HPE FlexNetwork MSR3000 Router Series

Overview

HPE FlexNetwork MSR3000 Router Series

The HPE FlexNetwork MSR3000 Router Series, the next generation of router from Hewlett Packard Enterprise (HPE), is a component of the HPE FlexBranch solution, which is a part of the comprehensive HPE FlexNetwork architecture. These routers feature a modular design that delivers unmatched application services for medium

sized branch offices. This gives your IT personnel the

benefit

The MSR3000 routers use the latest multicore CPUs, offer Gigabit switching, provide an enhanced PCI bus, and ship with the latest version of HPE Comware software to help ensu

featured, resilient routing platform, including IPv6 and MPLS, with up to 5 Mpps forwarding capacity and 3.3 Gbps of IPSec VPN encrypted throughput. These routers also support HPE Open Application Platform (OAP) modules to deliver integrated industryleading HPE AllianceOne partner applications such as virtualization, unified communications and collaboration (UC&C), and application optimization capabilities.

The MSR3000 series provides an agile, flexible network infrastructure that enables you to quickly adapt to changing business requirements while delivering integrated concurrent services on a single, easy-to-manage platform.

HPE FlexNetwork MSR3012 AC Router - Front

HPE FlexNetwork MSR3024 AC Router - Front

- to large-

of reduced complexity, and simplified configuration, deployment, and management.

re high performance with concurrent services. The MSR3000 series provides a full

Page

QuickSpecs

HPE FlexNetwork MSR3000 Router Series

Overview

HPE FlexNetwork MSR3044 Router- Front

HPE FlexNetwork MSR3064 Router - Front

Models

Description

SKU

HPE MSR3012 AC Router

JG409B

HPE FlexNetwork MSR3024 AC Router

JG406A

HPE FlexNetwork MSR3044 Router

JG405A

HPE FlexNetwork MSR3064 Router

JG404A

Key features

• Up to 5 Mpps forwarding performance; support for multiple concurrent services

• Open Application Platform for HPE AllianceOne applications

• Embedded security features with hardware-based encryption, stateful firewall, NAT, and VPNs

• No additional licensing complexity; no cost for advanced features

•

Zero-touch solution, with single pane-of-glass managemen

Page

QuickSpecs

HPE FlexNetwork MSR3000 Router Series

Standard Features

Performance

full service performance (NAT + QoS + ACL Performance by Platform, IMIX Traffic), 1Gbps for MSR3012/3024,

ware encryption accelerator to improve encryption performance; IPSec encryption throughput can be up to 3.3 Gb/s with a maximum of 4,000 IPSec VPN tunnels, support up to 2000 VRF instances.

Connectivity

IP technology that provides Layer 2 connectivity between distant Layer 2 network sites across an IP routed

scale data center that requires Layer 2

based network, using the "MAC in UDP" package

ed physical site

ckbone

is transparent to the customer sites, which can communicate with each other as if they were on the same LAN. The following

Network mobility (NEMO) enables a node to retain the same IP address and maintain application connectivity when the node

board Gigabit Ethernet ports, 8 or 24 ports GE supported on

port Fast/Giga Ethernet,POE/POE+; mobility access with 3G (WCDMA/HSPA)/4G LTE SIC modules and

upports internal loopback testing for maintenance purposes and an increase in availability; loopback detection protects

n various

ses USB memory disk to download and upload configuration/OS image files; supports an external USB 3G/4G modem for a

speed detection plus auto duplex and MDI/MDI-X

• Excellent forwarding performance

• Powerful security capacity

• Ethernet Virtual Interconnect (EVI)

• VXLAN (Virtual eXtensible LAN)

• Virtual Private LAN Service (VPLS)

Excellent

1.5Gbps for MSR3044, 2Gbps for MSR3064.

The MSR3000 series is available with standard or high encryption, an embedded hard

EVI is a MAC-innetwork. It is used for connecting geographically dispersed sites of a virtualized largeadjacency.

VXLAN (Virtual eXtensible LAN, scalable virtual local area network) is an IPof Layer VPN technology. VXLAN can be based on an existing ISP or enterprise IP networks for decentraliz provides Layer 2 communication, and can provide service isolation for different tenants.

Virtual Private LAN Service (VPLS) delivers a point-to-multipoint L2VPN service over an MPLS or IP backbone. The ba

protocols support on MSRs, RFC4447, RFC4761 and RFC4762, BFD detection in VPLS, Support hierarchical HOPE (H VPLS), MAC address recovery in H-VPLS to speed up convergence.

• NEMO (Network Mobility)

travels across networks. It allows location-independent routing of IP datagrams on the Internet.

• High-density port connectivity

Provides up to 10 interface module slots and up to three onone HMIM module.

• Multiple WAN interfaces

Provides traditional links with E1, T1, G.SHDSL, and ISDN links; high-density Ethernet access with WAN Gigabit Ethernet

and LAN 4- and 93G/4G USB modems, and high-speed T3 and 155 Mb/s OC3 access options

• Packet storm protection

Protects against broadcast, multicast, or unicast storms with user-defined thresholds

• Loopback

S against incorrect cabling or network configurations and can be enabled on a per-port or per-VLAN basis for added flexibility

• 3G/4G LTE access support

Provides 3G/4G LTE wireless access for primary or backup connectivity via a 3G/4G LTE SIC module certified o cellular networks; optional carrier 3G/4G LTE USB modems are available

• USB interface

U 3G/4G WAN uplink

• Flexible port selection

Provides a combination of fiber and copper interface modules, 100/1000BASE-X support, and 10/100/1000BASE-T auto

Page

QuickSpecs

HPE FlexNetwork MSR3000 Router Series

Standard Features

Layer 3 routing

ses a distance vector algorithm with UDP packets for route determination; supports RIPv1 and RIPv2 routing; includes loop

ior Gateway Protocol (IGP), which supports ECMP, NSSA, and

ing path vectors; uses TCP for enhanced reliability

IS routing and extended

only network design

only networks by encapsulating the IPv6 packet into a standard IPv4 packet; supports

Site Automatic Tunnel Addressing Protocol (ISATAP) tunnels; is an important element

ses BGP to advertise routes across Label Switched Paths (LSPs), but uses simple labels to forward packets from any Layer

aceful restart for reduced failure

istribution Protocol (LDP);

routable protocols;

ircuits (SVCs), Martini

llows custom filters for increased performance and security; supports ACLs, IP prefix, AS paths, community lists, and

aggregate policies

• Static IPv4 routing

• Routing Information Protocol (RIP)

• Open shortest path first (OSPF)

• Border Gateway Protocol 4 (BGP-4)

• Intermediate system to intermediate system (IS-IS)

• Static IPv6 routing

• Dual IP stack

• Routing Information Protocol next generation (RIPng)

• OSPFv3

• BGP+

• IS-IS for IPv6

• IPv6 tunneling

• Multiprotocol Label Switching (MPLS)

• Multiprotocol Label Switching (MPLS) Layer 3 VPN

• Multiprotocol Label Switching (MPLS) Layer 2 VPN

• Routing policy

Provides simple manually configured IPv4 routing

U protection

Delivers faster convergence; uses this link-state routing Inter MD5 authentication for increased security and graceful restart for faster failure recovery

Delivers an implementation of the Exterior Gateway Protocol (EGP) utiliz for the route discovery process; reduces bandwidth consumption by advertising only incremental updates; supports extensive policies for increased flexibility; scales to very large networks

Uses a path vector Interior Gateway Protocol (IGP), which is defined by the ISO organization for ISby IETF RFC 1195 to operate in both TCP/IP and the OSI reference model (Integrated IS-IS)

Provides simple manually configured IPv6 routing

Maintains separate stacks for IPv4 and IPv6 to ease the transition from an IPv4-only network to an IPv6-

Extends RIPv2 to support IPv6 addressing

Provides OSPF support for IPv6

Extends BGP-4 to support Multiprotocol BGP (MBGP), including support for IPv6 addressing

Extends IS-IS to support IPv6 addressing

Allows IPv6 packets to traverse IPv4manually configured, 6to4, and Intrafor the transition from IPv4 to IPv6

U 2 or Layer 3 protocol, which reduces complexity and increases performance; supports gr impact; supports LSP tunneling and multilevel stacks

Allows Layer 3 VPNs across a provider network; uses Multiprotocol BGP (MP-BGP) to establish private routes for increase security; supports RFC 2547bis multiple autonomous system VPNs for added flexibility; supports IPv6 MPLS VPN

Establishes simple Layer 2 point-to-point VPNs across a provider network using only MPLS Label D requires no routing and therefore decreases complexity, increases performance, and allows VPNs of nonuses no routing information for increased security; supports Circuit Cross Connect (CCC), Static Virtual C draft, and Kompella-draft technologies

Page

QuickSpecs

HPE FlexNetwork MSR3000 Router Series

Standard Features

Security

Prevention System (IPS) detects and protects the branch office from security threats. Optional HPE

ansport layer protocol inspection, ICMP error message check, andTCP SYN check.

Lite, ICMPv4/ICMPv6, SCTP, DCCP, RAWIP, HTTP, FTP, SMTP, DNS,

based model to a more flexible, more

based model. Interfaces are assigned to zones, and inspection policy is applied to traffic moving

es offer considerable flexibility and granularity, so different inspection policies can be

ugh the VPN Address Management (VAM) protocol, making

VPN establishment available between enterprise branches that use dynamic addresses to access the public network;

r features, such as NAT traversal

upports powerful ACLs for both IPv4 and IPv6; ACLs are used for filtering traffic to prevent unauthorized users from

accessing the network, or for controlling network traffic to save resources; rules can either deny or permit traffic to be

rules can be based on a Layer 2 header or a Layer 3 protocol header; rules can be set to operate on specific dates

llows normal packets to be forwarded correctly, but discards the attaching packet due to lack of reverse path route or

many NAT, and NAT control, enabling NAPT to support multiple connections; supports

device; with authentication and encryption, it protects against IP

spoofing and plain text password interception; increases the security of SFTP transfers

Convergence

Specific Multicast (SSM) to manage IPv4 multicast networks; supports

many transmission of information;

• IPS

Built-in Intrusion integration filters for client-side, branch protection from exploits and vulnerabilities

• Enhanced stateful firewall

Application layer protocol inspection, Tr Support more L4 and L7 protocols like TCP, UDP, UDPSIP, H.323, SCCP.

• Zone based firewall

Zone-Based Policy Firewall changes the firewall configuration from the older interfaceeasily understood zonebetween the zones. Inter-zone polici applied to multiple host groups connected to the same router interface.

• Auto Discover VPN (ADVPN):

Collects, maintains, and distributes dynamic public addresses thro

compared to traditional VPN technologies, ADVPN technology is more flexible and has riche of ADVPN packets, AAA identity authentication, IPSec protection of data packets, and multiple VPN domains

• IPSec VPN

Supports DES, 3DES, and AES 128/192/256 encryption, and MD5 and SHA-1 authentication

• Access control list (ACL)

forwarded; or times

• Terminal Access Controller Access-Control System (TACACS+)

Delivers an authentication tool using TCP with encryption of the full authentication request, providing additional security

• Unicast Reverse Path Forwarding (URPF)

A incorrect inbound interface; prevents source spoofing and distributed attacks

• Network login

Allows authentication of multiple users per port

• RADIUS

Eases security access administration by using a user/password authentication server

• Network address translation (NAT)

Supports one-to-one NAT, many-toblacklist in NAT, a limit on the number of connections, session logs, and multi-instances

• Secure Shell (SSHv2)

Uses external servers to securely log in into a remote

• Internet Group Management Protocol (IGMP)

Utilizes Any-Source Multicast (ASM) or SourceIGMPv1, v2, and v3

• Protocol Independent Multicast (PIM)

Defines modes of Internet IPv4 and IPv6 multicasting to allow one-to-many and many-tosupports PIM Dense Mode (DM), Sparse Mode (SM), and Source-Specific Multicast(SSM)

• Multicast Source Discovery Protocol (MSDP)

Allows multiple PIM-SM domains to interoperate; is used for inter-domain multicast applications

• Multicast Border Gateway Protocol (MBGP)

Allows multicast traffic to be forwarded across BGP networks and kept separate from unicast traffic

Page

QuickSpecs

HPE FlexNetwork MSR3000 Router Series

Standard Features

Layer 3 services

bandwidth optimization for file service and web applications. The policy engine module determines which traffic can be optimized and which optimization action should be taken. A pair of WAN optimization equipment can discover each other automatically and

PT) enables communication between IPv4 andIPv6 nodes by

lation, and according to different protocols, performs

semantic translation for packets. This technology is only suitable for communication between a pure IPv4 node and a pure

er IP host in the same subnet; supports static ARPs; gratuitous ARP allows detection

of duplicate IP addresses; proxy ARP allows normal ARP operation between subnets or when subnets are separated by a

implifies the management of large IP networks and supports client and server; DHCP Relay enables DHCP operation across

Product architecture

Defined

based

Flow matches packets against one or

core processors, gigabit switching, and PCIE bus; external RPS or dual internal power supplies, and internal and

rovides unmatched application and services flexibility, with the potential to deliver the functionality of multiple devices,

mproves the bandwidth of I/O module slots from 100 Mb/s to 1000 Mb/s, and improves uplink performance from 1 Gb/s

Eases utilization of the main processor by transmitting Layer 2 packets directly via the MGF

Convergence

Specific Multicast (SSM) to manage IPv4 multicast networks; supports

many transmission of information;

Allows multicast traffic to be forwarded across BGP networks and kept separate from unicast traffic

• WAN Optimization

MSR performs optimization using TFO and a combination of DRE, Lempel-Ziv (LZ) compression to provide the

complete the negotiation to establish a TCP optimization session.}

• NAT-PT

Network Address Translation – Protocol Translation (NATtranslating between IPv4 and IPv6 packets. It performs IP address trans

IPv6 node.

• Address Resolution Protocol (ARP)

Determines the MAC address of anoth

Layer 2 network

• User Datagram Protocol (UDP) helper

Redirects UDP broadcasts to specific IP subnets to prevent server spoofing

• xDynamic Host Configuration Protocol (DHCP)

S subnets

• SDN/OpenFlow

OpenFlow is the communications interface defined between the control and forwarding layers of a SDN (SoftwareNetworking) architecture. OpenFlow separates the data forwarding and routing decision functions. It keeps the flowforwarding function and employs a separate controller to make routing decisions. Open more flow tables. MSR support OpenFlow 1.3.1

• Ideal multiservice platform

Provides WAN router, Ethernet switch, 3G/4G WAN, statful firewall, VPN, and SIP/voice gateway on MSRs

• Advanced hardware architecture

Provides multi external CF cards are offered; new high-performance MIM modules (HMIM) supported

• New operation system

Ships with new Comware v7 operating system delivering the latest in virtualization and routing

• Open Application Platform architecture

P creating capital and operational expense savings and lasting investment protection

• Field-programmable gate array (FPGA)

O to 10 Gb/s

• Multi Gigabit Fabric (MGF)

• Internet Group Management Protocol (IGMP)

Utilizes Any-Source Multicast (ASM) or SourceIGMPv1, v2, and v3

• Protocol Independent Multicast (PIM)

Defines modes of Internet IPv4 and IPv6 multicasting to allow one-to-many and many-tosupports PIM Dense Mode (DM), Sparse Mode (SM), and Source-Specific Multicast(SSM)

• Multicast Source Discovery Protocol (MSDP)

Allows multiple PIM-SM domains to interoperate; is used for inter-domain multicast applications

• Multicast Border Gateway Protocol (MBGP)

Page

QuickSpecs

HPE FlexNetwork MSR3000 Router Series

Standard Features

Layer 2 switching

upports standard IEEE 802.1D STP, IEEE 802.1w Rapid Spanning Tree Protocol (RSTP) for faster convergence, and IEEE

Supports command switch to easily change switched ports to routed (maximum of four Fast Ethernet ports)

Quality of Service (QoS)

anages traffic uniformly, and hierarchically schedules traffic by user, network service, and application; provides more

Supports traffic shaping, MPLS QoS, MP QoS/LFI, and Control Plane Policing (CoPP).

Integration

to 7 services; monitors the health status

rovides enhanced stateful packet inspection and filtering; delivers advanced VPN services with Triple DES (3DES) and

n at high performance and low latency, URL filtering, and application

the

link

Additional information

implifies and streamlines deployment, management, and training through the use of a common operating system, thereby

llows new and custom features to be brought rapidly to market through engineering efficiencies, delivering better initial and

Provides support for RoHS and WEEE regulations

• Spanning Tree Protocol (STP)

802.1s Multiple Spanning Tree Protocol (MSTP)

• Internet Group Management Protocol (IGMP) and Multicast Listener Discovery (MLD) protocol snooping

Controls and manages the flooding of multicast packets in a Layer 2 network

• Port mirroring

Duplicates port traffic (ingress and egress) to a local or remote monitoring port

• VLANs

Supports up to 4,094 VLANS or IEEE 802.1Q-based VLANs

• sFlow

Allows traffic sampling

• Define port as switched or routed

• Traffic policing

Supports Committed Access Rate (CAR) and line rate

• Congestion management

Supports FIFO, PQ, CQ, WFQ, CBQ, and RTPQ

• Weighted random early detection (WRED)/random early detection (RED)

Delivers congestion avoidance capabilities through the use of queue management algorithms

• Hierarchical quality of service (HQoS)/Nested QoS

M granular traffic control and quality assurance services than traditional QoS

• Other QoS technologies

• Embedded NetStream

Improves traffic distribution using powerful scheduling algorithms, including Layer 4 of servers and firewalls

• Embedded VPN and firewall

P Advancekd Encryption Standard (AES) encryptio prioritization and enhancement

• SIP trunking

Delivers multiple concurrent calls on one link; the carrier authenticates only the link, rather than carrying each SIP call on

• OPEX savings

S cutting costs as well as reducing the risk of human errors associated with having to manage multiple operating systems across different platforms and network layers

• Faster time to market

A ongoing stability

• Green initiative support

Page

QuickSpecs

HPE FlexNetwork MSR3000 Router Series

Standard Features

Management

in support

s network administrators to centrally manage all network elements with a variety of automated

tasks, including discovery, categorization, baseline configurations, and software images; the software also provides

multiple privilege levels with password protection; ACLs provide

ent Information Base (MIB) plus

ses standard SNMP to monitor essential network functions; supports events, alarm, history, and statistics group plus a

ffers different mechanisms for configuration updates; FTP allows bidirectional transfers over a TCP/IP network; trivial FTP

fer Protocol (SFTP) runs over an SSH

ll logs, traps, and debugging information

generated by the system and maintains them in order of severity; outputs the network information to multiple channels based

m port and terminal interface; provides access through terminal interface, telnet,

nalyzes network performance and service quality by sending test packets, and provides network performance and service

rs such as jitter, TCP, or FTP connection delays; allows network manager to determine overall network

Integrates seamlessly into existing authentication services

Ease of deployment

Supports both USB disk auto deployment and 3G SMS auto deployment

Warranty and support

for warranty and support information included with your

; for details on the software releases

available with your product purchase, refer to http://www.hpe.com/networking/warrantysummary

• HPE Intelligent Management Center (IMC)

• Industry-standard CLI with a hierarchical structure

• Management security

• SNMPv1, v2, and v3

• Remote monitoring (RMON)

• FTP, TFTP, and SFTP support

• Debug and sampler utility

• Network Time Protocol (NTP)

• Information center

Integrates fault management, element configuration, and network monitoring from a central vantage point; builtfor third-party devices enable

configuration comparison tools, version tracking, change alerts, and more

Reduces training time and expenses, and increases productivity in multivendor installations

Restricts access to critical configuration commands; offers Telnet and SNMP access; local and remote syslog capabilities allow logging of all access

Provide complete support of SNMP; provide full support of industry-standard Managem private extensions; SNMPv3 supports increased security using encryption

U private alarm extension group

O (TFTP) is a simpler method using User Datagram Protocol (UDP); Secure File Trans tunnel to provide additional security

Supports ping and trace route for both IPv4 and IPv6

Synchronizes timekeeping among distributed time servers and clients; keeps timekeeping consistent among all clock dependent devices within the network so that the devices can provide diverse applications based on the consistent time

Provides a central repository for system and network information; aggregates a

on user-defined rules

• Management interface control

Provides management access through mode or SSH

• Network Quality Analyzer (NQA)

A quality paramete performance and diagnose and locate network congestion points or failures

• Role-based security

Delivers role-based access control (RBAC); supports 16 user levels (0~15)

• Standards-based authentication support for LDAP

• Zero-touch deployment

• 1-year Warranty

See http://www.hpe.com/networking/warrantysummary product purchase.

• Software releases

To find software for your product, refer to http://www.hpe.com/networking/support

Page

QuickSpecs

HPE FlexNetwork MSR3000 Router Series

Standard Features

Resiliency and high availability

interconnecting multiple

devices through stack ports. The customer can manage all the devices in the IRF stack by managing the logical device, which

llows groups of two routers to dynamically back each other up to create highly available routed environments; supports

identifying potential problems as early as possible;

layer protocols such as

routing protocols and MPLS

Investment protection

Supports existing SIC and MIM modules, transceivers, and cables for investment protection

• Intelligent Resilient Fabric (IRF)

Intelligent Resilient Fabric (IRF), allows the customer build an IRF stack, namely a logical device, by

is cost-effective like a box-type device, and scalable and highly reliable like a chassis-type distributed device.

• Backup Center

Acts as a part of the management and backup function to provide backup for device interfaces; delivers reliability by switchin traffic over to a backup interface when the primary one fails

• Virtual Router Redundancy Protocol (VRRP)

A VRRP load balancing

• Embedded Automation Architecture (EAA)

Monitors the internal event and status of system hardware and software, collects field information and attempts to automatically repair the issues; based on the user configuration, onsite informati will be sent to technical support

• Bidirectional Forwarding Detection (BFD)

Detects quickly the failures of the bidirectional forwarding paths between two devices for upper-

• Re-use of existing SIC and MIM modules

Page

QuickSpecs

HPE FlexNetwork MSR3000 Router Series

Configuration

Information

Build To Order: BTO

Router Chassis

Rule#

Description

SKU

3, 4, 5,

HPE FlexNetwork MSR3064 Router

JG404A

•

• 3U - Height

3, 4, 5, 8

HPE FlexNetwork MSR3044 Router

JG405A

• 1 Fixed 10M/100M/1000M RJ45 ports

• 2U - Height

1, 2, 3, 4, 5, 8

HPE FlexNetwork MSR3044 Router LoCry

JG405A#A59

1, 2, 3, 4, 5, 8

HPE FlexNetwork MSR3024 AC Router

JG406A

• 2 Fixed 10M/100M/1000M RJ45 ports

• 1U - Height

HPE FlexNetwork MSR3024 AC Router PDU Cable NA/JP/TW

JG406A#B2B

• C15 PDU Jumper Cord (NA/MEX/TW/JP)

HPE FlexNetwork MSR3024 AC Router PDU Cable ROW

JG406A#B2C

• C15 PDU Jumper Cord (ROW)

HPE FlexNetwork MSR3024 AC Router 220V N.A. - English localized

JG406A#B2E

• NEMA L6-20P Cord (NA/MEX/JP/TW)

is a standalone unit with no integration. BTO products ship standalone are not part of a CTO or Rack-Shippable solution.

1 Fixed 10M/100M/1000M RJ45 ports

• 2 COMBO 1000M RJ45/SFP ports min=0 \ max=2 SFP Transceivers

• 4 - SIC module slots / 2 - DSIC module slots

• 6 - HMIM module slots (4 Half Height + 2 Full Height Slots) / 1 - DHMIM module slot

(Double Width Full Height Slot)

• 2 - VPM slots

• 2 USB 2.0 Port for 3G modem and USB disk

• 1 CON/AUX port and 1 USB console port

• 2GB DDR3 SDRAM Included (4GB Max, by replacing existing single 2GB SDRAM)

• 1 - CF Card Slot

• Must select min 1 Power Supply (min=1 \ max=2)

• 2 COMBO 1000M RJ45/SFP ports min=0 \ max=2 SFP Transceivers

• 4 - SIC module slots / 2 - DSIC module slots

• 4 - HMIM module slots (4 - Half Height Slots) / 0 - DHMIM module slot (Double Width Full

Height Slot)

• 2 - VPM slots

• 2 USB 2.0 Port for 3G modem and USB disk

• 1 CON/AUX port and 1 USB console port

• 2GB DDR3 SDRAM Included (4GB Max, by replacing existing single 2GB SDRAM)

• 1 - CF Card Slot

• Must select min 1 Power Supply (min=1 \ max=2)

• 1 COMBO 1000M RJ45/SFP port min=0 \ max=1 SFP Transceiver

• 4 - SIC module slots / 2 - DSIC module slots

• 2 - HMIM module slots (2 - Half Height Slots) / 0 - DHMIM module slot (Double Width Full

Height Slot)

• 2 - VPM slots

• 2 USB 2.0 Port for 3G modem and USB disk

• 1 CON/AUX port and 1 USB console port

• 2GB DDR3 SDRAM Included (4GB Max, by replacing existing single 2GB SDRAM)

• 1 - CF Card Slot

• AC Power Supply included (+RPS Optional)

Page

QuickSpecs

HPE FlexNetwork MSR3000 Router Series

Configuration

Information

HPE MSR3024 AC Router

JG406A#AC3

• No Localized Power Cord Selected

HPE FlexNetwork MSR3024 AC Router LoCry

JG406A#A59

HPE FlexNetwork MSR3024 PoE Router PDU Cable NA/JP/TW

JG408A#B2B

• C15 PDU Jumper Cord (NA/MEX/TW/JP)

HPE FlexNetwork MSR3024 PoE Router PDU Cable ROW

JG408A#B2C

• C15 PDU Jumper Cord (ROW)

HPE FlexNetwork MSR3024 PoE Router 220V N.A. - english localized

JG408A#B2E

• NEMA L6-20P Cord (NA/MEX/JP/TW)

HPE MSR3024 PoE Router

JG408A#AC3

• No Localized Power Cord Selected

1, 2, 3, 8

HPE MSR3012 AC Router

JG409B

•

• 1U - Height

HPE MSR3012 AC Router PDU NA, JP or TW

JG409B#B2B

• C15 PDU Jumper Cord (NA/MEX/TW/JP)

HPE MSR3012 AC Router PDU ROW

JG409B#B2C

• C15 PDU Jumper Cord (ROW)

HPE MSR3012 AC Router United States 220 volt

JG409B#B2E

• NEMA L6-20P Cord (NA/MEX/JP/TW)

HPE MSR3012 AC Router

JG409B#A59

Configuration Rules

Rule#

Description

SKU

1 - AC Power Supply included

Localization required on orders without #B2B, #B2C or #B2E. (See Localization Menu)

3 The following Transceivers install into this Switch:

HPE X120 1G SFP LC SX Transceiver

JD118B

HPE X120 1G SFP LC LX Transceiver

JD119B

HPE X120 1G SFP LC LH100 Transceiver

JD103A

HPE X120 1G SFP RJ45 T Transceiver

JD089B

HPE X115 100M SFP LC FX Transceiver

JD102B

HPE X110 100M SFP LC LX Transceiver

JD120B

HPE X120 1G SFP LC BX 10-U Transceiver

JD098B

HPE X120 1G SFP LC BX 10-D Transceiver

JD099B

The following DDR SDRAM install into this Switch:

HPE FlexNetwork X610 4GB DDR3 SDRAM UDIMM Memory

JG530A

The following CF Card install into this Switch:

HPE X600 1G Compact Flash Card

JC684A

2 Fixed 10M/100M/1000M RJ45 ports

• 1 COMBO 1000M RJ45/SFP port min=0 \ max=1 SFP Transceiver

• 2 - SIC module slots / 0 - DSIC module slots

• 1 - HMIM module slot (1 - Full Height Slot) / 0 - DHMIM module slot (Double Width Full

Height Slot)

• 1 - VPM slot

• 2 USB 2.0 Port for 3G modem and USB disk

• 1 CON/AUX port and 1 USB console port

• 2GB DDR3 SDRAM Included (default=2GB \ max=2GB DDR SDRAM)

• AC Power Supply included

Page

QuickSpecs

HPE FlexNetwork MSR3000 Router Series

Configuration

Information

If this product is ordered for delivery to Russia, it must be ordered with the A59 option (also allowed for other countries desiring Low Encryption), then #A59 is the required option for BTO, and must be added in addition to #0D1 for CTO.

1 - DC Power Supply included

NOTE:

"Drop down under power supply should offer the following options and results: Switch/Router/Power Supply to PDU Power Cord - #B2B in North America, Mexico, Taiwan, and Japan or #B2C ROW. (Watson Default B2B or B2C for Rack Level CTO)

- Localized Option (Wat High Volt Switch/Router/Power Supply to Wall Power Cord - #B2E Option. (Offered only in North America, Mexico, Taiwan, and Japan)"

Rack Level Integration CTO Models

Router Chassis

Rule#

Description

SKU

3, 4, 5,

HPE FlexNetwork MSR3064 Router

JG404A

• 1 Fixed 10M/100M/1000M RJ45 ports

• 3U - Height

3, 4, 5, 7

HPE FlexNetwork MSR3044 Router

JG405A

• 1 Fixed 10M/100M/1000M RJ45 ports

• 2U - Height

Rule#

Description

SKU

1, 2, 3, 4, 5, 7

HPE FlexNetwork MSR3044 Router LoCry

JG405A#A59

1, 2, 3, 4, 5, 7

HPE FlexNetwork MSR3024 AC Router

JG406A

•

• 1 CON/AUX port and 1 USB console port

Switch/Router/Power Supply to Wall Power Cord

son Default for BTO and Box Level CTO)

• 2 COMBO 1000M RJ45/SFP ports min=0 \ max=2 SFP Transceivers

• 4 - SIC module slots / 2 - DSIC module slots

• 6 - HMIM module slots (4 Half Height + 2 Full Height Slots) / 1 - DHMIM module slot

(Double Width Full Height Slot)

• 2 - VPM slots

• 2 USB 2.0 Port for 3G modem and USB disk

• 1 CON/AUX port and 1 USB console port

• 2GB DDR3 SDRAM Included (4GB Max, by replacing existing single 2GB SDRAM)

• 1 - CF Card Slot

• Must select min 1 Power Supply (min=1 \ max=2)

• 2 COMBO 1000M RJ45/SFP ports min=0 \ max=2 SFP Transceivers

• 4 - SIC module slots / 2 - DSIC module slots

• 4 - HMIM module slots (4 - Half Height Slots) / 0 - DHMIM module slot (Double Width Full

Height Slot)

• 2 - VPM slots

• 2 USB 2.0 Port for 3G modem and USB disk

• 1 CON/AUX port and 1 USB console port

• 2GB DDR3 SDRAM Included (4GB Max, by replacing existing single 2GB SDRAM)

• 1 - CF Card Slot

• Must select min 1 Power Supply (min=1 \ max=2)

2 Fixed 10M/100M/1000M RJ45 ports

• 1 COMBO 1000M RJ45/SFP port min=0 \ max=1 SFP Transceiver

• 4 - SIC module slots / 2 - DSIC module slots

• 2 - HMIM module slots (2 - Half Height Slots) / 0 - DHMIM module slot (Double Width Full

Height Slot)

• 2 - VPM slots

• 2 USB 2.0 Port for 3G modem and USB disk

Page

QuickSpecs

HPE FlexNetwork MSR3000 Router Series

Configuration

Information

• 2GB DDR3 SDRAM Included (4GB Max, by replacing existing single 2GB SDRAM)

• 1U - Height

HPE FlexNetwork MSR3024 AC Router PDU Cable NA/JP/TW

JG406A#B2B

• C15 PDU Jumper Cord (NA/MEX/TW/JP)

HPE FlexNetwork MSR3024 AC Router PDU Cable ROW

JG406A#B2C

• C15 PDU Jumper Cord (ROW)

HPE MSR3024 AC Router

JG406A#AC3

• No Localized Power Cord Selected

HPE FlexNetwork MSR3024 AC Router LoCry

JG406A#A59

HPE FlexNetwork MSR3024 PoE Router PDU Cable NA/JP/TW

JG408A#B2B

• C15 PDU Jumper Cord (NA/MEX/TW/JP)

HPE FlexNetwork MSR3024 PoE Router PDU Cable ROW

JG408A#B2C

• C15 PDU Jumper Cord (ROW)

HPE MSR3024 PoE Router

JG408A#AC3

• No Localized Power Cord Selected

1, 2, 3, 7

HPE MSR3012 AC Router

JG409B

•

HPE MSR3012 AC Router PDU NA, JP or TW

JG409B#B2B

•

HPE MSR3012 AC Router PDU ROW

JG409B#B2C

• C15 PDU Jumper Cord (ROW)

HPE MSR3012 AC Router

JG409B#A59

Configuration Rules

Rule#

Description

SKU

1 - AC Power Supply included

"Localization (Wall Power Cord) required on orders without #B2B, #B2C (PDU Power Cord). (See Localization Menu) NOTE: When Switches/Routers are Factory Racked, Then #B2B, or #B2C should be the Defaulted Power Cable option on the Switches/Routers."

The following Transceivers install into this Router:

HPE X120 1G SFP LC SX Transceiver

JD118B

HPE X120 1G SFP LC LX Transceiver

JD119B

HPE X120 1G SFP LC LH100 Transceiver

JD103A

HPE X120 1G SFP RJ45 T Transceiver

JD089B

HPE X115 100M SFP LC FX Transceiver

JD102B

HPE X110 100M SFP LC LX Transceiver

JD120B

HPE X120 1G SFP LC BX 10-U Transceiver

JD098B

HPE X120 1G SFP LC BX 10-D Transceiver

JD099B

• 1 - CF Card Slot

• AC Power Supply included (+RPS Optional)

2 Fixed 10M/100M/1000M RJ45 ports

• 1 COMBO 1000M RJ45/SFP port min=0 \ max=1 SFP Transceiver

• 2 - SIC module slots / 0 - DSIC module slots

• 1 - HMIM module slot (1 - Full Height Slot) / 0 - DHMIM module slot (Double Width Full

Height Slot)

• 1 - VPM slot

• 2 USB 2.0 Port for 3G modem and USB disk

• 1 CON/AUX port and 1 USB console port

• 2GB DDR3 SDRAM Included (default=2GB \ max=2GB DDR SDRAM)

• AC Power Supply included

1U - Height

C15 PDU Jumper Cord (NA/MEX/TW/JP)

Page

QuickSpecs

HPE FlexNetwork MSR3000 Router Series

Configuration

Information

4 The following DDR SDRAM install into this Router:

HPE FlexNetwork X610 4GB DDR3 SDRAM UDIMM Memory

JG530A

The following CF Card install into this Router:

HPE X600 1G Compact Flash Card

JC684A

1 - DC Power Supply included

The following HMIM Module is NOT compatible with this Router:

HPE FlexNetwork MSR 1-port Clear Channel T3 HMIM Module

JH449A

NOTE:

Localized Option (Watson Default for BTO and

Box Level CTO)"

Clic UNB - If an option is ordered with #0D1/#B01, then the switch must have #0D1 option.

Power Supplies

Rule#

Description

SKU

(JG404A and JG405A only) System (std 0// max 1 or max 2) User Selection (min 1 // max 1 or max 2) MSR3064/3044 Router

3, 6

HPE FlexNetwork X351 300W 48-60VDC to 12VDC Power Supply

JG528A

1, 2, 3, 6

HPE FlexNetwork X351 300W 100-240VDC to 12VDC Power Supply

JG527A

HPE FlexNetwork X351 300W 100-240VDC to 12VDC Power Supply PDU Cable NA/JP/TW

JG527A#B2B

• C15 PDU Jumper Cord (NA/MEX/TW/JP)

HPE FlexNetwork X351 300W 100-240VDC to 12VDC Power Supply PDU Cable ROW

JG527A#B2C

• C15 PDU Jumper Cord (ROW)

HPE FlexNetwork X351 300W 100-240VDC to 12VDC Power Supply 220V N.A. - english localized

JG527A#B2E

•

Configuration Rules

Localization required on orders without #B2B, #B2C or #B2E options.

2 If #B2E is selected Then replace Localized option with #B2E for power supply and with #B2E for router. (Offered only in NA, Mexico, Taiwan, and Japan)

3 Maximum of 2 of this Power Supply for MSR3064 - JG404A and MSR3044 - JG405A. min=0\ max=2

Power Supplies cannot be mixed in the same Router enclosure

NOTE:

Drop down under power supply should offer the following options and results: Switch/Router/Power Supply to PDU Power Cord - #B2B in North America, Mexico, Taiwan, and Japan or #B2C ROW. (Watson Default B2B or B2C for Rack Leve Switch/Router/Power Supply to Wall Power Cord - Localized Option (Watson Default for BTO and Box Level CTO) High Volt Switch/Router/Power Supply to Wall Power Cord - #B2E Option. (Offered only in North America, Mexico, Taiwan, and Japan)

Switch/Router/Power Supply to Wall Power Cord -

NEMA L6-20P Cord (NA/MEX/JP/TW)

l CTO)

Page

QuickSpecs

HPE FlexNetwork MSR3000 Router Series

Configuration

Information

Enter the following menu selections as integrated to the CTO Model X server above if order is factory built.

SIC Modules

System (std 0 // max 2 or 4) User Selection (min 0 // max 2 or 4) per Host (See Modules for Port information)

Rule#

Description

SKU

16, 19, 20

HPE MSR 1-port E1/T1 Voice SIC Module

JH240A

• min=0 \ max=1 E1 or T1 Cable

2, 4, 7

HPE FlexNetwork MSR 1-port Fractional E1 SIC Module

JD634B

• min=0 \ max=1 E1 or 2E1 Cable

2, 4, 9

HPE FlexNetwork MSR 1-port Fractional SIC Module

JD538A

2, 4, 11

HPE FlexNetwork MSR 1-port Enhanced Serial SIC Module

JD557A

• min=0 \ max=1 Serial Port Cable

2, 4, 14

HPE FlexNetwork MSR 16-port Async Serial SIC Module

JG186A

2, 4, 7

HPE FlexNetwork MSR 1-port E1/CE1/PRI SIC Module

JG604A

• min=0 \ max=1 E1 Cable

2, 4, 11

HPE FlexNetwork MSR 2-port Enhanced Sync/Async Serial SIC Module

JG736A

• min=0 \ max=2 Serial Port Cable

2, 4, 11

HPE FlexNetwork MSR 4-port Enhanced Sync/Async Serial SIC Module

JG737A

• min=0 \ max=4 Serial Port Cable

1, 4, 6

HPE FlexNetwork MSR 1-port GbE Combo SIC Module

JG738A

• min=0 \ max=1 SFP Transceiver

1, 4

HPE FlexNetwork MSR 4-port Gig-T Switch SIC Module

JG739A

Configuration Rules

1 These Modules can install directly to the Routers (JG404A, JG405A, JG861A, JG406A, min=0\ max=2 per enclosure (only supported in Slots 2 and 4)

2 These Modules can install directly to the Routers (JG404A, JG405A, JG861A, JG406A, Jmin=0\ max=4 per enclosure

These Modules cannot install directly to the Routers (JG409B,)

4 These Modules can install directly to the Routers (JG409B) min=0\ max=2 per enclosure

The following Transceivers install into this Module:

HPE X115 100M SFP LC FX Transceiver

JD102B

HPE X110 100M SFP LC LX Transceiver

JD120B

The following Transceivers install into this Module:

HPE X120 1G SFP LC SX Transceiver

JD118B

HPE X120 1G SFP LC LX Transceiver

JD119B

HPE X120 1G SFP LC LH100 Transceiver

JD103A

HPE X120 1G SFP LC BX 10-U Transceiver

JD098B

HPE X120 1G SFP LC BX 10-D Transceiver

JD099B

HPE X120 1G SFP LC LH100 Transceiver

JD103A

HPE X120 1G SFP RJ45 T Transceiver

JD089B

The following E1 Cables install into this Module:

HPE FlexNetwork X260 E1 (2) BNC 75 ohm 3m Router Cable

JD175A

The following T1 Cables install into this Module: JD518A-HP X260 T1 Router Cable

HPE FlexNetwork X260 T1 Router Cable

JD518A

11 The following Cables install into this Module:

Page

QuickSpecs

HPE FlexNetwork MSR3000 Router Series

Configuration

Information

HPE FlexNetwork X260 RS449 3m DCE Serial Port Cable

JF826A

HPE FlexNetwork X260 RS449 3m DTE Serial Port Cable

JF825A

HPE FlexNetwork X200 V.24 DTE 3m Serial Port Cable

JD519A

HPE FlexNetwork X200 V.35 DTE 3m Serial Port Cable

JD523A

HPE FlexNetwork X260 RS530 3m DTE Serial Port Cable

JF827A

HPE FlexNetwork X200 V.35 DCE 3m Serial Port Cable

JD525A

HPE FlexNetwork X260 RS530 3m DCE Serial Port Cable

JF828A

HPE FlexNetwork X200 V.24 DCE 3m Serial Port Cable

JD521A

The following Antenna Cables install into this Module:

HPE MSR 3G RF 2.8m Antenna Cable

JG522A

The following E1/T1 Cables install into this Module:

HPE FlexNetwork X260 E1 RJ45 to 2xBNC 75ohm 3m Router Cable

JH294A

HPE FlexNetwork X260 E1 RJ45 120 ohm 2m Router Cable

JC156A

HPE FlexNetwork X260 T1 Router Cable

JD518A

These Modules can install directly to the Routers (JG404A, JG405A, JG406A) min=0\ max=4 per enclosure

These Modules can install directly to the Routers (JG409B) min=0\ max=2 per enclosure

HMIM Modules

System (std 0 // max 6 or 4 or 2 or 1) User Selection (min 0 // max 6 or 4 or 2 or 1) per Router Chassis (See Modules for Port information)

Rule#

Description

SKU

1, 3, 5, 11, 13, 14

HPE FlexNetwork MSR 2-port E1 Voice HMIM Module

JG431A

• (Full Height Module; Takes up 1 - Full Height slot or 2 - Half Height slots, vertically)

min=0 \ max=1 E1 Cable

2, 4, 6, 13, 21, 22

HPE FlexNetwork MSR 1-port Clear Channel T3 HMIM Module

JH449A

• (Half Height Module; Takes up 1 Half Height or 1 Full Height slot)

min=0 \ max=2 E3/T3 Cable

2, 4, 7, 12, 13

HPE FlexNetwork MSR 1-port OC-3c/STM 1c POS HMIM Module

JG438A

• (Half Height Module; Takes up 1 Half Height or 1 Full Height slot)

min=0 \ max=1 SFP Transceiver

2, 4, 8, 12, 13

HPE FlexNetwork MSR 8-port Enhanced Sync/Async Serial HMIM Module

JG443A

• (Half Height Module; Takes up 1 Half Height or 1 Full Height slot)

min=0 \ max=8 Serial Port Cable

2, 4, 12, 13

HPE FlexNetwork MSR 4-port Gig-T HMIM Module

JG421A

• (Half Height Module; Takes up 1 Half Height or 1 Full Height slot)

2, 4, 12, 13

HPE FlexNetwork MSR 8-port Gig-T HMIM Module

JG422A

• (Half Height Module; Takes up 1 Half Height or 1 Full Height slot)

2, 4, 12, 13, 17

HPE FlexNetwork MSR 8-port 1000BASE-X HMIM Module

JG425A

•

1, 3, 11, 13, 14

HPE FlexNetwork MSR 24-port Gig-T Switch HMIM Module

JG426A

• (Full Height Module; Takes up 1 - Full Height slot or 2 - Half Height slots, vertically)

(Half Height Module; Takes up 1 Half Height or 1 Full Height slot) min=0 \ max=8 SFP Modules

Page

QuickSpecs

HPE FlexNetwork MSR3000 Router Series

Configuration

Information

2, 4, 7, 12, 13

HPE FlexNetwork MSR 1-port OC-3/STM-1 CPOS HMIM Module

JG428A

•

• min=0 \ max=1 SFP Transceiver

1, 3, 10, 11, 13

HPE FlexNetwork MSR 2-port T1 Voice HMIM Module

JG432A

•

• min=0 \ max=2 T1 Cable

4, 7, 12, 13, 17, 18

HPE FlexNetwork MSR 8-port 10/100/1000BASE-T/2-port 1000BASE-X (Combo) Switch HMIM Module

JG741A

•

• min=0 \ max=2 SFP Transceivers

1, 3, 11, 13

HPE FlexNetwork MSR 16-port Enhanced Async Serial HMIM Module

JG445A

• (Full Height Module; Takes up 1 - Full Height slot or 2 - Half Height slots, vertically)

2, 4, 10, 12, 13, 19, 20

HPE FlexNetwork MSR 8-port E1/CE1/T1/CT1/PRI HMIM Module

JH169A

•

• min=0 \ max=8 E1/T1 Cable

2, 4, 10, 12, 13, 19, 20

HPE FlexNetwork MSR 8-port E1/Fractional E1/T1/Fractional T1 HMIM Module

JH172A

•

• min=0 \ max=8 E1/T1 Cable

2, 4, 7, 12, 13, 17

HPE FlexNetwork MSR 8-port 100BASE-FX/1000BASE-X/4-port 1000BASE-T (Combo) L2/L3 HMIM Module

JH238A

•

• min=0 \ max=8 SFP Modules

Configuration Rules

Rule#

Description

SKU

1 These Modules can install directly to the Router Chassis (JG404A) min=0

Height

slots, vertically)

2 These Modules can install directly to the Router Chassis (JG404A) min=0\ max=6 per enclosure

3 These Modules can install directly to the Router Chassis (JG405A) min=0

Half Height

slots, vertically)

4 These Modules can install directly to the Router Chassis (JG405A) min=0\ max=4 per enclosure

The following Cables install into this Module:

HPE FlexNetwork X260 E1 (2) BNC 75 ohm 3m Router Cable

JD175A

6 The following E3/T3 Cable and Connector install into this Module:

HPE FlexNetwork X260 T3/E3 Router Cable

JD531A

The following Transceivers install into this Module:

HPE X115 100M SFP LC FX Transceiver

JD102B

HPE X110 100M SFP LC LX Transceiver

JD120B

The following Cables install into this Module:

HPE FlexNetwork X260 RS449 3m DCE Serial Port Cable

JF826A

HPE FlexNetwork X260 RS449 3m DTE Serial Port Cable

JF825A

HPE FlexNetwork X200 V.24 DTE 3m Serial Port Cable

JD519A

HPE FlexNetwork X200 V.35 DTE 3m Serial Port Cable

JD523A

(Half Height Module; Takes up 1 Half Height or 1 Full Height slot)

(Full Height Module; Takes up 1 - Full Height slot or 2 - Half Height slots, vertically)

(Half Height Module; Takes up 1 Half Height or 1 Full Height slot)

\ max=4 per enclosure (Full Height Module; Takes up 1 - Full Height slot or 2 - Half

\ max=2 per enclosure (Full Height Module; Takes up 1 - Full Height slot or 2 -

Page

QuickSpecs

HPE FlexNetwork MSR3000 Router Series

Configuration

Information

HPE FlexNetwork X260 RS530 3m DTE Serial Port Cable

JF827A

HPE FlexNetwork X200 V.35 DCE 3m Serial Port Cable

JD525A

HPE FlexNetwork X260 RS530 3m DCE Serial Port Cable

JF828A

HPE FlexNetwork X200 V.24 DCE 3m Serial Port Cable

JD521A

The following T1 Cables install into this Module:

HPE FlexNetwork X260 T1 Router Cable

JD518A

These Modules can install directly to the Router Chassis (JG406A and JG861A) min=0

Half Height

slots, vertically)

These Modules can install directly to the Router Chassis (JG406A and JG861A) min=0\ max=2 per enclosure

These Modules can install directly to the Router Chassis (JG409B) min=0\ max=1 per enclosure

Full Height Module; Takes up 1 - Full Height slot or 2 - Half Height slots, vertically

Remark for Watson: Adapter Modules allow customers with existing MIM Modules to adapt them to HMIM slots of 1U HMIM Adapter Modules can adapt the following MIM Modules:

HP A-MSR 1-port E1 Voice MIM Module

JD565B

HP A-MSR 2-port E1 Voice MIM Module

JD567B

HP A-MSR 1-port T1 Voice MIM Module

JD566B

HP A-MSR 2-port T1 Voice MIM Module

JD568B

Remark for Watson: Adapter Modules allow customers with existing MIM Modules to adapt them to HMIM slots of HPE MSR 3000 Series Router.

0.5U HMIM Adapter Modules can adapt following MIM Modules:

HP A-MSR 2-port E1/CE1/PRI MIM Module

JD544B

HP A-MSR 4-port E1/CE1/PRI MIM Module

JD550B

17 The following Transceivers install into this Module:

HPE X120 1G SFP LC SX Transceiver

JD118B

HPE X120 1G SFP LC LX Transceiver

JD119B

HPE X120 1G SFP LC BX 10-U Transceiver

JD098B

HPE X120 1G SFP LC BX 10-D Transceiver

JD099B

HPE X120 1G SFP LC LH100 Transceiver

JD103A

18 These Modules can install directly to the Router Chassis (HP MSR3064) min=0\ max=5 per enclosure (Not supported in Slot 7)

The following E1 Cables install into this Module:

HPE FlexNetwork X260 E1 RJ45 to 2xBNC 75ohm 3m Router Cable

JH294A

The following E1 Cables install into this Module:

HPE FlexNetwork X260 E1 RJ45 120 ohm 2m Router Cable

JC156A

Available in Korea only

These Modules can install directly to the Router Chassis (JG406A) min=0\ max=2 per enclosure

\ max=1 per enclosure (Full Height Module; Takes up 1 - Full Height slot or 2 -

HPE MSR 3000 Series Router.

Page

QuickSpecs

HPE FlexNetwork MSR3000 Router Series

Configuration

Information

Transceivers

System (std 0 // max 2 or 1) User Selection (min 0 // max 2 or 1) per MSR3000 Router

Rule#

Description

SKU

1, 2

HPE X120 1G SFP LC SX Transceiver

JD118B

1, 2

HPE X120 1G SFP LC LX Transceiver

JD119B

1, 2

HPE X115 100M SFP LC FX Transceiver

JD102B

1, 2

HPE X110 100M SFP LC LX Transceiver

JD120B

1, 2

HPE X120 1G SFP LC LH100 Transceiver

JD103A

1, 2

HPE X120 1G SFP LC BX 10-U Transceiver

JD098B

1, 2

HPE X120 1G SFP LC BX 10-D Transceiver

JD099B

HPE X120 1G SFP RJ45 T Transceiver

JD089B

Configuration Rules

1 These Transceivers can install directly to JG404A and JG405A min=0\ max=2 per enclosure

2 These Transceivers can install directly to JG406A, JG861A and JG409B min=0\ max=1 per enclosure

Cables

HPE FlexNetwork X260 Mini D-28 to 4-RJ45 0.3m Router Cable

JG263A

HPE FlexNetwork X200 V.24 DTE 3m Serial Port Cable

JD519A

HPE FlexNetwork X200 V.24 DCE 3m Serial Port Cable

JD521A

HPE FlexNetwork X200 V.35 DTE 3m Serial Port Cable

JD523A

HPE FlexNetwork X200 V.35 DCE 3m Serial Port Cable

JD525A

HPE FlexNetwork X260 RS449 3m DTE Serial Port Cable

JF825A

HPE FlexNetwork X260 RS449 3m DCE Serial Port Cable

JF826A

HPE FlexNetwork X260 RS530 3m DTE Serial Port Cable

JF827A

HPE FlexNetwork X260 RS530 3m DCE Serial Port Cable

JF828A

HPE FlexNetwork X260 E1 (2) BNC 75 ohm 3m Router Cable

JD175A

HPE FlexNetwork X260 E1 RJ45 BNC 75-120 ohm Conversion Router Cable

JD511A

HPE FlexNetwork X260 T1 Router Cable

JD518A

HPE FlexNetwork X260 T3/E3 Router Cable

JD531A

HPE FlexNetwork X260 E1 RJ45 to 2xBNC 75ohm 3m Router Cable

JH294A

HPE FlexNetwork X260 E1 RJ45 120 ohm 2m Router Cable

JC156A

Configuration Rules

NOTE:

The following cable is used for RJ45 BNC Conversion:

HPE FlexNetwork X260 E1 RJ45 BNC 75-120 ohm Conversion Router Cable

JD511A

Router Enclosure Options

Antenna Cables

System (std 0 // max 2) User Selection (min 0 // max 2) per SIC Module (JG742B)

Remarks

Description

SKU

HPE MSR 3G RF 2.8m Antenna Cable

JG522A

SDRAM

User Selection (min 0 // max 1) (default=2GB \ max=4GB) per JG404A, JG405A, JG861A, JG406A, (4GB Max, by replacing existing single 2GB SDRAM)

HPE FlexNetwork X610 4GB DDR3 SDRAM UDIMM Memory

JG530A

• (Must remove existing 2GB UDIMM to install the 4GB UDIMM)

Page

QuickSpecs

HPE FlexNetwork MSR3000 Router Series

Configuration

Information

Compact Flash Card

System (std 0 // max 1 External CF Card) per JG404A, JG405A, JG861A, JG406A

HPE X600 1G Compact Flash Card

JC684A

External Redundant Power Supplies

Rule#

Description

SKU

JG406A, JG861A and JG409B only - System (std 0 // max 1) User Selection (min 0 // max 1)

1, 2, 3

HPE RPS 800 Redundant Power Supply

JD183A

• Height = 1U

Configuration Rules

1 These power supplies are supported on the following routers only:

HPE FlexNetwork MSR3024 AC Router

JG406A

HPE MSR3012 AC Router

JG409B

Localization required. (See Localization Menu for list.)

JD637A - HPE X290 MSR30 1m RPS Cable is required if power supply is selected.

Power Cables

System (std 0 // max 1) User Selection (min 0 // max 1) per JD183A

HPE FlexNetwork X290 MSR30 1m RPS Cable

JD637A

Page

QuickSpecs

HPE FlexNetwork MSR3000 Router Series

Related Options

HPE FlexNetwork MSR3000 Router Series accessories

Transceivers

Description

SKU

HPE X115 100M SFP LC FX Transceiver

JD102B

HPE X110 100M SFP LC LX Transceiver

JD120B

HPE X120 1G SFP LC SX Transceiver

JD118B

HPE X120 1G SFP LC LX Transceiver

JD119B

HPE X120 1G SFP LC LH100 Transceiver

JD103A

HPE X120 1G SFP LC BX 10-U Transceiver

JD098B

HPE X120 1G SFP LC BX 10-D Transceiver

JD099B

HPE X120 1G SFP RJ45 T Transceiver

JD089B

Router Modules

HPE FlexNetwork MSR 1-port E1/CE1/PRI SIC Module

JG604A

HPE FlexNetwork MSR 4-port Gig-T Switch SIC Module

JG739A

HPE FlexNetwork MSR 1-port GbE Combo SIC Module

JG738A

HPE FlexNetwork MSR 1-port Fractional E1 SIC Module

JD634B

HPE FlexNetwork MSR 1-port Fractional SIC Module

JD538A

HPE FlexNetwork MSR 1-port Enhanced Serial SIC Module

JD557A

HPE FlexNetwork MSR 2-port Enhanced Sync/Async Serial SIC Module

JG736A

HPE FlexNetwork MSR 4-port Enhanced Sync/Async Serial SIC Module

JG737A

HPE FlexNetwork MSR 16-port Async Serial SIC Module

JG186A

HPE FlexNetwork MSR 2-port E1 Voice HMIM Module

JG431A

HPE FlexNetwork MSR 2-port T1 Voice HMIM Module

JG432A

HPE FlexNetwork MSR 8-port Enhanced Sync/Async Serial HMIM Module

JG443A

HPE FlexNetwork MSR 1-port Clear Channel T3 HMIM Module

JH449A

HPE FlexNetwork MSR 1-port OC-3c/STM 1c POS HMIM Module

JG438A

HPE FlexNetwork MSR 4-port Gig-T HMIM Module

JG421A

HPE FlexNetwork MSR 8-port Gig-T HMIM Module

JG422A

HPE FlexNetwork MSR 8-port 1000BASE-X HMIM Module

JG425A

HPE FlexNetwork MSR 24-port Gig-T Switch HMIM Module

JG426A

HPE FlexNetwork MSR 8-port 10/100/1000BASE-T/2-port 1000BASE-X (Combo) Switch HMIM Module

JG741A

HPE FlexNetwork MSR 1-port OC-3/STM-1 CPOS HMIM Module

JG428A

HPE FlexNetwork MSR 8-port 100BASE-FX/1000BASE-X/4-port 1000BASE-T (Combo) L2/L3 HMIM Module

JH238A

HPE FlexNetwork MSR 16-port Enhanced Async Serial HMIM Module

JG445A

HPE FlexNetwork MSR 8-port E1/CE1/T1/CT1/PRI HMIM Module

JH169A

HPE FlexNetwork MSR 8-port E1/Fractional E1/T1/Fractional T1 HMIM Module

JH172A

HPE MSR 1-port E1/T1 Voice SIC Module

JH240A

Power Supply

HPE FlexNetwork X351 300W 100-240VDC to 12VDC Power Supply

JG527A

HPE FlexNetwork X351 300W 48-60VDC to 12VDC Power Supply

JG528A

HPE RPS 800 Redundant Power Supply

JD183A

Power cords and Adapters

HPE FlexNetwork X290 MSR30 1m RPS Cable

JD637A

Memory

HPE X600 1G Compact Flash Card

JC684A

HPE FlexNetwork X610 4GB DDR3 SDRAM UDIMM Memory

JG530A

Page

QuickSpecs

HPE FlexNetwork MSR3000 Router Series

Related Options

Cables

HPE FlexNetwork X200 V.24 DTE 3m Serial Port Cable

JD519A

HPE FlexNetwork X200 V.24 DCE 3m Serial Port Cable

JD521A

HPE FlexNetwork X200 V.35 DTE 3m Serial Port Cable

JD523A

HPE FlexNetwork X200 V.35 DCE 3m Serial Port Cable

JD525A

HPE FlexNetwork X260 RS449 3m DTE Serial Port Cable

JF825A

HPE FlexNetwork X260 RS449 3m DCE Serial Port Cable

JF826A

HPE FlexNetwork X260 RS530 3m DTE Serial Port Cable

JF827A

HPE FlexNetwork X260 RS530 3m DCE Serial Port Cable

JF828A

HPE FlexNetwork X260 E1 (2) BNC 75 ohm 3m Router Cable

JD175A

HPE FlexNetwork X260 E1 RJ45 BNC 75-120 ohm Conversion Router Cable

JD511A

HPE FlexNetwork X260 T1 Router Cable

JD518A

HPE FlexNetwork X260 Mini D-28 to 4-RJ45 0.3m Router Cable

JG263A

HPE FlexNetwork X260 T3/E3 Router Cable

JD531A

HPE FlexNetwork X260 E1 RJ45 to 2xBNC 75ohm 3m Router Cable

JH294A

Page

QuickSpecs

HPE FlexNetwork MSR3000 Router Series

Technical Specifications

HPE FlexNetwork MSR3024 AC Router (JG406A)

I/O ports and slots

2 HMIM slots

1 SFP fixed Gigabit Ethernet SFP port

Additional ports and slots

1 VPM slot

AP characteristics

Radios (via optional modules)

3G, 4G LTE

Physical characteristics

Dimensions

17.32(w) x 18.9(d) x 1.74(h) in (44 x 48 x 4.42 cm) (1U height)

Weight

17.42 lb (7.9 kg)

Memory and processor

RISC, 4 cores @ 1 GHz, 256 MB flash capacity, 2 GB DDR3 SDRAM

Mounting and enclosure

Desktop or can be mounted in a EIA standard 19-inch telco rack when used with the rack-mount kit in the package.

Performance

Throughput

up to 2.6 Mpps (64-byte packets)

Routing table size

500000 entries (IPv4), 500000 entries (IPv6)

Forwarding table size

500000 entries (IPv4), 500000 entries (IPv6)

Environment

Operating temperature

32ºF to 113ºF (0ºC to 45ºC)

Operating relative humidity

5% to 90%, noncondensing

Nonoperating/Storage temperature

-40ºF to 158ºF (-40ºC to 70ºC)

Nonoperating/Storage relative humidity

5% to 90%, noncondensing

Altitude

up to 16,404 ft (5 km)

Electrical characteristics

Frequency

50/60 Hz

Maximum heat dissipation

168 BTU/hr (177.24 kJ/hr)

Voltage

100 - 240 VAC, rated

Maximum power rating

125 W

Notes

Maximum power rating and maximum heat dissipation are the worstcase theoretical maximum numbers provided for planning the infrastructure with fully loaded PoE (if equipped), 100% traffic, all ports plugged in, and all modules populated.

Reliability

MTBF (years)

49.61

Safety

UL 60950-1; EN 60825-1 Safety of Laser Products-Part 1; EN 60825-2 Safety of Laser Products-Part

1; FDA 21 CFR Subchapter J; AS/NZS

60950-1; GB 4943.1

Emissions

EN 61000-4-11:2004;ANSI C63.4-2009; AS/NZS CISPR 22:2009; CISPR 22 Ed2.0 2008-09; EN

3:2006; EN

8:2010; ETSI EN 300 386

6 Ed3.0 (2008-10); IEC 61000-4-8 Ed2.0 (2009-09); VCCI V-3/2013.04

4 SIC slots or 2 DSIC slots 3 RJ-45 1000BASE-T ports (IEEE 802.3ab Type 1000BASE-T)

2; IEC 60950-1; EN 60950-1; CAN/CSA-C22.2 No. 60950-

55022:2010; EN 61000-3-3:2008; GB 9254-2008; IEC 61000-3-2 Ed3.0 (2009-02); IEC 61000-3Ed2.0 (2008-06); VCCI V-4/2012.04; CISPR 24 Ed2.0 2010-08; EN 55024:2010; EN 61000-32:2006+A1:2009+A2:2009; EN 61000-4-2:2009; EN 61000-4-29:2000; EN 61000-461000-4-4:2012; EN 61000-4-5:2006; EN 61000-4-6:2009; EN 61000-4V1.6.1(2012-09); FCC 47 CFR Part 15 (latest current version); ICES-003 Issue 5; IEC 61000-4Ed2.0 (2004-03); IEC 61000-4-2 Ed2.0 (2008-12); IEC 61000-4-29 Ed1.0 (2000-08); IEC 61000-43 Ed3.2 (2010-04); IEC 61000-4-4 Ed3.0 (2012-04); IEC 61000-4-5 Ed2.0 (2005-11); IEC 61000-4-

Page

QuickSpecs

HPE FlexNetwork MSR3000 Router Series

Technical Specifications

Telecom

FCC part 68; CS-03

Management

IMC - Intelligent Management Center; command-line interface; limited command-line interface;

232C or Micro USB); IEEE

802.3 Ethernet MIB

Services

Refer to the Hewlett Packard Enterprise website at http://www.hpe.com/networking/services for details

scriptions and product numbers. For details about services and response times in

your area, please contact your local Hewlett Packard Enterprise sales office

HPE FlexNetwork MSR3044 Router (JG405A)

I/O ports and slots

4 HMIM slots

2 SFP fixed Gigabit Ethernet SFP ports

Additional ports and slots

2 VPM slots

AP characteristics

Radios (via optional modules)

3G, 4G LTE

Physical

Dimensions

17.32(w) x 18.9(d) x 3.47(h) in (44 x 48 x 8.81 cm) (2U height)

Weight

27.45 lb (12.45 kg)

Memory and processor

RISC, 4 cores @ 1 GHz, 256 MB flash capacity, 2 GB DDR3 SDRAM

Mounting and

Desktop or can be mounted in a EIA standard 19-inch telco rack when used with the rack-mount kit in the

Performance

Throughput

up to 3.5 Mpps (64-byte packets)

Routing table size

500000 entries (IPv4), 500000 entries (IPv6)

Forwarding table size

500000 entries (IPv4), 500000 entries (IPv6)

Environment

Operating temperature

32ºF to 113ºF (0ºC to 45ºC)

Operating relative humidity

5% to 90%, noncondensing

Nonoperating/Storage temperature

-40ºF to 158ºF (-40ºC to 70ºC)

Nonoperating/Storage relative

5% to 90%, noncondensing

Altitude

up to 16,404 ft (5 km)

Electrical

Frequency

50/60 Hz

Maximum heat dissipation

172 BTU/hr (181.46 kJ/hr)

Voltage

100 - 240 VAC, rated

(depending on power supply chosen)

Maximum power rating

300 W

PoE power

450 W PoE+

Notes

Maximum power rating and maximum heat dissipation are the worst-case theoretical maximum numbers provided for planning the infrastructure with

raffic, all ports plugged in, and all modules populated. PoE Power is the power supplied by the internal power supply, it is dependent on the type and quantity of power supplies and may

ult power supply is included in the chassis; a minimum of one/maximum of four power supplies should be ordered.

characteristics

configuration menu; out-of-band management (RJ-45 Ethernet); SNMP Manager; Telnet; RMON1; FTP; inline and out-of-band; modem interface; out-of-band management (serial RS-

on the service-level de

4 SIC slots, or 2 DSIC slots, or a combination 3 RJ-45 1000BASE-T ports (IEEE 802.3ab Type 1000BASE-T)

2 Power Supply slots

package.

enclosure

humidity

characteristics

-36 to -75 VDC, rated

fully loaded PoE (if equipped), 100% t

be supplemented with the use of a External Power Supply (EPS). No defa

Page

QuickSpecs

HPE FlexNetwork MSR3000 Router Series

Technical Specifications

Reliability

MTBF (years)

82.57

Safety

UL 60950-1; EN 60825-1 Safety of Laser Products-Part 1; EN 60825-2 Safety of Laser Products-Part 2; IEC 60950-1; EN 60950-1; CAN/CSA-C22.2 No. 60950-1; FDA 21 CFR Subchapter J; AS/NZS 60950-1; GB 4943.1

Emissions

EN 61000-4-11:2004;ANSI C63.4-2009; AS/NZS CISPR 22:2009; CISPR 22 Ed2.0 2008-09; EN 55022:2010;

06); VCCI

2:2006+A1:2009+A2:2009; EN

5:2006; EN

09); FCC 47 CFR Part 15 (latest current

5 Ed2.0

(2005-11); IEC 61000-4-6 Ed3.0 (2008-10); IEC 61000-4-8 Ed2.0 (2009-09); VCCI V-3/2013.04

Telecom

FCC part 68; CS-03

Management

IMC - Intelligent Management Center; command-line interface; limited command-line interface; configuration

band; modem interface; out-of-band management (serial RS-232C or Micro USB); IEEE 802.3 Ethernet MIB

Services

Refer to the Hewlett Packard Enterprise website at http://www.hpe.com/networking/services for details on

level descriptions and product numbers. For details about services and response times in your area,

HPE FlexNetwork MSR3064 Router (JG404A)

I/O ports and slots

6 HMIM slots

2 SFP fixed Gigabit Ethernet SFP ports

Additional ports and slots

2 VPM slots

AP characteristics

Radios (via optional modules)

3G, 4G LTE

Physical

Dimensions

17.32(w) x 18.9(d) x 5.31(h) in (44 x 48 x 13.5 cm) (3U height)

Weight

36.49 lb (16.55 kg)

Memory and processor

RISC, 6 cores @ 1.3 GHz, 256 MB flash capacity, 2 GB DDR3 SDRAM

Mounting and enclosure

Desktop or can be mounted in a EIA standard 19-inch telco rack when used with the rack-mount kit in the

Performance

Throughput

up to 5 Mpps (64-byte packets)

Routing table size

500000 entries (IPv4), 500000 entries (IPv6)

Forwarding table size

500000 entries (IPv4), 500000 entries (IPv6)

Environment

Operating temperature

32ºF to 113ºF (0ºC to 45ºC)

Operating relative humidity

5% to 90%, noncondensing

Nonoperating/Storage temperature

-40ºF to 158ºF (-40ºC to 70ºC)

Nonoperating/Storage relative humidity

5% to 90%, noncondensing

Altitude

up to 16,404 ft (5 km)

EN 61000-3-3:2008; GB 9254-2008; IEC 61000-3-2 Ed3.0 (2009-02); IEC 61000-3-3 Ed2.0 (2008V-4/2012.04; CISPR 24 Ed2.0 2010-08; EN 55024:2010; EN 61000-361000-4-2:2009; EN 61000-4-29:2000; EN 61000-4-3:2006; EN 61000-4-4:2012; EN 61000-461000-4-6:2009; EN 61000-4-8:2010; ETSI EN 300 386 V1.6.1(2012version); ICES-003 Issue 5; IEC 61000-4-11 Ed2.0 (2004-03); IEC 61000-4-2 Ed2.0 (2008-12); IEC 61000-429 Ed1.0 (2000-08); IEC 61000-4-3 Ed3.2 (2010-04); IEC 61000-4-4 Ed3.0 (2012-04); IEC 61000-4-

menu; out-of-band management (RJ-45 Ethernet); SNMP Manager; Telnet; RMON1; FTP; in-line and out-of-

the serviceplease contact your local Hewlett Packard Enterprise sales office

4 SIC slots or 2 DSIC slots 3 RJ-45 1000BASE-T ports (IEEE 802.3ab Type 1000BASE-T)

2 Power Supply slots

characteristics

package.

Page

QuickSpecs

HPE FlexNetwork MSR3000 Router Series

Technical Specifications

Electrical

Frequency

50/60 Hz

Maximum heat dissipation

218 BTU/hr (229.99 kJ/hr)

Voltage

100 - 240 VAC, rated

(depending on power supply chosen)

Maximum power rating

300 W

PoE power

450 W PoE+

Notes

Maximum power rating and maximum heat dissipation are the worst-case theoretical maximum numbers provided for planning the infrastructure with fully loaded PoE (if equipped), 100% traffic, all ports plugged in, and all

ower supplied by the internal power

be supplemented with the use of a External Power Supply (EPS). No default

power supplies should be ordered.

Reliability

MTBF (years)

80.58

Safety

UL 60950-1; EN 60825-1 Safety of Laser Products-Part 1; EN 60825-2 Safety of Laser Products-Part 2;

1; GB

4943.1

Emissions

EN 61000-4-11:2004;ANSI C63.4-2009; AS/NZS CISPR 22:2009; CISPR 22 Ed2.0 2008-09; EN

3 Ed2.0

03); IEC

04); IEC ; IEC

61000-4-8 Ed2.0 (2009-09); VCCI V-3/2013.04

Telecom

FCC part 68; CS-03

Management

IMC - Intelligent Management Center; command-line interface; limited command-line interface; configuration

band; modem interface; out-of-band management (serial RS-232C or Micro USB); IEEE 802.3 Ethernet MIB

Services

Refer to the Hewlett Packard Enterprise website at http://www.hpe.com/networking/services for details

area, please contact your local Hewlett Packard Enterprise sales office

Standards and protocols (applies to all products in series)

BGP

• RFC 2796 BGP Route Reflection

characteristics

-36 to -75 VDC, rated

modules populated. PoE Power is the p supply, it is dependent on the type and quantity of power supplies and may

power supply is included in the chassis; a minimum of one/maximum of fo

IEC 60950-1; EN 60950-1; CAN/CSA-C22.2 No. 60950-1; FDA 21 CFR Subchapter J; AS/NZS 60950-

55022:2010; EN 61000-3-3:2008; GB 9254-2008; IEC 61000-3-2 Ed3.0 (2009-02); IEC 61000-3(2008-06); VCCI V-4/2012.04; CISPR 24 Ed2.0 2010-08; EN 55024:2010; EN 61000-32:2006+A1:2009+A2:2009; EN 61000-4-2:2009; EN 61000-4-29:2000; EN 61000-4-3:2006; EN 610004-4:2012; EN 61000-4-5:2006; EN 61000-4-6:2009; EN 61000-4-8:2010; ETSI EN 300 386 V1.6.1(2012-

09); FCC 47 CFR Part 15 (latest current version); ICES-003 Issue 5; IEC 61000-4-11 Ed2.0 (200461000-4-2 Ed2.0 (2008-12); IEC 61000-4-29 Ed1.0 (2000-08); IEC 61000-4-3 Ed3.2 (201061000-4-4 Ed3.0 (2012-04); IEC 61000-4-5 Ed2.0 (2005-11); IEC 61000-4-6 Ed3.0 (2008-10)

menu; out-of-band management (RJ-45 Ethernet); SNMP Manager; Telnet; RMON1; FTP; in-line and out-of-

on the service-level descriptions and product numbers. For details about services and response times in your

• RFC 1163 Border Gateway Protocol (BGP)

• RFC 1267 Border Gateway Protocol 3 (BGP-3)

• RFC 1657 Definitions of Managed Objects for BGPv4

• RFC 1771 BGPv4

• RFC 1772 Application of the BGP

• RFC 1773 Experience with the BGP-4 Protocol

• RFC 1774 BGP-4 Protocol Analysis

• RFC 1965 BGP-4 confederations

• RFC 1997 BGP Communities Attribute

• RFC 2439 BGP Route Flap Damping

• RFC 2547 BGP/MPLS VPNs

Page

QuickSpecs

HPE FlexNetwork MSR3000 Router Series

Technical Specifications

•

• RFC1998 An Application of the BGP Community Attribute in Multi-home Routing

VPN

• RFC 4305 - Cryptographic Algorithm Implementation Requirements for ESP and AH

Denial of service protection

• RFC 2576 (Coexistence between SNMP V1, V2, V3)

RFC 2842 Capability Advertisement with BGP-4

• RFC 2858 BGP-4 Multi-Protocol Extensions

• RFC 2918 Route Refresh Capability

• RFC 3065 Autonomous System Confederations for GP

• RFC 3107 Support BGP carry Label for MPLS

• RFC 3392 Capabilities Advertisement with BGP-4

• RFC 4271 A Border Gateway Protocol 4 (BGP-4)

• RFC 4273 Definitions of Managed Objects for BGP-4

• RFC 4274 BGP-4 Protocol Analysis

• RFC 4275 BGP-4 MIB Implementation Survey

• RFC 4276 BGP-4 Implementation Report

• RFC 4277 Experience with the BGP-4 Protocol

• RFC 4360 BGP Extended Communities Attribute

• RFC 4456 BGP Route Reflection: An Alternative to Full Mesh Internal BGP (IBGP)

• RFC 4724 Graceful Restart Mechanism for BGP

• RFC 4760 Multiprotocol Extensions for BGP-4

• RFC 1828 IP Authentication using Keyed MD5

• RFC 1853 IP in IP Tunneling

• RFC 2401 Security Architecture for the Internet Protocol

• RFC 2402 IP Authentication Header

• RFC 2403 The Use of HMAC-MD5-96 within ESP and AH

• RFC 2404 The Use of HMAC-SHA-1-96 within ESP and AH

• RFC 2405 The ESP DES-CBC Cipher Algorithm With Explicit IV

• RFC 2406 IP Encapsulating Security Payload (ESP)

• RFC 2407 The Internet IP Security Domain of Interpretation for ISAKMP

• RFC 2410 The NULL Encryption Algorithm and Its Use With IPSec

• RFC 2411 IP Security Document Roadmap

• RFC 3948 - UDP Encapsulation of IPSec ESP Packets

• RFC 4301 - Security Architecture for the Internet Protocol

• RFC 4302 - IP Authentication Header (AH)

• RFC 4303 - IP Encapsulating Security Payload (ESP)

• CPU DoS Protection

• Rate Limiting by ACLs

• Device management

• RFC 1155 Structure and Mgmt Information (SMIv1)

• RFC 1157 SNMPv1/v2c

• RFC 1305 NTPv3

• RFC 1591 DNS (client)

• RFC 1902 (SNMPv2)

• RFC 1908 (SNMP v1/2 Coexistence)

• RFC 1945 Hypertext Transfer Protocol -- HTTP/1.0

• RFC 2271 Framework

• RFC 2573 (SNMPv3 Applications)

Page

QuickSpecs

HPE FlexNetwork MSR3000 Router Series

Technical Specifications

•

• RFC 3417 (SNMP Transport Mappings)

General Protocols

• RFC 1364 BGP OSPF Interaction

RFC 2578-2580 SMIv2

• RFC 2579 (SMIv2 Text Conventions)

• RFC 2580 (SMIv2 Conformance)

• RFC 3416 (SNMP Protocol Operations v2)

• RFC 2385 BGP Session Protection via TCP MD5

RFC 1027 Proxy ARP

•

RFC 1034 Domain names - concepts and facilities

•

RFC 1035 Domain names - implementation and specification

•

RFC 1048 BOOTP (Bootstrap Protocol) vendor information extensions

•

RFC 1054 Host extensions for IP multicasting

•

RFC 1058 RIPv1

•

RFC 1059 Network Time Protocol (version 1) specification and implementation

•

RFC 1060 Assigned numbers

•

RFC 1063 IP MTU (Maximum Transmission Unit) discovery options

•

RFC 1071 Computing the Internet Checksum

•

RFC 1072 TCP extensions for long-delay paths

•

RFC 1079 Telnet terminal speed option

•

RFC 1084 BOOTP (Bootstrap Protocol) vendor information extensions

•

RFC 1091 Telnet Terminal-Type Option

•

RFC 1093 NSFNET routing architecture

•

RFC 1101 DNS encoding of network names and other types

•

RFC 1119 Network Time Protocol (version 2) specification and implementation

•

RFC 1122 Requirements for Internet Hosts - Communication Layers

•

RFC 1141 Incremental updating of the Internet checksum

•

RFC 1142 OSI IS-IS Intra-domain Routing Protocol

•

RFC 1164 Application of the Border Gateway Protocol in the Internet

•

RFC 1166 Internet address used by Internet Protocol (IP)

•

RFC 1171 Point-to-Point Protocol for the transmission of multi-protocol datagrams over Point-to-Point links

•

RFC 1172 Point-to-Point Protocol (PPP) initial configuration options

•

RFC 1185 TCP Extension for High-Speed Paths

•

RFC 1191 Path MTU discovery

•

RFC 1195 OSI ISIS for IP and Dual Environments

•

RFC 1213 Management Information Base for Network Management of TCP/IP-based internets

•

RFC 1253 (OSPF v2)

•

RFC 1265 BGP Protocol Analysis

•

RFC 1266 Experience with the BGP Protocol

•

RFC 1268 Application of the Border Gateway Protocol in the Internet

•

RFC 1271 Remote Network Monitoring Management Information Base

•

RFC 1284 Definitions of Managed Objects for the Ethernetlike Interface Types

•

RFC 1286 Definitions of Managed Objects for Bridges

•

RFC 1294 Multiprotocol Interconnect over Frame Relay

•

RFC 1305 NTPv3 (IPv4 only)

•

RFC 1321 The MD5 Message-Digest Algorithm

•

RFC 1323 TCP Extensions for High Performance

•

RFC 1331 The Point-to-Point Protocol (PPP) for the Transmission of Multi-protocol Datagrams over Point-to-Point Links

•

RFC 1332 The PPP Internet Protocol Control Protocol (IPCP)

•

RFC 1333 PPP Link Quality Monitoring

•

RFC 1334 PPP Authentication Protocols

•

RFC 1349 Type of Service

•

RFC 1350 TFTP Protocol (revision 2)

•

Page

QuickSpecs

HPE FlexNetwork MSR3000 Router Series

Technical Specifications

• RFC 1370 Applicability Statement for OSPF

Video Transport Working

Group

• RFC 1377 The PPP OSI Network Layer Control Protocol (OSINLCP)

RFC 1393 Traceroute Using an IP Option

•

RFC 1395 BOOTP (Bootstrap Protocol) Vendor Information Extensions

•

RFC 1398 Definitions of Managed Objects for the Ethernet-Like Interface Types

•

RFC 1403 BGP OSPF Interaction

•

RFC 1444 Conformance Statements for version 2 of the Simple Network Management Protocol (SNMPv2)

•

RFC 1449 Transport Mappings for version 2 of the Simple Network Management Protocol (SNMPv2)

•

RFC 1471 The Definitions of Managed Objects for the Link Control Protocol of the Point-to-Point Protocol

•

RFC 1473 The Definitions of Managed Objects for the IP Network Control Protocol of the Point-to-Point Protocol

•

RFC 1483 Multiprotocol Encapsulation over ATM Adaptation Layer 5

•

RFC 1490 Multiprotocol Interconnect over Frame Relay

•

RFC 1497 BOOTP (Bootstrap Protocol) Vendor Information Extensions

•

RFC 1519 CIDR

•

RFC 1531 Dynamic Host Configuration Protocol

•

RFC 1532 Clarifications and Extensions for the Bootstrap Protocol

•

RFC 1533 DHCP Options and BOOTP Vendor Extensions

•

RFC 1534 Interoperation Between DHCP and BOOTP

•

RFC 1541 Dynamic Host Configuration Protocol

•

RFC 1542 BOOTP Extensions

•

RFC 1542 Clarifications and Extensions for the Bootstrap Protocol

•

RFC 1548 The Point-to-Point Protocol (PPP)

•

RFC 1549 PPP in HDLC Framing

•

RFC 1570 PPP LCP (Point-to-Point Protocol Link Control Protocol) Extensions

•

RFC 1577 Classical IP and ARP over ATM

•

RFC 1597 Address Allocation for Private Internets

•

RFC 1618 PPP over ISDN

•

RFC 1619 PPP over SONET/SDH (Synchronous Optical Network/Synchronous Digital Hierarchy)

•

RFC 1624 Incremental Internet Checksum

•

RFC 1631 NAT

•

RFC 1650 Definitions of Managed Objects for the Ethernet-like Interface Types using SMIv2

•

RFC 1661 The Point-to-Point Protocol (PPP)

•

RFC 1662 PPP in HDLC-like Framing

•

RFC 1700 Assigned Numbers

•

RFC 1701 Generic Routing Encapsulation

•

RFC 1702 Generic Routing Encapsulation over IPv4 networks

•

RFC 1717 The PPP Multilink Protocol (MP)

•

RFC 1721 RIP-2 Analysis

•

RFC 1722 RIP-2 Applicability

•

RFC 1723 RIP v2

•

RFC 1724 RIP Version 2 MIB Extension

•

RFC 1757 Remote Network Monitoring Management Information Base

•

RFC 1777 Lightweight Directory Access Protocol

•

RFC 1812 IPv4 Routing

•

RFC 1825 Security Architecture for the Internet Protocol

•

RFC 1826 IP Authentication Header

•

RFC 1827 IP Encapsulating Security Payload (ESP)

•

RFC 1829 The ESP DES-CBC Transform

•

RFC 1877 PPP Internet Protocol Control Protocol Extensions for Name Server Addresses

•

RFC 1884 IP Version 6 Addressing Architecture

•

RFC 1885 Internet Control Message Protocol (ICMPv6) for the Internet Protocol Version 6 (IPv6) Specification

•

RFC 1886 DNS Extensions to support IP version 6

•

• RFC 1889 RTP (Real-Time Protocol): A Transport Protocol for Real-Time Applications. Audio-

Page

QuickSpecs

HPE FlexNetwork MSR3000 Router Series

Technical Specifications

• RFC 1933 Transition Mechanisms for IPv6 Hosts and Routers

• RFC 2548 (MS-RAS-Vendor only)

• RFC 1945 Hypertext Transfer Protocol -- HTTP/1.0

RFC 1962 The PPP Compression Control Protocol (CCP)

•

RFC 1966 BGP Route Reflection An alternative to full mesh IBGP

•

RFC 1970 Neighbor Discovery for IP Version 6 (IPv6)

•

RFC 1971 IPv6 Stateless Address Autoconfiguration

•

RFC 1972 A Method for the Transmission of IPv6 Packets over Ethernet Networks

•

RFC 1981 Path MTU Discovery for IP version 6

•

RFC 1982 Serial Number Arithmetic

•

RFC 1989 PPP Link Quality Monitoring

•

RFC 1990 The PPP Multilink Protocol (MP)

•

RFC 1994 PPP Challenge Handshake Authentication Protocol (CHAP)

•

RFC 2001 TCP Slow Start, Congestion Avoidance, Fast Retransmit, and Fast Recovery Algorithms

•

RFC 2002 IP Mobility Support

•

RFC 2003 IP Encapsulation within IP

•

RFC 2011 SNMPv2 Management Information Base for the Internet Protocol using SMIv2

•

RFC 2012 SNMPv2 Management Information Base for the Transmission Control Protocol using SMIv2

•

RFC 2013 SNMPv2 Management Information Base for the User Datagram Protocol using SMIv2

•

RFC 2018 TCP Selective Acknowledgement Options

•

RFC 2021 Remote Network Monitoring Management Information Base Version 2 using SMIv2

•

RFC 2073 An IPv6 Provider-Based Unicast Address Format

•

RFC 2082 RIP-2 MD5 Authentication

•

RFC 2091 Triggered Extensions to RIP to Support Demand Circuits

•

RFC 2104 HMAC: Keyed-Hashing for Message Authentication

•

RFC 2131 DHCP

•

RFC 2132 DHCP Options and BOOTP Vendor Extensions

•

RFC 2136 Dynamic Updates in the Domain Name System (DNS UPDATE)

•

RFC 2138 Remote Authentication Dial In User Service (RADIUS)

•

RFC 2205 Resource ReSerVation Protocol (RSVP) -- Version 1 Functional Specification

•

RFC 2209 Resource ReSerVation Protocol (RSVP) -- Version 1 Message Processing Rules

•

RFC 2210 Use of RSVP (Resource Reservation Protocol) in Integrated Services

•

RFC 2225 Classical IP and ARP over ATM

•

RFC 2236 IGMP Snooping

•

RFC 2246 The TLS Protocol Version 1.0

•

RFC 2251 Lightweight Directory Access Protocol (v3)

•

RFC 2252 Lightweight Directory Access Protocol (v3): Attribute Syntax Definitions

•

RFC 2283 MBGP

•

RFC 2292 Advanced Sockets API for IPv6

•

RFC 2309 Recommendations on queue management and congestion avoidance in the Internet

•

RFC 2463 Internet Control Message Protocol (ICMPv6) for the Internet Protocol Version 6 (IPv6) Specification

•

RFC 2464 Transmission of IPv6 Packets over Ethernet Networks

•

RFC 2465 Management Information Base for IP Version 6: Textual Conventions and General Group

•

RFC 2466 Management Information Base for IP Version 6: ICMPv6 Group

•

RFC 2472 IP Version 6 over PPP

•

RFC 2474 Definition of the Differentiated Services Field (DS Field) in the IPv4 and IPv6 Headers

•

RFC 2507 IP Header Compression

•

RFC 2508 Compressing IP/UDP/RTP Headers for Low-Speed Serial Links

•

RFC 2509 IP Header Compression over PPP

•

RFC 2510 Internet X.509 Public Key Infrastructure Certificate Management Protocols

•

RFC 2516 A Method for Transmitting PPP Over Ethernet (PPPoE)

•

RFC 2519 A Framework for Inter-Domain Route Aggregation

•

RFC 2529 Transmission of IPv6 over IPv4 Domains without Explicit Tunnels

•

RFC 2543 SIP: Session Initiation Protocol

•

Page

QuickSpecs

HPE FlexNetwork MSR3000 Router Series

Technical Specifications

• RFC 2553 Basic Socket Interface Extensions for IPv6

• RFC 2865 Remote Authentication Dial In User Service (RADIUS)

• RFC 2327 SDP: Session Description Protocol

• RFC 2338 VRRP

• RFC 2344 Reverse Tunneling for Mobile IP

• RFC 2358 Definitions of Managed Objects for the Ethernet-like Interface Types

• RFC 2364 PPP Over AAL5

• RFC 2365 Administratively Scoped IP Multicast

• RFC 2373 IP Version 6 Addressing Architecture

• RFC 2374 An IPv6 Aggregatable Global Unicast Address Format

• RFC 2375 IPv6 Multicast Address Assignments

• RFC 2385 Protection of BGP Sessions via the TCP MD5 Signature Option

• RFC 2427 Multiprotocol Interconnect over Frame Relay

• RFC 2428 FTP Extensions for IPv6 and NATs

• RFC 2433 Microsoft PPP CHAP (Challenge Handshake Authentication Protocol) Extensions

• RFC 2451 The ESP CBC-Mode Cipher Algorithms

• RFC 2452 IP Version 6 Management Information Base for the Transmission Control Protocol

• RFC 2453 RIPv2

• RFC 2454 IP Version 6 Management Information Base for the User Datagram Protocol

• RFC 2461 Neighbor Discovery for IP Version 6 (IPv6)

• RFC 2462 IPv6 Stateless Address Autoconfiguration

• RFC 2570 Introduction to Version 3 of the Internet-standard Network Management Framework

• RFC 2581 TCP Congestion Control

• RFC 2597 Assured Forwarding PHB Group

• RFC 2598 An Expedited Forwarding PHB

• RFC 2615 PPP over SONET/SDH (Synchronous Optical Network/Synchronous Digital Hierarchy)

• RFC 2616 HTTP Compatibility v1.1

• RFC 2617 HTTP Authentication: Basic and Digest Access Authentication

• RFC 2618 RADIUS Authentication Client MIB

• RFC 2620 RADIUS Accounting Client MIB

• RFC 2644 Changing the Default for Directed Broadcasts in Routers

• RFC 2661 L2TP

• RFC 2663 NAT Terminology and Considerations

• RFC 2665 Definitions of Managed Objects for the Ethernet-like Interface Types

• RFC 2668 Definitions of Managed Objects for IEEE 802.3 Medium Attachment Units (MAUs)

• RFC 2675 IPv6 Jumbograms

• RFC 2684 Multiprotocol Encapsulation over ATM Adaptation Layer 5

• RFC 2685 Virtual Private Networks Identifier

• RFC 2686 The Multi-Class Extension to Multi-Link PPP

• RFC 2694 DNS extensions to Network Address Translators (DNS_ALG)

• RFC 2698 A Two Rate Three Color Marker

• RFC 2702 Requirements for Traffic Engineering Over MPLS

• RFC 2711 IPv6 Router Alert Option

• RFC 2716 PPP EAP TLS Authentication Protocol

• RFC 2747 RSVP Cryptographic Authentication

• RFC 2763 Dynamic Name-to-System ID mapping

• RFC 2784 Generic Routing Encapsulation (GRE)

• RFC 2787 Definitions of Managed Objects for the Virtual Router Redundancy Protocol

• RFC 2827 Network Ingress Filtering: Defeating Denial of Service Attacks Which Employ IP Source Address Spoofing

• RFC 2833 RTP Payload for DTMF Digits, Telephony Tones and Telephony Signals

Page

QuickSpecs

HPE FlexNetwork MSR3000 Router Series

Technical Specifications

•

• RFC 3031 Multiprotocol Label Switching Architecture

IPv6

• RFC 5340 OSPF for IPv6

Network management

•

RFC 2866 RADIUS Accounting

• RFC 2868 RADIUS Attributes for Tunnel Protocol Support

• RFC 2869 RADIUS Extensions

• RFC 2884 Performance Evaluation of Explicit Congestion Notification (ECN) in IP Networks.

• RFC 2894 Router Renumbering for IPv6

• RFC 2917 A Core MPLS IP VPN Architecture

• RFC 2925 Definitions of Managed Objects for Remote Ping, Traceroute, and Lookup Operations

• RFC 2961 RSVP Refresh Overhead Reduction Extensions

• RFC 2963 A Rate Adaptive Shaper for Differentiated Services

• RFC 2965 HTTP State Management Mechanism

• RFC 2966 Domain-wide Prefix Distribution with Two-Level IS-IS

• RFC 2973 IS-IS Mesh Groups

• RFC 2976 The SIP INFO Method

• RFC 2993 Architectural Implications of NAT

• RFC 3011 The IPv4 Subnet Selection Option for DHCP

• RFC 3022 Traditional IP Network Address Translator (Traditional NAT)

• RFC 3024 Reverse Tunneling for Mobile IP, revised

• RFC 3025 Mobile IP Vendor/Organization-Specific Extensions

• RFC 3027 Protocol Complications with the IP Network Address Translator

• RFC 2080 RIPng for IPv6

• RFC 2460 IPv6 Specification

• RFC 2473 Generic Packet Tunneling in IPv6

• RFC 2475 IPv6 DiffServ Architecture

• RFC 2529 Transmission of IPv6 Packets over IPv4

• RFC 2545 Use of MP-BGP-4 for IPv6

• RFC 2553 Basic Socket Interface Extensions for IPv6

• RFC 2740 OSPFv3 for IPv6

• RFC 2893 Transition Mechanisms for IPv6 Hosts and Routers

• RFC 3056 Connection of IPv6 Domains via IPv4 Clouds

• RFC 3162 RADIUS and IPv6

• RFC 3315 DHCPv6 (client and relay)

• IEEE 802.1D (STP)

• RFC 1098 Simple Network Management Protocol (SNMP)

• RFC 1158 Management Information Base for network management of TCP/IP-based internets: MIB-II

• RFC 1212 Concise MIB definitions

• RFC 1215 Convention for defining traps for use with the SNMP

• RFC 1389 RIPv2 MIB Extension

• RFC 1448 Protocol Operations for version 2 of the Simple Network Management Protocol (SNMPv2)

• RFC 1450 Management Information Base (MIB) for version 2 of the Simple Network Management Protocol (SNMPv2)

• RFC 1902 Structure of Management Information for Version 2 of the Simple Network Management Protocol (SNMPv2)

• RFC 1903 SNMPv2 Textual Conventions

• RFC 1904 SNMPv2 Conformance

• RFC 1905 SNMPv2 Protocol Operations

RFC 1906 SNMPv2 Transport Mappings

Page

QuickSpecs

HPE FlexNetwork MSR3000 Router Series

Technical Specifications

•

• RFC 3418 Management Information Base (MIB) for the Simple Network Management Protocol (SNMP)

IP multicast

•

RFC 1908 Coexistence between Version 1 and Version 2 of the Internet-standard Network Management Framework

• RFC 1918 Private Internet Address Allocation

• RFC 2037 Entity MIB using SMIv2

• RFC 2261 An Architecture for Describing SNMP Management Frameworks

• RFC 2262 Message Processing and Dispatching for the Simple Network Management Protocol (SNMP)

• RFC 2263 SNMPv3 Applications

• RFC 2264 User-based Security Model (USM) for version 3 of the Simple Network Management Protocol (SNMPv3)

• RFC 2265 View-based Access Control Model (VACM) for the Simple Network Management Protocol (SNMP)

• RFC 2272 SNMPv3 Management Protocol

• RFC 2273 SNMPv3 Applications

• RFC 2274 USM for SNMPv3

• RFC 2275 VACM for SNMPv3

• RFC 2575 SNMPv3 View-based Access Control Model (VACM)

• RFC 3164 BSD syslog Protocol

• RFC 3411 An Architecture for Describing Simple Network Management Protocol (SNMP) Management Frameworks

• RFC 3412 Message Processing and Dispatching for the Simple Network Management Protocol (SNMP)

• RFC 3413 Simple Network Management Protocol (SNMP) Applications

• RFC 3414 SNMPv3 User-based Security Model (USM)

• RFC 3415 View-based Access Control Model (VACM) for the Simple Network Management Protocol (SNMP)

• RFC 1112 IGMP

• RFC 2362 PIM Sparse Mode

• RFC 2710 Multicast Listener Discovery (MLD) for IPv6

• RFC 2934 Protocol Independent Multicast MIB for IPv4

• RFC 3376 IGMPv3

• RFC 3376 IGMPv3 (host joins only)

RFC 5059 Bootstrap Router (BSR) Mechanism for Protocol Independent Multicast (PIM)

Page

QuickSpecs

HPE FlexNetwork MSR3000 Router Series

Technical Specifications

MIBs

• RFC 3813 MPLS LSR MIB

OSPF

•

Security

• RFC 3580 IEEE 802.1X Remote Authentication Dial In User Service (RADIUS) Usage Guidelines

• RFC 1213 MIB II

• RFC 1493 Bridge MIB

• RFC 1724 RIPv2 MIB

• RFC 1850 OSPFv2 MIB

• RFC 1907 SNMPv2 MIB

• RFC 2011 SNMPv2 MIB for IP

• RFC 2012 SNMPv2 MIB for TCP

• RFC 2013 SNMPv2 MIB for UDP

• RFC 2096 IP Forwarding Table MIB

• RFC 2233 Interfaces MIB

• RFC 2273 SNMP-NOTIFICATION-MIB

• RFC 2571 SNMP Framework MIB

• RFC 2572 SNMP-MPD MIB

• RFC 2573 SNMP-Notification MIB

• RFC 2574 SNMP USM MIB

• RFC 2674 802.1p and IEEE 802.1Q Bridge MIB

• RFC 2737 Entity MIB (Version 2)

• RFC 2863 The Interfaces Group MIB

• RFC 1245 OSPF protocol analysis

• RFC 1246 Experience with OSPF

• RFC 1583 OSPFv2

• RFC 1587 OSPF NSSA

• RFC 1765 OSPF Database Overflow

• RFC 1850 OSPFv2 Management Information Base (MIB), traps

• RFC 2328 OSPFv2

• RFC 2370 OSPF Opaque LSA Option

RFC 3101 OSPF NSSA

• IEEE 802.1X Port Based Network Access Control

• RFC 2082 RIP-2 MD5 Authentication

• RFC 2104 Keyed-Hashing for Message Authentication

• RFC 2138 RADIUS Authentication

• RFC 2139 RADIUS Accounting

• RFC 2408 Internet Security Association and Key Management Protocol (ISAKMP)

• RFC 2409 The Internet Key Exchange (IKE)

• RFC 2412 The OAKLEY Key Determination Protocol

• RFC 2459 Internet X.509 Public Key Infrastructure Certificate and CRL Profile

• RFC 2818 HTTP Over TLS

• RFC 2865 RADIUS Authentication

• RFC 2866 RADIUS Accounting

• RFC 3579 RADIUS Support For Extensible Authentication Protocol (EAP)

Page

QuickSpecs

HPE FlexNetwork MSR3000 Router Series

Technical Specifications

QoS/CoS

•

• IEEE 802.1p (CoS)

• RFC 2474 DS Field in the IPv4 and IPv6 Headers

• RFC 2475 DiffServ Architecture

• RFC 2597 DiffServ Assured Forwarding (AF)

• RFC 2598 DiffServ Expedited Forwarding (EF)

• RFC 2697 A Single Rate Three Color Marker

• RFC 3168 The Addition of Explicit Congestion Notification (ECN) to IP

• RFC 3247 Supplemental Information for the New Definition of the EF PHB (Expedited Forwarding Per-Hop Behavior)

RFC 3260 New Terminology and Clarifications for DiffServ

Page

QuickSpecs

HPE FlexNetwork MSR3000 Router Series

Summary of Changes

Date

Version History

Action

Description of Change:

02-Dec-2019

Version 28

Changed

Overview, Standard Features, Configuration Information, related Options and Technical Specifications sections were updated.

07-May-2018

Version 27

Changed

Configuration section updated

04-Dec-2017

Version 26

Changed

Minor edit on Features and benefits

05-Jun-2017

Version 25

Changed

Configuration section updated

07-Apr-2017

Version 24

Changed

Updates made on Features and benefits and Accessories

03-Apr-2017

Version 23

Added

SKU added: JH449A

06-Feb-2017

Version 22

Changed

Adding MSR #A59 option on Configuration section

05-Sep-2016

Version 21

Added

SKU added: JG742B

01-Aug-2016

Version 20

Changed

Adding #AC3 Option on Configuration section

06-Jun-2016

Version 19

Changed

Document name changed to HPE FlexNetwork MSR3000 Router Series. Product description updated.

29-Apr-2016

Version 18

Changed

SKU descriptions updated, changes made on Technical Specifications

31-Mar-2016

Version 17

Changed

Models added: JG409B

01-Dec-2015

Version 16

Changed

Overview and Technical Specifications updated

28-Aug-2015

Version 15

Changed

Configuration section updated

17-Aug-2015

Version 14

Changed

SKUs added: JG445A, JH169A, JH172A, JH238A, JH294A, JG929A

24-Feb-2015

Version 13

Added

Adding new rule 10 to Box Level CTO section

06-Oct-2014

Version 12

Changed

Removed SKU JD572A Configuration section updated

18-Aug-2014

Version 11

Changed

Added 9 new accessories: JG428A, JG432A, JG434A, JG741A, JG736A,

Content Edits

10-Jun-2014

Version 10

Added

3 new models: JG407A, JG408A, JG410A;

JG424A, JG425A, JG426A, JG427A, JG742A, JG743A, JG744A, JG528A

10-Feb-2014

Version 9

Changed

Key features was revised.

31-Jan-2014

Version 8

Added

GRE tunnels was added to Technical Specifications.

17-Dec-2013

Version 7

Changed

Overview image callout for HP MSR3012 AC Router-Front was revised.

09-Dec-2013

Version 6

Changed

Power Supplies, Modules, and Cables were revised.

22-Nov-2013

Version 5

Changed

Router Chassis, CTO Router Chassis, Power Supplies, Modules, and Cables 14-Oct-2013

Version 4

Added

Overview images were added.

30-Sep-2013

Version 3

Changed

Minor edits were made throughout Configuration.

27-Sep-2013

Version 2

Added

Configuration was added.

19-Aug-2013

Version 1

New

New QuickSpecs

SKUs added: JH240A, JH224AAE, JH228AAE Features and benefits updated

Updated Features and benefits, Configuration, Technical Specifications and Accessories

JG737A, JG738A, JG739A, JG740A

13 new accessories: JG604A, JG420A, JG421A, JG422A, JG423A,

were revised.

Page

QuickSpecs

HPE FlexNetwork MSR3000 Router Series

Summary of Changes

© Copyright 2019 Hewlett Packard Enterprise Development LP. The information contained herein is subject to change without notice. The only warranties for Hewlett Packard Enterprise products and services are set forth in the express warranty statements accompanying such pro be construed as constituting an additional warranty. Hewlett Packard Enterprise shall not be liable for technical or editorial errors or omissions contained herein.

To learn more, visit:

c04123140 - 14641 - Worldwide - V28 - 02-December-2019

ducts and services. Nothing herein should

http://www.hpe.com/networking
