QuickSpecs

HPE FlexFabric 5900 Switch Series

Overview

HPE FlexFabric 5900 Switch Series

Models

HPE FlexFabric 5900AF 48XG 4QSFP+ Switch

JC772A

HPE FlexFabric 5900AF 48G 4XG 2QSFP+ Switch

JG510A

HPE FlexFabric 5900AF 48XGT 4QSFP+ Switch

JG336A

HPE FlexFabric 5900 48XG 4QSFP+ Short Form Factor Switch

JH337A

Product overview

The HPE FlexFabric 5900 Switch Series is a family of high-density, ultra-low-latency, top-of-rack (ToR) switches that is part of the Hewlett Packard Enterprise (HPE) FlexNetwork architecture's HPE FlexFabric solution.

Ideally suited for deployment at the server access layer of large enterprise data centers, the also pow applications and performanc ultra-low-latency all in a single device.

Key features

• Cut-through with ultra low latency and wire speed

Features and benefits

HPE FlexFabric 5900 Switch Series is

erful enough for deployment at the data center core layer of medium-sized enterprises. With the increase in virtualized

server-to-server traffic, customers now require ToR switch innovations that will meet their needs for higher-

e server connectivity, convergence of Ethernet and storage traffic, the capability to handle virtual environments, and

• HPE Intelligent Resilient Fabric (IRF) for virtualization and two-tier architecture

• High 1/10GbE ToR port density with 40 GbE uplinks

• IPv6 support in ToR with full L2/L3 features

• Convergence ready with DCB, FCoE, and TRILL

Page

QuickSpecs

HPE FlexFabric 5900 Switch Series

Overview

Quality of Service (QoS)

(WDRR), SP+WDRR together, configurable buffers, Explicit Congestion Notification (ECN), and Weighted Random

Data center optimized

through and nonblocking architecture delivers low latency (~1 microsecond for 10GbE) for very demanding enterprise

Enterprise (HPE) Intelligent Resilient Fabric (IRF) technology simplifies the architecture of server access

networks; up to nine HPE FlexFabric 5900 switches can be combined to deliver unmatched scalability of virtualized access

ts of Links (TRILL) is supported to increase the scale

of enterprise data centers; Edge Virtual Bridging with Virtual Ethernet Port Aggregator (EVB/VEPA) provides connectivity

performance remote backup

Manageability

• Powerful QoS features:

− Flexible classification

− Feature support

creates traffic classes based on access control lists (ACLs), IEEE 802.1p precedence, IP, and DSCP or Type of Service (ToS) precedence; supports filter, redirect, mirror, remark, and logging

provides support for Strict Priority Queuing (SP), Weighted Fair Queuing (WFQ), Weighted Deficit Round Robin

Early Detection (WRED)

• Flexible high port density

the HPE FlexFabric 5900 Switch Series enables scaling of the server edge with 1 GbE and 10GbE ToR deployments to new heights with high-density 48-port solutions delivered in a 1RU design; the high server port density is backed by 40 GbE QSFP+ uplinks to deliver the availability of needed bandwidth for demanding applications; each 40 GbE QSFP+ port can also be configured as four 10GbE ports by using a 40-GbE-to-10GbE splitter cable

• High-performance switching

cutapplications; the switch delivers high-performance switching capacity and wire-speed packet forwarding

• Higher scalability

Hewlett Packard

layer switches and flatter two-tier networks using IRF, which reduces cost and complexity

• Advanced modular operating system

Comware v7 software's modular design and multiple processes bring native high stability, independent process monitoring, and restart; the OS also allows individual software modules to be upgraded for higher availability and supports enhanced serviceability functions like hitless software upgrades with single-chassis ISSU

• SPB, TRILL, and EVB/VEPA

Shortest Path Bridging (SPB) and Transparent Interconnection of Lo

into the virtual environment for a data center-ready environment

• Reversible airflow

enhanced for data center hot-cold aisle deployment with reversible airflow—for either front-to-back or back-to-front airflow

• Redundant fans and power supplies

1+1 internal redundant and hot-pluggable power supplies and dual fan trays enhance reliability and availability

• Lower OPEX and greener data center

provide reversible airflow and advanced chassis power management

• Data Center Bridging (DCB) protocols

provides support for IEEE 802.1Qbb Priority Flow Control (PFC), Data Center Bridging Exchange (DCBX), and IEEE

802.1Qaz Enhanced Transmission Selection (ETS) for converged applications

• FCoE support

provides support for Fibre Channel over Ethernet (FCoE), including expansion, fabric, trunk VF and N ports, and aggregation of E-port and N-port virtualization; fabric services such as name server, registered state change notification, and login services; per-VSAN fabric services, FSPF, soft and hard zoning, Fibre Channel traceroute, ping, debugging, and FIP snooping

• Jumbo frames

with frame sizes of up to 10,000 bytes on Gigabit Ethernet and 10-Gigabit ports, allows highand disaster-recovery services to be enabled

Page

QuickSpecs

HPE FlexFabric 5900 Switch Series

Overview

• Full-featured console

Resiliency and high availability

based networks

provides complete control of the switch with a familiar CLI

• Troubleshooting

− Ingress and egress port monitoring: enable network problem solving

• Multiple configuration files

• sFlow (RFC 3176)

• SNMP v1, v2c and v3

• Out-of-band interface

• Remote configuration and management

• ISSU and hot patching

• Autoconfiguration

• Network Time Protocol (NTP) and Secure Network Time Protocol (SNTP)

− Traceroute and ping: enable testing of network connectivity

allow multiple configuration files to be stored to a flash image

provides wire-speed traffic accounting and monitoring

facilitate centralized discovery, monitoring, and secure management of networking devices

isolates management traffic from user data plane traffic for complete isolation and total reachability, no matter what happens in the data plane

is available through a secure command-line interface (CLI) over Telnet and SSH; Role-Based Access Control (RBAC) provides multiple levels of access; Configuration Rollback and multiple configurations on the flash provide ease of operation; remote visibility is provided with sFlow and SNMP v1/v2/v3, and is fully supported in HPE Intelligent Management Center (IMC)

provides hitless software upgrades with single-unit In Services Software Upgrade (ISSU) and hitless patching of the modular operating system

provides automatic configuration via DHCP autoconfiguration, NETCONF and Python Scripting

synchronize timekeeping among distributed time servers and clients; keep consistent timekeeping among all clockdependent devices within the network so that the devices can provide diverse applications based on the consistent time. Precision Time Protocol (PTP) RFC 1855 Compliant

• HPE Intelligent Resilient Fabric (IRF) technology

enables an HPE FlexFabric to deliver resilient, scalable, and secured data center networks for physical and virtualized environments; groups up to nine HPE FlexFabric 5900 switches in an IRF configuration, allowing them to be configured and managed as a single switch with a single IP address; simplifies ToR deployment and management, reducing data center deployment and operating expenses

• IEEE 802.1w Rapid Convergence Spanning Tree Protocol

increases network uptime through faster recovery from failed links

• IEEE 802.1s Multiple Spanning Tree

provides high link availability in multiple VLAN environments by allowing multiple spanning trees

• Per VLAN Spanning Tree (PVST)

provides high link availability in multiple VLAN environments by allowing spanning tree instances per VLAN

• Virtual Router Redundancy Protocol (VRRP)

allows groups of two routers to dynamically back each other up to create highly available routed environments

• Hitless patch upgrades

allows patches and new service features to be installed without restarting the equipment, increasing network uptime and facilitating maintenance

• Ultrafast protocol convergence (< 50 ms) with standard-based failure detection—Bidirectional Forwarding

Detection (BFD) enables link connectivity monitoring and reduces network convergence time for RIP, OSPF, BGP, IS-IS, VRRP, MPLS, and IRF

• Device Link Detection Protocol (DLDP)

monitors link connectivity and shuts down ports at both ends if unidirectional traffic is detected, preventing loops in STP-

Page

QuickSpecs

HPE FlexFabric 5900 Switch Series

Overview

• Graceful restart

Layer 2 switching

Policy; IPv6 IGMP Snooping provides Layer 2 optimization of

Layer 3 services

determines the MAC address of another IP host in the same subnet; supports static ARPs; gratuitous ARP allows detection

Layer 3 routing

MD5 authentication for increased security and graceful restart for faster failure recovery

allows routers to indicate to others their capability to maintain a routing table during a temporary shutdown and significantly reduces convergence times upon recovery; supports OSPF, BGP, and IS-IS

• MAC-based, Protocol-based, and Subnet-based VLANs

provides granular control and security; uses RADIUS to map a MAC address/user to specific VLANs, map protocols to specific VLANs or subnets to specific VLANs.

• Address Resolution Protocol (ARP)

supports static, dynamic, and reverse ARP and ARP proxy

• Flow Control

IEEE 802.3x Flow Control provides intelligent congestion management via PAUSE frames

• Ethernet Link Aggregation

provides IEEE 802.3ad Link Aggregation of up to 128 groups of 16 ports; support for LACP, LACP Local Forwarding First, and LACP Short-time provides a fast, resilient environment that is ideal for the data center

• Spanning Tree Protocol (STP)

STP (IEEE 802.1D), Rapid STP (RSTP, IEEE 802.1w), and Multiple STP (MSTP, IEEE 802.1s)

• VLAN support

provides support for 4,096 VLANs based on port, MAC address, IPv4 subnet, protocol, and guest VLAN; supports VLAN mapping

• IGMP support

provides support for IGMP Snooping, Fast-Leave, and Groupmulticast traffic

• DHCP support at Layer 2

provides full DHCP Snooping support for DHCP Snooping Option 82, DHCP Relay Option 82, DHCP Snooping Trust, and DHCP Snooping Item Backup

• Address Resolution Protocol (ARP)

• Dynamic Host Configuration Protocol (DHCP)

• Operations, administration and maintenance (OAM) support

• Virtual Router Redundancy Protocol (VRRP) and VRRP Extended

• Policy-based routing

• Equal-Cost Multipath (ECMP)

• Layer 3 IPv4 routing

• Open shortest path first (OSPF)

of duplicate IP addresses; proxy ARP allows normal ARP operation between subnets or when subnets are separated by a Layer 2 network

simplifies the management of large IP networks and supports client and server; DHCP Relay enables DHCP operation across subnets

provides support for Connectivity Fault Management (IEEE 802.1AG) and Ethernet in the First Mile (IEEE 802.3AH); provides additional monitoring that can be used for fast fault detection and recovery

allow quick failover of router ports

makes routing decisions based on policies set by the network administrator

enables multiple equal-cost links in a routing environment to increase link redundancy and scale bandwidth

provides routing of IPv4 at media speed; supports static routes, RIP and RIPv2, OSPF, BGP, and IS-IS

delivers faster convergence; uses this link-state routing InteriorGateway Protocol (IGP), which supports ECMP, NSSA, and

Page

QuickSpecs

HPE FlexFabric 5900 Switch Series

Overview

• Border Gateway Protocol 4 (BGP-4)

IS routing and extended

Additional information

Management

facilitate centralized discovery, monitoring, and secure management of networking devices

delivers an implementation of the Exterior Gateway Protocol (EGP) utilizing path vectors; uses TCP for enhanced reliability for the route discovery process; reduces bandwidth consumption by advertising only incremental updates; supports extensive policies for increased flexibility; scales to very large networks

• Intermediate system to intermediate system (IS-IS)

uses a path vector Interior Gateway Protocol (IGP), which is defined by the ISO organization for ISby IETF RFC 1195 to operate in both TCP/IP and the OSI reference model (Integrated IS-IS)

• Static IPv6 routing

provides simple manually configured IPv6 routing

• Dual IP stack

maintains separate stacks for IPv4 and IPv6 to ease the transition from an IPv4-only network to an IPv6-only network design

• Routing Information Protocol next generation (RIPng)

extends RIPv2 to support IPv6 addressing

• OSPFv3

provides OSPF support for IPv6

• BGP+

extends BGP-4 to support Multiprotocol BGP (MBGP), including support for IPv6 addressing

• IS-IS for IPv6

extends IS-IS to support IPv6 addressing

• IPv6 tunneling

allows IPv6 packets to traverse IPv4-only networks by encapsulating the IPv6 packet into a standard IPv4 packet; supports manually configured, 6to4, and Intra-Site Automatic Tunnel Addressing Protocol (ISATAP) tunnels; is an important element for the transition from IPv4 to IPv6

• Policy routing

allows custom filters for increased performance and security; supports ACLs, IP prefix, AS paths, community lists, and aggregate policies

• Bidirectional Forwarding Detection (BFD)

enables link connectivity monitoring and reduces network convergence time for RIP, OSPF, BGP, IS-IS, VRRP, MPLS, and IRF

• Multicast Routing

provides robust support of multicast protocols PIM-SM, PIM-DM, PIM-SSM and PIM-BIDIR

• Layer 3 IPv6 routing

provides routing of IPv6 at media speed; supports static routing, RIPng, OSPFv3, BGP4+ for IPv6, and IS-ISv6

• Green IT and power

improves energy efficiency through the use of the latest advances in silicon development; shuts off unused ports and utilizes variable-speed fans, reducing energy costs

• Low power consumption

is rated to have one of the lowest power usages in the industry by Miercom independent tests

• USB support

− File copy

• Multiple configuration files

can be stored to the flash image

• SNMPv1, v2c, and v3

allows users to copy switch files to and from a USB flash drive

Page

QuickSpecs

HPE FlexFabric 5900 Switch Series

Overview

• Network Time Protocol (NTP)

based wirespeed network monitoring and accounting with no impact on network performance; this

via SNMP (v2c and v3) and syslog; provides log throttling and log filtering to

estricts access to critical configuration commands; offers multiple privilege levels with password protection; ACLs provide

Security

provide IP Layer 3 filtering based on source/destination IP address/subnet and source/destination TCP/UDP port number

encrypts all transmitted data for secure remote CLI access over IP networks

synchronizes timekeeping among distributed time servers and clients; keeps timekeeping consistent among all clockdependent devices within the network so that the devices can provide diverse applications based on the consistent time

• Out-of-band interface

isolates management traffic from user data plane traffic for complete isolation and total reachability, no matter what happens in the data plane

• Port mirroring

enables traffic on a port to be simultaneously sent to a network analyzer for monitoring

• Remote configuration and management

is available through a command-line interface (CLI)

• IEEE 802.1AB Link Layer Discovery Protocol (LLDP)

advertises and receives management information from adjacent devices on a network, facilitating easy mapping by network management applications

• sFlow (RFC 3176)

provides scalable ASICallows network operators to gather a variety of sophisticated network statistics and information for capacity planning and real-time network monitoring purposes

• Command authorization

leverages RADIUS to link a custom list of CLI commands to an individual network administrator's login; an audit trail documents activity

• Dual flash images

provide independent primary and secondary operating system files for backup while upgrading

• Command-line interface (CLI)

provides a secure, easy-to-use CLI for configuring the module via SSH or a switch console; provides direct real-time session visibility

• Logging

provides local and remote logging of events reduce the number of log events generated

• Management interface control

provides management access through a modem port and terminal interface, as well as in-band and out-of-band Ethernet ports; provides access through terminal interface, Telnet, or secure shell (SSH)

• Industry-standard CLI with a hierarchical structure

reduces training time and expenses, and increases productivity in multivendor installations

• Management security

r Telnet and SNMP access; local and remote syslog capabilities allow logging of all access

• Information center

provides a central repository for system and network information; aggregates all logs, traps, and debugging information generated by the system and maintains them in order of severity; outputs the network information to multiple channels based on user-defined rules

• Network management

HPE Intelligent Management Center (IMC) centrally configures, updates, monitors, and troubleshoots

• Remote intelligent mirroring

mirrors ingress/egress ACL-selected traffic from a switch port or VLAN to a local or remote switch port anywhere on the network

• Access control lists (ACLs)

• RADIUS/TACACS+

• Secure shell

eases switch management security administration by using a password authentication server

Page

QuickSpecs

HPE FlexFabric 5900 Switch Series

Overview

• IEEE 802.1X and RADIUS network logins

Convergence

Warranty and support

; for details on the software releases

HPE Recommended Options have the best performance, value and availability.

Recommended Options have been selected by Hewlett Packard Enterprise experts to provide the right technology for a range of

workloads and market segments. Fully integrated into the ProLiant management and security experience, Recommended Options provide the best fit with ti

Extended Options

requiring the utmost in performance or value. Options represent great value and performance but typically have a longer lead

control port-based access for authentication and accountability

• Port security

allows access only to specified MAC addresses, which can be learned or specified by the administrator

• LLDP-MED (Media Endpoint Discovery)

is a standard extension of LLDP that stores values for parameters such as QoS and VLAN to automatically configure network devices such as IP phones

• 1-year warranty

see http://www.hpe.com/networking/warrantysummary product purchase.

• Software releases

to find software for your product, refer to http://www.hpe.com/networking/support available with your product purchase, refer to http://www.hpe.com/networking/warrantysummary

for warranty and support information included with your

mely availability. View the list for your region.

provide an extended catalog of products tailored for customers in specific markets or with specific workloads,

Fully integrated into the ProLiant management and security experience, Extended

-time.

Page

QuickSpecs

HPE FlexFabric 5900 Switch Series

Configuration

Build To Order:

BTO is a standalone unit with no integration. BTO products ship standalone are not part of a CTO or Rack-Shippable solution.

Standard Switch Enclosures

HPE FlexFabric 5900AF 48XG 4QSFP+ Switch

JC772A

• 48 fixed 1000/10000 SFP+ ports (min=0 \ max=48)

See Configuration

HPE 5900AF 48XG 4QSFP with 4x5900AF 8xPSU 8xF-B Fan Trays 5xDAC 64x10G SR Optics and IMC Bundle

JG846A

HPE 5900AF 48XG 4QSFP FB Bundle

Each Switch:

See Configuration

PDU Cable NA/MEX/TW/JP (8 Cables)

JG846A#B2B

•

No Power Cord

JG846A#AC3

• No Localized Power Cord Selected

PDU Cable ROW (8 Cables)

JG846A#B2C

• C15 PDU Jumper Cord (ROW) (8 Cables)

HPE 5900AF 48XG 4QSFP with 4x5900AF 8xPSU 8xB-F Fan Trays 5xDAC 64x10G SR Optics and IMC Bundle

JG847A

HPE 5900AF 48XG 4QSFP BF Bundle

• 4 - JC772A HPE FlexFabric 5900AF 48XG 4QSFP+ Switch

See Configuration

• 4 QSFP+ 40-GbE ports (min=0 \ max=4

• Must select min 1 Power Supply

• Must select min 2 Fan Tray

• 1U - Height

• 4 - JC772A HPE FlexFabric 5900AF 48XG 4QSFP+ Switch

• 8 - JC680A HPE 58x0AF 650W AC Power Supply

• 8 - JC683A HPE 58x0AF Front (Port Side) to Back (Power Side) Airflow Fan Tray

• 6 - JD097C HPE FlexNetwork X240 10G SFP+ to SFP+ 3m Direct Attach Copper Cable

• 2 - JG081C HPE FlexNetwork X240 10G SFP+ to SFP+ 5m Direct Attach Copper Cable

• 64 - JD092B HPE X130 10G SFP+ LC SR Transceiver

• 48 fixed 1000/10000 SFP+ ports (System Std=20 \ max=48 User min=0 \ max=28)

• 4 QSFP+ 40-GbE ports (min=0 \ max=4) (System Std=4 \ max=4 User min=-4 \ max=0)

• 2 Power Supplies Standard (min=2 \ max=2)

• 2 Front to Back Fan Trays Standard (min=2 \ max=2)

• 1U - Height

NOTE: 1, 2, 4, 7, 8

NOTE:1, 2, 6

C15 PDU Jumper Cord (NA/MEX/TW/JP) (8 Cables)

NOTE:1, 2, 6

Page

QuickSpecs

HPE FlexFabric 5900 Switch Series

Configuration

• 8 - JC680A HPE 58x0AF 650W AC Power Supply

Each Switch:

PDU Cable NA/MEX/TW/JP (8 Cables)

JG847A#B2B

• C15 PDU Jumper Cord (NA/MEX/TW/JP) (8 Cables)

PDU Cable ROW (8 Cables)

JG847A#B2C

•

No Power Cord

JG847A #AC3

• No Localized Power Cord Selected

HPE FlexFabric 5900AF 48XGT 4QSFP+ Switch

JG336A

• 48 RJ-45 1/10GbE ports 4 QSFP+ 40-GbE ports (min=0 \ max=4)

See Configuration

HPE 5900AF 48XGT 4QSFP with 4x5900AF 8xPSU 8xF-B Fan Trays and IMC Bundle

JG850A

HPE 5900AF 48XGT 4QSFP FB Bundle

Each Switch:

See Configuration

PDU Cable NA/MEX/TW/JP (8 Cables)

JG850A#B2B

• 8 - JC682A HPE 58x0AF Back (Power Side) to Front (Port Side) Airflow Fan Tray

• 6 - JD097C HPE FlexNetwork X240 10G SFP+ to SFP+ 3m Direct Attach Copper Cable

• 2 - JG081C HPE FlexNetwork X240 10G SFP+ to SFP+ 5m Direct Attach Copper Cable

• 64 - JD092B HPE X130 10G SFP+ LC SR Transceiver

• 48 fixed 1000/10000 SFP+ ports (System Std=20 \ max=48 User min=0 \ max=28)

• 4 QSFP+ 40-GbE ports (min=0 \ max=4)

• 2 Power Supplies Standard (min=2 \ max=2)

• 2 Back to Front Fan Trays Standard (min=2 \ max=2)

• 1U - Height

C15 PDU Jumper Cord (ROW) (8 Cables)

• Must select min 1 Power Supply

• Must select min 2 Fan Tray

• 1U - Height

NOTE: 2, 7

• 4 - JG336A HPE FlexFabric 5900AF 48XGT 4QSFP+ Switch

• 8 - JC680A HPE 58x0AF 650W AC Power Supply

• 8 - JG552A HPE X711 Front (Port Side) to Back (Power Side) Airflow High Volume Fan Tray

• 48 RJ-45 10GbE ports

• 4 QSFP+ 40-GbE ports (min=0 \ max=4)

• 2 Power Supplies Standard (min=2 \ max=2)

• 2 Front to Back Fan Trays Standard (min=2 \ max=2)

• 1U - Height

NOTE:2, 6

Page

QuickSpecs

HPE FlexFabric 5900 Switch Series

Configuration

• C15 PDU Jumper Cord (NA/MEX/TW/JP) (8 Cables)

PDU Cable ROW (8 Cables)

JG850A#B2C

• C15 PDU Jumper Cord (ROW) (8 Cables)

No Power Cord

JG850A #AC3

• No Localized Power Cord Selected

HPE 5900AF 48XGT 4QSFP with 4x5900AF 8xPSU 8xB-F Fan Trays and IMC Bundle

JG851A

HPE 5900AF 48XGT 4QSFP BF Bundle

Each Switch:

See Configuration

PDU Cable NA/MEX/TW/JP (8 Cables)

JG851A#B2B

• C15 PDU Jumper Cord (NA/MEX/TW/JP) (8 Cables)

PDU Cable ROW (8 Cables)

JG851A#B2C

• C15 PDU Jumper Cord (ROW) (8 Cables)

No Power Cord

JG851A #AC3

•

HPE FlexFabric 5900AF 48G 4XG 2QSFP+ Switch

JG510A

• 48 autosensing 10/100/1000 ports (RJ45)

See Configuration

HPE 5900AF 48G 4XG 2QSFP with 4x5900AF 8xPSU 8xF-B Fan Trays 32x10G SR Optics and IMC Bundle

JG848A

• 4 - JG336A HPE FlexFabric 5900AF 48XGT 4QSFP+ Switch

• 8 - JC680A HPE 58x0AF 650W AC Power Supply

• 8 - JC553A HP X712 Bck(pwr)-Frt(ports) HV Fan Tray

NOTE: 2, 6

• 48 RJ-45 10GbE ports

• 4 QSFP+ 40-GbE ports (min=0 \ max=4)

• 2 Power Supplies Standard (min=2 \ max=2)

• 2 Back to Front Fan Trays Standard (min=2 \ max=2)

• 1U - Height

No Localized Power Cord Selected

• 4 fixed 1000/10000 SFP+ ports (min=0 \ max=4)

• 2 QSFP+ 40-GbE ports (min=0 \ max=2)

• Must select min 1 Power Supply

• Must select min 2 Fan Tray

• 1U - Height

NOTE: 1, 2, 8

Page

QuickSpecs

HPE FlexFabric 5900 Switch Series

Configuration

HPE 5900AF 48G 4XG 2QSFP FB Bdl

Each Switch:

See Configuration

PDU Cable NA/MEX/TW/JP (8 Cables)

JG848A#B2B

• C15 PDU Jumper Cord (NA/MEX/TW/JP) (8 Cables)

PDU Cable ROW (8 Cables)

JG848A#B2C

• C15 PDU Jumper Cord (ROW) (8 Cables)

No Power Cord

JG848A #AC3

• No Localized Power Cord Selected

HPE 5900AF-48G-4XG-2QSFP B-F Bundle

JG849A

HPE 5900AF-48G-4XG-2QSFP B-F 4xUnt Bundle

Each Switch:

See Configuration

PDU Cable NA/MEX/TW/JP (8 Cables)

JG849A#B2B

• 4 - JG510A HPE FlexFabric 5900AF 48G 4XG 2QSFP+ Switch

• 8 - JC680A HPE 58x0AF 650W AC Power Supply

• 8 - JC683A HPE 58x0AF Front (Port Side) to Back (Power Side) Airflow Fan Tray

• 32 - JD092B HPE X130 10G SFP+ LC SR Transceiver

(16 Transceivers for the 4 Switches and 16 additional)

• 48 autosensing 10/100/1000 ports (RJ45)

• 4 fixed 1000/10000 SFP+ ports (System Std=4 \ max=4 User min=0 \ max=0)

• 2 QSFP+ 40-GbE ports (min=0 \ max=2)

• 2 Power Supplies Standard (min=2 \ max=2)

• 2 Front to Back Fan Trays Standard (min=2 \ max=2)

• 1U - Height

NOTE:1, 2, 6

• 4 - JG510A HPE FlexFabric 5900AF 48G 4XG 2QSFP+ Switch

• 8 - JC680A HPE 58x0AF 650W AC Power Supply

• 8 - JC682A HPE 58x0AF Back (Power Side) to Front (Port Side) Airflow Fan Tray

• 32 - JD092B HPE X130 10G SFP+ LC SR Transceiver

(16 Transceivers for the 4 Switches and 16 additional)

NOTE: 1, 2, 6

• 48 autosensing 10/100/1000 ports (RJ45)

• 4 fixed 1000/10000 SFP+ ports(System Std=4 \ max=4 User min=0 \ max=0)

• 2 QSFP+ 40-GbE ports (min=0 \ max=2)

• 2 Power Supplies Standard (min=2 \ max=2)

• 2 Back to Front Fan Trays Standard (min=2 \ max=2)

• 1U - Height

Page

QuickSpecs

HPE FlexFabric 5900 Switch Series

Configuration

• C15 PDU Jumper Cord (NA/MEX/TW/JP) (8 Cables)

PDU Cable ROW (8 Cables)

JG849A#B2C

• C15 PDU Jumper Cord (ROW) (8 Cables)

Configuration Rules:

Note 1

The following Transceivers install into this switch:

HPE X130 10G SFP+ LC SR Transceiver

JD092B

HPE X130 10G SFP+ LC LRM Transceiver

JD093B

HPE X130 10G SFP+ LC LR Transceiver

JD094B

HPE X130 10G SFP+ LC SR Data Center Transceiver

JL437A

HPE X130 10G SFP+ LC LRM Data Center Transceiver

JL438A

HPE X130 10G SFP+ LC LR Data Center Transceiver

JL439A

HPE X130 10G SFP+ LC ER 40km Transceiver

JG234A

HPE FlexNetwork X240 10G SFP+ to SFP+ 0.65m Direct Attach Copper Cable

JD095C

HPE FlexNetwork X240 10G SFP+ to SFP+ 1.2m Direct Attach Copper Cable

JD096C

HPE FlexNetwork X240 10G SFP+ to SFP+ 3m Direct Attach Copper Cable

JD097C

HPE FlexNetwork X240 10G SFP+ to SFP+ 5m Direct Attach Copper Cable

JG081C

HPE FlexNetwork X240 10G SFP+ SFP+ 7m Direct Attach Copper Cable

JC784C

HPE X125 1G SFP LC LH40 1310nm Transceiver

JD061A

HPE X120 1G SFP LC LH40 1550nm Transceiver

JD062A

HPE X125 1G SFP LC LH70 Transceiver

JD063B

HPE X120 1G SFP RJ45 T Transceiver

JD089B

HPE X120 1G SFP LC SX Transceiver

JD118B

HPE X120 1G SFP LC LX Transceiver

JD119B

Note 2

The following 40G Transceivers install into this switch:

HPE X140 40G QSFP+ LC LR4 SM 10km 1310nm Transceiver

JG661A

HPE X140 40G QSFP+ LC BiDi 100m MM Transceiver

JL251A

HPE X140 40G QSFP+ MPO SR4 Transceiver

JG325B

HPE X140 40G QSFP+ MPO MM 850nm CSR4 300m Transceiver

JG709A

HPE FlexNetwork X240 40G QSFP+ QSFP+ 1m Direct Attach Copper Cable

JG326A

HPE FlexNetwork X240 40G QSFP+ QSFP+ 3m Direct Attach Copper Cable

JG327A

HPE FlexNetwork X240 40G QSFP+ QSFP+ 5m Direct Attach Copper Cable

JG328A

HPE FlexNetwork X240 40G QSFP+ to 4x10G SFP+ 1m Direct Attach Copper Splitter Cable

JG329A

HPE FlexNetwork X240 40G QSFP+ to 4x10G SFP+ 3m Direct Attach Copper Splitter Cable

JG330A

HPE FlexNetwork X240 40G QSFP+ to 4x10G SFP+ 5m Direct Attach Copper Splitter Cable

JG331A

Note 4 The following 10G Transceivers install into this switch:

HPE X130 10G SFP+ LC LH80 Tunable Transceiver

JL250A

Note 6

Localization (Wall Power Cord) required on orders without #B2B, #B2C (PDU Power Cord). (See Localization Menu)

Page

QuickSpecs

HPE FlexFabric 5900 Switch Series

Configuration

Note 7

The following 40G Transceivers install into this switch:

HPE X2A0 40G QSFP+ to QSFP+ 7m Active Optical Cable

JL287A

HPE X2A0 40G QSFP+ to QSFP+ 10m Active Optical Cable

JL288A

HPE X2A0 40G QSFP+ to QSFP+ 20m Active Optical Cable

JL289A

Note 8

The following 10G Transceivers install into this Module's SFP+ Ports:

HPE X2A0 10G SFP+ to SFP+ 7m Active Optical Cable

JL290A

HPE X2A0 10G SFP+ to SFP+ 10m Active Optical Cable

JL291A

HPE X2A0 10G SFP+ to SFP+ 20m Active Optical Cable

JL292A

Box Level Integration CTO Models

CTO Solution Sku

HPE 59xx Configure to order Switch Solution

JG505A

• SSP trigger sku

CTO Switch Chassis

HPE FlexFabric 5900AF 48XG 4QSFP+ Switch

JC772A

• 48 fixed 1000/10000 SFP+ ports (min=0 \ max=48)

See Configuration

HPE FlexFabric 5900AF 48XGT 4QSFP+ Switch

JG336A

• 48 RJ-45 1/10GbE ports

See Configuration

HPE FlexFabric 5900AF 48G 4XG 2QSFP+ Switch

JG510A

• 48 autosensing 10/100/1000 ports (RJ45)

See Configuration

Configuration Rules:

Note 1

The following Transceivers install into this switch: (Use #0D1 or #B01 quoted to switch if switch is CTO) - if applicable

HPE X130 10G SFP+ LC SR Transceiver

JD092B

HPE X130 10G SFP+ LC LRM Transceiver

JD093B

• 4 QSFP+ 40-GbE ports (min=0 \ max=4)

• Must select min 1 Power Supply

• Must select min 2 Fan Tray

• 1U - Height

• 4 QSFP+ 40-GbE ports (min=0 \ max=4)

• min=0 \ max=4 QSFP+ Transceivers

• Must select min 1 Power Supply

• Must select min 2 Fan Tray

• 1U - Height

• 4 fixed 1000/10000 SFP+ ports (min=0 \ max=4)

• 2 QSFP+ 40-GbE ports (min=0 \ max=2)

• Must select min 1 Power Supply

• Must select min 2 Fan Tray

• 1U - Height

NOTE: 1, 2, 5, 6, 10

NOTE: 2, 5, 10

NOTE: 1, 2, 6, 10

Page

QuickSpecs

HPE FlexFabric 5900 Switch Series

Configuration

HPE X130 10G SFP+ LC LR Transceiver

JD094B

HPE X130 10G SFP+ LC SR Data Center Transceiver

JL437A

HPE X130 10G SFP+ LC LRM Data Center Transceiver

JL438A

HPE X130 10G SFP+ LC LR Data Center Transceiver

JL439A

HPE X130 10G SFP+ LC ER 40km Transceiver

JG234A

HPE FlexNetwork X240 10G SFP+ to SFP+ 0.65m Direct Attach Copper Cable

JD095C

HPE FlexNetwork X240 10G SFP+ to SFP+ 1.2m Direct Attach Copper Cable

JD096C

HPE FlexNetwork X240 10G SFP+ to SFP+ 3m Direct Attach Copper Cable

JD097C

HPE FlexNetwork X240 10G SFP+ to SFP+ 5m Direct Attach Copper Cable

JG081C

HPE FlexNetwork X240 10G SFP+ SFP+ 7m Direct Attach Copper Cable

JC784C

HPE X125 1G SFP LC LH40 1310nm Transceiver

JD061A

HPE X120 1G SFP LC LH40 1550nm Transceiver

JD062A

HPE X125 1G SFP LC LH70 Transceiver

JD063B

HPE X120 1G SFP RJ45 T Transceiver

JD089B

HPE X120 1G SFP LC SX Transceiver

JD118B

HPE X120 1G SFP LC LX Transceiver

JD119B

Note 2

The following 40G Transceivers install into this switch: (Use #0D1 or #B01 quoted to switch if switch is CTO) - if applicable

HPE X140 40G QSFP+ LC LR4 SM 10km 1310nm Transceiver

JG661A

HPE X140 40G QSFP+ LC BiDi 100m MM Transceiver

JL251A

HPE X140 40G QSFP+ MPO SR4 Transceiver

JG325B

HPE X140 40G QSFP+ MPO MM 850nm CSR4 300m Transceiver

JG709A

HPE FlexNetwork X240 40G QSFP+ QSFP+ 1m Direct Attach Copper Cable

JG326A

HPE FlexNetwork X240 40G QSFP+ QSFP+ 3m Direct Attach Copper Cable

JG327A

HPE FlexNetwork X240 40G QSFP+ QSFP+ 5m Direct Attach Copper Cable

JG328A

HPE FlexNetwork X240 40G QSFP+ to 4x10G SFP+ 1m Direct Attach Copper Splitter Cable

JG329A

HPE FlexNetwork X240 40G QSFP+ to 4x10G SFP+ 3m Direct Attach Copper Splitter Cable

JG330A

HPE FlexNetwork X240 40G QSFP+ to 4x10G SFP+ 5m Direct Attach Copper Splitter Cable

JG331A

Note 3

The following FC Transceivers install into this switch: (Use #0D1 or #B01 quoted to switch if switch is CTO)

HPE StoreFabric 16Gb FC/10GbE 100m SR SFP+ Transceiver

H6Z42A

HPE 8Gb Short Wave Fibre Channel SFP+ 1 Pack

AJ718A

HPE 8Gb Long Wave 10km Fibre Channel SFP+ 1 Pack Transceiver

AW584A

Note 5

The following 40G Transceivers install into this switch: (Use #0D1 or #B01 quoted to switch if switch is CTO) - if applicable

HPE X2A0 40G QSFP+ to QSFP+ 7m Active Optical Cable

JL287A

HPE X2A0 40G QSFP+ to QSFP+ 10m Active Optical Cable

JL288A

HPE X2A0 40G QSFP+ to QSFP+ 20m Active Optical Cable

JL289A

Note 6

The following 10G Transceivers install into this Module's SFP+ Ports: (Use #0D1 or #B01 if switch is CTO) - if applicable

HPE X2A0 10G SFP+ to SFP+ 7m Active Optical Cable

JL290A

HPE X2A0 10G SFP+ to SFP+ 10m Active Optical Cable

JL291A

HPE X2A0 10G SFP+ to SFP+ 20m Active Optical Cable

JL292A

- if applicable

Page

QuickSpecs

HPE FlexFabric 5900 Switch Series

Configuration

Note 10

If the Switch Chassis is to be Box Level Factory Integrated (CTO), Then the #0D1 is required on the Switch Chassis and integrated to the JG505A per SSP)

Remarks:

Clic UNB - If an option is ordered with #0D1/#B01, then the switch must have #0D1 option.

Rack Level Integration CTO Models

CTO Switch Chassis

HPE FlexFabric 5900AF 48XG 4QSFP+ Switch

JC772A

• 48 fixed 1000/10000 SFP+ ports (min=0 \ max=48)

See Configuration

HPE FlexFabric 5900AF 48XGT 4QSFP+ Switch

JG336A

• 48 RJ-45 1/10GbE ports

See Configuration

HPE FlexFabric 5900AF 48G 4XG 2QSFP+ Switch

JG510A

• 48 autosensing 10/100/1000 ports (RJ45)

See Configuration

Configuration Rules:

Note 1

The following Transceivers install into this switch: (Use #0D1 or #B01 quoted to switch if switch is CTO) - if applicable

HPE X130 10G SFP+ LC SR Transceiver

JD092B

HPE X130 10G SFP+ LC LRM Transceiver

JD093B

HPE X130 10G SFP+ LC LR Transceiver

JD094B

HPE X130 10G SFP+ LC SR Data Center Transceiver

JL437A

HPE X130 10G SFP+ LC LRM Data Center Transceiver

JL438A

HPE X130 10G SFP+ LC LR Data Center Transceiver

JL439A

HPE X130 10G SFP+ LC ER 40km Transceiver

JG234A

HPE FlexNetwork X240 10G SFP+ to SFP+ 0.65m Direct Attach Copper Cable

JD095C

HPE FlexNetwork X240 10G SFP+ to SFP+ 1.2m Direct Attach Copper Cable

JD096C

HPE FlexNetwork X240 10G SFP+ to SFP+ 3m Direct Attach Copper Cable

JD097C

HPE FlexNetwork X240 10G SFP+ to SFP+ 5m Direct Attach Copper Cable

JG081C

HPE FlexNetwork X240 10G SFP+ SFP+ 7m Direct Attach Copper Cable

JC784C

HPE X125 1G SFP LC LH40 1310nm Transceiver

JD061A

- HPE 59xx Configure to order Switch Solution. (Min 1/Max 1 Switch

• 4 QSFP+ 40-GbE ports (min=0 \ max=4)

• Must select min 1 Power Supply

• Must select min 2 Fan Tray

• 1U - Height

• 4 QSFP+ 40-GbE ports (min=0 \ max=4)

• min=0 \ max=4 QSFP+ Transceivers

• Must select min 1 Power Supply

• Must select min 2 Fan Tray

• 1U - Height

• 4 fixed 1000/10000 SFP+ ports (min=0 \ max=4)

• 2 QSFP+ 40-GbE ports (min=0 \ max=2)

• Must select min 1 Power Supply

• Must select min 2 Fan Tray

• 1U - Height

NOTE: 1, 2, 4, 5, 11

NOTE:2, 4, 11

NOTE: 1, 2, 5, 11

Page

QuickSpecs

HPE FlexFabric 5900 Switch Series

Configuration

HPE X120 1G SFP LC LH40 1550nm Transceiver

JD062A

HPE X125 1G SFP LC LH70 Transceiver

JD063B

HPE X120 1G SFP RJ45 T Transceiver

JD089B

HPE X120 1G SFP LC SX Transceiver

JD118B

HPE X120 1G SFP LC LX Transceiver

JD119B

Note 2

The following 40G Transceivers install into this switch: (Use #0D1 or #B01 quoted to switch if switch is CTO) - if applicable

HPE X140 40G QSFP+ LC LR4 SM 10km 1310nm Transceiver

JG661A

HPE X140 40G QSFP+ LC BiDi 100m MM Transceiver

JL251A

HPE X140 40G QSFP+ MPO SR4 Transceiver

JG325B

HPE X140 40G QSFP+ MPO MM 850nm CSR4 300m Transceiver

JG709A

HPE FlexNetwork X240 40G QSFP+ QSFP+ 1m Direct Attach Copper Cable

JG326A

HPE FlexNetwork X240 40G QSFP+ QSFP+ 3m Direct Attach Copper Cable

JG327A

HPE FlexNetwork X240 40G QSFP+ QSFP+ 5m Direct Attach Copper Cable

JG328A

HPE FlexNetwork X240 40G QSFP+ to 4x10G SFP+ 1m Direct Attach Copper Splitter Cable

JG329A

HPE FlexNetwork X240 40G QSFP+ to 4x10G SFP+ 3m Direct Attach Copper Splitter Cable

JG330A

HPE FlexNetwork X240 40G QSFP+ to 4x10G SFP+ 5m Direct Attach Copper Splitter Cable

JG331A

Note 3

The following FC Transceivers install into this switch: (Use #0D1 or #B01 quoted to switch if

HPE StoreFabric 16Gb FC/10GbE 100m SR SFP+ Transceiver

H6Z42A

HPE 8Gb Short Wave Fibre Channel SFP+ 1 Pack

AJ718A

HPE 8Gb Long Wave 10km Fibre Channel SFP+ 1 Pack Transceiver

AW584A

Note 4

The following 40G Transceivers install into this switch: (Use #0D1 or #B01 quoted to switch if switch is CTO) - if applicable

HPE X2A0 40G QSFP+ to QSFP+ 7m Active Optical Cable

JL287A

HPE X2A0 40G QSFP+ to QSFP+ 10m Active Optical Cable

JL288A

HPE X2A0 40G QSFP+ to QSFP+ 20m Active Optical Cable

JL289A

Note 5

The following 10G Transceivers install into this Module's SFP+ Ports: (Use #0D1 or #B01 if switch is CTO) - if applicable

HPE X2A0 10G SFP+ to SFP+ 7m Active Optical Cable

JL290A

HPE X2A0 10G SFP+ to SFP+ 10m Active Optical Cable

JL291A

HPE X2A0 10G SFP+ to SFP+ 20m Active Optical Cable

JL292A

Note 11

If HPE CTO Switch Chassis is selected for Rack Level Integration, Then the Switch needs to integrate (with #0D1) to the Rack.

Remarks:

Clic UNB - If an option is ordered with #0D1/#B01, then the switch must have #0D1 option.

Enter the following menu selections as integrated to the CTO Model X server above if order is factory built.

Transceivers

SFP Transceivers

switch is CTO) - if applicable

Page

QuickSpecs

HPE FlexFabric 5900 Switch Series

Configuration

HPE X125 1G SFP LC LH40 1310nm Transceiver

JD061A

HPE X120 1G SFP LC LH40 1550nm Transceiver

JD062A

HPE X125 1G SFP LC LH70 Transceiver

JD063B

HPE X120 1G SFP RJ45 T Transceiver

JD089B

HPE X120 1G SFP LC SX Transceiver

JD118B

HPE X120 1G SFP LC LX Transceiver

JD119B

SFP+ Transceivers

HPE X130 10G SFP+ LC SR Transceiver

JD092B

HPE X130 10G SFP+ LC LRM Transceiver

JD093B

HPE X130 10G SFP+ LC LR Transceiver

JD094B

HPE X130 10G SFP+ LC SR Data Center Transceiver

JL437A

HPE X130 10G SFP+ LC LRM Data Center Transceiver

JL438A

HPE X130 10G SFP+ LC LR Data Center Transceiver

JL439A

HPE X130 10G SFP+ LC LH80 Tunable Transceiver

JL250A

HPE FlexNetwork X240 10G SFP+ to SFP+ 0.65m Direct Attach Copper Cable

JD095C

HPE FlexNetwork X240 10G SFP+ to SFP+ 1.2m Direct Attach Copper Cable

JD096C

HPE FlexNetwork X240 10G SFP+ to SFP+ 3m Direct Attach Copper Cable

JD097C

HPE FlexNetwork X240 10G SFP+ to SFP+ 5m Direct Attach Copper Cable

JG081C

HPE FlexNetwork X240 10G SFP+ SFP+ 7m Direct Attach Copper Cable

JC784C

HPE X130 10G SFP+ LC ER 40km Transceiver

JG234A

HPE X2A0 10G SFP+ to SFP+ 7m Active Optical Cable

JL290A

HPE X2A0 10G SFP+ to SFP+ 10m Active Optical Cable

JL291A

HPE X2A0 10G SFP+ to SFP+ 20m Active Optical Cable

JL292A

QSFP+ Transceivers

HPE X140 40G QSFP+ LC LR4 SM 10km 1310nm Transceiver

JG661A

HPE X140 40G QSFP+ LC BiDi 100m MM Transceiver

JL251A

HPE X140 40G QSFP+ MPO SR4 Transceiver

JG325B

HPE X140 40G QSFP+ MPO MM 850nm CSR4 300m Transceiver

JG709A

HPE FlexNetwork X240 40G QSFP+ QSFP+ 1m Direct Attach Copper Cable

JG326A

HPE FlexNetwork X240 40G QSFP+ QSFP+ 3m Direct Attach Copper Cable

JG327A

HPE FlexNetwork X240 40G QSFP+ QSFP+ 5m Direct Attach Copper Cable

JG328A

HPE FlexNetwork X240 40G QSFP+ to 4x10G SFP+ 1m Direct Attach Copper Splitter Cable

JG329A

HPE FlexNetwork X240 40G QSFP+ to 4x10G SFP+ 3m Direct Attach Copper Splitter Cable

JG330A

HPE FlexNetwork X240 40G QSFP+ to 4x10G SFP+ 5m Direct Attach Copper Splitter Cable

JG331A

HPE X2A0 40G QSFP+ to QSFP+ 7m Active Optical Cable

JL287A

HPE X2A0 40G QSFP+ to QSFP+ 10m Active Optical Cable

JL288A

HPE X2A0 40G QSFP+ to QSFP+ 20m Active Optical Cable

JL289A

Cables

MPO Cables

HPE Multi Fiber Push On to 4 x Lucent Connector 5m Cable (Recommended)

K2Q46A

HPE Multi Fiber Push On to 4 x Lucent Connector 15m Cable (Recommended)

K2Q47A

HPE Premier Flex MPO/MPO Multi-mode OM4 12 fiber 10m Cable (Recommended)

QK729A

HPE Premier Flex MPO/MPO Multi-mode OM4 8 fiber 50m Cable (Recommended)

QK731A

HPE Premier Flex MPO/MPO OM4 100m (12ft) Cable (Recommended)

H6Z30A

Page

QuickSpecs

HPE FlexFabric 5900 Switch Series

Configuration

Internal Power Supplies

(JC772A, JG336A and JG510A) System (std 0 // max 2) User Selection (min 1 // max 2) per switch

(JG846A, JG847A, JG850A, JG851A, JG848A and JG849A) System (std 2 // max 2) User Selection (min 0 // max 0) per switch

HPE 58x0AF 650W AC Power Supply

JC680A

• includes 1 x c13, 300w

See Configuration

PDU Cable NA/MEX/TW/JP

JC680A#B2B

• C15 PDU Jumper Cord (NA/MEX/TW/JP)

PDU Cable ROW

JC680A#B2C

• C15 PDU Jumper Cord (ROW)

HPE A58x0AF Back (Power Side) to Front (Port Side) Airflow 300W AC Power Supply

JG900A

•

See Configuration

NOTE: 1, 3, 5

PDU Cable NA/MEX/TW/JP

JG900A#B2B

• C15 PDU Jumper Cord (ROW)

High Volt Switch/Router to Wall Power Cord

JG900A#B2E

• C15 PDU Jumper Cord (ROW)

HPE A58x0AF Back (Power Side) to Front (Port Side) Airflow 300W DC Power Supply

JG901A

See Configuration

HPE FlexFabric Switch 650W 48V Hot Plug NEBS-compliant DC Power Supply

JH336A

See Configuration

Configuration Rules

Note 1

If 2 power supplies are selected they must be the same SKU number.

Note 2

Localization (Wall Power Cord) required on orders without #B2B, #B2C (PDU Power Cord) . (See Localization Menu) REMARK: When Switches/Routers are Factory Racked, Then #B2B, or #B2C should be the Defaulted Power Cable option on the Switches/Routers.

Note 3

Only supported on JC772A and JG510A.

Note 4

Only supported on JG336A, JC772A and JG510A.

NOTE: 1, 2, 4

C15 PDU Jumper Cord (NA/MEX/TW/JP)

NOTE: 1, 3, 6

NOTE: 1, 4

Page

QuickSpecs

HPE FlexFabric 5900 Switch Series

Configuration

Note 5

Localization (Wall Power Cord) required on orders without #B2B, #B2C (PDU Power Cord) or #B2E. (See Localization Menu) Defaulted Power Cable option on the Switches/Routers.

Note 6

Watson Only - Add "(NEBS)" after the description on the PS table

Remarks:

Drop down under power supply should offer the following options and results: Switch/Router/Power Supply to PDU Power Cord #B2C ROW. (Watson Default B2B or B2C for Rack Level CTO) Switch/Router/Power Supply to Wall Power Cord CTO) High Volt Power Electrical Module to Wall Power Cord

#B2E Option. (Offered only in North America, Mexico,

Taiwan, and Japan)

NOTE* Switches JC772A and JG510A should default selection of Power Supply as JC680A but allow selection of JG900A and JG901A

Switch Options

Fan Trays

(JC772A, JG336A and JG510A) System (std 0 // max 2) User Selection (min 2 // max 2) per switch

(JG846A, JG847A, JG850A, JG851A, JG848A and JG849A) System (std 2 // max 2) User Selection (min 0 // max 0) per switch

HPE 58x0AF Back (Power Side) to Front (Port Side) Airflow Fan Tray

JC682A

See Configuration

NOTE: 1, 3

HPE 58x0AF Front (Port Side) to Back (Power Side) Airflow Fan Tray

JC683A

See Configuration

NOTE: 1, 3

HPE X711 Front (Port Side) to Back (Power Side) Airflow High Volume Fan Tray

JG552A

See Configuration

NOTE: 1, 4

HPE X712 Back (Power Side) to Front (Port Side) Airflow High Volume Fan Tray

JG553A

See Configuration

NOTE: 1, 4

Configuration Rules

Note 1

Fan Trays cannot be mixed in the same switch enclosure

Note 3

Only supported on JC772A and JG510A.

Note 4

Only supported on JC772A, JG510A and JG336A.

Remarks:

Watson Blue Text: If there is any empty space below the switch in a rack when using Back to Front Fan Trays, JC682A, the rack will receive an Air Plenum kit that takes up 1U of additional space in the rack. The Air Plenum kit is not required on fully configured racks. This only applies for CTO Rack Level Integration. The Air Plenum Kit is a non Factory Rack Level Integration.

REMARK: When Switches/Routers are Factory Racked, Then #B2B, #B2C should be the

- #B2B in North America, Mexico, Taiwan, and Japan or

- Localized Option (Watson Default for BTO and Box Level

-saleable SKU, and is brought in automatically for CTO

Page

QuickSpecs

HPE FlexFabric 5900 Switch Series

Configuration

Page

QuickSpecs

HPE FlexFabric 5900 Switch Series

Technical Specifications

HPE FlexFabric 5900AF 48XG 4QSFP+ Switch (JC772A)

I/O ports and slots

48 fixed 1000/10000 SFP+ ports 4 QSFP+ 40-GbE ports

Additional ports and

1 RJ-45 serial console port

1 USB 2.0

Power supplies

2 power supply slots 1 minimum power supply required (ordered separately)

Fan tray

2 fan tray slots

requirements may void the product warranty.

Physical characteristics

Dimensions

17.32(w) x 25.98(d) x 1.72(h) in (43.99 x 65.99 x 4.37 cm)

Weight

28.66 lb (13 kg) shipping weight

Memory and processor

512 MB flash; Packet buffer size: 9 MB, 2 GB SDRAM

Performance

10 Gbps Latency

Throughput

up to 952 Mpps

Routing/Switching capacity

1280 Gbps

Routing table size

16000 entries (IPv4), 8000 entries (IPv6)

MAC address table size

128000 entries

Environment

Operating temperature

32°F to 113°F (0°C to 45°C)

Operating relative humidity

10% to 90%, noncondensing

Acoustic

Low-speed fan: 65.7 dB, High-speed fan: 70.6 dB

Electrical characteristics

Frequency

50/60 Hz

Maximum heat dissipation

887 BTU/hr (935.79 kJ/hr)

Voltage

100 - 240 VAC, rated

(depending on power supply chosen)

Maximum power rating

260 W

Idle power

200 W

Notes

Idle power is the actual power consumption of the device with no ports

with fully loaded PoE (if equipped), 100% traffic, all ports plugged in, and all modules populated.

Safety

UL 60950-1; EN 60825-1 Safety of Laser Products-Part 1; EN 60825-2 Safety of Laser Products-Part

Subchapter J; NOM; ROHS Compliance

Emissions

VCCI Class A; EN 55022 Class A; ICES-003 Class A; ANSI C63.4 2003; AS/NZS CISPR 22 Class A; EN

47, Part 15) Class A

slots

1 RJ-45 out-of-band management port

The customer must order fan trays, as fan trays are not included with the switch. This system requires two same-direction airflow fan trays to function properly. The system should not be operated with only one fan tray for more than 24 hours. The system should not be operated without a fan tray for more than two minutes. The system should not be operated outside of the temperature range of 32°F (0°C) to 113°F (45°C). Failure to comply with these operating

< 1.5 µs (64-byte packets)

-40 to -60 VDC, rated

connected. Maximum power rating and maximum heat dissipation are the worst-case theoretical maximum numbers provided for planning the infrastructure

2; IEC 60950-1; CAN/CSA-C22.2 No. 60950-1; Anatel; ULAR; GOST; EN 60950-1/A11; FDA 21 CFR

61000-3-2:2006; EN 61000-3-3:1995 +A1:2001+A2:2005; EMC Directive 2004/108/EC; FCC (CFR

Page

QuickSpecs

HPE FlexFabric 5900 Switch Series

Technical Specifications

Immunity

Generic

ETSI EN 300 386 V1.3.3

EN 55024:1998+ A1:2001 + A2:2003

ESD

EN 61000-4-2; IEC 61000-4-2

Radiated

EN 61000-4-3; IEC 61000-4-3

EFT/Burst

EN 61000-4-4; IEC 61000-4-4

Surge

EN 61000-4-5; IEC 61000-4-5

Conducted

EN 61000-4-6; IEC 61000-4-6

Power frequency magnetic field

IEC 61000-4-8; EN 61000-4-8

Voltage dips and interruptions

EN 61000-4-11; IEC 61000-4-11

Harmonics

EN 61000-3-2, IEC 61000-3-2

Flicker

EN 61000-3-3, IEC 61000-3-3

Management

IMC - Intelligent Management Center; command-line interface; out-of-band management; SNMP

Notes

The customer must order a power supply, as the device does not come with one. At least one JC680A

The HPE FlexFabric 5900AF-48XG-4QSFP+ Switch is NEBS GR-1089-CORE compliant.

Services

Refer to the Hewlett Packard Enterprise sales website at: http://www.hpe.com/networking/services

response times in your area, please contact your local Hewlett Packard Enterprise sales office.

HPE FlexFabric 5900AF 48G 4XG 2QSFP+ Switch (JG510A)

I/O ports and slots

48 autosensing 10/100/1000 ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX,

2 QSFP+ 40-GbE ports

Additional ports and

1 RJ-45 serial console port

1 USB 2.0

Power supplies

2 power supply slots 1 minimum power supply required (ordered separately)

Fan tray

2 fan tray slots

requirements may void the product warranty.

Physical characteristics

Dimensions

17.32(w) x 18.11(d) x 1.72(h) in (43.99 x 46.0 x 4.37 cm) (1U height)

Weight

28.66 lb (13 kg) shipping weight

Memory and processor

512 MB flash; Packet buffer size: 9 MB, 2 GB SDRAM

Performance

10 Gbps Latency

Throughput

up to 250 Mpps (64-byte packets)

Routing/Switching capacity

336 Gbps

Routing table size

16000 entries (IPv4), 8000 entries (IPv6)

MAC address table size

128000 entries

Manager; Telnet; FTP

or JC681A is required.

slots

for details on the service-level descriptions and product numbers. For details about services and

IEEE 802.3ab Type 1000BASE-T) Duplex: 10BASE-T/100BASE-TX: half or full; 1000BASE-T: full only 4 fixed 1000/10000 SFP+ ports

1 RJ-45 out-of-band management port

< 1.5 µs (64-byte packets)

Page

QuickSpecs

HPE FlexFabric 5900 Switch Series

Technical Specifications

Environment

Operating temperature

32°F to 113°F (0°C to 45°C)

Operating relative humidity

10% to 90%, noncondensing

Acoustic

Low-speed fan: 65.7 dB, High-speed fan: 70.6 dB

Electrical characteristics

Frequency

50/60 Hz

Maximum heat dissipation

887 BTU/hr (935.79 kJ/hr)

Voltage

100 - 240 VAC, rated

(depending on power supply chosen)

Maximum power rating

260 W

Idle power

200 W

Notes

Idle power is the actual power consumption of the device with no ports

modules populated.

Safety

UL 60950-1; EN 60825-1 Safety of Laser Products-Part 1; EN 60825-2 Safety of Laser Products-Part

Subchapter J; NOM; ROHS Compliance

Emissions

VCCI Class A; EN 55022 Class A; ICES-003 Class A; ANSI C63.4 2003; AS/NZS CISPR 22 Class A; EN

47, Part 15) Class A

Immunity

Generic

ETSI EN 300 386 V1.3.3

EN 55024:1998+ A1:2001 + A2:2003

ESD

EN 61000-4-2; IEC 61000-4-2

Radiated

EN 61000-4-3; IEC 61000-4-3

EFT/Burst

EN 61000-4-4; IEC 61000-4-4

Surge

EN 61000-4-5; IEC 61000-4-5

Conducted

EN 61000-4-6; IEC 61000-4-6

Power frequency magnetic field

IEC 61000-4-8; EN 61000-4-8

Voltage dips and

EN 61000-4-11; IEC 61000-4-11

Harmonics

EN 61000-3-2, IEC 61000-3-2

Flicker

EN 61000-3-3, IEC 61000-3-3

Management

IMC - Intelligent Management Center; command-line interface; out-of-band management; SNMP Manager; Telnet; FTP

Notes

The customer must order a power supply, as the device does not come with one. At least one JC680A or JC681A is required.

Services

Refer to the Hewlett Packard Enterprise sales website at: http://www.hpe.com/networking/services

response times in your area, please contact your local Hewlett Packard Enterprise sales office.

HPE FlexFabric 5900AF 48XGT 4QSFP+ Switch (JG336A)

-40 to -60 VDC, rated

connected. Maximum power rating and maximum heat dissipation are the worst-case theoretical maximum numbers provided for planning the infrastructure with fully loaded PoE (if equipped), 100% traffic, all ports plugged in, and all

2; IEC 60950-1; CAN/CSA-C22.2 No. 60950-1; Anatel; ULAR; GOST; EN 60950-1/A11; FDA 21 CFR

61000-3-2:2006; EN 61000-3-3:1995 +A1:2001+A2:2005; EMC Directive 2004/108/EC; FCC (CFR

interruptions

for details on the service-level descriptions and product numbers. For details about services and

Page

QuickSpecs

HPE FlexFabric 5900 Switch Series

Technical Specifications

I/O ports and slots

48 RJ-45 1/10GbE ports (IEEE 802.3an-2006 Type 10GBASE-T and IEEE 802.3ab-2008 Type

4 QSFP+ 40-GbE ports

Additional ports and

1 RJ-45 serial console port

1 USB 2.0

Power supplies

2 power supply slots 1 minimum power supply required (ordered separately)

Fan tray

2 fan tray slots

requirements may void the product warranty.

Physical characteristics

Dimensions

17.32(w) x 25.98(d) x 1.72(h) in (43.99 x 65.99 x 4.37 cm)

Weight

28.66 lb (13 kg) shipping weight

Memory and processor

512 MB flash; Packet buffer size: 9 MB, 2 GB SDRAM

Performance

10 Gbps Latency

< 1.5 µs (64-byte packets)

Throughput

up to 952 Mpps

Routing/Switching capacity

1280 Gbps

Routing table size

16000 entries (IPv4), 8000 entries (IPv6)

MAC address table size

128000 entries

Environment

Operating temperature

32°F to 113°F (0°C to 45°C)

Operating relative humidity

10% to 90%, noncondensing

Acoustic

Low-speed fan: 65.7 dB, High-speed fan: 70.6 dB

Electrical characteristics

Frequency

50/60 Hz

Maximum heat dissipation

887 BTU/hr (935.79 kJ/hr)

Voltage

100 - 240 VAC, rated

(depending on power supply chosen)

Maximum power rating

260 W

Idle power

200 W

Notes

Idle power is the actual power consumption of the device with no ports

ed PoE (if equipped), 100% traffic, all ports plugged in, and all

modules populated.

Safety

UL 60950-1; EN 60825-1 Safety of Laser Products-Part 1; EN 60825-2 Safety of Laser Products-Part

Emissions

VCCI Class A; EN 55022 Class A; ICES-003 Class A; ANSI C63.4 2003; AS/NZS CISPR 22 Class A; EN

47, Part 15) Class A

Immunity

Generic

ETSI EN 300 386 V1.3.3

1000BASE-T)

slots

1 RJ-45 out-of-band management port

-40 to -60 VDC, rated

connected. Maximum power rating and maximum heat dissipation are the worst-case theoretical maximum numbers provided for planning the infrastructure with fully load

2; IEC 60950-1; CAN/CSA-C22.2 No. 60950-1; Anatel; ULAR; GOST; EN 60950-1/A11; FDA 21 CFR Subchapter J; NOM; ROHS Compliance

61000-3-2:2006; EN 61000-3-3:1995 +A1:2001+A2:2005; EMC Directive 2004/108/EC; FCC (CFR

Page

QuickSpecs

HPE FlexFabric 5900 Switch Series

Technical Specifications

EN 55024:1998+ A1:2001 + A2:2003

ESD

EN 61000-4-2; IEC 61000-4-2

Radiated

EN 61000-4-3; IEC 61000-4-3

EFT/Burst

EN 61000-4-4; IEC 61000-4-4

Surge

EN 61000-4-5; IEC 61000-4-5

Conducted

EN 61000-4-6; IEC 61000-4-6

Power frequency magnetic field

IEC 61000-4-8; EN 61000-4-8

Voltage dips and

EN 61000-4-11; IEC 61000-4-11

Harmonics

EN 61000-3-2, IEC 61000-3-2

Flicker

EN 61000-3-3, IEC 61000-3-3

Management

IMC - Intelligent Management Center; command-line interface; out-of-band management; SNMP Manager; Telnet; FTP

Notes

The customer must order a power supply, as the device does not come with one. At least one JC680A or JC681A is required.

Services

Refer to the Hewlett Packard Enterprise sales website at: http://www.hpe.com/networking/services

response times in your area, please contact your local Hewlett Packard Enterprise sales office.

HPE FlexFabric 5900 48XG 4QSFP+ Short Form Factor Switch (JH337A)

I/O ports and slots

48 fixed 1000/10000 SFP+ ports; PHY-less 4 QSFP+; PHY-less

Additional ports and

1 RJ-45 serial console port

1 USB 2.0

Power supplies

2 power supply slots 1 minimum power supply required (ordered separately)

Fan tray

2 fan tray slots

direction airflow fan trays to function properly. The system should not be operated with only

to 113°F (45°C). Failure to comply with these operating requirements may void the product warranty

Physical characteristics

Dimensions

17.32(w) x 18.11(d) x 1.72(h) in (44 x 46 x 4.37 cm)

Weight

24.25 lb (11 kg) shipping weight

Memory and processor

512 MB flash; Packet buffer size: 9 MB, 2 GB SDRAM

Performance

10 Gbps Latency

Throughput

up to 952 Mpps

Routing/Switching capacity

1280 Gbps

Routing table size

16000 entries (IPv4), 8000 entries (IPv6)

MAC address table size

128000 entries

Environment

Operating temperature

32°F to 113°F (0°C to 45°C)

Operating relative humidity

10% to 90%, noncondensing

Acoustic

Low-speed fan: 65.7 dB, High-speed fan: 70.6 dB

interruptions

for details on the service-level descriptions and product numbers. For details about services and

slots

1 RJ-45 out-of-band management port

The customer must order fan trays, as fan trays are not included with the switch. This system requires two sameone fan tray for more than 24 hours. The system should not be operated without a fan tray for more than two minutes. The system should not be operated outside of the temperature range of 32°F (0°C)

< 1.5 µs (64-byte packets)

Page

QuickSpecs

HPE FlexFabric 5900 Switch Series

Technical Specifications

Electrical characteristics

Frequency

50/60 Hz

Maximum heat dissipation

887 BTU/hr (935.79 kJ/hr)

Voltage

100 - 240 VAC, rated

(depending on power supply chosen)

Maximum power rating

196 W

Idle power

106 W

Notes

Idle power is the actual power consumption of the device with no ports

modules populated.

Safety

UL 60950-1; EN 60825-1 Safety of Laser Products-Part 1; EN 60825-2 Safety of Laser Products-Part

Subchapter J; NOM; ROHS Compliance

Emissions

VCCI Class A; EN 55022 Class A; ICES-003 Class A; ANSI C63.4 2003; AS/NZS CISPR 22 Class A; EN

47, Part 15) Class A

Immunity

Generic

ETSI EN 300 386 V1.3.3

EN 55024:1998+ A1:2001 + A2:2003

ESD

EN 61000-4-2; IEC 61000-4-2

Radiated

EN 61000-4-3; IEC 61000-4-3

EFT/Burst

EN 61000-4-4; IEC 61000-4-4

Surge

EN 61000-4-5; IEC 61000-4-5

Conducted

EN 61000-4-6; IEC 61000-4-6

Power frequency magnetic field

IEC 61000-4-8; EN 61000-4-8

Voltage dips and interruptions

EN 61000-4-11; IEC 61000-4-11

Harmonics

EN 61000-3-2, IEC 61000-3-2

Flicker

EN 61000-3-3, IEC 61000-3-3

Management

IMC - Intelligent Management Center; command-line interface; out-of-band management; SNMP Manager; Telnet; FTP

Notes

The customer must order a power supply, as the device does not come with one. At least one JC680A

The HPE 5900AF-48XG-4QSFP+ Switch is NEBS GR-1089-CORE compliant.

Services

Refer to the Hewlett Packard Enterprise sales website at: http://www.hpe.com/networking/services

response times in your area, please contact your local Hewlett Packard Enterprise sales office.

Standards and protocols

BGP

RFC 4271 A Border Gateway Protocol 4 (BGP-4)

IPv6 RFC 2080 RIPng for IPv6 RFC 2460 IPv6 Specification RFC 2461 IPv6 Neig RFC 2462 IPv6 Stateless Address Auto configuration RFC 2463 ICMPv6

-40 to -60 VDC, rated

2; IEC 60950-1; CAN/CSA-C22.2 No. 60950-1; Anatel; ULAR; GOST; EN 60950-1/A11; FDA 21 CFR

61000-3-2:2006; EN 61000-3-3:1995 +A1:2001+A2:2005; EMC Directive 2004/108/EC; FCC (CFR

or JC681A is required.

for details on the service-level descriptions and product numbers. For details about services and

(applies to all products in series)

RFC 1163 Border Gateway Protocol (BGP) RFC 1771 BGPv4 RFC 1997 BGP Communities Attribute RFC 2918 Route Refresh Capability RFC 3392 Capabilities Advertisement with BGP-4

hbor Discovery

Page

QuickSpecs

HPE FlexFabric 5900 Switch Series

Technical Specifications

RFC 4360 BGP Extended Communities Attribute RFC 4456 BGP Route Reflection: An Alternative to

RFC 1531 Dynamic Host Configuration Protocol

RFC 2464 Transmission of IPv6 over Ethernet Networks RFC 2473 Generic Packet Tunneling in IPv6 RFC 2545 Use of MP RFC 2563 ICMPv6 RFC 2711 IPv6 Router Alert Op RFC 2740 OSPFv3 for IPv6 RFC 2767 Dual stacks IPv46 & IPv6 RFC 3315 DHCPv6 (client and relay) RFC 4291 IP Version 6 Addressing Architecture RFC 4862 IPv6 Stateless Address Auto configuration RFC 5095 Deprecation of Type 0 Routing Headers in IPv6

MIB

RFC 1213 MIB II RFC 1907 SNMPv2 MIB RFC 2571 SNMP Framework MIB RFC 2572 SNMP RFC 2573 SNMP RFC 2573 SNMP RFC 2574 SNMP USM MIB RFC 2737 Entity MIB (Version 2) RFC 3414 SNMP RFC 3415 SNMP LLDP LLDP LLDP

Network management

RFC 3164 BSD syslog Protocol

OSPF

RFC 1587 OSPF NSSA RFC 2328 OSPFv2 RFC 3101 OSPF NSSA RFC 3137 OSPF Stub Router Advertisement RFC 3623 Graceful OSPF Restart RFC 4577 OSPF as the Provi Protocol for BGP/MPLS IP Virtual Private Networks (VPNs) RFC 4811 OSPF Out Resynchronization RFC 4812 OSPF Restart Signaling RFC 4813 OSPF Link

QoS/CoS

IEEE 802.1p (CoS) RFC 2475 DiffServ Architecture RFC 2597 RFC 3247 Supplemental Information for the New Definition of the EF PHB (Expedited Forwarding Per

Full Mesh Internal BGP (IBGP) RFC 4760 Multiprotocol Extensions for BGP-4

Device management RFC 1157 SNMPv1/v2c RFC 1305 NTPv3 RFC 1591 DNS (client) RFC 1902 (SNMPv2) RFC 1908 (SNMP v1/2 Coexistence) RFC 2573 (SNMPv3 Applications) RFC 2576 (Coexistence between SNMP V1, V2, V3) Multiple Configuration Files Multiple Software Images SSHv1/SSHv2 Secure Shell TACACS/TACACS+

General protocols IEEE 802.1D MAC Bridges IEEE 802.1p Priority IEEE 802.1Q VLANs IEEE 802.1s Multiple Spanning Trees IEEE 802.1w Rapid Reconfiguration of Spanning Tree IEEE 802.3ad Link Aggregation Control Protocol (LACP) IEEE 802.3ae 10-Gigabit Ethernet IEEE 802.3ag Ethernet OAM IEEE 802.3ah Ethernet in First Mile over Point to Point Fiber - EFMF IEEE 802.3x Flow Control RFC 768 UDP RFC 783 TFTP Protocol (revision 2) RFC 791 IP RFC 792 ICMP RFC 793 TCP RFC 826 ARP RFC 854 TELNET RFC 856 TELNET RFC 868 Time Protocol RFC 896 Congestion Control in IP/TCP Internetworks RFC 950 Internet Standard Subnetting Procedure RFC 1027 Proxy ARP RFC 1058 RIPv1 RFC 1091 Telnet Terminal-Type Option RFC 1141 Incremental updating of the Internet checksum RFC 1142 OSI IS-IS Intra-domain Routing Protocol RFC 1191 Path MTU discovery RFC 1213 Management Information Base for Network Management of TCP/IP-based internets RFC 1253 (OSPF v2)

-BGP-4 for IPv6

tion

-MPD MIB

-Notification MIB

-Target MIB

-User based-SM MIB

-View based-ACM MIB

-EXT-DOT1-MIB

-EXT-DOT3-MIB

-MIB

der/Customer Edge

-of-Band LSDB

-Local Signaling

DiffServ Assured Forwarding (AF)

-Hop Behavior)

Page

QuickSpecs

HPE FlexFabric 5900 Switch Series

Technical Specifications

RFC 1533 DHCP Options and BOOTP Vendor

RFC 4253 The Secure Shell (SSH) Transport Layer

Address Autoconfiguration in IPv6

RFC 3260 New Terminology and Clarifications for DiffServ

Security

Access Control Lists (ACLs) SSHv2 Secure She

Extensions RFC 1534 DHCP/BOOTP Interoperation RFC 1541 DHCP RFC 1591 DNS (client only) RFC 1624 Incremental Internet Checksum RFC 1723 RIP v2 RFC 1812 IPv4 Routing RFC 2030 Simple Network Time Protocol (SNTP) v4 RFC 2131 DHCP RFC 2236 IGMP Snooping RFC 2338 VRRP RFC 2453 RIPv2 RFC 2581 TCP Congestion Control RFC 2644 Directed Broadcast Control RFC 2767 Dual Stacks IPv4 & IPv6 RFC 3046 DHCP Relay Agent Information Option RFC 3768 Virtual Router Redundancy Protocol (VRRP) RFC 4250 The Secure Shell (SSH) Protocol Assigned Numbers RFC 4251 The Secure Shell (SSH) Protocol Architecture RFC 4252 The Secure Shell (SSH) Authentication Protocol

Protocol RFC 4254 The Secure Shell (SSH) Connection Protocol RFC 4364 BGP/MPLS IP Virtual Private Networks (VPNs) RFC 4419 Diffie-Hellman Group Exchange for the Secure Shell (SSH) Transport Layer Protocol RFC 4594 Configuration Guidelines for DiffServ Service Classes RFC 4941 Privacy Extensions for Stateless

Page

QuickSpecs

HPE FlexFabric 5900 Switch Series

Accessories

HPE FlexFabric 5900 Switch Series accessories

Transceivers

HPE X120 1G SFP LC LH40 1550nm Transceiver

JD062A

HPE X120 1G SFP LC LX Transceiver

JD119B

HPE X120 1G SFP RJ45 T Transceiver

JD089B

HPE X120 1G SFP LC SX Transceiver

JD118B

HPE X125 1G SFP LC LH40 1310nm Transceiver

JD061A

HPE X125 1G SFP LC LH70 Transceiver

JD063B

HPE X130 10G SFP+ LC SR Transceiver

JD092B

HPE X130 10G SFP+ LC SR Data Center Transceiver

JL437A

HPE X130 10G SFP+ LC LRM Transceiver

JD093B

HPE X130 10G SFP+ LC LRM Data Center Transceiver

JL438A

HPE X130 10G SFP+ LC LR Transceiver

JD094B

HPE X130 10G SFP+ LC LR Data Center Transceiver

JL439A

HPE X130 10G SFP+ LC ER 40km Transceiver

JG234A

HPE FlexNetwork X240 10G SFP+ to SFP+ 0.65m Direct Attach Copper Cable

JD095C

HPE FlexNetwork X240 10G SFP+ to SFP+ 1.2m Direct Attach Copper Cable

JD096C

HPE FlexNetwork X240 10G SFP+ to SFP+ 3m Direct Attach Copper Cable

JD097C

HPE FlexNetwork X240 10G SFP+ to SFP+ 5m Direct Attach Copper Cable

JG081C

HPE FlexNetwork X240 40G QSFP+ QSFP+ 1m Direct Attach Copper Cable

JG326A

HPE FlexNetwork X240 40G QSFP+ QSFP+ 3m Direct Attach Copper Cable

JG327A

HPE FlexNetwork X240 40G QSFP+ QSFP+ 5m Direct Attach Copper Cable

JG328A

HPE FlexNetwork X240 40G QSFP+ to 4x10G SFP+ 1m Direct Attach Copper Splitter Cable

JG329A

HPE FlexNetwork X240 40G QSFP+ to 4x10G SFP+ 3m Direct Attach Copper Splitter Cable

JG330A

HPE FlexNetwork X240 40G QSFP+ to 4x10G SFP+ 5m Direct Attach Copper Splitter Cable

JG331A

HPE FlexNetwork X240 10G SFP+ SFP+ 7m Direct Attach Copper Cable

JC784C

HPE X140 40G QSFP+ LC LR4 SM 10km 1310nm Transceiver

JG661A

HPE X140 40G QSFP+ MPO SR4 Transceiver

JG325B

HPE X140 40G QSFP+ MPO MM 850nm CSR4 300m Transceiver

JG709A

HPE X130 10G SFP+ LC LRM Transceiver

JD093B

Power Supply

HPE 58x0AF 650W AC Power Supply

JC680A

HPE FlexFabric 5900AF 48XG 4QSFP+ Switch (JC772A)

HPE X2A0 40G QSFP+ to QSFP+ 7m Active Optical Cable

JL287A

HPE X2A0 40G QSFP+ to QSFP+ 10m Active Optical Cable

JL288A

HPE X2A0 40G QSFP+ to QSFP+ 20m Active Optical Cable

JL289A

HPE X2A0 10G SFP+ to SFP+ 7m Active Optical Cable

JL290A

HPE X130 10G SFP+ LC LH80 Tunable Transceiver

JL250A

HPE X2A0 10G SFP+ to SFP+ 10m Active Optical Cable

JL291A

HPE X2A0 10G SFP+ to SFP+ 20m Active Optical Cable

JL292A

HPE X140 40G QSFP+ LC LR4L 2km SM Transceiver

JL286A

HPE A58x0AF Back (Power Side) to Front (Port Side) Airflow 300W AC Power Supply

JG900A

HPE A58x0AF Back (Power Side) to Front (Port Side) Airflow 300W DC Power Supply

JG901A

HPE 58x0AF Back (Power Side) to Front (Port Side) Airflow Fan Tray

JC682A

HPE 58x0AF Front (Port Side) to Back (Power Side) Airflow Fan Tray

JC683A

Page

QuickSpecs

HPE FlexFabric 5900 Switch Series

Accessories

HPE X711 Front (Port Side) to Back (Power Side) Airflow High Volume Fan Tray

JG552A

HPE X712 Back (Power Side) to Front (Port Side) Airflow High Volume Fan Tray

JG553A

HPE FlexFabric 5900AF 48G 4XG 2QSFP+ Switch (JG510A)

HPE X2A0 40G QSFP+ to QSFP+ 7m Active Optical Cable

JL287A

HPE X2A0 40G QSFP+ to QSFP+ 10m Active Optical Cable

JL288A

HPE X2A0 40G QSFP+ to QSFP+ 20m Active Optical Cable

JL289A

HPE X2A0 10G SFP+ to SFP+ 7m Active Optical Cable

JL290A

HPE X130 10G SFP+ LC LH80 Tunable Transceiver

JL250A

HPE X2A0 10G SFP+ to SFP+ 10m Active Optical Cable

JL291A

HPE X2A0 10G SFP+ to SFP+ 20m Active Optical Cable

JL292A

HPE X140 40G QSFP+ LC LR4L 2km SM Transceiver

JL286A

HPE A58x0AF Back (Power Side) to Front (Port Side) Airflow 300W AC Power Supply

JG900A

HPE A58x0AF Back (Power Side) to Front (Port Side) Airflow 300W DC Power Supply

JG901A

HPE 58x0AF Back (Power Side) to Front (Port Side) Airflow Fan Tray

JC682A

HPE 58x0AF Front (Port Side) to Back (Power Side) Airflow Fan Tray

JC683A

HPE X711 Front (Port Side) to Back (Power Side) Airflow High Volume Fan Tray

JG552A

HPE X712 Back (Power Side) to Front (Port Side) Airflow High Volume Fan Tray

JG553A

HPE FlexFabric 5900AF 48XGT 4QSFP+ Switch (JG336A)

HPE X2A0 40G QSFP+ to QSFP+ 7m Active Optical Cable

JL287A

HPE X2A0 40G QSFP+ to QSFP+ 10m Active Optical Cable

JL288A

HPE X2A0 40G QSFP+ to QSFP+ 20m Active Optical Cable

JL289A

HPE X2A0 10G SFP+ to SFP+ 7m Active Optical Cable

JL290A

HPE X130 10G SFP+ LC LH80 Tunable Transceiver

JL250A

HPE X2A0 10G SFP+ to SFP+ 10m Active Optical Cable

JL291A

HPE X2A0 10G SFP+ to SFP+ 20m Active Optical Cable

JL292A

HPE X140 40G QSFP+ LC LR4L 2km SM Transceiver

JL286A

HPE X711 Front (Port Side) to Back (Power Side) Airflow High Volume Fan Tray

JG552A

HPE X712 Back (Power Side) to Front (Port Side) Airflow High Volume Fan Tray

JG553A

HPE FlexFabric 5900 48XG 4QSFP+ Short Form Factor Switch (JH337A)

HPE A58x0AF Back (Power Side) to Front (Port Side) Airflow 300W AC Power Supply

JG900A

HPE A58x0AF Back (Power Side) to Front (Port Side) Airflow 300W DC Power Supply

JG901A

HPE 58x0AF Back (Power Side) to Front (Port Side) Airflow Fan Tray

JC682A

HPE 58x0AF Front (Port Side) to Back (Power Side) Airflow Fan Tray

JC683A

HPE X711 Front (Port Side) to Back (Power Side) Airflow High Volume Fan Tray

JG552A

HPE X712 Back (Power Side) to Front (Port Side) Airflow High Volume Fan Tray

JG553A

Page

QuickSpecs

HPE FlexFabric 5900 Switch Series

Accessory Product Details

NOTE: Details are not available for all accessories. The following specifications were available at the time of publication.

HPE X120 1G SFP LC LH40 1550nm Transceiver

A small form pluggable (SFP) Gigabit LH40 transceiver that provides a Gigabit solution up to 40 km on a single mode fiber.

Ports

1 LC 1000BASE-LH port (no IEEE standard exists for 1550 nm optics)

Connectivity

Connector type

Wavelength

1550 nm

Physical characteristics Dimensions

2.17(d) x 0.6(w) x 0.46(h) in. (5.51 x 1.52 x

1.17 cm)

Full configuration weight

0.04 lb. (0.02 kg)

Electrical characteristics

Power consumption typical

0.8 W

Power consumption maximum

1.0 W

Cabling Cable type:

Single

Maximum distance:

Fiber type

Single Mode

Services

Refer to the Hewlett Packard Enterprise sales website at: level descriptions and product numbers. For details about services and response times in your area, please contact your local Hewlett Packard Enterprise sales office.

HPE X125 1G SFP LC

Ports

1 LC 1000BASE-LH port (no IEEE standard exists for 1550 nm optics)

Connectivity Connector type

Wavelength

1550 nm

Physical characteristics Dimensions

2.17(d) x 0.6(w) x 0.46(h) in. (5.51 x 1.52 x Full configuration weight

0.04 lb. (0.02 kg)

Electrical characteristics

Power consumption typical

0.8 W

Power consumption maximum

1.0 W

Cabling Cable type:

• 70km

Fiber type

Single Mode

Services

Refer to the Hewlett Packard Enterprise sales website

Enterprise sales office.

(JD062A)

-factor

full-duplex

LH70 Transceiver

(JD063B)

-mode fiber optic, complying with ITU-T G.652;

• 40km distance

http://www.hpe.com/networking/services for details on the service-

A small form-factor pluggable (SFP) Gigabit LH70 transceiver that provides a full-duplex Gigabit solution up to 70km on a single-mode fiber.

1.17 cm)

Single-mode fiber optic, complying with ITU-T G.652;

Maximum distance:

at: http://www.hpe.com/networking/services for details on the servicelevel descriptions and product numbers. For details about services and response times in your area, please contact your local Hewlett Packard

Page

QuickSpecs

HPE FlexFabric 5900 Switch Series

Accessory

Product Details

HPE X120 1G SFP LC SX

Ports

1 LC 1000BASE-SX port

Connectivity Connector type

Wavelength

850 nm

Physical characteristics Dimensions

2.17(d) x 0.6(w) x 0.46(h) in. (5.51 x 1.52 x

1.17 cm)

Full configuration weight

0.04 lb. (0.02 kg)

Electrical characteristics

Power consumption typical

0.8 W

Power consumption maximum

1.0 W

Cabling

Maximum distance:

• OM3 = Not Specified by standard

Cable length

up to 550m

Fiber type

Multi Mode

Services

Refer to the Hewlett Packard Enterprise sales website

Enterprise sales office.

HPE X120 1G SFP LC LX

Ports

1 SFP 1000BASE-LX port (IEEE 802.3z Type 1000BASE-LX)

Connectivity Connector type

Wavelength

1300 nm

Physical characteristics Dimensions

2.17(d) x 0.6(w) x 0.46(h) in. (5.51 x 1.52 x

1.17 cm)

Full configuration weight

0.04 lb. (0.02 kg)

Electrical characteristics

Power consumption typical

0.8 W

Power consumption maximum

1.0 W

Cabling Cable type:

• 10km for Singlemode

Fiber type

Both

Services

Refer to the Hewlett Packard Enterprise sales website

Enterprise sales office.

HPE X120 1G Ports

1 RJ-45 1000BASE-T port (IEEE 802.3ab Type 1000BASE-T)

Connectivity

Connector type

RJ-45

Transceiver (JD118B)

A small form-factor pluggable (SFP) Gigabit SX transceiver that provides a full-duplex Gigabit solution up to 550m on a Multimode fiber.

Transceiver (JD119B)

A small form-factor pluggable (SFP) Gigabig LX transceiver that provides a full duplex Gigabit solution up to 550m on MMF or 10Km on SMF

• FDDI Grade distance = 220m

• OM1 = 275m

• OM2 = 500m

SFP RJ45 T

Either single mode or multimode;

Maximum distance:

• 550m for Multimode

Page

QuickSpecs

HPE FlexFabric 5900 Switch Series

Accessory

Product Details

Transceiver

Physical Dimensions

2.71(d) x 0.54(w) x 0.55(h) in. (6.88 x 1.37 x 1.4 cm)

Full configuration weight

0.07 lb. (0.03 kg)

Electrical Power consumption typical

0.8 W

Power consumption maximum

1.0 W

Cabling

Cable type:

• 100m

Services

Refer to the Hewlett Packard Enterprise sales website

contact your local Hewlett Packard Enterprise sales office.

(JD089B)

A small form factor pluggable (SFP) Gigabit 1000Base-T transceiver that provides a full duplex Gigabit solution up to 100m on a Cat5+ cable.

characteristics

1000BASE-T: Category 5 (5E or better recommended), 100 Ù differential 4-pair unshielded twisted pair (UTP) or shielded twisted pair (STP) balanced, complying with IEEE 802.3ab 1000BASE-T;

Maximum distance:

at: http://www.hpe.com/networking/services for details on the service-level descriptions and product numbers. For details about services and response times in your area, please

Page

QuickSpecs

HPE FlexFabric 5900 Switch Series

Summary of Changes

Date

Version History

Action

Description of Change

06-Aug-2018

Version 36

Changed

Configuration section updated: Added 10G AOC Cable 07-May-2018

Version 35

Changed

Configuration section updated

06-Mar-2017

Version 34

Added

SKUs added: JL437A, JL438A, JL439A

11-Nov-2016

Version 33

Removed

Removed not supported transceivers: JD098B; JD099B

19-Aug-2016

Version 32

Changed

Configuration section updated (#AC3 option added)

01-Aug-2016

Version 31 Added

SKUs added: JL287A, JL288A, JL289A, JL290A, JL291A, JL292A, JL250A, JL286A

Changed

Overview and Technical Specifications updated.

06-June-2016

Version 30

Changed

Document name changed to HPE FlexFabric 5900 Switch

Product description updated.

15-Apr-2016

Version 29

Changed

SKUs descriptions updated on all the document.

16-Feb-2016

Version 28

Added

SKU added: JL251A

Changed

Overview, Technical Specifications and Accessories updated,

08-Jan-2016

Version 27

Changed

Warranty and support updated

12-Oct-2015

Version 26

Changed

Overview, Technical Specifications and Accessories updated,

12-Dec-2014

Version 25

Removed

Deleted SKU JG325A

01-Dec-2014

Version 24 Added

Accessories section added

Changed

Changes made on the entire document

09-June-2014

Version 23

Changed

Overview section revised.

31-Mar-2014

Version 22

Changed

Transceivers were revised.

19-Mar-2014

Version 21

Changed

Product descriptions, Transceivers, and notes were revised in Configuration.

04-Mar-2014

Version 20

Changed

Transceivers and Switch Options were revised.

25-Feb-2014

Version 19

Changed

Transceivers and Switch Options were revised.

18-Feb-2014

Version 18

Added

HPE FF 5900CP-48XG -4QSFP+ Switch was added to Configuration.

12-Nov-2013

Version 17

Changed

Build to Order, Box Level Integration CTO Models, Rack

and Switch Options were revised.

14-Oct-2013

Version 16

Added

Added a new Transceiver in two locations in the Configuration section.

09-Aug-2013

Version 15

Changed

Configuration as revised.

19-Jul-2013

Version 14

Changed

Configuration as revised.

02-Jul-2013

Version 13

Changed

The description of model JG336A was corrected 12-Jun-2013

Version 9

Changed

Build-to-Order was revised.

10-Jun-2013

Version 8

Changed

Configuration was revised.

25-Mar-2013

Version 7

Added

Added Part numbers and descriptions to the following

Section

Deleted

Deleted several part numbers to the Standards and Protocols Section

27-Feb-2013

Version 6

Changed

The formatting of the new Configuration section was revised.

19-Feb-2013

Version 5

Added

The configuration section was added. Line art was added.

compatibility

Series.

Level Integration CTO Models, Internal Power Supplies,

throughout.

Sections: Build to Order, Box Level Integration CTO Models, Rack Level Integration CTO Models , Switch Options Added Notes 3, and 4 to the Switch Options

Page

QuickSpecs

HPE FlexFabric 5900 Switch Series

Summary of Changes

Changed

Product overview, Features and benefits, Model specifications, and Accessories were revised.

04-Dec-2012

Version 3

Changed

Updated Features and Benefits and made minor updates to the model specifications and accessories.

02-Apr-2011

Version 2

Changed

Part number was revised.

16-Nov-2011

Version 1

Created

Document creation

© Copyright 2018 Hewlett Packard Enterprise Development LP. The information contained herein is subject to change without notice. The only warranties for Hewlett Packard Enterprise products and services are set forth in the express warranty statements accompanying such pro Nothing herein should be construed as constituting an additional warranty. Hewlett Packard Enterprise shall not be liable for technical or editorial errors or omissions contained herein.

To learn more, visit

c04111469

ducts and services.

http://www.hpe.com/networking

- 14252 - Worldwide - V36 - 6-August-2018

Page

HPE JC772A Getting Started Guide

Specifications and Main Features

Frequently Asked Questions

User Manual

Overview

Configuration

Technical Specifications

Accessories

Accessory Product Details

Summary of Changes
