hp e-commerce/

xml server accelerator

user guide

sa7150

Hewlett-Packard Company 3000 Hanover Street Palo Alto, CA 94304-1185

Publication Number

5971-3006 March 2001

Disclaimer

The information contained in this document is subject to change without notice.

HEWLETT-PACKARD COMPANY MAKES NO WARRANTY OF ANY KIND WITH REGARD TO THIS MATERIAL, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. Hewlett-Packard shall not be liable for errors contained herein or f or incidental or conse quential damages in connection with the furnishing, performance, or use of this material.

Hewlett-Packard assumes no responsibility for the use or reliability of its software on equipment that is not furnished by Hewlett-Packard.

Warranty

A copy of the specific warranty terms applicable to your Hewlett-Packard products and replacement parts can be obtained from http://www.hp.com/ serverappliances/support.

*Other brands and names are the prop erty of their respective owners.

Chapter 1: Introduction

Introduction to the SA7150. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Assumptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Benefits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Typographic Conventions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Chapter 2: Installation and Initial Configuration

Parts Checklist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Additional Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Physical Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Rack Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Free-Standing Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Network Connections. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

C O N T E N T S HP e-Commerce/XML Server Accelerator SA7150 User Guide

Console Connection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Using HyperTerminal* . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Fail-through Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Accessing the Command Prompt . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Chapter 3: Theory of Operation

XML Operations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

General Considerations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Server Mappings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

XML Data Model . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

URI expressions in XML Patterns . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Invalid URI Expressions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Negation Operator. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Operators. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Attributes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Filters. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Boolean Operators. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Function Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

XML Pattern Creation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Mapped Server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Default Keyword. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

XML Pattern Matching . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

XML “Well-formed” Check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Network Configurations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Single Server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Multiple Servers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Multiple SA7150s and Cascading . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Scalability and Cascading . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Spilling and Throttling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Availability . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

SSL Operations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Keys and Certificates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Cutting and Pasting with HyperTerminal* . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Obtaining a Certificate from VeriSign* or Other Authority . . . . . . . . . . . . . . . . . 34

Procedure. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Using an Existing Key/Certificate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Table of Contents

Exporting a Key/Certificate from a Server . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Apache Interface to Open SSL* (mod_ssl). . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Apache SSL*. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Stronghold*. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Importing into the SA7150 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Creating a new Key/Certificate on the SA7150. . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Procedure. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Global Site Certificates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Global Site Certificate Paste Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Redirection: Clients and Unsupported Ciphers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Client Authentication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Creating a Client CA Certificate using OpenSSL* . . . . . . . . . . . . . . . . . . . . . . . . 45

SSL Processing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

Mapping. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

Automapping. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Automapping with user-specified key and certificate. . . . . . . . . . . . . . . . . . . . 47

Automapping with multiple port combinations . . . . . . . . . . . . . . . . . . . . . . . . 47

Deleting automapping entries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Manual mapping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

Combining automapping and manual mapping . . . . . . . . . . . . . . . . . . . . . . . . 48

Blocking. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

Specific IP, Specific Port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

Subnet, Specific Port. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

All IPs, Specific Port. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

Delete a Block. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

Failure Conditions, Fail-safe, and Fail-through . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

Chapter 4: Scenarios

Scenario 1—Basic XML Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

Procedure for Scenario 1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

Scenario 2—Single Server Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

Procedure for Scenario 2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

Automapping. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

Manual Configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

Scenario 3—Multiple Server Configuration (SSL) . . . . . . . . . . . . . . . . . . . . . . . . . . 61

Procedure for Scenario 3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

C O N T E N T S HP e-Commerce/XML Server Accelerator SA7150 User Guide

Scenario 4—Cascaded SA7150s. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63

Initial Configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63

Procedure for Scenario 4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64

Scenario 5—Different Ingress and Egress Routers . . . . . . . . . . . . . . . . . . . . . . . . . . 66

Procedure for Scenario 5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66

Scenario 6—Configuring a Firewall. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

Server Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

SA7150 Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

Chapter 5: Command Reference

Online Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

Command Line Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72

User Authentication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72

Command Line Prompt . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72

Abbreviation to Uniqueness. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72

Input Editing Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

Moving the Insertion Point . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

Command History . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

Cut and Paste . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74

Command Summary. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75

Command Reference. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80

Help Commands. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80

Status Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80

XML Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81

Port Mapping Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88

Operational Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91

Remote Management Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93

Alarms and Monitoring Commands. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100

Configuration Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103

Administration Commands

Logging Commands. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 108

Chapter 6: Remote Management

Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113

Limitations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114

Remote Management CLI Commands. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114

Remote Telnet Sessions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 116

Table of Contents

Telnet and Windows 2000 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 116

Local Serial Console . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 116

Remote Console, Telnet. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117

Changing the Telnet Port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 118

Disabling Telnet. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 118

Remote SSH Sessions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 119

Local Serial Console . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 119

Remote Console, SSH . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120

Changing the SSH Port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120

Disabling SSH . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121

SNMP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121

Starting SNMP. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 122

Standards Compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 122

HP MIB Tree . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123

Supported MIB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 124

Where to find the MIB File. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 124

Trap Summary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 124

Standard SNMP Traps. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 124

Traps in the HP Private MIB. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 124

Enabling SNMP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 126

Specifying SNMP Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 126

Community String. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 127

Trap Community String . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128

Access Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128

Chapter 7: Alarms and Monitoring

Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 131

Alarm Types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 133

ESC: Encryption Status Change Alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 133

Alarm Modifiers and Messages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 133

RSC: Refused SSL Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 134

Alarm Modifiers and Messages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 134

Extended Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 134

RSC Alarm CLI Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 134

UTL: Utilization Threshold Alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 135

Alarm Modifiers and Messages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 135

Extended Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 135

vii

C O N T E N T S HP e-Commerce/XML Server Accelerator SA7150 User Guide

UTL Alarm CLI commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 136

OVL: Overload Alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 137

Alarm Modifiers and Messages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 137

Extended Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 137

OVL Alarm CLI Commands. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 137

NLS: Network Link Status Alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 138

Alarm Modifiers and Messages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 138

Extended Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 138

Alarm Logging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 138

Monitoring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 142

Monitoring Reports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 142

Console Configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 142

Report Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 142

Monitoring Reports CLI Commands. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 143

Chapter 8: Software Updates

Using HyperTerminal* . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 146

Chapter 9: Troubleshooting

Appendix A: Front Panel

Buttons and Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 154

Front Panel LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 154

Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 156

Appendix B: Failure/Bypass Modes

Bypass Button. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 158

Fail-through Switch (Security Level) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 158

Appendix C: Supported Ciphers

Cipher Strength. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 161

SSL Version Level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 162

viii

Table of Contents

Appendix D: Regulatory Information

Taiwan Class A EMI Statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 165

VCCI Statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 166

FCC Part 15 Compliance Statement. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 166

Canada Compliance Statement (Industry Canada). . . . . . . . . . . . . . . . . . . . . . . . . . 167

CE Compliance Statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 167

CISPR 22 Statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 167

VCCI Class A (Japan). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 168

Australia . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 168

WARNING. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 168

AVERTISSEMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 169

WARNUNG . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 169

AVVERTENZA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 170

ADVERTENCIAS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 171

Wichtige Sicherheitshinweise. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 172

Appendix E: Software License Agreement

Mozilla* and expat* License Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 178

MOZILLA PUBLIC LICENSE, Version 1.1 . . . . . . . . . . . . . . . . . . . . . . . . . . . 178

Appendix F: Support Services

Support for your SA7150 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 191

U.S. and Canada. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 191

Europe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 192

Asia . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 193

Latin America . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 193

Other Countries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 194

Glossary

Index

C O N T E N T S HP e-Commerce/XML Server Accelerator SA7150 User Guide

Notes

Introduction

Introduction to the SA7150

The HP e-Commerce/XML Server Acce lerator S A7150 prov ides the flexibility to analyze Extensible Markup Language (XML) traffic according to content and distribute it according to user-defined parameters. The SA7150 is positioned in the network in front of business-to-business (B2B) XML servers, where it detects and parses XML messages or transaction data. It se nds client data to the most appropriate server, based on rules pre-configured for each server. The most common application is a B2B environment where the client is often another server or application.

C H A P T E R 1 HP e-Commerce/XML Server Accelerator SA7150 User Guide

Assumptions

It is assumed that you are a net w ork ad mini st rator and that you have at least a basic understanding of the following:

• XML usage and syntax

• Networking concepts and terminology

• Network topologies

• Networks and IP routing

Benefits

The SA7150 offloads S ecure Socket Layer (SSL) processing f or your e-Commerce site, web site, or Intranet. The S A7150 is th e best XML processing solution available.

Feature Benefits Patent-pending rules engine

allows classification of XML transactions for example, by:

•

Trading partner name

• Trading partner type

• Transaction quantity

• Transaction value

• Time of day

• Time zone

NOTE: The above items are examples. You can define any number of classifications according to your business needs.

Multi-variable classification, including AND, OR

Handles up to 600 secure transactions per second

Business priorities easily configured:

• If the request is from Vendor A, then send to Server

• If transaction value is above $100,000, then send to

Server 2

Allows complex business priorities to be addressed.

Security with contin ued transaction speed

SA7150 Features

C H A P T E R 1 Specifications

Feature Benefits Offloads XML distribution

decisions from e-Business servers

Easy, drop-in installation between router and server

Specifications

Specification Description Servers supported

XML Dialects supported

Most Web servers (Apache*, Microsoft*, Netscape*, etc.) Most operating systems (UNIX*, Solaris*, Windows NT*, BSD*/

BSDI*, AIX*, etc.) Most server hardware (SUN*, HP*, IBM*, Compaq*, SGI*,

Intel*-based platforms) Supports up to 1000 servers Supports most XML dialects and e-Business standards, such as

SOAP*, Microsoft’s Biztalk*, Ariba’s cXML*, Commerce One’s CBL*, and the emerging ebXML standard via HTTP and HTTPS transport protocols

Helps maximize server investment

No additional hardware or software needed

SA7150 Features

System administration

Performance

Command line interface SNMP monitoring (MIB II and Private MIB ) Dynamic configuration through password-p rotected serial console,

Telnet, SSH v1, and SSH v2 Rated up to 1700 HTTP connections per second and 450 HTTPS

connections per second (1K data) Patent-pending technology offloads all cryptographic processing

from server

Specifications

C H A P T E R 1 HP e-Commerce/XML Server Accelerator SA7150 User Guide

Specification Description Dimensions

Weight Interface connection s

Patent pending XML routing

Security algorithms supported

Mounting: Standard 19-inch rack mount Height: 1.75 inches (4.45 cm) Width: 16.73 inches (46.99 cm) Depth: 18.5 inches (4.45 cm) 8 pounds (3.64 kg) 10/100 Ethernet TTY Serial - console XML patterns: Defined by URI and XML expressions, in the

form: URI Expression: */order.asp XML Expressio n:

//From[id=”acme”]

Blowfish, CAST, CAST5, DES, 3DES, DSA, IDEA MD5, MDC2, RC2, RC4, RSA, RMD-160, SHA, SHA-1

SSH for secure Command Line Interface (up to 168 bit encryp tion) Serial port logon

Specifications

C H A P T E R 1 Typographic Conventions

Typographic Conventions

The following typographic conven tions are used throughout this User Guide:

NOTE: This is an example of a note.

CAUTION: This is an example of a caution.

WARNING: This is an example of a warning.

NOTES clarify a point, emphasize vital information, or describe options, alternatives, or shortcuts. Except for those within tables, notes are always found in the left margin.

CAUTIONS are designed to prevent mistakes that could result in injury or equipment damage. Except for those within tables, cautions are always found in the left margin.

WARNINGS alert you to po tential hazar ds to life or l imb. Except for those within tables, warnings are always found in the le ft margin.

NUMBERED LISTS indicate step-by-step proce dures that you must follow in numeric order, as shown below:

1. This is the first step.

2. This is the second step.

3. This is the third step, etc. BULLETED LISTS indicate options or features available to you, as

shown below:

• The first feature or option

• The second feature or option

• The third feature or option, etc.

ITALICS are used for emphasis or to indicate onscreen controls, as shown in this example:

4. To edit the configuration settings, press the Configure tab. COMMANDS are shown in the following ways:

• Any command or command response text that appears on the

terminal is presented in the

• Any text that you need to type at the command line appears in

bold courier, for example:

HP SA7150> create gold

courier font.

C H A P T E R 1 HP e-Commerce/XML Server Accelerator SA7150 User Guide

Notes

Parts Checklist

Installation and Initial Configuration

Ensure that the items li sted below are included in th e shipping box:

• HP e-Commerce/XML Server Accelerator SA7150

• HP e-Commerce/XML Server Accelerator SA7150 Quick Start

Guide

• HP e-Commerce/XML Server Accelerator SA7150 User Guide

(this document)

• HP e-Commerce/XML Server Accelerator SA7150 Release Notes

• AC power cord

• Serial cable

• Rack mounting brackets wi th Phillips mounting screws

C H A P T E R 2 HP e-Commerce/XML Server Accelerator SA7150 User Guide

Additional Requirement s

Before you begin installation, acquire or prepare the following:

• IP address for SA7150 (Only if you intend to use the SA7150’s

Remote Management capabilities. Please see Chapter 6 for details.)

• IP addresses and port numbers of servers.

• Keys/certificates. (Only if you anticipate supporting secure

transactions. See Chapter 3 for information on obtaining keys and certificates.)

NOTE: Network cables are not provided wit h th e SA7150.

• Network cables, such as straight-through and/or crossover

cables. (Procedures in the section “Network Connection s” in this chapter will identify the types of cables you must u s e.)

If you are installing the SA7150 in a rack, you will also need:

• Phillips screwdriver (not provided)

• Rack-mounting screws

C H A P T E R 2 Physical Installation

Physical Installation

WARNING: Do not remove the device’s cover. There are no userserviceable parts inside.

Rack Installation

The SA7150 is physically installed in either of two ways:

• In a standard 19” rack, cantilevered from th e pro vided mounting

brackets

• Free-standing on a flat surface with sufficient space for air-flow

(1” on all sides)

Rack mounting requires the use of the mount ing brackets, and all four of the included Phillip s screws.

Mounting Bracket Installation

1. Locate the two mounting brackets and the four screws. (Two screws for each bracket.)

2. Attach a mounting bracket to each side of the SA7150, u sing two of the provided screws for each bracket. Use the holes near the front of the SA7150’s sides. The brackets have both round and oval holes; the flange with round holes attaches to the SA7150, the one with oval holes attaches to the rack.

3. Position the SA7150 in the desired space of your 19” rack and attach the front flange of each mounting bracket to the rack with two screws each. (Rack-mounting screws are not provided.)

C H A P T E R 2 HP e-Commerce/XML Server Accelerator SA7150 User Guide

Free-Standing Installation

Network Connections

1. Attach the provided self-adhesive rubber feet to the SA7150’s bottom.

2. Place the SA7150 on a flat surface and make sure that there is adequate airflow surrounding the unit (allow at least one inch of air space on all sides).

1. Use the table below to select and install the appropriate network cables (Category 5 UTP or better):

SA7150’s network connector

Workstation or Server Crossover cable Straight-through cable

Switch or Hub Straight-through cable Crossover cable

Router Crossover cable Not recommended

SA7150 network connector*

SA7150 server connector*

* Applicable only to multiple, cascaded units

N/A Straight-through cable

Straight-through cable N/A

SA7150’s server connector

NOTE: Never connect

both of the SA7150’s network ports to the same switch, hub, or router. Doing so creates a feedback loop that adversely effects network bandwidth.

2. Connect the provided power cable to the bac k of the uni t. (There is no power switch.) Under normal circumstances, the SA7150 requires approximately 30 seconds to boot. When the boot is complete, the unit’s Power LED is steadily illumin ated. (If the Power LED is not steadily illuminated, see Chapter 9, “Troubleshooting,” to rectify before proceeding to Step 3.)

3. The Inline LED should be either steadily illuminated or blinking (to indicate Inline mode). If it is not, press the Bypass switch on the device’s front panel to enable Inline mode.

C H A P T E R 2 Physical Installation

4. At this point both the Network and Server LEDs should be steadily illuminated. If not, please see Chapter 9, “Troubleshooting.”

XML Server 1

XML Server 2

hub/switch

Console Connection

hub/switch

HP e-Commerce/XML Server

Accelerator SA7150

Default Server

Wiring Connections

Run HyperTerminal* or a similar term inal emulator on your PC . The steps below assume HyperTerminal* is used. Other terminals will require different procedures.

1. Use the serial cable provided with the SA7150 to connect the device’s serial port (the left-hand serial port labeled “Console”) to the serial port of any terminal.

Power

(green)

Error (red)

LEDs

Overload

(amber)

Activity (green)

Network

(green)

LEDs

Inline

(green)

Server

(green)

Reset

Console

(CLI)

Aux Console (Diagnostics)

Network Link

(RJ45)

Fail-through switch

Server Link

(RJ45)

Bypass

Front Panel Connectors and LEDs

2. Type an appropriate name in the Name field of the Connection Description window (e.g., “Configuration”), and then click the OK button. The Phone Number panel appears.

3. In the Connect Using… field specify “COM1” (or the serial port through which the PC is connected to the SA7150 if different from COM1).

C H A P T E R 2 HP e-Commerce/XML Server Accelerator SA7150 User Guide

4. Click the OK button. The COM1 Properties panel appears. Set the values displayed here to 9600, 8, none, 1, and none.

5. Click the OK button.

Using HyperTerminal*

Fail-through Switch

If you’re using HyperTerminal* you must make the following configuration change:

1. In the File menu, click Properties.

2. Click the Settings tab.

3. Click the ASCII Setup button.

4. Change the values of Line and Character delay from 0 to at least 1 millisecond.

5. Click OK to exit ASCII Setup.

6. Click OK to exit Connection Properties.

The Fail-through switch allows you to choose between two options in the event of a failure. It is located in the opening between the Network and Server connectors. Use a small screwdriver or paper clip to operate the switch. The two options are:

• Allow traffic to flow through the SA7150 unprocessed. (Fail-

through mode, indicated by a steadily illuminated Inline LED.

Fail-through switch in DOWN position.)

• Block traffic flow t hr oug h t he S A7150 ent irel y. (Fail-safe mode,

indicated by a blinking Inline LED. Fail-through switch in UP position.)

Please see Appendix B for a description of LED display.

C H A P T E R 2 Physical Installation

Accessing the Command Prompt

NOTE: The password is not echoed on the command line.

After the SA7150 boots up, the password prompt appears.

1. Type admin at the password prompt and press Enter to access the prompt:

Password: admin (password is not echoed at prompt) Current date: 2000 11/01 05:01 HP SA7150>

You are now ready for operations at the Command Line Interface (CLI) of the SA7150. The following is a typical way to begin:

2. Change your password from admin to another of your choice. Use the password command.

HP SA7150> password

3. Use set date to correct the date/time, if necessary. The date and time affect the validity of the certificate.

HP SA7150> se t date

4. Use the help command to list available command (or refer to the Command Reference in Chapter 5 of the User Guide).

HP SA7150> help

5. Configure XML servers and patterns as appropriate for your business needs. (See Chapter 3 of the User Guide for details.)

6. If your operational model includes SSL traffic, configure the appropriate keys and certificates. (See Chapter 3 of the User Guide for details.)

C H A P T E R 2 HP e-Commerce/XML Server Accelerator SA7150 User Guide

Notes

Theory of Operation

This chapter discusses the general operating principles for the HP eCommerce/XML Server Accelerator SA7150. For details about the SA7150 command set, please see Chapter 5. For information about completing typical, specific tasks, please see Chapter 4.

XML Operations

The HP e-Commerce/XML Server Accelerator SA7150 provides a powerful means of using XML technology to facilitate Business-toBusiness transactions. In additi on to its XML capabilit y, the SA7150 provides SSL acceleration (discussed later in this chapter).

The SA7150 employs user-created rules to evaluate the content transmitted in XML documents and to distri bute this information among the appropriate data center resources. XML functionality is enabled or disabled for each user-specified “map” (i.e., a triad consisting of an IP address, network port, and server port.)

XML functionality is controlled by way of the Command Line Interface (CLI—detailed in Chapter 5). The SA7150 man a ges XML traffic using “XML patterns,” pairs of “URI expressions” and “XML expressions.” URI expressions serve as “coarse” filters, allowing the system to determine whether a HTTP POST request is targe ted at an XML-enabled server—if no URI match is found, the SA71 50 doesn’t

C H A P T E R 3 HP e-Commerce/XML Server Accelerator SA7150 User Guide

bother to examine the document for XML content, but simpl y passes the document to the “mapped” server (i.e., the one with the IP address and network port of the incoming message). XML expressions are the “fine” filters—those to be applied to the content and context of the XML data embedded in the HTTP POST request. XML patterns are assigned to servers (identified by IP address and server port), and when a match between a pat tern and an incomi ng request o ccurs, the SA7150 sends data to the appropriate server.

XML Server 1

Router

HP e-Commerce/XML Server

Accelerator SA7150

Basic SA7150 Operating Configuration

Multiple SA7150s can be connected in series, or “cascaded,” to multiply your site’s XML processing and availability capabilities, (and also its SSL processing capability, should you use it.)

HP e-Commerce/XML Server

Accelerator SA7150

hub/switchRouter

HP e-Commerce/XML Se rver

Accelerator SA7150

XML Server 2

XML Server 3

XML Server 1

XML Server 2

hub/switch

XML Server 3

Cascaded SA7150s

Before you configure the SA7150 for XML operations, you should first answer the following:

• Which of the several common formats or varieties of XML w ill

be used in the client application?

C H A P T E R 3 XML Operations

• Which XML elements, attributes, or text and HTTP fulfillment

locations contained or identified in the anticipated XML traffic should be used for XML pattern matching?

• Which servers will be assigned the XML patterns that yo u

create?

• Do you intend to use the SA7150’s SSL capabilities?

General Considerations

Some general facts to keep in mi nd concerning XML operat ions with the current version of the SA7150 are listed be low. These fac ts do not apply to SSL operations.

• The SA7150 uses an abbreviated version of the XPATH syntax.

• The SA7150 works with any XML applicati on the supports XML

1.0 and that is transported via HTTP or HTTPS POST request methods.

• Transport protocols other than HTTP and HTTPS such as FTP

and SMTP are not supported.

• Content of incoming documents must be of type “text.”

• URL encoding is supported.

• Base64 encoding is not supported.

• The complete XML data stre am must be encapsulated in the

body of the HTTP(S) POST request.

• Multi-part MIME messages are not supported.

• The first character of the POST request’s body must be the “less

than” (<) character; the final character must be the “greate r than” (>) character.

Server Mappings

Because the SA7150’s purpose is to send XML messages with specific content to specific servers, it must be configured to recogniz e these servers. This configuration is managed through the use of

“server mappings.” A server mapping consists of three items:

• A server’s IP address

• Network port

• Server port

C H A P T E R 3 HP e-Commerce/XML Server Accelerator SA7150 User Guide

Server mappings are created using the create map command. Typically, a map specifies a Key ID for SSL encryption and decryption, as in the example following.

HP SA7150> create map Server IP [0.0.0.0]: x.x.x.x Network port [443]: Cleartext (server) port [80]: KeyID to use for mappi ng: default HP SA7150>

If your operations involve processing only unen crypted XML traff ic, you should use a “clear text map,” i.e., a map with no Key ID. The example below illustrates the creation of a clear text map:

NOTE: In the example opposite, the prompt for a KeyID is ignored. Keys, certificates and related matters are discussed in this chapter under “SSL Operations.”

NOTE: XML examples here are indented for ease of reading—the leading spaces or tabs are not significant with regard to SA7150 operations.

HP SA7150> create map Server IP [0.0.0.0]: x.x.x.x Network port [443]: Cleartext (server) port [80]: KeyID to use for mappi ng: Cleartext map for XML only? [n]: y HP SA7150>

XML Data Model

XML data consists of three hierarchical components:

• Elements (data types)

• Attributes (subcategories of a data type or element)

• Text (specific data such as names, addresses, and quantities

contained within elements or attributes)

The content of an XML document is defined within these three components, as illustrated below. The example shows a block of incoming XML text as received by the SA7150 in an HTTP POST request.

<street>13280 Evening Creek Dr</street> <city>San Diego</city> <state>California</state> <zip>92128</zip>

</address>

</employee>

C H A P T E R 3 XML Operations

Where:

• employee, name, address, street, city, state,

and zip are the elements of the XML document.

• lastName, firstName, and initial are the attributes of the

element,

• 13280 Evening Cre ek Dr, San Diego, California,

name.

and 92128 are the text components of the elements, street,

city, state,

• “Smith,” and “John,” and “K” are the text components of the

lastName, firstName, and initial attributes of the name

element.

XML expressions configured in the SA7150 are matched against XML data which is then sent for fulfillment to server assignments defined in XML patterns.

URI expressions in XML Patterns

XML configurations use URI expressions to assign partic ular classes of URLs to particular servers for fulfillment. Applicable expressions are listed below:

and zip , respectively.

• File type expressions, such as *.asp

• Path expressions, such as /PurchaseOrder/*

• Unique file expressions, such as /purchase.cgi

• Wildcard expression, such as *

• Negation expressions, such as !*.asp or !*/purchase.cgi

Invalid URI Expressions

The following may not be used in URI expressions:

• Text on either side of the asterisk, such as /order*.asp

• Expressions containing more than one asterisk, such as

/order*.*

• Expressions containing one or more spaces or the dollar sign ($)

character

• Expressions containing a vertical bar ( | ) or a carat (^)

C H A P T E R 3 HP e-Commerce/XML Server Accelerator SA7150 User Guide

Negation Operator

The “*” and “!” operators are allowed in URI expressions, but they can exist only at the beginning or end of an expression. Also, a positive expression must appear after a not (!) expression, otherwise the (!) expression has no effect.

The order of URI expressions is significant only when the “not” (!) operator is used.

Expression Yields

NOTE: The SA7150 uses a subset of the XPath Language standard.

!*.asp

!*/PurchaseOrder

!/Buy.cgi

All non-ASP requests

All non-PurchaseOrder requests

All non-Buy.cgi requests

Use of the Negation Operator

Operators

XML expressions consist of sequences of one or more XML elements or attributes combined with various “operators.” “Step operators” tell the SA7150 where in the XML data tree to look, while “comparison operators” tell the SA7150 what to look for. In typical XML expressions, elements are separated by step operators—single or double slashes (/ or //). These are used to select el ements according to their location (“node”) in the XML data tree. Step operators are described in the table above. Comparison operators are the familiar “equal to,” “not equal t o, ” “greater than,” “less than,”and other such symbols. These form the bases upon which the SA7150 compares incoming XML data to it s own XML patterns to decide where to sen d each XML document for fu lfillment.

C H A P T E R 3 XML Operations

An XML expression’s first element must be preceded by a step operator.

Step Operator

Name Description

Child

Selects all immediate children of the context node

operator Descendant

Selects elements at any level under the context node

operator

XML Step Operators

The node to the left o f the l ast step operator in an XML expressi on is the “context node,” i.e., the node that establishes the level within the XML data tree’s hierarchy at which the SA7150 searches for a match when comparing XML data to XML expressions. The “ro ot node” is the top level of the XML data tree, and by implication is to the left of an XML expression’s left-most step operator. So me ex amples of the effects of step operators are:

• //address Tells the SA7150 to search for the <address>

element anywhere in the XML data tree.

• //employee//state Tells the SA7150 to search anywhere

under the <employee> element node for the <state> element.

• //employee/address Tells the SA7150 to search one level

below the <employee> node for the <address> element.

You can specify an element as “*”, which selects any element relat ive to the context node. You can also specify an op tional filter at t he end of a path to further refine parsing of the XML data stream.

C H A P T E R 3 HP e-Commerce/XML Server Accelerator SA7150 User Guide

Comparison operators allow the SA7150 to look for specific values in the XML data tree and compare them with corresponding val ues in your preconfigured XML patterns. An XML pattern might look like this:

URI Expression: */hr.asp XML Expressi o n : //address[ zi p > 90000]

Because the server to which the XML pattern belongs is configured for zip codes greater than 90000 (as defined in the XML expression component of the XML pattern), and John K. Smith’s zip code is 92128, the SA7150 sends his employee data to that server. The following table contains the available comparison operators

Comparison Operator

Name Description

Equal to Returns true if any values of the nodes specified in the pattern

equals given value

Not equal to Returns true if at least one value of the nodes specified in the

patterns does not equal given value

Less than Returns true if at least one value of the nodes specified in the

patterns is less than the specified value

Less than or equal to

Returns true if at least one value of the nodes specified in the patterns is less than or equal to the specified value

Greater than Returns true if at least one value of the nodes specified in the

patterns is greater than the specified value

Greater than or equal to

Returns true if at least one value of the nodes specified in the patterns is greater than or equal to the specified value

XML Comparison Operators

Attributes

Attributes are identified by the “at” sign (@). You can specify an attribute as relative to the context node.

@<AttributeName>, or use @* to select any attribute

C H A P T E R 3 XML Operations

Filters

Filters are identified by a FilterExpression enclosed within square brackets, [ ]. These define a pattern within a pattern following this general structure:

( (’/’ | ’//’) Element )? [ FilterExpression ]

Filter expressions are applied to every element returned by the preceding path pattern . They return a match if the server is a valid choice according to the filter expression.

The operative component of a FilterExpression is a comparison expression or any FunctionCal l expression that retur ns a string value, which compares either an element or an attribute against a specified value. An element in a Fi lterExpression refers to the chi ld element o f the context node, while an at tribute refers to the attribute of th e context node.

Comparison expression syntax:

(Element | Attrib ute | FunctionCall) ComparisonOperator Value

FunctionCall expression syntax:

FunctionName ’(’ (Argument (’,’ Argument)*)? ’)’

You can combine comparison expressions and the FunctionCall expression with Boolean operators and paren theses to create complex filter expressions.

Sample Pattern Description //PurchaseOrder

[Amount > 10000] //PurchaseOrder

[@CustomerID > 9000] //PurchaseOrder

[Amount > 10000 and @CustomerID > 9000]

Matches a PurchaseOrder element with a child element Amount value greater than 10000

Matches a PurchaseOrder element with an attribute

CustomerID value greater than 9000

Matches a PurchaseOrder element with a child element Amount value greater than 10000 and with an attribute greater than 9000

Comparison Expression Samples

CustomerID value

C H A P T E R 3 HP e-Commerce/XML Server Accelerator SA7150 User Guide

Boolean Operators

Boolean operators are logical operators between expressions. These operators are used in the PathExpression and the Fi lterExpression, as shown below.

• PathExpression BooleanOperator PathExpression

• FilterExpression BooleanOperator FilterExpression

Operator Name Description and or

Logical AND operator Performs a logical AND operation Logical OR operator Performs a logical OR operation

Boolean Operators

Sample Pattern Description //restaurant[@genre and

Food_Rating]

Matches if there is a restaurant element, a genre attribute, and a Food_Rating child element. genre and Food_Rating are associated with the restaurant element.

//restaurant[@genre or Food_Rating]

Matches if there is a restaurant element, a genre attribute, or a Food_Rating child element. genre and Food_Rating are associated with the restaurant element.

//restaurant or //theater

Matches if there is a restaurant element or a theater element anywhere in the XML data tree.

Boolean Operator Examples

Function Calls

NOTE: FunctionCalls can only be specified within FilterExpressions.

Function calls allow you to specify partial patterns within FilterExpressions. FunctionCall expressions are evaluated by using the FunctionName to identify a supported function, eval uat i ng each of the arguments if needed, and calling the function passing the

C H A P T E R 3 XML Operations

required arguments. Wrong number s of ar gumen ts or ar guments not of the required type result in errors. The result of the FunctionCall expression is the result returned by the functio n.

Function Description starts-with(value,

substring)

The starts-with function tests whether the string value of value starts the specified substring. value can be either an element, attribute, or function call that returns a string value. substring must be a literal value enclosed in single or double quotes.

contains(value, substring)

The contains function tests whether value contains the specified substring. value can be either an element, attribute, or function call that

returns a string value. substring must be a literal value enclosed in single or double quotes.

translate(value, fromString, toString)

The translate function replaces characters in the value string if they appear in the fromString with the corresponding characters in the toString. If a character appears in fromString but not in th e corre spond ing position in toString, the character will be dropped from the value string. The result string is returned. value can be either an element, attribute, or function call that returns a string value. Both fromString and toString have to be a literal value enclosed in single or double quotes.

Function Calls

Sample Pattern Description //Order[starts-with

(PartNumber, “001”)]

Matches if there is an Order element with a value of a PartNumber child element starting with “001.”

//Part[contains (@PartNumber, ‘12345’)]

//Part[contains(translate (@Description,’abcdefg hijklmnopqrstuvwxyz’, ‘ABCDEFGHIJKLMNOP QRSTUVWXYZ’), ‘ENGINE’)]

Matches if there is a Part element with the value of a PartNumber attribute containing “12345.”

Matches if there is a Part element with the value of a Description attribute containing “ENGINE.” All characters in the Description attribute are converted to uppercase before being passed to the

contains function.

Function Call Examples

C H A P T E R 3 HP e-Commerce/XML Server Accelerator SA7150 User Guide

Values

Values are used to specify the right operand of a comparison expression, and can be either literals (e.g., a string) or numeric values. Literals must be enclosed in either single or double quotes. If the literal string contains singl e quo tes, do ubl e quot es shou ld be use d to enclose the string. Conversely, if the literal string contains double quotes, it should be enclosed in single quotes. Character references (both decimal and hexadecimal format) and predefined entities as described in the XML specification can be used within the literal string.

The string value of the left operand is obtained for literal equality comparisons. If an element is specified for the left operand, only elements without a child element should be u sed. Although the up per level elements are not supported, this generally is not a problem, since in most cases only the lowest level element contains text values.

A number can be either a decimal value or an integer. Numbers should not be enclosed in quotes. (Numbers within quotes are treat ed as literals.) Numbers are signed by preceding them with the plus (+) or minus (-) sign. Decimal values must contain a decimal point with at least one digit to the right of it.

A numeric comparison is either an equality comparison with a numeric right operand or a non-equality comparison. Both the value of the left and right operands, if necessary, are con verted t o numeric values before a numeric comparison is made. If the value cannot be converted to a number, the comparison returns false.

C H A P T E R 3 XML Operations

XML Pattern Creation

XML patterns are created with the create pattern command. Because each pattern is assigned to a specific server, the comman d’s syntax requires that a server be specified.

HP SA7150> create pattern <server name>

After entering the command and a server name, the SA7 150 prompts you for a URI expression.

HP SA7150> create pattern gold URI Expression: /PurchaseOrder

Each time a new URI expression is entered, the system performs a “validity check” (a test for syntactical correctness). If the expression is invalid, the SA7150 displays an erro r message and prompts you to begin again.

NOTE: The validity warning opposite is an example for illustrative purposes only. Actual messages will vary depending on the error.

Improper use of ’*’ character in URI Expression Enter another pattern? [n]: y

After you enter a valid URI expression, the system prompts for an XML expression.

XML Expression: //order [amount>1000] Enter another pattern? [n]: HP SA7150>

As with the URI expressions, the SA7150 performs a validity check on each XML expression when entered and disp lays an error message if there is a problem. After you enter a valid XML expression, the SA7150 performs a “duplicate check,” (i.e., verifies that the newly entered pattern does not already exist). If the pattern already exists, the following message appears:

A pattern with this URI and XML expression already exists Enter another pattern? [n]:

When the above steps are complete, the SA7150 asks if you want to create another XML pattern.

The SA7150 stores each XML pattern i n a list on the server spe cified during the pattern ’s creation and assigns each a unique i ndex number within each server list. You can d isplay al l server l ists at th e con sol e by typing the show pattern command.

C H A P T E R 3 HP e-Commerce/XML Server Accelerator SA7150 User Guide

HP SA7150> show pattern

Server: std

Pattern ID Pattern ========== ======= == 1 * & //std

Server: gold

Pattern ID Pattern ========== ======= == 1 * & //gold

2 * & //order [amount>1000] Server: silver

Pattern ID Pattern ========== ======= == 1 * & //silver

You can display the list for a single serv er by using the show pattern command with the name of the ser ver whose pattern list you wish to view included as an argument.

HP SA7150> show pattern gold Server: gold Pattern ID Pattern ========== ======= == 1 * & //gold 2 * & //order [amount>1000] HP SA7150>

Mapped Server

For the purpose of discussing SA7150 operations, the “mapped server” is a server for which a map has been configured (see “Server Mappings” on page 17). This is the server to which the SA7150 sends messages for which no XML expression match is found among the active XML patterns, including any that contain the keyword “default” in their XML expression component. (Please see next section, “Default Keyword.”)

C H A P T E R 3 XML Operations

Default Keyword

The keyword default can be used as an XML pattern’s XML expression component to catch cases not covered by active XML patterns with specific XML expressions. To illustrate, imagine you have a number of active XML patterns assigned to dif fe rent servers, each with the same URI expression (orders.asp) but with different XML expressions.

orders.asp & //co mpany[name=”GM”] orders.asp & //co mpany[name=”Ford”] orders.asp & //co mpany[name=”Chrysler”] orders.asp & defa ult

For example, incoming XML messages aimed at the URI

“orders.asp” and containing the company names “Chevrolet,” “BMW,” or “Honda” would not result in exact matches with any of

the first three XML patterns i n the example above. However th e XML pattern containing default would catch all of these messages, because the URI expression is an exact match and default in the XML expression doesn’t match “GM,” “Ford,” or “Chrysler.”

NOTE: Multiple XML patterns can use the default keyword, but they must have different URI expressions.

Below is an example of the CLI input to create an XML pattern containing the default keyword.

HP SA7150> create pattern gold URI Expression: orders.asp XML Expression: default Enter another pattern? [n]: HP SA7150>

XML Pattern Matching

The SA7150 looks first for URI expression matches. If matches for URI expression are found, then the SA7150 looks for XML expression matches.

• If both the URI and XML expressions match, the SA7150 sends

the message to the server to wh ich the matching XML pattern is assigned.

• If only the URI expression matches, the SA7150 sends the

message to the default XML server, if one is specified, or if not, to the mapped server.

• If the URI expression does not match, the XML expression is

ignored and the message goes to the mapped server.

C H A P T E R 3 HP e-Commerce/XML Server Accelerator SA7150 User Guide

The table below illustrates ways in whic h XML messages are handled depending on which component of XML patterns mat ch and whether a default XML server is configured.

URI Match, no XML Match

XML Match, no URI Match

URI and XML Ma t ch

Default XML Server Configured

Default XML Server Not Configured

Default XML Server Mapped Server

Mapped Server Mapped Server

Server to which matching patt ern is assigned

Server to which matching pattern is assigned

XML Message Destinations

XML “Well-formed” Check

If the SA7150 detects a URI expression match in the XML data stream, it checks it for syntactical errors, and, if it detects any, by default sends an erro r message to the re questing client. Al ternately, it can be configured to send an incoming XML data stream to the mapped server when it detects punctuation or syntax errors. In all such cases the XML expression is ignored for normal processing purposes.

• If the xml_well_formed command is set to enable, when

malformed XML data is found in an incoming request the

SA7150 terminates the connection and returns HTTP Error 403 to

the client with the message, “XML data is not we ll-formed.”

• If xml_well_formed is set t o disable, when malformed XML

data is found in an incoming request it is sent to the mapped server.

C H A P T E R 3 Network Configurations

Network Configurations

Single Server

Router

Multiple Servers

The HP e-Commerce/XML Server Accelerator SA7150 is typically used with multiple servers although it can support multiple applications running on separate ports of a single server. In single server configurations the SA7150 is connected to the network between the router and the server.

Ideally, the SA7150 is installe d in the network in such a way as to minimize network latency.

App1 App 2 App 3

HP e-Commerce/XML Server Accelerator SA7150

Single Server

SA7150 in Single Server Configuration

In the more common multiple server configuration, the SA7150 sits between the router and the switch. XML traffic is intercepted, decrypted (if SSL-encrypted), pr ocessed, and sent to an XML ser ver.

HP e-Commerce/XML Server

Accelerator SA7150

hub/switchRouter

SA7150 in Multiple Server Configuration

XML Server 1

XML Server 2

XML Server 3

C H A P T E R 3 HP e-Commerce/XML Server Accelerator SA7150 User Guide

Multiple SA7150s and Cascading

HP e-Commerce/XML Server

Router

NOTE: The SA7150 restarts when spill is enabled. Depending on the size of the current configuration file, it can require from 30 seconds to seven minutes to return to operations.

Accelerator SA7 150

Scalability and Cascading

The SA7150’s capabilities are scalable by chaining, or “cascading,” multiple SA7150s together. In such config urations, each unit’s server side connector is wired to the network side connector of the next SA7150 in line. The last SA7150 in line is connected to the server or switch.

XML Server 1

HP e-Commerce/XM L Server

Accelerator SA7150

hub/switch

XML Server 2

XML Server 3

Cascaded SA7150s

Spilling and Throttling

When the SA7150’s “spill” option is enabled, if a given SA7150 cannot process a request within a specified interval, the request is passed on to the next SA7 150 in l i ne. T he l ast SA7150 on the server side can also be enabled to spill to the server. Spilling is p e rformed dynamically on a connection-by-connection basis. (See spill command, Chapter 5, “Command Reference.”) If spill is disabled, the SA7150 “throttles,” that is, does not accept incoming requests when it becomes overloaded.

Availability

When a SA7150 fails or is set to Bypass mode while Fail-through is enabled, the SA7150’s network side and ser ver side network adapters are directly connected, allowing traffic to pass through to the next device until the failed unit is brought back into service. This feature eliminates a single point of failure and provides a high level of availability, should ther e be a failure. See “Failure/Bypass Modes” in Appendix B for more information.

C H A P T E R 3SSL Operations

SSL Operations

Keys and Certificates

CAUTION: The SA7150 comes with default keys and certificates for test purposes. Certificates for production use should be obtained from a recognized certificate authority.

In addition to its XML processing capabili ties, the SA7150 provid es powerful SSL (Secure Socket Layer) decryption and encryption processing. When secure maps are used it becomes necessary to configure keys and certificates. A key is a set of numbers used to encrypt or decrypt data. A certificate is a “form” that identifies a server or user. The certificate contains information about your company as well as information from a third party that verifies your identity.

There are three ways to obtain keys and certificates:

• Obtaining a certificate from VeriSign* or other certificate

authority

• Using an existing key/certificate

• Creating a new key/certificate on the SA7150

Cutting and Pasting with HyperTerminal*

Cutting and pasting is an in tegral part of the next several pr ocedures. Below are procedures for cutting and pasting in HyperTerminal*. If you use some other terminal program, consult that product’s documentation for appropriate procedures.

To copy an item (key, certificate signing request, etc.) from HyperTerminal*:

1. Open the HyperTerminal* window.

2. Click and drag to select the item.

3. After the item is selected, open th e Edit menu and click Copy (or type <ctrl-c>).

4. Open the window where you will pa ste t he data, and position the cursor at the appropriate point.

5. In the Edit menu, click Paste (or type <ctrl-v>).

C H A P T E R 3 HP e-Commerce/XML Server Accelerator SA7150 User Guide

To paste an item (key, certificate signing request, etc.) into HyperTerminal*:

1. Display the item in the appropriate appl ication window, then click and drag to select the item.

2. Once the item is selected, click the Edit menu and select Copy (or type <ctrl-c>).

3. Move to the HyperTerminal* window, and position the cursor at the appropriate point.

4. Pull down the Edit menu, and select Paste to Host (or type <ctrl-v>).

Obtaining a Certificate from VeriSign* or Other Authority

Use the create key command to create your key and the create si gn command to create a signing request t o be sen t to VeriSig n* or ot her certificate authority for authentication. The certificate authority will return it in approximately one to five days. After you have received the certificate, use the import cert command to import it into the SA7150.

The fields input to create a signing request are called collectively a Distinguished Name (DN). For optimal security, one or more fields must be modified to make the DN unique.

Procedure

Create a key.

1. Type the create key command at the prompt.

HP SA7150> create key Key strength (512 /1024) [512]: New keyID [001]: 002 Keypair was created for keyID: 002

2. Create a Certificate Signing Request.

HP SA7150> create sign 002 You are about to be aske d to enter information that will be incorporated into your certificat e request. The "common name" must be unique. For other fields, you could use default value s.

C H A P T E R 3SSL Operations

Certifying authoriti es have specific guideli nes on how to answer each of the questions. These guidelines may vary by certifying authority. Please refer to th e guid eline s of th e cert ifyin g auth ority to who m you submit your Certificate Signing Request (CSR). Please keep the following in mind when entering the information that will be incorporated into your certificate request.

• Country code: This is the two-letter ISO abbreviation for your

country (for example, US for the United States).

• State or Province: This is the name of the state or province

where your organizati on’s head office is located. Please enter the full name of the state or province. Do not abbreviate.

• Locality: This is usually the name of the city where your

organization’s head office is located.

• Organization: This should be the organization that owns the

domain name. The organization name (corporation, limited partnership, university, or government agency) must be registered with some authority at the national, state, or city level. Use the legal name under which your organization is registered. Please do not abbrevi ate you r org anizatio n’s name and do not use any of the following characters: < > ~ ! @ # $ % ^ * / \ ( ) ?.

• Organizat i onal unit: This is n ormally the name of the

department or group that will use the certificate.

• Common name: The common name is the “fully qualified

domain name,” (or FQDN) used for DNS lookups of your server (for example, www.mysite.com). Browsers use this information to identify your Web site. Some browsers will refuse to establish a secure connection with your site if the server name does not match the common name in the certificate. Please do not include the protocol specifier “http://” or any port numbers or pat h names in the common name. Do not u se wildcard characters su ch as * or ?, and do not use an IP address.

• E-mail address: This should be the e-mail address of the

administrator responsible for the certificate.

3. Export the Certificate Signing Request (CSR).

C H A P T E R 3 HP e-Commerce/XML Server Accelerator SA7150 User Guide

In this example, xmod em i s used t o send the CSR to a PC c onnected to the console port.

HP SA7150> export sign mywebserver Export protocol : (xmodem, ascii) [ascii]:xmodem Use Ctrl-x to kill transmission Beginning export... Export successful! HP SA7150>

To submit the CSR to a certifying authority, paste it into the field provided in the authority’s online request form. Remember to include the “-----BEGIN CERTIFICATE REQUEST-----” and “-----END CERTIFICATE REQUES T-----” lines.

Typically, the CSR will look something like this:

-----BEGIN CERT IFICATE REQUEST----MIIBnDCCAQUACQAwXjELMAkGA1UEBhMCQ0ExEDOABgNV BAgTB09udGFayW8xEDAOBgNVBAcTB01vbnRyYWwxDDAK BgNVBAoTA0tGQzEdMBsGA1UEAxMUd3d3Lmlsb3ZlY2hp Y2tlbi5jb20wgZ0wDQYJKoZIhvcNAQEBBQADgYsAMIGH AoGBALmJA2FLSGJ9iCF8uwfPW2AKkyyKoe9aHnnwLLw8 WWjhl[ww9pLietwX3bp6Do87mwV3jrgQ1OIwarj9iKML T6cSdeZ0OTNn7vvJaNv1iCBWGNypQv3kVMMzzjEtOl2u Gl8VOyeE7jImYj4HlMa+R168AmXT82ubDR2ivqQwl7Ag EDoAAwDQYJKoZIhvcNAQEEBQADgYEAn8BTcPg4OwohGI MU2m39FVvh0M86ZBkANQCEHxMzzrnydXnvRMKPSE208x 3Bgh5cGBC47YghGZzdvxYJAT1vbkfCSBVR9GBxef6ytk uJ9YnK84Q8x+pS2bEBDnw0D2MwdOSF1sBb1bcFfkmbpj N2N+hqrrvA0mcNpAgk8nU=

-----END CERTIF ICATE REQUEST-----

NOTE: It is possible to import multiple certificates in a single file. The size of files containing combined certificates must not exceed 20KB.

4. When the certificate authority returns the certificate, import it into the SA7150. Use the import cert command, with the KeyID. As with the import key, choose an import protocol for importing the key. Use p for paste. After the paste is finished, add three periods to displa y the command line.

HP SA7150> import cert mywebserver keyid is mywebser ver; Import protocol: (paste, xmodem) [paste]: Type or paste in date, end with ... alone on line

C H A P T E R 3SSL Operations

-----BEGIN CERT IFICATE----MIIDKDCCAtKgAwIBAgIBADANBgkqhkiG9w0BAQQFADCB nDELMAkGA1UEBhMCVVMxCzAJBgNVBAgTAkNBMQ4wDAYD VQQHEwVQb3dheTEaMBgGA1UEChMRQ29tbWVyY2Ug . . .

-----END CERTIF ICATE----- <Enter> ... <Enter>

Import successful! HP SA7150>

5. Create mapping for Server 1. Use the create map command to

specify the server IP address, ports, and keyID.

HP SA7150> create map Server IP (0.0.0.0): 10.1.1.30 Network port [443]: Cleartext (serv er) port [80]: KeyID to use for mappi ng: mywebserver

6. Save the configuration when the server has been mapped.

HP SA7150> config save Saving configuration to flash... Configuration saved to flash HP SA7150>

Using an Existing Key/ Certificate

NOTE: Currently there is no published method for extracting private keys from Microsoft* IIS or Netscape* servers.

Exporting a Key/Certificate from a Server

This method is used when it is important that the existing keys and certificates are used.

Consult your server software documentat ion for detailed inst ructions on how to export keys and certificates. Once you have exported the keys and certificates, use the import key and import cert commands to paste the keys and certificates into your SA7150. Some general instructions are provided below for the Apache Web Server.

Apache Interface to Open SSL* (mod_ssl)

For key:

1. Look in $APACHEROOT/conf/httpd.conf for location of *.key file.

2. Copy and paste the key file.

C H A P T E R 3 HP e-Commerce/XML Server Accelerator SA7150 User Guide

For certificate:

1. Look in $APACHEROOT/conf/httpd.conf for location of *.crt file (certificate).

2. Copy and paste the certificate file.

Apache SSL*

For key:

1. Look in $APACHESSLROOT/conf/httpd.conf for location of *.key file.

2. Copy and paste the key file.

For certificate:

1. Look in $APACHESSLROOT/conf/httpd.conf for location of *.cert file.

2. Copy and paste the certificate file.

Stronghold*

For key:

1. Look in $STRONGHOLDROOT/conf/httpd.conf for location of *.key file.

2. Copy and paste the key file.

For certificate:

1. Look in $STRONGHOLDROOT/conf/httpd.conf for location of *.cert file.

2. Copy and paste the certificate file.

Importing into the SA7150

1. Use the import key command with the keyID, and choose an import protocol fo r importi ng the k ey. In this case, use the default to “paste.” When the paste is finished, add a line break followed by three periods to display the command line.

HP SA7150> import key mywebserver Import protocol: (paste, xmodem) [paste]: Type or paste in date, end with ... alone on line

C H A P T E R 3SSL Operations

-----BEGIN RSA PR IVATE KEY----MIIBOgIBAAJBALGOlBH14vIdtfuA+UnyRIoKya13ey8m j3GDQakdwoDJALu+jtcC . . . S9dPdwp6zctsZeztn/ewPeNamz3q8QoEhY8CawEA

-----END RSA PRIV ATE KEY-----<Enter> ... <Enter>

Import successful! HP SA7150>

2. Use the import cert command with the keyID. As with import

key, choose an import protocol for importing the key. Use the default to “paste.” When the paste is finished, add a line break followed by three periods to display the command line.

HP SA7150> import cert mywebserver keyid is mywebser ver; Import protocol: (paste, xmodem) [paste]: Type or paste in date, end with ... alone on line

-----BEGIN CERT IFICATE----MIIDKDCCAtKgAwIBAgIBADANBgkqhkiG9w0BAQQFADCB nDELMAkGA1UEBhMCVVMxCzAJBgNVBAgTAkNBMQ4wDAYD VQQHEwVQb3dheTEaMBgGA1UEChMRQ29tbWVyY2Ug . . .

-----END CERTIF ICATE----- <Enter> ... <Enter>

Import successful! HP SA7150>

3. Create a server mapping. Use the create map command to

specify the server IP address, ports, and keyID.

HP SA7150> create map Server IP (0.0.0.0): 10.1.1.30 SSL (network) por t [443]: Cleartext (serv er) port [80]: KeyID to use for mappi ng: mywebserver

C H A P T E R 3 HP e-Commerce/XML Server Accelerator SA7150 User Guide

4. Save the configuration when the server has been mapped.

HP SA7150> config save Saving configuration to flash... Configuration saved to flash HP SA7150>

Creating a new Key/Certificate on the SA7150

Use the create key and create cert commands to create new keys and certificates for SA7150 operation. This procedure can be used when there are no existing keys and certificates on the server. The advantage is that this method is very fast, but a certificate authority has not signed the certificates.

The fields input to create a certificate are called a Distinguished Name (DN). For optimal security, one or more fields must be modified to make the DN unique.

Procedure

1. Create a key.

HP SA7150> create key Enter the key strength [512,1024]: 512 New keyID [001]: mywebserver Keypair was created for keyID: mywebserver

2. Enter the create cert command with the keyID.

HP SA7150> create cert mywebserver You are about to be aske d to enter information…

Enter the information for the certificate, as prompted.

• Country

• State

• Locality

• Organization

• Organization unit

• Common name (for example, www.myserver.com)

• E-mail address.

C H A P T E R 3SSL Operations

3. Create a server mapping. Use the create map command to

specify the server IP address, ports, and keyID.

HP SA7150> create map Server IP (0.0.0.0): 10.1.1.30 SSL (network) por t [443]: Cleartext (serv er) port [80]: KeyID to use for mappi ng: mywebserver

4. Save the configuration when the server has been mapped.

HP SA7150> config save Saving configuration to flash... Configuration saved to flash HP SA7150>

Global Site Certificates

Overview

Four types of certificates are involved in the following discussion:

• Root Certificate. The certificate of a trusted Certificate Authority

(CA) such as VeriSign*.

• Server Certificate. Loaded on the server. Can be either self-

generated or received from a certificate authority such as VeriSign*. Interacts with requesting browser’s root certificate to establish encryption level.

• Global Site Certificate. An extended server certificate. Allows

128-bit encryption for export-r est rict ed browser s.

• Intermediate CA certificate. A certificate “signed,” that is,

authenticated, by a recognized CA such as VeriSign*, and used to validate a global site certificate. Called an “intermediate CA certificate” in the following discussion.

Export versions of Inte rnet Exp lorer* and Netscap e* Communicat or use 40-bit encryptio n to initiate connections to SSL servers. Upon receiving a client request, the server responds by sending a digital certificate. If this certificate is a conventional server certificate (that is, not a global site certificate), browser and serve r complete the SS L handshake and use a 40-bit key to encrypt application data. If the server responds to a re questing browser with a global sit e cer tific ate, the client automatically renegotiates the connection to use 128-bit encryption.

A global site certificate is validate d by an accompanying intermediate CA certificate. (Such pairs are called “chained certificates.”) Examples of intermediate CA certificates include Microsoft SGC

C H A P T E R 3 HP e-Commerce/XML Server Accelerator SA7150 User Guide

Root* and VeriSign Class 3*. When a requesting browser recei ves a global site certificate along with an intermediate CA certificate, the browser’s root certificate is used to validate the intermediate CA certificate, which in turn is used to validate the global site certificate, thus letting the browser know that it can renegotiate the connection to use 128-bit encryption.

Global Site Certificate Paste Procedure

If you wish to use a global site certificate, you must import both the global site certificate and its accompanying intermediate CA certificate. Both certificates must be chained together in a single file.

NOTE: The size of the file containing both certificates must not exceed 20KB.

NOTE: There must be no white space before, between, or after certificates, and the

“Begin...” headers and “End...” trailers must all

be retained.

Use the

import cert command to import either single or chained

certificates. In the latter case, paste the server ’s global site certificate first, followed by the intermediate CA certificate. Follow the intermediate CA certificate by typing three periods on a new line.

Example:

HP SA7150> import cert <keyID> Import protocol: (paste, xmodem) [paste]: Type or paste in data, end with ... alone on line

-----BEGIN CERT IFICATE----MIIFZTCCBM6gAwIBAgIQCTN2wvQH2CK+rgZKcTrNBzAN BgkqhkiG9w0BAQQFADCBujEfMB0GA1UEChMWVmVyaVNp Z24gVHJ1c3QgTmV0d29yazEXMBUGA1UECxMOVmVyaVNp Z24sIEluYy4xMzAxBgNVBAsTKlZlcmlTaWduIEludGVy bmF0aW9uYWwgU2Vy : dmVyIENBIC0gQ2xhc3MgMzFJMEcGA1UECxNAd3d3LnZl cmlzaWduLmNvbS9DUFMg SW5jb3JwLmJ5IFJlZi4gTElBQklMSVRZIExURC4oYyk5 NyBWZXJpU2lnbjAeFw05 OTExMTEwMDAwMDBaFw0wMDExMTAyMzU5NTlaMIHHMQsw CQYDVQQGEwJVUzETMBEG

-----END CERTIF ICATE-----

-----BEGIN CERT IFICATE----MIIEMTCCA5qgAwIBAgIQI2yXHivGDQv5dGDe8QjDwzAN BgkqhkiG9w0BAQIFADBfMQswCQYDVQQGEwJVUzEXMBUG A1UEChMOVmVyaVNpZ24sIEluYy4xNzA1BgNVBAsTLkNs YXNzIDMgUHVibGljIFByaW1hcnkgQ2VydGlmaWNhdGlv biBBdXRob3JpdHkwHhcNOTcwNDE3MDAwMDAwWhcN : OTk3IFZlcmlTaWduMA0GCSqGSIb3DQEBAgUAA4GBALiM

C H A P T E R 3 Redirection: Clients and Unsupported Ciphers

mMMrSPVyzWgNGrN0Y7uxWLaYRSLsEY3HTjOLYlohJGya wEK0Rak6+2fwkb4YH9VIGZNrjcs3S4bmfZv9jHiZ/ 4PC/ NlVBp4xZkZ9G3hg9FXUbFXIaWJwfE22iQYFm8hDjswMK NXRjM1GUOMxlmaSESQeSltLZl5lVR5fN5qu

-----END CERTIF ICATE-----<Enter> ...<Enter> Import successful! HP SA7150>

Redirection: Clients and Unsupported Ciphers

NOTE: The user must provide the redirect URL and ensure that it is available, as well as define the content of the redirect page.

WARNING: If the redirect URL causes a client to access the same SA7150 mapping that invoked the redirection an infinite loop condition will occur.

When a client that does not support t he selected ciph er suite att empts to connect to the SA7150 , the default behavi or is to reject the connection, resulting in the client system repo r ting a fatal error. However, the SA7150 allows you to specify a “redirect address” where you can provide clients with additional information. The set redirect command allows you to specify a redirect Web address for any Map ID. The show redirect command displays any redirect addresses currently configured.

If you are using a clear text map, the following three parameters are not applicable:

• Cipher Suite

• Redirect URL

• Client Authenticat ion

HP SA7150> list maps Map Net Ser Cipher Re- Client well ID KeyID Server IP Port Port Suites direct Auth XML form == ===== ========= ===== ==== ====== ===== ===== === ==== 1 default Any 443 80 all(v2+v3) n n n N/A HP SA7150> set redirect 2

Enter a redirect URL at following prompt e.g. http://www.e-comm_site.com/browser.html

Enter redirect URL []:http://www.e-comm_site.com/

cipher_info.html

C H A P T E R 3 HP e-Commerce/XML Server Accelerator SA7150 User Guide

To disable a redirect URL for a mapping:

HP SA7150> se t redirect 2 none HP SA7150> show redirect 2 Redirect URL for map 2 is not set

Client Authentication

The SA7150 supports only one root CA certificate per mapping. However, multiple intermediate CA certificates per sin gle mapping are supported.

First, use the list map command to display the current map IDs and their configurations including Client Authentication, enabled (y) or disabled (n).

HP SA7150> list map Map Net Ser Cipher Re- Client well ID KeyID Server IP Port Port Suites direct Auth XML form == ===== ========= ===== ==== ====== ===== ===== === ==== 1 default Any 443 80 all(v2+v3) n n n N/A 2 sample 10.1.2.57 443 80 med(v2+v3) n n n N/A HP SA7150>

Next, import the client CA certificate for Map ID 2.

HP SA7150> import client_ca 2 Import protocol: (paste, xmodem) [paste]: Type or paste in data, end with ... alone on

line

-----BEGIN CERT IFICATE----MIIDxzCCAzCgAwIBAgIBADANBgkqhkiG9w0BAQQFADCB

pDELMAkGA1UEBhMCVVMxEzARBgNVBAgTCkNhbGlmb3Ju aWExEjAQBgNVBAcTCVNhbiBEaWVnbzEUMBIGA1UE

. . .XcCabZcfBRuYcZeUoNrGUl8tD80jp2YNG1vidgLEaD1

YCli5I9/mNrcB25mSfdAR /08ROTMxm4VKOSA=

-----END CERTIF ICATE-----<Enter> ...<Enter>

C H A P T E R 3 Client Authentication

Verify the import by using t he list map command aga in. Note that the Client Auth column now shows client authentication for Map ID 2 enabled.

Clients connecting to “map 2” are required to present a client certificate signed by the CA whose certificate was imported above. If they do not present a properly signed certificate, their connection attempt is refused.

Creating a Client CA Certificate using OpenSSL*

NOTE: To acquire a copy of OpenSSL* for your environment, access the OpenSSL* Web site at www.openssl.org.

NOTE: In this example, ca_cert.pem is your trusted CA and signing certificate.

Software packages are available that handle the details of client certificate generation. However, you can also implement them manually. The following example illustrates the appropriate steps using OpenSSL*.

1. Generate the key pair for the client CA.

openssl genrsa -out ca_key.pem 1024

2. Create another private key by typing this command.

openssl genrsa -out ca_key.pem 1024

3. Generate the client CA certificate.

openssl req -new -x509 -config hp.cnf -key ca_key.pem -day s 365 -out ca_cert.pem

4. Use the import client_ca command to import ca_cert.pem for

each client.

1. Generate a key pair.

openssl genrsa -out key.pem 1024

2. Generate a certificate signing request.

openssl req -new -config hp.cnf -days 365 key key.pem -out cs r.pem

3. Sign the client certificate request by typing this command.

openssl X509 -req -Cacreatserial -Cakey ca_key.pem -CA ca _cert.pem -in csr.pem -out cert.pem

C H A P T E R 3 HP e-Commerce/XML Server Accelerator SA7150 User Guide

4. Combine the key.pem and cert.pem keys into one file by typing this command.

cat key.pem cert.pem > all.pem

5. Convert to p12 format by typing this command.

openssl pkcs12 -export -in all.pem -out <file>.p12 - name “MY NA ME”

The output file <file>.p12 will be imported into the browser as a personal certificate.

SSL Processing

The HP e-Commerce/XML Server Accelerator SA7150 handles several SSL protocols, for example, HTTPS (which is the default). For security purposes, you can block access to specified IPs or ports (see “Blocking” section in this chapter). Traffic that is not mapped or blocked flows through transparently (see “Failure Conditions” section at the end of this chapter). Supported protocols are listed below. (Ports listed are “well-known” port assignments. Any available port may be used.)

Mapping

NOTE: The SA7150 supports a maximum of 1000 mappings.

• HTTPS 443 (default)

• IMAPS 993

• POP3S 995

• SMTPS 465

• NNTPS 563

• LDAPS 636

Keypairs and their associated certificates are referenced by a keyID. A server is identified by a unique combination of server IP and network port. Mapping is the process of associating a keyID with a server (using server IP, network port, and server port). The SA7150 supports two types of mapping:

• Automapping

• Manual mapping

C H A P T E R 3 SSL Processing

Automapping

NOTE: Remember to save the configuration (with the config save command) after making mapping changes.

Automapped entries are identified by a server IP address of zero (0.0.0.0). When a server IP address of zero is specified, the SA7150 intercepts packets to any server IP address with the matching network ports. As with any mapping en try, the combination of server IP address and network port must be unique.

The initial configuration for the SA7150 provides an automapping entry for network p ort 443 an d server po rt 80. This is assoc iated with the internally generated default keypair and certificate with the keyID of “default.” Under this initial c onfiguratio n, automappi ng occurs o n any server with this ne twork port (443) when tr affic is routed thr ough the SA7150.

Automapping with user-specified key and certificate

When a user-specified key and certificate are to be automapped, the user can replace t he initial automapping entry with the create map command. By specifying the same unique identifier (server IP of

0.0.0.0, and network port of 443 with a user-generated keyID), the user can overwrite the initial automapping entry. (The key and certificate may be obtained through any of the methods described previously in this chapter.)

Automapping with multiple port combinations

The user can specify multiple automapping entries when the network port is unique. For example, a user might specify, in addition to the initial network (443) and server (80) port combination, a combinat ion of network (8010) and server (80) port.

Deleting automapping entries

Any automapping entry can be del eted, but if t he initial auto mapping is deleted and no other mapping entry is specified, the SA7150 automatically recreates the initial automapping entry. Either replace the initial automapping entry or create ano ther mapping/automapping entry and then delete the initial automapp ing entry using the delete map command.

C H A P T E R 3 HP e-Commerce/XML Server Accelerator SA7150 User Guide

Manual mapping

The user can create (with the create map command) one or more mapping entries for indi vidual servers. This is th e only way to specify unique keyIDs for each server. Normally, when manual mapping is performed, the initial automapping entry is deleted, but this is not a requirement.

Combining automapping and manual mapping

NOTE: If both manual mappings and applicabl e automappings are available, the SA7150 always uses the manual mapping.

Blocking

NOTE: Blocking is always performed before mapping.

Any combination of automappin g and manual mapping en tries, up to a total of 1000, can be used provided the server IP address and network port combinations are unique. Several of the scenarios in Chapter 4 include step-by-step mapping procedures.

For security purposes, the SA7150 allows the blocking of particular IP addresses and ports. IP/port combinations can be blocked on the basis of:

• Specific IP, specific port

• Subnet, specific port

• All IPs, specific port

Specific IP, Specific Port

To block a specific server IP and specific port combination:

1. Type the create block command.

2. Type the IP address.

3. Press Enter to accept the default IP mask

4. Type the specific port.

5. Press Enter to accept the default port mask.

C H A P T E R 3 SSL Processing

Example:

HP SA7150> create block Client IP to block [0.0.0.0]: 10.1.2.1 Client IP mask [0.0.0.0]: 255.255.255.255 Server IP to block [0.0.0.0]: 20.1.2.1 Server IP mask [0.0.0.0]: 25 5.255.255.255 Server Port to block: 80 Server Port mask [0xffff]:

Use the show block command to verify.

HP SA7150> show block (1) block 10.1.2. 1 255.255.255.255 20.1.2.1

255.255.255.255 80 0xffff

Subnet, Specific Port

To block a subnet and port combination:

1. Specify a subnet, using 0 as the final octet. (In the example

below, all IPs from “10.1.x.x” to “20.1.x.x” are blocked on port

80.)

2. Type the subnet mask, with 0 indicating the portion of the IP

address to be ignored.

3. Type the specific port.

4. Press Enter to accept the default port mask. Example:

HP SA7150> create block Client IP to block [0. 0.0.0]: 10.1.2.1 Client IP mask [0.0.0.0]: 255.255.0.0 Server IP to block [0. 0.0.0]: 20.1.2.1 Server IP mask [0.0.0.0]: 255.255.0.0 Server Port to block: 80 Server Port mask [0xffff]:

C H A P T E R 3 HP e-Commerce/XML Server Accelerator SA7150 User Guide

Use show block to verify.

HP SA7150> show block

-----------

blocks :

----------(1) block 10.1.2.1 255.255.0.0 20.1.2.1

255.255.0.0 80 0xffff

-----------

All IPs, Specific Port

To block a specific port on all IP addresses:

1. Type all zeroes as the IP address to be blocked.

2. Type all zeroes as the IP wildcard mask to be blocked.

3. Type the specific port.

4. Press Enter to accept the default port mask.

Example:

HP SA7150> create block Client IP to block [0.0.0.0]: Client IP mask [0.0.0.0]: Server IP to block [0.0.0.0]: Server IP mask [0.0.0.0]: Server Port to block: 80 Server Port mask [0xffff]:

5. Use the show block command to confirm the block.

HP SA7150> show block

-----------

blocks :

----------(1) block

0.0.0.0 0.0.0.0 0.0.0.0 0.0.0.0 80 0xffff

-----------

C H A P T E R 3 Failure Conditions, Fail-safe, and Fail-through

Delete a Block

The example below illus trates how to delete a subnet b lock. Type the delete bloc k command with the block ID (block ID is 1 in the example).

1. Use the show block command to identi f y th e bl ock t o b e del et ed.

HP SA7150> show block

-----------

blocks :

----------(1) block 10.1.2. 1 255.255.255.255 20.1.2.1

255.255.255.255 80 0xffff

-----------

2. Use the delete block command followed by the block ID to

delete the block.

HP SA7150> delete block 1

Failure Conditions, Fail-safe, and Fail-through

During a failure condition unprocessed data can either pass through the SA7150 or not, depending on whether Fail-safe or Fail-through mode is enabled. The Fail-through switch is by default in Fail-safe mode, meaning that during a failure no data packets will pass from one side of the SA7150 to the other. F or detail s, see “Failure/Bypass Modes” in Appendix B.

C H A P T E R 3 HP e-Commerce/XML Server Accelerator SA7150 User Guide

Notes

Scenarios

This section contains scenarios illustrating examples of HP eCommerce/XML Server Accelerator SA7150 configurations:

• Scenario 1: Basic XML Operation

• Scenario 2: Single Server Configuration

• Scenario 3: Multiple Server Configuration (SSL)

• Scenario 4: Cascaded SA7150s

• Scenario 5: Different Ingress and Egress Routers

• Scenario 6: Configuring a Firewall

C H A P T E R 4 HP e-Commerce/XML Server Accelerator SA7150 User Guide

Scenario 1—Basic XML Operation

As discussed in Chapter 3, th e SA7150 parses XML content, sea rches it for user-configured pattern s and distributes XML traf fic to variou s servers according to user-established rules embodied in XML patterns reflecting the user’s business needs.

This scenario illustrate s ste ps in a hypothetical situation in which you:

• Expect to receive purchase orders from three companies

• Want to categorize these purchase orders according to dollar

amount of order, method of payment and client’s zip code

• Want to send these different dollar amount categories to separa te

servers for processing

The illustration below shows the network diagram for Scenario 1. Though the illustration shows only three servers, th e principles demonstrated here could be applied to up to 1000 servers.

XML Server 1

XML Server 2

hub/switchRouter

HP e-Commerce/XML Server Accelera tor SA7150

XML Server 3

Network Diagram for Scenario 1

Note that Servers 1 and 3 use clear text maps, suitable when the anticipated XML t raf f ic is kn own to be unencrypted. Server 2 uses a normal map (i.e., one specifying a Key ID) to enable SSL enc ryption and decryption for XML data.

C H A P T E R 4 Scenario 1—Basic XML Operation

Procedure for Scenario 1

1. Create Server 1:

HP SA7150> create server Name: Server1 Server IP: 1.1.1.1 Cleartext (serv er) port [80]: Server MAC Address:00:a0:c9:fc:84:ab HP SA7150>

2. Create Server 2:

HP SA7150> create server Name: Server2 Server IP: 1.1.1.2 Cleartext (serv er) port [80]: Server MAC Address:00:a0:d9:fc:84:ab HP SA7150>

3. Create Server 3:

HP SA7150> create server Name: Server3 Server IP: 1.1.1.3 Cleartext (serv er) port [80]: Server MAC Address:00:a0:e9:fc:84:ab HP SA7150>

4. Create map for Server 1:

HP SA7150> create map Server IP [0.0.0.0]: 1.1.1.1 Network port [443]: Cleartext (serv er) port [80]: KeyID to use for mappi ng: Cleartext map for XML only? [n]: y HP SA7150>

5. Create map for Server 2 :

HP SA7150> create map Server IP [0.0.0.0]: 1.1.1.2 Network port [443]: Cleartext (serv er) port [80]: KeyID to use for mappi ng: 001 HP SA7150>

6. Create map for Server 3:

HP SA7150> create map Server IP [0.0.0.0]: 1.1.1.3 Network port [443]: Cleartext (serv er) port [80]: KeyID to use for mappi ng:

C H A P T E R 4 HP e-Commerce/XML Server Accelerator SA7150 User Guide

Cleartext map for XML only? [n]: y HP SA7150>

Verify creation of maps:

Map Net Ser Cipher Re- Client well ID KeyID Server IP Port Port Suites direct Auth XML form == ===== ========= ===== ==== ======== ===== ===== === ==== 1 N/A 1.1.1.1 443 80 N/A N/A N/A n N/A 2 001 1.1.1.2 443 80 all(v2+v3) n n n N/A 3 N/A 1.1.1.3 443 80 N/A N/A N/A n N/A

7. Enable XML for each mapping with the set xml command:

HP SA7150> set xml 1 enable HP SA7150> set xml 2 enable HP SA7150> set xml 3 enable

8. Create XML patterns for Server 1:

HP SA7150> create pattern server1 URI Expression: */order.asp XML Expression: //From[id = “Acme”] Enter another pattern? [n]: y

URI Expression: */order.asp XML Expression: //Amount[Value >= 10000] Enter another pattern? [n]: y

URI Expression: */order.asp XML Expression: default Enter another pattern? [n]:

9. Create XML patterns for Server 2:

HP SA7150> create pattern server2 URI Expression: */order.asp XML Expression: //From[id = “Widgets.com”] Enter another pattern? [n]: y

URI Expression: */order.asp XML Expression: //Amount[Value < 10000] Enter another pattern? [n]: y

URI Expression: */order.asp XML Expression: //Order[@type = "debit

card"]

Enter another pattern? [n]:

C H A P T E R 4 Scenario 1—Basic XML Operation

10.Create XML p a tterns for Server 3:

HP SA7150> create pattern server3 URI Expression: */order.asp XML Expression: //Amount[Value > 5000 and

Value < 10000]

Enter another pattern? [n]: y URI Expression: */order.asp

XML Expression: // Enter another pattern? [n]: y

URI Expression: */order.asp XML Expression: //Order[@type = "debit

card"]

Enter another pattern? [n]:

Address[zipcode < 9000]

The table below contains examples of XML patterns programmed i n the SA7150 for each of the three servers in Scenario 1.

Server URI Expression XML Expression

*/order.asp //From[id = “Acme”]

*/order.asp //Amount[Value >= 10000] */order.asp default */order.asp //From[id = “Widgets.com”]

*/order.asp //Amount[Value < 10000] */order.asp //Order[@type = “debit card”] */order.asp //Amount[Value > 5000 and Value < 10000]

*/order.asp //Address[zipcode < 9000] */order.asp //Order[@type= “debit card”]

XML Patterns for Scenario 1

C H A P T E R 4 HP e-Commerce/XML Server Accelerator SA7150 User Guide

The table below shows the SA7150’s responses to incoming XML data with URI expression */order.asp.

Incoming XML Data SA7150 Response

company name is Acme Sends to Server 1 company name is Widgets.com Sends to Server 2 company name is YourCo.com Sends to Server 3 purchase amount is $13,280 Sends to Server 1

Sends to Server 2 (Though the value satisfies patterns for

purchase amount is $7,280

both Servers 2 and 3, patterns are applied in order of server

map ID. Server 2 is the first w ith a matching pattern.) purchase amount is $713 Sends to Server 2 order is paid for with a debit card Sends to Server 2 customer’s zip code is 92128 Sends to Server 3 customer’s zip code is 27513 Sends to Server 1 due to the default setting order is paid for with a credit card Sends to Server 1 due to the default setting

SA7150 Responses to incoming XML traffic

C H A P T E R 4 Scenario 2—Single Server Configuration

Scenario 2—Single Server Configuration

NOTE: This configuration is intended primarily for use with SSL-intensive operations—it is not optimal for XML environments.

Router

Procedure for Scenario 2

This scenario describes a typic al configurat ion of a SA7150 with one server, using either automapping or manual configuration/mapping. This scenario describe s the fastest way to get up and running with a SA7150.

HP e-Commerce/XML Server Accelerator SA7150

Single Server

Single SA7150, Single Server Installation

Automapping

1. Physically connect the SA7150 to the router and to one server.

NOTE: XML is by default disabled for each map. You must specifically enable a map to process XML requests. See set xml command in Chapter 5.

2. Initiate HTTPS traf fic to the se rver. The SA7150 monitors traffic and uses the initial mapp ing (with associated default k ey and certificate) to decrypt HTTPS traffic and pass clear text HTTP traffic to the server.

Manual Configuration

1. Perform the installation as described in Chapter 2. Access the SA7150 command prompt.

2. Acquire the appropriate keys and certificates following the procedure in the “Keys and Certificates” section in Chapter 3.

C H A P T E R 4 HP e-Commerce/XML Server Accelerator SA7150 User Guide

3. Create a mapping for the server with the create map command:

HP SA7150> create map Server IP [0.0.0.0]: 1.1.1.30 Network port [443]: Cleartext (server) port [80]: KeyID to use for mappi ng: default HP SA7150>

4. After you have manually creat ed the mappi ng, you can d elete the default mapping. In this case, delete MapID number 1. The SA7150 automatically sorts MapIDs as they are created and deleted, thus MapID number 2 becomes MapID number 1 when the default is deleted.

HP SA7150> delete map 1 HP SA7150> list maps

Map Net Ser Cipher Re- Client well ID KeyID Server IP Port Port Suites direct Auth XML form == ===== ========= ===== ==== ======== ===== ===== === ==== 1 default 1.1.1.30 443 80 all(v2+v3)n n n N/A HP SA7150>

5. Save the configuration when the server has been mapped.

HP SA7150>config save

Saving configuration to flash... Configuration saved to flash

HP SA7150>

C H A P T E R 4 Scenario 3—Multiple Server Configuration (SSL)

Scenario 3—Multiple Server Configuration (SSL)

This scenario shows how to configure two or more servers.

Router

Procedure for Scenario 3

HP e-Commerce/XML Server

Accelerator SA7150

Hub/switch

Single SA7150, Multiple Server Installation

1. Perform the installation as described in Chapter 2. Access the SA7150 command prompt.

2. Acquire the appropriate keys and certificates following the procedure in the Keys and Certificates section in Chapter 3.

3. Create a mapping for Server 1 with the create map command.

HP SA7150> create map Server IP [0.0.0.0]: 1.1.1.30 Network port [443]: Cleartext (serv er) port [80]: KeyID to use for mappi ng: default HP SA7150>

4. Create a mapping for Server 2. As in the previous step, use the create map command to specify the parameters as prompted.

HP SA7150> create map Server IP [0.0.0.0]: 1.1.1.31 Network port [443]: Cleartext (serv er) port [80]: KeyID to use for mappi ng: default HP SA7150>

Server 1

10.1.1.30

Server 2

10.1.1.31

C H A P T E R 4 HP e-Commerce/XML Server Accelerator SA7150 User Guide

5. Use the list map command to view the mapping. (Multiple keys

and certificates can also be imported and each mapped to individual servers. If you do this, at least one field in the certificate information—usually the common name—must be unique.)

HP SA7150> list map Map Net Ser Cipher Re- Client well ID KeyID Server IP Port Port Suites direct Auth XML form == ===== ========= ===== ==== ======== ===== ===== === ==== 1 default Any 443 80 all(v2+v3) n n n N/A 2 default 1.1.1.30 443 80 all(v2+v3) n n n N/A 3 default 1.1.1.31 443 80 all(v2+v3) n n n N/A HP SA7150>

6. After you have manually c rea ted a map ping, the def ault mapp in g can be deleted. In this case, delete MapID number 1 . MapID number 2 becomes MapID number 1 when the default is deleted.

HP SA7150> de lete map 1 HP SA7150> list map

To configure a third or f ourth web server to oper ate with the SA7150, repeat the steps above, specifying a different IP address for each server.

7. Save the configuration when mapping is completed for the server(s).

HP SA7150> co nfig save Saving configuration to flash... Configuration saved to flash HP SA7150>

C H A P T E R 4 Scenario 4—Cascaded SA7150s

Scenario 4—Cascaded SA7150s

This scenario shows how to cascade SA7150s for additional performance and availability. The same procedures apply that were performed in Scenario 3. In addition, the complete configuration of the first SA7150 is exported to the second SA7150 in line.

Initial Configuration

HP e-Commerce/XML Server

Router

Accelerator SA7150

• Two or more SA7150s must be physically installed on the same

network. To cascade multiple SA7150s, connect from the server port of the first SA7150 to the network port of the next SA7150 in line, and then again connect from the server port to the network port of the next SA7150 in line, or to the server. (See Chapter 2: Installation and Initial Configur a tion, for more information.)

• The first SA7150 should be fully configur ed; any necessary keys,

certificates, or maps must exist. The complete configuration is exported from the first, then imported to the next SA7150 in line. This procedure is repeated for any additional SA7150s in line.

XML Server 1

XML Server 2

HP e-Commerce/XML Ser v er

Accelerator SA7150

hub/switch

XML Server 3

Multiple (Cascaded) SA7150s

C H A P T E R 4 HP e-Commerce/XML Server Accelerator SA7150 User Guide

Procedure for Scenario 4

NOTE: The SA7150 restarts when spill is enabled. Depending on the size of the current configuration file, it can require from 30 seconds to seven minutes to return to operations.

1. Configure the SA7150 farthest from the server as described in any of the preceding scenarios. Remain connected to that specific SA7150 for the export configuration procedure.

2. At the command prompt, type th e set spill enable command. This allows overflow traffic to be transferred to the second SA7150 for processing.

3. Save the configuration.

HP SA7150> co nfig save Saving configuration to flash... Configuration saved to flash

HP SA7150>

4. Export the configuration. Use the export config command. Choose xmodem mode (x) to export.

HP SA7150> export config Export protocol : (xmodem, ascii) [ascii]: x Beginning export...

5. Select Receive from the HyperTerminal* Transfer menu.

6. T ype or use the Browse button to specify the directo ry where you wish to place the received file.

7. Select xmodem as the receiving protocol.

8. Click the Receive button.

9. Specify a filename for the received file and click OK. The operation concludes and the normal prompt reappears.

Use Ctrl-X to kill transmission Export successful! HP SA7150>

10. Connect to the second SA7150, either through the console connection or another window (if both are connected to the same PC).

11. Import the configuration. Use the import config command to begin the process. Select xmodem (x) and press Enter to begin the import process.

HP SA7150> import config Import protocol: (paste, xmodem) [paste]: x Use Ctl-X to cancel up load

12. Select Send from the HyperTerminal* Transfer menu.

13. Type or use the Browse button to specify the file to send.

C H A P T E R 4 Scenario 4—Cascaded SA7150s

14. Select xmodem as the sending protocol.

15. Click the Send button. The transfer completes and then you are

prompted to verify that you wish to install this configuration.

Do you want to install this config ? [y]: y

16. After verification (y) or refusal (n), the prompt reappears.

HP SA7150>

17. Save the configuration.

HP SA7150> co nfig save Saving configuration to flash... Configuration saved to flash HP SA7150>

18. Repeat steps 11-17 for any additional SA7150s. On the last

SA7150 in the chain, disable spilling with the set spill disable command.

C H A P T E R 4 HP e-Commerce/XML Server Accelerator SA7150 User Guide

Scenario 5—Different Ingress and Egress Routers

This scenario describes the configuration of a SA7150 when the ingress and egress traffic paths are different. This scenario includes:

• One or more servers

• One or more cascaded SA7150s

• One or more ingress routers

• One egress router

HP e-Commerce/XML Server

Accelerator SA7150

Server

Client

Ingress Router

Egress Router

Switch

Procedure for Scenario 5

NOTE: Execute an “arp –a” (or equivalent

command for your OS) on the server to display the MAC address of the default gateway. This is the address you should use.

Installation with Ingress and Egress Routers

1. Configure your SA7150 (as described in any of the previous scenarios).

2. Determine the MAC address of the egress router you wish to route outbound traffic through.

3. At the CLI prompt, enter the default egress router.

HP SA7150> se t egress_mac 00:11:22:33:44:55 Egress MAC set to 00:1 1:22:33:44:55

HP SA7150> co nfig save Saving configuration to flash... Configuration saved to flash HP SA7150>

4. To reverse this process:

HP SA7150> se t egress_mac none

C H A P T E R 4 Scenario 6—Configuring a Firewall

Scenario 6—Configuring a Firewall

This scenario describes the recommended network configuration to allow a SA7150 to provide SSL services for a single server that also serves plain-text HTTP documents. Actual procedures for adjusting the firewall and server configurations vary widely depending upon the products used, so the steps outlined here are necessarily approximations and must be adjusted as required by the particula rs of your environment. Please consult your server and firewall documentation for additional information.

HP e-Commerce/XML Server Accelerator SA7150

Firewall

Server

Single SA7150 configured with single server and firewall

Server Configuration

Servers providing both HTTP and HTTPS services typically have two instances of the Web Server process configured:

• One listening on the standard HTTP port of 80, providing

unencrypted access to non-sensitive information, and

• Another listening on port 443 provid ing access to SSL encr ypted

sensitive information.

Port Number Connection Type Content Served

80 HTTP Non-sensitive

443 HTTPS Sensitive

C H A P T E R 4 HP e-Commerce/XML Server Accelerator SA7150 User Guide

For the SA7150 to provide SSL services, the web server process providing port 443 services requires two modifications.

• First, because the SA7150 performs all of the SSL processing,

the web server process must be configured to expect only standard HTTP (unenc rypted) connections, even for sensitive content.

• Second, the web server process must be configured to listen for

these HTTP connections on a port other than the standard HTTPS port (443). In this scenario we configure the port 443 service to listen on port 81.

Port Number Connection Type Content Served

80 HTTP Non-sensitive

81 HTTP Sensitive

SA7150 Configuration

The SA7150 must be configur ed to int ercep t HTTPS co nnecti ons on port 443 and forward them to the server. In t he precedin g section, we configured the server to provide access t o sensitive dat a through po rt 81, so that should be the clear text port when creating a server assignment (or “map”) on the SA7150. Perform the following steps to create the server assignment:

1. Perform the installation as described in Chapter 2 and access the command line prompt.

2. Acquire the appropriate keys and certificates following the procedure in the “Keys and Certificates” section in Chapter 3.

3. Create a mapping for the server . Use the create map command to specify the server IP address, ports, and keyID.

HP SA7150> create map Server IP (0.0.0.0): 1.1.1.3 SSL (network) port [443]: Cleartext (server) port [80]: 81 KeyID to use for mappi ng: serv1

C H A P T E R 4 Scenario 6—Configuring a Firewall

NOTE: The device automatically adjust s the list of MapIDs as they are created and deleted, thus MapID 2 becomes MapID 1 when the default (the original MapID 1) is deleted.

NOTE: In this configuration, the firewall may occasionally report the blocking of outbound packets from the Server on port 81. This is normal—a sideeffect of the varying latencies characteristic of Internet traffic—and does not indicate a problem with the configuration.

4. Once a user-created server assignment exists, the default mapping can be deleted. In this example, delete MapID number 1.

HP SA7150> list map Map Net Ser Cipher Re- Client well ID KeyID Server IP Port Port Suites direct Auth XML form == ===== ========= ===== ==== ======== ===== ===== === ==== 1 default 1.1.1.3 443 81 all(v2+v3) n n n N/A

5. Save the configuration.

HP SA7150> config save Saving configuration to flash... Configuration saved to flash

HP SA7150>

Firewall Configuration

Absent a firewall, outside clients would be able to connect to services on the web server and possibly gain access to sensitive data —on port 80 using HTTP to access non-sensitive data, on port 443 using HTTPS to access sensitive data, and on port 81 using HTTP to access that same sensitive data. Obviously, allowing access to sensitive data over an unencrypted connection on port 81 is not desirable. Consequently a firewall should be configured to prevent such access.

Port Access

80 Allowed

443 Allowed

All Others Denied

C H A P T E R 4 HP e-Commerce/XML Server Accelerator SA7150 User Guide

Notes

Online Help

Command Reference

The HP e-Commerce/XML Server Accelerator SA7150 is fully configurable through the Command Line Interface (CLI). The CLI is accessible through both the console and aux console RS232 ports or remotely via Telne t and SSH.

The SA7150 provides online help with the following options:

• Type help to display a summary of commands.

• Type hel p <command> (or ? <command>) for a de scription

of a specific command or, if relevant, a list of subcommands you can enter from within <command>.

• Type help us age (or ? usage)to display al l commands and

their usage.

• Type tty_char to display a list of special terminal editing

characters.

C H A P T E R 5 HP e-Commerce/XML Server Accelerator SA7150 User Guide

Command Line Interface

The CLI handles all user interactions on the console and auxiliary console RS232 ports. One instance per port runs at all times.

User Authentication

Command Line Prompt

Abbreviation to Uniqueness

To gain access to the CLI, the user must first be authenticated by providing a password at the logon ban ner prompt . The logon banner provides build versio n information and the seri al number.

The standard command line prompt for the SA7150 is:

HP SA7150>

The prompt can be changed with the set prompt command.

It is not always necessary to type t he entire command. CLI commands can be abbreviated to uniqueness. For example, “del” as show bel ow is sufficient to represent the delete command:

HP SA7150> del Usage: delete item [arg] block blockID cert keyID client_ca mapID key keyID logs logID|all map mapID patch pattern serverName patternID permit permitID server serverName sign keyID snmp_community trap_community

C H A P T E R 5 Input Editing Commands

However, “sh” as shown b elow, is not a n a bbreviat ion to u niquene ss in that it does not distinguish between show and showsnmp.

HP SA7150> sh

The solitary letter “e” in the context of the next example, (i.e., preceded by “ssh”), uniquely indicates ssh enable.

HP SA7150> se t ssh e SSH Service start ed.

Input Editing Commands

Moving the Insertion Point

Command Description ctrl-b ctrl-f ctrl-a ctrl-e ctrl-l

Command History

Command Description ctrl-p ctrl-n ctrl-r

ctrl-s

Move back one character. Move forward one character. Move to the start of the current line. Move to the end of the line. Redraw the current line.

A history of recently executed commands is stored in a buffer and can be accessed with the following commands:

Move “up” through the history list Move “down” through the history list (Reverse-search history) Search backward starting at the current

line and moving up incrementally through the command history. (Forward-search history) Search forward starting at the current

line and moving down incrementally through the command history.

C H A P T E R 5 HP e-Commerce/XML Server Accelerator SA7150 User Guide

Cut and Paste

Command Description ctrl-d ctrl-k

ctrl-u

ctrl-w

ctrl-y backspace/del

Delete the character underneath the cursor. Delete the text from the current cursor position to the end of the

line. Delete backward from the cursor to the beginning of the current

line. Delete the word behind the cursor, using white space as a word

boundary. Copy text that has been deleted. Delete the character to the left of the cursor.

C H A P T E R 5 Command Summary

Command Summary

This section contains a high-level view of the SA7150’s command structure. Details appear in the next section, Command Reference.

Command Command Options bypass config

create

delete

default compare reset save

block cert <keyID> key <keyID> map pattern <serverName> permit server sign <keyID>

block <blockID> cert <keyID> client_ca <mapID> key <keyID> logs<logID | all> map <mapID> patch pattern <serverName> <patternID> permit <permitID> server <serverName> sign <keyID> snmp_community trap_community

exit export

N/A key <keyID>

cert <keyID> sign <keyID> log <logID> config

C H A P T E R 5 HP e-Commerce/XML Server Accelerator SA7150 User Guide

Command Command Options factory_default help

import

inline insert list

N/A help

help <command> help usage

cert <keyID> client_ca <mapID> config key <keyID> patch upgrade

N/A server <ServerID> blocks

filters (shows blocks and permits) keys logs maps permits monitoring procs snmp_community system trap_community

nic password reboot

N/A N/A N/A

C H A P T E R 5 Command Summary

Command Command Options set

alarms <all, esc, rsc, utl, ovl, nls> cache <enable | disable> ciphers <mapID> ciphers <mapID> default client_tmo <seconds> date defcert egress_mac x:x:x:x:x:x egress_mac none ether idleto <timeout> ip <ip> <netmask> kstrength max_remote_sessions <0-5> monitoring <enable | disable> monitoring_interval <seconds> monitoring_fields more ovl_window <seconds> prompt redirect <mapID> redirect <mapID> none route x.x.x.x rsc_window <seconds> serial server_tmo <seconds> ssh <enabl e | disable> ssh_port <port> spill <enable | disable> telnet <enable | disable> telnet_port <p ort> utl_highwater <percentage> utl_lowwater <percentage> utl_window <seconds> xml_well_formed <mapID> <enable | disable> xml <mapID> <enable | disable>

C H A P T E R 5 HP e-Commerce/XML Server Accelerator SA7150 User Guide

Command Command Options show

alarm blocks cache ciphers <mapID> cert <keyID> client_ca <mapID> client_tmo config config default config saved date defcert egress_mac ether filters idleto info ip key <keyID> kstrength logs map max_remote_sessions monitoring monitoring_interval monitoring_fields more patch ovl_window pattern <serverName> pattern permits rsc_window redirect <mapID> route serial server server_tmo ssh ssh_port sign <keyID> spill status <arg> telnet

C H A P T E R 5 Command Summary

Command Command Options show

setsnmp

showsnmp

telnet_port utl_highwater utl_lowwater utl_window

snmp <enable | disable> snmp_community snmp_port <port> snmp_info sys_contact sys_location sys_name trap_authen <enable | disable> trap_community trap_port <port>

snmp snmp_community snmp_port snmp_info sys_contact sys_location sys_name trap_authen trap_community trap_port

status

tty_char

line realtime alarms <log>

N/A

C H A P T E R 5 HP e-Commerce/XML Server Accelerator SA7150 User Guide

Command Reference

Help Commands

Command Description help help <command> help usage tty_char

Display the list of available commands. Display usage for a single command. Display all commands and their usage. View the available list of keyboard shortcut commands.

Status Command

Command Description status

Display device statistics. Several modes are available, as described below. (Default: realtime.)

Syntax:

HP SA7150> status <line | realtime | alarms | <log> >

where: <line> specifies a line-oriented display of statistics.

<realtime> specifies that statistics be displayed in realtime. <alarms> shows current alarm events. <log> shows statistics and alarm events in a specified log file.

C H A P T E R 5 Command Reference

XML Commands

Command Description create server

delete server

Specify an XML server. Prompts for a unique name, a unique IP address/port pair , and the correct MAC addr ess to identify a server to fulfill XML requests.

NOTE: Server names are case insensitive.

Example:

HP SA7150> create server

Server Name: Standard Server IP: 10.1.1.2 Cleartext (server) port [80]: 8080 Server MAC Addr es s:00:a0:c9:fc:84:ab

HP SA7150>

Delete the specified XML server name from the system.

NOTE: Use the show server command to identify existing servers.

Syntax:

HP SA7150> delete server <serverName>

C H A P T E R 5 HP e-Commerce/XML Server Accelerator SA7150 User Guide

Command Description insert server

show server

XML servers exist in a numeric hierarchy reflecting the order in which they were created with the create server command . The system assigns a server index number to each server as it is created, incrementing the number with each new server. This order is relevant to XML operations—in cases in which a document has a match with two XML patter ns of two different servers, the message is sent to the server with the lower index number. This command allows you to alter the order within that hierarchy by assigning an index number to a server.

NOTE: Before using this command , e xecute the show server command to view the current hierarchy of server index numbers.

Syntax:

HP SA7150> insert server <ServerID>

Example:

insert server 2 Name: Gold Server IP: 10.1.1.6 Cleartext (server) port [80]: 8080 Server MAC Addr es s: 22:33:44:55:66:77

Display the list of XML servers along with Server names, IDs, IP addresses, and ports.

Example:

HP SA7150> show server Server ID S erve r IP Port MA C Ad dres s S erve r Nam e

========= ========= ===== ============ ===== ==========

1 10.1.1.2 80 00:a0:c9:fc:84:a b St an da rd 2 10.1.1.4 80 01:a9:bw:cf:69:c d Pr em ie r

C H A P T E R 5 Command Reference

Command Description create pattern

Create an XML pattern for a specified server. Patterns associated with a given server are uniquely identified by a system-generated numeric pattern ID. After you execute the command, you are prompted to enter the URI expression followed by the XML expression. After a pattern is created the system prompts the user to enter another pattern.

Syntax:

HP SA7150> create pattern <serverName>

HP SA7150> create pattern Standard URI Expression: */purchase.asp XML Expression: //From[Id=’acme’] Enter another pattern? [n]: n

URI Expression is the string identifying the target of the HTTP

POST (wildcards can be used). XML Expression is the string to which incoming XML data is

compared. Documents containing strings matching a pattern are sent to the server associated with the matched pattern.

The SA7150 checks each expression for syntactical correctness as it’s entered. If it detects an error during this check it presents a message similar to the one belo w. (Messages vary depending on t he nature of the error.)

Improper use of ’*’ character in URI Expression

After both the URI and XML expressions have been entered, the SA7150 checks for “duplicate patterns,” i.e., it verifies that the newly created pattern hasn’t already been defined. If it detects a duplicate it displays th e following message:

A pattern with th is URI and XML expression already exists

C H A P T E R 5 HP e-Commerce/XML Server Accelerator SA7150 User Guide

Command Description delete pattern

Delete an XML pattern specified by server and pattern ID.

NOTE: Use the show pattern command to identify existing patterns.

Syntax:

HP SA7150> delete pattern <serverName> <patternID>

Example:

HP SA7150> delete pattern Standard 1

C H A P T E R 5 Command Reference

Command Description show pattern

Display the list of XML patterns for:

• all servers, or

• a specified server

When executed without the server name parameter, the command displays all patterns defined fo r a ll server s. When a ser ver na me is specified the command displays only the patterns defined for that server. Pattern IDs appear in the left column, the content of the pattern appears to the rig ht. Note that in the “Pattern” column the URI expression and XML expressi on component s are separ ated by the ampersand character (&) with a space on either side.

Example (single, specified server):

HP SA7150> show pat te rn Standard

Server: Standa rd Pattern ID Pattern ========== ========= 1 * & //gold

2 * & //order

Example (all servers):

HP SA7150> show pat te rn

Server: Standa rd

Pattern ID Pattern ========== ========= 1 * & //std

Server: gold

Pattern ID Pattern ========== ========= 1 * & //gold

2 * & //order [amount>1000] Server: silver

Pattern ID Pattern ========== ========= 1 * & //silver

C H A P T E R 5 HP e-Commerce/XML Server Accelerator SA7150 User Guide

Command Description set xml

Enables processing based on the XML patterns defined for a specified map. Default: disabled.

NOTE: Setting the comma nd t o “enable” has no effect if no X ML servers are defined.

NOTE: Enabling xml automatically enables xml_well_formed (see below) for the specified map, while disabling xml automatically disables xml_well_formed (assuming it has not previously been manually disabled).

Syntax:

HP SA7150> set xml <mapID> enable

Where <mapID> is the index of the map whose defined XML patterns you wish to enable.

Example:

HP SA7150> set xml 1 enable

C H A P T E R 5 Command Reference

Command Description set xml_well_formed

Enables or disables the SA7150’s feature for the de tection of malformed XML data coming in via HTTP POST. xml_well_formed norm a lly works in parallel with the xml command (see above), that is, it is automatically enabled for a specified map when xml is enabled for that map, and automatically disabled (for a specified map) when xml is disabled (for that map). (Thus the only independ ent control options are to disable xml_well_formed when xml is enabled and to re-enable it without having disabled xml.)

xml_well_formed functions as follows:

• If xml_well_formed is enabled, when malformed XML data is

found in an incoming request the

SA7150 terminates the

connection and returns HTTP Error 403 to the clien t with the message, “XML data is not well-formed.”

• If xml_well_formed is disabled, when malformed XML data is

found in an incoming request the default server is used.

Syntax:

HP SA7150> set xm l_ well_formed <mapID> <enable | disable>

Where <mapID> is the identifier of the map for which you wish to enable the xml-well-formed check.

Example:

HP SA7150> set xml_well_formed 1 disable

C H A P T E R 5 HP e-Commerce/XML Server Accelerator SA7150 User Guide

Port Mapping Commands

Command Definition create block

These commands are used to execute the operations described in Chapter 3’s Mapping and Blocking sections.

Create a block to preclude access to specified IP addresses or through specified ports. A single IP, a single port, or all ports can be blocked. If fewer than all ports are to be blocked, you must repeat the create bloc k command for each one.

Example:

HP SA7150> create block Client IP to block [0.0.0.0]: 10.1.2.1 Client IP mask [0.0.0.0]: 255.255.0.0 Server IP to block [0.0.0.0]: 20.1.2.1 Server IP mask [0.0.0.0]: 255.255.0.0 Server Port to block: 80 Server Port mask [0 xffff]: HP SA7150>

delete block

Delete a block specified by index number. Use show block (see below) to correlate existing blocks with their numbers.

Example:

HP SA7150> delete block 1

show block

Display all existing blocks.

Example:

HP SA7150> show block

-------blocks :

--------(1) block 10.1.2. 1 255.255.0.0 20.1.2.1

255.255.0.0 80 0xffff

----------

C H A P T E R 5 Command Reference

Command Definition create permit

delete permit

show permit

Create a configuration allowing a specified user access to specified servers and ports, and/or denying the specified user access to specified servers and ports.

Example:

HP SA7150> create permit Client IP to permit [0.0.0.0]:10.1.2.1 Client IP mask [0.0.0.0]:255.255.0.0 Server IP to permit [0.0.0.0]:20.1.2.1 Server IP mask [0.0.0.0]:255.255.0.0 Server Port to permit: 443 Server Port mask [0 xffff]: HP SA7150>

Delete a permit specified by index number. Use show permit (see below) to correlate existing permits with their num bers.

Example:

HP SA7150> delete permit 1

Display permits currently in force.

Example:

HP SA7150> show permit

-------permits :

--------(1) permit 10.1.2.1 255.255.0.0 20.1.2.1

255.255.0.0 44 3 0xffff

---------HP SA7150>

C H A P T E R 5 HP e-Commerce/XML Server Accelerator SA7150 User Guide

Command Definition create map

Create a mapping that associates server IP, SSL port, and Key ID, and clear text port (clear text maps only).

Example 1 (for SSL operation):

HP SA7150> create map Server IP [0.0.0.0]: 1.1.1.1 Network port [443]: 443 Cleartext (server) port [80]: 8080 KeyID to use for map pi ng: 4

NOTE: The Key ID (SSL operations only—not app licable to clea r text maps) used with a new mapping must exist prior to executing create map. Use create key to create a new Key ID. Also, a certificate must be associated with the key ID prior to using the mapping. (See Chapter 3 for details.)

Example 2 (clear text map for unencrypted XML processing):

HP SA7150> create map Server IP [0.0.0.0]: 1.1.1.1 Network port [443]: Cleartext (server) port [80]: KeyID to use for map pi ng: Cleartext map for XML only? [n]: y

delete map <mapID>

show map

NOTE: Do not specify a KeyID when creating a clear text map.

Delete a mapping.

NOTE: All MapIDs of a higher number than the one specified for deletion are decremented by one when this command is executed.

Syntax:

HP SA7150> delete map <n>

where <n> is the Map ID of the mapping you wish to delete. Display all mappings. (Same as list maps.)
