QuickSpecs
HP Z38c 37.5-inch Curved Display
Technical Specifications
c05591685—DA 16029— Worldwide — Version 4 — December 14, 2017
Page 1
HP Z38c 37.5-inch Curved Display
1.
Menu button
Press to open the OSD menu, select a menu item from the OSD, or close the OSD menu.
2.
Function buttons
Use these buttons to navigate through the OSD menu based on the indicators above the buttons that are activated when the OSD menu is open.
3.
Power/LED
Press to turn the monitor on or off. When the monitor is on, the power light above the power button is on.
LED:
Fully powered = white Sleep mode = amber Sleep timer mode = flashing amber
Cable Management
Effortless routing of cables through the cable management tunnel at the base of the column NOTE: Function buttons can be configured in the OSD menu to quickly select the most commonly used operations.
QuickSpecs
HP Z38c 37.5-inch Curved Display
Technical Specifications
c05591685—DA 16029— Worldwide — Version 4 — December 14, 2017
Page 2
1.
Master power switch
Turns off all power to the monitor
2.
Power Connector
Connects AC power
3.
HDMI 2.0 port
Connects an HDMI cable to the source device
4.
DisplayPort™ 1.2 (input)
Connects a DisplayPort cable to the source device
5.
Audio out (headphone) jack
Connects optional powered stereo speakers, headphones, earbuds, a headset, or a television audio cable
6.
USB Type-A ports (2) (downstream)
Connects a USB device (no battery charging)
7.
Security cable slot
Connects a security cable to a stationary object
8.
USB Type-A port with battery charging 1.2 (downstream)
Connects a USB Type-A cable to the source device (delivers 5Volts / 2 Amps conforming to the BC1.2 standard)
9.
USB Type-C port (upstream & downstream)
Connects a USB Type-C cable to the source device (5v(3A), 5.25v(3A),9V(3A), 12v(3A), 15V(3A), 20v(3.25A)
NOTE: The USB Type-C port can also function as a USB downstream port when connected to a USB Type-C source device.
The USB Type-C port can function as a DisplayPort audio/video input, as a USB 3.0 upstream connection, or it can be used to deliver up to 65 watts of power to a device. Power outputs are 5V/3A, 5.25V/3A, 9V/3A, 10V/3A, 12V/3A, 15V/3A, 20V/3.25A to achieve 15W, 5.75W, 27W, 30W, 36W, 45W, 65W output for HP qualified E-MARK Cable and only 5V/3A to achieve 15W output for the other cable.
QuickSpecs
HP Z38c 37.5-inch Curved Display
Technical Specifications
c05591685—DA 16029— Worldwide — Version 4 — December 14, 2017
Page 3
Models: Z4W65AA, Z4W65A4 Panel
Type
37.5-inch IPS, LED Backlit
Viewable Image Area (diagonal)
95,29 cm (37.5 in) widescreen; diagonally measured
Panel Active Area (W x H)
87,97 x 36,65 cm (34.64 × 14.43 in.) Panel Type
IPS
Micro-Edge Bezel
Yes, 3-sided
Curved Panel
Yes, 2300r
Hardness
3H
Resolution
3840 x 1600 @ 60Hz
Aspect Ratio
21:9
Viewing Angle (typical)
Up to 178° horizontal/178° vertical (10:1 minimum contrast ratio)
Brightness (typical)*
300 cd/m²
Contrast Ratio (typical)*
1,000:1
Dynamic Contrast Ratio (typical)*
5,000,000:1
Response Time (typical)*,***
5ms Gray to Gray
***Product default is 14ms response time and can be adjusted to as low as 5ms in the display menu. See user guide for more information.
Pixel Pitch
0.22908 X 0.22908 mm
Pixels Per Inch (PPI)
100.93
Backlight Lamp Life (to half brightness)
30,000 hours minimum
Panel Bit Depth**
10-bit, Up to 1.07 billion colors
Color Gamut
98% of sRGB
*All performance specifications represent the typical specifications provided by HP's component manufacturers; actual performance may vary either higher or lower. **8+2 With the use of FRC technology.
User Controls
On Screen Display (OSD) User Controls
Brightness, Contrast, Color Control, Input Control, Image Control, Power Control, Menu control, Management, Language, Information
Monitor Control Buttons or Switches
Menu, Minus ("-")/Color Control, Plus ("+") /Viewing Modes, Back/Next Active Input, Power
User-Assignable Function Buttons
Yes, 10
Languages
10 (English, Spanish, German, French, Italian, Netherlands, Portuguese, Japanese, T-Chinese and S-Chinese)
Color Management
Factory Color Calibrated
Yes
Factory Calibration Accuracy
White Point Maximum
3.0 ∆E 2000
Grayscale Average (255 levels) Maximum
3.0 ∆E 2000
Gamma Target Tolerance (2.2 for sRGB, 2.4 for BT.709)
±0.1
X-Rite ColorChecker Average Maximum
3.0 ∆E 2000
Signal Interface/ Performance
27-130 kHz
Vertical Frequency
24-76Hz
Native Resolution
3840 x 1600 @ 60Hz
Preset VESA Graphic Modes (non­interlaced)
640 x 480 @60Hz 720 x 400 @70Hz 800 x 600 @60Hz 720 x 480 @60Hz
QuickSpecs
HP Z38c 37.5-inch Curved Display
Technical Specifications
c05591685—DA 16029— Worldwide — Version 4 — December 14, 2017
Page 4
1024 x 768 @60Hz 1280 x 720 @60Hz 1280 x 1024 @60Hz 1440 x 900 @60Hz 1600 x 900 @60Hz 1600 x 1200 @60Hz 1680 x 1050 @60Hz 1920 x 1080 @60Hz 1920 x 1200 @60Hz 1920 x 1600 @60Hz 2560 x 1080 @60Hz 2560 x 1600 @60Hz 3840 x 1600 @60Hz 3840 x 1600 @30Hz Maximum Pixel Clock Speed
600 MHz
Anti-Glare
Yes
Flicker Free
Yes
Default Color Temperature
D65
Connector Types
DisplayPort™
(1) DisplayPort 1.2
HDMI
(1) HDMI 2.0
USB Type-C™
(1) USB Type-C™
HDCP support
Yes, all video inputs
Audio
(1) Audio out (analog)
USB Port Specifications
USB Version
3.0
Location
(2) bottom, (1) side (see illustration on page 2)
USB Hub
Yes
Downstream Ports
3, USB3.0 Type A
Upstream Ports
1, Type-C™
Fast Charging USB Ports
1 Ports (side)
Power Output Maximum
PD 65w via USB Type-C™
USB-Type C™ Port Specifications
USB-Type C™ Version
USB 3.1 Gen1 / 5G bps
Location
Side (see illustration on page 2)
USB-Type C™ Hub
Yes
USB-Type C™ Ports (Upstream and Downstream) *
1
*The USB Type-C port can also function as a USB downstream port when connected to a USB Type-C source device.
Video Support
USB-C Alt mode - DisplayPort™ 1.2
Power Output
5V/5.25V/9V/10V/12V/15V, 3A. 20V 3.25A
Power Output Maximum
65w
Power Supply
Internal
Input Power
100 – 240 VAC at 50/60 Hz Typical Power1
80 W
Maximum Power2
195 W
Energy Saving/Standby Mode
0.5 W
VIDEO/OTHER INPUTS
POWER
QuickSpecs
HP Z38c 37.5-inch Curved Display
Technical Specifications
c05591685—DA 16029— Worldwide — Version 4 — December 14, 2017
Page 5
Mechanical
Dimensions (W x D x H)
Unpacked w/stand
(highest stand setting)
89,55 x 24,80 x 55,87 cm (35.26 x 9.76 x 22 in)
Unpacked w/o stand
(head only)
89,55 x 10,42 x 39,95 cm (35.26 x 4.10 x 15.73 in)
Packaged
106 x 45,2 x 55,5 cm
(41.73 x 17.8 x 21.85 in)
Weight
Head Only
9,8 kg (21.56 lb)
Unpacked
13,8 kg (30.36 lb)
Packaged
21 kg (46.26 lb) Plug and Play
Yes
Color
Black
Cable Management
Enhanced cable management for easy concealment of power, video and USB cables. Effortless routing of cables through the cable management tunnel at the base of the column.
Detachable Stand
Yes
Tilt Range
–5° to + 20° vertical
Swivel Range
45°L to 45°R
Display height adjustment:
Adjustment Range: 120 mm
Min (desk to bottom of display): 39 mm
Max (desk to bottom of display): 159 mm
Pivot Rotation
N/A
VESA Mounting
Yes, 100 mm
Security Lock-Ready
Yes
Specifications
Temperature - Operating
5° to 35° C (41° to 95° F)
Temperature - Non-operating
–20° to 60° C (-4° to 140° F)
Humidity - Operating
20% to 80% Relative Humidity non-condensing
Humidity - Non-operating
5% to 95%, 38.7° C max wet-bulb
Altitude - Operating
0 to 5,000 m (0 to 16,404 ft)
Altitude – Non-operating
0 to 12,192 m (0 to 40,000 ft)
White LED Backlights
Yes
CCFL Panel
No
Arsenic-Free Display Glass
Yes
Low Halogen3
Yes (except cables)
Mercury-Free Display Backlights
Yes
Eco-Label Certifications & declarations
This product has received or is in the process of being certified to the following approvals and may be labeled with one or more of these marks:
IT ECO declaration
Energy Consumption (in accordance with US ENERGY STAR® test method)
115VAC, 60Hz
230VAC, 50Hz
100VAC, 50Hz
Normal Operation
42.96 W
41.95 W
43.22 W
Sleep
0.45 W
0.48 W
0.50 W
Off
0.28 W
0.27 W
0.30 W
DIMENSIONS AND WEIGHT
MONITOR FEATURES
ENVIRONMENTAL
ENVIRONMENTAL DATA
QuickSpecs
HP Z38c 37.5-inch Curved Display
Technical Specifications
c05591685—DA 16029— Worldwide — Version 4 — December 14, 2017
Page 6
Heat Dissipation*
115VAC, 60Hz
230VAC, 50Hz
100VAC, 50Hz
Normal Operation
147 BTU/hr
143 BTU/hr
148 BTU/hr
Sleep
2 BTU/hr
2 BTU/hr
2 BTU/hr
Off
1 BTU/hr
1 BTU/hr
1 BTU/hr
*NOTE: Heat dissipation is calculated based on the measured watts, assuming the service level is attained for one hour.
Additional Information
This product is in compliance with the Restrictions of Hazardous Substances (RoHS)
directive - 2002/95/EC.
This HP product is designed to comply with the Waste Electrical and Electronic
Equipment (WEEE) Directive – 2002/96/EC.
This product is in compliance with California Proposition 65 (State of California; Safe
Drinking Water and Toxic Enforcement Act of 1986).
Plastics parts weighing over 25 grams used in the product are marked per ISO 11469
and ISO1043.
This product contains 19.8% post-consumer recycled plastic (by wt.) This product is 97.6% recycle-able when properly disposed of at end of life.
Packaging Materials
External:
PAPER/Corrugated
2929 g
PAPER/Paperboard
2 g
Internal:
PLASTIC/Polyethylene Expanded – EPE
2688 g
PLASTIC/Polyethylene high density - HDPE
28 g
PLASTIC/Other& COMPOSITE/paper/carton+plastic
4 g
RoHS Compliance
HP, Inc. is committed to compliance with all applicable environmental laws and regulations,
including the European Union Restriction of Hazardous Substances (RoHS) Directive. HP’s goal is
to exceed compliance obligations by meeting the requirements of the RoHS Directive on a worldwide basis. By July 1, 2006, RoHS substances will be virtually eliminated (virtually = to levels below legal limits) for all HP electronic products subject to the RoHS Directive, except where it is widely recognized that there is no technically feasible alternative (as indicated by an exemption under the EU RoHS Directive).
QuickSpecs
HP Z38c 37.5-inch Curved Display
Technical Specifications
c05591685—DA 16029— Worldwide — Version 4 — December 14, 2017
Page 7
Material Usage
This product does not contain any of the following substances in excess of regulatory limits (refer to the HP General Specification for the Environment at
http://www.hp.com/hpinfo/globalcitizenship/environment/pdf/gse.pdf):
Asbestos Certain Azo Colorants Certain Brominated Flame Retardants – may not be used as flame retardants in plastics Cadmium Chlorinated Hydrocarbons Chlorinated Paraffins Formaldehyde Halogenated Diphenyl Methanes Lead carbonates and sulfates Lead and Lead compounds Mercuric Oxide Batteries Nickel – finishes must not be used on the external surface designed to be frequently
handled or carried by the user.
Ozone Depleting Substances Polybrominated Biphenyls (PBBs) Polybrominated Biphenyl Ethers (PBBEs) Polybrominated Biphenyl Oxides (PBBOs) Polychlorinated Biphenyl (PCB) Polychlorinated Terphenyls (PCT) Polyvinyl Chloride (PVC) – except for wires and cables, and certain retail packaging has
been voluntarily removed from most applications.
Radioactive Substances Tributyl Tin (TBT), Triphenyl Tin (TPT), Tributyl Tin Oxide (TBTO)
Packaging
HP follows these guidelines to decrease the environmental impact of product packaging:
Eliminate the use of heavy metals such as lead, chromium, mercury and cadmium in
packaging materials.
Eliminate the use of ozone-depleting substances (ODS) in packaging materials. Design packaging materials for ease of disassembly. Maximize the use of post-consumer recycled content materials in packaging materials. Use readily recyclable packaging materials such as paper and corrugated materials. Reduce size and weight of packages to improve transportation fuel efficiency. Plastic packaging materials are marked according to ISO 11469 and DIN 6120
standards.
End-of-life Management and Recycling
Hewlett-Packard offers end-of-life HP product return and recycling programs in many geographic areas. To recycle your product, please go to: http://www.hp.com/go/reuse-recycle or contact your nearest HP sales office. Products returned to HP will be recycled, recovered or disposed of in a responsible manner.
The EU WEEE directive (2002/95/EC) requires manufacturers to provide treatment information for each product type for use by treatment facilities. This information (product disassembly instructions) is posted on the Hewlett Packard web site at: http://www.hp.com/go/recyclers. These instructions may be used by recyclers and other WEEE treatment facilities as well as HP OEM customers who integrate and re-sell HP equipment.
QuickSpecs
HP Z38c 37.5-inch Curved Display
Technical Specifications
c05591685—DA 16029— Worldwide — Version 4 — December 14, 2017
Page 8
HP, Inc. Corporate Environmental Information
For more information about HP’s commitment to the environment:
Global Citizenship Report
http://www.hp.com/hpinfo/globalcitizenship/gcreport/index.html
Eco-label certifications
http://www.hp.com/hpinfo/globalcitizenship/environment/productdesign/ecolabels.ht ml
ISO 14001 certificates:
http://h20195.www2.hp.com/V2/GetDocument.aspx?docname=c04755842
and
http://www.hp.com/hpinfo/globalcitizenship/environment/pdf/cert.pdf
OPTIONS
(Each sold separately)
HP USB Graphics Adapter Part number NL571AA
Enables connection of up to six simultaneous displays to help you boost productivity and multi-task across several open applications. Use one Adapter to bridge between a notebook or desktop PC and second monitor or use multiple Adapters to connect several displays to each other.
HP B500 PC Mounting Bracket Part number 2DW52AA
Maximize your available work area with a single-footprint solution. Simply attach the bracket to the back of your display, and your PC platform to the bracket via the 100mm VESA pattern. It’s that easy!
HP DisplayPort Cable Kit Part number VN567AA
Connects a DisplayPort connector on an HP Business Desktop computer to a DisplayPort connector on a monitor.
HP Business PC Security Lock Kit Part number PV606AA
Attaches to the rear of the PC with a six-foot steel cable that can be used to secure a PC or peripherals such as mice, keyboards, monitors or USB security devices to protect them against unauthorized removal by physically connecting the system to an anchor point.
What’s in the box?
Monitor and Accessories
HP Z38c 37.5-inch Curved Display, AC power cord 1,9 m (6.2 ft), (1) HDMI 1,8 m (5.9 ft), (1) DisplayPort™ 1,8 m (5.9 ft), (1) USB Type-
C™ 1,8 m (5.9 ft)
Documentation
CD, documentation
Other
Software included
HP Desktop Assistant
User Guide Languages
English, Arabic, S. Chinese, T. Chinese, Czech, Danish, Dutch, Finnish, French, German, Greek, Hungarian, Italian, Japanese, Kazakh, Korean, Norwegian, Polish, Brazilian Portuguese, Russian, Slovenian, Spanish, Swedish and Turkish.
Warranty Languages
English, Arabic, S. Chinese, T. Chinese, Czech, Danish, Dutch, Finnish, French, German, Greek, Hungarian, Italian, Japanese, Kazakh, Korean, Norwegian, Polish, Brazilian Portuguese, Russian, Slovenian, Spanish, Swedish and Turkish.
WHAT’S IN THE BOX?
QuickSpecs
HP Z38c 37.5-inch Curved Display
Technical Specifications
c05591685—DA 16029— Worldwide — Version 4 — December 14, 2017
Page 9
Country of Origin
China
Certification and Compliance
Microsoft WHQL Certification (Windows 10, Windows 8 and Windows 7), SmartWay Transport Partnership (NA only) CE, CB,KC/MSIP/Mexico CoC/PSB/ICES/TUV-S/ISO 9241 -307 / EAC / cTUVus / PSE / ISC / CCC / CEL / CECP / SEPA / VCC I/ FCC / BSMI / Vietnam MEPS / Australian-New Zealand MEPS / WEEE / BIS/ ErP/ E-Standby
Compatibility
Compatible with platforms using the VESA standard video modes. Recommended for use with HP products.
Service and Warranty
Protected by HP, including a 3 year standard limited warranty. Optional HP Care Pack Services are extended service contracts that extend your protection beyond the standard warranties.4
Zero Bright Dot Guarantee*
Yes
*The HP Pixel Policy allows no bright sub-pixel defects for this display. For complete details, see http://support.hp.com/us-
en/document/c00288895.
CERTIFICATION AND COMPLIANCE
QuickSpecs
HP Z38c 37.5-inch Curved Display
Technical Specifications
c05591685—DA 16029— Worldwide — Version 4 — December 14, 2017
Page 10
Copyright © 2017 HP Development Company, L.P.
The information contained herein is subject to change without notice. The only warranties for HP products are set forth in the express limited warranty statements accompanying such products. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.
DisplayPort™ and the DisplayPort™ logo are trademarks owned by the Video Electronics Standards Association (VESA®) in the United States and other countries.
1. Default Power is measured with factory defaults, including factory default brightness and USB ports loaded at 25% of maximum.
2. Maximum Power is measured with monitor at maximum brightness and with USB ports loaded at 100% of maximum.
3. External power supplies, power cords, cables and peripherals are not Low Halogen. Service parts obtained after purchase may not be
Low Halogen.
4. Service levels and response times for HP Care Pack Services may vary depending on your geographic location. Service starts from date
of hardware purchase. Restrictions and limitations apply. See http://www.hp.com/go/cpc for details.
5. The HP Quick Release has been designed to support a maximum of up to 24 lbs (10.9 kg) for all devices mounted. Because mounting
surfaces vary widely and the final mounting method and configuration may vary, mounting fasteners are not supplied (other than the VESA-compliant screws). HP recommends that you consult with a qualified engineering, architectural or construction professional to determine the appropriate type and quantity of mounting fasteners required for your application and to ensure that your mounting solution is properly installed to support applied loads.
QuickSpecs
HP Z38c 37.5-inch Curved Display
Technical Specifications
c05591685—DA 16029— Worldwide — Version 4 — December 14, 2017
Page 11
Change Log
28/08/2017
From V1 to V2
Panel Specs Updated
28/08/2017
From V2 to V3
Environmental data table added
14/12/2017
From V3 to V4
Corrected unpacked weight
Loading...
