HP ProLiant DL985, ProLiant DL388 Setup Poster
HP ProLiant Server
Setup Poster
Part number 407335-004
Edition: 4
January 2011
Translated versions
To view, select a language:
• English http://www.hp.com/support/ProLiant_Poster_en
• Francois http://www.hp.com/support/ProLiant_Poster_fr
• Italiano http://www.hp.com/support/ProLiant_Poster_it
• Español http://www.hp.com/support/ProLiant_Poster_sp
• Deutsch http://www.hp.com/support/ProLiant_Poster_gr
• Nederlands http://www.hp.com/support/ProLiant_Poster_nl
• Português Brasileiro http://www.hp.com/support/ProLiant_Poster_bp
• Русский http://www.hp.com/support/ProLiant_Poster_ru
• http://www.hp.com/support/ProLiant_Poster_jp
• http://www.hp.com/support/ProLiant_Poster_sc
Site requirements
Select an installation site that meets the detailed installation site
requirements described in the server user guide on the Documentation CD
and on the HP website www.hp.com.
Rack planning resources
The rack resource kit ships with all HP branded or Compaq branded
9000, 10000, and H9 series racks. For more information on the content of
each resource, refer to the rack resource kit documentation.
Contents of the server shipping carton
Unpack the server shipping carton, and locate the materials and
documentation necessary for installing the server.
1 Installing options
Install any hardware options before initializing the server. For options
installation information, see the documentation that ships with the
option. For server-specic information, see the server user guide on the
Documentation CD and on the HP website http://www.hp.com.
2 Installing the server
WARNING:The server is very heavy. To reduce the risk of
personal injury or damage to the equipment:
• Reduce the weight of the server by removing the hard drives and
power supplies before installing the server into the rack.
• Get help to lift and stabilize the server during installation. When
the server weighs more than 22.5 kg (50 lb), two people might
be required to install the server into the rack.
CAUTION:Always plan the rack installation so that the heaviest
item is on the bottom of the rack. Install the heaviest item rst, and
continue to populate the rack from the bottom to the top.
Install the server into the rack. For more information, see the Quick Deploy
Rail System Installation Instructions that ship with the rack hardware kit.
3 Connecting peripheral devices to
the server
IMPORTANT:When using cable management arm components,
be sure to leave enough slack in each of the cables to prevent
damage to the cables when the server is extended from the rack.
Connect the peripheral devices to the server. The ports are labeled on the rear
of the server. For more information on ports and connectors, see the server
user guide on the Documentation CD and on the HP website
http://www.hp.com.
© Copyright 2009, 2011 Hewlett-Packard Development Company, L.P.
The information contained herein is subject to change without notice. The only warranties
for HP products and services are set forth in the express warranty statements accompanying
such products and services. Nothing herein should be construed as constituting an additional
warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.
ImportantSafetyInformation
Les "Viktig sikkerhetsinformasjon" på dokumentasjons-CDen før du installerer dette produktet.
Læs dokumentet Vigtige sikkerhedsoplysninger på dokumentations-cd'en, før produktet installeres.
Prima dell'installazione, leggere sul CD le Informazioni importanti sulla sicurezza.
Tärkeisiin turvatietoihin" Documentation CD -levyllä ennen tuotteen asentamista.
Läs dokumentet Viktig säkerhetsinformation på dokumentations-cd:n innan du installerar denna produkt.
4 Connecting the power cord to the
power supply
WARNING:To reduce the risk of electric shock or damage to the
equipment:
• Do not disable the power cord grounding plug. The grounding
plug is an important safety feature.
• Plug the power cord into a grounded (earthed) electrical outlet
that is easily accessible at all times.
• Unplug the power cord from the power supply to disconnect
power to the equipment.
• Do not route the power cord where it can be walked on or
pinched by items placed against it. Pay particular attention to
the plug, electrical outlet, and the point where the cord extends
from the storage system.
1. Connect the power cord to the power supply.
2. Thread the power cord through the strain relief clip (if applicable). For
instructions on using the power cord strain relief clip, see the instructions
that ship with the clip.
3. Connect the power cord to the AC power source.
5 Powering up and conguring the
server
To power up the server, press the Power On/Standby button.
During the initial boot, the server conguration automatically defaults to
prepare for operating system installation.
To modify the server default settings, press the F9 key when prompted
during the boot process to enter ROM-Based Setup Utility (RBSU). By
default, RBSU runs in the English language.
NOTE:If an HP array controller has been added or is embedded in the
system, the array controller will default to a RAID conguration based
on the size and number of hard drives installed. Press the F8 key when
prompted during the array controller initialization to use the ORCA utility to
modify the controller default settings.
For more information on the automatic conguration, see the HP ROM-
Based Setup Utility User Guide on the Documentation CD and the HP
website http://www.hp.com.
6 Installing the operating system
To operate properly, the server must have a supported operating system.
For the latest information on operating system support, see the HP website
http://www.hp.com/go/supportos.
Three common methods are available to install an operating system on the
server:
• SmartStart assisted installation—For information on installing an
operating system with Smart Start, see the HP website
http://www.hp.com/servers/smartstart.
• Manual installation—Use one of the following options:
o Insert the operating system CD or DVD into the CD/DVD-ROM drive,
and then reboot the server.
o If the server does not have a CD/DVD-ROM drive, insert the
operating system CD or DVD into an external USB CD-ROM drive,
and then reboot the server. This process might require you to obtain
additional drivers from the HP website http://www.hp.com/support.
• Remote deployment installation—The operating system can be remotely
deployed using the Rapid Deployment Pack (RDP) or PXE boot over an
Ethernet connection.
Follow the on-screen instructions to begin the installation process.
For information on using these installation methods, see the HP website
http://www.hp.com/servers/smartstart.
7 Registering the server
To register the server, refer to the HP Registration website register.hp.com.
Additional information
The HP ProLiant Servers Troubleshooting Guide provides procedures for
resolving common problems and comprehensive courses of action for fault
isolation and identication, error message interpretation, issue resolution,
and software maintenance on ProLiant servers and server blades. This
guide includes problem-specic owcharts to help you navigate complex
troubleshooting processes. To view the guide, select a language:
• English http://www.hp.com/support/ProLiant_TSG_en
• Français http://www.hp.com/support/ProLiant_TSG_fr
• Italiano http://www.hp.com/support/ProLiant_TSG_it
• Español http://www.hp.com/support/ProLiant_TSG_sp
• Deutsch http://www.hp.com/support/ProLiant_TSG_gr
• Nederlands http://www.hp.com/support/ProLiant_TSG_nl
• http://www.hp.com/support/ProLiant_TSG_jp
For denitions of the acronyms used in this document, refer to “Acronyms
and abbreviations” on the Documentation CD.
