HT instruments MACROTEST G3 User Manual

User manual
MACROTESTG3 – COMBIG3
Copyright HT ITALIA 2014 Release EN 1.01 27/03/2014
MACROTESTG3 - COMBIG3
Table of contents:
1.PRECAUTIONS AND SAFETY MEASURES ............................................................... 3
1.1. Preliminary instructions ..................................................................................................... 3
1.2. During use ......................................................................................................................... 4
1.3. After use ............................................................................................................................ 4
1.4. Definition of measurement (overvoltage) category ............................................................ 4
2.GENERAL DESCRIPTION ........................................................................................... 5
2.1. Foreword ........................................................................................................................... 5
2.2. Instrument functions .......................................................................................................... 6
3.PREPARATION FOR USE ........................................................................................... 7
3.1. Initial checks ...................................................................................................................... 7
3.2. Instrument power supply ................................................................................................... 7
3.3. Calibration ......................................................................................................................... 7
3.4. Storage .............................................................................................................................. 7
4.NOMENCLATURE ........................................................................................................ 8
4.1. Instrument description ....................................................................................................... 8
4.2. Description of measuring leads ......................................................................................... 8
4.3. Keyboard description ......................................................................................................... 9
4.4. Display description ............................................................................................................ 9
4.5. Initial screen ...................................................................................................................... 9
5.GENERAL MENU ....................................................................................................... 10
5.1. Instrument settings .......................................................................................................... 10
5.1.1. Language ............................................................................................................................... 10
5.1.2. Automatic Power OFF for display and key sound ................................................................. 11
5.1.3. System ................................................................................................................................... 11
5.1.4. Operator name entry .............................................................................................................. 11
5.1.5. System date/time setting ........................................................................................................ 11
6.OPERATING INSTRUCTIONS ................................................................................... 12
6.1. LOW: Continuity of protective conductors .................................................................... 12
6.1.1. Anomalous situations ............................................................................................................. 15
6.2. M: Measurement of insulation resistance ..................................................................... 16
6.2.1. Anomalous situations ............................................................................................................. 19
6.3. RCD: Test on differential switches .................................................................................. 20
6.3.1. AUTO mode ........................................................................................................................... 24
6.3.2. x½, x1, x2, x5 modes ............................................................................................................. 25
6.3.3. Mode x1 – Test on RCDs with delay time .............................................................................. 25
6.3.4. Mode ................................................................................................................................. 26
6.3.5. Test on earth leakage relay RCD .......................................................................................... 27
6.3.6. Anomalous situations ............................................................................................................. 28
6.4. LOOP: Line impedance/Loop and overall earth resistance ............................................. 31
6.4.1. Test types ............................................................................................................................... 33
6.4.2. STD Mode – Generic test ...................................................................................................... 34
6.4.3. Mode kA – Verify of breaking capacity of protection device .................................................. 37
6.4.4. Mode I2t – Verify of protection against short-circuit ............................................................... 39
6.4.5. Mode - Verify of protection coordination ..................................................................... 42
6.4.6. Verify of protection against indirect contacts (TN system) .................................................... 44
6.4.7. Verify of protection against indirect contacts (IT systems) .................................................... 46
6.4.8. Verify of protection against indirect contacts (TT systems) ................................................... 47
6.4.9. Impedance measurement by means of the accessory IMP57 .............................................. 49
6.4.10. Anomalous situations ............................................................................................................. 51
6.5. SEQ: Phase sequence and phase concordance test ...................................................... 53
6.5.1. Anomalous situations ............................................................................................................. 56
6.6. LEAKAGE: Leakage current measurement ..................................................................... 57
6.7. EARTH: Measurement of earth resistance ...................................................................... 59
6.7.1. 3-wire or 2-wire earth measurement and 4-wire ground resistivity ....................................... 59
6.7.2. Earth measurement with optional clamp T2100 .................................................................... 65
6.7.3. Anomalous situations in 3-wire and 2-wire earth measurements .......................................... 68
6.8. AUX: Measure of ambient parameters through external probes ..................................... 69
EN - 1
MACROTESTG3 - COMBIG3
6.9. ΔV%: Voltage drop of main lines ..................................................................................... 71
6.9.1. Anomalous situations ............................................................................................................. 75
7.OPERATIONS WITH THE MEMORY ......................................................................... 77
7.1. Saving measurements ..................................................................................................... 77
7.2. Recalling measurements and deleting the memory ........................................................ 78
7.2.1. Anomalous situations ............................................................................................................. 79
8.CONNECTING THE INSTRUMENT TO A PC ............................................................ 80
8.1. Connection to iOS/Android devices through WiFi ........................................................... 80
9.MAINTENANCE .......................................................................................................... 81
9.1. General information ......................................................................................................... 81
9.2. Replacement of the batteries .......................................................................................... 81
9.3. Cleaning the instrument .................................................................................................. 81
9.4. End of life ........................................................................................................................ 81
10.TECHNICAL SPECIFICATIONS ................................................................................. 82
10.1.Technical characteristics ................................................................................................. 82
10.2.Reference guidelines ....................................................................................................... 86
10.3.General characteristics .................................................................................................... 86
10.4.Environment .................................................................................................................... 86
10.4.1. Environmental conditions for use ........................................................................................... 86
10.5.Accessories ..................................................................................................................... 86
11.SERVICE .................................................................................................................... 87
11.1.Warranty conditions ......................................................................................................... 87
11.2.Service ............................................................................................................................ 87
12.THEORETICAL APPENDIXES ................................................................................... 88
12.1.Continuity of protective conductors ................................................................................. 88
12.2.Insulation resistance........................................................................................................ 89
12.3.Checking circuit separation ............................................................................................. 90
12.4.Test on differential switches (RCD) ................................................................................. 92
12.5.Verify of the breaking capacity of protection devices ...................................................... 93
12.6.Verify of protection against indirect contacts in TN systems ........................................... 94
12.7.Verify of protection against indirect contacts in TT systems ........................................... 96
12.8.Verify of protection against indirect contacts in IT systems ............................................. 97
12.9.Verify of protection coordination L-L, L-N and L-PE ........................................................ 98
12.10.Verify of the protection against short circuits – Test I2t ................................................. 100
12.11.Verification of voltage drop on main lines ...................................................................... 101
12.12.Measurement of earth resistance in TN systems .......................................................... 101
12.12.1.Measurement of earth impedance by voltammetric method ............................................... 102
12.12.2.Ground resistivity measurement .......................................................................................... 104
EN - 2
MACROTESTG3 - COMBIG3
1. PRECAUTIONS AND SAFETY MEASURES
The instrument has been designed in compliance with directives IEC/EN61557 and IEC/EN61010-1 relevant to electronic measuring instruments. Before and after carrying out the measurements, carefully observe the following instructions:
Do not carry out any voltage or current measurement in humid environments. Do not carry out any measurements in case gas, explosive materials or flammables are
present, or in dusty environments.
Avoid any contact with the circuit being measured if no measurements are being
carried out.
Avoid contact with exposed metal parts, with unused measuring probes, etc. Do not carry out any measurement in case you find anomalies in the instrument such
as deformations, breaks, substance leaks, absence of display on the screen, etc.
Pay special attention when measuring voltages higher than 25V in special
environments (such as construction sites, swimming pools, etc.) and higher than 50V in normal environments, since a risk of electrical shock exists.
Only use original HT accessories.
The following symbols are used in this manual:
CAUTION: observe the instructions given in this manual; improper use could damage the instrument, its components or create dangerous situations for the operator.
High voltage danger: electrical shock hazard.
Double insulation
AC voltage or current
DC voltage or current
Connection to earth
The symbol indicates that the instrument must not be connected to systems with phase-to-phase rated delta voltage higher than 415V.
1.1. PRELIMINARY INSTRUCTIONS
This instrument has been designed for use in the environmental conditions specified in
§ 10.4.1. Do not use in different environmental conditions.
The instrument may be used for measuring and verifying the safety of electrical
systems. Do not use on systems exceeding the limit values specified in § 10.3.
We recommend following the normal safety rules devised to protect the user against
dangerous currents and the instrument against incorrect use.
Only the accessories supplied with the instrument guarantee compliance with safety
standards. They must be in good conditions and be replaced with identical models, when necessary.
Make sure the batteries are correctly installed. Before connecting the test leads to the circuit being measured, check that the desired
function has been selected.
EN - 3
MACROTESTG3 - COMBIG3
1.2. DURING USE
Please carefully read the following recommendations and instructions:
CAUTION
Failure to comply with the caution notes and/or instructions may damage the instrument and/or its components or be a source of danger for the operator.
Before changing function, disconnect the test leads from the circuit under test. When the instrument is connected to the circuit under test, never touch any terminal,
even if unused.
Avoid measuring resistance if external voltages are present. Even if the instrument is
protected, excessive voltage could cause damage.
While measuring current, place the clamp jaws as far as possible from the conductors
not involved in the measurement, as the magnetic field they produce could interfere with the measuring operations and place the conductor as much as possible in the center of the jaws to maximize accuracy.
1.3. AFTER USE
When measurements are completed, turn off the instrument by pressing and holding the ON/OFF key for some seconds. If the instrument is not to be used for a long time, remove the batteries and follow the instructions given in § 3.4.
1.4. DEFINITION OF MEASUREMENT (OVERVOLTAGE) CATEGORY
Standard "IEC/EN61010-1: Safety requirements for electrical equipment for measurement, control and laboratory use, Part 1: General requirements” defines what measurement category, commonly called overvoltage category, is. § 6.7.4: Measured circuits, reads: circuits are divided into the following measurement categories:
Measurement category IV is for measurements performed at the source of a low-
voltage installation.
Examples are electricity meters and measurements on primary overcurrent protection devices and ripple control units.
Measurement category III is for measurements performed on installations inside
buildings.
Examples are measurements on distribution boards, circuit breakers, wiring, including cables, bus-bars, junction boxes, switches, socket-outlets in fixed installation, and equipment for industrial use and some other equipment, for example, stationary motors with permanent connection to fixed installation.
Measurement category II is for measurements performed on circuits directly
connected to the low-voltage installation.
Examples are measurements on household appliances, portable tools and similar equipment.
Measurement category I is for measurements performed on circuits not directly
connected to MAINS.
Examples are measurements on circuits not derived from MAINS, and specially protected (internal) MAINS-derived circuits. In the latter case, transient stresses are variable; for that reason, the standard requires that the transient withstand capability of the equipment is made known to the user.
EN - 4
MACROTESTG3 - COMBIG3
2. GENERAL DESCRIPTION
2.1. FOREWORD
If used according to the instructions given in this manual, the instrument you have just purchased will guarantee accurate and reliable measures. This manual refers to MACROTESTG3 and COMBIG3 models. The characteristics of the models are listed in the following Table 1: In the whole manual, the word “instrument” generically indicates MACROTESTG3 model, unless otherwise indicated.
Icon Acronym Measurement description MACROTESTG3 COMBIG3
Continuity test of earth, protective and
RPE
M
RCD
LOOP
equipotential conductors with test current higher than 200mA and open-circuit voltage between 4V and 24V.
Measurement of insulation resistance with continuous test voltage of 50V, 100V, 250V, 500V or 1000V
Tests on molded case RCD (STD) and without integral current breaking device RCD (
General and Selective of type AC ( ), A ( ) and B ( ) of the following parameters:
Tripping time Tripping current Contact voltage
Measurement of overall earth resistance in sockets with no residual current protection
tripping (Ra impedance and of fault loop (Loop P-N, P-P, P­PE) with calculation of the assumed short­circuit current (Ipsc) in Standard or IMP57 mode (with high resolution by means of optional accessory IMP57)
) and measurement of line
)
Measurement of earth impedance and ground
EARTH
SEQ
AUX
LEAKAGE
ΔV%
resistivity by voltammetric method and measurement by using optional clamp T2100
Detection of phase rotation in a generic three­phase system with 2- or 1-terminal measuring method
Measurement of environmental parameters (Temperature, Humidity, Illuminance) by using optional probes
Real-time measurement of leakage current by using optional clamp HT96U
Measurement of percentage voltage drop on mains lines
Optional
Table 1: Characteristics of models
EN - 5
MACROTESTG3 - COMBIG3
2.2. INSTRUMENT FUNCTIONS
The instrument is equipped with a TFT color LCD display, with capacitive "touch-screen" that can be handled simply with the touch of a finger by the user and is structured with an icon-based menu allowing the direct selection of measurement functions for quick and intuitive use.
The instrument can perform the following tests (compatibly with the characteristics described in Table 1):
RPE Continuity test of earth, protective and equipotential conductors with test
current higher than 200mA and open-circuit voltage between 4V and 24V
M Measurement of insulation resistance with continuous test voltage of 50V,
100V, 250V, 500V or 1000V DC
RCD Test on molded case RCD (Standard – STD) and on earth leakage relay
RCD ( ) General (G), Selective (S) and Delayed ( ) of type A ( ) and AC ( ) and B ( ) of the following parameters: tripping time, tripping current, contact voltage
LOOP Measurement of line impedance/Loop P-N, P-P, P-E with calculation of
the assumed short-circuit current, also with high resolution (0.1m) (by means of optional accessory IMP57), overall earth resistance without causing the RCD tripping, check of the interruption capacity of magnetothermal protections (MCB) and fuses, I2t test, protection check in case of indirect contacts
EARTH Measurement of earth impedance and ground resistivity by
voltammetric method and by an external clamp connected to the instrument (optional accessory T2100) (MACROTESTG3 or COMBIG3
enabled) SEQ Indication of phase sequence with 2- or 1-terminal method AUX Measurement of environmental parameters (illuminance, air temperature,
humidity) by means of optional external probes and DC voltage signals LEAKAGE Measurement of leakage current (by means of the optional accessory
HT96U) ΔV% Measurement of percentage voltage drop on main lines
EN - 6
MACROTESTG3 - COMBIG3
3. PREPARATION FOR USE
3.1. INITIAL CHECKS
Before shipping, the instrument has been checked from an electric as well as mechanical point of view. All possible precautions have been taken so that the instrument is delivered undamaged. However, we recommend checking it to detect any damage possibly suffered during transport. In case anomalies are found, immediately contact the Dealer.
We also recommend checking that the packaging contains all the components indicated in
§ 10.5. In case of discrepancy, please contact the Dealer. In case the instrument should be returned, please follow the instructions given in § 11.
3.2. INSTRUMENT POWER SUPPLY
The instrument is powered by 6 1.5V alkaline batteries of type AA LR06 or 6 1.2V NiMH rechargeable batteries of type AA LR06 supplied with the instrument. Rechargeable batteries can be recharged with the external chargers provided with the instrument too.
The green “ ” symbol indicates a sufficient charge level for the correct execution of the tests. The red “ ” symbol indicates an insufficient charge level for the correct
execution of the tests. In this case, recharge the batteries (see § 9.2).
The instrument is capable of keeping data stored even without batteries.
The instrument has an AutoPower OFF function (which can be deactivated) after 5 minutes idling (see § 5.1.2).
3.3. CALIBRATION
The instrument has the technical specifications described in this manual. Its performance is guaranteed for 12 months from the date of purchase.
3.4. STORAGE
In order to guarantee precise measurement, after a long storage time under extreme environmental conditions, wait for the instrument to come back to normal condition (see §
10.4.1).
EN - 7
MACROTESTG3 - COMBIG3
4. NOMENCLATURE
4.1. INSTRUMENT DESCRIPTION
CAPTION:
1. Inputs
2. LCD Touch screen display
3. Function keys F1, F2, F3, F4
4. ,, , / ENTER keys
5. Compartment of the connector for optical cable/USB port
6. ESC key
7. GO/STOP key
8. HELP key
9. SAVE key
10. ON/OFF key
Fig. 1: Description of the front part of the instrument
Fig. 2: Description of the upper part of the instrument
Fig. 3: Description of the instrument's side
4.2. DESCRIPTION OF MEASURING LEADS
CAPTION:
1. Connector for remote probe
2. B1, B2, B3, B4 inputs
3. In1 input
CAPTION:
1. Connector for optical cable/USB port and adapter optical/WiFi C20103
CAPTION:
1. Hand protection
2. Safe area
Fig. 4: Description of measuring leads
EN - 8
MACROTESTG3 - COMBIG3
4.3. KEYBOARD DESCRIPTION
The keyboard includes the following keys:
ON/OFF key to switch on/off the instrument
ESC key to exit the selected menu without confirming
keys to move the cursor through the different screens in order to select the desired programming parameters
HOME / ENTER key to back to general Menu on each moment
GO/STOP key to start the measurement
SAVE key to save the measured values
HELP key to access the online help and display the possible connections
F1, F2, F3, F4
between the instrument and the system for each selected function
Function keys corresponding to the activation of the four icons on the bottom of the screen as an alternative to direct touch on the display
4.4. DISPLAY DESCRIPTION
The display is an LCD, 320x240pxl TFT color display with capacitive touch screen whose icon-structure can be directly selected with a simple touch. The first line of the display indicates the type of active measurement, the date/time and the battery charge indication.
4.5. INITIAL SCREEN
When switching on the instrument, the initial screen appears for a few seconds. It shows:
The HT manufacturer's logo The instrument model The Firmware version of the two instrument's internal
microprocessors (Fw1 and Fw2)
The serial number (SN:) of the instrument The date of instrument calibration (Calibration date:)
After a few seconds, the instrument switches to the general menu.
EN - 9
MACROTESTG3 - COMBIG3
5. GENERAL MENU
Pressing the ENTER key in any condition of the instrument allows to go back to the general menu in which internal parameters may be set, the saved measures can be displayed and the desired measuring function may be selected.
Fig. 5: General menu of the instrument
Touch the icon to move to the following page of the general menu and the icon to
go back to the previous page. Inside the screens, touch the icon to confirm a selection
or the icon to exit without confirming.
5.1. INSTRUMENT SETTINGS
Touch the icon. The screen to the side appears on the display. The following settings are available:
System language setting Setting of the type of electrical system Operator name setting System date/time setting Activation/deactivation of display AutoPower OFF and of
key sound
Settings will be maintained also after switching off the instrument.
5.1.1. Language
Touch the icon to select the system language. The screen to the side appears on the display.
Select the desired language, confirm the choice and return to the previous screen.
EN - 10
MACROTESTG3 - COMBIG3
5.1.2. Automatic Power OFF for display and key sound
Touch the icon. The screen to the side appears on the display.
Move the slide bar reference of section " " down/up to turn off/on the Automatic Power OFF of the instrument after a period of inactivity of 5 minutes.
Move the slide bar reference of section " " down/up to disable/enable the sound key when pressed. Confirm the choices made and go back to the previous screen.
5.1.3. System
Touch the icon to select the type of electrical system (TT, TN or IT), of the mains frequency (50Hz, 60Hz), of the limit value for contact voltage (25V, 50V) and rated voltage value to be used for calculating the assumed short-circuit current (see §). The screen to the side appears on the display.
Move the slide bar references to select the options. Confirm the choices made and go back to the previous screen.
5.1.4. Operator name entry
Touch the icon to enter the name of the operator that will be displayed in the header of each measurement downloaded to PC. The screen to the side appears on the display.
Set the desired name using the virtual keyboard (max 12
characters).
Confirm the settings or exit without saving.
5.1.5. System date/time setting
Touch the icon
to set the system date/time. The screen
to the side appears on the display.
Touch the "EU" icon for the European date/time system in the format "DD/MM/YY hh:mm" or the "US" icon for the American system in the format "MM/DD/YY hh:mm AM/PM". Touch the up/down arrow keys to set the desired value. Confirm the settings or exit without saving.
Current date/time is kept inside the instrument without batteries for approximately 12 hours.
EN - 11
MACROTESTG3 - COMBIG3
6. OPERATING INSTRUCTIONS
6.1. LOW: CONTINUITY OF PROTECTIVE CONDUCTORS
This function is performed in compliance with standards IEC/EN61557-4 and allows measuring the resistance of protective and equipotential conductors.
CAUTION
The instrument can be used for measurements on installations with overvoltage
category CAT III 240V to earth and CAT III 415V between inputs. Category CAT III is suitable for measurements carried out on installations inside buildings with low voltage (examples are distribution boards, wirings, switches, fixed installation sockets, electric motors, industrial equipment).
We recommend holding the alligator clip respecting the safety area created by
the hand protection (see § 4.2).
Check that no voltage is present at the ends of the item to be tested before
carrying out a continuity test.
The results may be influenced by the presence of auxiliary circuits connected in
parallel with the item to be tested or by transient currents.
The following operating modes are available:
Compensation of the resistance of the cables used for measurement. The
instrument automatically subtracts the value of cable resistance from the measured resistance value. Therefore, it is necessary that this value is measured each time the measuring cables are changed or extended.
AUTO The instrument carries out two measurements with inverted polarity and
displays their average value. Recommended mode
The instrument carries out the measurement with the possibility of setting a
duration time for testing. The operator may set a sufficiently long measuring time (between 1s and 99s) to be able to move the protective conductors while the instrument is carrying out the test, in order to find out a possible bad connection.
CAUTION
Continuity test is carried out by supplying a current higher than 200mA in case the resistance does not exceed ca. 2 (including resistance of the test cables). For higher resistance values, the instrument carries out the test with a current lower than 200mA.
Fig. 6: Continuity test by means of single cables and remote lead
EN - 12
MACROTESTG3 - COMBIG3
1. Touch the
icon. The screen to the side appears on the display. The instrument automatically carries out the test for the presence of voltage between the inputs (shown on the display) and blocks the test in case of voltage higher than 10V
Touch the “AUTO” icon to set the measuring mode. The following screen appears on the display:
2. Move the slide bar reference in the positions "AUTO" (Automatic mode) or "
" (Timer mode). Confirm the
choice by going back to the previous screen.
If Timer mode is selected, the following screen is shown:
3.
4.
Touch the icon to zero the value in the Timer field and use the virtual keyboard to set the value in seconds between 1s and 99s. Confirm the choice by going back to the initial measurement screen.
Touch the icon "Rxx" to set the maximum limit value of the resistance on which the instrument makes the comparison with the measured value. The screen to the side appears on the display.
Touch the
icon to zero the value in the “R” field. Use the virtual keyboard to set the value between 1 and 99.
Confirm the choice by going back to the initial measurement screen. Note the presence of the set limit value.
EN - 13
MACROTESTG3 - COMBIG3
5. Perform, if necessary, the compensation of the measuring leads resistance by connecting the cables or the remote lead as shown in Fig. 7.
Fig. 7: Compensation of single cables and remote lead resistance
6. Touch the icon to activate the measurement. After a few seconds, the instrument provides the screen to the side if the operation is successful (Rcables  2); the indication of the value is shown in the "Rcal" field and the
icon is shown on the display.
Touch the "AUTO" icon or " " to go back to the main measurement screen.
CAUTION
Before connecting the test leads, make sure that there is no voltage at the ends of the conductor to be tested.
7. Connect the alligator clips and/or test leads and/or remote lead to the conductor to be tested as in Fig. 6.
CAUTION
Always make sure, before any measurement, that the compensation resistance value is referred to the cables currently used. In case of
8.
Press the GO/STOP key on the instrument or the START key on the remote lead.
doubt, repeat points 5 and 6.
The instrument will start the measurement. During this whole stage, do not disconnect the test leads of the instrument from the conductor under test. The following screen appears on the display:
9. The value of the result is shown in the upper part of the screen, while the partial values of the test with inverted polarity of the test source in addition to the real test currents are reported in the fields "R+" and "R-".
The symbol indicates the positive result of the measurement.
Press the SAVE button or touch the icon to save the measurement (see § 7.1).
EN - 14
MACROTESTG3 - COMBIG3
10. At the end of the test, if the value of the measured resistance is higher than the set limit, the screen to the side is shown on the display.
The value is shown in red and the symbol indicates the negative result of the measurement. The "> 99.9" message indicates the instrument overload status.
Press the SAVE button or touch the icon to save the measurement (see § 7.1).
6.1.1. Anomalous situations
1.
In AUTO or " " modes if the instrument detects a resistance lower than the set limit value but for which is it not able to generate a current of 200mA, the screen to the side is displayed.
The symbol is shown on the display and the values of the real test current are indicated in red.
2. If in mode the instrument detects a resistance higher than 2 at its terminals, it resets the offset value
and displays a screen like the one to the side. The icon is shown on the display to indicate the calibration reset value (i.e. performing the operation with open terminals).
3. In case the instrument detects that the calibrated resistance is higher that the measured resistance, the instrument gives out a long sound and displays a screen
like the one to the side. The icon is shown on the display to indicate the calibration reset value.
EN - 15
MACROTESTG3 - COMBIG3
6.2. M: MEASUREMENT OF INSULATION RESISTANCE
This function is performed in compliance with standards IEC/EN61557-2 and allows measuring the insulation resistance between the active conductors and between each active conductor and the earth.
CAUTION
The instrument can be used for measurements on installations with overvoltage
category CAT III 240V to earth and CAT III 415V between inputs. Category CAT III is suitable for measurements carried out on installations inside buildings with low voltage (examples are distribution boards, wirings, switches, fixed installation sockets, electric motors, industrial equipment).
We recommend holding the alligator clip respecting the safety area created by
the hand protection (see § 4.2).
Check that the circuit being tested is not live and that all possible loads normally
The following operating modes are available:
AUTO The test is activated by the GO/STOP key of the instrument (or START of the
connected to it are disconnected before carrying out insulation measurement.
remote lead) and lasts 2 seconds. Recommended mode
The operator may set a sufficiently long measuring time (1s 999s) to be able
to move the test lead on the conductors being tested, while the instrument is carrying out the test. For the whole measurement duration, the instrument will give out a short sound every second. While measuring, if the insulation resistance reaches a lower value than the set limit, the instrument will give a continuous acoustic signal. To stop the test, press again the GO/STOP key on the instrument or the START key on the remote lead.
Fig. 8: Insulation test between phase and earth by means of single cables and remote lead
Fig. 9: Insulation test between phase and earth by means of shuko plug
EN - 16
MACROTESTG3 - COMBIG3
1. Touch the icon. The screen to the side appears on
the display. The instrument automatically carries out the test for the presence of voltage between the inputs (shown on the display) and blocks the test in case of voltage higher than 10V Touch the “AUTO” icon to set the measuring mode. The following screen appears on the display:
2. Move the slide bar reference in the positions "AUTO" (Automatic mode) or " " (Timer mode). Confirm the choice by going back to the previous screen.
If Timer mode is selected, the following screen is shown:
3. Touch the icon to zero the value in the Timer field
and use the virtual keyboard to set the value in seconds between 1s and 999s. Confirm the choice by going back to the initial measurement screen.
4.
Touch the icon "Rxx" to set the minimum limit value of the insulation resistance on which the instrument makes the comparison with the measured value. The screen to the side appears on the display.
Touch the icon to zero the value in the “R” field. Use the virtual keyboard to set the value between
0.01M and 999M. Confirm the choice by going back to the initial measurement screen. Note the presence of the set limit value.
5. Touch the "xxxxV" icon to set the test DC voltage in the insulation measurement. The screen to the side appears on the display.
Move the slide bar reference to the desired value for test voltage by choosing among 50, 100, 250, 500,
1000VDC.
Confirm the choice by going back to the initial measurement screen. Note the presence of the set limit value.
EN - 17
MACROTESTG3 - COMBIG3
CAUTION
Disconnect any cable not strictly involved in measurement and especially
check that no cable is connected to In1 input.
Before connecting the test leads, make sure that there is no voltage at the
ends of the conductors to be tested.
6. Connect the alligator clips and/or test leads and/or remote lead to the ends of the conductors to be tested as in Fig. 8 and Fig. 9.
7.
Press the GO/STOP key on the instrument or the START key on the remote lead. The instrument will start the measurement.
CAUTION
During this whole stage, do not disconnect the test leads of the instrument from the conductor under test. It could remain charged with a dangerous voltage due to the stray capacitances in the circuit being tested.
8. Regardless of the operating mode selected, at the end of the measurement, the instrument applies a resistance to the output leads to discharge the capacitances in the circuit.
9. In mode:
The final result is the minimum insulation value measured during the test Pressing a second time the GO/STOP key or the START key on the remote lead
stops the test before the set time has elapsed.
10. The measurement result is shown both as a numeric value and in the analog bar graph as shown in the screen to the side. The values of the real test voltage and the measurement time are present on the display.
The symbol indicates the positive result of the measurement.
Press the SAVE button or touch the icon to save the measurement (see § 7.1).
11. At the end of the test, if the value of the measured resistance is lower than the set limit, the screen to the side is shown on the display.
The value is shown in red and the
symbol indicates
the negative result of the measurement.
Press the SAVE button or touch the icon to save the measurement (see § 7.1).
EN - 18
MACROTESTG3 - COMBIG3
6.2.1. Anomalous situations
1. If the instrument measures a resistance higher than the set limit value but for which it is not able to generate the rated voltage, the screen to the side is displayed.
The symbol is shown on the display and the values of the real test voltage are indicated in red.
2. If the instrument detects a voltage value higher than 10V at its terminals, it does not carry out the test, gives out a long sound and the screen reported here to the side is displayed.
EN - 19
MACROTESTG3 - COMBIG3
6.3. RCD: TEST ON DIFFERENTIAL SWITCHES
This function is performed in compliance with standard IEC/EN61557-6 and allows measuring the tripping time and current of molded case differential switches of type A ( ), AC ( ) and B ( ), being General (G), Selective (S) and Delayed ( ). The instrument allows performing tests on earth leakage relay RCDs with currents up to 10A (with optional accessory RCDX10)
CAUTION
Some combinations of test parameters can be not available in compliance with the technical specification of the instrument and the RCD tables (see § 10.1 – the empty cells of RCD tables means not available situations)
The following operating connections are available to perforn the RCD test:
Testing the RCD tripping time causes its tripping. Therefore, check that there
are NO users or loads connected downstream of the differential switch being tested which could be damaged by a system downtime.
Disconnect all loads connected downstream of the differential switch as they could produce leakage currents further to those produced by the instrument, thus invalidating the results of the test.
CAUTION
Fig. 10: Connection for single-phase 230V system by means of shuko plug
Fig. 11: Connection for single-phase 230V system with single cables and remote lead
EN - 20
MACROTESTG3 - COMBIG3
Fig. 12: Connection for a 400V + N + PE three-phase system by means of single cables
and remote lead
Fig. 13: Connection for a 400V + N (no PE) three-phase system by means of single cables
and remote lead [no for RCD type B]
Fig. 14: Connection for a 400V + PE (no N) system with single cables and remote lead
Fig. 15: Connection to earth leakage relay RCDs with optional accessory RCDX10
EN - 21
MACROTESTG3 - COMBIG3
1. Touch the icon. The screen to the side appears on the display.
Touch the icon to the left to set the RCD operating mode. The following screen appears on the display:
2. Move the slide bar reference by selecting the desired operating mode between the options: G (General), S (Selective), (Delayed).
Confirm the choice by going back to the initial measurement screen. Note the presence of the chosen selection.
When selecting a Delayed RCD, the instrument displays the following screen.
3. Touch the icon to zero the value in the Timer
field and use the virtual keyboard to set the value of RCD delay time in seconds between 1ms and 500ms. Confirm the choice by going back to the initial measurement screen. Touch the second icon to set the type of RCD, the waveform and the tripping current. The following screen appears on the display.
4. Move the left slide bar reference and select the type of RCD between the following options: STD (molded case RCD) and “ ” (earth leakage delay RCD with use of optional accessory RCDX10). In case of earth leakage relay RCD the following screen appears on the display
EN - 22
MACROTESTG3 - COMBIG3
5. Touch the icon to zero the value in “A” field
and use the virtual keyboard to set the value of rated current of earth leakage relay RCD. The maximum rated current is 10.0A. Confirm the choice by going back to the previous screen. Move the second slide bar reference by selecting the waveform of the differential switch between the options: (type AC), (type A), (type B). For RCD of molded case type STD move the third slide bar reference by selecting the desired rated current of the differential switch between the options: 10, 30, 100, 300, 500, 650, 1000mA Confirm the choice by going back to the initial measurement screen. Note the presence of the chosen selections
6. Touch the third icon at the bottom of display and select the desired type of test among the following options:
x ½  Manual with multiplier ½ Idn  x 1  Manual with multiplier 1Idn  x 2  Manual with multiplier 2Idn  x 5  Manual with multiplier 5Idn  AUTO Automatic mode (6 tests in
sequence)
Ramp (measurement of the real tripping
current) Move the right slide bar reference by selecting the polarity of the test current between the options: (direct polarity), 180° (inverted polarity), 0°-180° (for Automatic mode only). Confirm the choice by going back to the initial measurement screen. Note the presence of the chosen selections
7. Touch the fourth icon at the bottom of the display and select the possible visualization of the contact voltage value at the end of measurement. The following options are possible:
The value of contact voltage is shown
on the display at the end of measurement
The value of contact voltage is not
shown on the display at the end of measurement. The symbol “- - -“ is shown by the instrument in this condition
8. Insert the green, blue and black connectors of the three-pin shuko plug into the relevant instrument input terminals B3, B4, B1. As an alternative, use the single cables and apply the relevant alligator clips to the free ends of the cables. It is also possible to use the remote lead by inserting its multipolar connector into the input lead B1. Connect the shuko plug, the alligator clips or the remote lead to the electrical mains according to Fig. 10, Fig. 11, Fig. 12, Fig. 13 and Fig. 14.
EN - 23
MACROTESTG3 - COMBIG3
A
6.3.1. AUTO mode
9.
Press the GO/STOP key on the instrument or the START key on the remote lead. The instrument will start the measurement.
The screen to the side is shown on the display when the hourglass icon indicates the performance of the test.
10 The AUTO mode foresees the automatic execution of 6
measurements in a sequence: IdN x 1 with phase 0° (the RCD must trip,reset the
switch, icon )
IdN x 1 with phase 180° (the RCD must trip,reset
the switch, icon )
IdN x 5 with phase 0° (the RCD must trip,reset the
switch, icon )
IdN x 5 with phase 180° (the RCD must trip,reset
the switch, icon )
IdN x½ with phase 0° (RCD must not trip) IdN x½ with phase 180° (RCD must not trip, end of
test)
11
The test has a positive result if all tripping times of molded case type STD comply with what indicated in Table 4 (see § 12.4). The test has a negative result when one of the values is out of range. During this whole stage, do not disconnect the measuring leads of the instrument from the system on test.
12 At the end of the test, if the tripping time of each test
complies with what is indicated in Table 4 (see § 12.4) the instrument shows the symbol to signal that the
test has been completed successfully, and displays a screen similar to the one reported here to the side.
Press the SAVE button or touch the
icon to save
the measurement (see § 7.1).
13 At the end of the test, if the tripping time of a test does
not comply with what is indicated in Table 4 (see §
12.4). the instrument shows the
symbol to signal that the test has not been completed successfully, and displays a screen similar to the one reported here to the side.
Press the SAVE button or touch the icon to save the measurement (see § 7.1).
CAUTION
ccording to standard EN61008, the test for Selective differential switches requires an interval of 60 seconds between the tests (30s for tests with ½ Idn). The instrument display shows a timer indicating the time remaining before the instrument can automatically perform the test.
EN - 24
MACROTESTG3 - COMBIG3
6.3.2. x½, x1, x2, x5 modes
9.
Press the GO/STOP key on the instrument or the START key on the remote lead. The instrument will start the measurement.
The screen to the side (concerning multiplier x1) is shown on the display when the hourglass icon indicates the performance of the test.
10
At the end of the test with multiplier x1/2, x1, x2 or x5 if the tripping time, for molded case type STD, is as listed in Table 4
the instrument shows the symbol to signal that the test has been completed successfully, and displays a screen similar to the one reported here to the side.
Press the SAVE button or touch the icon to save the measurement (see § 7.1).
11
At the end of the test, for molded case type STD, if the tripping time of a test does not comply with what is
indicated in Table 4the instrument shows the symbol to signal that the test has not been completed successfully, and displays a screen similar to the one reported here to the side.
Press the SAVE button or touch the icon to save the measurement (see § 7.1).
6.3.3. Mode x1 – Test on RCDs with delay time
9. At the end of the test, if the measured tripping time is within the interval: [limit delay = set delay time + value indicated in Table 4] the instrument displays
the symbol to indicate the positive outcome of the test and displays a screen like the one to the side.
Press the SAVE button or touch the icon to save the measurement (see § 7.1).
10 At the end of the test, if the measured tripping time is
external the interval: [limit delay = set delay time + value indicated in Table 4] the instrument displays
the symbol to indicate the negative outcome of the test and displays a screen like the one to the side.
Press the SAVE button or touch the icon to save the measurement (see § 7.1)
EN - 25
MACROTESTG3 - COMBIG3
6.3.4. Mode
The standard defines, for molded case type STD, the tripping times for RCDs at nominal current. The mode is used to detect the minimum tripping current (which could also be lower than the nominal voltage).
9.
Press the GO/STOP key on the instrument or the START key on the remote lead. The instrument will start the measurement.
The screen to the side is shown on the display when the hourglass icon indicates the performance of the test.
10 At the end of the test, if the tripping current is within the
values of the table in the relevant §, the instrument
displays the symbol to indicate the positive outcome of the test and displays a screen like the one to the side.
Press the SAVE button or touch the
icon to save
the measurement (see § 7.1).
11 At the end of the test, if the tripping current is not within
the values of the table in the relevant §, the instrument
displays the symbol to indicate the negative outcome of the test and displays a screen like the one to the side.
Press the SAVE button or touch the
icon to save
the measurement (see § 7.1).
EN - 26
MACROTESTG3 - COMBIG3
6.3.5. Test on earth leakage relay RCD
The instrument allows performing tests on earth leakage relay RCD with currents up to 10A (with optional accessory RCDX10)
8. Connect the instrument and the optional accessory RCDX10 to the installation (see Fig.
15). Pay attention to the connection of cables “1” and “2” of the RCDX10 accessory and to the direction of the current indicated by the arrow printed on the accessory. It is also possible to use the remote lead by inserting its multipolar connector into input lead B1
9.
Press the GO/STOP key on the instrument or the START key on the remote lead. The instrument will start the measurement.
The screen to the side is shown on the display when the hourglass icon indicates the performance of the test.
10 At the end of the test, if the tripping current is lower to
the set value, the instrument displays the symbol to indicate the positive outcome of the test and displays a screen like the one to the side.
Press the SAVE button or touch the icon to save the measurement (see § 7.1)
11 At the end of the test, if the tripping current is higher to
the set value, the instrument displays the symbol to indicate the negative outcome of the test and displays a screen like the one to the side.
Press the SAVE button or touch the
icon to save
the measurement (see § 7.1)
EN - 27
MACROTESTG3 - COMBIG3
6.3.6. Anomalous situations
1. If the voltage between inputs B1 and B4 and inputs B1 and B3 is higher than 265V, the instrument provides the warning screen shown to the side and blocks the execution of the tests.
2. If the voltage between inputs B1 and B4 and inputs B1 and B3 is lower than 100V, the instrument provides the warning screen shown to the side and blocks the execution of the tests.
3. If the instrument detects the absence of the signal to terminal B1 (phase conductor), it provides the warning screen shown to the side and blocks the execution of the tests.
4. If the instrument detects the absence of the signal to terminal B4 (neutral conductor), it provides the warning screen shown to the side and blocks the execution of the tests.
5. If the instrument detects the absence of the signal to terminal B3 (PE conductor), it provides the warning screen shown to the side and blocks the execution of the tests.
EN - 28
MACROTESTG3 - COMBIG3
6. If the instrument detects that the phase and neutral leads are inverted, it does not carry out the test and a screen similar to the one reported to the side is displayed. Rotate the shuko plug or check the connection of measuring cables.
7. If the instrument detects that the phase and PE leads are inverted, it does not carry out the test and a screen similar to the one reported to the side is displayed. Check the connection of measuring cables.
8. If the differential switch being tested trips during the preliminary checks (performed automatically by the instrument before executing the selected test), the instrument does not carry out the test and displays a screen like the one to the side. Check that the IdN set value is consistent with the differential switch in question and that all loads connected downstream of it are disconnected.
9. If the instrument detects a dangerious voltage on PE conductor it provides the warning screen shown to the side and blocks the execution of the tests. Check the PE conductor and earth plant efficiency. This message can also appair in case of an insufficient pressure of the GO/STOP key
10 If the instrument detects a dangerious contact voltage
Ut (over the set limit 25V or 50V) in the starting pre­test, it provides the warning screen shown to the side and blocks the execution of the tests. Check the PE conductor and earth plant efficiency
EN - 29
MACROTESTG3 - COMBIG3
11 If the instrument detects a voltage Vn-pe > 50V (or the
analogue Vn-pe >25V) it provides the warning screen shown to the side and blocks the test for safety reasons. Check the PE conductor and earth plant efficiency
12 If the instrument detects in the input terminals a too
high external impedance such that it can not provides the nominal current, it provides the warning screen shown to the side and blocks the test. Disconnect the possible loads downstream the LCD before perform the test
13
For only RCD type B if the instrument is not able to provide for the charging of the internal capacitors of the RCD, it provides the warning screen shown to the side and blocks the test. Check that the VL-N voltage should be more than 190V
14
For only RCD type B if the instrument detects a input voltage VL-N <190V, it provides the warning screen shown to the side and blocks the test. Chech the values of the voltages on the installation
15
For test on earth leakage relay RCD if the value set for the rated current of the protection device is out of the allowed range, the instrument provides the warning screen shown to the side and stops the tests. Change the value of the rated current of the protection device
EN - 30
MACROTESTG3 - COMBIG3
6.4. LOOP: LINE IMPEDANCE/LOOP AND OVERALL EARTH RESISTANCE
This function is performed in compliance with standard IEC/EN61557-3 and allows measuring the line impedance, the fault loop impedance and the prospective short-circuit current.
CAUTION
Depending on the selected electrical system (TT, TN or IT) some kind of
The following operating modes are available
L-N Standard (STD) measurement of the line impedance between the phase
L-L Standard (STD) measurement of the line impedance between the two phase
L-PE Standard (STD) measurement of the fault loop impedance between the phase
Ra Global earth resistance without causing the differential protections tripping in
connection and function modes are disabled by the instruments (see Table 2 )
conductor and the neutral conductor and calculation of the assumed phase-to­neutral short-circuit current. This measurement is carried out even with high resolution (0.1m) through the optional accessory IMP57.
conductors and calculation of the assumed phase-to-phase short-circuit current. This measurement is carried out even with high resolution (0.1m) through the optional accessory IMP57.
conductor and the earth conductor and calculation of the assumed phase-to­earth short-circuit current. This measurement is carried out even with high resolution (0.1m) through the optional accessory IMP57.
systems with and without neutral (see § 12.11).
CAUTION
The measurement of line impedance or fault loop impedance involves the circulation of a maximum current according to the technical specifications of the instrument (see § 10.1). This could cause the tripping of possible magnetothermal or differential protections at lower tripping currents.
Fig. 16: P-N/P-PE measure for single-phase/two-phase 230V systems with shuko plug
Fig. 17: P-N/P-PE measure for single-phase/two-phase 230V systems with cables and
remote lead
EN - 31
MACROTESTG3 - COMBIG3
Fig. 18: P-N/P-PE measurement for 400V+N+PE three-phase systems by means of single
cables and remote lead
Fig. 19: P-P measurement for 400V+N+PE three-phase systems
Fig. 20: P-PE/P-N measurement for 400V + PE (no N) systems by means of single cables
and remote lead
Fig. 21: P-PE measurement for IT systems by means of single cables and remote lead
EN - 32
MACROTESTG3 - COMBIG3
6.4.1. Test types
The protection of electrical lines is the essential part of a project so as to guarantee the correct functionality and avoid damages to persons or property. To this purpose, the safety guidelines impose on electrical designers also to design the electrical installation in order to reach:
1. The protection from short-circuits, that’s to say:
The breaking capacity of the protection device must be not lower than the supposed
short-circuit current in the point in which the device is installed
In case of short-circuit in any point of the protected line, the protection device must
trip on quickly enough to avoid that the insulation materials assume excessive temperatures
2. The protection from indirect contacts.
In order to verify the a.m. conditions, the instrument performs the following functions:
Check of protection from indirect contact – According to the type of distribution system (TT, TN, IT) set by the user, the instrument performs the measurement and verifies the condition imposed by the guidelines. Should it be reached, the instrument gives a positive outcome (see § 12.6, § 12.7,
§12.8)
kA Check of protection’s breaking capacity – The instrument detects the value
of the line impedance upstream to the measurement point, calculates the maximum value of short-circuit current and gives a positive outcome if the value is lower than the limit set by the user (see § 12.5)
I2t Check of protection from short-circuits – The instrument detects the value
of the line impedance upstream to the measurement point, calculates the value of short-circuit current and the corresponding value of the trip out time (t) of the protection device and gives a positive outcome if the value of specific energy passing through the protection device is lower than the specific short-circuit energy bearable by the cables according to the known relationship (see §
12.10):
2
*
where K and S are parameters of the cable, set by the user, that’s to say: K= parameter indicated by the guideline depending on the type of conductor material and on the material of the insulating sheath
To completion of the above checks, the instrument performs also:
S = section of the cable
Check of the coordination of protections – The instrument detects the value of the line impedance upstream to the measurement point, calculates the minimum value of short-circuit current and the corresponding value of the trip out time (t) of the protection device and gives a positive outcome if the value is lower than the limit set by the user (see § 12.9)
2
tISK
STD
The IMP57 optional accessory allows the instrument to perform both individual and high resolution (0.1m) Line/Loop impedance measurements
Generic test
EN - 33
MACROTESTG3 - COMBIG3
The following table summarizes the possible measures executable depending on the type of system (TT, TN and IT), of selected modes and the relationships that define limit values
L-L
TT TN IT
Mode Condition x OK outcome Condition x OK outcome Condition x OK outcome
STD
kA
I2t
(IscL-Lmin 2F) Tmax Tmax < Tlim (IscL-L min 2F) Tmax Tmax < Tlim (IscL-Lmin 2F) Tmax Tmax < Tlim
STD
No outcome No outcome No outcome
Isc L-L max < BC Isc L-L max < BC Isc L-L max < BC
2
(Isc L-L 3F)
* t < (K * S)2 (Isc L-L3F)2 * t < (K * S)2 (Isc L-L3F)2 * t < (K * S)2
No outcome No outcome No outcome
L-N
L-PE
Ra (No for IMP57)
kA
I2t
STD
kA
I2t
STD
kA
I2t
(Isc L-N min ) Tmax  Tmax < Tlim (Isc L-N min ) Tmax  Tmax < Tlim (Isc L-N min ) Tmax  Tmax < Tlim
Isc L-N max < BC Isc L-N max < BC Isc L-N max < BC
2
(Isc L-N)
(Rameas * Idn) < Utlim Isc L-PE MIN > Idn
* t < (K * S)2 (Isc L-N)2 * t < (K * S)2 (Isc L-N)2 * t < (K * S)2
No outcome Isc L-PE max< BC
2
(Isc L-PE) (Isc L-PE min ) Tmax  Tmax < Tlim Tlim  Ia  Isc L-PE MIN > Ia Utmeas < Utlim
* t < (K * S)2
Table 2: Conditions of positive outcome depending on the test parameters
Where:
Empty cells Not available mode for this particular combination of electric system Isc L-L_3F Prospective short circuit current three-phase Phase-Phase (see § 12.5) Isc L-L_Min2F Prospective short circuit current minimum two-phase Phase-Phase (see § 12.9) Isc L-N_Max Prospective short circuit current maximum Phase-Neutral (see § 12.5) Isc L-N_Min Prospective short circuit current minimum Phase-Neutral (see § 12.9) Isc L-PE_Max Prospective short circuit current maximum Phase-PE (see § 12.5) Isc L-PE_Min Prospective short circuit current minimum Phase-PE (see § 12.9) BC Breaking Capacity of the protection device - kA) K Constant relative to the I2t measurement (vedere § 12.10) S Section of conductor Tmax Maximum trip out time of the protection device Tlim Limit time of fault extinction by the protection set by the user Ut meas Contact voltage measured Ut lim Contact voltage limit (25V or 50V) Ra meas Global earth resistance measured Idn Trip out current of RCD devices
6.4.2. STD Mode – Generic test
EN - 34
MACROTESTG3 - COMBIG3
This mode performs the impedance measurement and the calculation of prospective short circuit current without applying any evaluation. Therefore, at the end of the test, no outcome is given by the instrument.
1. Select the options “TN, TT or “IT”, “25 or 50V”, “50Hz or 60Hz” and the reference voltage in the general settings of the instrument (see § 5.1.3).
Touch the icon. The screen to the side appears on the display.
Touch the lower icon. The following screen appears on the display:
2.
Move the left slide bar reference by selecting the icon to execute the measurement only with the instrument or
the icon to execute the measurement with the instrument + optional accessory IMP57 (see § 6.4.9).
Move the central slide bar reference by selecting the " L-L, L-N or L-PE” options. Move the right slide bar reference by selecting the "STD" option. Confirm the choice by going back to the previous screen.
3. If possible, disconnect all loads connected downstream of the measuring point, as the
impedance of these users could distort the test results.
4. Connect the shuko plug, the alligator clips or the remote lead to the electrical mains
according to Fig. 16, Fig. 17, Fig. 18 and Fig. 20.
5. Note the presence of the correct voltage values between L-N and L-PE corresponding to the selections carried out in the initial phase (see § 5.1.3) as shown in the screen to the side.
Press the GO/STOP key or the START key on the remote lead. During this whole stage, do not disconnect the measuring leads of the instrument from the system under test. The following screen appears on the instrument's display:
EN - 35
MACROTESTG3 - COMBIG3
6. The value of the assumed short-circuit current (Isc) is shown in the upper part of the display, while the Line/Loop ZPE impedance is shown at the bottom of the display.
Press the SAVE button or touch the icon to save the measurement (see § 7.1).
The Standard (Std) assumed short-circuit current (Isc) is calculated using the following formula:
U
Z
NOM
MEAS
I
SC
Z
= measured L-L,L-N,L-PE loop impedance
MEAS
= nominal voltage (depend on the system)
U
NOM
EN - 36
MACROTESTG3 - COMBIG3
6.4.3. Mode kA – Verify of breaking capacity of protection device
1. Select the options “TN, TT or “IT”, “25 or 50V”, “50Hz or
60Hz” and the reference voltage in the general settings of the instrument (see § 5.1.3).
Touch the icon. The screen to the side appears on the display.
Touch the lower icon. The following screen appears on the display:
2.
Move the left slide bar reference by selecting the icon to execute the measurement only with the
instrument or the icon to execute the measurement with the instrument + optional accessory IMP57 (see § 6.4.9). Move the central slide bar reference by selecting the “L-L”, “L-N” or “L-PE” options (for TN systems only). Move the right slide bar reference by selecting the "kA" option.
Touch the icon in the lower right corner to set the maximum tripping current expressed in "kA" that the protection must interrupt. The following screen appears on the display:
3.
Touch the icon to zero the value in the kA field and use the virtual keyboard to set the value of the breaking capacity of the protection between 1kA and 9999kA
Confirm the choice by going back to the initial measurement screen.
4. If possible, disconnect all loads connected downstream
of the measured point, as the impedance of these users could distort the test results. Connect the shuko plug, the alligator clips or the remote lead to the electrical mains according to Fig. 16, Fig. 17, Fig. 18 and Fig. 20 in the nearest possible point to the protection device Note the presence of the correct voltage values between L-L and L-PE corresponding to the selections carried out in the initial phase (see § 5.1.3) as shown in the screen to the side.
EN - 37
MACROTESTG3 - COMBIG3
5.
Press the GO/STOP key or the START key on the remote lead. During this whole stage, do not disconnect the measuring leads of the instrument from the system under test.
In case of positive outcome, the screen to the side is shown by the instrument.
Press the SAVE button or touch the icon to save the measurement (see § 7.1).
6. In case of test failure (measured Isc Max current > set
threshold), the screen to the side is displayed by the instrument.
Note the presence of the measurement result highlighted in red.
Press the SAVE button or touch the icon to save the measurement (see § 7.1).
EN - 38
MACROTESTG3 - COMBIG3
6.4.4. Mode I2t – Verify of protection against short-circuit
CAUTION
The verify of conductor protection against the thermic effect of short-circuit is performed under the following conditions:
Ambient temperature of 25°C Presence of external insulation (not live conductor) No harmonics Short-circuit at the beginning of the line or at the end of the line without
any overload protection
Not buried cable
The verify performed by the instrument DOES NOT replace in any case the project calculations
1. Select the options “TN, TT or “IT”, “25 or 50V”, “50Hz or
60Hz” and the reference voltage in the general settings of the instrument (see § 5.1.3).
Touch the icon. The screen to the side appears on the display.
Touch the lower icon. The following screen appears on the display:
2.
Move the left slide bar reference by selecting the icon to execute the measurement only with the
instrument or the icon to execute the measurement with the instrument + optional accessory IMP57 (see § 6.4.9).
Move the central slide bar reference by selecting the “L-L”, “L-N” or “L-PE” options (for TN systems only).
2
Move the right slide bar reference by selecting the "I
t"
option.
Touch the icon in the bottom center to set the protection type and its rated current. The following screen appears on the display:
3. Move the slide bar reference by selecting the type of
protection (Fuse of type gG or aM or magnetothermal MCB in curve B, C, K, D).
Touch the “In” field. The following screen appears on the display:
EN - 39
MACROTESTG3 - COMBIG3
4.
Touch the icon to zero the value in the In field and use the virtual keyboard to set the value of the RCD rated current within the values allowed by the instrument.
The following selections are available on the instrument
MCB current (B curve) selectable among:
6,10,13,15,16,20,25,32,40,50,63A
MCB current (C, K curves) selectable among:
0.5,1,1.6,2,4,6,10,13,15,16,20,25,32,40,50,63A
MCB current (D curve) selectable among: 0.5,1,1.6,2,4,6,10,13,15,16,20,25,32A Nominal current Fuse gG selectable among:
2, 4, 6, 8, 10, 12, 13, 16, 20, 25, 32, 40, 50, 63, 80, 100, 125, 160, 200, 250, 315, 400, 500, 630, 800, 1000, 1250A
Nominal current Fuse aM selectable among: 2, 4, 6,
8, 10, 12, 16, 20, 25, 32, 40, 50, 63, 80, 100, 125, 160, 200, 250, 315, 400, 500, 630A
Confirm the choice by going back to the previous screen.
Touch the icon in the bottom right corner to set the type, section and material forming the inner insulation of the cable of the line under test. The following screen appears on the display:
5.
Touch the “mm2” field and, by using the virtual keyboard, set and confirm the section value of the single cable free selectable
Touch the field “
”and, by using the virtual keyboard, set and confirm the possible number of parallel cords. In the case that the circuit have only one conductor set the “1” value
Move the central slide bar reference by selecting the type of conductor. The available options are Cu (Copper) and Al (Aluminum).
Move the right slide bar reference by selecting the insulation type of the cable between the options: PVC, Rub/Butil (Rubber/Butyl rubber) and EPR/XLPE (Ethylene propylene rubber/Cross-linked polyethylene)
Confirm the choice by going back to the initial measurement screen.
EN - 40
MACROTESTG3 - COMBIG3
6. If possible, disconnect all loads connected downstream of the measured point, as the impedance of these users could distort the test results. Connect the shuko plug, the alligator clips or the remote lead to the electrical mains according to Fig. 16, Fig. 17, Fig. 18 and Fig. 20. Note the presence of the correct voltage values between L-L and L-PE corresponding to the selections carried out in the initial phase (see § 5.1.3) as shown in the screen to the side
7.
Press the GO/STOP key or the START key on the remote lead. During this whole stage, do not disconnect the measuring leads of the instrument from the system under test.
In case of positive result (three-phase short-circuit current for the L-L case in the image supported by the cable with the performed selections), the screen to the side is displayed by the instrument.
Press the SAVE button or touch the icon to save the measurement (see § 7.1).
8. In case of negative result (three-phase Isc current for the L-L case in the image NOT supported by the cable with the performed selections), the screen to the side is displayed by the instrument.
Note the presence of the measurement result highlighted in red.
Press the SAVE button or touch the
icon to save
the measurement (see § 7.1).
EN - 41
MACROTESTG3 - COMBIG3
6.4.5. Mode - Verify of protection coordination
1. Select the options “TN, TT or “IT”, “25 or 50V”, “50Hz or 60Hz” and the reference voltage in the general settings of the instrument (see § 5.1.3).
Touch the icon. The screen to the side appears on the display.
Touch the lower icon. The following screen appears on the display:
2.
Move the left slide bar reference by selecting the icon to execute the measurement only with the
instrument or the icon to execute the measurement with the instrument + optional accessory IMP57 (see § 6.4.9).
Move the central slide bar reference by selecting the “L-L”, “L-N” or “L-PE” options (for TN systems only).
Move the right slide bar reference by selecting the " " option.
Touch the icon in the bottom center to set the protection type and its rated current. The following screen appears on the display:
3. Move the slide bar reference by selecting the type of protection (Fuse of type gG or aM or magnetothermal MCB in curve B, C, K, D).
Touch the “In” field. The following screen appears on the display:
4. Touch the
icon to zero the value in the In field and use the virtual keyboard to set the value of the RCD rated current within the values allowed by the instrument.
Confirm the choice by going back to the previous screen.
Touch the icon in the lower right corner to set the tripping time of the RCD. The following screen appears on the display:
EN - 42
MACROTESTG3 - COMBIG3
5. Move the slide bar reference by selecting the protection tripping time between the options: 0.1s, 0.2s, 0.4s, 5s.
Confirm the choice by going back to the initial measurement screen.
6. If possible, disconnect all loads connected downstream of the measured point, as the impedance of these users could distort the test results. Connect the shuko plug, the alligator clips or the remote lead to the electrical mains according to Fig. 16, Fig. 17, Fig. 18 and Fig. 20 in the farthest possible point respect the protection on test Note the presence of the correct voltage values between L-L and L-PE corresponding to the selections carried out in the initial phase (see § 5.1.3) as shown in the screen to the side.
7.
Press the GO/STOP key or the START key on the remote lead. During this whole stage, do not disconnect the measuring leads of the instrument from the system under test.
In case of positive result (minimum short-circuit current interrupted by the protection device within the time indicated by the performed selections), the screen to the side is displayed by the instrument.
Press the SAVE button or touch the
icon to save
the measurement (see § 7.1).
8. In case of negative result (minimum short-circuit current NOT interrupted by the protection device within the time indicated by the performed selections), the screen to the side is displayed by the instrument.
Note the presence of the measurement result highlighted in red.
Press the SAVE button or touch the icon to save the measurement (see § 7.1).
EN - 43
MACROTESTG3 - COMBIG3
6.4.6. Verify of protection against indirect contacts (TN system)
1. Select the options "TN", “25 or 50V”, “50Hz or 60Hz” and the reference voltage in the general settings of the instrument (see § 5.1.3).
Touch the icon. The screen to the side appears on the display.
Touch the lower icon. The following screen appears on the display:
2.
Move the left slide bar reference by selecting the icon to execute the measurement.
Move the central slide bar reference by selecting the "L-PE" option. The right slide bar reference is
automatically set in position .
Confirm the choice by going back to the initial measurement screen.
3. Move the slide bar reference by selecting the type of protection (Fuse of type gG or aM or magnetothermal MCB in curve B, C, K, D).
Touch the “In” field. The following screen appears on the display
4. Touch the
icon to zero the value in the In field and use the virtual keyboard to set the value of the nominal current of the protection within the values allowed by the instrument (see § 6.4.4)
Confirm the choice by going back to the previous screen.
Touch the icon in the lower right corner to set the tripping time of the protection. The following screen appears on the display
5. Move the slide bar reference by selecting the protection tripping time between the options: 0.1s, 0.2s, 0.4s, 5s.
Confirm the choice by going back to the initial measurement screen
EN - 44
MACROTESTG3 - COMBIG3
6. If possible, disconnect all loads connected downstream of the measured point, as the impedance of these users could distort the test results. Connect the alligator clips or the remote lead to the electrical mains according to Fig. 16, Fig. 17, Fig. 18 and Fig. 20 in the farthest possible point respect the protection on test. Note the presence of the correct voltage values between L-N and L-PE corresponding to the selections carried out in the initial phase (see § 5.1.3) as shown in the screen to the side.
7.
Press the GO/STOP key or the START key on the remote lead. During this whole stage, do not disconnect the measuring leads of the instrument from the system under test.
In case of positive result (calculated minimum short­circuit current HIGHER than tripping current of the protection device within the specified time – see §
12.6), the screen to the side is displayed by the instrument
Press the SAVE button or touch the icon to save the measurement (see § 7.1).
8. In case of negative result (calculated minimum short­circuit current LOWER than tripping current of the protection device within the specified time – see §
12.6), the screen to the side is displayed by the instrument
Press the SAVE button or touch the
icon to save
the measurement (see § 7.1).
EN - 45
MACROTESTG3 - COMBIG3
6.4.7. Verify of protection against indirect contacts (IT systems)
1. Select the options "IT", “25 or 50V”, “50Hz or 60Hz” and the reference voltage in the general settings of the instrument (see § 5.1.3).
Touch the icon. The screen to the side appears on the display.
Touch the lower icon. The following screen appears on the display:
2.
Move the left slide bar reference by selecting the icon to execute the measurement.
Move the central slide bar reference by selecting the "L-PE" option. The right slide bar reference is
automatically set in position .
Confirm the choice by going back to the initial measurement screen.
3. If possible, disconnect all loads connected downstream of the measured point, as the impedance of these users could distort the test results. Connect the alligator clips or the remote lead to the electrical mains according to Fig. 21. Note the presence of the correct voltage values between L-L and L-PE corresponding to the selections carried out in the initial phase (see § 5.1.3) and a possible N-PE voltage due to the IT system as shown in the screen to the side.
4.
Press the GO/STOP key or the START key on the remote lead. During this whole stage, do not disconnect the measuring leads of the instrument from the system under test. In case of positive result (contact voltage at the point <50V or <25V), the screen to the side is displayed by the instrument, which contains the value of the first fault current measured, expressed in mA (see § 12.8). With
Isc < 30mA the Ut value is not mdisplayed
Press the SAVE button or touch the the measurement (see § 7.1).
icon to save
5. In case of negative result (contact voltage at the point >50V or >25V), the screen to the side is displayed by the instrument.
Note the presence of the measurement result of the contact voltage highlighted in red.
Press the SAVE button or touch the icon to save the measurement (see § 7.1).
EN - 46
MACROTESTG3 - COMBIG3
6.4.8. Verify of protection against indirect contacts (TT systems)
1. Select the options "TT", “25 or 50V”, “50Hz or 60Hz” and the reference voltage in the general settings of the instrument (see § 5.1.3).
Touch the icon. The screen to the side appears on the display.
Touch the lower icon on the left. The following screen appears on the display:
2.
Move the left slide bar reference by selecting the icon to execute the measurement.
Move the middle slide bar reference by selecting the "
" option. The right slide bar reference is
automatically set in position
.
Confirm the choice by going back to the initial measurement screen.
Touch the lower icon on the right. The following screen appears on the display:
3. Move the left slide bar reference by selecting the RCD tripping time between the values: 10, 30, 100, 300, 500, 650, 1000mA
Move the right slide bar reference by selecting the connection type between the options: (presence of neutral conductor) or
(absence of neutral
conductor)
Confirm the choices by going back to the initial measurement screen.
4. If possible, disconnect all loads connected downstream of the measured point, as the impedance of these users could distort the test results. Connect the shuko plug, the alligator clips or the remote lead to the electrical mains according to Fig. 10, Fig. 11 and Fig. 12. The connection point of the instrument (near or far from the protection) is usually irrelevant to the test as the resistance of the wires is negligible compared to the value of earth resistance. Note the presence of the correct voltage values between L-L and L-PE corresponding to the selections carried out in the initial phase (see § 5.1.3) as shown in the screen to the side.
EN - 47
MACROTESTG3 - COMBIG3
5.
Press the GO/STOP key or the START key on the remote lead. During this whole stage, do not disconnect the measuring leads of the instrument from the system under test.
In case of positive result (overall earth resistance lower than the ratio between limit contact voltage and RCD tripping current), the screen to the side is displayed by the instrument, which contains the contact voltage value in the secondary display.
Press the SAVE button or touch the icon to save the measurement (see § 7.1).
6. In case of negative result (overall earth resistance higher than the ratio between limit contact voltage and RCD tripping current), the screen to the side is displayed by the instrument.
Note the presence of the measurement result of the contact voltage highlighted in red.
Press the SAVE button or touch the icon to save the measurement (see § 7.1).
EN - 48
MACROTESTG3 - COMBIG3
6.4.9. Impedance measurement by means of the accessory IMP57
Impedance measurements performed with the optional accessory IMP57 involve its connection to the Master unit (MACROTESTG3 or COMBIG3) via optical connector through the optical cable/RS-232 C2001 supplied with same accessory. The IMP57 must be directly powered by the mains on which measurements are performed. For detailed information, please refer to the user manual of the accessory IMP57.
Please find below the procedure for the measurement of STD L-L impedance in TN systems. The same procedures can be applied to any other case considering what is reported in previous chapters.
1. Select the options "TN", “25 or 50V”, “50Hz or 60Hz” and the reference voltage in the general settings of the instrument (see § 5.1.3).
Touch the icon. The screen to the side appears on the display.
Touch the lower icon on the left. The following screen appears on the display:
2. Move the left slide bar reference by selecting the
icon to execute the measurement with the accessory IMP57.
Move the central slide bar reference by selecting the "L-L" option.
Move the right slide bar reference by selecting the "STD" option.
Confirm the choice by going back to the following initial measurement screen.
3.
The
symbol on the display indicates that the accessory IMP57 is not connected to the instrument or not powered directly by the mains.
Connect the IMP57 to the instrument via the cable C2001 and to the powered system via the input terminals C1, C2 and P1, P2 placed on it (see the IMP57 user manual). The following screen appears on the display:
EN - 49
MACROTESTG3 - COMBIG3
4.
The symbol indicates the correct connection and recognition of the IMP57 by the instrument. Check the green STATUS LED lighting on the IMP57.
The value of the voltage between the measurement points is shown in the upper part of the display.
Press the GO/STOP key on the instrument to start the test. The following screen is shown on the display (in case of L-L measurement in STD mode)
5. The standard (STD) short-circuit current is shown in the upper part of the display.
The P-P Loop impedance values, in addition to its resistive and reactive components, are shown in the central part of the display, expressed in m.
Press the SAVE button or touch the icon to save the measurement (see § 7.1).
EN - 50
MACROTESTG3 - COMBIG3
6.4.10. Anomalous situations
1. If the instrument detects an L-N or L-PE voltage higher than the maximum limit (265V), it does not carry out the test and displays a screen like the one to the side. Check the connection of measuring cables.
2. If the instrument detects an L-N or L-PE voltage lower than the minimum limit (100V), it does not carry out the test and displays a screen like the one to the side. Check that the system being tested is supplied.
3. If the instrument detects the absence of the signal to terminal B1 (phase conductor), it provides the warning screen shown to the side and blocks the execution of the tests.
4. If the instrument detects the absence of the signal to terminal B4 (neutral conductor), it provides the warning screen shown to the side and blocks the execution of the tests.
5. If the instrument detects the absence of the signal to terminal B3 (PE conductor), it provides the warning screen shown to the side and blocks the execution of the tests.
EN - 51
MACROTESTG3 - COMBIG3
6. If the instrument detects that the phase and neutral leads are inverted, it does not carry out the test and a screen similar to the one reported to the side is displayed. Rotate the shuko plug or check the connection of measuring cables.
7. If the instrument detects that the phase and PE leads are inverted, it does not carry out the test and a screen similar to the one reported to the side is displayed. Check the connection of measuring cables.
8. If the instrument detects a danger voltage on PE conductor, it does not carry out the test and displays a screen like the one to the side. This message can also appair in case of an insufficient pressure of the GO/STOP key
9. If the instrument detects a voltage VN-PE>50V (or >25V depending on the selection), it does not carry out the test and displays a screen like the one to the side
EN - 52
MACROTESTG3 - COMBIG3
6.5. SEQ: PHASE SEQUENCE AND PHASE CONCORDANCE TEST
This function is performed in compliance with standards IEC/EN61557-7 and allows testing the phase sequence and concordance by direct contact with live parts (not on cables with insulating sheath). The following operating modes are available:
1T one lead measurement 2T two leads measurement.
Fig. 22: Phase sequence check of 1T phases with terminal and remote lead
Fig. 23: Phase sequence check of 2T phases with terminal and remote lead
1. Touch the
icon. The screen to the side appears on
the display.
Touch the “1T” icon to set the measuring mode. The following screen appears on the display:
2.
Move the slide bar reference in the position "1T" for the selection of the test with 1 terminal or in the position "2T" for the selection of the test with 2 terminals.
Confirm the choice by going back to the following initial measurement screen.
EN - 53
MACROTESTG3 - COMBIG3
3. Insert the blue and black connectors of the single cables in the corresponding input
terminals of the instrument B4, B1 (2T measurement). Insert in the free end of the cables the corresponding alligator clips or tips. It is also possible to use the remote lead by inserting its multipolar connector into the input lead B1. Connect the alligator clips, the tips or the remote lead to phase L1 and N according to Fig. 22 and Fig. 23.
4.
Press the GO/STOP key on the instrument or the START key on the remote lead. The instrument will start the measurement. During this whole stage, do not disconnect the measuring leads of the instrument from the system under test.
The symbol for the tip on phase L1 and the hourglass indicating the status of pending recognition of a voltage higher than the maximum allowed.
5. Once the correct voltage recognized, the symbol is
shown on the display. The instrument gives out a long sound until input voltage is present.
6. At the end of phase L1 acquisition, the instrument is in standby waiting for the signal on phase L2 and showing the symbol of "disconnected tip" as shown in the screen to the side.
Under these conditions, connect the alligator clips, the tips or the remote lead to phase L2 and N in accordance with Fig. 22 and Fig. 23.
7. The symbol for the tip on phase L2 and the hourglass indicating the status of pending recognition of a voltage higher than the maximum allowed.
Once the correct voltage recognized, the
symbol is
shown on the display.
EN - 54
MACROTESTG3 - COMBIG3
8. At the end of the test, if the detected phase sequence is correct, the instrument displays a screen like the one shown to the side (result "1-2-3").
Press the SAVE button or touch the icon to save the measurement (see § 7.1).
9. At the end of the test, if the two detected voltages are in phase (phase concordance between two distinct three-phase systems), the instrument displays a screen like the one to the side (result "1-1-").
10 At the end of the test, if the detected phase sequence is
not correct, the instrument displays a screen like the one shown to the side (result "2-1-3").
Press the SAVE button or touch the icon to save the measurement (see § 7.1).
EN - 55
MACROTESTG3 - COMBIG3
6.5.1. Anomalous situations
1. If between the test start and the acquisition of the first voltage or between the acquisition of the first and second voltage, a time longer than around 10s has elapsed, the instrument displays a screen like the one to the side.
2. If the instrument detects an input voltage higher than the maximum limit, it will display a screen like the one to the side.
3. If the instrument detects an input voltage frequency exceeding the allowed full scale, it will display a screen like the one to the side.
EN - 56
MACROTESTG3 - COMBIG3
6.6. LEAKAGE: LEAKAGE CURRENT MEASUREMENT
Using an external clamp, this function allows measuring the leakage current (by means of the optional accessory HT96U).
Fig. 24: Indirect measurement of leakage current in three-phase systems
Fig. 25: Direct measurement of leakage current in three-phase systems
1. Touch the icon. The screen to the side appears on the display.
Touch the icon in the lower left corner to set the full scale of the clamp used. The following screen appears on the display:
2. Touch the
icon to zero the value in the In field and use the virtual keyboard to set the full-scale value of the clamp used ((values of 1A, 100A, 1000A for the HT96U clamp).
Confirm the choice by going back to the previous screen. With FS = 1A, the instrument automatically carries out the measurement in mA.
3. Insert the external clamp into instrument input In1.
4. For indirect measurements of leakage current, connect the external clamp according to Fig. 24. For direct measurements of leakage current, connect the clamp according to Fig. 25 and disconnect possible additional earth connections that could influence the test results.
EN - 57
MACROTESTG3 - COMBIG3
CAUTION
Possible additional earth connections could influence the measured value. In case of real difficulty in removing them, we recommend performing the measurement in an indirect way.
5. The value of the measured leakage current appears in
real time on the display as shown in the screen to the side.
Press the SAVE button or touch the icon to save the measurement (see § 7.1).
EN - 58
MACROTESTG3 - COMBIG3
6.7. EARTH: MEASUREMENT OF EARTH RESISTANCE
The MACROTESTG3, MOD1, MOD2 models (or COMBIG3 with EARTH function enabled) allows performing the measurement of earth resistance of an installation in the following ways:
Measurement of earth resistance with 3-wire or 2-wire voltammetric method Measurement of ground resistivity () with Wenner 4-wire method Measurement of resistance of individual rods without disconnecting them by means of
the optional clamp T2100
6.7.1. 3-wire or 2-wire earth measurement and 4-wire ground resistivity
The measurement is carried out in compliance with standards IEC/EN61557-5.
CAUTION
The instrument can be used for measurements on installations with
overvoltage category CAT III 240V to earth with a maximum voltage of 415V between inputs. Do not connect the instrument to installations with voltages exceeding the limits indicated in this manual. Exceeding these limits could result in electrical shocks to the user and damage to the instrument.
Always connect the measuring cables to the instrument and to the alligator
clips with the accessories disconnected from the system.
We recommend holding the alligator clip respecting the safety area created
by the hand protection (see § 4.2).
If the length of the cables supplied is not suitable for the installation under
test, you can create your own extensions following the indications in §
12.12.1.
Fig. 26: Three-wire earth resistance measurement
EN - 59
MACROTESTG3 - COMBIG3
Fig. 27: Two-wire earth resistance measurement using an auxiliary rod
Fig. 28: Two-wire earth resistance measurement from the panel board
Fig. 29: Ground resistivity measurement
EN - 60
MACROTESTG3 - COMBIG3
1. Select the options “TN, TT or “IT”, “25 or 50V”, “50Hz or
60Hz” and the reference voltage in the general settings
of the instrument (see § 5.1.3). Touch the icon. The screen to the side (TT and IT systems) is shown on the display. The instrument automatically carries out the test in presence of voltage between the inputs (shown on the display) and blocks the test in case of voltage higher than 10V Touch the first icon in the lower left corner to set the measuring mode. The following screen appears on the display:
2.
Move the slide bar reference in the position " " for the selection of the earth measurement with
voltammetric method, in the position for the resistance measurement with use of optional clamp T2100 (see § 6.7.2) or in the "" position for the measurement of ground resistivity. Confirm the choice by going back to the initial measurement screen.
Touch the second icon in the lower left corner to set the tripping current of the differential switch (TT and IT systems). The following screen appears on the display:
3. Move the slide bar reference in the position
corresponding to the value of the tripping current of the RCD differential switch as shown in the screen to the side. On the basis of this selection and the value of contact voltage (25V or 50V), the instrument performs the calculation of the limit value of earth resistance (see
§ 12.11) that will compare with the measured value in order to provide the final positive or negative result of the measurement.
4.
For TN systems, the instrument shows the initial screen as in the figure to the side.
Touch the central icon to set the rated current of the RCD. The following screen appears on the display:
EN - 61
MACROTESTG3 - COMBIG3
5.
Touch the icon to zero the value in the "A" field and use the virtual keyboard to set the value of fault current (declared by the Energy distribution board) between 1A and 9999A. Confirm the choice by going back to the initial measurement screen.
Touch the icon in the lower right corner to set the tripping time of the RCD. The following screen appears on the display:
6.
Touch the icon to zero the value in the "s" field and use the virtual keyboard to set the value of the time for fault elimination t (declared by the Energy distribution board) between 0.04s and 10s. On the basis of previous selections, the instrument performs the calculation of the maximum limit of earth resistance according to the value of maximum allowable contact voltage (see § 12.11) that will compare with the measured value in order to provide the final positive or negative result of the measurement. Confirm the choice by going back to the initial measurement screen.
7.
For resistivity measurement, the instrument shows the initial screen as in the figure to the side.
Touch the icon to the right to set the measurement unit and the distance between the test probes. The following screen appears on the display:
8. Move the slide bar reference on the left to select the
measurement unit of the distance between the options: m (meters) or ft (feet).
Move the slide bar reference on the right to select the distance "d" between the measuring probes choosing between 1m 10m (3ft 30ft).
Confirm the choices by going back to the initial measurement screen.
9. Connect the blue, red, green and black cables to the corresponding instrument input terminals H, S, ES, E, then add the alligator clips, if necessary.
10Extend, if necessary, the blue and red measuring cables on a separate way by means of
cables with proper section. Adding any extension does not require calibration and does not affect the measured earth resistance value.
EN - 62
MACROTESTG3 - COMBIG3
11 Drive the auxiliary rods into the ground keeping to the distance instructions provided by the
standards (see § 12.12.1).
12Connect the alligator clips to the auxiliary rods and to the installation under test
according to Fig. 26, Fig. 27, Fig. 28 or Fig. 29.
13
Press the GO/STOP key. During this whole stage, do not disconnect the measuring leads of the instrument
from the system under test. The symbol is shown on the display for the entire duration of the test.
For earth resistance measurement in TT/IT systems, in case of positive result, the screen to the side is displayed by the instrument. It contains the value of contact voltage in the secondary display, the value of contact resistance of the voltage probe (Rs) and the value of contact resistance of the current probe (Rh).
Press the SAVE button or touch the icon to save the measurement (see § 7.1).
14
For earth resistance measurement in TT systems, in case of negative result (see § 12.7), the screen to the side is displayed by the instrument. It contains the value of contact voltage in the secondary display, the value of contact resistance of the voltage probe (Rs) and the value of contact resistance of the current probe (Rh).
Note the presence of the measurement result highlighted in red.
Press the SAVE button or touch the
icon to save
the measurement (see § 7.1).
15
For earth resistance measurement in IT systems, in case of negative result (see § 12.8), the screen to the side is displayed by the instrument. It contains the value of contact voltage in the secondary display, the value of contact resistance of the voltage probe (Rs) and the value of contact resistance of the current probe (Rh).
Note the presence of the measurement result highlighted in red.
Press the SAVE button or touch the icon to save the measurement (see § 7.1)
EN - 63
MACROTESTG3 - COMBIG3
16
For earth resistance measurement in TN systems, in case of positive result (see § 12.11), the screen to the side is displayed by the instrument. It contains the value of contact voltage in the secondary display, the value of contact resistance of the voltage probe (Rs) and the value of contact resistance of the current probe (Rh).
Press the SAVE button or touch the icon to save the measurement (see § 7.1).
17
For earth resistance measurement in TN systems, in case of negative result (see § 12.11), the screen to the side is displayed by the instrument. It contains the value of contact voltage in the secondary display, the value of contact resistance of the voltage probe (Rs) and the value of contact resistance of the current probe (Rh).
Note the presence of the measurement result highlighted in red.
Press the SAVE button or touch the icon to save the measurement (see § 7.1).
18
If the resistance value of Rs or Rh probes is > 100 * Rmeasured the instrument performs the measurement considering an accuracy of 10% of reading and marks the value in red in corrispondance of Rs and/or Rh the screen to the side is displayed
19
For ground resistivity measurement, the screen to the side is shown by the instrument. It contains the value of "" expressed in m and the "Vn" value of the possible interfering voltage measured by the instrument during the test.
Press the SAVE button or touch the icon to save the measurement (see § 7.1).
EN - 64
MACROTESTG3 - COMBIG3
6.7.2. Earth measurement with optional clamp T2100
This measurement allows evaluating the partial resistances of the single earth rods of complex ring networks without disconnecting them and performs the calculation of the corresponden parallel resistance. Please refer to the user manual of clamp T2100 for specific details. The following measurement methods are available:
Measurement of rod resistance with direct connection of clamp T2100 to the instrument. Measurement of rod resistance by means of clamp T2100 used independently and
subsequent connection of the clamp to the instrument for data transfer.
CAUTION
The measurement carried out by clamp T2100 can be used to evaluate single rods resistance values within an earth installation without disconnecting the rods, assuming they do not affect each other (see Fig. 30).
Fig. 30: Resistance measurement of single rods with clamp T2100
EN - 65
MACROTESTG3 - COMBIG3
1. Select the options “TN, TT or “IT”, “25 or 50V”, “50Hz or
60Hz” and the reference voltage in the general settings
of the instrument (see § 5.1.3). Touch the icon, touch the first icon in the lower left corner and set the
measurement mode (see § 6.7.1 point 2). The
following screen appears on the display. The icon indicates that the clamp T2100 is not connected to the instrument or is not in "RS232" mode. Configure the same settings on the protection parameters depending on the type of system (TT, TN or IT) (see § 6.7.1 points 3, 4, 5, 6).
2.
Connect the clamp T2100 by inserting the connector into input In1 of the instrument. Turn the clamp on and put it in "RS232" mode (see the user manual of the clamp). The
symbol appears on the display of the clamp. In these conditions, the instrument- clamp group is ready to perform the measurements. The following screen is shown on the display by the instrument.
3. The meaning of the symbols is the following:
This icon indicate the correct serial
connection of the clamp to the instrument
Touch this icon to zero all the values of the
measured probes and the correspondent parallel resistance
Touch this icon to add a rod to the
measurement. The "N " parameter increases by one unit.
RA indicates the calculation of the parallel of
resistances for each measurement performed on each rod.
This indicates the value of contact voltage
resulting from the measurement.
N
indicates the number of rods in the measure.
R indicates the resistance value of the rod
currently measured.
It allows downloading on the instrument the
memory contents of clamp T2100 in order to obtain the final result of the measurement.
Rods resistance measurement with clamp T2100 connected to the instrument
4. Connect the clamp to the first rod of the earth network considered as shown in Fig. 30.
Note the value of the resistance in the R value in the calculation of parallel resistance and increase the N (N
=1)
field and press the icon to insert this
parameter by one unit
EN - 66
MACROTESTG3 - COMBIG3
5. After the insertion of the value of the first rod it will be not possible to transfer the
eventually measrements saved inside the T2100 by means the key. Perform the same procedure for each rod of the network in question. At the end of the measurements, press the GO/STOP key on the instrument. The following screen appears on the display
6.
The RA field shows the value of the resistances in parallel performed on each rod of the earth network considered. This value is compared with the maximum limit value calculated by the instrument according to the selections made on the parameters of the protections.
In case of positive result (see § 12.7 and § 12.11), the
instrument shows the symbol and it is also possible to scroll through the values of partial resistances by
touching the keys and
Press the SAVE button or touch the icon to save the measurement (see § 7.1).
7. In case of negative result (see § 12.7 and § 12.11), the
instrument shows the symbol and the result value appears in red like in the screen to the side.
Press the SAVE button or touch the icon to save the measurement (see § 7.1).
Rods resistance measurement with clamp T2100 used in an independent way
1. Turn the clamp T2100 on, perform the measurements on each rod of the earth network considered by saving the results in its internal memory (see the user manual of clamp T2100).
2. At the end of the measurement, connect the clamp T2100 to the instrument by inserting the connector into input In1 and put it in "RS232" mode (see the user manual of clamp
T2100). The symbol appears on the display of the clamp.
3. Touch the icon. Any data stored in the memory of the clamp is downloaded in the
instrument and slides in sequence on the display. At the end of the operation, the symbol disappears from the display
4. With the clamp connected to the instrument is possible to perform and add other measurements according to the actions described in the previous point 4
5. Press the GO/STOP key on the instrument and observe the positive or negative results of the measurement as shown in points 6 and 7 of the previous mode.
EN - 67
MACROTESTG3 - COMBIG3
6.7.3. Anomalous situations in 3-wire and 2-wire earth measurements
1. When starting a measurement, if the instrument detects
an interfering voltage higher than 10V at the volt and ampere circuits input, it does not perform the test and displays the screen to the side.
2. When starting a measurement, the instrument checks
the continuity of measuring cables. If the voltmetric
circuit (red cable S and green cable ES) is interrupted or its resistance value is too high, the
instrument displays a screen similar to the one on the side. Check that the terminals are properly connected and that the rod connected to terminal S is not driven into a pebbly or scarcely conductive ground. In this latter case, pour water around the rod to decrease its resistance value (see § 12.12.1)
3. When starting a measurement, the instrument checks
the continuity of measuring cables. If the ampermetric
circuit (blue cable H and black cable E) is interrupted or its resistance value is too high, the
instrument displays a screen similar to the one on the side. Check that the terminals are properly connected and that the rod connected to terminal H is not driven into a pebbly or scarcely conductive ground. In this latter case, pour water around the rod to decrease its resistance value (see § 12.12.1)
4. When starting a measurement, the instrument checks
the situation of B2 (S) and B3 (ES) inputs. In case of reverse of conductors on the installation it blocks the test and the message is shown
EN - 68
MACROTESTG3 - COMBIG3
6.8. AUX: MEASURE OF AMBIENT PARAMETERS THROUGH EXTERNAL PROBES
By means of external transducers, this function allows measuring the following environmental parameters:
°C air temperature in °C by means of thermometric transducer °F air temperature in °F by means of thermometric transducer Lux(20) illuminance by means of luxmetric transducer with a 20Lux capacity Lux(2k) illuminance by means of luxmetric transducer with a 2kLux capacity Lux(20k) illuminance by means of luxmetric transducer with a 20kLux capacity RH% air relative humidity by means of humidity transducer mV input DC voltage (without applying any transduction constant)
Fig. 31: Measurement of environmental parameters through external probes
1.
Touch the icon and then the icon. The screen to the side appears on the display.
Touch the icon in the lower left corner to set the type of measurement. The following screen appears on the display:
2. Move the slide bar reference to select the type of
measurement among the options: °C (temperature in Celsius degrees), °F (temperature in Fahrenheit degrees), Lux(20) (illuminance with 20Lux capacity), Lux(2k) (illuminance with 2kLux capacity), Lux(20k) (illuminance with 20kLux capacity) ,%RH (relative humidity), mV (measurement of DC voltage up to 1V)
Confirm the choices by going back to the initial measurement screen.
3.
Insert in the auxiliary In1 input the transducer necessary for the desired measurement as shown in Fig. 31
EN - 69
MACROTESTG3 - COMBIG3
4. The measured value appears on the display in real time
as shown in the screen to the side.
Press the SAVE button or touch the icon to save the measurement (see § 7.1).
EN - 70
MACROTESTG3 - COMBIG3
6.9. ΔV%: VOLTAGE DROP OF MAIN LINES
This feature allows to evaluating the percentage value of voltage drop between two points of a main line in which a protection device is installed and comparing this value to possible limit value specified by guidelines. The following modes are available:
L-N Measurement of Phase to Neutral line impedance. The test can be performed
also with high resolution (0.1m) with optional accessory IMP57
L-L Measurement of Phase to Phase line impedance. The test can be performed
also with high resolution (0.1m) with optional accessory IMP57
CAUTION
The measurement of line impedance or fault loop impedance involves the circulation of a maximum current according to the technical specifications of the instrument (see § 10.1). This could cause the tripping of possible magnetothermal protections at lower tripping currents.
Fig. 32: Connection of the instrument for L-N mode voltage drop measurement
Fig. 33: Connection of the instrument for L-L mode voltage drop measurement
EN - 71
MACROTESTG3 - COMBIG3
1. Select the option “50Hz or 60Hz” and the reference
Phase-Neutral or Phase-Phase voltage in the general
settings of the instrument (see § 5.1.3). Touch the
icon and then the icon. The screen to the side appears on the display. Touch the lower left icon to set the type of measurement. The following screen appears on the display
2. Move the second slide bar reference and select the
type of measurement between the options: L-L (Phase­Phase measurement) or L-N (Phase-Neutral measurement).
Move the third slide bar reference and select the icon to carry out measurement with the optional accessory IMP57 (see § 6.4.9). Move the first slide bar reference thus selecting options:
Impedance measurement performed with the
instrument only. With this option the icon “ ” is shown on the display
Possibility for the operator to manually
set the Offset Z1 impedance without carrying out the first measurement. With this option the icon “ ” is shown on the display and the following screen appears on the display
3.
Touch the icon to zero the value in the “” field and use the virtual keyboard to set the value of the Offset Z1 impedance within the range 0.000 to 9999. Confirm the selection and go back to the previous screen. Touch the second lower icon and set the value of the rated current of the protection device on the main line being tested. The following screen appears on the display
4.
Touch the icon to zero the value in “A” field and use the virtual keyboard to set the value of rated current of protection device in the range 1A to 9999A. Confirm selection and go back to the previous screen.
Touch the third lower icon and set the maximum allowed limit value of voltage drop (V%) for the main line being tested. The following screen appears on the display.
EN - 72
MACROTESTG3 - COMBIG3
5.
Touch the icon to zero the value in the “%” field and use the virtual keyboard to set the value of V% in the range 1% to 99%.
Confirm the selection and go back to the previous screen
6.
Go to step no. 9 in case the value of Z1 (Offset) has been set manually. In case of the value of Z1 (Offset) has NOT been manually set connect the instrument to the initial point of the main line being tested (typically downstream to a protection device) according to Fig. 32 or Fig. 33 in order to carry out the first Z1 (Offset) impedance measurement. In this case the instrument will measure the impedance upstream of the initial point of the main line being tested taking it as start reference. The following screen (referred to L-L measurement) appears on the display
7.
Touch the icon “ ” to start the first Z1 (Offset) impedance measurement. The symbol “ ” appears on the display during measurement. At the end of measurement the following screen appears on the display
8.
The value of Z1 (Offset) impedance is shown on the display and is automatically included on the lower right icon, together with the “
” symbol to indicate the
instantaneous saving of the value
9. Connect the instrument to the final point of the main
line being tested according to Fig. 32 or Fig. 33 in order to measure the Z2 impedance at the end of line. The screen to the side is displayed. Note the previously measured Z1 (Offset) value displayed
EN - 73
MACROTESTG3 - COMBIG3
10
Press the GO/STOP key on the instrument to measure the Z2 impedance and complete the V% voltage drop measurement. During this whole stage, do not disconnect the measuring leads of the instrument from the system being tested
In case of positive result (maximum percentage value
of calculated voltage drop according to § 12.11 < set limit value), the screen to the side is displayed by
the instrument, which contains the value of the Z2 end of line impedance together the Z1 (Offset) value.
Press the SAVE button or touch the icon to save the measurement (see § 7.1)
11
In case of negative result (maximum percentage
value of calculated voltage drop according to §
12.11 > set limit value), the screen to the side is
displayed by the instrument, which contains the value of the Z2 end of line impedance together with the Z1
(Offset) value. Press the SAVE button or touch the icon to save measurement (see § 7.1)
EN - 74
MACROTESTG3 - COMBIG3
6.9.1. Anomalous situations
1. If the instrument detects an L-N or L-PE voltage higher
than the maximum limit (265V), it does not carry out the test and displays a screen like the one to the side. Check the connection of measuring cables
2. If the instrument detects an L-N or L-PE voltage lower
than the minimum limit (100V), it does not carry out the test and displays a screen like the one to the side. Check that the system being tested is supplied
3. If the instrument detects the absence of the signal to
terminal B1 (phase conductor), it provides the warning screen shown to the side and blocks the execution of the tests
4. If the instrument detects the absence of the signal to
terminal B4 (neutral conductor), it provides the warning screen shown to the side and blocks the execution of the tests
5. If the instrument detects the absence of the signal to
terminal B3 (PE conductor), it provides the warning screen shown to the side and blocks the execution of the tests.
EN - 75
MACROTESTG3 - COMBIG3
6. If the instrument detects that the phase and neutral
leads are inverted, it does not carry out the test and a screen similar to the one reported to the side is displayed. Rotate the shuko plug or check the connection of measuring cables
7. If the instrument detects that the phase and PE leads
are inverted, it does not carry out the test and a screen similar to the one reported to the side is displayed. Check the connection of measuring cables
8. If the instrument detects a danger voltage on PE
conductor, it does not carry out the test and displays a screen like the one to the side. This message can also appair in case of an insufficient pressure of the GO/STOP key
9. If the instrument detects a voltage VN-PE>50V (or
>25V depending on the selection), it does not carry out the test and displays a screen like the one to the side
10 If during the measurement the instruments detects an
end of line impedance value lower than the initial line impedance value it does not carry out the test and a screen similar to the one reported to the side is displayed. Check the status of the main line being tested
EN - 76
MACROTESTG3 - COMBIG3
7. OPERATIONS WITH THE MEMORY
7.1. SAVING MEASUREMENTS
The structure of the memory area (999 locations), of "tree" type with the possibility to expand/hide the nodes, allows the division up to 3 markers nested so as to finalize the precise locations of the measuring points with the insertion of test results. Each marker has associated up to 20 fixed names (non-editable or deletable) + max 20 names that can be freely defined by the user by means of management software (see the online help of the program). For each marker, it is also possible to associate a number between 1 and
250.
1.
At the end of each measurement, press the SAVE key
or touch the icon to save its result. The screen to the side appears on the display.
The meaning of the icons is the following:
It expands/hides the selected node
It allows the choice of a 1st level node
It inserts a nested sub-node (max 3 levels)
It adds a user comment on the performed
measurement
2.
Press the or key to insert a main marker or a sub-marker. The screen to the side is shown by the instrument.
Touch one of the names on the list this to select the
desired marker. Touch the arrow keys
or to
enter a number associated with the marker, if needed.
Confirm the choices by returning to the main screen.
Touch the key. The following screen appears on the display:
3. Use the virtual keyboard to enter any comment on the
measurement. This comment will be visible both after downloading the saved data to a PC with management software (see § 8) and recalling the result at display (see § 7.2)
Confirm the choices by returning to the main screen.
Further confirm to permanently save the measurement in the internal memory. A confirmation message is provided by the instrument.
EN - 77
MACROTESTG3 - COMBIG3
7.2. RECALLING MEASUREMENTS AND DELETING THE MEMORY
1.
Touch the icon in the general menu. The screen to the side appears on the display.
Each measurement is identified by the icons (test with positive result) or (test with negative result).
Touch the desired measurement to select it on the display.
Touch the icon to recall the measurement result. The following screen appears on the display:
2.
Touch the icon to recall and possibly change the comment entered when saving via the internal virtual keyboard.
Touch the icon to go back to the previous screen.
3.
Touch the icon to delete the last saved result in the instrument memory. The following screen appears on the display:
Touch the
icon to confirm the operation or the
icon to return to the previous screen.
4.
Touch the icon to delete all the results stored in the memory of the instrument. The following screen appears on the display:
Touch the
icon to confirm the operation or the
icon to return to the previous screen.
EN - 78
MACROTESTG3 - COMBIG3
7.2.1. Anomalous situations
1. In case there is no measure saved and the instrument
memory is accessed, a screen similar to the one reported here to the side is displayed.
2. In case tries to define a new sub-node over the 3rd
level the instrument provides the warning screen shown to the side and blocks the operation
3. In case tries to create a sub-node by using a just used
name, the instrument provides the warning screen shown to the side and is necessary to define a new name
4. In case tries to define a numebr of nodes of 1st, 2nd
and 3rd level higher than 250 (for each level), the instrument provides the warning screen shown to the side
5. In case tries to include a comment of length higher than
30 chars, the instrument provides the warning screen shown to the side
EN - 79
MACROTESTG3 - COMBIG3
8. CONNECTING THE INSTRUMENT TO A PC
The connection between a PC and the instrument can be done via a serial port (see Fig. 3) by means of an optical cable/USB C2006 or by means of an optical/wiFi adapter (optional accessory C2013). Before making the connection in USB mode, it is necessary to install on the PC the C2006 cable drivers present in the supplied CD-ROM in addition to the management software. To transfer stored data to PC keep to the following procedure:
Connection to PC via optical/USB cable
1.
Switch on the instrument by pressing the ON/OFF key.
2. Connect the instrument to the PC via the optical cable/USB.
3.
Touch the icon in the general menu. The screen to the side is shown by the instrument.
In these conditions, the instrument is able to communicate with the PC.
4. Use the management software to download the instrument memory contents to a PC. Please refer to the online help of the program itself for any detail regarding the operation.
5. Touch the icon to go back to the general menu of the instrument.
Connecting to a PC through WiFi
1. Enable the WiFi connection on the target PC (ex: by using a WiFi key installed and connected to a USB port).
2. Switch on the optional accessory C2013. The ON LED flashes. Wait for the C2013 recognition by the PC and perform the connection
3. Insert the C2013 into the instrument via the serial optical port (see Fig. 3).
4. Put the instrument in data transfer mode to a PC (see § 8 - point 3).
5. Launch the management software, select the "WiFi" port and "Detect instrument" within the section "PC-Instrument connection". Once the instrument recognized, the "WiFi" LED on the C2013 flashes together with the "ON" LED.
6. Use the management software to download the instrument memory contents to a PC. Please refer to the online help of the program itself for any detail regarding the operation.
8.1. CONNECTION TO IOS/ANDROID DEVICES THROUGH WIFI
The instrument can be connected remotely via WiFi connection to a Android/iOS smartphones and/or tablets for the transfer of measurement data using the optional accessory C2013 (see the accessory user guide) and the APP HTAnalysis. Proceed as follows:
1. Download and install the HTAnalysis on the desired remote device (Android/iOS).
2. Switch on the optional accessory C2013. The ON LED flashes. Wait for the C2013 recognition by the remote device
3. Insert the C2013 into the instrument via the serial optical port (see Fig. 3).
4. Put the instrument in data transfer mode to a PC (see § 8 - point 3).
5. Take reference to the HTAnalysis instruction for the management operation
EN - 80
MACROTESTG3 - COMBIG3
9. MAINTENANCE
9.1. GENERAL INFORMATION
While using and storing the instrument, carefully observe the recommendations listed
in this manual in order to prevent possible damage or danger during use.
Do not use the instrument in environments with high humidity levels or high
temperatures. Do not expose to direct sunlight.
Always switch off the instrument after use. Should the instrument remain unused for a
long time, remove the batteries to avoid liquid leaks that could damage the instruments internal circuits.
9.2. REPLACEMENT OF THE BATTERIES
When the LCD display shows the low battery symbol " ", replace the alkaline batteries or recharge the rechargeable batteries.
Only expert and trained technicians should perform this operation. Before carrying out this operation, make sure you have disconnected all cables from the input terminals.
1. Switch off the instrument by pressing the ON/OFF key.
2. Remove the cables from the input leads
3. Loosen the battery compartment cover fastening screw and remove the cover.
4. Remove all the batteries from the battery compartment and replace them with new batteries of the right type only (§ 10.3) making sure to respect the indicated polarities. To recharge the batteries, use the external battery chargers supplied with the instrument.
5. Restore the battery compartment cover into place and fasten it by mean of the relevant screw.
6. Do not scatter old batteries into the environment. Use the relevant containers for disposal.
9.3. CLEANING THE INSTRUMENT
Use a soft and dry cloth to clean the instrument. Never use wet cloths, solvents, water, etc.
9.4. END OF LIFE
CAUTION
CAUTION: the symbol on the instrument indicates that the appliance and its
accessories must be collected separately and correctly disposed of.
EN - 81
MACROTESTG3 - COMBIG3
(
)
10. TECHNICAL SPECIFICATIONS
Accuracy is calculated as: ±[%reading + (no. of digits) * resolution] at 23°C, <80%RH. Refer to the Table 1 for the correspondence between models and availbale features
10.1. TECHNICAL CHARACTERISTICS
AC TRMS voltage
Range [V] Resolution [V] Accuracy
15 460
Frequency
Range [Hz] Resolution [Hz] Accuracy
47.0 63.6
Continuity of protective conductor (LOW)
Range [
] Resolution []
0.01 9.99
10.0 99.9
(*) after calibration of measuring cables Test current: >200mA DC up to 2 (cables included) Test current resolution: 1mA Open-circuit voltage: 4 < V0 < 24V
Insulation resistance (M)
Test voltage [V]
50
Range [
0.01
] Resolution []
9.99
10.0 49.9
50.0 99.9 (5.0reading + 2digits)
9.99
0.01
100
10.0 99.9
100.0 199.9 (5.0reading + 2digits)
9.99
0.01
250
10.0 99.9 100 499
0.01
9.99
500
200 499 500 999 (5.0reading + 2digits)
0.01 9.99
1000
200 999
1000 1999 (5.0reading + 2digits)
Open-circuit voltage rated test voltage -0% +10% Rated measuring current: >1mA with 1k x Vnom (50V, 100V, 250V, 1000V), >2.2mA with 230k @ 500V Short-circuit current <6.0mA for each test voltage Safety protection: error message for input voltage > 10V
Line/Loop impedance (Phase-Phase, Phase-Neutral, Phase-Earth)
Range [
] Resolution []
0.01 9.99
10.0 199.9
(*) 0.1 m in range 0.1 199.9 m (by using the optional accessory IMP57) Maximum test current: 5.81A (at 265V); 10.10A (at 457V) Phase-Neutral/Phase-Phase Test voltage: (100V 265V) / (100V460V); 50/60Hz ±5% Protection types: MCB (B, C, D, K), Fuse (gG, aM) Insulating sheath materials: PVC, Butyl rubber, EPR, XLPE
1
0.1
0.01
0.1
0.01
0.1
EN - 82
0.01
0.1
0.01
0.1
0.01
0.1 1
0.01
0.1
1
0.01
0.1
1
(3%rdg + 2digits)
0.1%reading+1digit
Accuracy (*)
(5.0reading + 3digits)
Accuracy
(2.0reading + 2digits)
(2.0reading + 2digits)
(2.0reading + 2digits)
(5.0reading + 2digits)
(2.0reading + 2digits)10.0  199.9
(2.0reading + 2digits)10.0  199.9
Accuracy (*)
(5%rdg + 3digits)
MACROTESTG3 - COMBIG3
First fault current – IT systems
Range [mA] Resolution [mA] Accuracy
0.1 0.9 1 999
Limit contact voltage (ULIM) : 25V, 50V
Test on RCD protection (Molded case type)
Differential protection type (RCD): AC ( ), A ( ), B( ) – General (G), Selective (S) and Delayed ( ) Voltage range Phase-Earth, Phase-Neutral: 100V 265V RCD type AC and A, 190V 265V RCD type B Rated tripping currents (IN): 10mA, 30mA, 100mA, 300mA, 500mA, 650mA, 1000mA Frequency: 50/60Hz 5%
Molded case type RCD tripping current - (for General RCD only)
RCD type
AC, A
B
10mA <IN 650mA 30mA IN 100mA
I
N Range I
I
N = 10mA
(0.3
Measurement duration of Molded case type RCD tripping time – TT/TN systems
10mA
30mA
100mA
300mA
500mA 650mA
AC 999 999 999 999 999 999 200 250 50 150
A 999 999 999 999 999 999 200 250 50 150 B
AC 999 999 999 999 999 999 200 250 50 150
A 999 999 999 999 999 999 200 250 50 150 B 999 999 999 999 999 999 310
AC 999 999 999 999 999 999 200 250 50 150
A 999 999 999 999 999 999 200 250 50 150 B 999 999 999 999 999 999
AC 999 999 999 999 999 999 200 250 50 150
A 999 999 999 999 999 999 200 250 310 B
x 1/2 x 1 x 2 x 5 AUTO
\ G S
G S
0.1 1
[mA]
N
1.1) I
G S G S G S
Resolution [mA] Accuracy
0.1IN
N
(5reading+1digit)
(5reading + 3digits)
- 0%, +10%I
- 0%, +5%I
G S
   
   
   
 
310 310
310 310
310 310
310
N
N
AC 999 999 999 999 999 999 200 250
1000mA
A 999 999 999 999 999 999
B
Table with duration of tripping time measurement [ms] - Resolution: 1ms, Accuracy:(2.0reading + 2digits)
Measurement duration of Molded case type RCD tripping time – IT systems
AC 999 999 999 999 999 999 200 250 50 150
10mA
A B
30mA 100mA 300mA
AC 999 999 999 999 999 999 200 250 50 150
A B
AC 999 999 999 999 999 999 200 250 50 150
500mA 650mA
A B
AC 999 999 999 999 999 999 200 250
1000mA
A B
Table with duration of tripping time measurement [ms] - Resolution: 1ms, Accuracy:(2.0reading + 2digits)
x 1/2 x 1 x 2 x 5 AUTO
\ G S
G S
G S G S G S
 
 
 
G S
310
310
310
EN - 83
MACROTESTG3 - COMBIG3
(
)
(
)
(
)
Test on RCD without integral current breaking device (with accessory RCDX10)
Differential protection type (RCD): AC ( ), A ( ), B( ) – Generali (G), Selettivi (S) e Ritardati ( ) Voltage range Phase-Earth, Phase-Neutral: 100V 265V RCD type AC and A, 190V 265V RCD type B Rated tripping currents (IN): 0.3A  10A Frequency: 50/60Hz  5%
RCD without integral current breaking device tripping current - (for General RCD only)
RCD type
AC, A, B
300mA IN 10A (0.3  1.1) I
I
N Range I
[mA]
N
Duration of RCD without integral current breaking device tripping time – TT/TN systems
0.3A
1.0A
1.1A
3.0A
3.1A
6.5A
AC 999 999 999 999 999 999 200 250 50 150
A 999 999 999 999 999 999 200 250 50 150 B 999 999 999 999 999 999 310
AC 999 999 999 999 999 999 200 250 50 150
A 999 999 999 999 999 999 200 250 50 150 B 999 999 999 999 999 999
AC 999 999 999 999 999 999 200 250 50 150
A 999 999 999 999 999 999 200 250 50 150 B 999 999 999 999 999 999
x 1/2 x 1 x 2 x 5 AUTO
\ G S
G S
G S G S G S
Resolution [mA] Accuracy
0.1I
N
- 0%, +5%I
N
   
   
   
N
G S
310 310
310 310
310 310
6.6A
10.0A
AC 999 999 999 999 999 999 200 250
A 999 999 999 999 999 999
B
Table with duration of tripping time measurement [ms] - Resolution: 1ms, Accuracy:(2.0reading + 2digits)
Duration of RCD without integral current breaking device tripping time – IT systems
0.3A
3.0A
3.1A
6.5A
6.6A
10.0A
AC 999 999 999 999 999 999 200 250 50 150
A B
AC 999 999 999 999 999 999 200 250 50 150
A B
AC 999 999 999 999 999 999 200 250
A B
Table with duration of tripping time measurement [ms] - Resolution: 1ms, Accuracy:(2.0reading + 2digits)
x 1/2 x 1 x 2 x 5 AUTO
\ G S
G S
G S G S G S
 
 
Overall earth resistance without RCD tripping (Ra)
Voltage range Phase-Earth, Phase-Neutral: 100 265V, Frequency: 50/60Hz 5%
Global earth resistance in systems with Neutral
Range [
] Resolution []
0.01 9.99
10.0 199.9 200 1999
Ut LIM (UL): 25V or 50V, Maximum current: <15mA
0.01
0.1 1
Accuracy
5 reading + 0.1
5 reading + 1
5 reading + 3
Global earth resistance in systems without Neutral
Range [
1 1999
Maximum current: < ½ IN set ; Ut LIM (UL): 25V or 50V
] Resolution []
1
-0%, +(5.0 rdg + 3)
Accuracy
EN - 84
G S
310
310
MACROTESTG3 - COMBIG3
)
)
)
)
Contact voltage (measured during RCD and Ra test)
Range [V] Resolution [V] Accuracy
0 Ut LIM
Contact voltage (EARTH test – TT systems)
Range [V] Resolution [V] Accuracy
0 99.9
Contact voltage (EARTH test – TN systems)
Range [V] Resolution [V] Accuracy
0 99.9
100 999
Earth resistance (MACROTESTG3 / COMBIG3 enabled)
Range [] Resolution []
0.01 9.99
10.0 99.9 100 999
1.00k 49.99k
Test current: <10mA, 77.5Hz; Open-circuit voltage: <20Vrms (*) If 100*Rmeas < (Rs or Rh) < 1000* Rmeas, add 5% to te accuracy. Accuracy not declared if (Rs or Rh) > 1000* Rmis
Ground resistivity (MACROTESTG3 / COMBIG3 enabled)
Range [M] Resolution [m]
0.06 9.99
10.0 99.9 100 999
1.00k 9.99k
10.0k 99.9k 100k 999k
1.00M 3.14M
(*) with distance between the probes d= 10m; Distance range: 1 10m Test current: <10mA, 77.5Hz; Open-circuit voltage: <20Vrms
Phase rotation with 1 test lead
Voltage range P-N, P-PE[V] Frequency range
100 265 50Hz/60Hz 5%
Measurement is only carried out by direct contact with metal live parts (not on insulation sheath).
Voltage drop
Range [%] Resolution [%] Accuracy
0 100
Leakage current (input In1 – STD clamp)
Range [mA] Resolution [mA] Accuracy
2 999
Environmental parameters
Measurement Range Resolution Accuracy
°C
°F
RH%
DC voltage
Lux
-20.0
60.0°C
-4.0
140.0°F
0.0%
100.0%RH
0.1mV
0.001
1.0V
20.00lux (*) 0.001 0.02Lux
0.1 2.0klux (*) 0.1 2Lux 1 20.0klux (*) 1 20Lux
(*) Accuracy of the luxmetric probe according to Class AA
0.1
0.1
0.1 1
0.01
0.1 1
0.01k
0.01
0.1 1
0.01k
0.1k 1k
0.01M
0.1
1
0.1°C
0.1°F
0.1%RH
0.1mV
-0%, +(5.0 rdg + 3V)
-0%, +(5.0 lettura + 3V
-0%, +(5.0 rdg + 3V
-0%, +(5.0 rdg + 3V
Accuracy (*)
(5% reading + 3 digits)
Accuracy (*)
(5% reading + 3 digits)
(10%rdg + 4dgt
(5.0%rdg + 2digits)
(2%rdg + 2digits)
EN - 85
MACROTESTG3 - COMBIG3
10.2. REFERENCE GUIDELINES
Safety: IEC/EN61010-1, IEC/EN61557-1, -2, -3, -4, -5, -6, -7, -10 Technical documentation: IEC/EN61187 Safety of measuring accessories: IEC/EN61010-031, IEC/EN61010-2-032 Insulation: double insulation Pollution level: 2 Max operating altitude: 2000m (6562ft) Protection index: IP50 Measurement category: CAT III 240V to earth, maximum 415V between inputs LOW (200mA): IEC/EN61557-4 M: IEC/EN61557-2 RCD: IEC/EN61557-6 (only on Phase-Neutral-Earth systems) LOOP P-P, P-N, P-PE: IEC/EN61557-3 EARTH: IEC/EN61557-5 123: IEC/EN61557-7 Multifunction: IEC/EN61557-10 Short circuit current : EN60909-0 Earth resistance TN system: EN61936-1 + EN50522
10.3. GENERAL CHARACTERISTICS Mechanical characteristics
Size (L x W x H): 225 x 165 x 75mm ; (9 x 6 x 3in) Weight (batteries included): 1.2kg ; (42 ounces)
Power supply
Battery type: 6x1.5V alkaline batteries type AA IEC LR06 MN1500 6 x1.2V rechargeable batteries NiMH type AA
Low battery indication: low battery symbol “ ” on the display Battery life: > 500 tests for each function Auto Power OFF: after 5 minutes idling (if activated)
Miscellaneous
Display: TFT, color, capacitive touch-screen, 320x240mm Memory: 999 memory locations, 3 levels of markers Connection to PC: optical/USB port Remote connection: WiFi connection (with optional accessory C2013)
10.4. ENVIRONMENT
10.4.1. Environmental conditions for use
Reference temperature: 23° ± 5°C ; (73°F ± 41°F) Operating temperature: 0 ÷ 40°C ; (32°F ÷ 104°F) Allowable relative humidity: <80%RH Storage temperature: -10 ÷ 60°C ; (14°F ÷ 140°F) Storage humidity: <80%RH
This instrument satisfies the requirements of Low Voltage Directive 2006/95/EC
(LVD) and of EMC Directive 2004/108/EC
10.5. ACCESSORIES
See the attached packing list.
EN - 86
MACROTESTG3 - COMBIG3
11. SERVICE
11.1. WARRANTY CONDITIONS
This instrument is warranted against any material or manufacturing defect, in compliance with the general sales conditions. During the warranty period, defective parts may be replaced. However, the manufacturer reserves the right to repair or replace the product.
Should the instrument be returned to the After-sales Service or to a Dealer, transport will be at the Customers charge. However, shipment will be agreed in advance. A report will always be enclosed to a shipment, stating the reasons for the products return. Only use original packaging for shipment. Any damage due to the use of non-original packaging material will be charged to the Customer. The manufacturer declines any responsibility for injury to people or damage to property.
The warranty shall not apply in the following cases:
Repair and/or replacement of accessories and battery (not covered by warranty). Repairs that may become necessary as a consequence of an incorrect use of the
instrument or due to its use together with non-compatible appliances.
Repairs that may become necessary as a consequence of improper packaging. Repairs which may become necessary as a consequence of interventions performed
by unauthorized personnel.
Modifications to the instrument performed without the manufacturer's explicit
authorization.
Use not provided for in the instruments specifications or in the instruction manual.
The content of this manual cannot be reproduced in any form without the manufacturer's authorization.
Our products are patented and our trademarks are registered. The manufacturer reserves the right to make changes in the specifications and prices if this is due to improvements in technology.
11.2. SERVICE
If the instrument does not operate properly, before contacting the After-sales Service, please check the conditions of batteries and cables and replace them, if necessary. Should the instrument still operate improperly, check that the product is operated according to the instructions given in this manual.
Should the instrument be returned to the After-sales Service or to a Dealer, transport will be at the Customer's charge. However, shipment will be agreed in advance. A report will always be enclosed to a shipment, stating the reasons for the products return. Only use original packaging for shipment; any damage due to the use of non-original packaging material will be charged to the Customer.
EN - 87
MACROTESTG3 - COMBIG3
12. THEORETICAL APPENDIXES
12.1. CONTINUITY OF PROTECTIVE CONDUCTORS Purpose of the test
Check the continuity of: Protective conductors (PE), main equalizing potential conductors (EQP), secondary
equalizing potential conductors (EQS) in TT and TN-S systems Neutral conductors having functions of protective conductors (PEN) in TN-C system. This test is to be preceded by a visual check verifying the existence of yellow-green protective and equalizing potential conductors as well as compliance of the sections used with the standards requirements.
Parts of the system to be checked
Connect one of the test leads to the protective conductor of the socket and the other to the equalizing potential node of the earth installation.
Connect one of the test leads to the external mass (in this case the water pipe) and the other to the earth installation using for example the protective conductor of the closest socket.
Fig. 34: Examples for continuity measurements on conductors
Check the continuity among:
Earth poles of all the plug sockets and earth collector or node Earth terminals of class I appliances (boilers, etc.) and earth collector or node Main external masses (water tubes, gas pipes, etc.) and earth collector or node Additional external masses between each other and to earth terminal.
Allowable values
The standards do not require the measurement of continuity resistance and the comparison of the results with limit values. The standards simply require that the instrument in use warns the operator if the test was not carried out with a current of at least 200mA and an open circuit voltage ranging from 4 to 24V. The resistance values may be calculated according to the sections and lengths of the conductors under test. In general, if the instrument detects values of some ohms, the test may be considered as successful.
EN - 88
MACROTESTG3 - COMBIG3
12.2. INSULATION RESISTANCE
Purpose of the test
Check that the insulation resistance of the installation complies with the requirements of the applicable guidelines. This test has to be performed with the circuit being tested not powered and with the possible loads it supplies disconnected.
Parts of the system to be checked
Check that the insulation resistance between: Each active conductor and the earth (the neutral conductor is considered as an active
conductor except in TN-C power supply systems, where it is considered as part of the
earthing (PEN)). During this measurement, all active conductors may be connected to
each other. Should the measurement result not to be within the limits prescribed by the
standards, the test must be repeated separately for each single conductor. The active conductors. The guidelines recommends also checking the insulation
between active conductors when this is possible.
Allowable values
The values of the measured voltage and of the minimum insulation resistance can be taken from the following table
Circuit nominal voltage [V] Test voltage [V]
SELV and PELV * 250 Up to/equal to 500 V, except for the above-
mentioned circuits Over 500 V 1000 * The terms SELV and PELV replace, in the standards new wording, the old definitions of “Very
low safety voltage” or “Very low functional voltage”
500
Insulation resistance
[M
]
0,250
1,000
1,000
Table 3: Most common test types, insulation resistance measurement
If the system includes electronic devices, it is necessary to disconnect them from the system to prevent any damage. Should this not be possible, only perform the test between active conductors (which, in this case, must be connected to each other) and the earth connection.
In the presence of a very extended circuit, wires running side by side constitute a capacity that the instrument must load in order to obtain a correct measurement; in this case it is advisable to hold the start button of the measurement (in case you run the test in manual mode) until the result is stable.
The "> full scale" message indicates that the insulation resistance measured by the instrument is higher than the maximum measurable resistance, this result is obviously much higher than the minimum limits in the standard table above, so the insulation at that point is to be considered compliant.
EN - 89
MACROTESTG3 - COMBIG3
12.3. CHECKING CIRCUIT SEPARATION
Definitions
A SELV system is a zero-category system or safety extra low voltage system characterized by power supply from an independent (e.g. batteries, small generator set) or safety source (e.g. safety transformer), protective separation from other electrical systems (double or reinforced insulation or earthed metal screen) and absence of earthed points (insulated from the earth).
A PELV system is a zero-category system or protective extra low voltage system characterized by power supply from an independent (e.g. batteries, small generator set) or safety source (e.g. safety transformer), protective separation from other electrical systems (double or reinforced insulation or earthed metal screen) and, unlike SELV systems, presence of earthed points (not insulated from the earth).
A system with Electrical Separation is a system characterized by a power supply from an insulation transformer or independent source with equivalent characteristics (e.g. motor generator set), protective separation from other electrical systems (insulation no lower than that of the insulation transformer), protective separation to earth (insulation no lower than that of the insulation transformer).
Purpose of the test
The test, to be performed if protection is obtained through separation must check that the insulation resistance measured as described below (according to the type of separation) complies with the limits reported in the table relating to insulation measurements.
Parts of the system to be checked SELV System (Safety Extra Low Voltage):
Measure the resistance between the active parts of the circuit being tested
(separated) and the active parts of the other circuits.
Measure the resistance between the active parts of the circuit to be tested
(separated) and the earth.
PELV System (Protective Extra Low Voltage):
Measure the resistance between the active parts of the circuit being tested
(separated) and the active parts of the other circuits.
Electrical separation:
Measure the resistance between the active parts of the circuit being tested
(separated) and the active parts of the other circuits.
Measure the resistance between the active parts of the circuit to be tested
(separated) and the earth.
Allowable values
The test has a positive result when the insulation resistance shows values higher or equal to those indicated in Table 3.
EN - 90
MACROTESTG3 - COMBIG3
EXAMPLE OF SEPARATION TEST BETWEEN ELECTRICAL CIRCUITS
Insulation or safety transformer separating the circuits
TEST BETWEEN ACTIVE PARTS Connect an instrument probe to one of the two conductors of the separated circuit and the other to one of the conductors of a non­separated circuit.
TEST BETWEEN ACTIVE PARTS AND EARTH Connect an instrument probe to one of the two conductors of the separated circuit and the other to the equalizing potential node. This test must be performed for SELV circuits or circuits with electrical separation only.
Equalizing potential node
Fig. 35: Separation measurements between the circuits of a system
EN - 91
MACROTESTG3 - COMBIG3
12.4. TEST ON DIFFERENTIAL SWITCHES (RCD) Purpose of the test
Checking that the General (G) and Selective (S) and Delayed ( ) differential protection devices have been correctly installed and adjusted and that they maintain their characteristics over time. The check must make sure that the differential switch trips at a current not higher than its nominal operating current IdN and that the tripping time meets the following conditions, according to the case:
The tripping time does not exceed the maximum time as prescribed by the standard for
differential switches of a General type (according to what described in Table 4). The tripping time is between the minimum and the maximum tripping time for
differential switches of a Selective type (according to what described in Table 4). It does not exceed the maximum delay time (normally set by the user) in case of
Delayed differential switches.
The differential switch test performed with the test key helps so that no “gluing effect” jeopardizes the operation of the device if it has remained unused for a long time. This test is only performed to ascertain the mechanical functionality of the device and it is not sufficient to declare the devices conformity to the standard regarding differential current devices. According to statistics, switch verification through test key, if performed once a month, reduces to a half the devices malfunction rate. However, this test only detects 24% of the defective differential switches.
Parts of the system to be checked
All differential switches must be tested upon installation. In low-voltage systems, it is advisable to perform this test, fundamental in order to guarantee a correct safety level. In medical rooms, this test must be performed periodically every six months on all differential switches as prescribed by the guidelines.
Allowable values
Two tests must be performed on each molded case RCD type: a test with a leakage current beginning in phase with the positive half-wave of voltage (0°) and a test with a leakage current beginning in phase with the negative half-wave of voltage (180°). The result to be considered is the higher one. The test with ½In must not cause the differential switch tripping.
RCD type IdN x 1 IdN x 2 IdN x 5 * Description
General 0.3s 0.15s 0.04s Maximum tripping time in seconds
Selective S
0.13s 0.05s 0.05s Minimum tripping time in seconds
0.5s 0.20s 0.15s Maximum tripping time in seconds
Table 4: Tripping times for general and selective molded case RCD type
Measurement of tripping current for protection differential switches
This test aims at checking the real tripping current of general differential switches (it
does not apply to selective differential switches).
In the presence of differential switches with selectable tripping current, it is useful to
perform this test in order to check the real tripping current of the differential switch. For
differential switches with fixed differential current, this test may be performed in order to
detect possible leakages of the users connected to the system. Should an earth system not be available, perform the test by connecting the instrument
to a terminal on a conductor downstream of the differential device and a terminal on the
other conductor upstream of the device. Tripping current must be between ½Idn and Idn.
EN - 92
MACROTESTG3 - COMBIG3
12.5. VERIFY OF THE BREAKING CAPACITY OF PROTECTION DEVICES Purpose of the test
Checking that the breaking capacity of the protection device is higher than the maximum fault current possible in the system.
Parts of the system to be checked
The test must be performed at the point in which the maximum short-circuit current is possible, normally immediately downstream of the protection device to be checked. The test must be performed between phase and phase (Zpp) in three-phase systems and between phase and neutral (Zpn) in single-phase systems.
Allowable values
The instrument performs the comparison between the measured value and the value calculated according to the following relationships derived from standard EN60909-0:
NOM
U
LL
CIBC
3
MAXMAX
3
Z
LL
CIBC
MAXNLMAX
NOM
U
NL
Z
NL
2
Three-phase systems Single-phase systems
where: BC = breaking capacity of protection device ZLL = Impedance measured between phase and phase ZLN = Impedance measured between phase and neutral
Measured voltage U
C
NOM
230V-10% < Vmeasured < 230V+ 10% 230V 1.05 230V+10% < Vmeasured < 400V- 10% Vmeasured 1.10 400V-10% < Vmeasured < 400V+ 10% 400V 1.05
MAX
EN - 93
MACROTESTG3 - COMBIG3
12.6. VERIFY OF PROTECTION AGAINST INDIRECT CONTACTS IN TN SYSTEMS Purpose of the test
The protection against indirect contacts in the TN systems must be guarantee by means a protection device against the overcurrents (typically MCB or fuse) which swich off the power supply of the circuit or the electrical equipment in case of fault between an active part and a ground mass or a protection conductor within a interval not exceeding at 5s, sufficient for the equipments, or in compliance with the times declared in the following
Uo [V] Trip out time of protection [s]
50 120
120 230
230 400
0.8
0.4
0.2
>400 0.1
Table 5: Tripping times for protection devices
Uo = nominal AC voltage refer to ground of the system
The above conditions is satisfied by the following relationshisp:
Zs * Ia Uo
where:
Zs = Fault Loop P-PE impedance which includes the phase winding of the
transformer, the line conductor up to the fault point and the protective conductor from the fault point to the star center of the transformer
Ia = Tripping current of the protection device within the specified time in Table 5 Uo = nominal AC voltage refer to ground
CAUTION
The instrument must be used to measure fault loop impedance values at least 10 times higher than the resolution value of the instrument in order to minimize errors.
Parts of the system to be checked
The test must necessarily be performed on TN and IT systems not protected by differential devices.
Allowable values
The measurement is aimed at ensuring that in every point of the system the relationships derived from standard EN60909-0 are satisfied:
NOM
U
PEP
CIIa
Measured voltage U
MINPEPMIN
Z
NOM
PEP
C
MIN
230V-10% < Vmeasured < 230V+ 10% 230V 0.95 230V+10% < Vmeasured < 400V- 10% Vmeasured 1.00 400V-10% < Vmeasured < 400V+ 10% 400V 0.95
EN - 94
MACROTESTG3 - COMBIG3
Depending on the set values of phase-phase, phase-neutral or phase-PE voltage (see §
5.1.3) and the measured value of fault loop impedance, the instrument calculates the minimum value of the assumed short-circuit current to be interrupted by the protection device. For proper coordination, this value MUST always be greater than or equal to the Ia value of the tripping current of the type of protection considered.
The Ia reference value (see Fig. 36) depends on:
Protection type (curve) Rated current of the protection device Time of fault extinction by the protection
Fig. 36: Example of curves relative to magnetothermal (MCB) protection
The instrument allows the selection of the following parameters:
MCB current (B curve) selectable among values:
6, 10, 13, 15, 16, 20, 25, 32, 40, 50, 63A MCB current (C, K curves) selectable among values:
0.5, 1, 1.6, 2, 4, 6, 10, 13, 15, 16, 20, 25, 32, 40, 50, 63A
MCB current (D curve) selectable among values: 0.5, 1, 1.6, 2, 4, 6, 10, 13, 15, 16, 20, 25, 32A Nominal current Fuse gG selectable among values: 2, 4, 6, 8, 10, 12, 13, 16, 20, 25, 32,
40, 50, 63, 80, 100, 125, 160, 200, 250, 315, 400, 500, 630, 800, 1000, 1250A Nominal current Fuse aM selectable among values: 2, 4, 6, 8, 10, 12, 16, 20, 25, 32, 40,
50, 63, 80, 100, 125, 160, 200, 250, 315, 400, 500, 630A
Time of fault extinction by the protection selectable among: 0.1s, 0.2s, 0.4s, 5s
EN - 95
MACROTESTG3 - COMBIG3
12.7. VERIFY OF PROTECTION AGAINST INDIRECT CONTACTS IN TT SYSTEMS Purpose of the test
Checking that the protection device is coordinated with the value of earth resistance. We cannot assume a priori a reference limit value for earth resistance as a reference when checking the measurements result. It is necessary to check each time that the coordination prescribed by the standard is met.
Parts of the system to be checked
Earth installation in operating conditions. The test must be performed without disconnecting the earth rods.
Allowable values
The value of earth resistance, however measured, must satisfy the following relation:
RA < 50 / Ia
where: RA = resistance measured of earth installation whose value can be determined
with the following measurements:
Three-wire earth resistance with voltammetric method Impedance of the fault ring (*) Earth resistance with two wires (**) Earth resistance with two wires in socket (**) Earth resistance obtained by the measurement of contact voltage Ut (**)  Earth resistance obtained by the tripping time test of the RCDs (A, AC, B),
RCD S (A, AC) (**)
I
= tripping current of the automatic RCD or rated tripping current of the RCD (in
a
case of RCD S 2 IdN) in ampere
50 = safety limit voltage (reduced down to 25V in special environments)
(*) If the system protection is obtained through a differential switch, the measurement
must be performed upstream of this switch or downstream of it by short-circuiting the switch in order to prevent it from tripping.
(**) These methods, although not currently foreseen by guidelines provide values that
have been proven indicative of the earth resistance by numerous comparisons with the three-wire method.
EXAMPLE OF EARTH RESISTANCE CHECK
System protected by a 30mA differential switch.
Let us measure the earth resistance by using one of the above-mentioned methods. In order to understand if the system resistance is to be considered as compliant with
the standards, we need to multiply the value found by 0.03A (30mA). If the result is lower than 50V (or 25V for special environments), the system can be
considered as coordinated, as it satisfies the relationship indicated above. When dealing with 30mA differential switches (as in almost all civil systems), the
maximum allowable earth resistance is 50/0.03=1666. This enables using also the
indicated simplified methods which, although they do not provide an extremely precise
value, provide a sufficiently approximated value for coordination calculation.
EN - 96
MACROTESTG3 - COMBIG3
12.8. VERIFY OF PROTECTION AGAINST INDIRECT CONTACTS IN IT SYSTEMS
In IT systems the active parts must be isolated from the ground or be connected to earth through an impedance of sufficiently high value. In the case of a single earth fault current of the first fault is weak and therefore it is not necessary to interrupt the circuit. This connection can be made to the neutral point of the system or to an artificial neutral point. If there is no neutral point, can be connected to earth through an impedance of a line conductor. It must, however, take precautions to avoid the risk of harmful physiological effects on people in contact with conductive parts simultaneously accessible in the case of a double earth fault.
Purpose of the test
Verify that the impedance of the ground probe in which the mass are connected satisfyteh following relationship:
UIZ*
LdE
where:
ZE = L-PE impedance of the ground probe in which the mass are connected Id = L-PE current of first fault (typically expressed in mA) UL = Limit contact voltage 25V or 50V
Parts of the system to be checked
The earth system under operating conditions. The verification should be performed without disconnecting the ground probes.
EN - 97
MACROTESTG3 - COMBIG3
12.9. VERIFY OF PROTECTION COORDINATION L-L, L-N AND L-PE Purpose of the test
Test the coordination of protective devices (typically MCB or fuse) present in a Single­phase or Three-phase installation as a function of the limit time of fault extinction by the protection set by the user and the calculated value of the short-circuit current.
Parts of the system to be checked
The test must be performed at the point in which the minimum short-circuit current is possible, normally at the end of the line controlled by the protection device in the normal condition of the line. The test must performed between Phase-Phase in the Three-phase installations and between Phase-PE or Phase-PE in the Single-phase installation
Allowable values
The instrument performs the comparison between the calculated value of short-circuit current and the Ia = tripping current of the protection device within the specified time, accordinf to to following expressions:
where:
II
2_
_
_
aMinLLSC
II
aMinNLSC
II
aMinPELSC
Three-phase system Loop L-L impedance
Single-phase system Loop L-N impedance
Single-phase system Loop L-PE impedance
Isc L-L_Min2F = Prospective short-circuit current minimum double phase L-L Isc L-N_Min = Prospective short-circuit current minimum L-N Isc L-PE_Min = Prospective short-circuit current minimum L-PE
The calculation of prospective short-circuit current is performed by the instrument based on the fault loop impedance measurement in compliance with the following relationships derived from standard EN60909-0:
NOM
U
LL
CI
2_
MINMinLLSC
Z
LL
CI
_
MINMinNLSC
NOM
U
NL
Z
NL
CI
_L
MINMinPESC
NOM
U
PEL
Z
PEL
Phase – Phase Phase – Neutral Phase – PE
Measured voltage U
C
NOM
MIN
230V-10% < Vmeasured < 230V+ 10% 230V 0,95 230V+10% < Vmeasured < 400V- 10% Vmeasured 1,00 400V-10% < Vmeasured < 400V+ 10% 400V 0,95
where:
U L-L = Nominal Phase-Phase voltage U L-N = Nominal Phase-Neutral voltage U L-PE = Nominal Phase-PE voltage Z L-L = Impedance Phase-Phase measured Z L-N = Impedance Phase-Neutral measured Z L-PE = Impedance Phase-PE measured
EN - 98
MACROTESTG3 - COMBIG3
CAUTION
The instrument must be used to measure fault loop impedance values at least 10 times higher than the resolution value of the instrument in order to minimize errors.
Depending on the set values of nominal voltage (see § 5.1.3) and the measured value of fault loop impedance, the instrument calculates the minimum value of the assumed short­circuit current to be interrupted by the protection device. For proper coordination, this value MUST always be greater than or equal to the Ia value of the tripping current of the type of protection considered.
The Ia reference value depends on:
Protection type (curve) Rated current of the protection device Time of fault extinction by the protection
The instrument allows the selection of the following parameters:
MCB current (B curve) selectable among values:
6, 10, 13, 15, 16, 20, 25, 32, 40, 50, 63A MCB current (C, K curves) selectable among values:
0.5, 1, 1.6, 2, 4, 6, 10, 13, 15, 16, 20, 25, 32, 40, 50, 63A
MCB current (D curve) selectable among values: 0.5, 1, 1.6, 2, 4, 6, 10, 13, 15, 16, 20, 25, 32A Nominal current Fuse gG selectable among values: 2, 4, 6, 8, 10, 12, 13, 16, 20, 25, 32,
40, 50, 63, 80, 100, 125, 160, 200, 250, 315, 400, 500, 630, 800, 1000, 1250A Nominal current Fuse aM selectable among values: 2, 4, 6, 8, 10, 12, 16, 20, 25, 32, 40,
50, 63, 80, 100, 125, 160, 200, 250, 315, 400, 500, 630A
Time of fault extinction by the protection selectable among: 0.1s, 0.2s, 0.4s, 5s
EN - 99
Loading...
