Owner's Manual
18 pgs1.05 Mb0

Hunter 37755 Owner's Manual

Models 30755, 30756 & 37755
(remote included)
Replacement Filter Information
Model 30755 30756 37755
Pre-Filter
30901 30901 37901
www.hunterfan.com
41790-01 08/02/2005 © 2005 Hunter Fan Company
Table of Contents
Safety Instructions .................................................................................................. 3
Introduction ............................................................................................................ 3
Description of Air Filtration System
How the Air Purifier Works ............................................................................ 4
Air Purifier Components ................................................................................4
Display and Control Keys .............................................................................. 5
Operation
Initial Operation ............................................................................................. 6
Remote Operation...........................................................................................8
Filter Life Counters ........................................................................................ 9
Locking/Unlocking the Keypad ..................................................................... 9
Resetting the Air Purifier ............................................................................. 10
Using the Ionizer .......................................................................................... 10
Controlling the Backlight .............................................................................10
Air Purifier Maintenance
Cleaning Your Air Purifier............................................................................ 11
Changing the Pre-Filter ................................................................................11
Cleaning the Filter ........................................................................................12
Obtaining Replacement Filters .....................................................................14
Troubleshooting
Problem and Solutions ................................................................................. 15
Technical Support .........................................................................................15
Warranty Information ......................................................................................... 16
41790-01 2
SAFETY INSTRUCTIONS
IMPORTANT!
READ ALL INSTRUCTIONS BEFORE USING THIS AIR PURIFIER.
1. This air purifier is designed for use on a flat level floor and may not work properly on an
uneven floor. ALWAYS place the air purifier on a firm level floor. ALWAYS place the air purifier at least six (6) inches away from walls and heat sources such as stoves, radiators, or heaters.
2. Place the air purifier in an area that is out of the reach of children.
3. Before using the air purifier, extend the cord and inspect for any signs of damage. DO NOT use
the product if the cord has been damaged.
4. This product has a polarized plug (one blade is wider than the other) as a safety feature. This plug will fit into a polarized outlet only one way. If the plug does not fit fully into the outlet, reverse the plug. If the plug still does not fit, contact a qualified electrician. DO NOT attempt to defeat or override this safety feature.
5. ALWAYS UNPLUG the air purifier while it is being cleaned.
6. DO NOT move or tilt the air purifier while it is in operation. Turn off and unplug before moving.
7. DO NOT immerse the air purifier in water at any time because permanent damage will occur. To properly clean your air purifier, follow the instructions in the Maintenance section of this manual (pg. 11).
READ AND SAVE ALL INSTRUCTIONS.
Introduction
Thank you for purchasing the PermaLife™ Air Purifier from Hunter Fan Company. You have pur­chased our latest development in portable air purification which has been designed to improve the quality of the air that you breathe. The following innovative features are included in your Hunter Air Purifier.
• High Particulate Efficiency: The cleanable filter will remove 99.5% of 0.5 micron particles
from the air that passes through the filter.
• Odor Removal: The activated carbon pre-filter helps remove odors such as cooking, smoke, and
pet smells from the air. It also traps lint, hair, and other large particles to help extend the life and performance of the cleanable filter.
• Remote Control: This air purifier may also be controlled by the included remote. Using the re-
mote, you can turn off the air purifier or change the speed to sleep (1), active (2), or turbo clean (3).
• Ionizer: The ionizer improves the quality of air in the room by releasing negative ions into the
air that attract positively charged dust, smoke, and pollen particles.
• Quiet: The air purifier has been designed to operate quietly and efficiently. You can choose
among three speeds to best meet your needs at different times.
•Filter Counters: Filter maintenance is critical to the performance of the air purifier. To help you
determine when to change or clean the pre-filter and cleanable filter, the unit has built in life counters that keep track of the life remaining of each filter.
• NiteGlo™ Light: Your air purifier display has a backlight that is continuously lit as long as there
is power to the unit. You can choose to turn the backlight off or on.
3 41790-01
Description of Air Filtration System
How the PermaLife™ Air Purifier System Works
As the air is pulled into the purifier, the activated carbon pre-filter absorbs odors and catches large particles. Then, the air travels through the PermaLife™ Cleanable Filtration System where the smaller particles are collected. Then, the ionizer releases negative ions into the air that attract positively charged dust, smoke, and pollen particles. Finally, the clean purified air is released back into the room.
Dust & Irritants
Pollen & Allergens Odors Bacteria Pet Hair & Dander
Fig. 1 - Illustration of the Air Filtration System
Air Purifier Components
BASE
Fig. 2 - Air Purifier Components
Carbon
Pre-filter
PermaLife™
Cleanable
Filtration System
99.5% – .5 Microns
CLEANABLE FILTER
Ionizer
PRE-FILTER
FRONT GRILL
41790-01 4
Description of Air Filtration System
Display and Control Keys
The display and control keys allow for easy operation of the air purifier.
OFF/SPEED: Adjusts the blower speed and turns the unit on and off.
PRE-FILTER RESET: Resets the Carbon Pre-Filter Life Counter.
FILTER RESET: Resets the Cleanable Filter Life Counter.
IONIZER KEY: Turns the ionizer on and off.
PRE-FILTER RESET KEY
IONIZER KEY
FILTER RESET KEY
CARBON PRE-FILTER INDICATOR
PRE-FILTER LIFE COUNTER
BLOWER SPEED
KEYPAD LOCKED INDICATOR
INFRARED RECEIVER
IONIZER INDICATOR
ANIMATED BLOWER
Fig. 3 - Air Purifier Control Area and Alpha-numeric Display
CLEANABLE FILTER LIFE COUNTER
CLEANABLE FILTER INDICATOR
OFF/SPEED KEY
TURBO KEY
5 41790-01
Operation
Initial Operation
This section provides basic instructions on the use of your air purifier. After following these initial directions, please continue reading this booklet to learn how to operate the more advanced features of your air purifier.
Basic Operation of the Air Purifier:
1. Take the air purifier out of the box and remove the clear plastic protective bag. Place the unit on a firm level floor.
2. Before turning on the air purifier, you need to confirm that the filters are firmly in place and have not become loose during shipping. To check the filters, first open the front grill. Release the front grill by placing your fingers under the handle on the grill and pull forward, then up. Refer to Figs. 4 and 5.
HANDLE
Fig. 4
3. Next, check the cleanable filter by pressing firmly on all four corners of the filter to ensure that it is fully inserted into the filter opening.
4. The carbon pre-filter is mounted inside the front grill with hook tape. Confirm that it properly covers the grill vents. You may notice a few black particles com­ing off the pre-filter. Those particles are part of the odor-removing activated car­bon and will be collected on the filter during use.
41790-01 6
PULL FORWARD, THEN UP
Fig. 5
