The Care Free®

Warm Mist Humidiﬁer

ENGLISH

See page 1

Vea la página 15

ESPAÑOL

Models 35201, 35202, 35203, 35253,

36200, 36201, 36203, 36204, 36253

www.hunterfan.com

Page 2

READ AND SAVE THESE INSTRUCTIONS

Thank you for purchasing the Care Free

Warm Mist Humidiﬁer by Hunter Fan Company. Please read and save these instructions to receive maximum beneﬁt and performance from your humidiﬁer.

Important Safety Instructions:

Read all instructions before using

this humidiﬁer.

CAUTION: To avoid electrical

shock and/or ﬁre, please read all instructions before use.

1. This humidiﬁer may not work properly

on an uneven surface. ALWAYS place this humidiﬁer on a ﬁrm, level, and water resistant surface. ALWAYS place the humidiﬁer at least six (6) inches away from walls and heat sources, such as stoves, radiators, or heaters.

2. ALWAYS

that is out of the reach of children.

3. Before using the humidiﬁer, extend the cord and inspect for any sign of damage. DO NOT use the product if the cord has been damaged.

4. This product has a polarized plug as a safety feature (one blade is wider than the other). This plug will ﬁt into a polarized outlet only one way. If the plug does not fully ﬁt into the outlet, reverse the plug. If it still does not ﬁt, contact a qualiﬁed electrician. DO

NOT

feature.

5. ALWAYS humidiﬁer when it is not in operation or while it is being cleaned.

6. DO NOT while it is in operation. Never move the humidiﬁer while there is water in the tank. Empty the water tank, turn the unit off, and unplug the unit before moving.

7. In addition to routine maintenance which may be required, this humidiﬁer requires seasonal cleaning. Refer to and follow the instructions for CLEANING THE HUMIDIFIER AND THE WATER TANK.

place the humidiﬁer in an area

attempt to defeat or override this

unplug and empty the

tilt or move the humidiﬁer

8. This unit was designed to be used with

distilled and/or tap water. DO NOT add scented oils, perfumes or fragrance additives to the water.

9. DO NOT

disassemble the Base while there is hot water still in the unit. Allow a minimum of ﬁfteen (15) minutes cooling time before moving or disassembling the Base.

10. ALWAYS

the Water Tank.

11. To avoid the risk of electrical shock, DO

NOT

12. DO NOT

humidiﬁer is for indoor use only.

13. DO NOT

on the back of the enclosure, the cord, or the plug.

14. DO NOT

ﬂammable vapors and liquids near the humidiﬁer.

15. DO NOT

place hands or face directly over the Exhaust Grille while the unit is in operation.

16. DO NOT

directly face a wall surface. Direct mist aimed at a wall could cause damage, particularly to wallpaper.

attempt to move or

use clean, cool tap water to ﬁll

use an extension cord.

operate outdoors. This

let water get into the air inlets

store or use gasoline or other

touch hot surfaces. DO NOT

allow the Exhaust Grille to

Page 3

How The Care Free® Warm Mist Humidiﬁer Works

Exhaust Grille

Medicine Cup

Water Tank

Adjustable Humidistat*

Base

Night Light Button*

Power Button

Tank Cap

*Not available on all models

The Care Free® Warm Mist Humidiﬁer has a unique, patented design with several innovative features:

• Removable Boiling Chamber

The detachable heater can be easily

removed for cleaning and maintenance.

• Humidiﬁcation System through a heating element which creates warm mist to humidify the air. Stagnant water in the reservoir is eliminated due to minimal water quantity in the boiler reservoir.

• Built-In Antimicrobial Properties

The plastic parts in this humidiﬁer have

built-in antimicrobial properties to inhibit the growth of bacteria, mold and fungi that may affect these parts.

NOTE: The antimicrobial properties built-

into this humidiﬁer do not extend to the

–

– Water is passed

–

Assembly Of Humidiﬁer Parts

water, humidiﬁed air or users. Conduct routine cleaning and maintenance based upon use and individual conditions.

• No White Dust

Mist Humidiﬁer produces no white dust that can settle on furniture or be inhaled.

NOTE: You may notice mineral deposits

accumulating in the tank base or on other components. This is normal and comes with regular usage conditions. If you would like to remove these deposits and maintain humidiﬁer performance, please see the section CLEANING THE HUMIDIFIER AND THE WATER TANK.

• Dishwasher Safe

The Care Free® Warm Mist Humidiﬁer are top-rack dishwasher safe, except for the powered base.

– The Care Free® Warm

– All components of

ENGLISH

Page 4

1. Remove the Care Free® Warm Mist

Base

Water Tank

Humidiﬁer from its packaging.

2. Select a location for your humidiﬁer. The location should be ﬂat, hard, waterresistant, and at least six (6) inches away from walls and sources of heat. Mount the humidiﬁer on a drip tray if you are using the unit on a wood surface or other surface which could be damaged by accidental water spillage or condensation.

HUNTER WILL NOT ACCEPT RESPONSIBILITY FOR DAMAGE DUE TO WATER SPILLAGE.

3. Place the Base in the location you selected. Take the Water Tank to a sink or tub to ﬁll with water.

4. Unscrew the Tank Cap by twisting it counterclockwise and ﬁll the Water Tank with fresh, cool water. NEVER USE HOT

WATER.

6. Place the Water Tank back onto the Base. Make sure the Water Tank is properly seated on the Base or the humidiﬁer will not work properly.

HUNTER WILL NOT ACCEPT RESPONSIBILITY FOR DAMAGE DUE TO WATER SPILLAGE.

7. Make sure the Power Button is set to OFF and plug the humidiﬁer into the wall outlet.

CAUTION: Never plug in the humidiﬁer while your hands are wet, as electric shock could occur.

NOTE: Let the humidiﬁer sit for one minute after reﬁlling the tank, before turning the power back ON.

8. Push the Power Button to turn the humidiﬁer ON. Adjust the setting as needed.

5. Replace the Tank Cap by screwing it clockwise onto the Water Tank.

Page 5

Operating Your Humidiﬁer

There are two humidity level controls:

1. Adjustable Humidistat*

adjust the humidity setting.

Turn the dial to the right to increase

humidity.

Turn the dial to the left to decrease

humidity.

NOTE:

In a very dry room, the HI setting should be used to quickly achieve a comfortable level of humidity. Once the room is at the desired humidity level, you can turn the Adjustable Humidistat down. We suggest you begin with a middle setting and adjust the level using the Adjustable Humidistat to suit your needs.

Power Button – Sets humidity to HIGH, LOW, or OFF.

– Allows you to

Push the Power Button on the base of the

unit AGAIN to turn the humidiﬁer OFF. No indicator light will be illuminated, which indicates the unit has been turned OFF.

3. NiteGlo™ Night Light Button*

Illuminates with a soft blue glow.

Push the NiteGlo™ Button to turn the

light ON or OFF. The night light can be operated even when the humidiﬁer is OFF.

*Not available on all models.

–

ENGLISH

Push the Power Button on the base of the

unit ONCE to turn the humidiﬁer ON. A green indicator light will be illuminated, which indicates a HIGH setting.

NOTE:

It may take 2-3 minutes for the humidiﬁer to warm up and begin to release warm mist.

Push the Power Button on the base of

the unit AGAIN to change the setting to LOW. A yellow indicator light will be illuminated, which indicates a LOW setting.

Page 6

Base

Water Tank

Reﬁlling The Water Tank

1. When the water level is low, push the POWER button to turn the humidiﬁer OFF and unplug the humidiﬁer.

NOTE:

When the tank level is too low, the humidiﬁer will turn OFF and display a red light.

Low Water Level Light (Red)

2. Lift the Water Tank and take it to the

sink or a tub to reﬁll.

3. Turn the Water Tank over and

unscrew the Tank Cap by twisting it counterclockwise.

5. Replace the Tank Cap by screwing it clockwise onto the Water Tank. Make sure that the tank cap is properly seated before screwing it back onto the tank to ensure a proper seal.

6. Place the Water Tank back onto the Base. Make sure the Water Tank is properly seated on the Base or the humidiﬁer will not work properly.

HUNTER WILL NOT ACCEPT RESPONSIBILITY FOR DAMAGE DUE TO WATER SPILLAGE.

7. Make sure the Power Button is set to OFF and plug the humidiﬁer into the wall outlet.

4. Empty the Water Tank and reﬁll it with

fresh, cool water. NEVER USE HOT

WATER.

CAUTION: Never plug in the humidiﬁer while your hands are wet, as electric shock could occur.

NOTE: Let the humidiﬁer sit for one minute after reﬁlling the tank, before turning the power back ON.

8. Push the Power Button to turn the humidiﬁer ON. Adjust the setting as needed.

Page 7

Reassembly Of Humidiﬁer Parts

Exhaust Grille

Medicine Cup

Water Tank

Boiler Cover

Boiling Chamber

Adjustable Humidistat*

Base

Night Light Button*

Power Button

Tank Cap

*Not available on all models

Cleaning The Humidiﬁer And The Water Tank

ENGLISH

Many regions have hard water with high concentrations of minerals. When water evaporates from the Care Free® Warm Mist Humidiﬁer, minerals may be left behind. These minerals can form a hard white scale which can be removed by following the cleaning instructions. The frequency of cleaning due to mineral build up varies depending on the quality of water you have. Failure to perform the necessary cleaning steps can damage the unit and affect performance.

NOTE:

The Water Tank, Tank Cap, Medicine Cup, Boiler Cover, Boiling Chamber, and Exhaust Grille are dishwasher safe in the top rack only.

1. Push the POWER button to turn the unit OFF (the indicator light will be OFF) and unplug the humidiﬁer.

2. Remove the Water Tank and carry it to a

sink or a tub. Unscrew the Tank Cap by twisting it counterclockwise and empty any water in the Water Tank.

3. CAUTION: HEATING ELEMENT MAY BE

EXTREMELY HOT.

Allow at least ﬁfteen (15) minutes for the

hot water in the Boiling Chamber to cool after turning the humidiﬁer OFF before moving the Base or removing the Boiling Chamber from the Base. Pull the Boiling Chamber away from the Base to remove the Boiling Chamber.

Page 8

Boiler Cover

Boiling Chamber

Boiler

Base

4. Place the Boiling Chamber into an empty

Base

Water Tank

sink and carefully lift the Boiling Chamber Cover by pressing the Chamber Cover Release Tab. This will expose the Heater. Drain all water and rinse with cool, clean water. Use a soft brush or sponge to clean the Boiling Chamber and the Boiling Chamber Cover.

5. Pour one (1) cup of white vinegar into the Boiling Chamber and allow it to soak for 20-30 minutes. Rinse several times with cool, clean water. Wipe the Boiler clean if necessary.

6. Before reinstalling the Boiling Chamber, make sure the three metal pins in the Chamber are clean and completely dry. Place the Boiling Chamber Cover into the Boiling Chamber and slide the Chamber slowly back into place. Make sure the Chamber ﬁts properly in the Base.

7. To disinfect the Water Tank, create a solution of one (1) cup of white vinegar and one (1) gallon of clean water. Fill the Water Tank with the solution and allow it to soak for 20 minutes, occasionally swishing the solution to wet all interior surfaces. Empty the Water Tank completely and rinse with clean water several times. Reﬁll the Water Tank with cool, clean water and place it back on the humidiﬁer Base.

humidiﬁer surface, to clean plastic parts.

NEVER

use gasoline, kerosene, glass cleaner, furniture polish, paint thinner, or other household solvents to clean any part of the humidiﬁer.

9. The Water Tank should be drained EACH DAY, rinsed, and reﬁlled with clean tap water.

10. To clean the exterior surfaces, use a solution of water and mild detergent with a damp cloth. Rinse the surfaces with clean water and dry with a cloth. Allow sufﬁcient time to dry before plugging the electrical cord back into the outlet.

11. Place the Water Tank back onto the Base and resume normal use.

8. NEVER

use any metal or hard object,

which could cause scratching of the

Page 9

Storage Tips

If you do not plan to use your humidiﬁer for an extended period of time, such as during the summer months, it is important that you follow these instructions to help prevent problems from developing in the unit.

1. Clean your humidiﬁer as outlined in the CLEANING THE HUMIDIFIER AND THE WATER TANK section.

2. Make sure all water is emptied from

Troubleshooting

• Problem: Humidiﬁer not misting.

Solution:

1. Make sure the unit is plugged in.

2. Check the circuit breaker or fuses.

3. Adjust the humidity level using the Power Button and the Adjustable Humidistat. Once the room reaches the set humidity level, the humidiﬁer will turn OFF; this is normal.

4. Remove and reﬁll the Water Tank.

5. Reposition the Water Tank on the Base.

the tank and the hot and cold water reservoirs.

3. Make sure the unit is completely dry.

4. Leave the Tank Cap off to expose the Water Tank to air.

5. Pack the humidiﬁer in the original carton and store it in a cool, dry place.

• Problem: Humidity output and water usage decreased.

Solution:

1. Check the Adjustable Humidistat and Power Button to make sure they are set to the desired humidity level.

2. Clean any components that have mineral build-up. Refer to the section on CLEANING THE HUMIDIFIER AND THE WATER TANK.

ENGLISH

If you have questions or problems, please call 1-888-830-1326 for assistance before returning the unit to the retailer.

Page 10

Service Parts

To obtain a service part for your humidiﬁer, call Hunter Customer Service at 1-888830-1326 or e-mail us at [email protected]. Please be prepared to tell the operator the model number of your humidiﬁer, the name of the part you need to replace, and the part number.

Model Number

35201, 35202, 36200, 36201, 36204

35203, 36203

35253, 36253

Boiler Cover Exhaust Grille Medicine Cup Tank Cap Water Tank

96362-01-325 86731-01-325 75690-01-325 83736-01-325 96361-01-326

96362-01-325 86731-01-325 75690-01-325 83736-01-325 96361-01-504

96362-01-502 86731-01-502 75690-01-502 83736-01-502 96361-02-326

Page 11

Hunter Fan Company

The Care Free® Warm Mist Humidiﬁer

3 Year Limited Warranty

Hunter Fan Company, Inc. makes the following warranty to the original residential user or consumer purchaser of the Care Free® Warm Mist Humidiﬁer.

If any part of the Care Free® Warm Mist Humidiﬁer ("Humidiﬁer") fails during the ﬁrst three (3) years from the date of installation due to a defect in material or workmanship, we will provide a replacement part free of charge. If no replacement part can be provided, we will replace your humidiﬁer.

If your humidiﬁer fails anytime within one (1) year after the date of installation due to a defect in material or workmanship, labor to repair the defect will be provided free of charge at our nearest service center or at our Service Department in Memphis, Tennessee. You will be responsible for all parts and labor costs after this one year period.

If your humidiﬁer water tank, boiler cover, boiling chamber, base, knobs or tank cap fail at any time within one (1) year after the date of sale to you due to a defect in material or workmanship, we will repair, or at our option, replace the water tank, boiler cover, boiling chamber, base, knobs or tank cap free of charge for parts or labor at our nearest service center or at our Service Department in Memphis, Tennessee.

IF THE ORIGINAL RESIDENTIAL USER OF CONSUMER PURCHASER CEASES TO OWN THE HUMIDIFIER, THIS WARRANTY AND ANY IMPLIED WARRANTY WHICH THEN REMAINS IN EFFECT, INCLUDING BUT NOT LIMITED TO IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, ARE VOIDED.

NO WARRANTY, EXPRESSED OR IMPLIED, INCLUDING ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, IS MADE IN RESPECT TO THE FILTER.

THE WARRANTY IS IN LIEU OF ALL OTHER EXPRESS WARRANTIES. THE DURATION OF ANY IMPLIED WARRANTY, INCLUDING BUT NOT LIMITED TO ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, IN RESPECT TO THE MOTOR IS EXPRESSLY LIMITED TO THE PERIOD OF THE EXPRESS WARRANTY SET FORTH ABOVE.

This warranty is voided if your humidiﬁer is not purchased and used in the USA or Canada.

This warranty excludes and does not cover defects, malfunctions or failures which were caused by repairs by persons not authorized by Hunter Fan Company, or accessories not authorized by Hunter Fan Company, mishandling, modiﬁcations, or damage to the

Page 12

humidiﬁer while in your possession, or unreasonable use, including failure to provide reasonable and necessary maintenance. This warranty does not cover humidiﬁers used in commercial applications. There are no express or implied warranties as to commercial purchasers or users.

Technical Support

If you have any additional questions or problems with your Hunter Air Purier, please call

1-888-830-1326 from 8:00 am to 5:00 pm Central Time or contact us over the Internet at www. hunterfan.com. You will be responsible for insurance and freight or other transportation

to our factory service center. We will return the humidiﬁer, freight prepaid, to you. The humidiﬁer should be properly packaged to avoid damage in transit since we will not be responsible for any such damage. Proof of purchase is required when requesting warranty service. The purchaser must present the sales receipt or other documentation that establishes proof of purchase.

IN NO EVENT SHALL HUNTER FAN COMPANY BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, CONSEQUENTIAL OR INCIDENTAL DAMAGES IN EXCESS OF THE PURCHASE PRICE OF THE HUMIDIFIER. YOUR SOLE REMEDY WILL BE REPAIR OR REPLACEMENT AS PROVIDED ABOVE.

SOME AMERICAN STATES AND CANADIAN PROVINCES DO NOT ALLOW:

• LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS

• THE EXCLUSION OR LIMITATION OF DIRECT, INDIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES

• THE EXCLUSION OR INVALIDITY OF EXPRESS OR IMPLIED WARRANTIES IF THE USER CEASES TO OWN THE HUMIDIFIER

• THE LIMITATION OF REMEDIES AND RECOURSES AVAILABLE TO THE PURCHASER, OR

• THE INVALIDITY OF AN EXPRESS WARRANTY WHEN A PRODUCT IS IDENTIFIED BY BRAND NAME IS NOT USED (UNLESS SPECIFIC CONDITIONS ARE FULFILLED)

ENGLISH

SOME THE ABOVE LIMITATIONS OR EXCLUSIONS MAY NOT APPLY TO YOU.

Page 13

Other Home Comfort Products from Hunter

Hunter Original

QuietFlo™ HEPA Air

Puriﬁer

Programmable

Thermostat

To learn more about Hunter Fan products, visit our web page at:

www.hunterfan.com

H U NT E R FA N C O MPA N Y 2 5 0 0 F R I S C O A V E N U E MEMPHIS, TN 38114, USA
