HTC Xda orbit 2 User Manual

www.htc.com

Xda orbit 2

User Guide

Please Read Before Proceeding

THE BATTERY IS NOT CHARGED WHEN YOU TAKE IT OUT OF THE BOX.

DO NOT REMOVE THE BATTERY PACK WHEN THE DEVICE IS CHARGING.

YOUR WARRANTY IS INVALIDATED IF YOU OPEN OR TAMPER WITH THE DEVICE’S OUTER CASING.

PRIVACY RESTRICTIONS

Some countries require full disclosure of recorded telephone conversations, and stipulate that you must inform the person with whom you are speaking that the conversation is being recorded. Always obey the relevant laws and regulations of your country when using the recording feature of your PDA Phone.

INTELLECTUAL PROPERTY RIGHT INFORMATION

, , ExtUSB, HTC Touch, Touch Cruise, TouchFLO, and HTC

Care are trademarks and/or service marks of High Tech Computer Corp.

Microsoft, MS-DOS, Windows, Windows NT, Windows Server, Windows Mobile, Windows XP, Windows Vista, ActiveSync, Windows Mobile Device Center, Internet Explorer, MSN, Hotmail, Windows Live, Outlook, Excel, PowerPoint, Word, and Windows Media are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries.

Bluetooth and the Bluetooth logo are trademarks owned by Bluetooth SIG, Inc.

Wi-Fi is a registered trademark of the Wireless Fidelity Alliance, Inc.

microSD is a trademark of SD Card Association.

Java, J2ME and all other Java-based marks are trademarks or registered trademarks of Sun Microsystems, Inc. in the United States and other countries.

Macromedia, Flash, Macromedia Flash, Macromedia Flash Lite and Reader are trademarks and/or registered trademarks of Macromedia Netherlands, B.V. or Adobe Systems Incorporated.

Sprite Backup is a trademark or service mark of Sprite Software.

ArcSoft MMS Composer™ Copyright © 2003-2007, ArcSoft, Inc. and its licensors. All Rights Reserved. ArcSoft and the ArcSoft logo are registered trademarks of ArcSoft, Inc. in the United States and/or other countries.

All other company, product and service names mentioned herein are trademarks, registered trademarks or service marks of their respective owners.

HTC shall not be liable for technical or editorial errors or omissions contained herein, nor for incidental or consequential damages resulting from furnishing this material. The information is provided “as is” without warranty of any kind and is subject to change without notice. HTC also reserves the right to revise the content of this document at any time without prior notice.

No part of this document may be reproduced or transmitted in any form or by any means, electronic or mechanical, including photocopying, recording or storing in a retrieval system, or translated into any language in any form without prior written permission of HTC.

Disclaimers

THE WEATHER INFORMATION, DATA AND DOCUMENTATION ARE PROVIDED “AS IS” AND WITHOUT WARRANTY OR TECHNICAL SUPPORT OF ANY KIND FROM HTC. TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, HTC AND ITS AFFILIATES expressly disclaim any and all representations and warranties, express or implied, arising by law or otherwise, regarding the Weather Information, Data, Documentation, or any other Products and services, including without limitation any express or implied warranty of merchantability, express or implied warranty of fitness for a particular purpose, non-infringement, quality, accuracy, completeness, effectiveness, reliability, usefulness, that the Weather Information, Data and/or Documentation will be error-free, or implied warranties arising from course of dealing or course of performance.

Without limiting the foregoing, it is further understood that HTC and its Providers are not responsible for Your use or misuse of the Weather Information, Data and/or Documentation or the results from such use. HTC and its Providers make no express or implied warranties, guarantees or affirmations that weather information will occur or has occurred as the reports, forecasts, data, or information state, represent or depict and it shall have no responsibility or liability whatsoever to any person or entity, parties and non-parties alike, for any inconsistency, inaccuracy, or omission for weather or events predicted or depicted, reported, occurring or occurred. WITHOUT LIMITING THE GENERALITY OF THE FOREGOING, YOU ACKNOWLEDGE THAT THE WEATHER INFORMATION, DATA AND/OR DOCUMENTATION MAY INCLUDE INACCURACIES AND YOU WILL USE COMMON SENSE AND FOLLOW STANDARD SAFETY PRECAUTIONS IN CONNECTION WITH THE USE OF THE WEATHER INFORMATION, DATA OR DOCUMENTATION.

Limitation of Damages

TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO EVENT SHALL HTC OR ITS PROVIDERS BE LIABLE TO USER OR ANY THIRD PARTY FOR ANY INDIRECT, SPECIAL, CONSEQUENTIAL, INCIDENTAL OR PUNITIVE DAMAGES OF ANY KIND, IN CONTRACT OR TORT, INCLUDING, BUT NOT LIMITED TO, INJURY, LOSS OF REVENUE, LOSS OF GOODWILL, LOSS OF BUSINESS OPPORTUNITY, LOSS OF DATA, AND/OR LOSS OF PROFITS ARISING OUT OF, OR RELATED TO, IN ANY MANNER, OR THE DELIVERY, PERFORMANCE OR NONPERFORMANCE OF OBLIGATIONS, OR USE OF THE WEATHER INFORMATION, DATA OR DOCUMENTATION HEREUNDER REGARDLESS OF THE FORESEEABILITY THEREOF.

Important Health Information and Safety Precautions

When using this product, the safety precautions below must be taken to avoid possible legal liabilities and damages.

Retain and follow all product safety and operating instructions. Observe all warnings in the operating instructions on the product.

To reduce the risk of bodily injury, electric shock, fire, and damage to the equipment, observe the following precautions.

ELECTRICAL SAFETY

This product is intended for use when supplied with power from the designated battery or power supply unit. Other usage may be dangerous and will invalidate any approval given to this product.

SAFETY PRECAUTIONS FOR PROPER GROUNDING INSTALLATION

CAUTION: Connecting to an improperly grounded equipment can result in

an electric shock to your device.

This product is equipped with a USB cable for connecting the product to a desktop or notebook computer. Be sure your computer is properly grounded (earthed) before connecting the product to the computer. The power supply cord of a desktop or notebook computer has an equipmentgrounding conductor and a grounding plug. The plug must be plugged into an appropriate outlet which is properly installed and grounded in accordance with all local codes and ordinances.

SAFETY PRECAUTIONS FOR POWER SUPPLY UNIT

• Use the correct external power source

A product should be operated only from the type of power source indicated on the electrical ratings label. If you are not sure of the type of power source required, consult your authorized service provider or local power company. For a product that operates from battery power or other sources, refer to the operating instructions that are included with the product.

• Handle battery packs carefully

This product contains a Li-ion battery. There is a risk of fire and burns if the battery pack is handled improperly. Do not attempt to open or service the battery pack. Do not disassemble, crush, puncture, short external contacts or circuits, dispose of in fire or water, or expose a battery pack to temperatures higher than 60˚C (140˚F).

WARNING: Danger of explosion if battery is incorrectly replaced.

To reduce risk of fire or burns, do not disassemble, crush, puncture, short external contacts, expose to temperature above 60°C (140°F), or dispose of in fire or water. Replace only with specified batteries. Recycle or dispose of used batteries according to the local regulations or reference guide supplied with your product.

• Take extra precautions

• Keep the battery or device dry and away from water or any liquid

as it may cause a short circuit.

• Keep metal objects away so they don’t come in contact with the

battery or its connectors as it may lead to short circuit during operation.

• Do not use a battery that appears damaged, deformed, or

discoloured, or the one that has any rust on its casing, overheats, or emits a foul odour.

• Always keep the battery out of the reach of babies and small

children, to avoid swallowing of the battery. Consult the doctor immediately if the battery is swallowed.

If the battery leaks:

• Do not allow the leaking fluid to come in contact with skin

or clothing. If already in contact, flush the affected area immediately with clean water and seek medical advice.

• Do not allow the leaking fluid to come in contact with eyes.

If already in contact, DO NOT rub; rinse with clean water immediately and seek medical advice.

• Take extra precautions to keep a leaking battery away from fire

as there is a danger of ignition or explosion.

• Communicate the appropriate steps immediately in case a hazard occurs

SAFETY PRECAUTIONS FOR DIRECT SUNLIGHT

Keep this product away from excessive moisture and extreme temperatures. Do not leave the product or its battery inside a vehicle or in places where the temperature may exceed 60°C (140°F), such as on a car dashboard, window sill, or behind a glass that is exposed to direct sunlight or strong ultraviolet light for extended periods of time. This may damage the product, overheat the battery, or pose a risk to the vehicle.

PREVENTION OF HEARING LOSS

CAUTION: Permanent hearing loss may occur if earphones or

headphones are used at high volume for prolonged periods of time.

NOTE: For France, Headphones and Earphones (listed below) for this device have been tested to comply with the Sound Pressure Level requirement laid down in the applicable NF EN 50332-1:2000 and/or NF EN 50332-2:2003 standards as required by French Article L. 5232-1.

• Earphone, manufactured by HTC, Model name : HS S168 and S200.

SAFETY IN AIRCRAFT

Due to the possible interference caused by this product to an aircraft’s navigation system and its communications network, using this device’s phone function on board an aeroplane is against the law in most countries. If you want to use this device when on board an aircraft, remember to turn off the phone by switching to Flight Mode.

ENVIRONMENT RESTRICTIONS

Do not use this product in gas stations, fuel depots, chemical plants or where blasting operations are in progress, or in potentially explosive atmospheres such as fuelling areas, fuel storehouses, below deck on boats, fuel or chemical transfer or storage facilities, and areas where the air contains chemicals or particles, such as grain, dust, or metal powders. Please be aware that sparks in such areas could cause an explosion or fire resulting in bodily injury or even death.

EXPLOSIVE ATMOSPHERES

When in any area with a potentially explosive atmosphere or where flammable materials exist, the product should be turned off and the user should obey all signs and instructions. Sparks in such areas could cause an explosion or fire resulting in bodily injury or even death. Users are advised not to use the equipment at refuelling points such as service or gas stations, and are reminded of the need to observe restrictions on the use of radio equipment in fuel depots, chemical plants, or where blasting operations are in progress. Areas with a potentially explosive atmosphere are often, but not always, clearly marked. These include fueling areas, below deck on boats, fuel or chemical transfer or storage facilities, and areas where the air contains chemicals or particles, such as grain, dust, or metal powders.

ROAD SAFETY

Vehicle drivers in motion are not permitted to use telephony services with handheld devices, except in the case of emergency. In some countries, using hands-free devices as an alternative is allowed.

SAFETY PRECAUTIONS FOR RF EXPOSURE

• Avoid using your device near metal structures (for example, the steel

frame of a building).

• Avoid using your device near strong electromagnetic sources, such as

microwave ovens, sound speakers, TV and radio.

• Use only original manufacturer-approved accessories, or accessories

that do not contain any metal.

• Use of non-original manufacturer-approved accessories may violate

your local RF exposure guidelines and should be avoided.

INTERFERENCE WITH MEDICAL EQUIPMENT FUNCTIONS

This product may cause medical equipment to malfunction. The use of this device is forbidden in most hospitals and medical clinics.

If you use any other personal medical device, consult the manufacturer of your device to determine if it is adequately shielded from external RF energy. Your physician may be able to assist you in obtaining this information.

Turn the phone OFF in health care facilities when any regulations posted in these areas instruct you to do so. Hospitals or health care facilities may be using equipment that could be sensitive to external RF energy.

HEARING AIDS

Some digital wireless phones may interfere with some hearing aids. In the event of such interference, you may want to consult your service provider, or call the customer service line to discuss alternatives.

NONIONIZING RADIATION

Your device has an internal antenna. This product should be operated in its normal-use position to ensure the radiative performance and safety of the interference. As with other mobile radio transmitting equipment, users are advised that for satisfactory operation of the equipment and for the safety of personnel, it is recommended that no part of the human body be allowed to come too close to the antenna during operation of the equipment.

Use only the supplied integral antenna. Use of unauthorized or modified antennas may impair call quality and damage the phone, causing loss of performance and SAR levels exceeding the recommended limits as well as result in non-compliance with local regulatory requirements in your country.

To assure optimal phone performance and ensure human exposure to RF energy is within the guidelines set forth in the relevant standards, always use your device only in its normal-use position. Do not touch or hold the antenna area unnecessarily when placing or receiving a phone call. Contact with the antenna area may impair call quality and cause your device to operate at a higher power level than needed. Avoiding contact with the antenna area when the phone is IN USE optimises the antenna performance and the battery life.

Antenna location

General Precautions

• Avoid applying excessive pressure to the device

Do not put heavy objects or apply excessive pressure on the device to prevent damaging the device or distorting the touch screen display. Also avoid carrying the device inside your pocket for extensive lengths of time.

• Heed service markings

Except as explained elsewhere in the Operating or Service documentation, do not service any product yourself. Service needed on components inside these compartments should be done by an authorized service technician or provider.

• Damage requiring service

Unplug the product from the electrical outlet and refer servicing to an authorized service technician or provider under the following conditions:

• Liquid has been spilled or an object has fallen into the product.

• The product has been exposed to rain or water.

• The product has been dropped or damaged.

• There are noticeable signs of overheating.

• The product does not operate normally when you follow the

operating instructions.

• Avoid hot areas

The product should be placed away from heat sources such as radiators, heat registers, stoves, or other products (including, but not limited to, amplifiers) that produce heat.

• Avoid wet areas

Never use the product in a wet location.

• Avoid using your device after a dramatic change in temperature

When you move your device between environments with very different temperature and/or humidity ranges (For example, from warm indoor conditions in a cottage on a mountain to freezing outdoor conditions), condensation may form on or within the device. To avoid damaging the device, allow sufficient time for the moisture to evaporate before using the device.

NOTICE: When taking the device from low-temperature conditions into a

warmer environment or from high-temperature conditions into a cooler environment, allow the device to acclimate to room temperature before turning on power.

• Avoid pushing objects into product

Never push objects of any kind into cabinet slots or other openings in the product. Slots and openings are provided for ventilation. These openings must not be blocked or covered.

• Mounting accessories

Do not use the product on an unstable table, cart, stand, tripod, or bracket. Any mounting of the product should follow the manufacturer’s instructions, and should use a mounting accessory recommended by the manufacturer.

• Avoid unstable mounting

Do not place the product with an unstable base.

• Use product with approved equipment

This product should be used only with personal computers and options identified as suitable for use with your equipment.

• Adjust the volume

Turn down the volume before using headphones or other audio devices.

• Cleaning

Unplug the product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning, but NEVER use water to clean the LCD screen.

Contents

Chapter 1 Getting Started 17

1.1 Getting to Know Your PDA Phone and Accessories ..................... 18

1.2 Installing the USIM/SIM Card and Battery ................................... 22

1.3 Installing a Storage Card ............................................................... 25

1.4 Starting Up .....................................................................................26

1.5 The Today Screen ........................................................................... 30

1.6 The Start Menu ............................................................................... 31

1.7 Quick Menu .................................................................................... 31

1.8 TouchFLO™ ..................................................................................... 32

1.9 Status Icons ....................................................................................39

1.10 Programs ...................................................................................... 41

1.11 Settings ........................................................................................ 44

Chapter 2 Entering Text and Searching for Information 49

2.1 Entering Information ..................................................................... 50

2.2 Using the On-screen Keyboard .....................................................

2.3 Using

the Touch Keyboard ............................................................ 51

2.4 Using the Touch Keypad ................................................................54

2.5 Using the Symbol Pad ................................................................... 55

2.6 Using Letter Recognizer ................................................................

2.7 Using Block Recognizer .................................................................

2.8 Using Transcriber ...........................................................................

2.9 Searching for Information ............................................................ 58

Chapter 3 Using Phone Features 59

3.1 Using the Phone ............................................................................. 60

3.2 Making a Call .................................................................................. 62

3.3 Receiving a Call .............................................................................. 65

3.4 Making a Video Call .......................................................................

3.5 Receiving a Video Call ...................................................................

3.6 Smart Dialing .................................................................................

3.7 Additional Dialing Information .................................................... 73

3.8 Setting Up Bluetooth SIM Access for Car Kit Phones ..................73

Chapter 4 Setting Up Your Device 75

4.1 Basic Settings ................................................................................. 76

4.2 Personalizing the Today Screen .................................................... 79

4.3 Protecting Your Device ..................................................................81

Chapter 5 Synchronizing Information With Your Computer 83

5.1 About Synchronization .................................................................84

5.2 Setting Up Windows Mobile® Device Center on

Windows Vista® ..............................................................................

5.3 Setting Up ActiveSync® on Windows XP® ..................................... 87

5.4 Synchronizing With Your Computer ............................................. 88

5.5 Synchronizing via Bluetooth ........................................................89

5.6 Synchronizing Music and Video ................................................... 90

Chapter 6 Organizing Contacts, Appointments, Tasks, and Other

Information 9

6.1 Contacts .......................................................................................... 92

6.2 SIM Manager ..................................................................................96

6.3 Calendar ......................................................................................... 98

6.4 Tasks ..............................................................................................101

6.5 Notes ............................................................................................. 103

6.6 Voice Recorder .............................................................................105

Chapter 7 Exchanging Messages 107

7.1 Messaging ....................................................................................108

7.2 Text Messages ..............................................................................109

7.3 MMS ..............................................................................................111

7.4 Types of E-mail Accounts .............................................................

115

7.5 E-mail Setup Wizard .....................................................................116

7.6 Using E-mail .................................................................................

119

Chapter 8 Working With Company E-mails and Meeting

Appointments 125

8.1 Synchronizing with the Exchange Server ..................................126

8.2 Working With Company E-mails .................................................127

8.3 Managing Meeting Requests ......................................................132

8.4 Finding Contacts in the Company Directory .............................134

Chapter 9 Working With Documents and Files 137

9.1 Microsoft® Office Mobile .............................................................138

9.2 Adobe® Reader® LE ......................................................................139

9.3 Copying and Managing Files ......................................................140

9.4 ZIP .................................................................................................141

9.5 Backing Up Data .......................................................................... 142

Chapter 10 Getting Connected 145

10.1 Comm Manager ......................................................................... 146

10.2 O2 Connection Settings ............................................................147

10.3 Ways of Connecting to the Internet ......................................... 148

10.4 Wi-Fi ............................................................................................148

10.5 GPRS/3G .....................................................................................151

10.6 Dial-up ........................................................................................152

10.7 Starting a Data Connection ......................................................

153

10.8 Internet Explorer® Mobile ......................................................... 153

10.9 Windows Live™ ........................................................................... 155

10.10 Using Your Device as a Modem (Internet Sharing) ............... 159

10.11 Bluetooth .................................................................................161

Chapter 11 Using GPS 169

11.1 Guidelines and Preparation for Using GPS .............................. 170

11.2 Downloading Satellite Data

via QuickGPS ..............................172

11.3 GPS Controls ..............................................................................

174

Chapter 12 Experiencing Multimedia 175

12.1 Camera ....................................................................................... 176

12.2 Camera Album ...........................................................................188

12.3 Pictures & Videos .......................................................................192

12.4 Windows Media® Player Mobile ................................................ 194

12.5 Streaming Media .......................................................................199

12.6 Audio Manager ..........................................................................201

12.7 Using Audio Booster ..................................................................205

12.8 Using FM Radio ..........................................................................207

Chapter 13 Managing Your Device 213

13.1 Adding and Removing Programs .............................................214

13.2 Resetting Your Device ...............................................................214

13.3 Managing Memory ....................................................................216

13.4 Windows Update ........................................................................ 217

13.5 Battery Saving Tips ....................................................................218

Chapter 14 Using Other Applications 221

14.1 Voice Speed Dial ........................................................................ 222

14.2 Java .............................................................................................224

14.3 Spb GPRS Monitor .....................................................................226

Appendix 229

A.1 Regulatory Notices ...................................................................... 230

A.2 Specifications ..............................................................................

235

Index 239

Chapter 1

Getting Started

1.1 Getting to Know Your PDA

Phone and Accessories

1.2 Installing the USIM/SIM Card

and Battery

1.3 Installing a Storage Card

1.4 Starting Up

1.5 The Today Screen

1.6 The Start Menu

1.7 Quick Menu

1.8 TouchFLO™

1.9 Status Icons

1.10 Programs

1.11 Settings

18 Getting Started

1.1 Getting to Know Your PDA Phone and Accessories

Top panel

POWER

Press to turn off the display temporarily. To turn off the power, press and hold for about 5 seconds. For more information, see “Starting Up” in this chapter.

Left panel Right panel

VOICE COMMAND

• Press to activate or cancel

voice recognition. See

Chapter 14 for details.

• Press and hold to record a

voice note.

Volume Control

During a call or when playing music, slide up or down to adjust the sound volume.

Lanyard/Strap Holder

CAMERA

Press to launch the Camera. See Chapter 12 for details.

Stylus

microSD Slot

See "Installing a Storage Card" for details.

Getting Started 19

Front panel

Press to close a window or confirm settings (same as tapping or ).

Notification LEDs

* See description below.

Earpiece

Listen to a phone call from here.

Touch Screen

TALK

Press to answer an incoming call or dial a number.

NAVIGATION WHEEL/ENTER

• Use to scroll left, right, up, or down.

• Rotate or press the wheel to scroll through items or screens.

• Carry out a selection by pressing the centre button.

• When using the Camera, rotate the NAVIGATION WHEEL to

zoom in and out.

END

Press to end a call or to return to the Today screen. Press and hold to open the Quick List where you can select an action to perform.

In the Quick List, touch Settings to set the behaviour when pressing and holding the END key.

Second Camera

Use this video camera for video call conversations, or to take a self-portrait.

Start Menu

Press to open the Start Menu.

* Right LED: Shows green and amber lights for HSDPA/UMTS/EDGE/GSM/GPRS

standby, message, and network status as well as for notification and battery charging status. Shows a flashing red light when the battery level reaches 5% or lower.

Left LED:

Shows a flashing blue light when the Bluetooth system is ready to

transmit or receive Bluetooth signals, or

a flashing green light for Wi-Fi

status

. When both Bluetooth and Wi-Fi are enabled, their lights flash

alternately. Shows flashing amber light for GPS status.

20 Getting Started

Back panel

Speaker

3 Megapixel Camera

See

Chapter 12

for details.

Back Cover

Slide the back cover downward to remove it.

GPS Antenna Connector

Peel off the rubber cap and connect an external GPS antenna for better GPS signal reception.

Note Use only the

external GPS antenna with model number

GA S120.

Self-portrait Mirror

Bottom Panel

Sync Connector/Earphone Jack

Connect the supplied USB cable to synchronize information or plug in the AC adapter to recharge the battery. You can also connect the supplied USB stereo headset for hands-free conversation or for listening to audio media.

Microphone

RESET

Press the RESET button with the stylus to soft-reset your device.

Battery Cover Lock

Slide this switch to unlock or lock the battery cover.

Getting Started 21

Accessories

4 7

User Ma

ual

Read Me First

Screen

Protecto

No. Accessory Function

1 Battery Insert into the device before turning it on.

2 Screen protector Protects the touch screen from scratches.

3 Stereo headset Provides a volume control slider and a Send/End button.

Press the Send/End button to pick up a call or put a call on hold; press and hold the button to end the call.

4 AC adapter Recharges the battery.

5 USB sync cable Connects your device to a PC and synchronizes data.

6 Extra stylus Use to tap items onscreen.

7 User manual and

ReadMeFirst

Provide instructions for using your device.

8 Pouch Acts as a protective carrying case for your device.

9 Getting Started

and Applications discs

Sources for additional tools and programs.

10 Car Charger Charges the device while driving in your car.

11 Car Holder Holds the device securely in place while in your car.

22 Getting Started

1.2 Installing the USIM/SIM Card and Battery

Always turn off your device before installing/replacing the USIM/SIM card and battery. The USIM/SIM card contains your phone number, service details, and phonebook/message memory. Your device supports both 1.8V and 3V SIM cards. Some legacy SIM cards will not function with your device. You should consult with your service provider for a replacement USIM/SIM card. There may be fees for this service.

Your device contains a rechargeable Li-ion battery and is designed to use only manufacturer-specified original batteries and accessories. Battery performance depends on many factors, including network configuration, signal strength, the temperature of the environment in which you operate your device, the features and/or settings you select and use, items attached to connecting ports, and your voice, data, and other program usage patterns.

Battery life estimates (approximations):

• Standby time: Up to 400 hours for GSM

Up to

450 hours for UMTS

• Talk time: Up to 7 hours for GSM

Up to

4 hours for UMTS

Note: Battery life estimates subject to network and phone usage.

• Media playback time: Up to 8 hours for WMV

Up to

12 hours for WMA

Warning! To reduce risk of fire or burns:

• Do not attempt to open, disassemble, or service the battery pack.

• Do not crush, puncture, short external contacts, or dispose of in fire

or water.

• Do not expose to temperatures above 60oC (140oF).

• Replace only with the battery pack designated for this product.

• Recycle or dispose of used battery as stipulated by local

regulations.

Important Before opening the SIM card holder, make sure you turn off the device

first. Opening the SIM card holder while the device is turned on may damage the device.

Getting Started 23

To remove the back cover

Before installing the USIM/SIM card or battery, remove the back cover.

1. Make sure your device is turned off.

2. Slide the battery cover lock switch

to the unlock position

3. Slide the back cover off to remove

it.

To install the USIM/SIM card

1. Make sure your device is turned off.

2. Push the SIM card holder to the right to unlock it and then flip the

card holder up.

3. Insert the USIM/SIM card with its

gold contacts facing down and its cut-off corner facing the battery compartment.

Cut-off

corner

4. Push the SIM card holder down until it snaps into place to lock it.

24 Getting Started

To remove the USIM/SIM card

1. Push the USIM/SIM card in to

unlock the SIM card holder.

2. Flip the SIM card up, and then

remove the SIM card.

To install the battery

Install the battery by aligning its exposed copper contacts with the battery connectors inside the battery compartment. Insert the contact’s side of the battery ﬁrst, then gently push the battery into place. Make sure that you leave the black strip extended to make it easy for you to remove the battery.

Battery connectors

Black strip

After you have inserted the battery, replace the back cover.

To remove the battery

1. Make sure your device is turned off.

2. Slide the battery cover lock switch to the unlock position .

3. Slide the back cover off.

4. Remove the battery by lifting the black strip.

Getting Started 25

To replace the back cover

1. Slide the back cover on.

2. Slide the battery cover lock switch

to the lock position

1.3 Installing a Storage Card

A storage card slot is located on the right side of your device. To have additional storage for your images, videos, music, and files, you can purchase a microSDTM card and insert it into the slot.

To insert a microSD card

1. Prise open the storage card slot cover.

2. Insert the microSD

card into the slot with the gold contacts facing up.

3. Replace the card slot

cover.

Note To remove the

microSD card, press the microSD card to eject it from the slot.

Slot cover

Gold contacts

26 Getting Started

1.4 Starting Up

After inserting your USIM/SIM card and battery and charging the battery, you can now power on and start using your device.

Turn your device on and off

To turn on the power

• Press and hold the POWER button for a few seconds.

When you turn on your device for the first time, a Quick Start Wizard guides you through the calibration process and the setup of regional settings, date and time, and password. For more information about touch screen calibration, see “Calibrate the device” later in this chapter. After the Quick Start Wizard finishes, the device installs customisation settings, and then the device will restart.

Note After the device restarts, you may be prompted to set up an e-mail

account. Refer to Chapter 7 for details.

To turn off the power

• Press and hold the POWER button for a few seconds.

A message prompts you to choose whether or not to turn off the device completely.

Auto configure the data connection settings

The first time you power on your device, you will see a notification message from

Connection Settings on the Today screen.

O2 Connection Settings automatically configures your device’s data connections, such as GPRS, WAP, and MMS, so that you do not need to enter the settings manually for your device.

Getting Started 27

To automatically configure data connection settings

1. Select the I want to do auto configuration now check box.

2. Select the profile you want to use from the drop down list and tap OK.

O2 Connection Settings then starts to configure your device’s data connection settings.

3. After the O2 Connection Settings completes the configuration, you

are prompted to restart the device. Tap Yes.

For more information about O2 Connection Settings, see Chapter 10.

Charge the battery

New batteries are shipped partially charged. Before you start using your device, it is recommended that you install and charge the battery. Some batteries perform best after several full charge/discharge cycles. You can charge the battery in two ways:

•

Charging the device’s battery by connecting the power adapter.

• Connecting your device to a PC using the provided USB Sync cable.

Note Only the AC adapter and USB cable provided with your device should be

used to charge the device.

Charging is indicated by a solid amber light on the right LED indicator. As the battery is being charged while the device’s power is on, a charging icon appears on the title bar of the Today screen. After the battery has been fully charged, the right LED charging indicator becomes green and a full battery icon

appears on the Today screen’s title bar.

Warning! • Do not remove the battery from the device while you are charging it

using the AC or car adapter.

• As a safety precaution, the battery stops charging when it overheats.

28 Getting Started

Calibrate the device

Calibrating the touch screen involves tapping the centre of a cross with the stylus as the cross moves around the screen. This process ensures that when you tap the screen with your stylus, the tapped item is activated.

If your device does not accurately respond to screen taps, follow these steps to re-calibrate it:

1. Tap Start > Settings > System tab > Screen.

2. On the General tab, tap Align Screen and follow the on-screen

instructions to complete the calibration.

Manage screen settings

The device’s display has the following orientation modes: Portrait and Landscape. Portrait mode allows you to get a better view or a better

operation of certain programs, while Landscape mode may be optimal for viewing lengthy files.

• To change the orientation, tap Start > Settings > System tab >

Screen, and select the orientation you want.

• To smooth the edges of screen fonts for many programs, on the

ClearType tab, select the Enable ClearType check box.

• To increase the readability or to see more content on the screen, on

the Text Size tab, adjust the text size by moving the slider.

Switch your device to Sleep mode

Press and immediately release the POWER button to turn off the display temporarily and switch your device to Sleep mode

. Sleep mode suspends your device to a low power state while the display is off in order to save battery power.

Your device also automatically goes into Sleep mode when you leave the device idle after a certain period of time.

To specify the timeout period before your device goes into Sleep mode

1. Tap Start > Settings > System tab > Power > Advanced tab.

2. Under On battery power, make sure the Turn off device if not used

for check box is selected.

3. Select the battery timeout period, then tap OK.

Getting Started 29

You will still be able to receive messages and calls while your device is in Sleep mode. Pressing the POWER button again or incoming calls/messages will wake up your device.

Check battery power

• Tap Start > Settings > System tab >

Power

When the low-battery warning appears, immediately save your data by synchronising with your PC, or save your data on a storage card, and then turn off your device. Do not attempt to restart your device until you have connected it with the power adapter.

Battery power information

Tip To find out ways on saving battery power, see “Battery Saving Tips” in

Chapter 13.

30 Getting Started

1.5 The Today Screen

The Today screen displays important information, such as upcoming appointments and status indicators. You can tap a section on the screen to open the associated program.

View your day at a glance with forthcoming appointments

Open Start Menu

Notification

Signal strength

Adjust volume

Current time (tap and hold to change display modes)

Change the date and time, set up the alarm, and more

Connection status

Displays the current Profile

being used. Tap to change

or edit the current Profile

Tap

to lock the device.

The icon changes to .

Tap Unlock on the Today screen to unlock again

Tap to view the latest battery meter and memory meter reading

Drag the slider to adjust ringer and device volume

Open Meters Settings

for Battery, Memory,

and Storage

Tap to view power settings and memory status

Open Quick Menu

• To access the Today screen, tap Start > Today.

• To customise the Today screen display, including the background

image, tap Start

> Settings > Personal tab > Today.

For more information about customising the Today screen, see Chapter 4.

+ 216 hidden pages
