CLT-L0J
Quick Start Guide
Your Device at a Glance
NFC
NFC
1
3
4
5
6
7
8
10
9
2
11
12
13
14
15
16
Before you start, let's take a look at your new device.
l To power on your device, press and hold the power button
until the screen turns on.
l To power off your device, press and hold the power button,
and then touch .
l To restart your device, press and hold the power button,
and then touch .
l Press and hold the power button for 10 or more seconds to
forcibly restart your device.
Secondary microphone Laser sensor
Rear camera Flash / Color
Earpiece Card slot
Primary microphone USB-C port / Headset
Speaker Fingerprint scanner
temperature sensor
jack
Power button Volume button
Ambient light sensor /
Optical proximity
sensor
Front camera
Status indicator Infrared sensor
1
Getting Started
1 2
l Do not insert or remove the SIM card when your device
is powered on.
l Ensure that the card is correctly aligned and that the
card tray is level when you insert it into your device.
l Be careful not to scratch your device or hurt yourself
when using the eject pin.
l Store the eject pin out of the reach of children to
prevent accidental swallowing or injury.
l Do not use cut or modied SIM cards with your device
as these may not be recognized and could damage the
card tray (slot).
l If your SIM card does not match your device, please
contact your carrier.
Follow the instructions in the following gures to set up your
device. Please use the eject pin included.
Single-SIM:
2
