QuickSpecs
HPE Rackmount Uninterruptible Power Systems
Overview and Models
Page 1
HPE Rackmount Uninterruptible Power Systems (UPS)
Looking for cost-effective power protection for your small office environments?
HPE
up to 10
servers and other devices in both rackmount and desktop IT environments. Standard features include intuitive front panel displays
for local management, and
HPE
Power
a support option
on
or via a standard web
browser.
When you need it, use outstanding
HPE Pointnext operational
services
UPS will be covered at the same service level and
coverage period as your
year limited warranty, with the first year including parts and labor.
Also, standard on all
Failure Warranty, which ensures that when customers receive
notification from
Power Manager Software that the battery may fail, the battery is replaced free of charge under the warranty.
This warranty is o
Uninterrupted
Rack/Tower UPS Models
HPE R/T2200 G5 UPS Models
HPE R/T2200 G5 NA/JP Uninterruptible Power System
Q1L84A
HPE R/T2200 G4 Extended Runtime Module
J2R09A
HPE R/T3000 G5 UPS Models
HPE R/T3000 G5 Low Voltage NA/JP Uninterruptible Power System
Q1L85A
HPE R/T3000 G5 High Voltage NA/JP Uninterruptible Power System
Q1L86A
HPE R/T3000 G5 High Voltage INTL Uninterruptible Power System
Q1L87A
HPE R/T3000 G4 Extended Runtime Module
J2R10A
line interactive, single phase Rack/Tower and Rackmount Uninterruptible Power System (UPS) solutions can protect
HPE Enhanced Battery Management (EBM) that helps to extend the service-life of your batteries.
Protector, a power management software application, combined with a UPS Network Management Module,
all models, enables you to remotely monitor and manage your UPS through HPE Systems Insight Manager
HPE support services for your whole data center environment. With
, have the security of knowing that your HPE Rack/Tower and Rackmount
HPE server. HPE UPSs are backed by a 3-
HPE UPS units is our exclusive 30-day Battery Pre-
HPE
ffered worldwide.
• Remote access through an optional 1-GbE-based network management card ensures widespread connectivity with most
user networks.
• Web-based management applications, HPE Power Protector, allows you to monitor, manage, and control a single
Uninterrupted Power Supply both locally and remotely.
• Outlet switching and metering at the load segment allows you to monitor, control and prioritize access to the
Power Supply’s power
• Protects more devices by providing up to 14% more wattage compared to traditional Uninterrupted Power Supplies.
• HPE Enhanced Battery Management (EBM) technology delivers up to 50% longer battery life.
• Industry leading efficiency of up to 99% helps to ensure minimal power loss and lower power costs.
• Up to 4 extended runtime modules can be simply added to the Uninterrupted Power Supply configuration that extends
your Uninterrupted Power Supply by a factor of 15x or more
• Batteries can be hot-swapped safely without every shutting down IT equipment.
QuickSpecs
HPE Rackmount UPSs
Overview and
Models
Page 2
Rack UPS Models
R1500 G5 Models
HPE R1500 G5 NA Uninterruptible Power System
Q1L88A
HPE R1500 G5 JP/TWN Uninterruptible Power System
Q1L89A
HPE R1500 G5 INTL Uninterruptible Power System
Q1L90A
Management Card
HPE Single Phase 1Gb UPS Network Management Module
Q1C17A
QuickSpecs
HPE Rackmount UPSs
Specifications
Page 3
HPE Power Management
HPE Power Protector Software
UPS
Increase stability and security in your data center
HPE Power Protector gives you the ability to establish power failure policies and automatically respond 24×7 to power faults
secur
hardware are fully protected. Delay restart based on defined load segments after a shutdown to sequence the startup of system
com
Simplify management of UPS functions
Simple, effective management of environments, one UPS at a time. For users wanting ease of use, this is the tool to use
segmentation to power down prioritization and alert management, this tool offers everything needed from a single console. It
offers remote access via a web browser with secure SSL authentication. Simple, easy to read status "gauges" offer
glance.
See HPE Power Protector QuickSpec
Supported Operating Systems
Similar to hardware support, HPE Power Protector is designed to support a wide array of operating systems, spanning Microsoft
Windows, Linux, UNIX, and virtual platforms.
HPE Power Protector is a web-based application that enables administrators to manage an HPE UPS from a browser-based
management console. Administrators can monitor, manage, and control a single UPS locally and remotely. A familiar browser
interface provides secure access to the UPS Administrator Software and UPS Client Software from anywhere on the network.
Administrators may configure power failure settings and define UPS load segments for maximum uptime of critical servers. The
can also be configured to extend runtimes for critical devices during utility power failures. For most UPSs, the receptacles on the
rear panel are divided into one or more groups, called load segments, which can be controlled independently. By shutting down a
load segment that is connected to less critical equipment, the runtime for more critical equipment is extended, providing additional
protection.
• UPS power management via HPE Power Protector available via free download from HPE.com.
• Allows for local or network-based UPS monitoring, status updates, and control over shutdown communications
• Download to other servers or IT devices to create “clients” that can be configured for graceful shut down
• Access the HPE Power Protector user interface via a USB or serial connected server (proxy server) or through the optional
ponents and perform UPS diagnostics to ensure the availability of adequate battery backup times.
1GbE Network Management Card
or
ity risks without IT administrators present. Prioritize shutdowns in the event of a power failure to ensure that your data and
. From load
monitoring at a
for more information. .
even
QuickSpecs
HPE Rackmount UPSs
Specifications
Page 4
Operating system HPPP
(Client & Admin)
Service
Pack
Platform
HPPP
HPNMC
Admin
Client
NMC
Microsoft Windows
Windows
Server 2016
Standard, Data
Tested
Tested
Tested
Windows
Server 2012
Standard, Data
x64
Supported
Supported
Supported
Windows
Server 2012
R2
Standard, Data
x86, x64
Tested
Tested
Tested
Windows
Server 2008
R2
Standard, Data
SP1
x64, IA64
Tested
Tested
Tested
Windows
Server 2008
Standard, Data
SP2
x86, x64,
Supported
Supported
Supported
Windows
Server 2003
R2
Standard, Data
Not
Not supported
Not supported
Windows 10
Enterprise, Pro
x64
Tested
Tested
Tested
Windows 8.1
Enterprise, Pro
x64
Tested
Tested
Tested
Windows 8
Enterprise, Pro
x86, x64
Supported
Supported
Supported
Windows 7
Professional,
Standard
SP1
x86, x64
Tested
Tested
Tested
Windows XP
Professional
SP3 Not
supported
Not supported
Not supported
Linux
Red Hat
Enterprise
Linux
7.3 x86, x64
Tested
Tested
Tested
7.2
x86, x64
Tested
Tested
Tested
6.7
x86, x64
Tested
Tested
Tested
6.6 x86, x64
Supported
Supported
Supported
5.11
x86, x64
Tested
Tested
Tested
5.10
x86, x64
Supported
Supported
Supported
5.7 x86, x64
Not
Not supported
Not supported
SUSE Linux
Enterprise
Server/Novel
Fedora core
x86, x64
Not
Not supported
Not supported
Fedora core
x86, x64
Not
Not supported
Not supported
SUSE Linux
Enterprise
Server/Novel
12
SP2
x86, x64,
Tested
Tested
Tested
11
SP3
x86, x64,
Tested
Tested
Tested
Center, Core
Center, Core
Center, Core
Center, Core
Center, Core
Center, Core
Ultimate,
IA64
supported
15
14
supported
supported
supported
IA64
IA64
QuickSpecs
HPE Rackmount UPSs
Specifications
Page 5
OpenSuse
x86, x64
Not
Not supported
Not supported
OpenSuse
x86, x64
Not
Not supported
Not supported
Virtual environments
VMware
ESXi 6.5
X86, IA64
n/a
Tested
Tested
VMware
ESXi 6.0
U1
X86, IA64
n/a
Tested
Tested
ESXi 5.5
U3
X86, IA64
n/a
Tested
Tested
ESXi 5.1 (pay
U1 n/a
Supported
Supported
ESXi 5.0 (pay
U1 n/a
Supported
Supported
ESX 4.1 (pay
U1 n/a
Not supported
Not supported
ESXi 4.1 (pay
U1 n/a
Not supported
Not supported
ESX 4.0 (pay
U1 n/a
Not supported
Not supported
ESXi 4.0 (pay
U1 n/a
Not supported
Not supported
Microsoft
Windows
Server 2012
R2 n/a
Supported
Supported
Windows
Server 2008
R2
X86, IA64
n/a
Supported
Supported
Xen
Citrix
6.0
n/a
Supported
Supported
Citrix
5.6
IA64
n/a
Supported
Supported
OpenSource
RHEL 5
Not
Not supported
Not supported
OpenSource
Debian 5
Not
Not supported
Not supported
KVM
KVM 17
kernel
Not
Not supported
Not supported
For x86
bit compatibility mode. This implies that no native ports for these
for components that strictly require native ports, such as device drivers.
13.0
12.3
version only)
version only)
version only)
version only)
version only)
version only)
supported
supported
Hyper-V
Hyper-V
XenServer
XenServer
Xen 2.6 on
Xen 3.2 on
Linux 2.6.21
-64 and IA-64 architectures and on Microsoft Windows systems and HP-UX for IA-64, HPE Power Protector will work in 32-
supported
supported
supported
architectures will be made for these systems; the only exception is
QuickSpecs
HPE Rackmount UPSs
Specifications
Page 6
Flexible Rackmount and Rack/Tower Models Deliver Cost-Effective Power Protection
Key features
Ease of Use
Up to 4 extended runtime modules can be simply added to the UPS configuration that extend your UPS runtime by a factor
Management
wer Protector, allows you to monitor, manage, and control a single UPS, locally
Efficiency
HPE
Rack configuration
Tower configuration
• Next-generation LCD offers a graphical interface which provides all critical UPS information in a single screen view.
•
of 15x or more.
• Batteries can be hot-swapped safely without ever shutting down IT equipment.
• Remote access through an optional 1GbE-based network management card ensures widespread connectivity with most
user networks.
• Web-based management application, HPE Po
and remotely.
• Outlet switching and metering at the load segment level allows you to monitor, control and prioritize access to UPS power.
• Protects more devices by providing up to 28% more wattage compared to traditional UPSs.
• Enhanced Battery Management (EBM) technology delivers up to 50% longer battery life.
• Industry leading efficiency of up to 99% helps to ensure minimal power loss and lower power costs.
•
Rack/Tower UPS models
QuickSpecs
HPE Rackmount UPSs
Specifications
Page 7
HPE R/T3000 Uninterruptible Power System (UPS)
LV NA/JPN rear panel
1
USB communication port
8
Circuit breakers
Group 1: Two programmable outlets for connection of
equipment
Connector for automatic recognition of an additional battery
module
Group 2: Two programmable outlets for connection of
equipment
Slot for optional communication card, shown with optional
Management Card installed
Primary Group: outlets for connection of critical equipment
Connector for ROO (Remote On/Off) or RPO (Remote Power
Off) control
Attached input
Connector for additional battery module
LED indicating SWF (site wiring fault) alarm (Although the
LED remains on the rear panel, this feature is disabled for low
voltage models)
7
30A outlet (L5-30R) for connection of equipment
13
Ground connection
1
2
4
5
12
11
10
9b
9a
6
7
8
3
2 RS-232 communication port 9a
3
4
5
6
9b
10
11
12
power cord for AC power source
QuickSpecs
HPE Rackmount UPSs
Specifications
Page 8
HPE R/T3000 Uninterruptible Power System (UPS)
HV NA/JP and INTL rear panel
USB communication port
Group 1: Two programmable outlets for connection of
equipment
Group 2: Two programmable outlets for connection of
equipment
Connector for automatic recognition of an additional battery
module
Primary Group: 4 outlets for connection of critical e
Slot for optional communication card, shown with optional
HPE Management Card installed
Inlet
Connector for ROO (Remote On/Off) or RPO (Remote Power
Off) control
Ground connection
6
Connector for additional battery module
7
16A outlet for connection of equipment
7
10
9
1
2
3 4 5
6
8a
8b
11
1
2 RS-232 communication port 8b
3
4
5
8a
9
10
11
quipment
for connection to AC power source
QuickSpecs
HPE Rackmount UPSs
Specifications
Page 9
HPE R/T2200 Uninterruptible Power System (UPS)
NA/JPN rear panel
USB communication port
Group 1: Two programmable outlets for connection of
equipment
Group 2: Two programmable outlets for connection of
equipment
Connector for automatic recognition of an additional battery
module
Primary Group: outlets for
Slot for optional communication card, shown with optional
Management Card
Attached input power cord for AC power source
Connector for ROO (Remote On/Off) or RPO (Remote Power
Off) control
LED indicating SWF (site wiring fault) alarm (Although the
LED remains on the rear panel, this feature is disabled for
low voltage models)
6
Connector for additional battery module
11
Ground connection
R/T2200 and R/T3000 UPS Specifications
Electrical Input
Voltage Range
100V nominal = 80V – 128V
See Model Matrix for nominal and user selectable voltage settings.
Frequency
50/60 Hz
Online Efficiency
94%
Electrical Output
On battery Regulation
±5% of nominal voltage
Online Regulation
-10% to +6% of nominal voltage
Voltage Wave Form
Sine wave
Connections
See Model Selection Matrix; divided into 2 Load Segments
Output protection
Firmware overload sensing and control
Battery
Type
Extended Batteries
Up to four ERMs can be supported; recommendation is up to 2
Backup Time
See Backup Times Chart
Recharge Time
<3 hours to 90% usable capacity; <24 hours for complete recharge
Voltage
R/T2200 = 48V
R/T3000 = 72V
Communications
Serial Ports
Standard DB-9 and USB ports (ships with communication cables)
Option Slot
(1) (For optional Communication Card)
1
2
3
4
5
6
7a
11
8
9
10
7b
1
2 RS-232 communication port 7b
3
4
5
7a
installed
120V nominal = 89V – 159V
208V nominal = 160V – 163V
230V nominal = 160V – 294V
8
9
10
connection of critical equipment
QuickSpecs
HPE Rackmount UPSs
Specifications
Page 10
Option Cards
HPE UPS Network Management Module (sold separately)
LCD Interface
LED Display integrated into front panel
Management Software
Power Management including HPE Power Protector software. See
HPE Power Protector QuickSpec for more information.
Environmental and Safety
Operating Temperature
0°C to 40°C (32°F to 104°F); Long term use at higher temperature
will reduce battery life 25°C (77°F)
Non-operating
Temperature
-15°C to 50°C (5°F to 122°F)
Operating Humidity
0% to 90% (non-condensing)
Storage Humidity
0% to 90%
Operating Altitude
Up to 6,562 ft (2000 m) above sea level
Audible Noise
<40dB in normal operation. <45dBA on battery operation
Safety Markings
UL/cUL CE, TUV, C-tick, CES, EAC, VCCI, GS, KC, EK, BSMI, TIS, BIS
Safety Certifications
UL1778; UL60950, CSA22.2 No.107.1,No.107.3,; CB Bulletin
EMC Markings
FCC-A; CISPR 22; VCCI A; CE, BSMI, C-TICK
Emissions
FCC CFR 47, Part 15 Class A, EN50091-2
Immunity
EN 55024; EN 50091-2 consisting of IEC 61000-4-2 thru IEC
61000-4-6; IEC 61000-4-11
Surge Suppression
Conforms to IEEE 587B and ANSI C62.41
RPO/ROO Port
The Normally Closed (NC) RPO shuts off power to all UPS outlets
when closed. Opening the terminals again will shut off the UPS.
R/T2200 G5 Weights and
Unit Dimensions
(LxWxH)
20.55 x 17.36 x 3.39 inches / 522 x 441 x 86.2 mm
Shipping
Dimensions(LxWxH)
36.26 x 23.23 x 11.02 inches / 921 x 590 x 280 mm
Unit Weight
65.28 lbs/29.61 kg
Shipping Weight
83.62 lbs / 37.93 kg
R/T3000 G5 Weights and
Unit Dimensions
(LxWxH)
25.47 x 17.4 x 3.4 in / 647 x 441x 86.2 mm
Shipping
Dimensions(LxWxH)
36.26 x 23.23 x 11.02 inches / 921 x 590 x 280 mm
Unit Weight
87.17 lbs / 39.54 kg
Shipping Weight
107.48 lbs / 48.75 kg
IEC62040-1; IEC 60950-1; EN60950-1;EN 62040-1; EN 610003-2+A1 +A2; EN 61000-3-3
Dimensions
Dimensions
when opened. The UPS must be manually restarted once the
terminals are closed again. There is a preinstalled jumper in the
RPO terminals.
The Normally Open (NO) ROO initiates a UPS Power On function
QuickSpecs
HPE Rackmount UPSs
Specifications
Page 11
What’s in the box:
• Documentation
HPE R1500 G5 UPS Models
HPE R1500 G5 NA and JP/TWN UPS
1.
IUSB Communication Port
6a.
Group 1: programmable outlets for equipment
connection
2.
ES-232 Communication Port
6b.
Group 2: programmable outlets for equipment
connection
3.
Slot for optional communication card; shown with Network
Management Card installed
7.
Attached 6ft input power cord NEMA 5-15P for AC
power source,
4.
Connector for ROO(Remote On/Off) or RPO (Remote Power Off)
Control
8.
LED indicating site wiring fault alarm
5.
Primary Group: Outlets for connection of critical equipment
• HPE R/T2200 UPS or R/T3000 UPS
• Rail kit and mounting hardware
• Bezel components
• Output power jump cables (2) for HV North America and International models
• RS-232 communication cable (1)
• USB cable (1)
• Cable locking device for HV North America and International models
• Tower stands
9.
Ground screw
QuickSpecs
HPE Rackmount UPSs
Specifications
Page 12
HPE R1500 G5 International UPS
1.
USB communication port
6a.
Group 1: programmable outlets for equipment connection
2.
RS-232 communication port
6b
Group 2: programmable outlets for equipment connection
3.
Slot for optional communication card; shown with Network
Management Card installed
7.
Input power connection (IEC -320-C14) for powering unit to
AC power source
4.
Connector for ROO (Remote On/Off) or RPO (Remote Power
Off)
8.
Ground screw
5.
Primary Group: Outlets for connection of equipment
control
QuickSpecs
HPE Rackmount UPSs
Specifications
Page 13
HPE R1500 G5 UPS
Electrical Input
Voltage Range
± 15% of nominal 100 and 120V models and ± 20% of nominal on
230V models. See Model Matrix for nominal and user
voltage settings via LCD Front Display Panel
Frequency
50/60 Hz ± 5Hz (auto sensing at default voltage )
Online Efficiency
92%
Electrical Output
Online Regulation
-10% to +6% of nominal voltage*
On battery Regulation
-10% / + 6% of nominal voltage
Voltage Wave Form
Sine wave
Connections
See Model Matrix; divided into 3 Groups
Output Protection
Firmware overload sensing and control
Battery
Type
Maintenance-free, sealed, valve-regulated lead acid (VRLA)
Backup Time
See Backup Times Chart
Recharge Time
<3 hours to 90% usable capacity; <24 hours for complete recharge
Voltage
36V Battery String
Communications
Ports
Standard DB-9 port (Kit ships with cable for communication )
USB port (Kit ships with cable for communication)
Option Slot
(1) ( reserved for Optional Network Management Module)
Option Cards
HPE UPS Network Management Module (sold separately)
LCD Indicators
LED display integrated into the front panel
Management Software
Power Management including HPE Power Protector software. See
HPE Power Protector QuickSpec
Environmental and Safety
Operating Temperature
32° to 104° F (0° to 40° C) ( with battery)
Non-operating
Temperature
-15° to 1122° F (-26° to 50° C)
Operating Humidity
0% to 90% (non-condensing)
Storage Humidity
0% to 90% (non-condensing)
Operating Altitude
up to 2000 meters above sea level
Audible Noise
<40db (at 1m from surface of unit) <45dBA on battery operation
Safety Markings
UL/cUL CE, TUV, C-tick, CES, EAC, VCCI, GS, KC, EK, BSMI, TIS, BIS
Safety Certifications
UL1778; UL60950, CSA22.2 No.107.1,No.107.3,; CB Bulletin
IEC62040
2+A1 +A2; EN 61000-3-3
EMC Markings
FCC-BCISPR 22; VCCI B; CE, BSMI, C-TICK
Emissions
FCC CFR 47, Part 15 Class A, EN50091-2
Immunity
EN 55024; EN 50091-2 consisting of IEC 61000-4-2 thru IEC
61000-4-6 ; IEC 61000-4-11
Surge Suppression
Conforms to IEEE 587B and ANSI C62.41
RPO/ROO Port
The Normally Closed (NC) RPO shuts off power to all UPS outlets
when opened. The UPS must be manually restarted once the
terminals are closed again. There is a preinstalled jumper in the RPO
terminals.
The Normally Open (NO) ROO initiates a UPS Power On f
when closed. Opening the terminals again will shut off the UPS.
Unit Dimensions (LxWxH)
21.8x 17.2x 1.69 in (554 x 438 x 43 mm)
Shipping Dimensions
30.71x 22.8 x6.1 in (780 x 580 x 155 mm)
Unit Weight
39.06 lb (19.72 kg)
Shipping Weight
54.45 lb (24.7 kg)
selectable
for more information.
-1; IEC 60950-1; EN60950-1;EN 62040-1; EN 61000-3-
unction
QuickSpecs
HPE Rackmount UPSs
Specifications
Page 14
What’s in the box
•
• Documentation
10% / +6% of the selected nominal voltage. The regulation is accomplished by
e
3% of the selected nominal voltage as the target voltage to regulate
Transition set point voltages are subject to a hardware tolerances of +/-3% of the set point value.
HPE R1500 UPS
• Rail kit and mounting hardware
• Bezel components
• (2) Output power jump cables (International model only)
• (1) RS-232 communication cable
• (1)USB cable
• Cable locking device (International model only)
* The R1500 G5 UPS regulates the output voltage at bucking or boosting the input voltage. The voltage regulation operation is governed by the unit's input voltage spec of +/-20%. The
unit will regulate at -10% / +6% while within the limits set by the input spec. The unit will go to battery operation upon exceeding th
limits set by the input spec. The buck and boost voltage regulation operation, or AVR (Automatic Voltage Regulation), is
accomplished by adjusting output transformer tap selections via electromechanical relays. The transformer tap selection is
controlled via digital transition voltage set point values programmed in the unit's firmware. These programmed values are without
tolerance.
The unit will monitor the input voltage and accept a range of +/at -10% / +6%. For example, a unit configured to 120V nominal voltage will regulate at -10% / +6% for any voltage measured
between 116.4V and 123.6V. The digital transition voltage set point values will adjust accordingly to regulate to -10% / +6% of the
measured input voltage.
QuickSpecs
HPE Rackmount UPSs
Related Options
Page 15
UPS Network
Management Module
The HPE UPS Network Module enables you to monitor and manage power environments through
comprehensive control of HPE UPSs. The HPE UPS Management Module can support either a single
UPS configuration or provide additional power protection with support for dual redundant UPS
configuration for no
management control and flexible monitoring.
The management module can be configured to send alert traps to HPE Systems Insight Manager and
other SNMP management programs or u
enables you to monitor and manage UPSs through the network. To facilitate day
tasks, the embedded management software provides detailed system logs.
The HPE UPS Network Module prov
to the network. Configuration & Management of the UPS from anywhere and at anytime via a standard
web browser.
NOTE:
see: http://www.hpe.com/info/rackandpower.
HPE Single Phase 1GB UPS Network Management Module
Q1C17A
Extended Runtime
Module (ERM)
HPE Extended Runtime Modules increase the available runtime for the larger rack mounted UPS units
to allow customers to ensure all of their applications can be gracefully shutdown in the event of a power
failure.
•
HPE R/T2200 G4 Extended Runtime Module
J2R09A
HPE R/T3000 G4 Extended Runtime Module
J2R10A
2U R/T UPS ERM
Shipping Kit
HPE 2U Rack/Tower UPS Shipping Kit
L4Q11A
NOTE: The optional 2U shipping kit consists of heavy duty rails, front and back CTO
brackets and required mounting hardware for attaching the UPS or ERM to the rack.
This kit is an option that is required if the UPS and or ERM are going to be mounted
into a rac
whether UPS or ERM.
-single-point-of-failure. The additional serial ports will provide greater power
sed as a standalone management system. This flexibility
-to-day maintenance
ides remote management of a UPS by connecting the UPS directly
For more information on the UPS Network Module please
k that will be shipped via transport. One of these kits is required per unit,
QuickSpecs
HPE Rackmount UPSs
Warranty and Care Pack
Page 16
Warranty
When you need it, use outstanding HPE support services for your whole data center environment. With
HPE Pointnext operational services
the same service level and coverage period as your
limited warranty, with the first year including parts and labor. Also, standard on all
exclusive 30
from
under the warranty. This warranty is offered worldwide.
NOTE:
only).
The
standard on all
advantage of a
year, limited warranty by applying it to the battery before it actually fails. This
warranty is offered worldwide. Specifically, the Battery Pre-Failure Warning ensures that when customers
rec
replaced free of charge under the warranty.
NOTE: $250,000 Computer/Load Protection Guarantee is also provided in North America, in addition to
the
Warranty Upgrade Options
• Duration - Select duration of coverage for a minimum period of 1 year or multiple years
Service and Support
HPE Technology Services
HPE
infrastructure problems. We help keep your business running, boost ava
Protect your business beyond warranty with HPE Pointnext operational services
When you buy
HPE Pointnext operational services
choices designed to meet your IT and business need.
Parts and materials
Hewlett Packard Enterprise will provide HPE-supported replacement parts and materials necessary to
maintain the covered hardware product in operating condition, including parts and materials for
available and recommended engineering improvements.
Parts and components that have reached their maximum supported lifetime and/or the maximum usage
limitations as set forth in the manufacturer's operating manual, product QuickSpecs, or the technical
product data sheet will not be provided, repaired, or replaced a
The defective media retention service feature option applies only to Disk or eligible SSD/Flash Drives
replaced by HPE due to malfunction.
Coverage
For ProLiant servers and storage systems, this service covers HPE-branded hardware options qualified
for the server, purchased at the same time or afterward, internal to the enclosure, as well as external
monitors up to 22" and tower UPS products; these items will be covered at the same service level and for
the same coverage pe
usage limitation has been exceeded. Coverage of the UPS battery is not included; standard warranty
terms and conditions apply.
The defective media retention service feature option
replaced by
due to malfunction. It does not apply to any exchange of Disk or SSD/Flash Drives that
have not failed. SSD/Flash Drives that are specified by
exceeded maximum supported lifetime and/or the maximum usage limit as set forth in the
, have the security of knowing that your HPE UPS will be covered at
HPE server. HPE UPSs are backed by a 3-year
HPE UPS units is our
-day Battery Pre-Failure Warranty, which ensures that when customers receive notification
HPE Power Manager Software that the battery may fail, the battery is replaced free of charge
$250,000 Computer/Load Protection Guarantee is also provided (applicable in North America
HPE UPS is covered by a three year warranty, with the first year including parts and labor. Also,
HPE UPS units, is our exclusive Battery Pre-Failure Warning, which extends the
HPE three-
eive notification from HPE Power Management Software that the battery may fail, the battery is
HPE three year, limited warranty.
:
• Response - Upgrade on-site response from next business day to same day 4-hours
• Coverage - Extend hours of coverage from 5 days x 9 hours to 7 days x 24 hours
Technology Services offers you consultants and support experts to solve your most complex
HPE Options, it's also a good time to think about what level of service you may need.
provide total care and support expertise with committed response
s part of these services.
riod as the server unless the maximum supported lifetime and/or the maximum
HPE
applies only to Disk or eligible SSD/Flash Drives
HPE as consumable parts and/or that have
ilability and avoid downtime.
QuickSpecs
HPE Rackmount UPSs
Warranty and Care Pack
Page 17
manufacturer's operating manual or the technical data sheet are not eligible for the defective media
retention service feature option.
For more information
To learn more on services for HPE ESSN Options, please contact your Hewlett Packard Enterprise sales
representative or
visit:
or https://www.hpe.com/us/en/services/operational.html
Recommended HPE Pointnext operational services for optimal satisfaction with your HPE product
Recommended Services
3-Year HPE 24x7 4 hour Response, Hardware Support Onsite Service
Provides you with rapid remote support and if required
representative who will arrive on site any time and day of the year to begin hardware maintenance
service within 4 hours of the service request being logged.
HPE ProLiant Server Hardware Installation
Provides for the basic hardware installation of
devices and networking options to assist you in bringing your new hardware into operation in a timely
and professional manner
3-Year HPE 6 hour Hardware Support Onsite Call-to-Repair Service
Provides an IT manager with a team of support specialists who will quickly begin troubleshooting the
system to help return the hardware to operating condition within 6 hours of the initial service request to
the HPE Global Solution Center
HPE Proactive Select Service
Provides a flexible way to purchase
Proactive Select Service Credits when you purchase your hardware and then use the credits over the
next 12 months.
HPE Pointnext
operational services
HPE Install Universal Power Supply 3KVA to Below 6KVA Service
U4693E
HPE Install Universal Power Supply Less Than 3KVA Service
U4690E
Hewlett Packard Enterprise Authorized Channel Partner. Or
https://www.hpe.com/us/en/support.html
a Hewlett Packard Enterprise Authorized
Hewlett Packard Enterprise branded servers, storage
HPE best-in-class consultancy and technical services. You can buy
QuickSpecs
HPE Rackmount UPSs
HPE Model Matrix
Page 18
Rack/Tower models
HPE R/T2200 G5 UPS
Part Number
Operating
Voltage
Default Voltage
Setting
Power Out
(VA/Watts)
Input Connection
Output Connection
Q1L84A NA/JP
120V to 125V
1920/1920
NEMA 5-20P 20A,
(8) –NEMA 5-20
(2) Load Group 2
100V
1500/1400
HPE R/T3000 G5 UPS Models
Part Number
Operating
Voltage Settings
Power Out
(VA/Watts)
Input Connection
Output Connection
Q1L85A LV NA/JP
120V1 to 125V
2880/2700
L5-30P, 2.4m cord
(6) NEMA 5-20R
100V
1500/1400
Q1L86A HV NA/JP
208V1
3000/2700
L6-20P, 2.4m cord
(8) IEC C13
19 which includes
C13
200V
2490/2241
Q1L87A HV INTL
220V to 240V
3000/
2700
Detachable IEC C-20
(8) IEC C13
19 which includes
C13
2490/2241
3m cord
120V
Receptacles,
(4) Primary Group
(2) Load Group 1
(1) NEMA L5-30 which
includes
120V
(2) Primary Group 5-20R
and (1) L5-30,
(2) Load Group 1 5-20R
and (2) Load Group 2 5-
20R
(1) IEC C-
(4) Primary Group IEC C13
200V
and (1) IEC C19,
(2) Load Group 1 IEC C13
and (2) Load Group 2 IEC
230V
inlet plug for
attaching country
specific power cord
(1) IEC C-
(4) Primary Group IEC C13
and (1) IEC C19,
(2) Load Group 1 IEC C13
and (2) Load Group 2 IEC
QuickSpecs
HPE Rackmount UPSs
HPE Model Matrix
Page 19
Rack model
HPE R1500 G5 UPS
Part Number
Operating
Voltage Settings
Default Voltage
Setting
Power Out
(VA/Watts)
Input Connection
Output Connection
Q1L88A NA
120V to 125V
1920/1920
NEMA 5-15P
(5) NEMA 5-15R which
100V
1500/1400
Q1L89A JP/TWN
100V
1200/900
NEMA 5-15P
With Taiwan approval
(5) NEMA 5-15R which
includes
15R
120V1 to 125V
1440/1100
Q1L90A INTL
220V/230V/240V
1550/1100
C14 inlet for
(5) NEMA 5-15R which
includes
(1) Primary Group 5
(2) Load Group 1 5
and (2) Load Group 2 5
15R
200V to 208V
1395/990
NOTE: Voltage is user selectable via LCD Front Display Panel.
Estimated Runtime with Extended Runtime Module (ERM)
Power
Estimated Runtime (min)
Load %
Watts
Internal Batteries
1 ERM
2 ERMs
3 ERMs
4 ERMs
120V
includes
100V
(1) Primary Group 5-15R
(2) Load Group 1 5-15R
and (2) Load Group 2 5-
230V
attaching country
specific power cord
Battery runtimes are approximate and may vary with equipment, configuration, battery age, temperature, etc.
R/T2200 G5 UPS
10 191.1 80.1 286.9 491.0 725.3 898.3
20 382.2 30.5 122.9 217.7 311.0 406.2
30 573.3 17.3 74.9 135.3 189.5 255.4
40 764.4 11.6 52.7 96.5 133.3 183.7
50 955.5 8.5 40.1 74.3 101.5 142.3
60 1146.6 6.6 32.1 60.0 81.2 115.5
70 1337.7 5.3 26.6 50.1 67.3 96.8
80 1528.8 4.4 22.6 42.8 57.2 83.1
90 1719.9 3.7 19.5 37.3 49.5 72.6
100 1911 3.2 17.2 32.9 43.5 64.3
-15R
-15R
-
QuickSpecs
HPE Rackmount UPSs
HPE Model Matrix
Page 20
R/T3000 G5 UPS
Internal
Power Estimated Runtime (min)
Load % Watts
10 270 61.4 281.0 474.6 665.5 859.7
20 540 27.7 126.5 219.4 311.4 404.5
30 810 17.4 79.3 139.7 199.8 260.2
40 1080 12.5 57.0 101.4 145.8 190.3
50 1350 9.6 44.1 79.1 114.1 149.3
60 1620 7.8 35.7 64.6 93.5 122.4
70 1890 6.5 29.9 54.4 79.0 103.5
80 2160 5.6 25.7 46.9 68.2 89.5
90 2430 4.9 22.4 41.1 60.0 78.8
100 2700 4.3 19.8 36.6 53.4 70.3
Batteries
1 ERM 2 ERMs 3 ERMs 4 ERMs
QuickSpecs
HPE Rackmount UPSs
Estimated Backup Times
Page 21
R/T3000 G5 UPS High Voltage
Internal
Batteries
R1500 G5 UPS Estimated Runtime
R1500 G4 UPS Models
Load %
Watts
Estimated Runtime (min)
10
109
97
20
219
39
30
328
23
40
438
16
547
12
60
656
10
766
8
80
875
7
90
985
6
100
1094
5
Environment-friendly Products
Hewlett Packard Enterprise offers end-of-life product return, trade-in, and recycling
the
instructions may be used by recyclers and other WEEE treatment facilities as well as Hewlett
Power Estimated Runtime (min)
Load % Watts
10 270 83.3 259.1 456.9 655.5 853.5
20 540 31.4 121.8 219.2 316.8 414.0
30 810 17.7 78.3 142.7 207.1 271.1
40 1080 11.8 57.2 105.2 153.2 200.8
50 1350 8.6 44.9 83.0 121.2 159.1
60 1620 6.7 36.8 68.4 100.1 131.5
70 1890 5.4 31.1 58.1 85.2 112.0
80 2160 4.4 26.9 50.5 74.0 97.4
90 2430 3.8 23.6 44.5 65.4 86.1
100 2700 3.2 21.1 39.8 58.6 77.2
1 ERM 2 ERMS 3 ERMs 4 ERMs
50
70
and ApproachEnd-of-life Management and
programs, in many geographic areas, for our products. Products returned to Hewlett Packard
Enterprise will be recycled, recovered or disposed of in a responsible manner.
Recycling
The EU WEEE Directive (2012/19/EU) requires manufacturers to provide treatment
information for each product type for use by treatment facilities. This information (product
disassembly instructions) is posted on
Hewlett Packard Enterprise web site. These
QuickSpecs
HPE Rackmount UPSs
Estimated Backup Times
Page 22
Packard Enterprise OEM customers who integrate and re-sell Hewlett Packard Enterprise
equipment.
QuickSpecs
HPE Rackmount UPSs
Summary of Changes
Page 23
Date
Version History
Action
Description of Change
02-Apr-2018
Version 1
New
New QuickSpecs
