HTC Vive Tracker User Manual

Tracker user guide

English

English

2 3

About Vive Tracker

Attach the Vive Tracker to a compatible third-party
accessory so that it can be detected and used within the
Vive VR system.

1 Sensors 5 Standard camera mount
2 USB port 6 Stabilizing pin recess
3 Pogo pin connector 7 Status light
4 Friction pad 8 Power button

What’s inside the box

You’ll find the following items:

1 Vive Tracker 3 Dongle cradle
2 Dongle 4 USB cable

Important: Always ensure that the play area is entirely clear of all objects, obstacles

and other individuals when using Vive Tracker on any object intended to be moved
while wearing the Vive headset.

English

English

4 5

When Vive Tracker is fully charged, its status light either
shows white if it is off or green if it is turned on.

Charging Vive Tracker

Make sure to use the USB cable that’s in the box. Connect
the USB cable to the power adapter that came with your
Vive controllers, and then plug the power adapter to a
power outlet to charge Vive Tracker.

Note: You can also connect Vive Tracker to a computer’s USB port to charge it.

Attaching Vive Tracker to an accessory

Standard tripod docking: Align the tripod plate’s bolt
and stabilizing pin with the corresponding holes on Vive
Tracker. Turn the tab on the bottom side of the plate
clockwise to screw Vive Tracker securely in place.

Stabilizing pin

1/4 inch bolt

Note: For illustration purposes only. Third-party accessories are purchased separately.
