Hyundai H-MW1023 User Manual

H-MW1023

MICROWAVE OVEN

Instruction manual Руководство по эксплуатации

МИКРОВОЛНОВАЯ ПЕЧЬ

Description/Installation

1. Cabinet

2. Door assemble

3. Safety lock system

4. Window

5. Glass tray 1. LED display

6. Turntable ring 2. Menu indicators

7. Turntable shaft 3. Function buttons

8. Control panel 4. Rotatable knob

Grill rack

Turntable installation

• Never place the glass tray upside down. The glass tray should never be restricted.

• Both glass tray and turntable ring assembly must always be used during cooking.

• All food and containers of food are always placed on the glass tray for cooking.

• If glass tray or turntable ring assembly cracks or breaks, contact your nearest authorized service center.

Countertop installation

Remove all packing material and accessories. Examine the oven for any damage such as dents or broken door. Do not install if oven is damaged.

Cabinet: Remove any protective film found on the microwave oven cabinet surface.

Do not remove the light brown Mica cover that is attached to the oven cavity to protect the magnetron.

Installation

1. Select a level surface that provides enough open space for the intake and/or outlet vents. A minimum clearance of 3.0 inches (7.5 cm) is required between the oven and any adjacent walls. One side must be open.

• Leave a minimum clearance of 12 inches (30 cm) above the oven.

• Do not remove the legs from the bottom of the oven.

• Blocking the intake and/or outlet openings can damage the oven.

• All food and containers of food should always be placed on the glass tray for cooking.

• If glass tray or turntable ring assembly cracks or breaks, contact your nearest authorized service center.

2. Plug your oven into a standard household outlet. Be sure the voltage and the frequency are the same as the voltage and frequency on the rating label.

WARNING: Do not install oven over a range cooktop or other heat-producing appliance. If installed near or over a heat source, the oven could be damaged and the warranty would be void. The accessible surface may be hot during operation.

Important safeguards

WARNING: To reduce the risk of burns, electric shock, fire, injury to persons:

• Read all instructions before using microwave oven.

• The microwave oven is for household use only. Do not use for industrial purposes.

• Some products such as whole eggs and sealed containers (for example, close glass jars and sealed baby bottles with teat) may explode and should not be

heated in microwave oven.

• Use this microwave oven only for its intended use as described in this manual.

• Close supervision is necessary, when the microwave oven is used by children.

• Do not operate this microwave oven if it doesn’t work properly.

• To reduce the risk of fire in the oven cavity it is necessary to observe the following rules:

- Do not overcook food. Supervise the cooking process if paper, plastic or other combustible materials are placed inside the oven.

- Remove wire twist-ties from bags before placing food into the oven.

- If materials inside the oven should ignite, keep the oven door closed, shut off power at the fuse of circuit breaker panel.

• Do not use the oven for any reason other than food cooking. Never use it for drying clothes, paper or any other nonfood items or for sterilizing purposes.

• Do not operate the oven when empty. Do not keep any foreign object inside.

• Do not cook any food surrounded by a membrane, such as potatoes, chicken livers, etc without piercing several times with a fork.

• Do not cook eggs in the microwave oven.

• Do not cook foods directly on the glass tray. Place food in/on proper cooking utensil before placing in the oven.

WARNING: Cookware not to use in your microwave oven:

- Do not use metal pans or dishes with metal handles.

- Do not use anything with metal trim.

- Do not use paper covered with twist-ties on plastic bags.

- Do not use melamine dishes as they contain a material, which will absorb microwave energy. This may cause the dishes to crack or char and will

slow down the cooking speed.

- Do not use burnable container such as paper, wooden, bamboo willow container.

- The glaze is not suitable for microwave use.

- Do not cook in containers with restricted opening, such as a soft drink bottle or salad oil bottle, as they may explode.

- Do not use conventional meat or candy thermometers. Use thermometers purposed specifically for microwave cooking.

• Microwave utensils should be used only in accordance with manufacturer’s instructions.

• Please remember that a microwave oven heats the liquid in the container quicker that the container itself. Therefore, though the lid of a container is not

hot when removed from the oven please remember that the food/liquid inside will be hot.

• Always test the temperature of cooked food yourself especially if you are heating or cooking food/liquid for babies. It is advisable never to consume

food/liquid straight from the oven; leave it for a few minutes and stir food/liquid to distribute heat evenly.

• Food containing a mixture of fat or water, e.g. should stand for 30-60 seconds in the oven after it is turned off. This is to allow the mixture to settle and to

prevent bubbling when a spoon is placed in the food/liquid or a stock cube is added.

• Always follow the cooking instructions, when preparing/cooking food/liquid and remember that there are certain food, e.g. Christmas puddings, jam and

mincemeat, which heat up very quickly.

• The contents of feeding bottles and baby food jars are to be stirred and shaken and the temperature is to be checked before consumption, in order to avoid

burns.

WARNING: If the door or door seals are damaged, the oven must not be operated, till it is repaired by a competent person.

Radio interference

• Operation of the microwave oven can cause interference to your radio, TV or similar equipment.

• When there is interference, it may be reduced or eliminated by taking the following measures:

- clean door and sealing surface of the oven.

- reorient the receiving antenna of radio or television.

- relocate the microwave oven with respect to the receiver.

- plug the microwave oven into a different outlet so that microwave oven and receiver are on different branch circuits.

Before the first use

• Make sure that all the packing materials are removed from the inside of the door.

• Check the oven for any damage, such as misaligned or bent door, damaged door seals and sealing surface, broken or loose door hinges and latches and

dents inside the cavity or on the door. If there is any damage, do not operate the oven and contact qualified service personnel.

• This microwave oven must be placed on a flat, stable surface to hold its weight and the heaviest food likely to be cooked in the oven.

• Do not place the oven where heat, moisture or high humidity are generated, or near combustible materials.

• For correct operation, the oven must have sufficient airflow. Keep the oven at least 8cm away from both side walls and 10cm away from rear wall to

ensure the correct ventilation.

• Do not cover or block any openings on the unit. Do not remove feet.

How to choose your microwave cookware

Applicable

SORTS INSTRUCTIONS SORTS INSTRUCTIONS Heat-proof glassware

Most suitable for microwave cooking.

Heat-resistant plastic container Tightly closed containers are forbidden.

Cannot be used for packing or containing foods with high fat or sugar contents.

Earthenware or chinaware

Inapplicable

SORTS INSTRUCTIONS SORTS INSTRUCTIONS Metal wares (e.g. aluminum, stainless steel, etc.)

Lacquer ware

Paper, bamboo or wooden ware

Conventional utensils of these materials allowed unless firmed with gold, silver.

May spark or ignite while touching the cavity wall during cooking.

May flaw or peel off. Non-heat-proof glassware

May be burnt due to heating. Aluminum foil

ilm for freshment preservation and

heat-resistant

Combustible plastic wares

Only suitable for packing vegetables or being used as a lid. Never apply to packing meat or frying foods.

Inapplicable.

May deform or flaw in a highly hot conditions. Curved or strengthened glassware are not applicable.

May spark or ignite while touching the cavity wall during cooking.

Operation

Clock Setting

When the microwave oven is electrified, the LED will display «0:00», buzzer will ring once.

1. Press «Часы/Уст-ка» button, the hours will flash, indicator will light up.

2. Rotate the knob to adjust the hour figures, the input time should be within 0 –23.

3. Press «Часы/Уст-ка» button, the minute figures will flash.

4. Rotate the knob to adjust the minutes, the input time should be within 0 – 59.

5. Press «Часы/Уст-ка» button to finish clock setting. «:» will flash, and the time will be lighted. Clock indicator will blink off.

Note: If the clock is not set, it will not function when powered. During the process of clock setting, if you press «Стоп/Сброс», the oven will go back to the previous status automatically.

Microwave Cooking

Press «Микро» button the LED will display «P100». Press «Микро» button repeatedly or rotate the knob to choose the power you want, and «P100», «P80», «P50», «P30» or «P10» will display after each next press. Then press «Старт/+30cек./Подтвер.» button to confirm, and rotate the knob to set cooking time from 0:05 to 95:00. Press «Старт/+30cек./Подтвер.» button again to start cooking.

Example: If you want to use 80% of microwave power to cook for 20 minutes, you can operate the oven as the following steps.

1. Press «Микро» button once, the screen displays «P100». and indicators will light up.

2. Press «Микро» button once again or rotate the knob to choose 80% of microwave power.

3. Press «Старт/+30cек./Подтвер.» button to confirm, and the screen displays «P80».

4. Rotate the knob to adjust the cooking time till the oven displays «20:00».

5. Press «Старт/+30cек./Подтвер.» to start cooking . and indicators will flash.

Cooking time adjustment: Before turning the knob, the display shows 00:00. 1 After starting turning the knob, every 5 seconds are added after each

turn till the time on the display shows 1 minute;

2. Now every 10 seconds are added after each turn till the time on the display shows 5 minutes;

3. Every 30 seconds are added after each turn till the time on the display shows 10 minutes;

4. Every 1 minute is added after each turn till the time on the display shows 30 minutes;

5. Every 5 minutes are added after each turn till the time on the display shows 95 minutes.

«Microwave» pad instructions

Order Display Microwave power

1 Р100 100% 2 Р80 80% 3 Р50 50% 4 Р30 30% 5 Р10 10%

Steps

0 – 1 min : 5 seconds 1 – 5 min : 10 seconds 5 – 10 min : 30 seconds 10 – 30 min : 1 minute 30 – 95 min : 5 minutes

Grill or Combi. Cooking

Press «Гриль/Комби» button the LED will display «G», and press «Гриль/Комби» button repeatedly or rotate the knob to choose the power you want, and «G», «C-1» or «C-2» will display after each next press. Then press «Старт/+30cек./Подтвер.» button to confirm, and rotate the knob to set cooking time from 0:05 to 95:00. Press «Старт/+30cек./Подтвер.» button again to start cooking.

Example: If you want to use 55% of microwave power and 45% of grill power (C-1) to cook for 10 minutes, you can operate the oven as the following steps.

1. Press «Гриль/Комби» button once, the screen displays «G». indicator will light up.

2. Press «Гриль/Комби» button once again or rotate the knob to choose C-1 mode.

3. Press «Старт/+30cек./Подтвер.» button to confirm, and the screen displays «C-1».

4. Rotate the knob to adjust the cooking time till the oven displays «10:00».

5. Press «Старт/+30cек./Подтвер.» button to start cooking.

and indicators will flash.

«Grill/Combi.» pad instructions

Order Display Microwave power Grill power

1 G 0% 100% 2 C-1 55% 45% 3 C-2 36% 64%

Note: If one half of the grill time passes, the oven sounds twice, and this is normal. In order to have a better effect of grilling food, you should turn the food over, close the door, and then if there is no operation the oven will continue cooking.

Quick Start

1. In waiting state, press «Старт/+30cек./Подтвер.» button to start cooking with 100% power, each next press will increase 30 seconds cooking time up to

95 minutes. Indicators and will light up.

2. In microwave, grill, combi. cooking or time defrost state, each press of «Старт/+30cек./Подтвер.» button can increase 30 seconds of cooking time.

3. In waiting state, rotate the knob anti-clockwise to set cooking time with 100% microwave power, then press «Старт/+30cек./Подтвер.» button to start cooking.

Defrost By Weight

1. Press «Програм./Разморозка» button once, and the oven will display «dEF1». Indicators and will light up.

2. Rotate the knob to select the weight of food from 100 to 2000 g. «g» indicator will light up.

3. Press «Старт/+30cек./Подтвер.» Button to start defrosting. Indicators and will flash. «g» indicator will blink off.

Defrost By Time

1. Press «Програм./Разморозка» button twice, and the oven will display «dEF2». Indicators and will light up.

2. Rotate the knob to select the defrost time.

3. Press «Старт/+30cек./Подтвер.» button to start defrosting. Indicators and will flash.

Auto Reheat

1. Press «Авто подогрев» button once, and the LED will display «200». and indicators will light up. «g» indicator will light up.
