Dell™ Axim™ X50

Owner’s Manual

Models HC03U, HC03UL, and HD04U

www.dell.com | support.dell.com

Notes, Notices, and Cautions

NOTE: A NOTE indicates important information that helps you

make better use of your computer.

NOTICE: A NOTICE indicates either potential damage to

hardware or loss of data and tells you how to avoid the problem.

CAUTION: A CAUTION indicates a potential for property

damage, personal injury, or death.

Abbreviations and Acronyms

For a complete list of abbreviations and acronyms, see the "Glossary" on page 165.

____________________

Reproduction in any manner whatsoever without the written permission of Dell Inc. is strictly forbidden.

Trademarks used in this text: Dell, the DELL logo, Axim, TrueMobile,

Dimension, Inspiron,OptiPlex, Latitude, Dell Precision, PowerApp, PowerVault, PowerEdge, PowerConnect, and DellNet are trademarks of Dell Inc.; Intel, Pentium, and Celeron are registered trademarks and XScale and StrataFlash are trademarks of Intel Corporation; Microsoft,Windows,Windows Media, and ActiveSync are registered trademarks and Windows Mobile is a

trademark of Microsoft Corporation; Bluetooth is a registered trademark owned by Bluetooth SIG, Inc. and is used by Dell Inc. under license.

Other trademarks and trade names may be used in this document to refer to either the entities claiming the marks and names or their products. Dell Inc. disclaims any proprietary interest in trademarks and trade names other than its own.

Models HCO3U, HC03UL, and HD04U

July 2004 P/N N6966 Rev. A00

Contents

CAUTION: Safety Instructions . . . . . . . . . . 11

SAFETY: General

SAFETY: Power

SAFETY: Battery

SAFETY: Air Travel

SAFETY: Electromagnetic Compatibility Instructions

. . . . . . . . . . . . . . . 11

. . . . . . . . . . . . . . . 12

. . . . . . . . . . . . . . 13

. . . . . . . . . . . . . . . . . . 13

When Using Your Device

SAFETY: Ergonomic Computing Habits

SAFETY: Protecting Against Electrostatic Discharge

. . . . . . . . . . . . . . . . . . . 14

SAFETY: Battery Disposal

Finding Information

1 About Your Device

Front, Side, and Back Views . . . . . . . . . . . 17

Front and Side Views

Back View

Using the Battery

Installing and Removing the Battery

Charging the Battery

Connecting to a Computer

. . . . . . . . . . . . . . . . . . 19

. . . . . . . . . . . . . . . . . 19

. . . . . . . . . . . . . 13

. . . . 14

. . . . . . . . . . 15

. . . . . . . . . . . . . . . 15

. . . . . . . . . . . . . 17

. . . . . 20

. . . . . . . . . . . . . 22

. . . . . . . . . . . . 23

Contents 3

Using the Cradle . . . . . . . . . . . . . . . . 23

USB Charging

Using the Sync Cable

. . . . . . . . . . . . . . . . . 26

. . . . . . . . . . . . . 27

Checking Built-In Storage

Using Cards

. . . . . . . . . . . . . . . . . . . . 29

CompactFlash Cards

. . . . . . . . . . . . 28

. . . . . . . . . . . . . . 29

See the documentation that came with the card for information on using the card.

Secure Digital Memory Cards

Performing a Reset

Soft Reset

Hard Reset

. . . . . . . . . . . . . . . . 31

. . . . . . . . . . . . . . . . . . . 31

. . . . . . . . . . . . . . . . . . . 32

. . . . . . . . . 30

. . . 30

2 Using Microsoft® Windows Mobile™ 2003

Second Edition

Device Buttons and the Stylus . . . . . . . . . . 33

Today Screen

Status Icons

Programs

Program Buttons

Switcher Bar

. . . . . . . . . . . . . . . . . . . 33

. . . . . . . . . . . . . . . . . . . . 34

. . . . . . . . . . . . . . . . . . . . . 36

. . . . . . . . . . . . . . . . 36

. . . . . . . . . . . . . . . . . . 36

4 Contents

Navigation Bar and Command Bar

Pop-Up Menus

. . . . . . . . . . . . . . . . . . . 39

Finding and Organizing Information

Backing Up Data

. . . . . . . . . . . . . . . . . . 40

. . . . . . . . 38

. . . . . . . 39

3 Entering Information

Entering Text Using the Input Panel . . . . . . . 41

Typing With the Soft Keyboard

Letter Recognizer

Block Recognizer

Transcriber

Editing Typed Text

. . . . . . . . . . . . . . . 43

. . . . . . . . . . . . . . . . . . 43

. . . . . . . . . . . . . . 44

. . . . . . . . 42

Writing on the Screen

Editing Written Text

Drawing on the Screen

Creating a Drawing

Editing a Drawing

Recording a Message

Using My Text

. . . . . . . . . . . . . . . . . . . 50

. . . . . . . . . . . . . . 44

. . . . . . . . . . . . . 45

. . . . . . . . . . . . . . 48

. . . . . . . . . . . . . . . 48

. . . . . . . . . . . . . . . 49

4 Adjusting Settings

Personal Tab . . . . . . . . . . . . . . . . . . . 51

System Tab

Connections Tab

. . . . . . . . . . . . . . . . . . . . 51

. . . . . . . . . . . . . . . . . 52

5 Using Microsoft® ActiveSync

About ActiveSync . . . . . . . . . . . . . . . . . 53

Installing and Using ActiveSync

. . . . . . . . . 54

Contents 5

6 Scheduling and Communicating

About Microsoft® Pocket Outlook . . . . . . . . 55

Calendar

Contacts

Tasks

Notes

Messaging

. . . . . . . . . . . . . . . . . . . . . . 55

Using the Summary Screen

Creating Meeting Requests

. . . . . . . . . . . . . . . . . . . . . . 58

Finding a Contact

. . . . . . . . . . . . . . . 59

Using the Summary Screen

. . . . . . . . . . . . . . . . . . . . . . . . 59

. . . . . . . . . . . . . . . . . . . . . . . . 61

. . . . . . . . . . . . . . . . . . . . . 62

Synchronizing E-Mail Messages

. . . . . . . . . . 57

. . . . . . . . . . . 57

. . . . . . . . . . 59

. . . . . . . . 62

Connecting Directly to an E-Mail Server

Using the Message List

Composing Messages

. . . . . . . . . . . . 63

. . . . . . . . . . . . . . 65

Managing E-Mail Messages and Folders

Notifications

. . . . . . . . . . . . . . . . . . . . 67

7 Adding and Removing Programs

. . . . 63

. . . . 66

6 Contents

Adding Programs Using Microsoft® ActiveSync®69

Downloading Programs From the Internet

Adding a Program to the Start Menu

Using File Explorer on the Device

Using ActiveSync on the Computer

. . . . 70

. . . . . . . 70

. . . . . . . 71

Error when Installing Software . . . . . . . . . 71

Changing the Display Mode on Your Device

. . 72

Removing Programs

. . . . . . . . . . . . . . . 72

8 Using Companion Programs

Microsoft® Pocket Word . . . . . . . . . . . . . 73

Pocket Excel

Tips for Working in Pocket Excel

MSN Messenger

Setting Up

Working With Contacts

Chatting With Contacts

Microsoft Windows Media

. . . . . . . . . . . . . . . . . . . 75

. . . . . . . 77

. . . . . . . . . . . . . . . . . 77

. . . . . . . . . . . . . . . . . . 78

. . . . . . . . . . . . 78

. . . . . . . . . . . . 79

Player for Pocket PC 79

9 Using Microsoft® Pocket Internet Explorer

Mobile Favorites . . . . . . . . . . . . . . . . . 81

Conserving Memory

Mobile Favorites Folder

Favorite Links

. . . . . . . . . . . . . . 82

. . . . . . . . . . . . 82

. . . . . . . . . . . . . . . . . 83

Using AvantGo Channels

Browsing Mobile Favorites and the Web

10 Getting Connected

Using Infrared . . . . . . . . . . . . . . . . . . 87

. . . . . . . . . . . . . 83

. . . . . 84

Contents 7

Using Bluetooth® Wireless Technology . . . . . . 88

Using Wi-Fi (802.11b)

Creating a Modem Connection

Creating an Ethernet Connection

Creating a VPN Connection

Ending a Connection

Connecting Directly to an E-Mail Server

Getting Help on Connecting

11 Appendix

Specifications . . . . . . . . . . . . . . . . . . . 95

U.S. Terms and Conditions of Sale

Dell™ Software License Agreement

Regulatory Notices

FCC Notices (U.S. Only)

IC Notice (Canada Only)

CE Notice (European Union)

CE Mark Notice

Australia and New Zealand

VCCI Notice (Japan Only)

MIC Notice (Republic of Korea Only)

Polish Center for Testing and Certification Notice

NOM Information (Mexico Only)

. . . . . . . . . . . . . . . 88

. . . . . . . . . . 90

. . . . . . . . . 91

. . . . . . . . . . . . 92

. . . . . . . . . . . . . . . 93

. . . . . 93

. . . . . . . . . . . . 93

. . . . . . . . 99

. . . . . . . 103

. . . . . . . . . . . . . . . 105

. . . . . . . . . . . 106

. . . . . . . . . . . 107

. . . . . . . . . 108

. . . . . . . . . . . . . . . 108

. . . . . . . . . 110

. . . . . . . . . . 110

. . . . . 111

. . . . . . . . . . . . . 112

. . . . . . . 114

8 Contents

Wireless Regulatory Information

. . . . . . . . 115

Europe—CE Declaration of Conformity . . . . 115

Japan Standard

Canada—Industry Canada (IC)

FCC Standard

. . . . . . . . . . . . . . . . . . . . 119

Mexico

. . . . . . . . . . . . . . . . 118

. . . . . . . . 118

. . . . . . . . . . . . . . . . . 118

Singapore—Approved by IDA for Use in Singapore

Korea

. . . . . . . . . . . . . . . . . . . . . 120

Brazil

Radio Approvals

. . . . . . . . . . . . . . . 119

. . . . . . . . . . . . . . . 120

Contacting Dell

Limited Warranties

. . . . . . . . . . . . . . . . . . 120

. . . . . . . . . . . . . . . . 151

Limited Warranty for Dell-Branded Hardware Products (U.S. Only)

Total Satisfaction Return Policy (U.S. Only)

. . . . . . . . 151

. . 155

Limited Warranty Terms for Dell-Branded Hardware Products (Canada Only)

. . . . . . 156

"Total Satisfaction" Return Policy (Canada Only)

Dell Software and Peripherals (Canada Only)

. . . . . . . . . . . . . . . . . 160

. 161

1-Year End-User Manufacturer Guarantee (Latin America and the Caribbean Only)

Glossary

. . . . . . . . . . . . . . . . . . . . . . 165

. . . . 162

Index . . . . . . . . . . . . . . . . . . . . . . . . . . 169

Contents 9

10 Contents

FILE LOCATION: N:\systems\DiMaggio\OM\Paper\EN\N6966fi0.fm

CAUTION: Safety Instructions

Use the following safety guidelines to help ensure your own personal safety and to help protect your device and working environment from potential damage.

SAFETY: General

• Do not attempt to service the device yourself unless you are a trained service technician. Always follow installation instructions closely.

• If you use an extension power cable with your AC adapter, ensure that the total ampere rating of the products plugged in to the extension power cable does not exceed the ampere rating of the extension cable.

• Do not push objects into air vents or openings of your device. Doing so can cause fire or electric shock by shorting out interior components.

• Keep your device away from radiators and heat sources. Also, do not block cooling vents. Avoid placing loose papers underneath your device; do not place your device in a closed-in wall unit or on a bed, sofa, or rug.

• Place the AC adapter in a ventilated area, such as a desk top or on the floor, when you use it to run the device or to charge the battery. Do not cover the AC adapter with papers or other items that will reduce cooling; also, do not use the AC adapter inside a carrying case.

• The AC adapter may become hot during normal operation of your device. Use care when handling the adapter during or immediately after operation.

• Do not use your device in a wet environment, for example, near a bath tub, sink, or swimming pool or in a wet basement.

• If your device includes an integrated or optional (PC Card) modem, disconnect the modem cable if an electrical storm is approaching to avoid the remote risk of electric shock from lightning via the telephone line.

• To help avoid the potential hazard of electric shock, do not connect or disconnect any cables or perform maintenance or reconfiguration of this product during an electrical storm. Do not use your device during an electrical storm unless all cables have been disconnected and the device is operating on battery power.

• If your device includes a modem, the cable used with the modem should be manufactured with a minimum wire size of 26 American wire gauge (AWG) and an FCC-compliant RJ-11 modular plug.

• PC Cards may become very warm during normal operation. Use care when removing PC Cards after their continuous operation.

• Before you clean your device, disconnect the device from the electrical outlet. Clean your device with a soft cloth dampened with water. Do not use liquid or aerosol cleaners, which may contain flammable substances.

DELL CONFIDENTIAL – PRELIMINARY 7/29/04 - FOR PROOF ONLY

CAUTION: Safety Instructions 11

FILE LOCATION: N:\systems\DiMaggio\OM\Paper\EN\N6966fi0.fm

SAFETY: Power

• Use only the Dell-provided AC adapter approved for use with this device. Use of another AC adapter may cause a fire or explosion.

• Before you connect the device to an electrical outlet, check the AC adapter voltage rating to ensure that the required voltage and frequency match the available power source.

• To remove the device from all power sources, turn the device off, disconnect the AC adapter from the electrical outlet, and remove the battery installed in the battery bay.

• To help prevent electric shock, plug the AC adapter and device power cables into properly grounded power sources. These power cables may be equipped with 3-prong plugs to provide an earth grounding connection. Do not use adapter plugs or remove the grounding prong from the power cable plug. If you use a power extension cable,

www.dell.com | support.dell.com

use the appropriate type, 2-prong or 3-prong, to mate with the AC adapter power cable.

• Be sure that nothing rests on your AC adapter’s power cable and that the cable is not located where it can be tripped over or stepped on.

• If you are using a multiple-outlet power strip, use caution when plugging the AC adapter’s power cable into the power strip. Some power strips may allow you to insert the plug incorrectly. Incorrect insertion of the power plug could result in permanent damage to your device, as well as risk of electric shock and/or fire. Ensure that the ground prong of the power plug is inserted into the mating ground contact of the power strip.

SAFETY: Battery

• Use only Dell™ battery modules that are approved for use with this device. Use of other types may increase the risk of fire or explosion.

• Do not carry a battery pack in your pocket, purse, or other container where metal objects (such as car keys or paper clips) could short-circuit the battery terminals. The resulting excessive current flow can cause extremely high temperatures and may result in damage to the battery pack or cause fire or burns.

• The battery poses a burn hazard if you handle it improperly. Do not disassemble it. Handle a damaged or leaking battery pack with extreme care. If the battery is damaged, electrolyte may leak from the cells and may cause personal injury.

• Keep the battery away from children.

• Do not store or leave your device or battery pack near a heat source such as a radiator, fireplace, stove, electric heater, or other heat-generating appliance or otherwise expose it to temperatures in excess of 60ºC (140ºF). When heated to excessive temperatures, battery cells could explode or vent, posing a risk of fire.

DELL CONFIDENTIAL – PRELIMINARY 7/29/04 - FOR PROOF ONLY

12 CAUTION: Safety Instructions

FILE LOCATION: N:\systems\DiMaggio\OM\Paper\EN\N6966fi0.fm

• Do not dispose of your device’s battery in a fire or with normal household waste. Battery cells may explode. Discard a used battery according to the manufacturer’s instructions or contact your local waste disposal agency for disposal instructions. Dispose of a spent or damaged battery promptly.

SAFETY: Air Travel

• Certain Federal Aviation Administration regulations and/or airline-specific restrictions may apply to the operation of your Dell device while you are on board an aircraft. For example, such regulations/restrictions may prohibit the use of any personal electronic device (PED) that has the capacity for intentional transmission of radio frequency or other electromagnetic signals while on an aircraft.

– In order to best comply with all such restrictions, if your Dell portable device is

equipped with Dell TrueMobile™ or some other wireless communication device, please disable this device before you board the aircraft and follow all instructions provided by airline personnel with regard to such device.

– Additionally, the use of any PED, such as a portable device, may be prohibited in

aircraft during certain critical phases of flight, for example, takeoff and landing. Some airlines may further define the critical flight phase as any time the aircraft is below 3050 m (10,000 ft). Please follow the airline’s specific instructions as to when the use of a PED is allowed.

SAFETY: Electromagnetic Compatibility Instructions

Use shielded signal cables to ensure that you maintain the appropriate electromagnetic compatibility classification for the intended environment. For parallel printers, a cable is available from Dell. If you prefer, you can order a cable from Dell at its worldwide website at www.dell.com.

Static electricity can harm electronic components inside your device. To prevent static damage, discharge static electricity from your body before you touch any of your device’s electronic components, such as a memory module. You can do so by touching an unpainted metal surface.

WARNING:

accessories sold with this product, will expose you to lead, a chemical known to the State of California to cause birth defects or other reproductive harm.

Wash your hands after handling the cord

Handling the cord on this product, or cords associated with

When Using Your Device

Observe the following safe-handling guidelines to prevent damage to your device:

• When setting up the device for work, place it on a level surface.

DELL CONFIDENTIAL – PRELIMINARY 7/29/04 - FOR PROOF ONLY

When Using Your Device 13

FILE LOCATION: N:\systems\DiMaggio\OM\Paper\EN\N6966fi0.fm

• When traveling, do not check the device as baggage. You can put your device through an X-ray security machine, but never put your device through a metal detector. If you have the device checked by hand, be sure to have a charged battery available in case you are asked to turn on the device.

• When traveling, do not place the device in overhead storage compartments where it could slide around. Do not drop your device or subject it to other mechanical shocks.

• Protect your device and battery from environmental hazards such as dirt, dust, food, liquids, temperature extremes, and overexposure to sunlight.

• When you move your device between environments with very different temperature and/or humidity ranges, condensation may form on or within the device. To avoid damaging the device, allow sufficient time for the moisture to evaporate before using the device.

www.dell.com | support.dell.com

NOTICE: When taking the device from low-temperature conditions into a warmer

environment or from high-temperature conditions into a cooler environment, allow the device to acclimate to room temperature before turning on power.

• When you disconnect a cable, pull on its connector or on its strain-relief loop, not on the cable itself. As you pull out the connector, keep it evenly aligned to avoid bending any connector pins. Also, before you connect a cable make sure both connectors are correctly oriented and aligned.

• Handle components with care. Hold a component such as a memory module by its edges, not its pins.

• Clean the display with a soft, clean cloth and water. Apply the water to the cloth; then stroke the cloth across the display in one direction, moving from the top of the display to the bottom. Remove moisture from the display quickly and keep the display dry. Long-term exposure to moisture can damage the display. Do not use a commercial window cleaner to clean your display.

SAFETY: Ergonomic Computing Habits

CAUTION: Improper or prolonged keyboard use may result in injury.

CAUTION: Viewing the display or external monitor screen for extended periods of

time may result in eye strain.

SAFETY: Protecting Against Electrostatic Discharge

DELL CONFIDENTIAL – PRELIMINARY 7/29/04 - FOR PROOF ONLY

14 When Using Your Device

FILE LOCATION: N:\systems\DiMaggio\OM\Paper\EN\N6966fi0.fm

You can also take the following steps to prevent damage from electrostatic discharge (ESD):

• When unpacking a static-sensitive component from its shipping carton, do not remove the component from the antistatic packing material until you are ready to install the component. Just before unwrapping the antistatic packaging, be sure to discharge static electricity from your body.

• When transporting a sensitive component, first place it in an antistatic container or packaging.

• Handle all sensitive components in a static-safe area. If possible, use antistatic floor pads and workbench pads.

SAFETY: Battery Disposal

Your device uses a lithium-ion battery and a rechargeable NiMH battery. For instructions about replacing the batteries in your device, see "Using the Battery" on page 19.

Do not dispose of the battery along with household waste. Contact your local waste disposal agency for the address of the nearest battery deposit site.

Finding Information

What Are You Looking For? Find It Here:

How to set up my device and information on the connectors and buttons on my device

Information on using my device Dell Owner’s Manual and Pocket PC

Additional programs that can be installed on my device

Information on using programs on my device

Connecting to and synchronizing with a computer

The setup diagram and the Dell™

Owner’s Manual

Help.

To view Help, tap the Start button and tap Help.

Dell Companion CD

Pocket PC Help and, if available, tap Help within a specific program

Dell Owner’s Manual and Microsoft ActiveSync

Help on your computer.

To view Help, click Help and click Microsoft ActiveSync Help.

DELL CONFIDENTIAL – PRELIMINARY 7/29/04 - FOR PROOF ONLY

Finding Information 15

FILE LOCATION: N:\systems\DiMaggio\OM\Paper\EN\N6966fi0.fm

What Are You Looking For? Find It Here:

Last-minute updates and detailed technical information

The readme files, located in the ActiveSync folder on the computer and on the Dell Companion CD.

Up-to-date information on your

www.microsoft.com/windowsmobile

Pocket PC

My Service Tag Label located in the battery slot

(remove the battery)

www.dell.com | support.dell.com

DELL CONFIDENTIAL – PRELIMINARY 7/29/04 - FOR PROOF ONLY

16 Finding Information

About Your Device

Front, Side, and Back Views

CAUTION: Before performing any of the procedures in this section, read and

follow the safety instructions on page 11.

Front and Side Views

infrared sensor (top)

audio jack (top)

microphone

lanyard hook

CompactFlash card and Secure Digital memory

lock button

on/off button for WLAN/Bluetooth

record button

Calendar button

Contacts button

INFRARED SENSOR—The infrared sensor lets you transfer files from your device to

Inbox button

navigator button

About Your Device 17

wireless LED

power button

touch screen

Home button

FILE LOCATION: N:\systems\DiMaggio\OM\Paper\EN\N6966c10.fm

another infrared-compatible device without using cable connections.

MICROPHONE—Allows you to record audio.

OMPACTFLASH CARD AND SECURE DIGITAL MEMORY CARD SLOTS—See "Using Cards" on

page 29 for information on using CompactFlash cards and Secure Digital memory cards.

POWER BUTTON—Press the power button to turn the device on or off. Press and hold

the power button to dim the display. Repeat to light the display.

• When the device is connected to external power and the main battery is fully charged, the power button light is solid green.

• When the main battery charge is low, the power button light flashes amber.

• When the battery is being charged, the power button light is solid amber.

• When the device relays a notification, the power button light rapidly flashes

www.dell.com | support.dell.com

green.

TOUCH SCREEN—Use the touch screen and the stylus to enter information into your

device. See "Entering Information" on page 41.

ON/OFF BUTTON FOR WLAN/BLUETOOTH®WIRELESS TECHNOLOGY—On wireless devices, the

button turns both WLAN and Bluetooth wireless technology on and off. Turn off the wireless devices to conserve power. On non-WLAN devices, the button turns Bluetooth wireless technology on and off.

OME BUTTON —Press this button to launch Home or to turn on the device.

NAVIGATOR BUTTON—Press the right, left, top, or bottom of the navigator button to

move the cursor on the screen. Press the center to enter a selection.

ONTACTS BUTTON—Press this button to launch Contacts or to turn on the device.

ALENDAR BUTTON—Press this button to launch Calendar or to turn on the device.

RECORD BUTTON—See "Recording a Message" on page 49 for information on using

the record button.

LOCK BUTTON—Allows you to lock the device so that the device do not respond to

inadvertent pressing of keys.

DELL CONFIDENTIAL – PRELIMINARY 7/29/04 - FOR PROOF ONLY

18 About Your Device

FILE LOCATION: N:\systems\DiMaggio\OM\Paper\EN\N6966c10.fm

Back View

stylus (extended)

reset butto

battery

battery lock

cradle/sync cable connector (bottom)

BATTERY LOCK—

Use this switch to release and remove the main battery. See

"Installing and Removing the Battery" on page 20.

BATTERY—See "Using the Battery" on page 19 for information on the main battery.

CRADLE/SYNC CABLE CONNECTOR—Connect a cradle or sync cable. See "Connecting to

a Computer" on page 23.

RESET BUTTON—See "Performing a Reset" on page 31 for information on using the

reset button.

STYLUS—Use the stylus to write or draw on the screen. To remove the stylus, pull it

straight up and out of the holder. To avoid losing the stylus, store the stylus in the holder when you are not using it. Ensure that the stylus is oriented correctly when you replace it in the slot.

Using the Battery

NOTICE: Do not use your device until you have charged the main battery for at

least 8 hours for the first charge.

DELL CONFIDENTIAL – PRELIMINARY 7/29/04 - FOR PROOF ONLY

About Your Device 19

FILE LOCATION: N:\systems\DiMaggio\OM\Paper\EN\N6966c10.fm

Before you use your device for the first time, you must install and charge the battery. Once the battery is charged, use the power properties to monitor the battery charge. See Pocket PC Help on the device for more information.

Installing and Removing the Battery

To install the battery:

Ensure that the device is turned off.

Insert the right side of the battery into the battery slot at an angle, and lower the left side into the slot until it fits into the slot.

www.dell.com | support.dell.com

battery

Close the battery cover.

Lock the battery cover by sliding the battery latch to the right.

NOTE: The device will turn on immediately once the battery is inserted and

battery cover latch is locked.

DELL CONFIDENTIAL – PRELIMINARY 7/29/04 - FOR PROOF ONLY

20 About Your Device

FILE LOCATION: N:\systems\DiMaggio\OM\Paper\EN\N6966c10.fm

battery cover

battery latch

To remove the battery:

Slide the battery latch to the left to unlock the battery cover.

Lift the battery cover.

battery cover

battery latch

Pull the tab to lift the battery out of the slot.

DELL CONFIDENTIAL – PRELIMINARY 7/29/04 - FOR PROOF ONLY

About Your Device 21

FILE LOCATION: N:\systems\DiMaggio\OM\Paper\EN\N6966c10.fm

pull tab

battery

www.dell.com | support.dell.com

NOTE: Your Service Tag is located underneath the battery. You need your

Service Tag if you access Dell Support at support.dell.com or if you call Dell for customer service or technical support.

Charging the Battery

Use one of the following options to charge the main battery:

• Connect the AC adapter directly to the charger adapter and then to the device and to an electrical outlet.

• Connect the AC adapter directly to the sync cable and then to the device and to an electrical outlet.

• Connect the AC adapter to the cradle, and insert the device into the cradle. See "Using the Cradle" on page 23 for more information.

• Connect the cradle with the device to a computer, which is connected to an electrical outlet. See "USB Charging"

The Standard battery pack (1100mAh) gets completely charged in five hours and the Option battery pack (2200mAh) gets charged completely in 10 hours.

If the main battery is critically low, the device enters "deep sleep" mode and the device is powered off.

To recover from a critically low battery:

DELL CONFIDENTIAL – PRELIMINARY 7/29/04 - FOR PROOF ONLY

22 About Your Device

FILE LOCATION: N:\systems\DiMaggio\OM\Paper\EN\N6966c10.fm

Plug in the AC adapter or replace the main battery with a non-empty battery.

Press the power button to power on.

If you remove the main battery, the internal backup battery can last for up to 30 minutes in "deep sleep" mode. Do not remove the main battery if the backup battery power is low.

By default, the device will power off if the device is left unused for a period of time. See "System Tab" on page 51 for information about

Power

to set the

amount of time that the device can remain idle before it turns off.

Connecting to a Computer

You either connect your device to a computer using a cradle or directly to a computer using a sync cable. Connect your device to a computer to:

• Add programs to your device. See "Adding Programs Using Microsoft ActiveSync®" on page 69 for more information.

• Synchronize data on your device with data on your computer.

For information on synchronizing your data, see the following resources:

• "Using Microsoft

ActiveSync®" on page 53

• ActiveSync Help on your computer

• ActiveSync Help on your device

Using the Cradle

NOTE: Depending on the configuration of your device, the cradle is optional.

You can use the cradle to:

• Synchronize the data on your device with the data on your computer.

• Power the device with AC power to conserve battery power.

• Charge the main battery. See "Using the Battery" on page 19 for more information.

• Charge a spare battery.

NOTE: Before connecting your device to a computer for the first time, ensure

that you install ActiveSync on the computer from the Dell™ Companion CD.

To connect your device to the cradle:

DELL CONFIDENTIAL – PRELIMINARY 7/29/04 - FOR PROOF ONLY

About Your Device 23

FILE LOCATION: N:\systems\DiMaggio\OM\Paper\EN\N6966c10.fm

Place the cradle on a flat, level surface near your computer.

Connect the cradle cable to the USB connector on your computer.

power cord

www.dell.com | support.dell.com

AC adapter

cradle cable

cradle

USB connection to the computer

Connect the AC adapter to the cradle and to an electrical outlet.

DELL CONFIDENTIAL – PRELIMINARY 7/29/04 - FOR PROOF ONLY

24 About Your Device

FILE LOCATION: N:\systems\DiMaggio\OM\Paper\EN\N6966c10.fm

cradle

Align the connector on the bottom of the device with the connector on the cradle, and, keeping the front of the device flush with the front of the cradle, lower the device onto the cradle.

When the device is docked in the cradle, the connection status icon appears on the command bar (see page 34).

The spare battery status light on the cradle operates as follows:

• Green — The spare battery is fully charged.

• Amber — The spare battery is charging.

NOTE: The power button on the device indicates the charge status of the main

battery. See the description of the power button lights on page 18 for more information.

To remove the device from the cradle, pull the device straight up and out of the cradle.

DELL CONFIDENTIAL – PRELIMINARY 7/29/04 - FOR PROOF ONLY

About Your Device 25

FILE LOCATION: N:\systems\DiMaggio\OM\Paper\EN\N6966c10.fm

USB Charging

You can charge your device battery when the cradle with the device is connected to a computer by a USB cable, and the computer is plugged into an electrical outlet and turned on.

NOTE: USB charging will not take place if the device is turned on.

You can charge the battery using a 5V/500mA USB port when the device is turned off.

NOTE: If you are using an external USB hub with 5V/100mA ports to charge the

device battery, this may cause a temporary voltage drop in the hub, and other USB devices connected to the ports on the hub may not work normally till the

www.dell.com | support.dell.com

device is removed.

NOTE: Charging the battery through a USB port takes more time than direct AC

adapter charging.

NOTE:

The device charger stops the charging process after 7 hours. If you need more than 7 hours to charge the device battery, disconnect and reconnect the USB cable to restart the charging process.

DELL CONFIDENTIAL – PRELIMINARY 7/29/04 - FOR PROOF ONLY

26 About Your Device

FILE LOCATION: N:\systems\DiMaggio\OM\Paper\EN\N6966c10.fm

USB connection to the computer

Using the Sync Cable

Use the sync cable to connect your device directly to the computer without using the cradle.

NOTE: Depending on the configuration of your device, the sync cable is

optional.

To connect the sync cable:

Connect one end of the cable to the USB connector on your computer.

Connect the other end of the cable to your device.

DELL CONFIDENTIAL – PRELIMINARY 7/29/04 - FOR PROOF ONLY

About Your Device 27

FILE LOCATION: N:\systems\DiMaggio\OM\Paper\EN\N6966c10.fm

NOTICE: To avoid damaging the connector, press the two buttons on the sides

of the connector to release the self-lock structure before pulling the connector out of the device.

power cord

www.dell.com | support.dell.com

AC adapter

sync cable

device connector

sync cable connector

USB connection to the computer

Checking Built-In Storage

The amount of on-board flash memory in your device is dependent on the device configuration and the operating-system image size. The memory is non-volatile, so the data saved here is not lost even if the device is totally out of power.

To check the available non-volatile memory space on your device:

Tap t h e

DELL CONFIDENTIAL – PRELIMINARY 7/29/04 - FOR PROOF ONLY

28 About Your Device

Start

button and tap

System

tab and tap

Settings

Memory

FILE LOCATION: N:\systems\DiMaggio\OM\Paper\EN\N6966c10.fm

Tap the

Storage Card

tab, and then select

Built-in Storage

from the

drop-down menu to display the available space.

Using Cards

CompactFlash Cards

Your device supports CompactFlash Type II cards. Some common types of cards include:

• Modem — Connect a telephone line for modem data communications.

• Wireless communication — Perform data communications without the use of cable connections. You can use cards, such as internal cards with Bluetooth wireless technology and 802.11b wireless LAN.

• Storage — Save data or install programs on a storage card.

When you do not have a CompactFlash card installed, insert the plastic blank to protect the CompactFlash card slot.

To install a CompactFlash card:

1 If a blank is installed, remove it.

blank

tab

notch in CompactFlas card slot

2 Align the tab on the back of the CompactFlash card with the notch

in the CompactFlash card slot, and slide the card into the slot.

DELL CONFIDENTIAL – PRELIMINARY 7/29/04 - FOR PROOF ONLY

About Your Device 29

FILE LOCATION: N:\systems\DiMaggio\OM\Paper\EN\N6966c10.fm

NOTICE: Do not force the card. If you feel resistance, remove the card, check

the orientation, and reinsert it.

See the documentation that came with the card for information on using the card.

Secure Digital Memory Cards

Use Secure Digital memory cards to save or back up data.

To install a Secure Digital memory card:

If a card is already installed, press in the card to release it, and then

www.dell.com | support.dell.com

remove it.

blank

Ensure that the card is oriented correctly, and slide it into the slot until you feel a click.

NOTICE: Do not force the card. If you feel resistance, remove the card, check

the orientation, and reinsert it.

See the documentation that came with the card for information on using the card.

DELL CONFIDENTIAL – PRELIMINARY 7/29/04 - FOR PROOF ONLY

30 About Your Device

FILE LOCATION: N:\systems\DiMaggio\OM\Paper\EN\N6966c10.fm

Performing a Reset

Soft Reset

When you perform a soft reset, the device deletes any data that has not been saved but saves any data that has been stored in memory. Try performing a soft reset if the device does not respond when you tap the display or press a button.

To perform a soft reset, use the stylus reset tool to press the reset button.

reset tool

stylus

DELL CONFIDENTIAL – PRELIMINARY 7/29/04 - FOR PROOF ONLY

About Your Device 31

FILE LOCATION: N:\systems\DiMaggio\OM\Paper\EN\N6966c10.fm

reset toolreset button

www.dell.com | support.dell.com

Hard Reset

NOTICE: When you perform a hard reset, you lose all the data stored in your

device memory, and any programs that you installed on your device.

Perform a hard reset if:

• You want to delete all the data stored in your device memory.

• You forget your password and need to clear it.

• Your device is experiencing severe operational problems and you have already attempted a soft reset.

NOTICE: It is strongly recommended that you back up your data before you

perform a hard reset. See ActiveSync Help on your computer for more information.

To perform a hard reset:

Press and hold the power button.

Using the stylus reset tool, hold the reset button for about 2 seconds.

Follow the instructions on the screen.

DELL CONFIDENTIAL – PRELIMINARY 7/29/04 - FOR PROOF ONLY

32 About Your Device

Using Microsoft® Windows Mobile™ 2003 Second Edition

Device Buttons and the Stylus

Your device has hardware buttons that control actions and scroll functions, and a stylus for selecting items and entering information.

On the device, the stylus replaces the mouse:

• Tap — Touch the screen once with the stylus to open items and select options.

• Drag — Hold the stylus and drag across the screen to select text and images. Drag in a list to select multiple items.

• Tap and hold — Tap and hold the stylus on an item to see a list of actions available for that item. On the pop-up menu that appears, tap the action you want to perform.

See "Entering Information" on page 41 for more information.

Today Screen

When you turn on your device for the first time each day (or after 4 hours of inactivity), the tapping the the date and information about the device owner, today’s calendar, and important tasks. To customize the

Tap the

Use the

To da y

screen appears. You can also view the

Start

button and then tapping

Start

button and tap

Personal

Appearance

screen.

tab and tap

tab to change the background that displays on the

To da y

screen:

Settings

To da y

. The

To da y

screen displays

screen by

Use the

Items

tab to change the items that appear on the

Using Microsoft® Windows Mobile™ 2003 Second Edition 33

To da y

screen.

FILE LOCATION: N:\systems\DiMaggio\OM\Paper\EN\N6966c20.fm

Start button

www.dell.com | support.dell.com

connect configuration icon

volume control icon

status icon for Bluetooth wireless technology

New items menu

Status Icons

NOTE: If there is not enough room to display all notification icons, the

notification icon, , displays. Tap the notification icon to view all notifications.

Icon Description

Turns sound on and off.

DELL CONFIDENTIAL – PRELIMINARY 7/29/04 - FOR PROOF ONLY

34 Using Microsoft® Windows Mobile™ 2003 Second Edition

FILE LOCATION: N:\systems\DiMaggio\OM\Paper\EN\N6966c20.fm

Icon Description

Backup battery is low.

Main battery is charging.

Main battery is low.

Main battery is very low.

Main battery is full.

Connection is active. Tap the icon to configure connections.

Connection is not detected.

Wireless network is detected.

Synchronization is beginning or ending.

Synchronization is occurring.

New instant message(s).

New e-mail message(s).

DELL CONFIDENTIAL – PRELIMINARY 7/29/04 - FOR PROOF ONLY

Using Microsoft® Windows Mobile™ 2003 Second Edition 35

FILE LOCATION: N:\systems\DiMaggio\OM\Paper\EN\N6966c20.fm

Programs

You can switch from one program to another by selecting a program from the

Start

menu. To access programs that are not listed in the

Start

button, tap

Programs

, and then tap the program name.

NOTE: Some programs have abbreviated labels for check boxes and drop-

down menus. To see the full spelling of an abbreviated label, tap and hold the stylus on the label. Drag the stylus off the label so that the command is not carried out.

Program Buttons

You can also switch to some programs by pressing a program button. Your

www.dell.com | support.dell.com

device has four program buttons located on the front of the device. The icons on the buttons identify the programs to which they switch. By default, the buttons launch Home, Messaging, Contacts, and Calendar.

Switcher Bar

You can also use Switcher Bar to switch to or close open programs. To launch Switcher Bar:

Tap t h e

The Switcher Bar icon, , appears in the navigation bar.

Start

button and tap

System

tab and tap

Settings

Switcher Bar

Start

menu, tap the

Tap to view a list of all open programs. In the

•Tap

Brightness settings

Power settings

Switcher Bar

menu:

to configure those settings.

• Tap a program name to switch to that program.

•Tap

Exit current program

Exit all programs

Exit Switcher Bar

to close all open programs.

to close the menu.

to close the current program.

The following table contains a partial list of programs that are on your device. See the

Dell™ Companion

CD for additional programs that you can

install on your device.

DELL CONFIDENTIAL – PRELIMINARY 7/29/04 - FOR PROOF ONLY

36 Using Microsoft® Windows Mobile™ 2003 Second Edition

FILE LOCATION: N:\systems\DiMaggio\OM\Paper\EN\N6966c20.fm

Icon Program Description

ActiveSync Synchronize information

between your device and your computer.

Calendar Keep track of your

appointments and create meeting requests.

Contacts Keep track of your friends

and colleagues.

Messaging Send and receive e-mail

messages.

Pocket Internet Explorer Browse websites and WAP

sites, and download new programs and files from the Internet.

Notes Create handwritten or

typed notes, drawings, or recordings.

Tasks Keep track of your tasks.

Pocket Excel Create new workbooks or

view and edit Excel workbooks that you created on your computer.

MSN Messenger Send and receive instant

messages with your MSN Messenger contacts.

Pocket Word Create new documents or

view and edit Word documents that you created on your computer.

DELL CONFIDENTIAL – PRELIMINARY 7/29/04 - FOR PROOF ONLY

Using Microsoft® Windows Mobile™ 2003 Second Edition 37

FILE LOCATION: N:\systems\DiMaggio\OM\Paper\EN\N6966c20.fm

Navigation Bar and Command Bar

The navigation bar is located at the top of the screen. It displays the active program and current time and allows you to switch to other programs and close screens.

Use the command bar at the bottom of the screen to perform tasks in programs. The command bar includes menu names, icons, and the input panel icon. To create a new item in the current program, tap name of an icon, tap and hold the stylus on the icon. Drag the stylus off the icon so that the command is not carried out.

www.dell.com | support.dell.com

New

. To see the

navigation bar

Start menu

command bar

DELL CONFIDENTIAL – PRELIMINARY 7/29/04 - FOR PROOF ONLY

38 Using Microsoft® Windows Mobile™ 2003 Second Edition

FILE LOCATION: N:\systems\DiMaggio\OM\Paper\EN\N6966c20.fm

Pop-Up Menus

With pop-up menus, you can quickly select an action for an item. For example, you can use the pop-up menu in the contact list to delete a contact, make a copy of a contact, or send an e-mail message to a contact. The actions in the pop-up menus vary from program to program. To access a pop-up menu, tap and hold the stylus on an item name. When the menu appears, lift the stylus and tap the action you want to perform. To close the menu without performing an action, tap anywhere outside the menu.

Finding and Organizing Information

The Find feature on your device helps you to quickly locate information.

On the data type from the drop-down menu, and then tap

Start

menu, tap

DELL CONFIDENTIAL – PRELIMINARY 7/29/04 - FOR PROOF ONLY

Using Microsoft® Windows Mobile™ 2003 Second Edition 39

Find

. Enter the item that you want to find, select a

to start the search.

FILE LOCATION: N:\systems\DiMaggio\OM\Paper\EN\N6966c20.fm

You can also use the File Explorer to find files on your device and to organize your files into folders. On the

Explorer

Start

menu, tap

Programs

and tap

sort menu

File

www.dell.com | support.dell.com

folder location

Backing Up Data

To prevent or minimize data loss, you should periodically back up the data stored on your device. Use ActiveSync to synchronize the files on your device with the files on your computer. You can also drag and drop files from your device to your computer using Windows Explorer. See the ActiveSync Help on your computer for additional information.

DELL CONFIDENTIAL – PRELIMINARY 7/29/04 - FOR PROOF ONLY

40 Using Microsoft® Windows Mobile™ 2003 Second Edition

Entering Information

You have several options for entering information:

• Use the input panel to enter typed text using the soft keyboard or another input method.

• Write directly on the screen with the stylus.

• Draw pictures on the screen with the stylus.

• Speak into your device microphone to record a message.

Use Microsoft computer to your device. For more information on ActiveSync, see ActiveSync Help on your computer.

Entering Text Using the Input Panel

Use the input panel to enter information in any program on your device. You can type using the soft keyboard or write using Letter Recognizer, Block Recognizer, or Transcriber. The characters appear as typed text on the screen.

ActiveSync® to synchronize or copy information from your

input panel icon

To show or hide the input panel, tap the input panel icon. Tap the arrow next to the input panel icon to change input methods.

Entering Information 41

FILE LOCATION: N:\systems\DiMaggio\OM\Paper\EN\N6966c30.fm

When you use the input panel, your device anticipates the word you are typing or writing and displays it above the input panel. When you tap the displayed word, the word is inserted at the insertion point. The more you use your device, the more words it learns to anticipate.

www.dell.com | support.dell.com

suggested words

To change word suggestion options, such as the number of words suggested:

Tap t h e

Start

button and tap

Personal

tab, tap

Settings

Input

, and then tap the

Word Completion

tab.

Select the desired settings and tap OK.

Typing With the Soft Keyboard

Tap the arrow next to the input panel icon and tap

Tap the keys on the soft keyboard with your stylus.

DELL CONFIDENTIAL – PRELIMINARY 7/29/04 - FOR PROOF ONLY

42 Entering Information

Keyboard

FILE LOCATION: N:\systems\DiMaggio\OM\Paper\EN\N6966c30.fm

Letter Recognizer

Letter Recognizer allows you to use your stylus to write letters on the screen as you would write them on paper.

NOTE: Letter Recognizer is included with the English, French, German, Italian,

and Spanish operating systems. Other versions do not support Letter Recognizer.

Tap the arrow next to the input panel icon and tap

With your stylus, write a letter between the lines that appear on the

Letter Recognizer

bottom of the screen.

The letters are converted to typed text on the screen. For specific instructions on using Letter Recognizer, tap the question mark next to the writing area.

NOTE: Ta p Demo to learn the character strokes that the device can recognize.

Block Recognizer

Block Recognizer allows you to use character strokes that are similar to those used on other handheld devices.

NOTE: Block Recognizer is included with the English, French, German, Italian,

and Spanish operating systems. Other versions do not support Block Recognizer.

Tap the arrow next to the input panel icon and tap

Using your stylus, write the appropriate character stroke in the box that appears at the bottom of the screen.

The character strokes are converted to typed text on the screen. For specific instructions on using Block Recognizer, tap the question mark next to the writing area.

Block Recognizer

NOTE: Ta p Demo to learn the character strokes that the device can recognize.

Transcriber

Transcriber allows you to write anywhere on the screen using the stylus similar to the way that you would write on paper. Unlike Letter Recognizer and Block Recognizer, you can write a sentence or more, and then pause to let Transcriber change the written characters to typed characters.

DELL CONFIDENTIAL – PRELIMINARY 7/29/04 - FOR PROOF ONLY

Entering Information 43

FILE LOCATION: N:\systems\DiMaggio\OM\Paper\EN\N6966c30.fm

NOTE: Transcriber is included with the English, French, and German operating

systems. Other versions do not support Transcriber.

Tap the arrow next to the input panel icon and tap

With your stylus, write anywhere on the screen.

Transcriber

When you pause, Transcriber converts your written characters to typed characters. For specific instructions on using Transcriber, tap the question mark in the lower right hand corner of the screen.

Editing Typed Text

To edit or format typed text, you must select it first:

www.dell.com | support.dell.com

Drag the stylus across the text that you want to select.

Tap and hold the selected text.

Tap the appropriate editing command in the pop-up menu.

You can also tap

Edit

at the bottom of the screen to select editing

commands.

Writing on the Screen

In any program that accepts written text, such as the Notes program and the

Notes

tab in some programs, you can use your stylus to write directly on the screen. You can edit and format what you have written and convert the information to text at a later time.

NOTE: Some programs that accept written text may not have the pen icon. See

the documentation for that program to find out how to switch to writing mode.

To write on the screen, tap the pen icon to switch to writing mode. This action displays lines on the screen to help you write.

DELL CONFIDENTIAL – PRELIMINARY 7/29/04 - FOR PROOF ONLY

44 Entering Information

FILE LOCATION: N:\systems\DiMaggio\OM\Paper\EN\N6966c30.fm

pen icon

Editing Written Text

To edit or format written text, you must select it first:

Tap the pen icon to deselect it.

Drag the stylus across the text that you want to select.

Tap and hold the selected text.

Tap the appropriate editing command in the pop-up menu.

You can also tap commands.

Tap the pen icon to switch back to writing mode.

To convert written text to print-style text, tap

DELL CONFIDENTIAL – PRELIMINARY 7/29/04 - FOR PROOF ONLY

Edit

at the bottom of the screen to select editing

Tools

and tap

Entering Information 45

Recognize

FILE LOCATION: N:\systems\DiMaggio\OM\Paper\EN\N6966c30.fm

www.dell.com | support.dell.com

If you want to convert only certain words, select them before tapping

Recognize

(or tap and hold the selected words and then tap

Recognize

the pop-up menu). If a word is not recognized, it is not converted to printstyle text.

If the conversion is incorrect, you can select different words from a list of alternatives or return to the original written text:

Tap and hold the incorrect word.

On the pop-up menu, tap

Alternates

A menu with a list of alternative words appears.

Tap the correct word, or tap the written text at the top of the menu to return to the original written text.

DELL CONFIDENTIAL – PRELIMINARY 7/29/04 - FOR PROOF ONLY

46 Entering Information

FILE LOCATION: N:\systems\DiMaggio\OM\Paper\EN\N6966c30.fm

alternate words

Tips for getting good recognition:

• Write neatly.

• Write on the lines and draw descenders below the line. Write the cross of the "t" and apostrophes below the top line so that they are not confused with the word above. Write periods and commas above the line.

• For better recognition, try changing the zoom level to 300 percent using the

Tools

menu.

• Write the letters of a word closely and leave big gaps between words so that the device can easily determine where words begin and end.

• Hyphenated words, foreign words that use special characters such as accents, and some punctuation cannot be converted.

• You cannot add written text to a word to change it after the word has been recognized. You must delete the written word and write the new word.

DELL CONFIDENTIAL – PRELIMINARY 7/29/04 - FOR PROOF ONLY

Entering Information 47

FILE LOCATION: N:\systems\DiMaggio\OM\Paper\EN\N6966c30.fm

Drawing on the Screen

You can draw on the screen the same way that you write on the screen; however, selecting and editing drawings is different than selecting and editing written text. For example, selected drawings can be resized, while written text cannot.

Creating a Drawing

NOTE: To zoom in or out on your drawing, tap Tools and tap a zoom level.

Cross three ruled lines on your first stroke. A drawing box appears. Subsequent strokes that touch or are inside of the drawing box become part of the drawing. Drawings that do not cross three ruled lines are treated as

www.dell.com | support.dell.com

written text.

drawing box

Editing a Drawing

To edit or format a drawing, you must select it first:

DELL CONFIDENTIAL – PRELIMINARY 7/29/04 - FOR PROOF ONLY

48 Entering Information

FILE LOCATION: N:\systems\DiMaggio\OM\Paper\EN\N6966c30.fm

Tap and hold the stylus on the drawing until the selection handle appears.

To select multiple drawings, deselect the pen icon and drag to select the drawings.

Tap and hold the selected drawing and tap an editing command on the pop-up menu.

You can cut, copy, and paste selected drawings by tapping and holding the selected drawing and then tapping an editing command on the pop-up menu.

You can also tap

Edit

at the bottom of the screen to select editing

commands.

To resize a drawing, ensure that the Pen icon is not selected, and drag a selection handle.

Recording a Message

In any program where you can write or draw on the screen, you can also quickly capture thoughts, reminders, and phone numbers by recording a message. In Calendar, Tasks, and Contacts, you can include a recording in the

Notes

tab. In the Notes program, you can either create a stand-alone recording or include a recording in a written note. If you want to include the recording in a note, open the note first. In the Messaging program, you can add a recording to an e-mail message.

To record a message:

Hold the microphone near your mouth or other source of sound.

Press and hold the Record button on the side of your device until it beeps.

While holding down the Record button, make your recording.

To stop recording, release the Record button.

The device beeps twice. The new recording appears in the note list or as an embedded icon.

NOTE: You can also make a recording by tapping the Record icon on the

Recording toolbar.

DELL CONFIDENTIAL – PRELIMINARY 7/29/04 - FOR PROOF ONLY

Entering Information 49

FILE LOCATION: N:\systems\DiMaggio\OM\Paper\EN\N6966c30.fm

To play a recording, tap the name of the recording in the list or tap the speaker icon in the note.

Using My Text

When using Messaging or MSN Messenger, use My Text to quickly insert preset or frequently used messages. To insert a message, tap a message.

www.dell.com | support.dell.com

My Text

and tap

NOTE: You can add text to a My Text message after you insert the message.

To edit a My Text message:

In Messaging or MSN Messenger, tap

Ta p

Edit My Text Messages

Make the changes and tap OK.

DELL CONFIDENTIAL – PRELIMINARY 7/29/04 - FOR PROOF ONLY

50 Entering Information

Tools

Adjusting Settings

You can adjust the device settings to suit the way you work. To see available

Start

options, tap the

NOTE: Depending on the features of your device, you might have additional tabs

and additional items on the tabs.

See Pocket PC Help on your device for additional information on adjusting settings (tap the

button and tap

Start

button and tap

Personal Tab

•

Buttons

buttons.

Input

• other options.

•

Menus

•

Owner Information

•

Password

•

Sounds & Notification

"Notifications" on page 67 for more information.

•

To da y

the Today screen.

— Assign the programs that launch when you press the hardware

— Adjust the settings for input method, word completion, and

— Add or remove items from the

— Enter your contact information.

— Set a password to protect the data stored on your device.

— Adjust the volume and set notifications. See

— Customize the look and the information that is displayed on

Settings

Help

Start

menu.

System Tab

•

About

— Find information about Microsoft® Windows Mobile™ 2003

Second Edition and your device.

Brightness

•

Certificates

Certificates help establish your identity and the identity of other computers to prevent unauthorized users from accessing your data.

•

Clock & Alarms

— Adjust the brightness settings to conserve power.

— View or delete certificates stored on your device.

— Change the time or set the alarm.

Adjusting Settings 51

FILE LOCATION: N:\systems\DiMaggio\OM\Paper\EN\N6966c40.fm

•

Memory

— Allocate memory for data and program storage. View free

and used memory, storage card memory, and running programs.

•

Microphone

•

Power

— Adjust the microphone gain.

— Check the battery or charge status. Set the amount of time

that the device can remain idle before it turns off on the

•

Regional Settings

— View and change the formatting for regional

settings, such as currency, time, and date.

•

Remove Programs

— Remove programs from your device. For more

information, see "Adding and Removing Programs" on page 69.

•

Screen

— Adjust the screen if your device is not responding accurately

www.dell.com | support.dell.com

to taps, and select the screen orientation that you want to use. It can be hot launched by pressing the button immediately.

•

Switcher Bar

— Adjust the settings of the Switcher Bar program

launcher utility.

•

System Information

— View technical information about your device.

Connections Tab

Power

button followed by the

Advanced

Action

tab.

•

Beam

— Receive infrared beams from other devices.

•

Bluetooth

— Turn on the radio with Bluetooth® wireless technology

and off, and create and edit bonded devices. By default, the radio is off.

•

Connections

•

Dell WLAN Utility

•

Network Cards

DELL CONFIDENTIAL – PRELIMINARY 7/29/04 - FOR PROOF ONLY

52 Adjusting Settings

— Add and configure modem or server connections.

— Available only on devices with Wi-Fi.

— Configure your network adapter settings.

Using Microsoft® ActiveSync

About ActiveSync

You can synchronize the information on your computer with the information on your device with ActiveSync. Synchronization compares the data on your device with the data on your computer and updates both with the most recent information. For example:

• Keep Microsoft Pocket Outlook data up-to-date by synchronizing your device with Microsoft Outlook data on your computer.

• Synchronize Microsoft Word and Microsoft Excel files between your device and your computer. Your files are automatically converted to the correct format.

NOTE: By default, ActiveSync does not automatically synchronize all types of

information. You can change ActiveSync options to synchronize specific types of information.

With ActiveSync, you can also:

• Back up and restore your device data.

• Copy (rather than synchronize) files between your device and your computer.

• Select a synchronization mode to control when synchronization occurs. For example, you can synchronize continuously or only when you select the synchronize command.

• Select which information types are synchronized and control how much data is synchronized. For example, you can choose how many weeks of past appointments you want synchronized.

To synchronize your data, you need both the Microsoft Windows PC versions of ActiveSync. You must install the Windows version of ActiveSync on your computer using the version is already installed on your device.

Dell™ Companion

and Pocket

CD. The Pocket PC

NOTE: Before connecting your device to a computer for the first time, ensure that

you install ActiveSync on the computer from the Dell™ Companion CD.

Using Microsoft ActiveSync 53

FILE LOCATION: N:\systems\DiMaggio\OM\Paper\EN\N6966c50.fm

Installing and Using ActiveSync

To install ActiveSync:

Insert the

Click

After the installation is complete, the ActiveSync Setup Wizard helps you to connect your device to your computer, set up a partnership so that you can synchronize information between your device and your computer, and customize your synchronization settings. Your first synchronization process

www.dell.com | support.dell.com

automatically begins when you complete the wizard.

NOTE: The device must be powered on for the synchronization process to

occur.

During your first synchronization, information that was stored in Outlook on your computer is copied to Calendar, Contacts, and Tasks on your device.

After you set up ActiveSync and complete the first synchronization process, you can initiate synchronization from your device. To switch to ActiveSync on your device, tap the wireless LAN card, you can synchronize remotely from your device.

To find information on using ActiveSync on your device, open ActiveSync on your device, tap the

To find information on using ActiveSync on your computer, open ActiveSync on your computer, and click

Dell Companion

Getting Started

Start Here

to access the main menu.

Install ActiveSync

Start

button and tap

Start

button, and then tap

CD.

and follow the instructions on the screen.

ActiveSync

. If you have a

Help

Help→ Microsoft ActiveSync Help

DELL CONFIDENTIAL – PRELIMINARY 7/29/04 - FOR PROOF ONLY

54 Using Microsoft ActiveSync

Scheduling and Communicating

About Microsoft® Pocket Outlook

Pocket Outlook includes Calendar, Contacts, Tasks, Messaging, and Notes. You can use these programs individually or together. For example, e-mail addresses stored in Contacts can be used to address e-mail messages in Messaging.

Using Microsoft ActiveSync Outlook or Microsoft Exchange on your computer with your device. You can also synchronize this information directly with an Exchange server. Each time you synchronize, ActiveSync compares the changes you made on your device and computer or server and updates both computers with the latest information. For information on using ActiveSync, see ActiveSync Help on your computer.

You can switch to any of the following programs through the

Calendar

Use Calendar to schedule appointments, including meetings and other events. You can check your appointments in one of several views (Agenda, Day, Week, Month, and Year) and easily switch views by using the view menu. Tap the today icon to view the current date.

, you can synchronize information in Microsoft

Start

menu.

Scheduling and Communicating 55

FILE LOCATION: N:\systems\DiMaggio\OM\Paper\EN\N6966c60.fm

www.dell.com | support.dell.com

today icon

view menu

input panel icon

NOTE: To customize Calendar, such as changing the first day of the week, tap

Tools and tap Options.

To create an appointment:

In the Day or Week view, tap the desired date and time for the appointment.

Ta p

New

Tap a field to select it, and enter a description and a location using the input panel.

If necessary, tap the date and time to change them.

To see all available fields, tap the input panel icon to hide it. Enter the remaining information, if necessary.

To add notes, tap the

DELL CONFIDENTIAL – PRELIMINARY 7/29/04 - FOR PROOF ONLY

56 Scheduling and Communicating

Notes

tab.

FILE LOCATION: N:\systems\DiMaggio\OM\Paper\EN\N6966c60.fm

You can enter text, draw, or create a recording. For more information on creating notes, see "Notes" on page 61.

When you have finished entering information, tap OK to return to the calendar.

To receive a notification for an appointment, select

Remind me

in the appointment settings. You can configure notifications through the Sounds & Notifications icon. For more information, see "Notifications" on page 67.

Using the Summary Screen

When you tap an appointment in Calendar, a summary screen displays. To change the appointment, tap

Edit

Creating Meeting Requests

You can use Calendar to set up meetings with users of Outlook or Pocket Outlook. The meeting request is automatically created when you synchronize Messaging or when you connect to your e-mail server. To set how you want meeting requests sent, tap and receive e-mail messages through ActiveSync, select

To schedule a meeting:

Create an appointment.

On the

Attendees

The

Appointment

Attendees

tab, tap the input panel to hide it, and then tap

field lists the e-mail addresses that you have entered in

Contacts.

Tools

and tap

Options

. If you send

ActiveSync

Select the meeting attendees.

The meeting notice is created automatically and placed in the

Outbox

folder.

For more information on sending and receiving meeting requests, tap the

Start

button, tap

DELL CONFIDENTIAL – PRELIMINARY 7/29/04 - FOR PROOF ONLY

Help

, and then tap

Calendar

Scheduling and Communicating 57

Messaging

FILE LOCATION: N:\systems\DiMaggio\OM\Paper\EN\N6966c60.fm

Contacts

Use Contacts to maintain a list of your friends and colleagues. You can quickly share Contacts information with other device users using the infrared port.

Categories

and select a category

from the list. In the task list, you can display tasks by category.

To add notes, tap the

Notes

tab. You can enter text, draw, or create a recording. For more information on creating notes, see "Notes" on page 61.

When you have finished entering information, tap OK to return to the calendar.

DELL CONFIDENTIAL – PRELIMINARY 7/29/04 - FOR PROOF ONLY

60 Scheduling and Communicating

FILE LOCATION: N:\systems\DiMaggio\OM\Paper\EN\N6966c60.fm

NOTE: To quickly create a task with only a subject, tap Tools and tap Entry Bar.

Ta p Tap here to add a new task, and enter your task information.

Notes

Quickly capture thoughts, reminders, ideas, drawings, and phone numbers with Notes. You can create a written note or a recording. You can also include a recording in a note. If a note is open when you create the recording, it is included in the note as an icon. If a note is not open, the recording is saved as a stand-alone recording.

record icon

pen icon

input panel icon

To create a note:

Tap the

DELL CONFIDENTIAL – PRELIMINARY 7/29/04 - FOR PROOF ONLY

Start

menu, tap

Programs

, and then tap

Scheduling and Communicating 61

Notes

FILE LOCATION: N:\systems\DiMaggio\OM\Paper\EN\N6966c60.fm

Ta p

New

Create your note by writing, drawing, typing, or recording. For more information on using the input panel, writing and drawing on the screen, and creating recordings, see "Entering Information" on page 41.

Messaging

Use Messaging to send and receive e-mail messages:

• Synchronize e-mail messages using Exchange or Outlook on your computer.

• Send and receive e-mail messages by connecting directly to an e-mail

www.dell.com | support.dell.com

server through an ISP or a network.

Synchronizing E-Mail Messages

You can synchronize e-mail messages along with the rest of your data if you enable Messaging synchronization in ActiveSync. For information on enabling Messaging synchronization, see ActiveSync Help on your computer.

NOTE: You can also synchronize e-mail messages with your computer from a

remote location. For more information, see "Getting Connected" on page 87.

During synchronization:

• Messages are copied from the e-mail folders of Exchange or Outlook on your computer to the

ActiveSync

By default, you receive:

– Messages from the past 3 days

– The first 100 lines of each message

– File attachments of less than 100 KB in size

• E-mail messages in the

Outbox

Exchange or Outlook on your computer, and then sent from those programs.

• E-mail messages in subfolders on your computer must be selected in ActiveSync to be transferred.

folder in Messaging on your device.

folder on your device are transferred to

DELL CONFIDENTIAL – PRELIMINARY 7/29/04 - FOR PROOF ONLY

62 Scheduling and Communicating

FILE LOCATION: N:\systems\DiMaggio\OM\Paper\EN\N6966c60.fm

Connecting Directly to an E-Mail Server

In addition to synchronizing e-mail messages with your computer, you can send and receive e-mail messages by connecting to an e-mail server using a modem or network card connected to your device. You need to set up a remote connection to a network or an ISP, and a connection to your e-mail server. For more information, see "Getting Connected" on page 87.

When you connect to the e-mail server:

• New messages are downloaded to the device

• Messages in the device

Outbox

folder are sent.

• Messages that have been deleted on the e-mail server are removed from the device

Inbox

folder.

Messages that you receive directly from an e-mail server are linked to your e-mail server rather than to your computer. When you delete a message on your device, it is also deleted from the e-mail server the next time you connect depending on the settings you selected in ActiveSync.

When you are working online, you read and respond to messages while connected to the e-mail server. Messages are sent as soon as you tap which saves space on your device.

After you have downloaded new message headers or partial messages, you can disconnect from the e-mail server and then decide which messages to download completely. The next time you connect, Messaging downloads the messages you have marked for retrieval and sends the messages you have composed.

Inbox

folder.

Send

Using the Message List

Messages you receive are displayed in the message list. By default, the most recently received messages are displayed first in the list.

When you receive a message, tap to open it. Unread messages are displayed in bold.

DELL CONFIDENTIAL – PRELIMINARY 7/29/04 - FOR PROOF ONLY

Scheduling and Communicating 63

FILE LOCATION: N:\systems\DiMaggio\OM\Paper\EN\N6966c60.fm

www.dell.com | support.dell.com

delete icon

previous/next message

forward icon

When you connect to your e-mail server or synchronize with your computer, you receive by default:

• Messages from the last 5 days

• The first 100 lines of each new message

• File attachments of less than 100 KB in size

The original messages remain on the e-mail server or your computer. You can mark the messages that you want to retrieve in full during your next synchronization or e-mail server connection. In the message list, tap and hold the message that you want to retrieve. On the pop-up menu, tap

for Download

DELL CONFIDENTIAL – PRELIMINARY 7/29/04 - FOR PROOF ONLY

64 Scheduling and Communicating

. The icons in the Inbox message list indicate message status.

Mark

FILE LOCATION: N:\systems\DiMaggio\OM\Paper\EN\N6966c60.fm

You specify your downloading preferences when you set up the service or select your synchronization options. You can change the settings at any time:

• Change options for Messaging synchronization using ActiveSync options. For more information, see ActiveSync Help on your computer.

• Change options for direct e-mail server connections in Messaging on your device. Tap

Tools

and tap

Options

. On the

Account

tab, tap the

service that you want to change. Tap and hold the service and select

Delete

to remove a service.

Composing Messages

To compose a message:

Tap the

Ta p

New

Start

button and tap

Messaging

Contacts icon

record icon

DELL CONFIDENTIAL – PRELIMINARY 7/29/04 - FOR PROOF ONLY

Scheduling and Communicating 65

FILE LOCATION: N:\systems\DiMaggio\OM\Paper\EN\N6966c60.fm

In the To field, enter an e-mail of one or more recipients, separating them with a semicolon. Or tap the Contacts icon to select names from the contact list.

NOTE: All e-mail addresses entered in the e-mail fields in Contacts appear in

the Address Book.

Compose your message. To enter preset or frequently used messages,

My Text

tap

Ta p

Send

If you are working offline, the message is moved to the

and select a message.

when you have finished the message.

Outbox

folder

and sent the next time you connect.

www.dell.com | support.dell.com

Managing E-Mail Messages and Folders

By default, messages are displayed in one of five folders for each service you have created:

Deleted Items

device. The behavior of the on the options you have selected.To change the options, tap message list and tap

To create a new folder, tap

Inbox,Deleted Items,Drafts,Outbox

, or

Sent Items

. The

folder contains messages that have been deleted on the

Options

Tools

Deleted Items

. On the

, and tap

and

Sent Items

Message

tab, select your options.

Manage Folders

folders depends

Tools

in the

. To move a message to another folder, tap and hold the message in the message list and tap

Move to

on the pop-up menu.

Folder Behavior With a Direct Connection to an E-Mail Server

The behavior of the folders you create depends on whether you use ActiveSync, POP3, or IMAP4.

•

If you use ActiveSync

, e-mail messages in the

Inbox

folder in Outlook are automatically synchronized with your device. You can select to synchronize additional folders by designating them for ActiveSync. The folders you create and the messages you move are then mirrored on the server. For example, if you move messages from the to a folder named synchronization, the server creates a copy of the

Family

, and you have designated

Family

folder and

Inbox

for

copies the messages into that folder. You can then read the messages while away from your computer.

DELL CONFIDENTIAL – PRELIMINARY 7/29/04 - FOR PROOF ONLY

66 Scheduling and Communicating

folder

FILE LOCATION: N:\systems\DiMaggio\OM\Paper\EN\N6966c60.fm

•

If you use POP3 and you move e-mail messages to a folder you created

, the link is broken between the messages on the device and their copies on the e-mail server. The next time you connect, the e-mail server detects that the messages are missing from the device Inbox and deletes them from the server. This prevents you from having duplicate copies of a message. However, you no longer have access to messages that you move to folders created from anywhere except the device.

•

If you use IMAP4

, the folders you create and the e-mail messages you move are mirrored on the server. Therefore, messages are available to you any time you connect to your e-mail server, whether it is from your device or computer. This synchronization of folders occurs whenever you connect to the server, create new folders, or rename/delete folders when connected.

Notifications

You can set your device to remind you when you have something to do. For example, if you have set up an appointment in Calendar, a task with a due date in Tasks, or an alarm in Clock, you are notified in one of the following ways:

• A message box appears on the screen.

• A sound, which you can specify, is played.

• A light flashes on your device.

To configure the reminders and sounds for your device:

Tap the

On the

•

Start

button and tap

Personal

Sounds

tab — Adjust the volume and enable sounds.

Notifications

tab, tap

Settings

Sounds & Notifications

tab — Set notifications for specific events.

DELL CONFIDENTIAL – PRELIMINARY 7/29/04 - FOR PROOF ONLY

Scheduling and Communicating 67

FILE LOCATION: N:\systems\DiMaggio\OM\Paper\EN\N6966c60.fm

www.dell.com | support.dell.com

DELL CONFIDENTIAL – PRELIMINARY 7/29/04 - FOR PROOF ONLY

68 Scheduling and Communicating

Adding and Removing Programs

Programs that were already installed when you received your device are stored in ROM. You cannot remove these programs, and you never accidentally lose ROM contents. ROM programs can be updated using installation programs

*.xip

with the

You can install any program created for your device as long as your device has sufficient memory. The most popular place to find software for your device is on the Microsoft

www.microsoft.com/windowsmobile

extension. You can save data to either ROM or RAM.

Windows Mobile™ 2003 Second Edition website:

Adding Programs Using Microsoft

*.zip

Start

button and tap

System

tab, tap

Ver si on

file, a

Setup.exe

*.exe

Settings

About

tab, record the processor information.

file, or several versions of files for different

file.

ActiveSync

You need to install the appropriate software for your device on your computer before installing software on your device. See "Using Microsoft on page 53 for more information.

Determine your device and processor type so that you know which version of the software to install:

Tap the

On the

From the

Download the software to your computer (or insert the CD or floppy that contains the software into your computer). You may see a single

*.exe

, or device types and processors. Ensure that you select the program designed for the Pocket PC and your device processor type.

Read any installation instructions, readme files, or documentation that comes with the program. Many programs provide special installation instructions.

Connect your device to your computer.

Double-click the

ActiveSync®"

*.xip

Adding and Removing Programs 69

FILE LOCATION: N:\systems\DiMaggio\OM\Paper\EN\N6966c70.fm

If the file is an installer file, the installation wizard begins. Follow the directions on the screen. Once the software has been installed on your computer, the installer automatically transfers the software to your device.

If the file is not an installer file, you receive an error message stating that the program is valid but that it is designed for a different type of computer. You need to move this file to your device. If you cannot find any installation instructions for the program in the readme file or documentation, use ActiveSync Explore to copy the program file to the

Program Files

folder on your device. For more information on copying

files using ActiveSync, see ActiveSync Help on your computer.

www.dell.com | support.dell.com

To open a program after the installation is complete, tap the tap

Programs

, and then tap the program icon.

Downloading Programs From the Internet

Determine your device and processor type so that you know which version of the software to install:

Tap the

On the

From the

Using Pocket Internet Explorer, download the program to your device. You may see a single versions of files for different device types and processors. Ensure that you select the program designed for the Pocket PC and your device processor type.

Read any installation instructions, readme files, or documentation that comes with the program. Many programs provide special installation instructions.

Tap the file, such as a

The installation wizard begins. Follow the directions on the screen.

Start

button and tap

System

tab, tap

Ver si on

*.xip,*.exe

About

Settings

tab, record the processor information.

*.zip

file, a

Setup.exe

*.xip

or *

.exe

file.

Start

button,

file, or several

Adding a Program to the Start Menu

Tap t h e

DELL CONFIDENTIAL – PRELIMINARY 7/29/04 - FOR PROOF ONLY

70 Adding and Removing Programs

Start

button and tap

Settings

FILE LOCATION: N:\systems\DiMaggio\OM\Paper\EN\N6966c70.fm

Ta p

Menus

, tap the

Start Menu

tab, and then tap the check box for

the program.

If the program is not listed, you can either use File Explorer on the device to move the program to the

Start Menu

folder, or use ActiveSync on the computer to create a shortcut to the program and place the shortcut in the

Start Menu

folder.

Using File Explorer on the Device

Tap the

Locate the program. Tap the folder list (labeled default) and then tap device.

Tap and hold the program name and tap

Open the

Tap and hold a blank area of the window, and tap menu.

The program now appears on the using File Explorer, see "Finding and Organizing Information" on page 39.

Start

button, tap

Start Menu

Programs

, and tap

File Explorer

My Documents

My Device

to see a list of all folders on the

Cut

on the pop-up menu.

folder located in the Windows® folder.

Paste

on the pop-up

Start

menu. For more information on

Using ActiveSync on the Computer

Use Explorer in ActiveSync to explore your device files and locate the program. Right-click the program and click shortcut to the appears on the

Start Menu

Start

folder in the Windows folder. The shortcut now

menu. For more information, see ActiveSync Help on

Create Shortcut

. Move the

your computer.

Error when Installing Software

When installing software on your Dell Axim X50, you may receive the message:

properly because it was designed for a previous version of Microsoft

receive this message, perform the following steps:

The program you have installed may not display

Windows Mobile™ software.

If you

Ta p ok to continue installing the software.

Run the software in portrait mode. See "Changing the Display Mode."

DELL CONFIDENTIAL – PRELIMINARY 7/29/04 - FOR PROOF ONLY

Adding and Removing Programs 71

FILE LOCATION: N:\systems\DiMaggio\OM\Paper\EN\N6966c70.fm

NOTE: Most device programs function with the Windows Mobile 2003 Second

Edition operating system when using portrait mode. Dell cannot guarantee proper functioning of a program that was not written for Windows Mobile 2003 Second Edition.

NOTE: The Dell Axim X50 has the Windows Mobile 2003 Second Edition

operating system installed. Most device software packages currently available were designed for previous versions of the Windows Mobile operating system.

If you need technical assistance with the software you are trying to install, contact the manufacturer of the software. Dell does not provide support for third-party electronics and accessories.

www.dell.com | support.dell.com

For more information on the Dell™ Electronics and Accessories Technical Support Policy, search the Dell Knowledge Base at support.dell.com for document number RA1062902.

Changing the Display Mode on Your Device

To change the display mode from landscape to portrait:

Ta p

Start

Ta p

Settings

Tap t h e

Ta p

Screen

Ta p

Portrait

Ta p okand close the window.

. The

System

. The

Settings

tab.

Screen

window appears.

to select portrait mode.

NOTE: To change the display mode from portrait to landscape, follow the steps

in reverse order.

Removing Programs

Tap t h e

If the program does not appear in the list of installed programs, use File Explorer on your device to locate the program.

Start

button and tap

System

tab and tap

Settings

Remove Programs

Tap and hold the name of the program, and tap

Delete

on the pop-up

menu.

DELL CONFIDENTIAL – PRELIMINARY 7/29/04 - FOR PROOF ONLY

72 Adding and Removing Programs

Using Companion Programs

The companion programs include Microsoft Pocket Word, Microsoft Pocket Excel, Microsoft Money, Windows Media Player for Pocket PC, and Microsoft Reader.

To switch to a companion program on your device, tap the

Programs

, and then tap the program name.

Microsoft® Pocket Word

Pocket Word works with Microsoft Word on your computer to give you easy access to copies of your documents. You can create new documents on your device, or you can copy documents from your computer to your device. Synchronize documents between your computer and your device so that you have the most up-to-date content in both locations.

Use Pocket Word to create documents, such as letters, meeting minutes, and travel reports. To create a new file:

Tap the

Ta p

A blank document appears. Or, if you selected a template for new documents in the appropriate text and formatting already provided.

New

Start

button→Programs→Pocket Word

Options

dialog box, the template appears with

Start

button, tap

Using Companion Programs 73

FILE LOCATION: N:\systems\DiMaggio\OM\Paper\EN\N6966c80.fm

www.dell.com | support.dell.com

formatting toolbar

show/hide formatting toolbar

You can open only one document at a time. If you open a second document, you are asked to save the first one. You can create, save, or edit a document in a variety of formats, including Word ( Text Format (

.rtf

), and Plain Text (

.txt

.doc

), Pocket Word (

.psw

), Rich

Pocket Word contains a list of the files stored on your device. Tap a file in the list to open it. To delete, make copies of, or send files, tap and hold a file in the list. Then select the appropriate action in the pop-up menu.

You can enter information in Pocket Word in one of four modes: typing, writing, drawing, or recording. These modes are displayed on the

View

menu. Each mode has its own toolbar, which you can show and hide by tapping the

74 Using Companion Programs

Show/Hide Toolbar

DELL CONFIDENTIAL – PRELIMINARY 7/29/04 - FOR PROOF ONLY

icon on the command bar.

FILE LOCATION: N:\systems\DiMaggio\OM\Paper\EN\N6966c80.fm

To change the zoom magnification, tap

View

, tap

Zoom

, and then select the percentage that you want. Select a higher percentage to enter text and a lower percentage to see more of your document.

If you are opening a Word document created on a computer, select

Window

on the

View

menu so that you can see the entire document.

Wrap to

Pocket Excel

Pocket Excel works with Microsoft Excel on your computer to give you easy access to copies of your workbooks. You can create new workbooks on your device, or you can copy workbooks from your computer to your device. Synchronize workbooks between your computer and your device so that you have the most up-to-date content in both locations.

Use Pocket Excel to create workbooks, such as expense reports and mileage logs. To create a new file:

Tap the

Ta p

A blank workbook appears. Or, if you selected a template for new workbooks in the appropriate text and formatting already provided.

New

Start

button→Programs→Pocket Excel

Options

dialog box, the template appears with

DELL CONFIDENTIAL – PRELIMINARY 7/29/04 - FOR PROOF ONLY

Using Companion Programs 75

FILE LOCATION: N:\systems\DiMaggio\OM\Paper\EN\N6966c80.fm

www.dell.com | support.dell.com

formatting toolbar

show/hide formatting toolbar

You can open only one workbook at a time. If you open a second workbook, you are asked to save the first one. You can create, save, or edit a workbook in a variety of formats, including Pocket Excel (

.pxl

) and Excel (

.xls

Pocket Excel contains a list of the files stored on your device. Tap a file in the list to open it. To delete, make copies of, or send files, tap and hold a file in the list. Then select the appropriate action from the pop-up menu.

Pocket Excel provides fundamental spreadsheet tools, such as formulas, functions, sorting, and filtering. To display the toolbar, tap

Toolbar

DELL CONFIDENTIAL – PRELIMINARY 7/29/04 - FOR PROOF ONLY

76 Using Companion Programs

View

and tap

FILE LOCATION: N:\systems\DiMaggio\OM\Paper\EN\N6966c80.fm

If your workbook contains sensitive information, you can protect it with a password. To set a password, open the workbook, tap

Password

password, so choose one that is easy for you to remember but difficult for others to guess.

. Every time you open the workbook, you need to enter the

Edit

, and then tap

Tips for Working in Pocket Excel

Use the following tips when working in large worksheets in Pocket Excel:

View

•Tap possible. To exit full-screen mode, tap

• Show and hide window elements. Tap that you want to show or hide.

• Freeze panes on a worksheet. First select the cell where you want to freeze panes. Tap the top and leftmost panes in a worksheet to keep row and column labels visible as you scroll through a sheet.

• Split panes to view different areas of a large worksheet. Tap tap tap

• Show and hide rows and columns. To hide a row or column, select a cell in the row or column you want to hide. Tap

Column Tools

column. Then tap

For more information on using Pocket Excel, tap the

Help

and tap

Split

. Drag the split bar to where you want it. To remove the split,

View

and tap

, and then tap

, tap

Go To

Full Screen

View

Remove Split

, and then type a reference that is in the hidden row or

Format

to see as much of your worksheet as

Restore

View

and tap

Hide

Freeze Panes

. To show a hidden row or column, tap

, tap

Row or Column

and then tap the elements

. You might want to freeze

Format

, tap

, and then tap

Start

button and tap

View

Row

and

Unhide

MSN Messenger

With the MSN Messenger instant message program, you can:

• See who is online.

• Send and receive instant messages.

• Have instant message conversations with groups of contacts.

DELL CONFIDENTIAL – PRELIMINARY 7/29/04 - FOR PROOF ONLY

Using Companion Programs 77

FILE LOCATION: N:\systems\DiMaggio\OM\Paper\EN\N6966c80.fm

To use MSN Messenger, you must have a Microsoft Passport account or a Microsoft Exchange e-mail account. You must have a Passport to use MSN Messenger Service. If you have a Hotmail or MSN account, you already have a Passport. Once you have obtained either a Microsoft Passport or a Microsoft Exchange account, you are ready to set up your account.

NOTE: Sign up for a Microsoft Passport account at www.passport.com. Get a

free Microsoft Hotmail e-mail address at www.hotmail.com.

To switch to MSN Messenger, tap the

Messenger

Start

button→Programs→MSN

Setting Up

www.dell.com | support.dell.com

Before you can connect, you must enter Passport or Exchange account information.

To set up an account and sign in:

Tap t h e

Ta p

On the information.

To sign in, tap the sign-in screen and enter your e-mail address and password.

Start

Tools

Accounts

button→Programs→MSN Messenger

and tap

Options

tab, enter your Passport or Exchange account

Working With Contacts

The MSN Messenger window shows all of your messenger contacts at a glance, divided into while connected, you can chat, send an e-mail, block the contact from chatting with you, or delete contacts from your list using the pop-up menu.

NOTE: If you already use MSN Messenger on your computer, your contacts

show up on your device without having to be added.

To see others online without them seeing you, tap

Appear Offline

If you block a contact, you appear offline but remain on the blocked contact's list. To unblock a contact, tap and hold the contact, and then tap

Unblock

on the pop-up menu.

DELL CONFIDENTIAL – PRELIMINARY 7/29/04 - FOR PROOF ONLY

78 Using Companion Programs

Online

and

Not Online

categories. From this view,

Tools→My Status

→

FILE LOCATION: N:\systems\DiMaggio\OM\Paper\EN\N6966c80.fm

Chatting With Contacts

• Tap a contact name to open a chat window. Enter your message in the text entry area at the bottom of the screen or tap preset message, and then tap

• To invite another contact to a multiuser chat, tap then tap the contact you want to invite.

• To switch back to the main window without closing a chat, tap the

Contacts

select the person with whom you were chatting.

• To know if the contact you are chatting with is responding, look for the message under the text entry area.

For more information on using MSN Messenger, tap the

Help

tap

icon. To revert back to your chat window, tap

Send

My Text

Tools

, tap

Chats

Start

to enter a

Invite

, and

button and

Microsoft Windows Media® Player for Pocket PC

Use Windows Media Player for Pocket PC to play digital audio and video files that are stored on your device or on a network. To switch to Windows Media Player for Pocket PC, tap the

Media

Use Windows Media Player on your computer to copy digital audio and video files to your Pocket PC. You can play Windows Media and MP3 files on your Pocket PC.

For more information about using Windows Media Player for Pocket PC, tap the

Start

button and tap

Help

Start

button→Programs→Windows

DELL CONFIDENTIAL – PRELIMINARY 7/29/04 - FOR PROOF ONLY

Using Companion Programs 79

FILE LOCATION: N:\systems\DiMaggio\OM\Paper\EN\N6966c80.fm

www.dell.com | support.dell.com

DELL CONFIDENTIAL – PRELIMINARY 7/29/04 - FOR PROOF ONLY

80 Using Companion Programs

Using Microsoft® Pocket Internet Explorer

Use Pocket Internet Explorer to view Web or WAP pages:

• During synchronization with your computer, download your favorite links and mobile favorites that are stored in the Internet Explorer on your computer.

• Connect to an Internet service provider (ISP) or network and browse the Web. For more information on connecting to the Internet, see "Getting Connected" on page 87.

When the device is connected to an ISP or network, you can also download files and programs from the Internet or intranet.

To switch to Pocket Internet Explorer, tap the

Explorer

Mobile Favorites

If you are using Microsoft Internet Explorer 5.0 or later on your computer, you can download mobile favorites to your device. Synchronizing mobile favorites downloads Web content to your device so that you can view pages while you are disconnected from your ISP and computer. Use the Internet Explorer plugin installed with Microsoft ActiveSync

To create a mobile favorite on your computer and download it to your device:

On your computer, open Internet Explorer and click

Mobile Favorite

To change the link name, enter a new name in the

Specify an update schedule next to

ClickOK.

Internet Explorer downloads the latest version of the page to your computer.

to create mobile favorites quickly.

Mobile Favorites

Start

Update

(optional).

subfolder in

button and tap

Tools→ Create

Name

box.

Internet

Using Microsoft Pocket Internet Explorer 81

FILE LOCATION: N:\systems\DiMaggio\OM\Paper\EN\N6966c90.fm

In Internet Explorer on the computer, right-click the mobile favorite and click

On the

Properties

Download

tab, specify the number of levels deep you want to

download. To conserve device memory, go only one level deep.

Synchronize your device and computer.

Mobile favorites that are stored in the

Mobile Favorites

folder in

Internet Explorer are downloaded to your device.

If you did not specify an update schedule in step 3, you need to manually download content to keep the information updated on your computer and device. Before synchronizing with your device, click Explorer on your computer and click

www.dell.com | support.dell.com

Updated

column was the last time content was downloaded to the

Synchronize

Tools

in Internet

. The date in the

Last

computer. You can manually download content, if necessary.

NOTE: You can add an icon to the Internet Explorer toolbar for creating mobile

favorites. In Internet Explorer on your computer, click View→Toolbars, and then click Customize.

Conserving Memory

Mobile favorites take up storage memory on your device. To minimize the amount of memory used:

• Turn off pictures and sounds or stop some mobile favorites from being downloaded to the device in the options. For more information, see ActiveSync Help on your computer.

• Limit the number of downloaded linked pages. In Internet Explorer on the computer, right-click the mobile favorite you want to change and click

Properties

. On the

Download

of linked pages you want to download.

Favorites

settings in the ActiveSync

tab, specify 0 or 1 for the number

Mobile Favorites Folder

Only items stored in the in Internet Explorer on your computer are synchronized with your device. The folder was created automatically when you installed ActiveSync.

DELL CONFIDENTIAL – PRELIMINARY 7/29/04 - FOR PROOF ONLY

82 Using Microsoft Pocket Internet Explorer

Mobile Favorites

subfolder (in the

Favorites

folder)

FILE LOCATION: N:\systems\DiMaggio\OM\Paper\EN\N6966c90.fm

Favorite Links

During synchronization, the list of favorites in the on your computer is synchronized with Pocket Internet Explorer on your device. The computer and the device are updated with changes made to either list each time you synchronize. Unless you mark the favorite link as a mobile favorite, only the link is downloaded to your device—you need to connect to your ISP or network to view the content. For more information on synchronization, see ActiveSync Help on your computer.

Mobile Favorites

folder

Using AvantGo Channels

AvantGo is a free interactive service that gives you access to personalized content and thousands of popular websites. You subscribe to AvantGo channels directly from your device. Then synchronize your device and computer, or connect to the Internet to download the content. For more information, see the AvantGo website.

To sign up for AvantGo:

In ActiveSync options on your computer, turn on synchronization for the

AvantGo

In Pocket Internet Explorer on your device, tap your list of favorites.

Tap the

Ta p

Activate

Follow the directions on the screen.

You need to synchronize your device with your computer and then tap the

My Channels

information type.

AvantGo Channels

to complete the AvantGo setup.

link.

Favorites

to display

When synchronization is complete, tap the

AvantGo Channels

link in your list of favorites to see a few of the most popular channels. To add or remove channels, tap the

DELL CONFIDENTIAL – PRELIMINARY 7/29/04 - FOR PROOF ONLY

Add or Remove

Using Microsoft Pocket Internet Explorer 83

link.

FILE LOCATION: N:\systems\DiMaggio\OM\Paper\EN\N6966c90.fm

Browsing Mobile Favorites and the Web

You can use Pocket Internet Explorer to browse mobile favorites and channels that you have downloaded to your device without connecting to the Internet. You can also connect to the Internet through an ISP or a network connection and browse the Web.

www.dell.com | support.dell.com

back icon refresh icon

home icon

favorites icon

To view mobile favorites and channels:

Tap the favorites icon to display your list of favorites.

Tap the page you want to view.

DELL CONFIDENTIAL – PRELIMINARY 7/29/04 - FOR PROOF ONLY

84 Using Microsoft Pocket Internet Explorer

FILE LOCATION: N:\systems\DiMaggio\OM\Paper\EN\N6966c90.fm

The page that was downloaded the last time you synchronized with your computer appears. If the page is not on your device, the favorite is dimmed. You need to synchronize with your computer again to download the page to your device, or connect to the Internet to view the page.

To browse the Internet, set up a connection to your ISP or corporate network using

Connections

, as described in "Getting Connected" on page 87.

NOTE: To add a favorite link, go to the page that you want to add, tap and hold

the page, and then tap Add to Favorites.

To connect to and browse the Internet:

• Tap the favorites icon and tap the favorite you want to view.

•Tap

View

and tap

Address Bar

. In the address bar that appears at the

top of the screen, enter the Web address that you want to see and tap

. Tap the arrow to select previously entered addresses.

DELL CONFIDENTIAL – PRELIMINARY 7/29/04 - FOR PROOF ONLY

Using Microsoft Pocket Internet Explorer 85

FILE LOCATION: N:\systems\DiMaggio\OM\Paper\EN\N6966c90.fm

www.dell.com | support.dell.com

DELL CONFIDENTIAL – PRELIMINARY 7/29/04 - FOR PROOF ONLY

86 Using Microsoft Pocket Internet Explorer

Getting Connected

You can use your device to exchange information with other mobile devices or with a computer, a network, or the Internet. You can use any of the following connection options:

• Use the infrared (IR) port on your device to send and receive files between two devices. See the following section, "Using Infrared," for more information.

• Connect to your Internet service provider (ISP). Once you are connected, you can send and receive e-mail messages by using Messaging, and view Web or WAP pages by using Microsoft communication software for creating an ISP connection is already installed on your device. Your service provider provides software needed to install other services, such as paging and fax services.

• Connect to the network at your company or organization where you work. Once you are connected, you can send and receive e-mail messages by using Messaging, view Web or WAP pages by using Pocket Internet Explorer, and synchronize with your computer.

• Connect to your computer to synchronize remotely. Once you are connected, you can synchronize information such as your Pocket Outlook information. See Microsoft ActiveSync Connections Help on the device for more information.

Pocket Internet Explorer. The

Help on your computer or

Using Infrared

Using infrared, you can send and receive information, such as contacts and appointments, between two devices.

To send information:

Switch to the program where you created the item you want to send and locate the item in the list.

Align the infrared sensors so that they are unobstructed and within a close range.

Getting Connected 87

FILE LOCATION: N:\systems\DiMaggio\OM\Paper\EN\N6966100.fm

Tap and hold the item, and tap

xxxx

is the item that you want to beam.

Beam

xxxx

on the pop-up menu, where

You can also send items (excluding folders) from File Explorer. Tap and hold the item you want to send, and tap

Beam File

on the pop-up menu.

Using Bluetooth® Wireless Technology

To configure a device with Bluetooth wireless technology in a Pocket PC environment:

From the lower-right corner of the Bluetooth wireless technology,

www.dell.com | support.dell.com

From the pop-up menu, select

To establish a connection with Bluetooth wireless technology, tap

Ta p

Explore a Bluetooth device

Tap the remote device with Bluetooth wireless technology that you want to connect.

Tap the service that you want to use to create the connection.

Ta p

Finish

to create the connection.

Tap and hold the connection created under

Connect

If the device to which you are trying to connect prompts you for a

Passkey, enter the Passkey and tap

To da y

screen, tap the icon for

Bluetooth Manager

My Shortcuts

and tap

New

NOTE: You need to get the passkey from the remote device

wireless technology.

wit

h Bluetooth

An active connection with Bluetooth wireless technology is created and is ready to use.

NOTE: For more information about using Bluetooth wireless technology, tap

the Start button

→

Help→Bluetooth to access the Microsoft Help on your device.

Using Wi-Fi (802.11b)

To configure the Wireless Network in a PocketPC environment:

Press the wireless button to enable the wireless capability on your device.

DELL CONFIDENTIAL – PRELIMINARY 7/29/04 - FOR PROOF ONLY

88 Getting Connected

FILE LOCATION: N:\systems\DiMaggio\OM\Paper\EN\N6966100.fm

Tap the

To add, edit, or delete a profile, tap

Start

button→Settings→Connections

tab

Network Cards

NOTE: If tapping on the "Network Cards" icon does not open up the

Configure Wireless Networks screen, enable the wireless radio by pushing the WLAN/Bluetooth on/off button on your device.

On the

Configure Wireless Networks

screen, select one of the available

network names.

NOTE: If the network name is not listed, you must add a configuration profile

for each wireless network environment in which you want to use your (mobile) wireless client station. If you plan to use your wireless client station in multiple networking environments that require different configuration settings, you can define dedicated profiles for each environment. For example, you can create a configuration profile for your office headquarters, a branch office, and your home or SOHO network.

If there are none listed then tap network name. Choose the option to connect to either

Work

Internet

from the pull down menu. If this will be Peer-to-

Add New Settings...

Type in the

The

Peer connection tap the "This is a device-to-device(ad-hoc) connection" check box.

Tap the

Encryption

• To disable encryption, tap the

and select

Network Key

Open

. Now, select

tab to configure

Authentication

Disabled

Authetication and Data

drop-down menu

from the

Data Encryption

drop-down menu.

• If you are using

Authentication

the proper encryption method from the

Network Authentication (Shared mode)

drop-down menu, select

Shared,

and then select

Data Encryption

, tap

down menu.

• If you do require encryption and are provided with the key

automatically, the

The key is provided for me automatically

box, when unchecked, allows you to enter the encryption key yourself. You can enter key values in either Alphanumeric Value or Hexadecimal Value. The encryption key value is case-sensitive. Consult your LAN Administrator or wireless router documentation for the correct value.

drop-

check

DELL CONFIDENTIAL – PRELIMINARY 7/29/04 - FOR PROOF ONLY

Getting Connected 89

FILE LOCATION: N:\systems\DiMaggio\OM\Paper\EN\N6966100.fm

If you are using IEEE 802.1x option you will first need to get a certificate through a non 802.1x enabled wireless network connected to a certificate server. Select or configure a non 802.1x enabled wireless network from the list.

Creating a Modem Connection

Install a modem card and appropriate adapters to connect an external modem to your device through the serial port.

Obtain the following information from your ISP:

- ISP dial-up access telephone number

www.dell.com | support.dell.com

- Username and password

- TCP/IP settings

Some ISPs require information in front of the username, such as

MSN/username

Tap t h e

Under

My ISP

connection

Enter a name for the connection, such as

From the

Start

button→Settings→Connections

My Work Network

Select a modem

list, select your modem type, and tap

tab→Connections

, tap

Add a new modem

ISP Connection

If your modem type does not appear, try reinserting the modem card. If you are using an external modem that is connected to your device with a cable, select

Hayes Compatible on COM1

Enter the access phone number and tap

Enter your user name, password, and, if applicable, your domain.

NOTE: You should not need to change any settings in Advanced. Most ISPs

now use a dynamically assigned address.

If the ISP you are connecting to does not use a dynamically assigned address, tap

Advanced

, tap the

TCP/IP

tab, and then enter the

address.

Ta p

Select other appropriate options and tap

DELL CONFIDENTIAL – PRELIMINARY 7/29/04 - FOR PROOF ONLY

90 Getting Connected

Finish

FILE LOCATION: N:\systems\DiMaggio\OM\Paper\EN\N6966100.fm

When you open Messaging, Pocket Internet Explorer, or MSN Messenger, your device automatically connects. Once you are connected, you can:

• Send and receive e-mail messages using Messaging. Before you can use Messaging, you need to provide the information Messaging needs to communicate with the e-mail server. See "Connecting Directly to an EMail Server" on page 93 for more information.

• See Web and WAP pages using Pocket Internet Explorer. For more information, see "Using Microsoft

Pocket Internet Explorer" on

page 81.

• Send and receive instant messages with MSN Messenger. For more information, see "MSN Messenger" on page 77.

Creating an Ethernet Connection

Obtain the following information from your network administrator: user name password and domain name

Install the network card driver, if required.

See the documentation that came with your network card.

Network Settings will appear automatically the first time you insert the network card so that you can configure the network card. To change

Start

settings later, tap the

Connections

If you need to enter specific server information, tap the appropriate

adapter, and then tap

button→Settings→Connections

Properties

. You may need to enter proxy server

tab

→

and VPN connection settings. For more information, see your network administrator.

NOTE: Most networks use DHCP, so you need not have to change these

settings unless your network administrator instructs you to do so.

If necessary, connect the network card to the network by using a network cable. See the documentation that came with your network card.

You are now connected and start browsing your network.

DELL CONFIDENTIAL – PRELIMINARY 7/29/04 - FOR PROOF ONLY

Getting Connected 91

FILE LOCATION: N:\systems\DiMaggio\OM\Paper\EN\N6966100.fm

Creating a VPN Connection

Tap t h e

Ta p

Enter a name for the connection, such as your company's name.

In the

Next to authentication that you want to use with your device.

If you are unsure about which option to select, ask your network administrator.

www.dell.com | support.dell.com

Ta p

Enter your username, password, and, if required, domain.

Install the network card driver, if required.

See the documentation that came with your network card.

Insert the network card into your device.

• If a network with a broadcast SSID is detected, the wireless

• If a network with a broadcast SSID is not detected, skip to step 11.

Ta p

Start

button→Settings→Connections

Add a new VPN server connection

Host name/IP

VPN type

network icon,

field, enter the VPN server name or IP address.

, tap

IPSec

and the

appear in the navigation bar. Go to step 10.

The Internet

tab→Connections

PPTP

, depending on the type of

New Network Detected

bubble

NOTE: If multiple networks are detected, tap the network to which you want to

connect, tap The Internet, and tap Connect.

Tap t h e

On the

Enter the SSID next to

Tap t h e

Start

button→Settings→Connections

Wireless Ethernet

Wireless

tab, tap

icon.

New Settings

Network Name

Authentication

tab to enable or disable WEP settings,

, and tap

tab→Connections

The Internet

depending on your network type.

Ta p OK.

Tap the connection icon,

Tap the name of your VPN connection to enable it.

DELL CONFIDENTIAL – PRELIMINARY 7/29/04 - FOR PROOF ONLY

92 Getting Connected

that appears in the navigation bar.

FILE LOCATION: N:\systems\DiMaggio\OM\Paper\EN\N6966100.fm

Ending a Connection

To disconnect:

• When connected through dial-up or VPN, tap the your navigation bar and tap

• When connected through a cable or cradle, detach your device from the cable or cradle.

• When connected through the infrared sensor, move the device away from the computer.

• When connected through a network (Ethernet) card, remove the card from your device.

End

Connection

icon on

Connecting Directly to an E-Mail Server

You can set up a connection to an e-mail server so that you can send and receive e-mail messages by using a modem or network connection and Messaging on your device.

NOTE: The ISP or network must use a POP3 or IMAP4 e-mail server and an

SMTP gateway.

You can use multiple e-mail services to receive your messages. For each e-mail service you intend to use, you must first set up and name the e-mail service. If you use the same service to connect to different mailboxes, set up and name each mailbox connection.

To set up an e-mail service:

In Messaging on your device, tap

Follow the directions in the E-mail Setup wizard.

For more information, tap the

To connect to your e-mail server, tap information on using the Messaging program, see "Messaging" on page 62.

Start

Accounts

button and tap

Account

and tap

New Account

Help

Connect

. For more

Getting Help on Connecting

For more information on getting connected, see the following resources:

• "Messaging" on page 62.

DELL CONFIDENTIAL – PRELIMINARY 7/29/04 - FOR PROOF ONLY

Getting Connected 93

FILE LOCATION: N:\systems\DiMaggio\OM\Paper\EN\N6966100.fm

• Online Help on the device. Tap the

Messaging

Connections

Start

button and tap

• ActiveSync Help on your computer. In ActiveSync, click

Microsoft ActiveSync Help

• See www.microsoft.com/windowsmobile for troubleshooting information.

www.dell.com | support.dell.com

Help

. Tap

and click

DELL CONFIDENTIAL – PRELIMINARY 7/29/04 - FOR PROOF ONLY

94 Getting Connected

Appendix

Specifications

System Information

Processor Intel

Memory

RAM

ROM

Operating System Microsoft

Display

Type QVGA, VGA TFT Color 16-bit, touch-

Size 3.5 inches (QVGA)

Resolution 240 x 320 at 65,536 colors (QVGA)

XScale™ PXA270 processor at

up to 624 MHz

64-MB SDRAM

64-MB or 128-MB Intel® StrataFlash™ ROM

Windows Mobile™ 2003

Second Edition

sensitive, transflective display

3.7 inches (VGA)

480 x 640 at 65,536 colors (VGA)

LCD brightness QVGA:100 nits

VGA: 80 nits

Controls and Lights

Navigation 5-way navigation button

Buttons: four program buttons: Calendar,

Contacts, Messaging, Home

power on/off

Appendix 95

FILE LOCATION: N:\systems\DiMaggio\OM\Paper\EN\N6966110.fm

Controls and Lights (continued)

on/off button for WLAN/Bluetooth wireless technology

voice record button

reset button

lock button

Lights: synchronization/communication

event notification

charge status

www.dell.com | support.dell.com

Expansion Slots

Secure Digital memory card one Secure Digital memory card slot

(3.3v)

supports 1-bit and 4-bit SDIO card

CompactFlash card one CompactFlash Type II card slot

(3.3v)

Ports and Connectors

Infrared standard v1.2 (115 kbps)

Cradle/synchronization connector 36-pin connector

Audio stereo headphone connector and mono

microphone connector

Video VGA Connector (available with high

end device supporting VGA output).

Physical

Dimensions:

Length

Width

Height

DELL CONFIDENTIAL – PRELIMINARY 7/29/04 - FOR PROOF ONLY

119.0 mm (4.69 inches)

73.0 mm (2.87 inches)

16.9 mm (0.67 inch)

96 Appendix

FILE LOCATION: N:\systems\DiMaggio\OM\Paper\EN\N6966110.fm

Physical (continued)

Weight 165 g (0.36 lb) QVGA with standard

battery

175 g (0.38 lb) VGA with standard battery

NOTE: The weight described refers to the

device not including the CompactFlash card or the Secure Digital memory card.

Audio

Audio controller WM8750L sound chip

Stereo conversion 16-bit stereo; 8.0-, 11.025-, 22.05-, and

44.1-KHz sample rate

Record full duplex record and playback

Microphone/speaker integrated

Headphone stereo connector

Wireless Connectivity

WLAN (802.11b)

Host interface

Network standard

Data rate

Modulation

Network architecture

Operating frequencies

Operating channels

RF output power

Range

Client utility

IEEE 802.11b

1 Mbps, 2 Mbps, 5.5 Mbps, 11 Mbps

CCK (11 Mbps, 5.5 Mbps); DQPSK (2 Mbps); DBSPK (1 Mbps)

ad-hoc and infrastructure

2.4–2.497 GHz

1–11 (North America); 1–13 (Europe and Japan)

13.0 dBm maximum

indoor — up to 10 m (120 ft) at 5 Mbps and 75 m at 0.5 Mbps

automatic location profile, site survey, diagnostics, current link status, ping

DELL CONFIDENTIAL – PRELIMINARY 7/29/04 - FOR PROOF ONLY

Appendix 97

FILE LOCATION: N:\systems\DiMaggio\OM\Paper\EN\N6966110.fm

Wireless Connectivity (continued)

Software support

Lights

Wi-Fi certified

green (WLAN status)

blue (Bluetooth wireless technology status)

Switch

manual radio on/off (hardware button and software switch) to comply with aviation restrictions

Bluetooth wireless technology 2.4-GHz ISM band operation;

compatible Bluetooth 1.2 wireless

www.dell.com | support.dell.com

technology; includes manager for Bluetooth with wireless technology; Class II device; Max 4 dBm o/p power;

3.3V operation; UART interface

Power Supply

Battery type:

Main

1100-mAh lithium-ion removable, rechargeable battery (standard)

2200-mAh lithium-ion removable, rechargeable battery (optional)

Backup

20-mAh rechargeable nickel metal hydride button cell

AC adapter:

Supply voltage

Frequency

Current consumption

Output voltage

Output current

100–240 VAC

50–60 Hz

0.4 A

5.4 VDC

2.41 A

Environmental

Temperature range:

operating

DELL CONFIDENTIAL – PRELIMINARY 7/29/04 - FOR PROOF ONLY

0° to 40°C (32° to 104°F)

98 Appendix

FILE LOCATION: N:\systems\DiMaggio\OM\Paper\EN\N6966110.fm

Environmental (continued)

storage

Thermal gradient:

operating

storage

Relative humidity (maximum):

operating

storage

Altitude (maximum):

operating

storage

Maximum shock (measured with a 2 ms half-sine pulse):

operating

storage

Maximum vibration (using a randomvibration spectrum that simulates user environment):

operating

storage

–20° to 60°C (–4° to 140°F)

15°C (59°F) per hour maximum

20°C (68°F) per hour maximum

10% to 90% non-condensing

5% to 95% non-condensing

0 to 3048 m (0 to 10,000 ft)

0 to 12,190 m (0 to 40,000 ft)

200 G

400 G

2.6 GRMS

3.41 GRMS

U.S. Terms and Conditions of Sale

These terms and conditions ("Agreement") apply to your purchase of computer systems and/or related products and/or services and support sold in the United States ("Product") by the Dell entity named on the invoice or acknowledgement ("Dell") provided to you. By accepting delivery of the Product, you accept and are bound to the terms and conditions of this Agreement. If you do not wish to be bound by this Agreement, you must notify Dell immediately and return your purchase pursuant to Dell's Total Satisfaction Return Policy. (See: support.dell.com/ContactUs/ByPhone.aspx?c=us&l=en&s=gen for our contact information.) If returned, Product(s) must remain in the boxes in which they were shipped. THIS AGREEMENT SHALL APPLY UNLESS (I) YOU HAVE A SEPARATE PURCHASE AGREEMENT WITH DELL, IN WHICH CASE THE SEPARATE AGREEMENT SHALL GOVERN; OR (II) OTHER DELL TERMS AND CONDITIONS APPLY TO THE TRANSACTION.

DELL CONFIDENTIAL – PRELIMINARY 7/29/04 - FOR PROOF ONLY

Appendix 99

FILE LOCATION: N:\systems\DiMaggio\OM\Paper\EN\N6966110.fm

HTC HC3U, HC3UL User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
