2 Getting to Know Your Mobile
Phone
2.1 Mobile Phone View
2.1.1 Phone at a Glance
All the pictures in this guide are for your reference only. The actual appearance
and display features depend on the mobile phone you purchase.
Wrist strap
opening
Power
Volume
keys
Speaker
Menu
Back
OK
Earpiece
Status indicator
Headset jack
Camera
Home
Search
End
Send
Navigation
4
Microphone
Charge/Data port
2.1.2 Key Functions at Your Fingertips
• Press to power on your mobile phone.
• Press and hold to open the
• Press to lock the screen when your mobile phone is active.
• Touch to return to the previous screen.
• Touch to exit any application you are running.
• Touch to hide the keyboard.
Touch to open the menu on an active screen.
• Touch to return to the H ome screen.
• Touch and hold to show the most recently used applications.
• Touch to open Google search for searching your mobile phone and
the web.
• Touch and hold to open Google search by voice.
• Press to make or answer a call.
• Press to go to the
• Press to hang up a call.
• Press to return to the Home screen.
Press to navigate selectable items on the screen.
Press to select a highlighted item.
Call log
Phone options
screen.
menu.
5
2.2 Installing Your Mobile Phone
2.2.1 Installing the UIM Card and the Battery
1
Remove the battery cover
3
Insert the *microSD card4Install the battery
5
Install the battery cover
6
2
Insert the UIM card
*micro SD card is optional
2.2.2 Charging the Battery
Before charging the battery, ensure that it has been properly inserted into your phone.
1
2
1. Connect the USB cable that came with your mobile phone to the charger.
2. Connect the USB cable to your mobile phone. Then, plug in the connector of the
charger to an electrical outlet. The phone begins charging.
If your mobile phone is charged when it is powered on, the battery icon on the
Notification bar shows the charging status. When the battery icon changes to , it
indicates that your mobile phone is fully charged.
Status Indicator
The color of the status indicator tells the battery status of your mobile phone.
Status Indicator
Green: Fully charged (when connected to charger).
Orange: Charging in progress (when connected to charger).
Red: Battery low.
2.2.3 Important Information About the Battery
• If the battery has not been used for a long period of time, you may not be able to
power on your mobile phone immediately after you begin charging the battery.
7
Allow the battery to charge for a few minutes with the phone powered off before
attempting to power on the phone.
• The battery will not hold a charge for the way it did when it was new. When the
battery life becomes noticeably shorter than usual after being charged properly,
replace the battery with a new one of the same type.
• Using data services increases demand on the battery and will reduce the length of
time it can hold a charge.
• The time required to charge the battery depends on the ambient temperature and
the age of the battery.
• When the battery is low on power, the phone displays a prompt. When battery
power is almost exhausted, your phone will power off automatically.
2.2.4 Battery Saving Tips
The longevity of battery power depends on the network that you connect to, and how
you use your mobile phone.
Try the following to conserve battery power:
• When your mobile phone is not in use, switch off the screen.
• Reset the time it takes for your screen light to switch off when you leave your phone
idle.
• Lower the screen brightness.
• Use the AC adapter to plug your phone into an external power source whenever
possible.
• Turn Bluetooth off when you are not using it. Only make your phone visible to other
Bluetooth devices when you need to establish a Bluetooth connection.
• Switch off Wi-Fi when you are not using it.
• Turn off your phone connection to GPS satellites when you are not using it.
• Lower the volume.
• Close power-draining programs, when you do not need them.
• Turn off the data service.
8
2.3 Power On or Off Your Mobile Phone
2.3.1 Powering On Your Mobile Phone
Press . The first time you power on your phone, you will be asked to sign in to
your account and set up your mobile phone.
If personal identification number (PIN) protection is enabled on your mobile
phone, you must enter your PIN before using the mobile phone.
2.3.2 Setting Up Your Mobile Phone
The first time you power on your mobile phone, the phone displays a setup wizard to
help you set up the phone.
The setup wizard helps you:
• Learn about your mobile phone
• Create or sign into your account
• Make some initial decisions about how you want to use your mobile phone
2.3.3 Powering Off Your Mobile Phone
1. Press and hold to open the
Power off
OK
.
.
2. Touch
3. Touch
Phone options
menu.
2.4 Using the Touchscreen
2.4.1 Touchscreen Actions
•
Touch
: Use the touch of your finger to select an item, confirm a selection, or start an
application.
Touch and hold
•
your mobile phone responds. For example, to open the options menu for the active
screen, touch the screen and hold down until the menu appears.
Flick
•
: Touch an item with your finger and continue to press down until
: Move your finger either vertically or horizontally across the screen.
9
•
Drag
: Touch and hold the desired item with your finger. To move an item, Drag the
item to any part of the screen. You can drag an icon to move or delete it.
2.4.2 Rotating Your Mobile Phone Screen
The orientation of most screens will rotate with the phone as you turn it from upright to
sideways and back again.
2.5 Locking and Unlocking the Screen
2.5.1 Locking the Screen
• When your phone is on, press to lock the screen. When the screen is locked,
you can still receive messages and calls.
• If your phone is idle for a while, the screen will lock automatically.
2.5.2 Unlocking the Screen
1. Press to wake up the screen.
2. Drag the lock icon from left to right to unlock the screen.
If you have set up a screen unlock pattern, you will be prompted to draw the
pattern on the screen to unlock it.
10
2.6 Home Screen
10:23
Notifications bar:
Displays the reminders and status icons of
your phone. Flick down to open the
notifications panel.
Display area:
Shows the operation and display areas of
your phone.
Screen switching dots:
Indicate the number of the screens on the
left or right. Touch the left or right dots to
switch between the screen.
Touch to open the Browser.
Touch to view all your applications.
Touch to open the Phone application.
2.6.1 Notification and Status Icons
Call in progress
Call in progress using a
Bluetooth device
Call forwarding onCall on hold
Missed callConnected to a PC
GPS connectedMusic playing
New voicemailNew message
EV connectedEV in use
11
2.6.2 Notification Panel
Your mobile phone will notify you when you receive a new message or there is an
incoming event. The notification panel also informs you about alarms and settings, for
example, when
the wireless network operator is or to view a message, reminder, or event notification.
Call forwarding
is activated. Open the notification panel to see who
Opening the Notification Panel
1. When a new notification icon appears on the notification bar, touch and hold the
notification bar, and then flick down to open the notification panel.
2. On the notification panel, you can do the following:
• Touch a notification to open the related application.
• Touch
Clear
to clear all notifications.
Closing the Notification Panel
Touch and hold the bottom of the panel. Then flick up to close it.
2.6.3 Viewing Other Parts of the Home Screen
10:23
Flick your finger left or
right across the Home
screen.
Touch a thumbnail to
open the Home screen
or its extensions.
Touch and hold the small dots to view thumbnails
of the Home screen and its extensions.
12
2.6.4 Customizing the Home Screen
Adding a New Screen Item
1. Touch and hold a blank area on the Home screen until the
menu is displayed.
2. Select an item to add it to the Home screen.
Moving a Screen Item
1. Touch and hold an item on the Home screen until the item expands in size and the
mobile phone vibrates.
2. Without lifting your finger, drag the item to the desired position on the screen, and
then release it.
Removing a Screen Item
1. Touch and hold an item on the Home screen until the item expands and the mobile
phone vibrates.
2. Without lifting your finger, drag the item to the trash can. When the item and the
trash can turn red, the item is ready to be removed.
3. Release the item to remove it from the Home screen.
Add to Home screen
2.6.5 Changing the Wallpaper
1. On the Home screen, touch >
2. Do any of the following:
• Touch
Live wallpapers
• Touch
Pictures
to select a picture and set it as the wallpaper.
Wallpapers
• Touch
Wallpaper
.
to select a picture and set it as the wallpaper.
to select a picture and set it as the wallpaper.
2.7 Using a microSD Card
2.7.1 Using the microSD Card as USB Mass Storage
To transfer all your favorite music and pictures from your PC to your mobile phone’s
microSD card, set the micr oSD card as USB mass storage.
13
1. Connect your mobile phone to your PC with the USB cable. Your PC will detect the
microSD card as a removable disk.
2. Open the notification bar, and then touch
Turn on USB storage
3. Touch
to transfer files.
You can now transfer files from your PC to your mobile phone’s microSD card.
When your microSD card acts as USB mass storage, your mobile phone will not
use this memory space. Your PC will tell you how to safely disconnect the USB
mass storage device (your mobile phone) when you have finished transferring
files.
USB connected
in the dialog box that opens to confirm that you want
.
2.7.2 Removing the microSD Card
1. Touch >
2. Scroll down the screen, and then touch
SD card
3. Carefully remove the microSD card.
.
Settings
.
SD card & phone storage
>
Unmount
3 Calling
To make a phone call, you can dial a number or touch a number from your contact
list, on a Web page, or in a document. When you are on a call, you can answer other
incoming calls or send them to your voicemail box. You can also set up conference
calls with several participants.
3.1 Making a Call
To make a call, you can use the
Contacts
or
Call log
When you are on a call, you can touch to return to the Home screen and use
other functions. To return to the calling screen, flick the notification bar down and touch
Current call
.
Do not block the microphone at the bottom of your phone if you want your voice
heard.
14
Phone
.
application, or select a numbe r from
3.1.1 Making a Call with the Phone Application
1. Touch >
2. Touch the appropriate numeric keys to enter the phone number.
3. Touch to initiate the call.
Phone
If you are already working with
During a call, flick up the
to display the dialer.
Dialpad
Contacts
or
Call log
, touch the
Phone
tab to enter other numbers on the dialpad.
tab.
3.1.2 Making a Call from Contacts
1. Touch >
2. In the list, touch the contact you want to call.
3. Touch to dial the phone number.
Contacts
If you are already working with
to display the contact list.
Phone
or
Call log
, touch the
Contacts
tab.
3.1.3 Making a Call from Call log
1. If you are already working with
2. Touch to the right of the log entry to dial.
If you touch and hold a log entry, the options menu will open.
Contacts
or
Phone
, touch the
Call log
tab.
3.2 Answering or Rejecting a Call
3.2.1 Answering an Incoming Call
When you receive a phone call, the incoming call screen opens with the caller's name
and number that you have entered in
Drag the to the right to answer the call.
Contacts
.
15
3.2.2 Ending a Call
During a call, press or touch >
End call
3.2.3 Rejecting an Incoming Call
Drag the to the left to reject the call.
16
to hang up.
Loading...
+ 45 hidden pages
You need points to download manuals.
1 point = 1 manual.
You can buy points or you can get point for every manual you upload.
