HTC 2PS6200 Users Manual

User guide

HTC phone

6 About this guide

Only

About this guide

In this user guide, we use the following symbols to indicate useful and important information:

This is a note. A note often gives additional information, such as what happens when you choose
to do or not to do a certain action. A note also provides information that may only be applicable
to some situations.

This is a tip. A tip gives you an alternative way to do a particular step or procedure, or lets you
know of an option that you may find helpful.

This indicates important information that you need in order to accomplish a certain task or to
get a feature to work properly.

This provides safety precaution information, that is, information that you need to be careful
about to prevent potential problems.

Some apps may not be available in all regions or with your mobile operator.

7 Important RF Notice

Only

Important RF Notice

This device was tested for compliance with the applicable FCC and Industry Canada
specific absorption rate (SAR) limits for radio frequency (RF) exposure during typical
body-worn operations. To ensure that RF exposure levels remain at or below the tested
levels, use a belt-clip, holster, or similar accessory that maintains a minimum separation
distance of 1.0 cm between your body and the device, with either the front or back of the
device facing towards your body. Such accessories should not contain any metallic
components. Body-worn accessories that do not meet these specifications may not ensure
compliance with applicable SAR limits and their use should be avoided.

8 Important note on recoverable data

Important note on recoverable data

Files and other data that have been deleted, cleared, removed, or erased from your device
may still be recoverable by third-party data recovery software. Even a factory reset may not
permanently erase all data from your mobile device, including personal information.

9 Unboxing

20160215

Unboxing

HTC phone

1. POWER

2. VOLUME

3. nano SIM card slot

4. Front camera

5. Proximity sensor

6. 3.5mm headset jack

7. Earpiece

8. Notification LED

9. microSD™ card slot

10. BACK

11. HOME / Fingerprint scanner

12. USB Type-C connector

13. Speaker

14. RECENT APPS

HTC phone is available in either a 3G-only or 3G-and-4G/LTE™ version, depending on your
region and mobile operator. You need a 4G/LTE plan to use your operator's 4G/LTE network for
voice calls and data services. Check with your operator for details.

§ If you want to use a case or screen protector, don’t cover and block the proximity sensor.
Purchase a case or screen protector designed for HTC phone.

§ Avoid connecting third-party headsets or accessories with metallic charms that dangle near the
headset jack. Using these may affect signal reception.

Slots with card trays

There are trays inside the nano SIM and microSD slots that are used for inserting your cards.
When inserting the eject tool into the tray eject holes to remove the card trays, make sure not to

press on the trays to avoid damaging the eject mechanism inside the slots.

10 Unboxing

20160215

Also, if you want to use a protective case, make sure to buy a case that's designed for HTC phone and
that doesn't block the trays.

nano SIM card

HTC phone uses a nano SIM card.
Use a standard nano SIM card only. Inserting a modified card that is thicker than the standard

nano SIM card may cause the card to not fit properly or damage the card slot.

Inserting a nano SIM card

1. Hold the phone face down.

2. Insert the tip of the tray eject tool that came with your phone—or a small bent paperclip—

3. Push the tip all the way into the hole until the tray ejects, and then pull the tray out.

into the tray eject hole next to the nano SIM card slot.
