TRACTOR - MODEL NO. GTH2454T (96043002300), PRODUCT NO. 960 43 00-23
SCHEMATIC
02929-194276_Regulated-Tex
RED RED
WHITE
S
M
B
A1
G
A2
L
BATTERY
FUSE
RED
BLACK
PTO SWITCH
(DISENGAGED)
BLACK
BLACK
BLACK
SOLENOID
WHITE
RED
BLACK
WHITE
CLUTCH/BRAKE
(PEDAL UP)
2
3
1
6
JUNCTION
CONNECTOR
BLACK
BLACK
BLACKBLACK
GRAY
BLACK
STARTER
M
M
ELECTRIC CLUTCH
GRAY
REVERSE SWITCH
(NOT IN REVERSE)
SEAT SWITCH
(NOT OCCUPIED)
BLACK
IGNITION SWITCH
CIRCUITPOSITION
OFF
RUN/OVERRIDE
M+G+A1
B+S+A1START
B+A1
B+A1RUN
“MAKE”
L+A2
BLACK
02929
BLACK /WHITE
BLUE
BLUE
FUEL SHUT-OFF
(IF SO EQUIPPED)
ORANGE
LIGHT
SWITCH
63
52
41
CHASSIS HARNESS
CONNECTOR
(MATING SIDE)
FUEL
SOLENOID
RED
DASH HARNESS
(MATING SIDE)
IGNITION
UNIT
(OPTIONAL)
HOUR
METER
LINE
CHARGING SYSTEM OUTPUT
16AMPDC@36RPM
BROWN
6
3
5
2
4
1
CONNECTOR
29
CHASSIS
HARNESS
SPARK
PLUGS GAP
(2 PLUGS ON
TWIN CYL. ENGINES)
POWER OUTLET
(IF SO EQUIPPED)
REGULATOR
28 VOLTS AC @ 3600 RPM (REGULATOR DISCONNECTED)
HEADLIGHTS
WIRING INSULATED CLIPS
NOTE: IF WIRING INSULATED
CLIPS WERE REMOVED FOR
SERVICING OF UNIT, THEY
SHOULD BE REPLACED TO
PROPERLY SECURE YOUR
WIRING.
BLACK
12V
SHORTING
CONNECTOR
STATOR
BLACK
NON-REMOVABLE
CONNECTIONS
REMOVABLE
CONNECTIONS
Page 4
TRACTOR - MODEL NO. GTH2454T (96043002300), PRODUCT NO. 960 43 00-23
4646
59
ELECTRICAL
22
21
24
27
42
25
41
43
90
27
40
33
30
34
2
1
91
27
50
26
16
99
100
8
92
94
71
Battery
_28
29
93
55
28
194276
30
Page 5
TRACTOR - MODEL NO. GTH2454T (96043002300), PRODUCT NO. 960 43 00-23
ELECTRICAL
KEY PART
NO. NO. DESCRIPTION
1 532 14 49-27 Battery
2 874 76 04-12 Bolt Hex Hd 1/4-20 unc x 3/4
8 532 18 64-91 Battery Box
16 532 17 61-38 Switch Interlock
21 532 18 37-59 Harness Socket Light
22 532 00 41-52 Bulb, Light # 1156
24 532 40 02-53 Cable Battery
25 532 19 88-93 Cable Starter
26 532 17 51-58 Fuse
27 873 51 04-00 Nut Keps Hex 1/4-20 unc
28 532 14 54-91 Cable Ground 21" Blk 6 Ga.
29 532 40 15-45 Switch Seat
30 532 19 33-50 Switch Ign
33 532 14 04-01 Key Ign Molded Generic
34 532 11 07-12 Switch Light/Reset
40 532 40 11-05 Harness Ign
41 871 72 04-08 Screw Thd Cut 1/4-20 x 1/2
42 532 13 15-63 Cover Terminal Red
43 532 19 25-07 Solenoid
46 532 19 81-38 Gauge Hourmeter
50 532 17 46-51 Switch PTO
55 817 49 05-12 Screw Thdrol 5/16-18 x 3/4
59 532 40 03-03 Outlet 12-Volt
71 532 19 42-76 Harness Ign. Dash
90 532 18 04-49 Cover Terminal Battery
91 532 19 02-70 Strap Battery
92 532 19 66-15 Harness Pigtail
93 532 19 25-40 Screw Plastite 10-14 x 2.0
94 532 19 18-34 Module Reverse ROS
99 817 67 04-12 Screw Hexwsh Thdrol 1/4-20 x 3/4
100 819 09 14-16 Washer 9/32 x 7/8 x 16 Ga.
NOTE: All component dimensions given in U.S. inches
1 inch = 25.4 mm
31
Page 6
TRACTOR - MODEL NO. GTH2454T (96043002300), PRODUCT NO. 960 43 00-23
CHASSIS
15
208
18
207
203
204
210
212
214
14
130
25
221
181
196
162
189
162
58
199
178
161
156
176
176
37
181
176
194
206
156
211
209
216
130
202
205
52
213
139
152
215
218
52
216
213
139
217
5
182
176
184
176
130
52
175
185
150
34
130
180
68
194
177
68
165
228
189
99
chassis-tex_10-gt-husq
228
68
189
32
Page 7
TRACTOR - MODEL NO. GTH2454T (96043002300), PRODUCT NO. 960 43 00-23
CHASSIS
KEY PART
NO. NO. DESCRIPTION
5 532 40 18-23 Dash
14 532 40 18-24 Hood
15 532 19 89-07 Lens LH
18 532 40 02-97 Grille
25 532 19 89-06 Lens RH
34 532 19 61-25 Plate Engine
37 532 40 18-25 Fender
52 873 68 05-00 Nut Crown Lock 5/16-18
58 532 19 43-14 Bracket Fender
68 817 49 05-08 Screw 5/16-18 x 1/2
99 532 19 82-53 Rod Bypass Asm.
130 532 19 16-11 Screw 10 x 3/4 Single Lead Hex
150 532 19 85-13 Duct Heat Hood
152 532 19 63-90 Shield Browning/Debris
156 817 00 05-12 Screw 5/16-18 x 3/4
161 532 40 18-26 Console Fuel Window
162 532 14 24-32 Screw Hex Wsh Hi-Lo 1/4 x 1/2
165 532 19 68-26 Bracket Support Tank
175 532 19 63-04 Crossmember
176 532 40 07-76 Screw 10-24 x 5/8 Wshd Qdrx
177 532 19 52-27 Bushing Steering
178 532 19 97-82 Cargo Asm. Net
179 532 40 35-71 Plug N/Cruise
180 532 40 15-59 Chassis
181 532 40 30-25 Bushing Mtg. Fender Crgo.
182 532 19 47-87 Dash Lower
184 532 19 57-80 Spacer Fender
KEY PART
NO. NO. DESCRIPTION
185 874 78 05-20 Bolt Fin Hex 5/16-18 unc x 1-1/4
189 817 00 05-12 Screw 5/16-18 x 3/4
194 873 90 05-00 Nut Lock Hex Flange 5/16-18
196 532 40 02-99 Console Asm. Deck Lift
199 532 19 82-59 Plate Deck Lift
202 532 40 30-48 Vent Side Hood RH
203 532 40 30-76 Vent Side Hood LH
204 532 19 89-04 Vent Asm Hood Top
205 532 40 17-09 Skirt Hood Side RH
206 532 40 17-11 Skirt Hood Side LH
207 532 19 71-98 Bezel RH
208 532 19 71-99 Bezel LH
209 532 19 91-30 Insert Hex Top RH
210 532 19 91-31 Insert Hex Top LH
211 532 19 91-32 Insert Hex Bottom RH
212 532 19 91-33 Insert Hex Bottom LH
213 874 76 05-12 Bolt Hex Hd 5/16-18 unc x 3/4
214 532 19 91-45 Clip Retainer
215 532 19 80-43 Cover Chassis Front
216 817 67 05-08 Screw 5/16-18 x 1/2
217 532 15 65-24 Rod Pivot
218 532 19 63-95 Hood Stop
221 532 19 89-09 Refl ector LH
228 532 19 51-61 Stud Fastner
NOTE: All component dimensions given in U.S. inches
1 inch = 25.4 mm
33
Page 8
TRACTOR - MODEL NO. GTH2454T (96043002300), PRODUCT NO. 960 43 00-23
DRIVE
74
185
42
220
64
184
35
160
203
74
167
160
188
143
125
70
216
56
171
172
197
196
199
173
125
114
170
52
51
33
9
7
37
2
183
73
205
drive-tex_15-husq-hydro_0610_FS
116
51
187
190
52
186
189
51
50
49
162
159
1
15
17
159
15
175
29
195
125
73
114
183
161
2
211
178
116
162
37
166
166
23
159
221
166
176
198
22
201
114
93
201
7
205
33
34
Page 9
TRACTOR - MODEL NO. GTH2454T (96043002300), PRODUCT NO. 960 43 00-23
DRIVE
KEY PART
NO. NO. DESCRIPTION
1 - - - - - - Transaxle, Hydro 344-0610
(Order Parts from Transaxle Manu-
facturer)
2 532 18 62-11 Key 1/4 x 2.5
7 532 19 98-44 Hub Asm. Wheel
9 532 14 00-80 Bolt Hub Wheel
15 819 13 13-16 Washer 13/32 x 13/16 x 16 Ga.
17 532 19 72-96 Spring, Brake
22 532 19 73-29 Shifter Rod
23 532 14 08-45 Knob
29 532 19 94-67 Rod, Brake
33 812 00 00-60 Ring E
35 532 19 95-91 Rod, Brake, Park
37 532 12 17-49 Washer
42 532 12 48-72 Cover, Foot Pedal
49 872 11 06-14 Bolt
50 532 19 43-27 Pulley Idler Flat
51 873 90 06-00 Lock Nut 3/8-16
52 532 19 43-26 Idler V-Groove 910" Offset
56 532 14 02-18 V-Belt, Drive
64 532 19 62-00 Shaft Asm. Pedal Brake Control
70 532 40 02-98 Control Asm.
73 874 49 05-60 Bolt Hex Flghd 5/16-18 x 3.75
74 532 14 24-32 Screw 1/4 x 1/2
93 532 19 82-54 Link Shift
114 873 80 05-00 Nut Lock Hex w/Insert 5/16-18 unc
116 873 90 05-00 Nut Lock Hex Flange 5/16-18
125 817 00 05-12 Screw 5/16-18 x 3/4
143 817 49 05-08 Screw Thdrol 5/16-18 x 1/2
159 876 02 04-12 Pin Cotter 1/8 x 3/4
160 532 16 94-84 Retainer Clip
161 532 19 54-03 Spring, Return, Clutch
162 532 19 57-85 Spacer Trans.
KEY PART
NO. NO. DESCRIPTION
166 532 19 72-90 Nut Push .625
167 532 19 62-11 Latch Brake Parking
170 532 19 43-22 Keeper Belt Centerspan
171 872 11 06-16 Bolt
172 532 19 76-56 Strap Torque LH
173 532 19 74-24 Strap Torque RH
175 532 19 76-53 Shaft Asm Shift
176 532 19 62-14 Arm, Shift Rod
178 532 19 74-56 Spring Shift
183 532 40 04-24 Spacer Split
184 532 40 31-18 Handle Parking Brake
185 872 11 06-20 Bolt Rdhd Sqnk 3/8-16 x 2-1/2
186 532 19 43-21 Spacer Retainer
187 819 13 32-10 Washer
188 532 19 43-23 Link Clutch Ground Drive
189 532 19 43-17 Bellcrank Ground Drive
190 532 19 43-18 Keeper Bellcrank Ground Dr.
195 532 19 80-12 Bracket Rod Brake
196 817 00 06-16 Screw 3/8-16 x 1
197 532 19 97-69 Bracket Clutch Anti-Rotation
198 532 19 94-96 Screw 7/16-14 x 7/8 Flghd
199 872 14 05-08 Bolt Rdhd Sqnk 5/16-18 unc x 1
201 532 16 96-12 Bolt Shoulder 5/16-18 unc
203 819 11 11-16 Washer 11/32 x 11/16 x 16 Ga.
205 532 12 17-48 Washer
211 532 19 62-12 Bushing
216 532 19 61-31 Bracket Pulley Idler
220 532 19 89-08 Refl ector RH
221 532 40 31-87 Retainer Spring Clip Handle
NOTE: All component dimensions given in U.S. inches
1 inch = 25.4 mm
35
Page 10
TRACTOR - MODEL NO. GTH2454T (96043002300), PRODUCT NO. 960 43 00-23
STEERING ASSEMBLY
26
45
51
1
steering-tex_4-husq
64
13
21
16
28
22
59
63
19
35
58
68
69
60
57
63
61
6
4
15
70
9
8
7
14
67
2
9
67
62
8
14
66
7
6
5
13
8
15
53
13
KEY PART
NO. NO. DESCRIPTION
1 532 19 39-43 Wheel, Steering
2 532 19 59-68 Axle Asm., Front
4 532 19 79-37 Spindle Asm., LH
5 532 19 79-36 Spindle Asm., RH
6 532 12 49-31 Bearing, Race Thrust Harden
7 532 12 17-48 Washer 25/32 x 1-5/8 x 16 Ga.
8 812 00 00-29 Ring, Klip #T5304-75
9 532 12 12-32 Cap, Spindle
13 532 12 17-49 Washer 25/32 x 1-1/4 x 16 Ga.
14 810 04 06-00 Washer, Lock Hvy Hlcl Spr 3/8
15 873 54 06-00 Nut, Crown Lock 3/8-24 unf
16 532 19 47-46 Shaft Steering
19 532 19 47-29 Plate Steering
21 532 18 67-37 Adapter, Wheel Steering
22 532 19 48-45 Bushing, Strg. Blk
26 532 19 36-52 Insert, Wheel Steering
28 817 00 06-12 Screw 3/8-16 x 3/4
35 532 19 47-32 Gear, Sector Plate
45 819 18 38-12 Washer 9/16 x 2-3/8 x 12 Ga.
KEY PART
NO. NO. DESCRIPTION
51 873 94 08-00 Nut Hex Jam Toplock 1/2-20 unf
53 532 18 89-67 Washer Hardened .793 x 1.637 x
.060
57 532 19 72-46 Bracket Upstop
58 532 19 47-47 Bolt Shoulder Sector Pivot CFM
59 532 19 47-48 Washer Thrust Sector Steering
60 873 97 10-00 Nut Flange Lock 5/8-11
61 532 19 47-40 Draglink LH
62 532 19 47-41 Draglink, RH
63 817 06 05-12 Screw 5/16-18 x 3/4
64 532 19 98-49 Retainer Clip Spring Steering
66 871 02 07-48 Bolt Hex Fghd 7/16-14 x 3 Serr
67 532 19 47-37 Bushing PM Front Axle
68 873 90 07-00 Nut Lock Flange 7/16-14 Gr. 5
69 532 19 91-62 Washer 1.5 x .505 x .118
70 532 19 61-97 Bracket Deck Susp. Front
NOTE: All component dimensions given in U.S. inches
1 inch = 25.4 mm
36
Page 11
TRACTOR - MODEL NO. GTH2454T (96043002300), PRODUCT NO. 960 43 00-23
ENGINE
22
18
21
15
20
37
28
37
31
1
91
85
41
42
84
12
11
84
45
82
81
69
87
62
71
70
79
2
90
engine-tex_7-vgt
KEY PART
NO. NO. DESCRIPTION
1 - - - - - - Engine Briggs Model No. 445677
2 532 14 97-23 Muffl er
9 532 19 43-19 Keeper Belt Engine
11 532 17 93-35 Clutch Electric
12 532 40 24-63 Pulley Engine
15 532 19 34-99 Tank Fuel 4.0
18 532 19 42-67 Cap Asm
20 532 17 83-85 Control Throttle
21 532 19 16-11 Screw 10 x 3/4 Single Lead Hex
22 532 19 15-96 Control Choke
28 532 40 11-35 Fuel Line
29 532 13 71-80 Spark Arrester Kit
31 532 14 50-06 Clip Push-In
37 532 12 34-87 Clamp Hose
41 532 12 61-97 Washer 1-1/2 OD x 15/32 ID x .250
42 810 04 07-00 Washer Lock 7/16
45 873 51 04-00 Nut Keps Hex 1/4-20 unc
62 532 14 66-29 Shield Heat Muffl er
69 532 16 53-91 Gasket
70 532 15 99-55 Tube Exhaust LH
9
29
SPARK ARRESTER KIT
KEY PART
NO. NO. DESCRIPTION
71 532 16 05-89 Tube Exhaust RH
79 532 18 39-06 Screw Socket Head 5/16-18 x 1
81 532 14 84-56 Tube Drain Oil Easy
82 532 18 16-54 Plug Drain Oil
84 817 06 06-20 Screw 3/8-16 x 1-1/4
85 532 17 99-53 Bolt Hex 7/16-20 x 3.75 Gr. 5
87 532 19 82-39 Bolt 5/16-18 unc x 1 w/Sems
90 817 00 06-16 Screw 3/8-16 x 1
91 532 18 74-95 Bushing
NOTE: All component dimensions given in U.S. inches
1 inch = 25.4 mm
For engine service and replacement parts, call the toll free
number for your engine manufacturer listed below:
Briggs & Stratton 1-800-233-3723
Kohler Co. 1-800-544-2444
Tecumseh Products 1-800-558-5402
Honda Engines 1-800-426-7701
Kawasaki 1-949-460-5688
37
Page 12
TRACTOR - MODEL NO. GTH2454T (96043002300), PRODUCT NO. 960 43 00-23
SEAT ASSEMBLY
1
8
8
7
7
41
40
10
44
43
seat-tex_5-husq
KEY PART
NO. NO. DESCRIPTION
1 532 19 75-26 Seat
2 532 18 01-66 Bracket Pivot Fender
3 532 14 06-75 Strap, Asm Fender
5 532 14 50-06 Clip, Push In, Hinged
6 873 80 06-00 Nut, Lock W/Ins. 3/8-16 unc
7 532 12 41-81 Spring, Seat Cprsn
8 532 17 18-77 Bolt 5/16-18 uncx 3/4 w/Sems
10 532 19 69-77 Pan, Seat
21 532 17 18-52 Bolt, Shoulder 5/16-18
21
6
37
5
37
2
21
3
KEY PART
NO. NO. DESCRIPTION
37 873 80 05-00 Nut, Lock 5/16-18 unc
40 532 19 76-61 Handle Slide Seat
41 532 19 82-00 Spring Latch Seat
43 874 76 06-12 Bolt Fin Hex 3/8-16 unc x 3/4
44 819 13 38-12 Washer 13/32 x 2-3/8 x 12 Ga.
NOTE: All component dimensions given in U.S. inches
1 inch = 25.4 mm
38
Page 13
TRACTOR - MODEL NO. GTH2454T (96043002300), PRODUCT NO. 960 43 00-23
DECALS
13
16
6
5
15
17
2
14
14
9
3
8
16
1
KEY PART
NO. NO. DESCRIPTION
1 532 19 91-14 Decal, Operator's
2 532 40 21-28 Decal, Hood Insert
3 532 17 05-63 Decal, Warning
5 532 17 85-02 Decal, Caution
6 532 19 16-52 Decal, Eng. HP
8 532 19 87-85 Decal, Mower Sch.
9 532 14 50-05 Decal, Battery Dnge/Poi
13 532 40 44-84 Decal, Steeraing Whl
WHEELS AND TIRES
1
2
6
11
3
7
wheel_art_1-vgt
4
10
KEY PART
NO. NO. DESCRIPTION
14 532 40 44-71 Decal, Panel Side
15 532 18 09-41 Decal, Cust. Resp.
16 532 40 28-32 Decal, Hood Logo
17 532 40 43-13 Decal, Replacement
- - 532 16 69-60 Decal, Bypass
- - 532 40 17-71 Pad, Footrest, LH
- - 532 40 17-70 Pad, Footrest, RH
- - 532 40 43-82 Manual, Owner's (Eng)
- - 532 40 43-83 Manual, Owner's (Fr)
KEY PART
NO. NO. DESCRIPTION
1 532 05 91-92 Cap, Valve, Tire
2 532 06 51-39 Stem, Valve
3 532 14 45-09 Rim Assembly, Front
4 532 05 99-04 Tube, Front (Ser vice Item Only)
5 532 10 62-30 Tire, Front
6 532 12 49-57 Fitting, Grease (Front Wheel Only)
5
9
8
7 532 12 49-59 Bearing, Flange (Front Wheel Only)
8 532 17 50-39 Cap, Axle (Front Wheel Only)
9 532 18 47-08 Tire, Rear
10 532 12 49-26 Tube, Rear (Service Item Only)
11 532 40 17-82 Rim Assembly, Rear
- - 532 14 43-34 Sealant, Tire (10 oz. Tube)
NOTE: All component dimensions given in U.S. inches
1 inch = 25.4 mm
39
Page 14
TRACTOR - MODEL NO. GTH2454T (96043002300), PRODUCT NO. 960 43 00-23
MOWER DECK
116
117
120
49
114
113
21
122
46
6
21
98
32
194
46
185
39
34
192
49
52
43
196
97
33
31
12
59
1
16
19
49
52
33
50
21
60
47
46
7
33
32
31
30
29
25
26
24
27
18
190
187
188
mower_deck 54-tex_3
189
187
190
18
40
15
58
14
11
13
8
21
18
Page 15
TRACTOR - MODEL NO. GTH2454T (96043002300), PRODUCT NO. 960 43 00-23
MOWER DECK
KEY PART
NO. NO. DESCRIPTION
1 532 40 31-25 Deck Weldment Mower
6 532 19 60-66 Cover Mandrel LH
7 532 19 71-81 Cover Mandrel RH
8 532 17 43-65 Bolt 7/16 Asm. Blade
11 532 18 72-56 Blade High Lift
12 532 40 48-51 Bar Anti-Sway
13 532 18 72-91 Shaft Asm. w/Lower Bearing
14 532 18 72-81 Housing, Mandrel
15 532 11 04-85 Bearing, Ball, Mandrel
16 819 13 13-12 Washer 3/8
18 872 14 05-05 Bolt RdHd 5/16-18 unc x 5/8
19 532 19 42-08 Pin Cotter 5/16 Bowtie
21 873 68 05-00 Nut, Crownlock 5/16-18 unc
24 532 10 53-04 Cap Sleeve
25 532 17 81-02 Spring, Torsion
26 532 11 04-52 Nut, Push
27 532 18 89-38 Defl ector Shield
29 532 13 14-91 Rod, Hinge
30 532 17 39-84 Screw, Thdroll Washer Head
31 532 18 76-90 Washer, Spacer Mower Vented
32 532 17 34-35 Pulley, Mandrel
33 532 40 02-34 Nut, Flg. Top Lock
34 873 68 06-00 Nut Crownlock 3/8-46 UNC
39 532 19 61-04 Pulley, Idler, Stationary LH
43 532 19 60-65 Arm, Idler
46 532 13 77-29 Screw, Thdroll. 1/4-20 x 5/8
KEY PART
NO. NO. DESCRIPTION
47 532 19 61-03 Belt Deck Drive
49 873 90 06-00 Nut, Lock Flg. 3/8-16 unc
50 872 11 06-16 Bolt Carriage 3/8-16 x 2 Gr. 5
52 532 19 61-06 Pulley Idler
58 532 18 73-42 Baffl e Right
59 532 18 73-44 Baffl e Left
60 532 18 76-07 Baffl e Center
97 532 17 85-15 Washer Hardened
98 532 19 61-05 Spring Drive
113 872 11 05-08 Bolt Rdhd Sqnk 5/16-18 x 3/4
114 532 18 75-56 Rod Tension Relief
116 532 19 34-06 Bolt, Shoulder
117 532 17 48-73 Gauge Wheel
120 819 13 20-12 Washer 13/32 x 1-1/4 x 12 Ga.
122 532 18 75-57 Bushing Tension Relief
185 873 90 07-00 Nut Lock Flange 7/16-14 Gr. 5
187 532 19 51-61 Stud Fastener w/"D" Anti-Rotation
188 873 90 05-00 Nut Lock Hex Flange
189 532 19 51-85 Arm Susp. Mower Rear
190 532 19 65-39 Bolt Shoulder
192 532 19 84-68 Keeper Belt Idler
194 872 14 07-16 Bolt Carr Sqnk 7/16-24 x 2
196 872 14 06-20 Bolt RDHD SQNK 3/8-16 x 2-1/2
Gr.5
- - 532 18 72-92 Mandrel Asm. Service (Includes
Key Nos. 13-15 and 33)
- - 532 19 93-00 Replacement Mower, Complete
NOTE: All component dimensions given in U.S. inches
1 inch = 25.4 mm
41
Page 16
TRACTOR - MODEL NO. GTH2454T (96043002300), PRODUCT NO. 960 43 00-23
MOWER LIFT
7
87
87
87
90
89
3
10
97
89
88
2
91
98
97
lift-tex_3
KEY PART
NO. NO. DESCRIPTION
2 532 19 52-23 Shaft Asm., Lift
3 532 19 52-30 Lever Asm., Lift Rh
7 532 19 64-92 Grip, Lever
10 532 19 63-14 Spring Torsion
87 532 19 42-09 Pin Cotter 7/16 Bow Tie Lock
88 532 19 53-04 Spring Lift Assist
89 819 19 19-12 Washer Clear Zinc
90 532 19 42-08 Pin Cotter 5/16 Bow Tie Lock
91 532 40 34-07 Link Lift Susp Mower Rear
89
87
KEY PART
NO. NO. DESCRIPTION
92 532 19 51-74 Bracket Connect Link Lift
95 532 19 51-71 Bushing Alignment Link Lift
97 817 06 06-12 Screw 3/8-16 x .75 Smgml Tap/R.Z
98 532 19 52-64 Link Lift Susp. Front Mower
99 532 19 52-63 Bushing Spherical Susp Front
100 873 36 07-00 Nut Hex Jam ASF 7/16-20 unf
NOTE: All component dimensions given in U.S. inches
1 inch = 25.4 mm
42
Loading...
