HP ProLiant BL35p Server Blade Maintenance and Service Guide

Part Number 379103-007 February 2007 (Seventh Edition)

© Copyright 2005-2007 Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express

warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.

Microsoft and Windows are U.S. registered trademarks of Microsoft Corporation. AMD Opteron is a trademark of Advanced Micro Devices, Inc.

Audience assumptions

This guide is for an experienced service technician. HP assumes you are qualified in the servicing of computer equipment and trained in recognizing hazards in products with hazardous energy levels and are familiar with weight and stability precautions for rack installations.

Illustrated parts catalog ................................................................................................................. 5

Customer self repair................................................................................................................................... 5

ATA models.............................................................................................................................................. 6

Server blade exploded view ............................................................................................................. 6

HP BladeSystem p-Class sleeve and blanks exploded view.................................................................... 6

Spare parts list (ATA models) ............................................................................................................ 7

SAS models.............................................................................................................................................. 8

Server blade exploded view ............................................................................................................. 8

HP BladeSystem p-Class sleeve and blanks exploded view.................................................................... 9

Spare parts list (SAS models) ............................................................................................................9

Removal and replacement procedures........................................................................................... 11

Safety considerations............................................................................................................................... 11

Preventing electrostatic discharge .................................................................................................... 11

Rack warnings and cautions ........................................................................................................... 12

Preparation procedures............................................................................................................................ 12

Power down the server blade.......................................................................................................... 13

Remove the server blade ................................................................................................................ 13

ATA drive cage assembly......................................................................................................................... 14

ATA hard drive option .............................................................................................................................14

SAS drive cage assembly ......................................................................................................................... 15

SAS hard drive option ............................................................................................................................. 16

SAS controller and cables ........................................................................................................................17

Air baffle (dual-core processor models only)................................................................................................ 18

DIMMs................................................................................................................................................... 19

Processor ...............................................................................................................................................20

Fan assembly.......................................................................................................................................... 23

Dual Port Fibre Channel Adapter (2 GB) .................................................................................................... 24

NIC riser board ......................................................................................................................................24

Power converter module........................................................................................................................... 25

Power button/LED cable........................................................................................................................... 26

Server blade handle ................................................................................................................................ 26

System board assembly............................................................................................................................ 27

Server blade blanks................................................................................................................................. 28

HP BladeSystem p-Class sleeve ................................................................................................................. 28

HP BladeSystem p-Class sleeve board........................................................................................................ 29

Diagnostic tools.......................................................................................................................... 31

Troubleshooting resources ........................................................................................................................31

HP Insight Diagnostics.............................................................................................................................. 31

Survey Utility .......................................................................................................................................... 31

Integrated Management Log ..................................................................................................................... 32

HP Instant Support Enterprise Edition.......................................................................................................... 32

Web-Based Enterprise Service .................................................................................................................. 32

Open Services Event Manager.................................................................................................................. 33

Component identification............................................................................................................. 34

Contents 3

Server blade components ......................................................................................................................... 34

Front panel components and LEDs.................................................................................................... 34

Internal components....................................................................................................................... 36

System maintenance switch............................................................................................................. 37

Sleeve board and server blade LED locations.............................................................................................. 37

Local I/O cable ...................................................................................................................................... 38

Server blade enclosure bay numbering ......................................................................................................38

Server blade enclosure compatibility.......................................................................................................... 39

Specifications............................................................................................................................. 40

Environmental specifications ..................................................................................................................... 40

Server blade specifications....................................................................................................................... 40

Acronyms and abbreviations........................................................................................................ 41

Index......................................................................................................................................... 43

Contents 4

Illustrated parts catalog

In this section

Customer self repair ................................................................................................................................. 5

ATA models............................................................................................................................................. 6

SAS models............................................................................................................................................. 8

Customer self repair

What is customer self repair? HP's customer self-repair program offers you the fastest service under either warranty or contract. It

enables HP to ship replacement parts directly to you so that you can replace them. Using this program, you can replace parts at your own convenience.

A convenient, easy-to-use program:

• An HP support specialist will diagnose and assess whether a replacement part is required to address

a system problem. The specialist will also determine whether you can replace the part.

• Replacement parts are express-shipped. Most in-stock parts are shipped the very same day you

contact HP. You may be required to send the defective part back to HP, unless otherwise instructed.

• Available for most HP products currently under warranty or contract. For information on the warranty

service, refer to the HP website (http://h18004.www1.hp.com/products/servers/platforms/warranty/index.html

For more information about HP's customer self-repair program, contact your local service provider. For the North American program, refer to the HP website (http://www.hp.com/go/selfrepair

Customer replaceable parts are identified in the following tables.

Illustrated parts catalog 5

ATA models

Server blade exploded view

HP BladeSystem p-Class sleeve and blanks exploded view

Illustrated parts catalog 6

Spare parts list (ATA models)

NOTE: Always retain the server blade handle. The handle contains a serial number that

Item Description Spare part

1 System board assembly,

2 Processor — —

3 Fan assembly 361748-001 Yes 4 NIC riser board, mezzanine 361745-001 Yes 5 Power converter module 361752-001 Yes

maintains the original server blade warranty.

Mechanical components

with two single-core heatsinks, two dual-core heatsinks, and LED board

System components

a) 2.4-GHz AMD Opteron™ single-core 381836-001 Yes b) 1.8-GHz AMD Opteron™ dual-core 395083-001 Yes c) 2.0-GHz AMD Opteron™ dual-core 395084-001 Yes d) 2.2-GHz AMD Opteron™ dual-core 395085-001 Yes e) 2.4-GHz AMD Opteron™ dual-core 414452-001 Yes

Memory

Customer

number

381803-001 Yes

replaceable?

6 DIMMs — —

7 Heatsinks — —

8 Dual Port Fibre Channel Adapters (2 GB) — —

9 Hard drive, 60-GB, ATA 361751-001 Yes 10 Hardware kit 361750-001 Yes

a) DIMM, 512-MB, PC3200 DDR 400-MHz SDRAM 381817-001 Yes b) DIMM, 1-GB, PC3200 DDR 400-MHz SDRAM 381818-001 Yes c) DIMM, 2-GB, PC3200 DDR 400-MHz SDRAM 381819-001 Yes d) DIMM, 4-GB, PC2700 DDR 333-MHz SDRAM 416258-001 Yes Miscellaneous

a) Heatsink, single-core processor 381804-001 Yes b) Heatsink, dual-core processor 396768-001 Yes

a) QLogic-based Dual Port Fibre Channel Adapter (2-GB) 361744-001 Yes b) Emulex-based Dual Port Fibre Channel Adapter (2-

GB)*

a) 3U server blade blank — — b) Drive cage assembly — —

399852-001 Yes

11 HP BladeSystem p-Class sleeve access panel 361881-001 Yes

Illustrated parts catalog 7

Item Description Spare part

12 HP BladeSystem p-Class sleeve board 361746-001 Yes 13 Air baffle (dual-core processor systems only) 398028-001 Yes 14 Cable kit * 381805-001 Yes

15 Replacement battery, 3-V lithium * 234556-001 Yes 16 Local I/O cable * 355935-001 Yes

*Not shown

a) Power button/LED cable — — b) Hard drive cable — —

SAS models

Server blade exploded view

number

Customer replaceable?

Illustrated parts catalog 8

HP BladeSystem p-Class sleeve and blanks exploded view

Spare parts list (SAS models)

NOTE: Always retain the server blade handle. The handle contains a serial number that

Item Description Spare part

1 System board assembly, with two dual-core heatsinks and

2 Processor — —

3 Fan assembly 361748-001 Yes 4 NIC riser board, mezzanine 381816-001 Yes 5 Power converter module 361752-001 Yes

maintains the original server blade warranty.

Mechanical components

LED board System components

a) 1.8-GHz AMD Opteron™ dual-core 395083-001 Yes b) 2.2-GHz AMD Opteron™ dual-core 395085-001 Yes c) 2.4-GHz AMD Opteron™ dual-core 414452-001 Yes

Memory

Customer

number

404677-001 Yes

replaceable?

6 DIMMs — —

Illustrated parts catalog 9

Item Description Spare part

number

7 Heatsink, dual-core processor 396768-001 Yes 8 SAS controller 403624-001 Yes 9 Hard drives — —

10 Hardware kit 404678-001 Yes

11 HP BladeSystem p-Class sleeve access panel 361881-001 Yes 12 HP BladeSystem p-Class sleeve board 361746-001 Yes 13 Air baffle (dual-core processor systems only) 398028-001 Yes 14 Cable kit * 403623-001 Yes

a) 36-GB SAS 404784-001 Yes b) 72-GB SAS 404785-001 Yes c) 146-GB SAS 437862-001 Yes

a) 3U server blade blank — — b) Drive cage assembly * — — c) Latch release, spring, and screw * — —

a) Power button/LED cable — —

Customer replaceable?

15 Replacement battery, 3-V lithium * 234556-001 Yes 16 Local I/O cable * 355935-001 Yes

*Not shown

b) Hard drive cable — —

Illustrated parts catalog 10

Removal and replacement procedures

In this section

Safety considerations.............................................................................................................................. 11

Preparation procedures........................................................................................................................... 12

ATA drive cage assembly........................................................................................................................ 14

ATA hard drive option ............................................................................................................................ 14

SAS drive cage assembly........................................................................................................................ 15

SAS hard drive option ............................................................................................................................ 16

SAS controller and cables ....................................................................................................................... 17

Air baffle (dual-core processor models only) .............................................................................................. 18

DIMMs.................................................................................................................................................. 19

Processor .............................................................................................................................................. 20

Fan assembly......................................................................................................................................... 23

Dual Port Fibre Channel Adapter (2 GB) ................................................................................................... 24

NIC riser board ..................................................................................................................................... 24

Power converter module.......................................................................................................................... 25

Power button/LED cable.......................................................................................................................... 26

Server blade handle ............................................................................................................................... 26

System board assembly........................................................................................................................... 27

Server blade blanks................................................................................................................................ 28

HP BladeSystem p-Class sleeve ................................................................................................................ 28

HP BladeSystem p-Class sleeve board....................................................................................................... 29

Safety considerations

Preventing electrostatic discharge

Before performing service procedures, review all the safety information.

To prevent damaging the system, be aware of the precautions you need to follow when setting up the system or handling parts. A discharge of static electricity from a finger or other conductor may damage system boards or other static-sensitive devices. This type of damage may reduce the life expectancy of the device.

To prevent electrostatic damage:

• Avoid hand contact by transporting and storing products in static-safe containers.

• Keep electrostatic-sensitive parts in their containers until they arrive at static-free workstations.

• Place parts on a grounded surface before removing them from their containers.

• Avoid touching pins, leads, or circuitry.

• Always be properly grounded when touching a static-sensitive component or assembly.

Removal and replacement procedures 11

Rack warnings and cautions

WARNING: To reduce the risk of personal injury or damage to the equipment, be sure that:

• The leveling jacks are extended to the floor.

• The full weight of the rack rests on the leveling jacks.

• The stabilizing feet are attached to the rack if it is a single-rack installation.

• The racks are coupled together in multiple-rack installations.

• Only one component is extended at a time. A rack may become unstable if more than one

component is extended for any reason.

WARNING: To reduce the risk of personal injury or equipment damage when unloading a

rack:

• At least two people are needed to safely unload the rack from the pallet. An empty 42U

rack can weigh as much as 115 kg (253 lb), can stand more than 2.1 m (7 ft) tall, and may become unstable when being moved on its casters.

• Never stand in front of the rack when it is rolling down the ramp from the pallet. Always

handle the rack from both sides.

WARNING: This server blade enclosure is very heavy. To reduce the risk of personal injury or

damage to the equipment:

• Observe local occupational health and safety requirements and guidelines for manual

material handling.

• Get help to lift and stabilize the product during installation or removal, especially when the

product is not fastened to the rails. When the server blade enclosure weighs more than

22.5 kg (50 lb), at least two people must lift the server blade enclosure into the rack together. A third person may be required to help align the server blade enclosure if the server blade is installed higher than chest level.

• Use caution when installing the server blade enclosure in or removing the server blade

enclosure from the rack; it is unstable when not fastened to the rails.

WARNING: To reduce the risk of personal injury from hot surfaces, allow the drives and the

internal system components to cool before touching them.

Preparation procedures

To access some components and perform certain service procedures:

• Back up all critical data.

• Power down the server blade (on page 13).

For non-hot-plug service procedures, use the methods available to power down the server blade.

• Remove the server blade (on page 13).

Access to internal server blade components requires removal from the server blade enclosure and HP ProLiant p-Class sleeve.

Removal and replacement procedures 12

Power down the server blade

Before powering down the server blade, always back up critical data. Power down the server blade using either of the following methods:

• Press the Power On/Standby button on the server blade front panel.

Be sure that the server blade is in standby mode by observing that the power LED is amber. This process may take 30 seconds, during which time some internal circuitry remains active.

• Use the virtual power button feature in iLO.

After initiating a manual or virtual power down command, be sure that the server blade goes into standby mode by observing that the power LED is amber.

IMPORTANT: When the server blade is in standby mode, auxiliary power is still being

provided. To remove all power from the server blade, remove the server blade from the server blade enclosure. Removing the sleeve from the server blade enclosure is not necessary.

IMPORTANT: Remote power procedures require the most recent firmware for the power

enclosure and server blade enclosure management modules. For the most recent firmware, refer to the HP website (http://www.hp.com/go/support

Remove the server blade

1. Back up all server blade data.

2. Power down the server blade (on page 13).

3. Remove the server blade from the HP BladeSystem p-Class sleeve.

WARNING: To reduce the risk of personal injury from hot surfaces, allow the drives and the

internal system components to cool before touching them.

CAUTION: To prevent damage to electrical components, properly ground the server blade

before beginning any installation procedure. Improper grounding can cause ESD.

Removal and replacement procedures 13

ATA drive cage assembly

To remove the component:

1. Power down the server blade (on page 13).

2. Remove the server blade (on page 13).

3. Remove the drive cage assembly.

IMPORTANT: Be sure to disconnect the hard drive cable from the system board before

removing the drive cage assembly.

To replace the component, reverse the removal procedure.

ATA hard drive option

To remove the component:

1. Power down the server blade (on page 13).

2. Remove the server blade (on page 13).

3. Remove the ATA drive cage assembly (on page 14).

Removal and replacement procedures 14

+ 30 hidden pages
