/Info screen.

Moves to the Blue Link mode.

Moves to the Setup screen.

Press to eject a disc.

DISP

RESET

Turns the screen on/off.

Resets the system settings. (Preset radio channels and other data will not be deleted)

Steering Wheel Control

Name Description

When pressed quickly. (less than 0.8 seconds)

•If Android Auto is not connected, activates the multimedia system voice recognition

•If Google voice recognition is activated, ends Google voice recognition

When pressed and held. (more than 0.8 seconds)

•If the multimedia system voice recognition is activated, ends the multimedia system voice recognition

•If Android Auto is connected, activates Google voice recognition

•If iOS device is connected through Bluetooth, activates or ends Siri Eyes Free

VOL+

VOL-

Controls the volume

When keys are pressed quickly. (less than 0.8 seconds)

•FM/AM mode : searches broadcast frequencies saved to Presets

•SiriusXM™ mode : searches broadcast channels saved to Presets

•MEDIA (Disc/USB/iPod/My Music) mode : changes the track, file or title (except USB Image, AUX)

When keys are pressed and held. (more than 0.8 seconds)

•FM/AM mode : automatically searches broadcast frequencies

•SiriusXM™ mode : automatically searches broadcast channels

•MEDIA (Disc/USB/iPod/My Music) mode : quickly looks up songs (excluding USB images, AUX and Bluetooth audio files)

Component Names and Functions I 1-7

Steering Wheel Control

Name Description

•Each time this key is pressed, mode is changed in the following order: FM → AM → SiriusXM Disc → USB or iPod → AUX → Bluetooth Audio

→

My Music → Android Auto → Pandora → FM

MODE

•If the media is not connected, the corresponding modes will be disabled

•Press and hold the key (more than 0.8 seconds) to turn the Audio system on/off

•When power is off, press the key to turn power back on

When pressed quickly. (less than 0.8 seconds)

•When pressed in the dial screen, makes a call

•When pressed in the incoming call screen, answers the call

•When pressed during call waiting, switches to waiting call (Call Waiting)

When pressed and held. (more than 0.8 seconds)

•When pressed in Bluetooth the last dialed call

•When pressed dur

ing a Bluetooth® Hands-free

call, switches call back to mobile phone (Private)

•When pressed while calling on the mobile phone, switches call back to Bluetooth (operates only when Bluetooth connected)

•When pressed during a call, ends the phone call

•When pressed in the incoming call screen, rejects the call

Hands-free, redials

Hands-free

Hands-free is

→

1-8 I Basic

※

The actual feature in the vehicle may differ from the illustration.

Starting the System for the First Time

Turning the System On/Off

Press the engine start button or set the ignition key to On or ACC. Each time you turn on the system, a boot logo and safety warning will appear.

NOTICE

• Cannot operate the system while it is booting

up. It may take some time for all of features of the system, particularly the voice recognition system, to be ready for use.

Pressing and holding the power key on the head unit will turn off the system. You can change Screen Saver Settings in Setup to display a clock on the Screen Saver.

Information

• If you turn off the system during a phone call

using the Hands-free feature, then the call will automatically switch to your mobile phone.

System Reset

The System Reset function restores the system when it is not operating correctly. Press and hold the ond or longer. (It is recommended that you press the

RESET

a pin or a clip.)

RESET

ey for a sec-

key using a tool, such as

Pressing the power key on the head unit will display the safety guide. To change the system language between English, French, Spanish and Korean press the

Language

button.

NOTICE

• Check the volume when turning on the

system. Before turning on the system, adjust the volume to a reasonable level.

NOTICE

• Resetting the system restores all existing

settings and configurations (e.g. volume, display, etc.) back to their factory defaults.

Starting the System for the First Time I 1-9

Battery Warning Message

Always use the system while the car engine is running. If you turn on the system while the engine is off, a battery warning message will appear. When the engine starts, the message will disappear.

NOTICE

• If you use the system for a long time with

the engine off, the battery may become completely discharged.

Restrictions on Features for Safety Measures

Several features are limited while driving. The restriction screen will disappear when shifting gears into P or putting the parking brake on.

1-10 I Basic

Home Screen

Controls Menu Conﬁ guration for the Home Screen

Features Description

•

Radio/Media

Widget

Connectivity

Widget

All Menus

My Menu

Apps/Info

Setup

Shows brief information on the radio or media that is now playing.

•

Tap the area to move to the mode that you are listening to.

Shows any connected devices such as Android Auto, iPod, Pandora, and Bluetooth.

Shows all of the items in the system menu.

•You can add up to eight menus here.

•Add your favorite menus to have quick and easy access to them.

Moves to the Apps/Info screen.

Moves to the Setup screen.

Information Display on the Status Bar

Displays the date and time, along with the system status shown by the various icons to the right of the clock. The icons in the following table indicate the various types of system status details and events.

Icon Description

Displayed when the audio is muted.

Displays the remaining battery of the Bluetooth phone.

Displayed when connected to Bluetooth for handsfree.

Displayed when connected to Bluetooth for streaming audio.

Displayed when connected to Bluetooth for streaming audio and handsfree.

Displayed when downloading contacts or recent calls from the Bluetooth phone.

Displayed while on a call with the Bluetooth phone.

Displayed when the microphone of the Bluetooth or Blue Link phone is muted.

Displays the signal strength of the Bluetooth phone.

Displays the signal strength of the Blue Link.

Displayed when using 2G/3G/LTE data.

Information

• Received signal strength indicator of Blue Link and 2G/3G/LTE information

are displayed only in the devices that support the telematics system.

Starting the System for the First Time I 1-11

Adding Your Favorite Menu Items to My Menu

From the Home screen, select and then

Edit

My Menu

From the Edit My Menu screen, select menu items from the list on the right, then drag and drop them to a desired place on the left. To remove the item from My Menu, drag item from the left and drop them on the right.

Information

• Up to eight items can be added to My Menu.

▶

On-Screen Touch Controls

Learn how to touch the screen to operate the system.

Select

Tap lightly on a menu or an item to select it.

NOTICE

• The system will not recognize your touch if

you wear a glove or other non-conductive material. Touch the screen using your ﬁ nger, an electrostatic touch-screen glove, or a stylus pen.

Drag & Drop

Select a menu or item you want, then drag and drop it to where you want to place it.

Drag or touch the slider along the play bar in the music screens to jump to the point that you want to play from.

i Information

• Music screens for Disc CD and Disc MP3 do

not support this function.

1-12 I Basic

Flick (Quick Scrolling)

Drag the frequency bar to the left or right to move to the frequency that you want.

From the Edit My Menu screen, drag and drop icons to add, delete, or move to/from My Menu.

Quickly moves up and down in the list.

NOTICE

• Moving the list when there are many items will

display a handler on the right of the display. You can easily move many items at a time with the handler

You can view the previous or next image by flicking left/right on an image on the USB Image screen.

Flick left/right on the frequency bar in the radio player to look up the previous/next frequency available.

Starting the System for the First Time I 1-13

Press and Hold

Pressing the and buttons

in the music player will fast forward/rewind the music.

1-14 I Basic

part.2

Radio/Media

FM/AM

HD Radio™ Technology

SiriusXM™

About Disc

CD MP3 USB

iPod

AUX

Bluetooth

Audio

My Music

Radio/Media

FM/AM

Accessing FM/AM Mode

You can access the radio player either by pressing the

key or by selecting the Radio menu from All Menus on the Home screen.

Information

• If you press the and a radio broadcast will be tuned up.

• If you are in radio mode, select the media widget from the Home screen to access the radio player.

RADIO

key when power is off, the power will turn on

RADIO

Features Description

•The stored preset frequencies are displayed for

Preset

Frequencies

Frequency Bar

Frequency

Tag

Presets

SoundHound

user selection.

•After selecting frequency, press and hold the preset button for over 0.8 seconds. A beep sound will be heard and the frequency is to be stored in the selected preset button.

•Flick the frequency bar left/right to search for available radio channels to the left or right of the current channel.

•Dragging: Drag the frequency bar to the left/ right to find the radio channel that you want.

Displays the current frequency.

Saves the current music’s tag information to the head unit. If connected to iPod, the tag information can be saved on the device.

Shows the stored presets for user selection.

Runs the SoundHound feature. For more information, please see the SoundHound section in Info part.

•List Moves to the frequency list.

•Info Turns the Radio text information transmitted from the broadcasting station on and off.

•Preset Scan Plays preset frequencies for 10 seconds peritem.

•Sound Settings Moves to the Sound Settings.

2-2 I Radio/Media

Features Description

Scan/Preset

Scan

Band

HD Radio

Displays an active mode from Scan and Preset Scan modes.

Changes to the desired band from among FM, AM, and SirusXM.

Used to set whether to turn HD Radio™ reception On or Off.

Shortly plays the broadcasts for the frequen-

Scan

cies with superior reception for 5 seconds per item.

•Pressing this button briefly (less than 0.8 seconds) : Seeks the previous/next frequency.

•Pressing and holding this button (for more

SEEK/TRACK

than 0.8 seconds) : Moves quickly through all of the frequencies. The moment that you release the button, the system seeks the next available frequency.

TUNE

knob to manually seek avail-

TUNE

Turn the able frequencies.

•FM : Increment/decrement by 200 kHz

•AM : Increment/decrement by 10 kHz

FM/AM I 2-3

HD Radio™ Technology

Contributes to the superior user experience of HD

Radio™ Technology. Presents song name, artist, station IDs, HD2/HD3

Channel Guide, and other relevant data streams.

nal music as well as deep cuts into traditional genre.

signal. AM sounds like today’s FM and FM sounds like a CD.

Program Service Data :

Adjacent traditional main stations are extra local FM

channels. These HD2/HD3 Channels provide new, origi-

Digital, CD-quality sound. HD Radio™ Technology

enables local radio stations to broadcast a clean digital

If an HD Radio™ broadcast is received, the radio mode will switch from analog broadcast to HD Radio™ broadcast.

Information

• The

HD Radio™

when a HD Radio™ broadcast is being received

screen is displayed only

2-4 I Radio/Media

Basic Mode Screen (HD Radio™ reception ON)

Name Description

Displays main HD Radio™

HD Radio™ Reception &Channel buttons

channels and used to directly select the current available channels.

The HD Radio™ related icon display becomes active within regions where an HD Radio™ signal can be received.

Name Description

HD Channel

Number

Broadcast Info

HD Radio

HD channel number that is stored in presets.

Displays detailed information about the current broadcast. If the HD Radio is turned on, the information for album art, artist, and song appears (if available)

Used to set whether to turn HD Radio™ reception On/Off.

SiriusXM™

SiriusXM™ Mode Hard Key Controls

You can access the radio player either by pressing the

the Radio menu option from All Menus on the Home screen. Select the SiriusXM™ band from the radio player.

Information

• If you press the is off, then the power will turn on and a radio broadcast will be tuned up.

• If you are in the SiriusXM™ mode, select the SiriusXM™ radio widget from the Home screen to access the radio player.

• When the power is off, pressing the key will turn the power on and play a SiriusXM™ Radio broadcast.

RADIO

key or by selecting

RADIO

key when the power

RADIO

SiriusXM™ I 2-5

SiriusXM™ Mode Display Controls

Features Description

•Shows the stored presets for user selection.

Preset

Frequencies

Channel Logo

Channel Info

Content Info

Category Info

Band

Direct Tune

Scan

Category Lock

Category

Selection Buttons

Play Live

Skip Backward

•After selecting frequency preset button for over 0.8 seconds. A beep sound will be heard and the frequency is to be stored in the selected preset button.

Displays the current channel logo.

Displays the current channel number and name.

Displays the category of the currently playing song.

Displays the artist, title and other information about the current playing song

Changes to the desired band from among FM, AM, and SirusXM.

Plays all receivable channels for 10 seconds each

Plays all receivable channels for 10 seconds peritem.

If pressed, only the channels for the current category can be searched or scanned.

Used to select the previous/next category.

Switches to the live broadcast mode.

Repeats the previously broadcasted program.

•Holding for less than 0.8 seconds : Moves to the previous segment.

•Holding for more than 0.8 seconds : Moves to the previous 5 seconds.

, press and hold the

2-6 I Radio/Media

Features Description

Play/Pause

Skip/Forward

Pauses/plays the current broadcasting program.

Moves to the next segment.

Saves the current music’s tag information to the

Tag

head unit. If connected to iPod, the tag information can be saved on the device.

Presets

Shows the stored presets for user selection.

Runs the SoundHound feature.

SoundHound

For more information, please see the SoundHound section in Info part.

List

Moves to the channel list.

•What is on My Presets? The program schedule saved in my preset. (For more details, see Section 2.5. Viewing Menu.)

•Featured Favorites

Theme channels recommended by SiriusXM™ . (For more details, see Section 2.5. Viewing Menu.)

•Preset Scan Plays preset channels for 10 seconds each.

•Sound Settings Moves to the Sound Settings.

•Pressing this key shortly (for less than 0.8 seconds) : Plays the previous/next channel.

SEEK/TRACK

•Pressing and holding this key (for more than 0.8 seconds) : Continuously changes the channel until the key is released and plays the current channel.

TUNE

Changes the channel.

SiriusXM™ I 2-7

Selecting through Channel/Category List

Press the

egory and channel.

Select the desired category and the channel. Once selected, the previous screen will be restored and the selected channel will begin playing.

List

▶ Select the desired cat-

If you select the

scan channels using the

key or the

Skip

button, you can

TUNE

knob by skipping the

SEEK TRACK

channels that you chose to skip.

Direct Tune

Enter the number of the channel you want to receive.

Viewing Menu

Using the

can view the program schedule and information about the Featured Favorites provided by SiriusXM™ .

button on the right, you

2-8 I Radio/Media

What is on My Presets? (Program Schedule)

Name Description

By selecting this option, you can select a broadcasting date and time zone. Broadcast information will be provided for one week from the current date.

Change

Broadcast Date

You can select Menu to see program information and the schedules of broadcast channels listed in the presets.

Preset

Broadcasting

Time

Program

Information

Shows saved presets for user selection

A total of 18 frequencies for SiriusXM™ modes can be displayed

You can select the time that you want.

Shows you the program titles to be broadcasted at the time that you have chosen. Select a program to see more details.

If there is more information on the program you selected, an arrow button will be displayed on the right of the list. You can see more program information by selecting the arrow button.

SiriusXM™ I 2-9

Featured Favorites

Featured Favorites feature allows SiriusXM™ to broadcast additional presets

•Example 1 : "Martha's Favorites" may represent Martha Stuart's favorites presets on her radio

•Example 2 : During holidays, "Holiday Music" may represent all the SiriusXM™ channels that are playing the holiday music for easy access by users

Multiple sets Featured Favorites data can be broadcast by SiriusXM™ and can change from time to time

2-10 I Radio/Media

About Disc

Precautions upon Handling Discs

CAUTION

• After using a disc, put the disc back in its

original case to prevent disc scratches.

• Do not use abnormally shaped discs (8cm,

t-shaped, octagon-shaped) as such discs

hear could lead to errors.

• Do not clean discs with chemical solutions,

such as record spr antistatic liquids, benzene, or thinners.

• Do not expose the disc to direct sunlight or

high temper time. Such exposure may lead to disc deformation.

• Upon playing a disc contaminated by dirt

or other substances deteriorate and result in skipping sounds. Writing on either side of the disc could result in damage to disc surfaces.

ays, antistatic sprays,

atures for prolonged periods of

, the sound quality may

• Clean fingerprints and dust off the disc

surface (coated side) with a soft cloth.

• Copy-protected CDs, such as S-type CDs,

y not properly operate in the device. DATA

ma CDs cannot be played. (However, such discs may still abnormally operate.)

• Do not disassemble the device. Contact a

designated ser (Complete after ser provided if the user disassembles the device.)

• Do not use water to clean the device.

Exposure to w damage.

• Do not introduce foreign substances into

the disc inser substances could damage the device interior.

• The device may not properly operate

xtremely hot or cold temperatures.

in e (The operating temperature range is : 14˚F ~ 150˚F)

vice center in case of problems.

vice assistance will not be

ater could lead to product

t/eject slot. Introducing foreign

• Steam can become condensed on the ﬁ ber-

optic lens due to rain, wet conditions, or upon operating the heating system. In such cases, discs may not be properly recognized. Remove the disc and wait until the moisture dries.

• Skipping may occur during audio play when

iving on bumpy roads for prolonged periods

dr of time or upon severe shock to the vehicle. In case of severe shock, audio may not properly play.

About Disc I 2-11

Supported Disc Formats

This device supports the following disc formats.

Disc Type

Disc Type Disc Format Device Support

3inch (8cm)

5inch (12cm)

SACD

CD-R

CD-RW

Multisession-CD

SACD

(Single, SACD layer)

SACD (Hybrid)

Disc Format

Disc Type Disc Format Device Support

CD-DA

MP3

WMA

MPEG4 AAC

DTS-CD

CD-ROM

CD-G

CD-EXTRA

CD-TEXT

X O

O O (Read Only) O (Read Only) O (Read Only)

(Only CD layer)

O O O X X O X O O

Disc/Content Format Compatibility

By Format according to Disc Type

Disc Type Disc Format Device Support

CD LPCM

MPEG1, Layer3

MP3

WMA Ver9

MPEG2, Layer3

MPEG2.5

O O O

Ordinary Disc Compatibility

This device has been designed/ manufactured to be compatible with software bearing the following logo marks.

$XGLR&'

•CD-R/RW discs (Audio CD) created with CD recording devices or PCs may not properly operate in the device. This is a result of various causes, including disc format, recording method, and contamination to the disc or lens.

2-12 I Radio/Media

CD-R/RW Compatibility

•This device supports CD-R, CD-RW, and MP3 discs burned in Audio CD formats.

•The recording of CD-R and CD-RW discs with this device is not supported.

•CD-R/RW discs recorded as audio CDs

that were not finalized are not supported by this device.

PC-created Disc Compatibility

•When burning a disc on a PC, the disc may not operate in this device depending on the software settings. In such cases, inquire with the software manufacturer.

•Additional information regarding compatibility is displayed on the CD-R/RW software disc box.

•DVD-R/W discs are not compatible with

this device.

Cautions upon Writing CDs

•When a multi-session disc is being recorded, make sure to close the session before recording.

•If MP3/WMA file extensions are changed, such could result in errors.

•In the case of MP3/WMA, wr only English. (Other languages are not supported)

•Unauthorized use of copy-protected music files is prohibited by law.

•Prolonged use of CD-R/CD-RW products that do not satisfy related specifications may result in abnormal operation.

•When wr recommended.

iting CDs, low-speed writing is

ite using

Compressed Audio Compatibility

•Physical formats of CD : Model 1, Model 2 XA format 1.

•This device supports audio file compressed through MPEG-1 audio stream layer 3 (MP3) using 8kbps ~ 320kbps. (CBR or VBR)

•For stable operation, the use of files in 95kbps~192kbps bit rate range and

44.1kHz SAMPLING frequency is recommended.

•This device supports WMA audio files using 20kbps ~ 320kbps. (CBR or VBR)

•Variable bit rate files may operate, but the play time information may not be properly displayed.

•This device only supports tracks with file extension of “.mp3” or “.wma”.

•This device does not support multisession discs.

•This device supports only 8 layer folders.

About Disc I 2-13

•This device supports MP3 ID3 tag versions of Ver. 1.0, Ver. 1.1, Ver. 2.2, Ver.

2.3, Ver. 2.4. When using discs with other versions, the ID3 info will not be displayed.

•Although this device has been designated to be compatible with various bit rates, playing low bit rate MP3 tracks may result in low quality sound.

Before Playing an MP3 Disc

Supported MP3 File Speciﬁ cation

•Acceptable standard: MPEG1 Audio Layer 3.

•Acceptable sampling frequency : 8, 11.025, 12, 16, 22.05, 24, 32, 44.1, 48(kHz).

•Acceptab

Recommended Bit Rates and Frequency

•Sampling frequency : 96 ~ 192 Kbps fixed bit rate/44.1kHz.

le bit rate : 8 ~ 320 (Kbps).

Detailed Speciﬁ cation

•Maximum directory layers : 8 layers.

•Maximum folder length : 64 bytes, file name length: 64 bytes.

•Supported characters for folder name/file name: 2350 characters for Alphanumeric character and Korean character sets, 4888 characters for Simplified Chinese character set.

•Maximum number of folders per disc : 256 folders. (including ROOT)

•Maximum number of files per disc : 512 files.

2-14 I Radio/Media

NOTICE

• Supported ID3 tags : ID3v1.0, ID3v1.1,

ID3v1.2, ID3v2.2, ID3v2.3, ID3v2.4.

• Supported MP3 Media : CD-ROM.

• Supported media formats : ISO9660 LEVEL1

and LEVEL2.

Precautions upon Burning MP3 Files

•The use of ISO 9660 LEVEL 2 JOLIET format is recommended.

•Up to 32 characters in Korean/Chinese are supported for file names and up to 20 characters in Korean/Chinese are supported for folder names.

•The use of CDs exceeding 700MB may result in faulty disc recognition or errors upon play.

MP3 File Structure

Recognition occurs through the same folder structure used within the disc.

Folder structure as saved in CD-ROM Folder structure as saved in the system

About Disc I 2-15

Basic Mode Screen

Name Description

Mode

Track Index

Repeat/ Shuffle/Scan

Play Time

Play Info

Previous Tra ck

Play/Pause

Next Track

Repeat

Shuffle

Scan

List

Displays current operating mode

Shows the current track/total tracks

From Repeat/Shuffle/Scan, displays the current operating function

Displays the current play time

Displays track/artist/title/album information

•When the play time is under 3 seconds the previous track

•When the play time is over 3 seconds current song from the beginning

Plays/pauses the current track

Moves to the next track

Repeats the current track Press the repeating the current track repeat off

Plays disc tracks in random order Press the fle all

Scans the beginning parts of disc tracks (approx. 10 seconds per track) Press the all

Moves to the track list screen

Repeat

button to switch between

Shuffle

button to switch between shuf-

→ and turning shuffle off

Scan

button to switch between scan

→ and turning scan off

→ and turning

2-16 I Radio/Media

Name Description

Runs the SoundHound feature.

SoundHound

For more information, please see the SoundHound section in Info part.

Sound Settings : Moves to the Sound Settings screen. You can change the settings of the sound.

utton is pressed quickly (less than 0.8 sec-

•If b onds), it moves to previous or next track

utton is pressed and held (over than 0.8

•If b seconds), it rewinds or fast-forward the track

SEEK/TRACK

When pressed for 5 seconds, it will rewind or fast-forward the track at 4x speed. After that, it will rewind or fast-forward at 20x speed. Once released, the track will begin playing at normal speed.

Turn the

TUNE

knob and search a desired

track. When the track name is displayed, press

TUNE

the

If the

knob to play the track.

TUNE

knob is not pressed within 5 seconds of searching tracks, the track info for the current track is restored.

CD I 2-17

Name Description

Current Track

Back Button

Displays current playing track name

Converts to basic mode screen

When moving to a different list screen, moves to

the list page where the current file is located (Becomes disabled when the current list includes the current file)

•If button is pressed (less than 0.8 seconds): Plays previous/next track

utton is pressed (over than 0.8 seconds):

SEEK/TRACK

•If b Moves to play screen, and then it will rewind or fast-forward the track. It will play the track normally if it is released.

TUNE

knob to move the focus to the

TUNE

knob to play the track.

TUNE

Turn the next/previous track. If the desired track is selected, press the

2-18 I Radio/Media

MP3

Basic Mode Screen

Name Description

Mode

File Index

Repeat/ Shuffle/Scan

Play Time

Song Info

List

Previous File

Play/Pause

Next File

Repeat

Displays current operating mode

Shows the current MP3 file/total number of MP3 files

From Repeat/Shuffle/Scan, displays the current operating function

Displays the current play time

Displays folder/file/artist/title/album info for current song

Moves to the list screen

•If play time is less than 3 secs, moves to previous file

•If play time is over than 3 secs, play the current file from the beginning

Plays/pauses the current track

Moves to the next song

Repeats the current song or all songs in the folder Press the 1 song ing repeat off

Repeat Folder: Repeats songs in the folder

Repeat

button to switch between repeating

→ repeating folder → and turn-

Repeat 1 song: Repeats the current song

MP3 I 2-19

Name Description

Plays files in the folder or in the disc in random order

Shuffle

button to switch between shuffle

→ shuffle all → and turning

Shuffle folder : Plays songs in the folder in

Shuffle

Press the folder shuffle off

random order Shuffle All : Plays songs in the disc in random order.

Scans the beginning parts of MP3 files (approx. 10 seconds per file)

Scan

Press the folder → scan all → and turning scan off

Scan

button to switch between scan

Scan Folder : Scans tracks in the current folder

Scan All : Scans all tracks in the disc

Runs the SoundHound feature.

SoundHound

For more information, please see the SoundHound section in Info part.

Sound Settings : Moves to the Sound Settings screen. You can change the settings of the sound.

utton is pressed (less than 0.8 seconds):

•If b Plays previous/next track

SEEK/TRACK

utton is pressed (over than 0.8 seconds):

•If b Moves to play screen, and then it will rewind or fast-forward the track.

Turn the

TUNE

knob to search a desired track.

If the desired track is displayed, press the

TUNE

knob to play the track.

If the

TUNE

knob is not pressed within 5 seconds of searching tracks, the track info for the current track is restored.

2-20 I Radio/Media

Name Description

Folder Name

Current Song

Back Button

Upper Folder

Displays folder name for current file

Displays current playing file name

Converts to basic mode screen

Moves to Root Folder

When moving to a different list screen, moves to the

list page where the current file is located (Becomes disabled when the current list includes the current file)

utton is pressed (less than 0.8 seconds) :

•If b Plays previous/next track

SEEK/TRACK

utton is pressed (over than 0.8 seconds) :

•If b Moves to play screen, and then it will rewind or fast-forward the track.

TUNE

knob to move the focus to the

TUNE

knob to play the track.

TUNE

Turn the previous/next track. If the desired track is displayed, press the

MP3 I 2-21

USB

Before Playing a USB MP3

Connect the USB device after turning on the engine. The USB device may become damaged if it is already connected when the ignition is turned on.

•Files that are not standard format music/image files will not be played.

•For MP3/WMA/OGG files, only music files with compression rates between 8Kbps ~ 320Kbps can be played.

•Heed caution to static electricity when connecting/disconnecting

external USB devices.

•Encoded MP3 Players will not be recognized when connected

as an external device.

•When connecting an external USB device, the device may not

properly recognize the USB is in some states.

•Only products formatted with byte/sectors under 64Kbyte will be

recognized.

•This device recognizes USB devices formatted in FAT 12/16/32

file formats. This device does not recognize files in NTFS file format.

•Some USB devices may not be supported due to compatibility

issues.

2-22 I Radio/Media

•Take caution so that the USB connector does not come in contact with body parts or objects.

•Repeated connecting/disconnecting of USB devices within short periods of time may result in product malfunction.

•Make sure to connect/disconnect external USB devices with the audio power turned off.

•The amount of time required to recognize the external USB device may differ depending on the type, size, or file formats stored on the USB.

•The use of USB devices for purposes other than playing music and image files is prohibited.

•Do not use the USB I/F to charge batteries or USB accessories that generate heat. Such acts may lead to worsened performance or damage to the device.

•The device may not recognize the USB device if separately purchased USB hubs and extension cables are being used. Connect the USB directly with the multimedia terminal of the vehicle.

•When using mass storage USB devices with separate logical drives, only files saved to the root drive can be played.

•When application programs are installed to specific USBs, files may not properly play.

•The device may not operate normally if MP3 Players, cellular phones, digital cameras, or other electronic devices (USB devices not recognized as portable disk drives) are connected with the device.

•Charging through the USB may not work for some mobile devices.

•The device may not support normal operation when using a USB

memory type besides Metal Cover Type USB Memory.

•The device may not support normal operation when using for-

mats such as HDD Type, CF, or SD Memory.

•Upon playing iPods, please use a dedicated iPod car cable.

•Normal operations cannot be guaranteed when other cables are

being used.

•The device will not support files locked by DRM. (Digital Rights

Management)

•USB memory sticks used by connecting an Adaptor (SD Type or

CF Type) may not be properly recognized.

•Only use Plug type connector products, as shown in the figure

below.

Plug Type Connector

Product Name Manufacturer

XTICK LG

BMK BMK Technology

SKY-DRV Sky Digital

TRANSCEND JetFlash Transcend

Sandisk Cruzer SanDisk

Micro ZyRUS ZyRUS

NEXTIK Digiworks

Information

• Problems that occur through use of USB devices not listed within the above table are not covered by the product warranty.

USB I 2-23

USB MP3 Information and Precautions

Supported Image Speciﬁ cations

Name Description

MP3 File Specification

Recommended Bit Rates and Sampling Frequency

ID3 Tag

Detailed Specifications

Information

Specification : MPEG1 AUDIO LAYER 3

Acceptable sampling frequency : 32, 44.1, 48 (kHz)

Acceptable bit rate : 32, 40, 48, 56, 64, 80, 96, 112, 128, 160, 192, 224, 256, 320 (Kbps)

96, 128, 192 Kbps fixed bit rate/44.1kHz

Supports ID3v1.0 and ID3v1.1, ID3v2.2, ID3v2.3, ID3v2.4 ID3 tags

Maximum directory layers : 20 layers Maximum length of folder name/file name : 255Bytes Supported characters for folder name/file name : Alphanumeric characters, Korean standard character set 2,350 characters, Simplified Chinese 4888 characters Maximum number of folders which can be stored onto one USB : 2000 folders (including ROOT) Maximum number of files which can be stored onto one USB : 8000

• The sound quality of MP3 files that use bitrates exceeding

192 Kbps cannot be guaranteed. When using files without fixed bit

rates, some features (FF/REW features) may not properly operate.

Name Description

Image format

Supported image resolution

Supported image file size

JPG, GIF, BMP, PNG (animated GIF, etc. are not supported)

5M pixels for JPG, BMP, PNG (1M pixels maximum for GIF)

2-24 I Radio/Media

USB Music

Features Description

Mode

File Index

Repeat/ Shuffle/Scan

Play Time

Song Info

List

Displays current operating mode

Shows the current file/total files within the USB

From Repeat/Shuffle/Scan, displays the current operating function

Displays the current play time/total play time

Displays the information of the current track

•When a track in the file tab on the list screen is selected : Displays folder, file, title, artist, album info

•When a track in the other tabs on the list screen is selected : Displays artist, title, album info

Moves to the list screen

Features Description

Back Button

Converts to basic mode screen

If button is pressed (less than 0.8 seconds) :

ves to the previous file or play the current file

Mo from the beginning (Depends on the play time)

•If play time is less than 3 seconds, moves to

Previous File

previous file

•If play time is over than 3 seconds, play the current file from the beginning

If button is pressed (over than 0.8 seconds) it

winds the track

Play/Pause

Next File

Plays/pauses the current file

utton is pressed (less than 0.8 seconds) :

•If b Moves to the next file

utton is pressed (over than 0.8 seconds) :

•If b It fast-forwards the track

Repeats the current file

•If select the song in the file tab on the list screen : Press the between repeating one song

Repeat

folder

, and turning repeat off

•If select the song in the other tabs (Playlist, Artist, Song, Album) on the list screen : Press the

Repeat

button to switch between repeating

one song

and turning repeat off

Plays files in random order

Shuffle

•If select the song in the file tab on the list screen : Press the Shuffle Folder ing shuffle off

Shuffle

button to switch between

, Shuffle All , and turn-

•If select the song in the other tabs (Playlist, Artist, Song, Album) on the list screen : Press the button to switch between Shuffle Category and turning shuffle off

Repeat

button to switch

, repeating

Shuffle

USB I 2-25

Features Description

Scans the beginning parts of USB files (approx. 10 seconds per file)

•If select the song in the file tab on the list screen : Press the

Scan

between Scan Folder and turning scan off

•If select the song in the other tabs (Playlist, Artist, Song, Album) on the list screen : Press

Scan

the egory

button to switch between Scan cat and turning scan off

Scan

button to switch

, Scan All ,

Features Description

•Add to Playlist : Add the current track to the Playlist Playlist is placed on the left tab in the list

•Save to My Music : You can save the current

track to My Music. You can play saved track from My Music without USB. Access to My Music in the Media mode.

•Sound Settings : Moves to the Sound Settings screen. You can change the settings of the sound.

Runs the SoundHound feature.

SoundHound

For more information, please see the SoundHound section in Info part.

If button is pressed (less than 0.8 seconds)

ves to previous/next file or play the current

mo track from the beginning

•If play time is less than 3 seconds, moves to

SEEK/TRACK

previous/next file

•If play time is over than 3 seconds, play the current file from the beginning

If button is pressed (over than 0.8 seconds) it

wind/fast-forward the track

will re

Turn the

TUNE

track. If the desired track is displayed, press the

TUNE

knob to play the track.

If the

TUNE

5 seconds of searching tracks, the track info for the current track is restored.

knob to search a desired

knob is not pressed within

2-26 I Radio/Media

Features Description

Folder/ Category Name

Current Song

Back Button

Upper Folder/

Category

Displays folder/category name in the list

Displays current playing file name

Converts to basic mode screen

Moves to Upper Folder

Features Description

•Add to Playlist : Adds the current track to the Playlist: Playlist is placed on the left tab in the list (Maximum 100 files) Select a desired track and press “Add to Playlist” to add the track in the playlist.

•Delete from Playlist : Select a track you want to

Search Menu

SEEK/TRACK

TUNE

delete from the playlist and press “Delete from Playlist” to delete the track in the playlist

•Now Playing : When moving to a different list screen, moves to the list page where the current file is located (Becomes disabled when the current list includes the current file)

•Save to My Music : Stores the music. The stored music can be played in My Music. (This function is not provided in Playlist.)

Search tracks by the list type. Search songs according to File, Playlist, Artist, Song and Album.

If access the search menu while playing a track, it moves to the previous search mode.

If button is pressed (less than 0.8 seconds):

ys previous/next track

Pla

•If play time is less than 3 seconds, moves to previous/next file

•If play time is over than 3 seconds, play the current file from the beginning

If button is pressed (over than 0.8 seconds): Moves to play screen, and then it will rewind or fast-forward the track. It will play the track normally if button released.

Turn the previous/next list. If the desired track is displayed, press

TUNE

knob to move the focus to the

TUNE

knob to play the track.

USB I 2-27

USB Image

Features Description

Mode

Folder/File Name

File Index

Slideshow

Rotate

Info

Adjust Image Size

List

Previous/ Next image

Displays current operating mode

Displays folder name where image is located

Shows the current file/total files within the USB

images as slideshow in 5, 10, 20, 30 second intervals

Rotate image in clockwise direction

Shows the file name, resolution and file type of current image

Enlarge/reduce (zoom-in/zoom-out) image size

Moves to the list screen

Swipe image left or right to see Previous/ Next image

2-28 I Radio/Media

Features Description

Current File

Back Button

Displays current playing file name

Converts to basic mode screen

Now Playing : When moving to a different list

screen, moves to the list page where the current file is located (Becomes disabled when the current list includes the current file)

Controls background mode

SEEK/TRACK

•Radio mode : Changes Frequency and Channel

•Media mode : Changes Track (excluding AUX)

Controls background mode

•Radio mode : Changes Frequency and Channel

TUNE

•Media mode : Changes track (excluding AUX). If a desired track is displayed, press the knob to move to the track.

USB I 2-29

iPod

Using iPod Devices

•iPod is a registered trademark of Apple Inc.

•iPod mode will not operate if the connected iPod cannot be recognized due to operation of unsupported versions that do not support related protocols, iPod abnormalities, or iPod device defects. Some iPods with unsupported communication protocols may not properly operate with the Multimedia system.

•For fifth generation iPod Nano devices,

the iPod may not be recognized when the battery level is low. Please charge the iPod for use.

•Search/play orders shown within the

iPod device may differ with the orders shown within the Multimedia system.

•If the iPod malfunctions due to an iPod

device defect, reset the iPod and try again. (To learn more, refer to your iPod manual)

•If repeatedly connect and disconnect iPod/iPhone to the Multimedia system with USB cable in short time, it may

abnormal operation.

cause

•The time f

or recognition of iPod/iPhone may vary depending on device type, firmware version and iOS version.

•For some iPod Touch and iPhone devices, connecting Bluetooth

while the iPod is operating may result in discontinued iPod sound. When such devices with Bluetooth

support are connected, this problem occurs as the sound source is changed from the Dock Connector (USB connector cable) to Bluetooth.

•To prevent this symptom, Bluetooth Audio function in the Multimedia system is limited if iPod/iPhone is connected to the system through both cable and Bluetooth. To listen to the iPod sound, use either iPod menu with USB connection or Bluetooth Audio with Bluetooth connection.

•To listen to the iPod sound, reconnect the USB cable or change the audio output settings in iPod/iPhone to Dock.

•In order to use the iPod while operating the keys, you must use a dedicated iPod cable. (the cable that is supplied when purchasing iPod/ iPhone products)

※

During ACC ON state, connecting the

iPod through the iPod cable (The cable that is supplied when purchasing iPod/ iPhone product.) will charge the iPod through the head unit.

※

The use of genuine iPod cables sup-

plied by Apple is recommended. (The plied by Apple is recommended. (The use of other products may result in use of other products may result in noise or abnormal operation.)noise or abnormal operation.)

2-30 I Radio/Media

•When connecting with the iPod cable, make sure to fully insert the jack to prevent communication interference. If the iPod is connected to the vehicle while it is playing, a high pitch tone may sound for about 1~2 seconds immediately after connection. If possible, connect the iPod to the vehicle with the iPod stopped/ paused.

•Within iPhones, streaming audio and iPod control may occasionally conflict. If problems persist, remove the iPhone and connect again.

•When connecting to iPod Nano /Classic,

the HYUNDAI Motor logo appears on the Apple device. For the iPod Nano 6 generation, however, the logo image does not appear since it is not supported. Also, all iPhone and iPod Touch products do not support this function.

•In Apple’s iOS 6.0 version or later, Podcast and Audiobook media files are designed to be played with the Podcasts and iBooks applications specifically designed for Apple products. If the Apple device does not provide the Podcast and Audiobook lists, the playlist may not be displayed and played in the iPod mode.

•If the Apple Podcasts and iBooks apps are not installed on the Apple device, but the Apple device provides the Podcast and Audiobook lists, you can play files in other categories in iPod mode.

•The screen of multimedia system can be different when you run other music players (e.g. iHeartRadio) on your connected device.

iPod I 2-31

Caution

•While using a connected iPhone/iPod Touch device, it may not operate normally if the user changed some functions in the device.

•When calling with an iPhone connection, song may stop playing due to an Apple device feature. If sound does not resume after the call is terminated, check the device status.

•If lots of songs have the same informa-

tion, skipping may occur when previous/ next song is executed due to an Apple device feature. Also problems may occur depending on device type or iOS version.

•If lots of songs have the same informa-

tion, it may occur difference of playing songs between the Multimedia system and Apple device. Reset the device or delete the same songs in the Apple device using iTunes.

•If you control pause, repeat, shuffle, or seek songs when the play time is when the play time is less than 3s before finished playing, it may occur difference of playing song between the Multimedia

•We recommend that your Apple device uses the latest firmware since some problems may occur due to an outdated firmware or issues

other software related

system and Apple device. Access to iPod music from another mode or pause a song and then play a song again in Apple device.

Type 1G 2G 3G 4G 5G 6G 6.5G 7G

iPod Mini Not Supported

iPod Shuffle Not Supported

iPod Nano

iPod Touch

iPad

iPad Mini

iPod Classic Not Supported

Type 3G 3GS 4G 4GS 5G

iPhone

◯ ◯ ◯◯◯ ◯

◯

(iOS 1.1 not

supported)

Not verified,

Normal working not guaranteed

◯ ◯◯◯

◯

(Unable to charge, Not verified, Normal working not guaranteed)

◯

(Unable to charge, Not verified, Normal working not guaranteed)

◯

(iPod with

Video)

◯◯◯◯

◯

(iPod

Classic)

Not

released

Not released

◯

(iPod

Classic)

◯

Not

released

2-32 I Radio/Media

Caution

•If the iPhone/iPod Touch supports Bluetooth, it is unable to use Bluetooth Audio if the Apple device that is connected to the Multimedia system through both USB connection and Bluetooth. Disconnect the USB connection then use Bluetooth Audio

•If iPod/iPhone connected to the Multimedia system through both USB and AUX. iPod/iPhone keeps output sound via AUX, thus it may occur sound will not output in iPod mode.

•If AUX cable connected to iPod/iPhone

but not connect to the Multimedia system, it may occur sound will not output in iPod mode due to iPod/iPhone’s feature. Especially, if you use AUX cable like pictures, this problem may occur.

•Disconnect AUX cable from iPod/iPhone

first, then connect to the Multimedia system via USB. Or change settings to “Dock” in iPod/iPhone.

•If connect to the Multimedia system while podcast or iTunes music downloading to iPod/iPhone, it may occur some problems when you select song in the list. Reconnect iPod/iPhone to the Multimedia system when downloading is finished or the file deleted.

•If connect to the Multimedia system

while sync, it may occur some problems. Try to use iPod/iPhone connection after sync complete. (To learn more, refer to your iPod manual)

•iPhone and iPod Touch devices are guaranteed to work normally on iOS

7.0.6 or below. However, they may not w

ork normally on future iOS versions as their operations have not yet been tested.

iPod I 2-33

iPod

Features Description

Mode

Song Index

Repeat/Shuffle

Play Time

Song Info

List

Displays current operating mode

Shows the current song/total songs

From Repeat/Shuffle, displays the current operating function

Displays the current play time/total play time

Displays the artist/song title/album info

Moves to the list screen

Features Description

If button is pressed (less than 0.8 seconds):

es to the previous file or play the current file

Mov from the beginning (Depends on the play time)

•If play time is less than 3 seconds, moves to

Previous File

previous file

•If play time is over than 3 seconds, play the current file from the beginning

If button is pressed (over than 0.8 seconds) it

Play/Pause

winds the tr

Plays/pauses the current file

ack.

•If button is pressed (less than 0.8 seconds), Mov

Next File

es to the next file

•If button is pressed (ov does fast-forward the track.

Repeats the current file

Repeat

Press the ing 1 track

Repeat

button to switch between repeat-

, and turning repeat off

Plays files in random order

Shuffle

button, it changes to

→ deactivate shuffle then

Shuffle

When pressing shuffle category repeat

•Shuffle Category: Shuffle song in the current category

Back Button

Move to home/previous mode screen

Runs the SoundHound feature.

SoundHound

For more information, please see the SoundHound section in Info part.

Memo

Sound Settings : Moves to the Sound Settings screen. You can change the settings of the sound.

er than 0.8 seconds), it

2-34 I Radio/Media

Features Description

If button is pressed (less than 0.8 seconds)

ves to previous/next file or play the current

mo song from the beginning

SEEK/TRACK

TUNE

•If play time is less than 3 seconds, moves to

previous/next file

•If play time is over than 3 seconds, plays the

current file from the beginning

If button is pressed (over than 0.8 seconds) it will

wind/fast-forward the track

Turn the track. If the desired track is displayed, press the

If the 5 seconds of searching tracks, the track info for the current track is restored.

TUNE

knob to search a desired

TUNE

knob to play the track.

TUNE

knob is not pressed within

iPod I 2-35

Features Description

Category Name

Displays the category name

Displays the contents of selected category

Category List

If there are many items in the list, items are added in order and the scroll bar on the right is adjusted accordingly.

Back Button

Upper Folder

Converts to basic mode screen

Moves to Upper Folder

Search tracks by the list type. Search songs according to Playlist, Artist, Song, Album, Genre,

Search Menu

Composer, Podcast and Audiobook .

If access the search menu while playing a

track, it moves to the previous search mode.

If button is pressed (less than 0.8 seconds)

ves to previous/next file or play the current

mo song from the beginning

•If play time is less than 3 seconds, moves to

SEEK/TRACK

previous/next file

•If play time is over than 3 seconds, plays the current file from the beginning

If button is pressed (over than 0.8 seconds) it will

wind/fast-forward the track.

Turn the

TUNE

knob to search a desired

track. If the desired track is displayed, press

TUNE

the If you do not anything with the knob for 5 seconds, the

knob to play the track.

TUNE

minated.

knob search will be ter-

2-36 I Radio/Media

AUX

Connecting an External Device

If an external device connector is connected with the AUX terminal, then AUX mode will automatically operate. Once the connector is disconnected, the previous mode will be restored.

•AUX mode can be used only when an external audio player has been connected.

•The AUX volume can also be controlled separately through the connected device.

NOTICE

• If only a cable is connected to the AUX without

an external device, the mode will be changed

UX, but noise may occur. When an

to A external device is not being used, remove the connector jack.

• When the external device power is connected

wer jack, playing the external device

to the po may output noise. In such cases, disconnect the power connection before use.

AUX I 2-37

Bluetooth® Audio

Bluetooth Audio Mode

Features Description

Mode

Phone Name

Artist Info

Title

Previous File

Play/Pause

Next File

SoundHound

SEEK/TRACK

TUNE

Displays current operating mode

Displays name of connected phone

Name of current artist

Name of current song

•If play time is less than 3 seconds, moves to the previous file

•If play time is over than 3 seconds, plays the current file from the beginning

This function may differ depending on the model of mobile phone

Plays/Pauses Bluetooth Audio

Moves to the next file

•Connections: Moves to the Bluetooth Settings screen. You can pair a new device or change/ delete paired device(s).

•Sound Settings: Moves to the Sound Settings screen. You can change the settings of the sound.

Runs the SoundHound feature. For more information, please see the SoundHound section in Info part.

Plays the previous/next file

TUNE

is not supported.

2-38 I Radio/Media

Information

• Artist info and Title may not be supported by mobile phone

Bluetooth Connections Settings

Settings for pairing, connection and disconnection of a Bluetooth device

•In Bluetooth Audio play screen, select

and then

Connections

Information

• If the music in the mobile phone is not played after changing to audio streaming mode, press the play button. Thus check if the music is playing in the Bluetooth device after changing to audio streaming mode. Audio streaming may not be supported for some mobile phones.

• Please check the Bluetooth compatibility in below website : HYUNDAI Motor America https://www

.hyundaiusa.com/bluetooth

BluetoothⓇ Audio I 2-39

My Music

Features Description

Mode

File Index

Repeat/ Shuffle/Scan

Play Time

Song Info

List

Displays current operating mode

Shows the current file/total files

From Repeat/Shuffle/Scan, displays the current operating function

Displays the current play time/total play time

Displays the information about the current track

•When a track in the file tab on the list screen is selected : Displays file, artist, title, album info

•When a track in the other tab on the list screen is selected : Displays artist, title, album info

Moves to the list screen

Features Description

If button is pressed (less than 0.8 seconds):

ves to the previous file or play the current file

Mo from the beginning (Depends on the play time)

Previous File

Play/Pause

Next File

Repeat

•If play time is less than 3 seconds, moves to previous file

•If play time is over than 3 seconds, play the current file from the beginning

If button is pressed (over than 0.8 seconds) it

winds the track

Plays/pauses the current file

•If b

utton is pressed (less than 0.8 seconds):

Moves to the next file

utton is pressed (over than 0.8 seconds) it

•If b will fast-forward the file

Repeats the current file

•If select the song in the file tab on the list screen : Press the between repeating one song ing repeat off.

•If select the song in the other tabs (Playlist, Artist, Song, Album) on the list screen : Press

Repeat

the ing one song

button to switch between repeat-

Repeat

and turning repeat off

button to switch

and turn-

2-40 I Radio/Media

Features Description

Plays files in random order

•If select the song in the file tab on the list screen

Shuffle

button to switch between

and turning shuffle off

Shuffle

: Press the shuffle

•If select the song in the other tabs (Playlist, Artist, Song, Album) on the list screen : Press

Shuffle

the

button to switch between shuffle

and turning shuffle off

Features Description

Scans the beginning parts of files (approx. 10seconds per file)

•If select the song in the file tab on the list screen : Press the

Scan

between scan

•If select the song in the other tabs (Playlist, Artist, Song, Album) on the list screen : Press

Scan

the

button to switch between scan

and turning scan off

•Add to Playlist: Adds the current song to the Playlist Playlist is placed on the left tab in the list

•Delete Current File: Deletes the current track

from My Music.

•Sound Settings: Moves to the Sound Settings screen. You can change the settings of the sound.

Runs the SoundHound feature.

SoundHound

For more information, please see the SoundHound section in Info part.

If button is pressed (less than 0.8 seconds) mov

es to previous/next file or play the current

song from the beginning

SEEK/

TRACK

•If play time is less than 3 seconds, moves to previous/next file

•If play time is over than 3 seconds, plays the current file from the beginning

If button is pressed (over than 0.8 seconds) it will

ast-forward the track

wind/f

Turn the

TUNE

knob to search a desired track.

If the desired track is displayed, press the

TUNE

knob to play the track.

If the

TUNE

knob is not pressed within 5 seconds of searching tracks, the track info for the current track is restored.

Scan

button to switch

and turning scan off

My Music I 2-41

Features Description

Folder/

Category Name

Current Song

Back Button

Upper Folder

Displays folder/category name in the list

Displays current playing file name

Converts to basic mode screen

Moves to Root Folder

Features Description

•Add to Playlist : Adds the current track to the Playlist : Playlist is placed on the left tab in the list (Maximum 100 files) Select a track and press “Add to Playlist” to add the track in the playlist

•Delete from Playlist : Select a track from the playlist and press “Delete from Playlist” to

delete the track in the playlist

•Delete Files : Deletes files from My Music

If delete file from My Music, the information related to song also deleted in the list.

•Now Playing : When moving to a different list screen, moves to the list page where the current file is located (Becomes disabled when the current list includes the current file

Search tracks by the list type. Search songs accord-

Search Menu

ing to File, Playlist, Artist, Song and Album.

If access the search menu while playing a

track, it moves to the previous search mode.

If button is pressed (less than 0.8 seconds) mo

ves to previous/next file or play the current

song from the beginning

•If play time is less than 3 seconds, moves to

SEEK/TRACK

previous/next file

•If play time is over than 3 seconds, plays the current file from the beginning

If button is pressed (over than 0.8 seconds) it will

wind/fast-forward the track

TUNE

Turn the

knob to move the focus to pre-

vious/next file. If the file you want to play is dis-

TUNE

played, press

If the

TUNE

knob to play the track.

knob is not pressed within 5 seconds of searching tracks, Tune search will be terminated.

2-42 I Radio/Media

part.3

Before Using the Bluetooth® Handsfree

Bluetooth

Bluetooth Connection

Bluetooth Phone

Bluetooth

Before Using the Bluetooth® Handsfree

What is Wireless Technology?

•Bluetooth

to a short-distance wireless networking technology which uses a 2.45GHz frequency to connect various devices within a certain distance.

•Supported within PCs, external devices, Bluetooth tronic devices, and automotive environments, to be transmitted at high speeds without having to use a connector cable.

•Bluetooth which allows the user to conveniently make phone calls with Bluetooth mobile phones through the Multimedia system.

Bluetooth®

Wireless Technology refers

phones, PDAs, various elec-

Bluetooth

Wireless Technology

Handsfree refers to a device

•The Bluetooth

Handsfree feature may not be supported in some mobile phones. For more information on mobile phone compatibility, visit the HYUNDAI website

- HYUNDAI Motor America : https://www.

hyundaiusa.com/bluetooth

Precautions for Safe Driving

•Bluetooth® Handsfree is a feature that enables drivers to practice safe driving. Connecting the head unit with a Bluetooth conveniently make calls, receive calls, and manage the phonebook. Before using carefully read the contents of this user’s manual.

•Excessive use or operations while driving may lead to negligent driving practices and be the cause of accidents. Do not operate the device excessively while driving.

•Viewing the screen for prolonged peri-Viewing the screen for prolonged peri-

ods of time is dangerous and may lead ods of time is dangerous and may lead to accidents. When driving, view the to accidents. When driving, view the screen only for short periods of time.screen only for short periods of time.

phone allows the user to

Bluetooth

Wireless Technology,

3-2 I Bluetooth

CAUTIONS upon Connecting

Bluetooth

•Before connecting the head unit with the mobile phone, check to see that the mobile phone supports Bluetooth tures

•Even if the phone supports Wireless Technology, the phone will not be found during device searches if the phone has been set to hidden state or the Bluetooth Disable the hidden state or turn on the Bluetooth connecting with the head unit.

•If Auto Connection is used, the Bluetooth nected when the ignition is turned on, making it unnecessary to have to connect the phone with the head unit every time.

Phone

fea-

Bluetooth

power is turned off.

power prior to searching/

phone is automatically con-

•If you do not want automatic connection with your Bluetooth Bluetooth

feature off of the Bluetooth®

device, turn the

device.

•Park the vehicle when connecting the head unit with the mobile phone.

•Bluetooth

connection may become intermittently disconnected in some mobile phones. Follow these steps to try again.

1. Turn the Bluetooth

function within the mobile phone OFF/ON and try again.

2. Turn the mobile phone power OFF/ ON and try again.

3. Completely remove the mobile phone battery, reboot, and then again.

4. Reboot the Multimedia System and try again.

5. Delete all paired devices from both of Phone and Head Unit sides and then try again

•The Handsfree call volume and quality may differ depending on the mobile phone.

•Pairing Bluetooth other Bluetooth

devices and use of

features are not supported when the vehicle is in motion. For safety, please first park your vehicle.

•If you continue having issues with downloading contacts, please check the mobile phone status or inquire of the mobile phone manufacturer.

Before Using the Bluetooth® Handsfree I 3-3

Bluetooth Connection

Pairing a New Device

Before you can use the Bluetooth feature, you must first pair/connect your mobile phone to your car. Up to 5 Bluetooth devices can be paired. Only one Bluetooth device can be connected at a time.

Pairing a New Device by Selecting Phone/Call

Select

control. ▶ Pair your car after your mobile phone detects the Bluetooth device. ▶ Enter the passkey or accept the authorization popup. ▶ Connect Bluetooth.

PHONE

key in the head unit or

key in the steering wheel remote

Pairing a New Device Through the Phone Settings

Phone

Select

SETUP

key in the head unit. ▶

. ▶ Select

Add New

Bluetooth Connection

. ▶ Pair your car after

Select Select

▶

your mobile phone detects the Bluetooth device. ▶ Enter the passkey or accept the authorization popup. ▶ Connect Bluetooth.

The default passkey is 0000. The vehicle name above is an example. Check the actual information on the product.

Connecting Bluetooth Devices

Connects the Bluetooth devices that you add.

Connecting Devices by Selecting Phone/Call

Select

control. ▶ Select the name of the device to connect. ▶ Connect Bluetooth.

PHONE

key in the head unit or

key in the steering wheel remote

3-4 I Bluetooth

Connecting Devices Through the Phone Settings

Select Select

▶

SETUP

key in the head unit. ▶

Phone

. ▶ Select

Bluetooth Connection

Select the name of the device to connect. Connect Bluetooth.

Disconnecting Bluetooth Devices

Disconnects Bluetooth devices that are

connected.

Select Select

▶

connect.

SETUP

key in the head unit. ▶

Phone

. ▶ Select

Bluetooth Connection

Select the name of the device to dis-

Deleting Bluetooth Devices

Deletes the Bluetooth devices that you added. Note that deleting a Bluetooth device will delete all Call History and Contact Info downloaded along with it.

Select

SETUP

Phone

. ▶ Select

Delete Devices

key in the head unit. ▶

Bluetooth Connection

. ▶ Select the device

Delete

Select

▶

name to delete. ▶ Select

Bluetooth Connection I 3-5

Bluetooth Phone

Phone Status Icons

Shows the current phone status in the right top of the display.

Icons Description

You can use Bluetooth phones when a Bluetooth Hands-free connection is established.

You can use Bluetooth audio features when a Bluetooth audio connection is established.

You can use Bluetooth phones and audio features when both Bluetooth Hands-free and audio connections are established.

Call signal strength indicator

Battery level of the Bluetooth devices connected

Downloading Call History list

Downloading Contacts

In a Bluetooth phone call

Microphone muted

Information

• The battery level icon and the call signal

strength indicator may not be supported in some Bluetooth devices.

• The battery level may differ from the actual

el remaining

3-6 I Bluetooth

Dial

Dials a call after the Bluetooth devices are connected.

•Select

remote control.

•You can also select

PHONE

key in the head unit or

key in the steering wheel

All Menus

▶

Phone

Name Description

Use the keypad to enter the phone number that you want

Keypad

Delete

Settings

Call

to call. Press and hold the last number of a speed dial to dial a number that you added to the Speed Dial list in the phone

Deletes the numbers that you entered.

Moves to a screen of Phone Settings.

Makes a call after you dial a number and select CALL. If the number is listed in Dialed Calls, you can select the number and press CALL to automatically dial that number again.

Information

• Some types of mobile phones may not

support the Speed Dial function.

Accept/Reject Call

If there is an incoming call after you made a Bluetooth connection, a popup message will appear.

Name Description

Reject

Information

• In some mobile phones, the caller's number

may not be displayed, and the Reject feature may not be supported.

Answers the call.

Ignores the call.

Bluetooth Phone I 3-7

Using the Menu During a Phone Call

When making a call, you can use the following menu items.

Name Description

Use Private

End

Contacts

Outgoing Volume

Keypad

Switch

Switches a voice call from the car Hands-free to the mobile phone.

Ends a call.

Displays the Contacts list.

Displays the Mic Volume settings. You can adjust the in-call volume that the other party hears (level 1 - 5).

Moves to a screen for entering ARS numbers.

Switches to a call on hold, if any. You can also switch calls by selecting the number in the Information Display. The Switch function switches the current call to a waiting call in order to answer a new incoming call.

Information

• If the caller's number is listed in Contacts, the

caller's name will be displayed. Otherwise, only the number will be displayed. In some mobile phones, the phone number may not be displayed.

• In some Bluetooth devices, the Use Private

eature may not be supported.

• In some Bluetooth devices, the Switch feature

y not be supported.

• During a phone call on a Bluetooth Hands-

, you cannot access other modes, such as

free Radio and Settings.

• Depending on handset types, the in-call

olume the other party hears may differ. If the

v other party hears your voice too low or too loud, adjust the mic volume.

3-8 I Bluetooth

Call History

Select then

PHONE

Call History

key in the head unit ▶ and

Name Description

All

Dialed

Received

Missed

Call History

Information

Download

Call

Contacts Info

Lists the all call history.

Lists the calls that you made.

Lists the calls that you have received.

Lists the calls you missed.

Displays all of your call history. Select from the list to dial the number.

Displays the details of your call history information.

Downloads the call history information from your mobile phone.

Dials the selected number in your Call History Information.

Goes to the Contact Information screen if the number has been stored.

Information

• In some mobile phones, call records may not

be added to your Call History.

• Calls from restricted ID's are not added to

your Call Histor

• Up to 50 calls can be added in each Dialed

Calls/Received Calls/Missed Calls list.

• The dur

not display

• While the call history download is in progress,

the status bar displays an icon (

• If the call history download is turned off on the

Bluetooth device will fail.

• Some devices require a device authentication

or do

wnloading your call history. If download

f fails, check if the Bluetooth settings or display status are normal.

• Some devices do not support call history

wnload.

do supports download feature. For details regarding Bluetooth-supported devices and their functional compatibility, visit https://www. hyundaiusa.com/bluetooth

y Information.

ations of each dialed/received call are

ed in your car's Call History list.

, the call history download

Check if your Bluetooth device

Bluetooth Phone I 3-9

Contacts

Select then

PHONE

Contacts

key in the head unit ▶ and

Name Description

Contacts List

Information

Download

Search by

Name

Search by

Number

Add to

Favorites

The list of Contacts. Select from the list to dial the number.

Displays contact information.

Downloads contacts from your mobile phone.

Searches Contacts for the name that you enter.

Searches Contacts for the number that you enter.

Adds a phone number to Favorites.

Information

• Up to 5000 phone numbers can be

downloaded from a single, paired Bluetooth device.

• You cannot edit or delete downloaded phone

umbers from your car.

• Contacts can be viewed only when the

Bluetooth de

• Even if the Bluetooth device is disconnected,

the do (Note that deleting a paired phone will also delete all downloaded Contacts and Call History data)

• Downloaded phone numbers may be lost

depending on the condition of the head unit. Keep your important data in a safe place.

• Contacts from both the SIM card and your

mobile phone are do time by default.

• The status bar displays a (

downloading contacts.

• The download will not be available if the

contacts do your Bluetooth device.

vice is connected.

wnloaded data will remain.

wnloaded at the same

) while

wnload function is turned off on

3-10 I Bluetooth

• Some devices require a device authentication

for downloading your contacts. If download fails,check your phone screen and conﬁ rm the download if necessary.

• Some devices do not support contacts

wnload feature. Check if your Bluetooth

do device supports contacts download. For Bluetooth supporting devices details and compatibility, visit https://www.hyundaiusa. com/bluetooth

Favorites

Select then

PHONE

key in the head unit ▶ and

Favorites

Name Description

Favorites

Add New

Delete Items

Delete All

Lists the phone numbers saved as Favorites. Select from the list to dial the number.

Adds a new number to Favorites.

Deletes numbers that you select from Favorites.

Deletes all of the numbers from Favorites.

Bluetooth Phone I 3-11

MEMO

part.4

Blue Link

Name and Function of Each Part

Before Use

Getting Started with Blue Link

Driving Info

Vehicle Diagnostics

Blue Link Settings

Blue Link

Name and Function of Each Part

Rear View Mirror Switch

Using the Rear View Mirror switch

Selecting the Rear View mirror switch will allow you to make service required inquiries, place search, and emergency Service by connecting to the Blue Link Center. Such features can be used only after subscribing to the Blue Link service.

Instructions

Display

Starts or ends the Blue Link call.

Moves to the navigation map for Android Auto, if connected.

SOS

※

Refer to Blue Link service manual for more Blue Link features.

Starts or ends the SOS call.

Contents

※

The actual feature in the vehicle may differ from the illustration.

4-2 I Blue Link®

Before Use

What Is Blue Link?

This is a Hyundai telematics service based on our cutting-edge IT system that makes your driving experience more convenient and fun and features safety, security, vehicle diagnostics, remote control and even smartphone synchronization functions. Enjoy a smarter driving style with Blue Link.

What Is Telematics?

The word “Telematics” stems from the combination of telecommunications and informatics, and refers to an information system that provides a variety of driving information through the built-in terminal by analyzing each symptom and driving state. This allows for a much safer and more comfortable driving experience.

About Transmission and Reception of Radio Waves

For radio wave transmission/reception status, refer to the status displayed on the Blue Link screen. It is recommended that you use the Blue Link system when the antenna icon (

Connection to the Blue Link Center or wireless data transmission may be disrupted in the following places.

•

Inside tunnels

•

Mountainous areas or dense forest

•

Roads close to cliff edges

•

Densely built-up areas

•

On highways or roads underneath higher interchange roads

•

Inside buildings

) shows four bars or more.

Before Use I 4-3

Getting Started with Blue Link

Use Blue Link features such as Driving Info and Vehicle Diagnostics. Blue Link features can be used after activating the service.

Information

• A separate fee may be charged for using Blue

Link, and features may differ according to your service plan.

Select the

BLUELINK

key in the head unit.

Name Description

Displays information such

Driving Info

Vehicle Diagnostics

Blue Link Settings

as Driving Time/Idle Time, Deceleration/Acceleration Distribution, Driving Speed and Driving Distance.

Inspects vehicle malfunctions and provides diagnostics.

Activates the service or displays modem information.

Connecting with the Blue Link Center

Press the key in the rear-view

mirror to connect with the Blue Link center.

4-4 I Blue Link®

Blue Link® Safety and Security Service

Auto Crash Notiﬁ cation

Provides immediate assistance when an accident occurs and an airbag is deployed. In this event, an ACN signal, containing customer and location information, will automatically be transmitted to the response center. Upon receipt of the signal, a response specialist will attempt to establish voice communications with the vehicle occupants and forward any pertinent information to Blue Link emergency services.

SOS

Customers request emergency Blue Link emergence services by pressing the dedicated

This action transmits vehicle information and location to specially trained response specialists, who assist in coordinating the dispatch of appropriate emergency assistance to the customer.

The response specialist remains on the line with the customer until advised assistance has arrived.

key in the vehicle.

SOS

Stolen Vehicle Recovery

In the event a customer’s vehicle is reported stolen (and a stolen vehicle report has been filed with the appropriate police department), the response center can provide assistance to the police in an attempt to recover the vehicle.

Vehicle Slowdown

Used with Stolen Vehicle Recovery, this enables law enforcement to gradually reduce the engine power of the vehicle, thus slowing it down to safe levels. A warning shall be transmitted to the driver prior to the slowdown procedure.

Vehicle Immobilization

Used with Stolen Vehicle Recovery, this enables law enforcement to send a signal to the vehicle which immobilizes the engine management system, thus preventing startup. This capability is only valid when the ignition is off, but can be saved for later immobilization if the vehicle is on or in motion at the time of signal transmission.

Getting Started with Blue Link I 4-5

Driving Info

Select the Select

BLUELINK

Driving Info

key in the head unit ▶

Vehicle Diagnostics

Select the Select

BLUELINK

key in the head unit ▶

Vehicle Diagnostics

You can have your vehicle inspected only after stopping the vehicle because some control units can't be diagnosed while driving. Vehicle Diagnostics will be canceled if you switch to another screen while diagnosis is in progress. To receive result details, you need to first sign up to the Blue Link.

Blue Link Settings

This service can be used while your car is stopped and the engine is on. Select

Update

button to receive up-to-

date driving information.

4-6 I Blue Link

Name Description

Service Link

Calls the Blue Link Center to check for vehicle problems

For more details, refer to part 8. Setup > Blue Link Settings.

part.5

Voice Recognition Screen Overview

Voice Recognition

What is Voice Recognition?

Precautions Required for Successful Voice Recognition

Starting/Ending and Setting Voice Recognition

Voice Commands

Siri Eyes Free

Voice Recognition

What is Voice Recognition?

Voice recognition technology runs the system as ordered by recognizing your voice command for operation of the multimedia while y

ou are driving the car. Regretfully, not all possible voice commands are recognized by the system due to technological limitations. To make up for these limitations, the system displays the voice commands that are available for you to use. There are errors in communication between people. Likewise, voice recognition sometimes misunderstands your voice command in some circumstances. If this happens, either check the screen for the available options and say the command again, or manually select and press the button for the corresponding command on the screen.

Precautions Required for Successful Voice Recognition

1. Voice recognition supports only the commands that are displayed on the screen and written in the User's Guide.

2. To ensure the correct recognition and execution of your command, say your command when you hear the beep after a voice prompt.

3. Voice recognition automatically ends if:

1) A call is incoming or outgoing

2) A media (USB or iPod, etc.) is con-

nected or disconnected

3) The front or rear view camera is

operated (optional)

4) The car engine starts or stops

5) A system key, such as

MEDIA

key is selected

RADIO

key

4. The microphone that recognizes your voice is located over the head part in the driver's seat. To make your commands better understood, keep your body straight in the driver's seat when speaking the command.

5. Speaking naturally and clearly will ensure better recognition of your voice commands.

6. In the following cases voice recognition will be affected by ambient noise.

1) The sound of the wind if any win-

dow or the sun roof is open.

2) High speed blower from the air

ents. Set climate control to blow

lower than level 3.

Vibrations from passing through a tunnel.

4) Vibrations from driving on an

uneven road.

5) Storms and heavy rain.

5-2 I Voice Recognition

Starting/Ending and Setting Voice Recognition

Starting Voice Recognition

Press the key briefly (less than 0.8

seconds) on the steering wheel control to activate voice recognition.

Ending Voice Recognition

1. Select “Exit” to the left of the bottom to end voice recognition.

2. Press and hold (over 0.8 seconds) the

key on the steering wheel con-

trol to end voice recognition.

Quick Run of Voice Recognition (Manual Mode)

Usually, you are supposed to say a command to execute the desired operation after the voice guidance. However, it takes a little time to wait for the voice guidance. If you would like to activate the desired operation more quickly, you can just touch the commands displayed on the screen.

This feature is useful when you feel the voice guidance is too long or voice commands do not work as you desired.

Starting/Ending and Setting Voice Recognition I 5-3

Extending the Listening Time

When the system is waiting for your command, after the voice prompt and beep have been heard, if you press the

key (shorter than 0.8 seconds), then the beep will sound again and standby mode will restart.

When activated, voice recognition waits for your command for 5 seconds. If you say nothing for 5 seconds, a voice prompt will ask for your command again.

5-4 I Voice Recognition

Skipping Prompt Messages

When you hear the prompt message, press the

wheel remote control to skip the message and go directly to listening mode to say y

our command.

This results in faster operation when you feel the message is too long or you already know the command to use.

key on the steering

Adjusting Voice Recognition Volume

During voice recognition, rotate the volume knob to adjust the message volume.

Starting/Ending and Setting Voice Recognition I 5-5

Voice Recognition Screen Overview

Start Screen

Name Description

Most frequently used commands

Not available command

Displays the six most frequently used commands.

Displays commands that are not available due to a failure in meeting the conditions for using them and thus need additional settings. The conditions required for using them will be described briefly under each command.

Name Description

Voice

recognition status icons

Recognized

results

User's

speaking volume being recognized

Help

Exit

Standby Voice guidance Voice command process

Displays the voice recognition result.

Displays the voice command volume in real time.

Displays all available help commands in a tree format.

Ends the voice recognition.

Help Display

Name Description

• Shows the available

Command list

How to use for selected item

How to use in general

commands.

•Select or say a command to display additional commands in detail.

This section shows how to use voice recognition for the selected item.

This section displays how to use voice recognition in general.

5-6 I Voice Recognition

Instructions for Using Voice Recognition

Name Description

Detail instruction

Close button

This section describes how to use voice recognition in detail.

Closes the screen and restarts voice recognition.

Information

• In the instructions screen, no voice is recognized, so you must manually issue commands. Because the instructions screen displays a lot of content, you can not view it while driving for safety precautions.

Voice Recognition Screen Overview I 5-7

Voice Commands

Types of Commands

Voice recognition commands are classified as “Global Commands” and “Local Commands”.

1. Global Commands (

ately after activating voice recognition.

2. Local Commands (

multimedia or Bluetooth function is running, or displayed on the screen, after activating voice recognition.

Call Commands

* Check the following before using call commands :

1. Voice commands related to phone calls can be used after connecting a Bluetooth device.

To call a person, for example “Call <John Smith>” whose name

is listed in Contacts, you must first download the Contacts list. For details on downloading contacts, see “Part 3. Using Bluetooth > Chapter 3. Bluetooth Phone > 3.10 Contacts”.

3. After downloading the Bluetooth contacts, it will take some time to convert the Contacts into voice data during which time you cannot make a call by name yet. The time it takes to convert v

oice data may vary depending on the number of Contacts

downloaded on the phone.

): Commands that can be used immedi-

●

): Commands that can be used when a

○

Command Operation

Call

●

Call <Name>

●

Call <Name> on

●

Mobile

Call <Name> in

●

Office

Call <Name> at

●

Home

Call <Name> on

●

Other

Dial Number

●

Dial <Phone #>

●

Redial

●

Call History

●

Displays downloaded Contacts, after this you can make a call by saying the name.

You can directly call a person by <Name> in the downloaded Contacts.

You can call a person <name> directly to

umber that is saved as “Mobile” in

the n the downloaded Contacts. e.g.) Call “John Smith” on Mobile

You can call a person <name> directly to

umber that is saved as “Office” in the

the n downloaded Contacts. e.g.) Call “John Smith” in Office

You can call a person <name> directly to

umber that is saved as “Home” in the

the n downloaded Contacts. e.g.) Call “John Smith” at Home

You can call a person <name> directly to the n

umber that is saved as “Other” than “Mobile, Home, or Office” in the downloaded Contacts. e.g.) Call “John Smith” on Other

Displays a screen where you can say a phone number to dial.

You can directly say the number to call. e.g.) Dial 111 555 1234

Directly calls at the number that you last dialed.

Displays your Call History, where you can say the list number to make a call.

5-8 I Voice Recognition

Radio Commands

Command Operation

Radio

●

FM Plays FM radio.

●

<87.5~107.9>

SiriusXM Plays SiriusXM™ radio.

●

SiriusXM

●

<0~999>

AM Plays AM radio.

●

AM <530~1710>

●

Preset <1~40> Tunes to your preset stations (1 to 40).

○

Channel

○

<0~999>

Plays the most recent radio channels from FM, AM, and SiriusXM™.

Tunes to FM <Frequency> according to what you say. e.g.) FM 87.5: FM eighty seven point five

Tunes to SiriusXM™ Channel <Channel Number> according to what you say. e.g.) SiriusXM 23: SiriusXM Twenty three

Tunes to AM <Frequency> according to what you say. e.g.) AM 530: AM Five Thirty

In SiriusXM™ Radio mode, turns on the <Channel Number> that you say.

Voice Commands I 5-9

Media Commands

* Check the following before you use media commands.

1. If no media is connected or if no playable files exist at the time when you use these commands, a voice message will tell you that this is not available.

2. If you say the name of the media that is currently playing again, then that media will continue playing.

e.g.) Saying “USB” while USB content is playing.

Command Operation

Music Continues the last media you played.

●

Plays the iPod currently connected. This

iPod

●

USB

●

Bluetooth Audio

●

AUX

●

My Music Plays My Music files stored in the system.

●

Pandora Radio

●

will work the same when an iPhone is connected. If a USB is connected, then it will be played instead of the iPod.

Plays the music on the USB currently connected. If an iPod is connected, then the iPod will be played instead of the USB.

Plays the music on the Bluetooth phone currently connected. This may not be supported depending on the Bluetooth connection status.

Plays external devices that are currently connected.

Plays Pandora Radio that is currently connected.

5-10 I Voice Recognition

1. Audio CD Command

2. MP3 CD / USB Music / iPod / My Music Command

Command Operation

○

Play

Pause

Track <1~99>

Shuffle

Shuffle Off

Repeat

Repeat Off

Plays a paused track. Maintains the current settings during playback.

Pauses a track that is currently playing. Maintains current settings while paused during playback.

Plays a desired track number.

Plays tracks or files randomly. Maintains current settings during shuffled playback.

Cancels Shuffle and plays tracks sequentially. Maintains current settings during sequential playback.

Plays the current track repeatedly. Maintains the current settings during repeat playback.

Cancels Repeat and plays multiple tracks or files. Maintains current settings during multiple track playback.

Command Operation

○

Play

Pause

Shuffle

Shuffle Off

Repeat

Repeat Off

Plays a selected file. Maintains the current settings during playback.

Pauses a file that is playing. Maintains current settings while paused during playback.

Plays tracks or files randomly. Maintains current settings during shuffled playback.

Cancels Shuffle and plays tracks sequentially. Maintains current settings during sequential playback.

Plays the current track or file repeatedly. Maintains the current settings during repeat playback.

Cancels Repeat and plays multiple tracks or files. Maintains current settings during multiple track playback.

Voice Commands I 5-11

3. Pandora Radio command 4. Bluetooth audio / AUX command

Command Operation

Skip Moves to the next track.

○

If you like the genre of the music currently

Thumbs up

○

Thumbs down

○

Play

○

Pause

○

Shuffle

○

playing, say “Thumbs up” so that more similar music will play.

If you don’t like the music currently playing, say “Thumbs down” to minimize the number of playbacks of similar genre music.

Plays a selected file. Maintains the current settings during playback.

Pauses a file that is playing. Maintains current settings while paused during playback.

Plays tracks or files randomly. Maintains current settings during shuffled playback.

For Bluetooth audio and external devices (AUX), local commands are unavailable, including Play, Pause, Repeat and Shuffle.

5-12 I Voice Recognition

Other Commands List (Commands used in List / Help)

Command Operation

Moves to the voice recognition help screen.

Help

●

Line 1~4

○

(One~Four)

Yes / No

○

Previous/Next

○

Manual Input

○

Go Back Moves to the previous screen.

○

Exit Ends the voice recognition.

●

All available commands can then be identified and used.

When you cannot select a certain name, such as in Call History, you can select it using numbers. Simple numbers can be recognized, such as “One” or “Two”.

When voice recognition is activated, this command is used when an answer is requested for a confirmation question.

When four or more searched items are listed, you can move to the previous or next page using a voice command.

When Dial entry results are displayed, this command is used to search manually, rather than to search with a voice command. Voice recognition stops after this command is used.

Voice Commands I 5-13

Siri Eyes Free

How to start Siri

If you want to use Siri, you have to connect your iOS device to Multimedia system through Bluetooth. (Please check whether your iOS device supports Siri and turning Siri On) Then you can use Siri while pressing and holding

key on the steering wheel.

How to use Siri

When you access the Siri screen while pressing and holding

steering wheel, you can press ton and then you can speak what you want. Please see the Multimedia system only supports “Phone” related functions. Other functions will be performed in your iOS device. If you press voice key quickly, Siri would re-start. If you hold down voice key, Siri would be terminated and the screen would go back to the previous screen. Eyes-Free mode would be activated automatically while you are driving. When shifting gears into P or putting the Parking break on, Eyes-Free mode would be deactivated automatically.

key on the

pea

but-

Information

• Functions and feedbacks from voice commands via Siri are executed in iOS device. If iOS version changed, functions and feedbacks can be changed according to iOS device.

5-14 I Voice Recognition

part.6

Apps/Info

Start up

Pandora

SiriusXM™ Data

SoundHound

Android Auto

Apps/Info

Start Up

APPS/

Press the

screen. The screen is composed of :

• “Pandora phone

• “Quick Guide” to provide information about how to controls and major functions

• “SiriusXM Data” to show weather, traffic, stock, gas station, sports, and movie information provided by SiriusXM™ Travel Link.

• “Voice Commands” to provide information about available voice command list to use voice recognition.

• Android Auto to conveniently use various functions of your mobile phone while driving (For more information, refer to the manual from Google or visit its company website.).

key on the head unit to move to the information

” to listen to Pandora® Radio by connecting a smart

Pandora

Press the “Pandora” icon after selecting All Menus or the

key to enter Pandora®. Pandora, the Pandora logo, and the Pandora trade dress are trademarks or registered trademarks of Pandora Media, Inc. Used with permission. Pandora is only available in certain countries. Please visit http://www.pandora.com/legal for more information.

APPS/

6-2 I Apps/Info

Pandora® Screen Controls

Name Description

Mode Displays current operating mode.

Station Name Shows the station name current playing.

Artist Name Shows the artist/title information current playing.

Song Title Shows the song title current playing.

Album Name Shows the album name current playing.

Play Time Displays the current play time.

Name Description

If you don’t like the music current playing, press this button to move to the next music and to min-

Thumbs

Down

imize the number of playbacks of similar genre music.

You can move to next song up to specific times

which Pandora

allows

If you like the genre of the music current playing, press this button to send a “Thumbs Up” signal to

Thumbs Up

Pandora

so that more similar music will play.

This function can not be reset once setting is

chosen.

Add the music current playing to the bookmarks list.

Bookmark Tr a ck

You can view your bookmarked songs from your Pandora com, then click on the “Your profile” button above the player. That will bring up a page with

profile online. Go to pandora.

your stations, bookmarked songs. This function can not be reset once setting is

chosen.

Play/Pause Plays/pauses the current song

Moves to the next track

SKIP

You can move to next song up to specific times which Pandora

allows

Station List Moves to the station list screen.

Shared

Station Icon

Indicates that the station is already shared.

Thumbs Up/Down in not available for shared

stations.

Pandora® I 6-3

Name Description

•Sound Settings Moves to the sound settings screen.

•Quit Exit current Pandora previous AV mode.

You can view your bookmarked artists and songs from your Pandora pandora.com, then click on the “Your Profile” button above the player. That will bring up a page with your stations, bookmarked artists, and bookmarked songs.

SoundHound

Icon

SEEK/TRACK

TUNE

Moves to the SoundHound searching music application.

Press briefly to play the next song.

Rotate the Press the

TUNE

knob to search for a station.

TUNE

knob to play the station when

you find the name that you want.

mode and then move to

profile online. Go to

6-4 I Apps/Info

Name Description

Current

Station

Shuffle

Shared

Station Icon

SEEK/

TRACK

TUNE

Shows the name of the station current displayed.

Shuffling your stations provides a more diverse mix of music by randomly playing songs from the stations in your list.

Sorts stations by the items in the menu.

•A-Z : Sorts stations in alphabetical order.

•By Date: Sorts stations in the order they were generated.

Indicates that the station is already shared.

Press briefly to play the next song.

TUNE

knob to move to the previous/

Rotate the next list. Press the selected file.

TUNE

knob to play a

Pandora® I 6-5

SiriusXM™ Data

All M

About SiriusXM™ Data Service

The SiriusXM™ Data Service is a paid membership satellite radio service that provides users with information such as weather, fuel prices, stocks, sports and movies. However, weather information is not supported for vehicles purchased in Canada.

Accessing SiriusXM™ Data

Press the “SiriusXM Data” icon after selecting

enus

or the

key to enter the SiriusXM™ Data mode.

APPS/

hard-

6-6 I Apps/Info

SiriusXM™ Weather

Announcement

At the “SiriusXM Data” screen, press the “Weather” icon to enter the Weather Announcement mode.

Weather Forecast

This service provides current weather information and weather forecasts for the next five days in your region. To change the region, press the select the desired region.

ther Cit

button and

Warnings and Advisories

This service provides weather warnings and advisories, such as tornado, storm, flood, etc.

SiriusXM™ Data I 6-7

SiriusXM™ Fuel Price Information

At the “SiriusXM Data” screen, press the “Fuel Prices” icon to enter the Fuel Prices Information mode.

Search for Nearby Stations, and Register Key Locations as Favorite Stations.

Search for nearby stations with the “Nearby Stations” menu. It shows station locations, starting from the nearest one, and select “Nearest” menu on the top right side to further sort them by price or brand name.

Select the ★ button to the right of the list to register key locations as a Favorite Station so that you can go there again with the “Favorite Stations” menu.

6-8 I Apps/Info

HYUNDAI MOBIS ATBB0G2AN1 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
