HP VR Backpack G2 QuickSpecs

Download
QuickSpecs
HP VR Backpack G2

Overview

c06274598 —DA16466 —Worldwide — Version 6 — February 10, 2021
Page 1
HP VR Backpack G2
Front View
1.
Programmable LED Bar
2.
LED HP logo
QuickSpecs
HP VR Backpack G2
Overview
c06274598 —DA16466 —Worldwide — Version 6 — February 10, 2021
Page 2
Top View
Bottom View
1.
HTC Vive™ HMD power port
5.
Audio jack
2.
(2) USB 3.0 Type A
6.
Power Button
3.
(2) Mini DisplayPort™ 1.4
7.
Dock Connector
4.
(1) USB Type-C™, Thunderbolt™
8.
Dock Guide Posts
9.
External Battery power ports
NOTE: HTC Vive™ HMD power port on the HP VR Backpack G2 only accepts the power connector that exists on the HTC Vive Combo cable accessory provided with the HP VR Backpack G2 solution. The HTC Vive long (5m) HMD cable cannot be used without the HTC Vive Link box that come with the HTC Vive product.
QuickSpecs
HP VR Backpack G2
Overview
c06274598 —DA16466 —Worldwide — Version 6 — February 10, 2021
Page 3
Right side view
Left side view
1.
Power Button
4.
DC in port
2.
(2) USB 3.0 Type A
3.
(1) RJ-45 LAN port
QuickSpecs
HP VR Backpack G2
Overview
c06274598 —DA16466 —Worldwide — Version 6 — February 10, 2021
Page 4
At A Glance
• Windows 10 Pro edition
• Full performance industrial design, in a wearable form factor using a backpack harness solution. Reinforced
chassis, top cover frame features customizable system health RGB LED indicator.
• Docking station solution to convert the HP VR Backpack G2 from backpack to desktop use modes.
• VR Ready NVIDIA ® GeForce® discrete graphics: NVIDIA® GeForce® RTX2080 with 8GB GDDR6 memory.
• ISV certified to provide fast and reliable performance with workstation applications, including manipulation of 3D
textures.
• 8th generation Intel® Core™ i7 with vPro™ technology (vPro™optional).
• Two SODIMMs, for system memory up to 32 GB.
• Supports multi-display, including up to four (4) displays, 2 direct from the HP VR Compact Workstation and
additional 2 via docking solution.
• One (1) Thunderbolt™ 3 port (supporting DisplayPort™ 1.2, USB 3.1, PCIe Gen 3 devices) on the new USB-CTM connector, for high speed data/video/audio transfer support.
• DTS Headphone:X® audio optimized for high fidelity audio with immersive surround sound with deep, rich bass and crystal clear dialog without distortion at high volume
• Internal battery to support wearable harness use mode with hot swap external batteries:
• RJ45 LAN on PC
• Wireless connectivity options included:
o Intel® Dual Band Wireless-M.2/PCIe AC 9260 802.11 AC (2x2) WiFi and Bluetooth® 5 combo adaptor
(vPro) or
o Realtek RTL8822BE-CG PCIe 802.11 AC/abgn WLAN with Bluetooth® 4.2 combo adaptor
• Dedicated storage slot: (1) M.2
• Designed to pass military standard Mil-Std-810G testing. MIL STD 810G testing is pending and is not intended to
demonstrate fitness for U.S. Department of Defense contract requirements or for military use. Test results are not a guarantee of future performance under these test conditions. Damage under the MIL STD test conditions or any accidental damage requires an optional HP Accidental Damage Protection Care Pack.
• Low halogen
• Depending on configuration ordered, the HP VR Backpack G2 may include the following items:
o HP VR Backpack G2 o HP VR Backpack Dock o HP 330W Smart AC Adapter o HP VR Backpack G2 Harness o 2x HP VR Backpack External Battery o HP VR Backpack External Battery Charger o HP 180W Smart AC Adapter o Dock to Battery Charger cable
NOTE: HTC VIVE Business Edition VR System headset sold separately. NOTE: See important legal disclosures for all listed specs in their respective features sections.
QuickSpecs
HP VR Backpack G2
Overview
c06274598 —DA16466 —Worldwide — Version 6 — February 10, 2021
Page 5
Form Factor
Small Form Factor, wearable PC
Operating Systems
Preinstalled:
• Windows 10 Pro 641
Notes:
1. Not all features are available in all editions or versions of Windows. Systems may require upgraded and/or separately purchased hardware, drivers, software or BIOS update to take full advantage of Windows functionality. Windows 10 is automatically updated, which is always enabled. ISP fees may apply and additional requirements may apply over time for updates. See http://www.windows.com
2. In accordance with Microsoft´s support policy, HP does not support the Windows® 8 or Windows® 7 operating system on products configured with Intel and AMD 7th generation and forward processors or provide any Windows® 8 or Windows® 7 drivers on http://www.support.hp.com.
QuickSpecs
HP VR Backpack G2
Overview
c06274598 —DA16466 —Worldwide — Version 6 — February 10, 2021
Page 6
Processors*
Name
Cores
Clock
Speed
(GHz)
Intel® Turbo Boost
Technology
1
Cache
(MB)
Memory
Speed (MT/s)
Hyper-
Threading
Integrated
Graphics
Featuring
Intel® vPro™
Technology
TDP
(W)
HP VR Backpack G2 Performance base unit
Intel® Core™ i7-9750H
6
2.6 GHz
4.5 GHz
12 MB
2666
(DDR4)
Yes
N/A2 No
45W
Intel® Core™ i7-9850H
6
2.6 GHz
4.6 GHz
12 MB
2666
(DDR4)
Yes
N/A2
Yes
45W
1. The specifications shown in this column represent the maximum turbo frequency with one core active. Turbo boost stepping occurs in 100MHz increments. Processors that do not have turbo functionality are denoted as N/A.
2. Integrated Graphics is NOT enabled in the HP VR Backpack G2. All graphics for the platform is provided by the NVIDIA® GeForce® RTX2080 GPU.
NOTES:
* Multicore is designed to improve performance of certain software products. Not all customers or software applications will necessarily benefit from use of this technology. Performance and clock frequency will vary depending on application
workload and your hardware and software configurations. Intel’s numbering is not a measurement of higher
performance.
INTEL® Core™ i7 with vPro™
Intel® Core™ i7 with vPro™ technology is a selectable feature that is available on units configured with select processors, a qualified Intel® Centrino® WLAN module and a preinstalled Windows® operating system. It provides advances in remote manageability, security, energy efficient performance, and wireless connectivity. Intel® Active Management Technology (iAMT) offers built-in manageability and proactive security for networked mobile workstations, even when they are powered off* or when the operating system is inoperable. It can help identify threats before they reach the network, isolate infected systems, and update regardless of their power state.
*Requires a Windows operating system, network hardware and software, connection with a power source, and a direct (non-VPN) corporate network connection which is either cable or wireless LAN.
NOTE: Some functionality of Intel® Core™ i7 with vPro™ such as Intel® Active Management technology and Intel®
Virtualization technology, requires additional third- party software in order to run. Availability of future "virtual appliances" applications for Intel® Core™ i7 with vPro™ technology is dependent on third- party software providers. Compatibility with future "virtual appliances" is yet to be determined.
Graphics
Video Outputs:
Mini DisplayPort™ 1.4 USB-C Thunderbolt™ 3 enabled with DisplayPort™ 1.2 DisplayPort™ 1.2 on HP Z VR Backpack Dock
Intel Integrated:
Integrated Graphics is NOT enabled in the HP VR Backpack. Discrete graphics is the only available graphics.
Discrete:
NVIDIA® GeForce® RTX2080 with 8GB dedicated GDDR6
QuickSpecs
HP VR Backpack G2
Overview
c06274598 —DA16466 —Worldwide — Version 6 — February 10, 2021
Page 7
NOTE: NVIDIA® GEFORCE® mobile graphics support up to four independent displays when
used with an HP Z VR Backpack Dock (included with the HP VR Backpack G2) Connecting a Virtual Reality HMD will take one or more of the display connections depending on the HMD requirements, thus reducing the number of simultaneous external displays connected accordingly.
NVIDIA® GC6 Technology is supported allowing S0 state power usage optimization.
DisplayPort™ 1.2 protocol features supported on Thunderbolt™ 3 ports:
• Legacy displays (HDMI, DVI, VGA) may be attached to Thunderbolt™ port with the use of a certified dongle.
• DisplayPort™ monitors capable of supporting DisplayPort™ 1.2 may be directly attached to the Thunderbolt™ port to achieve HBR2 with the use a dongle.
• Thunderbolt™ 3 enabled monitors may be directly attached to the Thunderbolt
port to achieve HBR2 and MST.
• DisplayPort™1.2 MST feature ("daisy-chain" feature) is supported through Thunderbolt™ 3 port on Thunderbolt™ 3 enabled devices or DisplayPort™1.2
monitors (requires monitor with DisplayPort™ 1.2 MST capability) with the use of
a dongle.
• Up to 2 streams (eight lanes) of DisplayPort™ 1.2 are supported over a single Thunderbolt™ 3 port. Up to (2) 4K displays 24/30-bit color depth at 60 Hz or (1)
5K display supported over a single Thunderbolt™
3 port. (Requires Intel®
certified Thunderbolt™ cable).
DisplayPort™ 1.2 w/MST (Multi-stream Transport): Supports resolutions up to Full 4K, 24/30-
bit color depth at 60 Hz, and WUXGA (1920 x1200) monitors, 24/30-bit color depth at 120 Hz.
NOTE: Thunderbolt™ 3 is superset port supporting DisplayPort™ 1.2, USB 3.1 Gen 2, and
PCIe Gen 3 devices over the new USB-C™ connector. Install all the latest drivers for your
Thunderbolt™ device before connecting the device to the Thunderbolt™ port. Thunderbolt™ cable and Thunderbolt™ device (sold separately) must be compatible with Windows. To
determine whether your device is Thunderbolt™ Certified for Windows, see
https://Thunderbolttechnology.net/products
Other System Specs
Color
Black
Convertibility
The HP VR Backpack G2 can either be mounted on the backpack harness as a wearable PC for VR usage, placed in its docking station on the desktop, or mounted to a compatible Z display on the desktop
NOTE:Mounting accessory sold separately
Expansion Slots
1 80mm M.2 slot (PCIe Gen3 x4) 1 30mm M.2 slot (PCIe Gen3 x1)*
* For WLAN/BT M.2 module only Expansion Bays
None
Top I/O
Power button, 2 USB 3.0 ports, 2 Mini Display Port™ 1.4, 1 USB Type C™ (Thunderbolt™), 1 audio combo jack, 1 DC power output (for HTC Vive™ HMD, the HP HMD Combo cable provided must be used)
QuickSpecs
HP VR Backpack G2
Overview
c06274598 —DA16466 —Worldwide — Version 6 — February 10, 2021
Page 8
Side I/O
2 USB 3.0 ports, 330W AC Adapter DC In port RJ-45 LAN port
Bottom I/O
Docking connector, 2 Battery DC In ports
Chassis Dimensions (H x W x D)
Standard desktop orientation: 333.5 x 236.4 x 60.9 mm
Weight
Exact weights depend upon configuration; Minimum Weight: 2.5 kg (PC)
Typical Weight: 2.5 kg (PC) Maximum Weight: 4.665 kg* (when used as a wearable PC backpack with the Z VR Backpack harness and external batteries)
Max Supported Weight (as used in backpack mode): 4.665 kg* (2501 g (PC) + 941 g (battery x2) + 1223 g (Backpack)= 4665 g)
* When used as a wearable PC backpack with the Z VR Backpack harness and external batteries. Excludes any VR or AR head mounted display used with the HP VR Compact Workstation.
Temperature
Operating: 40° to 95°F (5° to 35°C) Non-operating: -4° to 140°F (-20° to 60°C)
NOTE: De-rate the maximum operating temperature by one degree C (1.8 degrees F) for every 305m (1,000 ft) altitude over 1,524m (5,000 ft).
Humidity
Operating: 8% to 85% Non-operating: 8% to 90%
Maximum Altitude (non-pressurized)
Operating: 2,286 m (7,500 ft) Non-operating: 9,100 m (30,000 ft).
Power Supply
330W 92.6% Efficiency at 115Vac
Chipset
Intel® QM370 chipset
Memory
2 SODIMM slots, supporting up to 32GB non-ECC, DDR4 2666 MT/s
Workstation ISV Certifications
See the latest list of certifications at
http://www.hp.com/united-states/campaigns/workstations/partnerships.html
QuickSpecs
HP VR Backpack G2

Supported Components

c06274598 —DA16466 —Worldwide — Version 6 — February 10, 2021
Page 9
Processors
Factory
Configured
Option Kit
9th generation Intel® Core™ processor family
Intel® Core™ i7-9750H 2.6/4.5 12M 6C CPU
Y
N
Intel® Core™ i7-9850H 2.6/4.6 12M 6C CPU
Y
N
Monitors / Displays
HP DreamColor Z24x Professional Display HP DreamColor Z27x Professional Display HP Z34c Curved Display HP Z22n Narrow Bezel IPS Display HP Z23n Narrow Bezel IPS Display HP Z24n Narrow Bezel IPS Display HP Z24nf Narrow Bezel IPS Display HP Z24nq Narrow Bezel IPS Display HP Z24s IPS UHD 4K Display HP Z25n Narrow Bezel IPS Display HP Z27n Narrow Bezel IPS Display HP Z27n Narrow Bezel IPS Display
NOTE: Monitors purchased separately.
Notes
HP VR Backpack G2 Accessories
Factory
Configured
Option Kit
Option Kit
Part Number
HP VR Backpack G2 Harness
1
Y
Y
7CZ31AA
HP Z VR Backpack Battery Pack
Y
Y
2HY48AA
HP Z VR Backpack Battery Charger
Y
Y
2HY51AA
HP Z VR Backpack G1 Dock
Y
Y
2LM71AA
HP 330W Smart AC Power Adapter
Y
Y
2YD04AA
NOTE 1: The HP VR Backpack G2 Harness is the cloth used to hold HP VR Backpack G2 Harness PC Mount.
QuickSpecs
HP VR Backpack G2
Supported Components
c06274598 —DA16466 —Worldwide — Version 6 — February 10, 2021
Page 10
PCIe SSDs
M.2 PCIe SSDs for HP Workstations
Factory
Configured
Option Kit
Option Kit
Part Number
256GB TLC
Y N
512GB TLC
Y N
1TB TLC Y N
** Choice of one installed in native M.2 slot on HP VR Backpack G2 motherboard
NOTE: For storage drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 36GB (for Windows 10) of system disk is reserved for system recovery software.
Graphics
Factory
Configured
Option Kit
Option Kit
Part Number
Supported #
of cards
Discrete Graphics
NVIDIA® GeForce® RTX2080 8GB Graphics
Y
N
1
NOTE: No CPU Integrated Graphics available. Only Discrete Graphics enabled.
QuickSpecs
HP VR Backpack G2
Supported Components
c06274598 —DA16466 —Worldwide — Version 6 — February 10, 2021
Page 11
Memory
DDR4-2666 non-ECC Unbuffered SODIMMs
HP 16GB (2x8GB) DDR4-2666 RAM
HP 32GB (2x16GB) DDR4-2666 RAM
NOTE: Two channels of DDR4 memory are supported. To realize full performance at least one DIMM must be inserted into each channel.
The CPUs determine the speed at which the memory is clocked. A 2666 MT/s CPU can support memory speed maximum rates of 2666 MT/s. To achieve maximum memory speed, 2666 MT/s memory must be used.
NOTE: Only unbuffered DDR4 SODIMMs are supported.
Multimedia and Audio Devices
Factory
Configured
Option Kit
Option Kit Part
Number
RealTek ALC3866-CG with Integrated DTS Headphone:X®
Y
N
Optical and Removable Storage
Factory
Configured
Option Kit
Option Kit Part
Number
HP SlimTray Optical Drives
HP External USB Optical Drive
N
Y
F2B56AA
NOTE: Actual speeds may vary. Does not permit copying of commercially available DVD movies or other copyright protected materials. Intended for creation and storage of your original material and other lawful uses. Double Layer discs can store more data than single layer discs. However, double-layer discs burned with this drive may not be compatible with many existing single-layer DVD drives and players. NOTE: With Blu-ray, certain disc, digital connection, compatibility and/or performance issues may arise, and do not constitute defects in the product. Flawless playback on all systems is not guaranteed. In order for some Blu-ray titles to play, they may require a DVI or HDMI digital connection and your display may require HDCP support. HD-DVD movies cannot be played on this workstation.
Networking and Communications
Factory
Configured
Option
Kit
Option Kit Part
Number
Realtek RTL8153B 10/100/1000 Mbit (no vPro)
Y
N
The Intel® Gigabit Ethernet Connection I219LM (with vPro™)
Y
N
Intel® 9260 Wireless LAN (802.11ac) and Bluetooth® 5 Module (with vPro™) Or Realtek RTL8822BE-CG PCIe 802.11 AC/abgn WLAN with Bluetooth® 4.2 combo module
Y
N
NOTE: Full Intel® vPro™ Technology enabling requires either the Intel 9260 Wireless LAN or Gigabit Ethernet I219LM controller to be enabled and active. NOTE: Realtek RTL8153B Ethernet access is only possible through the HP Z VR Backpack G1 Dock. Intel vPro is not supported with Realtek Ethernet. NOTE: "Gigabit" Ethernet indicates compliance with IEEE standard 802.3ab for Gigabit Ethernet, and does not connote actual operating speed of 1 Gb/sec. For high speed transmission, connection to a Gigabit Ethernet server and network infrastructure is required.
QuickSpecs
HP VR Backpack G2
Supported Components
c06274598 —DA16466 —Worldwide — Version 6 — February 10, 2021
Page 12
Physical Security
Factory
Configured
Option Kit
Option Kit Part
Number
HP Keyed Cable Lock 10mm
N Y T1A62AA
HP Master Keyed Cable Lock 10mm
N Y T1A63AA
HP Dual Head Keyed Cable Lock
N Y T1A64AA
HP Dual Head Master Cable Lock
N Y T1A65AA
HP Essential Combination Lock (Herb)
N Y T0Y16AA
HP Combination Lock (Stuart)
N Y T0Y15AA
Input Devices
Factory
Configured
Option Kit
Option Kit Part
Number
HP Slim USB Keyboard and Mouse
N Y T6T83AA
HP Slim Wireless Keyboard and Mouse
N Y T6L04AA
HP USB Essential Keyboard and Mouse
N Y H6L29AA
Other Hardware
Factory
Configured
Option Kit
Option Kit Part
Number
HP Stereo 3.5mm Headset
N Y T1A66AA
HP Stereo USB Headset
N Y T1A67AA
Software
Factory
Configured
Option Kit
Support
Notes
HP Remote Graphics Software (RGS) 7.1
N
N
See Note 2
HP Client Security Software
N
N
See Note 3
NOTE: RGS available as a free download from
http://www.hp.com/go/rgs
NOTE: Windows 10 OS only. HP Client Security available as a SoftPaq download.
Operating Systems
Windows 10 Pro 64
QuickSpecs
HP VR Backpack G2

System Technical Specifications

c06274598 —DA16466 —Worldwide — Version 6 — February 10, 2021
Page 13
System Board
System Board Form Factor
313 mm x 209 mm (12.3 x 8.23 inches) Processor Socket
FCBGA1440
CPU Bus Speed
DMI link between CPU & PCH
Chipset
Intel® QM370
Memory Expansion Slots
2 SODIMM DDR4 memory slots
Memory Type Supported
DDR4, SODIMM (Unbuffered), non-ECC Memory Modes
Non-Interleaved for single channel. Interleaved when both channels are populated.
Memory Speed Supported
2666MHz DDR4 Memory Protection
None
Maximum Memory
32GB
Memory Configuration (Supported)
8GB and 16GB non-ECC unbuffered SODIMMs are supported.
Integrated Graphics
None
NOTE: Integrated Graphics is NOT enabled in the HP Z VR Backpack G1 product
Discrete Graphics
NVIDIA® GeForce® RTX2080 with 8GB GDDR6 memory Memory width: 256 bit NVIDIA® CUDA™ Cores: 2944 API support: DirectX 12, Shader Version 6.3, Open GL 4.6, OpenCL 1.2 Display outputs: 6 (only 4 are implemented). DisplayPort™ 1.4
Network Controller
RealTek RTL 8153B 10/100/1000 Mbs LAN. Management capabilities: WOL, PXE 2.1. The Intel® Gigabit Ethernet Connection I219LM (with vPro™) : WOL, PXE 2.1
Wireless Network Controller
M.2 PCIe
Intel® 9260 WLAN/BT. Management capabilities: WOL(partial), vPro™/iAMT Or Realtek RTL8822BE-CG WLAN/BT. Management capabilities: n/a
Supported Drive Interfaces
M.2 PCIe
NVMe SSD – 80mm size, 256GB, 512GB, 1TB
USB Connector(s)
Top
2 USB 3.0 Type-A 1 USB 3.1 Type-C™ with Thunderbolt™ 3
QuickSpecs
HP VR Backpack G2
System Technical Specifications
c06274598 —DA16466 —Worldwide — Version 6 — February 10, 2021
Page 14
Side
2 USB 3.0 Type-A 1 RJ-45 gigabit LAN port
Display Connectors
Top
2 mini-DisplayPort™ 1.4 1 USB 3.1 Type-C™ (DisplayPort through Thunderbolt™)
Power Connector
Top
12V DC out power jack for HTC Vive™ HMD
Side
DC-in power jack for external 330W power supply
Bottom
DC-in integrated with dock connector
Dock Connector
Bottom
Proprietary combo connector that mates with the HP Z VR Backpack Dock (HP Part Number: 2LM71AA)
HD Integrated Audio
RealTek ALC3866-CG with software integration of DTS Headphone:X®
Flash ROM
Yes
Chassis Fan
Yes: 1 for CPU + memory + system, 1 for GPU + memory
CMOS Battery Holder ­Lithium
Yes Battery
36Whr Lithium Ion, internal
Trusted Platform Module
Infineon SLB9670 TPM 2.0
Power Supply Headers
Yes, One DC-in jack for external power supply One 12V DC-out jack for HTC Vive™ HMD
Power Switch, Power LED
The power and Sleep State LED are combined in the Top-Side power switch.
Storage LED Indicator
None
Clear Password Jumper
Yes Keyboard/Mouse
Not provided with Base Unit. Separate AMO accessory.
Power Supply
330W HP Smart AC Adapter, 92.6% efficiency, wide-ranging, active PFC Power Supply
Operating Voltage Range
115-230 VAC Rated Voltage Range
100–240 VAC
Rated Line Frequency
50-60 Hz
Operating Line Frequency Range
47–63 Hz Rated Input Current
1.9A @ 90Vac
QuickSpecs
HP VR Backpack G2
System Technical Specifications
c06274598 —DA16466 —Worldwide — Version 6 — February 10, 2021
Page 15
ENERGY STAR® qualified (Config Dependent)
Yes
FEMP Standby Power Compliant
No
Surge Tolerant Full Ranging Power Supply (Common mode power surges up to 2000V)
Yes
Internal Battery
36Whr Battery operating information shown in table below
Allowable Temperature Range
0℃ ~ 50℃
Charge Initial Temperature
0℃ ~ 50℃
Continuous Charging
-10℃ ~ 60℃
For start of discharge below 0˚C, the battery
pack must have a charge ≥ 80%
-20℃ ~ 60℃
-20℃ ~ 45℃
-20℃ ~ 30℃
Storage Temperature 1 month 3 month 6 month
External Battery
73Whr Battery operating information shown in table below
Allowable Temperature Range
0℃ ~ 45℃
Charge Initial Temperature
0℃ ~ 45℃
Continuous Charging
-10℃ ~ 60℃
For start of discharge below 0˚C, the battery
pack must have a charge ≥ 80%
-20℃ ~ 60℃
-20℃ ~ 45℃
-20℃ ~ 30℃
Storage Temperature 1 month 3 month 6 month
QuickSpecs
HP VR Backpack G2
System Technical Specifications
c06274598 —DA16466 —Worldwide — Version 6 — February 10, 2021
Page 16
Declared Noise Emissions
Declared Noise Emissions
System Configuration
Processor Info
Intel® Core™ i7-8850H 2.6G/9M/6C
Memory Info
2 - 16GB DDR4-2666 SO-DIMM Memory
Graphics Info
NVIDIA® GeForce® RTX2080 with 8GB GDDR6 Disks/SSD
1 - Samsung 1TB PCIe M.2 SSD
Declared Noise Emissions (in
accordance with ISO 7779 and ISO 9296)
Sound Power
(LWAd, bels)
Deskside Sound Pressure
(LpAm, decibels)
Under Operating Load (playing VR content)
QuickSpecs
HP VR Backpack G2
System Technical Specifications
c06274598 —DA16466 —Worldwide — Version 6 — February 10, 2021
Page 17
Physical Security and Serviceability
Access Panel
No access panel. Tools required to remove top cover (rubber feet covers must be removed first). System is not designed for customer access. Hard Drives
None
Expansion Cards
M.2 module requires a screwdriver to service and replace.
Processor Socket
No CPU socket. CPU soldered on motherboard.
Memory
Must remove shielding cover (for EMI) first (requires tools).
System Board
Screw-In
Single Color Power and HD LED on Front of Computer
The Power LED is on the top of the system. No HDD LED on the system.
Over-Temp Warning on Screen
No. System will automatically throttle in over-temperature situations. Restore CD/DVD Set
None
Dual Function Front Power Switch
Yes, causes a fail-safe power off when held for 4 seconds (default)
Cable Lock Support
Yes, but requires use of the HP VR Backpack Dock with a Kensington Cable Lock solution (optional): Locks HP VR Backpack G2 to the Dock once cable lock is engaged on the docking station. Secures HP VR Backpack G2 to docking station. 3 mm x 7 mm slot on the HP VR Backpack Dock station.
Serial, Parallel, Enable/Disable Port Control
No serial or parallel ports are available on the HP VR Backpack G2.
USB Enable/Disable Port Control
Yes – enable/disable per port control.
Removable Media Write/Boot Control
Yes, prevents ability to boot from removable media on supported devices (and can disable writes to media)
Power-On Password
Yes, prevents an unauthorized person from booting up the workstation
Setup Password
Yes, prevents an unauthorized person from changing the workstation configuration
NIC LEDs (integrated) (Green & Amber)
No.
QuickSpecs
HP VR Backpack G2
System Technical Specifications
c06274598 —DA16466 —Worldwide — Version 6 — February 10, 2021
Page 18
CPUs and Heatsinks
Not serviceable.
Power Supply Diagnostic LED
No. Not applicable. Front Power LED
Yes, RGB
Internal Speaker
No
System/Emergency ROM Flash Recovery
Crisis recovery feature recovers from corrupted system BIOS by using Boot Block support. Cooling Solution
Air cooled forced convection
CPU Heatsink Fan
Yes. Heatsink is common between CPU and GPU assembly areas.
GPU Heatsink Fan
Yes. Heatsink is common between CPU and GPU assembly areas.
Chassis Fan
Two fan system.
Memory Heatsink Fan
No
HP PC Hardware Diagnostics UEFI
HP PC Hardware Diagnostics (UEFI) enables hardware level testing outside the operating system on many components. The diagnostics can be invoked by pressing F2 at POST, and is available as a download from HP Support.
Access Panel Key Lock
Not applicable. No chassis access panel.
ACPI-Ready Hardware
Advanced Configuration and Power Management Interface (ACPI).
• Allows the system to wake from a low power mode.
• Controls system power consumption, making it possible to place individual cards and
peripherals in a low-power or powered-off state without affecting other elements of the system
Trusted Platform Module Chip
Yes M.2 Card Retention
Yes, all M.2 modules are retained by a single screw
Flash ROM
Yes
DIMM Connectors
Yes, 2 SODIMM connectors
QuickSpecs
HP VR Backpack G2
System Technical Specifications
c06274598 —DA16466 —Worldwide — Version 6 — February 10, 2021
Page 19
BIOS
PCI 3.0 Support
Full BIOS support for PCI Express through industry standard interfaces.
BBS
BIOS Boot Specification v1.01. Provides more control over how and from what devices the workstation will boot.
WMI Support
WMI is Microsoft's implementation of Web-Based Enterprise Management (WBEM) for Windows. WMI is fully compliant with the Distributed Management Task Force (DMTF) Common Information Model (CIM) and WBEM specifications.
ROM Based Computer Setup Utility (F10)
Review and customize system configuration settings controlled by the BIOS.
System/Emergency ROM Flash Recovery with Video
Recovers system BIOS in corrupted Flash ROM.
Replicated Setup
Saves BIOS settings to USB flash device in human readable file. BIOS Configuration Utility (BCU) utility can then replicate these settings on machines being deployed without entering Computer Configuration Utility (F10 Setup).
SMBIOS
System Management BIOS 3.0., for system management information.
Boot Control
Disables the ability to boot from removable media on supported devices.
Thermal Alert
Monitors the temperature state within the chassis. Three modes:
• NORMAL - normal temperature ranges.
• ALERTED - excessive temperatures are detected. Raises a flag so action can be taken to
avoid shutdown or provide for a smoother system shutdown.
• SHUTDOWN - excessive temperatures are encountered. Automatically shuts down the computer without warning before hardware component damage occurs.
Remote ROM Flash
Provides secure, fail-safe ROM image management from a central network console. Updates can be performed before starting the OS. Updates can be periodically scheduled.
ACPI (Advanced Configuration and Power Management Interface)
Allows the system to enter and resume from low power modes (sleep states). Enables an operating system to control system power consumption based on the dynamic workload. Makes it possible to place individual cards and peripherals in a low-power or powered-off state without affecting other elements of the system. Supports ACPI 6.0 for full compatibility with 64-bit operating systems.
Ownership Tag
A user-defined string stored in non-volatile memory that is displayed in the BIOS splash screen.
Remote Wakeup/Remote Shutdown
System administrators can power on, restart, and power off a client computer from a remote location.
ASF 2.0 Compliant
Yes.
QuickSpecs
HP VR Backpack G2
System Technical Specifications
c06274598 —DA16466 —Worldwide — Version 6 — February 10, 2021
Page 20
Instantly Available PC (Suspend to RAM ­ACPI sleep state S3)
Allows for very low power consumption with quick resume time.
Remote System Installation via F12 (PXE 2.1) (Remote Boot from Server)
Allows a new or existing system to boot over the network and download software, including the operating system.
ROM revision levels
Reports the system BIOS revision level in Computer Configuration Utility (F10 Setup). Version is available through an industry standard interface (SMBIOS) so that management SW applications can use and report this information.
System board revision level
Allows management SW to read revision level of the system board. Revision level is digitally encoded into the HW and cannot be modified.
Start-up Diagnostics (Power-on Self-Test)
Assesses system health at boot time with selectable levels of testing.
Auto Setup when new hardware installed
System automatically detects addition of new hardware.
Keyboard-less Operation
The system can be booted without a keyboard.
Localized ROM Setup
Common BIOS image supports System Configuration Utility (F10 Setup) menus in 5 languages with local keyboard mappings.
Asset Tag
The user or IT administrator to set a unique tag string in non-volatile memory.
Per-slot Control
Allows I/O slot parameters (option ROM enable/disable) to be configured individually.
Adaptive Cooling
Control parameters are set according to detected hardware configuration for optimal acoustics.
Pre-boot Diagnostics
(Pre-video) critical errors are reported via beeps and blinks on the power LED.
Digitally and Cryptographically Signed BIOS
Helps to prevent the installation of unauthorized versions of a BIOS (a rogue BIOS) from a virus, malware, or other code that could lead to compromised system security, data access, physical service, or even system board replacement.
Boot Block Emergency Recovery Mode (BIOS Recovery)
The HP BIOS offers a write-protected boot block ROM that provides recovery from a failed flashing of the computer BIOS. This special recovery mode prevents the system from becoming unusable or “bricked” when a BIOS update is interrupted.
UEFI Specification Revision
UEFI 2.7 ACPI
Advanced Configuration and Power Management Interface, Version 6.0 ASF
Alert Standard Format Specification, Version 2.0
QuickSpecs
HP VR Backpack G2
System Technical Specifications
c06274598 —DA16466 —Worldwide — Version 6 — February 10, 2021
Page 21
EDD
- Enhanced Disk Drive Specification Version 1.1
- BIOS Enhanced Disk Drive Specification Version 3.0
PCI Express
PCI Express Base Specification, Revision 3.0.
PMM
POST Memory Manager Specification, Version 1.01
SATA
- Serial ATA Specification, Revision 1.0a
- Serial ATA II: Extensions to Serial ATA 1.0, Revision 1.0a
- Serial ATA II Cables and Connectors Volume 2 Gold
- SATA-IO SATA Revision 3.0 Specification
SPD
PC SDRAM Serial Presence Detect (SPD) Specification, Revision 1.2B
TPM
Trusted Computing Group TPM Specification Version 2.0
USB
Universal Serial Bus Revision 1.1 Specification Universal Serial Bus Revision 2.0 Specification Universal Serial Bus Revision 3.0 Specification
QuickSpecs
HP VR Backpack G2
System Technical Specifications
c06274598 —DA16466 —Worldwide — Version 6 — February 10, 2021
Page 22
Battery Management and Battery Charge Level Indicators
The HP VR Backpack uses the white LED HP logo and LED light bar located on the PC unit top to report the status
of the internal and external battery charge levels. These LED’s are shown below. The reporting behavior of battery
charge level status is dependent on the HP VR Backpack PC system BIOS revision level. It is highly recommended that the PC unit uses system BIOS revision level F.01 or later. The F.01 or later BIOS can be obtained from HP Support Services on HP.com. For maximum performance while in battery operation mode, the external batteries must be charged. If they fall below a certain threshold as described below depending on the system BIOS revision level on the PC unit, the VR experience will quickly become be suboptimal and compromised if the external batteries are not swapped with charged battery replacements.
LED Reporting Behavior for System BIOS Revisions F.01 or Later
For systems using the BIOS revisions F.01 or later, the low battery algorithm is as follows:
Internal Battery
Charge Level
External Batteries Charge Level
HP Logo LED
Behavior
Light Bar LED Behavior
> 12%
Both > 12%
Solid ON (White)
Solid ON (White)
Only one > 12%
Solid ON (White)
Slow Flashing (Yellow)
Both <= 12%
Solid ON (White)
Fast Flashing (Yellow)
<= 12%
Both > 12%
Slow Flashing
(Yellow)
Solid ON (White) (Yellow)
Only one > 12%
Slow Flashing
(Yellow)
Slow Flashing (Yellow)
Both <= 12%
Fast Flashing
(Yellow)
Fast Flashing (Yellow)
It may be useful to recognize that the HP Logo LED primarily reports the status of the PC internal battery, while the Light Bar LED reports the status of the external batteries. For added notification emphasis, when all batteries are below 12%, both the HP Logo and Light Bar will be set to fast flashing mode.
QuickSpecs
HP VR Backpack G2
System Technical Specifications
c06274598 —DA16466 —Worldwide — Version 6 — February 10, 2021
Page 23
OS Level Battery Charge Reporting
If the HP VR Backpack PC is configured to wirelessly connect to a display monitor, keyboard and mouse, it is possible for the operator to use the Windows 10 Pro battery status application usually located in the Notifications area of the Windows 10 Task Bar. Simply click on the battery icon and 3 batteries with their status information should be displayed. If a battery is missing from the report, check all external battery connections to the PC to make sure they are secure.
QuickSpecs
HP VR Backpack G2
System Technical Specifications
c06274598 —DA16466 —Worldwide — Version 6 — February 10, 2021
Page 24
Eco-Label Certifications & Declarations
This product is low halogen except for power cords, cables and peripherals. Service parts obtained after purchase may not be Low Halogen.
• ENERGY STAR® (energy-saving features available on selected configurations – Windows® only)
• China Energy Conservation Program (CECP)
IT ECO declaration
Batteries
The battery in this product complies with EU Directive 2006/66/EC Battery size: CR2032 (coin cell) Battery type: Lithium Metal
The battery in this product does not contain:
• Mercury greater than 5ppm by weight
• Cadmium greater than 10ppm by weight
Lead greater than 40ppm by weight
Batteries – Internal 36Whr
The battery in this product complies with EU Directive 2006/66/EC Battery size: 4 cell Battery type: Lithium ion Metal
The battery in this product does not contain:
• Mercury greater than 5ppm by weight
• Cadmium greater than 10ppm by weight
• Lead greater than 40ppm by weight
Lead greater than 40ppm by weight
Restricted Material Usage
This product meets the material restrictions specified in HP's General Specification for the Environment. http://www.hp.com/hpinfo/globalcitizenship/environment/pdf/gse.pdf HP Inc. is committed to compliance with all applicable environmental laws and regulations, including the European Union Restriction of Hazardous Substances (RoHS) Directive. HP's goal is to exceed compliance obligations by meeting the requirements of the RoHS Directive on a worldwide basis.
Low Halogen Statement
This product is low halogen except for power cords, cables and peripherals. Service parts obtained after purchase may not be Low Halogen.
End-of-Life Management and Recycling
HP Inc. offers end-of-life HP product return and recycling programs in many geographic areas. To recycle your product, please go to: http://www.hp.com/recycle or contact your nearest HP sales office. Products returned to HP will be recycled, recovered or disposed of in a responsible manner. This product is greater than 90% recyclable by weight when properly disposed of at end of life.
HP Inc. Corporate Environmental Information
For more information about HP's commitment to the environment: Living Progress Report http://www.hp.com/hpinfo/globalcitizenship/gcreport/index.html
QuickSpecs
HP VR Backpack G2
System Technical Specifications
c06274598 —DA16466 —Worldwide — Version 6 — February 10, 2021
Page 25
Eco-label certifications
http://www.hp.com/hpinfo/globalcitizenship/environment/productdesign/ecolabels.html
ISO 14001 certificates:
http://www.hp.com/hpinfo/globalcitizenship/environment/operations/envmanagement.html
Additional Information
• This HP product is designed to comply with the Waste Electrical and Electronic Equipment (WEEE) Directive - 2002/96/EC.
• Plastic parts weighing over 25 grams used in the product are marked per ISO 11469 and ISO1043.
• This product is >90% recycle-able when properly disposed of at end of life
EPEAT® Silver registered in the U.S. EPEAT registration varies by country. See
http://www.epeat.net for registration status by country.
Packaging
HP Workstation product packaging meets the HP General Specification for the Environment at
http://www.hp.com/hpinfo/globalcitizenship/society/gen_specifications.html
• Does not contain restricted substances listed in HP Standard 011-1 General Specification for the Environment
• Does not contain ozone-depleting substances (ODS)
• Does not contain heavy metals (lead, mercury, cadmium or hexavalent chromium) in
excess of 100 ppm sum total for all heavy metals listed
• Maximizes the use of post-consumer recycled content materials in packaging materials
• All packaging material is recyclable
• All packaging material is designed for ease of disassembly
• Reduced size and weight of packages to improve transportation fuel efficiency
Plastic packaging materials are marked according to ISO 11469 and DIN 6120 standards formatting
Packaging Materials
Internal
Cushions made from fabricated recycled expanded-polyethylene (EPE) or recycled expanded­polypropylene (EPP). May also be made from recycled molded paper-pulp (MPP).
External
Carton made from corrugated fiberboard with at least 25% recycled content.
QuickSpecs
HP VR Backpack G2
System Technical Specifications
c06274598 —DA16466 —Worldwide — Version 6 — February 10, 2021
Page 26
Manageability
Intel® Active Management Technology (AMT)
The HP VR Backpack G2 supports Intel® vPro™ technology when purchased with a vPro™ technology capable CPU: Intel® Core™ i7 processors with Intel® VT-d/VT-x and Intel® TXT technology.
Remote Manageability Software Solutions
Visit: http://www.hp.com/go/easydeploy
System Software Manager
Visit: http://www.hp.com/go/ssm
Service, Support, and Warranty
Limited 1-year limited warranty. Batteries have a default one year limited warranty.
Optional HP Care Pack Services are extended service contracts which go beyond your standard limited warranties. To choose the right level of service for your HP product, use the HP Care Pack Services Lookup Tool at http://www.hp.com/go/cpc. Sold separately or as an optional feature. Service levels and response times for HP Care Packs may vary depending on your geographic location.
Service starts on date of hardware purchase. Restrictions and limitations apply. HP services are governed by the applicable HP terms and conditions of service provided or indicated to Customer at the time of purchase. Customer may have additional statutory rights according to applicable local laws, and such rights are not in any way affected by the HP terms and conditions of service or the HP Limited Warranty provided with your HP Product. Consult your local HP Customer Support Center for details.
QuickSpecs
HP VR Backpack G2

Technical Specifications - Processors

c06274598 —DA16466 —Worldwide — Version 6 — February 10, 2021
Page 27
Name
Cores
Clock
Speed
(GHz)
Intel® Turbo Boost Technology1
Cache
(MB)
Memory
Speed (MT/s)
Hyper-
Threading
Integrated
Graphics
Featuring
Intel® vPro™
Technology
TDP
(W)
HP VR Backpack G2 Performance base unit
Intel® Core™ i7-9750H
6
2.6 GHz
4.5 GHz
12 MB
2666
(DDR4)
Yes
N/A2 No
45W
Intel® Core™ i7-9850H
6
2.6 GHz
4.6 GHz
12 MB
2666
(DDR4)
Yes
N/A
2
Yes
45W
1. The specifications shown in this column represent the maximum turbo frequency with one core active. Turbo boost stepping occurs in 100MHz increments. Processors that do not have turbo functionality are denoted as N/A.
2. Integrated Graphics is NOT enabled in the HP VR Backpack G2. All graphics for the platform is provided by the NVIDIA® GeForce® RTX2080 GPU.
QuickSpecs
HP VR Backpack G2

Technical Specifications - Storage

c06274598 —DA16466 —Worldwide — Version 6 — February 10, 2021
Page 28
M.2 NVMe SSD
1TB TLC
Capacity
1024GB
Protocol
NVMe
Form Factor
M.2 2280
Controller
NVMe
Rated for 24/7/365 operation
NO Physical Size (Height)
0.14 in; 3.65 mm
Physical Size (Width)
0.87 in; 22 mm
Drive Weight
0.02; 10 g
Interface
PCIe NVMe Gen3 x4
Synchronous Transfer Rate (Maximum)
Read: Up to 3300 MB/s; Write: Up to 1,775 MB/s
Operating Temperature
32° to 158° F (0° to 70° C)
M.2 NVMe SSD
512GB TLC
Capacity
512GB
Protocol
NVMe
Form Factor
M.2 2280
Controller
NVMe
Rated for 24/7/365 operation
NO Physical Size (Height)
0.14 in; 3.65 mm
Physical Size (Width)
0.87 in; 22 mm
Drive Weight
0.02; 10 g
Interface
PCIe NVMe Gen3 x4
Synchronous Transfer Rate (Maximum)
Read: Up to 3200 MB/s; Write: Up to 1300 MB/s
Operating Temperature
32° to 158° F (0° to 70° C)
M.2 NVMe SSD
256GB TLC
Capacity
256GB
Protocol
NVMe
Form Factor
M.2 2280
Controller
NVMe
Rated for 24/7/365 operation
NO Physical Size (Height)
0.14 in; 3.65 mm
Physical Size (Width)
0.87 in; 22 mm
Drive Weight
0.02; 10 g
Interface
PCIe NVMe Gen3 x4
Synchronous Transfer Rate (Maximum)
Read: Up to 3200 MB/s; Write: Up to 1255 MB/s
Operating Temperature
32° to 158° F (0° to 70° C)
QuickSpecs
HP VR Backpack G2

Technical Specifications - Graphics

c06274598 —DA16466 —Worldwide — Version 6 — February 10, 2021
Page 29
NVIDIA® GeForce® RTX2080 8GB Graphics
Maximum Resolution
DisplayPort 1.4:
- up to 7680 x 4320 @ 60Hz (DSC)
- supports High Bit Rate 3 (HBR3) and Multi-Stream Transport (MST) HDMI 2.0 output:
- up to 4096x2160 x 30 bpp @ 60Hz
Display Output
Maximum number of displays:
- 4 direct attached monitors Maximum number of DisplayPort™ displays possible per
DisplayPort™ output (Multiple displays daisy-chained from one DisplayPort™ 1.3 port requires DisplayPort™ 1.2 MST capable
displays or DP1.3 MST capable hub):
- 4 1920x1200 @ 60 Hz
- 2 2560x1600 @ 60 Hz
- 1 4096x2160 @ 60 Hz Maximum number of monitors across all available RTX2080 outputs is
4.
Supported Graphics APIs
OpenGL 4.6 DirectX 12
API support includes: CUDA C, CUDA C++, DirectCompute 5.0, OpenCL, Java, Python, and Fortran
Available Graphics Drivers
Microsoft Windows 10 HP qualified drivers may be preloaded or available from the HP
support Web site:
http://welcome.hp.com/country/us/en/support.html
QuickSpecs
HP VR Backpack G2

Technical Specifications - Network

c06274598 —DA16466 —Worldwide — Version 6 — February 10, 2021
Page 30
Realtek RTL8153B GbE Controller
Connector
RJ-45
Controller
Realtek RTL8153B GbE platform LAN connect networking controller, USB 3.0 bus connection to host.
Memory
Tx and Rx packet buffer memory
Data Rates Supported
10/100/1000 Mbps
Compliance
802.1as/1588, 802.1p, 802.1Q, 802.3, 802.3ab, 802.3az, 802.3i,
802.3u
Bus Architecture
USB 3.0
Data Transfer Mode
USB-based interface for active state operation (S0 state) and SMBus for host and management traffic (Sx low power state)
Power Requirement
Requires 3.3V (integrated regulators for core Vdc)
Boot ROM Support
Yes
Network Transfer Mode
Full-duplex; Half-duplex (not supported for the 1000BASE-T transceiver)
Network Transfer Rate
10BASE-T (half-duplex) 10 Mbps 10BASE-T (full-duplex) 10 Mbps 100BASE-TX (half-duplex) 100 Mbps 100BASE-TX (full-duplex) 100 Mbps 1000BASE-T (full-duplex) 1000 Mbps
Management Capabilities
WOL, auto MDI crossover, PXE, ACPI, LPM, VLAN, Multicast Listener Discovery (MLD)
Intel I219LM GbE Controller
Connector
RJ-45
Controller
Intel® Ethernet Connection I219LM LAN connect networking controller, PCIe bus connection to host.
Memory
Tx and Rx packet buffer memory
Data Rates Supported
10/100/1000 Mbps
Compliance
802.1as/1588, 802.1p, 802.1Q, 802.3, 802.3ab, 802.3az, 802.3i,
802.3u
Bus Architecture
PCIe
Data Transfer Mode
PCIe-based interface for active state operation (S0 state) SMBus-based interface for host and management traffic (Sx low power state)
Power Requirement
Requires 3.3V (integrated regulators for core Vdc)
Boot ROM Support
Yes
Network Transfer Mode
Full-duplex; Half-duplex (not supported for the 1000BASE-T transceiver)
Network Transfer Rate
10BASE-T (half-duplex) 10 Mbps 10BASE-T (full-duplex) 10 Mbps 100BASE-TX (half-duplex) 100 Mbps 100BASE-TX (full-duplex) 100 Mbps 1000BASE-T (full-duplex) 1000 Mbps
Management Capabilities
WOL, auto MDI crossover, PXE, RSS, ACPI, Advanced cable diagnostic, loopback modes, VLAN, Multicast Listener Discovery (MLD)
QuickSpecs
HP VR Backpack G2
Technical Specifications - Network
c06274598 —DA16466 —Worldwide — Version 6 — February 10, 2021
Page 31
Intel® 9260 Wireless LAN (802.11ac) and Bluetooth 5 Module
Connector
M.2 (Supports 2230 form factor; E Key) Motherboard Interface
Controller
Intel® Dual Band Wireless-AC 9260
Compliance
Wi-Fi CERTIFIED: IEEE 802.11a/b/g/n/ac with wave 2 feature WMM, WMM-PS, WPA, WPA2, WPS2, Protected Management Frames, Wi­Fi Miracast as Source, and Wi-Fi Direct IEEE 802.11d, 802.11e, 802.11i, 802.11h, 802.11w, 802.11r,
802.11k, 802.11v pending OS support; Fine Timing Measurement based on 802.11REVmc FIPS, FISMA Bluetooth® 5
Antenna
2x2
Tx/Rx Streams
2x2
Bands
2.4 GHz, 5GHz
Bus Architecture
PCI Express Gen3 x1 and USB 2.0
Management Capabilities
F10 BIOS Menu option to disable/enable WLAN and Bluetooth® radios, supports seamless roaming between 802.11 wireless access points
Throughput
Max PHY throughput 1.73 Gbps (802.11ac 160MHz) for WLAN
Realtek RTL8822BE­CG Wireless LAN.
Connector
M.2 (Supports 2230 form factor; E Key) Motherboard Interface
Controller
Realtek RTL8822BE-CG
Compliance
Wireless LAN: IEEE 802.11abgn, 802.11ac IEEE 802.11x, 802.11i, WEP, WPA, WPA-PSK, WPA2, WPA2-PSK, and WPS Bluetooth®: 2.1+EDR, 3.0+HS, 4.0LE, 4.1, and 4.2
Antenna
2x2
Tx/Rx Streams
2x2
Bands
2.4 GHz, 5GHz
Bus Architecture
PCI Express Gen3 x1 and USB 2.0
Management Capabilities
F10 BIOS Menu option to disable/enable WLAN and Bluetooth® radios, supports seamless roaming between 802.11 wireless access points
Throughput
Max PHY throughput 867 Mbps (802.11ac) for WLAN
Notes
Wireless access point and internet service required. Availability of public wireless access points limited. The specifications for the
802.11ac WLAN are draft specifications and are not final. If the final
QuickSpecs
HP VR Backpack G2
Technical Specifications - Network
c06274598 —DA16466 —Worldwide — Version 6 — February 10, 2021
Page 32
specifications differ from the draft specifications, it may affect the ability of the notebook to communicate with other 802.11ac WLAN devices.
QuickSpecs
HP VR Backpack G2

Technical Specifications – Power

c06274598 —DA16466 —Worldwide — Version 6 — February 10, 2021
Page 33
HP 330W Smart AC Adapter (for HP VR Backpack G2)
Dimensions
5.9 x 5.9 x 1.48 in (150 x 150 x 37.5 mm)
Weight
2.43lb / 1.1kg nominal
Input
100 to 240 VAC
Input Efficiency
92.6% average at 115Vac and 93.2% average at 230Vac
Input frequency range
47 to 63 Hz
Input AC current
4.2A RMS at 90 VAC, maximum
Output
Output power
330W nominal
DC output
19.5 VDC nominal
Hold-up time
10 msec at 115 VAC input with maximum load
Output current limit
34A (5ms)
Over voltage protection
Shall not exceed 29 Volts for no longer than 250ms, auto shutdown
Connector
3 pin/grounded, mates with interchangeable cords
Environmental Design
Operating temperature
32° to 95° F (0° to 35° C)
Non-operating (storage) temperature
-4° to 185° F (-20° to 85° C) Altitude
Up to 16400 ft (5000 m)
Humidity
up to 95%, non-condensing
Storage Humidity
up to 95%, non-condensing
EMI and Safety Certifications
CE Mark- full compliance with LVD and EMC directives; Worldwide safety standards- IEC950, EN60950, UL1950, Class 1, SELV; Agency approvals- C-UL-US, NORDICS, DENAN, EN55032 Class B, FCC Class B, CISPR22 Class B, CCIB, NOM-1 NYCE; MTBF- over 200,000 hours at 25°C ambient condition.
HP 180W Smart AC Adapter (for external battery charger)
Dimensions
7.1 x 3.35 x 1.65 in (180 x 85 x 42mm)
Weight
1.81 lb (820 g)
Input
90 to 264 VAC
Input Efficiency
89% min at 115 VAC
Input frequency range
47 to 63 Hz
Input AC current
2.5 A at 90 VAC, 1.45 A at 180 VAC
Output
Output power
180W nominal
DC output
19.5V nominal
Hold-up time
>5 msec at 115 VAC input
Output current limit
Not exceed 240VA for more than 60s, automatic shutdown
Over voltage protection
29V max for no longer than 250ms, automatic shutdown
Connector
3 pin/grounded, mates with interchangeable cords
Environmental Design
Operating
temperature
41° to 95° F (5° to 35° C)
Non-operating (storage) temperature
-4° to 185° F (-20° to 85° C)
Altitude
0 to 16405 ft (0 to 5000 m) with 32° C max ambient temperature at max altitude
QuickSpecs
HP VR Backpack G2
Technical Specifications – Power
c06274598 —DA16466 —Worldwide — Version 6 — February 10, 2021
Page 34
Humidity
20% to 95%
EMI and Safety Certifications
Worldwide safety and EMC approvals including CE, UL, CSA or cUL, GS, Australian Electric Permit, C-tick, NOM, CCC, KC, GOST, SABS, S mark, BSMI, ISC, PSE, PSB and SII.
QuickSpecs
HP VR Backpack G2

Options and Accessories (sold separately and availability may vary by country)

c06274598 —DA16466 —Worldwide — Version 6 — February 10, 2021
Page 35
Option Type
Description
Part Number
HP VR Backpack G2 –
HP VR Backpack Harness
7CZ31AA HP Z VR Backpack Battery Pack
2HY48AA
HP Z VR Backpack Battery Charger
2HY51AA
HP Z VR Backpack G1 Dock
2LM71AA
Input/Output
HP Slim USB Keyboard and Mouse
T6T83AA
HP Slim Wireless Keyboard and Mouse
T6L04AA
HP USB Essential Keyboard and Mouse
H6L29AA
HP Stereo 3.5mm Headset
T1A66AA
HP Stereo USB Headset
T1A67AA
USB-C to HDMI 1.4
N9K77AA
HP USB-C to DisplayPort Adapter
N9K78AA
Power
HP 330W Smart AC Adapter
2YD04AA
Security
HP Essential Combination Lock (Herb)
T0Y16AA
HP Combination Lock (Stuart)
T0Y15AA
HP Dual Head Keyed Cable Lock (Sumo)
T1A64AA
HP Dual Head Master Cable Lock (Sumo MK)
T1A65AA
HP Keyed Cable Lock 10mm
T1A62AA
HP Master Keyed Cable Lock
T1A63AA
Storage - external
HP External USB Optical Drive
F2B56AA
QuickSpecs
HP VR Backpack G2

Summary of Changes

c06274598 —DA16466 —Worldwide — Version 6 — February 10, 2021
Page 36
Date of change:
Version History:
Description of change:
October 8, 2019
From v1 to v2
Added
HP VR Backpack G2 Harness and HP VR Backpack G2 Harness PC Mount to Accessories
March 20, 2020
From v2 to v3
Changed
HP VR Backpack G2 Accessories
March 26, 2020
From v3 to v4
Changed
Format page 9
December 12, 2020
From v4 to v5
Changed
Accessories section
February 10, 2021
From v5 to v6
Updated
Intel® Core™ i7-9750H and Intel® Core™ i7-9850H
QuickSpecs

HP VR Backpack G2

c06274598 —DA16466 —Worldwide — Version 6 — February 10, 2021
Page 37
Loading...
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
