HuddleCam HC20X-G2 Data Sheet

Please check HUDDLECAMHD.com for
the most up to date version of this document 1 Rev 1.7 11/17

From 3X - 30X, We’ve got you covered

Model Number:
HC20X-GY-G2 (Black)
HC20X-WH-G2(White)

https://huddlecamhd.com
/huddlecamhd-20x/

Conferencing Camera

The HuddleCamHD 20X is ideal for medium to large sized meeting rooms.
Comes standard with a certified SONY lens.

• 20X Optical Zoom

• USB 3.0 (requires

quad-core processor)

• USB 2.0 (Reduced FPS)

• RS-232 Serial Control

• 1920 x 1080

• 58° Field of View

• Up to 30 fps

• 64 Presets

• IR Remote

1. Lens

4. Standby LED

7. VISCA IN Port

20x Optical Zoom

Orange LED blinks
for Stand-By status

Used for connecting hard-wired
joystick for camera control

2. IR Receiver

5. USB 3.0 Interface

8. VISCA OUT Port/RS-485

To receive IR remote
controller signal

For connection to PC USB

3.0 port (also compatible
w/ USB 2.0 port & driver)

Used for daisy chaining multiple
units in a succession with a hard
wired joystick for camera control

3. Power LED

6. IR Select Switch

9. DC In 12V Socket

Blue LED lights when
unit is powered and is
dark in standby mode.

Control up to 3 cameras
through a single IR remote

Only use the power adapter
supplied with this camera

Image Sensor & Lens

Physical

Video CMOS Sensor 1/2.8” CMOS, 2.1 Mega Pixel

Material Aluminum, Plastic

Resolution 1080p-30/25, 720p-30/25

Dimensions (in.) 5.7W x 6.4H x 6.0D (7.4H max w/ tilt)

Frame Rate up to 30fps (MJPEG)

Dimensions (mm) 145 x 163 x 151 (188H max w/ tilt)

Lens Zoom 20X Optical Zoom f=4.7-94mm

Weight 2.52 lbs (1.14 kg)

Field of View 5° (tele) to 58° (wide)

Box Dimensions 12.1”W x 9.5”H x 9.6”D (307mm x 241mm x 244mm)

Pan/Tilt Movement

Boxed Weight 5.6 lbs (2.54 kg)

Pan Movement ±340°

Operating Temperature 32°F to 113°F (0°C to 45°C)

Tilt Rotation Up: 90°, Down: 30°

Colors Gray, White

Presets 64 Presets

Rear Board Connectors

Electrical Index

Video Interface USB 3.0

Power Supply Adapter 12V DC 2A

Controller Signal Interface Mini DIN-8 (VISCA IN/OUT, PELCO-D IN/OUT)

Input Voltage 12V DC (10.5-14V DC)

Controller Signal Config. Dip-Switch Pin 6/TTL Signal

Input Power 24W (Max)

Baud Rate 9600 bps

Working Environment Indoor

Power Supply Interface DC 12V 2A

Other

Quality Management System

Mfg. Warranty 2 Years Parts & Labor

QMS Certified ISO9001: 2008

• 20X Zoom USB 3.0 Camera

• 12V/2.0A DC Power Adapter

• Installation Bracket & Screw

• USB 3.0 Data Cable (3m)

• Serial Control Cable

• RS-232C to RS-485 Adaptor

• IR Remote Control

• User Manual

(also available online)

1 2 3 4 2 5 6 7 8

9

DATA SHEET HuddleCamHD Camera Specifications

152 Robbins Road Downingtown, PA 19335 HuddleCamHD.com 800-486-5276

Compatibility

• Windows 7/8/8.1/10

• Mac OSX

• Acano

• Adobe Connect

• Blue Jeans

• Cisco Jabber

• Cisco Webex*

• Easy Meeting

• Facetime

• Fuzebox

• Google Hangouts

• GoToMeeting

• Lifesize

• Skype for Business (Lync)

• Polycom Real Presence

• Radavision

• Spontania

• Skype

• TurboMeeting US

• Vidyo

• Zoom.US

• Google Hangouts on Air

• YouTube Live

• Any app that supports the

UVC camera interface

*These apps do not support
Image Flip

IR Remote Control Functionality

1. Reset

Restarts the camera and restores
it to Factory Default settings.
(Note: Will delete all saved
settings and presets.)

2. Camera Selection

Select which Camera to control via
IR: 1, 2 or 3

3. Preset Positions

1-9: Preset Positions
Set: Set a Preset Position
Clear: Clear a Preset Position
Call: Call a Preset Position
Note: If you want to set (or call)
the first preset position to 1, you
simply press number key “1”, then

press ”Set” or “Call” to set (call)

the position.

4. Fast Zoom In/Out Control Zone

+: Zoom In quickly

-: Zoom Out quickly

5. Pan/Tilt Controller

Tilt Up
Tilt Down

Pan Left
Pan Right

Auto Pan (through Full pan

range)

6. Additional Function Zone

Model Dependent Functions
Not applicable to this model

7. Power Supply Switch

Switch for turning camera on/off
(i.e. Working mode vs. Stand-By
mode)

8. OSD Menu Zone

Model Dependent Functions
Not applicable to this model

9. Slow Zoom In/Out Control Zone

+: Zoom In slowly

-: Zoom Out slowly

10. Focus Control Zone

Auto: Turn on Auto Focus
Manual: Turn on Manual Focus
Far: Set focus at a farther distance
(requires Manual Focus)
Near: Set focus at a nearer
distance (requires Manual Focus)

11. Pan/Tilt Function Zone

Home: Go to camera’s Home
position
Rev: Enable image flip for ceiling
mounting
L-Limit: Sets left limit for Scan
feature
R-Limit: Sets right limit for Scan
feature
Scan: Auto pan to L&R limits
Tour: Auto tour of all saved
presets
