Page 1
QuickSpecs
HP Z27s 27-inch IPS UHD Display
Overview
c04557329 —DA 15209—Worldwide — Version 4 — June 06, 2016
Page 1
.
HP Z27s 27-inch IPS UHD Display
1.
Menu button
3.
Power button
2.
4-button OSD
1.
Master power switch
6.
Mini-DisplayPort
2.
Power connector
7.
Audio Output 3.5 mm
3.
HDMI v 1.4 input
8.
USB 3.0 upstream port
4.
HDMI v 1.4 input (MHL 2.0)
9.
(2) USB 3.0 downstream
5.
DisplayPort v 1.2
Page 2
QuickSpecs
HP Z27s 27-inch IPS UHD Display
Overview
c04557329 —DA 15209—Worldwide — Version 4 — June 06, 2016
Page 2
1.
USB 3.0 downstream
Overview
Join the Ultra High Definition movement and expand your visual workspace with the HP Z27s 27-inch IPS UHD 4k1
Display.
Key features:
Enjoy massive 3840 x 2160 resolution plus 100% sRGB color gamut and 1.07 billion colors
2
for an
incredible presentation.
Connect your display to a workstation, PC, and range of digital video devices.
Instantly mirror your smart phone or tablet content and charge your devices through MHL.
3
Boost your productivity with more expansive views of your projects, documents, and media with 8 million
pixels—4x that of a Full HD display.
Find your most comfortable viewing position with 4-way ergonomic adjustability.
Design the screen for how you work with HP Display Assistant software.
Get award-winning service and support, and extend your protection with optional HP Care Packs.
4
Reduce power consumption and help lower your costs with an energy-efficient design.
1 4K content required.
2 All specifications represent the typical specifications provided by HP's component manufacturers; actual performance may vary either higher or lower.
3 MHL 2.0 port will charge a MHL compatible smart phone and tablet battery. Includes a DisplayPort to HDMI dongle to increase connect flexibility. Requires the
smart phone or tablet to be enabled for MHL or have an HDMI dongle to connect to the monitor. See your mobile device specifications. Max display resolution is Full
HD.
4 Service levels and response times for HP Care Packs may vary depending on your geographic location. Service starts on date of hardware purchase. Restrictions
and limitations apply. For details, visit www.hp.com/go/cpc. HP services are governed by the applicable HP terms and conditions of service provided or indicated to
Customer at the time of purchase. Customer may have additional statutory rights according to applicable local laws, and such rights are not in any way affected by
the HP terms and conditions of service or the HP Limited Warranty provided with your HP Product.
Page 3
QuickSpecs
HP Z27s 27-inch IPS UHD Display
Technical Specifications
c04557329 —DA 15209—Worldwide — Version 4 — June 06, 2016
Page 3
Models: J3G07A4
Panel
Type
27-inch IPS w/LED backlight
Viewable Image Area
(diagonal)
68,4 cm (26.9-inch) widescreen; diagonally measured
Panel Active Area
(W × H)
59,62 x 33,53 cm (23.47 × 13.2 in)
Resolution
3840 x 2160 @ 60 Hz (UHD)
Aspect Ratio
16:9
Viewing Angle
Up to 178° horizontal/178° vertical typical
Brightness
300 cd/m2
Contrast Ratio (Typical)
1000:1 Static; 5,000,000:1 Dynamic (DCR)
Response Times*
6 ms typical (G-to-G) with Overdrive
Pixel Pitch
155.25 um
Pixels Per Inch (PPI)
163 DPI
Backlight Lamp Life
(to half brightness)
30,000 hours minimum
Color Production
10-bit (1.07 B)
Color Gamut (Typical)
100% sRGB
* Performance specifications represent the typical specifications provided by HP's component
manufacturers; actual performance may vary either higher or lower.
User Controls
Buttons or Switches
Menu, 4-button OSD and Power
Languages
10 (English, Spanish, German, French, Italian, Netherlands,
Portuguese, Japanese, T-Chinese and S-Chinese)
On Screen Display
(OSD) User Controls
Brightness, Contrast, Color, Image Control, OSD control, Management,
Language, Information, Factory Reset, Input Control
Audio Controls
N/A
Signal
Interface/
Performance
Horizontal Frequency
30–135 kHz
Vertical Frequency
24-60 Hz
Native Resolution
3840 x 2160 @ 60 Hz (UHD)
NOTE: The video card must be capable of supporting 3840 × 2160 –
60Hz to drive the monitor at the Preferred Mode.
Preset Graphic Modes
(non-interlaced)
640 x 480 @ 60Hz
720 x 400 @ 70 Hz
800 x 600 @ 60 Hz
1024 x 768 @ 60 Hz
Page 4
QuickSpecs
HP Z27s 27-inch IPS UHD Display
Technical Specifications
c04557329 —DA 15209—Worldwide — Version 4 — June 06, 2016
Page 4
1280 x 720 @ 60 Hz
1280 x 1024 @ 60 Hz
1440 x 900 @ 60 Hz
1680 x 1050 @ 60 Hz
1920 x 1080 @ 60 Hz
1920 x 1200 @ 60 Hz
2560 x 1440 @ 60 Hz
2560 x 1600 @ 60 Hz
3840 x 2160 @ 24, 30, 60 Hz
Maximum Pixel Clock
Speed
600 MHz
Anti-Glare
Yes
Video/Other
Inputs
Plug and Play
Yes
Input Connectors
(1) HDMI 1.4, (1) MHL 2.01/HDMI 1.4
(1) DisplayPort 1.2, (1) Mini-DisplayPort
HDCP support on all inputs
USB
Integrated USB 3.0 hub with four downstream connectors
Video Cables Included
(1) DisplayPort 1,8 m (5.9 ft) (1) Mini-DisplayPort 1,8 m (5.9 ft)
(1) USB 3.0 1,8 m (5.9 ft)
Audio
(1) Audio output 3.5mm
Multimedia
Speakers
N/A
Power
Power Supply
Internal
Input Power
100 - 240 VAC 50/60 Hz
Maximum Power
92 W
Typical Power
61 W
Sleep Power
0.5 W
Power Cable Length
1,9 m (6 ft)
Mechanical
Dimensions
(W × D × H)
Unpacked w/stand
(highest setting)
62,56 x 24,24 x 53,59 cm
(24.62 x 9.54 x 21.1 in)
Unpacked w/o stand
(head only)
62,56 x 6,09 x 37,03 cm
(24.62 x 2.4 x 14.57 in)
Packaged
71,8 x 30,2 x 49,1 cm
(28.27 x 11.89 x 19.33 in)
Weight
Head Only
5,4 kg (11.8 lb)
Unpacked
7,8 kg (17.2 lb)
Packaged
10,2 kg (22.4 lb)
Ergonomic
Features
Detachable Stand
Yes, ships detached
Height Adjustment
Yes, 120 +/-3 mm
Page 5
QuickSpecs
HP Z27s 27-inch IPS UHD Display
Technical Specifications
c04557329 —DA 15209—Worldwide — Version 4 — June 06, 2016
Page 5
Tilt Range
-5° to + 20° vertical
Swivel
Yes, 45° +/-2°
Pivot
Yes
Quick Release4
HP QR2 quick release included
Environmental
Temperature - Operating
5° to 35° C (41° to 95° F)
Temperature - Nonoperating
–34° to 60° C (-29° to 140° F)
Humidity - Operating
20% to 80% non-condensing
Humidity - Non-operating
5% to 95%, 38.7° C max wet-bulb
Altitude - Operating
0 to 5,000 m (0 to 16,404 ft)
Altitude – Non-operating
0 to 12,192 m (0 to 40,000 ft)
White LED Backlights
Yes
CCFL Panel
No
Arsenic-Free Display Glass
Yes
Low Halogen2
Yes (except cables)
Mercury-Free Display
Backlighting
Yes
Options
HP LCD Speaker Bar—Part
number NQ576AA
Powered directly by the connected PC, the Speaker Bar seamlessly
attaches to the monitor's lower bezel to bring full audio support to
select HP flat panel monitors. Features include dual speakers with full
sound range and dual external headphone jacks. Sold separately. For
more information, refer to the product’s QuickSpecs.
HP Thin Client Mount Kit—
Part number E5J35AA
Attach your HP Thin Client or USDT PC to the back of select HP Z
Displays and maintain optimal ergonomic adjustability with the HP
Thin Client Mount Kit. Simply mount an HP Thin Client to the Kit’s VESA
plate, slide it into place on the back of an HP Z27s, Z24i, Z27i or Z30i
IPS Display stand, and you’re ready to go.
HP DisplayPort Cable Kit —
Part number VN567AA
Connects a DisplayPort connector on an HP Business Desktop
computer to a DisplayPort connector on a monitor
HP LCD Monitor Quick
Release — Part number
EM870AA4
An easy-to-use, VESA-compliant, LCD monitor mounting solution that
allows you to quickly and securely attach an LCD monitor to a variety
of stands, brackets, arms or wall mounts. For more information, refer
to this product's QuickSpecs document.
HP Business PC Security
Lock Kit — Part number
PV606AA
Attaches to the rear of the PC with a six-foot steel cable that can be
used to secure a PC or peripherals such as mice, keyboards, monitors
or USB security devices to protect them against unauthorized removal
by physically connecting the system to an anchor point.
Page 6
QuickSpecs
HP Z27s 27-inch IPS UHD Display
Technical Specifications
c04557329 —DA 15209—Worldwide — Version 4 — June 06, 2016
Page 6
What’s in the
box?
Monitor and Accessories
HP Z27s 27-inch IPS UHD Display, AC power cord (1.9m) 6.0 ft,
DisplayPort cable (1.8m) 5.9 ft, Mini-DisplayPort to DisplayPort cable
(1.8m) 5.9 ft
Documentation
CD (includes user guide, warranty, drivers)
Software
HP Display Assistant
Other
User Guide Languages
English, Arabic, S. Chinese, T. Chinese, Czech, Danish, Dutch, Finnish, French,
German, Greek, Hungarian, Italian, Japanese, Kazakh, Korean, Norwegian, Polish,
Brazilian Portuguese, Russian, Slovenian, Spanish, Swedish and Turkish.
Warranty Languages
English, Arabic, S. Chinese, T. Chinese, Czech, Danish, Dutch, Finnish, French,
German, Greek, Hungarian, Italian, Japanese, Kazakh, Korean, Norwegian, Polish,
Brazilian Portuguese, Russian, Slovenian, Spanish, Swedish and Turkish.
Color
Black
VESA Mounting
100 mm VESA mount
Security Lock-Ready
Yes
Country of Origin
China
Certification
and Compliance
CEL Grade 2, Microsoft WHQL Certification (Windows 8.1 and Windows 7), CE, CB, KC, KCC, NOM, PSB, ICE,
TUV-S, CCC, CECP, SEPA, EPA, ISC, VCCI, FCC, Taiwan: BSMI
Compatibility
Compatible with platforms using the VESA standard video modes. Recommended for use with HP products.
Service and
Warranty
Protected by HP, including a 3 year standard limited warranty. Optional HP Care Pack Services are extended
service contracts that extend your protection beyond the standard warranties.3
1. MHL 2.0 port will charge a MHL compatible smart phone and tablet battery. Requires the smart phone or tablet to be enabled for MHL or
have an HDMI dongle to connect to the monitor. See your mobile device specifications.
2. External power supplies, power cords, cables and peripherals are not Low Halogen. Service parts obtained after purchase may not be
Low Halogen.
3. Service levels and response times for HP Care Pack Services may vary depending on your geographic location. Service starts from date
of hardware purchase. Restrictions and limitations apply. See http://www.hp.com/go/cpc for details.
4. The HP Quick Release has been designed to support a maximum of up to 24 lbs (10.9 kg) for all devices mounted. Because mounting
surfaces vary widely and the final mounting method and configuration may vary, mounting fasteners are not supplied (other than the
VESA-compliant screws). HP recommends that you consult with a qualified engineering, architectural or construction professional to
determine the appropriate type and quantity of mounting fasteners required for your application and to ensure that your mounting
solution is properly installed to support applied loads.
© Copyright 2016 Hewlett-Packard Development Company, L.P.
All specifications represent the typical specifications provided by HP's component manufacturers; actual performance may vary
either higher or lower. The only warranties for HP products and services are set forth in the express warranty statements
accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not
be liable for technical or editorial errors or omissions contained herein.
Page 7
QuickSpecs
HP Z27s 27-inch IPS UHD Display
Change Log
c04557329 —DA 15209—Worldwide — Version 4 — June 06, 2016
Page 7
Change Log
January 1, 2015
From v1 to v2
Update
Added Environmental Data Chart
May 20, 2016
From v2 to v3
Update
Removed ENERGY STAR and EPEAT references
June 6, 2016
From v3 to v4
update
Removed TCO references
