Hunter 33283 Owner's Manual

English

Inglés

The Care Free

Evaporative Humidifier

Model 33283

ENGLISH

see page 2

ESPAÑOL

vea la página 7

FRANÇAIS

voir la page 13

CONTENTS

Safety Instructions .....................................................................2

How the Humidifier Works .........................................................2

Humidifier Parts .........................................................................3

Humidifier Features ................................................................... 3

Using Your Humidifier ................................................................ 3

Refilling the Water Tank .............................................................4

Cleaning the Humidifier ............................................................. 4

Humidifier Troubleshooting ........................................................5

Service Parts ............................................................................. 5

Other Home Comfort Products from Hunter ..............................5

Español......................................................................................6

Français ................................................................................... 12

SAFETY INSTRUCTIONS

The Care Free® Evaporative Humidifier has a unique patented design with several innovative features:

• Low Maintenance – Other humidifiers have paper filters

that need to be replaced every few months. Our exclusive PermaWick™ filter saves time and money. It’s designed to last season after season, saving up to $45 a year. No wet paper odors either.

• Pump System – By dispersing water from the top of the

PermaWick™ filter, stagnant water around the PermaWick™ filter is eliminated, and the buildup of mineral residue that can

clog the filter and impede performance is eliminated.

NOTE: The filter has a coating on the wick which may make it appear old or used, but is actually new.

• Built-in Antimicrobial Properties – The plastic parts and the

PermaWick™ filter have built-in antimicrobial properties to inhibit the growth of bacteria, mold and fungi that may affect these parts.

NOTE: This product contains antimicrobial properties which are built-in to inhibit the growth of bacteria which may affect the plastic and PermaWick™ filter in the humidifier. These properties do not extend to the water, humidified air or users. Conduct routine cleaning and maintenance based upon use and individual conditions.

• No White Dust – The Care Free® Humidifier Plus Evaporative

Humidifier produces no white dust that can settle on furniture or be inhaled.

NOTE: You may notice mineral deposits accumulating in the tank base or on the PermaWick™ filter. This is normal and does not affect performance. If you would like to clean these

deposits away, please see CLEANING THE HUMIDIFIERAND

WATER TANK.

HOW THE HUMIDIFIER WORKS

Important Safety Instructions:

Read all instructions before using this

humidifier.

1. This humidifier may not work properly on an uneven

surface. ALWAYS place this humidifier on a firm, level, and water resistant surface. ALWAYS place the humidifier

at least six (6) inches away from walls and 3 ft. from heat sources such as stoves, radiators, or heaters.

2. ALWAYS place the humidifier in an area that is out of the

reach of children.

3. Before using the humidifier, extend the cord and inspect for any signs of damage. DO NOT use the product if the

cord has been damaged.

4.This product has a polarized plug (one blade is wider than the other) as a safety feature. This plug will fit into a polarized outlet only one way. If the plug does not fit fully into the outlet, reverse the plug. If it still does not fit,

contact a qualified electrician. DO NOT attempt to defeat

or override this safety feature.

5. ALWAYS UNPLUG AND EMPTY the humidifier when it is

not in operation or while it is being cleaned.

6. DO NOT tilt or move the humidifier while it is in operation.

Never move the humidifier while there is water in the tank. Empty the water tank, turn off, and unplug the unit before moving.

7. In addition to routine maintenance which may be required, this humidifier requires seasonal cleaning. Refer to and

follow CLEANING THE HUMIDIFIER AND THE WATER

TANK instructions.

8. This unit is designed to be used with distilled and/or tap

water. DO NOT add scented oils, perfumes, or fragrance

additives to the water.

Thank you for purchasing The Care Free® Humidifier Plus Evaporative Humidifier by Hunter Fan Company. Please read and save these instructions to receive the maximum benefit and performance from your humidifier.

TABLE OF CONTENTS

HUMIDIFIER PARTS

Figure 1

Base

PermaWick™

Filter

PermaWick™

Filter Frame

Tank

Cap

Main

Housing

Power/Speed

Control

Humidistat

Controls

Water

Tank

Easy Tote

Handle

Adjustable Humidistat: Enables you to set a desired maximum humidity level. Once this level is reached, the unit will shut off until the humidity level drops. NOTE: The humidifier may not be running because the humidistat setting may need to be adjusted.

Power/Speed Control: Turns the humidifier ‘ON’ and ‘OFF’. The power should always be off before unplugging the humidifier, moving the humidifier, or refilling the water tank.

Power Light: The light will be illuminated when the power is

on.There are 2 fan speeds, high and low.

NiteGlo™ Night Light Control: Turns the night light ‘ON’ and ‘OFF’. The night light can be turned on even if the humidifier fan is turned off.

HUMIDIFIER FEATURES

Figure 2

Power

Light

Power/Speed

Control

Adjustable

Humidistat

Control

NiteGlo™

Night

Light

Control

1. Remove The Care Free® Evaporative Humidifier from its packaging. Read and Save the Instructions.

2. Place the humidifier on a hard, flat, water resistant surface. Always place the humidifier at least six (6) inches away from walls and sources of heat.

3. Lift the main housing to confirm that the PermaWick™ filters

are placed upright in the slots. Replace the main housing. (See Figure 1.)

4. Remove the water tank and take it to the sink or tub to fill.

5. Turn the tank upside down and unscrew the tank cap by turning it counterclockwise. Fill the water tank with cool water

and replace the tank cap (Never use hot water). Be sure not

to fill the tank to overflowing as water damage may occur to furniture or flooring due to spillage.

HUNTER WILL NOT ACCEPT RESPONSIBILITY FOR DAMAGE TO PROPERTY CAUSED BY WATER SPILLAGE.

6. Carry the tank back to the humidifier. Turn the tank upright and place the full tank on the unit and allow the water to fill

the bottom tray. Be sure that the tank is seated properly in

the base. If the tank is properly located on the base, you will see air bubbles flowing up into the tank.

7. With the power control knob in the ‘OFF’ position, plug the humidifier into the wall.

CAUTION: Never plug in the Humidifier while your hands are wet as Electric Shock could occur.

8. Once the water is at the proper level, the tank will stop

bubbling. Run the unit on “HI” speed for 11⁄2 minutes for

optimum pump operation. Set the unit to the desired speed.

9. You can choose the desired humidity output by adjusting the Adjustable Humidistat knob. In a very dry room, the “HI” setting should be used to quickly achieve a comfortable level of humidity. Once the room is comfortable, you can turn the Adjustable Humidistat down. Selection of your desired humidity level is a personal choice and you may have to adjust the dial to find the level where you feel most comfortable. To begin with, we suggest you try a middle location between the lowest and the maximum setting. Then, adjust the level to suit your needs.

10. When the humidity reaches the level you have set, the

Humidifier will shut off. The humidifier will not output humidity while the humidity in the room is at the selected humidity level. When the humidity in the room drops below the selected level, the humidifier will cycle on again.

11. Follow REFILLING THE WATER TANK directions.

12. Use the control button to turn the night light off and on.

The night light can be operated even if the humidifier fan is turned ‘OFF’.

Using Your Humidifier

1. When the water tank level is low, turn the humidifier ‘OFF’, and unplug.

2. Remove the tank and take it to the sink or tub to refill.

3. Turn the tank upside down and unscrew the tank cap by turning it counterclockwise. Empty the tank, refill with fresh cool water (never use hot water), and replace the tank cap.

Be sure not to overfill the tank as water damage may occur

to furniture or flooring due to spillage.

HUNTER WILL NOT ACCEPT RESPONSIBILITY FOR DAMAGE TO PROPERTY CAUSED BY WATER SPILLAGE.

4. Carry the tank back to the humidifier. Turn the tank upright

and place it on the humidifier. Be sure that the tank is seated

properly in the base. If the tank is properly located on the base, you will see air bubbles flowing up into the tank.

5. Place the full tank on the unit and allow the water to fill the bottom tray. The water is at the proper level in the bottom tray when the tank stops bubbling. Run the unit on “HI” speed for 11⁄2 minutes for optimum pump operation. Set the unit to the desired speed.

REFILLING THE WATER TANK

Cleaning the Humidifier

Many regions have hard water with high concentrations of

minerals. When water evaporates from The Care Free® Evaporative Humidifier, minerals may be left behind. These minerals can form a hard white scale which can be removed by following the cleaning instructions. The frequency of cleaning due to mineral build up can vary depending upon the quality of water you may have. Refer to Figure 1 for part names.

1. Turn the humidifier ‘OFF’ and unplug the unit.

2. Lift the main housing and remove the PermaWick Filter

Frame containing the PermaWick™ Filter. The motor is

attached to the main housing. Do not place the motor near water. Do not use a wet towel on the motor or motor housing

as electrical shock may occur.

3. The PermaWick™ Filter should be cleaned in a vinegar and water solution to remove any mineral buildup. Place in a solution of one (1) gallon of water and eight (8) ounces of undiluted white vinegar. Allow the filter to soak for 20 minutes.

4. After soaking, rinse it several times with clean water. Place the PermaWick™ Filter in a location where it can drip dry while you clean the other parts of your humidifier.

5. Remove the water tank from the base and empty any water that is left in the tank. Soak the base in a mixture of one (1) gallon of water and eight (8) ounces of vinegar for 20 minutes.

6. After soaking, wipe the base with a soft cloth or sponge to remove any mineral build up. Rinse with clean water several times. If you are planning on storing the humidifier, be sure

the base is completely dry.

7. Fill the water tank with one (1) gallon of water and eight ounces of undiluted white vinegar. Replace the tank cap and shake the tank vigorously until all interior surfaces of the tank have been exposed to the water/vinegar mixture.

8. Empty the tank of the water/vinegar mixture. Rinse it several times with clean water and then replace the tank cap. If you are planning on storing the humidifier, dry it inside and out, leaving the cap off to allow the tank to completely dry. Continue to clean the other parts of your humidifier.

9. Remove the water diffuser cap by squeezing the two tabs as shown in Figure 3. Rinse the cap in clean water to remove any debris. If the cap contains hard water residue, soak it in a mixture of one (1) quart of water and two (2) ounces of vinegar for 20 minutes. Rinse well and reinstall the

water diffuser cap. Do not expose motor or other electrical

components to water.

10. Wipe the surfaces of the main housing with a soft cloth.

11. Once all the parts are clean, reassemble the humidifier,

and follow the USING YOUR HUMIDIFIER instructions to

continue use. If you are storing the humidifier, make sure the parts are completely dry, reassemble, and store in a dry location.

Figure 3

Water Diffuser Cap

Ta b

HUMIDIFIER TROUBLESHOOTING

1. When I turn my humidifier on, it does nothing but hum.

Sometimes mineral deposits from the water can get trapped in the impeller of the humidifier. Follow the cleaning instructions on page 5.

2. I just bought my humidifier and I am setting it up, but my filter is filthy right out of the box.

Your filter has been treated with an anti-microbial agent that can give the appearance that the filter has mineral deposits on it.

3. My humidifier is starting to sound like a waterfall when I run

it. What should I do?

Follow the cleaning instructions on page 5. Your humidifier filter or water diffuser cap may be clogged.

4. I used to add chemicals to my water such as water softeners

or anti-microbial treatments. Do I need these with my Hunter

humidifier?

There is no need for additives with your Hunter humidifier. Anti-microbial properties have already been molded into the plastic in the unit. Adding these type of treatments could cause damage to the pump system.

5. If the unit is “Care Free”, why do I have to clean it?

All humidifiers require some maintenance. To keep your Hunter humidifier running it is necessary to clean minerals deposits from the filter and pump system.

6. How do I clean my Hunter humidifier and how often?

Refer to page 5 for cleaning instructions. Check your humidifier filters periodically and when you start to see crystal like formations coating the filter or inside of the unit, it is time to be cleaned.

To obtain a service part for your humidifier, call customer service at 1-888-830-1326 or e-mail us at Techsupport@ hunterfanhq.com. Please be prepared to tell the operator the model number of your humidifier and the name of the part you need to replace and the part number. Refer to Figure 1 for part names.

SERVICE PARTS

Filter Frame

95449

Base

98502

Water Tank

95857

Knob A

76729

Tank Cap

86113

Water Diffuser

74884

Filter

74080

To learn more about Hunter Fan Company products, please

see our web page at:

www.hunterfan.com

OTHER HOME COMFORT PRODUCTS

FROM HUNTER

Hunter Original®

QuietFlo™

True HEPA Air

Purifier

Programmable

Thermostat

HUNTER FAN COMPANY

2500 FRISCO AVENUE

MEMPHIS, TN 38114, USA
