HTC HS S00 User Manual

Touch Phone

User Manual

www.htc.com

Please Read Before Proceeding

THE BATTERY IS NOT CHARGED WHEN YOU TAKE IT OUT OF THE BOX.

DO NOT REMOVE THE BATTERY PACK WHEN THE DEVICE IS CHARGING.

YOUR WARRANTY IS INVALIDATED IF YOU OPEN OR TAMPER WITH THE DEVICE’S OUTER CASING.

PRIVACY RESTRICTIONS

Some countries require full disclosure of recorded telephone conversations, and stipulate that you must inform the person with whom you are speaking that the conversation is being recorded. Always obey the relevant laws and regulations of your country when using the recording feature of your device.

INTELLECTUAL PROPERTY RIGHT INFORMATION

, , , ExtUSB, HTC Touch, HTC Care, Touch Dual, and TouchFLO are

trademarks and/or service marks of High Tech Computer Corp.

Microsoft, MS-DOS, Windows, Windows NT, Windows Server, Windows Mobile, Windows XP, Windows Vista, ActiveSync, Windows Mobile Device Center, Internet Explorer, Windows Live, MSN, Hotmail, Outlook, Excel, PowerPoint, Word, and Windows Media are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries.

Bluetooth and the Bluetooth logo are trademarks owned by Bluetooth SIG, Inc.

microSD is a trademark of SD Card Association.

Java, J2ME and all other Java-based marks are trademarks or registered trademarks of Sun Microsystems, Inc. in the United States and other countries.

Macromedia, Flash, Macromedia Flash, Macromedia Flash Lite and Reader are trademarks and/or registered trademarks of Macromedia Netherlands, B.V. or Adobe Systems Incorporated.

ArcSoft MMS Composer™ Copyright © 2003-2007, ArcSoft, Inc. and its licensors. All Rights Reserved. ArcSoft and the ArcSoft logo are registered trademarks of ArcSoft, Inc. in the United States and/or other countries.

Sprite Backup is a trademark or service mark of Sprite Software.

The device is under RIM Keyboard technology.

All other company, product and service names mentioned herein are trademarks, registered trademarks or service marks of their respective owners.

HTC shall not be liable for technical or editorial errors or omissions contained herein, nor for incidental or consequential damages resulting from furnishing this material. The information is provided “as is” without warranty of any kind and is subject to change without notice. HTC also reserves the right to revise the content of this document at any time without prior notice.

No part of this document may be reproduced or transmitted in any form or by any means, electronic or mechanical, including photocopying, recording or storing in a retrieval system, or translated into any language in any form without prior written permission of HTC.

Disclaimers

THE WEATHER INFORMATION, DATA AND DOCUMENTATION ARE PROVIDED “AS IS” AND WITHOUT WARRANTY OR TECHNICAL SUPPORT OF ANY KIND FROM HTC. TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, HTC AND ITS AFFILIATES expressly disclaim any and all representations and warranties, express or implied, arising by law or otherwise, regarding the Weather Information, Data, Documentation, or any other Products and services, including without limitation any express or implied warranty of merchantability, express or implied warranty of fitness for a particular purpose, non-infringement, quality, accuracy, completeness, effectiveness, reliability, usefulness, that the Weather Information, Data and/or Documentation will be error-free, or implied warranties arising from course of dealing or course of performance.

Without limiting the foregoing, it is further understood that HTC and its Providers are not responsible for Your use or misuse of the Weather Information, Data and/or Documentation or the results from such use. HTC and its Providers make no express or implied warranties, guarantees or affirmations that weather information will occur or has occurred as the reports, forecasts, data, or information state, represent or depict and it shall have no responsibility or liability whatsoever to any person or entity, parties and non-parties alike, for any inconsistency, inaccuracy, or omission for weather or events predicted or depicted, reported, occurring or occurred. WITHOUT LIMITING THE GENERALITY OF THE FOREGOING, YOU ACKNOWLEDGE THAT THE WEATHER INFORMATION, DATA AND/OR DOCUMENTATION MAY INCLUDE INACCURACIES AND YOU WILL USE

COMMON SENSE AND FOLLOW STANDARD SAFETY PRECAUTIONS IN CONNECTION WITH THE USE OF THE WEATHER INFORMATION, DATA OR DOCUMENTATION.

Limitation of Damages

TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO EVENT SHALL HTC OR ITS PROVIDERS BE LIABLE TO USER OR ANY THIRD PARTY FOR ANY INDIRECT, SPECIAL, CONSEQUENTIAL, INCIDENTAL OR PUNITIVE DAMAGES OF ANY KIND, IN CONTRACT OR TORT, INCLUDING, BUT NOT LIMITED TO, INJURY, LOSS OF REVENUE, LOSS OF GOODWILL, LOSS OF BUSINESS OPPORTUNITY, LOSS OF DATA, AND/OR LOSS OF PROFITS ARISING OUT OF, OR RELATED TO, IN ANY MANNER, OR THE DELIVERY, PERFORMANCE OR NONPERFORMANCE OF OBLIGATIONS, OR USE OF THE WEATHER INFORMATION, DATA OR DOCUMENTATION HEREUNDER REGARDLESS OF THE FORESEEABILITY THEREOF.

Important Health Information and Safety Precautions

When using this product, the safety precautions below must be taken to avoid possible legal liabilities and damages.

Retain and follow all product safety and operating instructions. Observe all warnings in the operating instructions on the product.

To reduce the risk of bodily injury, electric shock, fire, and damage to the equipment, observe the following precautions.

ELECTRICAL SAFETY

This product is intended for use when supplied with power from the designated battery or power supply unit. Other usage may be dangerous and will invalidate any approval given to this product.

SAFETY PRECAUTIONS FOR PROPER GROUNDING INSTALLATION

CAUTION: Connecting to an improperly grounded equipment can result in an electric

shock to your device.

This product is equipped with a USB cable for connecting the product to a desktop or notebook computer. Be sure your computer is properly grounded (earthed) before connecting the product to the computer. The power supply cord of a desktop or notebook computer has an equipment-grounding conductor and a grounding plug. The plug must be plugged into an appropriate outlet which is properly installed and grounded in accordance with all local codes and ordinances.

SAFETY PRECAUTIONS FOR POWER SUPPLY UNIT

• Use the correct external power source

A product should be operated only from the type of power source indicated on the electrical ratings label. If you are not sure of the type of power source required, consult your authorized service provider or local power company. For a product that operates from battery power or other sources, refer to the operating instructions that are included with the product.

• Handle battery packs carefully

This product contains a Li-ion battery. There is a risk of fire and burns if the battery pack is handled improperly. Do not attempt to open or service the battery pack. Do not disassemble, crush, puncture, short external contacts or circuits, dispose of in fire or water, or expose a battery pack to temperatures higher than 60˚C (140˚F).

WARNING: Danger of explosion if battery is incorrectly replaced. To

reduce risk of fire or burns, do not disassemble, crush, puncture, short external contacts, expose to temperature above 60°C (140°F), or dispose of in fire or water. Replace only with specified batteries. Recycle or dispose of used batteries according to the local regulations or reference guide supplied with your product.

• Take extra precautions

• Keep the battery or device dry and away from water or any liquid as it may

cause a short circuit.

• Keep metal objects away so they don’t come in contact with the battery or

its connectors as it may lead to short circuit during operation.

• Do not use a battery that appears damaged, deformed, or discolored, or the

one that has any rust on its casing, overheats, or emits a foul odor.

• Always keep the battery out of the reach of babies and small children, to

avoid swallowing of the battery. Consult the doctor immediately if the battery is swallowed.

• If the battery leaks:

• Do not allow the leaking fluid to come in contact with skin or clothing. If

already in contact, flush the affected area immediately with clean water and seek medical advice.

• Do not allow the leaking fluid to come in contact with eyes. If already

in contact, DO NOT rub; rinse with clean water immediately and seek medical advice.

• Take extra precautions to keep a leaking battery away from fire as there

is a danger of ignition or explosion.

• Communicate the appropriate steps immediately in case a hazard occurs.

SAFETY PRECAUTIONS FOR DIRECT SUNLIGHT

Keep this product away from excessive moisture and extreme temperatures. Do not leave the product or its battery inside a vehicle or in places where the temperature may exceed 60°C (140°F), such as on a car dashboard, window sill, or behind a glass that is exposed to direct sunlight or strong ultraviolet light for extended periods of time. This may damage the product, overheat the battery, or pose a risk to the vehicle.

PREVENTION OF HEARING LOSS

CAUTION: Permanent hearing loss may occur if earphones or

headphones are used at high volume for prolonged periods of time.

NOTE: For France, mobile headphones or earphones (listed below) for this device have been tested to comply with the Sound Pressure Level requirement laid down in the applicable NF EN 50332-1:2000 and/or NF EN 50332-2:2003 standards as required by French Article L. 5232-1

• Earphone, manufactured by HTC, Model HS S200

SAFETY IN AIRCRAFT

Due to the possible interference caused by this product to an aircraft’s navigation system and its communications network, using this device’s phone function on board an airplane is against the law in most countries. If you want to use this device when on board an aircraft, remember to turn off the phone by switching to Airplane Mode.

ENVIRONMENT RESTRICTIONS

Do not use this product in gas stations, fuel depots, chemical plants or where blasting operations are in progress, or in potentially explosive atmospheres such as fuelling areas, fuel storehouses, below deck on boats, fuel or chemical transfer or storage facilities, and areas where the air contains chemicals or particles, such as grain, dust, or metal powders. Please be aware that sparks in such areas could cause an explosion or fire resulting in bodily injury or even death.

EXPLOSIVE ATMOSPHERES

When in any area with a potentially explosive atmosphere or where flammable materials exist, the product should be turned off and the user should obey all signs and instructions. Sparks in such areas could cause an explosion or fire resulting in bodily injury or even death. Users are advised not to use the equipment at refueling points such as service or gas stations, and are reminded of the need to observe restrictions on the use of radio equipment in fuel depots, chemical plants, or where blasting operations are in progress. Areas with a potentially explosive atmosphere are often, but not always, clearly marked. These include fueling areas, below deck on boats, fuel or chemical transfer or storage facilities, and areas where the air contains chemicals or particles, such as grain, dust, or metal powders.

ROAD SAFETY

Vehicle drivers in motion are not permitted to use telephony services with handheld devices, except in the case of emergency. In some countries, using hands-free devices as an alternative is allowed.

SAFETY PRECAUTIONS FOR RF EXPOSURE

• Avoid using your device near metal structures (for example, the steel frame of a

building).

• Avoid using your device near strong electromagnetic sources, such as microwave

ovens, sound speakers, TV and radio.

• Use only original manufacturer-approved accessories, or accessories that do not

contain any metal.

• Use of non-original manufacturer-approved accessories may violate your local RF

exposure guidelines and should be avoided.

INTERFERENCE WITH MEDICAL EQUIPMENT FUNCTIONS

This product may cause medical equipment to malfunction. The use of this device is forbidden in most hospitals and medical clinics.

If you use any other personal medical device, consult the manufacturer of your device to determine if it is adequately shielded from external RF energy. Your physician may be able to assist you in obtaining this information.

Turn the phone OFF in health care facilities when any regulations posted in these areas instruct you to do so. Hospitals or health care facilities may be using equipment that could be sensitive to external RF energy.

HEARING AIDS

Some digital wireless phones may interfere with some hearing aids. In the event of such interference, you may want to consult your service provider, or call the customer service line to discuss alternatives.

NONIONIZING RADIATION

Your device has an internal antenna. This product should be operated in its normal-use position to ensure the radiative performance and safety of the interference. As with other mobile radio transmitting equipment, users are advised that for satisfactory operation of the equipment and for the safety of personnel, it is recommended that no part of the human body be allowed to come too close to the antenna during operation of the equipment.

Use only the supplied integral antenna. Use of unauthorized or modified antennas may impair call quality and damage the phone, causing loss of performance and SAR levels exceeding the recommended limits as well as result in non-compliance with local regulatory requirements in your country.

To assure optimal phone performance and ensure human exposure to RF energy is within the guidelines set forth in the relevant standards, always use your device only in its normal-use position. Do not touch or hold the antenna area unnecessarily when placing or receiving a phone call. Contact with the antenna area may impair call quality and cause your device to operate at a higher power

Internal antenna location

level than needed. Avoiding contact with the antenna area when the phone is IN USE optimizes the antenna performance and the battery life.

General Precautions

• Heed service markings

Except as explained elsewhere in the Operating or Service documentation, do not service any product yourself. Service needed on components inside the device should be done by an authorized service technician or provider.

• Damage requiring service

Unplug the product from the electrical outlet and refer servicing to an authorized service technician or provider under the following conditions:

• Liquid has been spilled or an object has fallen into the product.

• The product has been exposed to rain or water.

• The product has been dropped or damaged.

• There are noticeable signs of overheating.

• The product does not operate normally when you follow the operating

instructions.

• Avoid hot areas

The product should be placed away from heat sources such as radiators, heat registers, stoves, or other products (including amplifiers) that produce heat.

• Avoid wet areas

Never use the product in a wet location.

• Avoid using your phone after a dramatic change in temperature

When you move your device between environments with very different temperature and/or humidity ranges, condensation may form on or within the device. To avoid damaging the device, allow sufficient time for the moisture to evaporate before using the device. NOTICE: When taking the device from low-temperature conditions into a warmer environment or from high-temperature conditions into a cooler environment, allow the device to acclimate to room temperature before turning on power.

• Avoid pushing objects into product

Never push objects of any kind into cabinet slots or other openings in the product. Slots and openings are provided for ventilation. These openings must not be blocked or covered.

• Mounting Accessories

Do not use the product on an unstable table, cart, stand, tripod, or bracket. Any mounting of the product should follow the manufacturer’s instructions, and should use a mounting accessory recommended by the manufacturer.

• Avoid unstable mounting

Do not place the product with an unstable base.

• Use product with approved equipment

This product should be used only with personal computers and options identiﬁed as suitable for use with your equipment.

• Adjust the volume

Turn down the volume before using headphones or other audio devices.

• Cleaning

Unplug the product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning, but NEVER use water to clean the LCD screen.

Contents

Chapter 1 Getting Started 15

1.1 Getting to Know Your Device and Accessories ..................................16

1.2 Installing the SIM Card, Battery, and Storage Card ..........................20

1.3 Starting Up...........................................................................................23

1.4 The Today Screen .................................................................................26

1.5 The Start Menu ....................................................................................27

1.6 Quick Menu ..........................................................................................28

1.7 QuickTasks ...........................................................................................28

1.8 HTC Home™ ..........................................................................................29

1.9 TouchFLO™ ...........................................................................................34

1.10 Status Icons ........................................................................................41

1.11 Programs ............................................................................................43

1.12 Settings ...............................................................................................46

Chapter 2 Entering and Searching Information 51

2.1 Entering Information ...........................................................................52

2.2 Using the 20-key QWERTY Hardware Keyboard ................................54

2.3 Using the Onscreen Keyboard ............................................................56

2.4 Using Touch Keyboard .........................................................................56

2.5 Using Touch Keypad.............................................................................57

2.6 Using Symbol Pad ................................................................................ 58

2.7 Using Letter Recognizer ......................................................................59

2.8 Using Block Recognizer ....................................................................... 60

2.9 Using Transcriber .................................................................................60

2.10 Searching Information ......................................................................61

Chapter 3 Using Phone Features 63

3.1 Using the Phone ...................................................................................64

3.2 Making a Call ........................................................................................ 66

3.3 Receiving a Call ....................................................................................69

3.4 Making a Video Call .............................................................................72

3.5 Receiving a Video Call .......................................................................... 76

3.6 Smart Dial .............................................................................................76

3.7 Additional Dialing Information ..........................................................78

3.8 Setting Up Bluetooth SIM Access for Car Kit Phones ........................78

Chapter 4 Setting Up Your Device 81

4.1 Basic Settings .......................................................................................82

4.2 Personalizing the Today Screen ..........................................................85

4.3 Protecting Your Device ........................................................................87

Chapter 5 Synchronizing Information With Your Computer 89

5.1 About Synchronization .......................................................................90

5.2 Setting Up Windows Mobile® Device Center on Windows Vista® .... 91

5.3 Setting Up ActiveSync® on Windows XP® ..........................................93

5.4 Synchronizing With Your Computer ...................................................94

5.5 Synchronizing via Bluetooth ..............................................................95

5.6 Synchronizing Music and Video .........................................................96

Chapter 6 Organizing Contacts, Appointments, Tasks,

and Other Information 97

6.1 Contacts ................................................................................................98

6.2 SIM Manager ......................................................................................102

6.3 Calendar..............................................................................................104

6.4 Tasks ....................................................................................................107

6.5 Notes ...................................................................................................109

6.6 Voice Recorder ....................................................................................111

Chapter 7 Exchanging Messages 113

7.1 Messaging ..........................................................................................114

7.2 Text Messages ....................................................................................115

7.3 MMS ....................................................................................................117

7.4 Types of E-mail Accounts ..................................................................121

7.5 E-mail Setup Wizard ..........................................................................122

7.6 Using E-mail .......................................................................................125

Chapter 8 Working With Company E-mails and Meeting

Appointments 131

8.1 Synchronizing Your Device with the Exchange Server ...................132

8.2 Working With Company E-mails .......................................................133

8.3 Managing Meeting Requests ...........................................................137

8.4 Finding Contacts in the Company Directory ...................................139

Chapter 9 Working With Documents and Files 141

9.1 Microsoft® Office Mobile ...................................................................142

9.2 Adobe® Reader® LE ............................................................................143

9.3 Copying and Managing Files .............................................................144

9.4 ZIP .......................................................................................................145

9.5 Backing Up Data.................................................................................146

Chapter 10 Getting Connected 149

10.1 Comm Manager ................................................................................150

10.2 Connection Setup ............................................................................151

10.3 Ways of Connecting to the Internet ................................................152

10.4 GPRS/3G............................................................................................152

10.5 Dial-up ..............................................................................................154

10.6 Starting a Data Connection .............................................................154

10.7 Internet Explorer® Mobile ...............................................................155

10.8 Windows Live™ .................................................................................157

10.9 Using Your Device as a Modem (Internet Sharing) ........................161

10.10 Bluetooth .......................................................................................163

Chapter 11 Experiencing Multimedia 171

11.1 Camera ..............................................................................................172

11.2 Camera Album..................................................................................183

11.3 Pictures & Videos .............................................................................187

11.4 Windows Media® Player Mobile ......................................................189

11.5 Streaming Media .............................................................................194

11.6 Flash Lite Player ...............................................................................196

11.7 Audio Manager ................................................................................197

11.8 Audio Booster ..................................................................................201

Chapter 12 Managing Your Device 205

12.1 Adding and Removing Programs ...................................................206

12.2 Using Task Manager .........................................................................206

12.3 Resetting Your Device ......................................................................208

12.4 Managing Memory ..........................................................................210

12.5 Windows Update ..............................................................................211

12.6 Battery Saving Tips ..........................................................................212

Chapter 13 Using Other Applications 213

13.1 Voice Speed Dial...............................................................................214

13.2 Java ...................................................................................................216

13.3 Spb GPRS Monitor ...........................................................................218

Appendix 221

A.1 Specifications .....................................................................................222

A.2 Regulatory Notices ............................................................................225

Index 231

Chapter 1

Getting Started

1.1 Getting to Know Your Device and Accessories

1.2 Installing the USIM/SIM Card, Battery,

and Storage Card

1.3 Starting Up

1.4 The Today Screen

1.5 The Start Menu

1.6 Quick Menu

1.7 QuickTasks

1.8 HTC Home™

1.9 TouchFLO™

1.10 Status Icons

1.11 Programs

1.12 Settings

16 Getting Started

Getting Started 17

1.1 Getting to Know Your Device and Accessories

Top panel

POWER

Press to turn off the display temporarily. To turn off the power, press and hold for about 5 seconds. For more information, see “Starting Up” in this chapter.

Lanyard/Strap holder

Left panel

Volume Buttons

• Press the top or bottom to adjust the speaker volume.

• During a call, press the top or bottom to adjust the earpiece volume.

RESET

Remove the back cover to see the Reset button. With the stylus, press the RESET button to soft-reset your device.

Sync Connector/Earphone Jack/AC adapter connector

Connect the supplied USB cable to synchronize information or plug in the AC adapter to recharge the battery. You can also connect the supplied USB stereo headset for hands-free conversation or for listening to audio media.

Right panel

Stylus

CAMERA

Press to launch the Camera. See Chapter 11 for details.

microSD Slot

See "Installing a Storage Card" for details.

Front panel

Notification LEDs

* See description below.

Second Camera

Use this camera for video call conversations or to take a

Earpiece

Listen to a phone call from here.

Touch Screen

TALK

Press to answer an incoming call or dial a number.

20-key QWERTY keyboard

Slide up the front panel of the device to reveal the keyboard. Use to dial phone numbers and enter information.

* Right LED: Shows Green and Amber lights for HSDPA/UMTS/GSM/GPRS/EDGE

standby, message, and network status as well as for notification and battery charging status. Shows a flashing red light when the battery level reaches 5% or lower.

Left LED: Shows a flashing Blue light when the Bluetooth system is powered up and

ready to transmit/receive Bluetooth radio signals.

self-portrait.

NAVIGATION CONTROL/ ENTER

Press this multi-directional control up, down, left, or right to move through menus and program instructions; carry out the selection by pressing the center button.

END

Press to end a call or to return to the Today screen. Press and hold to open the Quick List where you can choose an action to do.

In the Quick List, touch

Settings (or tap Start > Settings > System tab > Long Press End Key) to set

the behavior when pressing and holding the END key.

18 Getting Started

Getting Started 19

User Ma

ual

Read Me First

Screen

Protector

Back panel

2 Megapixel Camera

See Chapter 11 for details.

Speaker

Self-portrait Mirror

Use it when taking selfportrait shots.

Accessories

4 7

Back Cover

Remove to install the SIM card and battery.

Bottom panel

Microphone

No. Accessory Function

1 Battery Insert into the device before turning it on.

2 Screen protector Stick on the touch screen to prevent scratches.

3 Stereo headset Provides a volume control slider and a Send/End button.

4 AC adapter Recharges the battery.

5 USB sync cable Connects your device to a PC and synchronizes data.

6 Extra stylus Use to tap items onscreen.

7 User manual and

ReadMeFirst

8 Pouch Acts as a protective carrying case for your device.

9 Getting Started

and Applications discs

Press the Send/End button to pick up a call or put a call on hold; press and hold the button to end the call.

References for using your device.

Source for additional tools and programs.

20 Getting Started

Getting Started 21

1.2 Installing the USIM/SIM Card, Battery, and Storage Card

Always turn off your device before installing or removing the USIM/SIM card or battery.

The USIM/SIM card contains your phone number, service details, and phonebook/message memory. Your device supports both 1.8V and 3V SIM cards. Some legacy SIM cards will not function with your device. You should consult with your service provider for a replacement SIM card. There may be fees for this service.

Your device contains a rechargeable Li-ion battery. It is designed to use only manufacturer-specified original batteries and accessories. Battery performance depends on many factors, including network configuration, signal strength, the temperature of the environment in which you operate your device, the features and/or settings you select and use, items attached to connecting ports, and your voice, data, and other program usage patterns.

Battery life estimates (approximations):

• Standby time: Up to 180 hours for GSM

Up to 250 hours for UMTS (Subject to network and phone usage)

• Talk time: Up to 5 hours for GSM.

Up to 3 hours for UMTS. (Subject to network and phone usage)

• Media playback time: Up to 4.95 hours for WMV;

Up to 6 hours for WMA.

Warning! To reduce risk of fire or burns:

• Do not attempt to open, disassemble, or service the battery pack.

• Do not crush, puncture, short external contacts, or dispose of in fire

or water.

• Do not expose to temperatures above 60oC (140oF).

• Replace only with the battery pack designated for this product.

• Recycle or dispose of used battery as stipulated by local regulations.

To remove the back cover

Before installing the USIM/SIM card or battery, you have to remove the back cover.

1. Make sure your device is turned o.

2. Hold the device securely with the front facing down.

3. With your thumb or ﬁnger, lift up the bottom of the back cover.

Lift from here

To install the USIM/SIM card

1. Pull back the red rubber door near the SIM card slot to allow you to

insert the USIM/SIM card.

2. Insert the USIM/SIM card with the gold contacts facing down and the

cut corner on the outside.

Note You can check the SIM card drawing on the SIM card slot to see how to

insert the USIM/SIM card.

3. Secure the USIM/SIM card in place by closing the red rubber door.

Cut corner of SIM card

Red rubber door

22 Getting Started

Getting Started 23

To install the battery

Install the battery by inserting it with its exposed copper part aligned with the protruding copper conductor on the lower-right side of the battery compartment.

Insert the bottom side of the battery first, then gently push the battery into place.

To replace the back cover

1. Secure the top part of the back

cover by ‘locking’ it into the 3 openings on the device.

2. Press the middle portion of the

back cover.

3. Press the bottom part of the

back cover to lock it into place. You should hear a click.

To install the microSD™ card

1. Pry open the rubber cover at the

bottom-left side of the device.

2. Insert the microSD card with the

gold contacts facing up.

3. Close the rubber cover.

Tip Press the microSD card to pop it

out of the slot.

Copper conductor

1.3 Starting Up

After inserting your USIM/SIM card and battery, you can now power on and start using your device.

Turn your device on and off

To turn on the power

Press and hold the POWER button for a few seconds.

When you turn on your device for the first time, a Quick Start Wizard will guide you through the calibration process and the setup of regional settings, date and time, and password. For more information about touch screen calibration, see “Calibrate the device”.

To turn off the power

Press and hold the POWER button for a few seconds.

A message will then be displayed, prompting you whether or not to turn off the device completely.

Auto configure the data connection settings

The first time you power on your device, you will see a notification message from the Connection Setup on the Today screen.

The Connection Setup can automatically configure your device’s data connections, such as GPRS, WAP, and MMS, for you so that you do not need to enter the settings manually onto your device.

24 Getting Started

Getting Started 25

To automatically configure data connection settings

1. When you see the notiﬁcation message from the Connection Setup,

tap Yes.

Notes • If you do not see the notification message, tap on the title bar to

• If your USIM/SIM card supports multiple network operator profiles, a

2. Connection Setup then starts to conﬁgure your device’s data

connection settings.

3. After the Connection Setup completes the conﬁguration, tap Restart.

For more information about the Connection Setup, see Chapter 10.

Charge the battery

New batteries are shipped partially charged. Before you start using your device, it is recommended that you charge the battery. Some batteries perform best after several full charge/discharge cycles. You can charge the battery in two ways:

•

Charging the device’s battery by connecting the power adapter.

• Connecting your device to a PC via the provided USB Sync cable.

Note Only the AC adapter and USB cable provided with your device should be

Charging is indicated by a solid amber light on the right LED indicator. As the battery is being charged while the device’s power is on, a charging icon ( ) will be shown on the title bar of the Today screen. After the battery has been fully charged, the right LED becomes green and a full battery icon ( ) appears on the Today screen’s title bar.

Warning! • Do not remove the battery from the device while you are charging it

display the message.

message will appear with network profile choices. Select the profile you want to use and tap OK.

used to charge the device.

using the AC or car adapter.

• As a safety precaution, the battery stops charging when it overheats.

Calibrate the device

Calibrating the touch screen involves tapping the center of a cross with the stylus as the cross moves around the screen. This process ensures that when you tap the screen with your stylus, the tapped item is activated.

If your device does not accurately respond to screen taps, follow these steps to re-calibrate it:

1. Tap Start > Settings > System tab > Screen.

2. On the General tab, tap Align Screen, then follow the onscreen

instructions to complete the calibration.

Manage screen settings

The device’s display has the following orientation modes: Portrait and Landscape. To change the orientation, tap Start > Settings > System tab > Screen, and select the orientation you want.

Tip To quickly change the screen orientation, you can also tap the Rotate Screen

icon in HTC Home’s Launcher. See “HTC Home” later in this chapter for details.

To smooth the edges of screen fonts for many programs, on the ClearType tab, select the Enable ClearType check box.

To increase the readability or to see more content on the screen, on the

Text Size tab, adjust the text size by moving the slider.

Switch your device to Sleep mode

Quickly pressing the POWER button turns off the display temporarily and switches your device to Sleep mode. Sleep mode suspends your device to a low power state while the display is off in order to save battery power.

Your device also automatically goes into Sleep mode when you leave the device idle after a certain amount of time.

To specify the timeout period before your device goes into Sleep mode

1. Tap Start > Settings > System tab > Power > Advanced tab.

2. Under On battery power, make sure the Turn off device if not used

for check box is selected.

3. Select the battery timeout period, then tap OK.

26 Getting Started

Getting Started 27

You will still be able to receive messages and calls while your device is in Sleep mode. Pressing the POWER button again or new incoming calls/ messages will wake up your device.

1.4 The Today Screen

The Today screen displays important information, such as upcoming appointments and status indicators. You can touch or tap a section on the screen to open the associated program.

Connection status

Notification

Open Start Menu

HTC Home (See “HTC Home” in this chapter for details)

Your upcoming appointments

Signal strength

Adjust volume

Battery status

Open Quick Menu (See “Quick Menu” in this chapter for details)

Enlarged Title Bar See third bulleted item below

1.5 The Start Menu

The Start menu, located at the top left corner of the Today screen, displays a list of programs. You can start a program by scrolling through the programs list and then pressing ENTER, or by tapping a program with the stylus.

Open a recently-used program.

Switch to the Today screen.

Open a program. (The items displayed in the Start menu can be customized by tapping Start > Settings > Personal tab > Menus).

Access more programs. View and change settings.

View Help information for the current screen.

Tip By default, the Start menu is displayed

in a large size to make it easier for you to select menu items by simply touching them with your finger. To display the Start menu in its normal size, tap Start >

Settings > Personal tab > Large Start Menu then clear the Enable large Start menu check box.”

• To access the Today screen, tap Start > Today.

• To customize the Today screen display, including the background

image, tap Start > Settings > Personal tab > Today.

• Touch the area in the Title bar where the icons are to show the

enlarged title bar. In the enlarged Title bar, touch the item to activate it. The enlarged Title bar is available in all screens.

For more information about customizing the Today screen, see Chapter 4.

28 Getting Started

Getting Started 29

1.6 Quick Menu

The Quick Menu, located at the top right corner of the Today screen, shows the currently running programs. You can quickly switch between running programs, stop programs, and see how much program memory is being used.

Customize how programs are closed. (See “Using Task Manager” in Chapter 12.)

Stop all currently running programs.

Tap this button to open the Quick Menu.

Shows the total program memory usage (in percentage). Tap to open Memory settings.

• To switch to a running program, tap the program name.

• To stop running a program, tap .

1.7 QuickTasks

QuickTasks lets you quickly

access frequently-used tasks by simply opening the front panel of the device.

The QuickTasks screenn only opens when you open the keyboard while on the Today screen.

You can disable the Quick Tasks by tapping Start >

Settings > System tab > Keypad QuickTasks and clearing the Enable QuickTasks when keypad is opened check box.

Note QuickTasks will not open when the screen orientation is in Landscape mode.

Touch to activate the item

1.8 HTC Home™

HTC Home™ is a Today screen plug-in that gives you up-to-date local

information at a glance, such as time, day and weather information, and shows new messages and missed calls. It also has a customizable launcher where you can add your favorite applications for one-touch access and a Profile selector where you can quickly change the profile or ring tone of your device.

HTC Home has four components: Home, Weather, Launcher and Sounds. At the bottom of HTC Home, there is a toolbar that allows you to switch between these components.

HTC Home Toolbar

Home Weather Launcher

To switch between the different components of HTC Home

Do any of the following:

• Touch the tabs in the toolbar using your ﬁnger.

• Tap the tabs in the toolbar using the stylus.

• Use the NAVIGATION CONTROL. If the toolbar is not selected, press

NAVIGATION up/down ﬁrst to select the toolbar. Press NAVIGATION left/right to select a tab and then press ENTER.

Sounds

30 Getting Started

Getting Started 31

Home

Home displays the current day, date and local time. When you have new

incoming messages and calls, it shows you the number of new e-mails, SMS/MMS messages, and missed calls. If you have set up the alarm, it also shows the Alarm icon.

Time display. Touch this display area when you want to change the date or time, or to enable the alarm.

Number of new e-mails. Touch this icon to view your e-mails.

Weather

Weather shows you the current weather as well as weather information of

the next four days of the week. The first time you use this feature, you need to select your city first to get the weather information of your city.

To select your city

Date Alarm icon

Number of missed calls. Touch this icon to view the Call History.

Number of new SMS/MMS messages. Touch this icon to view your SMS and MMS messages.

Tip You can also browse through the list of cities to choose your city.

4. Select the city on the list and tap Select.

To view weather information

After selecting your city, your device automatically connects to the Internet via GPRS/3G and downloads weather information of the current day and the next four days of the week. The current temperature, the highest and lowest temperatures, and a visual indicator of the climate (showing if it’s a cloudy or rainy day, etc.) will be displayed in the Weather tab.

Shows the time or days that have

Tap this area if you want to select another city.

Current day’s weather

Tap this area to return to the current day’s weather.

passed since the last download of weather information. Tap this item to download the latest weather data.

Tap this area to view weather information of the next four days of the week.

1. Select the Weather tab ( ).

2. Tap the area that shows Select your city here.

3. On the Select City screen, type in the city name whose weather

information you want to track, then tap .

Weather for the next 4 days

Note If you have not connected to the Internet and downloaded weather

information for five days, the following error message will be displayed: "Unable to retrieve data for selected city. Select here to retry." Use GPRS/3G to connect your device to the Internet, then tap the area that shows the error message to download weather data.

To customize weather settings

1. Tap the area that shows the city name.

2. On the Select City screen, select Menu > Weather Options.

32 Getting Started

Getting Started 33

3. You can enable or disable the following options:

Tip To check for more detailed weather information on the AccuWeather Web

Launcher

Launcher allows you to add quick shortcuts to your favorite programs and settings for one-touch access. Quick settings such as Adjust Backlight, Rotate Screen and Lock Device, and a few program shortcuts are added by

default. They can be replaced with your preferred settings and programs.

• Download weather data automatically. When this check box is

selected, weather information will automatically be downloaded from the AccuWeather Web site whenever you select the Weather tab, if the data

has not been updated within the last three hours. Weather data will also be downloaded every time an ActiveSync connection occurs (through overthe-air or USB connection).

Clear this check box if you prefer to manually download weather information.

• Download when roaming. Select

this check box only if you want to allow automatic download of weather data when roaming. This may incur additional costs.

• Temperature Scale. Choose

whether to display temperature in Celsius or Fahrenheit.

site, select Menu > About Weather on the Select City screen and then tap the link that shows AccuWeather.com. Internet Explorer Mobile then opens and brings you to the AccuWeather Web site.

Touch an empty slot to add a shortcut to a setting or your favorite program.

Touch a shortcut to remove it.

Return

Note To replace a shortcut, you need to delete it first and then add a shortcut to

your favorite program or setting.

Sound

Sound provides a selection of profiles, each preconfigured with a different

volume setting. It also lets you quickly change the ring tone of your device.

Tap to open the phone sound settings where you can select the ring tone.

Tap to set the device volume to Automatic profile. If Automatic is selected, the device will vibrate during a scheduled event in your calendar; when there is no scheduled event in your calendar, the device will use the

Normal mode settings.

Note For information about manually adjusting the device volume, see Chapter 3.

Tap a button to select a profile (from left to right):

Normal, Silent, Vibrate, Automatic

Touch a quick shortcut to open the associated program or apply the associated setting.

Remove shortcuts

34 Getting Started

Getting Started 35

1.9 TouchFLO™

TouchFLO™ is a special feature that gives you a better touch panel

experience on your device. With TouchFLO, you can simply use your finger to scroll and pan the screen.

TouchFLO also features the Touch Cube where you can launch messaging programs, Internet Explorer® Mobile, and more. You can also add your favorite contacts, play music, and access your pictures and videos.

Note Touch Cube is displayed in portrait view only. To be able to open Touch Cube,

make sure your display is set to portrait mode.

Touch Cube

To open the Touch Cube

Slide your finger upward, starting from the bottom of the touch screen where it shows a logo image.

To close the Touch Cube

To close the Touch Cube and return to the screen prior to opening the Touch Cube, slide your finger downward on the touch screen.

To navigate the Touch Cube

The Touch Cube is a three-dimensional, cubic user interface. To flip the interface from one side to another, slide your finger left or right on the touch screen.

Touch Cube screens

There are three sides to the Touch Cube interface:

• On the ﬁrst side of the interface, you can add up to nine favorite

contacts. If you make calls to certain people frequently, you can add them as favorite contacts for quicker access.

Note You should already have contacts with phone numbers stored on your

device or USIM/SIM card before you can add them as favorite contacts.

For more information about creating contacts, see Chapter 6. For more information about synchronizing contacts and other information between your device and PC, see Chapter 5. For information about synchronizing your device with the Exchange Server, see Chapter 8.

36 Getting Started

Getting Started 37

When you have different phone numbers assigned to the same contact, an icon appears on the top left corner of the contact square to tell you which number is assigned to the particular square.

Tap to call the number associated with the contact. Tap and hold to open the contact card.

Open the Phone program. (See Chapter 3 for details.)

Open Call History. (See Chapter 3 for details.)

Select a favorite contact to remove it.

Return to your list of favorite contacts.

When you add a favorite contact and there is no photo associated to that contact, the contact’s first name (or last name) will be displayed.

Select an empty slot to add a favorite contact. If the contact has more than one contact number, select the number to call when you touch the contact.

Delete favorite contacts.

Open Contacts. (See Chapter 6 for details)

• The second side of the interface

provides quick shortcuts to your e-mail messages, text and MMS messages, the Internet, and other applications.

Simply touch the icons on the screen to open the corresponding program.

• On the third side of the interface, you can play back music and access

the images and video ﬁles on your device.

Touch this icon to open Audio Manager and play back music files (For more information about using Audio Manager, see Chapter 11.)

While playback is in progress in Audio Manager, return to this screen. You will then see playback controls and the music title, artist, and remaining playback time of the current music.

Open Camera Album for still images. (See Chapter 11 for details.)

Open Camera Album for videos. (See Chapter 11 for details.)

Touch these buttons to control music playback. From left to right: Backward, Play/ Pause, Forward

38 Getting Started

Getting Started 39

Finger scrolling and finger panning

With TouchFLO, you can use finger scrolling and finger panning when viewing content that cannot be fit entirely on the screen, such as Web pages, documents, and messages. Finger scrolling can also be used to scroll up and down lists such as the contacts list, file list, message list, calendar appointments list, and more.

Note Finger scrolling and panning works in both portrait and landscape modes.

To use finger scrolling

• Slide your ﬁnger downward to scroll up the screen.

• Slide your ﬁnger upward to scroll down the screen.

• To scroll towards the left, slide your ﬁnger to the right.

• To scroll towards the right, slide your ﬁnger to the left.

• While the screen is scrolling, you can stop the scrolling by pressing

your ﬁnger on the touch screen.

Note Scrollbars on the screen indicate that there is more content that cannot fit

When finger scrolling up and down, slide anywhere within this area.

on the screen. You can finger-scroll up and down only when there's a vertical scrollbar shown on the screen. Likewise, you can finger-scroll left and right only when there's a horizontal scrollbar.

To use finger panning

• To pan downward, touch and hold on the touch screen then drag

your ﬁnger upward.

• To pan upward, touch and hold on the touch screen then drag your

ﬁnger downward.

• To pan towards the right, touch and hold on the touch screen then

drag your ﬁnger to the left.

• To pan towards the left, touch and hold on the touch screen then

drag your ﬁnger to the right.

• You can also pan diagonally.

Note Scrollbars on the screen indicate that there is content that cannot fit on the

screen. You can use finger panning only when there are scrollbars on the screen.

To continuously pan

1. Drag your ﬁnger towards the boundary and hold. The Web page,

document, or message that you are viewing then continuously pans.

Left and right boundaries

Top and bottom boundaries

2. Release your ﬁnger to stop panning.

40 Getting Started

Getting Started 41

To go to the next or previous message

While reading a message, slide your finger across the screen to go to the next or previous message.

To go to the next message, slide your finger from right to left on the screen; To go to the previous message, slide your finger from left to right on the screen.

To go to the next or previous messaging account

While on a messaging account screen, you can slide your finger across the screen to go to next or previous messaging account.

TouchFLO settings

You can enable or mute the finger scrolling and panning sound. Tap Start > Settings > System tab > TouchFLO then select or clear the Enable sound when finger scrolling and panning check box.

1.10 Status Icons

The following are some of the status icons that you may see on the device.

Icons that appear in this area

Connection Setup

There are more notifications. In the enlarged Title Bar, tap to view all New text messages; SMS notification of voice mail

Receiving MMS message

New MMS message received

Sending MMS message

MMS message sent

Cannot send MMS message

New instant message from Live Messenger

Missed call

Speakerphone on

Roaming

Alarm

Bluetooth stereo headset detected

ActiveSync notification

Synchronization error

Icons that appear in this area

GPRS available

EDGE available

HSDPA available

UMTS available

Connection is active

Connection is not active

Synchronization in progress

42 Getting Started

Getting Started 43

Icons that appear in this area

GPRS connecting

GPRS in use

EDGE connecting

EDGE in use

HSDPA connecting

HSDPA in use.

UMTS connecting

UMTS in use

Maximum signal strength

No signal

Phone is turned off

No phone service.

Searching for phone service

Voice call in progress

Call on hold

Calls are forwarded

Dialing while no SIM card is inserted

No SIM card inserted

Icons that appear in this area

Vibration mode

Sound on

Sound off

Icons that appear in this area

Battery charging

Battery full

Battery very low

1.11 Programs

The following are programs that are preinstalled on your device.

Programs in the Start Menu

Icon Description

Office Mobile Use the complete suite of Microsoft® Office applications

for your mobile device.

Excel Mobile Create new workbooks or view and edit Microsoft® Office Excel® workbooks.

PowerPoint Mobile View Microsoft® Office PowerPoint® slides and presentations.

Word Mobile Create, view, and edit Microsoft® Office Word documents.

Calendar Keep track of your appointments and create meeting requests.

Contacts Keep track of your friends and colleagues.

Internet Explorer Mobile Browse Web and WAP sites as well as

download new programs and files from the Internet.

Messaging Send and receive e-mail, MMS, and text messages.

Phone Make and receive calls, switch between calls, and set up

conference calling.

Help See Help topics for the current screen or program.

Programs screen

Icon Description

Games Play two pre-installed games: Bubble Breaker and Solitaire.

ActiveSync Synchronize information between your device and a PC or

the Exchange Server.

Adobe Reader LE View PDF (Portable Document Format) files on your device.

44 Getting Started

Getting Started 45

Icon Description

Audio Booster Enhances your music experience by providing you with

controls for adjusting equalizer, 3D sound, treble, and bass settings.

Audio Manager Browse and play back music files.

Bluetooth Explorer Search for other Bluetooth devices that have file

sharing enabled and access their Bluetooth shared folder.

Calculator Perform basic arithmetic and calculations, such as addition, subtraction, multiplication, and division.

Camera Take photos or shoots video clips with accompanying audio.

Camera Album View photos that you captured using the device's

camera.

Comm Manager Manage your device’s connections (including GPRS/3G, Bluetooth, and ActiveSync), turn the phone on or off, switch to ringer/ vibration mode, enable or disable the Direct Push function, and more.

File Explorer Organize and manage files on your device.

Flash Lite Player Play back Flash Lite™ files on your device.

Internet Sharing Connect your computer to the Internet using your

device's data connection.

Spb GPRS Monitor You will find this program in the provided disc. You can install and use this program to measure the amount of data transfers that you have made via the GPRS/3G or GSM network connection, and calculate network usage costs. See Chapter 13 for details.

Java Download and install Java applications, such as games and tools, on your device.

Messenger Use this mobile version of Windows Live Messenger to send and receive instant messages on your device.

Notes Create handwritten or typed notes, drawings, and voice recordings.

Pictures & Videos View, organize, and sort pictures, animated GIFs, and video files on your device or a storage card.

Icon Description

SAPSettings Enable Bluetooth Remote SIM access on your device.

Search Search contacts, data, and other information on your device.

SIM Manager Manage the contacts that are stored on your SIM card.

You can also use this program to copy SIM contents to Contacts on your device.

Sprite Backup You will find this program in the provided disc. You can install and use this program to back up your data and files. See Chapter 9 for details.

STK (SIM Tool Kit) Service Access information and other services offered by your wireless service provider.

Streaming Media Stream live or on-demand video.

Tasks Keep track of your tasks.

Voice Recorder Record your voice, play it back, then send it via e-mail,

MMS or beaming. You can also set the recorded voice as your ring tone.

Voice Speed Dial Record voice tags so that you can dial a phone number or launch programs simply by speaking a word.

Windows Live Use this mobile version of Windows Live™ to find information on the Web. It also lets you sign into your Windows Live account so that you can access your Live Mail messages and send/receive instant messages in Live Messenger.

Windows Media Player Mobile Play back audio and video files.

ZIP Save memory and free up storage space on your device by

compressing files in the conventional ZIP format.

46 Getting Started

Getting Started 47

1.12 Settings

You can adjust the device settings to suit the way you work. To see all available settings, tap Start > Settings, then tap the Personal, System, and

Connections tabs located at the bottom of the screen.

Personal tab

Icon Description

Buttons Assign a program or function to a hardware button.

Input Set options for each of the input methods.

Large Start Menu Enable or disable the large Start menu.

Lock Set a password for your device.

Menus Set what programs will appear in the Start menu.

Owner Information Enter your personal information on your device.

Phone Customize phone settings such as ring tone, set a PIN number for

your SIM card, and more.

Sounds & Notifications Enable sounds for events, notifications, and more, and set the type of notification for different events.

TTY Enable TTY (Teletypewriter) support for your device.

Today Customize the appearance and the information to be displayed

on the Today screen.

Voice Speed Dial Create voice tags for voice dialing contacts and SIM contacts as well as for launching programs.

System tab

Icon Description

About This is where you can see basic information such as the Windows

Mobile® version and type of processor used on your device. You can also specify a name for your device.

Backlight Set the backlight timeout and adjust brightness.

Certificates See information about certificates that are installed on your

device.

Clear Storage Tap this icon only when you need to remove all your data and files from the memory and reset your device to factory default settings.

Clock & Alarms Set the device clock to the date and time of your locale or to a visiting time zone when you’re traveling. Alarms can also be set at specified days and times of a week.

Device Information See information about the firmware version, hardware, identity, and the duration of calls made on your device.

Device Lock Select the Enable auto device lock check box to automatically lock the device when the backlight turns off.

Encryption Allow files on your storage card to be encrypted. Encrypted files will be readable only on your device.

Error Reporting Enable or disable the device's error reporting function. When this function is enabled and a program error occurs, technical data about the state of the program and your computer will be logged in a text file and delivered to Microsoft's technical support if you choose to send it.

External GPS Set the appropriate GPS communication ports, if required. You may need to do this when there are programs on your device that access GPS data or you have connected a GPS receiver to your device. See Help for details.

Key Lock Lock the buttons on your device except for the POWER button when the device is in Sleep mode. This ensures you will not switch the device on by accident and consume unnecessary power.

Keypad QuickTasks Enable or disable the QuickTasks screen when you open the front panel of the device.

48 Getting Started

Getting Started 49

Icon Description

Long Press End Key Lets you set the behavior when you press and hold

the END key.

Memory Check the device memory allocation status and memory card information. You can also stop currently running programs.

Microphone AGC Adjust the volume of your voice automatically when you are recording.

Power Check the remaining battery power. You can also set the timeout for turning off the display (switching device to Sleep mode) to conserve battery power.

Regional Settings Set the regional configuration to use, including the format for displaying numbers, currency, date, and time on your device.

Remove Programs Remove programs that you installed on your device.

Screen Change the screen orientation, re-calibrate the screen, and

change the screen text size.

Task Manager Stop running programs and set the Exit button ( ) to end programs immediately when you tap the button. For more information, see "Task Manager" in Chapter 12.

TouchFLO You can enable or mute the finger scrolling and panning sound. See "TouchFLO settings" in this chapter for details.

Windows Update Update Windows Mobile® on your device with the latest updates, security patches or fixes, if they are available.

Connections tab

Icon Description

Beam Set your device to receive incoming Bluetooth beams.

Bluetooth Turn Bluetooth on, set your device to visible mode, and scan

for other Bluetooth devices.

Connection Setup Configure your device’s data connections, such as GPRS, WAP, and MMS, based on the detected or selected network operator. See Chapter 10 for details.

Connections Set up one or more types of modem connections for your device, such as phone dial-up, GPRS, and more, so that your device can connect to the Internet or a private local network.

CSD Line Type Set the line type to use when making a circuit switch data (CSD) connection. Normally, you do not need to change the setting unless you encounter a problem on establishing a connection.

GPRS Setting Set the GPRS authentication method.

HSDPA Turn on or off High Speed Data Packet Access (HSDPA), a 3.5G

high-speed digital data service that provides downstream data rates up to 3.6 Mbps. Your wireless service provider must support this feature to be able to turn it on.

Network Cards Set up your device's network card.

SMS Service Set your device to send SMS text messages via a data

connection, such as GPRS or a circuit-switched connection.

USB to PC Set a USB serial connection between your device and PC when there are problems connecting ActiveSync.

50 Getting Started

Chapter 2

Entering and Searching

Information

2.1 Entering Information

2.2 Using the 20-key QWERTY Hardware Keyboard

2.3 Using the Onscreen Keyboard

2.4 Using Touch Keyboard

2.5 Using Touch Keypad

2.6 Using Symbol Pad

2.7 Using Letter Recognizer

2.8 Using Block Recognizer

2.9 Using Transcriber

2.10 Searching Information

52 Entering and Searching Information

Entering and Searching Information 53

2.1 Entering Information

When you start a program or select a field that requires text or numbers, you can either use the 20-key QWERTY hardware keyboard or one of the onscreen input methods to enter information.

20-key QWERTY hardware keyboard

To reveal the 20-key QWERTY keyboard, slide up the front panel of the device.

To toggle between showing and hiding the Input Panel, simply tap the Input Panel icon.

Input Panel (Touch Keyboard)

Input Selector arrow

Input Panel icon

Icon Input method

Onscreen Keyboard

Touch Keyboard

Slide up the front panel

Tip When dialing phone numbers, use the 20-key QWERTY keyboard.

Onscreen input methods

When you start a program or select a field that requires text or numbers, the Input Panel icon becomes available on the menu bar.

Tap the Input Selector arrow (that appears next to the Input Panel icon) to open a menu where you can select a text input method and customize input options. After selecting a text input method, the corresponding Input Panel is then displayed and you can use it to enter text.

Touch Keypad

Letter Recognizer or Block Recognizer

Transcriber

Note Some text input methods may not be available in certain language versions

of the device.

54 Entering and Searching Information

Entering and Searching Information 55

2.2 Using the 20-key QWERTY Hardware Keyboard

You can enter text, numbers, and symbols by using the 20-key QWERTY keyboard. When you select a field that requires entering text or numbers, the phone automatically selects the appropriate input mode.

To change the input method, press and hold and select the input method you want to use on the menu.

You can do the following with the 20-key QWERTY keyboard:

• To use all uppercase letters, press twice. To change back to all

lowercase letters, press again.

• To use a single uppercase letter, press and then press the

corresponding key.

• To enter a number or symbol (labeled in blue color), press and

then press the corresponding key.

• Press to open the Symbol pad.

• Press to insert a hard return. Press to delete the previous

character.

• Press and hold to access your voicemail.

• Press and hold to toggle between Vibrate and Ringer modes.

Multipress mode

In Multipress mode, you enter a character by pressing the key on which the character appears.

To enter text in Multipress mode

• To enter the ﬁrst character, press once. To enter the second character,

press twice, and so on.

• To enter characters that are on the same key, wait for the highlight on

the character to disappear before you press the key again.

XT9 mode

To form a word in XT9 mode, press the keys that contain the letters you want. As you enter letters, XT9 analyzes your keypresses and attempts to complete the word. XT9 also tries to predict your next word based on previous sentences you have type.

To enter text in XT9 mode

1. Press and hold the key.

2. On the menu, select XT9 English.

To change XT9 settings, press and hold and on the menu, select XT9 Settings.

Tip To type in all uppercase letters, press the key twice.

While typing, words will appear at the bottom of the screen. Use the NAVIGATION CONTROL to choose the word you want to insert and press ENTER.

Numeric mode

Input numbers by changing the input method to Numeric mode.

To enter numbers

1. Press and hold the key and select 123 on the menu.

2. On the keyboard, enter the number(s) you want.

+ 105 hidden pages
