QuickSpecs

Overview

HP Z400 Workstation

HP recommends Windows Vista

Business

®

1.

3 External 5.25" Bays

2.

Power Button

3.

Front I/O: 2 USB 2.0, 1 IEEE 1394a (optional card required), Headphone,
Microphone

DA - 13276 Worldwide QuickSpecs — Version 1 — 3.30.2009

Page 1

QuickSpecs

Overview

4.

3 External 5.25” Bays

5.

4 DIMM Slots for DDR3 ECC Memory

6.

2 Internal 3.5” Bays

7.

475W, 85% efficient Power Supply

8.

Dual/Quad Core Intel 3500 Series Processors

HP Z400 Workstation

9.

Rear I/O: 6 USB 2.0, PS/2 keyboard/mouse
1 RJ-45 to Integrated Gigabit LAN
1 Audio Line In, 1 Audio Line Out, 1 Microphone In

10.

2 PCIe x16 Gen2 Slots

11..

1 PCIe x4 Gen2, 1 PCIe x4 Gen1, 2 PCI Slots

12

4 Internal USB 2.0 ports

Form Factor
Compatible Operating

Systems

Available Processors

Available Processor
Disclaimers

Convertible Minitower
Genuine Windows Vista® Business 32-bit*

Genuine Windows Vista® Business 64-bit*
Genuine Windows Vista® Business 32-bit with downgrade to Windows® XP Professional 32-bit custom
installed** (expected available until August 2009)
Genuine Windows Vista® Business 64-bit with downgrade to Windows® XP Professional x64 custom
installed** (expected available until August 2009)
HP Linux Installer Kit for Linux (includes drivers for both 32-bit & 64-bit OS versions of Red Hat Enterprise
Linux WS4 and WS5 - see:
Novell Suse SLED 11 (expected availability May 2009)

*Certain Windows Vista product features require advanced or additional hardware. See

http://www.microsoft.com/windowsvista/getready/hardwarereqs.mspx
http://www.microsoft.com/windowsvista/getready/capable.mspx

Advisor can help you determine which features of Windows Vista will run on your computer. To
download the tool, visit
**Windows Vista Business disk may also be included for future upgrade if desired. To qualify for this
downgrade an end user must be a business (including governmental or educational institutions) and is
expected to order at least 25 customer systems with the same custom image.

Intel® Xeon® Processor W3503 2.40 GHz, 4MB cache, 1066 memory, 4.8GT/s QPI, Dual-Core
Intel Xeon Processor W3505 2.53 GHz, 4MB cache, 1066 memory, 4.8GT/s QPI, Dual-Core
Intel Xeon Processor W3520 2.66 GHz, 8MB cache, 1066 memory, 4.8 GT/s QPI, Quad-Core, HT,
Turbo
Intel Xeon Processor W3540 2.93 GHz, 8MB cache, 1066 memory, 4.8 GT/s QPI, Quad-Core, HT,
Turbo
Intel Xeon Processor W3570 3.20 GHz, 8MB cache, 1333 memory, 6.4 GT/s QPI, Quad-Core, HT,
Turbo

Intel processor numbers are not a measurement of higher performance. Processor numbers differentiate
features within each processor family, not across different processor families. See:

http://www.intel.com/products/processor_number/

http://www.hp.com/workstations/software/linux

for details. Windows Vista Upgrade

http://www.windowsvista.com/upgradeadvisor

for details.

)

and

.

64-bit computing on Intel® 64 architecture requires a computer system with a processor, chipset, BIOS,
operating system, device drivers and applications enabled for Intel 64 architecture. Processor will not
operate (including 32-bit operation) without an Intel 64 architecture-enabled BIOS. Performance will vary
depending on your hardware and software configurations. See:
more information.

Dual-Core and Quad-Core technologies are designed to improve performance of multithreaded software
products and hardware-aware multitasking operating systems and may require appropriate operating
system software for full benefits; check with software provider to determine suitability; Not all customers or
software applications will necessarily benefit from use of these technologies.

Intel's numbering is not a measurement of higher performance.

DA - 13276 Worldwide QuickSpecs — Version 1 — 3.30.2009

http://www.intel.com/info/em64t

Page 2

for

QuickSpecs

Overview

HP Z400 Workstation

Color
Convertibility
Expansion Slots

system board section for
more details)

Expansion Bays
storage section for more
details)

Front I/O
Rear I/O

Interfaces Supported
Chassis Dimensions

D x H)
Weight

Temperature

Humidity

Maximum Altitude
pressurized)

Power Supply

(see

(see

(W x

(non-

Jack Black/Alloy metallic
Yes. 5.25" drives rotate for Minitower or Desktop orientation.

2 PCI slots (full-height, full-length)
1 PCI Express Gen2 slot x8 mechanical/x4 electrical
1 PCI Express Gen1 slot x8 mechanical/x4 electrical
2 PCI Express x16 Gen2 slots (one dedicated for graphics)

2 internal 3.5" bays
3 external 5.25" bays

NOTE:

2 USB 2.0, 1 IEEE 1394 (requires optional PCI card to function), 1 audio out, and 1 microphone.
6 USB 2.0, 1 optional serial port, 2 PS/2, RJ-45 (NIC), 1 audio line in, 1 audio line out, 1 microphone

in; audio ports can be retasked to function as line in, line out, microphone, or headphone.
22-in-1 Media Card Reader (optional)
Standard minitower orientation: 6.6 x 17.9 x 17.7 in (16.79 x 45.53 x 45.02 cm)

Converted desktop orientation: 6.6 x 17.9 x 17.7 in (16.79 x 45.53 x 45.02 cm)
Exact weights depend upon configuration

Minimum: 29.8 lbs (13.5 kg)
Standard: 33.2 lbs (15.1 kg)
Maximum: 43.2 lbs (19.6 kg)

Operating:
Non-operating
Operating:
Non-operating
Operating:
Non-operating
475 watts wide-ranging, active Power Factor Correction, 85% Efficient

Third external 5.25" bay is not full depth; maximum depth 170 mm (6.7 inches)

40° to 95°F (5° to 35°C)
–40° to 140° F (–40° to 60° C)
8% to 85%
8% to 90%
10,000 feet; 3,000 m
30,000 feet; 9,100 m

DA - 13276 Worldwide QuickSpecs — Version 1 — 3.30.2009

Page 3

QuickSpecs

Supported Components

HP Z400 Workstation

Processors

Option

Factory

Quad-Core Intel® Xeon® Processor 3500 Series with Intel® 64 Architecture
Intel Xeon W3503, 2.40GHz, 4MB cache, 1066

memory, 4.8GT/s QPI, Dual-Core
Intel Xeon W3505, 2.53GHz, 4MB cache, 1066

memory, 4.8GT/s QPI, Dual-Core
Intel Xeon W3520, 2.66GHz, 8MB cache, 1066

memory, 4.8GT/s QPI, Quad-Core, HT, Turbo
Intel Xeon W3540, 2.93GHz, 8MB cache, 1066

memory, 4.8GT/s QPI, Quad-Core, HT, Turbo
Intel Xeon W3570, 3.20GHz, 8MB cache, 1333

memory, 6.4GT/s, Quad-Core, HT, Turbo

When ordering two processors, the second processor must be the same as the first. Intel processor
numbers are not a measurement of higher performance. Processor numbers differentiate features within
each processor family, not across different processor families. See:

http://www.intel.com/products/processor_number/

Dual-Core and Quad-Core technologies are designed to improve performance of multithreaded software
products and hardware-aware multitasking operating systems and may require appropriate operating
system software for full benefits; check with software provider to determine suitability; Not all customers or
software applications will necessarily benefit from use of these technologies.

Configured

Y

Y

Y

Y

Y

for details.

Option

Kit

N

N

N

N

N

Kit Part

Number

Support

Notes

SAS Hard Drives

64-bit computing on Intel® 64 architecture requires a computer system with a processor, chipset, BIOS,
operating system, device drivers and applications enabled for Intel 64 architecture. Processor will not
operate (including 32-bit operation) without an Intel 64 architecture-enabled BIOS. Performance will vary
depending on your hardware and software configurations. See:
more information.

Intel's numbering is not a measurement of higher performance.

Sub-Section Description/Notes
For hard drives, 1 GB = 1 billion bytes; TB = 1 trillion bytes. Actual formatted capacity is less. Up to 12

GB of hard drive (or system disk) is reserved for the system recovery software (XP and XP Pro). Up to 3 GB
of system disk is reserved for system recovery software (Vista).

HP SAS (Serial Attached SCSI) Hard Drives for HP Workstations
146 GB 15K rpm SAS 3.0 Gb/s 3.5" Hard Drive
300 GB 15K rpm SAS 3.0 Gb/s 3.5" Hard Drive
450 GB 15K rpm SAS 3.0 Gb/s 3.5" Hard Drive

Sub-Section Description/Notes

http://www.intel.com/info/em64t

Option Kit

Factory

Configured

Y Y
Y Y
Y Y

Option

Kit

Part

Number

EA330AA

EM174AA

FM803AA

for

Support

Notes

DA - 13276 Worldwide QuickSpecs — Version 1 — 3.30.2009

Page 4

QuickSpecs

Supported Components

HP Z400 Workstation

SATA Hard Drives

Up to (4) 3.5-inch 7200 rpm SATA drives:160, 250, 320, 500, 1000, 1500 GB; 6.0 TB max
Up to (4) 2.5-inch 10K rpm SATA drives:160, 300 GB 1.2 TB max
Up to (4) 3.5-inch 15K rpm SAS devices: 146, 300, 450, 600 GB; 2.42 TB max

Removable Boot Drive option

SATA (Serial ATA) Hard Drives for HP Workstations
160 GB 7,200 rpm SATA 3.0 Gb/s with NCQ 3.5"

Hard Drive
250 GB 7,200 rpm SATA 3.0 Gb/s with NCQ 3.5"

Hard Drive
320 GB 7,200 rpm SATA 3.0 Gb/s with NCQ 3.5"

Hard Drive
500 GB 7,200 rpm SATA 3.0 Gb/s with NCQ 3.5"

Hard Drive
1 TB 7,200 rpm SATA 3.0 Gb/s with NCQ 3.5" Hard

Drive
160 GB 10K rpm SATA with NCQ 2.5" Hard Drive
300 GB 10K rpm SATA with NCQ 2.5" Hard Drive

NOTE:

SAS Controller, not integrated, is required)

Y Y

Y Y

Y Y

Y Y

Y Y

Y Y
Y Y

PV944A

EA788AA

FH963AA

PV943A

GE262AA

EW222AA

FM802AA

Hard Drive
Controllers

For hard drives, 1 GB = 1 billion bytes; TB = 1 trillion bytes. Actual formatted capacity is less. Up to 12
GB of hard drive (or system disk) is reserved for the system recovery software (XP and XP Pro). Up to 3 GB
of system disk is reserved for system recovery software (Vista).

Factory

Integrated SATA 3.0 Gb/s Controller
Integrated SATA 3.0 Gb/s
Factory integrated RAID on motherboard for SATA drives
RAID 0 Configuration - Striped Array
RAID 0 Data Configuration -- Boot/OS Drive + 2

Drive Striped Array
RAID 1 Configuration - Mirrored Array
LSI 3041E 4-Port SAS 3.0 Gb/s RAID Card
LSI 3041E 4-Port SAS 3.0 Gb/s RAID Card

LSI MegaRAID® SAS 8888ELP Host Bus Adapter (HBA)
LSI 8888ELP 8-port SAS HW RAID Card

SATA hardware RAID is not supported on Linux systems. The Linux kernel, with built-in software RAID, provides
excellent functionality and performance. It is a good alternative to hardware-based RAID. Please visit

http://h20000.www2.hp.com/bc/docs/support/SupportManual/c00060684/c00060684.pdf

capabilities with Linux.
All drives must be identical in type and capacity
All RAID arrays must be less than 2 TB
NOTE

1: Requires identical hard drives (speeds, capacity, interface. Specific user-configured hardware SAS
RAID configurations are supported on this Linux system. Please visit:

http://www.hp.com/support/linux_hardware_matrix

Configured

Y

Y
Y

Y

Y Y

N

for details.

Option Kit

N

N
N

N

Option Kit Part

Y

Number

EH417AA

GE258AA

Support Notes

See note 1
See note 1

See note 1

See note 2

and 3

for RAID

DA - 13276 Worldwide QuickSpecs — Version 1 — 3.30.2009

Page 5

QuickSpecs

Supported Components

HP Z400 Workstation

Graphics

NOTE 2
Please visit:
NOTE 3

: Specific user-configured hardware SAS RAID configurations are supported on this Linux system.

http://www.hp.com/support/linux_hardware_matrix

: Not supported when HD drive 1 is SATA

Professional 2D
NVIDIA Quadro NVS 450 512 MB PCIe

Graphics Card
NVIDIA Quadro NVS 295 256MB PCIe

Graphics Card
NVIDIA Quadro NVS 290 256 MB PCIe

Graphics Card with 'DMS-59 to Dual DVI
cable' included - for Workstations

Entry 3D
NVIDIA Quadro FX 380 256MB PCIe

Graphics Card
ATI FirePro V3700 256MB PCIe Graphics

Card
NVIDIA Quadro FX 580 512MB PCIe

Graphics Card
Mid-range 3D
NVIDIA Quadro FX 1800 768MB PCIe

Graphics Card
ATI FirePro V5700 512MB PCIe Graphics

Card
High End 3D
NVIDIA Quadro FX 3800 1.0GB PCIe

Graphics Card (NOT AVAILABLE UNTIL
JUNE 2009)

ATI FirePro V7750 1.0GB PCIe Graphics
Card

NVIDIA Quadro FX 4800 1.5GB PCIe
Graphics Card

NVIDIA Quadro CX - The Accelerator for
Creative Suite 4

for details.

Option Kit

Factory

Configured

Y Y

Y Y

N

Y Y

Y Y

Y Y

Y Y

Y Y

Y Y

Y Y

Y Y

Y

Option

Kit

Y

N

Part

Number

FH519AA

FY943AA

GN502AA

NB769AA

FY944AA

FY945AA

FY946AA

VY947AA

FY949AA

FY948AA

FQ138AA

Support Notes

2nd card must

be NVS 295

2nd card must

be NVS 295

1 or 2 of these

cards are

supported - 2nd

card must be

NVS 290 or

NVS 440

2

2

2

2

2

1

1

1

1

Supported

Multi

Mixed

1

2

2

DA - 13276 Worldwide QuickSpecs — Version 1 — 3.30.2009

Page 6

QuickSpecs

Supported Components

HP Z400 Workstation

Memory

CTO
PC3-10600 DDR3-1333 ECC Unbuffered DIMMs CTO
1GB (1x1GB) DDR3-1333 ECC Unbuffered RAM 1-CPU
2GB (2x1GB) DDR3-1333 ECC Unbuffered RAM 1-CPU
3GB (3x1GB) DDR3-1333 ECC Unbuffered RAM 1-CPU
4GB (4x1GB) DDR3-1333 ECC Unbuffered RAM 1-CPU
4GB (2x2GB) DDR3-1333 ECC Unbuffered RAM 1-CPU
6GB (3x2GB) DDR3-1333 ECC Unbuffered RAM 1-CPU
8GB (2x4GB) DDR3-1333 ECC Unbuffered RAM 1-CPU
8GB (4x2GB) DDR3-1333 ECC Unbuffered RAM 1-CPU
12GB (3x4GB) DDR3-1333 ECC Unbuffered RAM 1-CPU
16GB (4x4GB) DDR3-1333 ECC Unbuffered RAM 1-CPU

Sub-Section Description/Notes
NOTE:

to XP 64. DIMMs should be distributed across all three memory channels for optimal performance.
Each processor supports up to 3 channels of DDR3 memory. To realize full performance at least 1 DIMM
must be inserted into each channel. To get full 6 channel support, 2 processors MUST be installed.

AMO
PC3-10600 DDR3-1333 ECC Unbuffered DIMMs AMO
1GB (1x1GB) DDR3-1333 ECC Unbuffered RAM
2GB (1x2GB) DDR3-1333 ECC Unbuffered RAM
4GB (1x4GB) DDR3-1333 ECC Unbuffered RAM

NOTE:

Configurations less than 1 GB are not supported on Windows Vista 64 or Vista 64 downgrade

Only unbuffered DDR3 DIMMs are supported.

Support Notes

Multimedia and Audio
Devices

Integrated Intel/Realtek HD ALC262 Audio
HP Thin USB Powered Speakers
Creative X-Fi Titanium PCIe Audio Card

Factory

Configured

Y
Y Y
Y Y

Option

Kit

N

Option Kit

Part

Number

KK912AA

NH222AA

Support

Notes

DA - 13276 Worldwide QuickSpecs — Version 1 — 3.30.2009

Page 7

QuickSpecs

Supported Components

HP Z400 Workstation

Optical and Removable
Storage

Factory

Configured
HP 16X DVD-ROM SATA Drive
HP 16X DVD+-RW SuperMulti SATA Drive
HP Blu-ray Writer

1.44 MB Diskette Drive (1 only)
HP 22-in-1 Media Card Reader Kit (Workstations)

Actual speeds may vary. Does not permit copying of commercially available DVD movies or other
copyright protected materials. Intended for creation and storage of your original material and other lawful
uses. Double Layer discs can store more data than single layer discs. However, double-layer discs burned
with this drive may not be compatible with many existing single-layer DVD drives and players.
As Blu-ray is a new format containing new technologies, certain disc, digital connection, compatibility
and/or performance issues may arise, and do not constitute defects in the product. Flawless playback on
all systems is not guaranteed. In order for some Blu-ray titles to play, they may require a DVI or HDMI
digital connection and your display may require HDCP support. HD-DVD movies cannot be played on this
workstation.

NOTE 1

: Not supported as a 2nd drive option.

Y Y
Y Y
Y Y
Y Y
Y Y

Option

Kit

Option Kit

Part

Number
AR629AA
AR630AA
AR482AA

NK360AA
NK361AA

Support Notes

See note 1

Controller Cards

Monitors

HP FireWire/IEEE 1394a PCI Card
HP IEEE 1394b FireWire PCIe Card

HP LP1965 19-inch LCD Monitor
HP LP2275w 22-inch Widescreen LCD Monitor
HP LP2475w 24-inch Widescreen LCD Monitor
HP DreamColor LP2480zx Professional Display
HP LP3065 30-inch Widescreen LCD Monitor

NOTE:

Supported by all Operating Systems available from HP (screen size diagonally measured)

Factory

Configured

Y Y
Y Y

Factory

Configured

Y Y
Y Y
Y Y
Y Y
Y Y

Option

Kit

Option

Kit

Option Kit

Part

Number

PA997A

NK653AA

Option
Kit Part

Number
RA373A
KE289A

KD911A

GV546A

EZ320A

Support

Notes

Support

Notes

DA - 13276 Worldwide QuickSpecs — Version 1 — 3.30.2009

Page 8

QuickSpecs

Supported Components

HP Z400 Workstation

Networking and
Communications

Racking and Physical
Security

Factory

Configured
Integrated Broadcom 5764 PCIe LOM Controller
Broadcom NetXtreme Gigabit Ethernet Plus NIC

(PCIe)

Intel Gigabit CT Desktop NIC

NOTE 1

http://www.microsoft.com/windowsvista/getready/hardwarereqs.mspx
http://www.microsoft.com/windowsvista/getready/capable.mspx

Advisor can help you determine which features of Windows Vista will run on your computer. To download
the tool, visit

"Gigabit" Ethernet indicates compliance with IEEE standard 802.3ab for Gigabit Ethernet, and does not
connote actual operating speed of 1 Gb/sec. For high speed transmission, connection to a Gigabit
Ethernet server and network infrastructure is required.

Security Cable with Kensington Lock
HP Solenoid Hood Lock & Hood Sensor
HP (CMT) Solenoid Lock
HP xw4/Z4 Depth Adjustable Fixed Rail Rack Kit

: Certain Windows Vista product features require advanced or additional hardware. See

http://www.windowsvista.com/upgradeadvisor

Y
Y Y

N

Option

Kit

N

for details. Windows Vista Upgrade

.

Factory

Configured

N

N
N

Y

Option Kit

FH969AA

and

Option

Kit

Y

Y
Y

Part

Number

FS215AA

Option
Kit Part

Number

PC766A

DE618A

EK729AA

Support Notes

This is a PCI

Express card

based on the

Broadcom

5761 chip.

Support

Notes

Input Devices

HP PS/2 Standard Keyboard
HP USB Standard Keyboard
HP PS/2 Optical Scroll Mouse
HP USB 2-Button Optical Scroll Mouse
HP USB Laser Mouse
HP USB Optical 3-Button Mouse
HP USB Smart Card Keyboard
HP 2.4GHz Wireless Keyboard & Mouse
HP USB Optical 3-Button 2.9M OEM Mouse
HP SpaceExplorer 3D USB Controller
HP SpacePilot 3D USB Intelligent Controller

Factory

Configured

Y Y
Y Y
Y Y
Y Y
Y Y

Y Y
N
N
N
N
N

Option

Kit

Y
Y
Y
Y
Y

Option Kit

Part

Number
DT527A
DT528A

EY703AA

DC172B

GW405AA

DY651A

ED707AA

NB896AA

ET424AA
RY429AA
EF390AA

Support

Notes

DA - 13276 Worldwide QuickSpecs — Version 1 — 3.30.2009

Page 9

QuickSpecs

Supported Components

HP Z400 Workstation

Other Hardware

Software

Configure minitower in desktop orientation
HP ENERGY STAR 5.0 Enabled Configuration
HP Workstation Mouse Pad

HP eSATA PCI Cable Kit
HP Power Cord Kit
HP 2nd Serial Port Adapter
HP Internal USB Port Kit
HP Optical Bay HDD Mounting Bracket
HP Workstation to LTO SAS Int. Cable
HP Fan and Front Card Guide Kit

HP Performance Tuning Framework
Roxio Easy Media Creator (CD or DVD burner)
Intervideo WinDVD with DVD player
HP Backup and Recovery

PDF Complete
Microsoft Office 2007 Small Business Edition
Microsoft Office 2007 Trial Edition
HP Client Manager Software v6.2 (optional

download)
HP ProtectTools Security

Factory

Configured

Y
Y
Y

Y Y
N
N
N
N
N
N

Factory

Configured

Y
Y
Y
Y

Y
Y
Y
Y

Y

Option

Option

Kit

N
N
N
N

N
N
N
N

N

Kit

N
N
N

Y
Y
Y
Y
Y
Y

Option Kit

Part

Number

GM110AA

DM293A

PA716A

EM165AA

NQ099AA

EH925A
DY648A

Option
Kit Part

Number

Support

Notes

Japan

only.

Support Notes

Supported on

Windows XP

ONLY

Must select as
a Configure to
Order Option.

Delivered as a

"Drop in the

Box" CD

DA - 13276 Worldwide QuickSpecs — Version 1 — 3.30.2009

Page 10

QuickSpecs

Supported Components

HP Z400 Workstation

Operating Systems

Genuine Windows Vista® Business
32-bit

Genuine Windows Vista® Business
64-bit

Genuine Windows Vista® Business
32-bit with downgrade to
Windows® XP Professional 32-bit
custom installed

Genuine Windows Vista® Business
64-bit with downgrade to
Windows® XP Professional x64
custom installed

HP Linux Installer Kit

Support Notes
Certain Windows Vista product features require advanced or

additional hardware. See

www.microsoft.com/windowsvista/getready/hardwarereqs.mspx

and

www.microsoft.com/windowsvista/getready/capable.mspx

for details. Windows Vista Upgrade Advisor can help you
determine which features of Windows Vista will run on your
computer. To download the tool, visit

www.windowsvista.com/upgradeadvisor

Certain Windows Vista product features require advanced or
additional hardware. See

www.microsoft.com/windowsvista/getready/hardwarereqs.mspx

and

www.microsoft.com/windowsvista/getready/capable.mspx

for details. Windows Vista Upgrade Advisor can help you
determine which features of Windows Vista will run on your
computer. To download the tool, visit
www.windowsvista.com/upgradeadvisor.

Windows Vista Business disk may also be included for future
upgrade if desired. To qualify for this downgrade an end user must
be a business (including governmental or educational institutions)
and is expected to order at least 25 customer systems with the same
custom image.

Windows Vista Business disk may also be included for future
upgrade if desired. To qualify for this downgrade an end user must
be a business (including governmental or educational institutions)
and is expected to order at least 25 customer systems with the same
custom image.

see:

http://www.hp.com/workstations/software/linux

.

DA - 13276 Worldwide QuickSpecs — Version 1 — 3.30.2009

Page 11

QuickSpecs

System Technical Specifications

System Board

System Board Form Factor
Processor Socket
CPU Bus Speed
Chipset
Super I/O Controller
Memory Expansion Slots
Memory Type Supported
Memory Modes
Memory Speed Supported
Memory Protection
Memory
Maximum Memory

ATX 9.6 x 12 inches (243.84 x 304.8 mm)
Single LGA1366
QPI: Up to 6.4GT/sec
Intel® X58 Express
SMSC SCH5327, Rev B
4 DDR3 memory slots
DDR3, UDIMM (Unbuffered), ECC
Channel Interleaved
800MHz, 1066MHz and 1333MHz DDR3
ECC available on data, parity on address and command

NOTE:
Vista Business 64, XP Professional x64 Edition, Red Hat Linux 64-bit. Genuine Windows Vista Business
32 and XP Professional (32-bit) support up to 4 GB. 32-bit Linux supports up to 8 GB.

* Maximum memory capacities assume 64-bit operating systems, such as genuine Windows®

HP Z400 Workstation

Memory Configuration
(Supported)

PCI Express Connectors
(Gen2 Rev 0.7 connectors)

PCI Connectors
Interfaces Supported

Serial Attached SCSI

Integrated RAID
Integrated Graphics
Network Controller
External SATA
IDE connector
Floppy connector

(5.0V)

(eSATA)

The 4GB DIMM for Z400 and Z600 is NOT compatible with the 4GB DIMMs offered on the
Z800.
They are NOT interchangeable.
Only ECC DIMMs are supported.

1 x8 PCIe (x4)

2 PCI
SATA

Hardware RAID is not supported on Linux systems. The Linux kernel, with built-in software RAID, provides
excellent functionality and performance. It is a good alternative to hardware-based RAID. Please visit

http://h20000.www2.hp.com/bc/docs/support/SupportManual/c00060684/c00060684.pdf

RAID capabilities with Linux.

NOTE:

No
Integrated HP Gbit LAN by Broadcom
4 ports are eSATA configurable with optional eSATA After-Market Option cable kit.
No
Yes

Requires identical hard drives (speeds, capacity, interface)

Integrated 6-channel SATA 3.0Gb/sec controller with RAID 0,
1, 5, 10 and NCQ. (Factory integrated RAID is Microsoft
Windows only)

for

DA - 13276 Worldwide QuickSpecs — Version 1 — 3.30.2009

Page 12

QuickSpecs

System Technical Specifications

HP Z400 Workstation

Network Controller
Serial
2nd Serial
Parallel
Audio
CD-ROM input/Audio
AUX INPUT; Audio
IEEE 1394 Connector(s)

USB Connector(s)

HD Integrated Audio
Flash ROM
Clear Fan Header
CPU Fan Header
Chasiss Fan Header
Front PCI Fan Header
Front Control

Panel/Speaker Header
CMOS Battery Holder -

Lithium
Integrated Trusted Platform

Module
Power Supply Headers
Power Switch, Power LED

& Hard Drive LED Header
Clear Password Jumper
Serial Port
Parallel Port
Keyboard/Mouse
Power Supply
Operating Voltage Range
Rated Voltage Range
Rated Line Frequency
Operating Line Frequency

Range
Rated Input Current
Heat Dissipation
Power Supply Fan
ENERGY STAR® qualified

(Config Dependent)

Management capabilities WOL, PXE 2.1 and ASF 2.0
1 internal header (requires optional Serial Port Adaptor)
No
No
High Definition Integrated Realtek ALC262 Audio with Line in, Line Out, Microphone, Headphone
No
Yes
Front
Rear
Internal
Front
Rear
Internal
High Definition Integrated Realtek ALC262 Audio with Line in, Line Out, Microphone, Headphone
Yes
No
Yes
1 Rear System Chassis Fan Header, 1 Optional Front Chassis Fan Header
Yes
Yes

Yes

Integrated TPM 1.2

Yes
Yes

Yes
1 internal header (requires optional Serial Port Adaptor)
No
USB or PS/2
475w 80+ BRONZE, Custom
90-269 VAC
118V
400 Hz
393-407 Hz

10A @ 118 VAC
Maximum 2027 btu/hr (511 kg-cal/hr)
92x25 mm variable speed
Yes

1 IEEE 1394a (requires optional PCI card to function)
No
No
2 USB 2.0
6 USB 2.0
2 USB 2.0 headers

DA - 13276 Worldwide QuickSpecs — Version 1 — 3.30.2009

Page 13

QuickSpecs

System Technical Specifications

HP Z400 Workstation

80 PLUS Compliant
FEMP Standby Power

Compliant 115V (Wake­on LAN disabled) (<2W
in S5 - Power Off)

Power consumption in
sleep mode (as defined by
ENERGY STAR) - Suspend
to RAM (S3)

Built-in Self Test (BIST) LED
Surge Tolerant Full

Ranging Power Supply
(withstands power surges
up to 2000V)

Hood Lock Header
Hood Sensor Header
ASF 2.0

Format)

Z400 Required Power Supply Info
Power Supply
Operating Voltage Range
Rated Voltage Range
Rated Line Frequency
Operating Line Frequency Range
Rated Input Current

Heat Dissipation (Configuration and software
dependent)

Power Supply Fan
Energy Star Compliant (config dependent)
80 PLUS® Compliant
FEMP Standby Power Compliant@115V (Wake-on

LAN disabled)(<2W in S5-Power Off)
EuP Compliant@230V (<1 W in S5-Power Off)
Power Consumption in sleep mode (as defined by

ENERGY STAR) - Suspend to RAM (S3) (Instantly
Available PC) measured at 115V.

Built-in Selft Test LED
Surge Tolerant Full Ranging Power Supply (withstands

power surges up to 2000V

(Alert Standard

Yes, Bronze
Yes

<5W

Yes
Yes

Yes
Yes
Yes

475 watt custom power supply - (Wide Ranging Active PFC)

90 - 269 VAC

100 - 240 VAC

50-60 Hz

47 - 66 Hz

10 A @ 110-127 VAC

6 A @ 200-240 VAC

Typical 954 btu/hr (240.3 kg-cal/hr)

Maximum 1977 btu/hr (498.2 kg-cal/hr)

92x25 mm variable speed

YES

Yes, Bronze

YES

YES

<6W

YES
YES

*Input Voltage Restrictions

118 VAC

400 Hz

393 - 407 Hz

10 A @118 VAC

DA - 13276 Worldwide QuickSpecs — Version 1 — 3.30.2009

Page 14

QuickSpecs

System Technical Specifications

HP Z400 Workstation

DA - 13276 Worldwide QuickSpecs — Version 1 — 3.30.2009

Page 15

QuickSpecs

System Technical Specifications

HP Z400 Workstation

DA - 13276 Worldwide QuickSpecs — Version 1 — 3.30.2009

Page 16

QuickSpecs

System Technical Specifications

HP Z400 Workstation

DA - 13276 Worldwide QuickSpecs — Version 1 — 3.30.2009

Page 17

QuickSpecs

System Technical Specifications

HP Z400 Workstation

Declared Noise Emissions

System Configuration
(Entry level)

(Entry-level and High-end configurations)

Processor Info
Memory Info
Graphics Info
Disks/Optical/Floppy

DA - 13276 Worldwide QuickSpecs — Version 1 — 3.30.2009

Intel Xeon Processor W3505 2.53 GHz
4 x 1GB DDR3 1333 MHz
NVIDIA Quadro NVS 295
1 x 160 GB 7200 RPM SATA / DVD-ROM / No Floppy

Page 18

QuickSpecs

System Technical Specifications

HP Z400 Workstation

Declared Noise Emissions
(in accordance with ISO
7779 and ISO 9296)

System Configuration
(High-end)

Declared Noise Emissions
(in accordance with ISO
7779 and ISO 9296)

Idle
SATA Hard drive

Operating (random reads)
Floppy Drive Operating

(continuous copy)
DVD-ROM Operating

(sequential reads)

Processor Info
Memory Info
Graphics Info
Disks/Optical/Floppy

Idle
SATA Hard drive

Operating (random reads)
Floppy Drive Operating

(continuous copy)
DVD-ROM Operating

(sequential reads)

Sound Power

Intel Xeon Processor W3570 3.20 GHz
4 x 1GB DDR3 1333 MHz
NVIDIA Quadro FX 4600
2 x 450 GB 15K SAS / DVD-ROM / No Floppy

Sound Power

( LWAd, bels )

3.9 Bels

4.2 Bels

4.7 Bels

5.1 Bels

( LWAd, bels )

4.6 Bels

5.2 Bels

5.0 Bels

5.3 Bels

Deskside Sound Pressure

Deskside Sound Pressure

23 dB
25 dB

29 dB

38 dB

27 dB
35 dB

32 dB

38 dB

Environmental
Requirements

Temperature

Humidity

Maximum Altitude

Dynamic (new)

Cooling

Operating: 40° to 95° F (5° to 35° C)
Non-operating: -40° to 140° F (-40° to 60° C)

Operating: 8% to 85% RH, non-condensing
Non-operating: 8% to 90% RH, non-condensing

Operating: 10,000 feet (3,000 m)
Non-operating: 30,000 feet (9,100 m)

Shock
Operating: ½-sine: 40g, 2-3ms
Non-operating:
½-sine: 160 cm/s, 2-3ms (~100g)
square: 422 cm/s, 20g

NOTE:
repetitive shock events.

Vibration
Operating random: 0.5g (rms), 5-300 Hz
Non-operating random: 2.0g (rms), 10-500 Hz

NOTE:

Above 5000 ft (1524 m) altitude, maximum operating temperature is de­rated by 1.8° F (1° C) per 1000 ft (305 m) elevation increase

Values represent individual shock events and do not indicate

Values do not indicate continuous vibration.

Physical Security and Serviceability

DA - 13276 Worldwide QuickSpecs — Version 1 — 3.30.2009

Page 19

QuickSpecs

System Technical Specifications

HP Z400 Workstation

Access Panel

Optical Drive
Floppy Drive
Hard Drives
Expansion Cards
Processor Socket
Green User Touch Points
Color-coordinated Cables

and Connectors
Memory
System Board
Dual Color Power and HD

LED on Front of Computer
Configuration Record SW
Over-Temp Warning on

Screen
Restore CD Set
Dual Function Front Power

Switch
Padlock Support

Cable Lock Support

Universal Chassis Clamp
Lock Support

Solenoid Lock and Hood
Sensor

Rear Port Control Cover
Serial, Parallel, USB,

Audio, Network,
Enable/Disable Port
Control

Removable Media
Write/Boot Control

Power-On Password
Setup Password

3.3V Aux Power LED on
System PCA

NIC LEDs (integrated)
(Green & Amber)

CPUs and Heatsinks

Tool-less
Includes system board and memory information

Tool-less
Tool-less
Tool-less
Tool-less
Tool-less
Yes, on tool-free internal chassis components
Yes

Tool-less
Tool-less
Yes

Yes
Yes

Restores the computer to its original factory shipping image - Can be obtained via HP Support
Yes, causes a fail-safe power off when held for 4 seconds

Yes (optional): Locks side cover and secures chassis from theft

0.22-in diameter padlock loop at rear of system
Yes, Kensington Cable Lock (optional): Locks side cover and secures chassis from theft

3 mm x 7 mm slot at rear of system
Yes (optional): Locks side cover and locks cables to chassis. Secures chassis from theft and allows

multiple units to be chained together when used with optional cable
Threaded feature at rear of system

Yes (optional)
The Solenoid Hood Lock eliminates the need for a physical key by making the chassis lockable through
software and a password. You can also lock and unlock the chassis remotely over the network. The
Sensor Kit detects when the access panel has been removed

Yes, locks rear IO cables to prevent cable theft
Yes, enables or disables serial, USB, audio, and network ports

Yes, prevents ability to boot from removable media on supported devices (and can disable writes to
media)

Yes, prevents an unauthorized person from booting up the workstation
Yes, prevents an unauthorized person from changing the workstation configuration
Yes

Yes

A T-15 Torx or flat blade screwdriver is needed to remove the CPU heatsink before the CPU can be
removed. CPU removal is tool-less

DA - 13276 Worldwide QuickSpecs — Version 1 — 3.30.2009

Page 20

QuickSpecs

System Technical Specifications

HP Z400 Workstation

Power supply diagnostic
LED

Power Button
Power LED
Hard drive activity LED
Internal speaker
System/Emergency ROM

Flash Recovery
OS CD (Restore OS CD)

ASF 2.0 support (Alert
Standard Format)

Cooling Solutions
Power Supply Fans
CPU Heatsink Fan(s)

Chassis Fans
Memory Fans
Insight Diagnostics

Yes

Yes, ACPI multi-function
Yes, blue (normal), red (fault)
Yes, green
Yes
Recovers corrupted system BIOS.

Restores computer to its original factory shipping Operating System - No recovery CDs will ship with
Windows XP, Vista or Linux - an ISO image will be available on an HD partition.

Industry-standard specification for network alerting in operating system-absent environments

Air cooled forced convection, liquid cooling (optional)
92 mm x 92 mm x 25 mm 2-wire (non-serviceable)
Mainstream (<=95W): 80 mm x 80 mm x 15 mm 5-wire PWM

Performance (>95W): 92 mm x 92 mm x 25 mm 5-wire PWM
92 mm x 92mm x 25 mm 4-wire PWM
No
HP Insight Diagnostics Offline Edition

The diagnostics utility enables you to perform testing and to view critical computer hardware and
software configuration information from various sources. This utility enables you to:

Access Panel Key Lock
ACPI-Ready Hardware

Trusted Platform Module
Chip with optional
ProtectTools Software

Integrated Chassis
Handles

Run diagnostics
iew the hardware configuration of the system

Key features and benefits
HP Insight Diagnostics simplifies the process of effectively identifying, diagnosing, and isolating the
hardware issues. In addition to robust management tools, service tools can be invaluable in quickly
resolving system problems. To streamline the service process and resolve problems quickly, it is necessary
to have the right information available at the time that a service call is placed. The primary information
requirement, which is also the one that provides the greatest insight into potential system issues, is the
configuration of the system. Insight Diagnostics helps provide higher system availability. Typical uses of
the Insight Diagnostics are:

Testing and diagnosing apparent hardware failures
Documenting system configurations for upgrade planning, standardization, inventory tracking,
disaster recovery, and maintenance

Sending configuration information to another location for more in-depth analysis
No
Advanced Configuration and Power Management Interface (ACPI).

Allows the system to wake from a low power mode.

Controls system power consumption, making it possible to place individual cards and peripherals

in a low-power or powered-off state without affecting other elements of the system
Yes, Infineon SLB9635TT1.2

No

DA - 13276 Worldwide QuickSpecs — Version 1 — 3.30.2009

Page 21

QuickSpecs

System Technical Specifications

HP Z400 Workstation

Power Supply
PCI Card Retention
Flash ROM
Diagnostic Power Switch

LED on board
Clear Password Jumper
Clear CMOS Button
CMOS Battery Holder for

easy Replacement
DIMM Connectors for

easy Upgrade
HP ProtectTools Security

Manager

BIOS

BIOS 32-bit Services
PCI 3.0 Support
ATAPI
BBS
WMI Support

BIOS Boot Spec 1.01+
BIOS Power On
ROM Based Computer

Setup Utility (F10)
System/Emergency ROM

Flash Recovery with Video
Replicated Setup

SMBIOS
Boot Control
Memory Change Alert
Thermal Alert

Requires T15 Torx or flat blade screwdriver
Yes, rear (all), middle (none), front (full-length cards with extender)
Yes
Yes

Yes
Yes
Yes

Yes

Yes - Not supported on Microsoft XP x64 or Linux

Standard BIOS 32-bit Service Directory Proposal v0.4
Full BIOS support for PCI Express through industry standard interfaces.
ATAPI Removable Media Device BIOS Specification Version 1.0.
BIOS Boot Specification v1.01.
WMI is Microsoft's implementation of Web-Based Enterprise Management (WBEM) for Windows. WMI

is fully compliant with the Distributed Management Task Force (DMTF) Common Information Model (CIM)
and WBEM specifications.

Provides more control over how and from what devices the workstation will boot.
Users can define a specific date and time for the system to power on.
Review and customize system configuration settings controlled by the BIOS.

Recovers system BIOS in corrupted Flash ROM.

Saves BIOS settings to diskette or USB flash device in human readable file. Repset.exe utility can then
replicate these settings on machines being deployed without entering Computer Configuration Utility (F10
Setup).

System Management BIOS 2.6, for system management information.
Disables the ability to boot from removable media on supported devices.
Alerts management console if memory is removed or changed.
Monitors the temperature state within the chassis. Three modes:

Remote ROM Flash
ACPI

(Advanced
Configuration and Power
Management Interface)

NORMAL - normal temperature ranges
ALERTED - excessive temperatures are detected. Raises a flag so action can be taken to avoid
shutdown or provide for a smoother system shutdown
SHUTDOWN - excessive temperatures are encountered. Automatically shuts down the computer
without warning before hardware component damage occurs

Provides secure, fail-safe ROM image management from a central network console.

Allows the system to enter and resume from low power modes (sleep states).]
Enables an operating system to control system power consumption based on the dynamic
workload.
Makes it possible to place individual cards and peripherals in a low-power or powered-off state

DA - 13276 Worldwide QuickSpecs — Version 1 — 3.30.2009

Page 22

QuickSpecs

System Technical Specifications

without affecting other elements of the system.

Supports ACPI 2.0 for full compatibility with 64-bit operating systems.
Ownership Tag
Remote Wakeup/Remote

Shutdown
ASF 2.0 Compliant
Instantly Available PC

(Suspend to RAM - ACPI
sleep state S3)

Remote System Installation
via F12 (PXE 2.1) (Remote
Boot from Server)

ROM revision levels

System board revision
level

Start-up Diagnostics
(Power-on Self-Test)

Auto Setup when new
hardware installed

Keyboard-less Operation
Localized ROM Setup

Asset Tag
Per-slot Control
Adaptive Cooling
Pre-boot Diagnostics
Industry Standard

Specification Support
Industry Standard
ACPI
ASF
ATA

(IDE)
CD Boot
EDD

EHCI
PCI

PCI Express
PMM
SATA

A user-defined string stored in non-volatile memory that is displayed in the BIOS splash screen.
System administrators can power on, restart, and power off a client computer from a remote location.

Allows workstation status to be monitored on a remote console.
Allows for very low power consumption with quick resume time.

Allows a new or existing system to boot over the network and download software, including the
operating system.

Reports the system BIOS revision level in Computer Configuration Utility (F10 Setup). Version is available
through an industry standard interface (SMBIOS) so that management SW applications can use and
report this information.

Allows management SW to read the revision level of the system board
Revision level is digitally encoded into the HW and cannot be modified.

Assesses system health at boot time with selectable levels of testing.

System automatically detects addition of new hardware.

The system can be booted without a keyboard.
Common BIOS image supports System Configuration Utility (F10 Setup) menus in 12 languages with

local keyboard mappings.
The user or MIS to set a unique tag string in non-volatile memory.
Allows I/O slot parameters (option ROM enable/disable, bus latency) to be configured individually.
Control parameters are set according to detected hardware configuration for optimal acoustics.
(Pre-video) critical errors are reported via beeps and blinks on the power LED.

Revision Supported by the BIOS
Advanced Configuration and Power Management Interface, Version 2.0c
Alert Standard Format Specification, Version 2.0
AT Attachment 6 with Packet Interface (ATA/ATAPI-6), Revision 3b
"El Torito" Bootable CD-ROM Format Specification Version 1.0

Enhanced Disk Drive Specification Version 1.1
BIOS Enhanced Disk Drive Specification Version 3.0

Enhanced Host Controller Interface for Universal Serial Bus, Revision 1.0

PCI Local Bus Specification, Revision 2.3
PCI Power Management Specification, Revision 1.1

PCI Firmware Specification, Revision 3.0, Draft .7
PCI Express Base Specification, Revision 2.0
POST Memory Manager Specification, Version 1.01

Serial ATA Specification, Revision 1.0a

Serial ATA 3.0Gb/s: Extensions to Serial ATA 1.5Gb/s, Revision 1.0

HP Z400 Workstation

DA - 13276 Worldwide QuickSpecs — Version 1 — 3.30.2009

Page 23

QuickSpecs

System Technical Specifications

HP Z400 Workstation

SPD
TPM
UHCI
USB 1.1
USB 2.0
SMBIOS

PC SDRAM Serial Presence Detect (SPD) Specification, Revision 1.2B
Trusted Computing Group TPM Specification Version 1.2
Universal Host Controller Interface Design Guide, Revision 1.1
Universal Serial Bus Revision 1.1 Specification
Universal Serial Bus Revision 2.0 Specification
System Management BIOS Reference Specification, Version 2.6

System Software Management and Updating

HP Client Management
Solutions

Product Change

Support Software CD &
WWW

HP Client Manager
System Software Manager

(free)
Social and Environmental

Responsibility
Eco-Label Certifications &

Declarations

Visit:

http://www.hp.com/go/easydeploy

Program to proactively communicate Product Change Notifications (PCNs) and Customer
Advisories by email to customers, based on a user-defined profile.
PCNs provide advance notification of hardware and software changes to be implemented in the
factory providing time to plan for transition.
Customer Advisories provide concise, effective problem resolution, greatly reducing the need to call
technical support.

Yes

Visit:

http://www.hp.com/go/easydeploy

Visit:

http://www.hp.com/go/ssm

This product has received or is in the process of being certified to the following approvals and may be
labeled with one or more of these marks:

Batteries

Restricted Material Usage

ENERGY STAR® (energy-saving features available on selected configurations -Windows only)
US Federal Energy Management Program (FEMP)
China Energy Conservation Program
IT ECO declaration
Japan PC Green label*

*This product conforms to the examination standards (2003 version) under JEITA's 'PC Green Label
System.'

This product complies with ISO standards:

EU Directive 91/ 157/ EEC
EU Directive 93/ 86/ EEC
EU Directive 98/ 101/ EEC

Batteries used in the product do not contain:

Mercury greater than 5ppm by weight
Cadmium greater than 10ppm by weight
Lead greater than 4000ppm by weight

Battery size: CR2032 (coin cell)
Battery type: Lithium

This product does not contain any of the following substances in excess of regulatory limits (refer to the HP
General Specification for the Environment at

DA - 13276 Worldwide QuickSpecs — Version 1 — 3.30.2009

Page 24

QuickSpecs

System Technical Specifications

HP Z400 Workstation

Packaging

http://www.hp.com/hpinfo/globalcitizenship/environment/supplychain/gen_specifications.html

Asbestos
Batteries - Mercury
Batteries - Cadmium
Batteries - Lead (non-rechargeable)
Batteries - Non-rechargeable Alkaline and Carbon-Zinc Batteries
Batteries - Classification as "Not Restricted" for Transport
Brominated Flame Retardants (PBBs, PBDEs, including DecaBDE)
Brominated Flame Retardants (all BFRs in external case plastic parts)
Cadmium and its compounds
Certain Azo Colorants
Chlorinated Hydrocarbons
Chlorinated Paraffins
Formaldehyde
Formaldehyde - emissions
Hexavalent Chromium and its compounds in metallic applications
Hexavalent Chromium and its compounds in non-metallic applications
Lead and its compounds
Lead in paint
Lead in Polyvinyl Chloride (PVC) coating of external cables, wires and cords
Mercury and its compounds
Nickel on external surfaces
Ozone Depleting Substances (ODS)
Polycyclic Aromatic Hydrocarbons (PAH)
Perfluorooctane sulfonates (PFOS) in parts
Perfluorooctane sulfonates (PFOS) in preparations
Polychlorinated Biphenyls (PCBs) and Polychlorinated Terphenyls (PCTs)
Polychlorinated Naphthalenes
Polyvinyl Chloride (PVC) in external case plastic parts
Radioactive Substances
Tributyl Tin (TBT), Triphenyl Tin (TPT), Tributyl Tin Oxide (TBTO)

HP Workstation product packaging meets the following (refer to the HP General Specification for the
Environment at

http://www.hp.com/hpinfo/globalcitizenship/environment/supplychain/gen_specifications.html

):

:

Longevity and Upgrading

Does not contain restricted substances listed in HP Standard 011-1 General Specification for the
Environment (see link above).
Does not contain ozone-depleting substances (ODS).
Design packaging materials for ease of disassembly.
Does not contain heavy metals (lead, mercury, cadmium or hexavalent chromium) in excess of 100
ppm sum total for all heavy metals listed.
Maximizes the use of post-consumer recycled content materials in packaging materials.
All packaging material is recyclable.
Reduces size and weight of packages to improve transportation fuel efficiency.
Plastic packaging materials are marked according to ISO 11469 and DIN 6120 standards.

This product is designed to be upgraded, possibly extending its useful life by several years. Spare parts
are available throughout the warranty period and for up to 5 years after the end of production.
Upgradeability features contained in the product include:

Intel LGA775 processor socket

DA - 13276 Worldwide QuickSpecs — Version 1 — 3.30.2009

Page 25

QuickSpecs

System Technical Specifications

12 USB ports

3 PCI slots
4 PCI Express slots

Packaging Materials
External
Internal
End-of-Life Management

and Recycling

Hewlett-Packard Corporate
Environmental Information

Service, Support and
Warranty

Cardboard carton and insert: 1.536 kg
LDPE Foam: .366 kg
Hewlett-Packard offers end-of-life HP product return and recycling programs in many geographic areas.

To recycle your product, please go to:
office. Products returned to HP will be recycled, recovered or disposed of in a responsible manner.

For more information about HP's commitment to the environment:
[link to new HP white paper now in progress]
Global Citizenship Report:
Eco-label certifications:

http://www.hp.com/hpinfo/globalcitizenship/environment/productdesign/ecolabels.html

ISO 14001 certificates:

http://www.hp.com/hpinfo/globalcitizenship/environment/operations/envmanagement.html

On-site Warranty and Service (
on-site, next business-day (
8am - 5pm. Global coverage (
to another, non-restricted country will remain fully covered under the original warranty and service offering

NOTE 1:
NOTE 2:
HP third-party provider, and is not available in certain countries. Global service response times are based
on commercially reasonable best effort and may vary by country.
NOTE 3:
hardware and software. Toll-free calling and 24 x 7 support may not be available in some countries.

Terms and conditions may vary by country. Certain restrictions and exclusions apply.
On-site service may be provided pursuant to a service contract between HP and an authorized

Technical telephone support applies only to HP-configured, HP and HP-qualified, third-party

7 rear
3 internal - 1 Type A
2 front

1 PCI Express ×1 slot
2 Gen2 PCI Express ×16 slots

http://www.hp.com/recycle

http://www.hp.com/hpinfo/globalcitizenship/gcreport/index.html

Note 1

): One and three-years, limited warranty and service offering delivers

Note 2

) service for parts and labor and includes free telephone support (

Note 2

) ensures that any product purchased in one country and transferred

HP Z400 Workstation

or contact your nearest HP sales

Note 3

)

Additional Information

HP Care Pack Services extend service contracts beyond the standard warranties. Service starts from date
of hardware purchase. To choose the right level of service for your HP product, use the HP Care Pack
Services Lookup Tool at
information by product is available at
times for HP Care Packs may vary depending on your geographic location

This product is in compliance with the Restrictions of Hazardous Substances (RoHS) directive ­2002/95/EC.
This HP product is designed to comply with the Waste Electrical and Electronic Equipment (WEEE)
Directive - 2002/96/EC.
Plastic parts weighing over 25 grams used in the product are marked per ISO 11469 and
ISO1043.
This product contains 0% recycled materials (by weight)
This product is >90% recycle-able when properly disposed of at end of life.

DA - 13276 Worldwide QuickSpecs — Version 1 — 3.30.2009

http://www.hp.com/go/lookuptool

http://www.hp.com/hps/carepack

. Additional HP Care Pack Services

. Service levels and response

Page 26

QuickSpecs

Technical Specifications - Processors

HP Z400 Workstation

Processors

Intel Xeon W3503, 2.40GHz, 4MB cache, 1066 memory, 4.8GT/s QPI, Dual-Core
Intel Xeon W3505, 2.53GHz, 4MB cache, 1066 memory, 4.8GT/s QPI, Dual-Core
Intel Xeon W3520, 2.66GHz, 8MB cache, 1066 memory, 4.8GT/s QPI, Quad-Core, HT, Turbo
Intel Xeon W3540, 2.93GHz, 8MB cache, 1066 memory, 4.8GT/s QPI, Quad-Core, HT, Turbo
Intel Xeon W3570, 3.20GHz, 8MB cache, 1333 memory, 6.4GT/s, Quad-Core, HT, Turbo

Introduction

Intel's latest-generation microarchitecture represents the next step in unprecedented processor performance and dynamic scalability.
Designed from the ground up to take advantage of hafnium-based Intel® 45nm hi-k metal gate silicon technology, Intel®
Microarchitecture (Nehalem) unleashes parallel processing performance enabled by Intel® QuickPath technology providing an
integrated memory controller and high-speed interconnect per independent processing core.

Performance and Features

Maximum multitasking performance Intel® Microarchitecture (Nehalem) offers the latest in processor innovation, including:

'Dynamic scalability, managed cores, threads, cache, interfaces, and power for energy-efficient performance on demand.
Design and performance scalability for servers, workstations, notebooks and desktops with support for 2-8+ cores and up to
16+ threads with Intel® Hyper-Threading Technology (Intel® HT Technology), and scalable cache sizes, system interconnects,
and integrated memory controllers.
Intel® Turbo Boost Technology delivers additional performance automatically when needed by taking advantage of the
processor's power and thermal headroom. This enables increased performance of both multi-threaded and single-threaded
workloads.
Intel Hyper-Threading Technology brings high-performance applications into mainstream computing with 1-16+ threads
optimized for a new generation multi-core processor architecture.
Scalable shared memory of Intel® QuickPath technology features memory distributed to each processor with integrated
memory controllers and high-speed point-to-point interconnects to unleash the performance of future versions of next-generation
Intel® multi-core processors.
Multi-level shared cache improves performance and efficiency by reducing latency to frequently used data.

Turbo Boost Technology

This technology now built into Xeon 3500 Series Quad-Core processors will increase the speed of your processor on demand (from
OS) if the CPU is operating below power / thermal specifications:

Benefit of Turbo Boost (how much CPU speed up) depends on number of active cores
Likelihood of Turbo Boost operation increases when less cores are active
Likelihood of Turbo Boost operation increases when dynamic power mgt is enabled

DA - 13276 Worldwide QuickSpecs — Version 1 — 3.30.2009

Page 27

QuickSpecs

Technical Specifications - Hard Drives

HP Z400 Workstation

HP SAS (Serial Attached
SCSI) Hard Drives for HP
Workstations

300 GB
(15K)

146 GB
(15K)

450 GB
(15K)

Capacity
Height
Width

Interface
Synchronous Transfer Rate

(Maximum)
Buffer
Seek Time

includes controller
overhead, including
settling)

Rotational Speed
Logical Blocks
Operating Temperature

Capacity
Height
Width

Interface
Synchronous Transfer Rate

(Maximum)
Buffer
Seek Time

includes controller
overhead, including
settling)

Rotational Speed
Logical Blocks
Operating Temperature

Capacity
Height
Width

Interface
Synchronous Transfer Rate

(Maximum)
Buffer
Seek Time

includes controller
overhead, including
settling)

(typical reads,

(typical reads,

(typical reads,

300 GB
1 in; 2.5 cm
Media Diameter
Physical Size
SAS

3.0 Gb/s

16 MB
Single Track

Average

Full Stroke

15,000 rpm
585,937,500 - 512 byte blocks
50° to 95° F (10° to 35° C)

146 GB
1 in; 2.5 cm
Media Diameter
Physical Size
SAS

3.0 Gb/s

16 MB
Single Track

Average

Full Stroke

15,000 rpm
86,749,488 - 512 byte blocks
50° to 95° F (10° to 3°5 C)

450 GB
1 in; 2.5 cm
Media Diameter
Physical Size
SAS

3.0 Gb/s

16 MB
Single Track

Average

Full Stroke

3.5 in; 8.9 cm
4 in; 10.2 cm

0.2 ms

3.5 ms

6.7 ms

3.5 in; 8.9 cm
4 in; 10.2 cm

0.2 ms

3.5 ms

6.7 ms

3.5 in; 8.9 cm
4 in; 10.2 cm

0.2 ms

3.6 ms

6.6 ms

DA - 13276 Worldwide QuickSpecs — Version 1 — 3.30.2009

Page 28

QuickSpecs

Technical Specifications - Hard Drives

HP Z400 Workstation

SATA (Serial ATA) Hard
Drives for HP
Workstations

Rotational Speed
Logical Blocks
Operating Temperature

160,041,885,696
bytes
(10K)

1,000,204,886,016
bytes
(7,200)

500,107,862,016
bytes
(7,200)

Capacity
Height
Width

Interface

Synchronous Transfer
Rate

(Maximum)
Buffer
Seek Time

reads, includes
controller overhead,
including settling)

Rotational Speed
Logical Blocks
Operating Temperature

Capacity
Height
Width

Interface

Synchronous Transfer
Rate

Buffer
Seek Time

reads, includes
controller overhead,
including settling)

Rotational Speed
Logical Blocks
Operating Temperature

Capacity
Height
Width

Interface

(typical

(Maximum)

(typical

15,000 rpm
879, 097, 968 - 512 byte blocks
50° to 95° F (10° to 35° C)

160,041,885,696 bytes
1 in; 2.5 cm
Media Diameter
Physical Size
Serial ATA (1.5 Gb/s), Native Command Queuing

enabled
Up to 150 MB/s

16 Mbytes
Single Track

Average

Full Stroke

10,000 rpm
312,581,808
41 to 131 F (5 to 55 C)

1,000,204,886,016 bytes
1 in; 2.5 cm
Media Diameter
Physical Size
Serial ATA (3.0 Gb/s), Native Command Queuing

enabled
Up to 300 MB/s

32 MB
Single Track

Average

Full Stroke

7,200 rpm
1,953,525,168
41 to 131 F (5 to 55 C)

500,107,862,016 bytes
1 in; 2.5 cm
Media Diameter
Physical Size
Serial ATA (3.0 Gb/s), Native Command Queuing

enabled

3.5 in; 8.9 cm
4 in; 10.2 cm

0.3 ms

4.6 ms

10.2 ms

3.5 in; 8.9 cm
4 in; 10.2 cm

2 ms

11 ms

21 ms

3.5 in; 8.9 cm
4 in; 10.2 cm

DA - 13276 Worldwide QuickSpecs — Version 1 — 3.30.2009

Page 29

QuickSpecs

Technical Specifications - Hard Drives

HP Z400 Workstation

Synchronous Transfer
Rate

(Maximum)
Buffer
Seek Time

reads, includes
controller overhead,
including settling)

Rotational Speed
Logical Blocks
Operating Temperature

250,059,350,016
bytes
(7,200)

160,041,885,696
bytes
(7,200)

Capacity
Height
Width

Interface

Synchronous Transfer
Rate

Buffer
Seek Time

reads, includes
controller overhead,
including settling)

Rotational Speed
Logical Blocks
Operating Temperature

Capacity
Height
Width

Interface

Synchronous Transfer
Rate

Buffer
Seek Time

reads, includes
controller overhead,
including settling)

Rotational Speed
Logical Blocks
Operating Temperature

(typical

(Maximum)

(typical

(Maximum)

(typical

300 MB/s

16 MB
Single Track

Average

Full Stroke

7,200 rpm
976,773,168
41 to 131 F (5 to 55 C)

250,059,350,016 bytes
1 in; 2.5 cm
Media Diameter
Physical Size
Serial ATA (3.0 Gb/s), Native Command Queuing

enabled
300 MB/s

16 MB
Single Track

Average

Full Stroke

7,200 rpm
488,397,168
41 to 131 F (5 to 55 C)

160,041,885,696 bytes
1 in; 2.5 cm
Media Diameter
Physical Size
Serial ATA (3.0 Gb/s), Native Command Queuing

enabled
300 MB/s

8 MB
Single Track

Average

Full Stroke

7,200 rpm
312,581,808
41 to 131 F (5 to 55 C)

2 ms

11 ms

21 ms

3.5 in; 8.9 cm
4 in; 10.2 cm

2 ms

11 ms

21 ms

3.5 in; 8.9 cm
4 in; 10.2 cm

2 ms

11 ms

21 ms

DA - 13276 Worldwide QuickSpecs — Version 1 — 3.30.2009

Page 30

QuickSpecs

Technical Specifications - Hard Drives

HP Z400 Workstation

300,069,052,416
bytes
(10K)

320,072,933,376
bytes
(7,200)

Capacity
Height
Width

Interface

Synchronous Transfer
Rate

(Maximum)
Buffer
Seek Time

reads, includes
controller overhead,
including settling)

Rotational Speed
Logical Blocks
Operating Temperature

Capacity
Height
Width

Interface

Synchronous Transfer
Rate

Buffer
Seek Time

reads, includes
controller overhead,
including settling)

Rotational Speed
Logical Blocks
Operating Temperature

(typical

(Maximum)

(typical

300,069,052,416 bytes

0.6 in; 1.53 cm
Media Diameter
Physical Size
Serial ATA (3.0Gb/s), Native Command Queuing

enabled
Up to 300 MB/s

16 MB
Single Track

Average

Full Stroke

10,000 rpm
586,072,368
41° to 131° F (5° to 55° C)

320,072,933,376 bytes

0.98 in; 2.5 cm
Media Diameter
Physical Size
Serial ATA (3.0 Gb/s), Native Command Queuing

enabled
300 MB/s

8 MB
Single Track

Average

Full Stroke

7,200 rpm
625,142,448
41° to 131° F (5° to 55° C)

2.5 in; 6.36 cm
4 in; 10.17 cm

0.7 ms (maximum)

4.4 ms

9.5 ms

3.5 in; 8.9 cm

4.0 in; 10.17 cm

2

12

21

DA - 13276 Worldwide QuickSpecs — Version 1 — 3.30.2009

Page 31

QuickSpecs

Technical Specifications - Hard Drive Controllers

HP Z400 Workstation

LSI 3041E 4-Port SAS 3.0
Gb/s RAID Card

PCI Bus
PCI Modes
RAID Levels
PCI Data Burst Transfer

Rate

SAS Bandwidth

PCI Card Type
PCI Voltage
PCI Power
Bracket
Certification Level
IO Bus
SAS Processor
Internal Connectors
External Connectors
Maximum Number of

SCSI Devices
LED Indicators
Integrated Mirroring

PCI-Express x4 lanes
Bus Master DMA
RAID 0, 1, 1E and 10E
250 MB/s per lane half duplex

500 MB/s per lane full duplex
1,000 MB/s 4-lane half duplex

Half Duplex

Full Duplex

3.3 volt add-in c
12 V ± 10%

7.5 Watts
Full height and Low-profile
PCI-Express 1.0a
Four 3 Gb/s SAS/SATA ports
LSISAS1064E
Four- SATA x1 connectors
None
122

On-board activity and fault LEDs
Integrated Mirroring option available

Single lane – 300 MB/s
Wide Port (2 lanes) – 600 MB/s
Wide Port (4 lanes) – 1200 MB/s

Single SAS Lane – 600 MB/s
Wide Port (2 lanes) –1200 MB/s
Wide Port (4 lanes) – 2400 MB/s

LSI MegaRAID® SAS
8888ELP Host Bus
Adapter (HBA)

PCI Bus
PCI Modes
RAID Levels

PCI Data Burst Transfer
Rate

Full Duplex
PCI Voltage
PCI Power
Certification Level
IO Bus
Internal Connectors
External Connectors
Maximum Number of

SCSI DeviceS
LED Indicators

PCI-Express x8 lanes
Bus Master DMA
RAID 0, 1, and 5

RAID spans 10 and 50
Up to 3Gb/s per port

Up to 1.5 GB/s
+3.3V Add-in Card

7.5 Watts
PCI-Express 1.0a
Eight 3Gb/s SAS/SATA ports
Two SAS SFF8087 x4
Two SAS SFF8088 x4
32

Connector LEDs indicate whether the internal or external connector is active
for ports 0-3 and 4-7

DA - 13276 Worldwide QuickSpecs — Version 1 — 3.30.2009

Page 32

QuickSpecs

Technical Specifications - Graphics

HP Z400 Workstation

NVIDIA Quadro NVS
450 512 MB PCIe
Graphics Card

Form Factor

Bus Type
Memory
Connectors

Maximum Resolution

Supported Graphics APIs

Available Graphics
Drivers

Power consumption

ATX Full Height, 1/2 length
Passive cooling

PCI Express x16, Generation 2.0
512 MB GDDR3 (256MB per GPU)
Four DisplayPort;

Four DisplayPort to DVI-D adapters included.
('DisplayPort to VGA' and 'DisplayPort to Dual Link DVI' adapters available as
an accessory)

DisplayPort connectors support ultra-high-resolution panels (up to 2560 x

1600)
OpenGL 3.0

Direct X 10.0
Genuine Microsoft Windows Vista(64-bit and 32-bit), Microsoft Windows XP

Professional(64-bit and 32-bit)
Red Hat Enterprise Linux(RHEL) WS4 & 5 Desktop/Workstation
HP qualified drivers may be preloaded or available from the HP support web
site:

http://welcome.hp.com/country/us/eng/software_drivers.html

Novell SUSE Linux Enterprise drivers may be obtained from:

ftp://download.nvidia.com/novell or http://www.nvidia.com

35 Watts

.

NVIDIA Quadro NVS
295 256MB Graphics
Card

Form Factor
Graphics Controller
Bus Type
Memory
Connectors

Maximum Resolution
Display Output

Supported Graphics APIs

Available Graphics
Drivers

2.731 inches (H) × 6.600 inches (L), Half-Height
NVIDIA Quadro NVS 295 Graphics Board
PCI Express x16, Generation 2.0
256 MB GDDR3 SDRAM unified graphics memory
2 DisplayPort

Comes with 2 DisplayPort to DVI-D Adapters
('DisplayPort to VGA' and 'DisplayPort to DL DVI' adapters available as an
accessory)

Two DisplayPort outputs drive two digital displays up to 2560 x 1600

Drives DisplayPort enabled digital displays at resolutions up to 2560 ×
1600 at 60 Hz with reduced blanking
Drives DVI enabled digital displays at resolutions up to 1920 × 1200
at 60 Hz with reduced blanking (through DisplayPort to DVI-D (single
link) cable)

OpenGL 3.0
DirectX 10.0

Genuine Windows Vista Business (64-bit and 32-bit)
Microsoft Windows XP Professional (64-bit and 32-bit)
Red Hat Enterprise Linux(RHEL) WS4 & 5 Desktop/Workstation

HP qualified drivers may be preloaded or available from the HP support Web
site:

http://welcome.hp.com/country/us/en/support.html

Novell SUSE Linux Enterprise drivers may be obtained from:

ftp://download.nvidia.com/novell

DA - 13276 Worldwide QuickSpecs — Version 1 — 3.30.2009

or

http://www.nvidia.com

Page 33

QuickSpecs

Technical Specifications - Graphics

HP Z400 Workstation

NVIDIA Quadro NVS
290 256 MB PCIe
Graphics Card

Power consumption

Form Factor
Bus Type
Memory

Connectors

Maximum Resolution

RAMDAC
Image Quality Features

Programmable Video
Processor

Display Output

Supported Graphics APIs
Available Graphics

Drivers

High-Resolution
AntiAliasing

CUDA™ Parallel
Processor Cores

22.69 Watts

Low Profile
PCIe x16
256 MB 400MHz DDR2 SDRAM unified frame buffer, Z-buffer and Texture

storage
DMS-59, includes DMS-59 to Dual DVI-I cable. DMS-59 to Dual VGA cable

available as an option.
Dual integrated analog display controllers supporting up to two analog

displays at 2048x1536 @ 85Hz on both displays or dual digital displays at
1920x1200 (single-link).
NVIEW advanced multi-display desktop and application management
seamlessly integrated into Microsoft® Windows®

Integrated dual 400MHz
Full-screen, full-frame video playback of HDTV and DVD content

DVD-ready motion compensation for MPEG-2
Independent hardware color controls for video overlay
Hardware color-space conversion (YUV 4:2:2 and 4:2:0)
IDCT motion compensation
5-tap horizontal by 3-tap vertical filtering
8:1 up/down scaling

Full-screen, full-frame video playback of HDTV and DVD content
DVD-ready motion compensation for MPEG-2
Independent hardware color controls for video overlay
Hardware color-space conversion (YUV 4:2:2 and 4:2:0)
IDCT motion compensation
5-tap horizontal by 3-tap vertical filtering
8:1 up/down scaling

Dual integrated analog display controllers supporting up to two analog
displays at 2048x1536 @ 85Hz on both displays or dual digital displays at
1920x1200 (single-link).
NVIEW advanced multi-display desktop and application management
seamlessly integrated into Microsoft® Windows®

OGL 2.1 & DX10 Support; Shader Model 4.0
Genuine Windows Vista Business(64-bit and 32-bit), Microsoft Windows XP

Professional(64-bit and 32-bit)(Provides full native Dual View mode, Span or
Big Desktop mode, and Clone mode )
Red Hat Enterprise Linux(RHEL) WS3, WS4 & 5 Desktop/Workstation
HP qualified drivers may be preloaded or available from the HP support web
site:

http://welcome.hp.com/country/us/eng/software_drivers.html

Novell SUSE Linux Enterprise drivers may be obtained from:

ftp://download.nvidia.com/novell or http://www.nvidia.com

Color planes: 32-bit color buffer
Overlay planes: Hardware supported

NVIDIA Quadro NVS 290 (256 MB DH) PCIe Graphics Card with full
height bracket attached, DMS-59 to Dual DVI cable, Workstation Software
Driver CD, documentation.

.

DA - 13276 Worldwide QuickSpecs — Version 1 — 3.30.2009

Page 34

QuickSpecs

Technical Specifications - Graphics

HP Z400 Workstation

NVIDIA Quadro FX 380
256MB Graphics Card

Form Factor
Graphics Controller
Bus Type
Memory
Connectors

Maximum Resolution

RAMDAC
Shading architecture

Supported graphics APIs

Available graphics drivers

4.376 inches (H) × 6.60 inches (L)
NVIDIA Quadro FX 380 Graphics Board
PCI Express x16, Generation 2.0
256 MB GDDR3 SDRAM unified graphics memory
2 Dual Link DVI-I

Two DVI-I to VGA adapters included
Two dual-link DVI-I outputs drive two digital displays at resolutions up to 2560

x 1600 @ 60Hz or two analog displays at resolutions up to 2048 x 1536
@ 85Hz

Dual Internal 400 MHz DAC
Full Shader Model 4.0 (OpenGL 2.1/DirectX 10 class)

Long fragment programs (unlimited instructions)
Long vertex programs (unlimited instructions)
Looping and subroutines (up to 256 loops per vertex program)
Dynamic flow control
Conditional execution

OpenGL 3.0
Direct X 10.0

Genuine Windows Vista Business(64-bit and 32-bit), Microsoft Windows XP
Professional(64-bit and 32-bit)
Red Hat Enterprise Linux(RHEL) WS4 & 5 Desktop/Workstation

HP qualified drivers may be preloaded or available from the HP support Web
site:

http://welcome.hp.com/country/us/en/support.html

Novell SUSE Linux Enterprise drivers may be obtained from:

ftp://download.nvidia.com/novell

High-level Shader
Languages

CUDA™ Parallel
Processor Cores

Power consumption

Optimized compiler for Cg and Microsoft HLSL
OpenGL 2.1 and DirectX 10 support
Open source compiler

16

33.91 Watts

or

http://www.nvidia.com

DA - 13276 Worldwide QuickSpecs — Version 1 — 3.30.2009

Page 35

QuickSpecs

Technical Specifications - Graphics

HP Z400 Workstation

ATI FirePro V3700
256MB Graphics Card

Form Factor
Graphics Controller
Bus Type
Memory
Connectors

Maximum Resolution

Shading architecture

Supported graphics APIs

Available graphics drivers

4.40 inches (H) × 6.70 inches (L) (11.18 cm (H) × 17.02 cm (L))
ATI FirePro V3700 Graphics Board
PCI Express x16, Generation 2.0
256 MB GDDR3 SDRAM unified graphics memory
2 Dual Link DVI-I

Two DVI-I to VGA adapters included
Two dual-link DVI-I outputs drive two digital displays at resolutions up to 2560

x 1600 @ 60Hz or two analog displays at resolutions up to 2048 x 1536
@ 85Hz

Full Shader Model 4.0

40 Stream Processing Units
Dynamic load balancing and resource allocation for vertex, geometry,
and pixel shaders
Common instruction set and texture unit access supported for all types
of shaders
Dedicated branch execution units and texture address processors

OpenGL 2.1
DirectX 10.1

Genuine Windows Vista Business (64-bit and 32-bit)
Microsoft Windows XP Professional (64-bit and 32-bit)

NVIDIA Quadro FX 580
512MB Graphics Card

Power consumption

Form Factor
Graphics Controller
Bus Type
Memory
Connectors

Maximum Resolution

RAMDAC
Shading architecture

HP qualified drivers may be preloaded or available from the HP support Web
site:

http://welcome.hp.com/country/us/en/support.html

Linux drivers may be obtained from:

http://ati.amd.com/support/driver.html

32 Watts

4.376 inches (H) × 6.60 inches (L)
NVIDIA Quadro FX 580 Graphics Board
PCI Express x16, Generation 2.0
512MB GDDR3 SDRAM unified graphics memory
2 DisplayPort, 1 Dual-Link DVI-I.

One DisplayPort to DVI and one DVI to VGA adapter included

('DisplayPort to VGA' and 'DisplayPort to Dual Link DVI' adapters available as
an accessory)

Two DisplayPort outputs drive two digital displays up to 2560 x 1600
One dual-link DVI-I output drives one digital display at resolutions up to
2560 x 1600 @ 60Hz or one analog display at resolutions up to

2048 x 1536 @ 85Hz
Single Internal 400 MHz DAC
Full Shader Model 4.0 (OpenGL 2.1/DirectX 10 class)

Long fragment programs (unlimited instructions)

Long vertex programs (unlimited instructions)

DA - 13276 Worldwide QuickSpecs — Version 1 — 3.30.2009

Page 36

QuickSpecs

Technical Specifications - Graphics

Supported graphics APIs

Available graphics drivers

High-level Shader
Languages

CUDA™ Parallel
Processor Cores

Power consumption

HP Z400 Workstation

Looping and subroutines (up to 256 loops per vertex program)

Dynamic flow control

Conditional execution
OpenGL 3.0

Direct X 10.0
Genuine Windows Vista Business(64-bit and 32-bit), Microsoft Windows XP

Professional(64-bit and 32-bit)
Red Hat Enterprise Linux(RHEL) WS4 & 5 Desktop/Workstation

HP qualified drivers may be preloaded or available from the HP support Web
site:

http://welcome.hp.com/country/us/en/support.html

Novell SUSE Linux Enterprise drivers may be obtained from:

ftp://download.nvidia.com/novell

Optimized compiler for Cg and Microsoft HLSL

OpenGL 2.1 and DirectX 10 support

Open source compiler
32

40 Watts

or

http://www.nvidia.com

NVIDIA Quadro FX 1800
768MB Graphics Card

Form Factor
Graphics Controller
Bus Type
Memory
Connectors

Maximum Resolution

RAMDAC
Shading Architecture

Supported Graphics APIs

Available Graphics
Drivers

4.376 inches (H) x 7.8 inches (L)
NVIDIA Quadro FX 1800 Graphics Board
PCI Express x16, Generation 2.0
768MB GDDR3 SDRAM unified graphics memory
2 DisplayPort, 1 Dual-Link DVI-I.

One DisplayPort to DVI-D and one DVI to VGA adapter included

('DisplayPort to VGA' and 'DisplayPort to Dual Link DVI' adapters available as
an accessory)

Two DisplayPort outputs drive two digital displays up to 2560 x 1600

One dual-link DVI-I output drives one digital display at resolutions up to

2560 x 1600 @ 60Hz or one analog display at resolutions up to

2048 x 1536 @ 85Hz
Single Internal 400 MHz DAC
Full Shader Model 4.0 (OpenGL 2.1/DirectX 10 class)

Long fragment programs (unlimited instructions)

Long vertex programs (unlimited instructions)

Looping and subroutines (up to 256 loops per vertex program)

Dynamic flow control

Conditional execution
OpenGL 3.0

Direct X 10.0
Genuine Windows Vista Business(64-bit and 32-bit), Microsoft Windows XP

Professional(64-bit and 32-bit)
Red Hat Enterprise Linux(RHEL) WS4 & 5 Desktop/Workstation

DA - 13276 Worldwide QuickSpecs — Version 1 — 3.30.2009

Page 37

QuickSpecs

Technical Specifications - Graphics

High-level Shader
Languages

CUDA™ Parallel
Processor Cores

Power consumption

HP Z400 Workstation

HP qualified drivers may be preloaded or available from the HP support Web
site:

http://welcome.hp.com/country/us/en/support.html

Novell SUSE Linux Enterprise drivers may be obtained from:

ftp://download.nvidia.com/novell

Optimized compiler for Cg and Microsoft HLSL

OpenGL 2.1 and DirectX 10 support

Open source compiler

64.

59 Watts

or

http://www.nvidia.com

ATI FirePro V5700
512MB Graphics Card

Form Factor
Graphics Controller
Bus Type
Memory
Connectors

Maximum Resolution

Shading architecture

Supported graphics APIs

Available graphics drivers

4.40 inches (H) × 6.70 inches (L) (11.18 cm (H) × 17.02 cm (L))
ATI FirePro V5700 Graphics Board
PCI Express x16, Generation 2.0
512 MB GDDR3 SDRAM unified graphics memory
2 DisplayPort, 1 Dual-Link DVI-I.

One DisplayPort to DVI and one DVI to VGA adapter included
('DisplayPort to VGA' and 'DisplayPort to Dual Link DVI' adapters available as
an accessory)

Two DisplayPort outputs drive two digital displays up to 2560 x 1600

One dual-link DVI-I output drives one digital display at resolutions up to

2560 x 1600 @ 60Hz or one analog display at resolutions up to

2048 x 1536 @ 85Hz
Full Shader Model 4.0

320 Stream Processing Units

Dynamic load balancing and resource allocation for vertex, geometry,

and pixel shaders

Common instruction set and texture unit access supported for all types

of shaders

Dedicated branch execution units and texture address processors
OpenGL 2.1

DirectX 10.1
Genuine Windows Vista Business (64-bit and 32-bit)

Microsoft Windows XP Professional (64-bit and 32-bit)

HP qualified drivers may be preloaded or available from the HP support Web
site:

http://welcome.hp.com/country/us/en/support.html

Linux drivers may be obtained from:

http://ati.amd.com/support/driver.html

Power consumption

DA - 13276 Worldwide QuickSpecs — Version 1 — 3.30.2009

56 Watts

Page 38

QuickSpecs

Technical Specifications - Graphics

HP Z400 Workstation

NVIDIA Quadro FX 3800

1.0GB Graphics Card
(NOT AVAILABLE UNTIL
JUNE 2009)

Form Factor

Graphics Controller
Bus Type
Memory
Connectors

Maximum Resolution

RAMDAC
Shading architecture

Supported graphics APIs

Available graphics drivers

4.376 inches (H) x 9.0 inches (L)
Single slot card

NVIDIA Quadro FX 3800 Graphics Board
PCI Express x16, Generation 2.0
1GB GDDR3 SDRAM unified graphics memory
2 DisplayPort, 1 Dual-Link DVI-I.

One DisplayPort to DVI-D and one DVI to VGA adapter included

('DisplayPort to VGA' and 'DisplayPort to Dual Link DVI' adapters available as
an accessory)

Two DisplayPort outputs drive two digital displays up to 2560 x 1600

One dual-link DVI-I output drives one digital display at resolutions up to

2560 x 1600 @ 60Hz or one analog display at resolutions up to

2048 x 1536 @ 85Hz
Single Internal 400 MHz DAC
Full Shader Model 4.0 (OpenGL 2.1/DirectX 10 class)

Long fragment programs (unlimited instructions)

Long vertex programs (unlimited instructions)

Looping and subroutines (up to 256 loops per vertex program)

Dynamic flow control

Conditional execution
OpenGL 3.0

Direct X 10.0
Genuine Windows Vista Business(64-bit and 32-bit), Microsoft Windows XP

Professional(64-bit and 32-bit)
Red Hat Enterprise Linux(RHEL) WS4 & 5 Desktop/Workstation

High-level Shader
Languages

CUDA™ Parallel
Processor Cores

Power consumption

HP qualified drivers may be preloaded or available from the HP support Web
site:

http://welcome.hp.com/country/us/en/support.html

Novell SUSE Linux Enterprise drivers may be obtained from:

ftp://download.nvidia.com/novell

Optimized compiler for Cg and Microsoft HLSL

OpenGL 2.1 and DirectX 10 support

Open source compiler
192

107.9 Watts

or

http://www.nvidia.com

DA - 13276 Worldwide QuickSpecs — Version 1 — 3.30.2009

Page 39

QuickSpecs

Technical Specifications - Graphics

HP Z400 Workstation

ATI FirePro V7750

1.0GB Graphics Card

Form Factor
Graphics Controller
Bus Type
Memory
Connectors

Maximum Resolution

Shading architecture

Supported graphics APIs

Available graphics drivers

4.40 inches (H) × 13.0 inches (L) (11.18 cm (H) × 33.02 cm (L))
ATI FirePro V7750 Graphics Board
PCI Express x16, Generation 2.0
1024 MB GDDR3 SDRAM unified graphics memory
2 DisplayPort, 1 Dual-Link DVI-I.

One DisplayPort to DVI and one DVI to VGA adapter included
('DisplayPort to VGA' and 'DisplayPort to Dual Link DVI' adapters available as
an accessory)

Two DisplayPort outputs drive two digital displays up to 2560 x 1600

One dual-link DVI-I output drives one digital display at resolutions up to

2560 x 1600 @ 60Hz or one analog display at resolutions up to

2048 x 1536 @ 85Hz
Full Shader Model 4.0

320 Stream Processing Units

Dynamic load balancing and resource allocation for vertex, geometry,

and pixel shaders

Common instruction set and texture unit access supported for all types

of shaders

Dedicated branch execution units and texture address processors
OpenGL 2.1

DirectX 10.1
Genuine Windows Vista Business (64-bit and 32-bit)

Microsoft Windows XP Professional (64-bit and 32-bit)

Power consumption

HP qualified drivers may be preloaded or available from the HP support Web
site:

http://welcome.hp.com/country/us/en/support.html

Linux drivers may be obtained from:

http://ati.amd.com/support/driver.html

76 Watts

DA - 13276 Worldwide QuickSpecs — Version 1 — 3.30.2009

Page 40

QuickSpecs

Technical Specifications - Graphics

HP Z400 Workstation

NVIDIA Quadro FX 4800

1.5GB PCIe Graphics
Card

Form Factor

Graphics Controller
Bus Type
Memory
Connectors

Maximum Resolution

Shading Architecture

Supported Graphics APIs

Available Graphics
Drivers

4.36" (H) x 10.5" (L)
Dual slot card

NVIDIA Quadro FX 4800 graphics board
PCI Express x16, Generation 2.0

1.5 GB GDDR3 SDRAM unified graphics memory
2 DisplayPort, 1 Dual-Link DVI-I, 1 3-pin Mini DIN stereo output, Two

DisplayPort to DVI-D adapters included
('DisplayPort to VGA' and 'DisplayPort to Dual Link DVI' adapters available as
an accessory)

2 DisplayPort connectors support ultra-high-resolution panels (up to

2560 x 1600)

Dual-link DVI-I output drives one digital display at resolutions up to

2560 x 1600 @ 60Hz

Internal 400 MHz DACs-One analog display up to 2048 x 1536 @

85Hz

Full Shader Model 4.0 (OpenGL 2.1/DirectX 10 class)

Long fragment programs (unlimited instructions)

Long vertex programs (unlimited instructions)

Looping and subroutines (up to 256 loops per vertex program)

Dynamic flow control

Conditional execution
OpenGL 3.0

Direct X 10.0
Genuine Windows Vista Business (64-bit and 32-bit)

Microsoft Windows XP Professional (64-bit and 32-bit)
Red Hat Enterprise Linux(RHEL) WS4 & 5 Desktop/Workstation

High-Resolution
AntiAliasing

High-level Shader
Languages

CUDA™ Parallel
Processor Cores

Power consumption

HP qualified drivers may be preloaded or available from the HP support Web
site:

http://welcome.hp.com/country/us/en/support.html

Novell SUSE Linux Enterprise drivers may be obtained from:

ftp://download.nvidia.com/novell

Rotated Grid Full-Scene Antialiasing (RG FSAA)

32xFSAA dramatically reduces visual aliasing artifacts or "jaggies" at

resolution up to 1920 x 1200

64x FSAA SLI Mode

Optimized compiler for Cg and Microsoft HLSL

OpenGL 2.1 and DirectX 10 support

Open source compiler
192

146 Watts

or

http://www.nvidia.com

DA - 13276 Worldwide QuickSpecs — Version 1 — 3.30.2009

Page 41

QuickSpecs

Technical Specifications - Graphics

HP Z400 Workstation

NVIDIA Quadro CX

Form Factor

Graphics Controller
Bus Type
Memory
Connectors

Maximum Resolution

RAMDAC
Shading Architecture

Supported Graphics APIs

Available Graphics
Drivers

4.36" (H) x 10.5" (L)
Dual slot card

NVIDIA Quadro CX 1.5GB Graphics Card
PCI Express x16, Generation 2.0

1.5 GB GDDR3 SDRAM unified graphics memory
2 DisplayPort, 1 Dual-Link DVI-I, 1 3-pin Mini DIN stereo output.

Two DisplayPort to DVI-D adapters included

('DisplayPort to VGA' and 'DisplayPort to Dual Link DVI' adapters available as
an accessory)

2 DisplayPort connectors support ultra-high-resolution panels (up to

2560 x 1600)

Dual-link DVI-I output drives one digital display at resolutions up to

2560 x 1600 @ 60Hz

Internal 400 MHz DACs-One analog display up to 2048 x 1536 @

85Hz
400MHz

Full Shader Model 4.0 (OpenGL 2.1/DirectX 10 class)

Long fragment programs (unlimited instructions)

Long vertex programs (unlimited instructions)

Looping and subroutines (up to 256 loops per vertex program)

Dynamic flow control

Conditional execution
OpenGL 3.0

Direct X 10.0
Genuine Windows Vista Business (64-bit and 32-bit)

Microsoft Windows XP Professional (64-bit and 32-bit)

High-Resolution
AntiAliasing

High-level Shader
Languages

CUDA™ Parallel
Processor Cores

Power consumption

HP qualified drivers may be preloaded or available from the HP support Web
site:

http://welcome.hp.com/country/us/en/support.html

Rotated Grid Full-Scene Antialiasing (RG FSAA)

32xFSAA dramatically reduces visual aliasing artifacts or "jaggies" at

resolution up to 1920 x 1200

64x FSAA SLI Mode

Optimized compiler for Cg and Microsoft HLSL

OpenGL 2.1 and DirectX 10 support

Open source compiler
192

146 Watts

DA - 13276 Worldwide QuickSpecs — Version 1 — 3.30.2009

Page 42

QuickSpecs

Technical Specifications - Multimedia and Audio Devices

HP Z400 Workstation

Integrated Intel/Realtek
HD ALC262 Audio

Type
High Definition Codec
FM Synthesis Support
OPL3 FM Synthesis

Support
Sound Blaster

Compatibility
Meets Premium

performance for Windows
Logo Program 3.0

Audio Jacks

Sampling

Wavetable Syntheses
(software)

3D Positional Sound
Digital Audio
Analog Audio
DVD Audio
Number of Channels on

Line-Out
Internal Audio Speaker

Power Rating
Internal Speaker
Hardware Equalizer for

Internal Speaker
External Speaker Jack

(Line-Out)

Integrated
Yes
Yes
Yes

Yes

Yes

Front panel microphone in and headphone out - fixed usage.
Rear panel line in and line out jacks - jacks are retaskable
One Line-In* (12-K ohm Input Impedance)*

NOTE:

3 stereo ADCs support 16/20-bit PCM format with 44.1K/48K/96kHz
sample rate
2 stereo DAC supports 16/20/24-bit PCM format with

44.1K/48K/96K/192kHz sample rate
Yes – GM and FM Midi Support, Direct Music and Down Loadable Soundset

(4 Meg DLS Level 1 and 2 Support)
No
Yes
Yes
Yes
Stereo (Left & Right channels)

1.5 W

Yes
No

Yes

External Speakers need to be powered externally.

DA - 13276 Worldwide QuickSpecs — Version 1 — 3.30.2009

Page 43

QuickSpecs

Technical Specifications - Multimedia and Audio Devices

HP Z400 Workstation

HP Thin USB Powered
Speakers

SoundBlaster (Creative
Labs) X-Fi Titanium PCIe
Audio Card

Frequency Response
3dB, 24-bit/96kHz input)

Dimensions
On/Off/Volume Controls
Power LED
Watts
Net weight
Environmental

conditions non-condensing)

Speaker cable length

Color
Kit Contents

24-bit Analog-to-Digital
conversion of analog
inputs

24-bit Digital-to-Analog
conversion of digital
sources

24-bit Digital-to-Analog
conversion of stereo
digital sources

16-bit to 24-bit recording
sampling rates

Enhanced SoundFont
support

Signal-to-Noise Ratio
(2okHz Low-pass filter, A­Weighted)

Total Harmonic Distortion
+ Noise at 1kHz
Low-pass filter)

Frequency Response
3dB, 24-bit/96kHz input)

Frequency Response
3dB, 24-bit/192kHz
input)

Speaker and Headphone
connections

Flexijack
Front Panel Header

(-

(all

(20kHz

(-

(-

FO to 20kHz

Speakers: 5.72 x 3.74 x 0.96 in (14.52 x 9.50 x 2.45 cm) per speaker
Right side of right speaker
Front of right speaker (green)
2/3 watt (normal/maximum)

0.68 lbs (0.31kg)
Temperature
Relative Humidity

(operating):
Input cord: 5.91 ft (1800mm±35mm)

L-channel cord: 3.28 ft (1000mm±35mm)
USB cord: 5.91 ft (1800mm±35mm)

HP Carbonite
One pair of HP Thin USB Powered Speakers with attached audio signal and

USB power cables for connecting to your PC
HP Warranty documentation

96kHz sample rate

96kHz to analog 7:1 speaker output

8, 11.025, 16, 22.05, 24, 32, 44.1, 48 and 96kHz

16-bit/44.1kHz, 16-bit/48kHz, 24-bit/44.1kHz, 24-bit/48kHz and 24­bit/96kHz with direct monitoring

Up to 24-bit resolution

109dB

.004%

10Hz to 46kHz

10Hz to 46kHz

Stereo to 7.1 (Line Out via three 3.5mm mini jacks)

Line In/ Microphone In/Optical Out via shared 3.5mm mini jack
Intel HD Audio Compatible (2x5 pin)

(operating):

14° to 104° F (-10° to 40° C)
40% to 90%

DA - 13276 Worldwide QuickSpecs — Version 1 — 3.30.2009

Page 44

QuickSpecs

Technical Specifications - Multimedia and Audio Devices

HP Z400 Workstation

Operating System

Minimum System
Requirements

Microsoft Windows Vista Business 64
Microsoft Windows Vista Business 32
Microsoft® Windows® XP Professional SP2
Microsoft Windows XP Professional x64 Edition

System RAM
Operating System

512MB
Windows Vista 32-bit and 64-bit version or

Windows XP 32-bit or 64-bit version

DA - 13276 Worldwide QuickSpecs — Version 1 — 3.30.2009

Page 45

QuickSpecs

Technical Specifications - Optical and Removable Storage

HP Z400 Workstation

NOTE 1
materials. Intended for creation and storage of your original material and other lawful uses. Double Layer discs can store more data
than single layer discs. However, double-layer discs burned with this drive may not be compatible with many existing single-layer
DVD drives and players.

HP DVD-ROM Drive

: Actual speeds may vary. Does not permit copying of commercially available DVD movies or other copyright protected

Description
Mounting Orientation
Interface Type
Dimensions
Disc Capacity

Access Times

Power

Operating Environmental
(all conditions non­condensing)

(WxHxD)

5.25-inch, half-height, tray-load
Either horizontal or vertical
SATA/ATAPI

5.9 x 1.7 x 8.0 in (15.0 x 4.4 x 20.3 cm)
DVD-ROM

DVD-ROM Single Layer
CD-ROM Mode 1
Full Stroke DVD
Full Stroke CD
Source
DC Power Requirements

DC Current

Temperature
Relative Humidity
Maximum Wet Bulb

Temperature
Operating Systems

Supported

Single layer: Up to 4.7 GB Double layer: Up to

8.5 GB
< 140 ms (typical)
< 125 ms (typical)
< 250 ms (seek)
< 210 ms (seek)
SATA DC power receptacle
5 VDC ± 5%-100 mV ripple p-p

12 VDC ± 5%-200 mV ripple p-p
5 VDC - <1000 mA typical, < 1600 mA

maximum
12 VDC - < 600 mA typical, < 1400 mA
maximum

41° to 122° F (5° to 50° C)
10% to 90%
86° F (30° C)

Windows Vista Business 64* Windows Vista
Business 32*, Windows Vista Home Basic 32*,
Windows 2000, Windows XP Professional or
Windows XP Home 32*.
Red Hat Enterprise Linux(RHEL) WS3, WS4, 5
Desktop/Workstation
Novell SLES 9 & SLE 10
No driver is required for this device. Native
support is provided by the operating system.

* Certain Windows Vista product features
require advanced or additional hardware.
Windows Vista Upgrade Advisor can help you
determine which features of Windows Vista will
run on your computer. To download the tool,
visit:

http://www.windowsvista.com/
upgradeadvisor

requirements, visit:

http://www.windowsvista.com/
systemrequirements

DA - 13276 Worldwide QuickSpecs — Version 1 — 3.30.2009

. For Windows Vista system

.

Page 46

QuickSpecs

Technical Specifications - Optical and Removable Storage

HP Z400 Workstation

HP DVD+/-RW Drive

Description
Mounting Orientation
Interface Type
Dimensions
Disc Formats

Disc Capacity

Maximum Data Transfer
Rates

Power

Operating Environmental
(all conditions non­condensing)

(WxHxD)

5.25-inch, half-height, tray-load
Either horizontal or vertical
SATA/ATAPI

5.9 x 1.7 x 8.0 in (15.0 x 4.4 x 20.3 cm)
DVD-RAM

DVD+R
DVD+RW
DVD+R DL
DVD-R DL
DVD-R
DVD-RW
CD-R
CD-RW

DVD-ROM
Full Stroke DVD
Full Stroke CD
CD ROM Read

DVD ROM Read

Source
DC Power Requirements

DC Current

Temperature
Relative Humidity
Maximum Wet Bulb

Temperature
Operating Systems

Supported

8.5 GB DL or 4.7 GB standard
< 250 ms (seek)
< 210 ms (seek)
CD-ROM, CD-R Up to 40X

CD-RW Up to 32X
DVD-RAM
DVD+RW
DVD-RW
DVD+R DL
DVD-R DL
DVD-ROM
DVD-ROM DL
DVD+R
DVD-R
SATA DC power receptacle
5 VDC ± 5%-100 mV ripple p-p

12 VDC ± 5%-200 mV ripple p-p
5 VDC -1000 mA typical, 1600 mA maximum

12 VDC -600 mA typical, 1400 mA maximum
41° to 122° F (5° to 50° C)
10% to 90%
86° F (30° C)

Windows Vista Business 64*, Windows Vista
Business 32*, Windows Vista Home Basic 32*,
Windows 2000, Windows XP Professional or
Windows XP Home 32*.
Red Hat Enterprise Linux(RHEL) WS3, WS4, 5
Desktop/Workstation
Novell SLES 9 & SLE 10
No driver is required for this device. Native support
is provided by the operating system.

Up to 12X
Up to 8X
Up to 8X
Up to 8X
Up to 8X
Up to 16X
Up to 8X
Up to 16X
Up to 16X

DA - 13276 Worldwide QuickSpecs — Version 1 — 3.30.2009

Page 47

QuickSpecs

Technical Specifications - Optical and Removable Storage

Kit Contents

HP Z400 Workstation

* Certain Windows Vista product features require
advanced or additional hardware. Windows Vista
Upgrade Advisor can help you determine which
features of Windows Vista will run on your
computer. To download the tool, visit:

http://www.windowsvista.com/upgradeadvisor

For Windows Vista system requirements, visit:

http://www.windowsvista.com/
systemrequirements

* LightScribe functionality is not natively supported
by Linux distributions. Customers may download
LightScribe Linux drivers from:

http://www.lightscribe.com/
downloadSection/linux/index.aspx

HP SATA SuperMulti LightScribe DVD Writer drive,
LightScribe software, Roxio Easy Media Creator
software, Intervideo WinDVD Software, installation
guide, and DVD+R media.

.

.

HP Blu-Ray Writer

Description
Mounting Orientation
Interface Type
Dimensions
Disc Formats

Disc Capacity

(WxHxD)

5.25-inch, half-height, tray-load
Either horizontal or vertical
SATA

5.9 x 1.7 x 8.0 in (15.0 x 4.4 x 20.3 cm)
BD-ROM

BD-R
BD-RE
DVD-RAM
DVD+R
DVD+RW
DVD+R DL
DVD-R DL
DVD-R
DVD-RW
CD-R
CD-RW

DVD-ROM
Blu-ray
Full Stroke DVD
Full Stroke CD
Blu-ray
Startup Time

ready from tray loading)

(Time to drive

8.5 GB DL or 4.7 GB standard
50 GB DL or 25 GB standard
< 250 ms (seek)
< 210 ms (seek)
Blu-ray
BD-ROM (SL/DL)
BD-R (SL/DL)
BD-RE (SL/DL)
DVD-ROM (SL/DL)
DVD-R (SL/DL)
DVD-RW

25S / 28S
25S / 28S
25S / 28S
18S / 18S
25S / 25S
25S

DA - 13276 Worldwide QuickSpecs — Version 1 — 3.30.2009

Page 48

QuickSpecs

Technical Specifications - Optical and Removable Storage

HP Z400 Workstation

Maximum Data Transfer
Rates

Power

Operating Environmental
(all conditions non­condensing)

CD ROM Read

DVD ROM Read

Blu-Ray

Source
DC Power Requirements

DC Current

Temperature
Relative Humidity
Maximum Wet Bulb

Temperature
Operating Systems

Supported

DVD+R (SL/DL)
DVD+RW
DVD-RAM
CD-ROM
CD-ROM

CD-R
CD-RW

DVD-RAM
DVD+RW
DVD-RW
DVD+R DL
DVD-R DL
DVD-ROM
DVD-ROM DL
DVD+R
DVD-R
BD-ROM
BD-ROM DL
BD-R
BD-R DL
BD-R
BD-RE SL/DL
SATA DC power receptacle
5 VDC ± 5%-100 mV ripple p-p

12 VDC ± 10%-100 mV ripple p-p
5 VDC -900 mA typical, 1200 mA maximum

12 VDC -1000 mA typical, 1600 mA maximum
41° to 122° F (5° to 50° C)
15% to 80%
86° F (30° C)

Windows Vista Business 64*, Windows Vista
Business 32*, Windows Vista Home Basic 32*,
Windows 2000, Windows XP Professional or
Windows XP Home 32*.
Red Hat Enterprise Linux(RHEL) WS3, WS4, 5
Desktop/Workstation
Novell SLES 9 & SLE 10

25S / 25S
25S
45S
45S
Up to 40X

Up to 40X
Up to 40X

Up to 5X
Up to 10X
Up to 10X
Up to 8X
Up to 8X
Up to 16X
Up to 8X
Up to 12X
Up to 12X
Up to 6X
Up to 4.8X
Up to 6X
Up to 4.8X
Up to 6X
Up to 4.8X

No driver is required for this device. Native
support is provided by the operating system.

Kit Contents

Disclaimer

DA - 13276 Worldwide QuickSpecs — Version 1 — 3.30.2009

As Blu-Ray is a new format containing new technologies, certain disc, digital
connection, compatibility and/or performance issues may arise, and do not

HP Blue Laser RW Drive, LightScribe software,
Roxio Easy Media Creator software, Intervideo
WinDVD Software, installation guide.

Page 49

QuickSpecs

Technical Specifications - Optical and Removable Storage

constitute defects in the product. Flawless playback on all systems is not
guaranteed. In order for some Blu-Ray titles to play, they may require a DVI or
HDMI digital connection and your display may require HDCP support. HD­DVD movies cannot be played on this workstation.

HP Z400 Workstation

HP 22-in-1 Media Card
Reader

Description

Mounting Orientation

Interface Type

Dimensions
Disc Formats

(WxHxD)

The Media Card Reader device uses the same physical form factor and
mounting as a Floppy Disk Drive. The device connects to a 2x5 two-channel
USB header on the motherboard of the system. There is no USB controller
card provided. Please see the Disc Formats section below for a list of flash
memory card formats that are supported.

The Media Card Reader can be mounted in a dedicated Floppy Drive bay (if
the chassis provides one) or in an appropriate Optical Bay adapter. It will
operate in any orientation.

USB 2.0 (one channel dedicated to the separate USB port; one channel
dedicated to the flash memory card slots)

4.9 x 4.0 x 1.0 in (124.5 x 101.6 x 25.4 mm)
xD-Picture

Micro SD
Micro SDHC
SD
SDHC
Mini SD
Mini SDHC
MultiMediaCard (MMC)
Reduced Size MultiMediaCard (RS MMC)
MultiMedia Card 4.2 (MMC Plus, including MMC Plus HC)
Reduced Size MultiMedia Card 4.2 (MMC Mobile, including MMC Mobile
HC)
CompactFlash Card Type I
CompactFlash Card Type II
MicroDrive
Memory Stick (MS)
MagicGate Memory Stick (MG)
MagicGate Memory Stick Duo
Memory Stick Select
Memory Stick Duo (MS Duo)
Memory Stick PRO (MS PRO)
Memory Stick PRO Duo (MS PRO Duo)
Memory Stick PRO-HG Duo

Two additional formats are usable with adapters (not supplied):
MMC Micro
Memory Stick Micro (M2)

DA - 13276 Worldwide QuickSpecs — Version 1 — 3.30.2009

Page 50

QuickSpecs

Technical Specifications - Controller Cards

HP Z400 Workstation

HP FireWire/IEEE 1394a
PCI Card

Data Transfer Rate
Device Interface Protocol
Devices Supported
Bus Type
Certification Level

Ports
Internal Connectors
System Requirements

Burst Data Rate up to 400 Mbps
IEEE-1394a
IEEE-1394 compliant devices
PCI card with brackets for low profile and full height PCI slots.
FCC Part 15B, cULus 60950, CE Mark EN55022B(1995)/EN55024-

1998 STD, Taiwan BSMI CNS13438, Korea MIC
Two IEEE 1394 6-Pin Connector (Rear)
One 10-Pin (9 Contacts) Custom Connector
Windows Vista Business 64*, Windows Vista Business 32*, Windows Vista

Home Basic 32*, Windows 2000, Windows XP Professional or Windows
XP Home 32*. No driver is required for this device. Native support is
provided by the operating system.

* Certain Windows Vista product features require advanced or additional
hardware. Windows Vista Upgrade Advisor can help you determine which
features of Windows Vista will run on your computer. To download the tool,
visit:

http://www.windowsvista.com/upgradeadvisor

system requirements, visit:

http://www.windowsvista.com/systemrequirements

. For Windows Vista

.

Temperature - Operating
Temperature - Storage
Relative Humidity -

Operating
Operating Systems

Supported

Pentium II 266 or above
128-MB RAM
1-GB Hard Drive
CD-ROM drive
Built-in sound system
Available PCI slot

50° to 131° F (10° to 55° C)

-22° to 140° F (-30° to 60° C)
20% to 80%

Windows Vista Business 64*, Windows Vista Business 32*, Windows Vista
Home Basic 32*, Windows 2000, Windows XP Professional or Windows
XP Home 32

* Certain Windows Vista product features require advanced or additional
hardware. Windows Vista Upgrade Advisor can help you determine which
features of Windows Vista will run on your computer. To download the tool,
visit:

http://www.windowsvista.com/upgradeadvisor

system requirements, visit:

http://www.windowsvista.com/systemrequirements

*

. For Windows Vista

.

DA - 13276 Worldwide QuickSpecs — Version 1 — 3.30.2009

Page 51

QuickSpecs

Technical Specifications - Controller Cards

HP Z400 Workstation

HP IEEE 1394b FireWire
PCIe Card

Data Transfer Rate
Devices Supported
Bus Type
Ports
Internal Connectors
System Requirements

Temperature – Operating
Temperature – Storage
Relative Humidity –

Operating
Compliances

Operating Systems
Supported

Supports up to 800 Mbps
IEEE-1394 compliant devices
PCIe card full height PCIe slots
Two IEEE-1394b bilingual 9-Pin Connector (Rear)
One 10-Pin header Custom Connector
Microsoft Windows XP Professional, Windows XP Home, Windows Vista.

Not supported on Linux. Pentium® III or higher processor 128-MB RAM 1-GB
Hard Drive CD-ROM drive Built in sound system Available PCI slot

50° to 131° F (10° to 55° C)
–22° to 140° F (–30° to 60° C)
20% to 80%

FCC Part 15B, cULus 60950, CE Mark EN55022B(1995)/EN55024­1998 STD, Taiwan BSMI CNS13438, Korea MIC

Microsoft Windows XP and Windows Vista

DA - 13276 Worldwide QuickSpecs — Version 1 — 3.30.2009

Page 52

QuickSpecs

Technical Specifications - Networking and Communications

HP Z400 Workstation

NOTE 1
operating speed of 1 Gb/sec. For high speed transmission, connection to a Gigabit Ethernet server and network infrastructure is
required.

Integrated Broadcom
5764 PCIe LOM
Controller

Broadcom (5761)
NetXtreme Gigabit
Ethernet Plus NIC

: "Gigabit" Ethernet indicates compliance with IEEE standard 802.3ab for Gigabit Ethernet, and does not connote actual

Connector
Data Rates Supported
Bus Architecture
Alerting

Connector
Controller
Memory
Data Rates Supported
Compliance
Bus Architecture
Data Path Width
Data Transfer Mode
Hardware Certifications

Power Requirement
Boot ROM Support
Network Transfer Mode

Network Transfer Rate

Operating Temperature
Operating Humidity
Dimensions
Operating System Driver

Support
Management Capabilities

Kit Contents

RJ45
10/100/1000BT
PCIe X1
ASF 2.0

RJ-45
Broadcom 5761 PCI-Express LAN Controller
8 MB NVRAM serial Flash
10/100/1000 Mbps
IEEE 802.1P, 802.1Q, 802.2, 802.3, 802.3AB, 802.3u, and 802.3x
PCI-Express
Single Channel PCI-Express
Bus Master DMA
FCC class B, Canada and US NRTL Mark, C-Tick for Australia, BSMI for

Taiwan, VCCI for Japan, MIC for Korea, GOST for Russia, UL listed
(E212044), European Union Notice (CE 0682)

1.8W @ 3.3V
Yes
Full-duplex

Half-duplex (not available for the 1000BASE-T transceiver)
10BASE-T (half-duplex) 10 Mbps

10BASE-T (full-duplex) 20 Mbps
100BASE-TX (half-duplex) 100 Mbps
100BASE-TX (full-duplex) 200 Mbps
1000BASE-T (full-duplex) 2000 Mbps

32° to 131°F (0° to 55° C)
131° F (55° C) with 5% to 95% non-condensing humidity

2.75 in x 4.13 in (7 cm x 10.5 cm), low profile compatible
Windows Vista 32-bit SP1, Windows Vista x64 SP1, Windows XP 32 bit

professional, Windows XP x64 .
ACPI, WOL and DMI 2.0, PXE 2.0, WfM 2.0, Broadcom mgmt utility,

ASF2.0, DASH 1.0 and DASH 1.1 profiles
Broadcom NetXtreme Gigabit Ethernet Plus NIC, Broadcom NetXtreme

Gigabit Ethernet Plus NIC USB Cable Assembly, CD, drivers, quick install
guide, product warranty statement

DA - 13276 Worldwide QuickSpecs — Version 1 — 3.30.2009

Page 53

QuickSpecs

Technical Specifications - Networking and Communications

HP Z400 Workstation

Intel Gigabit CT Desktop
NIC

Connector
Controller
Memory
Data Rates Supported
Compliance

Bus Architecture
Data Path Width
Data Transfer Mode
Hardware Certifications

Power Requirement
Boot ROM Support
Network Transfer Rate

Operating Temperature
Operating Humidity
Dimensions
Operating System Driver

Support

Management Capabilities
Kit Contents

RJ-45
Intel WG82574L Gigabit Ethernet Controller
Integrated Dual 48K configurable transmit receive FIFO Buffers
10/100/1000 Mbps
IEEE 802.1P, 802,1Q, 802.2, 802.3, 802.3AB and 802.3u compliant,

802.3x flow control
PCI-E 1.0a
X1, 250 MB/s, Bi-directional interface
Bus-master DMA
FCC, B, CE, TUV- cTUVus Mark Canada and United States, TUV- GS Mark

for European Union
Aux 3.3V, 3.0 Watts in 1000base-T and 2.0 Watts in 100Base-T
Yes
10BASE-T (half-duplex) 10 Mbps

10BASE-T (full-duplex) 20 Mbps
100BASE-TX (half-duplex) 100 Mbps
100BASE-TX (full-duplex) 200 Mbps
1000BASE-T (full-duplex) 2000 Mbps

32° to 131°F (0° to 55° C)
85% at 131° F (55° C)

4.75 x 2.25 x 0.8 in (12.1 x 5.7 x 2.0 cm)
Windows Vista Business 64, Windows Vista Business 32, Windows XP

Professional, Windows XP x64.
Red Hat Enterprise Linux 4, Red Hat Enterprise Linux 5.

WOL , PXE, DMI, WFM 2.0
Intel Gigabit CT Desktop NIC, low profile bracket, CD containing Intel

PROset II NIC drivers, quick install guide, product warranty statement

© Copyright 2009 Hewlett-Packard Development Company, L.P.
The information contained herein is subject to change without notice.

All rights reserved. Microsoft, Windows, Windows Vista, and Windows XP are registered trademarks or trademarks of Microsoft
Corporation in the U.S. and/or other countries. Intel, the Intel logo, Pentium, and Pentium Inside are trademarks or registered
trademarks of Intel Corporation or its subsidiaries in the United States and other countries. Linux is a registered trademark of Linus
Torvalds in the United States and other countries.

Warranty - year(s) Protected by HP Services, including a 3 years parts, 3 years labor, and 3 years onsite service (3/3/3) standard
warranty. Terms and conditions vary by country. Certain restrictions and exclusions apply.

DA - 13276 Worldwide QuickSpecs — Version 1 — 3.30.2009

Page 54
