HP Z440 QuickSpecs

QuickSpecs

Overview

HP Z440 Workstation

HP Z440 Workstation

?1.

Integrated Front Handle

2.

Dedicated 9.5mm Optical Drive Bay

3.

Power Button

?

4.

HDD Activity LED

5.

Front I/O: 4 USB 3.0 with Charging Port (topmost port),
1 Microphone, 1 Headset

DA - 15077???Worldwide QuickSpecs ¡ª Version 37 ¡ª 7/8/2019

Page? 1

QuickSpecs

Overview

HP Z440 Workstation

6.

2 External 5.25"? Bays

7.

2 Internal 3.5"? Bays

8.

Fan and Front Card Guide Kit (optional)

9.

6 6Gb/s SATA Ports

10.

Rear Grip

11.

525W, 85% Efficient Power Supply or
700W, 90% Efficient Power Supply

Overview

12.

Rear I/O: Rear Power Button, 4 USB 3.0, 2 USB 2.0,
PS/2 Ports, 1 RJ-45 to Integrated GbE, 1 Audio Line In,
Audio Line Out

13.

8 DIMM Slots for DDR4 ECC Registered Memory

14.

Intel Xeon Processors: E5-1600 v3/v4 family (4C/6C/8C),
E5-2600 v3 family (8C)

15.

2 PCIe x16 Gen 3 Slots

16.

1 PCIe x8 Gen 3, 1 PCIe x1 Gen 2, 1 PCIe x4 Gen 2,
1 PCI Slot

1

DA - 15077???Worldwide QuickSpecs ¡ª Version 37 ¡ª 7/8/2019

Page? 2

QuickSpecs

Overview

HP Z440 Workstation

Form Factor
Operating Systems

Minitower
Preinstalled:

Windows 10 Pro 64

for Workstations
Windows 10 Pro 64 downgrade to Windows 7 Professional 64
Windows 10 Home 64 High-end
Windows 8.1 Pro 64-bit
HP Installer Kit for Linux (includes drivers for 64-bit OS versions of RHEL 6.6, RHEL 7, SUSE Linux
Enterprise Desktop 11, Ubuntu 14.04)
Red Hat? Enterprise Linux Desktop (Paper license with 1 year support; no preinstalled OS) ?

Supported:

Windows 8/8.1 Enterprise 64-bit
Windows 7 Enterprise 64-bit
Red Hat Enterprise Linux Desktop 6, 7
SUSE Linux Enterprise Desktop 11 SP3, 12

Notes

: For detailed OS/hardware support information for Linux, see:

http://www.hp.com/support/linux_hardware_matrix

Available Processors

?

?

Clock

Name

Cores

Speed

(GHz)

Intel? Xeon?

8
E5-1680 v4 processor
Intel? Xeon?
E5-1660 v4 processor
Intel? Xeon?
E5-1650 v4 processor
Intel? Xeon?
E5-1630 v4 processor
Intel? Xeon?
E5-1620 v4 processor
Intel? Xeon?
E5-1607 v4 processor
Intel? Xeon?
E5-1603 v4 processor

? ?

Intel Xeon
E5-1680 v3 processor

Intel Xeon
E5-1660 v3 processor

Intel Xeon
E5-2630 v3 processor

Intel Xeon
E5-1650 v3 processor

Intel Xeon
E5-1630 v3 processor

Intel Xeon
E5-1620 v3 processor

Intel Xeon
E5-1607 v3 processor

8

6

4

4

4

4

8

8

8

6

4

4

4

3.4

3.2

3.6

3.7

3.5

3.1

2.8

3.2

3.0

2.4

3.5

3.7

3.5

3.1

Cache

(MB)

20 2400

20 2400

15 2400

10 2400

10 2400

10 2133

10 2133

20 2133

20 2133

20 1866

15 2133

10 2133

10 2133

10 1866

Memory

Speed
(MT/s)

Hyper-

Threading

YES YES

YES YES

YES YES

YES YES

YES YES

NO

NO

YES YES

YES YES

YES YES

YES YES

YES YES

YES YES

NO

Featuring Intel?

TM

vPro

Technology

YES

YES

YES

Intel? Turbo

Boost

Technology

2, 4, 6

2, 4, 6

2, 2, 4

1, 1, 3

1, 3

N/A

N/A

3, 6

3, 5

2, 8

1, 3

1, 1

1, 1

N/A

TDP

(W)

1

140

140

140

140

140

140

140

140

140

85

140

140

140

140

DA - 15077???Worldwide QuickSpecs ¡ª Version 37 ¡ª 7/8/2019

Page? 3

QuickSpecs

Overview

Intel Xeon
E5-1603 v3 processor

?

Intel Xeon
E5-2637 v4 processor

Intel Xeon
E5-2623 v4 processor

? ?
?

?

Available Processors
Disclaimers

Color

Convertibility

Expansion Slots (see
system board section for
more details)
?

1

one core maximum turbo steps). Turbo boost stepping occurs in 100MHz increments. Processors
that do not have turbo functionality are denoted as N/A.

?

NOTE:

Workstation does not support dual processor configurations.

?
Intel's numbering is not a measurement of higher performance. Processor numbers differentiate features
within each processor family, not across different processor families. See:

http://www.intel.com/products/processor_number/

64-bit computing on Intel? 64 architecture requires a computer system with a processor, chipset, BIOS,
operating system, device drivers and applications enabled for Intel 64 architecture. Processor will not
operate (including 32-bit operation) without an Intel 64 architecture-enabled BIOS. Performance will vary
depending on your hardware and software configurations. See:
information.
Quad-Core, Six-Core, and Eight-Core technologies are designed to improve performance of multithreaded
software products and hardware-aware multitasking operating systems and may require appropriate
operating system software for full benefits. Check with software provider to determine suitability. Not all
customers or software applications will necessarily benefit from use of these technologies.
?
Jack Black
?
No
?

Slot 1

PCI Express Gen2 x1 with open-ended connector*
Full-height, Half-length
?

Slot 2:

PCI Express Gen3 x16
Full-height, Full-length (with extender)

?
Slot 3:

PCI Express Gen2 x4 with open-ended connector*
Full-height, Full-length (with extender)
?

Slot 4:

PCI Express Gen3 x8 with open-ended connector*
Full-height, Full-length (with extender)
?

Slot 5:

PCI Express Gen3 x16
Full-height, Full-length (with extender)
?

Slot 6:

HP Z440 Workstation

4

4

4

The specifications shown in this column represent the following: (all core maximum turbo steps,

(top):

2.8

3.5

2.6

10 1866

15 2400

10 2133

NO

YES YES

YES YES

YES

N/A

1, 2

2, 6

140

135

85

Although the Intel Xeon E5-2600 processor family supports dual processors, the HP Z440

for details.

?

http://www.intel.com/info/em64t

? for more

?

DA - 15077???Worldwide QuickSpecs ¡ª Version 37 ¡ª 7/8/2019

Page? 4

QuickSpecs

Overview

PCI 32bit/33MHz
Full-height, Full-length (with extender)
?

* Open-ended connector allows a greater bandwidth (e.g. x16) card to be installed physically into a lower
bandwidth connector/slot.

?

Expansion Bays (see
storage section for more
details)
?

Front I/O
?
Internal I/O
?

2 internal 3.5" bays (with acoustic dampening rail assemblies pre-installed)
2 external 5.25" bays

?
1 dedicated 9.5mm slim optical disk drive bay
?
4 USB 3.0, 1 Headset, 1 Microphone
?

2 USB 2.0 ports available with a single 2x5 header. The 2x5 header can be converted to a standard (Type-A)
USB connector through the use one HP Internal USB Port Kit (EM165AA). This port kit uses one half of the
2x5 header. The 2x5 header also supports up to one 15-in-1 Media Card Reader.
1 USB 3.0 port available by a 2x10 header.

HP Z440 Workstation

3rd and 4th 3.5" HDD each occupy one external bay
3rd and 4th 2.5" HDD/SSD occupy a single external bay within a 2:1 carrier)

Rear I/O
?

Interfaces Supported
?

On-board RAID Support?RAID 0, 1, 10 (Factory integrated)

Chassis Dimensions (H x W
x D)
?

Rack Dimensions
?
Weight
?

Temperature
?

Humidity
?

Maximum Altitude (non­pressurized)
?

4 USB 3.0, 2 USB 2.0, 2 PS/2, 1 RJ-45 (NIC), 1 Audio Line-In, 1 Audio Line-Out.
Serial supported with optional connector on PCI bracket cabled to system board connector.
?
15-in-1 Media Card Reader (optional)
6-channel SATA interface (6 @ 6.0 Gb/s). 6 channels are eSATA configurable for use with eSATA CTO/AMO
Kit (No hot plug / hot swap supported).
USB 2.0, USB 3.0
?

RAID 5 (NOT Factory integrated)

Factory integrated RAID available for SATA/SAS drives (RAID 0, 0 Data, 1, and 10)
?

Footprint Dimensions:

H: 17.0"?? [431.8mm]
W: 6.65"? [168.91mm]
D: 17.5"?? [444.7mm] (measured to the rear of service panel)

Maximum Dimensions:

H: 17.0"?? [431.8mm]
W: 6.65"? [168.91mm]
D: 17.9"? [455.7mm] (measured to the rear padlock loop)

4U

Exact weights depend upon configuration.
Minimum: 11.0 kg (24.3 lbs.)
Standard: 13.5 kg (29.8 lbs.)
Maximum: 17.5 kg (38.5 lbs.)
?
Operating: 5¡ã to 35¡ãC (40¡ã to 95¡ãF)
Non-operating: -40¡ã to 60¡ãC (-40¡ã to 140¡ãF)
?
Operating: 8% to 85% relative humidity, non-condensing
Non-operating: 8% to 90% relative humidity, non-condensing
?
Operating: 3,048m (10,000ft)
Non-operating: 9,144m (30,000ft)
?

?

?

DA - 15077???Worldwide QuickSpecs ¡ª Version 37 ¡ª 7/8/2019

Page? 5

QuickSpecs

Overview

HP Z440 Workstation

Power Supply
?

Workstation ISV
Certifications

ENTRY

525 watts wide-ranging, active Power Factor Correction, 85% Efficient, with no 6-pin graphics power cable
?
The Z440 525W power supply efficiency report can be found at this link:

http://www.plugloadsolutions.com/psu_reports/HEWLETT%20PACKARD_753084­001_525W_ECOS%203914_Report.pdf

HIGH-END

700 watts wide-ranging, active Power Factor Correction, 90% Efficient, with two graphics power cables
700w PSU will support up to 225w of graphics
?
The Z440 700W power supply efficiency report can be found at this link:

http://www.plugloadsolutions.com/psu_reports/HEWLETT%20PACKARD_719795­001_700W_ECOS%203915_Report.pdf

?
See the latest list of certifications at

http://www.hp.com/united-states/campaigns/workstations/partnerships.html

DA - 15077???Worldwide QuickSpecs ¡ª Version 37 ¡ª 7/8/2019

Page? 6

QuickSpecs

Supported Components

HP Z440 Workstation

Processors

Factory

?
Intel? Xeon? E5-1600 v4 Series CPU

Intel? Xeon? E5-1603 v4 2.8 2133 4C CPU
Intel? Xeon? E5-1607 v4 3.1 2133 4C CPU
Intel? Xeon? E5-1620 v4 3.5 2400 4C CPU
Intel? Xeon? E5-1630 v4 3.7 2400 4C CPU

Intel? Xeon? E5-1600 v3 Series CPU

Intel? Xeon? E5-1680 v3 3.2 2133 8C CPU
Intel? Xeon? E5-1660 v3 3.0 2133 8C CPU
Intel? Xeon? E5-1650 v3 3.5 2133 6C CPU
Intel? Xeon? E5-1630 v3 3.7 2133 4C CPU
Intel? Xeon? E5-1620 v3 3.5 2133 4C CPU
Intel? Xeon? E5-1603 v3 2.8 1866 4C CPU

Intel? Xeon? E5-2600 v3 Series CPU

Intel? Xeon? E5-2630 v3 2.4 1866 8C CPU

????????

ϒ⁄

Multicore is designed to improve performance of certain software products. Not all customers or
software applications will necessarily benefit from use of this technology. Performance and clock
frequency will vary depending on application workload and your hardware and software configurations.
Intel's numbering, branding and/or naming is not a measurement of higher performance.

Configured

Y
Y
Y
Y

Y
Y
Y
Y
Y
Y

? ? ? ?

Y

Option

Kit

N
N
N
N

N
N
N
N
N
N

N

Option Kit Part

Number

? ?
? ?
? ?
? ?

? ?
? ?
? ?
? ?
? ?
? ?

? ?

Support

Notes

?

?

Monitors / Displays

?
?

HP Z Display Z27n 27-inch IPS LED Backlit Monitor
HP Z Display Z25n 25-inch IPS LED Backlit Monitor
HP Z Display Z24n 24-inch IPS LED Backlit Monitor
HP Z Display Z24nq 23.8-inch
HP Z Display Z24nf 23.8-inch IPS Backlit Monitor
HP Z Display Z23n 23-inch IPS LED Backlit Monitor
HP Z Display Z22n 21.5-inch IPS LED Backlit Monitor

Supported by all operating systems available from HP
Screen size measured diagonally

IPS

Backlit Monitor

?

Factory

Configured

?
?
?
?
?
?
?

Option

Kit

Y
Y
Y
Y
Y
Y
Y

Option Kit Part

Number

K7C09A8#ABA
K7C01A8#ABA
K7B99A8#ABA
L1K59A8#ABA
K7C00A8#ABA
M2J79A8#ABA
M2J71A8#ABA

Support

Notes

?
?
?
?
?
?
?

Storage / Hard Drives

? ? ? ? ?
SAS Hard Drives

SAS Hard Drives for HP Workstations

Factory

Configured

Option

Kit

Option
Kit Part
Number

Support

Notes

HP 1.2TB SAS 10K SFF HDD
HP 600GB SAS 10K SFF HDD
HP 300GB SAS 10K SFF HDD

DA - 15077???Worldwide QuickSpecs ¡ª Version 37 ¡ª 7/8/2019

Y Y
Y Y
Y Y

E2P04AA

A2Z21AA
A2Z20AA

Page? 7

?
?
?

QuickSpecs

Supported Components

HP Z440 Workstation

?

SATA Hard Drives
?

?

?

600GB SAS 15K SFF HDD
300GB SAS 15K SFF HDD

NOTES:

Up to (4) 2.5-inch 15K rpm SAS drives: 300, 600 GB; 2.4 TB max
?
Up to (4) 2.5-inch 10K rpm SAS drives: 300, 600 GB, 1.2 TB; 4.8 TB max
?

NOTE:

SAS controller add-in card required

?

NOTE:

3rd and 4th SFF SAS HDDs require and will be automatically installed into a single 2:1 5.25" external bay
adapter. This hardware is required when installing 3rd/4th HDDs using Aftermarket Option (AMO) drives.
?
Removable Boot Drive option

?

Factory

Configured

SATA (Serial ATA) Hard Drives for HP Workstations

500GB SATA 7200 rpm 6Gb/s 3.5" HDD
1TB SATA 7200 rpm 6Gb/s 3.5" HDD
1TB SATA 7200 rpm 6Gb/s 3.5" HDD (Enterprise Class)
1TB SATA 7200 rpm 6Gb/s 3.5" HDD (Enterprise Class)

2.0TB SATA 7200 rpm 6Gb/s 3.5" HDD

3.0TB SATA 7200 rpm 6Gb/s 3.5" HDD
4TB SATA 7200 rpm 6Gb/s 3.5" HDD

(Enterprise Class)
500GB SATA 7.2K SED SFF HDD
1TB SATA 7200 rpm 8GB 3.5" SSHD (hybrid)

NOTES:

?
Up to (4) 3.5-inch 7200 rpm SATA drives: 500 GB, 1.0, 2.0, 3.0, 4.0 TB; 16.0 TB max
?
Up to (1) 2.5-inch SATA Self-Encrypting Drive (SED): 500 GB Opal 1
?
Up to (1) 3.5-inch 7200 RPM SATA Solid State Hybrid Drive (SSHD): 1TB + 8GB NAND
?

NOTE:

3rd and 4th HDDs require and will be automatically installed in the factory into a single 3.5" to 5.25"
external bay adapter, available as AMO (NQ099AA). This hardware is required when installing 3rd/4th HDDs
using Aftermarket Option (AMO) drives.
?
Removable Boot Drive option

? ? ? ? ?

Y Y
Y Y

Option Kit

Y Y
Y Y
Y Y
Y Y
Y Y
Y Y
Y Y

Y
Y Y

L5B75AA
L5B74AA

Option
Kit Part
Number

LQ036AA

LQ037AA
W0R10AA
W0R10AA

QB576AA

QF298AA

K4T76AA

N

D8N29AA
M7S54AA

Support

Notes

?
?
?
?
?
?
?

?
?

?
?

?

DA - 15077???Worldwide QuickSpecs ¡ª Version 37 ¡ª 7/8/2019

Page? 8

QuickSpecs

Supported Components

HP Z440 Workstation

SATA Solid State Drives

Option

Factory

Configured

HP Solid State Drives (SSDs) for Workstations

HP 128GB* SATA 6Gb/s SSD Y Y
HP 256GB* SATA 6Gb/s SSD Y Y
HP 512GB* SATA 6Gb/s SSD Y Y
HP 1TB SATA* 6Gb/s SSD
HP 2TB SATA 6Gb/s SSD
HP 256GB SATA* 6Gb/s SED SSD
HP 256GB SATA 6Gb/s SED Opal 2 SSD
HP 512GB SATA SED SSD
HP Enterprise Class 240GB SATA SSD
HP Enterprise Class 480GB SATA SSD

NOTES:

Up to (4) 2.5-inch 6Gb/s SATA Solid State Drives: 128, 256, 512 GB, 1 TB; 4.0 TB max
?
Up to (1) 2.5-inch 6Gb/s SATA Self-Encrypting Solid State Drive (SED SSD): 256 GB Opal 2, 512 GB Opal 2
?
Up to (4) 2.5-inch HP Enterprise Class 6Gb/s SATA Solid State Drives: 240, 480 GB; 1.9 TB max
?
3rd and 4th SSDs require and will be automatically installed into a single 2:1 5.25" external bay adapter,
available as AMO (K4T74AA). This hardware is required when installing 3rd/4th SSDs using Aftermarket
Option (AMO) drives.

? ? ? ?

Y Y
Y Y
Y
Y Y
Y Y
Y Y
Y Y

Option Kit

N

Kit Part
Number

A3D25AA

A3D26AA

D8F30AA

F3C96AA

Y6P08AA

? ?
G7U67AA
N8T26AA
T3U07AA
T3U08AA

Support

Notes

?
?
?
?
?

?
?

?

?

PCIe Solid State Drives

?

PCIe SSDs for HP Workstations

HP Z Turbo Drive 512GB SSD
HP Z Turbo Drive 256GB SSD
HP Z Turbo Drive G2 512GB SSD
HP Z Turbo Drive G2 256GB SSD
HP Z Turbo Drive G2 1TB SSD
HP Z Turbo Drive G2 256GB TLC SSD
HP Z Turbo Drive G2 512GB TLC SSD
HP Z Turbo Drive G2 1TB TLC SSD
HP Z Turbo Drive G2 256GB SED SSD
HP Z Turbo Drive G2 512GB SED SSD

HP Z Turbo Drive Quad Pro

HP Z Turbo Drive Quad Pro 2x256GB PCIe SSD
HP Z Turbo Drive Quad Pro 2x512GB PCIe SSD
HP Z Turbo Drive Quad Pro 2x1TB PCIe SSD
HP Z Turbo Drive G2 1TB TLC SSD
HP Z Turbo Drive G2 256GB TLC SSD
HP Z Turbo Drive G2 512GB TLC SSD
HP Z Turbo Drive Quad Pro 256GB SSD module

Option

Factory

Configured

Y Y
Y Y
Y Y
Y Y
Y Y
Y Y
Y Y
Y Y
Y Y
Y Y

Y Y
Y Y
Y Y
Y Y
Y Y
Y Y
N

Option Kit

? ? ? ?

? ? ? ?

Y

Kit Part
Number

G3G89AA
G3G88AA
M1F74AA
M1F73AA
T9H98AA

Y1T46AA
Y1T49AA
Y1T52AA
Y1T55AA
Y1T58AA

N2M98AA
N2M99AA

T9H99AA

Y1T52AA
Y1T46AA
Y1T49AA

N2N00AA

Support

Notes

?
?
?
?
?
?
?
?
?
?

Note 2
Note 2
Note 2

?
?
?

Note 1

DA - 15077???Worldwide QuickSpecs ¡ª Version 37 ¡ª 7/8/2019

Page? 9

QuickSpecs

Supported Components

HP Z440 Workstation

HP Z Turbo Drive Quad Pro 512GB SSD module
HP Z Turbo Drive Quad Pro 1TB SSD module
HP Z Turbo Drive Quad Pro 2x256GB PCIe SSD
HP Z Turbo Drive Quad Pro 2x512GB PCIe SSD
HP Z Turbo Drive Quad Pro 2x1TB PCIe SSD

Intel 750 Series AIC PCIe SSD

Intel 750 Series AIC 400GB PCIe SSD
Intel 750 Series AIC 800GB PCIe SSD
Intel 750 Series AIC 1.2TB PCIe SSD

NOTES:

Up to (4) PCI Express Solid State Drives: 256, 512 GB, 1 TB; 4.0 TB max (via Quad Pro)
Up to (1) Intel 750 Series PCIe SSD: 400GB, 800GB, 1.2TB

NOTE:

525W PSU on Z440 only has power connections for (2) HDDs standard. 3rd/4th HDDs/SSDs require a

4pin-to-dual-SATA cable.

NOTE:

PCIe SSDs are not available with SAS controller or SAS HDDs. All PCIe SSD configurations require the

HP Z4 Fan and Front Card Guide Kit, which is available both CTO (G8T99AV) and AMO (J9P80AA).

NOTE 1:
NOTE 2:

M.2 SSD module only
Dual M.2 SSD modules plus carrier

N
N
Y Y
Y Y
Y Y

? ? ? ?
Y Y
Y Y
Y Y

Y
Y

N2N01AA

T9J00AA
N2M98AA
N2M99AA

T9H99AA

?Y4A61AV
?Y4A62AV

Y4A63AV

Note 1
Note 1

?
?
?

?
?
?

?

Hard Drive Controllers

Option

Factory

?
Integrated SATA 6.0 Gb/s Controller

Integrated SATA 6.0 Gb/s Controller

Factory integrated RAID on motherboard for SATA drives

RAID 0 Configuration - Striped Array
RAID 0 Data Configuration -- Boot/OS Drive + 2 Drive Striped

Array
RAID 1 Configuration - Mirrored Array
RAID 10 Configuration - Striped/Mirrored Array

LSI 9217-4i4e 8-port SAS 6Gb/s RAID Card

LSI 9217-4i4e 8-port SAS 6Gb/s RAID Card

LSI 9270-8i SAS 6Gb/s ROC RAID Card and iBBU9 Battery
Backup Unit

LSI 9270-8i SAS 6Gb/s ROC RAID Card
LSI iBBU09 Battery Backup Unit

Integrated RAID for PCIe SSDs

RAID 0 Data Configuration

?
SATA hardware RAID is supported on Linux systems that have support for the Intel RSTe technology. The
Linux kernel, with built-in software RAID, provides excellent functionality and performance. It is a good
alternative to hardware-based RAID. Please visit http://www.hp.com/support/linux_hardware_matrix for
RAID capabilities with Linux.
All drives must be identical in type and capacity.
RAID arrays greater than 2 TB are fully supported.

Configured

Y

? ? ? ?

Y

Y

Y
Y

? ? ? ?

Y Y

? ? ? ?

N
N

? ? ? ?

Y

Option

Kit

N

N

N

N
N

Y
Y

N

Kit Part

Number

?

?

?

?
?

E0X20AA

E0X21AA
E0X19AA

?

Support

Notes

Six Ports

Note 1

Note 1

Note 1
Note 1

Note 2, 4

Note 2, 4

?

Note 3

DA - 15077???Worldwide QuickSpecs ¡ª Version 37 ¡ª 7/8/2019

Page? 10

QuickSpecs

Supported Components

HP Z440 Workstation

?

?

Graphics

?

NOTE 1:

SAS RAID configurations are supported on this Linux system. For details, please visit

http://www.hp.com/support/linux_hardware_matrix

?

NOTE 2:

Striping of 2 or more HDDs into a single logical volume
IM: Mirroring of 2 HDDs into a single logical volume
IME: Mirroring of 3 or more HDDs into a single logical volume.?
For details, please visit

?

NOTE 3:
Note 4:

and AMO (J9P80AA).

?

Professional 2D

NVIDIA NVS 310 1GB Graphics
NVIDIA NVS 315 1GB Graphics
NVIDIA NVS 510 2GB Graphics

Graphics Cable Adapters

HP DisplayPort to Dual Link DVI Adapter
HP DisplayPort To DVI-D Adapter
HP DisplayPort To DVI-D Adapter (2-Pack)
HP DisplayPort To DVI-D Adapter (4-Pack)
HP DisplayPort To DVI-D Adapter (6-Pack)
HP DisplayPort To VGA Adapter
HP DisplayPort To VGA Adapter 2nd

Entry 3D

NVIDIA? Quadro? K620 2GB Graphics
NVIDIA? Quadro? K420 2GB Graphics
NVIDIA? Quadro? P400 2GB Graphics
NVIDIA? Quadro? P600 2GB Graphics
AMD FirePro W2100 2GB Graphics

Mid-range 3D

NVIDIA? Quadro? K1200 4GB Graphics
NVIDIA? Quadro? K2200 4GB Graphics
NVIDIA? Quadro? M2000 4GB Graphics
NVIDIA? Quadro? P
NVIDIA? Quadro? P2000 5GB Graphics
Radeon ProTM WX4100 4GB Graphics
AMD FirePro W4300 4GB Graphics
AMD FirePro W5100 4GB Graphics

High End 3D

NVIDIA? Quadro? M4000 8GB Graphics

Requires hard drives with identical speed, capacity, and interface. Specific user-configured hardware

Specific user-configured hardware SAS RAID configurations are supported on this Linux system. IS:

http://www.hp.com/support/linux_hardware_matrix

PCIe SSDs NOT available for Boot RAID Configuration

Configuration requires the HP Z4 Fan and Front Card Guide Kit, which is available both CTO (G8T99AV)

1000 4GB Gr

aphics

Factory

Configured

? ? ? ? ?
Y Y
Y Y
Y Y

? ? ? ? ?
Y Y
Y Y
Y
Y
Y
Y Y
Y

? ? ?
Y Y
Y Y
Y Y
Y Y
Y Y

? ? ?
Y Y
Y Y
Y Y
Y Y
Y Y
Y Y
Y Y
Y Y

? ? ?
Y Y

Option

Kit

N
N
N

N

Option Kit

Part Number

M6V51AA

E1U66AA

C2J98AA

NR078AA

FH973AA

? ?
? ?
? ?

AS615AA

? ?

J3G87AA
N1T07AA
1ME43AA
1ME42AA

J3G91AA

L4D16AA

J3G88AA

T7T60AA
1ME01AA
1ME41AA

Z0B15AA

T7T58AA

J3G92AA

M6V52AA

Support

Notes

Note 1
Note 1
Note 2

?
?

?

?
?
?
?
?

?

Note 5

Note 5, 6

?

Note 5
Note 5, 6
Note 5, 6
Note 5, 6

Notes 3, 4

Supported

# of cards

3
3
2

1
1
1
1
1
1
1

2
2
2
2
2

2
2
2
2
2
2
2
2

2

DA - 15077???Worldwide QuickSpecs ¡ª Version 37 ¡ª 7/8/2019

Page? 11

QuickSpecs

Supported Components

HP Z440 Workstation

NVIDIA? Quadro? M5000 8GB Graphics
NVIDIA? Quadro? P
NVIDIA? Quadro? P5000 16GB Graphics

AMD FireProTM W7100 8GB Graphics
?
?
?
?
? ? ? ? ? ? ?
?

Memory

Radeon ProTM WX7100 8GB Graphics

Ultra 3D

NVIDIA? Quadro? P6000 24GB Graphics

NVIDIA? Quadro? Sync II

Note 1:

When configuring with a 3rd NVS 310 or 315--the configuration requires the HP Z4 Fan and Front Card Guide

Kit, which is available both CTO (G8T99AV) and AMO (J9P80AA).

Note 2:

Note 3:

AMO (J9P80AA).

Note 4:

Note 5:

Note 6:

(G8T99AV) and AMO (J9P80AA).

If 1st graphics card is NVS 510 then 2nd graphics card must be NVS 510 or NVS 310.

Configuration requires the HP Z4 Fan and Front Card Guide Kit, which is available both CTO (G8T99AV) and

Supported on 700W PSU chassis only.
Dual graphics configuration supported on 700W PSU chassis only.
Dual graphics configuration requires the HP Z4 Fan and Front Card Guide Kit, which is available both CTO

CTO

DDR4-2133 ECC Registered DIMMs

16GB DDR4-2133 ECC Registered RAM
8GB DDR4-2133 ECC Registered RAM
HP 32GB (1x32GB) DDR4-2400 ECC Reg RAM
HP 16GB (1x16GB) DDR4-2400 ECC Reg RAM
HP 8GB (1x8GB) DDR4-2400 ECC Reg RAM
HP 4GB (1x4GB) DDR4-2400 ECC Reg RAM
? ? ? ?

NOTES:

For details on the supported memory configurations on the HP Z440 Workstation, please refer to the
System Technical Specifications - System Board section of this document.
?
Each processor supports up to 4 channels of DDR4 memory. To realize full performance at least 1 DIMM
must be inserted into each channel.
?
The CPUs determine the speed at which the memory is clocked. If an 2133MT/s capable CPU is used in the
system, the maximum speed the memory will run at is 2133MT/s, regardless of the specified speed of
the memory.

4000 8GB Gr

aphics

Y Y
Y Y
Y Y
Y Y
Y Y

? ? ? ? ?
Y Y
N

Y

M6V53AA
1ME40AA

Z0B13AA

J3G93AA

Z0B14AA

Z0B12AA

1WT20AA

Option Kit Part

Number

? ? ?
J9P83AA
J9P82AA

T9V41AA
T9V40AA
T9V39AA
T9V38AA

Notes 3, 4
Notes 3, 4
Notes 3, 4
Notes 3, 4
Notes 3, 4

Notes 3, 4

? ?

Support Notes

1,2
1,2
1,2
1,2
1,2
1,2

1
1
1
1
2

1

?

?
?
?
?
?
?

NOTE 1:

DDR3 DIMMs ARE NOT SUPPORTED.

NOTE 2:

Z440 Memory Cooling Solution, which is available both CTO (J2R51AV) and AMO (J2R52AA).

NOTE:

numbers designated as "2133"? or "2400"? will be transitioned to using 2666MHz speed memory
components. This does not affect HP part number availability nor does it affect system performance or
operation. All hardware configurations currently supporting HP memory part numbers designated as
"2133"? or "2400"? have been tested to work with 2666MHz memory and are fully-supported by HP
under standard support terms.

?

ONLY registered DDR4 DIMMs are supported.

Configurations of greater than 4x memory DIMMs or that include 32GB DIMMs require the HP

Factory-configured CTO (xxxxxAV) and aftermarket AMO (xxxxxAA, xxxxxAT) HP memory part

DA - 15077???Worldwide QuickSpecs ¡ª Version 37 ¡ª 7/8/2019

Multimedia and Audio Devices

?

?

Page? 12

QuickSpecs

Supported Components

?

Multimedia and Audio Devices

?

Integrated Realtek HD ALC221 Audio
? ? ? ? ?

?

Optical and Removable Storage

?

HP SlimTray Optical Drives

HP 9.5mm Slim DVD Writer
HP 9.5mm Slim DVD-ROM Drive
HP 9.5mm Slim BDXL Blu-Ray Writer

HP 15-in-1 Media Card Reader

HP 15-in-1 Media Card Reader

HP DX115 Removable Drive Enclosure

HP DX115 Removable HDD Frame/Carrier
HP DX115 Removable HDD Carrier

Actual speeds may vary. Does not permit copying of commercially available DVD movies or other copyright
protected materials. Intended for creation and storage of your original material and other lawful uses.
Double Layer discs can store more data than single layer discs. However, double-layer discs burned with
this drive may not be compatible with many existing single-layer DVD drives and players.
?
With Blu-ray, certain disc, digital connection, compatibility and/or performance issues may arise, and do
not constitute defects in the product. Flawless playback on all systems is not guaranteed. In order for
some Blu-ray titles to play, they may require a DVI or HDMI digital connection and your display may require
HDCP support. HD-DVD movies cannot be played on this workstation.
?

NOTE 1:
NOTE 2:
NOTE 3

optical (5.25") bay.

NOTE 4:

Not supported as a 2nd drive option.
Cannot be ordered in combination with another Blu-ray Writer.

: Only one DX115 device can be installed into Z440. This device can only be installed into the top

Carrier requires a Z440 to have the DX115 frame installed. This part number is for the carrier only.

HP Z440 Workstation

Option Kit

Factory

Configured

Factory

Configured

? ? ? ?
Y Y
Y Y
Y Y

? ? ? ?
Y Y

? ? ? ?

N
N

Option Kit

Y

Y
Y

Option Kit

N

Option Kit Part

Part

Number

Number

K3R64AA
K3R63AA
K3R65AA

G1S79AA

FZ576AA

NB792AA

?

Support

Notes

? ?

Support

Notes

?
Note 1
Note 2

?

Note 3

?

?

Controller Cards

?
? ?

?

?

HP IEEE 1394b FireWire? PCIe Card
HP ThunderboltTM 2 PCIe 1-port I/O Card

NOTE 1:

Compatible with NVIDIA? Quadro? K620, K2200, and K4200.

DA - 15077???Worldwide QuickSpecs ¡ª Version 37 ¡ª 7/8/2019

Factory

Configured

Y Y
Y Y

Option Kit

Option Kit

Part

Number

NK653AA
F3F43AA

Support

Notes

?

Note 1

Page? 13

QuickSpecs

Supported Components

Networking and Communications

?

Integrated Intel? I218LM PCIe GbE Controller
Intel? Ethernet I210-T1 PCIe NIC
HP X520 10GbE Dual Port Adapter
HP 10GbE SFP+ SR Transceiver
HP 361T PCIe Dual Port Gigabit NIC
Intel? Ethernet I350-T2 2-Port 1Gb NIC
Intel? Ethernet I350-T4 4-port 1Gb NIC
Intel? 7260 802.11 a/b/g/n PCIe WLAN NIC
Intel? 8260 802.11 a/b/g/n/ac with Bluetooth 4.2 PCIe

NIC

Factory

Configured

Y
Y Y
Y Y
Y Y

N

Y Y
N
N
N

HP Z440 Workstation

Option Kit

N

Y

Y
Y
Y

Option Kit

Part

Number

? ?

E0X95AA
C3N52AA
C3N53AA
C3N37AA
V4A91AA

W8X25AA

F2P07AA

N0S95AA

Support Notes

?
?
?

Note 1

?

Note 1

?

?

NOTE 1:

not connote actual operating speed of 1 Gb/sec. For high speed transmission, connection to a Gigabit
Ethernet server and network infrastructure is required.

*Wireless access point and internet service required. Availability of public wireless access points limited.

"Gigabit" Ethernet indicates compliance with IEEE standard 802.3ab for Gigabit Ethernet, and does

Racking and Physical Security

HP Solenoid Hood Lock & Hood Sensor
HP Business PC Security Lock Kit
HP Z240/Z440 Depth Adjust Fixed Rail Rack Kit

?

HP Keyed Cable Lock 10mm

Input Devices

Option Kit

Factory

?

Configured

Y
N
N
N

Option Kit

N
Y
Y
Y

Part

Number

? ?

PV606AA

WH340AA

T1A62AA

Support

Notes

?
?
?

DA - 15077???Worldwide QuickSpecs ¡ª Version 37 ¡ª 7/8/2019

Page? 14

QuickSpecs

Supported Components

HP Z440 Workstation

?

Factory

Configured

HP PS/2 Keyboard
HP USB Keyboard
HP USB Smart Card Keyboard
HP Wireless Keyboard and Mouse
HP PS/2 Mouse
HP USB Optical Mouse
HP USB 1000dpi Laser Mouse
HP USB Optical 3-Button 2.9M OEM Mouse
HP USB Hardened Mouse
HP SpaceMouse Pro USB 3D Input Device
HP SpacePilot Pro 3D USB Intelligent Controller
3Dconnexion CADMouse
HP PS/2 Business Slim Keyboard

?

HP USB Business Slim Keyboard
HP Wireless Business Slim Keyboard

NOTE 1:

Combo kit includes wireless mouse

Y Y
Y Y
Y Y
Y Y
Y Y
Y Y
Y Y
N
Y Y
N
N
Y Y
Y Y
Y Y
Y Y

Option

Kit

Y

Y
Y

Option Kit

Part

Number

QY774AA
QY776AA
E6D77AA
QY449AA
QY775AA
QY777AA
QY778AA

ET424AA
P1N77AA
B4A20AA

WH343AA

M5C35AA

N3R86AA
N3R87AA
N3R88AA

Support

Notes

?

?

?
?
?
?
?
?

Note 1

?

Other Hardware

?

Option Kit

Factory

?

Z440 HP Z Cooler
HP Z440 Memory Cooling Solution
HP Z440 Fan and Front Card Guide Kit
HP Internal USB Port Kit
HP eSATA PCI Cable Kit
HP Serial Port Adapter
HP Optical Bay HDD Mounting Bracket
HP Power Cord Kit
HP Workstation Mouse Pad
HP ENERGY STAR? Enabled Configuration

?
Note 1:

The HP Z440 Memory Cooling Solution is available to add to any configuration for improved system
cooling, but is required for any memory configuration using more than 4x DIMMs or that uses 32GB DIMMs.
?

Note 2

: Fan and Front Card Guide required for any configuration that includes any of the following

components:

- 1 x LSI 9217 SAS Controller

- 1 x NVIDIA? Quadro? P5000

- 1 x AMD Radeon Pro WX 7100

- 2 x AMD FirePro W4300

- 2 x NVIDIA? Quadro? M2000

- 3 x NVIDIA NVS 310/315

- 1 x NVIDIA? Quadro? M4000

- 1 x NVIDIA? Quadro? M5000

Configured

Y
Y Y
Y Y

N

Y Y

Y Y
N
N

Y

Y

Option Kit

N

Y

Y
Y
N
N

Part

Number

? ?
J2R52AA
J9P80AA

EM165AA
GM110AA

PA716A

NQ099AA

DM293A

?

? ?

Support Notes

Note 1
Note 2
Note 3
Note 4

?
?
?

Japan only

DA - 15077???Worldwide QuickSpecs ¡ª Version 37 ¡ª 7/8/2019

Page? 15

QuickSpecs

Supported Components

- 1 x NVIDIA? Quadro? K4200

- 1 x NVIDIA? Quadro? K5200

- 2 x AMD FirePro W5100

- 1 x AMD FirePro W7100

- 1 x HP Z Turbo Drive 256GB

- 1 x HP Z Turbo Drive 512GB

- 1 x HP Z Turbo Drive G2 256GB

- 1 x HP Z Turbo Drive G2 512GB

- Any HP Z Turbo Quad Pro configuration

Note 3:
?
Note 4:

?

Software

?

HP Performance Advisor
HP Remote Graphics Software (RGS) 7.1
MS Office Home & Business 2016
Cyberlink PowerDVD and Power2Go

?
?

Foxit PhantomPDF Express

NOTE 1:
NOTE 2:

?? Windows 7 Professional 32/64
?? Windows 8.1 Professional 32/64
?? RHEL v6.6, 7
?? SLED 11 SP3

The HP Internal USB Port kit has a single USB 2.0 type A connector.

No hot plug / hot swap supported

Option Kit

Factory

Available as a free download here:
Supported operating systems:

Configured

Y Y
Y Y
Y Y
Y
Y

www.hp.com/go/performanceadvisor

Option Kit

N
N

?
?
?
? ?
? ?

HP Z440 Workstation

Part

Number

Support Notes

Note 1
Note 2
Note 3

?

Operating
Systems

For more information, go to:

NOTE 3

: Must select as a Configure to Order option.

?

Windows 10 Pro 64
Windows 10 Pro downgrade to Windows 7 Professional 64
Windows 10 Home 64
HP Linux Installer Kit
Red Hat Enterprise Linux (RHEL) Workstation - Paper License (1yr)

NOTE 1

: This second OS must be ordered with the HP Linux Installer Kit as the first OS.

http://www.hp.com/go/rgs

Support Notes

?
?

High end

?

Note 1

DA - 15077???Worldwide QuickSpecs ¡ª Version 37 ¡ª 7/8/2019

Page? 16

QuickSpecs

HP Z440 Workstation

System Technical Specifications

?

System Board

System Board Form Factor?Main System Board:

? 24 x 31 cm
? 9.6 x 12.2 inches

Processor Socket
Chipset
Super I/O Controller
Memory Expansion Slots
Memory Type Supported

Memory Modes
Memory Speed Supported
Memory Protection
Memory
Memory Configuration Table?Please refer to the table below for details on how supported memory configurations are installed in

Single LGA2011 R3
Intel? C612 Chipset
Nuvoton NPCD379H (SIO-12)
8 DDR4 memory slots
DDR4, RDIMM (Registered), ECC: 4GB, 8GB, 16GB and 32GB

?
Channel Interleaved
1600MT/s, 1866MT/s, 2133MT/s, and 2400MT/s
ECC available on data, parity on address and command

?

your system.
?
* For 32 bit operating systems, there is a memory limit of 4GB.
?
~ Although technically possible, these configurations are not available to order at this time.
?

?

? ?

? ?

Capacity

4 GB

8 GB

12 GB

16 GB

32 GB

48 GB

64 GB

96 GB
128 GB
128 GB
256 GB

Slot Load Order

Notes

*

?

?

?

?

~

?

~

?
?
?

CPU 0

Front Slots

DIMM1 DIMM2 DIMM3 DIMM4 DIMM5 DIMM6 DIMM7 DIMM8

4 GB
4 GB

8 GB
4 GB
4 GB

8 GB

4 GB
8 GB

16 GB

8 GB 4 GB 8 GB 4 GB 4 GB 8 GB 4 GB 8 GB
8 GB

16 GB
16 GB

16 GB 16 GB 16 GB 16 GB 16 GB 16 GB 16 GB 16 GB
32 GB
32 GB 32 GB 32 GB 32 GB 32 GB 32 GB 32 GB 32 GB

1 5 3 7 8 4 6 2

? ? ? ? ? ? ?

? ? ? ? ? ?

?

?

4 GB

?
?

8 GB

?

8 GB

?

4 GB
4 GB

?

4 GB
8 GB

?

8 GB

16 GB
16 GB

32 GB

? ? ? ?

? ?

4 GB

?
?

8 GB

?

8 GB 8 GB

? ?

4 GB

?
?

8 GB

?

Rear Slots

4 GB

?

4 GB
8 GB

?

8 GB

16 GB
16 GB

32 GB

?

4 GB

?
?

8 GB

?

8 GB

?

4 GB

?
4 GB
4 GB

8 GB

4 GB
8 GB

16 GB

8 GB

16 GB
16 GB

32 GB

?

?

Rating

Fair

Good

Fair

Better

Best

Good

Best
Best

Good

Best
Best

Best
Best

Best
Best
Best

?

For a detailed diagram, please refer to the label located on the inside of the system side panel.

DA - 15077???Worldwide QuickSpecs ¡ª Version 37 ¡ª 7/8/2019

Page? 17

QuickSpecs

System Technical Specifications

HP Z440 Workstation

Maximum Memory
?

Memory Configuration
(Supported)

Note on Maximum Memory?Maximum memory capacities assume 64-bit operating systems such as Windows 8.1 64-bit, Windows 7

PCI Express Connectors
?

PCI Connectors (5.0V)
?

Supports up to 256GB
?

Only ECC DIMMs are supported.
?

Ultimate 64-bit, or Windows 7 Professional 64-bit. Windows 7 Professional 32-bit supports up to 4GB.
Linux 32-bit supports up to 8GB.
?

Slot 1 (top):
PCI Express Gen2 x1
Full-height, Half-length
Slot 2:
PCI Express Gen3 x16
Full-height, Full-length (with extender)
Slot 3:
PCI Express Gen2 x4 with open-ended connector**
Full-height, Full-length (with extender)
Slot 4:
PCI Express Gen3 x8 with open-ended connector**
Full-height, Full-length (with extender)
Slot 5:
PCI Express Gen3 x16
Full-height, Full-length (with extender)
** Open-ended connector allows a greater bandwidth (e.g. x16) card to be installed physically into a
lower bandwidth connector/slot.
?

Slot 6:
PCI 32bit/33MHz
Full-height, Full-length (with extender)
?

DA - 15077???Worldwide QuickSpecs ¡ª Version 37 ¡ª 7/8/2019

Page? 18

QuickSpecs

System Technical Specifications

HP Z440 Workstation

Supported Drive Interfaces?SATA

?

Serial Attached SCSI
?

Integrated RAID
?

Integrated Graphics
?

Network Controller
?

External SATA (eSATA)
?

IDE connector
?

Floppy connector
?

Serial
?

2nd Serial
Parallel
AUX IN (audio)

IEEE 1394 Connector(s)
?

USB Connector(s)
?

?

HD Integrated Audio

Front
?

Rear

?

Internal

?

Front
?

Rear

?

Internal

?

Realtek ALC221

2 SATA @6Gb/s, supports RAID 0,1 and NCQ.
4 sSATA @6Gb/s, Supports RAID 0,1,10 and NCQ.
Factory integrated RAID is Microsoft Windows only.

Requires Optional PCIe card
?

SATA: RAID 0, 1
SSATA: RAID 0, 1, 10
? RAID 0 configuration - striped array (supported and configure to
order)
? RAID 1 configuration - mirrored array (supported and configure to
order)
? RAID 5 parity striping (supported but not configure to order)
? RAID 10 striped and mirrored array
*HW RAID functionality not supported by Linux. Use SW RAID
functionality provided in the Red Hat Operating system instead.
?

No
?

Integrated Intel I-218 Gbit LAN
?
Supports the following management functionalities: Intel AMT9.1,
TXT, DASH 1.1, WOL, VLAN, Teaming and PXE 2.1
?

Supported on all SATA and sSATA ports configurable with optional
eSATA* cable kit
* hot plug / hot swap not supported with eSATA
?

No
?

No
?

1 internal header
?

No
No
No
None

?
2 IEEE 1394b (requires optional PCIe card)

?
None

?
4 USB 3.0

?
4 USB 3.0

2 USB 2.0
?

2 USB 2.0 port available with a single 2x5 header. The 2x5 header can
be converted to a standard (Type-A) USB connector through the use
one HP Internal USB Port Kit (EM165AA). This port kit uses one half of
the 2x5 header.
1 USB 3.0 port available by a 2x10 header.

DA - 15077???Worldwide QuickSpecs ¡ª Version 37 ¡ª 7/8/2019

Page? 19

QuickSpecs

System Technical Specifications

HP Z440 Workstation

Flash ROM
CPU Fan Header
Chassis Fan Header
Front PCI Fan Header
Front Control Panel/Speaker

Header
CMOS Battery Holder - Lithium
Integrated Trusted Platform

Module

Power Supply Headers
Power Switch, Power LED &

Hard Drive LED Header
Clear Password Jumper
Serial Port
Parallel Port
Keyboard/Mouse
Power Supply

Power Supply

Operating Voltage Range
Rated Voltage Range
Rated Line Frequency
Operating Line Frequency

Range
Rated Input Current
Heat Dissipation

(Configuration and software
dependent)

Power Supply Fan
ENERGY STAR Qualified

(Configuration dependent)

Yes
Yes
1 Rear System Chassis Fan Header
Yes
Yes

?
Yes
Trusted Platform Module (TPM) 1.2 (Infineon SLB 9660).

Common Criteria EAL4+ Certified. Upgradable to TPM 2.0 through Firmware v5.51 upgrade (Infineon
SLB9665). Convertible to FIPS 140-2 Certified mode. (TPM 2.0 is not available for Win 7 32-bit.). When
the SLB 9660 is converted (via Firmware v5.51) to TPM 2.0 mode then it is renamed as SLB 9665. Once
converted to TPM2.0 the SLB9665 is CC EAL4+ certified.
CG TPM Certified products list:

http://www.trustedcomputinggroup.org/certification/tpmcertifiedproducts/

Yes
Yes

?
Yes
1 internal header
No
USB or PS/2
?

700W 90% Efficient, Custom PSU

(Wide-Ranging, Active PFC)

90-269 VAC 90-269 VAC

100-240 VAC

50-60 Hz
47-66 Hz

100-240V @ 9.5A

Typical = 1648 btu/hr (415 kg-cal/hr)

Max = 2746 btu/hr (692 kg-cal/hr)

92x25 mm variable speed 92x25 mm variable speed

Yes Yes

Yes, 90% Efficient

118 VAC

400 Hz

393-407 Hz

118V @ 9.5A

525W 85% Efficient, Custom PSU

(Wide-Ranging, Active PFC)

100-240 VAC

50-60 Hz
47-66 Hz

100-240V @ 7A

Typical = 1311 btu/hr (330 kg-cal/hr)

Max = 2185 btu/hr (551 kg-cal/hr)

Yes, 85% Efficient

118 VAC

400 Hz

393-407 Hz

118V @ 7A

80 PLUS?

FEMP Standby Power
Compliant @115V
(<2W in S5

EuP Compliant @ 230V
(<0.5 W in S5 - Power Off)

CECP Compliant @ 220V
(<4W in S3 - Suspend to
RAM)

Compliant

- Power Off

)

?

The Z440 700W power supply efficiency report

can be found at this link:

http://www.plugloadsolutions.com/psu_reports/

HEWLETT%20PACKARD_719795-

001_700W_ ECOS%203915_Report.pdf

Yes Yes

Yes Yes

Yes; Configuration dependent Yes; Configuration dependent

DA - 15077???Worldwide QuickSpecs ¡ª Version 37 ¡ª 7/8/2019

The Z440 525W power supply efficiency report

http://www.plugloadsolutions.com/psu_reports/
HEWLETT%20PACKARD_753084-001_525W

_ECOS%203914_Report.pdf

?

can be found at this link:

Page? 20

QuickSpecs

System Technical Specifications

Power Consumption in
sleep mode
(as defined by ENERGY
STAR) - Suspend to RAM
(S3)
(Instantly Available PC)

Built-in Self Test LED
Surge Tolerant Full

Ranging Power Supply
(withstands power surges
up to 2000V)

?

Hood Lock Header
Hood Sensor Header
Memory Fan

?

System Configuration

Yes
Yes
1 Memory Fan Header

HP Z440 Workstation

<15w <15w

Yes Yes

Yes Yes

Example
Configuration #1

ENERGY STAR
QUALIFIED

?
Energy

Consumption

?

?
Heat Dissipation
(Btu/hr)

?

Processor
Memory
Graphics
Disks / Optical
Power Supply
Other

?

Windows Idle (S0)
Windows Busy Typ(S0)
Windows Busy Max (S0)
Sleep (S3)
Off (S5)
Zero Power Mode (ErP)

?
?

Windows Idle (S0)
Windows Busy

Typ(S0)
Windows Busy Max

(S0)
Sleep (S3)
Off (S5)
Zero Power Mode

(ErP)

1x Intel Xeon E5-1603 v3 (Quad-Core)
1x 4GB DDR4-2133? Registered RAM
1x NVIDIA NVS 310
1x 500GB SATA 7200 / 1x Slim DVD-ROM SATA
525W 85% Custom PSU
N/A

115 VAC 230 VAC 100 VAC

LAN Enabled

LAN Disabled

LAN Enabled

LAN Disabled

LAN Enabled

LAN Disabled

51.01 W 51.29 W 53.01 W

112.95 W 110.62 W 113.96 W

117.16 W 112.45 W 114.67 W

2.34 W 2.19 W 2.54 W 2.41 W 2.33 W

2.19W

0.825 W 0.784 W 1.024 W 0.985 W 0.851 W 0.772 W

0.190 W 0.382 W 0.178 W

115 VAC 230 VAC 100 VAC

LAN Enabled

LAN Disabled

LAN Enabled LAN Enabled

LAN Disabled

LAN Enabled

174.06 Btu/hr 175.02 Btu/hr 180.89 Btu/hr

385.39 Btu/hr

377.4 Btu/hr

388.83 Btu/hr

399.75 Btu/hr 383.68 Btu/hr 391.25 Btu/hr

7.98 Btu/hr 7.49 Btu/hr 8.68 Btu/hr 8.21 Btu/hr 7.95 Btu/hr 7.47 Btu/hr

2.18 Btu/hr 2.67 Btu/hr 3.49 Btu/hr 3.36 Btu/hr 2.90 Btu/hr 2.63 Btu/hr

0.649 Btu/hr 1.303 Btu/hr 0.607 Btu/hr

DA - 15077???Worldwide QuickSpecs ¡ª Version 37 ¡ª 7/8/2019

Page? 21

QuickSpecs

System Technical Specifications

HP Z440 Workstation

Example
Configuration #2

ENERGY STAR
QUALIFIED

Energy
Consumption

(Watts)

?

?
Heat Dissipation

(Btu/hr)

?

Example
Configuration #3

Energy
Consumption

(Watts)

?

?
Heat Dissipation

(Btu/hr)

Processor
Memory
Graphics
Disks / Optical
Power Supply
Other

?

Windows Idle (S0)
Windows Busy

Typ(S0)
Windows Busy Max

(S0)
Sleep (S3)
Off (S5)
Zero Power Mode

(ErP)

?
?

Windows Idle (S0)
Windows Busy

Typ(S0)
Windows Busy Max

(S0)

Sleep (S3)
Off (S5)
Zero Power Mode

(ErP)

Processor
Memory
Graphics
Disks/Optical
Power Supply
Other
?

Windows Idle (S0)
Windows Busy

Typ(S0)
Windows Busy Max

(S0)
Sleep (S3)
Off (S5)
Zero Power Mode

(ErP)

?
?

Windows Idle (S0)
Windows Busy

Typ(S0)

1x Intel Xeon E5-1630 v3 (Quad-Core)
2x 4GB DDR4-2133 Registered RAM
1x NVIDIA? Quadro? K620
1x 500GB SATA 7200 / 1xSlim DVD-ROM SATA
700W 90% Custom PSU
N/A

115 VAC 230 VAC 100 VAC

LAN Enabled

LAN Disabled

LAN Enabled

LAN Disabled

LAN Enabled

LAN Disabled

62.25 W 61.50 W 62.31 W

112.48 W 111.39 W 113.48 W

136.87 W 129.05 W 113.64 W

2.25 W

2.147 W

2.41 W 2.30 W 2.25 W 2.14 W

0.821 W 0.775 W 1.024 W 0.925 W 0.842 W 0.769 W

0.167 W 0.306 W 0.158 W

115 VAC 230 VAC 100 VAC

LAN Enabled

212.43? Btu/hr

LAN Disabled

LAN Enabled LAN Enabled

LAN Disabled

209.85 Btu/hr 212.62 Btu/hr

LAN Enabled

383.78 Btu/hr 380.06 Btu/hr 387.19 Btu/hr

467.00 Btu/hr 440.32 Btu/hr 387.74 Btu/hr

7.69 Btu/hr 7.31 Btu/hr 8.21 Btu/hr 7.85 Btu/hr 7.67 Btu/hr 7.31 Btu/hr

2.80 Btu/hr 2.65 Btu/hr 3.49 Btu/hr 3.16 Btu/hr 2.87 Btu/hr 2.62 Btu/hr

0.568 Btu/hr 1.043 Btu/hr 0.538 Btu/hr

1x Intel Xeon E5-1620 v3 (Quad-Core)
2x 8GB DDR4-2133 Registered RAM
1x NVIDIA? Quadro? K2200
2x 1TB SATA 7200 / 1x Slim DVDRW SATA
525W 85% Custom PSU
N/A

115 VAC 230 VAC 100 VAC

LAN Enabled

LAN Disabled

LAN Enabled

LAN Disabled

LAN Enabled

LAN Disabled

51.41 W 51.15 W 52.42 W

179.17 W 175.74 W 176.74 W

201.86 W 198.12 W 196.99 W

2.35 W 2.28 W 2.55 W 2.49 W 2.38 W 2.27 W

0.827 W 0.785 W 1.028 W 0.986 W 0.853 W 0.770 W

0.167 W 0.382 W 0.177 W

115 VAC 230 VAC 100 VAC

LAN Enabled

LAN Disabled

LAN Enabled LAN Enabled

LAN Disabled

LAN Enabled

178.82 Btu/hr 174.56 Btu/hr 178.88 Btu/hr

611.33 Btu/hr 599.62 Btu/hr 603.04 Btu/hr

DA - 15077???Worldwide QuickSpecs ¡ª Version 37 ¡ª 7/8/2019

Page? 22

QuickSpecs

System Technical Specifications

HP Z440 Workstation

?

Example
Configuration #4

Energy
Consumption

(Watts)

?

?

Heat Dissipation

(Btu/hr)

?

Windows Busy Max
(S0)

Sleep (S3)
Off (S5)
Zero Power Mode

(ErP)

Processor
Memory
Graphics
Disks / Optical
Power Supply
Other

?

Windows Idle (S0)
Windows Busy

Typ(S0)
Windows Busy Max

(S0)
Sleep (S3)
Off (S5)
Zero Power Mode

(ErP)

?
?

Windows Idle (S0)
Windows Busy

Typ(S0)
Windows Busy Max

(S0)
Sleep (S3)
Off (S5)
Zero Power Mode

(ErP)

688.75 Btu/hr 675.99 Btu/hr 672.13 Btu/hr

8.02 Btu/hr 7.79 Btu/hr 8.71 Btu/hr 8.48 Btu/hr 8.13 Btu/hr 7.76 Btu/hr

2.82 Btu/hr 2.67 Btu/hr 3.51 Btu/hr 3.36 Btu/hr 2.91 Btu/hr 2.62 Btu/hr

0.571 Btu/hr 1.305 Btu/hr 0.604 Btu/hr

1x Intel Xeon E5-1680 v3 (Eight-Core)
4x 16GB DDR4-2133 Registered RAM
1x NVIDIA? Quadro? K5200
4x 2TB SATA 7200 / 1x Slim DVDRW SATA
700W 90% Custom PSU
N/A

115 VAC 230 VAC 100 VAC

LAN Enabled

LAN Disabled

LAN Enabled

LAN Disabled

LAN Enabled

LAN Disabled

61.88 W 61.39 W 62.35 W

296.64 W 290.88 W 303.03 W

338.63 W 334.85 W 333.11 W

3.99 W 3.91 W 4.02 W 4.04 W 3.99 W 3.91 W

0.86 W

0.764 W

1.02 W 0.91 W 0.86 W 0.76 W

0.166 W 0.305 W 0.165 W

115 VAC 230 VAC 100 VAC

LAN Enabled

LAN Disabled

LAN Enabled LAN Enabled

LAN Disabled

LAN Enabled

211.16 Btu/hr 209.47 Btu/hr 212.75 Btu/hr

1012.14 Btu/hr

992.48 Btu/hr

1033.94 Btu/hr

1155.41 Btu/hr 1142.51 Btu/hr 1136.57 Btu/hr

13.6 Btu/hr 13.4 Btu/hr 13.7 Btu/hr 13.8 Btu/hr 13.6 Btu/hr 13.4 Btu/hr

2.94 Btu/hr 2.60 Btu/hr 3.49 Btu/hr 3.11 Btu/hr 2.91 Btu/hr 2.58 Btu/hr

0.565 Btu/hr 1.042 Btu/hr 0.563 Btu/hr

NOTE:

Power consumption measurements do not take advantage of the Intel Turbo Boost Technology. As a result, power

consumption measurements may be higher.

?

Declared Noise Emissions

Declared Noise Emissions
System Configuration

(Entry level)

?

(Entry-level and High-end configurations)

Processor Info
Memory Info
Graphics Info
Disks/Optical/Floppy

DA - 15077???Worldwide QuickSpecs ¡ª Version 37 ¡ª 7/8/2019

1x Intel Xeon E5-2650 v3 2.30 GHz

2 - DDR4 8 GB 2133 MT/s RDIMM

1x NVIDIA NVS 310

1x 1 TB SATA 7200 RPM

1x Blu-ray DVD-RW

Page? 23

QuickSpecs

System Technical Specifications

?

?

Declared Noise Emissions

(in accordance with ISO
7779 and ISO 9296)

?

?

Environmental Data

?

Idle
Hard drive Operating

(random reads)

DVD-ROM Operating

(sequential reads)

Sound Power

(LWAd, bels)

3.2

3.3

4.3

HP Z440 Workstation

Deskside Sound Pressure

(LpAm, decibels)

14

15

30

Environmental
Requirements

?

?

?

Temperature

Humidity

Maximum Altitude

Dynamic (new)

Cooling

Operating: 5¡ã to 35¡ã C (40¡ã to 95¡ã F)
Non-operating: -40¡ã to 60¡ã C (-40¡ã to 140¡ã F)
?

Operating: 8% to 85% RH, non-condensing
Non-operating: 8% to 90% RH, non-condensing
?

Operating: 3,000 m (10,000 feet)
Non-operating: 9,100 m (30,000 feet)
?

Shock

?? Operating: ?-sine: 40g, 2-3ms (~62 cm/sec)
?? Non-operating:
????? ?-sine: 160 cm/s, 2-3ms (~105g)
????? square: 422 cm/s, 20g

NOTE:

Values represent individual shock events and do not indicate

repetitive shock events.

Vibration

?? Operating random: 0.5g (rms), 5-300 Hz, up to 0.0025g2/Hz
?? Non-operating random: 2.0g (rms), 5-500 Hz, up to 0.0150 g2/Hz
??

NOTE:

Values do not indicate continuous vibration.

?
Above 1524 m (5,000 ft.) altitude, maximum operating temperature is de-

rated by 1¡ã C (1.8¡ã F) per 305 m (1,000 ft.) elevation increase
?

Physical Security and Serviceability

Access Panel

Optical Drive
Hard Drives
Expansion Cards
Processor Socket
Green User Touch Points
Color-coordinated Cables

and Connectors

Tool-less
Includes system board and memory information.

Tool-less
Tool-less
Tool-less
Tool-less
Yes, on primary serviceable components.
Yes

?

DA - 15077???Worldwide QuickSpecs ¡ª Version 37 ¡ª 7/8/2019

Page? 24

QuickSpecs

System Technical Specifications

HP Z440 Workstation

Memory
System Board
Dual Color Power and HD

LED on Front of Computer
Configuration Record SW
Over-Temp Warning on

Screen
Restore CD/DVD Set
Dual Function Front Power

Switch
Padlock Support

Cable Lock Support

Universal Chassis Clamp
Lock Support

Solenoid Lock and Hood
Sensor

Serial, Parallel, USB,
Audio, Network,
Enable/Disable Port
Control

Removable Media
Write/Boot Control

Power-On Password
Setup Password

3.3V Aux Power LED on
System PCA

NIC LEDs (integrated)
(Green & Amber)

CPUs and Heatsinks

Power Supply Diagnostic
LED

Front Power Button
Rear Power Button
Front Power LED

Front Hard Drive Activity
LED

Front ODD Activity LED

Internal Speaker

System/Emergency ROM
Flash Recovery

Cooling Solutions
Power Supply Fans

Tool-less
Screw-In
Yes

?
Yes
Yes, at POST screen on reboot

?
Restores the computer to its original factory shipping image; can be obtained via HP Support.
Yes, causes a fail-safe power off when held for 4 seconds

?
Yes (optional): Locks side cover and secures chassis from theft

7.0 mm (0.2756 in) diameter padlock loop at rear of system
?

Yes, Kensington Cable Lock (optional): Locks side cover and secures chassis from theft
3 mm x 7 mm slot at rear of system

Yes (optional): Locks side cover and locks cables to chassis. Secures chassis from theft and allows multiple
units to be chained together when used with optional cable
Threaded feature at rear of system

Yes (optional)
The Solenoid Hood Lock eliminates the need for a physical key by making the chassis lockable through
software and a password. You can also lock and unlock the chassis remotely over the network. The Sensor
Kit detects when the access panel has been removed

Yes, enables or disables serial, USB, audio, and network ports
?

Yes, prevents ability to boot from removable media on supported devices (and can disable writes to media)

Yes, prevents an unauthorized person from booting up the workstation
Yes, prevents an unauthorized person from changing the workstation configuration
Yes

?
Yes

?
A T-15 Torx or flat blade screwdriver is needed to remove the CPU heatsink before the CPU can be

removed. CPU removal is tool-less
Yes

?
Yes, ACPI multi-function
Yes
Yes, white (normal), red (fault)

?
Yes, white

?
Yes, on device

?
Yes

?
Recovers corrupted system BIOS.

Air cooled forced convection heatsinks
92 mm x 92 mm x 25 mm (non-serviceable)

DA - 15077???Worldwide QuickSpecs ¡ª Version 37 ¡ª 7/8/2019

Page? 25

QuickSpecs

System Technical Specifications

HP Z440 Workstation

CPU Heatsink Fan
Chassis Fan

Memory Heatsink Fan

HP PC Hardware
Diagnostics UEFI

Access Panel Key Lock

ACPI-Ready Hardware

Trusted Platform Module
Chip

Integrated Chassis
Handles

Power Supply

PCIe Card Retention
Flash ROM
Diagnostic Power Switch

LED on board
Clear Password Jumper
Clear CMOS Button
CMOS Battery Holder
DIMM Connectors

?

?

92 mm x 25 mm, 6-wire, PWM
Front:

(Optional) 92 mm x 92mm x 25 mm, 4-wire, PWM
?
Rear:
92 mm x 92mm x 25 mm, 4-wire, PWM
?

Dual 60 mm x 60 mm x 25 mm, 6-wire, PWM, Blindmate
?

HP Vision Diagnostics Offline Edition
The diagnostics utility enables you to perform testing and to view critical computer hardware and software
configuration information from various sources. This utility enables you to:
?

Run diagnostics

View the hardware configuration of the system
?
Key features and benefits
HP Vision Diagnostics simplifies the process of effectively identifying, diagnosing, and isolating the
hardware issues. In addition to robust management tools, service tools can be invaluable in quickly
resolving system problems. To streamline the service process and resolve problems quickly, it is necessary
to have the right information available at the time that a service call is placed. The primary information
requirement, which is also the one that provides the greatest Vision into potential system issues, is the
configuration of the system. Vision Diagnostics helps provide higher system availability.
?
Typical uses of the Vision Diagnostics are:
?

Testing and diagnosing apparent hardware failures

Documenting system configurations for upgrade planning, standardization, inventory tracking,

disaster recovery, and maintenance

Sending configuration information to another location for more in-depth analysis

Entered? using F2
No

?
Advanced Configuration and Power Management Interface (ACPI).

?

Allows the system to wake from a low-power mode.

Controls system power consumption, making it possible to place individual cards and peripherals in

a low-power or powered-off state without affecting other elements of the system
Infineon TPM 1.2 Certified

Yes, Front handle and dedicated rear recess
?

Requires T15 Torx or flat blade screwdriver
?

Yes, rear (all), middle (all), front (full-length cards with extender, using HP Z4 Fan and Front Card Guide Kit)
Yes
Yes

?
Yes
Yes
Yes
Yes

DA - 15077???Worldwide QuickSpecs ¡ª Version 37 ¡ª 7/8/2019

Page? 26

QuickSpecs

System Technical Specifications

BIOS

BIOS 32-bit Services
PCI 3.0 Support
ATAPI
BBS
WMI Support

BIOS Boot Spec 1.01+
BIOS Power On
ROM Based Computer

Setup Utility (F10)
System/Emergency ROM

Flash Recovery with Video
Replicated Setup

SMBIOS
Boot Control
Memory Change Alert
Thermal Alert

Remote ROM Flash
ACPI (Advanced

Configuration and Power
Management Interface)

Ownership Tag
Remote Wakeup/Remote

Shutdown
Instantly Available PC

(Suspend to RAM - ACPI
sleep state S3)

Remote System
Installation via F12 (PXE

2.1) (Remote Boot from
Server)

ROM revision levels

System board revision
level

Start-up Diagnostics
(Power-on Self-Test)

Auto Setup when new
hardware installed

Keyboard-less Operation

Standard BIOS 32-bit Service Directory Proposal v0.4
Full BIOS support for PCI Express through industry standard interfaces.
ATAPI Removable Media Device BIOS Specification Version 1.0.
BIOS Boot Specification v1.01.
WMI is Microsoft's implementation of Web-Based Enterprise Management (WBEM) for Windows. WMI is

fully compliant with the Distributed Management Task Force (DMTF) Common Information Model (CIM) and
WBEM specifications.

Provides more control over how and from what devices the workstation will boot.
Users can define a specific date and time for the system to power on.
Review and customize system configuration settings controlled by the BIOS.

?
Recovers system BIOS in corrupted Flash ROM.

?
Saves BIOS settings to diskette or USB flash device in human readable file. Repset.exe utility can then

replicate these settings on machines being deployed without entering Computer Configuration Utility (F10
Setup).

System Management BIOS 2.7, for system management information.
Disables the ability to boot from removable media on supported devices.
Alerts management console if memory is removed or changed.
Monitors the temperature state within the chassis. Three modes:

? NORMAL - normal temperature ranges.
? ALERTED - excessive temperatures are detected. Raises a flag so action can be taken to avoid shutdown
or provide for a smoother system shutdown.
? SHUTDOWN - excessive temperatures are encountered. Automatically shuts down the computer without
warning before hardware component damage occurs.

Provides secure, fail-safe ROM image management from a central network console.
Allows the system to enter and resume from low power modes (sleep states).

Enables an operating system to control system power consumption based on the dynamic workload.
Makes it possible to place individual cards and peripherals in a low-power or powered-off state without
affecting other elements of the system.
Supports ACPI 4.0 for full compatibility with 64-bit operating systems.

A user-defined string stored in non-volatile memory that is displayed in the BIOS splash screen.
System administrators can power on, restart, and power off a client computer from a remote location.

?
Allows for very low power consumption with quick resume time.

?

Allows a new or existing system to boot over the network and download software, including the operating
system.
?

Reports the system BIOS revision level in Computer Configuration Utility (F10 Setup). Version is available
through an industry standard interface (SMBIOS) so that management SW applications can use and report
this information.

Allows management SW to read revision level of the system board.
Revision level is digitally encoded into the HW and cannot be modified.

Assesses system health at boot time with selectable levels of testing.
?

System automatically detects addition of new hardware.
?

The system can be booted without a keyboard.

HP Z440 Workstation

DA - 15077???Worldwide QuickSpecs ¡ª Version 37 ¡ª 7/8/2019

Page? 27

QuickSpecs

System Technical Specifications

HP Z440 Workstation

Localized ROM Setup

Asset Tag
Per-slot Control
Adaptive Cooling
Pre-boot Diagnostics
Industry Standard

Specification Support??
Industry Standard
UEFI Specification

Revision
ACPI
ATA (IDE)
CD Boot
EDD

EHCI
PCI

PCI Express

PMM
SATA

SPD
TPM

UHCI

USB

SMBIOS

?

?

Common BIOS image supports System Configuration Utility (F10 Setup) menus in 12 languages with local
keyboard mappings.

The user or MIS to set a unique tag string in non-volatile memory.
Allows I/O slot parameters (option ROM enable/disable, bus latency) to be configured individually.
Control parameters are set according to detected hardware configuration for optimal acoustics.
(Pre-video) critical errors are reported via beeps and blinks on the power LED.

Revision Supported by the BIOS

2.3.1

Advanced Configuration and Power Management Interface, Version 4.0
AT Attachment 6 with Packet Interface (ATA/ATAPI-6), Revision 3b
"El Torito" Bootable CD-ROM Format Specification Version 1.0

- Enhanced Disk Drive Specification Version 1.1

- BIOS Enhanced Disk Drive Specification Version 3.0
Enhanced Host Controller Interface for Universal Serial Bus, Revision 1.0
PCI Local Bus Specification, Revision 2.3

PCI Power Management Specification, Revision 1.1
PCI Firmware Specification, Revision 3.0, Draft .7

PCI Express Base Specification, Revision 2.0
PCI Express Base Specification, Revision 3.0

POST Memory Manager Specification, Version 1.01
Serial ATA Specification, Revision 1.0a

Serial ATA 3 Gb/s:? Serial ATA Specification, Revision 2.5
Serial ATA 6 Gb/s: Serial ATA Specification, Revision 3.0

PC SDRAM Serial Presence Detect (SPD) Specification, Revision 1.2B
Trusted Computing Group TPM Specification Version 1.2

?
Universal Host Controller Interface Design Guide, Revision 1.1

?
Universal Serial Bus Revision 1.1 Specification

?
Universal Serial Bus Revision 2.0 Specification
?
Universal Serial Bus Revision 3.0 Specification

System Management BIOS Reference Specification, Version 2.7

?

External BIOS simulator found at:? http://h20464.www2.hp.com/index.html

Social and Environmental Responsibility

Eco-Label Certifications &
Declarations

Batteries

This product has received or is in the process of being certified to the following approvals and may be
labeled with one or more of these marks:

ENERGY STAR? (energy-saving features available on selected configurations-Windows only)
US Federal Energy Management Program (FEMP)
China Energy Conservation Program

The ECO declaration (TED)
The battery in this product complies with EU Directive 2006/66/EC
Battery size: CR2032 (coin cell)
Battery type: Lithium Metal

DA - 15077???Worldwide QuickSpecs ¡ª Version 37 ¡ª 7/8/2019

Page? 28

QuickSpecs

System Technical Specifications

The battery in this product does not contain:

Mercury greater than 5ppm by weight

Cadmium greater than 10ppm by weight

Lead greater than 40ppm by weight

Restricted Material Usage

Low Halogen Statement

End-of-Life Management
and Recycling

HP Inc. Corporate
Environmental
Information

This product meets the material restrictions specified in HP's General Specification for the Environment.

http://www.hp.com/hpinfo/globalcitizenship/environment/pdf/gse.pdf

HP Inc. is committed to compliance with all applicable environmental laws and regulations, including the
European Union Restriction of Hazardous Substances (RoHS) Directive. HP's goal is to exceed compliance
obligations by meeting the requirements of the RoHS Directive on a worldwide basis.
This product is low-halogen except for power cords, external cables and peripherals.? The following
customer-configurable internal components may not be low-halogen: 3 ?" SAS HDDs and LSI 9217-4i4e
SAS ROC RAID Card.? Service parts obtained after purchase may not be low-halogen.
HP Inc. offers end-of-life HP product return and recycling programs in many geographic areas. To recycle
your product, please go to:
returned to HP will be recycled, recovered or disposed of in a responsible manner. This product is greater
than 90% recyclable by weight when properly disposed of at end of life.
For more information about HP's commitment to the environment:
Global Citizenship Report

Eco-label certifications

http://www.hp.com/hpinfo/globalcitizenship/environment/productdesign/ecolabels.html

HP Z440 Workstation

http://www.hp.com/recycle

http://www.hp.com/hpinfo/globalcitizenship/gcreport/index.html

or contact your nearest HP sales office. Products

Additional Information

Packaging

Packaging Materials
Internal
External

?

?

?

Manageability

Industry Standard
Specifications

Intel Active Management

ISO 14001 certificates:

http://www.hp.com/hpinfo/globalcitizenship/environment/operations/envmanagement.html

This HP product is designed to comply with the Waste Electrical and Electronic Equipment (WEEE)

Directive - 2002/96/EC.

http://www.hp.com/hpinfo/globalcitizenship/environment/productdata/disassemblyworkstatio.html

Plastic parts weighing over 25 grams used in the product are marked per ISO 11469 and ISO1043.

EPEAT Gold registered in the United States. See

country. EPEAT

http://www.epeat.net

party option store for solar energy accessory at
HP Workstation product packaging meets the HP General Specification for the Environment at

http://www.hp.com/hpinfo/globalcitizenship/society/gen_specifications.html

Does not contain restricted substances listed in HP Standard 011-1 General Specification for the

Environment

Does not contain ozone-depleting substances (ODS)

Does not contain heavy metals (lead, mercury, cadmium or hexavalent chromium) in excess of 100

ppm sum total for all heavy metals listed

Maximizes the use of post-consumer recycled content materials in packaging materials

All packaging material is recyclable

All packaging material is designed for ease of disassembly

Reduced size and weight of packages to improve transportation fuel efficiency

Plastic packaging materials are marked according to ISO 11469 and DIN 6120 standards formatting
?
Cushions and plastic bags made of low density polyethylene (LDPE).
Outer carton, accessories carton, and insert made of corrugated paper board.

This product meets the following industry standard specifications for manageability functionality:

DASH 1.1 (via Intel? LAN on motherboard)
Intel? Active Management Technology (AMT) 9.1

? registered where applicable.

for registration status by country. Search keyword

http://www.epeat.net

EPEAT registration varies by country. See

http://www.hp.com/go/options

for registration status in your

generator

on HP¡äs 3

rd

DA - 15077???Worldwide QuickSpecs ¡ª Version 37 ¡ª 7/8/2019

Page? 29

QuickSpecs

System Technical Specifications

Technology (AMT)

Intel? vProTM Technology

?
An advanced set of remote management features and functionality providing IT administrators the latest
and most effective tools to remotely discover, heal, and protect networked client systems regardless of the
system's health or power state. AMT 9.1 includes the following advanced management functions:

Power Management (on, off, reset, graceful shutdown, sleep and hibernate)

Hardware Inventory (includes BIOS and firmware revisions)

Hardware Alerting

Agent Presence

System Defense Filters

Serial Over LAN (SOL)

IDE Redirect

ME Wake-on-LAN (WOL)

DASH 1.1 compliance

IPv6 Support

Fast Call for Help - a client inside or outside the firewall may initiate a call for help via BIOS screen,

periodic connections, or alert triggered connection

Remote Scheduled Maintenance - pre-schedule when the system connects to the IT or service

provider console for maintenance.

Remote Alerts - automatically alert IT or service provider if issues arise

Access Monitor - Provides oversight into Intel? AMT actions to support security requirements

PC Alarm Clock

Microsoft NAP Support

Host Base set-up and configuration

Management Engine (ME) firmware roll back

Local Time Sync to UTC

Remote Memory Dump Command - Creates memory dump for debug
The HP Z440 Workstation supports Intel? vPro technology when configured as outlined below:

HP Z440 Workstation

Support in Max Power Savings (Shutdown and Hibernate Modes)

Remote Manageability
Software Solutions

System Software Manager
Service, Support, and
Warranty

Intel? Xeon processor E5-1600 v3 or E5-2600 v3 product family featuring Intel? vPro Technology

Intel? C612 chipset

Intel?

I218LM GbE LAN

The HP Z440 Workstation is supported on the following remote manageability software consoles:

LANDesk Management Suite (HP recommended solution)

Microsoft System Center Configuration Manager

HP Client Automation Enterprise

For questions or support for manageability needs, please visit
For questions or support for SSM, please visit:
On-site Warranty and Service (
next business-day (
5pm. Global coverage (
another, non-restricted country will remain fully covered under the original warranty and service offering.

NOTE 1:
NOTE 2:

third-party provider, and is not available in certain countries. Global service response times are based on
commercially reasonable best effort and may vary by country.

NOTE 3:

hardware and software. Toll-free calling and 24x7 support service may not be available in some countries.
HP Care Pack Services extend service contracts beyond the standard warranties. Service starts from date of
hardware purchase. To choose the right level of service for your HP product, use the HP Care Pack Services
Lookup Tool at:
product is available at:
Packs may vary depending on your geographic location.

Terms and conditions may vary by country. Certain restrictions and exclusions apply.
On-site service may be provided pursuant to a service contract between HP and an authorized HP

Technical telephone support applies only to HP-configured, HP and HP-qualified, third-party

Note 2

Note 2

http://www.hp.com/go/lookuptool

http://www.hp.com/hps/carepack

Note 1

): Three-years, limited warranty and service offering delivers on-site,

) service for parts and labor and includes free telephone support (

) ensures that any product purchased in one country and transferred to

http://www.hp.com/go/ssm

. Additional HP Care Pack Services information by

http://www.hp.com/go/easydeploy

Note 3

) 8am -

. Service levels and response times for HP Care

DA - 15077???Worldwide QuickSpecs ¡ª Version 37 ¡ª 7/8/2019

Page? 30

QuickSpecs

System Technical Specifications

HP Z440 Workstation

Product Change
Notification

Program to proactively communicate Product Change Notifications (PCNs) and Customer Advisories

by email to customers, based on a user-defined profile.

PCNs provide advance notification of hardware and software changes to be implemented in the

factory providing time to plan for transition.

Customer Advisories provide concise, effective problem resolution, greatly reducing the need to call

technical support.

DA - 15077???Worldwide QuickSpecs ¡ª Version 37 ¡ª 7/8/2019

Page? 31

QuickSpecs

Stable & Consistent Offerings

?

?

Processors

? ? ?
Hard Drives

As part of its commitment to hardware, software, and solution innovation, HP is proud to introduce this
breakthrough platform configuration stability to HP Workstation customers. HP Stable & Consistent
Offerings are built on the foundation of a carefully chosen set of hardware and software designed and
tested to work with all HP Z Workstation platforms through their end of life. These components and their
corresponding HP Workstation platform compatibility are outlined in this section.

HP Stable & Consistent Offerings are available worldwide to all HP Workstation customers-no
special programs, no additional cost-no kidding. Simply select your hardware and software components
when you customize your HP Workstation and be assured that you'll be able to buy that same
configuration throughout the lifecycle of the product.

Product #

J6S66AV
J6S68AV
J6S69AV
J6S71AV

Product #

J3H77AV
J3H98AV
J3J19AV
J3J39AV
J3H78AV
J3H99AV
J3J20AV
J3J40AV

HP Z440 Workstation

Offering

Intel Xeon E5-1603 v3 2.8GHz 4-core 10MB 1866
Intel Xeon E5-1620 v3 3.5GHz 4-core 10MB 2133
Intel Xeon E5-1630 v3 3.7GHz 4-core 10MB 2133
Intel Xeon E5-2630 v3 2.4GHz 8-core 20MB 1866

Offering

500GB 7200 RPM SATA 1st Hard Disk Drive
500GB 7200 RPM SATA 2nd Hard Disk Drive
500GB 7200 RPM SATA 3rd Hard Disk Drive
500GB 7200 RPM SATA 4th Hard Disk Drive
1TB 7200 RPM SATA 1st Hard Disk Drive
1TB 7200 RPM SATA 2nd Hard Disk Drive
1TB 7200 RPM SATA 3rd Hard Disk Drive
1TB 7200 RPM SATA 4th Hard Disk Drive

? ? ?
Graphics

? ? ?

?

Product #

J1P69AV
J1P81AV
J1P71AV
J1P83AV
J1P72AV
J1P84AV
J1P76AV
J1P85AV

Offering

NVIDIA NVS 510 2GB 1st Graphics
NVIDIA NVS 510 2GB 2nd Graphics
NVIDIA? Quadro? K620 2GB 1st Graphics
NVIDIA? Quadro? K620 2GB 2nd Graphics
NVIDIA? Quadro? K2200 4GB 1st Graphics
NVIDIA? Quadro? K2200 4GB 2nd Graphics
AMD FirePro W2100 2GB 1st Graphics
AMD FirePro W2100 2GB 2nd Graphics

DA - 15077???Worldwide QuickSpecs ¡ª Version 37 ¡ª 7/8/2019

Page? 32

QuickSpecs

Stable & Consistent Offerings

HP Z440 Workstation

Memory*

?

*

Factory-configured CTO (xxxxxAV) and aftermarket AMO (xxxxxAA, xxxxxAT) HP memory part numbers designated as "2133"? or
"2400"? will be transitioned to using 2666MHz speed memory components. This does not affect HP part number availability nor does it
affect system performance or operation. All hardware configurations currently supporting HP memory part numbers designated as
"2133"? or "2400"? have been tested to work with 2666MHz memory and are fully-supported by HP under standard support terms.

?

Product #

G8U28AV
G8U32AV
G8U34AV
G8U36AV
G8U35AV
G8U37AV
G8U38AV

Offering

8GB DDR4-2133 (1x8GB) Registered RAM
16GB DDR4-2133 (2x8GB) Registered RAM
32GB DDR4-2133 (4x8GB) Registered RAM
64GB DDR4-2133 (8x8GB) Registered RAM
32GB DDR4-2133 (2x16GB) Registered RAM
64GB DDR4-2133 (4x16GB) Registered RAM
128GB DDR4-2133 (8x16GB) Registered RAM

DA - 15077???Worldwide QuickSpecs ¡ª Version 37 ¡ª 7/8/2019

Page? 33

QuickSpecs

Technical Specifications - Processors

?

Intel Xeon E5-1680 v3 3.2 2133 8C CPU
Intel Xeon E5-1660 v3 3.0 2133 8C CPU
Intel Xeon E5-1650 v3 3.5 2133 6C CPU
Intel Xeon E5-1630 v3 3.7 2133 4C CPU
Intel Xeon E5-1620 v3 3.5 2133 4C CPU
Intel Xeon E5-1607 v3 3.1 1866 4C CPU
Intel Xeon E5-1603 v3 2.8 1866 4C CPU

?

Intel Xeon E5-2630 v3 2.4 1866 8C CPU
Intel Xeon E5-2637 v4 3.5 2400 4C CPU
Intel Xeon E5-2623 v4 2.6 2133 4C CPU

?
?
?
?

HP Z440 Workstation

DA - 15077???Worldwide QuickSpecs ¡ª Version 37 ¡ª 7/8/2019

Page? 34

QuickSpecs

Technical Specifications - Hard Drives

Storage/Hard Drives

HP Z440 Workstation

HP SAS (Serial Attached
SCSI) Hard Drives for HP
Workstations

?

?

HP 600GB SAS 10K SFF
HDD

HP 300GB SAS 10K SFF
HDD

HP 300GB SAS 10K SFF
HDD

Capacity
Height
Width
Interface
Synchronous Transfer

Rate

(Maximum)

Cache
Seek Time

includes controller
overhead, including
settling)

Rotational Speed
Operating Temperature

Capacity
Height
Width
Interface
Synchronous Transfer

Rate
Cache
Seek Time

includes controller
overhead, including
settling)

Rotational Speed
Operating Temperature

Capacity
Height
Width

Interface
Synchronous Transfer

Rate
Buffer
Cache
Seek Time

includes controller
overhead, including
settling)

Rotational Speed
Logical Blocks

(typical reads,

(Maximum)

(typical reads,

(Maximum)

(typical reads,

600GB

5.9 in; 15 cm

Media Diameter

12Gb/s SAS
up to 1200 MB/s (SAS single port)

128MB

Average

15K rpm
41¡ã to 131¡ã F (5¡ã to 55¡ã C)

300GB

5.9 in; 15 cm

Media Diameter

12Gb/s SAS
up to 1200 MB/s (SAS single port)

128MB

Average

15K rpm
41¡ã to 131¡ã F (5¡ã to 55¡ã C)

300GB

0.6 in; 1.53 cm

Media Diameter
Physical Size

SAS 6Gb/s
Up to 600MB/s

64MB
multi-segmentable cache buffer

Single Track
Average
Full Stroke

10,000 rpm
585,937,500

2.5 in; 6.36 cm

2.0ms

2.5 in; 6.36 cm

2.0ms

2.5 in; 6.36 cm

2.75 in; 6.99 cm

0.4 ms (max)

3.6 ms

7.3 ms

?

DA - 15077???Worldwide QuickSpecs ¡ª Version 37 ¡ª 7/8/2019

Page? 35

QuickSpecs

Technical Specifications - Hard Drives

HP Z440 Workstation

Operating Temperature

?

HP 600GB SAS 10K SFF
HDD

?

?

HP 1.2TB SAS 10K SFF HDD

Capacity
Height
Width

Interface
Synchronous Transfer

Rate

(Maximum)

Buffer
Cache
Seek Time

includes controller
overhead, including
settling)

Rotational Speed
Logical Blocks
Operating Temperature

Capacity
Height
Width

Interface
Synchronous Transfer

Rate
Buffer
Seek Time

includes controller
overhead, including
settling)

Rotational Speed
Logical Blocks
Operating Temperature

(typical reads,

(Maximum)

(typical reads,

41¡ã to 131¡ã F (5¡ã to 55¡ã C)

600GB

0.6 in; 1.53 cm

Media Diameter
Physical Size

SAS 6Gb/s
Up to 600MB/s

64MB
multi-segmentable cache buffer

Single Track
Average
Full Stroke

10,000 rpm
1,172,123,568
41¡ã to 131¡ã F (5¡ã to 55¡ã C)

1.2TB

0.6 in; 1.53 cm

Media Diameter
Physical Size

SAS 6Gb/s
Up to 600MB/s

64MB

Single Track
Average
Full Stroke

10,000 rpm
2,344,225,968
41¡ã to 131¡ã F (5¡ã to 55¡ã C)

2.5 in; 6.36 cm

2.75 in; 6.99 cm

0.4 ms (max)

3.6 ms

7.3 ms

2.5 in; 6.36 cm

2.75 in; 6.99 cm

0.18ms (max)

3.5ms

7.17ms

?

SATA (Serial ATA) Hard
Drives for HP
Workstations

500GB SATA 7200 rpm
6Gb/s 3.5" HDD

DA - 15077???Worldwide QuickSpecs ¡ª Version 37 ¡ª 7/8/2019

Capacity
Height
Width

Interface
Synchronous Transfer

Rate

(Maximum)

Buffer

500GB
1 in; 2.54 cm

Media Diameter
Physical Size

Serial ATA (6.0Gb/s), NCQ enabled
Up to 600MB/s

16MB

3.5 in; 8.9 cm
4 in; 10.17 cm

Page? 36

QuickSpecs

Technical Specifications - Hard Drives

HP Z440 Workstation

?
?
1TB SATA 7200 rpm

6Gb/s 3.5" HDD

2.0TB SATA 7200 rpm
6Gb/s 3.5" HDD

?

3.0TB SATA 7200 rpm
6Gb/s 3.5" HDD

Seek Time

includes controller
overhead, including
settling)

Rotational Speed
Logical Blocks
Operating Temperature

? ?

Capacity
Height
Width

Interface
Synchronous Transfer

Rate
Buffer
Cache
Seek Time

includes controller
overhead, including
settling)

Rotational Speed
Operating Temperature
Capacity
Height
Width

?

Interface
Synchronous Transfer

Rate
Buffer
Seek Time

includes controller
overhead, including
settling)

Rotational Speed
Logical Blocks
Operating Temperature

? ?

Capacity
Height
Width

Interface
Synchronous Transfer

Rate
Buffer

(typical reads,

(Maximum)

(typical reads,

(Maximum)

(typical reads,

(Maximum)

Single Track
Average
Full Stroke

7,200 rpm
976,773,168
41¡ã to 131¡ã F (5¡ã to 55¡ã C)

1TB
1 in; 2.54 cm

Media Diameter
Physical Size

Serial ATA (6.0Gb/s), NCQ enabled
Up to 600 MB/s

64MB
Adaptive

Single Track
Average
Full Stroke

7,200 rpm
41¡ã to 131¡ã F (5¡ã to 55¡ã C)

2.0TB
1 in; 2.54 cm

Media Diameter
Physical Size

Serial ATA (6.0 Gb/s), NCQ Enabled
Up to 600 MB/s

64MB

Single Track
Average
Full Stroke

7,200 rpm
3,907,029,168
41¡ã to 131¡ã F (5¡ã to 55¡ã C)

3.0TB
1 in; 2.54 cm

Media Diameter
Physical Size

Serial ATA (6.0Gb/s), NCQ enabled
Up to 6.0 Gb/s

64MB

2 ms
11 ms
21 ms

3.5 in; 8.9 cm
4 in; 10.17 cm

2 ms
11 ms
21 ms

3.5 in; 8.9 cm
4 in; 10.17 cm

1.0 ms
11 ms
18 ms

3.5 in; 8.9 cm

4.0 in; 10.17 cm

DA - 15077???Worldwide QuickSpecs ¡ª Version 37 ¡ª 7/8/2019

Page? 37

QuickSpecs

Technical Specifications - Hard Drives

HP Z440 Workstation

Seek Time

includes controller
overhead, including
settling)

Rotational Speed
Operating Temperature

?

1TB SATA 7200 rpm 6Gb/s

3.5" HDD (Enterprise
Class)

?

?

Capacity
Protocol
Form Factor
Controller
Reliability
Rated Power On Hours
Annualized Failure Rate

(based on Rated POH)

Rated for 24/7/365
operation

Physical Size
Physical Size
Media Diameter
Interface
Synchronous Transfer

Rate
Buffer
Seek Time

includes controller
overhead, including
settling)

Operating Temperature
Performance

Enterprise Class Features

(typical reads,

(MTBF)

(Height)
(Width)

(Maximum)

(typical reads,

Single Track
Average
Full Stroke

7,200 rpm
41¡ã to 140¡ã F (5¡ã to 60¡ã C)

1TB
SATA

3.5"
AHCI

2.0M hours
8760/yr
<0.62%

YES

1 in; 2.54 cm
4 in; 10.17 cm

3.5 in; 8.9 cm
Serial ATA (6Gb/s), NCQ enabled
Up to 600MB/s

128MB

Single Track
Average
Full Stroke

41¡ã to 140¡ã F (5¡ã to 60¡ã C)

Sequential Read
Sequential Write

High Reliability

0.6 ms
11 ms
Not Specified

0.32ms

7.45ms

14.2ms

up to 226MB/s
up to 226MB/s

DA - 15077???Worldwide QuickSpecs ¡ª Version 37 ¡ª 7/8/2019

Page? 38

QuickSpecs

Technical Specifications - Hard Drives

HP Z440 Workstation

4TB SATA 7200
rpm 6Gb/s 3.5"
HDD

(Enterprise Class)

?

?

?

Capacity
Height
Width

?

Interface
Synchronous Transfer

Rate

(Maximum)

Buffer

Seek Time

reads, includes
controller overhead,
including settling)

Rotational Speed
Operating Temperature

500GB SATA 7.2K SED
SFF HDD

(typical

4TB

0.275 in; 0.7 cm

Media Diameter
Physical Size

Serial ATA (6Gb/s), NCQ enabled
Up to 600MB/s

128MB

Single Track
Average
Full Stroke

7,200 rpm
32¡ã to 140¡ã F (0¡ã to 60¡ã C)

Capacity
Height
Width

?

Interface
Synchronous Transfer

Rate

(Maximum)

Buffer

Seek Time

includes controller
overhead, including
settling)

Rotational Speed
Operating Temperature

(typical reads,

2.5 in; 6.36 cm

2.75 in; 6.99 cm

0.7ms

8.5ms

15.7ms
?

500GB

0.275 in; 0.7 cm

Media Diameter
Physical Size

Serial ATA (6Gb/s)
Up to 600MB/s

32MB

Single Track
Average
Full Stroke

7,200 rpm
32¡ã to 140¡ã F (0¡ã to 60¡ã C)

2.5 in; 6.36 cm

2.75 in; 6.99 cm

1ms

4.2ms
25ms (typical)
?

?

1TB SATA 7200
rpm 8GB 3.5"
SSHD (hybrid)

?

Capacity
Height
Width

Interface
Synchronous Transfer

Rate

(Maximum)

Buffer
Cache
Rotational Speed
Operating Temperature

DA - 15077???Worldwide QuickSpecs ¡ª Version 37 ¡ª 7/8/2019

1TB
1 in; 2.54 cm

Media Diameter
Physical Size

6Gb/s SATA
Up to 600MB/s

64MB standard HDD cache buffer
8GB NAND flash
7200 rpm
32¡ã to 140¡ã F (0¡ã to 60¡ã C)

3.5 in; 8.9 cm
4 in; 10.17 cm

Page? 39

QuickSpecs

Technical Specifications - Hard Drives

HP Z440 Workstation

SATA SSDs for HP
Workstations

HP 128GB
SATA 6Gb/s
SSD

Capacity
Protocol
Form Factor
Controller
NAND Type
Endurance
Reliability
Physical Size
Physical Size
Interface
Synchronous

Transfer Rate

(Maximum)

Operating
Temperature

Performance

(MTTF)

(Height)
(Width)

128GB
SATA

2.5"
AHCI
MLC
100TBW (TB Written)

1.5M hours

0.28 in; 0.7 cm

2.5 in; 6.36 cm
SATA 6Gb/s
Up to 550MB/s (Sequential Read)

32¡ã to 158¡ã F (0¡ã to 70¡ã C)

Sequential Read
Sequential Write
Random Read
Random Write

560 MB/s
400 MB/s
90K IOPS
88K IOPS

?

?

HP 256GB
SATA 6Gb/s
SSD

?

Capacity
Protocol
Form Factor
Controller
NAND Type
Endurance
Reliability
Physical Size
Physical Size
Interface
Synchronous Transfer

Rate
Operating Temperature
Performance

(MTTF)

(Height)
(Width)

(Maximum)

256GB
SATA

2.5"
AHCI
MLC
200TBW (TB Written)

1.5M hours

0.28 in; 0.7 cm

2.5 in; 6.36 cm
SATA 6Gb/s
Up to 600MB/s

32¡ã to 158¡ã F (0¡ã to 70¡ã C)

Sequential Read
Sequential Write
Random Read
Random Write

560MB/s (max)
510MB/s (max)
100K IOPS (max)
88K IOPS (max)

DA - 15077???Worldwide QuickSpecs ¡ª Version 37 ¡ª 7/8/2019

Page? 40

QuickSpecs

Technical Specifications - Hard Drives

?

HP 256GB
SATA 6Gb/s
SED Opal 2
SSD

? ?

Capacity
Protocol
Form Factor
Controller
NAND Type
Endurance
Reliability
Physical Size
Physical Size
Interface
Synchronous Transfer

Rate
Operating Temperature
Performance

Self-Encrypting Drive
Support

(MTTF)

(Height)
(Width)

(Maximum)

256GB
SATA

2.5"
AHCI
MLC
200TBW (TB Written)

1.5M hours

0.28 in; 0.7 cm

2.5 in; 6.36 cm
6Gb/s SATA
Up to 550MB/s (Sequential Read)

32¡ã to 158¡ã F (0¡ã to 70¡ã C)

Sequential Read
Sequential Write
Random Read
Random Write

OPAL 2

HP Z440 Workstation

560MB/s
510 MB/s
100K IOPS
88K IOPS

?

?

HP 512GB
SATA 6Gb/s
SSD

?

Capacity
Protocol
Form Factor
Controller
NAND Type
Endurance
Reliability
Physical Size
Physical Size
Interface
Synchronous Transfer

Rate
Operating Temperature
Performance

(MTTF)

(Height)
(Width)

(Maximum)

512GB
SATA

2.5"
AHCI
MLC
300TBW (TB Written)

1.5M hours

0.28 in; 0.7 cm

2.5 in; 6.36 cm
SATA 6Gb/s
Up to 550MB/s (Sequential Read)

32¡ã to 158¡ã F (0¡ã to 70¡ã C)

Sequential Read
Sequential Write
Random Read
Random Write

560 MB/s
510 MB/s
100K IOPS
88K IOPS

DA - 15077???Worldwide QuickSpecs ¡ª Version 37 ¡ª 7/8/2019

Page? 41

QuickSpecs

Technical Specifications - Hard Drives

?

HP 512GB
SATA SED SSD

? ?

Capacity
Protocol
Form Factor
Controller
NAND Type
Endurance
Reliability
Physical Size
Physical Size
Interface
Synchronous Transfer

Rate
Operating Temperature
Performance

Self-Encrypting Drive
Support

(MTTF)

(Height)
(Width)

(Maximum)

512GB
SATA

2.5"
AHCI
MLC
300TBW (TB Written)

1.5M hours

0.28 in; 0.7 cm

2.5 in; 6.36 cm
SATA 6Gb/s
Up to 600MB/s

32¡ã to 158¡ã F (0¡ã to 70¡ã C)

Sequential Read
Sequential Write
Random Read
Random Write

OPAL 1 and 2

HP Z440 Workstation

560 MB/s
510 MB/s
100K IOPS
88K IOPS

?

?

?

HP 1TB SATA
6Gb/s SSD

Capacity
Protocol
Form Factor
Controller
NAND Type
Endurance
Reliability
Physical Size
Physical Size
Interface
Synchronous Transfer

Rate
Operating Temperature
Performance

(MTTF)

(Height)
(Width)

(Maximum)

1TB
SATA

2.5"
AHCI
MLC
400TBW (TB Written)

1.5M hours

0.28 in; 0.7 cm

2.5 in; 6.36 cm
SATA 6Gb/s
Up to 550MB/s (Sequential Read)

32¡ã to 158¡ã F (0¡ã to 70¡ã C)

Sequential Read
Sequential Write
Random Read
Random Write

560 MB/s
510 MB/s
100K IOPS
88K IOPS

DA - 15077???Worldwide QuickSpecs ¡ª Version 37 ¡ª 7/8/2019

Page? 42

QuickSpecs

Technical Specifications - Hard Drives

?

HP 2TB SATA
6Gb/s SSD

Capacity
Protocol
Form Factor
Controller
NAND Type
Endurance
Reliability
Physical Size
Physical Size
Interface
Synchronous Transfer

Rate
Operating Temperature
Performance

(MTTF)

(Height)
(Width)

(Maximum)

2TB
SATA

2.5"
AHCI
3D TLC
400TBW (TB Written)

1.5M hours

0.28 in; 0.7 cm

2.5 in; 6.36 cm
SATA 6Gb/s
Up to 550MB/s (Sequential Read)

32¡ã to 158¡ã F (0¡ã to 70¡ã C)

Sequential Read
Sequential Write
Random Read
Random Write

HP Z440 Workstation

530 MB/s
500 MB/s
92K IOPS
83K IOPS

?

?

HP Enterprise Class
240GB SATA SSD

Capacity
Protocol
Form Factor
Controller
NAND Type
Endurance
Reliability
Physical Size
Physical Size
Interface
Synchronous Transfer

Rate
Operating Temperature
Performance

Enterprise Class
Features

(MTTF)

(Height)
(Width)

(Maximum)

240GB
SATA

2.5"
AHCI
MLC
920TBW (TB Written)

2.0M hours

0.28 in; 0.7 cm

2.5 in; 6.36 cm
6Gb/s SATA
Up to 600MB/s

32¡ã to 158¡ã F (0¡ã to 70¡ã C)

Sequential Read
Sequential Write
Random Read
Random Write

High Endurance NAND
Power Loss Protection
End-to-End Data Protection

420 MB/s
290 MB/s
63K IOPS
18K IOPS

?

DA - 15077???Worldwide QuickSpecs ¡ª Version 37 ¡ª 7/8/2019

Page? 43

QuickSpecs

Technical Specifications - Hard Drives

?

HP Enterprise Class
480GB SATA SSD

Capacity
Protocol
Form Factor
Controller
NAND Type
Endurance
Reliability
Physical Size
Physical Size
Interface
Synchronous Transfer

Rate
Operating Temperature
Performance

Enterprise Class
Features

(MTTF)

(Height)
(Width)

(Maximum)

480GB
SATA

2.5"
AHCI
MLC
1850TBW (TB Written)

2.0M hours

0.28 in; 0.7 cm

2.5 in; 6.36 cm
6Gb/s SATA
Up to 600MB/s

32¡ã to 158¡ã F (0¡ã to 70¡ã C)

Sequential Read
Sequential Write
Random Read
Random Write

High Endurance NAND
Power Loss Protection
End-to-End Data Protection

HP Z440 Workstation

420 MB/s
380 MB/s
63K IOPS
23K IOPS

?

PCIe SSDs for HP
Workstations

?

HP Z Turbo Drive 256GB
SSD

Capacity
Protocol
Form Factor
Controller
NAND Type
Endurance
Interface
Operating Temperature
Performance

256GB
PCIe
Half-height, half-length
AHCI
MLC
146TB
PCI Express 2.0 x4 electrical? x4 physical
32¡ã to 158¡ã F (0¡ã to 70¡ã C)

Sequential Read
Sequential Write
Random Read
Random Write

1080 MB/s
800 MB/s
120K IOPS
60K IOPS

DA - 15077???Worldwide QuickSpecs ¡ª Version 37 ¡ª 7/8/2019

Page? 44

QuickSpecs

Technical Specifications - Hard Drives

HP Z440 Workstation

HP Z Turbo Drive 512GB
SSD

?

HP Z Turbo Drive G2
256GB SSD

Capacity
Protocol
Form Factor
Controller
NAND Type
Endurance
Interface
Operating Temperature
Performance

Capacity
Protocol
Form Factor
Controller
NAND Type
Endurance
Reliability
Interface
Operating Temperature
Performance

(MTBF)

512GB
PCIe
Half-height, half-length
AHCI
MLC
292TB
PCI Express 2.0 x4 electrical? x4 physical
32¡ã to 158¡ã F (0¡ã to 70¡ã C)

Sequential Read
Sequential Write
Random Read
Random Write

256GB
PCIe
Half-height, half-length
NVMe
MLC
146TB

1.5M hours
PCI Express 3.0 x4 electrical? x4 physical
32¡ã to 158¡ã F (0¡ã to 70¡ã C)

Sequential Read
Sequential Write
Random Read
Random Write

1170 MB/s
950 MB/s
122K IOPS
72K IOPS

2150 MB/s
1260 MB/s
300K IOPS
100K IOPS

?
?

HP Z Turbo Drive G2
512GB SSD

?

Capacity
Protocol
Form Factor
Controller
NAND Type
Endurance
Reliability
Interface
Operating Temperature
Performance

(MTBF)

512GB
PCIe
Half-height, half-length
NVMe
MLC
292TB

1.5M hours
PCI Express 3.0 x4 electrical x4 physical
32¡ã to 158¡ã F (0¡ã to 70¡ã C)

Sequential Read
Sequential Write
Random Read
Random Write

2150 MB/s
1550 MB/s
300K IOPS
100K IOPS

DA - 15077???Worldwide QuickSpecs ¡ª Version 37 ¡ª 7/8/2019

Page? 45

QuickSpecs

Technical Specifications - Hard Drives

HP Z440 Workstation

HP Z Turbo Drive G2 1TB
SSD

?
?
?
?

HP Z Turbo Drive Quad Pro
2x256GB PCIe SSD

Capacity
Protocol
Form Factor
Controller
NAND Type
Endurance
Reliability
Interface
Operating Temperature
Performance

Capacity
Protocol
Form Factor
Controller
NAND Type
Endurance
Reliability
Interface
Operating Temperature
Performance

(MTTF)

(MTBF)

1TB
PCIe
Half-height, half-length
NVMe
MLC
600TB

1.5M hours
PCI Express 3.0 x4 electrical? x4 physical
32¡ã to 158¡ã F (0¡ã to 70¡ã C)

Sequential Read
Sequential Write
Random Read
Random Write

512GB
PCIe
PCIe Card, Full Height PCIe Slot
NVMe
MLC
146TB

1.5M hours
PCIe Gen3 x4 architecture
32¡ã to 158¡ã F (0¡ã to 70¡ã C)

Sequential Read
Sequential Write
Random Read
Random Write

2500 MB/s
1550 MB/s
210K IOPS
130K IOPS

2150 MB/s
1260 MB/s
300K IOPS
100K IOPS

?

HP Z Turbo Drive Quad Pro
2x512GB PCIe SSD

?

DA - 15077???Worldwide QuickSpecs ¡ª Version 37 ¡ª 7/8/2019

Capacity
Protocol
Form Factor
Controller
NAND Type
Endurance
Reliability
Interface
Operating Temperature
Performance

(MTBF)

1TB
PCIe
PCIe Card, Full Height PCIe Slot
NVMe
MLC
292TB

1.5M hours
PCIe Gen3 x4 architecture
32¡ã to 158¡ã F (0¡ã to 70¡ã C)

Sequential Read
Sequential Write
Random Read
Random Write

2150 MB/s
1550 MB/s?
300K IOPS
100K IOPS

Page? 46

QuickSpecs

Technical Specifications - Hard Drives

HP Z440 Workstation

HP Z Turbo Drive G2
256GB SED SSD

?

HP Z Turbo Drive G2
512GB SED SSD

Capacity
Protocol
Form Factor
Controller
NAND Type
Endurance
Reliability
Interface
Operating Temperature
Performance

Self-Encrypting Drive
Support

Capacity
Protocol
Form Factor
Controller
NAND Type
Endurance
Reliability
Interface
Operating Temperature
Performance

Self-Encrypting Drive
Support

(MTBF)

(MTBF)

256GB?
PCIe
Half-height, half-length
NVMe
MLC
150TBW (TB Written)

1.5M hours
PCI Express 3.0 x4 electrical? x4 physical
32¡ã to 158¡ã F (0¡ã to 70¡ã C)

Sequential Read
Sequential Write
Random Read
Random Write

OPAL 2

512GB
PCIe
Half-height, half-length
NVMe
MLC
300TBW (TB Written)

1.5M hours
PCI Express 3.0 x4 electrical? x4 physical
32¡ã to 158¡ã F (0¡ã to 70¡ã C)

Sequential Read
Sequential Write
Random Read
Random Write

OPAL 2

3100 MB/s
1400 MB/s
330K IOPS
280K IOPS

3200 MB/s
1700 MB/s
330K IOPS
300K IOPS

?

DA - 15077???Worldwide QuickSpecs ¡ª Version 37 ¡ª 7/8/2019

Page? 47

QuickSpecs

Technical Specifications - Hard Drives

HP Z440 Workstation

HP Z Turbo Drive Quad Pro
2x256GB PCIe SSD

?

HP Z Turbo Drive Quad Pro
2x512GB PCIe SSD

Capacity
Protocol
Form Factor
Controller
NAND Type
Endurance
Reliability
Interface
Operating Temperature
Performance

Capacity
Protocol
Form Factor
Controller
NAND Type
Endurance
Reliability
Interface
Operating Temperature
Performance

(MTBF)

(MTBF)

512GB
PCIe
PCIe Card, Full Height PCIe Slot
NVMe
MLC
146TB

1.5M hours
PCIe Gen3 x4 architecture
32¡ã to 158¡ã F (0¡ã to 70¡ã C)

Sequential Read
Sequential Write
Random Read
Random Write

1TB
PCIe
PCIe Card, Full Height PCIe Slot
NVMe
MLC
292TB

1.5M hours
PCIe Gen3 x4 architecture
32¡ã to 158¡ã F (0¡ã to 70¡ã C)

Sequential Read
Sequential Write
Random Read
Random Write

2150 MB/s
1260 MB/s
300K IOPS
100K IOPS

2150 MB/s
1550 MB/s?
300K IOPS
100K IOPS

?

HP Z Turbo Drive Quad Pro
2x1TB PCIe SSD

?

DA - 15077???Worldwide QuickSpecs ¡ª Version 37 ¡ª 7/8/2019

Capacity
Protocol
Form Factor
Controller
NAND Type
Endurance
Interface
Operating Temperature
Performance

2TB
PCIe
PCIe Card, Full Height PCIe Slot
NVMe
MLC
600TB
PCI Express 3.0 x4 electrical x4 physical
32¡ã to 158¡ã F (0¡ã to 70¡ã C)

Sequential Read
Sequential Write
Random Read
Random Write

3200 MB/s
1800 MB/s
430K IOPS
320K IOPS

Page? 48

QuickSpecs

Technical Specifications - Hard Drives

HP Z440 Workstation

HP Z Turbo Drive G2 256GB
TLC SSD

?

HP Z Turbo Drive G2 512GB
TLC SSD

Capacity
Protocol
Form Factor
Controller
NAND Type
Endurance
Reliability
Interface
Operating Temperature
Performance

Capacity
Protocol
Form Factor
Controller
NAND Type
Endurance
Reliability
Interface
Operating Temperature
Performance

(MTBF)

(MTBF)

256GB
PCIe
M.2 in Half-height, half-length card
NVMe
3D TLC
75TBW (TB Written)

1.5M hours
PCI Express 3.0 x4 electrical? x4 physical
32¡ã to 158¡ã F (0¡ã to 70¡ã C)

Sequential Read
Sequential Write

Random Read
Random Write

512GB
PCIe
M.2 in Half-height, half-length card
NVMe
3D TLC
150TBW (TB Written)

1.5M hours
PCI Express 3.0 x4 electrical? x4 physical
32¡ã to 158¡ã F (0¡ã to 70¡ã C)

Sequential Read
Sequential Write

Random Read
Random Write

2800 MB/s
320 MB/s (1100 MB/s

max/Turbo)
250K IOPS
180K IOPS

2800 MB/s
660 MB/s (1600 MB/s

max/Turbo)
260K IOPS
260K IOPS

?

HP Z Turbo Drive G2 1TB
TLC SSD

?

DA - 15077???Worldwide QuickSpecs ¡ª Version 37 ¡ª 7/8/2019

Capacity
Protocol
Form Factor
Controller
NAND Type
Endurance
Reliability
Interface
Operating Temperature
Performance

(MTBF)

1TB
PCIe
M.2 in Half-height, half-length card
NVMe
3D TLC
300TBW (TB Written)

1.5M hours
PCI Express 3.0 x4 electrical? x4 physical
32¡ã to 158¡ã F (0¡ã to 70¡ã C)

Sequential Read
Sequential Write

Random Read
Random Write

3000 MB/s
1150 MB/s (1700 MB/s

max/Turbo)
360K IOPS
330K IOPS

Page? 49

QuickSpecs

Technical Specifications - Hard Drives

HP Z440 Workstation

HP Z Turbo Drive G2
256GB TLC SSD

?

HP Z Turbo Drive G2
512GB TLC SSD

Capacity
Protocol
Form Factor
Controller
NAND Type
Endurance
Reliability
Interface
Operating Temperature
Performance

Capacity
Protocol
Form Factor
Controller
NAND Type
Endurance
Reliability
Interface
Operating Temperature
Performance

(MTBF)

(MTBF)

256GB
PCIe
M.2 in Half-height, half-length card
NVMe
3D TLC
75TBW (TB Written)

1.5M hours
PCI Express 3.0 x4 electrical? x4 physical
32¡ã to 158¡ã F (0¡ã to 70¡ã C)

Sequential Read
Sequential Write

Random Read
Random Write

512GB
PCIe
M.2 in Half-height, half-length card
NVMe
3D TLC
150TBW (TB Written)

1.5M hours
PCI Express 3.0 x4 electrical? x4 physical
32¡ã to 158¡ã F (0¡ã to 70¡ã C)

Sequential Read
Sequential Write

Random Read
Random Write

2800 MB/s
320 MB/s (1100 MB/s

max/Turbo)
250K IOPS
180K IOPS

2800 MB/s
660 MB/s (1600 MB/s

max/Turbo)
260K IOPS
260K IOPS

?

HP Z Turbo Drive G2 1TB
SSD

?

DA - 15077???Worldwide QuickSpecs ¡ª Version 37 ¡ª 7/8/2019

Capacity
Protocol
Form Factor
Controller
NAND Type
Endurance
Reliability
Interface
Operating Temperature
Performance

(MTTF)

1TB
PCIe
M.2 in Half-height, half-length card
NVMe
3D TLC
300TBW (TB Written)

1.5M hours
PCI Express 3.0 x4 electrical? x4 physical
32¡ã to 158¡ã F (0¡ã to 70¡ã C)

Sequential Read
Sequential Write

Random Read
Random Write

3000 MB/s
1150 MB/s (1700 MB/s

max/Turbo)
360K IOPS
330K IOPS

Page? 50

QuickSpecs

Technical Specifications - Hard Drives

HP Z440 Workstation

HP Z Turbo Drive G2 256GB
SED SSD

?

?

?

?

HP Z Turbo Drive G2 512GB
SED SSD

?

Capacity
Protocol
Form Factor
Controller
NAND Type
Endurance
Reliability
Interface
Operating Temperature
Performance

Self-Encrypting Drive
Support

Capacity
Protocol
Form Factor
Controller
NAND Type
Endurance
Reliability
Interface
Operating Temperature
Performance

Self-Encrypting Drive
Support

(MTBF)

(MTBF)

256GB?
PCIe
M.2 in Half-height, half-length card
NVMe
3D MLC
150TBW (TB Written)

1.5M hours
PCI Express 3.0 x4 electrical? x4 physical
32¡ã to 158¡ã F (0¡ã to 70¡ã C)

Sequential Read
Sequential Write
Random Read
Random Write

OPAL 2

512GB
PCIe
M.2 in Half-height, half-length card
NVMe
3D MLC
300TBW (TB Written)

1.5M hours
PCI Express 3.0 x4 electrical? x4 physical
32¡ã to 158¡ã F (0¡ã to 70¡ã C)

Sequential Read
Sequential Write
Random Read
Random Write

OPAL 2

3100 MB/s
1400 MB/s
330K IOPS
280K IOPS
?

3200 MB/s
1700 MB/s
330K IOPS
300K IOPS
?

?

DA - 15077???Worldwide QuickSpecs ¡ª Version 37 ¡ª 7/8/2019

Page? 51

QuickSpecs

Technical Specifications - Hard Drives

HP Z440 Workstation

HP Z Turbo Drive Quad
Pro

?

?

HP Z Turbo Drive Quad Pro
2x256GB PCIe SSD

HP Z Turbo Drive Quad Pro
2x512GB PCIe SSD

HP Z Turbo Drive Quad Pro
2x1TB PCIe SSD

HP Z Turbo Drive Quad Pro
256GB SSD module

HP Z Turbo Drive Quad Pro
512GB SSD module

HP Z Turbo Drive Quad Pro
1TB SSD module

Capacity

Interface
Operating Temperature
Capacity

Interface
Operating Temperature
Capacity
Interface
Operating Temperature
Capacity
Interface

Operating Temperature
Capacity
Interface

Operating Temperature
Capacity
Interface

Operating Temperature

2x256GB (two M.2 PCIe NVMe
modules)

PCI Express Gen3 x16
32¡ã to 158¡ã F (0¡ã to 70¡ã C)
2x512GB (two M.2 PCIe NVMe

modules)
PCI Express Gen3 x16
32¡ã to 158¡ã F (0¡ã to 70¡ã C)
2x1TB (two M.2 PCIe NVMe modules)
PCI Express Gen3 x16
32¡ã to 158¡ã F (0¡ã to 70¡ã C)
256GB (one M.2 PCIe NVMe module)
PCI Express 3.0 x4 electrical? x4

physical
32¡ã to 158¡ã F (0¡ã to 70¡ã C)
512GB (one M.2 PCIe NVMe module)
PCI Express 3.0 x4 electrical? x4

physical
32¡ã to 158¡ã F (0¡ã to 70¡ã C)
1TB (one M.2 PCIe NVMe module)
PCI Express 3.0 x4 electrical? x4

physical
32¡ã to 158¡ã F (0¡ã to 70¡ã C)

?

Intel 750 Series AIC PCIe
SSD

?

Intel 750 Series AIC 400GB
PCIe SSD

Capacity
Protocol
Form Factor
Controller
NAND Type
Endurance
Reliability
Operating Temperature
Performance

(MTBF)

400GB
PCIe
PCIe Card, Half Height
NVMe
MLC
127TBW (TB Written)

1.2M hours
32¡ã to 131¡ã F (0¡ã to 55¡ã C)

Sequential Read
Sequential Write
Random Read
Random Write

2200 MB/s
900 MB/s
430K IOPS
230K IOPS

DA - 15077???Worldwide QuickSpecs ¡ª Version 37 ¡ª 7/8/2019

Page? 52

QuickSpecs

Technical Specifications - Hard Drives

HP Z440 Workstation

Intel 750 Series AIC 800GB
PCIe SSD

?

Intel 750 Series AIC 1.2TB
PCIe SSD

Capacity
Protocol
Form Factor
Controller
NAND Type
Endurance
Reliability
Operating Temperature
Performance

Capacity
Protocol
Form Factor
Controller
NAND Type
Endurance
Reliability
Operating Temperature
Performance

(MTBF)

(MTBF)

800GB
PCIe
PCIe Card, Half Height
NVMe
MLC
127TBW (TB Written)

1.2M hours
32¡ã to 131¡ã F (0¡ã to 55¡ã C)

Sequential Read
Sequential Write
Random Read
Random Write

1.2TB
PCIe
PCIe Card, Half Height
NVMe
MLC
127TBW (TB Written)

1.2M hours

1.2TB

Sequential Read
Sequential Write
Random Read
Random Write

2100 MB/s
800 MB/s
420K IOPS
210K IOPS

2500 MB/s
1200 MB/s
460K IOPS
290K IOPS

?
?
?
?

DA - 15077???Worldwide QuickSpecs ¡ª Version 37 ¡ª 7/8/2019

Page? 53

QuickSpecs

Technical Specifications - Hard Drive Controllers

?

Hard Drive Controllers

HP Z440 Workstation

LSI 9217-4i4e 8-port SAS
6Gb/s RAID Card

?

LSI 9270-8i SAS 6Gb/s ROC
RAID Card and iBBU9
Battery Backup Unit

PCI Bus
RAID Levels
PCI Data Burst Transfer

Rate
SAS Bandwidth
PCI Card Type
PCI Voltage
PCI Power
Bracket
Certification Level
SAS Processor
Internal Connectors
External Connectors
Maximum Number of SCSI

Devices
LED Indicators

PCI Bus
RAID Levels
PCI Data Burst Transfer

Rate
PCI Card Type
PCI Voltage
PCI Power
Bracket
Certification Level
SAS Processor
Internal Connectors
External Connectors
Maximum Number of SCSI

Devices
LED Indicators

8 lanes, PCI Express 3.0
Offers Integrated RAID (0, 1, 1E and 10)
Half Duplex? x8, PCIe, 8000 MB/s

Half Duplex

3.3V Add-in Card
12 V ¡À 10%

9.8W typical, Airflow min 200 LFM
Full height and low profile
PCI Express 3.0 compliant
LSI SAS2308/ Fusion MPT 2.0
One x4? internal mini-SAS? (SFF8087)
One x4 external mini-SAS (SFF8088)
256 Non-RAID SAS/SATA devices

N/A

x8 lane PCIe 3.0 compliant
RAID 0, 1, 5, and 6
RAID spans 10, 50 and 60

Low profile, single PCIe slot design with full height bracket.
+3.3V Add-in Card
+3.3V, +12V
PCI-Express 3.0
Eight 6Gb/s and 3Gb/s compatible SAS/SATA ports
LSISAS2208 Dual-Core RAID on Chip (ROC)
Two SAS SFF8087 x4 (Mini-SAS)
None
Up to 128 SAS and/or SATA hard drives and SSDs

Heartbeat LED on card

600 MB/s per lane

?
?

DA - 15077???Worldwide QuickSpecs ¡ª Version 37 ¡ª 7/8/2019

Page? 54

QuickSpecs

Technical Specifications - Graphics

Graphics

HP Z440 Workstation

NVIDIA NVS 310
1GB Graphics

Form Factor

Graphics Controller

Bus Type
Memory

Connectors
Maximum Resolution

Image Quality Features

Display Output

Shading Architecture

Low Profile:

2.713 inches in height ¡Á 6.150 inches in length
Weight: ~142 grams

NVIDIA NVS 310
GPU: GF119-825

PCI Express x16, 2.0 compliant
Size: 1GBB DDR3

Clock: 875Mhz
Memory Bandwidth: 14GB/

2x DisplayPort 1.2
Up to 2560 x 1600 (digital display) per display.

The following video formats are supported:

- MPEG2

- MPEG4 Part 2 Advanced Simple Profile

- H.264 SVC codec support

- Support for 3D Blu Ray

- VC1

- DivX version 3.11 and later

- MVC
?
A full range of video resolutions are supported including 1080p, 1080i, 720p, 480p and
480i. The NVS 310 GPU provides hardware acceleration for the computationally intensive
parts of video processing, as well as provides improved video playback speeds via faster
decode and transcode.

Up to 2 displays in the following configurations:
?
DisplayPort output:

Drives two DisplayPort enabled digital display at resolutions up to 2560 ¡Á 1600 at
60 Hz with reduced blanking, when connected natively using the 2 DisplayPort

connecto
Supports 2 monitors up to resolution of 1920 ¡Á 1200 at 60 Hz with reduced

blanking using DisplayPort 1.2 multi stream topology technology.
?
DVI-D output:

Drives two digital display at resolutions up to 1920 ¡Á 1200 at 60 Hz with reduced

blanking using DisplayPort to DVI-D single-link cable adaptors

Drives two digital display at resolutions up to 2560¡Á 1600 at 60 Hz with reduced

blanking using DisplayPort to DVI-D dual-link cable adaptors
?
HDMI output:

NVS 310 is capable of driving two high definition (HD) panels up to resolutions of

1920 ¡Á 1080P at 60 Hz using DisplayPort to HDMI cable adaptors
?
VGA display output:

Drives two analog display at resolutions up to 1920 ¡Á 1200 at 60 Hz using

DisplayPort to VGA cable adaptors
Shader Model 5.0

rs on the NVS 310 graphics card

DA - 15077???Worldwide QuickSpecs ¡ª Version 37 ¡ª 7/8/2019

Page? 55

QuickSpecs

Technical Specifications - Graphics

HP Z440 Workstation

?

?

NVIDIA NVS 315 1 GB
Graphics

Supported Graphics
APIs

Available Graphics
Drivers

Notes

Form Factor

DX11, OpenGL 4.1

Windows 8.1
Windows 8
Genuine Windows 7 Professional (64-bit and 32-bit)
Red Hat Enterprise Linux(RHEL)
SUSE Linux Enterprise Desktop 11 (64-bit and 32-bit)
?
HP qualified drivers may be preloaded or the latest HP qualified drivers are available from
the HP support Web site:

http://welcome.hp.com/country/us/en/support.html

?
SUSE Linux Enterprise drivers may also be obtained from:

ftp://download.nvidia.com/novell

1.

The thermal solution used on this card is an active fan heatsink.

2.

Factory configured NVS 310 graphics card have no cable adpaters included.

Adapters must be ordered separately.

3.

Option kit NVS 310 includes 2 DP to DVI-D cable adapters.

4.

Configurations of three NVS 310 graphics cards in HP Z440 Workstation require the

HP Z440 Fan and Front Card Guide Kit, configurable from the factory (CTO PN:

G8T99AV) or as an Aftermarket Option (AMO PN: J9P80AA).

Low Profile:

2.713 inches in height ¡Á 5.7 inches in length
Weight: ~142 grams

or

http://www.nvidia.com

Graphics Controller

Bus Type
Memory

Connectors

Maximum Resolution

Image Quality Features

NVIDIA NVS 315 (using GF119-825 GPU)
Number of Cores: 48 CUDA cores
Max. Power: 19.3W
Cooling Solution: Active fan heatsink

PCI Express x16, 2.0 compliant
Size: 1GB DDR3

Clock: 875Mhz
Memory Bandwidth: 14GB/s

DMS-59 output
Cables included:

- For CTO: DMS-59 to DVI cable

- For AMO: DMS-59 to DVI cable and DMS-59 to VGA cable
Maximum number of displays supported: 2

?
Maximum Resolution Support:
?- DMS-59 to VGA: 2048 x 1536 @ 85Hz
?- DMS-59 to DVI: 1980 x 1200 @ 60Hz
?- DMS-59 to DP: 2560 x 1600 @ 60Hz
?

See Display Output section.
?
The following video formats are supported:

- MPEG2

- MPEG4 Part 2 Advanced Simple Profile

DA - 15077???Worldwide QuickSpecs ¡ª Version 37 ¡ª 7/8/2019

Page? 56

QuickSpecs

Technical Specifications - Graphics

HP Z440 Workstation

- H.264 SVC codec support

- Support for 3D Blu Ray

- VC1

- DivX version 3.11 or later
?
A full range of video resolutions are supported including 1080p, 1080i, 720p,
480p and 480i. The NVS 315 GPU provides hardware acceleration for the
computationally intensive parts of video processing, as well as provides
improved video playback speeds via faster decode and transcode.
?

Display Output

Shading Architecture
Supported Graphics APIs
Available Graphics

Drivers

Up to 2 displays using one of the following DMS-59 cables:

- DMS-59 to DVI

- DMS-59 to VGA

- DMS-59 to DP
?
DisplayPort output:

Drives two DisplayPort enabled digital displays at resolutions up to
2560 ¡Á 1600 at 60 Hz with reduced blanking, when connected via the

DMS-59 to DP adapter.
?
DVI-D output:

Drives two digital display at resolutions up to 1920 ¡Á 1200 at 60 Hz

with reduced blanking using DMS-59 to DVI-D single-link cable adaptor
?
VGA display output:

Drives two analog displays at resolutions up to 2048 ¡Á 1536 at 85 Hz

using DMS-59 to VGA cable adaptor.
?

Shader Model 5.0
DX11, OpenGL 4.3
Windows 8

Microsoft Windows 7 Professional (64-bit and 32-bit)
Microsoft Windows XP Professional (64-bit and 32-bit)
Red Hat Enterprise Linux(RHEL)
SUSE Linux Enterprise Desktop 11 (64-bit and 32-bit)
?
HP qualified drivers may be preloaded or the latest HP qualified drivers are
available from the HP support Web site:

http://welcome.hp.com/country/us/en/support.html

?
SUSE Linux Enterprise drivers may also be obtained from:
ftp://download.nvidia.com/novell or
?

http://www.nvidia.com

?

NVIDIA? NVS 510 2GB
Graphics

Notes

Form Factor

DA - 15077???Worldwide QuickSpecs ¡ª Version 37 ¡ª 7/8/2019

1. The thermal solution used on this card is an active fan heatsink.

2. Factory configured NVS 310 graphics card have no cable adapters included.
Adapters must be ordered separately.

3. Option kit graphics card includes DMS-59 to DVI and DMS-59 to VGA cables
(one each).

?

Low Profile, 2.713 inches ¡Á 6.3 inches, single slot

Page? 57

QuickSpecs

Technical Specifications - Graphics

Graphics

Graphics Controller

Bus Type
Memory
Connectors

Maximum Resolution

Image Quality Features

Display Output

Supported Graphics APIs

Available Graphics

HP Z440 Workstation

NVS 510 GPU
Core Clock: 797 MHz
Memory Clock: 891 MHz
CUDA Cores: 192

PCI Express x16, Generation 2.0
2GB DDR3
Four mini-DisplayPort.

Four mini-DisplayPort-to-DisplayPort adapters included.
(DisplayPort to DVI-D, DisplayPort to VGA, DisplayPort to HDMI, and
DisplayPort to Dual-Link DVI adapters available as separate accessories)

Mini-DisplayPort connectors support ultra-high-resolution panels (up to 3840
x 2160 @ 60Hz)
?

Note: This card supports up to four displays. For Windows XP, only 2 active
displays are supported.

10-bit internal display processing, including hardware support for 10-bit
scan-out

DisplayPort with Multi-Stream Technology (MST) and High Bit Rate 2 (HBR2)
support.
?

Digital Display Support

?

DisplayPort Output

Drives four DisplayPort enabled digital display at resolutions up to

3840 ¡Á 2160 at 60 Hz with reduced blanking, when connected natively

using the 4 DisplayPort connectors on the NVS 510 graphics card.

DisplayPort Multi-Stream Topology (MST) Technology: Supports

various combinations of display resolutions and number of displays

when using DisplayPort multi stream topology technology - up to a

maximum of 4 monitors at a resolution of 1920 ¡Á 1200 at 60 Hz with

reduced blanking.
?

DVI-D Output

Drives four digital displays at resolutions up to 1920 ¡Á 1200 at 60 Hz

with reduced blanking using DisplayPort to DVI-D single-link cable

adaptors.

Drives four digital displays at resolutions up to 2560¡Á 1600 at 60 Hz

with reduced blanking using DisplayPort to DVI-D dual-link cable

adaptors.
?

HDMI Output

The NVS 510 graphics board is capable of driving four high definition

(HD) panels up to resolutions of 1920 ¡Á 1080P at 60 Hz using

DisplayPort to HDMI cable adaptors.
?

Analog Display Support

?

VGA display output

Drives four analog displays at resolutions up to 1920 ¡Á 1200 at 60 Hz

using DisplayPort to VGA cable adaptors.
?

Full Microsoft DirectX 11, Shader Model 5.0 support
Full OpenGL 4.3 support
?

Genuine Windows 7 Professional (64-bit and 32-bit)

DA - 15077???Worldwide QuickSpecs ¡ª Version 37 ¡ª 7/8/2019

Page? 58

QuickSpecs

Technical Specifications - Graphics

Drivers

Notes

?

NVIDIA? Quadro? K620
2GB Graphics

Form Factor

Graphics Controller

Bus Type
Memory

Connectors

Maximum Resolution

Image Quality Features

Display Output

Shading Architecture
Supported Graphics APIs

Available Graphics
Drivers

HP Z440 Workstation

Microsoft Windows XP Professional (64-bit and 32-bit)
Red Hat Enterprise Linux(RHEL) 6 Desktop/Workstation
SUSE Linux Enterprise Desktop 11 (64-bit and 32-bit)
?
HP qualified drivers may be preloaded or available from the HP support Web
site:

http://welcome.hp.com/country/us/en/support.html

?

Heatsink cooler design is active.

2.713"? H x 6.3"? L
Single Slot, Low Profile
Full Height Profile bracket installed
Low Profile bracket included
Weight: 133 grams

NVIDIA? Quadro? K620 Graphics Card
GM107 GPU
384 CUDA cores
Max Power: 45 Watts

PCI Express 2.0 x16
2 GB GDDR3, 900 MHz

128-bit memory I/O path
29 GB/s memory bandwidth

1 DL-DVI(I) output, 1 DisplayPort output
Factory Configured: No video cable adapter included
Option Kit: One DP-to-DVI adapter included with card
?
Additional DVI-to-VGA, DisplayPort-to-VGA or DisplayPort-to-DVI adapters are
available as Factory Configuration or Option Kit accessories.

DisplayPort 1.2:

- up to 4096x2160 x 30 bpp @ 60Hz

- supports High Bit Rate 2 (HBR2) and Multi-Stream Transport (MST)
?
Dual Link DVI(I) output:

- up to 2560 x 1600 x 32 bpp @ 60Hz
?
Single Link-DVI(I) output:

- up to 1920 x 1200 x 32 bpp @ 60Hz
10-bit internal display processing pipeline

10-bit scan-out support
1 Dual-link DVI-I connector

1 Display Port connector
Full Microsoft DirectX 11.1 Shader Model 5.0
OpenGL 4.4

DirectX 11.1?????????
API support includes:
CUDA C, CUDA C++, DirectCompute 5.0, OpenCL, Java, Python, and Fortran

Microsoft Windows 8.1
Microsoft Windows 8
Microsoft Windows 7
Linux
?
HP qualified drivers may be preloaded or available from the HP support Web

DA - 15077???Worldwide QuickSpecs ¡ª Version 37 ¡ª 7/8/2019

Page? 59

QuickSpecs

Technical Specifications - Graphics

?

?

NVIDIA? Quadro? K420 2GB
Graphics

Notes

Form Factor

Graphics Controller

Bus Type
Memory

Connectors

Maximum Resolution

Image Quality Features

Display Output

HP Z440 Workstation

site:

http://welcome.hp.com/country/us/en/support.html

?

1.

Factory configured Quadro K620 does not include a video cable adapter.
Video cable adapters must be ordered separately.

2.

Quadro K620 offered as an Option Kit (AMO) includes one DP-to-DVI
video cable adapter. Additional cables must be ordered separately.

Low Profile:

2.713 inches ¡Á 6.3 inches
Cooling: Active

NVIDIA? Quadro? K420
GPU: GK107 with 192 CUDA cores
Power: 41W

PCI Express x16, 2.0 compliant
Size: 2GB DDR3

Clock: 891MHz
Memory Bandwidth: 29GB/s
Memory Width: 128 bit

One dual-link DVI-I connector
One DisplayPort connector
?
Factory Configured: No video cable adapter included
After market option kit: One DP-to-DVI adapter included with
card
?
Additional DisplayPort-to-VGA or DisplayPort-to-DVI adapters
are available as Factory Configuration or Option Kit accessories.
?

VGA (via adapter cable):
?- 2048 ¡Á 1536 ¡Á 32 bpp at 85 Hz
?
Dual-link DVI
?- 2560 ¡Á 1600 ¡Á 32 bpp at 60 Hz (reduced blanking)
?
Single-link DVI
?- 1920 ¡Á 1200 ¡Á 32 bpp at 60 Hz (reduced blanking)
?
DisplayPort 1.2
?- 3840 ¡Á 2160 ¡Á 30 bpp at 60 Hz
?

12-bit internal display pipeline (hardware support for 12-bit
scanout on supported panels, applications and connection)
?
Stereoscopic 3D display support including NVIDIA? 3D Vision
technology, 3D DLP, Interleaved, and passive stereo

?

Maximum number of displays:

- 2 direct attached monitors

- 4 using DP 1.2a with MST and HBR2 enabled monitors
?
Maximum number of DisplayPort displays possible (may require
MST and/or HBR2):

- 4 1920x1200

TM

DA - 15077???Worldwide QuickSpecs ¡ª Version 37 ¡ª 7/8/2019

Page? 60

QuickSpecs

Technical Specifications - Graphics

Shading Architecture

Supported Graphics APIs

Available Graphics Drivers

Notes

HP Z440 Workstation

- 2 2560x1600

- 1 3840x2160
?
Maximum number of monitors across all available Quadro K420
outputs is 4.

?

Shader Model 5.0

?

DX11, OpenGL 4.4
Programming support for CUDA C, CUDA C++, DirectCompute 5.0,
OpenCL, Python, and Fortran
?

Microsoft Windows 8.1
Microsoft Windows 8
Microsoft Windows 7
Linux - Full OpenGL implementation, complete with NVIDIA and
ARB extensions
?

1.

Factory configured Quadro K420 does not include any
video adapters. Adapters must be ordered separately.

2.

Option kit Quadro K420 includes one DP to DVI-D adapter.

3.

Full Height Profile bracket installed. Low Profile bracket
included in after market kit.

?

NVIDIA? Quadro? P400
2GB Graphics

Form Factor

Graphics Controller

Bus Type
Memory

Connectors

Maximum Resolution

Image Quality Features

Display Output
Shading Architecture
Supported Graphics APIs

Available Graphics Drivers

Dimensions:
Single Slot, Low Profile
Cooling: Active
Weight: 129 grams
?

NVIDIA? Quadro? P400 Graphics Card
GP107-825 GPU
256 CUDA cores
Max Power: 30 Watts

PCI Express 3.0 x16
Size: 2 GB GDDR5, 2000 MHz

Memory Interface: 64-bit
Memory Bandwidth: 32 GB/s

3mDP Outputs*
?

DisplayPort 1.4:

- up to 3x 5120 x 2880 x 24 bpp @ 60Hz

- supports Multi-Stream Transport (MST)
10-bit internal display processing pipeline

10-bit scan-out support
3 mDP Connectors
Full Microsoft DirectX 12 Shader Model 5.1
OpenGL 4.5

DirectX 12
Vulkan 1.0
API support includes:
CUDA C, CUDA C++, DirectCompute , OpenCL

Microsoft Windows 10

2.713"? H x 5.7"? L

DA - 15077???Worldwide QuickSpecs ¡ª Version 37 ¡ª 7/8/2019

Page? 61

QuickSpecs

Technical Specifications - Graphics

?

Notes

HP Z440 Workstation

Microsoft Windows 8.1
Microsoft Windows 7
Linux
?
HP qualified drivers may be preloaded or available from the HP support
Web site:
http://welcome.hp.com/country/us/en/support.html
?

*P400, P600 and P1000 only have mini-DisplayPort (mDP) video ports.

Note 1: Two mDP-to-DP adapters will ship with each P400, P600 or P1000

configured in HP Z Workstations Compatibles.

Note 2:

AMO kits for P400, P600, P1000 and Adapters will ship in July 2017.

????????

ϒ⁄

????????

ϒ⁄

Two mDP-to-DP Adapters are included in the P400, P600 and P1000

AMO kits.

If mDP-to-DP Adapters are needed, Adapters can be ordered separately:

?????????

-

-

2KW86A6 -? HP (Bulk 4) miniDP-to-DP Adapter Cables

?????????

2KW87A6 -? HP (Bulk 12) miniDP-to-DP Adapter Cables

?

NVIDIA? Quadro?
P600
2GB Graphics

Form Factor

Graphics Controller

Bus Type
Memory

Connectors
Maximum Resolution

Image Quality Features

Display Output
Shading Architecture

Supported Graphics
APIs

Available Graphics
Drivers

Dimensions:
Single Slot, Low Profile
Cooling: Active
Weight: 129 grams
?

NVIDIA? Quadro? P600 Graphics Card
GP107-850 GPU
384 CUDA cores
Max Power: 40 Watts

PCI Express 3.0 x16
Size: 2 GB GDDR5,

Memory Interface: 128-bit
Memory Bandw

4mDP Outputs
DisplayPort 1.4:

- up to 4x 5120 x 2880 x 24 bpp @ 60Hz

- supports Multi-Stream Transport (MST)
10-bit internal display processing pipeline

10-bit scan-out support
4 mDP Connectors
Full Microsoft DirectX 12 Shader Model 5.1

?

OpenGL 4.5
DirectX 12
Vulkan 1.0
API support includes:
CUDA C, CUDA C++, DirectCompute , OpenCL

Microsoft Windows 10
Microsoft Windows 8.1
Microsoft Windows 7
Linux

2.713"? H x 5.7"? L

2000 MHz

idth:

64 GB/

s

*

DA - 15077???Worldwide QuickSpecs ¡ª Version 37 ¡ª 7/8/2019

Page? 62

QuickSpecs

Technical Specifications - Graphics

Notes

????????

ϒ⁄

????????

ϒ⁄

?

NVIDIA? Quadro? K1200
4GB Graphics

Form Factor

Graphics Controller

Bus Type

Memory

Connectors

Maximum Resolution

HP Z440 Workstation

?
HP qualified drivers may be preloaded or available from the HP support
Web site:

http://welcome.hp.com/country/us/en/support.html

*P400, P600 and P1000 only have mini-DisplayPort (mDP) video ports.

Note 1: Two mDP-to-DP adapters will ship with each P400, P600 or P1000 configured in

HP Z Workstations Compatibles.

Note 2:

AMO kits for P400, P600, P1000 and Adapters will ship in July 2017.

Two mDP-to-DP Adapters are included in the P400, P600 and P1000 AMO kits.

If mDP-to-DP Adapters are needed, Adapters can be ordered separately:

?????????

-

-

Dimensions: 2.71" H x 6.875"? L
Single Slot, Low Profile
Cooling: Active
Weight: ~175 grams
?

NVIDIA? Quadro? K1200 Graphics Card
GPU: GM107 with 512 CUDA cores
Power: 46 Watts
?

PCI Express 2.0 x16
?

Size: 4GB GDDR5
Memory Bandwidth: 80 GB/s
Memory Width: 128-bit

?

4 mini-DisplayPort 1.2a
?
Factory Configured Option: 4 mini-DP-to-DP adapters included with card
Option Kit: 4 mini-DP-to-DP adapters included with card
?
Additional DisplayPort-to-VGA or DisplayPort-to-DVI adapters are available
as accessories
?

DisplayPort:

- up to 4096 x 2160 x 30 bpp @ 60Hz

- supports High Bit Rate 2 (HBR2) and Multi-Stream Transport (MST)
?
DL-DVI(I) output:

- up to 2560 x 1600 x 32 bpp @ 60Hz
?
Single Link-DVI(I) output:

- up to 1920 x 1200 x 32 bpp @ 60Hz
?
VGA (via adapter cable):
?- 2048 ¡Á 1536 ¡Á 32 bpp at 85 Hz
?

2KW86A6 -? HP (Bulk 4) miniDP-to-DP Adapter Cables

?????????

2KW87A6 -? HP (Bulk 12) miniDP-to-DP Adapter Cables

DA - 15077???Worldwide QuickSpecs ¡ª Version 37 ¡ª 7/8/2019

Page? 63

QuickSpecs

Technical Specifications - Graphics

HP Z440 Workstation

Image Quality Features

Display Output

Shading Architecture

Supported Graphics APIs

Available Graphics Drivers

Notes

12-bit internal display pipeline (hardware support for 12-bit scanout on
supported panels, applications and connection)
?

Maximum number of displays

- 4 direct attached monitors
?
Maximum number of DisplayPort displays possible:

- 4 1920x1200

- 4 2560x1600

- 4 4096x2160
?
Maximum number of monitors across all available Quadro K1200 outputs is 4.
?

Shader Model 5.0
?

OpenGL 4.4
DirectX 11.1
???????????????
API support includes:
CUDA C, CUDA C++, DirectCompute 5.0, OpenCL, Java, Python, and Fortran

?

Microsoft Windows 8.1
Microsoft Windows 8
Microsoft Windows 7
Linux - Full OpenGL implementation, complete with NVIDIA and ARB
extensions
?
HP qualified drivers may be preloaded or available from the HP support Web
site:

http://welcome.hp.com/country/us/en/support.html

?

1.

Quadro K1200 offered as Factory Configured Option includes 4 miniDP
to DP video cable adapters. Other video cable adapters must be
ordered separately.

2.

Quadro K1200 offered as an Option Kit includes 4 mini-DP to DP
adapters. Additional cables must be ordered separately.

3.

A total maximum of 4 active monitors are supported across all display
output types. This may be accomplished by using daisy chained
DisplayPort 1.2 displays (displays must support MST and HBR2).

?

?

NVIDIA? Quadro? K2200
4 GB Graphics

Form Factor

Weight:
Graphics Controller

Bus Type
Memory

DA - 15077???Worldwide QuickSpecs ¡ª Version 37 ¡ª 7/8/2019

4.38" H x 7.97" L
Single Slot, Full Height

240 grams
NVIDIA? Quadro? K2200 Graphics Card

GM107 GPU
640 CUDA cores
Max Power: 67.7 Watts

PCI Express 2.0 x16
4 GB GDDR5, 2500 Mhz

128-bit memory I/O path
80 GB/s memory bandwidth

Page? 64

QuickSpecs

Technical Specifications - Graphics

HP Z440 Workstation

Connectors

Maximum Resolution

Image Quality Features

Display Output

Shading Architecture
Supported Graphics APIs

Available Graphics Drivers

Notes

1 DL-DVI(I) output, 2 DisplayPort outputs
Factory Configured Option: No video cable adapter included
Option Kit: One DP-to-DVI adapter included with card
?
Additional DVI-to-VGA, DisplayPort-to-VGA or DisplayPort-to-DVI adapters
are available as accessories

DisplayPort:

- up to 4096 x 2160 x 30 bpp @ 60Hz

- supports High Bit Rate 2 (HBR2) and Multi-Stream Transport (MST)
?
DL-DVI(I) output:

- up to 2560 x 1600 x 32 bpp @ 60Hz
10-bit internal display processing pipeline

10-bit scan-out support
VGA:

requires use of DVI-to-VGA and/or DP-to-VGA video cable adapters
400 MHz integrated RAMDAC

Max resolution: 2048 x 1536 x 32 bpp @ 85 Hz
?
DL-DVI(I):

Max resolution: 2560 x 1600 x 32 bpp @ 60 Hz
?
SL-DVI(I):

Max resolution: 1920 x 1200 x 32 bpp @ 60 Hz
?
DisplayPort:

Supports HBR2 and MST

Max resolution: 4096 x 2160 x 30 bpp @ 60 Hz (only one monitor can

be connected to a Quadro K2200 DisplayPort connector at this

resolution)

Max number of DisplayPort daisy-chained monitors or hub connected

monitors from a single Quadro K2200 DisplayPort connector: 4 with

maximum resolution of 1920 x 1200
?
Maximum number of monitors across all available Quadro K2200 outputs is 4.

Full Microsoft DirectX 11.1 Shader Model 5.0
OpenGL 4.4

DirectX 11.1?????????
API support includes:
CUDA C, CUDA C++, DirectCompute 5.0, OpenCL, Java, Python, and Fortran

Microsoft Windows 8.1
Microsoft Windows 8
Microsoft Windows 7
Linux
?
HP qualified drivers may be preloaded or available from the HP support Web
site:

http://welcome.hp.com/country/us/en/support.html

?

1.

Quadro K2200 offered as Factory Configured Option does not include a

video cable adapter. Video cable adapters must be ordered separately.

2.

Quadro K2200 offered as an Option Kit includes one DP-to-DVI video

cable adapter. Additional cables must be ordered separately.

3.

A total maximum of 4 active monitors are supported across all display

output types. This may be accomplished by using daisy chained

DisplayPort 1.2 displays or a DisplayPort 1.2 hub device.

4.

DA - 15077???Worldwide QuickSpecs ¡ª Version 37 ¡ª 7/8/2019

Page? 65

QuickSpecs

Technical Specifications - Graphics

?

NVIDIA? Quadro? M2000
4GB Graphics

Form Factor

Graphics Controller

Bus Type

Memory

Connectors

Maximum Resolution

Image Quality Features

Display Output

Shading Architecture

Supported Graphics APIs

3.

4.

A DisplayPort hub device may be used to connect multiple DisplayPort

monitors to a single Quadro K2200 DisplayPort output.

Dimensions: 4.376" H x 6.6"? L
Single Slot, Full Height
Cooling: Active
Weight: 239 grams
?

NVIDIA? Quadro? M2000 Graphics Card
GPU: GM206 with 768 CUDA cores
Power: 75 Watts
?

PCI Express 3.0 x16
?

Size: 4GB GDDR5
Memory Bandwidth: 105.7 GB/s
Memory Width: 128-bit

?

4x DisplayPort 1.2a
?
Factory Configured Option: No video cable adapter included
After Market Option: No video cable adapter included
?
Additional DisplayPort-to-VGA, DisplayPort-to-HDMI, or DisplayPort-to-DVI
adapters are available as accessories
?

DisplayPort:

- up to 4096 x 2160 x 30 bpp @ 60Hz

- up to 2560 x 1600 x 30 bpp @ 120 Hz

- supports High Bit Rate 2 (HBR2) and Multi-Stream Transport (MST)
?
Using two DP outputs, the M2000 can drive one dual DP input display with
5120 x 2880 x 30 bpp @ 60Hz resolution.
?

12-bit internal display pipeline (hardware support for 12-bit scanout on
supported panels, applications and connection)
?
Stereoscopic 3D display support including NVIDIA? 3D VisionTM technology,
3D DLP, Interleaved, and passive stereo
?

Maximum number of displays

- 4 direct attached monitors
?
Maximum number of monitors across all available Quadro M2000 outputs is

4.
?

Shader Model 5.0
?

OpenGL 4.5
DirectX 12
???????????????
API support includes:
CUDA C, CUDA C++, DirectCompute 5.0, and OpenCL software

?

HP Z440 Workstation

DA - 15077???Worldwide QuickSpecs ¡ª Version 37 ¡ª 7/8/2019

Page? 66

QuickSpecs

Technical Specifications - Graphics

HP Z440 Workstation

?

NVIDIA? Quadro?
P1000
4GB Graphics

Available Graphics Drivers

Notes

Form Factor

Graphics Controller

Bus Type
Memory

Connectors
Maximum Resolution

Image Quality Features

Display Output
Shading Architecture
Supported Graphics

APIs

Available Graphics
Drivers

Notes

Microsoft Windows 10
Microsoft Windows 7
Linux - Full OpenGL implementation, complete with NVIDIA and ARB
extensions
?
HP qualified drivers may be preloaded or available from the HP support Web
site:

http://welcome.hp.com/country/us/en/support.html

?

??????

1.

Quadro M2000 offered as Factory Configured Option does not include a video

cable adapter. Video cable adapters must be ordered separately.

??????

2.

Quadro M2000 offered as an After Market Option does not include video

cables. Video cable adapters must be ordered separately.

Dimensions:2.
Single Slot, Low Profile
Cooling: Active
Weight: 129 grams

NVIDIA? Quadro? P1000 Graphics Card
GP107-860 GPU
640 CUDA cores
Max Power: 47 Watts

PCI Express 3.0 x1
Size:

4 GB GDDR5, 2500 MHz
Memory Interface:
Memory Bandwidth: 80 GB/s memory bandwidth

4mDP Outputs*
DisplayPort 1.4:

- up to 4x 5120 x 2880 x 24 bpp @ 60Hz

- supports Multi-Stream Transport (MST)
10-bit internal display processing pipeline

10-bit scan-out support
4 mDP Connectors
Full Microsoft DirectX 12 Shader Model 5.1
OpenGL 4.5

DirectX 12
Vulkan 1.0
API support includes:
CUDA C, CUDA C++, DirectCompute , OpenCL

Microsoft Windows 10
Microsoft Windows 8.1
Microsoft Windows 7
Linux
?
HP qualified drivers may be preloaded or available from the HP support
Web site:
http://welcome.hp.com/country/us/en/support.html

*P400, P600 and P1000 only have mini-DisplayPort (mDP) video ports.

Note 1: Two mDP-to-DP adapters will ship with each P400, P600 or P1000 configured in

HP Z Workstations Compatibles.

Note 2:

713"? H x 5.7"?

6

128-bit memory interface

AMO kits for P400, P600, P1000 and Adapters will ship in July 2017.

L

DA - 15077???Worldwide QuickSpecs ¡ª Version 37 ¡ª 7/8/2019

Page? 67

QuickSpecs

Technical Specifications - Graphics

????????

ϒ⁄

????????

ϒ⁄

?

NVIDIA Quadro P2000 5GB
Graphics

Form Factor

Graphics Controller

Bus Type

Memory

Connectors

Maximum Resolution

Image Quality Features

HP Z440 Workstation

Two mDP-to-DP Adapters are included in the P400, P600 and P1000 AMO kits.

If mDP-to-DP Adapters are needed, Adapters can be ordered separately:

?????????

-

-

Dimensions: 4.4"?Hx7.9"?L
Single Slot
Cooling: Active
Weight: 260 grams
?

NVIDIA Quadro P2000 Graphics Card
Power: 75 Watts
?

PCI Express 3.0 x16
?

Size: 5GB GDDR5
Memory Bandwidth: 140 GB/s
Memory Width: 160-bit
?

4x DisplayPort 1.4
?
Factory Configured Option: No adapter included with card
After Market Option: No video cable adapter included
?
Additional DVI to VGA, DisplayPortTM to VGA,? DisplayPortTM to DVI, and
DisplayPortTM to Dual-Link DVI adapters available as accessories.
?

DisplayPort:

- up to 5120 x 2880 x 24 bpp @ 60Hz

- supports High Bit Rate 2 (HBR2) and Multi-Stream Transport (MST) DP 1.3 &

1.4 ready.
?
DL-DVI(I) output:

- up to 2560 x 1600 x 32 bpp @ 60 Hz
?
Single Link-DVI(I) output:

- up to 1920 x 1200 x 32 bpp @ 60Hz
?
HDMI 2.0 (requires DP to HDMI adapter):
?5120 x 2880 x 24 bpp @ 60Hz
?

12-bit internal display pipeline (hardware support for 12-bit scanout on
supported panels, applications and connection)
?
Stereoscopic 3D display support including NVIDIA? 3D VisionTM technology,
NVIDIA? Mosaic and nView.
?

2KW86A6 -? HP (Bulk 4) miniDP-to-DP Adapter Cables

?????????

2KW87A6 -? HP (Bulk 12) miniDP-to-DP Adapter Cables

DA - 15077???Worldwide QuickSpecs ¡ª Version 37 ¡ª 7/8/2019

Page? 68

QuickSpecs

Technical Specifications - Graphics

HP Z440 Workstation

Display Output

Shading Architecture

Supported Graphics APIs

Available Graphics Drivers

Notes

1.

??????

Maximum number of displays

- 4 direct attached monitors
?
Maximum number of monitors across all available Quadro P2000 outputs is

4.
?

Shader Model 5.1

?

OpenGL? 4.5
DirectX? 12
???????????????
API support includes:
CUDA C, CUDA C++, DirectCompute 5.0, OpenCL, Java, Python, and Fortran
software
?

Microsoft Windows 10
Microsoft Windows 7 Professional 64bit
Linux - Full OpenGL implementation, complete with NVIDIA and ARB
extensions
?
HP qualified drivers may be preloaded or available from the HP support Web
site:

http://welcome.hp.com/country/us/en/support.html

?

Quadro P2000 offered as Factory Configured Option does not include a video

cable adapter. Video cable adapters must be ordered separately.

?

RadeonTM Pro WX 4100
4GB Graphics

Form Factor
Graphics Controller

Memory

Connectors

Maximum Resolution

Image Quality Features

Display Output

GPU Architecture

??????

2.

Quadro P2000 offered as an After Market Option does not include video

cables. Video cable adapters must be ordered separately.

Low-Profile Single Slot (
Polaris 11 Baffin GL XT

GPU: 1024 Stream Processors organized into 16 Compute Units
Power: 50 Watts
Cooling: Active

4GB GDDR5 memory
Memory Bandwidth: 6 Gbps / 96 GB/s
Memory Width: 128 bit
?

4x Mini DisplayPort 1.4 - HDR ready connectors with HBR3 and MST support.
?
Factory Configured:? Four mDP-to-DP cable adapters included
After market option kit:? Four mDP-to-DP cable adapters included
?
Additional DisplayPort-to-VGA or DisplayPort-to-DVI adapters are available
as Factory Configuration or Option Kit accessories.

5K support @ 60Hz

????????

ϒ⁄

1x single-cable 5K monitor, or 2x dual-cable 5K monitors

4x 4K support @ 60Hz
Advanced support for 8-bit and 10-bit per RGB color component. High

bandwidth scaler for high quality up and downscaling
4 full physical DP1.3 HBR3 / DP1.4 HDR outputs

FreeSync support
?

GCN 4th Generation

6.6"? Length

)

DA - 15077???Worldwide QuickSpecs ¡ª Version 37 ¡ª 7/8/2019

Page? 69

QuickSpecs

Technical Specifications - Graphics

HP Z440 Workstation

Supported Graphics APIs

Available Graphics Drivers

Notes

DirectX?12
OpenGL? 4.5
OpenCLTM 2.0
VulkanTM 1.0

Windows 10 64-bit
Windows? 7 64-bit
Linux 64-bit (selected Enterprise distributions)
?
HP qualified drivers may be preloaded or available from the HP support Web
site:

http://welcome.hp.com/country/us/en/support.html

?

??????

1.

HDR content requires that the system be configured with a fully
HDR-ready content chain, including: graphics card, monitor/TV,
graphics driver and application. Video content must be graded in
HDR and viewed with an HDR-ready player. Windowed mode
content requires operating system support.

??????

2.

AMD PowerTune and AMD ZeroCore Power are technologies
offered by certain FireProTM and RadeonTM Pro products, which
are designed to intelligently manage GPU power consumption in
response to certain GPU load conditions.

??????

3.

As of September 2016, certified for DisplayPortTM 1.4 HBR3 and
ready for DisplayPortTM 1.4 HDR based on independent
verification by DisplayPortTM testing authority. HDR content
requires that the system be configured with a fully HDR- ready
content chain, including: graphics card, monitor/TV, graphics
driver and application. Video content must be graded in HDR and
viewed with an HDR-ready player. Windowed mode content
requires operating system support.

?

AMD FirePro W2100 2GB
Graphics

Form Factor

Graphics Controller

Bus Type

Memory

Connectors

Maximum Resolution

Low Profile, half length (full-height bracket included)

AMD FireProTM W2100 professional graphics
Power: <50W
Cooling: Active

PCI Express? x8, Generation 3.0

2GB DDR3 memory
Memory Bandwidth: 14.4 GB/s

2x Display Port 1.2 connectors
?
Factory Configured: No video cable adapter included
Option Kit: One DP-to-DVI adapter included with card
?
Additional DisplayPort-to-VGA or DisplayPort-to-DVI adapters are available

as Factory Configuration or Option Kit accessories.
?

DisplayPort 1.2:

up to 4096x2160 x 30 bpp @ 60Hz

DA - 15077???Worldwide QuickSpecs ¡ª Version 37 ¡ª 7/8/2019

Page? 70

QuickSpecs

Technical Specifications - Graphics

HP Z440 Workstation

?
Dual Link DVI(I) (requires adapter cable):

up to 2560 x 1600 x 32 bpp @ 60Hz
?
Single Link-DVI(I)(requires adapter):

up to 1920 x 1200 x 32 bpp @ 60Hz
?
VGA(requires adapter):

up to 1920 x 1200 x 32 bpp @ 60Hz

?

?

AMD FirePro W4300 4GB
Graphics

Display Output

Shading Architecture

Supported Graphics APIs

Available Graphics Drivers

Notes

Form Factor

2 x DisplayPort? 1.2

Shader Model 5.0

OpenCLTM 1.2, DirectX? 11 and OpenGL 4.4

Windows 8.1 (64-bit and 32-bit)
Windows 7 (64-bit and 32-bit)
Red Hat Enterprise Linux (RHEL)
SUSE Linux Enterprise Desktop 11(64-bit and 32-bit)
Ubuntu
HP qualified drivers may be preloaded or available from the HP support Web

site:

http://welcome.hp.com/country/us/en/support.html

?

Depending on the card model, native DisplayPortTM connectors and/or
certified DisplayPortTM active or passive adapters to convert your monitor's
native input to your card's DisplayPortTM or Mini-DisplayPortTM connector(s)
may be required. See

Low Profile, single slot (6.6"? x 3.118"?)
Full Height, single slot (6.6" x 4.725")

www.amd.com/firepro

for details

Graphics Controller

Bus Type
Memory

Connectors

DA - 15077???Worldwide QuickSpecs ¡ª Version 37 ¡ª 7/8/2019

AMD FirePro W4300 graphics
GPU Frequency: 930Mhz
Memory Clock Speed: 1500Mhz
GPU: 768 Stream Processors organized into 12 Compute Units
Power: <50 Watts
Cooling: Active

PCI Express? x16, Generation 3.0
4GB GDDR5 memory

Memory Bandwidth: up to 96 GB/s
Memory Width: 128 bit

4x Mini Display Port 1.2 connectors with HBR2 and MST support.
?
Factory Configured: No video cable adapter included
After market option kit: No video cable adapter included
?
Additional DisplayPort-to-VGA, DisplayPort-to-HDMI, or DisplayPort-to-DVI

Page? 71

QuickSpecs

Technical Specifications - Graphics

HP Z440 Workstation

adapters are available as Factory Configuration or Option Kit accessories.
?

Maximum Resolution

Image Quality Features

Display Output

Shading Architecture

Supported Graphics APIs

Available Graphics Drivers

Notes

DisplayPort:

- 4096x2160 @24bpp (3 x 4K @ 60Hz, 4 x 4K @ 30Hz)
Advanced support for 8-bit, 10-bit, and 16-bit per RGB color component.

High bandwidth scaler for high quality up and downscaling
Incorporated Adaptive-Sync enables FreeSyncTM technology from AMD that
allows
GPU control of display refresh rates for tear-free and jitter-free image quality
when rotating models or viewing video content.(Requires FreeSync compliant
displays)

Max number of monitors supported using DisplayPort 1.2a:

4 direct attached monitors

6 using DP 1.2a with MST and HBR2 enabled monitors?
?
Monitor chaining from a single DisplayPort (subject to a max of 6 total
monitors across all outputs, requires use of DisplayPort enabled monitors
supporting MST and HBR2):

one 4096x2160 display

two 2560x1600 displays

four 1920x1200 displays
Shader Model 5.0

?

OpenGL 4.4
OpenCL 2.0
DirectX 12.0

Windows 10?? (64-bit and 32-bit)
Windows? 7?? (64-bit and 32-bit)
Linux
?
HP qualified drivers may be preloaded or available from the HP support Web
site:

http://welcome.hp.com/country/us/en/support.html

1.

AMD Eyefinity technology supports up to six DisplayPortTM monitors

on an enabled graphics card. Supported display quantity, type and

resolution vary by model and board design; confirm specifications with

manufacturer before purchase. To enable more than two displays, or

multiple displays from a single output, additional hardware such as

DisplayPort-ready monitors or DisplayPort 1.2 MST-enabled hubs may

be required.? A maximum of two active adapters is recommended for

consumer systems. See www.amd.com/eyefinityfaq for full details.

2.

Configurations of two FirePro W4300 graphics cards in HP Z440

Workstation require the HP Z440 Fan and Front Card Guide Kit,

configurable from the factory (CTO PN: G8T99AV) or as an Aftermarket

Option (AMO PN: J9P80AA).

?

AMD FirePro W5100 4GB
Graphics

Form Factor

Graphics Controller

DA - 15077???Worldwide QuickSpecs ¡ª Version 37 ¡ª 7/8/2019

Full height, single slot (6.75"? X 4.376"?)

AMD FirePro W5100 graphics
GPU Frequency: 930Mhz
GPU: 768 Stream Processors organized into 12 Compute Units
Power: <75 Watts

Page? 72

QuickSpecs

Technical Specifications - Graphics

HP Z440 Workstation

Cooling: Active

Bus Type

Memory

Connectors

Maximum Resolution

Image Quality Features

Display Output

Shading Architecture

PCI Express? x16, Generation 3.0

?

4GB GDDR5 memory
Memory Bandwidth: up to 96 GB/s
Memory Width: 128 bit
?

4x Display Port 1.2 connectors with HBR2 and MST support.
?
Factory Configured: No video cable adapter included
After market option kit: No video cable adapter included
?
Additional DisplayPort-to-VGA or DisplayPort-to-DVI adapters are available
as Factory Configuration or Option Kit accessories.

DisplayPort:

- 4096x2160 @24bpp 60Hz
?
Dual Link DVI:

- 2560x1600 (requires DP to DL-DVI adapter)
?
Single Link DVI:

- 1920x1200 (requires DP to DVI adapter)
?
VGA:

- 1920x1200 (requires DP to VGA adapter)
Advanced support for 8-bit, 10-bit, and 16-bit per RGB color component.

High bandwidth scaler for high quality up and downscaling
Max number of monitors supported using DisplayPort 1.2a:

- 4 direct attached monitors

- 6 using DP 1.2a with MST and HBR2 enabled monitors?
?
Monitor chaining from a single DisplayPort (subject to a max of 6 total
monitors across all outputs, requires use of DisplayPort enabled monitors
supporting MST and HBR2):

- one 4096x2160 display

- two 2560x1600 displays

- four 1920x1200 displays
Shader Model 5.0

?

Supported Graphics APIs

?

?

Available Graphics Drivers

Notes

DA - 15077???Worldwide QuickSpecs ¡ª Version 37 ¡ª 7/8/2019

OpenGL 4.4
OpenCL 1.2 and 2.0
DirectX 11.2 / 12
AMD Mantle

Windows 8.1 / 8 (64-bit and 32-bit)
Windows? 7 (64-bit and 32-bit)
Linux
?
HP qualified drivers may be preloaded or available from the HP support Web
site:

http://welcome.hp.com/country/us/en/support.html

?

1. AMD Eyefinity technology supports up to six DisplayPortTM monitors on an

Page? 73

QuickSpecs

Technical Specifications - Graphics

HP Z440 Workstation

enabled graphics card. Supported display quantity, type and resolution vary
by model and board design; confirm specifications with manufacturer before
purchase. To enable more than two displays, or multiple displays from a
single output, additional hardware such as DisplayPort-ready monitors or
DisplayPort 1.2 MST-enabled hubs may be required.? A maximum of two
active adapters is recommended for consumer systems. See

www.amd.com/eyefinityfaq

for full details.

?

?

NVIDIA? Quadro?
M4000 8GB
Graphics
?

Form Factor

Form Factor

Graphics Controller

Bus Type

Memory

Connectors

Maximum Resolution

Image Quality Features

Full height, single slot (6.75"? X 4.376"?)

Dimensions: 4.4"? H x 9.5"? L
Single Slot, Full Height
Cooling: Active
Weight: 475 grams (without extender)
?

NVIDIA? Quadro? M4000
GPU: GM204 with 1664 CUDA cores
Power: 120 Watts
?

PCI Express 3.0 x16
?

Size: 8GB GDDR5
Memory Bandwidth: 192 GB/s
Memory Width: 256-bit

?

4 DisplayPort 1.2a
Factory configured Option: No video cable adapter included
After market option kit: No video cable adapter included
?
Additional DisplayPort-to-VGA or DisplayPort-to-DVI adapters are available as
accessories
?

DisplayPort:

- single DisplayPort up to 4096 x 2160 x 30 bpp @ 60Hz

- supports High Bit Rate 2 (HBR2) and Multi-Stream Transport (MST)
?
DL-DVI(I) output:

- up to 2560 x 1600 x 32 bpp @ 60Hz
?
Single Link-DVI(I) output:

- up to 1920 x 1200 x 32 bpp @ 60Hz
?
VGA (via adapter cable):
?- 2048 ¡Á 1536 ¡Á 32 bpp at 85 Hz
?

12-bit internal display pipeline (hardware support for 12-bit scanout on supported
panels, applications and connection)
?
NVIDIA? 3D VisionTM technology, 3D DLP, Interleaved, and other 3D stereo format
support
?
Full OpenGL quad buffered stereo support
?

DA - 15077???Worldwide QuickSpecs ¡ª Version 37 ¡ª 7/8/2019

Page? 74

QuickSpecs

Technical Specifications - Graphics

Display Output

Shading Architecture

Supported Graphics
APIs

HP Z440 Workstation

Support for large-scale, ultra-high resolution visualization using the NVIDIA? SVS
platform which includes NVIDIA? Mosaic, NVIDIA? Sync and NVIDIA? Warp/Blend
technologies
?

Maximum number of displays

- 4 direct attached monitors

- 4 using DP 1.2a with MST and HBR2 enabled monitors
?
Maximum number of DisplayPort displays possible:

- 4 1920x1200

- 4 2560x1600

- 4 4096x2160

- 2 5120x2880 (requires dual DP input capable 5k displays)
?
Maximum number of monitors across all available Quadro M4000 outputs is 4.
?

Shader Model 5.0
?

OpenGL 4.5
DirectX 12
???????????????
API support includes:
CUDA C, CUDA C++, DirectCompute 5.0, OpenCL, Java, Python, and Fortran

?

?

NVIDIA? Quadro?
M5000 8GB
Graphics

Available Graphics
Drivers

Notes

Form Factor

Graphics Controller

Microsoft Windows 10
Microsoft Windows 8.1
Microsoft Windows 8
Microsoft Windows 7
Linux - Full OpenGL implementation, complete with NVIDIA and ARB extensions
?
HP qualified drivers may be preloaded or available from the HP support Web site:

http://welcome.hp.com/country/us/en/support.html

?

1. Configurations using the Quadro M4000 graphics card in HP Z440 Workstation require
the HP Z440 Fan and Front Card Guide Kit, configurable from the factory (CTO PN:
G8T99AV) or as an Aftermarket Option (AMO PN: J9P80AA).

Dimensions: 4.4"? H x 10.5"? L
Dual Slot, Full Height
Cooling: Active
Weight: 525 grams (without extender)
?

NVIDIA? Quadro? M5000
GPU: GM204 with 2048 CUDA cores
Power: 150 Watts
?

Bus Type

PCI Express 3.0 x16
?

DA - 15077???Worldwide QuickSpecs ¡ª Version 37 ¡ª 7/8/2019

Page? 75

QuickSpecs

Technical Specifications - Graphics

HP Z440 Workstation

Memory

Connectors

Maximum Resolution

Image Quality Features

Display Output

Shading Architecture
Supported Graphics

APIs

Size: 8GB GDDR5 ECC capable
Memory bandwidth: 211GB/s
Memory Width: 256-bit

?

1 Dual Link DVI-I
4 DisplayPort 1.2a
?
Factory configured option: No adapter included with card.
After market option kit: No adaptor included with card.
?
Additional DVI to VGA, DisplayPort to VGA,? DisplayPort to DVI, and DisplayPort to Dual­Link DVI adapters available as accessories
?

DisplayPort:

- up to four 4096 x 2160 x 30 bpp @ 60Hz displays

- up to two 5120 x 2880 @ 60Hz displays

- supports High Bit Rate 2 (HBR2) and Multi-Stream Transport (MST)
?
DL-DVI(I) output:

- up to 2560 x 1600 x 32 bpp @ 60Hz
?
Single Link-DVI(I) output:

- up to 1920 x 1200 x 32 bpp @ 60Hz
?
VGA (via adapter cable):
?- 2048 ¡Á 1536 ¡Á 32 bpp at 85 Hz
?

12-bit internal display pipeline (hardware support for 12-bit scanout on supported
panels, applications and connection)
?
NVIDIA? 3D VisionTM technology, 3D DLP, Interleaved, and other 3D stereo format
support.
?
Full OpenGL quad buffered stereo support.
?
Support for large-scale, ultra-high resolution visualization using the NVIDIA? SVS
platform which includes NVIDIA? Mosaic, NVIDIA? Sync and NVIDIA? Warp/Blend
technologies.
?

Maximum number of displays

- 4 direct attached monitors

- 4 using DP 1.2a with MST and HBR2 enabled monitors
?
Maximum number of DisplayPort displays possible (may require MST and/or HBR2):

- 4 1920x1200

- 4 2560x1600

- 4 4096x2160

- 2 5120x2880 (requires dual DP input 5k displays)
?
Maximum number of monitors across all available Quadro M5000 outputs is 4.
?

Shader Model 5.0
OpenGL 4.5

DirectX 12
?
API support for NVIDIA's CUDATM C, CUDA C++, DirectCompute 5.0, OpenCL, Java, Python,

DA - 15077???Worldwide QuickSpecs ¡ª Version 37 ¡ª 7/8/2019

Page? 76

QuickSpecs

Technical Specifications - Graphics

HP Z440 Workstation

Fortran

?

?

NVIDIA?
Quadro? P4000
8GB Graphics
?

Available Graphics
Drivers

Notes

Form Factor

Graphics Controller

Microsoft Windows 10
Microsoft Windows 8.1
Microsoft Windows 8
Microsoft Windows 7
Linux - Full OpenGL implementation, complete with NVIDIA and ARB extensions
?
HP qualified drivers may be preloaded or available from the HP support Web site:

http://welcome.hp.com/country/us/en/support.html

?

1. Factory configured Quadro M5000 does not include a video cable adapter. Video cable
adapters must be ordered separately.

2. A total maximum of 4 active monitors are supported across all display output types.
This may be accomplished by using daisy chained DisplayPort 1.2 displays (displays must
support MST and HBR2).

3. Configurations of a single Quadro M5000 graphics card in HP Z440 Workstation require
the HP Z440 Fan and Front Card Guide Kit, configurable from the factory (CTO PN:
G8T99AV) or as an Aftermarket Option (AMO PN: J9P80AA).

Dimensions: 4.4"?H x 9.5"?L
Single-slot, full-height
Weight: 475 grams

NVIDIA? Quadro? P4000 Graphics Card
GPU: GP104 with 1792 CUDA cores
Power: 120 Watts
?

(without extender)

Bus Type
Memory

Connectors

Maximum
Resolution

PCI Express 3.0 x1
Size: 8GB GDDR5

Memory Bandwidth: 243 GB/s
Memory Width: 256-bit

4 x DisplayPort
3-pin mini-DIN connector via optional bracket
1 x 6-pin auxiliary power connector
4-pin header for stereo signal
SYNC connector for Quadro? Sync II
2 x SLI connectors
?
Factory Configured Option: No video cable adapter included
After Market Option: No video cable adapter included
?
Additional DisplayPort-to-VGA, DisplayPort-to-HDMI, or DisplayPort-to- DVI adapters are
available as accessories
?

Dual-link internal TMDS (DVI 1.0):

- up to 2560 x 1600 x 32 bpp @ 60 Hz
?
Single-link internal TMDS (DVI 1.0):

- up to 1920 x 1200 x 32 bpp @ 60 Hz
?
HDMITM 2.0b (requires DP to HDMI adapter):

6

1.4

DA - 15077???Worldwide QuickSpecs ¡ª Version 37 ¡ª 7/8/2019

Page? 77

QuickSpecs

Technical Specifications - Graphics

- up to 5120 x 2880 x 24 bpp @ 60Hz
?
DisplayPort:

- up to 4096 x 2160 x 30 bpp @ 60Hz

- up to 2560 x 1600 x 30 bpp @ 120 Hz

- supports High Bit Rate 2 (HBR2) and Multi-Stream Transport (MST)
?
Using two DP outputs, the P4000 can drive one dual DP input display with
5120 x 2880 x 30 bpp @ 60Hz resolution.

Image Quality
Features

Display Output

Shading
Architecture

Supported Graphics
APIs

Advanced support for 8-bit, 10-bit, and 12-bit per RGB color component.
HDCP 2.2 support over DisplayPort, DVI, and HDMI connectors
NVIDIA 3D VisionTM and other 3D stereo technologies
NVIDIA Mosaic and nView
?

Maximum number of displays

- 4 direct attached monitors
?
Maximum number of monitors across all available Quadro P4000 outputs is 4.

Shader Model 5.1

OpenGL 4.5
DirectX 12
Vulcan 1.0
?
API support includes:
CUDA C, CUDA C++, DirectCompute 5.0, OpenCL, Java, Python, and Fortran

HP Z440 Workstation

Available Graphics
Drivers

Notes

?

NVIDIA? Quadro? P5000 16GB Graphics
Form Factor

Full-Height Dual Slot (4.4"? Height x 10.5"? Length)
Weight: 815 grams / 1.80 lbs
?

Graphics Controller

QuadroTM P5000 graphics
GPU: 2560 NVIDIA CUDA? Parallel Processing Cores
Power: 180 Watts
Cooling: Active
?
?

Memory

16GB GDDR5X memory
Memory Bandwidth: Up to 288 GB/s

Microsoft Windows 10
Microsoft Windows 7
Linux - Full OpenGL implementation, complete with NVIDIA and ARB
extensions
?
HP qualified drivers may be preloaded or available from the HP support
Web site:
http://welcome.hp.com/country/us/en/support.html

??????

1.

Quadro P4000 offered as Factory Configured Option does not include a video cable adapter.

Video cable adapters must be ordered separately.

??????

2.

Quadro P4000 offered as an After Market Option does not include video cables. Video cable

adapters must be ordered separately.

DA - 15077???Worldwide QuickSpecs ¡ª Version 37 ¡ª 7/8/2019

Page? 78

QuickSpecs

HP Z440 Workstation

Technical Specifications - Graphics

Memory Width: 256 bit
ECC Memory (disabled by default)
?

Connectors

DP (x4) with HDR support
DL-DVI(D)
3-pin mini-DIN connector
SLI connector
Quadro Sync connector (compatible with Quadro II Sync)
One 8-pin auxiliary power connector
?
Factory configured option: No video cable adapter included with card.
After market option Kit: No video cable adaptor included with card.
?
DVI to VGA, DisplayPort to VGA, DisplayPort to DVI, and DisplayPort to Dual-Link DVI adapters available as accessories.
?

Maximum Resolution

5K support @ 60Hz
1x single-cable 5K monitor, or 2x dual-cable 5K monitors
?

Image Quality Features

Advanced support for 8-bit, 10-bit, and 12-bit per RGB color component.
HDCP 2.2 support over DisplayPort, DVI, and HDMI connectors
NVIDIA 3D VisionTM and other 3D stereo technologies
NVIDIA Mosaic and nView Desktop Management
?

Display Outputs

4x DP1.4 HDR outputs (up to 3840x2160 UHD @ 120Hz refresh, or up to 8K at 30Hz)
1x Dual-link DVI-D output (up to 2560 x 1600 @ 60 Hz and 1920x1200 @ 120 Hz)
?

GPU Architecture

NVIDIA Pascal

Supported Graphics APIs

DirectX?12 , OpenGL? 4.5, OpenCLTM 1.0, VulkanTM 1.0
Developer API support includes: CUDA C, CUDA C++, DirectCompute 5.0, OpenCL, Java, Python, and Fortran

Available Graphics Drivers

Windows? 10 64-bit
Windows? 7 64-bit
Linux 64-bit
?
HP qualified drivers may be preloaded or available from the HP support Web site:

http://welcome.hp.com/country/us/en/support.html

Notes

?????

1-

?????

2-

?????

3-

?

1

TM

Supports up to a total of 4 displays
For HP Z440 Workstations, the 700W power supply option must be used.
For HP Z840 Workstation configurations, the 1125W power supply option must be used for multiple P5000 configurations.

?
?

NVIDIA? Quadro?
K4200 4GB
Graphics

Form Factor

Weight:

Graphics Controller

DA - 15077???Worldwide QuickSpecs ¡ª Version 37 ¡ª 7/8/2019

Dimensions: 4.376"? H x 9.5"? L
Single Slot, Full Height
Cooling: Active

461 grams (without extender)

NVIDIA? Quadro? K4200
GPU: GK104-850 GPU with 1344 CUDA cores
Power: 108 Watts
?

Page? 79

QuickSpecs

Technical Specifications - Graphics

HP Z440 Workstation

Bus Type

Memory

Connectors

Maximum Resolution

Image Quality Features

Display Output

Shading Architecture

PCI Express 2.0 x16

?

Size: 4GB GDDR5
Memory Bandwidth: 173 GB/s
Memory Width: 256-bit
?

1 DL-DVI(I)
2 DisplayPort 1.2a
?
Factory Configured Option: No video cable adapter included
After market option kit: One DP-to-DVI adapter included with card
?
Additional DVI-to-VGA, DisplayPort-to-VGA or DisplayPort-to-DVI adapters are available
as accessories
?

DisplayPort:

- up to 3840 x 2160 x 30 bpp @ 60Hz

- supports High Bit Rate 2 (HBR2) and Multi-Stream Transport (MST)
?
DL-DVI(I) output:

- up to 2560 x 1600 x 32 bpp @ 60Hz
?
Single Link-DVI(I) output:

- up to 1920 x 1200 x 32 bpp @ 60Hz
?
VGA (via adapter cable):
?- 2048 ¡Á 1536 ¡Á 32 bpp at 85 Hz
?

10-bit internal display processing (hardware support for 10-bit scanout for both
windowed desktop and full screen, only available on Windows with Aero disabled and
Linux)
?
NVIDIA? 3D VisionTM technology, 3D DLP, Interleaved, and other 3D stereo format
support
?
Full OpenGL quad buffered stereo support
?
Support for large-scale, ultra-high resolution visualization using the NVIDIA? SVS
platform which includes NVIDIA? Mosaic, NVIDIA? Sync and NVIDIA? Warp/Blend
technologies
?

Maximum number of displays

- 3 direct attached monitors

- 4 using DP 1.2a with MST and HBR2 enabled monitors
?
Maximum number of DisplayPort displays possible (may require MST and/or HBR2):

- 4 1920x1200

- 4 2560x1600

- 2 3840x2160
?
Maximum number of monitors across all available Quadro K4200 outputs is 4.
?

Shader Model 5.0

?

DA - 15077???Worldwide QuickSpecs ¡ª Version 37 ¡ª 7/8/2019

Page? 80

QuickSpecs

Technical Specifications - Graphics

HP Z440 Workstation

Supported Graphics
APIs

Available Graphics
Drivers

Notes

OpenGL 4.4
DirectX 11.1
???????????????
API support includes:
CUDA C, CUDA C++, DirectCompute 5.0, OpenCL, Java, Python, and Fortran
?

Microsoft Windows 8.1
Microsoft Windows 8
Microsoft Windows 7
Linux - Full OpenGL implementation, complete with NVIDIA and ARB extensions
?
HP qualified drivers may be preloaded or available from the HP support Web site:

http://welcome.hp.com/country/us/en/support.html

?

1. Quadro K4200 offered as CTO does not include a video cable adapter. Video cable
adapters must be ordered separately.

2. Quadro K4200 offered as After Market Kits includes one DP-to-DVI video cable
adapter. Additional cables must be ordered separately.

3. A total maximum of 4 active monitors are supported across all display output types.
This may be accomplished by using daisy chained DisplayPort 1.2 displays (displays must
support MST and HBR2).

4. Configurations of a single Quadro K4200 graphics card in HP Z440 Workstation require
the HP Z440 Fan and Front Card Guide Kit, configurable from the factory (CTO PN:
G8T99AV) or as an Aftermarket Option (AMO PN: J9P80AA).

?

NVIDIA? Quadro? K5200
8GB Graphics

Form Factor

Weight:

Graphics Controller

Bus Type

Memory

Connectors

4.376"? H x 10.5"? L
Dual Slot

~880 grams

NVIDIA? Quadro? K5200
GK 110 GPU
2304 CUDA cores
Max Power: 150 Watts

PCI Express 3.0 x16

8GB GDDR5
256-bit memory I/O path
192 GB/s memory bandwidth

DVI-I (1), DVI-D (1), DP (2),
?
Factory configured option: No adapter included with card.
Option Kit: No adaptor included with card.
?
DVI to VGA, DisplayPort to VGA, DisplayPort to DVI, and DisplayPort to Dual­Link DVI adapters available as accessories.
?

Image Quality Features

DA - 15077???Worldwide QuickSpecs ¡ª Version 37 ¡ª 7/8/2019

DisplayPort with Multi-Stream Technology (MST) and High Bit Rate 2
(HBR2), HDMI 1.4, and HDCP support

NVIDIA 3D VisionTM technology

Page? 81

QuickSpecs

Technical Specifications - Graphics

HP Z440 Workstation

Display Output

Shading Architecture

Supported Graphics APIs

400 MHz integrated RAMDAC

Maximum resolution over VGA (through DVI to VGA cable): 2048 ¡Á

1536 ¡Á 32 bpp at 85 Hz
?
Dual-link internal TMDS (DVI 1.0)

Maximum resolution over digital port (single GPU and SLI mode): 2560

¡Á 1600 ¡Á 32 bpp at 60 Hz (reduced blanking)
?
Single-link internal TMDS (DVI 1.0)

Maximum resolution over digital port (single GPU and SLI mode):1920

¡Á 1200 ¡Á 32 bpp at 60 Hz (reduced blanking)
?
DisplayPort with MST and HBR2.

Maximum resolution: 4096 ¡Á 2160 ¡Á 30 bpp at 60Hz

Maximum resolution:2560 x 1600 x 30bpp at 120Hz
?
HDMI

Maximum resolution: 1920 ¡Á 1080 ¡Á 32 bpp at 60Hz
?

Shader Model 5.0
?

OpenGL 4.4
DirectX 11
API support for NVIDIA's CUDA TM C, CUDA C++, DirectCompute 5.0, OpenCL,
Java, Python, and Fortran
?

?

AMD FirePro
W7100 8GB
Graphics

Available Graphics Drivers

Notes

Form Factor

Weight:

Windows 8
Windows 7 Professional (64-bit and 32-bit)
Red Hat Enterprise Linux (RHEL) 6 Desktop/Workstation (64-bit)
SUSE Linux Enterprise Desktop 11 SP3(64-bit and 32-bit)
?

HP qualified drivers may be preloaded or available from the HP support Web
site:

http://welcome.hp.com/country/us/en/support.html

?

1.

NVIDIA GRID VGX Pass Through feature supported on NVIDIA? Quadro?

K5200 to enable direct mapping of GPU to Virtual Machine.

2.

No display output adapter included.

Full height, single slot (9.5"? X 4.376"?)
?

AMD FirePro W7100 graphics
GPU: 1792 Stream Processors organized into 28 Compute Units
Power: <75 Watts
Cooling: Active
?

Graphics Controller

DA - 15077???Worldwide QuickSpecs ¡ª Version 37 ¡ª 7/8/2019

PCI Express? x16, Generation 3.0
?

Page? 82

QuickSpecs

Technical Specifications - Graphics

HP Z440 Workstation

Bus Type

Memory

Connectors

8GB GDDR5 memory
Memory Bandwidth: up to 176 GB/s
Memory Width: 256 bit

?

4x Display Port 1.2a connectors with HBR2 and MST support.
?
Factory Configured: No video cable adapter included
After market option kit: No video cable adapter included
?
Additional DisplayPort-to-VGA or DisplayPort-to-DVI adapters are available as Factory
Configuration or Option Kit accessories.
?

DisplayPort:

- 4096x2160 @24bpp 60Hz
?
Dual Link DVI:

- 2560x1600 (requires DP to DL-DVI adapter)
?
Single Link DVI:

- 1920x1200 (requires DP to DVI adapter)
?
VGA:

- 1920x1200 (requires DP to VGA adapter)
?

Image Quality Features

Display Output

Shading Architecture

Supported Graphics
APIs

Available Graphics
Drivers

Advanced support for 8-bit, 10-bit, and 16-bit per RGB color component.
High bandwidth scaler for high quality up and downscaling
?

Max number of monitors supported using DisplayPort 1.2a:

- 4 direct attached monitors

- 6 using DP 1.2a with MST and HBR2 enabled monitors?
?
Monitor chaining from a single DisplayPort (subject to a max of 6 total monitors across all
outputs, requires use of DisplayPort enabled monitors supporting MST and HBR2):

- one 4096x2160 display

- two 2560x1600 displays

- four 1920x1200 displays
?

Shader Model 5.0
?

OpenGL 4.4
OpenCL 1.2 and 2.0
DirectX 11.2 / 12
AMD Mantle
?

Windows 8.1 / 8 (64-bit and 32-bit)
Windows? 7 (64-bit and 32-bit)
Linux
?
HP qualified drivers may be preloaded or available from the HP support Web site:

http://welcome.hp.com/country/us/en/support.html

?

Notes

1. AMD Eyefinity technology supports up to six DisplayPortTM monitors on an enabled

DA - 15077???Worldwide QuickSpecs ¡ª Version 37 ¡ª 7/8/2019

Page? 83

QuickSpecs

Technical Specifications - Graphics

?

RadeonTM Pro WX
7100 8GB Graphics

Form Factor
Graphics Controller

Memory

Connectors

Maximum Resolution

Image Quality
Features

Display Output

GPU Architecture
Supported Graphics

APIs

Available Graphics
Drivers

Notes

HP Z440 Workstation

graphics card. Supported display quantity, type and resolution vary by model and board
design; confirm specifications with manufacturer before purchase. To enable more than
two displays, or multiple displays from a single output, additional hardware such as
DisplayPort-ready monitors or DisplayPort 1.2 MST-enabled hubs may be required.? See
www.amd.com/eyefinityfaq for full details.

2. OpenGL 4.4 support available with driver 14.301.xxx or later.

3. OpenCL 2.0 support planned in driver updates for early 2015.

4. For HP Z440 Workstation configurations, the HP Z4 Fan and Front Card Guide Kit, which
is available both CTO (G8T99AV) and AMO (J9P80AA), is required.

Full-Height Single Slot (9.5"? Length )
RadeonTM Pro WX 7100 graphics

GPU: 2304 Stream Processors organized into 36 Compute Units
Power: 130 Watts
Cooling: Active
?

8GB GDDR5 memory
Memory Bandwidth: 7 Gbps / 224 GB/s
Memory Width: 256 bit
?

4x Display Port 1.4 - HDR ready connectors with HBR3 and MST support.
?
Factory Configured: No video cable adapter included
After market option kit: No video cable adapter included
?
Additional DisplayPort-to-VGA or DisplayPort-to-DVI adapters are available as Factory
Configuration or Option Kit accessories.
?

5K support @ 60Hz

1x single-cable 5K monitor, or 2x dual-cable 5K monitors

?
Advanced support for 8-bit, 10-bit, and 16-bit per RGB color component.?

High bandwidth scaler for high quality up and downscaling
?

4 full physical DP1.3 HBR3 / DP1.4 HDR outputs
FreeSync support
?

GCN 4th Generation
DirectX?12

OpenGL? 4.5
OpenCLTM 2.0
VulkanTM 1.0

Windows 10 64-bit
Windows? 7 64-bit
Linux 64-bit
?
HP qualified drivers may be preloaded or available from the HP support Web site:

http://welcome.hp.com/country/us/en/support.html

?

??????

4.

HDR content requires that the system be configured with a fully HDR-ready
content chain, including: graphics card, monitor/TV, graphics driver and
application. Video content must be graded in HDR and viewed with an HDR­ready
?player. Windowed mode content requires operating system support.

??????

5.

Radeon VR Ready Creator Products are select Radeon Pro and AMD FirePro
GPUs that meet or exceed the Oculus Rift or HTC Vive recommended
specifications for video cards/GPUs. Other hardware (including CPU) and

TM

DA - 15077???Worldwide QuickSpecs ¡ª Version 37 ¡ª 7/8/2019

Page? 84

QuickSpecs

HP Z440 Workstation

Technical Specifications - Graphics

system requirements recommended by Oculus Rift or HTC Vive should also
be met in order to operate the applicable HMDs as intended. As VR
technology, HMDs and other VR hardware and software evolve and/or
become available, these criteria may change without notice.

??????

6.

AMD PowerTune and AMD ZeroCore Power are technologies offered by
certain FireProTM and RadeonTM Pro products, which are designed to
intelligently manage GPU power consumption in response to certain GPU
load conditions.

??????

7.

As of September 2016, certified for DisplayPortTM 1.4 HBR3 and ready for
DisplayPortTM 1.4 HDR based on independent verification by DisplayPort
testing authority. HDR content requires that the system be configured with a
fully HDR-ready content chain, including: graphics card, monitor/TV,
graphics driver and application. Video content must be graded in HDR and
viewed with an HDR-ready player. Windowed mode content requires
operating system support.

?

NVIDIA? Quadro? P6000 24GB Graphics
Form Factor

Full-Height Dual Slot (4.4"? Height x 10.5"? Length)

Weight: 967 grams / 2.14 lbs

?

Graphics Controller

QuadroTM P6000 graphics
GPU: 3840 NVIDIA CUDA? Parallel Processing Cores
Power: 250 Watts
Cooling: Active
?
?

Memory

24GB GDDR5X memory
Memory Bandwidth: Up to 432 GB/s
Memory Width: 384 bit
ECC Memory (disabled by default)
?

Connectors

DP (x4) with HDR support
DL-DVI(I)
3-pin mini-DIN connector
SLI connector
Quadro Sync connector (compatible with Quadro II Sync)
One 8-pin auxiliary power connector
?
Factory configured option: No video cable adapter included with card.
After market option Kit: No video cable adaptor included with card.
?
DVI to VGA, DisplayPort to VGA, DisplayPort to DVI, and DisplayPort to Dual-Link DVI adapters available as accessories.
?

Maximum Resolution

5K support @ 60Hz
1x single-cable 5K monitor, or 2x dual-cable 5K monitors
?

Image Quality Features

Advanced support for 8-bit, 10-bit, and 12-bit per RGB color component.
HDCP 2.2 support over DisplayPort, DVI, and HDMI connectors
NVIDIA 3D VisionTM and other 3D stereo technologies
NVIDIA Mosaic and nView

Display Outputs

4x DP1.4 HDR outputs (up to 3840x2160 UHD @ 120Hz refresh, or up to 8K at 30Hz)
1x Dual-link DVI-D output (up to 2560 x 1600 @ 60 Hz and 1920x1200 @ 120 Hz)
?

GPU Architecture

1

TM

DA - 15077???Worldwide QuickSpecs ¡ª Version 37 ¡ª 7/8/2019

Page? 85

QuickSpecs

HP Z440 Workstation

Technical Specifications - Graphics

NVIDIA Pascal

Supported Graphics APIs

DirectX?12 , OpenGL? 4.5, OpenCLTM 1.0, VulkanTM 1.0
Developer API support includes: CUDA C, CUDA C++, DirectCompute 5.0, OpenCL, Java, Python, and Fortran

Available Graphics Drivers

Windows? 10 64-bit
Windows? 7 64-bit
Linux 64-bit
?
HP qualified drivers may be preloaded or available from the HP support Web site:

http://welcome.hp.com/country/us/en/support.html

Notes

1­2­3-

?

NVIDIA? Quadro? Sync II

TM

?????

Supports up to a total of 4 displays

?????

For HP Z440 Workstations, the 700W power supply option must be used.

?????

For HP Z840 Workstation configurations, the 1125W power supply option must be used for multiple P5000 configurations.

Part number
Dimensions (HxD)
Devices Supported

Bus Type
PCI Form Factor
Ports

Internal Connectors

1WT20AA

6.0 inches ¡Á 4.2 inches
NVIDIA? Quadro? P4000

NVIDIA? Quadro? P5000
NVIDIA? Quadro? P6000

Requires one free mechanical PCIe bus slot.
Full Height, half length, single slot
2 RJ45 connectors for carrying frame lock signals over CAT5 cables.

BNC Connector for external house synchronization.
6 NVIDIA SLI? style edge fingers for connection to compatible GPUs

6-pin PCI or SATA power connector

????????

ϒ⁄

????????

ϒ⁄

System Requirements

Temperature - Operating
Temperature - Storage
Relative Humidity -

Operating
Power Requirements
Operating Systems

Supported

Kit Contents

Included with the board are 4

GPU's

Included with the board are 2

GPU's
Requires one free mechanical PCIe bus slot.

Must be used with NVIDIA Quadro P4000, P5000 or P6000 graphics cards.
Requires Quadro driver version

0¡ã to 55¡ã C

-40¡ã to 60¡ã C
10% to 80%

?
Board power dissipation:
Windows 10 64-bit

Windows 7 64-bit
Linux 64-bit

Contains:

Quadro Sync II Card
4 x 12-Inch Short Sync Cables
2 x 24-Inch Long Sync Cables (Two)
Quick Start Guide

<15W

12-Inch Short Sync Cables

24-Inch Long Sync Cables

6-pin PCI or SATA power connector

R375

or later.

to connect to

to connect to

?
?

DA - 15077???Worldwide QuickSpecs ¡ª Version 37 ¡ª 7/8/2019

Page? 86

QuickSpecs

Technical Specifications ¨C Optical and Removable Storage

?

Optical and Removable Storage

wwidth="710"ass="MsoNormalTable" cellPadding="0" width="720" border="0">

HP 9.5mm Slim DVD Writer
Description

9.5mm height, tray-load

Mounting Orientation

Either horizontal or vertical

Interface Type

SATA/ATAPI

Dimensions

128 x 9.5 x 127mm

Supported Media Types

DVD+R
DVD+RW
DVD+R DL
DVD-R DL
DVD-R
DVD-RW
CD-R
CD-RW
?

Disc Capacity

DVD-ROM

8.5 GB DL or 4.7 GB standard
Full Stroke DVD
< 200 ms (seek)
Full Stroke CD
< 200 ms (seek)

Maximum Data Transfer Rates

CD ROM Read
CD-ROM, CD-R? Up to 24X
CD-RW? Up to 24X
?
DVD ROM Read
DVD+RW? Up to 8X
DVD-RW? Up to 8X
DVD+R DL? Up to 8X
DVD-R DL? Up to 8X
DVD-ROM? Up to 8X
DVD-ROM DL? Up to 8X
DVD+R? Up to 8X
DVD-R? Up to 8X
?

Power

Source
SATA DC power receptacle
DC Power Requirements
5 VDC ¡À 5%-100 mV ripple p-p
DC Current
5 VDC -< 800 mA typical, <1600 mA maximum

Operating Environmental

Temperature

(WxHxD)

(all conditions non-condensing)

HP Z440 Workstation

DA - 15077???Worldwide QuickSpecs ¡ª Version 37 ¡ª 7/8/2019

Page? 87

QuickSpecs

HP Z440 Workstation

Technical Specifications ¨C Optical and Removable Storage

41¡ã to 122¡ã F (5¡ã to 50¡ã C)
Relative Humidity
10% to 80%
Maximum Wet Bulb Temperature
84¡ã F (29¡ã C)

Operating Systems Supported

Windows 10, Windows 7 Professional 32-bit and 64-bit,
Windows Vista Business 64*, Windows Vista Business 32*, Windows Vista Home Basic 32*, Windows 2000, Windows XP Professional
or Windows XP Home 32*.
Red Hat Enterprise Linux(RHEL) WS4**, 5, 6 Desktop/Workstation
SUSE Linux Enterprise Desktop 10 & 11
?

* No driver is required for this device. Native support is provided by the operating system.

Kit Contents

HP SATA DVD Writer drive, installation guide.

?

wwidth="710"ass="MsoNormalTable" cellPadding="0" width="720" border="0">

HP 9.5mm Slim DVD-ROM Drive
Description

9.5mm height, tray-load

Mounting Orientation

Either horizontal or vertical

Interface Type

SATA / ATAPI

Dimensions

128 x 9.5 x 127mm

Disc Capacity

DVD-ROM
Single layer: Up to 4.7 GB
Double layer: Up to 8.5 GB
?

Access Times

DVD-ROM Single Layer
< 110 ms (typical)
CD-ROM Mode 1
< 110 ms (typical)
Full Stroke DVD
< 230 ms (typical)
Full Stroke CD
< 220 ms (typical)

Power

Source
SATA DC power receptacle
DC Power Requirements
5 VDC ¡À 5%-100 mV ripple p-p
DC Current
5 VDC - <800mA typical, < 1600 mA maximum

Operating Environmental

Temperature
41¡ã to 122¡ã F (5¡ã to 50¡ã C)
Relative Humidity
10% to 80%
Maximum Wet Bulb Temperature
84¡ã F (29¡ã C)

Operating Systems Supported

Windows 8.1, Windows 8 32-bit and 64-bit, Windows 7 Professional 32-bit and 64-bit,

(WxHxD)

(all conditions non-condensing)

DA - 15077???Worldwide QuickSpecs ¡ª Version 37 ¡ª 7/8/2019

Page? 88

QuickSpecs

HP Z440 Workstation

Technical Specifications ¨C Optical and Removable Storage

Windows Vista Business 64*, Windows Vista Business 32*, Windows Vista Home Basic 32*, Windows 2000, Windows XP Professional
or Windows XP Home 32*.
Red Hat Enterprise Linux(RHEL) WS4**, 5, 6 Desktop/Workstation
SUSE Linux Enterprise Desktop 10 & 11
?
No driver is required for this device. Native support is provided by the operating system.
?

Kit Contents

9.5mm Slim DVD-ROM Drive, 5.25" ODD Bay adapter/carrier, slim SATA data/power cable, installation guide

?

wwidth="710"ass="MsoNormalTable" cellPadding="0" width="720" border="0">

HP 9.5mm Slim BDXL Blu-Ray Writer
Description

9.5mm height, tray-load

Mounting Orientation

Either horizontal or vertical

Interface Type

SATA/ATAPI

Dimensions

128 x 9.5 x 127mm

Supported Media Types

BD-ROM
BD-R
BD-RE
DVD-RAM
DVD+R
DVD+RW
DVD+R DL
DVD-R DL
DVD-R
DVD-RW
CD-R
CD-RW
?

Disc Capacity

DVD-ROM

8.5 GB DL or 4.7 GB standard
Blu-ray
25 GB (single-layer)
50 GB (dual-layer)
100/128 GB (BDXL)
Full Stroke DVD
< 230 ms (seek)
Full Stroke CD
< 220 ms (seek)
Blu-ray
< 230 ms (seek) (Full Stroke Blu-ray)
Startup Time
(Time to drive ready from tray loading)
BD-ROM (SL/DL)????? 25S / 28S
BD-R (SL/DL)??????? 25S / 28S
BD-RE (SL/DL)?????? 25S / 28S
DVD-ROM (SL/DL)???? 18S / 18S
DVD-R (SL/DL)?????? 25S / 25S
DVD-RW????????????? 25S
DVD+R (SL/DL)?????? 25S / 25S

(WxHxD)

DA - 15077???Worldwide QuickSpecs ¡ª Version 37 ¡ª 7/8/2019

Page? 89

QuickSpecs

HP Z440 Workstation

Technical Specifications ¨C Optical and Removable Storage

DVD+RW????????????? 25S
DVD-RAM???????????? 45S
CD-ROM????????????? 15S
?

Maximum Data Transfer Rates

CD ROM Read
CD-ROM, CD-R? Up to 24X
CD-RW? Up to 24X
DVD ROM Read
DVD-RAM? Up to 8X
DVD+RW? Up to 8X
DVD-RW? Up to 8X
DVD+R DL? Up to 8X
DVD-R DL? Up to 8X
DVD-ROM? Up to 8X
DVD-ROM DL? Up to 8X
DVD+R? Up to 8X
DVD-R? Up to 8X
Blu-ray
BD-ROM? Up to 6X
BD-ROM DL??? Up to 6X
BD-R???????? Up to 6X
BD-R DL????? Up to 6X
BD-R???????? Up to 6X
BD-RE SL/DL? Up to 6X
?

Power

Source
SATA DC power receptacle
DC Power Requirements
5 VDC ¡À 5%-100 mV ripple p-p
DC Current
5 VDC -900 mA typical, 2000mA maximum

Operating Environmental

Temperature
41¡ã to 122¡ã F (5¡ã to 50¡ã C)
Relative Humidity
10% to 80%
Maximum Wet Bulb Temperature
84¡ã F (29¡ã C)

Operating Systems Supported

Windows 8.1, Windows 8 32-bit and 64-bit, Windows 7 Professional 32-bit and 64-bit,
Windows Vista Business 64*, Windows Vista Business 32*, Windows Vista Home Basic 32*, Windows 2000, Windows XP Professional
or Windows XP Home 32*.
Red Hat Enterprise Linux(RHEL) WS4**, 5, 6 Desktop/Workstation
SUSE Linux Enterprise Desktop 10 & 11
?
No driver is required for this device. Native support is provided by the operating system.
?

?
Kit Contents

9.5mm Slim BDXL Blu-Ray Writer, 5.25" ODD Bay adapter/carrier, slim SATA data/power cable, installation guide
?
As Blu-ray is a new format containing new technologies, certain disc, digital connection, compatibility and/or performance issues
may arise, and do not constitute defects in the product. Flawless playback on all systems is not guaranteed. In order for some Blu­ray titles to play, they may require a DVI or HDMI digital connection and your display may require HDCP support. HD-DVD movies
cannot be played on this workstation.

(all conditions non-condensing)

DA - 15077???Worldwide QuickSpecs ¡ª Version 37 ¡ª 7/8/2019

Page? 90

QuickSpecs

Technical Specifications ¨C Optical and Removable Storage

?

wwidth="710"ass="MsoNormalTable" cellPadding="0" width="720" border="0">

HP DX115 Removable Drive Enclosure
Interface Type

Compatible with SAS or SATA controllers.? Offers 6Gb/s performance when used with 6Gb/s HDDs.

Dimensions

147.6mm W x 41.1mm H x 205mm D
(5.81"? W x 1.62"? H x 8.08"? D)

Approvals

Frame and Carrier: 1.73 kg (3.8 lbs.)
Carrier: 0.45 kg (1 lbs.)

?

HP 15-in-1 Media Card
Reader

?

(WxHxD)

Description

Interface Type

Dimensions

Supported Media Types

Operating Systems
Supported

(WxHxD)

Supports hardware ECC (Error Correction Code) function
Supports hardware CRC (Cyclic Redundancy Check) function
Supports MS 4-bit parallel transfer mode
Supports MS-PRO 4-bit parallel transfer mode
Supports MS PRO-HG Duo 4-bit parallel transfer mode
Supports SD 4-bit parallel transfer mode
Supports UHS-104 SD 4-bit card (version 3.0)
Supports CF v6.0 with PIO mode 6 and Ultra DMA 7 mode

USB 3.0 High-speed interface

Note:

If there is a USB2 connection, USB2 transfer speeds are supported.

4.9 x 4 x 1 in (124.5 x 101.6 x 25.4 mm) Fits conveniently in the 5.25" drive
bay.

CompactFlash Type I
CompactFlash Type II
Microdrive
Secure Digital Card (SD)
Secure Digital High Capacity (SDHC)
SD Extended Capacity Memory Card (SDXC)
SD Ultra High Speed II(SD UHSII)
Memory Stick
Memory Stick Select
Memory Stick Duo (MS Duo)
Memory Stick PRO (MS PRO)
Memory Stick PRO Duo (MS PRO Duo)
Memory Stick PRO-HG Duo
MagicGate Memory Stick (MG)
MagicGate Memory Stick Duo
?
These additional media types are supported with a card adapter.
Memory Stick Micro (M2)
miniSD
miniSD High Capacity
Micro SD Memory Card (MicroSD)
Micro SD High Capacity Memory Card (MicroSDHC)
?

Test Parameters/Conditions - Power applied, unit operating on system ¡À5%

Windows 8 Pro (64-bit)*
Windows 8.1 (64-bit)*
Windows 8 (64-bit)*
Windows 7 Ultimate (32-bit)**
Windows 7 Ultimate (64-bit)**
Windows 7 Professional (32-bit)**
Windows 7 Professional (64-bit)**

HP Z440 Workstation

DA - 15077???Worldwide QuickSpecs ¡ª Version 37 ¡ª 7/8/2019

Page? 91

QuickSpecs

Technical Specifications ¨C Optical and Removable Storage

Windows 7 Home Basic**
Windows 7 Home Premium (32-bit)**
Windows 7 Home Premium (64-bit)**
Windows Vista Business 64
Windows Vista Business 32
Windows Vista Home Basic 32
Windows XP Professional
Windows XP Home 32
?
No driver is required for this device. Native support is provided by the
operating system.
?
Not all features are available in all editions of Windows 8. Systems may
require upgraded and/or separately purchased hardware, drivers and/or
software to take full advantage of Windows 8 functionality. See

http://www.microsoft.com

Not all features are available in all editions of Windows 7. This system may
require upgraded and/or separately purchased hardware to take full
advantage of Windows 7 functionality.
See

http://www.microsoft.com/windows/windows-7/

?

?

?

?

Kit Contents

Approvals

Weight

Media card reader, 5.25" bracket/rails/bezel, Install Guide, IO & Security
Software and Documentation CD

USB-IF, WHQL, Compliant with USB Mass Storage Class Bulk only Transport
Specification Rev. 1.0,
Compliant Intel Front Panel I/O Connectivity Design Guide V. 1.3, FCC, CE,
BSMI, C-Tick, VCCI, MIC, cUL, TUVT
?

0.35 lbs. (0.16 kg)

HP Z440 Workstation

.

for details.

DA - 15077???Worldwide QuickSpecs ¡ª Version 37 ¡ª 7/8/2019

Page? 92

QuickSpecs

Technical Specifications - Controller Cards

Controller Cards

HP Z440 Workstation

HP IEEE 1394b FireWire
PCIe Card

?

HP Thunderbolt-2 PCIe 1­port I/O Card

Data Transfer Rate
Devices Supported
Bus Type
Ports
Internal Connectors
System Requirements

Temperature - Operating
Temperature - Storage
Relative Humidity -

Operating
Compliances

Operating Systems
Supported

Data Transfer Rate
Devices Supported
Bus Type
Ports

Internal Connectors
System Requirements

Temperature - Operating
Temperature - Storage
Relative Humidity -

Operating
Compliances

Operating Systems
Supported

Kit Contents

Supports up to 800 Mb/s
IEEE-1394 compliant devices
PCIe card full height PCIe slots
Two IEEE-1394b external 9-Pin connectors (Rear)
One 10-Pin header connector
Windows 8.1 64-bit, Windows 7 Professional 32-bit and 64-bit, SLED 11 and

RHEL 6. Intel i5 series or higher processor, min 2GB of RAM, 20GB Hard
Drive, CD-ROM drive, built in sound system, Available PCIe slot.

50¡ã to 131¡ã F (10¡ã to 55¡ã C)

-22¡ã to 140¡ã F (-30¡ã to 60¡ã C)
20% to 80%

FCC Part 15B, cULus 60950, CE Mark EN55022B(1995)/EN55024-1998 STD,
Taiwan BSMI CNS13438, Korea MIC

Windows 8.1 64-bit, Windows 7 Professional 32-bit and 64-bit

Supports up to 20 Gb/s (20,000 Mb/s)
ThunderboltTM certified devices
PCIe card, full or half height PCIe slots
One ThunderboltTM 2 external 20-Pin output connectors (Rear)

One full size DisplayPort input connector (Rear)
One 5-Pin header connector
Genuine Windows 7 Professional 64-bit, Genuine Windows 8.1 64-bit, Intel

i5 series or higher processor, 4-GB RAM, 20-GB Hard Drive, available PCIe
slot.

50¡ã to 131¡ã F (10¡ã to 55¡ã C)

-22¡ã to 140¡ã F (-30¡ã to 60¡ã C)
20% to 80%

FCC Part 15B, cULus 60950, CE Mark EN55022B(1995)/EN55024-1998 STD,
Taiwan BSMI CNS13438, Korea MIC

Genuine Windows 7 Professional 64-bit, Genuine Windows 8.1 64-bit.

HP ThunderboltTM 2 PCIe 1-port I/O Card, full height and half height
bracket, DisplayPort to DisplayPort cable, internal header cables (2), user
documentation and warranty card.

DA - 15077???Worldwide QuickSpecs ¡ª Version 37 ¡ª 7/8/2019

Page? 93

QuickSpecs

Technical Specifications - Networking and Communications

Networking and Communications

HP Z440 Workstation

Integrated Intel I218LM
PCIe GbE Controller

Connector
Controller
Memory
Data Rates Supported
Compliance

Bus Architecture
Data Transfer Mode

Power Requirement
Boot ROM Support
Network Transfer Mode
Network Transfer Rate

Management Capabilities

RJ-45 (motherboard integration)
Intel I218LM GbE platform LAN connect networking controller
3 KB FIFO packet buffer memory (both Tx and Rx)
10/100/1000 Mbps

802.1as, 802.1p, 802.1Q, 802.3, 802.3ab, 802.3az, 802.3i, 802.3u, 802.3x,

802.3z
PCI Express 1.1 (x1) and SMBus
PCIe-based interface for active state operation (S0 state) and SMBus for host

and management traffic (Sx low power state)
Requires 3.3V only (integrated regulators)
Yes
Full-duplex; Half-duplex (not supported for the 1000BASE-T transceiver)
10BASE-T (half-duplex) 10 Mbps

10BASE-T (full-duplex) 20 Mbps
100BASE-TX (half-duplex) 100 Mbps
100BASE-TX (full-duplex) 200 Mbps
1000BASE-T (full-duplex) 2000 Mbps

WOL, auto MDI crossover, PXE, Muti-port teaming, RSS, Advanced cable
diagnostics
AMT 9.1 support, vPro compliant

?

HP X520 10GbE Dual Port
Adapter

?

HP 10GbE SFP+ SR
Transceiver

?

Hardware Certifications

Operating Temperature
Operating Humidity
Dimensions

(H x W x D)

FCC B, UL, CE, VCCI, BSMI, CTICK, KCC

0¡ãC to 45¡ãC (32¡ãF to 113¡ãF)
0% to 85%, noncondensing

0.47(h) x 0.54(w) x 2.19(d)inches
(1.19 x 1.38 x 5.57 cm)

DA - 15077???Worldwide QuickSpecs ¡ª Version 37 ¡ª 7/8/2019

Page? 94

QuickSpecs

Technical Specifications - Networking and Communications

HP Z440 Workstation

HP 361T PCIe Dual Port
Gigabit NIC

Connector
Controller
Data Rates Supported
Compliance

Data Path Width
Power Requirement

Network Transfer Rate

Operating Temperature
Operating Humidity
Dimensions
Operating System Driver

Support

Kit Contents

(H x W x D)

Two RJ-45
Intel? Ethernet I350 Controller
10/100/1000 Mbps, Half- and full-duplex

802.3, 802.3u, 802.3x, 802.3ab, 802.3ad, 802.1p, 802.1Q, 802.3az, IEEE 1588
PCIe v2.0 standard
RoHS (6 of 6)
FCC (U.S. only) Class B
DOC (Canada) Class B
CE EN 55024, EN55022 Class B
VCCI Class II
UL 1950
CSA 950
EN 60950
CE
ACPI 1.1a
Microsoft WHQL (Windows Hardware Quality Labs)

Four lane (x4) PCI Express compatible with x4, x8, and x16 PCI Express slots

4.1W idle without EEE link partner

3.2W idle with EEE link partner

4.2W maximum
10BASE-T (half-duplex) 10 Mb/s

10BASE-T (full-duplex) 20 Mb/s
100BASE-TX (half-duplex) 100 Mb/s
100BASE-TX (full-duplex) 200 Mb/s
1000BASE-T (full-duplex) 2000 Mb/s

32¡ã to 131¡ãF (0¡ã to 55¡ã C)
10% to 95% non-condensing

5.3 x 2.5 in (13.50 cm x 6.4 cm) (without brackets)
Windows 7 Professional 32-bit and 64-bit.

Red Hat Enterprise Linux(RHEL) WS4, 5, 6 Desktop/Workstation
Novell SLED 10 & SLED 11

HP 361T PCIe Dual Port Gigabit NIC PCA with a standard height bracket
attached to it (the low profile bracket is included in the clamshell that the PCA
ships in)
Product Warranty statement and the Quick Install Card (QIC).

?

DA - 15077???Worldwide QuickSpecs ¡ª Version 37 ¡ª 7/8/2019

Page? 95

QuickSpecs

Technical Specifications - Networking and Communications

HP Z440 Workstation

Intel Ethernet I350-T2 2­Port 1Gb NIC

Connector
Controller
Data Rates Supported
Compliance

Data Path Width
Power Requirement

Network Transfer Rate

Operating Temperature
Operating Humidity
Dimensions
Operating System Driver

Support

Kit Contents

(H x W x D)

Two RJ-45
Intel? Ethernet I350 Controller
10/100/1000 Mbps, Half- and full-duplex

802.3, 802.3u, 802.3x, 802.3ab, 802.3ad, 802.1p, 802.1Q, 802.3az, IEEE 1588
PCIe v2.1 standard
RoHS (6 of 6)
FCC (U.S. only) Class B
DOC (Canada) Class B
CE EN 55024, EN55022 Class B
VCCI Class II
UL 1950
CSA 950
EN 60950
CE
ACPI 1.1a
Microsoft WHQL (Windows Hardware Quality Labs)
?

Four lane (x4) PCI Express compatible with x4, x8, and x16 PCI Express slots

4.1W idle without EEE link partner

3.2W idle with EEE link partner

4.2W maximum
?

10BASE-T (half-duplex) 10 Mb/s
10BASE-T (full-duplex) 20 Mb/s
100BASE-TX (half-duplex) 100 Mb/s
100BASE-TX (full-duplex) 200 Mb/s
1000BASE-T (full-duplex) 2000 Mb/s
?

32¡ã to 131¡ã F (0¡ã to 55¡ã C )
10% to 95% non-condensing

5.3 x 2.5 in (13.50cm x 6.4 cm) (without brackets)
Windows 7 32-bit and 64-bit; Windows 10 32-bit and 64-bit; Red Hat

Enterprise Linux(RHEL) WS4, 5, 6 Desktop/Workstation
Novell SLED 10 & SLED 11
?

Intel I350-T2 PCIe Dual Port Gigabit NIC PCA with a standard height bracket
attached to it (the low profile bracket is included in the clamshell that the PCA
ships in)
Product Warranty statement and the Installation Guide.

?

DA - 15077???Worldwide QuickSpecs ¡ª Version 37 ¡ª 7/8/2019

Page? 96

QuickSpecs

Technical Specifications - Networking and Communications

HP Z440 Workstation

Intel Ethernet I350-T4 4­port 1Gb NIC

Connector
Controller
Data Rates Supported
Compliance

Data Path Width
Power Requirement

Network Transfer Rate

Operating Temperature
Operating Humidity
Dimensions
Operating System Driver

Support

Kit Contents

(H x W x D)

Four RJ-45
Intel? Ethernet I350 Controller
10/100/1000 Mbps, Half- and full-duplex

802.3, 802.3u, 802.3x, 802.3ab, 802.3ad, 802.1p, 802.1Q, 802.3az, IEEE 1588
PCIe v2.1 standard
RoHS (6 of 6)
FCC (U.S. only) Class B
DOC (Canada) Class B
CE EN 55024, EN55022 Class B
VCCI Class II
UL 1950
CSA 950
EN 60950
CE
ACPI 1.1a
Microsoft WHQL (Windows Hardware Quality Labs)
?

Four lane (x4) PCI Express compatible with x4, x8, and x16 PCI Express slots

5.0W (typical)
?

10BASE-T (half-duplex) 10 Mb/s
10BASE-T (full-duplex) 20 Mb/s
100BASE-TX (half-duplex) 100 Mb/s
100BASE-TX (full-duplex) 200 Mb/s
1000BASE-T (full-duplex) 2000 Mb/s
?

32¡ã to 131¡ã F (0¡ã to 55¡ã C )
10% to 95% non-condensing

5.3 x 2.5 in (13.50cm x 6.4 cm) (without brackets)
Windows 7 32-bit and 64-bit; Windows 10 32-bit and 64-bit; Red Hat

Enterprise Linux(RHEL) WS4, 5, 6 Desktop/Workstation
Novell SLED 10 & SLED 11

Intel I350-T4 PCIe Quad Port Gigabit NIC PCA with a standard height bracket
attached to it (the low profile bracket is included in the clamshell that the PCA
ships in)
Product Warranty statement and the Installation Guide.
?

?

DA - 15077???Worldwide QuickSpecs ¡ª Version 37 ¡ª 7/8/2019

Page? 97

QuickSpecs

Technical Specifications - Networking and Communications

HP Z440 Workstation

Intel 7260 802.11
a/b/g/n PCIe WLAN NIC

?

Intel 8260 802.11 a/b/g/n/ac
with Bluetooth 4.2 PCIe NIC

Operating Humidity

Dimensions

Kit Contents

Notes

(H x W x D)

Operating Temperature
Operating Humidity

Kit Contents

Operating??????? 10% to 90% (non-condensing)
Non-operating?? 5% to 95% (non-condensing)

Native HMC: 26.8 x 30.0 x 2.4 mm
Carrier Card Assembly 3.3 x 4.7 in (84 x 119 mm)

PCIe x1 card with full height bracket, rf antenna, antenna cable, separate
low profile bracket, software CD and warranty.

??????

1.

WLAN supplier's client utility is required for Cisco Compatible
Extensions support with Microsoft Windows XP. WLAN may also
be compatible with certain third-party software supplicants.
WLAN supplier IHV extensions required for Cisco Compatible
Extensions support for Microsoft Windows Vista.

??????

2.

Check latest software/driver release for updates on supported
security features.

??????

3.

Maximum output power may vary by country according to local
regulations.

??????

4.

In Power Save Polling mode and on battery power.

??????

5.

Receiver sensitivity is measured at a packet error rate of 8% for

802.11b (CCK modulation) and a packet error rate of 10% for

802.11a/g (OFDM modulation).

0 to 80 C
Non-operating?? 50% to 90% RH non-condensing (at

temperatures of 25C to 35C)
WLAN module with PCIe x1 card, Dual band antenna, USB

cable for internal Bluetooth connection, installation guide,
warranty card

?
?

DA - 15077???Worldwide QuickSpecs ¡ª Version 37 ¡ª 7/8/2019

Page? 98

QuickSpecs

Summary of Changes

Summary of Changes

HP Z440 Workstation

Date of change:

August 21, 2014
October 1, 2014

December 3, 2014

January 1, 2015

February 1, 2015

March 1, 2015

April 1, 2015

May 1, 2015

July 1, 2015

August 1, 2015

September 1, 2015

November 1, 2015

Version History:

V1
From v1 to v2

From v2 to v3

From v3 to v4

From v4 to v5

From v5 to v6

From v6 to v7

From v7 to v8

From v8 to v9

From v9 to v10

From v10 to v11

From v11 to v12

?

Added
Added

Changed

Removed

Added

Added

Added

Changed
Added

Changed

Changed

Added
Added
Changed

Added

Changed
Removed
Added

Changed

Removed

Added

Changed

Removed
Added

Description of change:

Style and technical specifications
Rack dimensions, note to supported components: memory, Foxit
PhantomPDF Express and Cyberlink Power2Go: software, Optical drives:
DVD, BD-XL specs
Turbo specs for E5-1660v3, Acoustics - only 1 ODD on the high-end
config, not 2, Declared Noise Emissions section, Supported Components:
Graphics, Optical and Removable Storage, Overview, Stable & Consistent,
power supply configurations, Noise Emissions section, Updated Power
Supply Configurations and table
Cyberlink MediaSuite, TPM 2.0 references, HP Power Assistant and PDF
Complete
HP Z440 Memory Cooling Solution, power cable descriptor in Overview
and System Technical Specifications sections
OS under Overview, and Support Components, Memory support matrix
and load order
AMD W5100, W7100 GPU,
SATA 6Gb/s SED OPAL 2 SSD from Supported Components
Internal I/O USB, OS under overview, and Supported components.
Operating Systems: Red Hat and SUSE Support, 600 and 300GB SAS SFF
HDD, 4TB SATA HD, HD Controller
HP Installer Kit for Linux, RAID, SAS and SATA Hard Drives Notes, ACPI
support under BIOS section
Hard Drives Notes and Memory Notes in Supported Components section.
Memory Speed Supported in System Board. Memory Info from System
Configuration.
Chassis Dimensions
Integrated RAID for PCIe SSDs and note in Hard Drive Controllers section
Notes in Hard Drive Controllers sections, High Performance GPU
Computing, and Other Hardware
1TB SATA 7200 rpm 8GB 3.5" SSHD (hybrid), HP Z Turbo Drive G2 512GB
SSD, HP Z Turbo Drive G2 256GB SSD, and notes for Supported
Components and Technical Specifications; 3Dconnexion CADMouse to
Input Devices.
Storage/Hard Drives section Descriptions/Notes
600GB SAS 15K rpm 6Gb/s 3.5" HDD, 300GB SAS 15K rpm 6Gb/s 3.5" HDD
Windows 10 64-bit, SUSE Linux Enterprise Desktop 11 SP3, 12 in OS,
Overview; NVIDIA NVS 310 1GB Graphics in Professional 2D; NVIDIA?
Quadro? K420 2GB Graphics in Entry 3D Graphics section; Intel Xeon E5­1630 v3 in Stable and consistent offerings in Stable and consistent
offerings
HP Solenoid Hood Lock & Hood Sensor in Supported Components, Racking
and Physical Security section; Intel Xeon E5-1603 v3
Windows 8.1 64-bit, Windows 8.1 Emerging Market, SUSE Linux Enterprise
Desktop 11 SP3
HP 512GB SATA SED SSD in Supported Components, Storage and Technical
Specifications
Notes for SATA SSDs, and PCI Express in Supported Components, HP
Solenoid Hood Lock & Hood Sensor in Racking and Physical Security,
Notes for Memory Cooling Solution in Other Hardware
Intel Pro 1500 180GB SATA SSD
Storage PCIe notes, HP Z Turbo Drive Quad Pro, 256GB, and 512GB SSD
modules, NVIDIA? Quadro? M4000 8GB Graphics, NVIDIA? Quadro? M5000

DX115 Removable HDD Frame/Carrier, 256GB

DA - 15077???Worldwide QuickSpecs ¡ª Version 37 ¡ª 7/8/2019

Page? 99

QuickSpecs

Summary of Changes

January 1, 2016
February 1, 2016

March 1, 2016

March 31, 2015

June 7, 2016

July 1, 2016
September 1, 2016
October 1, 2016

November 1, 2016

January 1, 2017

February 1, 2017
March 1, 2017
April 1, 2017

April 14, 2017

May 1, 2017

May 1, 2017

From v12 to v13
From v13 to v14

From v14 to v15

From v15 to v16

From v16 to v17

From v17 to v18
From v18 to v19
From v19 to v20

From v20 to v21

From v21 to v22

From v22 to v23
From v23 to v24
From v24 to v25

From v25 to v26

From v26 to v27

From v27 to v28

Changed

Added
Added

Changed
Removed

Added

Removed

Added

Changed

Added

Removed
Added
Added
Added

Removed
Added

Changed
Removed
Added

Changed
Added
Added

Changed

Removed

Added
Changed

Added

Changed

HP Z440 Workstation

8GB Graphics, Z440 HP Z Cooler and notes from Other Hardware section;
Controller Cards section notes; HP Remote Graphics Software (RGS) 7.1,
MS Office Home & Business 2016 from Software section; Windows 10 Pro
64 and Windows 10 Pro downgrade to Windows 7 Professional 64 from
Operative Systems section.
Updated Preinstalled OS in Overview section
HP Enterprise Class 240GB SATA SSD and HP Enterprise Class 480GB SATA
SSD, NVIDIA? Quadro? K1200 4GB Graphics, HP PS/2 Business Slim
Keyboard, HP USB Business Slim Keyboard, HP Wireless Business Slim
Keyboard
SATA SSDs notes
Samsung Enterprise 240GB SATA SSD, Samsung Enterprise 480GB SATA
SSD, NVIDIA? Quadro? K5200 8GB Graphics, NVIDIA? Quadro? K6000 12GB
Graphics.
Windows 10 Home 64 High-end in Overview and Supported Components;
AMD FirePro W4300 4GB Graphics in Mid-Ranga Category, Intel 8260

802.11 a/b/g/n/ac with Bluetooth 4.2 PCIe NIC in Networking and
Communications
Ubuntu 14.04, and Windows 8.1 64-bit from Overview OS; NVIDIA NVS 310
512MB Graphics, NVIDIA? Quadro? K420 1GB Graphics in Graphics
Intel Xeon E5-2600 v3 Series CPUs, HP Z Turbo Drive G2 1TB SSD, Intel
Ethernet I350-T2 2-Port 1Gb NIC
AMD FirePro W2100 2GB Graphics moved to Entry 3D; PCIe Drives and
Memory notes; HP Solenoid Hood Lock & Hood Sensor option.
Enterprise Class status for4TB SATA HDD, HP USB Hardened Mouse, Intel
Xeon E5-1600 v4 Series CPU, Note 6 for NVIDIA? Quadro? M2000
Windows 8.1 Pro Downgrade to Windows 7 Professional 64-bit
HP Keyed Cable Lock 10mm
Z Turbo SED, and notes for PCIe SSDs, Specs for SATA SSDs
Intel 750 Series PCIe SSDs, Added Z Turbo TLC SSDs, Added 1TB Enterprise
HDD
OS options, Xeon v3 processors, 4GB 2133 DIMMs
1TB SATA 7200 rpm HDD (Enterprise Class), HP Z Turbo and Z Turbo Quad
Pro SSD Drives
PCIe drives note
Intel Xeon v3 processors, 4GB DDR4-2133 RAM, Win 7, and 8.1 Pro 64-bit
Radeon Pro WX 7100 8GB graphics, HP Z Turbo Drive G2 256GB TLC, HP Z
Turbo Drive G2 512GB TLC, HP Z Turbo Drive G2 1TB TLC, 2TB SATA SSD,

9.5mm Slim DVD-Writer.
HP 9.5mm Slim SuperMulti DVD Writer specs and HP Inc. disclaimers
NVIDIA Quadro P5000
Hard Drive Controllers section note 4, Fan and Front Card Guide
Components,?
SATA Hard Drives, HP Solid State Drives (SSDs) notes, Notes 5&6 to Mid­Range Quadro M2000, FirePro 4300Graphics and Radeon Pro WX7100,
TPM content
The System Configuration (High-end) & Declared Noise Emissions (in
accordance with ISO 7779 and ISO 9296) subsections under The DECLARED
NOISE EMISSIONS section was removed.
The NVIDIA? Quadro? P2000 5GB Graphics to Mid-range 3D Graphics
Changed The HP 9.5mm Slim SuperMulti DVD Writer for The HP 9.5mm
Slim DVD Writer.
In page 12 added notes 1 & 2 to all the memory parts, added
HP 32GB (1x32GB) DDR4-2400 ECC Reg RAM to Memory section, added
new configurations to DIMM slots for capacities of 128GB & 256GB in the
System Board section.
Changed the Maximum Memory support from 128GB to 256GB, changed
the Mixed support configuration in the Graphics section.

DA - 15077???Worldwide QuickSpecs ¡ª Version 37 ¡ª 7/8/2019

Page? 100
