User Guide
© Copyright 2017 HP Development Company,
L.P.
HDMI, the HDMI Logo and igh-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC. Windows is either a registered trademark or trademark of Microsoft Corporation in the United States and/or other countries.
The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.
First Edition: January 2017
Document Part Number: 913656-001
About This Guide
This guide provides information on monitor features, setting up the monitor, using the software and technical specifications.
WARNING! Text set off in this manner indicates that failure to follow directions could result in bodily harm or loss of life.
CAUTION: Text set off in this manner indicates that failure to follow directions could result in damage to equipment or loss of information.
NOTE: Text set off in this manner provides important supplemental information.
TIP: Text set off in this manner provides helpful hints.
This product incorporates HDMI technology.
iii
iv About This Guide
Table of contents
1 Getting Started ............................................................................................................................................. |
1 |
Important safety information ............................................................................................................................... |
1 |
Product features and components ........................................................................................................................ |
2 |
Features ............................................................................................................................................... |
2 |
Front components ............................................................................................................................... |
3 |
Rear and side components .................................................................................................................. |
4 |
Setting up the monitor .......................................................................................................................................... |
5 |
Use caution when setting up the monitor ........................................................................................... |
5 |
Connecting the cables ......................................................................................................................... |
5 |
Adjusting the monitor ......................................................................................................................... |
8 |
Turning on the monitor ....................................................................................................................... |
9 |
Mounting the monitor ....................................................................................................................... |
10 |
Removing the monitor stand .......................................................................................... |
10 |
Attaching the VESA mounting bracket ........................................................................... |
11 |
Re-attaching the monitor stand ....................................................................................................... |
12 |
2 Using the monitor ........................................................................................................................................ |
13 |
Software and utilities .......................................................................................................................................... |
13 |
The Information file ........................................................................................................................... |
13 |
The Image Color Matching file ........................................................................................................... |
13 |
Installing the INF and ICM files ............................................................................................................................ |
13 |
Installing from the optical disc (available in select regions) ............................................................ |
13 |
Downloading from the web ............................................................................................................... |
14 |
Using the on-screen display (OSD) menu ............................................................................................................ |
14 |
Assigning the Function buttons ........................................................................................................................... |
15 |
Webcam ............................................................................................................................................................... |
16 |
Setting up Windows Hello .................................................................................................................................... |
16 |
Adjusting to Low Blue Light Mode ....................................................................................................................... |
16 |
Using Auto-Sleep Mode ....................................................................................................................................... |
17 |
Using Picture-in-Picture (PIP) .............................................................................................................................. |
17 |
3 Support and troubleshooting ........................................................................................................................ |
18 |
Solving common problems .................................................................................................................................. |
18 |
Button lockouts ................................................................................................................................................... |
19 |
Product support ................................................................................................................................................... |
19 |
Preparing to call technical support ..................................................................................................................... |
19 |
v
Locating the rating label ...................................................................................................................................... |
20 |
4 Maintaining the monitor .............................................................................................................................. |
21 |
Maintenance guidelines ....................................................................................................................................... |
21 |
Cleaning the monitor ......................................................................................................................... |
21 |
Shipping the monitor ......................................................................................................................... |
21 |
Appendix A Technical sp fi t ons ................................................................................................................. |
22 |
Preset display resolutions ................................................................................................................................... |
23 |
Entering user modes ......................................................................................................................... |
24 |
Power adapter ..................................................................................................................................................... |
24 |
Energy saver feature ........................................................................................................................................... |
24 |
Appendix B Accessibility ................................................................................................................................. |
25 |
Supported assistive technologies ....................................................................................................................... |
25 |
Contacting support .............................................................................................................................................. |
25 |
vi
1Getting Started
Important safety information
A power cord is included with the monitor. If another cord is used, use only a power source and connection appropriate for this monitor. For information on the correct power cord set to use with the monitor, refer to the Product Notices provided on your optical disc, if one is included, or in your documentation kit.
WARNING! To reduce the risk of electric shock or damage to the equipment:
•Plug the power cord into an AC outlet that is easily accessible at all times.
•Disconnect power from the computer by unplugging the power cord from the AC outlet.
•If provided with a 3-pin attachment plug on the power cord, plug the cord into a grounded (earthed) 3-pin outlet. Do not disable the power cord grounding pin, for example, by attaching a 2-pin adapter. The grounding pin is an important safety feature.
For your safety, do not place anything on power cords or cables. Arrange them so that no one may accidentally step on or trip over them. Do not pull on a cord or cable. When unplugging from the AC outlet, grasp the cord by the plug.
To reduce the risk of serious injury, read the Safety and Comfort Guide. It describes proper workstation, setup, posture, and health and work habits for computer users, and provides important electrical and mechanical safety information. This guide is located on the web at http://www.hp.com/ergo.
CAUTION: For the protection of the monitor, as well as the computer, connect all power cords for the computer and its peripheral devices (such as a monitor, printer, scanner) to some form of surge protection device such as a power strip or Uninterruptible Power Supply (UPS). Not all power strips provide surge protection; the power strips must be specifically labeled as having this ability. Use a power strip whose manufacturer offers a Damage Replacement Policy so you can replace the equipment, if surge protection fails.
Use the appropriate and correctly sized furniture designed to properly support your HP LCD monitor.
WARNING! LCD monitors that are inappropriately situated on dressers, bookcases, shelves, desks, speakers, chests, or carts may fall over and cause personal injury.
Care should be taken to route all cords and cables connected to the LCD monitor so that they cannot be pulled, grabbed, or tripped over.
NOTE: This product is suitable for entertainment purposes. Consider placing the monitor in a controlled luminous environment to avoid interference from surrounding light and bright surfaces that may cause disturbing re ections from the screen.
Important safety information |
1 |
Product features and components
Features
The monitor features include the following:
●86.36 cm (34 in) curved 1800r with 3440 x 1440 resolution, Ultra-Wide Quad High Definition (UWQHD) backlit display, plus full-screen support for lower resolutions
●Skype for Business certified popup webcam and microphone for online collaboration
●Windows® Hello facial recognition to allow signing in with increased security
●Tilt capability and easy viewing from sitting or standing position, or while moving from one side of the monitor to the other
● HDMI igh-Definition Multimedia Interface) video input
●DisplayPort video input
●USB Type-C port with power delivery up to 65 W
●Premium integrated speakers
●Plug and Play capability if supported by your operating system
●On-screen display (OSD) adjustments in several languages for easy setup and screen optimization
●HP Display Assistant software for adjusting monitor settings and enabling theft-deterrence features
●HDCP (High-bandwidth Digital Content Protection) used on digital inputs
●Software and documentation optical disc provided with the monitor in select regions that includes monitor drivers and product documentation
●VESA mounting bracket for attaching the monitor to a wall-mount device or swing arm
●Low Blue Light Mode settings to create a more relaxing and less stimulating image
NOTE: For safety and regulatory information, refer to the Product Notices provided on your optical disc, if one is included, or in your documentation kit. To locate updates to the user guide for your product, go to http://www.hp.com/support. Select Find your product, and then follow the on-screen instructions.
2Chapter 1 Getting Started
Front components
Component |
Function |
|
|
|
|
1 |
Webcam microphones |
Allow you to participate in a video conference. |
|
|
|
2 |
Webcam lens |
Transmits your image in a video conference. |
|
|
|
3 |
Webcam LED |
On: The webcam is in use. |
|
|
|
4 |
Speakers |
Transmit sound from audio input. |
|
|
|
5 |
+/- (Plus/Minus) button |
Press to increase (+) or decrease (-) speaker volume. |
|
|
|
6 |
Answer/Call button |
Press to answer or make a call. |
|
|
|
7 |
Mute microphone button |
Press to mute or activate the webcam microphone. |
|
|
|
8 |
Mute speaker button |
Press to mute or activate the speakers. |
|
|
|
9 |
Reject/Hang up button |
Press to decline or end a call. |
|
|
|
10 |
Menu button |
Press to open the OSD menu, select a menu item from the OSD, or close the |
|
|
OSD menu. An indicator is activated above the Menu button when the OSD |
|
|
menu is open. |
|
|
|
11 |
Function buttons |
Use these buttons to navigate through the OSD menu based on the |
|
|
indicators above the buttons that are activated when the OSD menu is open. |
|
|
NOTE: You can reconfigure the Function buttons in the OSD menu to |
|
|
quickly select the most commonly used operations. See Assigning the |
|
|
Function buttons on page 15 for more information. |
|
|
|
12 |
Power button |
Press the button to turn the monitor on or off. When the monitor is on, the |
|
|
power light above the Power button is on. |
|
|
|
Product features and components |
3 |
Rear and side components
Component |
Function |
|
|
|
|
1 |
Audio-out (headphone) |
Connects optional powered stereo speakers, headphones, earbuds, a |
|
jack |
headset, or a television audio cable. |
|
|
WARNING! To reduce the risk of personal injury, adjust the volume before |
|
|
using headphones, earbuds, or a headset. For additional safety information, |
|
|
see the Product Notices provided on the optical disc, if one is included with |
|
|
your product. |
|
|
NOTE: When a device is connected to the headphone jack, the monitor |
|
|
speakers are disabled. |
|
|
|
2 |
Power connector |
Connects an AC adapter to the monitor. |
|
|
|
3 |
HDMI port |
Connects the HDMI cable from the source device to the monitor. |
|
|
|
4 |
DisplayPort |
Connects the DisplayPort cable from the source device to the monitor. |
|
|
|
5 |
Audio-in jack |
Connects analog audio to the monitor. |
|
|
|
6 |
USB ports (2) |
Connects a USB device to the monitor. |
|
|
|
7 |
USB Type-B port |
Connects the USB Type-B cable from the source device to the monitor. |
|
|
|
8 |
USB Type-C port |
Connects the USB Type-C cable from the source device to the monitor. |
|
|
|
4Chapter 1 Getting Started
