Hunter 40080 User Manual

Installation of

Carrier Colem an Comfor tm ake r Bryant, Payne Rheem-Ruud Weathe rtron York Lennox (1) Lennox (2)

R 24 VA C R R R R R R R R V-V R

Y Compress or Y or Y 1 Y Y Y Y Y Y Y M

O Reversing valve - Cool O O O O O O R

B Reversing valve - Heat B B

GFan G G G G G G G G F

E Emerg enc y Heat E E jumper to W2 E E jumper to W2 jumper to W2 E E

W2 A uxillary Heat W2 W2 W1 W2 W2 W- U W W1 Y

X Common C X C C, C1 , X 1 X B B C X

Hunter Connection Labels

Note: W2 & X

wires no

connection

Note: X2 & T

w ires no

connection

Cool Off Heat Norm Em er Auto On

No Heating, No Cooling, No Fan, No Lights .

Cooling Mode - Compres sor contac tor and f an relay cycle from thermostat.

Heat Mode - Stage 1 Only - Compr ess or contactor and fan relay cycle fr om thermos tat.

Heat Mode - Both Stages - Compressor contac tor, f an relay, auxiliary heat relays , and aux. light on.

Emergency Heat Mode - Stage 1 Only - Fan and emergency heat r elay energized. Compressor locked out at thermostat. Emer. light on.

Emer. Heat Mode - Both Stages - Fan, emergency heat, and aux iliary heat relays energized. Compressor locked out at ther mostat. Emer . and aux. lights on.

Fan runs continuously regardless of system sw itch position.

Show s Pos ition of Sw itch and Sys tem Function in Operation

Reversing valve energized if connected to "O" terminal

This System Function w ill operate if jumper from E to W2 is connected. (Optional)

Reversing valve energized if connected to "B" terminal

COMPONENT OPERATION

SWITCH POSITIONS SYSTEM FUNCTION

SYSTEM

Cont act

Aux

He at

Em e r

He at

Em er Heat FAN Fan

Re la y

Re v

Valve

Aux

Light

Hunter

Heat Pump Thermostat

Model 40080

nals to the Hunter terminals. Ignore the color of the wires, as they do not always match the standard.

Attaching Thermostat to Wall

1. Pull about 4 inches of thermostat wire through the wall open-

Specifications

Thermal Data

Temperature Range: 50°F to 90°F (10°C to 32°C) Differential: Stage 1 Heat - 1 1/4°F

Stage 2 Heat - 0.1 to 1.2 Amps Cooling - .2 to 1.0 Amp

Electrical Data

Switch Rating: 24 volts A.C. (30 VAC max.)

Stage 1 Heat - .2 to 1.2 Amps Stage 2 Heat - 0.1 to 1.2 Amps Cooling - .2 to 1.0 Amps

Switch Action: Sealed Mercury Switches

Stage 1 Heat & Cool - SPDT Stage 2 Heat - SPST

Anticipator Rating: Stage 1 Heat - 24 volts A.C. fixed

Stage 2 Heat - 0.1 to 1.2 Amps adjustable Cooling - 24 volts A.C. fixed

Safety

This thermostat is a precision instrument, and should be handled carefully. Rough handling or distorting components could cause the control to malfunction.

ing and lead through the large opening near the center of the thermostat.

2. Attach the thermostat directly to the wall with screws and anchors provided or to a standard horizontal outlet box using the two elongated mounting holes.

3. Level the thermostat. Use a level placed on top of the thermostat for best results. Minor adjustments can be made using the elongated holes. Securely tighten mounting screws. IMPORTANT: This thermostat was calibrated at true level. Any inaccuracy in level will cause control point deviation. Care must be taken to mount the thermostat in a true level position.

Disposal Information

This product contains mercury in a sealed tube. DO NOT place this control in the trash at the end of its useful life. If this product is replacing a control that contains mercury, DO NOT place the old product in the trash. Contact your local waste management authority for instructions regarding recycling and the proper disposal of this product, or of and for any old control containing mercury in a sealed tube.

CAUTION: To prevent electrical shock and/or equipment damage, disconnect electric power to system, at main fuse or circuit breaker box, until installation is complete. WARNING: Do not use on circuits exceeding 30 volts. Higher voltage will damage control - could cause shock or fire hazard. Do not exceed the specification ratings.

Installation

1. Remove the thermostat cover by carefully pulling outward until it snaps free.

2. Carefully remove and discard any packing which protects

Attaching Thermostat Wire

1. Strip wires 1/4 inch.

2. Raise levers on terminal block. (Accepts 16 awg. stranded, 18-24 awg. sold or stranded)

3. Place leads into hole in terminal block under appropriate terminal designation on circuit board and tightly close lever by pushing downward. (Refer to wiring diagrams for proper system hook-up.)

4. Push excess wire into wall or outlet box and plug up the hole to preven drafts from affecting thermostat operation.

the thermometer and the mercury switches during shipment.

3. If a thermostat is being replaced and it is in a satisfactory location and the wiring is in good condition, use the exist-

sional replace the wiring.

ing wiring. If in doubt, have an electrician or HVAC profes-

4. If replacing an existing thermostat, place enclosed wire labels on each wire to match the terminals on the old thermostat. Refer to the wiring chart to help match the old termi-

Two Mounting Holes

Thermostat Cable Opening

Wiring Diagram

Failure to read and follow all instructions carefully, before installing or operating this thermostat, could cause personal injury and/or property damage. NOTE: The “Y” terminal activates the compressor contactor for first stage HEAT and first stage COOL. The changeover relay valve is activated in either the COOLING or the HEATING mode on all models. By connecting the relay to the “0” terminal, the relay is activated by moving the system switch to COOL. By connecting the relay to the “B” terminal the relay is activated by moving the system to HEAT. Check your owners manual for the appropriate connection for your system.

Common wire “X” must be connected for proper operation.

Flip-up Lever Terminal Block Adjustment

Lever

Second Stage

Heat Anticipation

GREEN LIGHT (AUXiliary HEAT) - This light indicates auxiliary heaters are assisting the heat pump in normal system operation. The aux. light will cycle with second stage heat in either “NORMal HEAT” or “EMERgency HEAT” switch positions. RED LIGHT (EMERgency HEAT) - This light will glow when the emergency heat switch has been moved to the “EMER HEAT” position. DO NOT use this switch for normal heating operations. The switch will bring on electric or gas auxilliary heat and at the same time prevent the heat pump from operating. With a jumper installed between “E” and “W2” terminals the

auxilliary heat strips will be activated for use as emergency heat strips. See operation chart.

System Operation and Thermostat Check

Use the chart to check all functions of your thermostat. It explains the operation of your thermostat with the switches in vari-

Heating Anticipation

This thermostat is equipped with fixed anticipators for stage one heat and cooling which do not require adjustment. Stage 2 (or AUXilliary) heat has an adjustable anticipator. Additional adjustments, if necessary, may be made as follows: Heat cycles too long - Set adjustable heater to a slightly lower dial setting (1/2 division). Heat cycles too short - Set adjustable heater to a slightly higher dial setting (1/2 division).

Operation and System Check

The chart shows the different system functions with switches in various positions. Some models may not have certain system

ous positions. After checking, your thermostat is now ready for operation. Set system to desired operations. Set thermostat temperature lever to the room temperature. It takes at least one hour after the room temperature has reached the thermostat setting for all sensors to stabilize. NOTE: In heat pump applications, time delays are involved before the compressor can be activated to prevent short cycling. The delays are provided by a minimum time off timer in the heat pump unit which prevents the compressor from starting for up to 5 minutes from when the thermostat last turned the compressor off, or from the time the system first received power. For technical support, contact us at 888-830-1326.

functions.

Compr.

O B

Wiring Chart and Diagram

Use the chart below to match the wires on your current system or thermostat. Most heat pumps will have connections like one of these. NOTE: Remove the factory installed jumper if your heat pump has separate wires for E and W2.

Hunter Fan Company 2500 Frisco Avenue Memphis, Tennessee 38114
