Hp PROLIANT BL20P Maintenance and Service Guide

Compaq ProLiant BL20p Server Blade

Maintenance and Service Guide

Part Number 316080-001

January 2003 (First Edition)

This document provides detailed instructions for maintenance and service personnel. It includes removal and replacement procedures, spare parts information, an overview of diagnostic tools, locations for interface components, and related specifications for the Compaq

ProLiant BL20p server blade.

COMPAQ CONFIDENTIAL Codename: AvalancheX Part Number: 316080-001 Last Saved On: 12/18/02 11:27 AM

Microsoft and Windows are trademarks of Microsoft Corporation in the U.S. and/or other countries.

Intel and Pentium are trademarks of Intel Corporation in the U.S. and/or other countries.

Compaq shall not be liable for technical or editorial errors or omissions contained herein. The information in this document is provided “as is” without warranty of any kind and is subject to change without notice. The warranties for Compaq products are set forth in the express limited warranty statements accompanying such products. Nothing herein should be construed as constituting an additional warranty.

Compaq ProLiant BL20p Server Blade Maintenance and Service Guide

January 2003 (First Edition) Part Number 316080-001

COMPAQ CONFIDENTIAL Codename: AvalancheX Part Number: 316080-001 Last Saved On: 12/18/02 11:27 AM

About This Guide

Symbols in Text.......................................................................................................................................... vii

Important Safety Information ..................................................................................................................... vii

Compaq Technician Notes ......................................................................................................................... vii

Where to Go for Additional Help.............................................................................................................. viii

Integrated Management Log ..................................................................................................................ix

Telephone Numbers...............................................................................................................................ix

Text Conventions .........................................................................................................................................ix

Chapter 1

Illustrated Parts Catalog

ProLiant BL20p Server Blade Components .............................................................................................. 1-2

Server Blade Exploded View.............................................................................................................. 1-2

Server Blade Spare Parts List ............................................................................................................. 1-3

Chapter 2

Removal and Replacement Procedures

Safety Considerations................................................................................................................................ 2-1

Electrostatic Discharge Information ................................................................................................... 2-1

Server Blade Warnings and Cautions ................................................................................................. 2-1

Rack Warnings and Cautions.............................................................................................................. 2-2

Symbols on Equipment....................................................................................................................... 2-3

Server Blade Components ......................................................................................................................... 2-4

Server Blade Preparation .................................................................................................................... 2-4

Access Panel ....................................................................................................................................... 2-6

Hard Drive Blanks .............................................................................................................................. 2-7

Hot-Plug SCSI Hard Drives................................................................................................................ 2-8

DIMMs................................................................................................................................................ 2-9

Processor Power Module .................................................................................................................. 2-10

Processor Assembly .......................................................................................................................... 2-11

Battery-Backed Write Cache Enabler............................................................................................... 2-12

Blower Assembly.............................................................................................................................. 2-13

Compaq Smart Array 5i Controller Module ..................................................................................... 2-14

NIC Modules..................................................................................................................................... 2-15

SCSI Backplane ................................................................................................................................ 2-16

Power Button/LED Board................................................................................................................. 2-17

Battery............................................................................................................................................... 2-18

System Board.................................................................................................................................... 2-21

Server Blade Blanks.......................................................................................................................... 2-23

Compaq ProLiant BL20p Server Blade Maintenance and Service Guide iii

COMPAQ CONFIDENTIAL Codename: AvalancheX Part Number: 316080-001 Last Saved On: 12/18/02 11:27 AM

Contents

Chapter 3

Diagnostic Tools

ProLiant BL p-Class Diagnostic Tools ......................................................................................................3-2

Firmware Upgrades for Management Modules .........................................................................................3-4

Chapter 4

Connectors, LEDs, and Switches

Connectors .................................................................................................................................................4-2

ProLiant BL20p Server Blade ............................................................................................................. 4-2

Diagnostic Cable .................................................................................................................................4-4

LEDs .......................................................................................................................................................... 4-5

ProLiant BL20p Server Blade Front Panel.......................................................................................... 4-6

Hot-Plug SCSI Hard Drives ................................................................................................................4-7

Switches .....................................................................................................................................................4-9

Buttons ................................................................................................................................................4-9

System Switches................................................................................................................................4-10

Chapter 5

Specifications

ProLiant BL20p Server Blade.................................................................................................................... 5-2

Memory...................................................................................................................................................... 5-2

Wide Ultra3 SCSI Hard Drives..................................................................................................................5-3

Index

List of Figures

1-1 Server blade exploded view.................................................................................................................1-2

2-1 Pressing the Power On/Standby button ............................................................................................... 2-4

2-2 Removing the server blade from the server blade enclosure...............................................................2-5

2-3 Removing the server blade access panel .............................................................................................2-6

2-4 Removing a hard drive blank ..............................................................................................................2-7

2-5 Removing a hot-plug SCSI hard drive ................................................................................................2-8

2-6 Removing a DIMM .............................................................................................................................2-9

2-7 Removing a PPM...............................................................................................................................2-10

2-8 Removing a processor assembly .......................................................................................................2-11

2-9 Removing the Battery-Backed Write Cache Enabler ........................................................................2-12

2-10 Removing a blower assembly............................................................................................................2-13

2-11 Removing the Smart Array 5i Controller .......................................................................................... 2-14

2-12 Removing the NIC module................................................................................................................ 2-15

2-13 Removing the SCSI backplane..........................................................................................................2-16

2-14 Removing the power button/LED retaining screws ..........................................................................2-17

2-15 Removing the power button/LED board ...........................................................................................2-18

2-16 Battery holder ....................................................................................................................................2-19

2-17 Opening the battery retaining clip .....................................................................................................2-19

2-18 Removing the battery ........................................................................................................................2-20

2-19 Loosening the system board thumbscrew..........................................................................................2-21

2-20 Identifying alignment keys and keyhole locations ............................................................................ 2-22

2-21 Disengaging the system board...........................................................................................................2-22

iv Compaq ProLiant BL20p Server Blade Maintenance and Service Guide

COMPAQ CONFIDENTIAL Codename: AvalancheX Part Number: 316080-001 Last Saved On: 12/18/02 11:27 AM

Contents

2-22 Removing the system board.............................................................................................................. 2-23

2-23 Removing a server blade blank......................................................................................................... 2-23

4-1 ProLiant BL20p diagnostic port.......................................................................................................... 4-2

4-2 ProLiant BL20p server blade rear panel connectors...........................................................................4-3

4-3 ProLiant BL20p system board components and connectors............................................................... 4-4

4-4 Diagnostic cable connectors ............................................................................................................... 4-5

4-5 ProLiant BL20p server blade front panel LEDs ................................................................................. 4-6

4-6 Hot-plug SCSI hard drive LEDs ......................................................................................................... 4-7

4-7 Power On/Standby button................................................................................................................... 4-9

4-8 Server blade system switches............................................................................................................ 4-10

List of Tables

1-1 Server Blade Spare Parts List ............................................................................................................. 1-3

3-1 Diagnostic Tools ................................................................................................................................. 3-2

4-1 ProLiant BL20p Server Blade Rear Panel Connectors ....................................................................... 4-3

4-2 System Board Components and Connectors....................................................................................... 4-4

4-3 Diagnostic Cable Connectors.............................................................................................................. 4-5

4-4 ProLiant BL20p Server Blade Front Panel LEDs............................................................................... 4-6

4-5 Hot-Plug SCSI Hard Drive LEDs ....................................................................................................... 4-7

4-6 Server Blade System Switches.......................................................................................................... 4-10

4-7 iLO Switch (SW2) Settings .............................................................................................................. 4-11

4-8 System Switch (SW3) Settings ......................................................................................................... 4-11

4-9 System Configuration Switch (SW1) Settings.................................................................................. 4-12

5-1 Operating and Performance Specification for a ProLiant BL20p Server Blade ................................. 5-2

5-2 SDRAM DIMM Specifications .......................................................................................................... 5-2

5-3 Operating and Performance Specifications for Wide Ultra3 SCSI Hard Drives ................................ 5-3

Compaq ProLiant BL20p Server Blade Maintenance and Service Guide v

COMPAQ CONFIDENTIAL Codename: AvalancheX Part Number: 316080-001 Last Saved On: 12/18/02 11:27 AM

This maintenance and service guide is a troubleshooting guide that can be used for reference when servicing Compaq ProLiant BL20p server blades.

WARNING: To reduce the risk of personal injury from electric shock and hazardous energy levels, only authorized service technicians should attempt to repair this equipment. Improper repairs can create conditions that are hazardous.

Symbols in Text

These symbols may be found in the text of this guide. They have the following meanings.

WARNING: Text set off in this manner indicates that failure to follow directions in the warning could result in bodily harm or loss of life.

CAUTION: Text set off in this manner indicates that failure to follow directions could result in

damage to equipment or loss of information.

About This Guide

IMPORTANT: Text set off in this manner presents clarifying information or specific instructions.

NOTE: Text set off in this manner presents commentary, sidelights, or interesting points of information.

Important Safety Information

Before installing this product, read the Important Safety Information document provided.

Compaq Technician Notes

WARNING: Only authorized technicians trained by Compaq should attempt to repair this equipment. All troubleshooting and repair procedures are detailed to allow only subassembly/module-level repair. Because of the complexity of the individual boards and subassemblies, no one should attempt to make repairs at the component level or to make modifications to any printed wiring board. Improper repairs can create a safety hazard.

Compaq ProLiant BL20p Server Blade Maintenance and Service Guide vii

COMPAQ CONFIDENTIAL Codename: AvalancheX Part Number: 316080-001 Last Saved On: 12/18/02 11:27 AM

About This Guide

WARNING: To reduce the risk of personal injury from electric shock and hazardous energy levels, do not exceed the level of repairs specified in these procedures. Because of the complexity of the individual boards and subassemblies, do not attempt to make repairs at the component level or to make modifications to any printed wiring board. Improper repairs can create conditions that are hazardous.

WARNING: To reduce the risk of electric shock or damage to the equipment:

• Disconnect power from the system by unplugging all power cords from the power supplies.

• Do not disable the power cord grounding plug. The grounding plug is an important safety feature.

• Plug the power cord into a grounded (earthed) electrical outlet that is easily accessible at all times.

CAUTION: To properly ventilate the system, you must provide at least 7.6 cm (3.0 in) of

clearance at the front and back of the server.

CAUTION: The computer is designed to be electrically grounded (earthed). To ensure proper operation, plug the AC power cord into a properly grounded AC outlet only.

NOTE: Any indications of component replacement or printed wiring board modifications may void any warranty.

Where to Go for Additional Help

In addition to this guide, the following information sources are available:

• Compaq ProLiant BL p-Class System Setup and Installation Guide

• Compaq ProLiant BL p-Class System Hardware Installation and Configuration Poster

• Compaq Servers Troubleshooting Guide

• Compaq Altiris eXpress Deployment Server for Compaq ProLiant Servers User Guide

• Compaq Integrated Lights-Out User Guide

• Compaq ROM-Based Setup and Utility User Guide

• White paper: Compaq ProLiant BL p-Class System Overview and Planning

• White paper: Configuring a Preboot eXecution Environment (PXE) using Red Hat Linux

7.2 on Compaq ProLiant Servers

• QuickSpecs

• Compaq Service Quick Reference Guide

• Service training guides

• Compaq service advisories and bulletins

viii Compaq ProLiant BL20p Server Blade Maintenance and Service Guide

COMPAQ CONFIDENTIAL Codename: AvalancheX Part Number: 316080-001 Last Saved On: 12/18/02 11:27 AM

• Compaq QuickFind™ information services

• Compaq Insight Manager software

For additional information or copies of these documents, visit the Compaq website:

www.compaq.com

Integrated Management Log

The server blade includes an integrated, nonvolatile management log that contains fault and management information. The contents of the Integrated Management Log (IML) can be viewed with Compaq Insight Manager 7.

Telephone Numbers

For the name of the nearest Compaq authorized reseller:

• In the United States, call 1-800-345-1518.

• In Canada, call 1-800-263-5868.

About This Guide

For Compaq technical support:

• In the United States and Canada, call 1-800-OK COMPAQ.

• For Compaq technical support phone numbers outside the United States and Canada, visit

the Compaq website:

www.compaq.com

Text Conventions

This document uses the following conventions:

• Italic type is used for complete titles of published guides or variables. Variables include information that varies in system output, in command lines, and in command parameters in text.

• Bold type is used for emphasis, for onscreen interface components (window titles, menu names and selections, button and icon names, and so on), and for keyboard keys.

Monospace typeface is used for command lines, code examples, screen displays,

•

error messages, and user input.

Sans serif typeface is used for uniform resource locators (URLs).

•

Compaq ProLiant BL20p Server Blade Maintenance and Service Guide ix

COMPAQ CONFIDENTIAL Codename: AvalancheX Part Number: 316080-001 Last Saved On: 12/18/02 11:27 AM

Illustrated Parts Catalog

This chapter provides illustrated parts and spare parts lists for the Compaq ProLiant BL20p server blade components. Refer to Tables 1-1 through 1-6 for the names of referenced spare parts.

Compaq ProLiant BL20p Server Blade Maintenance and Service Guide 1-1

COMPAQ CONFIDENTIAL Codename: AvalancheX Part Number: 316080-001 Last Saved On: 12/18/02 11:28 AM

Illustrated Parts Catalog

ProLiant BL20p Server Blade Components

Server Blade Exploded View

Figure 1-1: Server blade exploded view

1-2 Compaq ProLiant BL20p Server Blade Maintenance and Service Guide

COMPAQ CONFIDENTIAL Codename: AvalancheX Part Number: 316080-001 Last Saved On: 12/18/02 11:28 AM

Illustrated Parts Catalog

Server Blade Spare Parts List

Table 1-1: Server Blade Spare Parts List

Item Description Spare Part Number

1 Access panel 237570-001

2 Hard drive blank 122759-001

3 Power button/LED board 237552-001

4 SCSI backplane 237551-001

5 System board 237505-001

6 Compaq NC3163 Fast Ethernet NIC Embedded 10/100 WOL 237555-001

7 Compaq Smart Array 5i Controller module 237550-001

8 Intel Pentium III processor assembly, 1.4 GHz 237504-001

9 Processor power module (PPM) 237553-001

10 Power converter module, 190 W 237554-001

11 Blower assembly 237569-001

12 Plastics and hardware kit * 237583-001

Bezel assembly —

Anchor pins (4) —

EMI fastener clips —

Ejector latch —

System board thumbscrew —

13 Replacement battery, 3-V lithium * 234556-001

14 ProLiant BL20p server blade return kit * 237582-001

15 DIMM, 128-MB, registered 133-MHz SDRAM * 159226-001

16 DIMM, 256-MB, registered 133-MHz SDRAM * 159304-001

17 DIMM, 512-MB, registered 133-MHz SDRAM * 159227-001

18 DIMM, 1-GB, registered 133-MHz SDRAM * 163902-001

Mechanical Components

Boards

System Components

Miscellaneous

Memory

* Not shown

continued

Compaq ProLiant BL20p Server Blade Maintenance and Service Guide 1-3

COMPAQ CONFIDENTIAL Codename: AvalancheX Part Number: 316080-001 Last Saved On: 12/18/02 11:28 AM

Illustrated Parts Catalog

Table 1-1: Server Blade Spare Parts List continued

Item Description Spare Part Number

20 Dual NC7780 Gigabit (NIC) upgrade module * 237585-001

21 Battery-Backed Write Cache Enabler, with cable * 260740-001

* Not shown

Options

1-4 Compaq ProLiant BL20p Server Blade Maintenance and Service Guide

COMPAQ CONFIDENTIAL Codename: AvalancheX Part Number: 316080-001 Last Saved On: 12/18/02 11:28 AM

Removal and Replacement Procedures

This chapter provides subassembly/module-level removal and replacement procedures for system components. After completing all necessary removal and replacement procedures, verify that all components operate properly by running the appropriate diagnostic software:

• For server blade components, run the Compaq Server Diagnostics utility, available from the Compaq website:

www.compaq.com

• For server blade enclosure and power enclosure components, run the infrastructure diagnostics. Refer to Chapter 3, “Diagnostic Tools,” for more information.

Safety Considerations

Electrostatic Discharge Information

A discharge of static electricity can damage static-sensitive devices or microcircuitry. Proper packaging and grounding techniques are necessary precautions to prevent damage. To prevent electrostatic damage, observe the following precautions:

• Transport products in static-safe containers such as conductive tubes, bags, or boxes.

• Keep electrostatic-sensitive parts in their containers until they arrive at static-free

stations.

• Cover workstations with approved static-dissipating material. Use a wrist strap connected to the work surface and properly grounded tools and equipment.

• Keep the work area free of nonconductive materials such as ordinary plastic assembly aids and foam packing.

• Always be properly grounded when touching a static-sensitive component or assembly.

• Use conductive field service tools.

Server Blade Warnings and Cautions

WARNING: To reduce the risk of shock or injury from high current electrical energy, do not remove the server blade access panel while the server blade is installed in the server blade enclosure. Do not remove the server blade access panel and then install the server blade into the server blade enclosure.

Compaq ProLiant BL20p Server Blade Maintenance and Service Guide 2-1

COMPAQ CONFIDENTIAL Codename: AvalancheX Part Number: 316080-001 Last Saved On: 12/18/02 11:31 AM

Removal and Replacement Procedures

WARNING: Setting the server blade Power On/Standby button to the standby position removes power from most areas of the server blade. This process may take 30 seconds, during which time some internal circuitry remains active. To remove power completely, remove the server blade from the server blade enclosure.

WARNING: To reduce the risk of personal injury from hot surfaces, allow the internal system components to cool before touching them.

CAUTION: When performing non-hot-plug operations, you must power down the server

blade and/or the system. However, it may be necessary to leave the server blade powered up when performing other operations, such as hot-plug installations or troubleshooting.

Rack Warnings and Cautions

WARNING: The power supply enclosure and the server blade enclosure are very heavy. To reduce the risk of personal injury or damage to the equipment:

• Observe local occupational health and safety requirements and guidelines for

manual material handling.

• Remove hot-plug power supplies and server blades from their enclosures before

installing or removing the enclosures.

• Use caution and get help to lift and stabilize enclosures during installation or

removal, especially when the enclosure is not fastened to the rack.

WARNING: Always use at least two people to lift a power supply enclosure or server blade enclosure into the rack. If the enclosure is being loaded into the rack above chest level, a third person MUST assist with aligning the enclosure with the rails while the other two people support the weight of the enclosure.

WARNING: To reduce the risk of personal injury or damage to the equipment, be sure that:

• The leveling jacks of the rack are extended to the floor.

• The full weight of the rack rests on the leveling jacks.

• The stabilizers are attached to the rack if it is a single rack installation.

• The racks are coupled in multiple rack installations.

WARNING: When installing the server blade enclosure in a telco rack, be sure that the rack frame is adequately secured to the building structure.

WARNING: To reduce the risk of personal injury or damage to the equipment, at least two people are needed to safely unload the rack from the pallet. An empty 42U rack weighs 115 kg (253 lb), is over 2.1 m (7 ft) tall, and may become unstable when being moved on its casters. Do not only stand in front of the rack as it rolls down the ramp from the pallet, but handle the rack from both sides.

2-2 Compaq ProLiant BL20p Server Blade Maintenance and Service Guide

COMPAQ CONFIDENTIAL Codename: AvalancheX Part Number: 316080-001 Last Saved On: 12/18/02 11:31 AM

Removal and Replacement Procedures

WARNING: To reduce the risk of shock or injury from high current electrical energy, do not reach into a server blade enclosure once it has been installed in a rack and connected to a working rack bus bar. Do not touch the power or data backplanes within the server blade enclosure once it has been installed.

WARNING: To reduce the risk of shock or injury from high current electrical energy, do not reach into a power supply enclosure once it has been installed in a rack and connected to a power source. Do not touch the connectors within the power supply enclosure once it has been installed.

WARNING: To reduce the risk of shock or injury from high current electrical energy, do not opening any access covers on the rack bus bar after it has been connected to a power source.

CAUTION: Protect equipment from power fluctuations and temporary interruptions with a

regulating UPS device or battery bank. This device protects the hardware from damage caused by power surges and voltage spikes and keeps the system in operation during a power failure.

CAUTION: Always ensure that equipment is properly grounded before beginning any installation procedure. Electrostatic discharge resulting from improper grounding can damage electronic components. For more information, refer to the setup and installation guide.

Symbols on Equipment

Any product or assembly marked with these symbols indicates that the component exceeds the recommended weight for one individual to handle safely.

25 kg

55 lb

WARNING: To reduce the risk of personal injury or damage to the equipment, observe local occupational health and safety requirements and guidelines for manual material handling

Any surface or area of the equipment marked with these symbols indicates the presence of a hot surface or hot component

WARNING: To reduce the risk of injury from a hot component, allow the surface to cool before touching it.

To reduce the risk of injury from electric shock hazards, do not open this enclosure.

WARNING: Any surface or area of the equipment marked with these symbols indicates the presence of electric shock hazards. The enclosed area contains no operator serviceable parts.

Any RJ-45 receptacle marked with these symbols indicates a Network Interface Connection.

WARNING: To reduce the risk of electric shock, fire, or damage to the equipment, do not plug telephone or telecommunications connectors into this receptacle.

Compaq ProLiant BL20p Server Blade Maintenance and Service Guide 2-3

COMPAQ CONFIDENTIAL Codename: AvalancheX Part Number: 316080-001 Last Saved On: 12/18/02 11:31 AM

Removal and Replacement Procedures

Server Blade Components

Use the procedures in this section to perform service events on ProLiant BL20p server blades.

Server Blade Preparation

To service any internal server blade component, you must power down the server blade and remove it from the server blade enclosure.

CAUTION: Electrostatic discharge can damage electronic components. Be sure you are properly grounded before beginning any installation procedure. For more information, refer to the “Electrostatic Discharge Information” section in this chapter.

System power in server blades does not completely shut off with the front panel Power On/Standby switch or Integrated Lights-Out (iLO) Virtual Power Button feature. The function toggles between on and standby modes, rather than on and off. The standby position removes power from most electronics and the drives, but portions of the power supply and some internal circuitry remain active.

To service internal server blade components:

1. Identify the proper server blade in the server blade enclosure.

2. Remove power from the server blade in one of the following ways:

— Use the Virtual Power Button feature in the iLO Remote Console to power down the

server blade from a remote location. Be sure that the server blade is in standby mode by observing that the power LED is amber.

— Press the Power On/Standby button on the front of the server blade. Be sure that the

server blade is in standby mode by observing that the power LED is amber.

Figure 2-1: Pressing the Power On/Standby button

2-4 Compaq ProLiant BL20p Server Blade Maintenance and Service Guide

COMPAQ CONFIDENTIAL Codename: AvalancheX Part Number: 316080-001 Last Saved On: 12/18/02 11:31 AM

Removal and Replacement Procedures

CAUTION: After you press the release button, the server blade is unlocked from the enclosure. Use both hands to support the server blade when you remove it from the rack.

3. Remove the server blade from the server blade enclosure:

a. Press the release button (1).

b. Open the lever (2).

c. Grasp the lever and slide the server blade from the enclosure (3). Place a hand under

the server blade to support it as you remove it from the enclosure.

Figure 2-2: Removing the server blade from the server blade enclosure

d. Place the server blade on a flat, level surface.

CAUTION: Always populate server blade enclosure bays with either a server blade or server blade blank. Operating the enclosure without a server blade or server blade blank results in improper airflow and improper cooling that can lead to thermal damage.

Reverse steps 1 through 3 to install and power up a server blade. Server blades are set to power up automatically upon insertion. If you have changed this setting, use the Power On/Standby button or iLO Virtual Power Button feature to power up the server blade.

For more information about iLO, refer to the Compaq Integrated Lights-Out User Guide.

Compaq ProLiant BL20p Server Blade Maintenance and Service Guide 2-5

COMPAQ CONFIDENTIAL Codename: AvalancheX Part Number: 316080-001 Last Saved On: 12/18/02 11:31 AM

Removal and Replacement Procedures

Access Panel

To remove the access panel:

1. Power down the server blade and remove it from the server blade enclosure. Refer to the “Server Blade Preparation” section in this chapter.

2. Loosen the thumbscrew (1).

3. Press down on the thumb indentations, slide the access panel toward the rear of the unit about 1.25 cm (0.5 in), and lift to remove the panel (2).

Figure 2-3: Removing the server blade access panel

Reverse steps 1 through 3 to replace the access panel.

2-6 Compaq ProLiant BL20p Server Blade Maintenance and Service Guide

COMPAQ CONFIDENTIAL Codename: AvalancheX Part Number: 316080-001 Last Saved On: 12/18/02 11:31 AM

Hard Drive Blanks

To remove a hard drive blank:

1. Press the release buttons simultaneously (1).

2. Pull the blank out of the drive bay (2).

Removal and Replacement Procedures

Figure 2-4: Removing a hard drive blank

CAUTION: Always populate hard drive bays with either a hot-plug SCSI hard drive or hard

drive blank. Operating the server blade without a hot-plug SCSI hard drive or hard drive blank results in improper airflow and improper cooling that can lead to thermal damage.

To replace the hard drive blank, slide the blank into the bay until it locks into place.

Compaq ProLiant BL20p Server Blade Maintenance and Service Guide 2-7

COMPAQ CONFIDENTIAL Codename: AvalancheX Part Number: 316080-001 Last Saved On: 12/18/02 11:31 AM

+ 42 hidden pages
