HTC HD Mini Quick Start Guide

Your HTC HD mini

Quick start guide

2 Quick start guide

Before you do anything else, please read this

Charge the battery

The battery in your phone hasn’t been charged yet. While your
phone is charging, it’s important that you do not remove the
battery pack. Doing so can damage your phone. Also, please don’t
try to take your phone apart. (If you do, it may invalidate your
warranty.)

Choose a rate plan wisely

Your phone can use up a lot of Internet bandwidth really quickly.
Before you use your phone, we strongly recommend that you talk
to your mobile operator about data rates. If you’re on a standard
data plan, the costs could really add up. Switching to a flat-rate
plan could be a lot cheaper.

Know about privacy laws

Some countries have strict laws about how and when you can
record phone conversations. For example, you may need to tell the
person you’re speaking to before you start recording. It’s a good
idea to find out what the laws are where you live before you use
your phone’s recording feature.

And finally, a few important words from our legal team

(LIMITATION OF DAMAGES)

To the maximum extent permitted by applicable law, in no event
shall HTC or its affiliates be liable to you, any user, or third party
for any indirect, special, consequential, incidental or punitive
damages of any kind, arising in contract, tort, or otherwise,
including, but not limited to, injury, loss of revenue, loss of
goodwill, loss of business opportunity, loss of data, and/or loss of
profits, regardless of the foreseeability thereof or whether HTC or
its affiliates have been advised of the possibility of such damages.
And in no event shall the total liability of HTC or its affiliates
exceed the amount received from you, regardless of the legal
theory under which the cause of action is brought. The foregoing
does not affect any statutory rights which may not be disclaimed.

Quick start guide 3

This quick start guide will help you get started with
your phone. In this guide, we use the following
symbols to indicate important or useful information:

Notes Important information

Tips Safety precaution

For the complete user guide and other helpful
resources, check out the HTC support website at
www.htc.com/support.

Contents

1. What ’s in the box 4

2. Get to k now your p hone 4

3. Befo re you turn on your ph one 5

4. Get started 7

5. Star t scree n 7

6. Lock screen 8

7. Get your contacts in to the pho ne 8

8. Expe rienc e HTC Sense 9

9. Connect to the I nternet 15

10. Get your m essag es acros s 17

11. Use the camera 19

12. Share p hotos and videos 21

13. Manag e your pho ne’s wire less controls 24

14. Sync with your computer 24

15. Factory resetti ng 25

16. Troublesho oting tip s 26

4 Quick start guide

1. What’s in the box

Here’s what you should find inside the box:

Phone

•

Battery

•

USB cable

•

3.5mm stereo headset

•

Power adapter

•

This quick start guide

•

2. Get to know your phone

3.5 mm headset jack

Notification
LED

Volume
Control

Touch Screen

HOME

TALK/SEND

Earpiece
POWER

START

BACK

END

USB connector

3. Before you turn on your phone

Take the back cover off

Hold your phone securely.

1.

Pull from the gap on the

2.
top panel as shown.

Carefully remove the back

3.
cover.

Insert the SIM card

Insert the SIM card with its

1.
gold contacts facing down
and its cut-off corner
facing out from the slot.

Slide the SIM card

2.
completely into the slot.

Insert the battery

Insert the battery with its

1.
exposed copper contacts
into the phone first. The
exposed copper contacts
should be on the right
when you insert the battery.

Push the battery all the

2.
way in.

Quick start guide 5

6 Quick start guide

Insert a microSD card

1.

2.

Put the back cover on

1.

2.

You must install the back cover for the antenna to
function properly.

Charge the battery

1.

2.

If the AC adapter that comes with your phone has
interchangeable plugs, you must first attach the plug to
the AC adapter before charging the battery.

Insert a microSD card (not
included) into the slot with
its gold contacts facing
down.

Push it all the way in until
you hear a click.

Insert the tabs inside the
back cover into the holes
inside the bottom panel of
the phone.

Press the phone against
the back cover until it
clicks into place.

Plug the power adapter
into the USB connector at
the bottom of your phone.

Plug in the power adapter
to an electrical outlet to
start charging the battery.
It will take about three
hours for the battery to be
fully charged.

Quick start guide 7

After installing the SIM card, battery, and microSD card
and charging the battery, you are now ready to turn your
phone on for the first time. Press the POWER button to
turn on your phone.

Read on and start exploring what you can do with your
phone.

4. Get started

When you turn on your phone for the first time, your
phone displays tutorials and guides you to set up your
email accounts and favorite social networks. You can
follow the onscreen instructions to complete the setup,
or skip the setup and do it at another time by pressing
START and then tapping Setup.

5. Start screen

Press the START ( ) button
on your phone to open the Start
screen.

The Start screen gives you
access to the essential features
and programs of your phone.

8 Quick start guide

6. Lock screen

The Lock screen is displayed
whenever your phone is locked.
This prevents accidental button or
touch screen presses.

Your phone automatically locks
when the display is turned off
(automatically or you have
pressed the POWER button) and
your phone goes to sleep mode.

When you see the Lock screen,
slide the Unlock Bar down to
unlock your phone.

For more information about the Lock screen, refer to the
“Getting Started” chapter in the User Manual PDF.

7. Get your contacts into the phone

There are several ways to add contacts to your phone.

Creating new contacts

You can create new contacts and enter their phone
number, email address, and other details on your phone.

1. On the Home screen, slide to the People tab, tap All
People, and then tap New.

2. To add a photo of the contact, tap the Contact
Photo icon ( ) in the upper-left corner of the New
Contact Card screen. Choose whether to use the
person’s photo from Facebook or Outlook, select a
photo from Albums, or take the person’s photo using
the Camera.

3. Enter the contact details in the fields provided. You
can also assign a ringtone to the contact.

4. When finished, tap Done.

Quick start guide 9

On the New Contact Card screen, scroll down to the bottom
of the screen and then tap More to enter additional contact
details.

Synchronizing Outlook contacts

You can sync your Outlook contacts or the Exchange
Server (Outlook work account) with your phone. For more
information about synchronizing your phone with your
computer, see “Sync With Your Computer” in this guide.
Refer to the User Manual PDF to learn how to sync your
phone with the Exchange Server.

Synchronizing With Microsoft My Phone

Microsoft® My Phone syncs information between your
phone and a password-protected website hosted by
Microsoft. You can back up and restore your contacts,
calendar appointments, photos, and other information.
Refer to the User Manual PDF for details.

8. Experience HTC Sense

Discover HTC Sense™ on your phone, an intuitive,
seamless experience built upon three fundamental
principles — make it mine, stay close, and discover the
unexpected.

Personalized Home screen

See the time and weather of your
current location on the weather
clock of the Home screen. The
Home screen also displays your
upcoming appointment. Tap the
respective item when you want
to change the weather clock to
display another location, update
the weather information, or
access the Calendar.
