HTC J, Z321e User Guide

Your HTC J Z321e

User guide

2 Contents

Contents

Unboxing

HTC J 9
Replacing the headset jack cover 10
Back cover 11
UIM and SIM cards 14
Storage card 15
Battery 16
Switching the power on or off 17
Want some quick guidance on your phone? 18

Setting up your phone

Setting up HTC J for the first time 19
Home screen 19
Getting contacts into HTC J 20
Transferring contacts from your old phone through Bluetooth 21
Getting photos, videos, and music on or off HTC J 21
Getting to know your settings 22
Updating the HTC J software 22

Your first week with your new phone

Features you'll enjoy on HTC J 24
Touch gestures 26
Motion gestures 29
Sleep mode 31
Unlocking the screen 32
Making your first call 32
Sending your first text message 33
The HTC Sense keyboard 33
Notifications 33
Copying and sharing text 36
Capturing the HTC J screen 37
Switching between recently opened apps 37
Can't find the Menu button? 37
Checking battery usage 38

Camera

Camera basics 39
Taking a photo 40

3 Contents

Recording video 40
Keeping the camera on standby 41
Taking continuous camera shots 41
Camera scenes 42
Improving portrait shots 42
Taking a group shot 42
Taking a panoramic photo 42
Using HDR 43
Recording videos in slow motion 43
Improving video stability 43
Changing camera and video settings 44

Personalizing

Making HTC J truly yours 45
Personalizing HTC J with scenes 45
Changing your wallpaper 46
Applying a new skin 47
Personalizing your Home screen with widgets 47
Adding apps and other shortcuts on your Home screen 48
Rearranging or removing widgets and icons on your Home screen 49
Personalizing the launch bar 50
Grouping apps into a folder 50
Rearranging the Home screen 51
Personalizing with sound sets 52
Rearranging application tabs 53
Customizing the lock screen style 54
Hiding missed calls and messages on the lock screen 54
Securing HTC J with a personal touch 54

Phone calls

Making a call with Smart dial 56
Returning a missed call 56
Using Speed dial 57
Calling a phone number in a text message 57
Calling a phone number in an email 57
Calling a phone number in a Calendar event 57
Making an emergency call 58
Receiving calls 58
What can I do during a call? 59
Setting up a three-way call (CDMA) 61
Setting up a conference call (GSM) 61
Call history 62
Home dialing 63
Call settings 63

Messages

About the Messages app 64
Sending a text message (SMS) 64
Sending a multimedia message (MMS) 65
Resuming a draft message 66
Checking your messages 66
Replying to a message 67

4 Contents

Forwarding a message 68
WAP push messages 69
Managing message conversations 69
Backing up your text messages 70
Setting message options 71

Search and Web browser

Searching HTC J and the Web 72
Getting instant information with Google Now 73
Browsing the Web 75
Private browsing 77
Adding and managing your bookmarks 77
Saving web content for later 78
Viewing your browsing history 79
Downloading files and apps 79
Setting browser options 80

Photos, videos, and music

Gallery 81
Music 89
Movie Editor 94
Wireless display 95

Storage

Where apps, data, and files are stored 98
Copying files to or from the phone storage 99
Making more storage space 99
Encrypting data on HTC J 100

Sync, backup, and reset

Sync 101
Backup 103
Reset 104

HTC Sync Manager

Syncing your media and data with HTC Sync Manager 106
Installing on a Windows computer 107
The HTC Sync Manager main screen 107
Importing media to HTC Sync Manager 107
Importing music, videos, and playlists from other applications 108
Playing music in HTC Sync Manager 108
Viewing photos and videos in HTC Sync Manager 109
Deleting an album from HTC Sync Manager 110
Syncing music with the computer 110
Syncing photos and videos with the computer 111
Syncing documents with the computer 111
Syncing your contacts with the computer 112
Syncing your calendar events 112
Syncing your web bookmarks with the computer 113
Quickly transferring media from HTC Sync Manager to HTC J 113

5 Contents

People

About the People app 114
Your contacts list 114
Setting up your profile 115
Adding a new contact 115
Importing or copying contacts 116
Merging contact information 117
Contact information and conversations 118
Contact groups 119
Adding People widgets 121
Sending contact information 121
Backing up your contacts 122

Social

Facebook 123
Twitter for HTC Sense 123
About Friend Stream 123
Updating your status in Friend Stream 124
Enjoying Facebook in Friend Stream 124
Tweeting in Friend Stream 125

Email

Gmail 127
Mail 128

Calendar

About Calendar 135
Creating an event 135
Viewing the Calendar 136
Managing Calendar events 137
Accepting or declining a meeting invitation 138
Setting reminders for your events 138
Dismissing or snoozing event reminders 139
Showing or hiding calendars 139
Changing Calendar settings 140

Online storage and services

Dropbox 141
SkyDrive 145
HTC Watch 148

HTC Car

On the road with HTC Car 151
Playing music in HTC Car 151
Listening to Internet radio with TuneIn 152
Finding your way with HTC Car 152
Staying connected to your contacts 153
Changing HTC Car settings 153

6 Contents

Travel and maps

Location settings 154
Locations 154
Google Maps 161

Essential apps

Using the Clock 165
Checking Weather 167
Viewing a PDF 168
Working on documents 168
Taking notes 170
Keeping track of your tasks 172
Keeping track of your stocks 176

Google Play and other apps

Getting apps from Google Play 177
Uninstalling an app 178
Watching videos on YouTube 178
Listening to FM Radio 180
Recording voice clips 181
Sharing games and apps 181

Internet connections

Data connection 182
Managing your data usage 184
Wi‑Fi 186
Connecting to a virtual private network (VPN) 188
Using HTC J as a wireless router 189
Sharing your mobile data connection by USB tethering 190
Connecting to the Internet through a computer 190

Bluetooth

Bluetooth basics 192
Connecting a Bluetooth headset or car kit 192
Disconnecting or unpairing from a Bluetooth device 193
Sending information using Bluetooth 194
Receiving information using Bluetooth 195

Settings and security

Optimizing battery life with power saver mode 197
Getting the battery to last longer 197
Turning Airplane mode on or off 200
Changing display settings 200
Changing sound settings 201
Changing the display language 202
Accessibility settings 202
Protecting your UIM or SIM card with a PIN 203
Protecting HTC J with a screen lock 203
Checking information about HTC J 204

7 Contents

Other essentials

Using the onscreen keyboard 205
Entering words with predictive text 206
Entering text by tracing 207
Entering text by speaking 208
Printing 208
Stopping running applications using Task Manager 209
Status icons 210

Trademarks and copyrights

Index

8 Conventions used in this guide

Conventions used in this guide

In this user guide, we use the following symbols to indicate useful and important
information:

This is a note. A note often gives additional information, such as what happens
when you choose to do or not to do a certain action. A note also provides
information that may only be applicable to some situations.

This is a tip. A tip gives you an alternative way to do a particular step or procedure,
or lets you know of an option that you may find helpful.

This indicates important information that you need in order to accomplish a certain
task or to get a feature to work properly.

This provides safety precaution information, that is, information that you need to be
careful about to prevent potential problems.

9 Unboxing

Unboxing

HTC J

1. BACK

2. HOME

3. RECENT APPS (can be configured in

Settings to open the Menu)

4. VOLUME

5. Notification LED

6. Front camera

7. POWER

8. 3.5mm headset jack

9. Proximity sensor

10. USB connector

If you want to use a screen protector, please don't cover and block the proximity
sensor. You can purchase the dedicated screen protector for HTC J that already
has a small opening for the sensor.

10 Unboxing

Replacing the headset jack cover

The headset jack cover prevents water and contaminants from getting inside HTC J.
Replace the headset jack cover when you're not using a headset.

1. Align the bottom edge of the headset jack cover with audio jack compartment's

lower edge.

2. Press down on the top of the headset jack cover, making sure the rubber plug

goes into the hole.

3. Gently press the back of the headset jack cover to make sure it is firmly closed.

11 Unboxing

Back cover

Removing the back cover

The HTC J back cover was specially designed to keep water and contaminants out.

Don't pull on the chassis frame when opening the battery cover. Make sure to
follow all the steps to prevent the chassis frame from being damaged.

Follow these instructions to remove the back cover.

1. Securely hold HTC J facing up.

2. With your thumb or finger, lift up the back cover from the small opening at the

bottom of HTC J.

12 Unboxing

3. Slide your fingernail to the right and pull the battery cover open at the corner.

4. Slide your fingernail in the other direction and pull the battery cover open at the

corner.

1

2

3

4

5

6

7

8

9

13 Unboxing

5. Slip your fingers into the battery compartment.

6. Pull the battery cover away from the middle to remove it.

Replacing the back cover

Antennas are placed underneath the cover. To get the best signal for calls and data
connection, be sure to secure the cover tightly.

1. Align the back cover onto the top part of HTC J.

2. Press down on the back cover in the order shown.

You will hear a click when the back cover is locked in place.

14 Unboxing

UIM and SIM cards

HTC J has a card slot that accommodates either a CDMA UIM card or a GSM SIM card.

You can also use a dual-mode card in the slot. A dual-mode card allows you to
connect to either a CDMA network or a GSM network.

Inserting a UIM or SIM card

1. Take the back cover off.

2. Remove the battery.

3. Insert a CDMA UIM or GSM SIM card into the slot. When inserting, make sure the

card’s gold contacts are facing down and its cut-off corner facing out.

Removing a UIM or SIM card

Make sure to switch off HTC J before removing your UIM or SIM card.

1. Take the back cover off.

2. Remove the battery.

3. Slide the UIM or SIM card out from the UIM/SIM slot.

15 Unboxing

Storage card

Use a storage card to store your photos, videos, and music.

Inserting the storage card

1. Take the back cover off.

2. Insert the microSD™ card into the storage card slot with its gold contacts facing

down and push it until it clicks into place.

Removing the storage card

1. Take the back cover off.

2. Push the storage card in to eject it from its slot.

3. Slide the storage card out from its slot.

Unmounting the storage card

When you need to remove the storage card while HTC J is on, unmount the storage
card first to prevent corrupting or damaging the files in the storage card.

1. Slide the Notifications panel open, and then tap .

2. Tap Storage > Unmount SD card.

16 Unboxing

Battery

Removing the battery

Before using HTC J for the first time, you need to remove the protective thin film
from the battery.

1. Take the back cover off.

2. With your thumb or finger, lift the battery from the battery compartment.

Inserting the battery

Please use only original batteries that came in the box or replacements that we
recommend.

1. Take the back cover off.

2. Insert the battery (with its exposed copper contacts first) into the battery

compartment.

17 Unboxing

Charging the battery

Before you turn on and start using HTC J, it is recommended that you charge the
battery.

§ The battery is already installed in HTC J when shipped. A thin film is inserted
between the battery and the compartment. You need to remove this film before
you can charge the battery.

§ Only the power adapter and USB cable provided in the box must be used to
charge the battery.

§ Do not remove the battery from HTC J while you are charging it using the power
or car adapter.

1. Insert the small end of the USB cable into the USB connector.

2. Insert the other end of the USB cable into the power adapter.

3. Plug in the power adapter to an electrical outlet to start charging the battery.

As a safety precaution, the battery stops charging if it overheats.

Switching the power on or off

Switching the power on

Press the POWER button.

When you turn on HTC J for the first time, you’ll need to set it up.

18 Unboxing

Switching the power off

1. If the display is off, press the POWER button to turn it back on, then unlock the

screen.

2. Press and hold the POWER button for a few seconds.

3. Tap Power off on the options menu.

Want some quick guidance on your phone?

Learning the basics with Quick Tips

After your phone starts, you'll see a transparent overlay of Quick Tips on some
screens (such as the Home screen) that will guide you in using HTC J. The tips for a
screen won't display again after you've closed them.

To view the Quick Tips again, slide the Notifications panel open, and then tap >

About > Help > Show all quick tips.

Exploring HTC J

Tips & Help lets you get the most out of HTC J in seconds.

§ Need to know how to do something right away? Just type in some keywords
and get clear, up-to-date answers right on HTC J.

§ Ever have the feeling that you're not getting the most out of your phone?
Browse through the friendly walkthroughs on Tips & Help to learn how. The
topics range from intro to advanced and the Tips & Help widget even
recommends topics that you might like.

To open Tips & Help from the Home screen, tap > Tips & Help.

If you haven't downloaded Tips & Help content yet, or if there's updated content
available, just tap the download link to get it.

To change the sync settings of Tips & Help, tap

> Update settings.

Searching Tips & Help

1. In Tips & Help, tap , and then enter the words you want to search for.

2. Tap a search result to jump straight to that item.

19 Setting up your phone

Setting up your phone

Setting up HTC J for the first time

When you switch on HTC J for the first time, you’ll be asked to set it up.

§ Walk through the on-device setup to choose your Internet connection, turn
location services on or off, and more.

§ Use our HTC Get Started service to set up your accounts and personalize HTC J
from your computer.

The on-device setup shows you the URL of our Get Started site.

When personalizing HTC J, you can choose the wallpaper, sounds, apps, home
screen layouts, and more. Or just choose a Quick Style that already has all these
items preselected for you. You need an HTC Account to save your HTC Get
Started setup and to download your settings to HTC J.

To find out more, see the Help and FAQ on our HTC Get Started site.

Some features that need to connect to the Internet such as location-based services
and auto-sync of your online accounts may incur extra data fees. Don’t worry. You
can enable or disable them in Settings later on.

Home screen

Your Home screen is where you make HTC J your own. You can add your favorite
applications, shortcuts, folders and widgets so they’re always just a tap away. To find
out how, see Personalizing on page 45.

Extended Home screen

As you start to do more things with HTC J, you might find that one Home screen is
not enough. No problem.

Slide your finger horizontally to the left or right on the screen and you’ll discover more
space for adding icons, widgets, and more.

Press to return to the main Home screen.

20 Setting up your phone

Using Leap view

§ To jump straight to the screen that you want, press or pinch the screen to
show the Leap view. It reveals all Home screens as thumbnails. Just tap the one
you want and you’ll leap right there.

§ In Leap view, if there's space to add a new screen, you can tap Add Panel to do
so. An empty Home screen appears and you can start customizing from there.

Getting contacts into HTC J

There are several ways you can add contacts to HTC J.

Sync with your
computer

™

Gmail

Social network
accounts

Phone contacts You can create and store contacts directly in HTC J.
UIM and SIM card Copy all your UIM and SIM contacts to HTC J.
Microsoft Exchange

ActiveSync
Transfer Use the Transfer app to transfer contacts and other data from

®

Sync the contacts from your old phone to your computer, and
then use HTC Sync Manager to sync HTC J with your
computer's Microsoft® Outlook®, Outlook Express or Windows
Contacts.

Google® contacts are imported to HTC J after you sign in to
your Google Account. You can also create more Google
contacts right from HTC J.

Log in to your favorite social networks to import contact
information from them.

HTC J syncs your work contacts from the Microsoft Exchange
ActiveSync Server in your workplace.

your old phone to HTC J through Bluetooth®.

®

21 Setting up your phone

Transferring contacts from your old phone through Bluetooth

Depending on the capabilities of your old phone, the Transfer app may be able to
transfer not only contacts but also other data such as calendar events and text
messages to HTC J.

1. From the Home screen, tap

2. Tap Next to begin.

3. Choose your old phone's name and model.

4. On your old phone, turn Bluetooth on and set it to discoverable mode.

5. Follow the onscreen instructions on your old phone and HTC J to pair them.

6. Choose the types of data to transfer:

§ If you selected Contacts and Calendar, you can choose whether to transfer

them to the phone or to an account you're signed into (such as Exchange
ActiveSync).

§ If you're transferring data from the HTC One series (or newer phones), you

can also select SMS, Bookmark, and Task. These data types can only be
transferred locally to HTC J.

7. Wait for the data transfer to finish.

> Transfer.

Getting photos, videos, and music on or off HTC J

There are two ways you can transfer your media.

§ Connect HTC J to your computer. Your computer will recognize it just like any
removable USB drive, and you can copy your media between them.

§ Download and use our HTC Sync Manager software. You can easily set it up to
sync folders containing media and playlists on your computer with HTC J. HTC
Sync Manager can also automatically get photos and videos off HTC J to your
computer. For details, see HTC Sync Manager on page 106.

Tired of transferring your media every time you change to a new phone? Use online
storage services to put your media in one place so you can access them anywhere —
on your computer, HTC J, and other mobile devices.

Check first what online storage accounts are available on HTC J and sign in to the one
you want to use. To sign in to an account, slide the Notifications panel open, and then
tap
storage.

> Accounts & sync > . Use the Gallery app to access media in your online

22 Setting up your phone

Getting to know your settings

Want to change the ringtone, set up a Wi‑Fi® connection or make the screen brighter?
Do this and more in Settings.

Slide the Notifications panel open, and then tap . Here are some of the basic
settings you can change:

§ Tap the On/Off switch next to an item such as Wi-Fi to turn it on or off. Tap the

item itself to configure its settings.

§ Tap Sound to set a ringtone, choose a sound profile, and configure incoming call

sound settings.

§ Tap Display, gestures & buttons (or Display & buttons) to change the screen

brightness or set how long the screen is idle before going to sleep.

§ Tap Security to secure HTC J, for example with a screen lock.

Updating the HTC J software

HTC J can check and notify you if there’s a new update available. You can also
manually check if there's an available update.

You might want to use Wi‑Fi or your computer's Internet connection to download
software updates to save on data usage. You can set this option in Settings >

About > Software updates > .

Installing a software update

When the Internet connection is on and there's a new software update available, the
update notification icon appears in the status bar.

1. Slide the Notifications panel open, and then tap the system update notification.

2. If you want to avoid additional data charges, select Use Wi-Fi or cable only.

3. Tap OK.

4. When download is complete, select Install now, and then tap OK.

Wait for the update to finish. HTC J restarts automatically.

23 Setting up your phone

Installing an application update

When the Internet connection is on and there's an available update for one of your
apps, the update notification icon appears in the status bar.

1. Slide the Notifications panel open, and then tap the update notification.

The Updates screen opens with the list of application updates to be installed.

2. Tap an item to view its details, and then tap .

3. When you're done reviewing the updates, tap Install. You'll be asked to restart

HTC J if needed.

Checking for updates manually

1. Slide the Notifications panel open, and then tap .

2. Tap About > Software updates > Check now.

24 Your first week with your new phone

Your first week with your new phone

Features you'll enjoy on HTC J

HTC J gives you an amazing camera, great sound experience, and more.

Capture every moment as it happens

§ Activate Camera instantly. Launch it from the lock screen and take your shots
with no delay.

And when Camera goes into sleep mode, just press POWER to use it right away.

§ With VideoPic, you can snap a picture while you're shooting video. See Taking a

photo while recording a video on page 41.

You can also capture a photo from a previously recorded video. See Taking a

photo while watching a video on page 82.

§ Use Continuous shooting mode to capture 20 consecutive shots or more. See

Taking continuous camera shots on page 41.

§ By just tapping the screen (or shutter button), take three shots of your subject
at different exposures and combine them into a nice, evenly exposed photo. See

Using HDR on page 43.

§ In Gallery, use Map view to see photos grouped by location, or Events view to
see photos and videos grouped by date taken. For details, see Viewing photos

and videos on page 81.

Immerse in music

§ Our HTC Music app keeps all your music sources and services in one place. See

About the Music app on page 89.

§ Beats Audio™ integration gives you a rich, authentic sound experience, whether
you’re listening to music, watching a YouTube® video, or playing a game. To find
out more, see Making your music sound better on page 90.

HD entertainment on the go

§ Rent or buy movies and shows. Choose from our wide collection of titles in HTC
Watch™. See About HTC Watch on page 148.

§ Use HTC Media Link HD to wirelessly share your media from HTC J to your HD
TV. See Sharing on a big screen on page 95.

25 Your first week with your new phone

Quick, easy set-up

With our HTC Get Started service, you can set up and personalize HTC J from your
computer, and just download your settings to HTC J. See Setting up HTC J for the

first time on page 19.

Dropbox integration with HTC Sense

Always have access to your photos, videos, and documents anywhere by storing them
in Dropbox. When you sign in to your Dropbox account from HTC J, you can even get
an additional 23 GB of free Dropbox storage for two years. To find out how, see Using

Dropbox on HTC J on page 141.

The 23 GB offer is available only if Dropbox is preloaded. If it's not preloaded, you
can download it from Google Play and still enjoy Dropbox integration with apps
such as Gallery and Mail.

HTC Car

With the HTC Car app, keep yourself entertained while finding your way on the road.
You can use turn-by-turn navigation, browse maps, take calls, and listen to music or
Internet radio. To find out more, see HTC Car on page 151.

Rich and seamless browsing experience

Enjoy HTML5 content on the go. And no more panning left and right. The web
browser's text reflow automatically adjusts text to the width of your screen. To find
out more about using the web browser, see Browsing the Web on page 75.

You can also keep a copy of what you're browsing so you can read it later even
without an Internet connection. See Saving web content for later on page 78.

Smart dial

The phone dialer’s Smart dial feature makes it quick and easy for you to place a call.
Just enter the phone number or first few letters of the contact name. See Making a

call with Smart dial on page 56.

26 Your first week with your new phone

Touch gestures

Use touch gestures to get around the Home screen, open apps, scroll through lists,
and more.

Tap

Tap the screen with your finger when you want to select
onscreen items such as application and settings icons, or press
onscreen buttons.

Press and hold

Swipe or slide

To open the available options for an item (for example, a
contact or link in a webpage), just press and hold the item.

Quickly swipe your finger vertically or horizontally across the
screen to go to other Home pages, scroll through documents,
and more.

27 Your first week with your new phone

Drag

Press and hold your finger with some pressure before you start
to drag. While dragging, don't release your finger until you
have reached the target position.

Flick

Flicking the screen is similar to swiping, except that
you need to swipe your finger in light, quicker
strokes, such as when moving right and left on the
Home screen, or flicking through a contacts or
message list.

Press and flick

On the Home screen, you can easily move a widget or
icon from one screen to another.

Press and hold the widget or icon with one finger, and
flick the screen to the new location with another finger.

28 Your first week with your new phone

Pinch and spread

Pinch the screen to zoom out of the picture or text.

In some apps, like Gallery, Messages, Mail,
or the web browser, spread your fingers
on the screen to zoom in when viewing a
picture or text.

Two-finger swipe

In some apps that have sorting, like Mail or People, swipe up or
down using two fingers to scroll the screen. The screen displays the
sorting order, and you can easily scroll to the information you want.

29 Your first week with your new phone

Three-finger swipe

Swipe up using three fingers to share content such as
photos, videos, and music from HTC J to your TV or
speakers.

HTC gestures is enabled by default, making the three-finger gesture exclusive for
sharing content. You also won't be able to use multi-finger gestures (gestures that
use three fingers or more) in apps such as games or musical instrument apps.

To use multi-finger gestures in such apps, clear the HTC gestures option in Settings
> Display, gestures & buttons. This disables content sharing.

Motion gestures

Use motion gestures to mute HTC J, turn on the speakerphone, and more.

Flip to silence / flip for speakerphone

When a call comes in you can turn HTC J over
to mute it.

30 Your first week with your new phone

Pick up to lower volume

While in a call, turn HTC J over to turn the
speakerphone on for hands-free conversations
or for conference calling.

In a business meeting or restaurant, pick
HTC J up when a call comes in to lower
the ringtone volume.

Set volume to automatically rise while in your pocket or bag

On a noisy street and can't hear HTC J ringing in your
bag?

You can set HTC J to recognize when it's in your bag or
pocket and raise the ringtone volume so that you can
hear it in noisy environments.

31 Your first week with your new phone

Rotate HTC J for a better view

For many screens, you can
automatically change the screen
orientation from portrait to
landscape by turning HTC J
sideways.

When entering text, you can turn
HTC J sideways to bring up a
bigger keyboard.

Sleep mode

Sleep mode saves battery power by putting HTC J into a low power state while the
display is off. It also stops accidental button presses when HTC J is in your bag.

Switching to Sleep mode

Briefly press the POWER button to turn off the display and switch to Sleep mode.
HTC J also automatically goes into Sleep mode when it’s left idle for a while.

You can change the time before HTC J sleeps in the Display, gestures & buttons (or

Display & buttons) settings.

Waking up from Sleep mode

To wake HTC J up manually, press the POWER button. You’ll need to unlock the
screen.

HTC J automatically wakes up when you have an incoming call.

32 Your first week with your new phone

Unlocking the screen

Pull the ring up to unlock the screen.

If you've set up a screen lock, you'll be asked to provide your credentials before
HTC J unlocks.

If you've set an event reminder or an alarm, you can drag or to the ring to
snooze or dismiss the event or alarm.

Opening an app or folder from the lock screen

§ On the lock screen, drag an app or folder icon to the ring to unlock the screen
and directly go to the app or folder.

The shortcuts on the lock screen are the same ones on your Home screen's launch
bar. To change the lock screen shortcuts, replace the apps or folders on the launch
bar.

§ When there's a notification or info shown on the lock screen such as a missed
call or new message, you can drag it to the ring to directly go to its app.

Making your first call

1. On the Home screen, tap

2. Enter the phone number or first few letters of the contact’s name.

3. From the list, tap a contact to call.

4. To hang up, tap End Call.

.

33 Your first week with your new phone

Sending your first text message

1. From the Home screen, tap > Messages.

2. Tap .

3. Tap , and then select the contacts you want to send the message to.

4. Tap the box that says Add text, and then enter your message.

5. Tap to add quick text, change the font size, and more.

6. Tap Send.

The HTC Sense keyboard

Typing is fast and accurate with the HTC Sense™ keyboard.

§ Turn on the Trace keyboard so you can enter words by just sliding your finger
from one letter to another.

§ You can type words by just speaking.

§ Predictive text also saves typing time. As you type, you'll see word suggestions

that you can choose from. You can even add more words to the predictive text
dictionary.

§ Just swipe right to access the numeric and symbol keyboard. Or swipe left to
switch between languages.

§ The keys have secondary numbers, punctuation symbols, or other characters
that you can quickly insert without having to switch to the numeric and symbol
keyboard.

For example, the first row of keys has numbers. Just press and hold a key to
insert a number.

§ Choose from a selection of smileys and insert one right from the keyboard.

§ Show or hide navigational arrow keys on the keyboard. If you enable the arrow

keys in Settings, they will only appear on the portrait keyboard.

And since everyone has their own typing style, you can go to Settings to calibrate the
keyboard so it learns how you type.

For more details on using the HTC Sense keyboard, see Using the onscreen keyboard
on page 205.

Notifications

Notification LED

34 Your first week with your new phone

The notification LED shows a:

§ Solid green light when HTC J is connected to the power adapter or a computer
and the battery is fully charged.

§ Flashing green light when you have a pending notification.

§ Solid orange light when the battery is being charged.

§ Flashing orange light when the battery level reaches very low.

35 Your first week with your new phone

Notifications panel

Notification icons inform you of new messages, calendar events, alarms, and activities
in progress such as files downloading.

When you see notification icons, open the Notifications panel to check out details of
the notifications that you've received. You can also quickly access settings from the
Notifications panel.

1. To open the Notifications panel, slide down from the top of the screen.

If you have several notifications, scroll down the screen to see them all.

2. On the Notifications panel:

§ You can expand certain notifications to see more information, such as email
previews and calendar events. Spread with your two fingers to expand a
notification, or pinch to collapse it.

§ You'll see icons in some notifications that allow you to take immediate
actions. For example, when you have a missed call, tap the available icons
to return the call or reply with a text message.

§ Tap the notification icon on the left to open the corresponding app.

§ To dismiss just one notification in the list, drag it left or right.

3. To close the Notifications panel, slide up from the bottom bar of the panel or

press .

You can also tap to dismiss all notifications and close the Notifications panel.

36 Your first week with your new phone

Copying and sharing text

In apps such as the web browser and Mail, you can select and copy text, and then
paste or share it.

Selecting text

1. Press and hold on a word.

2. Drag the start and end markers to highlight the surrounding text you want to

select.

To copy the address of a linked webpage, press and hold the link, and then tap

Copy link URL.

Copying and pasting text

1. After you have selected the text you want to copy, tap Copy.

The selected text is then copied to the clipboard.

2. In a text entry field (for example while composing an email), press and hold at

the point where you want to paste the text.

3. Tap Paste.

Sharing text

1. After you have selected the text you want to share, tap Share.

2. Choose where to paste and share the selected text, such as in an email message

or social network status update.

37 Your first week with your new phone

Capturing the HTC J screen

Want to show off your high game score, write a blog post about HTC J features, or
post a status update about a song you're playing? It's easy to take a picture of the
screen and share it from Gallery.

Press and hold POWER and then press . The screen is saved in the Camera shots
album in Gallery.

Switching between recently opened apps

You can easily access apps you've just recently opened.

1. Press .

2. Slide your finger left or right to see recently-opened apps.

§ To switch back to an app, just tap it.

§ To remove an app from the list, drag it up.

Can't find the Menu button?

Do you miss having a Menu button? You can set the Recent apps button to open the
Menu as well.

1. Slide the Notifications panel open, and then tap

2. Tap Display, gestures & buttons (or Display & buttons).

3. Tap Recent apps button and select how you want to open the Menu, such as

press or press and hold the button.

.

38 Your first week with your new phone

Checking battery usage

See a ranking list of apps that are using the battery. You can also see how much and
how long the battery has been used for each app.

1. Slide the Notifications panel open, and then tap .

2. Tap Power > Usage.

3. You can:

§ Tap an app to check how it's using the battery. You'll see how much
battery power is used by resources such as the display and CPU for the app
and other use details.

§ Tap to close an app.

If you see buttons while viewing an app's battery use details, you can tap them to
adjust settings that affect battery usage, stop the app, and more.

Checking battery history

Check how long you've been using HTC J since the last charge. You can also see a
chart that shows how long the screen has been on, and how long you've been using
connections like the mobile network or Wi‑Fi.

1. Slide the Notifications panel open, and then tap .

2. Tap Power > History.

3. If you've used HTC J for a long time since the last charge, swipe left or right to

scale the graph that details battery usage over time.

You can also spread your fingers or pinch to scale the graph.

39 Camera

Camera

Camera basics

Capture photos instantly, with no delay. Just directly launch the camera from the lock
screen, even if HTC J is password protected.

1. When your display is off, press POWER.

2. Drag the Camera icon to the lock screen ring so you can start taking photos and

videos right away.

From the Home screen, you can also tap Camera to launch it.

Use the controls on the Viewfinder screen to add effects, zoom in or out, and more.

When you leave the Viewfinder screen, you'll need to unlock HTC J if you've set a
screen lock.

Zooming

§ Before taking a photo or video, slide your finger on the zoom bar to zoom in or
out.

§ When you're recording video, the zoom bar is always onscreen. You can freely
zoom in or out while recording.

Switching between the front and main camera

On the Viewfinder screen, tap .

Some camera features are not available when you’re using the front camera, such
as zooming.

40 Camera

Choosing an effect

Use the available camera effects to make your photos look like they’ve been taken
through special lenses or filters. You can also apply certain effects to videos.

1. Tap .

2. Scroll through the available effects and tap one that you like.

Setting the resolution

1. On the Viewfinder screen, tap .

2. Tap Aspect and Resolution, and then choose an image resolution.

3. Tap Video Quality, and then choose a video resolution.

Choosing a flash mode

Tap the flash icon to choose a flash mode.

When using Flash on or Auto flash mode, the camera intelligently sets the best flash
brightness for your photo.

Taking a photo

1. Open Camera from the lock screen or Home screen.

2. Just point the camera at what you want to capture. The camera adjusts the

focus automatically as you move it.

3. When you're ready to take the photo, tap

You can also tap anywhere on the screen to take a photo (be sure that Touch to
capture is selected in > Camera options).

.

Recording video

1. Open Camera from the lock screen or Home screen.

2. When you're ready to start recording, tap .

3. While recording, you can:

§ Freely zoom in or out.

§ Change focus to a different subject or area by just tapping it on the

Viewfinder screen.

§ Tap the flash icon to turn the flash on or off.

4. To stop recording, tap .

41 Camera

Taking a photo while recording a video

While you're recording video using the main camera, tap to capture a still shot of
your subject.

Keeping the camera on standby

While waiting to capture your next subject, switch HTC J to Sleep mode and keep the
camera ready to take more photos and videos.

1. Open Camera from the lock screen or Home screen.

2. Take your first batch of photos or videos.

3. To switch HTC J to Sleep mode, press POWER.

4. When you're ready to take more photos and videos, just press POWER again to

launch the camera.

When you leave the Viewfinder screen, you'll need to unlock HTC J if you've set a
screen lock.

Taking continuous camera shots

Do you want to take photos of moving subjects? Whether it’s your kid's football game
or a car race, you can capture the action.

Make sure that you're in Normal scene to use this feature.

1. On the Viewfinder screen, just press and hold . The camera takes up to 20

consecutive shots of your subject.

Want to capture a lot more shots? Tap > Continuous shooting, and then clear
the Limit to 20 frames option.

2. After taking the shots, select the photo that you like the most, and then tap Best
shot. To save more photos from the batch, just delete the photos you don’t

want to keep.

42 Camera

Camera scenes

A scene is a collection of settings to suit the lighting and environment. Use Normal
and let the camera automatically determine optimal settings, or choose from a wide
selection of scenes before you start taking photos.

Improving portrait shots

If you'd like your family or friends to look their best in your photos, make sure to use
the portrait scene. It smoothens the skin in your shots.

1. On the Viewfinder screen, tap .

2. Tap Scene selection > Portrait.

3. When you're ready to take the photo, tap .

Taking a group shot

Finding it difficult to make everyone smile and have them look at the camera at the
same time? With HTC J, you get perfect group portraits with the most smiles and the
fewest blinks.

1. On the Viewfinder screen, tap

2. Tap Group portrait.

3. When you're ready to take the photo, tap . The camera takes several shots

and merges them into the best possible group photo.

.

Taking a panoramic photo

Whether it’s the Golden Gate Bridge or the Eiffel Tower, you can capture anything
wide or tall in a single photo.

§ Zoom and flash are disabled when you're in this mode.

§ You can't change the image resolution when taking a panorama.

1. On the Viewfinder screen, tap .

2. Tap Panorama.

43 Camera

3. When you're ready to take the first shot, tap . Directional arrows appear,

prompting you to pan left or right in landscape view (or pan up or down in
portrait view).

4. Pan HTC J as smoothly as you can, and then pause when you see a complete

frame on the Viewfinder screen. The camera automatically captures the shot.

5. Repeat the previous step to take the remaining shots.

Or, tap to stop capturing anytime.

The camera stitches the shots into a single photo.

Using HDR

When shooting portraits against a bright background, use the HDR (High Dynamic
Range) scene to capture your subjects clearly. HDR brings out the details of both the
highlights and shadows, even in high contrast lighting.

1. On the Viewfinder screen, tap .

2. Tap HDR.

3. When you're ready to take the photo, tap .

The camera takes three shots at different exposure levels and combines them into one
enhanced photo.

Recording videos in slow motion

Relive high speed action bit by bit and add a touch of suspense to your videos.

1. On the Viewfinder screen, tap .

2. Tap Slow motion video.

3. Frame your subject on the Viewfinder screen.

4. Tap to start recording.

Improving video stability

Lessen shakes and blurs in your video, especially when you're following a moving
subject.

1. On the Viewfinder screen, tap

2. Tap Video options > Video stabilization.

.

44 Camera

Changing camera and video settings

1. On the Viewfinder screen, tap .

2. As well as changing basic camera and video settings, you can also:

§ Change the review duration to set how long a captured photo or video will
be displayed on the Review screen before the camera changes back to the
Viewfinder screen.

§ Automatically take a shot when your subject smiles (photo mode only).

§ Geo-tag photos to store GPS location in your captured photos (photo

mode only).

§ Set the ISO level. Higher ISO numbers are better for taking pictures in low
light conditions (photo mode only).

§ Automatically upload photos to a social network (photo mode only). You
can set the upload frequency, select the album to upload to, and set the
privacy level.

45 Personalizing

Personalizing

Making HTC J truly yours

Make HTC J look and sound just the way you want it. Personalize it with a different
wallpaper, skin, ringtone, and notification sound for events such as incoming text,
email, and calendar reminders.

Personalizing HTC J with scenes

HTC J becomes multiple phones in one when you use scenes. Scenes are personalized
Home screen layouts that you can quickly apply. By switching between scenes, you
instantly turn HTC J into your perfect weekend phone, travel phone, work phone, or
pure play phone.

Everytime you add or modify something on the Home screen, HTC J automatically
saves your changes to the current scene selected.

Using a preset scene

HTC J features preset scenes, each preconfigured with a different wallpaper and
collection of widgets that reflect different moments in your life. You can choose a
scene that is suitable for work, play, travel, or your social life.

1. Slide the Notifications panel open, and then tap > Personalize.

2. On the Display tab, tap Scene.

3. Slide your finger on the screen from right to left to select the scene you want.

4. Tap Apply.

Creating a new scene

You’ll start with an empty Home screen when you create a new scene.

1. Slide the Notifications panel open, and then tap > Personalize.

2. On the Display tab, tap Scene.

3. Tap > New.

46 Personalizing

4. Enter a new scene name, and then tap Done.

5. Personalize the scene by adding widgets and apps, changing the wallpaper, and

more. All of your changes will be automatically saved to this scene.

Renaming a scene

1. Slide the Notifications panel open, and then tap > Personalize.

2. On the Display tab, tap Scene.

3. Slide your finger on the screen from right to left to select the scene you want to

rename.

4. Press and hold a scene thumbnail, and then tap Rename.

5. Enter a new scene name.

6. Tap Done.

Deleting scenes

1. Slide the Notifications panel open, and then tap > Personalize.

2. On the Display tab, tap Scene.

3. Tap > Delete.

4. Slide your finger on the screen from right to left to browse through scenes, then

tap one or more scenes you want to delete.

5. Tap Delete.

Changing your wallpaper

Pick your favorite photo as your Home wallpaper. Choose from the available
wallpapers, or use any photo you've taken with the camera.

1. Slide the Notifications panel open, and then tap > Personalize.

2. On the Display tab, tap Wallpaper.

3. Tap one of the following:

HTC wallpapers Choose a preset wallpaper, and then tap Preview.
Live wallpapers Choose a preset animated wallpaper, and then tap Preview. If

the animated wallpaper you chose can be customized, tap

Settings.

Gallery Choose an existing photo and crop it.

4. Tap Save or Apply.

47 Personalizing

Applying a new skin

Personalize beyond the Home screen by applying a new skin. Skins give a different
look and feel to most onscreen buttons, application screens, option menus, and other
items.

1. Slide the Notifications panel open, and then tap > Personalize.

2. On the Display tab, tap Skin.

3. Slide your finger on the screen from right to left to select the skin you want.

4. Tap Apply.

Personalizing your Home screen with widgets

Widgets put at-a-glance important information and media content up front on your
Home screen. Some widgets are already added to your Home screen for your
convenience. You can add more from the available selections of widgets.

Adding a widget to your Home screen

1. Press and hold on an empty space on your Home screen.

2. On the Widgets tab, you can:

§ Slide left or right to browse through the complete set of widgets.

§ Tap to search for specific widgets.

§ Tap and then choose a widget.

Some widgets are available in different styles and sizes.

3. Drag a widget to a home screen thumbnail where you want to add it.

You can also add widgets that allow you to quickly switch on or off certain settings
such as Wi‑Fi and Bluetooth. Tap

want.

> Settings, and then tap the widget that you

48 Personalizing

Changing the settings of a widget

You can modify basic settings of some widgets (for example, the People and Mail
widgets) from the Home screen.

1. Press and hold a widget on your Home screen, and then drag it to .

The relevant screen where you can change some settings for this widget then
opens.

2. Customize the widget settings.

Resizing a widget

Some widgets can be resized after you've added them to your Home screen.

1. Press and hold a widget on the Home screen, and then release your finger. If

you see directional arrow buttons appear on the widget, that means the widget
is resizable.

2. Drag an arrow button to enlarge or shrink the widget size.

Adding apps and other shortcuts on your Home screen

Place apps you often use on your Home screen. You can also add shortcuts to
frequently used settings, bookmarked webpages, and more.

1. Press and hold on an empty space on your Home screen.

2. On the Apps or Shortcuts tab, choose whether to add an app or a shortcut.

To add an app, you can also tap , press and hold an app, and then drag it to an
empty area on your Home screen.

49 Personalizing

Rearranging or removing widgets and icons on your Home screen

Moving a widget or icon

You can easily move a widget or icon from one Home screen panel to another.

1. Press and hold the widget or icon with one finger.

2. With another finger, flick left or right to rotate the screen to another Home

screen panel.

3. Release the widget or icon.

4. To move the widget or icon to another position on the panel, just press and hold

and then drag it.

Removing a widget or icon

1. Press and hold the widget or icon you want to remove, and then drag it to .

2. When the widget or icon turns red, lift your finger.

50 Personalizing

Personalizing the launch bar

The launch bar on your Home screen gives you one-touch access to commonly used
apps. You can replace the apps on the launch bar with other apps you often use.

1. Press and hold the app you want to replace, and then drag it out of the launch

bar.

2. Tap to go to the All apps screen.

3. Press and hold an app, and then drag it to the empty slot on the launch bar.

§ You can also place shortcuts to settings or information on the launch bar. Add a
shortcut first to the Home screen, and then drag it to the launch bar.

§ The apps or shortcuts you see on the lock screen are the same as the ones on the
launch bar.

Grouping apps into a folder

Use folders to group apps on the launch bar or your Home screen to free up space so
you can add more apps.

1. Press and hold an app, and then drag it over to another app to automatically

create a folder.

2. Tap the folder to open it.

3. Tap .

4. Select one or more apps that you want to add to the folder.

5. Tap Add.

You can also add shortcuts to settings or information. Add a shortcut first to the
Home screen, and then drag it over to the folder.

51 Personalizing

Renaming a folder

1. Tap the folder to open it.

2. Tap the folder window’s title bar.

3. Enter a new folder name.

4. Tap outside the folder to close it.

Removing items from a folder

1. Tap the folder to open it.

2. Press and hold an app or shortcut, and then drag it to the Home screen, or drag

it out to to remove. Repeat this process to remove more items from the
folder.

If there's only one item left in the folder, the folder ungroups the last item and
removes itself automatically.

Rearranging the Home screen

Reorder your Home screen panels in any way that fits how you use them. For
example, move the panels with frequently-used widgets, shortcuts, and folders closer
to the main Home screen.

1. Pinch the Home screen to show the Leap view.

2. Press and hold the thumbnail of the home screen you want to move. HTC J then

vibrates. Don’t lift your finger just yet.

3. Drag the thumbnail to its new position, and then lift your finger.

52 Personalizing

Removing a Home screen panel

If you feel you need fewer Home screens, you can remove some.

1. On the Home screen, pinch the touch screen or press to go to Leap view.

2. Press and hold the panel you want to remove. Don't lift your finger just yet.

3. Drag the panel to .

Adding back a Home screen panel

Add back a Home screen if you have more widgets, apps, and shortcuts that you want
to access right away.

1. On the Home screen, pinch the touch screen or press to go to Leap view.

2. Tap . A new Home screen appears. You can start adding widgets, apps, and

shortcuts.

Personalizing with sound sets

Each sound set gives you a different combination of sounds for your ringtone and
notifications such as incoming messages, email, calendar event reminders, and more.
By switching between sound sets, you can instantly make HTC J ring or alert you with
fun sounds when you're out with friends or change to subtle sounds while you're at
work.

Creating a sound set

1. Slide the Notifications panel open, and then tap > Personalize.

2. On the Sound tab, tap Sound set.

3. On the Sound sets screen, tap .

4. Enter a new sound set name, and then tap Done.

The newly created sound set is then added to the list of sound sets. You can assign
different tones to the sound set to your preference.

Changing your ringtone, notifications, and sounds

1. Slide the Notifications panel open, and then tap > Personalize.

2. On the Sound tab, tap Sound set.

3. Choose a sound set you want to customize, or create a new one, and then tap
Apply.

4. Change the ringtone, notification sound, and alarm from the Personalize screen.

HTC J automatically saves your choices to the current sound set.

53 Personalizing

Deleting sound sets

1. Slide the Notifications panel open, and then tap > Personalize.

2. On the Sound tab, tap Sound set.

3. Tap .

4. Select one or more sound sets you want to delete.

5. Tap Delete.

Rearranging application tabs

You can rearrange the tabs at the bottom of some apps to prioritize the types of
information you frequently use. You can also add or remove tabs.

1. Open an app that has the usual tabs at the bottom of its screen.

2. Press and hold the current tab until the screen changes and shows a message

about rearranging tabs.

If you don't see any tabs on the app, tap

3. You can:

§ Change the order of the tabs. Press and hold a tab, and then drag it to its
new position.

§ Drag a tab into or out of the bottom row to add or remove it.

> Edit tabs or Filters.

4. When you’re done, press .

54 Personalizing

Customizing the lock screen style

Choose from our selection of lock screens. Some lock screens are customizable.

1. Slide the Notifications panel open, and then tap > Personalize.

2. On the Display tab, tap Lock screen style.

3. Slide your finger left or right to choose a lock screen style.

4. Tap the lock screen style to see a preview. If you want to further customize it,
tap Settings.

5. Tap Apply.

The shortcuts on the lock screen are the same apps as the ones on your Home
screen's launch bar. To change them, you'll have to replace the apps on the launch
bar.

Hiding missed calls and messages on the lock screen

You'll see missed calls and messages on the lock screen. Want these hidden instead?

1. Slide the Notifications panel open, and then tap > Security.

2. Clear the Phone notification preview and Message notification preview options.

Securing HTC J with a personal touch

Make unlocking your phone as easy as looking at it. Protect your personal information
and prevent others from using HTC J without your permission by setting up face
unlock.

1. Slide the Notifications panel open, and then tap > Security.

2. Tap Screen lock > Face Unlock.

3. Tap Set it up and follow the onscreen instructions.

55 Personalizing

4. Choose a backup lock to use in case the phone doesn't recognize you.

5. Tap Lock phone after, then specify the idle time before the screen is locked.

You can also tap Improve face matching on the Security screen to train HTC J to
recognize your face in different situations, such as when you're wearing glasses or
sporting a beard.

You'll be asked to unlock the screen every time HTC J is turned on or when it’s idle for
a certain period of time.

To further improve security, select Liveness check on the Security screen. You'll be
asked to blink to unlock the screen.

56 Phone calls

Phone calls

Making a call with Smart dial

You can either dial a number directly, or use Smart dial to quickly place a call. Smart
dial searches and calls a stored/synced contact or a number from your call history.

1. On the Home screen, tap

2. Enter the phone number or first few letters of the contact’s name.

3. From the list, tap a contact to call.

To check other phone numbers associated with the contact, tap beside the
contact name.

4. To hang up, tap End Call.

.

Changing the Phone dialer layout

Switch between the Smart dial keypad to find contacts with just a few taps and a full
screen keypad that gives you more room to enter phone numbers.

1. On the Home screen, tap .

2. Tap > Full screen keypad or Smart dial keypad.

Returning a missed call

You'll see the missed call icon in the status bar when you miss a call.

1. Slide the Notifications panel open to check who the caller is.

2. To return the call, spread your two fingers on the missed call notification to

expand it, and then tap Call back.

If you have multiple missed calls, tap the missed calls notification to open the Call
History screen.

57 Phone calls

Using Speed dial

Use Speed dial to call a phone number with a single tap. For example, if you assign a
contact’s number to the number 2 key, you can just press and hold 2 to dial the
number.

The number 1 key is generally reserved for your voicemail. Press and hold this key
to call voicemail and retrieve your voicemail messages.

Assigning a speed dial key

1. On the Home screen, tap .

2. Press and hold an unassigned number, and then tap Yes.

You can also tap > Speed dial > .

3. Select a contact from the list.

4. On the Speed dial screen, choose the phone number of the contact to use, and a

speed dial key to assign.

5. Tap Save.

Calling a phone number in a text message

1. Tap the phone number within the message.

2. Tap Call.

To call the message sender, tap the received message, and then tap Call on the
options menu.

Calling a phone number in an email

1. Tap the phone number in the email body.

2. Tap Call.

Calling a phone number in a Calendar event

1. Open an event in Calendar.

2. On the Event details screen, tap the phone number.

3. Tap Call.

4. When the call is received, tap

call ID or meeting PIN code on the Phone dialer screen.

to see event details such as the conference

58 Phone calls

Making an emergency call

In some regions, you can make emergency calls from HTC J even if you don’t have a
UIM or SIM card installed or your card has been blocked.

If you don't have a network signal, you won't be able to make an emergency call.

1. On the Home screen, tap .

2. Dial the emergency number for your locale, and then tap Call.

Receiving calls

When you receive a phone call from a contact, the Incoming call screen appears.

You can use the polite ringer and pocket mode features for receiving calls.

Answering a call

Do one of the following:

§ If the display is locked when you get a call, drag to the Lock screen ring.

§ If the display is on when you get a call, tap Answer.

Rejecting a call

Do one of the following:

§ If the display is locked when you get a call, drag to the Lock screen ring.

§ If the display is on when you get a call, tap Decline.

After declining a call, you can send a text message to the caller or create a task for
returning the call.

You can also press the POWER button twice to reject a call.

Muting the ringing sound without rejecting the call

Do one of the following:

§ Press the VOLUME DOWN or VOLUME UP button.

§ Press the POWER button.

§ Place HTC J face down on a level surface.

If HTC J is already facing down, it will still ring when there are subsequent incoming
calls.

59 Phone calls

Look who's calling

Every time you make a call or your friend gives you a ring, you get to see your friend’s
latest social network status update right on the call screen. You’ll also see a birthday
reminder if your friend’s birthday (stored on your phone or online account) will
happen in a few days.

Viewing a task reminder while on a call

Did you promise to babysit for a friend this weekend? If you associate a task to a
contact, you'll see a task reminder on the call screen when you're on a call with that
friend.

What can I do during a call?

When a call is in progress, you can turn the speakerphone on, place the call on hold,
and more.

Putting a call on hold (GSM only)

To put the call on hold, tap (or tap > Hold). The status bar then displays the hold
call icon .

To resume the call, tap (or tap > Unhold).

60 Phone calls

Switching between calls

If you’re already in a call and you accept another call, you can switch between the two
calls.

1. When you receive another call, tap Answer to accept the second call and put

the first call on hold.

2. To switch between the calls, tap the person you want to talk to on the screen.

Turning the speakerphone on during a call

To decrease potential damage to your hearing, do not hold HTC J to your ear when
the speakerphone is on.

Do one of the following:

§ Flip HTC J over during a call (be sure that Flip for speaker is selected in Sound

settings).

§ On the call screen, tap .

The speakerphone icon appears in the status bar when the speakerphone is on.

To turn the speakerphone off, just flip HTC J over again, facing it up. Or tap again.

Muting the microphone during a call

On the call screen, tap to toggle between turning the microphone on or off. When
the microphone is turned off, the mute icon appears in the status bar.

Ending a call

Do one of the following to end the call:

§ On the call screen, tap End Call.

§ Slide the Notifications panel open, then tap .

If the phone number of the person who called is not in your contacts list, you can
choose to save the number to your contacts list after you hang up.

61 Phone calls

Setting up a three-way call (CDMA)

Three-way calling with your friends, family, or co-workers is easy. Make the first call,
and then dial another number to add it to the call.

Make sure you have three-way call service enabled by your mobile operator.

1. Make a call to the first participant.

2. When connected, tap > Add call, and then dial the number of the second

participant. The first participant is put on hold when you dial the second
participant.

3. When connected to the second participant, tap .

To end the call, tap End call.

Setting up a conference call (GSM)

Conference calling with your friends, family, or co-workers is easy. Make the first call
(or accept a call), and then simply dial each subsequent call to add it to the
conference.

Make sure your UIM or SIM card is enabled with conference calling service. Contact
your mobile operator for details.

1. Make a call to the first conference call participant.

2. When connected, tap > Add call, and then dial the number of the second

participant. The first participant is put on hold.

3. When connected to the second participant, tap .

4. To add another participant, tap , and then dial the number of the contact.

5. When connected, tap to add the participant to the conference call.

6. To talk to a person in the conference call in private, tap and then select
Private call.

To end the call with a participant, tap and then tap Finish this call.

To end the conference call, tap End Call.

62 Phone calls

Call history

Use Call History to check missed calls, your dialed numbers, and received calls.

Checking calls in the Call History

1. On the Home screen, tap .

2. Tap the Call History tab.

3. On the Call History screen, you can:

§ Tap a name or number in the list to call.

§ Press and hold a name or number in the list to display the options menu.

§ Tap to check only the call history of a particular contact.

§ Tap to display just a particular type of call such as missed calls or

outgoing calls.

Adding a new phone number to your contacts from Call History

1. On the Call History screen, press and hold the phone number, and then tap Save
to People.

2. Choose whether to create a new contact or save the number to an existing

contact.

Clearing the Call History list

On the Call History screen, do one of the following:

Remove one name or
number

Clear the entire list Tap > Remove call history. On the Delete from call history

Press and hold the name or number, and then tap Delete
from call history.

screen, tap > Select all, and then tap Delete.

Blocking a caller

When you block a phone number or a contact, all calls from the phone number or
contact will be declined automatically.

1. On the Home screen, tap .

2. Tap the Call History tab.

3. Press and hold the contact or phone number you want to block, and then tap
Block contact.

You can always remove a caller from your blocked list. On the Call History screen,
tap > Blocked contacts. Press and hold a contact, and then tap Unblock contact.

63 Phone calls

Home dialing

When you're on a trip abroad, it's easy to dial friends and family from home.

Your home country code is automatically added when you call your contacts while
roaming. But when manually entering a phone number to call, you need to enter a plus
(+) sign and country code before the number.

Changing the default country code for Home dialing

1. Slide the Notifications panel open, and then tap > Call.

2. Tap Home dialing settings.

3. Select a country, and then tap OK.

Turning off Home dialing

If you prefer to manually enter complete phone numbers to call while roaming, you
can turn off Home dialing.

1. Slide the Notifications panel open, and then tap > Call.

2. Under Other settings, clear the Home dialing check button.

Call settings

You can change your voicemail number and other call settings.

Contact your mobile operator if you're not certain how to change call settings.

Slide the Notifications panel open, and then tap > Call.

64 Messages

Messages

About the Messages app

Keep in touch with important people in your life. Use the Messages app to compose
and send text and multimedia messages. Your sent and received messages are neatly
grouped into conversations, by contact name or phone number. You can also keep
private messages in the secure box or move unwanted messages to the block box.

Sending a text message (SMS)

1. From the Home screen, tap > Messages.

2. Tap .

3. Enter a contact name or mobile number in the To field.

Sending the message to a group of friends? Tap , and then select the contacts to
whom you want to send the message.

4. Tap the box that says Add text, and then enter your message.

5. Tap Send, or press to save the message as a draft.

§ There is a limit on the number of characters for a single text message (displayed

above the Send button). If you exceed the limit, your text message will be
delivered as one but will be billed as more than one message.

§ Your text message automatically becomes a multimedia message if you enter an
email address as the recipient, add a message subject, attach an item, or compose
a very long message.

65 Messages

Sending a multimedia message (MMS)

1. From the Home screen, tap > Messages.

2. Tap

3. Enter a contact name, mobile number, or email address in the To field.

Sending the message to a group of friends? Tap , and then select the contacts to
whom you want to send the message.

4. To add a subject line, tap > Add subject.

5. Tap the box that says Add text, and then enter your message.

6. Tap , and then choose an attachment type.

7. Select or browse for the item to attach.

8. After adding an attachment, tap to see options for replacing, viewing or

removing your attachment.

9. Tap Send, or press to save the message as a draft.

.

Creating a slideshow

1. After you've added either a photo, video, or audio in the multimedia message
you’re composing, tap > Slide.

2. Choose where you want to insert the next slide.

3. Right after adding a slide, do one of the following:

§ Tap , and then choose to add a photo or a video.

§ Tap > Audio to add music or a voice recording to a slide.

§ Tap Add text, and then enter your caption.

§ Tap

4. Tap > Preview. Tap once on the preview screen to see playback controls.

If you don't see Preview, scroll down the menu.

5. When finished, tap Send, or press to save the message as a draft.

to see options for replacing, viewing or removing your attachment.

Can't find your contacts' email addresses in Messages?

1. If only phone numbers are showing up when you're entering a contact

name, tap .

2. Tap > Show Email.

To always show email addresses, tap on the Messages screen, and then tap
Settings > General > Show email address.

66 Messages

Resuming a draft message

1. On the Messages screen, tap > Drafts.

2. Tap the message and then resume editing it.

3. Tap Send.

Checking your messages

Depending on your notification settings, HTC J plays a sound, vibrates, or displays the
message briefly in the status bar when you receive a new message. A new message
icon is also displayed in the status bar.

To open and read the message, you can:

§ Open the Notifications panel, and then tap the new message notification.

§ Go to the Messages app and open the message.

Viewing and saving an attachment from a multimedia message

§ If there’s a media attachment such as a photo or video in a received message,
tap it to view the content.

§ To save the attachment, tap the multimedia message, and then choose to save
from the options menu.

§ If the attachment is a contact (vCard), tap it to view the contact information,
then tap Save to add to your contacts.

§ If the attachment is an appointment or event (vCalendar), tap it to choose the
calendar where to save it, and then tap Import.

If you are concerned about the size of your data downloads, you can choose to
check the size and subject first before you download a multimedia message. On the
Messages screen, tap > Settings > Multimedia messages (MMS). Clear the Auto-

retrieve option.

Saving a text message in the Tasks app

Save a text message in your Tasks list so you can remind yourself when to reply.

1. On the Messages screen, tap a contact (or phone number) to display the

exchange of messages with that contact.

2. Tap the message you want to save, and then tap Save as task.

3. Enter other details or change the task title.

4. Tap Save.

67 Messages

Moving messages to the secure box

Move private messages to the secure box. You will need to enter a password to read
these messages.

1. On the Messages screen, tap a contact (or phone number) to display the

exchange of messages with that contact.

2. Tap > Move to secure box.

3. Select the messages, and then tap Move.

To move all the messages from a contact, on the Messages screen, press and hold
the contact and tap Move to secure box.

§ To read messages in the secure box, on the Messages screen, tap > Secure. If
it is your first time to use the secure box, set a password.

§ To remove messages or contacts from the secure box, press and hold the
contact (or phone number) and tap Move to general box.

Blocking unwanted messages

Declutter your Messages screen by moving spam messages from contacts to the
block box. If you have blocked a contact, that contact's messages will also be in the
block box.

On the Messages screen, press and hold a contact (or phone number) and tap Block
contact.

To block multiple contacts, tap > Move to block box, select the contacts, and tap
Move.

When the contact sends you messages, you will not see them in the Messages screen
or receive notifications and calls. To completely discard future messages from blocked
contacts, unselect Save block message in the Messages settings.

§ To read messages in the block box, on the Messages screen, tap > Block.

§ To remove messages or contacts from the block box, press and hold the

contact (or phone number) and tap Unblock.

Replying to a message

1. On the Messages screen, tap a contact (or phone number) to display the

exchange of messages with that contact.

2. Tap the box that says Add text, and then enter your message.

3. Tap Send.

68 Messages

Replying to a contact's other phone number

When a contact has multiple phone numbers stored on HTC J, you’ll see the particular
phone number used below the contact's name.

Keep in mind that your response will be sent to the phone number of the latest
message you’ve received from this contact.

1. On the Messages screen, tap a contact (or phone number) to display the

exchange of messages with that contact.

2. Tap , and then select another phone number of this contact.

3. Tap the box that says Add text, then enter your reply message.

4. Tap Send.

Forwarding a message

1. On the Messages screen, tap a contact (or phone number) to view the exchange

of messages with that contact.

2. Tap a message, and then tap Forward.

3. In the To field, fill in one or more recipients.

4. Tap Send.

69 Messages

WAP push messages

WAP push messages contain a web link. Often, the link will be to download a file that
you have requested from a service provider.

When you receive a WAP push message, a notification icon is displayed in the
status bar.

Opening and reading a new WAP push message

1. Open the Notifications panel, and then tap the push message notification.

2. Tap Visit website.

Viewing all your WAP push messages

1. From the Home screen, tap > Messages.

2. Tap > Push messages.

You can only see this option if you've previously received WAP push messages.

Managing message conversations

Locking a message

You can lock a message so that it will not be deleted even if you delete the other
messages in the conversation.

1. On the Messages screen, tap a contact (or phone number) to display the

exchange of messages with that contact.

2. Tap the message that you want to lock.

3. Tap Lock message on the options menu. A lock icon is displayed.

Copying a text message to your UIM or SIM card

1. On the Messages screen, tap a contact (or phone number) to display the

exchange of messages with that contact.

2. Tap the message, and then tap Copy to UIM/SIM. Text messages that are saved

to either card will have the icon.

Deleting a single message

1. On the Messages screen, tap a contact (or phone number) to display the

exchange of messages with that contact.

2. Tap the message that you want to delete.

70 Messages

3. If the message is locked, tap Unlock message on the options menu, and then tap

the message to display the options menu again.

4. Tap Delete message, and then tap OK.

Deleting several messages within a conversation

1. On the Messages screen, tap a contact (or phone number) to display the

exchange of messages with that contact.

2. Tap > Delete messages.

3. Tap Delete by selection or Delete by phone number (if the contact used

multiple phone numbers throughout the conversation).

In the Messages settings, tap General > Delete old messages to auto delete old
messages per conversation.

Deleting a conversation

1. On the Messages screen, press and hold a contact (or phone number) whose
messages you want to delete, and then tap Delete.

2. Tap OK to delete the entire thread.

Any locked messages in the conversation thread will not be deleted unless you
select the Delete locked messages option.

Deleting several conversations

1. On the Messages screen, tap > Delete threads.

2. Select the conversation threads you want to delete.

3. Tap Delete. Any locked messages will not be deleted.

Backing up your text messages

1. From the Home screen, tap

2. Tap > Back up/Restore SMS > Back up > Back up SMS.

3. Enter a name for your backup file, and then tap OK.

> Messages.

71 Messages

Backing up text messages by email

You need to set up your email account in the Mail app.

1. On the Messages screen, tap > Back up/Restore SMS.

2. Tap Back up > Back up SMS via mail.

The back up file is attached to an email.

3. Enter your email address.

4. Compose your email message, and then tap Send.

To restore your text messages to HTC J, open the email message with the backup file
attachment from the Mail app. Tap the attachment to download it first, and then tap it
again to open the backup file to import.

Restoring text messages

You can only restore text messages that were exported using the Back up SMS
feature.

1. From the Home screen, tap > Messages.

2. Tap > Back up/Restore SMS > Restore.

3. Choose how you want to restore the messages, and tap Next.

4. Tap the backup file to import.

5. Tap OK.

Setting message options

Access and change the settings of the Messages app. You can personalize it by
changing the background or the color of the message bubbles or by adding signature
to your messages. You can also edit messaging options, and more.

On the Messages screen, tap

Personalizing the Messages screen

Customize the background of the Messages screen or change the color of the
message bubbles.

> Settings.

1. On the Messages screen, tap > Settings > General.

2. Under Personalize, customize the appearance of the screen:

§ Tap Background, and choose between a photo from the Gallery or an HTC

stock background.

§ Tap Colors, and choose a color scheme for the message bubble.

72 Search and Web browser

Search and Web browser

Searching HTC J and the Web

You can search for information on HTC J and on the Web by using Google Search.
Start your search by entering a keyword or by using Google Voice Search™.

Some apps, such as People or Mail, have their own search function, which you can
use to search only within those apps.

Performing searches on the Web and HTC J

1. From the Home screen, tap .

If you can't find the Google search bar on your Home screen, tap

2. In the search box, enter what you want to search for. As you type, matching

items on HTC J and suggestions from Google web search are shown.

3. If what you’re searching for is in the list of suggestions, tap the item to open it in

its compatible app.

> Google.

Searching the Web with your voice

Use Google Voice Search to find information on the Web just by speaking to HTC J.

1. From the Home screen, tap > Voice Search.

If the Google search bar is available on the Home screen, you can also tap

2. Say what you want to search for. After speaking, matching items from Google

web search are shown.

3. If what you’re searching for is in the list, tap the item to open it in its compatible
app. Otherwise, tap Retry to search again.

.

73 Search and Web browser

Setting search options

1. From the Home screen, tap .

If you can't find the Google search bar on your Home screen, tap > Google.

2. Press to hide the keyboard, and then tap > Settings to set the following

options:

§ Voice. Set the Google Voice Search language, speech output, and more.

§ Phone search. Select the apps on HTC J which you want included when

doing a search.

§ Privacy and accounts. Manage your location history, enable recent web

searches to show, or clear your search history.

Getting instant information with Google Now

Do you want to know the weather or your morning commute time before you start
your day? Google Now delivers quick and up-to-date information that matters to you
—all without the search.

Depending on your location, time of day, and previous Google searches, Google Now
displays information cards that include:

§ The day's weather and the weather forecast for upcoming days.

§ The traffic conditions on your way to work or your commute back home.

§ The directions and travel time to your next appointment.

§ The next train or bus arriving at your platform or bus stop.

§ Your favorite team's score and standings while you enjoy the game.

74 Search and Web browser

Setting up Google Now

Before setting up Google Now:

§ Make sure that you're signed in to your Google account.

§ Turn location services on and make sure that you have an Internet connection.

1. From the Home screen, tap .

If you can't find the Google search bar on your Home screen, tap > Google.

2.

The subsequent screens show examples of Google Now information cards. Tap

Next until you reach the Get Google Now! screen.

3. Tap Yes, I'm in. Google Now information cards will start to appear on the

Google search screen.

More information cards will appear on the Google search screen as you use HTC J to
search the Web, create appointments, and more.

Changing card settings

You can easily customize the settings of Google Now cards to suit your information
needs. For example, you can change your home and work addresses in the Traffic
card or choose which time of the day the Weather card appears. You can also keep a
card from appearing on the Google search screen.

1. From the Home screen, tap .

If you can't find the Google search bar on your Home screen, tap

2. Scroll to the bottom of the screen, and then tap > Settings > Google Now.

3. Tap the information card you want to customize.

4. Tap a card setting, and then change it to your preference.

To hide the card, tap the On/Off switch next to the card name.

5. Press to save your changes and return to the previous screen.

> Google.

75 Search and Web browser

Refreshing Google Now

Refresh Google Now to show relevant cards for information that you've just added on
HTC J, like an upcoming appointment in Calendar.

1. From the Home screen, tap .

If you can't find the Google search bar on your Home screen, tap > Google.

2. Scroll to the bottom of the screen, and then tap > Refresh.

Turning off Google Now

1. From the Home screen, tap .

If you can't find the Google search bar on your Home screen, tap

2.

Scroll to the bottom of the screen, and then tap > Settings > Google Now.

3. Tap the On/Off switch next to Google Now.

> Google.

Browsing the Web

1. From the Home screen, tap > Internet.

2. If the webpage is in fullscreen mode, flick down the screen to quickly show the

URL box and other options.

To always show the URL box on the screen, tap > Settings > General, and make
sure that Fullscreen is unselected.

3. Tap the URL box on top of the screen.

4. Enter your search keywords or a webpage address.

5. On the webpage, you can:

§ Tap a link to open it, or press and hold a link to see more options.

§ Tap an email address to send a message to the email address.

Switching to Read mode

Want to read an article or blog without distractions? Read mode removes menus,
banners, and backgrounds from a webpage.

While viewing a webpage, tap (when it's available) to switch to Read mode. You
will stay in Read mode even if you browse other pages that are in the website.

To turn Read mode off, tap

76 Search and Web browser

Viewing the full version of a website

While viewing a webpage, tap > View desktop site.

Opening or switching between browser tabs

Open multiple browser tabs to make it easier for you to switch from one website to
another.

1. While viewing a webpage, tap Tabs.

2. Do one of the following:

§ To open a new tab, tap New tab.

§ To switch to another browser tab, slide your finger until the webpage you

want to view appears. Tap a webpage to display it in full screen.

Tap

to close a webpage.

Viewing previously visited pages

You can go back to the pages you've previously visited without opening another tab
or going through your history.

While viewing a webpage, tap > Back or Forward.

77 Search and Web browser

Private browsing

You can use incognito tabs to browse the Web with more privacy. Browser cookies
are deleted and not shared when you close all incognito tabs. Pages you view in
incognito also won't appear in your browser history except for files you download.

From the browser screen, tap Tabs > New incognito tab.

Adding and managing your bookmarks

Bookmarking a webpage

Bookmark a webpage in a normal browser screen (not when you're using an
incognito tab).

1. While viewing a webpage, tap > Add to > Bookmarks.

2. Edit the bookmark name if needed.

3. Under Account, choose Local if you want to save the bookmark on your phone,

or choose an account to sync it with.

4. Under Add to, you can choose to save the bookmark to a new folder.

5. Tap

6. Tap Done.

You can also add a bookmark to the Home screen. While viewing a webpage, tap
> Add to > Home screen.

> , and assign a folder name.

Opening a bookmark

1. While viewing a webpage, tap Bookmarks.

2. On the Bookmarks tab, navigate to the bookmark you want to open, and then

tap it.

Not seeing your bookmark? Tap and select All bookmarks to display bookmarks
stored on HTC J and those synced with an online account.

Editing a bookmark

1. While viewing a webpage, tap Bookmarks.

2. On the Bookmarks tab, tap > Edit.

3. Tap at the right of the bookmark you want to edit.

4. Enter your changes, and then tap Done.

78 Search and Web browser

Syncing your bookmarks with Google Chrome

Create bookmarks from your computer's Google Chrome™ browser and sync them on
HTC J. For more information about Google Chrome, visit http://support.google.com/

chrome.

§ Using your Google Chrome desktop browser, you need to sign in to your Google
Account and set up Google Chrome sync.

§ Be sure that you are logged in to your Google Account every time you save
Google Chrome bookmarks on your computer.

1. Slide the Notifications panel open, and then tap > Accounts & sync.

2. Tap Google.

3. Tap your Google Account.

4. Select the Internet option.

Saving web content for later

Save webpages to read later, even without an Internet connection. Some video clips in
webpages can also be added to the Watch list so you can quickly find and watch
them during your free time.

Only webpages will be stored on HTC J. You need to connect to the Internet when
opening linked pages and video clips.

1. While viewing a webpage, tap > Add to.

2. Do one of the following:

§ To save the webpage to your list, tap Reading list.

§ Tap Watch list if the webpage contains one or more video clips, and then

select the videos to add to the Watch list.

Viewing items in your Reading list or Watch list

1. While viewing a webpage, tap Saved.

2. On the Saved tab, do any of the following:

§ Under Reading list, tap a thumbnail of the webpage you want to open.

§ Under Watch list, tap a thumbnail of the video clip you want to open.

§ Tap to see more options.

79 Search and Web browser

Viewing your browsing history

1. While viewing a webpage, tap > History.

You can also press and hold .

2. On the History tab, tap a time period to see a list of webpages you've visited.

Clearing your browsing history

1. While viewing a webpage, tap > History.

2. On the History tab, tap > Clear all.

Viewing a page that you often visit

1. While viewing a webpage, tap > History.

2. On the Most visited tab, navigate to the page you want to view, and then tap

the page.

Clearing the list of most visited pages

1. While viewing a webpage, tap > History.

2. On the Most visited tab, tap > Clear all.

Downloading files and apps

You can download files and apps directly from your favorite websites.

Files and apps downloaded from the Web can be from unknown sources. To
protect HTC J and your personal data, we strongly recommend that you download
and open only the files you trust.

1. Open your web browser, then go to the website where you can download the

file you want.

2. Do any of the following:

§ Follow the website's download instructions for apps.

§ Press and hold an image or a web link, and then tap Save link.

Before you can install the downloaded app, you need to set HTC J to allow installation
of third-party apps in Settings > Security > Unknown sources.

Viewing your downloads

1. From the Home screen, tap > Downloads.

2. Tap the file to open it.

80 Search and Web browser

Setting browser options

Customize the web browser to suit your browsing style. Set display, privacy, and
security options when using the web browser.

From the browser screen, tap > Settings.

Setting your homepage

1. From the browser screen, tap > Settings.

2. Tap General > Set homepage.

3. Select the homepage you want to use.

81 Photos, videos, and music

Photos, videos, and music

Gallery

About the Gallery app

Reminisce on good times. Use Gallery to view all your photos and videos that are on
HTC J or your online albums.

You can:

§ View photos by event or location.

§ Add photo frames and apply effects.

§ Trim your videos.

§ Share to your social networks, photo sharing sites, and more.

§ View your photos and videos on a big screen TV.

Viewing photos and videos

1. From the Home screen, tap > Gallery.

2. Tap the location of your photo or video. If you want to view photos stored on
HTC J, tap My phone.

3. Browse to an album or a group of photos.

4. Tap a photo or video to view it in full screen.

Viewing photos and videos by event

View photos and videos based on when they were taken.

1. In Gallery, tap My phone.

2. Tap > Events. Photos and videos stored on HTC J are displayed according to

the time they were taken.

3. Tap a photo or video. All the photos and videos taken around that time are

displayed.

Viewing photos by location

Using the Map view, you can view photos according to location.

1. In Gallery, tap My phone.

2. Tap Map.

82 Photos, videos, and music

3. Pinch the screen or pan across the map until (location indicator) appears.

The location indicator shows how many photos are taken in that area.

Only photos with geo-tag info appear on the map.

4. Tap the location indicator. The photos taken in the same area are displayed.

Want to know where you took a particular photo? While viewing the photo in full
screen, tap anywhere on the screen, and then tap More > Show on map. (Show on

map is available when you've enabled Geo-tag photos in Camera.)

Starting a photo slideshow

1. In Gallery, tap My phone.

2. Go to the group of photos that you want to view.

3. Tap Play.

During the slideshow, tap the screen to show the controls. Tap

to set slideshow

preferences.

Watching a video

1. In the Gallery app's Album or Events view, go to the video that you want to

watch.

2. Tap the onscreen controls to control the video playback, adjust the volume,
capture an image during playback, and more.

Tap More > Select player to share the video on your home network.

Taking a photo while watching a video

While you're watching a video in Gallery, tap to capture a still shot.

83 Photos, videos, and music

Editing your photos and videos

Rotating a photo

1. In Gallery, tap My phone.

2. Browse to the photo that you want to edit.

3. Press and hold the photo, and then tap Edit > Rotate left or Rotate right.

Cropping a photo

1. In Gallery, tap My phone.

2. Browse to the photo that you want to edit.

3. Press and hold the photo, and then tap Edit > Crop. You’ll see a crop box

around the photo.

4. You can:

§ Drag the crop box over the part of the photo you want to crop.

§ Press and hold the edge of the crop box. When directional arrows appear,

drag your finger inward or outward to resize the crop box.

5. Tap Save.

The cropped photo is saved as a copy. The original photo remains unedited.

Adding photo effects

1. In Gallery, tap My phone.

2. Browse to the photo that you want to edit.

3. Press and hold the photo, and then tap Edit > Effects.

4. Tap an effect to apply to the photo.

5. Tap Save.

The enhanced photo is saved as a copy. The original photo remains unedited.

84 Photos, videos, and music

Adding custom photo effects

Are the existing photo effects not exactly what you are looking for? You can make
your own photo effects in Gallery.

You can only add effects to photos that are stored locally.

1. In Gallery, tap My phone.

2. Browse to the photo that you want to edit.

3. Press and hold the photo, and then tap Edit > Effects.

4. Tap > .

5. Tap a filter.

6. Drag the slider to get the effect you want.

7. You can do any of the following:

§ Add more than one filter to create a complex effect.

§ Rearrange filters to modify the effect. Press and hold the filter you want to

move. Then drag it to a new position.

§ Remove filters. Press and hold the filter you want to remove. Then drag it

to Remove.

§ Tap to add a frame to your photo.

8. Tap Done to apply the effects to your photo.

To save your custom effects for future use, tap Save Preset.

9. Tap Save.

Trimming a video

Remove unwanted scenes from a video you recorded on HTC J.

1. In the Gallery app's Album or Events view, go to the video that you want to edit.

2. Press and hold the video, and then tap Trim.

85 Photos, videos, and music

3. Drag the two trim sliders to the part where you want the video to begin and

end.

As you drag a slider, you'll see time markers and video frames. The one in the
middle is your start or end frame.

4. Tap to preview your video.

5. Tap Done.

The trimmed video is saved as a new file. The original video remains unedited.

Organizing your photos and videos

Moving a photo to another album

1. In Gallery, tap My phone.

2. Go to the album that has the photo you want to move.

3. Press and hold the photo.

4. Tap Move to and choose a destination album.

To copy a photo instead of moving it, press and hold a photo and tap Copy to.

Renaming an album

If you have created albums to organize photos, you can rename these albums.

1. In the Gallery app's Albums view, press and hold the album that you want to

rename.

2. Tap Rename.

Some albums, like Camera shots and All photos, cannot be renamed.

86 Photos, videos, and music

Viewing photos in your social networks

Right in the Gallery app, check what you and your friends have uploaded to your
social networks or photo sharing sites.

Log on to your accounts and add them in Gallery before you start viewing online
photos.

1. From the Home screen, tap > Gallery.

2. Tap a social network account or photo sharing site.

In social networks, to comment on a photo, press and hold a photo thumbnail and
then tap Add comment.

Sending your photos and videos

Send photos and videos to your computer or to another device via email, MMS, or
Bluetooth.

Sending photos or videos by email

You can send several photos, videos, or both in an email message. They are added as
file attachments in your email.

1. From the Home screen, tap > Gallery.

2. Tap My phone, and then go to the photo album or group of photos that you

want to share.

3. Tap Share, and then tap Gmail or Mail.

4. Select the photos or videos you want to share and then tap Next.

5. Compose your message and then tap (Gmail) or Send (Mail).

If you selected Mail and you have multiple email accounts, the default email
account will be used.

Sending a photo or video by MMS

1. From the Home screen, tap > Gallery.

2. Tap My phone, and then go to the photo album or group of photos that you

want to share.

3. Tap Share > Messages.

4. Tap the photo or video you want to send. The photo or video is automatically

added into the MMS message.

5. To add another photo or video to your slideshow attachment, tap and then
tap Picture or Video.

6. Compose your message and then tap Send.

87 Photos, videos, and music

Sending photos or videos using Bluetooth

Use Bluetooth to send photos and videos to another device or to your computer.

1. From the Home screen, tap > Gallery.

2. Tap My phone, and then go to the photo album or group of photos that you

want to share.

3. Tap Share > Bluetooth.

4. Select the photos or videos you want to share and then tap Next.

You’ll be asked to turn on Bluetooth and connect to the receiving Bluetooth device so
the files can be sent.

Sharing your photos and videos on the Web

Use the Gallery app to share photos and videos straight to your social networks. And
you can post videos on YouTube.

You can also share a photo or video right after you’ve captured it.

Sharing photos or videos on Facebook

Log in to your Facebook account before you upload photos or videos.

1. In Gallery, tap My phone.

2. Browse to the group of photos that you want to share.

3. Tap Share > Facebook.

4. Select the photo or video you want to share.

5. Add a status update, tag friends, indicate your location, or change privacy

settings.

6. Tap Post.

Sharing photos and videos on Flickr

Log in to your Flickr

®

account before you upload photos or videos.

1. In Gallery, tap My phone.

2. Browse to the group of photos that you want to share.

3. Tap Share > Flickr for HTC Sense.

4. Select the photos or videos you want to share and then tap Next.

88 Photos, videos, and music

5. Select which album to upload to and set privacy settings for the uploaded
photos or videos.

Tap Add tag and description to enter a caption on each photo or video or tag
friends on your photos. If you're sharing several photos or videos, slide to the left to
go to the next one. Remember to tap Save after you're done.

6. Tap Done.

Sharing photos on Picasa Web Albums

Sign in to your Google Account before you upload photos to Picasa™ Web Albums.

1.

In Gallery, tap My phone.

2. Browse to the group of photos that you want to share.

3. Tap Share > Picasa.

4. Select the photos you want to share and then tap Next.

5. Enter a caption for the photos you're uploading.

6. Select the online album where you want to upload the photos, or tap to

create a new album.

7. Tap Upload.

Sharing videos on YouTube

Sign in to your Google Account before you upload videos to YouTube.

1. In Gallery, tap My phone.

2. Browse to the group of photos and videos that you want to share.

3. Tap Share > YouTube.

4. Select the videos you want to share and then tap Next.

5. Tap the Google Account that you want to use, and select which data connection

to use to upload the videos.

6. Enter a title and description for the videos you're uploading.

7. Select a privacy option for the videos or tag them for easy searching.

8. Tap .

89 Photos, videos, and music

Music

About the Music app

The Music app is a central hub for your favorite music whether it is on HTC J or
streamed through a music service.

You can:

§ Browse music by artists, albums, playlists, or folders.

§ Quickly access recently played tracks on the main screen.

§ Add shortcuts to music services or music apps installed in HTC J.

§ Learn more about a song's lyrics and the artist.

Browsing music

1. From the Home screen, tap > Music.

2. You can:

§ Browse music stored on HTC J. Tap My phone > , and choose if you want

to browse by artists, album, or others.

§ Tap a music service to find songs or radio stations.

On the Music main screen, you can add shortcuts to other music services or music
apps installed in HTC J. Tap > Add app shortcut, then choose an app.

90 Photos, videos, and music

Making your music sound better

When you plug in your headset or connect HTC J to an external speaker, HTC J
automatically turns on the Beats Audio profile to give you an enhanced sound
experience. Songs and videos played through apps such as Music, Gallery, or others
sound richer and more authentic.

Beats by Dr. Dre branded headphones are not required to use the Beats Audio
profile. But, we recommend using them as they have a component that further
enhances the audio quality when paired with HTC J.

To turn the Beats Audio profile on or off, slide the Notifications panel open, tap ,
and then tap the Beats Audio On/Off switch.

Listening to music

Enjoy your favorite songs on HTC J using the Music app.

1. While browsing your music collection, tap a song to play it.

2. Tap the onscreen icons to control music playback, repeat songs, and more.

Press and drag your finger across the
progress bar to jump to any part of the song.

Show options for adding the song to a
playlist, sharing the song, and more.

Turn shuffle on or off. (Shuffle is off when
button is gray.)

Cycle through the repeat modes: repeat all
songs, repeat current song, and don’t repeat.

Finding music videos on YouTube

It's easy to find music videos of the song you’re listening to on YouTube. On the Now
playing screen, tap > Search > YouTube.

Updating album covers

1. On the Now playing screen, tap > Update album art.

2. Choose whether to automatically or manually update all album covers or update

just the current song on the Now playing screen.

91 Photos, videos, and music

Playing music from the Lock screen

When you’re listening to music and the screen turns off, press POWER to turn the
screen back on and control the music playback directly on the Lock screen.

You can also control music playback right from the Notifications panel.

Creating a playlist

Personalize your music experience by creating music playlists. Make a playlist
containing just your favorite songs or create one to match your mood for the day.
You can make as many playlists as you like.

1. From the Home screen, tap > Music > My phone.

2. Start playing a song that you want to add to a new playlist.

3. Tap > Add to playlist.

If there are no existing playlists, you will be prompted to enter a new playlist name.

4. On the Select playlist screen, tap .

5. Enter a playlist name.

6. Tap Save.

You can also add additional songs while creating a new playlist. Tap > Add songs
to add more songs.

92 Photos, videos, and music

Playing the songs in a playlist

1. From the Home screen, tap > Music > My phone.

2. Tap > Playlists.

3. Tap a playlist, and then tap the song you want to play first.

When you tap a song in the list to play it, the Now playing screen is updated with the
songs from your playlist.

Managing playlists

After creating a playlist, you can add more songs to it, rearrange their order, and
more.

1. From the Home screen, tap > Music > My phone.

2. Tap > Playlists, and then tap the playlist you want to edit.

3. Tap > Edit playlist.

Add songs 1. Tap > Add songs.

2. Tap to choose a category, and then browse for songs.

3. Select the songs you want to add to the playlist, and then
tap Add.

Rearrange songs Press and hold next to the song title you want to move,

and then drag it to its new position.

Delete songs Select the songs you want to remove from the playlist.
Change playlist

Type the new name of the playlist in the title text box.

name

4. Tap Save.

Deleting playlists

1. From the Home screen, tap > Music > My phone.

2. Tap > Playlists.

3. You can:

§ Press and hold the playlist you want to delete, and then tap Delete playlist.

§ Tap > Delete playlists to remove several playlists.

93 Photos, videos, and music

Adding a song to the queue

While playing a song, you can also browse other tracks stored on HTC J. Add a song
or an album to the queue so it plays when the current playlist has finished playing.

1. While a song is playing, browse for other tracks.

2. When you find the album, playlist, artist, or folder that you like, press and hold it,

and tap Add to queue.

To add a single track, browse for the song, and then tap > Add to queue.

Setting a song as a ringtone

Pick a song from your Music library and set it as your ringtone or as ringtone for a
favorite contact.

1. From the Home screen, tap > Music > My phone.

2. Find the song that you want to set as a ringtone.

3. Tap > Set as ringtone.

4. Tap Phone ringtone or Contact ringtone. If you select Contact ringtone, choose

the contacts you want to associate the ringtone with.

Trimming an MP3 ringtone

Use the Music app's ringtone trimmer if you want to set only a part of the song as
ringtone.

1. When you find the song that you want, tap > Set as ringtone > Trim the
ringtone.

2. Drag the trim sliders to the part where you want the ringtone to begin and

end.

For a more precise trimming, tap the left or right arrow buttons. Time markers
indicate where you are on the song.

3. When you're done trimming, tap Set as.

4. Choose whether to set your trimmed song as your Phone ringtone or Contact
ringtone.

You can see your new ringtone in the phone settings. Slide the Notifications panel
open, and then tap > Sound > Phone ringtone.

94 Photos, videos, and music

Sharing music using Bluetooth

Choose a song from the Music app’s library and use Bluetooth to send it to another
device or your computer.

1. From the Home screen, tap > Music > My phone.

2. Find the song you want to send.

3. Tap > Share > Share file > Bluetooth.

You’ll be asked to turn on Bluetooth on HTC J and connect to the receiving Bluetooth
device so the music can be sent.

Don't know what song they're playing?

SoundHound can find info about the song you're listening to.

1. On the Music main screen, tap SoundHound.

2. Sing or play a few lines of the song.

You can look up the lyrics, learn about the artist's tour dates, and more.

Movie Editor

Creating a new slideshow with Movie Editor

Want a novel way to share your photos and videos? Movie Editor lets you make short
theme-based slideshow movies complete with transitions and background music.

1. From the Home screen, tap > Movie Editor.

2. Tap , and then enter a title for your slideshow.

3. Tap Select a theme. Themes include slide transitions, the default theme music,

and motion background.

4. Tap the theme you want, and then tap Done.

5. Tap , select the photos and videos from Gallery, and then tap Next.

6. Edit your slideshow:

Insert items
between existing
photos and videos

Trim a video Tap an existing video, and then tap Trim. Drag the two

Tap an existing photo or video, and then tap Insert.
Select the items to add, and then tap Next. New items are
inserted before the item you tapped.

trim sliders to the part where you want the video to begin
and end, and then tap Done.

Reorder photos and
videos

Remove photos
and videos

Press and hold a photo or video and drag it to a new
position.

Tap the photo or video you want to remove, and then tap
Remove.

95 Photos, videos, and music

Change the theme Tap the theme name to choose another theme.
Preview the

slideshow
Change the

soundtrack

Movie Editor automatically saves your movies so you don't have to worry about
losing any changes you make.

7. Tap Save, and then choose a resolution.

You can share the slideshow from Gallery. Browse for the slideshow, and then tap
Share.

Tap to start viewing your slideshow.

Tap > > Choose music track, then and pick a song
stored on your phone.

If you have videos in your slideshow, you can balance the
volume levels of the audio in the videos with the
soundtrack. Simply drag the volume slider to the level
you want.

Wireless display

Sharing on a big screen

Share what you're viewing on HTC J onto a big screen TV.

§ If you have a home theater system that's DLNA® compliant, you can share your
photos, videos, movies, and music from HTC J to your TV through your home
Wi‑Fi network.

§ Don't have a DLNA setup at home? Don't worry. Just purchase the HTC Media
Link HD and hook it up to your HDMI TV. You can then wirelessly share what
you're viewing or listening on HTC J to your TV.

96 Photos, videos, and music

About HTC Media Link HD

You can plug in HTC Media Link HD to any TV with HDMI port, and use it to display
content wirelessly to your TV.

HTC Media Link HD is sold separately.

Easy to set up and use

With just a three-finger swipe, connect HTC J to HTC Media Link HD and share on the
big screen.

Multitask with dual-screen display

HTC Media Link HD gives you dual-screen display when you're:

§ Viewing a photo or video in Gallery

§ Playing music in the HTC Music app

§ Watching a trailer, purchased movie, or rented show in HTC Watch

While you're playing media on the big screen, you can multitask and do other things
such as take calls, browse the Web, or send email on HTC J.

Turns your TV into a digital photo frame

Use the TV screen saver feature to store up to 30 photos from HTC J on HTC Media
Link HD, and display them as a slideshow on your TV.

To find out more about setting up HTC Media Link HD and using it with HTC J, refer to
the HTC Media Link HD user guide.

Sharing your media on DLNA devices

If you'll be using a DLNA compliant TV or audio system, refer to its documentation
on how to connect it to your home network.

1. Connect HTC J to your home network via Wi‑Fi.

2. Open the Gallery, HTC Watch, or Music app.

3. Locate the media stored on HTC J that you want to share, and then tap it.

97 Photos, videos, and music

4. Do one of the following:

While viewing photos or
videos in Gallery

Tap the screen to show the controls, and then
tap More > Select player.

While playing music in Music Tap > Select player.
While playing a movie in HTC

Watch

Tap the screen to show the controls, and then
tap More > Select player.

5. Choose the device on your network where you want to play the media.

6. Once connected to the other device, tap the onscreen controls to control

playback, adjust the volume, and more.

For more information about DLNA, visit www.dlna.org.

98 Storage

Storage

Where apps, data, and files are stored

HTC J uses these storage types:

Apps and
data
storage

File
storage

USB
storage

Apps are installed to this storage, labeled as App storage in your phone
settings. It also stores data such as your text messages, contacts you
created or synchronized to your phone, account settings, and more.

This storage is managed and carefully guarded by your phone since it
contains your private information. When you connect your phone to
your computer, this storage is not accessible from your computer.

Storage contents will be erased when you do a factory reset. Make sure
to back up your data before starting a factory reset. Some apps allow
you to back up to your storage card, such as People.

This is another built-in storage, labeled either as Camera storage or
Phone storage in your phone settings. This is where you can store your
files.

When you connect your phone to your computer, this storage is
accessible and you can copy files between them.

When you plug in an external USB storage device (such as a USB flash
drive or an SD card reader), you can view photos and videos stored on
the device right from Gallery and play songs stored on the device in
Music. You can also open PDFs and edit Office documents.

You need a USB On-The-Go micro cable adapter to connect HTC J and a
USB storage device. HTC J supports USB storage devices (except
portable hard drives) up to 64 GB.

Storage
card

The default storage for your files may vary from app to app. Some apps allow you to
set the default storage.

You can store your files such as photos, music, and videos to this
removable storage.

When you connect your phone to your computer, this storage is
accessible and you can copy files between them.

99 Storage

Copying files to or from the phone storage

You can copy your music, photos, and other files to HTC J.

1. Connect HTC J to the computer using the supplied USB cable. You'll see options

for viewing or importing files on the computer screen.

2. Choose to view files.

3. Copy the files from your computer to HTC J, or vice versa.

4. After copying the files, disconnect HTC J from the computer.

You can use apps that access the phone storage (such as Camera or Gallery) even if it
is connected to a computer.

Making more storage space

As you use HTC J, you will accumulate data and fill its storage capacity over time.
Here are some tips on how to increase storage space.

Store files in Dropbox

Photos, email attachments, and other documents can be stored in Dropbox and
accessed anywhere you are. You can set the Camera app to automatically upload
photos to Dropbox.

Manage photos and videos

§ Set the Camera app to automatically upload to a photo-sharing site or online
storage. When you reach the storage limit, just delete all your photos. You can
retrieve them from the photo-sharing site or online storage when needed.

§ After taking continuous camera shots, keep only the best shot and discard the
rest.

§ After editing a photo or trimming a video, the original file is kept. You can delete
original files or move them to online storage or to your computer.

§ If you are not printing large photos or are only sending videos through MMS, use
a lower resolution. High-resolution media takes up more space. In Camera
settings, tap Aspect and Resolution for photos or tap Video Quality for videos.

Back up apps data

Keep only the most recent data from apps on HTC J. You can back up calendars,
contacts, and bookmarks or export text messages, and personal dictionaries. For
details, see Backing up files, data, and settings on page 103.

Run the storage wizard

For general clean-up purposes, use the storage wizard to uninstall apps, change
download settings for email and text messages, and delete apps data and other files.

100 Storage

Disable some apps

Apps, even if not used often, may be running in the background and downloading
data into the phone storage. If the app cannot be removed, you can disable it. In
Settings, tap Apps > All, and select the app that you want to disable. Tap Disable.

Freeing up space with the storage wizard

Easily free up space in the phone storage by cleaning the application cache, moving
or uninstalling apps, and changing Mail and Messages settings so that only the most
recent data are kept.

You cannot uninstall some preinstalled apps.

1.

Slide the Notifications panel open, and then tap

2. Tap Storage, and under Phone storage tap Make more space.

3. Follow the instructions on the screen.

.

Encrypting data on HTC J

You can encrypt data such as your online accounts, settings, music files and other
media. After encryption, you will need to enter the screen lock PIN or password to
turn on your phone and access the data.

§ Set a lock screen PIN or password before encrypting your data.

§ Fully charge the battery and keep HTC J connected to the power adapter during

encryption. The encryption process takes about an hour.

§ You cannot undo encryption. If you want to return to an unencrypted phone, you
must perform a factory reset.

1. Slide the Notifications panel open, and then tap .

2. Tap Storage.

3. Select the encryption option for the type of storage you want to encrypt.

4. Tap OK.

5. Enter the lock screen PIN or password, and tap Next.

6. Tap OK.

Encryption starts and the progress is displayed. The phone may restart a few times.

When the encryption process is complete, enter your PIN or password.
