HPE MSA 2050 Storage
Data sheet
HPE MSA Storage has been the industry
leading entry fibre channel SAN platform
for the past eight years1 with over
500000 storage systems sold worldwide.
Hewlett Packard Enterprise now introduces
the fifth generation HPE MSA platform with
HPE MSA 2050 Storage system that provides
2X more performance than the previous
generation at the same price.2 HPE MSA 2050
performs in excess of 200000 IOPS starting
at under $10K for aordable application
acceleration. However, do not let the simplicity
and low cost fool you.
HPE MSA 2050 Storage system keeps
your business running with expanded data
protection features. New virtualized snapshot
technology makes data protection and
instant recovery a snap. Remote replication
with Fibre Channel (FC) or iSCSI supports
aordable disaster recovery.
HPE MSA 2050 allows you to grow flexibly
now and into the future. Customers can
start small and scale as needed with any
combination of SSD, Enterprise, or Midline
SAS drives.
The latest HPE MSA array features two
high-performance controllers with support
for entry storage’s most popular FC, iSCSI and
SAS host interfaces. HPE MSA 2050 delivers
midmarket features to entry SAN customers
wanting to utilize the latest hybrid flash
technologies. HPE MSA 2050 is simple to
deploy and simple to manage.
Key features and benefits
Accelerates applications aordable
• HPE MSA 2050 performs at over 200000
IOPS starting at under $10K for aordable
application acceleration.
• Flexible base model delivers 2X more
performance than the previous generation
HPE MSA 2040 for the same price.
No experience required
• HPE MSA 2050 is easy to install, easy to
use, easy to maintain—no storage expertise
necessary.
• Automated tiering dynamically responds to
workload changes, so you don’t have to.
Keep your business running with
expanded data protection features
• New virtualized snapshot technology makes
data protection and instant recovery a snap.
• Remote replication with FC and iSCSI
supports aordable disaster recovery.
Grow flexibly now and into the future
• Data-in-place upgrades protect drive
investments and mitigate risky data
migrations.
• Customers can start small and scale as
needed with any combination of SSD,
Enterprise, or Midline SAS drives.
1
IDC WW Quarte rly Enterprise Storag e Systems Tracker,
4Q16, based o n vendor revenues .
2
Based on HPE interna l study, MSA 2050 flexib le base
model de livers 2x more per formance than prev ious
generat ion for the same pric e, May 2017.
Data sheet
Technical specification
Page 2
HPE MSA 2050 Storage
Drive description Up to 192 SFF SSD/SAS/MDL SAS or 96 LFF SSD/SAS/MDL SAS maximum including base array and expansion,
Max. drive type 10 TB 12G 72K LFF dual-port MDL SAS HDD
Max. raw capacity 614 TB SFF/960 TB LFF
Storage expansion options HPE MSA 2050 LFF Disk Enclosure
Host interface options 8 Gb/16 Gb FC 8 ports per system or
Storage controllers 2 controllers per system included
SAN backup support Yes
RAID levels 1, 5, 6, 10
HPE Systems Insight Manager support Yes
Compatible operating systems
depending on model
18 TB 12G 10K SFF dual-port SAS HDD
2 TB 12G 72K SFF dual-port MDL SAS HDD
32 TB SFF SSD
Including expansion, depending on model
HPE MSA 2050 SFF Disk Enclosure
HPE MSA 2050 SAS DC Power Carrier Grade SFF Disk Enclosure
1GbE/10GbE iSCSI 8 ports per system
8Gb SAS 8 ports per system
Microsoft® Windows Server® 2016
Microsoft Windows Server 2012
VMware®
HP-UX
Red Hat® Enterprise Linux®
SUSE Linux
Detailed information available at hpe.com/storage/spock
Clustering support Windows®, Linux, HP-UX
Form factor 2U base array, 2U LFF or SFF disk enclosures
Warranty (parts/labor/on-site) 3/0/0
Warranty and included services 3-year parts only next business day, no labor or on-site support
Data sheet
Page 3
HPE MSA software and data
services
HPE MSA Performance Automated Tiering
HPE MSA Performance Automated Tiering
engine moves data between available tiers
based on the access characteristics of that
data. Frequently accessed pages migrates to
the highest available tier delivering improved
I/Os to the application. Another feature of
HPE MSA tiering engine is Archive Tiering
where cold or less frequently accessed
data can be moved to lower performance
tiers. Pages are migrated between tiers
automatically to enhance performance, and
reduce operational expenses.
HPE MSA Performance Automated Tiering
functionality can be obtained with the optional
HPE MSA Advanced Data Services LTU.
HPE MSA Snapshot Software
HPE MSA Snapshot Software enables
increased data protection by creating
recovery points for your data, taking a picture
of what your data was at the time of the
snapshot. The snapshots are then maintained
even as data continues to change. In the
event of a failure, you can recover data to
any previous snapshot. Snapshots are a great
complement to tape or disk backup strategy.
A 64-snapshot license is included with
all HPE MSA 2050 models. A total of
512 snapshots can be supported on HPE MSA
2050 with the purchase of the optional
HPE MSA Advanced Data Services LTU.
HPE MSA Volume Copy Software
HPE MSA Volume Copy Software makes
a physical copy of the data to another set
of disks within the same array. One of the
benefits of HPE MSA Snapshot and Volume
Copy Software is the ability to mount a snap
or volume copy to another server for backup,
application testing, or data mining. HPE MSA
Volume Copy Software is controller based,
meaning no host resources are used. It
provides a physical copy of data from one LUN
to another with no server performance impact.
HPE MSA Remote Snap Software
HPE MSA Remote Snap Software is storage
based asynchronous replication technology
that provides both local and remote replication
on HPE MSA 2050 arrays. HPE Remote Snap
functionality is based on existing Snapshot
technology. Supporting both Ethernet (iSCSI)
and FC interconnects provides flexible options
to your application environments.
HPE MSA Remote Snap functionality can be
obtained with the purchase of the optional
HPE MSA Advanced Data Services LTU.
HPE StoreEasy Gateway Storage
An HPE StoreEasy 3000 Gateway Storage
can add file, print, iSCSI, and manage hosting
services to an HPE MSA 2050 array. For more
information, visit hpe.com/storage/storeeasy.
HPE MSA Advanced Data Services Suite
The optional HPE MSA Advanced Data Services
Suite includes the following software titles:
• HPE MSA Performance Automated Tiering
LTU
• HPE MSA 512-Snapshot Software LTU
• HPE MSA Remote Snap Software LTU
This optional software suite licenses all
software functionality on HPE MSA 2050.
Data sheet
Resources
QuickSpecs
HPE MSA 2050 Storage
HPE Factory Express
HPE Factory Express oers configuration,
customization, integration, and deployment
services for HPE servers and storage products.
Customers can choose how their factory solutions
are built, tested, integrated, shipped, and deployed.
HPE Factory Express oers service packages
for simple configuration, racking, installation,
complex configuration, and design services as
well as individual factory services, such as image
loading, asset tagging, and custom packaging.
HPE products supported through HPE Factory
Express include a wide array of ser vers and
storage: HPE Integrity, HPE ProLiant, HPE Apollo,
HPE ProLiant Server Blades, HPE BladeSystem,
HPE 9000 ser vers, as well as the HPE MSA family
of storage systems.
Customer Technical Training
The job responsibility of a storage administrator
has evolved to one that needs to adapt to
changes quickly. Companies need the right
people with the right skills and expertise to
manage immense volumes of data, making
certain their teams maintain high levels of sta
motivation and productivity. They should be
able to view and manage storage ecosystems
holistically and operate all components
together—from services, applications, devices,
and infrastructure.
HPE Financial Services
Optimize your IT investment strategy with new
ways to acquire, pay for, and use technology, in
lock-step with your business and transformation
goals. hpe.com/solutions/hpefinancialservices
Learn more at
hpe.com/services/getconnected
HPE MSA
Make the right purchase
decision. Click here to
chat with our presales
specialists.
Sign up for updates
HPE Pointnext
This service includes available response
times of next business day, 4-hour response,
HPE Pointnext leverages our strength
in infrastructure, partner ecosystems,
and end-to-end lifecycle experience, to
accelerate powerful, scalable IT solutions
to provide you the assistance for faster
time to value. HPE Pointnext provides a
comprehensive portfolio including Advisory
and Transformational, Professional, and
Operational Services to help accelerate your
digital transformation.
Operational Services
• HPE Flexible Capacity
With HPE Flexible Capacity, you get the
speed, scalability, and economics of the
public cloud in the privacy of your data
center. Gain the advantages of the public
cloud—consumption-based payment and
rapid scalability without worrying about
capacity constraints. Reduce the heavy
lifting needed to operate a data center.
And retain the advantages that IT provides
the business, such as control, security, and
others. Deliver the right user experience,
choose the right technology for the business,
manage privacy and compliance, and
manage the cost of IT. And, you have the
option to use the public cloud when needed.
• HPE Datacenter Care Service
HPE Datacenter Care helps improve IT
stability and security, increase the value of
IT, and enable agility and innovation. It is a
structured framework of repeatable, tested,
and globally available services building
blocks. You can deploy, operate, and evolve
your data center wherever you are on your
IT journey. With HPE Datacenter Care, you
or 6-hour to repair with answers to software
questions within two hours. This service also
includes collaborative software support for
independent software vendors (ISVs), such
as Red Hat, VMware, Microsoft, and others
running on your HPE servers.
• HPE Foundation Care Service
HPE Foundation Care connects you
to Hewlett Packard Enterprise 24x7
for assistance on resolving issues. This
service includes available response times
of next business day, 4-hour response,
or 6-hour to repair with answers to
software questions within two hours.
Hewlett Packard Enterprise is a leading
manufacturer who makes this level of
coverage available as a standard service
oering for your valuable servers. In
addition, collaborative software support
is included and provides troubleshooting
assistance on industry-leading software
running on your server. Simplify
your support experience and make
Hewlett Packard Enterprise your first call to
help resolve hardware or software problems.
Advisory and Transformation Services—
HPE Pointnext designs the transformation
and builds a road map tuned to your unique
challenges including Hybrid IT, Workload
and Application Migration, Big Data, and the
Intelligent Edge. Hewlett Packard Enterprise
leverages proven architectures and blueprints,
integrates HPE and partner products and
solutions, and engages Professional and
Operational Services teams from HPE Pointnext
as needed.
benefit from a personalized relationship with
Hewlett Packard Enterprise via a single point
of accountability for HPE and others’ products.
• HPE Proactive Care Service
HPE Proactive Care gives customers an
enhanced call experience. When your products
are connected to Hewlett Packard Enterprise,
we help you prevent problems and maintain
IT stability by utilizing personalized proactive
reports with recommendations and advice.
© Copyright 2017 Hewlett Packard Enterprise Development LP. The information contained herein is subject to change
without notice. The only warranties for Hewlett Packard Enterprise products and services are set forth in the express warranty
statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty.
Hewlett Packard Enterprise shall not be liable for technical or editorial errors or omissions contained herein.
Microsoft, Windows, and Windows Server are either registered trademarks or trademarks of Microsoft Corporation in the United States
and/or other countries. VMware is a registered trademark or trademark of VMware, Inc. in the United States and/or other jurisdictions.
Red Hat is a registered trademark of Red Hat, Inc. in the United States and other countries. Linux is the registered trademark of Linus
Torvalds in the U.S. and other countries. All other third-party trademark(s) is/are property of their respective owner(s).
a00016008ENW, September 2017, Rev. 1
Professional Services—HPE Pointnext
creates and integrates configurations that
get the most out of software and hardware,
and works with your preferred technologies
to deliver a more eicient solution. Services
provided by the HPE Pointnext team, certified
channel partners, or specialist delivery
partners include installation and deployment
services, mission-critical and technical
services, and education services.
Loading...
