HPE FlexFabric 12500 Switch Series

Overview

1

HPE FlexFabric 12500 Switch Series

HPE FlexFabric 12508E Switch

HPE FlexFabric 12518E Switch

Models

HPE 12504 AC Switch Chassis

JC654A

HPE 12504 DC Switch Chassis

JC655A

HP 12508 AC Switch Chassis

JF431C

HP 12508 DC Switch Chassis

JC652A

HP 12518 AC Switch Chassis

JF430C

HP 12518 DC Switch Chassis

JC653A

HPE FlexFabric 12508E AC Switch Chassis

JG782A

HPE FlexFabric 12508E DC Switch Chassis

JG783A

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

Page

QuickSpecs

HPE FlexFabric 12500 Switch Series

Overview

2

HPE FlexFabric 12518E AC Switch Chassis

JG784A

HPE FlexFabric 12518E DC Switch Chassis

JG785A

Product overview

The HPE 12500 Switch Series is a family of powerful, next-generation routing switches with outstanding capacity and scale for the
network core or data center.

Designed for high performance with nonblocking and distributed Clos
switching capacity and 10.8 Bpps throughput with up to 400 Gbps per line card slot.

The 12500 switches also have energy
contemplating large
deployments, and other applications requiring a robust, reliable and highly available switching platform.

Key features

• Optimized for cata centers with extensive virtualization and convergence featured

Features and benefits

Data center optimized

E 802.1Qaz Data Center Bridging Exchange (DCBX), Enhanced Transmission Selection (ETS), and

Software

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

architecture, these switches deliver up to 24.3 Tbps

-efficiency features that drive down operational expenses and are ideal for organizations

-scale data center consolidations, business continuity and disaster recovery sites, metropolitan area network

• Broad interface options from 1G to 100G scaling up to 24.3 Tbps switching capacity

• SDN ready with Open Flow 1.3 support

• Large Layer 2 and Layer 3 tables to support large scale deployments

• Fully redundant architecture with hot swappable components

• Scalable Layer 2 fabrics

build flexible, resilient, and scalable Layer 2 fabrics with SPB and HPE IRF

• Multitenant Device Context (MDC)

is an innovative data center virtualization solution that enables multi-tenancy, giving customers the ability to virtualize a
physical switch into multiple logical devices, with each logical switch having its own tenants

• HPE Ethernet Virtual Interconnect (EVI)

is an HPE Virtual Application Network innovation that provides a Layer 2 extension across the data center to simplify the
interconnectivity of geographically disperse data centers

• NEW Data Center Bridging (DCB) protocols

provide support for IEE
IEEE 802.1Qbb Priority Flow Control (PFC) for converged fabrics

• NEW Fibre Channel over Ethernet (FCoE) features

deliver support for FCoE, including expansion, fabric, trunk VF and N ports, and aggregation of E-port and N-port
virtualization

• Accelerated perfomance with jumbo frames

for intra-data-center communication, or for data center to data center traffic (disaster recovery), reducing the amount of
time required for data backup and recovery

• Network load balancing (NLB) multicast ARP

Microsoft® NLB co-works with multicast ARP to provide servers with load balancing and fault switchover, which lowers
costs and investment

-defined networking

• NEW Supports OpenFlow 1.3 specifications

to enable SDN by allowing separation of the data (packet forwarding) and control (routing decision) paths

Page

QuickSpecs

HPE FlexFabric 12500 Switch Series

Overview

3

Performance

cessors to isolate key tasks: control plane (STP, OSPF, BGP, MPLS, etc.), fast

Product architecture

Resiliency and high availability

Quality of Service (QoS)

• Virtual Output Queue (VOQ)

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

• NEW High performance design with nonblocking and distributed Clos architecture

delivers up to 24.3 Tbps switching capacity and 10.8 Bpps throughput with up to 400 Gbps per line card slot

• NEW High-density 1GbE,10GbE and 40GbE interface connectivity

offers up to 18 interface module slots to scale up to 864 1GbE and 1/10GbE and 288 40GbE ports

• Hardware-based wirespeed access control lists (ACLs)

help provide high levels of security and ease of administration without impacting network performance with a feature-rich
TCAM-based ACL implementation

• High-performance processor system

the supervisor module uses three different pro
recovery protocols (RRPP, BFD, etc.), and chassis management (temperature, power, etc.)

• Distributed architecture with separation of data and control planes

delivers enhanced fault tolerance and facilitates continuous operation and zero service disruption during planned or
unplanned control-plane events

• Advanced Comware modular operating system

brings modularity, enhanced serviceability, stability and independent process monitoring through modern Comware v7
Operating System

• In-Service Software Upgrade (ISSU)

provides an upgrade of the entire chassis, or an individual task or process, with zero packet loss

• Intelligent Resilient Fabric (IRF)

creates virtual resilient switching fabrics, where two or more switches perform as a single L2 switch and L3 router;
switches do not have to be co-located and can be part of a disaster-recovery system; servers or switches can be attached
using standard LACP for automatic load balancing and high availability; can eliminate the need for complex protocols like
Spanning Tree Protocol, Equal-Cost Multipath (ECMP), or VRRP, thereby simplifying network operation

• Ultrafast protocol convergence

enables link connectivity monitoring and reduces network convergence time for RIP, OSPF, BGP, IS-IS, VRRP, MPLS, and
IRF

• Device Link Detection Protocol (DLDP)

monitors link connectivity and shuts down ports at both ends if unidirectional traffic is detected, preventing loops in STP­based networks

• Complete set of routing protocols (Layer 3 IPv4 and IPv6)

support virtually all existing routing protocols (RIP, OSPF, IS-IS, and BGP) for both Layer 3 IPv4 and Layer 3 IPv6;
complete support of PIM-DM, PIM-SM, PIM-SSM, and MSDP

• Hot patching

the 12500 switch series supports hot patching, allowing in-service patching for some isolated software problems

• Non Stop Forwarding/Graceful Restart (NSF/GR)

using standardized-based IETF protocols, the 12500 switch series provides nonstop forwarding (switching/routing) for
Layer 3 routing protocols (control plane – OSPF, BGP, and MPLS), providing hitless failover

• Fully redundant and hot swappable components

providing full hardware redundancy for each component including power supplies, fan trays, supervisor modules and
fabric modules to enable the highest level of availability

• Rapid Ring Protection Protocol (RRPP)

provides fast recovery for ring Ethernet-based topology

Page

QuickSpecs

HPE FlexFabric 12500 Switch Series

Overview

4

prevents head-of-line (HOL) blocking per port at peak time and distributes it over a period of time, increasing switch

Compartmentalization

ayer 2 VPN technology that allows a complete separation of customer and provider

Layer 2 switching

Layer 3 routing

• OSPF and OSPFv3 support

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

performance

• IEEE 802.1p prioritization

delivers data to devices based on the priority and type of traffic

• Layer 4 prioritization

enables prioritization based on TCP/UDP port numbers

• Broadcast control

allows limitation of broadcast traffic rate to cut down on unwanted network broadcast traffic

• Advanced classifier-based QoS

classifies traffic using multiple match criteria based on Layer 2, 3, and 4 information; applies QoS policies such as setting
priority level and rate limit to selected traffic on a per-port or per-VLAN basis

• Bandwidth shaping

- Port-based rate limiting

provides per-port ingress-/egress-enforced maximum bandwidth

- Classifier-based rate limiting

uses access control lists (ACLs) to enforce maximum bandwidth for ingress/egress traffic on each port

• Department protection

using network virtualization standards (QinQ, VRF, and MPLS), the 12500 switch series allows organizations to isolate
different business units with different resources (VRFs); using standard-based mechanisms, the network is completely
virtualized, reducing cost and operations

• IEEE 802.1ah Provider Backbone Bridge (MAC in MAC)

Provider Backbone Bridge (PBB) is a L
domains by sealing the user MAC in the service provider MAC, which enhances the scalability of an Ethernet network

• Multiple VLAN Registration Protocol (MVRP)

helps to maintain VLAN configuration dynamically based on current network configurations

• GARP VLAN Registration Protocol

allows automatic learning and dynamic assignment of VLANs

• IP multicast snooping and data-driven IGMP

automatically prevents flooding of IP multicast traffic

• IEEE 802.1ad QinQ

increases the scalability of an Ethernet network by providing a hierarchical structure; connects multiple LANs on a high­speed campus or metro network

• Bridge Protocol Data Unit (BPDU) tunneling

transmits Spanning Tree Protocol BPDUs transparently, allowing correct tree calculations across service providers, WANs,
or MANs

• VLAN support and tagging

supports IEEE 802.1Q (4K VLAN IDs)

• Spanning Tree

the 12500 switch series supports the entire set of STP protocols (STP, RSTP, and MSTP), facilitating a complete
integration with standard networks

• Layer 3 IPv4 routing

provides routing of IPv4 at media speed; supports static routes, RIP and RIPv2, OSPF, IS-IS, and BGP

• RIP and RIPng support

provides complete support of RIP for both IPv4 and IPv6

Page

QuickSpecs

HPE FlexFabric 12500 Switch Series

Overview

5

provides complete support of OSPF for both IPv4 and IPv6

Management

provides local and remote logging of events via SNMP (v2c and v3) and syslog; provides log throttling and log filtering to

enables or disables each of the following interfaces depending on security preferences: console port, Telnet port, and SSH

Remote Intelligent Mirroring

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

• IS-IS and IS-ISv6 support

provides complete support of IS-IS for both IPv4 and IPv6

• Equal-Cost Multipath (ECMP)

enables multiple equal-cost links in a routing environment to increase link redundancy and scale bandwidth

• Layer 3 IPv6 routing

provides routing of IPv6 at media speed; supports static routes, RIPng, OSPFv3, IS-ISv6, and BGP4+

• IPv6 tunneling

allows a smooth transition from IPv4 to IPv6 by encapsulating IPv6 traffic over an existing IPv4 infrastructure

• Complete multicast protocol stack

PIM-DM, PIM-SM, PIM-SSM, MSDP, and extensions to BGP provide one of the most complete multicast protocol stacks

• Policy routing

allows custom filters for increased performance and security; supports ACLs, IP prefix, AS paths, community lists, and
aggregate policies

• MPLS support

provides extended support of MPLS, including MPLS VPNs and MPLS Traffic Engineering (MPLS TE)

• VPLS support

provides extended support of VPLS for data center to data center communication at Layer 2; provides support of
hierarchical VPLS for scalability

• sFlow

• IEEE 802.1ab LLDP discovery

• USB support

• Multiple configuration files

• Command-line interface (CLI)

• Logging

• Management interface control

• Out-of-band interface

• Network management

• Network management

• RADIUS accounting

• RMON

•

provides scalable, ASIC-based network monitoring and accounting; this allows network operators to gather a variety of
sophisticated network statistics and information for capacity planning and real-time network monitoring purposes

advertises and receives management information from adjacent devices on a network, facilitating easy mapping by
network management applications

- File copy

allows users to copy switch files to and from a USB flash drive

can be stored to the flash image

provides a secure, easy-to-use CLI for configuring the module via SSH or a switch console; provides direct real-time
session visibility

reduce the number of log events generated

port

isolates management traffic from user data plane traffic for complete isolation and total reachability, no matter what
happens in the data plane

HPE Intelligent Management Center (IMC) centrally configures, updates, monitors, and troubleshoots

SNMP v2c/v3 MIB-II with traps

logs all session details that can be used to generate usage reports or interface to a billing system

provides advanced monitoring and reporting capabilities for statistics, history, alarms, and events

Page

QuickSpecs

HPE FlexFabric 12500 Switch Series

Overview

6

mirrors ingress ACL-selected traffic from a switch port or VLAN to a local or remote switch port anywhere on the network

Connectivity

Security

Convergence

(ASM) or Source-Specific Multicast (SSM) to manage IPv4 multicast networks

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

• IPv6 native support:

- IPv6 host

enables switches to be managed and deployed at the IPv6 network's edge

- Dual stack (IPv4 and IPv6)

transitions from IPv4 to IPv6, supporting connectivity for both protocols

- Multicast Listener Discovery (MLD) snooping

forwards IPv6 multicast traffic to the appropriate interface

- IPv6 ACL/QoS

supports ACL and QoS for IPv6 network traffic, preventing traffic flooding

- IPv6 routing

supports IPv6 static routes and IPv6 versions of RIP and OSPF routing protocols

• Control Plane Policing (CoPP)

provides protection against DoS attacks at infrastructure routers and switches and ease of configuration for control plane
policies

• IEEE 802.1X and RADIUS network logins

control port-based access for authentication and accountability

• Secure FTP

allows secure file transfer to and from the switch; protects against unwanted file downloads or unauthorized copying of a
switch configuration file

• Switch management logon security

can require either RADIUS or TACACS+ authentication for secure switch CLI logon

• DHCP protection

blocks DHCP packets from unauthorized DHCP servers, preventing denial-of-service attacks

• Dynamic ARP protection

blocks ARP broadcasts from unauthorized hosts, preventing eavesdropping or theft of network data

• Secure Shell (SSHv2)

encrypts all transmitted data for secure, remote CLI access over IP networks

• Secure management access

securely encrypts all access methods (CLI, GUI, or MIB) through SSHv2 and SNMPv3

• Access control lists (ACLs)

provide IPv4 and IPv6 filtering based on source/destination IP address/subnet and source/destination TCP/UDP port
number

• Media access control (MAC) authentication

provides simple authentication based on a user's MAC address; supports local or RADIUS-based authentication

• Layer 2, 3, and 4 QoS mechanisms

• IP multicast snooping and data-driven IGMP

• LLDP-MED

• Internet Group Management Protocol (IGMP)

support DiffServ priority tagging based on IP address, IP Type of Service (ToS), Layer 3 protocol, TCP/UDP port number,
and source port

automatically prevent flooding of IP multicast traffic

is a standard extension that automatically configures network devices, including LLDP-capable IP phones

is used by IP hosts to establish and maintain multicast groups; supports IGMPv1, v2, and v3; utilizes Any-Source Multicast

Page

QuickSpecs

HPE FlexFabric 12500 Switch Series

Overview

7

• Protocol Independent Multicast (PIM)

M

, and Maintenance (OAM) mechanism

Investment protection

Warranty and support

e releases

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

defines modes of Internet IPv4 and IPv6 multicasting to allow one-to-many and many-to-many transmission of
information; supports PIM Dense Mode (DM), Sparse Mode (SM), and Source-Specific Multicast(SSM)

• Multicast Source Discovery Protocol (MSDP)

is used for inter-domain multicast applications, allowing multiple PIM-SM domains to interoperate

• Multicast VLAN

allows multiple VLANs to receive the same IPv4 or IPv6 multicast traffic, lessening network bandwidth demand by
reducing or eliminating multiple streams to each VLAN

onitor and diagnostics

• Port mirroring

enables traffic on a port to be simultaneously sent to a network
analyzer for monitoring

• Connectivity fault detection (IEEE 802.1ag)

connectivity fault detection (CFD) provides a Layer 2 link Operations, Administration
used for link connectivity detection and fault locating

• Modular switch fabric

provides investment protection by enabling future performance upgrades and increased port density

• Environmentally friendly

RoHS support and low power consumption based on the latest technology provide outstanding power efficiency

• 1-year warranty

see http://www.hpe.com/networking/warrantysummary
product purchase.

• Software releases

to find software for your product, refer to http://www.hpe.com/networking/support
available with your product purchase, refer to http://www.hpe.com/networking/warrantysummary

for warranty and support information included with your

; for details on the softwar

Page

QuickSpecs

HPE FlexFabric 12500 Switch Series

Configuration

8

Build To Order:

BTO is a standalone unit with no integration. BTO products ship standalone are not part of a CTO or Rack-Shippable solution.

HPE 12504 AC Switch Chassis

JC654A

• 2 - MPUx (Management Ports)

HPE FlexFabric 12508E AC Switch Chassis

JG782A

• 2 - MPUx (Management Ports)

See Configuration

PDU Cable NA/MEX/TW/JP

JG782A#B2B

• C19 PDU Jumper Cord (NA/MEX/TW/JP)

PDU Cable ROW

JG782A#B2C

• C19 PDU Jumper Cord (ROW)

High Volt Power Entry Module to Wall Power Cord

JG782A#B2E

• NEMA L6-20P Cord (NA/MEX/JP/TW)

No Power Cord

JG782A#AC3

• No Localized Power Cord Selected

HPE FlexFabric 12518E AC Switch Chassis

JG784A

• 2 - MPUx (Management Ports)

• PEM included

See Configuration

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

• 4 - I/O module slots

• 4 - Fabric module slots

• Must select min 1 Management Module

• Must select min 3 Power Supply

• Must select Min 1 Fans

• Must select Min 4 Fabric Modules

• 10U - Height Rack

• 8- I/O module slots

• 9 - Fabric module slots

• Must select min 1 Management Module

• Must select min 3 Power Supply

• PEM included

• Must select Min 2 Fans

• Must select Min 8 Fabric Modules

• 22U - Height Rack

NOTE:1

• 18 - I/O module slots

• 9 - Fabric module slots

• Must select min 1 Management Module

• Must select min 6 Power Supply

NOTE:1

Page

QuickSpecs

HPE FlexFabric 12500 Switch Series

Configuration

9

• Must select min 2 Fans

PDU Cable NA/MEX/TW/JP

JG784A#B2B

• C19 PDU Jumper Cord (NA/MEX/TW/JP)

PDU Cable ROW

JG784A#B2C

• C19 PDU Jumper Cord (ROW)

High Volt Power Entry Module to Wall Power Cord

JG784A#B2E

• NEMA L6-20P Cord (NA/MEX/JP/TW)

No Power Cord

JG784A#AC3

• No Localized Power Cord Selected

Configuration Rules:

Note 1

Localization required on orders without #B2B, #B2C or #B2E options.

Box Level Integration CTO Models

CTO Solution Sku

HPE 125xx Configure-to-order Switch Solution

JG477A

• SSP trigger SKU

CTO Switch Chassis

HPE 12504 AC Switch Chassis

JC654A

• 2 - MPUx (Management Ports)

See Configuration

Configuration Rules:

Note 1

If this Switch is selected at least one of these Power Supplies is required: (Use #0D1 if switch is CTO)

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

• Must select Min 8 Fabric Modules

• 38U - Height Rack

• 4 - I/O module slots

• 4 - Fabric module slots

• Must select min 1 Management Module

• Must select min 3 Power Supply

• Must select Min 1 Fans

• Must select Min 4 Fabric Modules

• 10U - Height Rack

NOTE:1, 2

Page

QuickSpecs

HPE FlexFabric 12500 Switch Series

Configuration

10

JF429A - HPE 12500 2000W AC Power Supply

Note 2

If the Switch Chassis is to be Box Level Factory Integrated (CTO)), Then the #0D1 is required on the Switch Chassis
and integrated to the JG477A - HP 125xx CTO Switch Solution (Min 1/Max 1 Switch per SSP)

Rack Level Integration CTO Models

HPE 12504 AC Switch Chassis

JC654A

• 2 - MPUx (Management Ports)

See Configuration

HPE FlexFabric 12508E AC Switch Chassis

JG782A

• 2 - MPUx (Management Ports)

See Configuration

PDU Cable NA/MEX/TW/JP

JG782A#B2B

•

PDU Cable ROW

JG782A#B2C

•

No Power Cord

JG782A#AC3

• No Localized Power Cord Selected

HPE FlexFabric 12518E AC Switch Chassis

JG784A

• 2 - MPUx (Management Ports)

•

See Configuration

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

• 4 - I/O module slots

• 4 - Fabric module slots

• Must select min 1 Management Module

• Must select min 3 Power Supply

• Must select Min 1 Fans

• Must select Min 4 Fabric Modules

• 10U - Height Rack

• 8- I/O module slots

• 9 - Fabric module slots

• Must select min 1 Management Module

• Must select min 3 Power Supply

• PEM included

• Must select Min 2 Fans

• Must select Min 8 Fabric Modules

• 22U - Height Rack

NOTE:1, 2, 3

NOTE:1, 3, 5

C19 PDU Jumper Cord (NA/MEX/TW/JP)

C19 PDU Jumper Cord (ROW)

• 18 - I/O module slots

• 9 - Fabric module slots

• Must select min 1 Management Module

• Must select min 6 Power Supply

• PEM included

• Must select min 2 Fans

Must select Min 8 Fabric Modules

NOTE:1, 3, 5

Page

QuickSpecs

HPE FlexFabric 12500 Switch Series

Configuration

11

• 38U - Height Rack

PDU Cable NA/MEX/TW/JP

JG784A#B2B

• C19 PDU Jumper Cord (NA/MEX/TW/JP)

PDU Cable ROW

JG784A#B2C

• C19 PDU Jumper Cord (ROW)

No Power Cord

JG784A#AC3

• No Localized Power Cord Selected

Configuration Rules:

Note 1

If this Switch is selected at least one of these Power Supply is required: (Use #0D1 if switch is CTO)
JF429A - HPE 12500 2000W AC Power Supply

Note 2

When Switches/Routers are Factory Racked, Then #B2B, or #B2C should be the Defaulted Power Cable option on the
Power Electrical Module. (See Drop down remark in the "Internal Power Supplies" section.)

Note 3

If HPE CTO Switch Chassis is selected to be Rack Level Integration, Then the CTO Switch Chassis needs to integrate
(with #0D1) to the P9K48A HPE Universal Rack Only. (Default to the P9K48A)

Note 5

Localization required on orders without #B2B or #B2C options.

Enter the following menu selections as integrated to the CTO Model X above if order is factory built.

Modules

Management Modules

System (std 0 // max 2) User Selection (min 1 // max 2) per Switch

HPE FlexFabric 12500E Main Processing Unit

JG802A

•

See Configuration

Configuration Rules:

Note 1

Management Modules cannot be mixed, They must all be the same SKU.

Note 3

Supported on JC654A Switch Chassis only.

Note 4

Supported on JG782A and JG784A Switch Chassis only.

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

No supported Transceivers

NOTE:1, 3, 4

Page

QuickSpecs

HPE FlexFabric 12500 Switch Series

Configuration

12

Fabric Modules

12504 - System (std 0 // max 4) User Selection (min 4 // max 4) per Switch

12508 and 12518 System (std 0 // max 9) User Selection (min 8 // max 9) per Switch

HPE 1250x G2 Fabric Module

JC658A

See Configuration

HPE FlexFabric 12508E Fabric Module

JG798A

See Configuration

NOTE:

HPE FlexFabric 12518E Fabric Module

JG800A

See Configuration

NOTE:

Configuration Rules:

Note 3

Supported on Switch JC654A Switch Chassis only.

Note 4

Fabric Modules cannot be mixed, They must all be the same SKU

Note 6

Supported on Switch JG782A Switch Chassis only.

Note 7

Supported on Switch JG784A Switch Chassis only.

I/O Modules

12504 - System (std 0 // max 4) User Selection (min 0 // max 4)

12508 - System (std 0 // max 8) User Selection (min 0 // max 8)

12518 - System (std 0 // max 18) User Selection (min 0 // max 18)

HPE FlexFabric 12500 16-port 40GbE QSFP+ FD Module

JG790A

• Min 0 // Max 16 QSFP+ Transceivers

See Configuration

HPE FlexFabric 12500 48-port 1/10GbE SFP+ FD Module

JG796A

• Min 0 // Max 48 SFP+ Transceivers

See Configuration

11

HPE FlexFabric 12500 40-port 1/10GbE SFP+ FD Module

JG792A

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

NOTE: 3, 4

4, 6

4, 7

NOTE:2, 6, 10, 11

NOTE:3, 4, 6, 10,

Page

QuickSpecs

HPE FlexFabric 12500 Switch Series

Configuration

13

• Min 0 // Max 40 SFP+ Transceivers

See Configuration

11

HPE FlexFabric 12500 40-port 1/10GbE SFP+ FG Module

JG794A

•

See Configuration

11

HPE FlexFabric 12500 4-port 100GbE CFP FD Module

JG786A

• Min 0 // Max 4 CFP Transceivers

See Configuration

12

HPE FlexFabric 12500 4-port 100GbE CFP FG Module

JG788A

• Min 0 // Max 4 CFP Transceivers

See Configuration

12

Configuration Rules:

Note 2

The following 40G Transceivers install into this Module:

HPE X140 40G QSFP+ LC LR4 SM 10km 1310nm Transceiver

JG661A

HPE X140 40G QSFP+ MPO SR4 Transceiver

JG325B

HPE X140 40G QSFP+ MPO MM 850nm CSR4 300m Transceiver

JG709A

Note 3

The following Transceivers install into this Module:

HPE X170 1G SFP LC LH70 1550 Transceiver

JD109A

HPE X170 1G SFP LC LH70 1570 Transceiver

JD110A

HPE X170 1G SFP LC LH70 1590 Transceiver

JD111A

HPE X170 1G SFP LC LH70 1610 Transceiver

JD112A

HPE X170 1G SFP LC LH70 1510 Transceiver

JD115A

HPE X120 1G SFP LC LH100 Transceiver

JD103A

HPE X125 1G SFP LC LH40 1310nm Transceiver

JD061A

HPE X120 1G SFP LC LH40 1550nm Transceiver

JD062A

HPE X120 1G SFP RJ45 T Transceiver

JD089B

HPE X120 1G SFP LC SX Transceiver

JD118B

HPE X120 1G SFP LC LX Transceiver

JD119B

HPE X120 1G SFP LC BX 10-U Transceiver

JD098B

HPE X120 1G SFP LC BX 10-D Transceiver

JD099B

Note 4

The following Transceivers install into this Module: (Use #0D1 or #B01 if switch is CTO) - if
applicable

HPE X130 10G SFP+ LC SR Transceiver

JD092B

HPE X130 10G SFP+ LC LRM Transceiver

JD093B

HPE X130 10G SFP+ LC LR Transceiver

JD094B

HPE X130 10G SFP+ LC SR Data Center Transceiver

JL437A

HPE X130 10G SFP+ LC LRM Data Center Transceiver

JL438A

HPE X130 10G SFP+ LC LR Data Center Transceiver

JL439A

HPE FlexNetwork X240 10G SFP+ to SFP+ 3m Direct Attach Copper Cable

JD097C

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

NOTE:3, 4, 6, 10,

Min 0 // Max 40 SFP+ Transceivers

NOTE:3, 4, 6, 10,

NOTE: 6, 10, 11,

NOTE: 6, 10, 11,

Page

QuickSpecs

HPE FlexFabric 12500 Switch Series

Configuration

14

HPE FlexNetwork X240 10G SFP+ to SFP+ 5m Direct Attach Copper Cable

JG081C

HPE X130 10G SFP+ LC ER 40km Transceiver

JG234A

HPE FlexNetwork X240 10G SFP+ SFP+ 7m Direct Attach Copper Cable

JC784C

Note 6

If this Module is selected then ONLY the following Fabric Modules must be selected as well:

HP 12518 G2 Fabric Module

JC657A

HPE 1250x G2 Fabric Module

JC658A

HPE FlexFabric 12508E Fabric Module

JG798A

HPE FlexFabric 12518E Fabric Module

JG800A

Note 10

Supported on JF431C, JC652A, JF430C, JC653A, JC654A, JC655A, JG782A, JG783A, JG784A
and JG785A Switch Chassis only.

Note 11

These modules require JG800A, JG798A, JC658A, JC657A, JC815A, JC816A, JG497A or JG802A
MPU.

Note 12

The following Transceivers install into this Module:

HPE X150 100G CFP LC LR4 10km SM Transceiver

JG829A

Remarks

JC064B and JC476B - Do not install the card in any of the following slots: slot 16, 17, 18, or 19 of
the S12518.

Transceivers

SFP Transceivers

HPE X120 1G SFP LC LH100 Transceiver

JD103A

HPE X125 1G SFP LC LH40 1310nm Transceiver

JD061A

HPE X120 1G SFP LC LH40 1550nm Transceiver

JD062A

HPE X125 1G SFP LC LH70 Transceiver

JD063B

HPE X120 1G SFP RJ45 T Transceiver

JD089B

HPE X120 1G SFP LC SX Transceiver

JD118B

HPE X120 1G SFP LC LX Transceiver

JD119B

HPE X120 1G SFP LC BX 10-U Transceiver

JD098B

HPE X120 1G SFP LC BX 10-D Transceiver

JD099B

SFP+ Transceivers

HPE X130 10G SFP+ LC SR Transceiver

JD092B

HPE X130 10G SFP+ LC LRM Transceiver

JD093B

HPE X130 10G SFP+ LC LR Transceiver

JD094B

HPE X130 10G SFP+ LC SR Data Center Transceiver

JL437A

HPE X130 10G SFP+ LC LRM Data Center Transceiver

JL438A

HPE X130 10G SFP+ LC LR Data Center Transceiver

JL439A

HPE X130 10G SFP+ LC ER 40km Transceiver

JG234A

HPE FlexNetwork X240 10G SFP+ to SFP+ 3m Direct Attach Copper Cable

JD097C

HPE FlexNetwork X240 10G SFP+ to SFP+ 5m Direct Attach Copper Cable

JG081C

HPE FlexNetwork X240 10G SFP+ SFP+ 7m Direct Attach Copper Cable

JC784C

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

Page

QuickSpecs

HPE FlexFabric 12500 Switch Series

Configuration

15

QSFP+ Transceivers

HPE X140 40G QSFP+ LC LR4 SM 10km 1310nm Transceiver

JG661A

HPE X140 40G QSFP+ MPO SR4 Transceiver

JG325B

HPE X140 40G QSFP+ MPO MM 850nm CSR4 300m Transceiver

JG709A

XFP Transceivers

HPE X135 10G XFP LC ER Transceiver

JD121A

HPE X130 10G XFP LC ZR Single Mode 80km 1550nm Transceiver

JD107A

HPE X130 10G XFP LC SR Transceiver

JD117B

HPE X130 10G XFP LC LR Single Mode 10km 1310nm Transceiver

JD108B

Internal Power Supplies

12508 and 12504 - System (std 0 // max 6) User Selection (min 3 // max 6)

12508E - System (std 0 // max 8) User Selection (min 3 // max 8)

12518 - System (std 0 // max 12) User Selection (min 6 // max 12)

HPE 12500 2000W AC Power Supply

JF429A

See Configuration

Configuration Rules:

Note 1

Supported on Switches JC654A, JG782A and JG784A only.

Remarks:

12504 only - Default 6 power supplies and allow the user to change down to 3.
12508E only
12518E only - Default 12 power supplies and allow the user to change down to 6.

The power module support load balancing and N+1/N+M redundancy. Deploying N+1 power redundancy
The total number of power modules (JF431C, JF430C) = Ceiling (total power load of the chassis/2000) + 1
For example, if the total load of the chassis i
Deploying 1:1 power redundancy
JF431C
JF430C
For example, if the total power load of
= 10.

Localization is not required on these internal AC power supplies. Localization is covered on the chassis for the 125x8E
AC models (JG782A, JG784A), or on the PEMs listed below for the AC 125xx models (JC654A).

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

NOTE:1

- Default 6 power supplies and allow the user to change down to 3.

s 3000 W, the number of power modules must be 2 + 1 = 3.

-Requires 6 power modules.

-Total number of power modules = [Ceiling (total power load of the chassis/2000) ] x 2
the chassis is 7000 W, the total number of power modules must be (4 + 1) x 2

Page

QuickSpecs

HPE FlexFabric 12500 Switch Series

Configuration

16

Server Specific Options

Multi-Mode Cables

HPE Premier Flex LC/LC Multi-mode OM4 2 fiber 1m Cable

QK732A

HPE Premier Flex LC/LC Multi-mode OM4 2 fiber 2m Cable

QK733A

HPE Premier Flex LC/LC Multi-mode OM4 2 fiber 5m Cable

QK734A

HPE Premier Flex LC/LC Multi-mode OM4 2 fiber 15m Cable

QK735A

HPE Premier Flex LC/LC Multi-mode OM4 2 fiber 30m Cable

QK736A

HPE Premier Flex LC/LC Multi-mode OM4 2 fiber 50m Cable

QK737A

Cable Guides

System (std 0 // max 1) User Selection (min 0 // max 1) Per Switch

HP 12500 Side Cable Management Guide

JC084A

HPE FlexFabric 12508E Optional Extended Cable Guide for AC Powered Switch

JG830A

See Configuration

NOTE:5

HPE FlexFabric 12518E Optional Extended Cable Guide for AC Powered Switch

JG831A

See Configuration

NOTE:6

Configuration Rules:

Note 5

Supported on Switch JG782A - HPE FlexFabric 12508E AC Switch Chassis only.

Note 6

Supported on Switch JG784A - HPE FlexFabric 12518E AC Switch Chassis only.

Remarks:

These items are optional .and used by customers for I/O cabling management.

Fan Assemblies

12504 Only - System (std 0 // max 1) User Selection (min 1 // max 1) Per Switch

12508 and 12518 Only - System (std 0 // max 2) User Selection (min 2 // max 2) Per Switch

HPE 12504 Fan Assembly

JC664A

See Configuration

NOTE:3

HPE FlexFabric 12500E Fan Tray Assembly

JG805A

See Configuration

NOTE:4

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

Page

QuickSpecs

HPE FlexFabric 12500 Switch Series

Configuration

17

Configuration Rules:

Note 3

Supported on Switch JC654A Switch Chassis only.

Note 4

Supported on JG782A and JG784A Switch Chassis only.

Air Filter Assemblies

System (std 0 // max 1) User Selection (min 0 // max 1)

HPE FlexFabric 12508E Optional Air Filter

JG808A

See Configuration

HPE FlexFabric 12518E Optional Air Filter

JG809A

See Configuration

Configuration Rules:

Note 3

Supported on Switch JG782A Switch Chassis only.

Note 4

Supported on Switch JC653A and JG784A Switch Chassis only.

Power Monitor Module

12508E and 12518E only-System (std 0 // max 1) User Selection (min 0 // max 1) Per Switch

HPE FlexFabric 12500E Spare Power Monitor Module

JG804A

See Configuration

NOTE:2

Configuration Rules:

Note 2

This item is only used to replace the Power Monitor Module of an JG782A, JG784A. A host is delivered with the
Power Monitor Module.

Mounting Kit

HPE X421 Chassis Universal 4-post Rackmount Kit

JC665A

Remarks:

This item is optional and used by customers to allow the chassis to slide in and out of the rack

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

NOTE:3

NOTE:4

Page

QuickSpecs

HPE FlexFabric 12500 Switch Series

Technical Specifications

18

HPE 12504 AC Switch Chassis (JC654A)

I/O ports and slots

4 open module slots

Supports a maximum of 192 Gigabit Ethernet ports or
192 1/10GbE ports or 64 40GbE ports, or a combination

Additional ports and

2 MPU (for management modules) slots

4 switch fabric slots

Physical characteristics

Dimensions

17.4(w) x 27.87(d) x 17.4(h) in (44.2 x 70.8 x 44.2 cm) (10U height)

Weight

132.28 lb (60 kg)

Full configuration weight

220.46 lb (100 kg)

Memory and processor

Gigabit Module

PowerPC @ 667 MHz, 1 GB RAM; Packet buffer size: 512 MB (Ingress,
shared by 24 1

10G Module

PowerPC @ 667 MHz, 1 GB RAM; Packet buffer size: 512 MB
(Ingress/shared by 2 10GbE ports)

Management Module

Quad Core CPU @ 1800 MHz, 512 MB flash, 4 GB compact flash, 8 GB
RAM

Fabric

PowerPC @ 400 MHz, 128 MB RAM

Mounting and enclosure

Mounts in an EIA-standard 19 in. Telco rack or equipment cabinet

Performance

Throughput

1920 Mpps

Routing/Switching
capacity

3240 Gb/s

Environment

Operating temperature

32°F to 104°F (0°C to 40°C)

Operating relative
humidity

5% to 95%, non-condensing

Nonoperating/Storage
temperature

-40°F to 158°F (-40°C to 70°C)

Nonoperating/Storage
relative humidity

5% to 95%, non-condensing

Electrical characteristics

Frequency

50/60 Hz

Maximum heat

8123 BTU/hr (8569.77 kJ/hr)

Voltage

100 - 120 / 200 - 240 VAC, rated
(depending on power supply chosen)

Maximum power rating

2380 W

Notes

Maximum power rating and maximum heat dissipation are the worst-case
theoretical maximum numbers provided for planning the infrastructure
with fully loaded PoE (if equipped), 100% traffic, all ports plugged in, and all
modules populated.

Safety

CE Labeled; cUL Certified; UL Listed; EN 60825-1 Safety of Laser Products-Part 1; EN 60825-2 Safety

1:2003; EN 60950-1:2001; ROHS Compliance

Emissions

VCCI Class A; EN 55022 Class A; VCCI V-3/2000.04; ICES-003 Class A; AS/NZS CISPR22 Class A; EMC
Directive 2004/108/EC; FCC (CFR 47, Part 15) Class A

Immunity

Generic

ETSI EN 300 386 V1.3.3

EN

EN 55024:1998+ A1:2001 + A2:2003

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

slots

-GbE ports)

dissipation

of Laser Products-Part 2; IEC 60825; IEC 60950-1:2001 (with CB Report); CAN/CSA-C22.2 No.
60950-1-03; Anatel; ULAR; GOST; EN 60950-1/A11; FDA 21 CFR Subchapter J; NOM; UL 60950-

Page

QuickSpecs

HPE FlexFabric 12500 Switch Series

Technical Specifications

19

ESD

EN 61000-4-2; IEC61000-4-2

Radiated

EN 61000-4-3; IEC61000-4-3

EFT/Burst

EN 61000-4-4; IEC61000-4-4

Surge

EN 61000-4-5; IEC61000-4-5

Conducted

EN 61000-4-6; IEC61000-4-6

Power frequency
magnetic field

IEC 61000-4-8; EN61000-4-8

Voltage dips and
interruptions

EN 61000-4-11; IEC61000-4-11

Harmonics

EN 61000-3-2, IEC 61000-3-2

Flicker

EN 61000-3-3, IEC 61000-3-3

Management

IMC - Intelligent Management Center; command-line interface; out-of-band management (serial RS-

Services

Refer to the Hewlett Packard Enterprise website at: http://www.hpe.com/networking/services for

HPE 12504 DC Switch Chassis (JC655A)

I/O ports and slots

4 open module slots

Additional ports and
slots

2 MPU (for management modules) slots

Physical characteristics

Dimensions

17.4(w) x 27.87(d) x 17.4(h) in (44.2 x 70.8 x 44.2 cm) (10U height)

Weight

132.28 lb (60 kg)

Full configuration weight

220.46 lb (100 kg)

Memory and processor

Gigabit Module

PowerPC @ 667 MHz, 1 GB RAM; Packet buffer size: 512 MB (Ingress,
shared by 24 1-GbE ports)

10G Module

PowerPC @ 667 MHz, 1 GB RAM; Packet buffer size: 512 MB
(Ingress/shared by 2 10GbE ports)

Management Module

Quad Core CPU @ 1800 MHz, 512 MB flash, 4 GB compact flash, 8 GB
RAM

Fabric

PowerPC @ 400 MHz, 128 MB RAM

Mounting and enclosure

Mounts in an EIA-standard 19 in. Telco rack or equipment cabinet

Performance

Throughput

up to 1920 Mpps

Routing/Switching
capacity

3240 Gbps

Environment

Operating temperature

32°F to 104°F (0°C to 40°C)

Operating relative
humidity

5% to 95%, non-condensing

Nonoperating/Storage
temperature

-40°F to 158°F (-40°C to 70°C)

Nonoperating/Storage
relative humidity

5% to 95%, non-condensing

Electrical characteristics

Maximum heat
dissipation

8123 BTU/hr (8569.77 kJ/hr)

Voltage

-48 to -60 VDC, rated

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

232C); SNMP Manager; Telnet; RMON1; FTP; in-line and out-of-band; terminal interface (serial RS­232C); modem interface

details on the service-level descriptions and product numbers. For details about services and response
times in your area, please contact your local Hewlett Packard Enterprise sales office

Supports a maximum of 192 Gigabit Ethernet ports or 192 1/10GbE ports or 64 40GbE ports, or a
combination

4 switch fabric slots

Page

QuickSpecs

HPE FlexFabric 12500 Switch Series

Technical Specifications

20

(depending on power supply chosen)

Maximum power rating

2380 W

Notes

Maximum power rating and maximum heat dissipation are the worst-case
theoretical maximum numbers provided f
with fully loaded PoE (if equipped), 100% traffic, all ports plugged in, and all
modules populated.

Safety

CE Labeled; cUL Certified; UL Listed; EN 60825-1 Safety of Laser Products-Part 1; EN 60825-2 Safety

1:2003; EN 60950-1:2001; ROHS Compliance

Emissions

VCCI Class A; EN 55022 Class A; VCCI V-3/2000.04; ICES-003 Class A; AS/NZS CISPR22 Class A; EMC
Directive 2004/108/EC; FCC (CFR 47, Part 15) Class A

Immunity

Generic

ETSI EN 300 386 V1.3.3

EN

EN 55024:1998+ A1:2001 + A2:2003

ESD

EN 61000-4-2; IEC61000-4-2

Radiated

EN 61000-4-3; IEC61000-4-3

EFT/Burst

EN 61000-4-4; IEC61000-4-4

Surge

EN 61000-4-5; IEC61000-4-5

Conducted

EN 61000-4-6; IEC61000-4-6

Power frequency
magnetic field

IEC 61000-4-8; EN61000-4-8

Voltage dips and
interruptions

EN 61000-4-11; IEC61000-4-11

Harmonics

EN 61000-3-2, IEC 61000-3-2

Flicker

EN 61000-3-3, IEC 61000-3-3

Management

IMC - Intelligent Management Center; command-line interface; out-of-band management (serial RS-

232C); modem interface

Services

Refer to the Hewlett Packard Enterprise website at: http://www.hpe.com/networking/services for

times in your area, please contact your local Hewlett Packard Enterprise sales office

HP 12508 AC Switch Chassis (JF431C)

I/O ports and slots

8 open module slots

combination

Additional ports and
slots

2 MPU (for management modules) slots

Physical characteristics

Dimensions

17.4(d) x 29.13(w) x 38.39(h) in. (44.2 x 73.99 x 97.51 cm) (22U height)

Weight

209.44 lb (95 kg)

Full configuration weight

374.78 lb. (170 kg)

Memory and processor

Gigabit Module

PowerPC @ 667 MHz, 1 GB RAM; Packet buffer size: 512 MB (Ingress,
shared by 24 1-GbE ports)

10G Module

PowerPC @ 667 MHz, 1 GB RAM; Packet buffer size: 512 MB
(Ingress/shared by 2 10GbE ports)

Management Module

Quad Core CPU @ 1800 MHz, 512 MB flash, 4 GB compact flash, 8 GB
RAM

Fabric

PowerPC @ 400 MHz, 128 MB RAM

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

or planning the infrastructure

of Laser Products-Part 2; IEC 60825; IEC 60950-1:2001 (with CB Report); CAN/CSA-C22.2 No.
60950-1-03; Anatel; ULAR; GOST; EN 60950-1/A11; FDA 21 CFR Subchapter J; NOM; UL 60950-

232C); SNMP Manager; Telnet; RMON1; FTP; in-line and out-of-band; terminal interface (serial RS-

details on the service-level descriptions and product numbers. For details about services and response

Supports a maximum of 384 Gigabit Ethernet ports or 384 1/10GbE ports or 128 40GbE ports, or a

9 switch fabric slots

Page

QuickSpecs

HPE FlexFabric 12500 Switch Series

Technical Specifications

21

Mounting and enclosure

Mounts in an EIA-standard 19 in. Telco rack or equipment cabinet

Performance

Throughput

up to 3840 Mpps

Routing/Switching
capacity

6120 Gbps

Environment

Operating temperature

32°F to 104°F (0°C to 40°C)

Operating relative
humidity

5% to 95%, non-condensing

Nonoperating/Storage
temperature

-40°F to 158°F (-40°C to 70°C)

Nonoperating/Storage
relative humidity

5% to 95%, non-condensing

Electrical characteristics

Frequency

50/60 Hz

Achieved Miercom Certified Green Award*

* Products within this series have achieved sufficient scores in each of the rated criteria to achieve

information.

Description

10GbE modules consume half the power compared to competitive
products; redundant, scalable, 90% efficient pow
reliability in the data center; new ASIC technology has low power
consumption when providing rich features.

Maximum heat
dissipation

14587 BTU/hr (15389.29 kJ/hr)

Voltage

100 - 120 / 200 - 240 VAC, rated
(depending on power supply chosen)

Maximum power rating

4750 W

Notes

Maximum power rating and maximum heat dissipation are the worst-case
theoretical maximum numbers provided for planning the infrastructure
with fully loaded PoE (if equipped), 100% traffic, all ports plugged in, and all
modules populated.

Safety

CE Labeled; cUL Certified; UL Listed; EN 60825-1 Safety of Laser Products-Part 1; EN 60825-2 Safety

Emissions

VCCI Class A; EN 55022 Class A; VCCI V-3/2000.04; ICES-003 Class A; AS/NZS CISPR22 Class A; EMC
Directive 2004/108/EC; FCC (CFR 47, Part 15) Class A

Immunity

Generic

ETSI EN 300 386 V1.3.3

EN

EN 55024:1998+ A1:2001 + A2:2003

ESD

EN 61000-4-2; IEC61000-4-2

Radiated

EN 61000-4-3; IEC61000-4-3

EFT/Burst

EN 61000-4-4; IEC61000-4-4

Surge

EN 61000-4-5; IEC61000-4-5

Conducted

EN 61000-4-6; IEC61000-4-6

Power frequency
magnetic field

IEC 61000-4-8; EN61000-4-8

Voltage dips and
interruptions

EN 61000-4-11; IEC61000-4-11

Harmonics

EN 61000-3-2, IEC 61000-3-2

Flicker

EN 61000-3-3, IEC 61000-3-3

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

the Miercom Certified Green distinction Award. See the Specifications section of this series for more

er supplies deliver high

of Laser Products-Part 2; IEC 60825; IEC 60950-1:2001 (with CB Report); CAN/CSA-C22.2 No.
60950-1-03; Anatel; ULAR; GOST; EN 60950-1/A11; FDA 21 CFR Subchapter J; NOM; UL 60950­1:2003; EN 60950-1:2001; ROHS Compliance

Page

QuickSpecs

HPE FlexFabric 12500 Switch Series

Technical Specifications

22

Management

IMC - Intelligent Management Center; command-line interface; out-of-band management (serial RS-

232C); modem interface

Services

Refer to the Hewlett Packard Enterprise website at: http://www.hpe.com/networking/services for

times in your area, please contact your local Hewlett Packard Enterprise sales office

HP 12508 DC Switch Chassis (JC652A)

I/O ports and slots

8 open module slots

combination

Additional ports and

2 MPU (for management modules) slots

Physical characteristics

Dimensions

17.4(d) x 29.13(w) x 38.39(h) in. (44.2 x 73.99 x 97.51 cm) (22U height)

Weight

209.44 lb (95 kg)

Full configuration weight

374.78 lb. (170 kg)

Memory and processor

Gigabit Module

PowerPC @ 667 MHz, 1 GB RAM; Packet buffer size: 512 MB (Ingress,
shared by 24 1-GbE ports)

10G Module

PowerPC @ 667 MHz, 1 GB RAM; Packet buffer size: 512 MB
(Ingress/shared by 2 10GbE ports)

Management Module

Quad Core CPU @ 1800 MHz, 512 MB flash, 4 GB compact flash, 8 GB
RAM

Fabric

PowerPC @ 400 MHz, 128 MB RAM MB

Mounting

Mounts in an EIA-standard 19 in. Telco rack or equipment cabinet

Performance

Throughput

up to 3840 Mpps

Routing/Switching
capacity

6120 Gbps

Environment

Operating temperature

32°F to 104°F (0°C to 40°C)

Operating relative
humidity

5% to 95%, non-condensing

Nonoperating/Storage
temperature

-40°F to 158°F (-40°C to 70°C)

Nonoperating/Storage
relative humidity

5% to 95%, non-condensing

Electrical characteristics

Maximum heat
dissipation

14587 BTU/hr (15389.29 kJ/hr)

Voltage

-48 to -60 VDC, rated
(depending on power supply chosen)

Maximum power rating

4750 W

Notes

Maximum power rating and maximum heat dissipation are the worst-case
theoretical maximum numbers p
with fully loaded PoE (if equipped), 100% traffic, all ports plugged in, and all
modules populated.

Safety

CE Labeled; cUL Certified; UL Listed; EN 60825-1 Safety of Laser Products-Part 1; EN 60825-2 Safety

1:2003; EN 60950-1:2001; ROHS Compliance

Emissions

VCCI Class A; EN 55022 Class A; VCCI V-3/2000.04; ICES-003 Class A; AS/NZS CISPR22 Class A; EMC

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

232C); SNMP Manager; Telnet; RMON1; FTP; in-line and out-of-band; terminal interface (serial RS-

details on the service-level descriptions and product numbers. For details about services and response

Supports a maximum of 384 Gigabit Ethernet ports or 384 1/10GbE ports or 128 40GbE ports, or a

slots

9 switch fabric slots

rovided for planning the infrastructure

of Laser Products-Part 2; IEC 60825; IEC 60950-1:2001 (with CB Report); CAN/CSA-C22.2 No.
60950-1-03; Anatel; ULAR; GOST; EN 60950-1/A11; FDA 21 CFR Subchapter J; NOM; UL 60950-

Directive 2004/108/EC; FCC (CFR 47, Part 15) Class A

Page

QuickSpecs

HPE FlexFabric 12500 Switch Series

Technical Specifications

23

Immunity

Generic

ETSI EN 300 386 V1.3.3

EN

EN 55024:1998+ A1:2001 + A2:2003

ESD

EN 61000-4-2; IEC61000-4-2

Radiated

EN 61000-4-3; IEC61000-4-3

EFT/Burst

EN 61000-4-4; IEC61000-4-4

Surge

EN 61000-4-5; IEC61000-4-5

Conducted

EN 61000-4-6; IEC61000-4-6

Power frequency
magnetic field

IEC 61000-4-8; EN61000-4-8

Voltage dips and
interruptions

EN 61000-4-11; IEC61000-4-11

Harmonics

EN 61000-3-2, IEC 61000-3-2

Flicker

EN 61000-3-3, IEC 61000-3-3

Management

IMC - Intelligent Management Center; command-line interface; out-of-band management (serial RS-

232C); modem interface

Services

Refer to the Hewlett Packard Enterprise website at: http://www.hpe.com/networking/services for

times in your area, please contact your local Hewlett Packard Enterprise sales office

HP 12518 AC Switch Chassis (JF430C)

I/O ports and slots

18 open module slots

combination

Additional ports and
slots

2 MPU (for management modules) slots

Physical characteristics

Dimensions

17.4(d) x 29.13(w) x 66.38(h) in. (44.2 x 73.99 x 168.61 cm) (38U
height)

Weight

352.74 lb (160 kg)

Full configuration weight

639.33 lb (290 kg)

Memory and processor

Gigabit Module

PowerPC @ 667 MHz, 1 GB RAM; Packet buffer size: 512 MB (Ingress,
shared by 24 1

10G Module

PowerPC @ 667 MHz, 1 GB RAM; Packet buffer size: 512 MB
(Ingress/shared by 2 10GbE ports)

Management Module

Quad Core CPU @ 1800 MHz, 512 MB flash, 4 GB compact flash, 8 GB
RAM

Fabric

PowerPC @ 400 MHz, 128 MB RAM

Mounting and enclosure

Mounts in an EIA-standard 19 in. Telco rack or equipment cabinet

Performance

Throughput

up to 8640 Mpps

Routing/Switching
capacity

13.3 Tbps

Environment

Operating temperature

32°F to 104°F (0°C to 40°C)

Operating relative
humidity

5% to 95%, non-condensing

Nonoperating/Storage
temperature

-40°F to 158°F (-40°C to 70°C)

Nonoperating/Storage
relative humidity

5% to 95%, non-condensing

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

232C); SNMP Manager; Telnet; RMON1; FTP; in-line and out-of-band; terminal interface (serial RS-

details on the service-level descriptions and product numbers. For details about services and response

Supports a maximum of 864 Gigabit Ethernet ports or 864 1/10GbE ports or 288 40GbE ports, or a

9 switch fabric slots

-GbE ports)

Page

QuickSpecs

HPE FlexFabric 12500 Switch Series

Technical Specifications

24

Electrical characteristics

Frequency

50/60 Hz

Maximum heat
dissipation

32859 BTU/hr (34666.24 kJ/hr)

Voltage

100 - 120 / 200 - 240 VAC, rated
(depending on power supply chosen)

Maximum power rating

10700 W

Notes

Maximum power rating and maximum heat dissipation are the worst-case
theoretical maximum numbers provided for planning the infrastructure
with fully loaded PoE (if equipped), 100% traffic, all ports plugged in, and all
modules populated.

Safety

CE Labeled; cUL Certified; UL Listed; EN 60825-1 Safety of Laser Products-Part 1; EN 60825-2 Safety

1:2003; EN 60950-1:2001; ROHS Compliance

Emissions

VCCI Class A; EN 55022 Class A; VCCI V-3/2000.04; ICES-003 Class A; AS/NZS CISPR22 Class A; EMC
Directive 2004/108/EC; FCC (CFR 47, Part 15) Class A

Immunity

Generic

ETSI EN 300 386 V1.3.3

EN

EN 55024:1998+ A1:2001 + A2:2003

ESD

EN 61000-4-2; IEC61000-4-2

Radiated

EN 61000-4-3; IEC61000-4-3

EFT/Burst

EN 61000-4-4; IEC61000-4-4

Surge

EN 61000-4-5; IEC61000-4-5

Conducted

EN 61000-4-6; IEC61000-4-6

Power frequency
magnetic field

IEC 61000-4-8; EN61000-4-8

Voltage dips and
interruptions

EN 61000-4-11; IEC61000-4-11

Harmonics

EN 61000-3-2, IEC 61000-3-2

Flicker

EN 61000-3-3, IEC 61000-3-3

Management

IMC - Intelligent Management Center; command-line interface; out-of-band management (serial RS-

232C); modem interface

Services

Refer to the Hewlett Packard Enterprise website at: http://www.hpe.com/networking/services for

HP 12518 DC Switch Chassis (JC653A)

I/O ports and slots

18 open module slots

combination

Additional ports and
slots

2 MPU (for management modules) slots

Physical characteristics

Dimensions

17.4(d) x 29.13(w) x 66.38(h) in. (44.2 x 73.99 x 168.61 cm) (38U
height)

Weight

352.74 lb (160 kg)

Full configuration weight

639.33 lb (290 kg)

Memory and processor

Gigabit Module

PowerPC @ 667 MHz, 1 GB RAM; Packet buffer size: 512 MB (Ingress,
shared by 24 1-GbE ports)

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

of Laser Products-Part 2; IEC 60825; IEC 60950-1:2001 (with CB Report); CAN/CSA-C22.2 No.
60950-1-03; Anatel; ULAR; GOST; EN 60950-1/A11; FDA 21 CFR Subchapter J; NOM; UL 60950-

232C); SNMP Manager; Telnet; RMON1; FTP; in-line and out-of-band; terminal interface (serial RS-

details on the service-level descriptions and product numbers. For details about services and response
times in your area, please contact your local Hewlett Packard Enterprise sales office

Supports a maximum of 864 Gigabit Ethernet ports or 864 1/10GbE ports or 288 40GbE ports, or a

9 switch fabric slots

Page

QuickSpecs

HPE FlexFabric 12500 Switch Series

Technical Specifications

25

10G Module

PowerPC @ 667 MHz, 1 GB RAM; Packet buffer size: 512 MB
(Ingress/shared by 2 10GbE ports)

Management Module

Quad Core CPU @ 1800 MHz, 512 MB flash, 4 GB compact flash, 8 GB
RAM

Fabric

PowerPC @ 400 MHz, 128 MB RAM

Mounting and enclosure

Mounts in an EIA-standard 19 in. Telco rack or equipment cabinet

Performance

Throughput

up to 8640 Mpps

Routing/Switching
capacity

13.3 Tbps

Environment

Operating temperature

32°F to 104°F (0°C to 40°C)

Operating relative
humidity

5% to 95%, non-condensing

Nonoperating/Storage
temperature

-40°F to 158°F (-40°C to 70°C)

Nonoperating/Storage
relative humidity

5% to 95%, non-condensing

Electrical characteristics

Maximum heat
dissipation

32859 BTU/hr (34666.24 kJ/hr)

Maximum power rating

10700 W

Voltage

-48 to -60 VDC, rated
(depending on power supply chosen)

Notes

Maximum power rating and maximum heat dissipation are the worst-case
theoreti
with fully loaded PoE (if equipped), 100% traffic, all ports plugged in, and all
modules populated.

Safety

CE Labeled; cUL Certified; UL Listed; EN 60825-1 Safety of Laser Products-Part 1; EN 60825-2 Safety

1:2003; EN 60950-1:2001; ROHS Compliance

Emissions

VCCI Class A; EN 55022 Class A; VCCI V-3/2000.04; ICES-003 Class A; AS/NZS CISPR22 Class A; EMC
Directive 2004/108/EC; FCC (CFR 47, Part 15) Class A

Immunity

Generic

ETSI EN 300 386 V1.3.3

EN

EN 55024:1998+ A1:2001 + A2:2003

ESD

EN 61000-4-2; IEC61000-4-2

Radiated

EN 61000-4-3; IEC61000-4-3

EFT/Burst

EN 61000-4-4; IEC61000-4-4

Surge

EN 61000-4-5; IEC61000-4-5

Conducted

EN 61000-4-6; IEC61000-4-6

Power frequency
magnetic field

IEC 61000-4-8; EN61000-4-8

Voltage dips and
interruptions

EN 61000-4-11; IEC61000-4-11

Harmonics

EN 61000-3-2, IEC 61000-3-2

Flicker

EN 61000-3-3, IEC 61000-3-3

Management

IMC - Intelligent Management Center; command-line interface; out-of-band management (serial RS-

232C); modem interface

Services

Refer to the Hewlett Packard Enterprise website at: http://www.hpe.com/networking/services for

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

cal maximum numbers provided for planning the infrastructure

of Laser Products-Part 2; IEC 60825; IEC 60950-1:2001 (with CB Report); CAN/CSA-C22.2 No.
60950-1-03; Anatel; ULAR; GOST; EN 60950-1/A11; FDA 21 CFR Subchapter J; NOM; UL 60950-

232C); SNMP Manager; Telnet; RMON1; FTP; in-line and out-of-band; terminal interface (serial RS-

Page

QuickSpecs

HPE FlexFabric 12500 Switch Series

Technical Specifications

26

details on the service-level descriptions and product numbers. For details about services and response
times in your area, please contact your local Hewlett Packard Enterprise sales office

HPE FlexFabric 12508E AC Switch Chassis (JG782A)

I/O ports and slots

8 open module slots
Supports a maximum of 384 Gigabit Ethernet ports or 384 1/10GbE ports or 128 40GbE ports

Additional ports and
slots

2 MPU (for management modules) slots

Physical characteristics

Dimensions

17.4(w) x 29.13(d) x 38.39(h) in (44.2 x 74.0 x 97.51 cm) (22U height)

Weight

242.51 lb (110 kg)

Full configuration weight

374.78 lb (170 kg)

Memory and processor

Gigabit Module

PowerPC @ 667 MHz, 1 GB RAM; Packet buffer size: 512 MB (Ingress,
shared by 24 1-GbE ports)

10G Module

PowerPC @ 667 MHz, 1 GB RAM; Packet buffer size: 512 MB
(Ingress/shared by 2 10GbE ports)

Management Module

Quad Core CPU @ 1800 MHz, 512 MB flash, 4 GB compact flash, 8 GB
RAM

Fabric

PowerPC @ 400 MHz, 128 MB RAM

Mounting and enclosure

Mounts in an EIA-standard 19 in. Telco rack or equipment cabinet

Performance

Throughput

up to 4800 Mpps

Routing/Switching
capacity

10.8 Tbps

Environment

Operating temperature

32°F to 104°F (0°C to 40°C)

Operating relative

5% to 95%, non-condensing

Nonoperating/Storage
temperature

-40°F to 158°F (-40°C to 70°C)

Nonoperating/Storage
relative humidity

5% to 95%, non-condensing

Electrical characteristics

Frequency

50/60 Hz

Achieved Miercom Certified Green Award

Description

10GbE modules consume half the power compared to competitive
products; redundant, scalable, 90% efficient power supplies deliver high
reliability in the data center; new ASIC technology has low power
consumption when providing rich features.

Maximum heat
dissipation

14587 BTU/hr (15389.29 kJ/hr)

Voltage

100 - 120 / 200 - 240 VAC, rated
(depending on power supply chosen)

Maximum power rating

4750 W

Notes

Maximum power rating and maximum heat dissipation are the worst-case
theoretical maximum numbers provided for planning the infrastructure
with fully loaded PoE (if equipped), 100% traffic, all ports plugged in, and all
modules populated.

Safety

CE Labeled; cUL Certified; UL Listed; EN 60825-1 Safety of Laser Products-Part 1; EN 60825-2 Safety

1:2003; EN 60950-1:2001; ROHS Compliance

Emissions

VCCI Class A; EN 55022 Class A; VCCI V-3/2000.04; ICES-003 Class A; AS/NZS CISPR22 Class A; EMC

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

9 switch fabric slots

humidity

of Laser Products-Part 2; IEC 60825; IEC 60950-1:2001 (with CB Report); CAN/CSA-C22.2 No.
60950-1-03; Anatel; ULAR; GOST; EN 60950-1/A11; FDA 21 CFR Subchapter J; NOM; UL 60950-

Page

QuickSpecs

HPE FlexFabric 12500 Switch Series

Technical Specifications

27

Directive 2004/108/EC; FCC (CFR 47, Part 15) Class A

Immunity

Generic

ETSI EN 300 386 V1.3.3

EN

EN 55024:1998+ A1:2001 + A2:2003

ESD

EN 61000-4-2; IEC61000-4-2

Radiated

EN 61000-4-3; IEC61000-4-3

EFT/Burst

EN 61000-4-4; IEC61000-4-4

Surge

EN 61000-4-5; IEC61000-4-5

Conducted

EN 61000-4-6; IEC61000-4-6

Power frequency
magnetic field

IEC 61000-4-8; EN61000-4-8

Voltage dips and
interruptions

EN 61000-4-11; IEC61000-4-11

Harmonics

EN 61000-3-2, IEC 61000-3-2

Flicker

EN 61000-3-3, IEC 61000-3-3

Management

IMC - Intelligent Management Center; command-line interface; out-of-band management (serial RS-

232C); modem interface

Services

Refer to the Hewlett Packard Enterprise website at: http://www.hpe.com/networking/services for

times in your area, please contact your local Hewlett Packard Enterprise sales office

HPE FlexFabric 12508E DC Switch Chassis (JG783A)

I/O ports and slots

8 open module slots
Supports a maximum of 384 Gigabit Ethernet ports or 384 1/10GbE ports or 128 40GbE ports

Additional ports and
slots

2 MPU (for management modules) slots

Physical characteristics

Dimensions

17.4(w) x 29.13(d) x 38.39(h) in (44.2 x 73.99 x 97.51 cm) (22U height)

Weight

209.44 lb (95 kg)

Full configuration weight

374.78 lb (170 kg)

Memory and processor

Gigabit Module

PowerPC @ 667 MHz, 1 GB RAM; Packet buffer size: 512 MB (Ingress,
shared by 24 1-GbE ports)

10G Module

PowerPC @ 667 MHz, 1 GB RAM; Packet buffer size: 512 MB
(Ingress/shared by 2 10GbE ports)

Management Module

Quad Core CPU @ 1800 MHz, 512 MB flash, 4 GB compact flash, 8 GB
RAM

Fabric

PowerPC @ 400 MHz, 128 MB RAM

Mounting and enclosure

Mounts in an EIA-standard 19 in. Telco rack or equipment cabinet

Performance

Throughput

up to 4800 Mpps

Routing/Switching
capacity

10.8 Tbps

Environment

Operating temperature

32°F to 104°F (0°C to 40°C)

Operating relative
humidity

5% to 95%, non-condensing

Nonoperating/Storage
temperature

-40°F to 158°F (-40°C to 70°C)

Nonoperating/Storage
relative humidity

5% to 95%, non-condensing

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

232C); SNMP Manager; Telnet; RMON1; FTP; in-line and out-of-band; terminal interface (serial RS-

details on the service-level descriptions and product numbers. For details about services and response

9 switch fabric slots

Page

QuickSpecs

HPE FlexFabric 12500 Switch Series

Technical Specifications

28

Electrical characteristics

Maximum heat
dissipation

14587 BTU/hr (15389.29 kJ/hr)

Maximum power rating

4750 W

Voltage

-48 to -60 VDC, rated
(depending on power supply chosen)

Notes

Maximum power rating and maximum heat dissipation are the worst-case
theoretical maximum numbers provided for planning the infrastructure
with fully loaded PoE (if equipped), 100% traffic, all ports plugged in, and all
modules populated.

Safety

CE Labeled; cUL Certified; UL Listed; EN 60825-1 Safety of Laser Products-Part 1; EN 60825-2 Safety

1:2003; EN 60950-1:2001; ROHS Compliance

Emissions

VCCI Class A; EN 55022 Class A; VCCI V-3/2000.04; ICES-003 Class A; AS/NZS CISPR22 Class A; EMC
Directive 2004/108/EC; FCC (CFR 47, Part 15) Class A

Immunity

Generic

ETSI EN 300 386 V1.3.3

EN

EN 55024:1998+ A1:2001 + A2:2003

ESD

EN 61000-4-2; IEC61000-4-2

Radiated

EN 61000-4-3; IEC61000-4-3

EFT/Burst

EN 61000-4-4; IEC61000-4-4

Surge

EN 61000-4-5; IEC61000-4-5

Conducted

EN 61000-4-6; IEC61000-4-6

Power frequency
magnetic field

IEC 61000-4-8; EN61000-4-8

Voltage dips and
interruptions

EN 61000-4-11; IEC61000-4-11

Harmonics

EN 61000-3-2, IEC 61000-3-2

Flicker

EN 61000-3-3, IEC 61000-3-3

Management

IMC - Intelligent Management Center; command-line interface; out-of-band management (serial RS-

232C); modem interface

Services

Refer to the Hewlett Packard Enterprise website at: http://www.hpe.com/networking/services for

times in your area, please contact your local Hewlett Packard Enterprise sales office

HPE FlexFabric 12518E AC Switch Chassis (JG784A)

I/O ports and slots

18 open module slots

combination

Additional ports and

2 MPU (for management modules) slots

Physical characteristics

Dimensions

17.4(w) x 29.13(d) x 66.38(h) in (44.2 x 73.99 x 168.61 cm) (38U height)

Weight

352.74 lb (160 kg)

Full configuration weight

639.33 lb (290 kg)

Memory and processor

Gigabit Module

PowerPC @ 667 MHz, 1 GB RAM; Packet buffer size: 512 MB (Ingress,
shared by 24 1-GbE ports)

10G Module

PowerPC @ 667 MHz, 1 GB RAM; Packet buffer size: 512 MB
(Ingress/shared by 2 10GbE ports)

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

of Laser Products-Part 2; IEC 60825; IEC 60950-1:2001 (with CB Report); CAN/CSA-C22.2 No.
60950-1-03; Anatel; ULAR; GOST; EN 60950-1/A11; FDA 21 CFR Subchapter J; NOM; UL 60950-

slots

232C); SNMP Manager; Telnet; RMON1; FTP; in-line and out-of-band; terminal interface (serial RS-

details on the service-level descriptions and product numbers. For details about services and response

Supports a maximum of 864 Gigabit Ethernet ports or 864 1/10GbE ports or 288 40GbE ports, or a

9 switch fabric slots

Page

QuickSpecs

HPE FlexFabric 12500 Switch Series

Technical Specifications

29

Management Module

Quad Core CPU @ 1800 MHz, 512 MB flash, 4 GB compact flash, 8 GB
RAM

Fabric

PowerPC @ 400 MHz, 128 MB RAM

Mounting and
enclosure

Mounts in an EIA-standard 19 in. Telco rack or equipment cabinet

Performance

Throughput

up to 10.8 Bpps

Routing/Switching
capacity

24.3 Tbps

Environment

Operating temperature

32°F to 104°F (0°C to 40°C)

Operating relative
humidity

5% to 95%, non-condensing

Nonoperating/Storage
temperature

-40°F to 158°F (-40°C to 70°C)

Nonoperating/Storage

5% to 95%, non-condensing

Electrical characteristics

Frequency

50/60 Hz

Maximum heat
dissipation

32859 BTU/hr (34666.24 kJ/hr)

Voltage

100 - 120 / 200 - 240 VAC, rated
(depending on power supply chosen)

Maximum power rating

10700 W

Notes

Maximum power rating and maximum heat dissipation are the worst-case
theoretical maximum numbers provided for planning the
with fully loaded PoE (if equipped), 100% traffic, all ports plugged in, and all
modules populated.

Safety

CE Labeled; cUL Certified; UL Listed; EN 60825-1 Safety of Laser Products-Part 1; EN 60825-2 Safety

1:2003; EN 60950-1:2001; ROHS Compliance

Emissions

VCCI Class A; EN 55022 Class A; VCCI V-3/2000.04; ICES-003 Class A; AS/NZS CISPR22 Class A; EMC
Directive 2004/108/EC; FCC (CFR 47, Part 15) Class A

Immunity

Generic

ETSI EN 300 386 V1.3.3

EN

EN 55024:1998+ A1:2001 + A2:2003

ESD

EN 61000-4-2; IEC61000-4-2

Radiated

EN 61000-4-3; IEC61000-4-3

EFT/Burst

EN 61000-4-4; IEC61000-4-4

Surge

EN 61000-4-5; IEC61000-4-5

Conducted

EN 61000-4-6; IEC61000-4-6

Power frequency
magnetic field

IEC 61000-4-8; EN61000-4-8

Voltage dips and

EN 61000-4-11; IEC61000-4-11

Harmonics

EN 61000-3-2, IEC 61000-3-2

Flicker

EN 61000-3-3, IEC 61000-3-3

Management

IMC - Intelligent Management Center; command-line interface; out-of-band management (serial RS-

232C); modem interface

Services

Refer to the Hewlett Packard Enterprise website at: http://www.hpe.com/networking/services for

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

relative humidity

infrastructure

of Laser Products-Part 2; IEC 60825; IEC 60950-1:2001 (with CB Report); CAN/CSA-C22.2 No.
60950-1-03; Anatel; ULAR; GOST; EN 60950-1/A11; FDA 21 CFR Subchapter J; NOM; UL 60950-

interruptions

232C); SNMP Manager; Telnet; RMON1; FTP; in-line and out-of-band; terminal interface (serial RS-

Page

QuickSpecs

HPE FlexFabric 12500 Switch Series

Technical Specifications

30

details on the service-level descriptions and product numbers. For details about services and response
times in your area, please contact your local Hewlett Packard Enterprise sales office

HPE FlexFabric 12518E DC Switch Chassis (JG785A)

I/O ports and slots

18 open module slots

combination

Additional ports and
slots

2 MPU (for management modules) slots

Physical characteristics

Dimensions

17.4(w) x 29.13(d) x 66.38(h) in (44.2 x 73.99 x 168.61 cm) (38U height)

Weight

352.74 lb (160 kg)

Full configuration weight

639.33 lb (290 kg)

Memory and processor

Gigabit Module

PowerPC @ 667 MHz, 1 GB RAM; Packet buffer size: 512 MB (Ingress,
shared by 24 1-GbE ports)

10G Module

PowerPC @ 667 MHz, 1 GB RAM; Packet buffer size: 512 MB
(Ingress/shared by 2 10GbE ports)

Management Module

Quad Core CPU @ 1800 MHz, 512 MB flash, 4 GB compact flash, 8 GB
RAM

Fabric

PowerPC @ 400 MHz, 128 MB RAM

Mounting and
enclosure

Mounts in an EIA-standard 19 in. Telco rack or equipment cabinet

Performance

Throughput

up to 10.8 Bpps

Routing/Switching

24.3 Tbps

Environment

Operating temperature

32°F to 104°F (0°C to 40°C)

Operating relative
humidity

5% to 95%, non-condensing

Nonoperating/Storage
temperature

-40°F to 158°F (-40°C to 70°C)

Nonoperating/Storage
relative humidity

5% to 95%, non-condensing

Electrical characteristics

Maximum heat
dissipation

32859 BTU/hr (34666.24 kJ/hr)

Maximum power rating

10700 W

Voltage

-48 to -60 VDC, rated
(depending on power supply ch

Notes

Maximum power rating and maximum heat dissipation are the worst-case
theoretical maximum numbers provided for planning the infrastructure
with fully loaded PoE (if equipped), 100% traffic, all ports plugged in, and all
modules populated.

Safety

CE Labeled; cUL Certified; UL Listed; EN 60825-1 Safety of Laser Products-Part 1; EN 60825-2 Safety

1:2003; EN 60950-1:2001; ROHS Compliance

Emissions

VCCI Class A; EN 55022 Class A; VCCI V-3/2000.04; ICES-003 Class A; AS/NZS CISPR22 Class A; EMC
Directive 2004/108/EC; FCC (CFR 47, Part 15) Class A

Immunity

Generic

ETSI EN 300 386 V1.3.3

EN

EN 55024:1998+ A1:2001 + A2:2003

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

Supports a maximum of 864 Gigabit Ethernet ports or 864 1/10GbE ports or 288 40GbE ports, or a

9 switch fabric slots

capacity

osen)

of Laser Products-Part 2; IEC 60825; IEC 60950-1:2001 (with CB Report); CAN/CSA-C22.2 No.
60950-1-03; Anatel; ULAR; GOST; EN 60950-1/A11; FDA 21 CFR Subchapter J; NOM; UL 60950-

Page

QuickSpecs

HPE FlexFabric 12500 Switch Series

Technical Specifications

31

ESD

EN 61000-4-2; IEC61000-4-2

Radiated

EN 61000-4-3; IEC61000-4-3

EFT/Burst

EN 61000-4-4; IEC61000-4-4

Surge

EN 61000-4-5; IEC61000-4-5

Conducted

EN 61000-4-6; IEC61000-4-6

Power frequency
magnetic field

IEC 61000-4-8; EN61000-4-8

Voltage dips and
interruptions

EN 61000-4-11; IEC61000-4-11

Harmonics

EN 61000-3-2, IEC 61000-3-2

Flicker

EN 61000-3-3, IEC 61000-3-3

Management

IMC - Intelligent Management Center; command-line interface; out-of-band management (serial RS-

Services

Refer to the Hewlett Packard Enterprise website at: http://www.hpe.com/networking/services for

Standards and protocols

BGP

RFC 1657 Definitions of Managed Objects for
BGPv4
RFC 1771 BGPv4
RFC 1772 Application of the BGP
RFC 1773 Experience with the BGP
RFC 1774 BGP
RFC 1997 BGP Communities Att
RFC 1998 PPP Gandalf FZA Compression Protocol
RFC 2385 BGP Session Protection via TCP MD5
RFC 2439 BGP Route Flap Damping
RFC 2796 BGP Route Reflection
RFC 2842 Capability Advertisement with BGP
RFC 2858 BGP
RFC 2918 Ro

Denial of service protection

RFC 2267 Network Ingress Filtering
Automatic Filtering of well known Denial of Service
Packets
CPU DoS Protection
Rate Limiting by ACLs

Device management

RFC 1155 Structure and Mgmt Information
(SMIv1)
RFC 1157 SNMPv1/v2c
RFC 1305 NTPv3
RFC 1945 Hypertext Transfer Protocol
HTTP/1.0
RFC 2452 MIB for TCP6
RFC 2454 MIB for UDP6
RFC 2573 (SNMPv3 Applications)
RFC 2578-2580 SMIv2

RFC 2466 ICMPv6 MIB
RFC 2571 SNMP Framework
RFC 2572 SNMP
RFC 2573 SNMP
RFC 2613 SMON MIB
RFC 2618 RADIUS Client MIB
RFC 2620 RADIUS Accounting MIB
RFC 2665 Ethernet
RFC 2674 802.1p and IEEE 802.1Q Bridge MIB
RFC 2737 Entity MIB (Version 2)
RFC 2787 VRRP MIB
RFC 2819
RFC 2863 The Interfaces Group MIB
RFC 2925 Ping MIB
RFC 2932IP (Multicast Routing MIB)
RFC 2933 IGMP MIB
RFC 3273 HC
RFC 3414 SNMP
RFC 3415 SNMP
RFC 3418 MIB for SNMPv3
RFC 3621 Power Ethernet MIB
RFC
RFC 3814 MPLS FTN MIB
RFC 3815 MPLS LDP MIB
RFC 3826 AES for SNMP's USM MIB
RFC 4133 Entity MIB (Version 3)
LLDP
LLDP
LLDP

MPLS

RFC 2205 Resource ReSerVation Protocol (RSVP)

­RFC 2209 Resource ReSerVation Protocol (RSVP)

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

232C); SNMP Manager; Telnet; RMON1; FTP; in-line and out-of-band; terminal interface (serial RS­232C); modem interface

details on the service-level descriptions and product numbers. For details about services and response
times in your area, please contact your local Hewlett Packard Enterprise sales office

(applies to all products in
series)

-4 Protocol

-4 Protocol Analysis
ribute

-4 Multi-Protocol Extensions

ute Refresh Capability

--

RMON MIB

-4

3813 MPLS LSR MIB

-EXT-DOT1-MIB

-EXT-DOT3-MIB

-MIB

Version 1 Functional Specification

MIB

-MPD MIB

-Target MIB

-Like-MIB

-RMON MIB

-User based-SM MIB

-View based-ACM MIB

Page

QuickSpecs

HPE FlexFabric 12500 Switch Series

Technical Specifications

32

RFC 2579 (SMIv2 Text Conventions)
RFC 2580 (SMIv2 Conformance)
RFC 2819 (RMON
and Statistics only)
RFC 2819 RMON
RFC 3417 (SNMP Transport Mappings)
SNMP v3 and RMON RFC support
SSHv1/SSHv2 Secure Shell
TACACS/TACACS+

General protocols

IEEE 802.1ad Q
IEEE 802.1ag Service Layer OAM
IEEE 802.1ah Prov
IEEE 802.1D MAC Bridges
IEEE 802.1p Priority
IEEE 802.1Q VLANs
IEEE 802.1s Multiple Spanning Trees
IEEE 802.1v VLAN classification by Protocol and
Port
IEEE 802.1w Rapid Reconfiguration of Spanning
Tree
IEEE 802.1X PAE
IEEE 802.3ab 10
IEEE 802.3ad Link Aggregation (LAG)
IEEE 802.3ae 10
IEEE 802.3ah Ethernet in First Mile over Point to
Point Fiber
IEEE 802.3ba 40 and 100 Gigabit Ethernet
Architecture
IEEE 802.3i 10BASE
IEEE 802.3u 100BASE
IEEE 802.3x
IEEE 802.3z 1000BASE
RFC 768 UDP
RFC 783 TFTP Protocol (revision 2)
RFC 791 IP
RFC 792 ICMP
RFC 793 TCP
RFC 826 ARP
RFC 854 TELNET
RFC 868 Time Protocol
RFC 903 RARP
RFC 951 BOOTP
RFC 959 File Transfer Protocol (FTP)
RFC 1027 Proxy ARP
RFC 1
RFC 1350 TFTP Protocol (revision 2)
RFC 1519 CIDR
RFC 1542 BOOTP Extensions
RFC 1812 IPv4 Routing
RFC 2131 DHCP
RFC 2338 VRRP
RFC 2784 Generic Routing Encapsulation (GRE)
RFC 2865 Remote Authentication Dial In User

RFC 2702 Requirements for Traffic Engineering
Over MPLS
RFC 2858 Multiprotocol Extensions for BGP
RFC 3031 Multiprotocol Label Switching
Architecture
RFC 3032 MPLS Label Stack Encoding
RFC 3036 LDP Speci
RFC 3107 Carrying Label Information in BGP
RFC 3209 RSVP
Tunnels
RFC 3479 Fault Tolerance for the Label
Distribution Protocol (LDP)
RFC 3487 Graceful Restart Mechanism for LDP
RFC 4090 Fast Reroute Extensions to RS
for LSP Tunnels
RFC 4364 BGP/MPLS IP Virtual Private Networks
(VPNs)
RFC 4379 Detecting Multi
Switched (MPLS) Data Plane Failures
RFC 4447 Pseudowire Setup and Maintenance
Using LDP
RFC 4448 Encapsulation Methods for Transport of
Ether
RFC 4664 Framework for Layer 2 Virtual Private
Networks
RFC 4665 Service Requirements for Layer 2
Provider Provisioned Virtual Private Networks
RFC 4761 Virtual Private LAN Service (VPLS)
Using BGP for Auto
RF
Using Label Distribution Protocol (LDP) Signaling

Network management

IEEE 802.1AB Link Layer Discovery Protocol
(LLDP)
IEEE 802.1D (STP)
RFC 1155 Structure of Management Information
RFC 1157 SNMPv1
RFC 1215 SNMP Ge
RFC 1757 RMON 4 groups: Stats, History, Alarms
and Events
RFC 1905 SNMPv2 Protocol Operations
RFC 2211 Controlled
RFC 2272 SNMPv3 Management Protocol
RFC 2273 SNMPv3 Applications
RFC 2274 USM for SNMPv3
RFC 2571 SNMP Management Fra
RFC 2572 SNMPv3 Message Processing
RFC 2573 SNMPv3 Applications
RFC 2576 Coexistence between SNMP versions
RFC 2578 SMIv2
RFC 2819 Four groups of RMON: 1 (statistics), 2
(history), 3 (alarm) and 9 (events)
RFC 3164 BSD syslog Protocol
RFC 3415 SNMP
Model VACM)

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

– EFMF

Flow Control

042 IP Datagrams

groups Alarm, Event, History

-in-Q

ider Backbone Bridges

00BASE-T

-Gigabit Ethernet

-T

-X

-X

fication

-TE: Extensions to RSVP for LSP

-Protocol Label

net over MPLS Networks

-Discovery and Signaling

C 4762 Virtual Private LAN Service (VPLS)

neric traps

-Load Network

v3 View-based Access Control

-4

-4

VP-TE

meworks

Page

QuickSpecs

HPE FlexFabric 12500 Switch Series

Technical Specifications

33

Service (RADIUS)

IP mult

RFC 1112 IGMP
RFC 2236 IGMPv2
RFC 2283 Multiprotocol Extensions for BGP
RFC 2362 PIM Sparse Mode
RFC 2934 Protocol Independent Multicast MIB for
IPv4
RFC 3376 IGMPv3
RFC 3618 Multicast Source Discovery Protocol
(MSDP)
RFC 4601 PIM Sparse Mode

IPv6

RFC 1350 TFTP
RFC 1981 IPv6 Path MTU Discovery
RFC 2080 RIPng for IPv6
RFC 2460 IPv6 Specification
RFC 2461 IPv6 Neighbor Discovery
RFC 2462 IPv6 Stateless Address Auto
configuration
RFC 2463 ICMPv6
RFC 2473 Generic Packet Tunneling in IPv6
RFC 2475 IPv6 D
RFC 2529 Transmission of IPv6 Packets over IPv4
RFC 2710 Multicast Listener Discovery (MLD) for
IPv6
RFC 2740 OSPFv3 for IPv6
RFC 2893 Transition Mechanisms for IPv6 Hosts
and Routers
RFC 2925 Definitions of Managed Objects for
Remote
(Ping only)
RFC 3315 DHCPv6 (client only)
RFC 3484 Default Address Selection for IPv6
RFC 3513 IPv6 Addressing Architecture
RFC 3587 IPv6 Global Unicast Address Format
RFC 3810 Multicast Listener Discovery Version 2
(MLDv2) for IPv6
RFC 4251 SSHv6 Architecture
RFC 4252 SSHv6 Authentication
RFC 4253 SSHv6 Transport Layer
RFC 4254 SSHv6 Connection
RFC 4541 IGMP & MLD Snooping Switch
RFC 4862 IPv6 Stateless Address Auto
configuration

MIBS

IEEE8023
RFC 1213 MIB I
RFC 1229 Interface MIB Extensions
RFC 1286 Bridge MIB
RFC 1493 Bridge MIB
RFC 1573 SNMP MIB II
RFC 1643 Ethernet MIB

ANSI/TIA-1057 LLDP Media Endpoint Discovery
(LLDP
SNMPv1/v2c/v3

OSPF

RFC 1245 OSPF protocol analysis
RFC 1246 Experience with OSPF
RFC 1587 OSPF NSSA
RFC 1765 OSPF Database Overflow
RFC 1850 OSPFv2 Management
(MIB), traps
RFC 2328 OSPFv2
RFC 2370 OSPF Opaque LSA Option
RFC 3101 OSPF NSSA
RFC 3623 Graceful OSPF Restart

QoS/CoS

IEEE 802.1p (CoS)
RFC 2212 Guaranteed Quality of Service
RFC 2474 DS Field in the IPv4 and IPv6 Headers
RFC 2475 DiffSe
RFC 2597 DiffServ Assured Forwarding (AF)
RFC 2598 DiffServ Expedited Forwarding (EF)
RFC 2697 A Single Rate Three Color Marker
RFC 2698 A Two Rate Three Color Marker
Bi

Security

IEEE 802.1AE MAC Security Standard
IEEE 802.1X Port Based Network Access Control
RFC 1321 The MD5 Message
RFC 2082 RIP
RFC 2104 Keyed
Authentication
RFC 2716 PPP EAP TLS Authentication Protocol
RFC 2865 RADIUS Authentication
RFC 2866 RADIUS Accounting
RFC 2867 RADIUS Accounting Modifications for
Tunnel Protocol Support
RFC 2868 RADIUS Attributes for Tunnel Protocol
Support
RFC 2869 RADIUS Extensions
RFC 3567 Intermediate System (IS) to IS
Cryptographic Authentication
Access C
Guest VLAN for 802.1X
MAC Authentication
SSHv2 Secure Shell
Web Authentication

IKEv1

RFC 2865
Service (RADIUS)

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

-MED)

icast

Ping, Traceroute, and Lookup Operations

-LAG-MIB

iffServ Architecture

I

-4

-

-directional Rate Shaping

ontrol Lists (ACLs)

-

Information Base

rv Architecture

-Digest Algorithm

-2 MD5 Authentication

-Hashing for Message

- Remote Authentication Dial In User

(MACSec)

Page

QuickSpecs

HPE FlexFabric 12500 Switch Series

Technical Specifications

34

RFC 1657 BGP-4 MIB
RFC 1724 RIPv2 MIB
RFC 1757 Remote Network Monitoring MIB
RFC 1850 OSPFv2 MIB
RFC 2011 SNMPv2 MIB for IP
RFC 2012 SNMP
RFC 2013 SNMPv2 MIB for UDP
RFC 2021 RMONv2 MIB
RFC 2096 IP Forwarding Table MIB
RFC 2233 Interfaces MIB
RFC 2273 SNMP
RFC 2452 IPV6
RFC 2454 IPV6
RFC 2465 IPv6 MIB

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

v2 MIB for TCP

-NOTIFICATION-MIB

-TCP-MIB

-UDP-MIB

Page

QuickSpecs

HPE FlexFabric 12500 Switch Series

Accessories

35

HPE FlexFabric 12500 Switch Series accessories

Modules

HPE FlexFabric 12500E Main Processing Unit

JG802A

HP 12500 MPU w/Comware V7 OS

JG497A

HP 12500 Main Processing Unit

JC072B

HPE FlexFabric 12500 4-port 100GbE CFP FD Module

JG786A

HPE FlexFabric 12500 4-port 100GbE CFP FG Module

JG788A

HPE FlexFabric 12500 16-port 40GbE QSFP+ FD Module

JG790A

HPE FlexFabric 12500 48-port 1/10GbE SFP+ FD Module

JG796A

HPE FlexFabric 12500 40-port 1/10GbE SFP+ FD Module

JG792A

HPE FlexFabric 12500 40-port 1/10GbE SFP+ FG Module

JG794A

HP 12500 16-port 10GbE SFP+ LEB Module

JC782A

HP 12500 16-port 10GbE SFP+ LEC Module

JC783A

HP 12500 32-port 10GbE SFP+ REB Module

JC064B

HP 12500 32-port 10GbE SFP+ REC Module

JC476B

HP 12500 8-port 10GbE SFP+ LEB Module

JC780A

HP 12500 8-port 10GbE SFP+ LEC Module

JC781A

HP 12500 8-port 10GbE SFP+ LEF Module

JC659A

HP 12500 48-port Gig-T LEB Module

JC074B

HPE 12500 48-port Gig-T LEC Module

JC065B

HP 12500 48-port GbE SFP LEB Module

JC075B

HPE 12500 48-port GbE SFP LEC Module

JC069B

HPE 12500 48-port GbE SFP LEF Module

JC660A

HP 12500 Spare Power Monitor Module

JC502A

Transceivers

HPE X125 1G SFP LC LH40 1310nm Transceiver

JD061A

HPE X120 1G SFP LC LH40 1550nm Transceiver

JD062A

HPE X125 1G SFP LC LH70 Transceiver

JD063B

HPE X120 1G SFP RJ45 T Transceiver

JD089B

HPE X120 1G SFP LC BX 10-U Transceiver

JD098B

HPE X120 1G SFP LC BX 10-D Transceiver

JD099B

HPE X120 1G SFP LC LH100 Transceiver

JD103A

HPE X170 1G SFP LC LH70 1550 Transceiver

JD109A

HPE X170 1G SFP LC LH70 1570 Transceiver

JD110A

HPE X170 1G SFP LC LH70 1590 Transceiver

JD111A

HPE X170 1G SFP LC LH70 1610 Transceiver

JD112A

HPE X170 1G SFP LC LH70 1510 Transceiver

JD115A

HPE X120 1G SFP LC SX Transceiver

JD118B

HPE X120 1G SFP LC LX Transceiver

JD119B

HPE X130 10G XFP LC ZR Single Mode 80km 1550nm Transceiver

JD107A

HPE X130 10G XFP LC LR Single Mode 10km 1310nm Transceiver

JD108B

HPE X130 10G XFP LC SR Transceiver

JD117B

HPE X135 10G XFP LC ER Transceiver

JD121A

HPE X180 10G XFP LC LH 80km 1538.98nm DWDM Transceiver

JG226A

HPE X180 10G XFP LC LH 80km 1539.77nm DWDM Transceiver

JG227A

HPE X180 10G XFP LC LH 80km 1542.94nm DWDM Transceiver

JG230A

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

Page

QuickSpecs

HPE FlexFabric 12500 Switch Series

Accessories

36

HPE X130 10G SFP+ LC SR Transceiver

JD092B

HPE X130 10G SFP+ LC LRM Transceiver

JD093B

HPE X130 10G SFP+ LC LR Transceiver

JD094B

HPE X130 10G SFP+ LC ER 40km Transceiver

JG234A

HPE X130 10G SFP+ LC LH 80km Transceiver

JG915A

HPE FlexNetwork X240 10G SFP+ to SFP+ 3m Direct Attach Copper Cable

JD097C

HPE FlexNetwork X240 10G SFP+ to SFP+ 5m Direct Attach Copper Cable

JG081C

HPE FlexNetwork X240 10G SFP+ SFP+ 7m Direct Attach Copper Cable

JC784C

HPE X140 40G QSFP+ MPO SR4 Transceiver

JG325B

HPE X140 40G QSFP+ MPO MM 850nm CSR4 300m Transceiver

JG709A

HPE X140 40G QSFP+ LC LR4 SM 10km 1310nm Transceiver

JG661A

HPE X140 40G QSFP+ LC BiDi 100m MM Transceiver

JL251A

HP X150 100G CFP LC LR4 10km SM Transceiver

JG829A

Cables

HPE Premier Flex LC/LC Multi-mode OM4 2 fiber 1m Cable

QK732A

HPE Premier Flex LC/LC Multi-mode OM4 2 fiber 2m Cable

QK733A

HPE Premier Flex LC/LC Multi-mode OM4 2 fiber 5m Cable

QK734A

HPE Premier Flex LC/LC Multi-mode OM4 2 fiber 15m Cable

QK735A

HPE Premier Flex LC/LC Multi-mode OM4 2 fiber 30m Cable

QK736A

HPE Premier Flex LC/LC Multi-mode OM4 2 fiber 50m Cable

QK737A

Mounting Kit

HPE X421 Chassis Universal 4-post Rackmount Kit

JC665A

Memory

HPE FlexFabric 4GB Compact Flash Card

JG806A

HPE FlexFabric 4GB DDR3 SDRAM Memory

JG807A

HPE X600 1G Compact Flash Card

JC684A

HPE 12504 AC Switch Chassis (JC654A)

HPE 1250x G2 Fabric Module

JC658A

HPE 12500 AC Power Entry Module

JF426A

HPE 12500 2000W AC Power Supply

JF429A

HPE 12504 Fan Assembly

JC664A

HPE 12504 DC Switch Chassis (JC655A)

HPE 1250x G2 Fabric Module

JC658A

HPE X210 10m JG Connector to Bare 6AWG 37800 Watt 72V DC Power Cable

JG280A

HPE 12500 1800W DC Power Supply

JC651A

HPE 12504 Fan Assembly

JC664A

HP 12508 AC Switch Chassis (JF431C)

HPE 1250x G2 Fabric Module

JC658A

HP 12508 Top and Bottom Cable Guides for AC Powered Switch

JC785A

HP 12500 Side Cable Management Guide

JC084A

HPE 12500 2000W AC Power Supply

JF429A

HPE 12500 AC Power Entry Module

JF426A

HP 12508 Fan Assembly

JC081A

HP 12508 Optional Air Filter

JC082A

HP 12508 DC Switch Chassis (JC652A)

HP 12508 Fabric Module

JC067B

HPE 1250x G2 Fabric Module

JC658A

HP 12508 Top and Bottom Cable Guides for DC Powered Switch

JC787A

HP 12500 Side Cable Management Guide

JC084A

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

Page

QuickSpecs

HPE FlexFabric 12500 Switch Series

Accessories

37

HPE X210 10m JG Connector to Bare 6AWG 37800 Watt 72V DC Power Cable

JG280A

HPE 12500 1800W DC Power Supply

JC651A

HP 12508 Fan Assembly

JC081A

HP 12508 Optional Air Filter

JC082A

HP 12518 AC Switch Chassis (JF430C)

HP 12518 G2 Fabric Module

JC657A

HP 12518 Fabric Module

JC066A

HP 12518 Top and Bottom Cable Guides for AC Powered Switch

JC786A

HP 12500 Side Cable Management Guide

JC084A

HPE 12500 2000W AC Power Supply

JF429A

HPE 12500 AC Power Entry Module

JF426A

HP 12518 Fan Assembly

JC080A

HP 12518 Optional Air Filter

JC083A

HP 12518 DC Switch Chassis (JC653A)

HP 12518 G2 Fabric Module

JC657A

HP 12518 Fabric Module

JC066A

HP 12518 Top and Bottom Cable Guides for DC Powered Switch

JC788A

HP 12500 Side Cable Management Guide

JC084A

HPE X210 10m JG Connector to Bare 6AWG 37800 Watt 72V DC Power Cable

JG280A

HPE 12500 1800W DC Power Supply

JC651A

HP 12518 Fan Assembly

JC080A

HP 12518 Optional Air Filter

JC083A

HPE FlexFabric 12508E AC Switch Chassis (JG782A)

HPE FlexFabric 12508E Fabric Module

JG798A

HPE FlexFabric 12508E Optional Extended Cable Guide for AC Powered Switch

JG830A

HPE FlexFabric 12508E Optional Extended Cable Guide for DC Powered Switch

JG832A

HPE 12500 2000W AC Power Supply

JF429A

HPE FlexFabric 12500E Spare Power Monitor Module

JG804A

HPE FlexFabric 12500E Fan Tray Assembly

JG805A

HPE FlexFabric 12508E Optional Air Filter

JG808A

HPE FlexFabric 12508E DC Switch Chassis (JG783A)

HPE FlexFabric 12508E Fabric Module

JG798A

HP 12508 Top and Bottom Cable Guides for DC Powered Switch

JC787A

HP 12500 Side Cable Management Guide

JC084A

HPE X210 10m JG Connector to Bare 6AWG 37800 Watt 72V DC Power Cable

JG280A

HPE FlexFabric 12508E Optional Extended Cable Guide for DC Powered Switch

JG832A

HPE 12500 1800W DC Power Supply

JC651A

HPE FlexFabric 12500E Spare Power Monitor Module

JG804A

HPE FlexFabric 12500E Fan Tray Assembly

JG805A

HPE FlexFabric 12508E Optional Air Filter

JG808A

HPE FlexFabric 12518E AC Switch Chassis (JG784A)

HPE FlexFabric 12518E Fabric Module

JG800A

HP 12518 Top and Bottom Cable Guides for AC Powered Switch

JC786A

HP 12500 Side Cable Management Guide

JC084A

HPE FlexFabric 12518E Optional Extended Cable Guide for AC Powered Switch

JG831A

HPE 12500 2000W AC Power Supply

JF429A

HPE 12500 AC Power Entry Module

JF426A

HPE FlexFabric 12500E Spare Power Monitor Module

JG804A

HPE FlexFabric 12500E Fan Tray Assembly

JG805A

HPE FlexFabric 12518E Optional Air Filter

JG809A

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

Page

QuickSpecs

HPE FlexFabric 12500 Switch Series

Accessories

38

HPE FlexFabric 12518E DC Switch Chassis (JG785A)

HPE FlexFabric 12518E Fabric Module

JG800A

HP 12518 Top and Bottom Cable Guides for DC Powered Switch

JC788A

HP 12500 Side Cable Management Guide

JC084A

HPE X210 10m JG Connector to Bare 6AWG 37800 Watt 72V DC Power Cable

JG280A

HPE FlexFabric 12518E Optional Extended Cable Guide for DC Powered Switch

JG833A

HPE 12500 1800W DC Power Supply

JC651A

HPE FlexFabric 12500E Spare Power Monitor Module

JG804A

HPE FlexFabric 12500E Fan Tray Assembly

JG805A

HPE FlexFabric 12518E Optional Air Filter

JG809A

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

Page

QuickSpecs

HPE FlexFabric 12500 Switch Series

Accessory Product Details

39

NOTE: Details are not available for all accessories. The following specifications were available at the time of publication.

Modules

HPE FlexFabric 12500

I/O ports and slots

4 CFP 100GbE ports

Physical characteristics

Dimensions

15.75(w) x 18.39(d) x 1.57(h) in (40.0 x 46.7 x

4.0 cm)

Weight

13.12 lb (5.95 kg)

Services

Refer to the Hewlett Packard Enterprise website at:

level

HPE FlexFabric 12500

I/O ports and slots

4 CFP 100GbE ports

Physical characteristics

Dimensions

15.75(w) x 18.39(d) x 1.57(h) in (40.0 x 46.7 x

4.0 cm)

Weight

12.68 lb (5.75 kg)

Services

Refer to the Hewlett Packard Enterprise website at:

level

sales office

HP 12500 48-port Gig-T

Ports

48 RJ-45 autosensing 10/100/1000 ports (IEEE 802.3 Type 10BASE-T,

10BASE-T/100BASE-TX: half or full; 1000BASE-T: full only

Physical characteristics

Dimensions

18.39(d) x 15.75(w) x 1.57(h) in. (46.7 x 40 x 4
cm)

Weight

9.37 lb. (4.25 kg)

Services

Refer to the Hewlett Packard Enterprise website at:

level

sales office

HPE 12500 48-port Gig-

Ports

48 RJ-45 autosensing 10/100/1000 ports (IEEE 802.3 Type 10BASE-T,

Physical characteristics

Dimensions

18.39(d) x 15.75(w) x 1.57(h) in. (46.7 x 40 x 4
cm)

Weight

9.79 lb. (4.44 kg)

Services

Refer to the Hewlett Packard Enterprise website at:

level

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

4-port 100GbE CFP FG
Module

(JG788A)

4-port 100GbE CFP FD
Module

(JG786A)

LEB Module
(JC074B)

http://www.hpe.com/networking/services for details on the service­descriptions and product numbers. For details about services and response
times in your area, please contact your local Hewlett Packard Enterprise
sales office

http://www.hpe.com/networking/services for details on the service­descriptions and product numbers. For details about services and response
times in your area, please contact your local Hewlett Packard Enterprise

IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T);
Duplex:

http://www.hpe.com/networking/services for details on the service­descriptions and product numbers. For details about services and response
times in your area, please contact your local Hewlett Packard Enterprise

T LEC Module
(JC065B)

IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T)
Duplex: 10BASE-T/100BASE-TX: half or full; 1000BASE-T: full only

http://www.hpe.com/networking/services for details on the service­descriptions and product numbers. For details about services and response
times in your area, please contact your local Hewlett Packard Enterprise
sales office

Page

QuickSpecs

HPE FlexFabric 12500 Switch Series

Accessory Product Details

40

HP 12500 48-port GbE

Ports

48 SFP 100/1000 Mbps ports

Physical characteristics

Dimensions

18.39(d) x 15.75(w) x 1.57(h) in. (46.7 x 40 x 4
cm)

Weight

9.96 lb. (4.52 kg)

Services

Refer to the Hewlett Packard Enterprise website at:

level

sales office

HPE 12500 48-port GbE

Ports

48 SFP 100/1000 Mbps ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u

Duplex: 10BASE-T/100BASE-TX: half or full; 1000BASE-T: full only

Physical characteristics

Dimensions

18.39(d) x 15.75(w) x 1.57(h) in. (46.7 x 40 x 4
cm)

Weight

10.03 lb. (4.55 kg)

Services

Refer to the Hewlett Packard Enterprise website at:

level

sales office

HP 12500 32-port

Ports

32 SFP+ 10-GbE ports
Duplex: full only

Physical characteristics

Dimensions

18.39(d) x 15.75(w) x 1.57(h) in. (46.7 x 40 x 4
cm)

Weight

13.45 lb. (6.10 kg)

Services

Refer to the Hewlett Packard Enterprise website at:

level

sales office

Transceivers

HPE X125 1G SFP LC
LH40 1310nm
Transceiver

A small form
pluggable SFP Gigabit
LH40 transceiver that
provides a full duplex
Gigabit solution up to
40km on a single
fiber.

Ports

1 LC 1000Base-LH port (no IEEE standard exists for 1550 nm optics)

Connectivity

Connector type

LC

Wavelength

1310 nm

Physical characteristics

Dimensions

2.17(d) x 0.6(w) x 0.46(h) in. (5.51 x 1.52 x

1.17 cm)

Full configuration weight

0.04 lb. (0.02 kg)

Electrical characteristics

Power consumption typical

0.8 W

Power consumption
maximum

1.0 W

Cabling

Cable type:
Single

Maximum distance:

Fiber type

Single Mode

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

SFP LEB Module
(JC075B)

SFP LEC Module
(JC069B)

http://www.hpe.com/networking/services for details on the service­descriptions and product numbers. For details about services and response
times in your area, please contact your local Hewlett Packard Enterprise

Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T)

http://www.hpe.com/networking/services for details on the service­descriptions and product numbers. For details about services and response
times in your area, please contact your local Hewlett Packard Enterprise

10GbE SFP+ REB
Module (JC064B)

http://www.hpe.com/networking/services for details on the service-

descriptions and product numbers. For details about services and response
times in your area, please contact your local Hewlett Packard Enterprise

(JD061A)

-factor

-mode

-mode fiber optic, complying with ITU-T G.652;

• 40km distance

Page

QuickSpecs

HPE FlexFabric 12500 Switch Series

Accessory Product Details

41

Services

Refer to the Hewlett Packard Enterprise website at:

http://www.hpe.com/networking/services

descriptions and product numbers. For details about services and response
times in your area, please contact your local Hewle
sales office

HPE X120 1G SFP LC
LH40 1550nm
Transceiver

A small form
pluggable (SFP) Gigabit
LH40 transceiver that
provides a full
Gigabit solution up to 40
km on a single mode fiber.

Ports

1 LC 1000BASE-LH port (no IEEE standard exists for 1550 nm optics)

Connectivity

Connector type

LC

Wavelength

1550 nm

Physical characteristics

Dimensions

2.17(d) x 0.6(w) x 0.46(h) in. (5.51 x 1.52 x

1.17 cm)

Full configuration weight

0.04 lb. (0.02 kg)

Electrical characteristics

Power consumption typical

0.8 W

Power consumption
maximum

1.0 W

Cabling

Cable type:
Single

Maximum distance:

Fiber type

Single Mode

Services

Refer to the Hewlett Packard Enterprise website at:

http://www.hpe.com/networking/services

descriptions and product numbers. For details about services and response
times in your area, pleas
sales office

HPE X125 1G SFP LC

Ports

1 LC 1000BASE-LH port (no IEEE standard exists for 1550 nm optics)

Connectivity

Connector type

LC Wavelength

1550 nm

Physical characteristics

Dimensions

2.17(d) x 0.6(w) x 0.46(h) in. (5.51 x 1.52 x

1.17 cm)

Full configuration weight

0.04 lb. (0.02 kg)

Electrical characteristics

Power consumption
typical

0.8 W

Power consumption
maximum

1.0 W

Cabling

Cable type:

• 70km

Fiber type

Single Mode

Services

Refer to the Hewlett Packard Enterprise website at:

level

sales office

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

for details on the service-level

tt Packard Enterprise

(JD062A)

-factor

-duplex

-mode fiber optic, complying with ITU-T G.652;

• 40km distance

for details on the service-level

e contact your local Hewlett Packard Enterprise

LH70 Transceiver
(JD063B)

A small form-factor
pluggable (SFP) Gigabit
LH70 transceiver that
provides a full-duplex
Gigabit solution up to
70km on a single-mode
fiber.

Single-mode fiber optic, complying with ITU-T G.652;

Maximum distance:

http://www.hpe.com/networking/services for details on the service­descriptions and product numbers. For details about services and response
times in your area, please contact your local Hewlett Packard Enterprise

Page

QuickSpecs

HPE FlexFabric 12500 Switch Series

Accessory Product Details

42

HPE X120 1G

Ports

1 RJ-45 1000BASE-T port (IEEE 802.3ab Type 1000BASE-T)

Connectivity

Connector type

RJ-45

Physical

Dimensions

2.71(d) x 0.54(w) x 0.55(h) in. (6.88 x 1.37 x 1.4 cm)

Full configuration weight

0.07 lb. (0.03 kg)

Electrical

Power consumption typical

0.8 W

Power consumption maximum

1.0 W

Cabling

Cable type:

Services

Refer to the Hewlett Packard Enterprise website at:

descriptions and

your local Hewlett Packard Enterprise sales office

HPE X120 1G SFP LC BX

Ports

1 LC 1000BASE-BX10 port (IEEE 802.3ah Type 1000BASE-BX10-U);
Duplex: full only

Connectivity

Connector type

LC

Physical characteristics

Dimensions

2.17(d) x 0.6(w) x 0.46(h) in. (5.51 x 1.52 x

1.17 cm)

Full configuration weight

0.04 lb. (0.02 kg)

Electrical characteristics

Power consumption
typical

0.8 W

Power consumption
maximum

1.0 W

Cabling

Maximum distance:

• 10km

Fiber type

Single Mode

Notes

TX 1310nm RX 1490nm

Services

Refer to the Hewlett Packard Enterprise website at:

level

sales office

HPE X120 1G SFP LC BX

ovides a full duplex

Ports

1 LC 1000BASE-BX10 port (IEEE 802.3ah Type 1000BASE-BX10-D);
Duplex: full only

Connectivity

Connector type

LC

Physical characteristics

Dimensions

2.17(d) x 0.6(w) x 0.46(h) in. (5.51 x 1.52 x

1.17 cm)

Full configuration weight

0.04 lb. (0.02 kg)

Electrical characteristics

Power consumption
typical

0.8 W

Power consumption

1.0 W

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

SFP RJ45 T
Transceiver

(JD089B)

A small form
factor pluggable
(SFP) Gigabit
1000Base-T
transceiver that
provides a full
duplex Gigabit
solution up to
100m on a Cat­5+ cable.

characteristics

characteristics

1000BASE-T: Category 5 (5E or better recommended), 100 Ù differential 4-pair unshielded
twisted pair (UTP) or shielded twisted pair (STP) balanced, complying with IEEE 802.3ab
1000BASE-T;

Maximum distance:

• 100m

10-U Transceiver
(JD098B)

A small form-factor
pluggable (SFP) Gigabit
LX-BX10-U transceiver
that provides a full duplex
Gigabit solution up to
10km on a single mode
cable.

http://www.hpe.com/networking/services for details on the service-level
product numbers. For details about services and response times in your area, please contact

http://www.hpe.com/networking/services for details on the service­descriptions and product numbers. For details about services and response
times in your area, please contact your local Hewlett Packard Enterprise

10-D Transceiver
(JD099B)

A small form-factor
pluggable (SFP) Gigabit
LX-BX10-D transceiver
that pr
Gigabit solution up to
10km on a single mode

Page

QuickSpecs

HPE FlexFabric 12500 Switch Series

Accessory Product Details

43

cable.

maximum

Cabling

Maximum distance:

• Up to 10km

Fiber type

Single Mode

Notes

TX 1490nm RX 1310nm

Services

Refer to the Hewlett Packard Enterprise website at:

level

sales office

HPE X120 1G SFP LC

Ports

1 LC 1000BASE-LH port (no IEEE standard exists for 1550 nm optics)

Connectivity

Connector type

LC Wavelength

1550 nm

Electrical characteristics

Power consumption
typical

0.8 W

Power consumption
maximum

1.0 W

Cabling

Cable type:

• Up to 100km

Fiber type

Single Mode

Services

Refer to the Hewlett Packard Enterprise website at:

level

sales office

HPE X120 1G SFP LC SX

Ports

1 LC 1000BASE-SX port

Connectivity

Connector type

LC

Wavelength

850 nm

Physical characteristics

Dimensions

2.17(d) x 0.6(w) x 0.46(h) in. (5.51 x 1.52 x

1.17 cm)

Full configuration weight

0.04 lb. (0.02 kg)

Electrical characteristics

Power consumption
typical

0.8 W

Power consumption
maximum

1.0 W

Cabling

Maximum distance:

• OM3 = Not Specified by standard

Cable length

up to 550m

Fiber type

Multi Mode

Services

Refer to the Hewlett Packard Enterprise website at:

level

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

LH100 Transceiver
(JD103A)

A small form factor
pluggable (SFP) Gigabit
LH100 transceiver that
provides a full-duplex
Gigabit solution up to
100km on a single mode
fiber.

http://www.hpe.com/networking/services for details on the service­descriptions and product numbers. For details about services and response
times in your area, please contact your local Hewlett Packard Enterprise

Single-mode fiber optic, complying with ITU-T G.652;

Maximum distance:

http://www.hpe.com/networking/services for details on the service­descriptions and product numbers. For details about services and response
times in your area, please contact your local Hewlett Packard Enterprise

Transceiver (JD118B)

A small form-factor
pluggable (SFP) Gigabit
SX transceiver that
provides a full-duplex
Gigabit solution up to
550m on a Multimode
fiber.

• FDDI Grade distance = 220m

• OM1 = 275m

• OM2 = 500m

http://www.hpe.com/networking/services for details on the service-

Page

QuickSpecs

HPE FlexFabric 12500 Switch Series

Accessory Product Details

44

descriptions and product numbers. For details about services and response

sales office

HPE X120 1G SFP LC LX

Ports

1 SFP 1000BASE-LX port (IEEE 802.3z Type 1000BASE-LX)

Connectivity

Connector type

LC

Wavelength

1300 nm

Physical characteristics

Dimensions

2.17(d) x 0.6(w) x 0.46(h) in. (5.51 x 1.52 x

1.17 cm)

Full configuration weight

0.04 lb. (0.02 kg)

Electrical characteristics

Power consumption
typical

0.8 W

Power consumption
maximum

1.0 W

Cabling

Cable type:

• 10km for Singlemode

Fiber type

Both

Services

Refer to the Hewlett Packard Enterprise website at:

level

sales office

Cables

HPE Premier Flex LC/LC

Notes

Cable Specs: Graded-index, "bendable" fiber optic multimode OM3+
50/125um duplex cable and Ethernet assembly with LC duplex connectors
on each end.

• Core Diameter: 50um ±3um, C
diameter: 245 ± 10um

• Bandwidth: 3000 MHz

• Jacket Color: Blue

• Jacket Material: Riser Grade

thermoplastic

• Boot Color: White

• Outer Jacket Print:

Type OFNR (UL), LSZH, cUL, OFN FT4, ROHS. Cable also has a longitudinal
white stripe that runs the entire length of the cable.

• Insertion Loss: Less than 0.5dB @ 850nm with LED source, 0.003dB/m

added for lengths >30m

• Maximum Cable Attenuation: 3.0 dB/km @ 850nm, 1.0 dB/km @ 1310nm
@ 23°C as tested in accordance with EIA 455-45

Services

Refer to the Hewlett Packard Enterprise website at:

http://www.hpe.com/networkin

level
descriptions and product numbers. For details about services and response
times in your area, please contact your local Hewlett Packard Enterprise
sales office

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

times in your area, please contact your local Hewlett Packard Enterprise

Transceiver (JD119B)

A small form-factor
pluggable (SFP) Gigabig
LX transceiver that
provides a full duplex
Gigabit solution up to
550m on MMF or 10Km
on SMF

Either single mode or multimode;

Maximum distance:

• 550m for Multimode

http://www.hpe.com/networking/services for details on the service­descriptions and product numbers. For details about services and response
times in your area, please contact your local Hewlett Packard Enterprise

Multi-mode OM4 2 fiber
1m Cable (QK732A)

ladding diameter: 125um ±2um; Coating

-km @ 850nm (Laser)

– Low Smoke Zero Halogen (LSZH)

HPE PremierFlex OM3+ Fiber Optic Cable, 50/125um,

g/services for details on the service-

Page

QuickSpecs

HPE FlexFabric 12500 Switch Series

Accessory Product Details

45

HPE Premier Flex LC/LC

Notes

Cable Specs: Graded-index, "bendable" fiber optic multimode OM3+
50/125um duplex cable and Ethernet assembly with LC duplex connectors
on each end.

• Core diameter: 50um ±3um, Cladding diameter: 125um ±2um; Coating
diameter: 245 ± 1

• Bandwidth: 3000 MHz

• Jacket Color: Blue

• Jacket Material: Riser Grade

thermoplastic

• Boot Color: White

• Outer Jacket Print:

PremierFlex OM3+ Fiber Optic Cable, 50/125um,
Type OFNR (UL), LSZH, cUL, OFN FT4, ROHS. Cable also has a longitudinal
white stripe that runs the entire length of the cable.

• Insertion Loss: Less than 0.5dB @ 850nm with LED source, 0.003dB/m

added for lengths >30m

• Maximum Cable Attenuation: 3.0 dB/km @ 850nm, 1.0 dB/km @ 1310nm
@ 23°C as tested in accordance with EIA 455-45

Services

Refer to the Hewlett Packard Enterprise website at:

http://www.hpe.com/networking/services

level
descriptio
times in your area, please contact your local Hewlett Packard Enterprise
sales office

HPE Premier Flex LC/LC

Notes

Cable Specs: Graded-index, "bendable" fiber optic multimode OM3+
50/125um duplex cable and Ethernet assembly with LC duplex connectors
on each end.

• Core diameter: 50um ±3um, Cladding diameter: 125um ±2um; Coating
diameter: 245 ± 10um

• Bandwidth: 3000 MHz

• Jacket C

• Jacket Material: Riser Grade

thermoplastic

• Boot Color: White

• Outer Jacket Print:

PremierFlex OM3+ Fiber Optic Cable, 50/125um,
Type OFNR (UL), LSZH, cUL, OFN FT4, ROHS. Cable also has a longitudinal
whit

• Insertion Loss: Less than 0.5dB @ 850nm with LED source, 0.003dB/m

added for lengths >30m

• Maximum Cable Attenuation: 3.0 dB/km @ 850nm, 1.0 dB/km @ 1310nm

@ 23°C as tested in accordance with EIA 455-45

Services

Refer to the Hewlett Packard Enterprise website at:

http://www.hpe.com/networking/services

level
descriptions and product numbers. For details about services and
times in your area, please contact your local Hewlett Packard Enterprise
sales office

HPE Premier Flex LC/LC

Notes

Cable Specs: Graded-index, "bendable" fiber optic multimode OM3+
50/125um duplex cable and Ethernet assembly with LC duplex connectors
on each end.

• Core diameter: 50um ±3um, Cladding diameter: 125um ±2um; Coating
diameter: 245 ± 10um

• Bandwidth: 3000 MHz-km @ 850nm (Laser)

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

Multi-mode OM4 2 fiber
2m Cable (QK733A)

0um

-km @ 850nm (Laser)

– Low Smoke Zero Halogen (LSZH)

HPE

ns and product numbers. For details about services and response

Multi-mode OM4 2 fiber
5m Cable (QK734A)

olor: Blue

e stripe that runs the entire length of the cable.

Multi-mode OM4 2 fiber
15m Cable (QK735A)

for details on the service-

-km @ 850nm (Laser)

– Low Smoke Zero Halogen (LSZH)

HPE

for details on the service-

response

Page

QuickSpecs

HPE FlexFabric 12500 Switch Series

Accessory Product Details

46

• Jacket Color: Blue

• Jacket Material: Riser Grade

thermoplastic

• Boot Color: White

• Outer Jacket Print:

PremierFlex OM3+ Fiber Optic Cable, 50/125um,
Type OFNR (UL), LSZH, cUL, OFN FT4, ROHS. Cable also has a longitudinal
white stripe that runs the entire length of the cable.

• I

added for lengths >30m

• Maximum Cable Attenuation: 3.0 dB/km @ 850nm, 1.0 dB/km @ 1310nm

@ 23°C as tested in accordance with EIA 455-45

Services

Refer to the Hewlett Packard Enterprise website at:

http://www.hpe.com/networking/services

level
descriptions and product numbers. For details about services and response
times in your area, please contact your local
sales office

HPE Premier Flex LC/LC

Notes

Cable Specs: Graded-index, "bendable" fiber optic multimode OM3+
50/125um duplex cable and Ethernet assembly with LC duplex connectors
on e

• Core diameter: 50um ±3um, Cladding diameter: 125um ±2um; Coating
diameter: 245 ± 10um

• Bandwidth: 3000 MHz

• Jacket Color: Blue

• Jacket Material: Riser Grade

thermoplastic

• Boot Color: White

• Outer Jacket Print:

PremierFlex OM3+ Fiber Optic Cable, 50/125um,
Type OFNR (UL), LSZH, cUL, OFN FT4, ROHS. Cable also has a longitudinal
white stripe that runs the entire length of the cable.

• Insertion Loss: Less than 0.5dB @ 850nm with LED source

added for lengths >30m

• Maximum Cable Attenuation: 3.0 dB/km @ 850nm, 1.0 dB/km @ 1310nm

@ 23°C as tested in accordance with EIA 455-45

Services

Refer to the Hewlett Packard Enterprise website at:

http://www.hpe.com/networking/services

level
descriptions and product numbers. For details about services and response
times in your area, please contact your local Hewlett Packard Enterprise
sales office

HPE Premier Flex LC/LC

Notes

Cable Specs: Graded-index, "bendable" fiber optic multimode OM3+
50/125um duplex cable and Ethernet assembly with LC duplex connectors

Type OFNR (UL), LSZH, cUL, OFN FT4, ROHS. Cable also has a longitudinal
white stripe that runs the entire length of the cable.

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

– Low Smoke Zero Halogen (LSZH)

HPE

nsertion Loss: Less than 0.5dB @ 850nm with LED source, 0.003dB/m

for details on the service-

Hewlett Packard Enterprise

Multi-mode OM4 2 fiber
30m Cable (QK736A)

Multi-mode OM4 2 fiber
50m Cable (QK737A)

ach end.

on each end.

• Core diameter: 50um ±3um, Cladding diameter: 125um ±2um; Coating
diameter: 245 ± 10um

• Bandwidth: 3000 MHz-km @ 850nm (Laser)

• Jacket Color: Blue

• Jacket Material: Riser Grade – Low Smoke Zero Halogen (LSZH)

thermoplastic

• Boot Color: White

• Outer Jacket Print: HPE PremierFlex OM3+ Fiber Optic Cable, 50/125um,

-km @ 850nm (Laser)

– Low Smoke Zero Halogen (LSZH)

HPE

, 0.003dB/m

for details on the service-

Page

QuickSpecs

HPE FlexFabric 12500 Switch Series

Accessory Product Details

47

• Insertion Loss: Less than 0.5dB @ 850nm with LED source, 0.003dB/m

enuation: 3.0 dB/km @ 850nm, 1.0 dB/km @ 1310nm

@ 23°C as tested in accordance with EIA 455-45

Services

Refer to the Hewlett Packard Enterprise website at:

level

sales office

HP 12500 MPU

Physical characteristics

Dimensions

23.2(w) x 30.7(d) x 11.2(h) in (58.93 x 77.98 x

28.45 cm)

Weight

22.16 lb (10.05 kg)

Services

Refer to the Hewlett Packard Enterprise website at:

level

sales office

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

added for lengths >30m

• Maximum Cable Att

http://www.hpe.com/networking/services for details on the service­descriptions and product numbers. For details about services and response
times in your area, please contact your local Hewlett Packard Enterprise

w/Comware V7 OS
(JG497A)

http://www.hpe.com/networking/services for details on the service-

descriptions and product numbers. For details about services and response
times in your area, please contact your local Hewlett Packard Enterprise

Page

QuickSpecs

HPE FlexFabric 12500 Switch Series

Summary of Changes

48

Date

Version History

Action

Description of Change

25-Sep-2017

From Version 40 to
41

Changed

Configuration section updated

17-Jul-2017

From Version 39 to
40

Changed

Configuration section updated

18-Apr-2017

From Version 38 to
39

Added

Transceivers added on the Configuration section: JL437A,
JL438A, JL439A

17-Feb-2017

From Version 37 to
38

Changed

Configuration section updated: Removing Defaults in
Remarks sections

01-Aug-2016

From Version 36 to
37

Changed

Configuration section was completely revised including
the addition of the #AC3 Option

06-June-2016

From Version 35 to

Changed

Document name changed to HPE FlexFabric 12500

Product description updated.

22-Apr-2016

From Version 34 to
35

Changed

SKU descriptions updated on the entire document

18-Mar-2016

From Version 33 to
34

Changed

Changes made on Configuration section and Product
images

16-Feb-2016

From Version 32 to
Added

SKU added: JL251A

Changed

Accessories and Technical Specifications updated

8-Jan-2016

From Version 31 to
32

Changed

Warranty and Support updated

2-Oct-2015

From Version 30 to
31

Changed

Models list added on Overview

21-Aug-2015

From Version 29 to

Changed

Configuration Menu updated

30-Mar-2015

From Version 28 to

Added

Transceiver added: JG915A

Changed

Changes made on the entire QuickSpecs

20-Jan-2015

From Version 27 to

Changed

Minor changes made on Technical Specifications

15-Jan-2015

From Version 26 to
27

Changed

Minor changes made on Technical Specifications

13-Aug-2014

From Version 25 to
26

Changed

General protocols and Security updated on Technical
Specifications

3-Jul-2014

From Version 23 to
25

Changed

Configuration menu updated.

12-May-2014

From Version 22 to
23

Added

Added two new modules to the Accessories section.

14-Apr-2014

From Version 21 to
22

Changed

Configuration was revised.

31-Mar-2014

From Version 20 to
21

Changed

Configuration was revised.

16-Jan-2014

From Version 19 to
20

Changed

Corrected the descriptions of the images.

12-Nov-2013

From Version 18 to
19

Changed

Notes were revised in Configuration.

18-Oct-2013

From Version 17 to
18

Changed

Configuration was revised.

30-Sep-2013

From Version 16 to

Added

HPE 12504 DC Switch Chassis, HPE 125008 DC Switch

Fire Module were added to Configuration

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

36

33

30

29

28

Switch Series.

17

Chassis, HPE 12518 AC Switch Chassis, HPE 12500 8­port 10GbE XFP LEC Module, HPE 12500 20Gbps VPN

Page

QuickSpecs

HPE FlexFabric 12500 Switch Series

Summary of Changes

49

15-Jul-2013

From Version 14 to
16

Changed

Corrected the new Configuration section.

10-Jun-2013

From Version 13 to
14

Added

OM4 cables were added, as well as mounting kit
information in the Configuration section.

19-Mar-2013

From Version 12 to
13

Changed

Corrected the new Configuration section.

1-Mar-2013

From Version 11 to
12

Changed

Corrected the formatting in the new Configuration section.

19-Feb-2013

From Version 10 to
11

Added

Added the Configuration section, as well as several
images.

4-Dec-2012

From Version 9 to 10

Changed

Significant changes were made to the first half of Features

as did the Accessories section.

2-Nov-2012

From Version 8 to 9

Changed

Updated Jumbo frames in Features and Benefits.

24-Sep-2012

From Version 7 to 8

Changed

Updated Features and Benefits, Introduction, the
specifications, and Accessories.

26-Mar-2012

From Version 6 to 7

Changed

The Accessories and specifications sections were updated.

13-Feb-2012

From Version 5 to 6

Added

Some new modules were added.

Changed

The model numbers were updated, as well as the part
numbers for some of the modules.

14-Nov-2011

From Version 4 to 5

Changed

Changes were made throughout, including changing the
title.

7-Sep-2011

From Version 3 to 4

Added

Jumps were added to the Accessory Product Details.

30-Aug-2011

From Version 2 to 3

Added

Added the Accessories Product Details section.

15-Mar-2011

From Version 1 to 2

Changed

Accessories was revised.

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

and Benefits. The model specifications had minor updates,

Page

QuickSpecs

HPE FlexFabric 12500 Switch Series

Su

50

Sign up for updates

© Copyright 2017 Hewlett Packard Enterprise Development LP. The information contained herein is
subject to change without notice. The only warranties
services are set forth in the express warranty statements accompanying such products and services.
Nothing herein should be construed as constituting an additional warranty. Hewlett Packard Enterprise
shall not

To learn more, visit:

c04111591

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

mmary of Changes

for Hewlett Packard Enterprise products and

be liable for technical or editorial errors or omissions contained herein.

http://www.hpe.com/networking

- 13785 - Worldwide - V41 - 25-September-2017

Page
