HYUNDAI MOBIS ADC40A9AN, ADBB0A9AN User Manual

CAR MULTIMEDIA SYSTEM

USER'S MANUAL

Read the following safety precautions for your safety

Notations used within this User's Manual

Before using the product, read the contents of this user's manual

carefully and use this product safely.

※

The design and speciﬁ cations of this product may change without prior

notiﬁ cation for product and service improvement.

The actual features in the vehicle may differ from the illustrations.

For more accurate information about the vehicle, please refer to the

catalogue.

※

This Audio system contains open source software, including without

limitation, software distributed and/or modiﬁ ed under the GNU General

Public license, Version 2, June 1991, and the GNU lesser General Public

License, Version 2.1, February 1999.

For additional information and to obtain related materials including

without limitation, the previous referred to licenses and software, please

WARNING

• Failure to observe the instructions within this category could result in death

or serious injury or damage to the vehicle.

CAUTION

• Information on matters that could potentially lead to injury or vehicle

damage/malfunction Information that could lead to higher user safety

Information

• Information and tips that provide additional user convenience in using the

product

NOTICE

• Information on specific features that facilitate proper product use and

functional understanding

• Information on terminology used within this manual

K_UMa_UVO3[USA_EU]AV_PART0.indd 1K_UMa_UVO3[USA_EU]AV_PART0.indd 1 2016-01-27 오후 4:22:522016-01-27 오후 4:22:5

iPod

iPod® is a registered trademark of Apple Inc.

Bluetooth®

Wireless Technology

A compatible Bluetooth® Wireless Technology-enabled cell phone is

required to use Bluetooth

The Bluetooth

word mark and logos are registered trademarks owned

Wireless Technology.

by Bluetooth SIG, Inc. and any use of such marks by Kia is under license.

Other trademarks and trade names are those of their respective owners.

A Bluetooth

enabled cell phone is required to use Bluetooth® Wireless

Technology.

A Bluetooth

Bluetooth

Wireless Technology enabled cell phone is required to use

Wireless Technology. Bluetooth® Wireless Technology phone

compatibility can be checked by visiting http://www.kia.com.

HD Radio™ Technology

HD Radio™ Technology manufactured under license from iBiquity Digital

Corporation. U.S. and Foreign Patents.

HD Radio™ and the HD, HD Radio, and "Arc" logos are proprietary

trademarks of iBiquity Digital Corp.

Pandora

Pandora, the Pandora logo, and the Pandora trade dress are trademarks

or registered trademarks of Pandora Media, Inc. Used with permission.

Pandora is only available in certain countries. Please visit http://www.

pandora.com/legal for more information.

Wi-Fi

The Wi-Fi CERTIFIED™ Logo is a certiﬁ cation mark of Wi-Fi Alliance.

K_UMa_UVO3[USA_EU]AV_PART0.indd 6K_UMa_UVO3[USA_EU]AV_PART0.indd 6 2016-01-27 오후 4:22:542016-01-27 오후 4:22:5

part.1

Component Names and Functions

Starting the System for the First Time

Basic

Warnings and Cautions

Key Product Features

K_UMa_UVO3[USA_EU]AV_PART1.indd 1-1K_UMa_UVO3[USA_EU]AV_PART1.indd 1-1 2016-01-27 오후 4:23:052016-01-27 오후 4:23:0

Basic

Safety Warnings

• Do not stare at the screen while driving. Staring at the screen for prolonged periods of time could lead to traffic accidents.

• Do not disassemble, assemble, or modify the Multimedia system. Such acts could result in accidents, fire, or electric shock.

• Heed caution not to spill water or introduce foreign objects into the device. Such acts could lead to smoke, fire, or product malfunction.

• If you use phone related functions while driving, you will find it difficult to concentrate on operating the vehicle and the current traffic conditions, so the possibility of an accident may increase. Please use phone related functions only when parked.

• Please refrain from use if the screen is blank or no sound can be heard as these signs may indicate product malfunction. Continued use in such conditions could lead to accidents (fires, electric shock) or product malfunctions.

• Do not touch the antenna during thunder or lightening as such acts may lead to lightning induced electric shock.

• Do not stop or park in parking-restricted areas to operate the product. Such acts could lead to traffic accidents.

• For most Audio and multimedia modes, the display will not operate when the vehicle is in motion. For your safety, first park the vehicle to watch or view the screen.(The screen will only operate when the parking brake is ON for manual transmission vehicles and when the parking brake is ON or the gearshift is in the P (PARK) position for automatic.)

• Some functions other than the one mentioned above cannot be used while driving. These functions operate only when the vehicle is parked.

1-2 I Basic

K_UMa_UVO3[USA_EU]AV_PART1.indd 1-2K_UMa_UVO3[USA_EU]AV_PART1.indd 1-2 2016-01-27 오후 4:23:052016-01-27 오후 4:23:0

Safety Cautions

Pay attention to traffic conditions while driving.

• Operating the device while driving could lead to accidents due to a lack of attention to external surroundings. First park the vehicle before operating the device. In addition, the touch screen may not work for some functions when the vehicle is in motion. The touch screen feature will be supported once the vehicle has stopped.

• Adjust the volume to levels that allow the driver to hear sounds from outside of the vehicle. Driving in a state where external sounds cannot be heard may lead to accidents.

• Pay attention to the volume setting when turning the device on. A sudden output of extreme volume upon turning the device on could lead to hearing impairment. (Adjust the volume to a suitable levels before turning off the device.)

• If you want to change the position of device installation, please inquire with your place of purchase or service maintenance center. Technical expertise is required to install or disassemble the device.

• Turn on the car ignition before using this device. Do not operate the Multimedia system for long periods of time with the ignition turned off as such operations may lead to battery discharge.

• Upon using the Multimedia system for more than 10 minutes with the car engine turned off, the following warning will be displayed. After 10 minutes, the warning will be displayed for 5 seconds every 1 minute.

• Do not subject the device to severe shock or impact. Direct pressure onto the front side of the monitor may cause damage to the LCD or touch screen.

• When cleaning the device, make sure to turn off the device and use a dry and smooth cloth. Never use tough materials, chemical cloths, or solvents(alcohol, benzene, thinners, etc.) as such materials may damage the device panel or cause color/quality deterioration. When experiencing product concerns, inquire with your place of purchase or service maintenance center.

• Prevent caustic solutions such as perfume and cosmetic oil from contacting the dashboard because they may cause damage or discoloration.

Warnings and Cautions I 1-3

K_UMa_UVO3[USA_EU]AV_PART1.indd 1-3K_UMa_UVO3[USA_EU]AV_PART1.indd 1-3 2016-01-27 오후 4:23:062016-01-27 오후 4:23:0

Key Product Features

This device is a Multimedia system equipped with a multifunctional disc player that supports Radio (FM, AM), HD Radio™ Technology (if equipped), SiriusXM™, Audio CD, MP3, USB, iPod, AUX, Bluetooth Audio and My Music features. The WIDE VGA LCD provides a high quality resolution while the powerful and rich sound system adds to the driving enjoyment.

Wide TFT-LCD Display

Display

Radio

Multimedia

Player

• Provides high quality video through a Wide TFTLCD Display using an LED Back Light.

• Touch screen for maximum user convenience.

Digital Tuner Feature

• Digital Tuner using PLL method that supports memory of 40 broadcast stations.

Radio broadcast station name

• Displays broadcast station names.

HD Radio™(if equipped)/Satellite Radio feature

• Supports HD Radio™(if equipped) reception and Satellite Radio (SiriusXM™).

Support for various Media Formats

• Support for various media formats, including Radio, Audio CD, MP3, USB, iPod, AUX and Bluetooth

Audio Streaming modes

My Music

• Supports copying of music stored within USB devices into My Music (internal memory) mode

Miscellaneous

Bluetooth

• Convenient use of Bluetooth

Wireless Technology

Handsfree by

using buttons within the steering wheel control

Digital Screen Control Features

• Easy control of features through touch screen options

Steering Wheel Control

• Control over audio features, voice recognition and Bluetooth

through the steering wheel

control for maximum convenience

1-4 I Basic

K_UMa_UVO3[USA_EU]AV_PART1.indd 1-4K_UMa_UVO3[USA_EU]AV_PART1.indd 1-4 2016-01-27 오후 4:23:062016-01-27 오후 4:23:0

Component Names and Functions

Head Unit

Name Description

Press to insert or eject disc

RADIO

MEDIA

SEEK

TRACK

PWR/

VOL

Selects FM/AM/SiriusXM™ mode

• Each time this is pressed, the mode is changed in the following order: FM → AM → SiriusXM™ → FM.

Selects MEDIA mode.

• If the media is not connected MEDIA mode will not be activated.

When pressed quickly (less than 0.8 seconds),

• FM/AM mode: Plays the previous/next frequency.

• SiriusXM™ mode: Changes the channel.

• MEDIA (Disc/USB/iPod/My Music) mode: Changes the track, file or title (except for USB Image and AUX).

When pressed and held down (more than 0.8 seconds),

• FM/AM mode: Continuously changes the frequency until the key is released.

• MEDIA (Disc/USB/iPod/My Music) mode: Rewinds or fast forwards the track or file (except for USB Image, Bluetooth Audio, and AUX).

• When power is off, press to turn power on.

• When power is on, press and hold (more than 0.8 seconds) to turn the power off.

• When power is on, press quickly (less than 0.8 seconds) to turn Audio off.

• Turn left/right to adjust the volume.

Name Description

DISP

APPS/

PHONE

UVO

SETUP

Turns the screen on/off.

Moves to the Apps/Info screen.

Displays the Bluetooth phone mode.

Displays the UVO mode

Moves to the Setup screen.

• FM/AM mode: Changes the frequency.

• SiriusXM™ mode: Changes the channel.

TUNE

• MEDIA (Disc/USB/iPod/My Music) mode: Changes the track, file or title (except USB Image, Bluetooth Audio, and AUX).

RESET

※

The actual feature in the vehicle may differ from the illustration.

Resets the system settings. (Preset radio channels and other data will not be deleted)

Component Names and Functions I 1-5

K_UMa_UVO3[USA_EU]AV_PART1.indd 1-5K_UMa_UVO3[USA_EU]AV_PART1.indd 1-5 2016-01-27 오후 4:23:062016-01-27 오후 4:23:0

Steering Wheel Controls

Name Description

When pressed quickly (less than 0.8 seconds),

• If Android Auto is not connected, activates the multimedia system voice recognition

• If Android Auto is connected, activates or ends Google voice recognition

When pressed and held (more than 0.8 seconds),

• If the multimedia system voice recognition is activated, ends the multimedia system voice recognition

• If Android Auto is connected, activates or ends Google voice recognition

• If iOS device is connected through Bluetooth, activates or ends Siri Eyes Free

• Each time this is pressed, the mode is changed in the f

ollowing order: FM → AM → SiriusXM → Disc

→

USB or iPod → AUX → Bluetooth Audio → My

Music → Android A

MODE

• If the media is not connected, the corresponding modes will be disab

• Press and hold (more than 0.8 seconds) to turn the Audio system on/off

• When power is off, press button to turn power back on

※

The actual feature in the vehicle may differ from the illustration.

Controls the volume

uto → Pandora → FM

led

Name Description

When pressed quickly (less than 0.8 seconds),

• FM/AM mode: searches broadcast frequencies saved to Presets

• SiriusXM™ mode: searches broadcast channels saved to Presets

• MEDIA (Disc/USB/iPod/My Music) mode: changes the track, file or title (except USB Image, AUX)

When pressed and held (more than 0.8 seconds),

• FM/AM mode: automatically searches broadcast frequencies

• SiriusXM™ mode: automatically searches broadcast channels

• MEDIA (Disc/USB/iPod/My Music) mode: quickly looks up songs (e

xcluding USB images, A

Bluetooth audio files)

When pressed quickly (less than 0.8 seconds),

• When pressed in the dial screen, makes a call

• When pressed in the incoming call screen, answers the call

• When pressed during call waiting, switches to waiting call (Call Waiting)

When pressed and held (more than 0.8 seconds),

• When pressed in Bluetooth the last dialed call

• When pressed during a Bluetooth call, switches call back to mobile phone (Private)

• When pressed while calling on the mobile phone, switches call back to Bluetooth (operates only when Bluetooth connected)

• When pressed during a call, ends the phone call

• When pressed in the incoming call screen, rejects the call

UX and

Hands-free, redials

Hands-free

Hands-free is

K_UMa_UVO3[USA_EU]AV_PART1.indd 1-7K_UMa_UVO3[USA_EU]AV_PART1.indd 1-7 2016-01-27 오후 4:23:132016-01-27 오후 4:23:1

Starting the System for the First Time

Turning the System On/Off

Press the engine start button or set the ignition key to On or ACC. Each time you turn on the system, a boot logo and safety warning will appear.

NOTICE

• You cannot operate the system while it is

booting up. It may take some time for all of features of the system, particularly the voice recognition system, to be ready for use.

Pressing and holding the power key on the head unit will turn off the system. You can change Screen Saver Settings in Setup to display a clock on the Screen Saver.

Information

• If you turn off the system during a phone call

using the Hands-free feature, then the call will automatically switch to your mobile phone.

System Reset

The System Reset function restores the system when it is not operating correctly. Press and hold the ond or longer. (It is recommended that you press the

RESET

a pin or a clip.)

RESET

key for a sec-

key using a tool, such as

Pressing the power key on the head unit will display the safety guide. To change the system language between English, French, Spanish and Korean, select the

Language

K_UMa_UVO3[USA_EU]AV_PART1.indd 1-9K_UMa_UVO3[USA_EU]AV_PART1.indd 1-9 2016-01-27 오후 4:23:152016-01-27 오후 4:23:1

button.

NOTICE

• Check the volume when turning on the

system. Before tur the v

olume to a reasonable level.

ning on the system, adjust

Starting the System for the First Time I 1-9

Battery Warning Message

Always use the system while the car engine is running. If you turn on the system while the engine is off, a battery warning message will appear. When the engine starts, the message will disappear.

Restrictions on Features for Safety Measures

Several features are limited while driving. The restriction screen will disappear when shifting gears into P or putting the parking brake on.

WARNING

- Touching the Antenna During A Thunder Storm

• Do not touch the antenna during thunder or

lightning as such acts may lead to lightning induced electric shock.

NOTICE

• If you use the system for a long time with

the engine off, the battery may become completely discharged.

1-10 I Basic

K_UMa_UVO3[USA_EU]AV_PART1.indd 1-10K_UMa_UVO3[USA_EU]AV_PART1.indd 1-10 2016-01-27 오후 4:23:162016-01-27 오후 4:23:1

WARNING

- Blank Screen

• Refrain from use if the screen is blank or

no sound can be heard as these signs ma indicate product malfunction. Continued use in such conditions could lead to accidents (ﬁ res, electric shock).

Home Screen

Controls Menu Conﬁ guration for the Home Screen

Tap the icon on any screen to display the Home Screen below.

Features Description

Radio/Media

Widget

Connectivity

Widget

All Menus

My Menu

Apps/Info

Setup

• Shows brief information on the radio or media that is now playing.

• Tap the area to move to the mode that you are listening to.

Shows any connected devices such as Android Auto, iPod, Pandora, and Bluetooth.

Shows all of the items in the system menu.

You can add up to eight menus here.

•

• Add your favorite menus to have quick and easy access to them.

Moves to the Apps/Info screen.

Moves to the Setup screen.

Information Display on the Status Bar

Displays the date and time, along with the system status shown by the various icons to the right of the clock. The icons in the following table indicate the various types of system status details and events.

Icon Description

Displayed when the audio is muted.

Displays the remaining battery of the Bluetooth phone.

Displayed when connected to Bluetooth for handsfree.

Displayed when connected to Bluetooth for streaming audio.

Displayed when connected to Bluetooth for streaming audio and handsfree.

Displayed when downloading contacts or recent calls from the Bluetooth phone.

Displayed while on a call with the Bluetooth phone.

Displayed when the microphone of the Bluetooth is muted.

Displays the signal strength of the Bluetooth phone.

Displayed when connected to Wi-Fi.

Displayed when connecting to Wi-Fi.

Displayed when 911 connect is available.

Starting the System for the First Time I 1-11

K_UMa_UVO3[USA_EU]AV_PART1.indd 1-11K_UMa_UVO3[USA_EU]AV_PART1.indd 1-11 2016-01-27 오후 4:23:172016-01-27 오후 4:23:1

Adding Your Favorite Menu Items to My Menu

From the Home screen, select icon, and then

Edit

From the Edit My Menu screen, select menu items from the list on the right, then drag and drop them to a desired place on the left. To remove the item from My Menu, drag item from the left and drop them on the right.

Information

• Up to eight items can be added to My Menu.

My Menu

On-Screen Touch Controls

Learn how to touch the screen to operate the system.

Select

Tap lightly on a menu or an item to select it.

NOTICE

• The system will not recognize your touch if

you wear a glove or other non-conductive material. Touch the screen using your ﬁ nger, an electrostatic touch-screen glove, or a stylus pen.

Drag & Drop

Select a menu or item you want, then drag and drop it to where you want to place it.

Drag or touch the slider along the play bar in the music screens to jump to the point that you want to play from.

Information

• Music screens for Disc CD and Disc MP3 do

not support this function.

1-12 I Basic

K_UMa_UVO3[USA_EU]AV_PART1.indd 1-12K_UMa_UVO3[USA_EU]AV_PART1.indd 1-12 2016-01-27 오후 4:23:182016-01-27 오후 4:23:1

Flick (Quick Scrolling)

Drag the frequency bar to the left or right to move to the frequency that you want.

From the Edit My Menu screen, drag and drop icons to add, delete, or move to/from My Menu.

Quickly moves up and down in the list.

NOTICE

• Moving the list when there are many items will

display a handler on the right of the display. You can easily move many items at a time with the handler

You can view the previous or next image by flicking left/right on an image on the USB Image screen.

Flick left/right on the frequency bar in the radio player to look up the previous/next frequency available.

Starting the System for the First Time I 1-13

K_UMa_UVO3[USA_EU]AV_PART1.indd 1-13K_UMa_UVO3[USA_EU]AV_PART1.indd 1-13 2016-01-27 오후 4:23:182016-01-27 오후 4:23:1

Press and Hold

Pressing the and buttons

in the music player will fast forward/rewind the music.

1-14 I Basic

K_UMa_UVO3[USA_EU]AV_PART1.indd 1-14K_UMa_UVO3[USA_EU]AV_PART1.indd 1-14 2016-01-27 오후 4:23:202016-01-27 오후 4:23:2

part.2

Radio/Media

FM/AM

HD Radio™ Technology

SiriusXM™

About Disc

Disc CD

Disc MP3

USB

iPod

AUX

Bluetooth

Audio

My Music

K_UMa_UVO3[USA_EU]AV_PART2.indd 2-1K_UMa_UVO3[USA_EU]AV_PART2.indd 2-1 2016-01-27 오후 4:23:382016-01-27 오후 4:23:3

Radio/Media

FM/AM

You can access the radio player either by pressing the

key or by selecting the Radio menu from All Menus on the Home screen.

FM/AM Mode Display Controls

Information

• If you press the

adio broadcast will be tuned from the current mode.

and a r

• If you are in radio mode

to access the r

2-2 I Radio/Media

RADIO

adio player.

key when power is off, the power will turn on

, select the media widget from the Home screen

RADIO

Features Description

•

The stored preset frequencies are displaye

or user selection.

Preset

Frequencies

Frequency Bar

Frequency

Tag

Presets

SoundHound

• After selecting frequency, press and hold the preset button for more than 0.8 seconds. A beep sound will be heard and the frequency is to be stored in the selected preset b

•

Flick the preset frequencies up/do

kly through presets.

quic

•

Flick the frequency bar left/right to search f

vailable radio channels to the left or r

a the current channel. Dragging: Drag the frequency bar to the left/

• right to find the radio channel that you want.

Displays the current frequency.

Saves the current music’s tag information to the head unit. If connected to iPod, the tag information can be saved on the device.

Shows the stored presets for user selection.

Runs the SoundHound feature. For more details regarding this feature, refer to the SoundHound information in the Info section.

• List

ves to the frequency list.

• Inf

o Turns the Radio text information tr from the broadcasting station on and off

• Preset

• Sound

Scan Plays preset frequencies f item.

Settings Moves to the Sound Settings.

wn to scroll

ansmitted

or 10 seconds per

utton.

ight of

K_UMa_UVO3[USA_EU]AV_PART2.indd 2-2K_UMa_UVO3[USA_EU]AV_PART2.indd 2-2 2016-01-27 오후 4:23:392016-01-27 오후 4:23:3

Features Description

Scan/

Preset Scan

Band

HD Radio

Scan

Displays an active mode from Scan and Preset Scan modes.

Changes to the desired band from among FM, AM, and SiriusXM.

Used to set whether to turn HD Radio™ reception On or Off.

Shortly plays the broadcasts for the frequencies with superior reception for 5 seconds per item.

• When pressed quickly (less than 0.8 seconds): Seeks the previous/next frequency.

• When pressed and held (more than 0.8 sec-

SEEK/TRACK

onds): Moves quickly through all of the frequencies. The moment that you release the button, the system seeks the next available frequency.

TUNE

knob to manually seek avail-

TUNE

Turn the able frequencies.

• FM: Increment/decrement by 200 kHz

• AM: Increment/decrement by 10 kHz

FM/AM I 2-3

K_UMa_UVO3[USA_EU]AV_PART2.indd 2-3K_UMa_UVO3[USA_EU]AV_PART2.indd 2-3 2016-01-27 오후 4:23:402016-01-27 오후 4:23:4

HD Radio™ Technology

Contributes to the superior user experience of HD

Radio™ Technology. Presents song name, artist, station IDs, HD2/HD3

Channel Guide, and other relevant data streams.

nal music as well as deep cuts into traditional genre.

signal. AM sounds like today’s FM and FM sounds like a CD.

Program Service Data:

Adjacent traditional main stations are extra local FM

channels. These HD2/HD3 Channels provide new, origi-

Digital, CD-quality sound. HD Radio™ Technology

enables local radio stations to broadcast a clean digital

If an HD Radio™ broadcast is received, the radio mode will switch from analog broadcast to HD Radio™ broadcast.

Information

• The HD Radio™ screen is displayed only

when a HD Radio™ broadcast is being received

2-4 I Radio/Media

K_UMa_UVO3[USA_EU]AV_PART2.indd 2-4K_UMa_UVO3[USA_EU]AV_PART2.indd 2-4 2016-01-27 오후 4:23:422016-01-27 오후 4:23:4

Basic Mode Screen (HD Radio™ reception ON)

Name Description

Displays main HD Radio™ channels and

HD Radio™

Reception & Channel buttons

HD Channel

Number

HD Broadcast

Info

HD Radio

used to directly select the current available channels.

The HD Radio™ related icon display

becomes active within regions where an HD Radio™ signal can be received.

Analog station and corresponding HD Radio™ channel number saved in the preset list.

Displays detailed information about the current broadcast (the details of the information shown are different depending on whether the Info button is selected)

When the HD Radio™ soft button is ON (the blue indicator on the HD Radio™ button is illuminated), HD Radio™ signals will be broadcast.

HD Radio™ Technology I 2-5

K_UMa_UVO3[USA_EU]AV_PART2.indd 2-5K_UMa_UVO3[USA_EU]AV_PART2.indd 2-5 2016-01-27 오후 4:23:432016-01-27 오후 4:23:4

SiriusXM™

You can access the radio player either by pressing the

key or by selecting the Radio menu option from All Menus on the Home screen. Select the SiriusXM™ band from the radio player.

SiriusXM™ Mode Display Controls

Information

• If you press the

on and a r

• If you are in the SiriusXM™ mode, select the SiriusXM™ radio widget

from the Home screen to access the r

• When the power is off, pressing the

y a SiriusXM™ Radio broadcast.

and pla

RADIO

key when the power is off, the power will turn

adio broadcast will be tuned from the current mode.

adio player.

RADIO

key will turn the power on

RADIO

Features Description

Shows the stored presets for user selection.

•

Preset Frequencies

Channel Logo

Channel Info

Content Info

Category Info

Band

Direct Tune

Scan

Category Lock

Category

Selection Buttons

Play Live

Skip Backward

• After selecting frequency, press and hold the preset button for more than 0.8 seconds. A beep sound will be heard and the frequency is to be stored in the selected preset button.

Displays the current channel logo.

Displays the current channel number and name.

Displays the artist, title and other information about the current playing song.

Displays the category of the currently playing song.

Changes to the desired band from among FM, AM, and SirusXM.

Used to search for the desired channel by entering the channel number.

Plays all receivable channels for 10 seconds per item.

If pressed, only the channels for the current category can be searched or scanned.

Used to select the previous/next category.

Switches to the live broadcast mode.

Repeats the previously broadcasted program.

•

Holding for less than 0.8 seconds: Mov the previous segment.

•

Holding for more than 0.8 seconds: Mov the previous 5 seconds.

es to

2-6 I Radio/Media

K_UMa_UVO3[USA_EU]AV_PART2.indd 2-6K_UMa_UVO3[USA_EU]AV_PART2.indd 2-6 2016-01-27 오후 4:23:432016-01-27 오후 4:23:4

Features Description

Play/Pause

Skip/Forward

Pauses/plays the current broadcasting program.

Moves to the next segment.

Saves the current music’s tag information to the

Tag

head unit. If connected to iPod, the tag information can be saved on the device.

Presets

Shows the stored presets for user selection.

Runs the SoundHound feature.

SoundHound

For more details regarding this feature, refer to the SoundHound information in the Info section.

List

Moves to the channel list.

•

What is on My Presets?

The program schedule saved in my preset. (For more details, see Section 2.5. Viewing Menu.)

eatured Favorites

• F

Theme channels recommended by SiriusXM™. (For more details, see Section 2.5. Viewing Menu.)

• Preset Scan

Plays preset channels for 10 seconds each.

• Sound Settings

Moves to the Sound Settings.

• When pressed quickly (less than 0.8 seconds): Plays the previous/next channel.

•

SEEK/TRACK

When pressed and held (more than 0.8 seconds): Continuously changes the channel until the key is released and pla channel.

TUNE

Changes the channel.

ys the current

SiriusXM™ I 2-7

K_UMa_UVO3[USA_EU]AV_PART2.indd 2-7K_UMa_UVO3[USA_EU]AV_PART2.indd 2-7 2016-01-27 오후 4:23:442016-01-27 오후 4:23:4

Selecting through Channel/Category List

Select the

egory and channel.

Select the desired category and the channel. Once selected, the previous screen will be restored and the selected channel will begin playing.

List

▶ Select the desired cat-

If you select the scan channels using the

key or the

Skip

button, you can

TUNE

knob by skipping the

SEEK

TRACK

channels that you chose to skip.

Direct Tune

Enter the number of the channel you want to receive.

Viewing Menu

Using the

can view the program schedule and information about the Featured Favorites provided by SiriusXM™ .

button on the right, you

2-8 I Radio/Media

K_UMa_UVO3[USA_EU]AV_PART2.indd 2-8K_UMa_UVO3[USA_EU]AV_PART2.indd 2-8 2016-01-27 오후 4:23:452016-01-27 오후 4:23:4

What is on My Presets? (Program Schedule)

Name Description

By selecting this option, you can select a broadcasting date. Broadcast information will be provided for one week from the current date.

Change

Broadcast Date

Preset

You can select Menu to see program information and the schedules of broadcast channels listed in the presets.

Program

Information

K_UMa_UVO3[USA_EU]AV_PART2.indd 2-9K_UMa_UVO3[USA_EU]AV_PART2.indd 2-9 2016-01-27 오후 4:23:462016-01-27 오후 4:23:4

Shows saved presets for user selection

A total of 40 frequencies for SiriusXM™ modes

can be displayed.

Shows you the program titles to be broadcasted at the time that you have chosen. Select a program to see more details.

If there is more information on the program you

selected, an arrow button will be displayed on the right of the list. You can see more program information by selecting the arrow button.

SiriusXM™ I 2-9

Featured Favorites

Featured Favorites feature allows SiriusXM™ to broadcast additional presets.

• Example 1: "Martha's Favorites" may represent Martha Stuart's favorites presets on her radio.

• Example 2: During holidays, "Holiday Music" may represent all the Sir channels that are pla

ying the holiday

music for easy access by users.

Multiple sets Featured Favorites data can be broadcast by SiriusXM™ and can change from time to time.

iusXM™

2-10 I Radio/Media

K_UMa_UVO3[USA_EU]AV_PART2.indd 2-10K_UMa_UVO3[USA_EU]AV_PART2.indd 2-10 2016-01-27 오후 4:23:472016-01-27 오후 4:23:4

About Disc

Precautions upon Handling Discs

CAUTION

• After using a disc, put the disc back in its

original case to prevent disc scratches.

• Do not use abnormally shaped discs (8cm,

t-shaped, octagon-shaped) as such discs

hear could lead to errors.

• Do not clean discs with chemical solutions,

such as record spr antistatic liquids, benzene, or thinners.

• Do not expose the disc to direct sunlight or

high temper of time. Such exposure may lead to disc deformation.

• Upon playing a disc contaminated by dirt

or other substances deteriorate and result in skipping sounds.

iting on either side of the disc could result

Wr in damage to disc surf

ays, antistatic sprays,

atures for prolonged periods

, the sound quality may

aces.

• Clean fingerprints and dust off the disc

surface (coated side) with a soft cloth.

• Copy-protected CDs, such as S-type CDs,

y not properly operate in the device. DATA

ma CDs cannot be played. (However,

y still abnormally operate.)

• Do not disassemble the device. Contact a

designated ser (Complete after ser

vided if the user disassembles the device.)

pro

• Do not use water to clean the device.

Exposure to w damage.

• Do not introduce foreign substances into

the disc inser substances could damage the device interior.

• The device may not properly operate in

xtremely hot or cold temperatures. (The

e operating temperature range is: 14˚F ~ 150˚F)

vice center in case of problems.

vice assistance will not be

ater could lead to product

t/eject slot. Introducing foreign

such discs

• Steam can become condensed on the

ﬁ beroptic lens due to rain, wet conditions, or upon operating the heating system. In such cases, discs may not be properly recognized. Remove the disc and wait until the moisture dries.

• Skipping may occur during audio play when

iving on bumpy roads for prolonged per

dr of time or upon se case of severe shock, audio may not proper pla

vere shock to the vehicle. In

iods

About Disc I 2-11

K_UMa_UVO3[USA_EU]AV_PART2.indd 2-11K_UMa_UVO3[USA_EU]AV_PART2.indd 2-11 2016-01-27 오후 4:23:472016-01-27 오후 4:23:4

Supported Disc Formats

This device supports the following disc formats.

Disc Type

Disc Type Disc Format Device Support

3inch (8cm)

5inch (12cm)

SACD

CD-R

CD-RW

Multisession-CD

SACD

(Single, SACD layer)

SACD (Hybrid)

Disc Format

Disc Type Disc Format Device Support

X O O

O (Read Only) O (Read Only) O (Read Only)

(Only CD layer)

Disc/Content Format Compatibility

By Format according to Disc Type

Disc Type Disc Format Device Support

CD LPCM

MPEG1, Layer3

MP3

WMA Ver9

MPEG2, Layer3

MPEG2.5

O O O

Ordinary Disc Compatibility

This device has been designed/manufactured to be compatible with software bearing the following logo marks.

$XGLR&'

• CD-R/RW discs (Audio CD) created with CD recording devices or PCs may not properly operate in the device. This is a result of various causes, including disc format, recording method, and contamination to the disc or lens.

CD-DA

MP3

WMA

2-12 I Radio/Media

K_UMa_UVO3[USA_EU]AV_PART2.indd 2-12K_UMa_UVO3[USA_EU]AV_PART2.indd 2-12 2016-01-27 오후 4:23:472016-01-27 오후 4:23:4

MPEG4 AAC

DTS-CD

CD-ROM

CD-G

CD-EXTRA

CD-TEXT

O O O

X X

X O O

CD-R/RW Compatibility

• This device supports CD-R, CD-RW, and MP3 discs burned in Audio CD formats.

• The recording of CD-R and CD-RW discs with this device is not supported.

• CD-R/RW discs recorded as audio CDs

ere not finalized are not suppor

that w b

y this device.

ted

PC-created Disc Compatibility

• When burning a disc on a PC, the disc

y not operate in this device depend-

ma ing on the software settings. In such cases, inquire with the software manufacturer.

• Additional information regarding compatibility is displayed on the CD-R/RW software disc box. DVD-R/W discs are not compatib

• this de

vice.

le with

Cautions upon Writing CDs

• When a multi-session disc is being recorded, make sure to close the session before recording.

• If MP3/WMA file extensions are changed, such could result in errors.

• In the case of MP3/WMA, write using only English. (Other languages are not suppor

ted)

Unauthorized use of copy-protected

• music files is prohibited by law.

• Prolonged use of CD-R/CD-RW products that do not satisfy related specifications may result in abnormal operation. When writing CDs, low-speed wr

• recommended.

iting is

Compressed Audio Compatibility

• Physical formats of CD: Model 1, Model ormat 1.

2 XA f

• This device supports audio file com-

pressed through MPEG-1 audio stream layer 3 (MP3) using 8kbps ~ 320kbps. (CBR or VBR)

• For stable operation, the use of files

in 95kbps~192kbps bit rate range and

44.1kHz SAMPLING frequency is recommended.

• This device supports WMA audio files

using 20kbps ~ 320kbps. (CBR or VBR)

• Variable bit rate files may operate, but

the play time information may not be properly displayed.

•

This device only supports trac extension of “.mp3” or “.wma”.

• This device does not support multises-

sion discs. This device supports only 8 layer folders.

•

ks with file

About Disc I 2-13

K_UMa_UVO3[USA_EU]AV_PART2.indd 2-13K_UMa_UVO3[USA_EU]AV_PART2.indd 2-13 2016-01-27 오후 4:23:482016-01-27 오후 4:23:4

• This device supports MP3 ID3 tag versions of Ver. 1.0, Ver. 1.1, Ver. 2.2, Ver.

2.3, Ver. 2.4. When using discs with other versions, the ID3 info will not be displayed.

• Although this device has been designated to be compatible with various bit rates, playing low bit rate MP3 tracks may result in low quality sound.

Before Playing an MP3 Disc

Supported MP3 File Speciﬁ cation

• Acceptable standard: MPEG1 Audio Layer 3.

• Acceptable sampling frequency: 8,

11.025, 12, 16, 22.05, 24, 32, 44.1, 48(KHz).

• Acceptable bit rate: 8 ~ 320 (Kbps).

Recommended Bit Rates and Frequency

• Sampling frequency: 96 ~ 192 Kbps fixed bit rate/44.1 kHz.

Detailed Speciﬁ cation

• Maximum directory layers: 8 layers.

• Maximum folder length: 64 bytes, file name length: 64 bytes. Supported characters for f

• name:

2350 characters for Alphanumer character and Korean character sets, 4888 characters for Simplified Chinese character set. Maximum number of folders per disc:

• f

olders. (including ROOT)

• Maximum number of files per disc: 512 files.

older name/file

256

NOTICE

• Supported ID3 tags: ID3v1.0, ID3v1.1,

ID3v1.2, ID3v2.2, ID3v2.3, ID3v2.4.

• Supported MP3 Media: CD-ROM.

• Supported media formats:

and LEVEL2.

ISO9660 LEVEL1

Precautions upon Burning MP3 Files

• The use of ISO 9660 LEVEL 2 JOLIET ormat is recommended.

•

Up to 32 characters in K are suppor

ted for file names and up to

orean/Chinese

20 characters in Korean/Chinese are supported for folder names. The use of CDs exceeding 700MB ma

•

y result in faulty disc recognition or errors upon pla

2-14 I Radio/Media

K_UMa_UVO3[USA_EU]AV_PART2.indd 2-14K_UMa_UVO3[USA_EU]AV_PART2.indd 2-14 2016-01-27 오후 4:23:482016-01-27 오후 4:23:4

MP3 File Structure

Recognition occurs through the same folder structure used within the disc.

Folder structure as saved in CD-ROM Folder structure as saved in the system

About Disc I 2-15

K_UMa_UVO3[USA_EU]AV_PART2.indd 2-15K_UMa_UVO3[USA_EU]AV_PART2.indd 2-15 2016-01-27 오후 4:23:482016-01-27 오후 4:23:4

+ 120 hidden pages
