QuickSpecs
HPE 1910 Switch Series
Overview
Page 1
HPE 1910 Switch Series
Models
HP 1910-48G Switch
JE009A
HP 1910-24G-PoE (365W) Switch
JE007A
HP 1910-24G-PoE(170W) Switch
JE008A
HP 1910-24G Switch
JE006A
HP 1910-16G Switch
JE005A
HP 1910-8G Switch
JG348A
HP 1910-8G-PoE+ (65W) Switch
JG349A
HP 1910-8G-PoE+ (180W) Switch
JG350A
HP 1910-24 Switch
JG538A
HP 1910-8 Switch
JG536A
HP 1910-48 Switch
JG540A
HP 1910-8 -PoE+ Switch
JG537A
HP 1910-24-PoE+ Switch
JG539A
Key features
Product overview
The HPE 1910 Switch Series consists of advanced smart
configuration Gigabit and Fast Ethernet switches designed for small businesses in an easy most power efficient in the market.
The series has 13 sw are equipped with additional Gigabit SFP ports for fiber connectivity; in addition to non Ethernet models are available with PoE (at two different levels) or without PoE. The 10/100 models are available with 8, 24 and 48 ports, and come with two additional combination uplink ports. The 8 without PoE.
The network. All models support rack mounting or desktop operation. Customizable features include basic Layer 2 features like VLA and link a switches come with a limited lifetime warranty covering the unit, fans, and power supplies.
Features and benefits
RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may
have older product names and model numbers that differ from current models.
Customized operation using intuitive Web interface
Layer 3 static routing with 32 network segments and expansion routes.
Access control lists for granular security control
Spanning Tree: STP, RSTP, and MSTP
Limited Lifetime Warranty
-managed fixed-
-to-administer solution. By utilizing the latest design in silicon technology, this series is one of the
itches: eight Gigabit Ethernet and five Fast Ethernet models. The 8-, 16-, 24-, and 48-port 10/100/1000 models
-PoE models, the 8- and 24-port Gigabit
- and 24-port Fast Ethernet models are available with or
HPE 1910 Switch Series provides a great value, and includes features to satisfy even the most advanced small business
ggregation, as well as advanced features such as Layer 3 static routing, IPv6, ACLs, and Spanning Tree Protocols. The
Ns
QuickSpecs
HPE 1910 Switch Series
Overview
Page 2
Management
restricts access to critical configuration commands; offers multiple privilege levels with password protection; ACLs provide
Quality of Service (QoS)
Connectivity
o
RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may
have older product names and model numbers that differ from current models.
Simple Web management
Single IP management
Secure Web GUI
SNMPv1, v2c, and v3
Complete session logging
Dual flash images
Port mirroring
Management security
Network Time Protocol (NTP)
IEEE 802.1AB Link Layer Discovery Protocol (LLDP)
Limited CLI
RMON
Default DHCP client mode
allows for easy management of the switch- even by nontechnical users- through an intuitive Web GUI; http and secure http (https) is supported
enables management of up to four HPE 1910 devices using a single Web interface; simplifies management of multiple devices
provides a secure, easy-to-use graphical interface for configuring the module via HTTPS
facilitates management of the switch, as the device can be discovered and monitored from an SNMP management station
provides detailed information for problem identification and resolution
provides independent primary and secondary operating system files for backup while upgrading
enables traffic on a port to be simultaneously sent to a network analyzer for monitoring
Telnet and SNMP access; local and remote syslog capabilities allow logging of all access
synchronizes timekeeping among distributed time servers and clients; keeps timekeeping consistent among all clock­dependent devices within the network so that the devices can provide diverse applications based on the consistent time
advertises and receives management information from adjacent devices on a network, facilitating easy mapping by network management applications
enables users to quickly deploy and troubleshoot devices in the network
provides advanced monitoring and reporting capabilities for statistics, history, alarms, and events
allows the switch to be directly connected to a network, enabling plug-and-play operation; in absence of DHCP server on the network, the switch will fallback to a unique static address determined by the MAC address of the switch
Broadcast control
allows limitation of broadcast traffic rate to cut down on unwanted network broadcast traffic
Rate limiting
sets per-port ingress enforced maximums and per-port, per-queue minimums
Traffic prioritization
provides time-sensitive packets (like VoIP and video) with priority over other traffic based on DSCP or IEEE 802.1p classification; packets are mapped to four hardware queues for more effective throughput
IPv6
IPv6 host
QuickSpecs
HPE 1910 Switch Series
Overview
Page 3
Secu
Perfor
Selectable queue configurations
RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may
have older product names and model numbers that differ from current models.
enables switches to be managed and deployed at the IPv6 network's edge
o IPv6 routing
supports IPv6 static routes
o MLD snooping
forwards IPv6 multicast traffic to the appropriate interface, preventing traffic flooding
o IPv6 ACL/QoS
supports ACL and QoS for IPv6 network traffic
Auto-MDI/MDIX
adjusts automatically for straight-through or crossover cables on all 10/100/1000 ports
IEEE 802.3X flow control
provides a flow throttling mechanism propagated through the network to prevent packet loss at a congested node
IEEE 802.3af Power over Ethernet (PoE) ready
provides up to 15.4 W per port to power standards-compliant IP phones, wireless LAN access points, Web cameras, and more (all PoE models)
IEEE 802.3at Power over Ethernet (PoE+)
provides up to 30 W per port which allows support of the latest PoE+-capable devices such as IP phones, wireless access points, and security cameras, as well as any IEEE 802.3af-compliant end device; eliminates the cost of additional electrical cabling and circuits that would otherwise be necessary in IP phone and WLAN deployments. (NOTE: applies to all PoE models, except the two 24G-PoE models which support a pre-standard implementation of PoE+)
Packet storm protection
protects against broadcast, multicast, or unicast storms with user-defined thresholds
Cable diagnostics
detects cable issues remotely, using a browser-based tool
rity
Advanced access control lists (ACLs)
enables network traffic filtering and enhances network control using MAC- and IP-based ACLs; time-based ACLs allow for greater flexibility with managing network access
Secure Sockets Layer (SSL)
encrypts all HTTP traffic, allowing secure access to the browser-based management GUI in the switch
IEEE 802.1X and RADIUS network logins
controls port-based access for authentication and accountability
Automatic VLAN assignment
assigns users automatically to the appropriate VLAN based on their identity, location and time of day
STP BPDU port protection
blocks Bridge Protocol Data Units (BPDUs) on ports that do not require BPDUs, preventing forged BPDU attacks
STP root guard
protects the root bridge from malicious attacks or configuration mistake
Automatic denial-of-service protection
monitors for malicious attacks and protects the network by blocking the attacks
Management password
provides security so that only authorized access to the Web browser interface is allowed
mance
Half-/full-duplex auto-negotiating capability on every port
doubles the throughput of every port
QuickSpecs
HPE 1910 Switch Series
Overview
Page 4
allows for increased performance by selecting the number of queues and associated memory buffering that best meet the
Layer 2 switching
Layer 3 services
determines the MAC address of another IP host in the same subnet; supports static ARPs; gratuitous ARP allows detection
Layer 3 routing
Resiliency and high availability
Convergence
defines a standard extension of LLDP that stores values for parameters such as QoS and VLAN to automatically configure network devices such as IP phones
RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may
have older product names and model numbers that differ from current models.
requirements of the network applications
IGMP snooping
improves network performance through multicast filtering, instead of flooding traffic to all ports
Fiber uplink
provides greater distance connectivity using Gigabit fiber uplinks
VLAN support and tagging
supports IEEE 802.1Q (4,094 VLAN IDs) and 256 VLANs simultaneously
Spanning Tree Protocol (STP)
supports standard IEEE 802.1D STP, IEEE 802.1w Rapid Spanning Tree Protocol (RSTP) for faster convergence, and IEEE
802.1s Multiple Spanning Tree Protocol (MSTP)
BPDU filtering
drops BPDU packets when STP is enabled globally but disabled on a specific port
Jumbo frame support
supports up to 10 kilobyte frame size to improve the performance of large data transfers
Address Resolution Protocol (ARP)
of duplicate IP addresses; proxy ARP allows normal ARP operation between subnets or when subnets are separated by a Layer 2 network
DHCP relay
simplifies management of DHCP addresses in networks with multiple subnets
NEW Static IPv4/IPv6 routing
provides basic routing (supporting up to 32 static routes and 8 virtual VLAN interfaces); allows manual configuration of routing
Available redundant power supply
provides additional PoE of up to 740 W for high-power applications like HPE Gigabit Ethernet IntelliJack switches; the HPE RPS1600 Redundant Power System (JG136A), sold separately, is only for use with the 1910-24G-PoE (365W) Switch model
Link aggregation
groups together multiple ports (up to a maximum of 2 ports) automatically using Link Aggregation Control Protocol (LACP), or manually, to form an ultra-high-bandwidth connection to the network backbone; helps prevent traffic bottlenecks
LLDP-MED (Media Endpoint Discovery)
QuickSpecs
HPE 1910 Switch Series
Overview
Page 5
Additional information
Warranty and support
RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may
have older product names and model numbers that differ from current models.
PoE allocations
supports multiple methods (automatic, IEEE 802.3af class, LLDP-MED, or user-specified) to allocate PoE power for more efficient energy savings
Auto voice VLAN
recognizes IP phones and automatically assigns voice traffic to dedicated VLAN for IP phones
Green initiative support
provides support for RoHS and WEEE regulation
Green IT and power
improves energy efficiency through the use of the latest advances in silicon development; shuts off unused ports and utilizes variable-speed fans, reducing energy costs
Limited Lifetime Warranty
See http://www.hpe.com/networking/warrantysummary product purchase.
for warranty and support information included with your
QuickSpecs
HPE 1910 Switch Series
Configuration
Page 6
Build To Order
Shippable solution.
HP 1910-8 Switch
JG536A
See Configuration
HP 1910-8 -PoE+ Switch
JG537A
See Configuration
HP 1910-8G Switch
JG348A
See Configuration
PDU Cable NA/MX/TW/JP
JG348A#B2B
PDU Cable ROW
JG348A#B2C
HP 1910-8G-PoE+ (65W) Switch
JG349A
See Configuration
PDU Cable NA/MX/TW/JP
JG349A#B2B
PDU Cable ROW
JG349A#B2C
RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may
have older product names and model numbers that differ from current models.
: BTO is a standalone unit with no integration. BTO products ship standalone are not part of a CTO or Rack-
8 RJ-45 autosensing 10/100 ports
2 SFP dual-personality 1000 Mbps ports
min=0 \ max=2 SFP Transceivers
1U - Height
8 RJ-45 auto-negotiating 10/100 ports
2 SFP dual-personality 1000 Mbps ports
min=0 \ max=2 SFP Transceivers
1U - Height
8 RJ-45 auto-negotiating 10/100/1000 ports
1 SFP 1000 Mbps port
min=0 \ max=1 SFP Transceiver
1U - Height
NOTE: 2,3
NOTE:2,3
NOTE: 4,5
C15 PDU Jumper Cord (NA/MX/TW/JP)
C15 PDU Jumper Cord (ROW)
8 RJ-45 auto-negotiating 10/100/1000 ports
1 SFP 1000 Mbps port
min=0 \ max=1 SFP Transceiver
1U - Height
C15 PDU Jumper Cord (NA/MX/TW/JP)
NOTE: 4,5
QuickSpecs
HPE 1910 Switch Series
Configuration
Page 7
HP 1910-8G-PoE+ (180W) Switch
JG350A
See Configuration
PDU Cable NA/MX/TW/JP
JG350A#B2B
PDU Cable ROW
JG350A#B2C
HP 1910-16G Switch
JE005A
See Configuration
PDU Cable NA/MX/TW/JP
PDU Cable ROW
HP 1910-24G-PoE(170W) Switch
JE008A
See Configuration
PDU Cable NA/MX/TW/JP
JE008A#B2B
PDU Cable ROW
JE008A#B2C
RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may
have older product names and model numbers that differ from current models.
C15 PDU Jumper Cord (ROW)
8 RJ-45 auto-negotiating 10/100/1000 ports
1 SFP 1000 Mbps port
min=0 \ max=1 SFP Transceiver
1U - Height
C15 PDU Jumper Cord (NA/MX/TW/JP)
C15 PDU Jumper Cord (ROW)
16 RJ-45 auto-negotiating 10/100/1000 ports
4 SFP 1000 Mbps port
min=0 \ max=4 SFP Transceivers
1U - Height
NOTE:4,5
NOTE:1, 5
JE005A#B2B
C15 PDU Jumper Cord (NA/MX/TW/JP)
JE005A#B2C
C15 PDU Jumper Cord (ROW)
24 RJ-45 auto-negotiating 10/100/1000 ports
4 SFP 1000 Mbps ports
min=0 \ max=4 SFP Transceivers
1U - Height
C15 PDU Jumper Cord (NA/MX/TW/JP)
NOTE:1, 5
C15 PDU Jumper Cord (ROW)
QuickSpecs
HPE 1910 Switch Series
Configuration
Page 8
HP 1910
See Configuration
PDU Cable NA/MX/TW/JP
JE007A#B2B
PDU Cable ROW
JE007A#B2C
HP 1910-24G Switch
JE006A
See Configuration
PDU Cable NA/MX/TW/JP
JE006A#B2B
PDU Cable ROW
JE006A#B2C
HP 1910-24 Switch
JG538A
See Configuration
HP 1910-24-PoE+ Switch
JG539A
See Configuration
HP 1910
48 RJ-45 auto-negotiating 10/100/1000 ports
See Configuration
RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may
have older product names and model numbers that differ from current models.
-24G-PoE (365W) Switch JE007A 24 RJ-45 auto-negotiating 10/100/1000 ports
4 SFP 1000 Mbps ports
min=0 \ max=4 SFP Transceivers
1U - Height
NOTE:1, 5
C15 PDU Jumper Cord (NA/MX/TW/JP)
C15 PDU Jumper Cord (ROW)
24 RJ-45 auto-negotiating 10/100/1000 ports
4 SFP 1000 Mbps ports
min=0 \ max=4 SFP Transceivers
1U - Height
C15 PDU Jumper Cord (NA/MX/TW/JP)
NOTE:1, 5
C15 PDU Jumper Cord (ROW)
24 RJ-45 autosensing 10/100 ports
2 SFP dual-personality 1000 Mbps ports
min=0 \ max=2 SFP Transceivers
1U - Height
24 RJ-45 auto-negotiating 10/100 ports
2 SFP dual-personality 1000 Mbps ports
min=0 \ max=2 SFP Transceivers
1U - Height
-48G Switch JE009A
NOTE:2,3
NOTE: 2,3
QuickSpecs
HPE 1910 Switch Series
Configuration
Page 9
PDU Cable NA/MX/TW/JP
JE009A#B2B
PDU Cable ROW
JE009A#B2C
HP 1910-48 Switch
JG540A
See Configuration
Configuration Rules:
Note 1
The following Transceivers install into this switch:
HP X121 1G SFP LC SX Transceiver
J4858C
HP X121 1G SFP LC LX Transceiver
J4859C
HP X121 1G SFP RJ45 T Transceiver
J8177C
HP X120 1G SFP LC SX Transceiver
JD118B
HP X120 1G SFP LC LX Transceiver
JD119B
HP X125 1G SFP RJ45 T Transceiver
JD089A
HP X125 1G SFP LC LH40 1310nm Transceiver
JD061A
HP X120 1G SFP LC LH40 1550nm Transceiver
JD062A
HP X125 1G SFP LC LH70 Transceiver
JD063B
HP X120 1G SFP LC BX 10-U Transceiver
JD098B
HP X120 1G SFP LC BX 10
JD099B
Note 2
Localization required. (See Localization Menu for list.)
Note 3
The following Transceivers install into this switch:
HP X121 1G SFP LC SX Transceiver
J4858C
HP X121 1G SFP LC LX Transceiver
J4859C
HP X120 1G SFP LC LX Transceiver
JD119B
Note 4
The following Transceivers install into this switch:
HP X121 1G SFP LC SX Transceiver
J4858C
HP X121 1G SFP LC LX Transceiver
J4859C
HP X121 1G SFP RJ45 T Transceiver
J8177C
RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may
have older product names and model numbers that differ from current models.
4 SFP 1000 Mbps ports
min=0 \ max=4 SFP Transceivers
1U - Height
NOTE:1, 5
C15 PDU Jumper Cord (NA/MX/TW/JP)
C15 PDU Jumper Cord (ROW)
48 RJ-45 autosensing 10/100 ports
2 RJ-45 autosensing10/100/1000 ports
2 SFP 1000 Mbps ports
min=0 \ max=2 SFP Transceivers
1U - Height
NOTE: 2,3
-D Transceiver
QuickSpecs
HPE 1910 Switch Series
Configuration
Page 10
HP X120 1G SFP LC SX Transceiver
JD118B
HP X120 1G SFP LC LX Transceiver
JD119B
HP X120 1G SFP RJ45 T Transceiver
JD089B
HP X125 1G SFP LC LH40 1310nm Transceiver
JD061A
HP X120 1G SFP LC LH40 1550nm Transceiver
JD062A
HP X125 1G SFP LC LH70 Transceiver
JD063B
Note 5
Localization (Wall Power Cord) required on orders without #B2B or #B2C (PDU Power Cord). (See Localization Menu)
Internal or External Power Supplies(Model Dependant)
Internal Power supplies Included
External Redundant Power Supplies
HP RPS1600 Redundant Power System
JG136A
See Configuration
HP RPS1600 1600W AC Power Supply
JG137A
See Configuration Configuration Rules:
Note 1
If this power supply is selected, The JG136A System must be on order or onsite.
Note 2
Localization required.
Note 3
Each switch will
Note 4
This power supply only supported on switch JE007A.
Options for the HP 1600 External RPS Power Supply
HP X290 1000 A JD5 2m RPS Cable
JD187A
See Configuration
NOTE:1
Remark:
These cables are used to connect the External Power System to Switch.
Configuration Rules:
RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may
have older product names and model numbers that differ from current models.
Height = 1U
includes 1 x c13, 1600w and Power Supply port
NOTE:2,3,4
Installs into JG136A only
NOTE:1,3
- HP A-RPS1600 Redundant Power
only support 1 JG136A and 1 JG137A Power supply systems.
QuickSpecs
HPE 1910 Switch Series
Configuration
Page 11
Note 1
This Cable is only supported on switch JE007A when used with the RPS 1600 (JG136A)
Transceivers
SFP Transc
HP X121 1G SFP LC SX Transceiver
J4858C
HP X121 1G SFP LC LX Transceiver
J4859C
HP X121 1G SFP RJ45 T Transceiver
J8177C
HP X120 1G SFP LC SX Transceiver
JD118B
HP X120 1G SFP LC LX Transceiver
JD119B
HP X120 1G SFP RJ45 T Transceiver
JD089B
HP X120 1G SFP LC BX 10-U Transceiver
JD098B
HP X120 1G SFP LC BX 10-D Transceiver
JD099B
HP X125 1G SFP LC LH40 1310nm Transceiver
HP X120 1G SFP LC LH40 1550nm Transceiver
JD062A
HP X125 1G SFP LC LH70 Transceiver
JD063B
Cables
Multi-Mode Cables
HP LC to LC Multi-mode OM3 2-Fiber 0.5m 1-Pack Fiber Optic Cable
AJ833A
HP LC to LC Multi-mode OM3 2-Fiber 1.0m 1-Pack Fiber Optic Cable
AJ834A
HP LC to LC Multi-mode OM3 2-Fiber 2.0m 1-Pack Fiber Optic Cable
AJ835A
HP LC to LC Multi-mode OM3 2-Fiber 5.0m 1-Pack Fiber Optic Cable
AJ836A
HP LC to LC Multi-mode OM3 2-Fiber 15.0m 1-Pack Fiber Optic Cable
AJ837A
HP LC to LC Multi-mode OM3 2-Fiber 30.0m 1-Pack Fiber Optic Cable
AJ838A
HP LC to LC Multi
HP Premier Flex LC/LC Multi-mode OM4 2 fiber 1m Cable
QK732A
HP Premier Flex LC/LC Multi-mode OM4 2 fiber 2m Cable
QK733A
HP Premier Flex LC/LC Multi-mode OM4 2 fiber 5m Cable
QK734A
HP Premier Flex LC/LC Multi-mode OM4 2 fiber 15m Cable
QK735A
HP Premier Flex LC/LC Multi-mode OM4 2 fiber 30m Cable
QK736A
HP Premier Flex LC/LC Multi-mode OM4 2 fiber 50m Cable
QK737A
RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may
have older product names and model numbers that differ from current models.
eivers
JD061A
-mode OM3 2-Fiber 50.0m 1-Pack Fiber Optic Cable AJ839A
QuickSpecs
HPE 1910 Switch Series
Technical Specifications
Page 12
HP 1910-48G Switch
Physical characteristics
Dimensions
17.4(w) x 10.24(d) x 1.7(h) in (44.2 x 26.01 x 4.32 cm) (1U height)
Weight
6.8 lb (3.08 kg)
Memory and processor
Module
ARM @ 333 MHz, 128 MB flash, 128 MB RAM; packet buffer size: 512 KB
Mounting and enclosure
Mounts in an EIA-standard 19 in. telco rack or equipment cabinet (hardware included)
100 Mb Latency
< 5 µ
< 5 µ
Throughput
up to 77.4 Mpps (64
capacity
104 Gbps
Routing table size
32 entries (IPv4), 32 entries (IPv6)
MAC address table size
8192 entries
Operating temperature
32°F to 113°F (0°C to 45°C)
10% to 90%, non
Nonoperating/Storage temperature
-
10% to 95%, non
Electrical characteristics
Frequency
50/60
Voltage
100
Maximum power rating
59.8 W
Maximum power rating and maximum heat dissipation are the worst theoretical maximum numbers provided for planning the infrastructure with fully loaded PoE (if equipped), 100% traffic, all ports plugged in, and all modules populated.
Safety
61000-3-3; ICES-003 Class A
IEEE 802.3 Ethernet MIB
Notes
RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may
have older product names and model numbers that differ from current models.
(JE009A)
Ports 48 RJ-45 auto-negotiating 10/100/1000 ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type
100BASE-TX, IEEE 802.3ab Type 1000BASE-T) 4 SFP 1000 Mbps ports 1 RJ-45 console port to access limited CLI port Supports a maximum of 48 autosensing 10/100/1000 ports plus 4 1000BASE-X SFP ports, or a combination 4 SFP 1000 Mbps ports Supports a maximum of 48 autosensing 10/100/1000 ports plus 4 1000BASE-X SFP ports, or a combination
Performance
Environment
Achieved Miercom Certified Green Award
1000 Mb Latency
Routing/Switching
Operating relative humidity
Nonoperating/Storage relative humidity
Notes
s s
-byte packets)
-condensing
40°F to 158°F (-40°C to 70°C)
-condensing
Hz
-240 VAC
-case
UL 60950; IEC 60950-1; EN 60950-1; CAN/CSA-C22.2 No. 60950-1-03
Emissions FCC part 15 Class A; VCCI Class A; EN 55022 Class A; CISPR 22 Class A; EN 55024; EN 61000-3-2 2000,
Management IMC - Intelligent Management Center; limited command-line interface; Web browser; SNMP Manager;
SFP ports and copper ports work simultaneously, independent of each other to give a total of 52
QuickSpecs
HPE 1910 Switch Series
Technical Specifications
Page 13
Gigabit-capable ports.
times in your area, please contact your local Hewlett Packard Enterprise sales office
HP 1910-24G-PoE (365 W) Switch
combination
Dimensions
Weight
Mounting and enclosure
Mounts in an EIA-standard 19 in. telco rack or equipment cabinet (hardware included)
100 Mb Latency
1000 Mb Latency
Throughput
Routing table size
32 entries (IPv4), 32 entries (IPv6)
MAC address table size
Operating temperature
humidity
Non-operating/Storage temperature
relative humidity
Frequency
Voltage
PoE power
365 W
supplemented with the use of an external power supply (EPS).
Emissions
61000-3-3; ICES-003 Class A
RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may
have older product names and model numbers that differ from current models.
Services
Refer to the Hewlett Packard Enterprise website at http://www.hpe.com/networking/services for details on the service-level descriptions and product numbers. For details about services and response
(JE007A)
Ports 24 RJ-45 auto-negotiating 10/100/1000 PoE ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type
100BASE-TX, IEEE 802.3ab Type 1000BASE-T, IEEE 802.3af PoE) 4 SFP 1000 Mbps ports 1 RJ-45 console port to access limited CLI port Supports a maximum of 24 autosensing 10/100/1000 ports plus 4 1000BASE-X SFP ports, or a
Physical characteristics
17.4(w) x 16.54(d) x 1.7(h) in (44.2 x 42.01 x 4.32 cm) (1U height)
6.8 lb (3.08 kg)
Memory and processor Module ARM @ 333 MHz, 128 MB flash, 128 MB RAM; packet buffer size: 512 KB
Performance
< 5 µs < 5 µs up to 41.7 Mpps (64-byte packets)
Routing/Switching capacity
56 Gbps
8192 entries
Environment
Operating relative
32°F to 113°F (0°C to 45°C)
10% to 90%, non-condensing
-40°F to 158°F (-40°C to 70°C)
Non-operating/Storage
Electrical characteristics
10% to 95%, non-condensing
50 / 60 Hz 100-240 VAC
Maximum power rating 523 W
Notes Maximum power rating and maximum heat dissipation are the worst-case
theoretical maximum numbers provided for planning the infrastructure with fully loaded PoE (if equipped), 100% traffic, all ports plugged in, and all modules populated. PoE power is the power supplied by the internal power supply. It is dependent on the type and quantity of power supplies and may be
Safety UL 60950; IEC 60950-1; EN 60950-1; CAN/CSA-C22.2 No. 60950-1-03
FCC part 15 Class A; VCCI Class A; EN 55022 Class A; CISPR 22 Class A; EN 55024; EN 61000-3-2 2000,
Loading...
+ 29 hidden pages
