Page 1

Evaporative Evaporative Evaporative

Humidier

Owner’s Guide

English

Model

33116 33118 33119

Page 2

Table of Contents

At A Glance

Warnings and Introduction ................................................................................ 3

Know Your Humidier ....................................................................................... 4

Using Your Humidier

Initial Setup and Operation ................................................................................ 5

Maintenance

Cleaning and Storage ....................................................................................... 6

Humidier Assistance

Troubleshooting ................................................................................................ 8

Service Parts and Support ................................................................................. 9

Warranty

3 Year Guarantee ........................................................................................... 10

Page 3

At A Glance

Warnings and Introduction

READ AND SAVE THESE INSTRUCTIONS

Important Safety Instructions: Read all instructions before using this humidier.

• This humidier may not work properly on an uneven surface. ALWAYS place this humidier on a rm, level and water resistant surface. ALWAYS place the humidier at least six (6) inches away from walls and heat sources such as stoves, radiators or heaters.

• ALWAYS place the humidier in an area that is out of the reach of children.

• Before using the humidier, extend the cord and inspect for any sign of damage. DO NOT use the product if the cord has been damaged.

• This product has a polarized plug as a safety feature (one blade is wider than the other). This plug will t into a polarized outlet only one way. If the plug does not fully t into the outlet, reverse the plug. If it still does not t, contact a qualied electrician. DO NOT attempt to defeat or override this feature.

• ALWAYS unplug and empty the humidier when it is not in operation or while it is being cleaned.

• DO NOT tilt or move the humidier while it is in operation. Never move the humidier while there is water in the tank. Empty the water tank, turn the unit off, and unplug the unit before moving.

• In addition to routine maintenance which may be required, this humidier requires seasonal cleaning. Refer to and follow the instructions for “Cleaning and Storage” on page 6.

• This unit was designed to be used with distilled and/or tap water. DO NOT add scented oils, perfumes or fragrance additives to the water.

• Never ll the humidier tank with hot water. Always use clean, cool tap water.

• The warnings and cautions in this owner’s manual cannot cover all situations, or events that may arise. Common sense and caution should be used by the operator in using this device to prevent injury or accident.

The Hunter® Evaporative Humidier has a unique, patented design with several innovative features:

• Built-in Antimicrobial Properties – We use Microban of bacteria, mold and fungi that may affect these parts.

NOTE: This product contains antimicrobial properties which are built-in to inhibit the growth of bacteria which may affect the plastic and wick in the humidier. These properties do not extend to the water, humidied air, or users. Conduct routine cleaning and maintenance based upon use and individual conditions.

• No White Dust – The Hunter

NOTE: You may notice mineral deposits accumulating in the tank Tray. This is normal and does not affect performance. If you would like to clean these deposits away, please see “Cleaning and Storage” on page 6.

Evaporative Humidier produces no white dust that can settle on furniture or be inhaled.

on many of the plastic parts and wick. This helps inhibit the growth

Page 4

Housing

Wick

Know Your Humidiﬁer

At A Glance

Tank Handle

Water Tank

Water Tray

Control Knob

Vapor Pad Tray

Tank Cap

Exhaust Grill

Tank Handle

O

Niteglo™

Nitelight

44062-01 • 05/17/2011

Page 5

Using Your Humidiﬁer

Initial Setup and Operation

Initial Setup

1. Remove the Hunter® Evaporative Humidier from its packaging.

2. Place the humidier on a hard, at, water resistant surface. Always place the humidier at least six (6) inches away from walls and sources of heat.

3. Make sure the power/speed control is in the ‘OFF’ position.

NOTE: The power/speed control should always be off before unplugging the humidier, moving the humidier, or relling the water tank.

4. Lift the housing to ensure the wick is properly seated, resting on the bottom of the water tray and not tilted or otherwise out of position. Figure 1. Place the housing back on the water tray.

5. Grasp the water tank by the tank handle and remove it from the water tray. Figure 2.

6. Turn the water tank upside-down and remove the tank cap by turning counterclockwise. Figure 3.

Wick

Figure 1.

Tank Handle

7. Fill the water tank with clean, cool water and return the tank cap to its position. Tighten it by turning clockwise, and return the water tank to the water tray.

8. Plug the humidier’s power cord into a standard household power outlet.

9. Turn the power/speed control to your desired humidier fan speed.

Operation

Off Turns the unit off.

Low: Extends the time between rells by running the fan on low.

Lowest noise setting recommended for nighttime use.

High: Average rell rate and optimal for day use. Minimal noise

level.

To turn on or off the Niteglo™ Nitelight, just press the Niteglo™ Button on the top of the unit.

See Figure 4. for a display of your controls.

If you choose to use vapor pads in your humidier:

Remove 1 vapor pad from the packaging, and insert it lengthwise into the vapor pad tray on the top of the exhaust grill. Vapor pads will typically last for 24 hours before needing replacement.

Control

Knob

Figure 2.

Figure 3.

Niteglo™

Nitelight

O

Vapor Pad Tray

Figure 4.

Page 6

Cleaning and Storage

Maintenance

Many regions have hard water with high concentrations of minerals. When water evaporates from the Hunter These minerals can form a hard white scale which can be removed by following the cleaning instructions. The frequency of cleaning due to mineral build up can vary depending upon the quality of water you may have. Refer to “Know Your Humidier” on page 4 for gure names.

1. Turn the humidier off and unplug the unit.

2. Lift the main housing and remove the water dispersion tray and the wick. The motor is attached to the main housing. Do not place the motor near water. Do not use a wet towel on the motor or motor housing as electrical shock may occur.

3. Replace the humidier’s wick every 4 months or when it has turned brown.

4. Remove the water tank from the base and empty any water that is left in the tank. Soak the base in a mixture of one (1) gallon of water and eight (8) ounces of vinegar for 20 minutes. The base is dishwasher safe.

5. After soaking, wipe the base with a soft cloth or sponge to remove any mineral build up. Rinse with clean water several times. If you are planning on storing the humidier, be sure the base is completely dry.

evaporative humidier, minerals may be left behind.

1 gallon Water

8oz. Vinegar

Solution

Figure 5.

6. Fill the water tank with one (1) gallon of water and eight ounces of undiluted white vinegar. Figure 5. Replace the tank cap and shake the tank vigorously until all interior surfaces of the tank have been exposed to the water/vinegar mixture.

7. Empty the tank of the water/vinegar mixture. Rinse it several times with clean water and then replace the tank cap. If you are planning to store the humidier, dry it inside and out, leaving the cap off to allow the tank to completely dry. Continue to clean the other parts of your humidier.

8. Wipe the surfaces of the main housing with a soft cloth. Figure 6.

9. Once all the parts are clean, reassemble the humidier, and follow ”Initial Setup and Operation” on page 5 to continue use. If you are storing the humidier, make sure all parts are completely dry before reassembling, and storing in a dry location.

Figure 6.

44062-01 • 05/17/2011

Page 7

Maintenance

Replacing the Wick

NOTE: The humidier’s wick is made of paper and is NOT washable.

Over time, minerals in your water will build up in the humidier’s wick, degrading its ability to absorb water and reducing the humidier’s output. Therefore, you should replace the humidier’s wick every season, depending on the hardness of your water.

1. Turn the humidier off and unplug the unit.

2. Lift the main housing, remove it from the base, and set it aside. Figure 7.

3. Grasp the humidier wick, hold it over the base, and squeeze the water from it. Figure 8. This will keep water from dripping onto your oor. You may also want to wrap the wick in a towel to keep it from dripping while you transport it to disposal.

4. Replace the old wick with a new Hunter humidier wick. New wicks are available at your local Hunter retailer or at www.hunterfan.com.

5. Ensure the wick is properly seated, resting on the bottom of the base and not tilted or otherwise out of position.

Figure 7.

6. Return the main housing to its position on the base. Make certain the main housing is properly seated on the base.

7. Plug the humidier’s power cord into a standard household power outlet and turn the power/speed control to your desired setting.

Figure 8.

Page 8

Humidiﬁer Assistance

Troubleshooting

Problem:

Excessive noise.

Solution:

1. Check the water tank to make sure it is properly seated on the base.

2. Check the water tank to make sure there are no bubbles when the water tank is full and running. If there are bubbles, turn the unit OFF until the bubbling stops. When the bubbling has stopped, set the unit to the desired speed.

Problem:

Humidier not working.

Solution:

1. Make sure the power knob is not set to OFF and the unit is plugged into a working wall outlet.

Problem:

Mineral build-up on the water tank or water tray.

Solution:

1. Refer to the section “Cleaning and Storage” on page 6.

Problem:

Humidity output and water usage decreased.

Solution:

1. Check the power knob to make sure it is set to the desired speed.

3. Clean any components that have mineral build-up. Refer to the section “Cleaning and Storage” on page 6.

44062-01 • 05/17/2011

Page 9

Service Parts and Support

Service Parts

Part # Part Name Part Replace

89754-01-326 Water Tank

Humidiﬁer Assistance

G0841-01-679

31948 Wick

99940-01-679 Water Tray

Tank Assembly

Cap

1 per month or

as needed

Technical Support

If you need any assistance with setup, operation, or parts for your new Hunter Humidier, please call us, our technical support staff is ready to help!

USA: 1-888-830-1326

Canada: 1-866-268-1936

Hours of operation are from 7:00 am to 7:00 pm Monday - Friday and 8:00 am to 5:00 pm on Saturday, Central Time. You may also contact us over the Internet at www.hunterfan.com or register your product at www.hunterfan. com/register and select your product under product registration.

Page 10

Warranty

3 Year Guarantee

The Hunter Fan Company, Inc. makes the following warranty to the original residential user or consumer purchaser of the evaporative humidier: If any part of the evaporative humidier fails during the rst 3 (three) years from the date of purchase due to a defect in material or workmanship, we will provide a replacement part free of charge.

If no replacement part can be provided, we will replace your humidier. IF THE ORIGINAL RESIDENTIAL USER OR CONSUMER PURCHASER CEASES

TO OWN THE HUMIDIFIER, THIS WARRANTY AND ANY IMPLIED WARRANTY WHICH THEN REMAINS IN EFFECT, INCLUDING BUT NOT LIMITED TO ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, ARE VOIDED. THIS WARRANTY IS IN LIEU OF ALL OTHER EXPRESS WARRANTIES. THE DURATION OF ANY IMPLIED WARRANTY, INCLUDING BUT NOT LIMITED TO ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE IS EXPRESSLY LIMITED TO THE PERIOD OF THE EXPRESS WARRANTY SET FORTH ABOVE.

This warranty is voided if your humidier is not purchased and used in the USA or Canada.

This warranty excludes and does not cover defects, malfunctions, or failures of the humidier which were caused by repairs by persons not authorized by us, use of parts, or accessories not authorized by us, mishandling, modications, or damage to the humidier while in your possession, or unreasonable use, including failure to provide reasonable and necessary maintenance. This warranty does not cover humidiers used in commercial applications. There are no express or implied warranties as to commercial purchasers or users.

To obtain service, contact the nearest Hunter authorized service center or the Hunter Fan Company Service Department, 7130 Goodlett Farms Pkwy., Suite 400, Memphis, TN 38016, 1-888-830-1326. You will be responsible for insurance and freight or other transportation to our factory service center. We will return the Vaporizer freight prepaid to you. The humidier should be properly packaged to avoid damage in transit since we will not be responsible for any such damage. Proof of purchase is required when requesting warranty service. The purchaser must present the sales receipt or other document that establishes proof of purchase.

IN NO EVENT SHALL HUNTER FAN COMPANY BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, CONSEQUENTIAL OR INCIDENTAL DAMAGES IN EXCESS OF THE PURCHASE PRICE OF THE VAPORIZER. YOUR SOLE REMEDY WILL BE REPAIR OR REPLACEMENT AS PROVIDED ABOVE. SOME AMERICAN STATES AND CANADIAN PROVINCES DO NOT ALLOW:

• LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS;

• THE EXCLUSION OR LIMITATION OF DIRECT, INDIRECT, SPECIAL, INCIDENTAL

OR CONSEQUENTIAL DAMAGES;

• THE EXCLUSION OR INVALIDITY OF EXPRESS OR IMPLIED WARRANTIES IF

THE USER CEASES TO OWN THE HUMIDIFIER;

• THE LIMITATION OF THE REMEDIES AND RECOURSES AVAILABLE TO THE

PURCHASER; OR THE INVALIDITY OF AN EXPRESS WARRANTY WHEN A PRODUCT IDENTIFIED BY BRAND NAME IS NOT USED (UNLESS SPECIFIC

CONDITIONS ARE FULFILLED); SO THE ABOVE LIMITATIONS OR EXCLUSIONS MAY NOT APPLY TO YOU. THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS AND YOU MAY ALSO HAVE OTHER RIGHTS WHICH VARY FROM STATE TO STATE OR PROVINCE TO PROVINCE.

44062-01 • 05/17/2011
