HP Photosmart Plus B209 series

Windows Help

HP Photosmart Plus B209 series

1 HP Photosmart Plus B209 series Help...................................................................................3

2 Finish setting up the HP Photosmart

Add the HP Photosmart to a network.........................................................................................5

Set up a Bluetooth connection..................................................................................................10

3 Get to know the HP Photosmart

Printer parts..............................................................................................................................15

Control panel features..............................................................................................................18

4 How do I?.................................................................................................................................19

6Print

Print documents........................................................................................................................29

Print photos..............................................................................................................................30

Print a creative project..............................................................................................................35

Print a Web page......................................................................................................................39

Print forms and templates (Quick Forms)...............................................................................39

7Scan

Scan to a computer..................................................................................................................45

Scan to a memory card or USB storage device.......................................................................46

8Copy

Copy text or mixed documents.................................................................................................51

9 Reprint photos........................................................................................................................57

10 Save photos

Save photos to your computer..................................................................................................59

Back up photos to a USB storage device.................................................................................60

11 Maintain the HP Photosmart

Check the estimated ink levels.................................................................................................61

Order ink supplies.....................................................................................................................62

Replace the cartridges..............................................................................................................62

Cartridge warranty information.................................................................................................64

Print and evaluate a print quality report....................................................................................65

Contents

12 Solve a problem

HP support................................................................................................................................69

Setup troubleshooting...............................................................................................................70

Print troubleshooting.................................................................................................................76

Print quality troubleshooting.....................................................................................................81

Memory card troubleshooting...................................................................................................81

Scan troubleshooting................................................................................................................84

Copy troubleshooting................................................................................................................85

Errors........................................................................................................................................86

14 Technical information

Notice......................................................................................................................................117

Cartridge chip information......................................................................................................117

Specifications.........................................................................................................................118

Environmental product stewardship program.........................................................................119

Regulatory notices..................................................................................................................125

Regulatory wireless statements..............................................................................................127

Index............................................................................................................................................131

Contents

1 HP Photosmart Plus B209 series

Help

For information about the HP Photosmart, see:

•“

Finish setting up the HP Photosmart” on page 5 Get to know the HP Photosmart” on page 15

•“ How do I?” on page 19

•“ Print” on page 29

•“ Scan” on page 45

•“ Copy” on page 51

•“ Reprint photos” on page 57

•“ Save photos” on page 59

•“ Maintain the HP Photosmart” on page 61

•“ Technical information” on page 117

•“

HP Photosmart Plus B209 series

Help

HP Photosmart Plus B209 series Help 3

Help

Chapter 1

HP Photosmart Plus B209 series

4 HP Photosmart Plus B209 series Help

2 Finish setting up the

HP Photosmart

• Add the HP Photosmart to a network

Set up a Bluetooth connection

•

Add the HP Photosmart to a network

•“WiFi Protected Setup (WPS)” on page 5 Wireless with a router (infrastructure network)” on page 6

•“ Wireless without a router (ad hoc connection)” on page 7

•“

WiFi Protected Setup (WPS)

To connect the HP Photosmart to a wireless network using WiFi Protected Setup (WPS), you will need the following:

 A wireless 802.11 network that includes a WPS-enabled wireless router or access

point.

 A desktop computer or laptop with either wireless networking support, or a network

interface card (NIC). The computer must be connected to the wireless network that you intend to install the HP Photosmart on.

To connect the HP Photosmart using WiFi Protected Setup (WPS)

1. Do one of the following:

Use Push Button (PBC) method a. Select setup method.

 On Home screen, touch right arrow to view more options.  Touch Setup.

 Touch Network.  Touch WiFi Protected Setup.  Touch Push Button.

b. Set up wireless connection.

 Touch Start.  Press corresponding button on WPS-enabled router or other networking

device.

c. Install software.

Finish setting up the HP Photosmart 5

Finish setting up the HP Photosmart

Chapter 2

NOTE: The product begins a timer for approximately two minutes in which the

corresponding button on the networking device needs to be pressed.

Use PIN method a. Select setup method.

 On Home screen, touch right arrow to view more options. Touch Setup.

Touch Network. Touch WiFi Protected Setup. Touch PIN.

b. Set up wireless connection.

Touch Start.

The device displays a PIN.

 Enter the PIN on WPS-enabled router or other networking device. Touch OK.

c. Install software.

NOTE: The product begins a timer for approximately two minutes in which the

PIN needs to be entered on the networking device.

2. View the animation for this topic.

Related topics

Install the software for a network connection” on page 9

“

Wireless with a router (infrastructure network)

The HP Photosmart Software CD and included USB setup cable provide an easy way to connect the HP Photosmart to your wireless network.

For optimal performance and security in your wireless network, HP recommends you use a wireless router or access point (802.11) to connect the product and the other network elements. When network elements are connected through a wireless router or access point, this is called an infrastructure network.

6 Finish setting up the HP Photosmart

To connect the HP Photosmart to an integrated wireless WLAN 802.11 network, you will need the following:

 A wireless 802.11 network that includes a wireless router or access point.  A desktop computer or laptop with either wireless networking support, or a network

interface card (NIC). The computer must be connected to the wireless network that you intend to install the HP Photosmart on.

 Broadband Internet access (recommended) such as cable or DSL.

If you connect the HP Photosmart on a wireless network that has Internet access, HP recommends that you use a wireless router (access point or base station) that uses

Dynamic Host Configuration Protocol (DHCP).  Network name (SSID).  WEP key or WPA Passphrase (if needed).

To connect the product

1. Insert the product Software CD in the computer CD-ROM drive.

2. Follow the instructions on the screen.

When you are prompted, connect the product to the computer using the USB setup

cable included in the box. The product will attempt to connect to the network. If the

connection fails, follow the prompts to correct the problem, and then try again.

3. When the setup is finished, you will be prompted to disconnect the USB cable and

test the wireless network connection. Once the product connects successfully to the

network, install the software on each computer that will use the product over the

network.

Related topics

“

Install the software for a network connection” on page 9

Wireless without a router (ad hoc connection)

Use this section if you want to connect the HP Photosmart to a wireless-capable computer without using a wireless router or access point.

There are two methods you may use to connect the HP Photosmart to your computer using an ad hoc wireless network connection. Once connected, you can install the HP Photosmart software.

Finish setting up the HP Photosmart

Add the HP Photosmart to a network 7

Chapter 2

▲ Turn on the wireless radio for the HP Photosmart and the wireless radio on your

computer. On your computer, connect to the network name (SSID) hpsetup, which is the default ad hoc network created by the HP Photosmart.

▲ Use an ad hoc network profile on your computer to connect to the product. If your

computer is not currently configured with an ad hoc network profile, consult the Help file for your computer Operating System for the proper method to create an ad hoc profile on your computer. Once the ad hoc network profile has been created, insert the installation CD that came with the product and install the software. Connect to the ad hoc network profile you created on your computer.

NOTE: An ad hoc connection can be used if you do not have a wireless router or

access point but do have a wireless radio on your computer. However, an ad hoc connection may result in a lower level of network security and possibly reduced performance when compared to an infrastructure network connection using a wireless router or access point.

To connect the HP Photosmart to a Windows computer with an ad hoc connection, the computer must have a wireless network adapter and an ad hoc profile. Create a network profile for a Windows Vista or Windows XP computer using the directions below.

NOTE: If you have an operating system other than Windows Vista or Windows XP,

HP recommends that you use the configuration program that came with your wireless LAN card. To find the configuration program for your wireless LAN card, access your computer's list of programs.

Finish setting up the HP Photosmart

To create a network profile

NOTE: The product comes configured with a network profile with hpsetup as the

network name (SSID). However, for security and privacy HP recommends you create a new network profile on your computer as described here.

1. In the Control Panel, double-click Network Connections.

2. On the Network Connections window, right-click the Wireless Network

Connection. If you see Enable on the pop-up menu, select it. Otherwise, if you see Disable on the menu, the wireless connection is already enabled.

3. Right-click the Wireless Network Connection icon, and then click Properties.

4. Click the Wireless Networks tab.

5. Select the Use Windows to configure my wireless network settings check box.

6. Click Add, and then do the following:

a.In Network name (SSID) box, type in a unique network name of your choice.

NOTE: The network name is case sensitive, so it is important to remember

any uppercase (capital) and lowercase (small) letters.

b. If there is a Network Authentication list, select Open. Otherwise, go to the next

step.

c.In the Data encryption list, select WEP. d. Make sure that the check box is not selected next to The key is provided for me

automatically. If it is selected, click the check box to clear it.

8 Finish setting up the HP Photosmart

e.In the Network key box, type a WEP key that has exactly 5 or exactly 13

alphanumeric (ASCII) characters. For example, if you enter 5 characters, you might enter ABCDE or 12345. Or, if you enter 13 characters, you might enter ABCDEF1234567. (12345 and ABCDE are examples only. Select a combination of your choosing.)

Alternatively, you can use HEX (hexadecimal) characters for the WEP key. A HEX WEP key must be 10 characters for 40 bit encryption, or 26 characters for 128 bit encryption.

f.In the Confirm network key box, type the same WEP key you typed in the

previous step.

NOTE: You must remember the exact uppercase (capital) and lowercase

(small) letters. If you enter your WEP key incorrectly on the product, the wireless connection will fail.

g. Write down the WEP key exactly as you typed it, including uppercase and

lowercase letters.

h. Select the check box for This is a computer-to-computer (ad hoc) network;

wireless access points are not used.

i. Click OK to close the Wireless network properties window, and then click OK

again.

j. Click OK again to close the Wireless Network Properties Connection window.

To connect the product

1. Insert the product Software CD in the computer CD-ROM drive.

2. Follow the instructions on the screen.

When you are prompted, connect the product to the computer using the USB setup cable included in the box. The product will attempt to connect to the network. If the connection fails, follow the prompts to correct the problem, and then try again.

3. When the setup is finished, you will be prompted to disconnect the USB cable and

test the wireless network connection. Once the product connects successfully to the network, install the software on each computer that will use the product over the network.

Related topics

“

Install the software for a network connection” on page 9

Install the software for a network connection

Use this section to install the HP Photosmart software on a computer connected to a network. Before you install the software, make sure you have connected the HP Photosmart to a network. If the HP Photosmart has not been connected to a network, follow the onscreen instructions during the software installation to connect the product to the network.

Finish setting up the HP Photosmart

Add the HP Photosmart to a network 9

Finish setting up the HP Photosmart

Chapter 2

NOTE: If your computer is configured to connect to a series of network drives, make

sure that your computer is currently connected to these drives before installing the software. Otherwise, the HP Photosmart software installer might try to use one of the reserved drive letters and you will not be able to access that network drive on your computer.

NOTE: Installation time can range from 20 to 45 minutes depending on your

operating system, the amount of available space, and the processor speed of your computer.

To install the Windows HP Photosmart Software on a networked computer

1. Quit all applications running on your computer.

2. Insert the Windows CD that came with the product into the CD-ROM drive on your

computer and follow the onscreen instructions.

NOTE: If the HP Photosmart is not connected to a network, when prompted,

connect the product to the computer using the USB setup cable included in the box. The product will then attempt to connect to the network.

3. If a dialog box about firewalls appears, follow the instructions. If you see firewall pop-

up messages, you must always accept or allow the pop-up messages.

4. On the Connection Type screen, select an appropriate option, and then click Next.

The Searching screen appears as the Setup program searches for the product on the network.

5. On the Printer Found screen, verify that the printer description is correct.

If more than one printer is found on the network, the Printers Found screen appears. Select the product you want to connect.

6. Follow the prompts to install the software.

When you have finished installing the software, the product is ready for use.

7. To test your network connection, go to your computer and print a self-test report to

the product.

Set up a Bluetooth connection

If you insert an HP Bluetooth Adapter (such as the HP bt500) into the front USB port, you can print to the HP Photosmart from Bluetooth devices such as PDAs, camera phones, and computers.

This section contains the following topics:

•“

What you need for a Bluetooth connection” on page 10 Connect the HP Photosmart to a computer using a Bluetooth® wireless

•“ connection” on page 11

Connect the HP Photosmart to other Bluetooth devices using a Bluetooth® wireless

•“ connection” on page 13

What you need for a Bluetooth connection

To connect the HP Photosmart with a Bluetooth connection, you will need the following:

10 Finish setting up the HP Photosmart

 A Bluetooth (compatible HCRP or SPP profile) capable device (such as a PDA,

camera phone, or computer)

 An HP Bluetooth Adapter

Some Bluetooth products exchange device addresses when they communicate with each other, so you might also need to find out the device address of the HP Photosmart in order to establish a connection.

To find out the device address of the product

1. Insert the HP Bluetooth Adapter into the front USB port.

2. On the Home Screen, touch the right arrow to view more options.

3. Touch Setup.

4. Touch Bluetooth.

5. Touch Device Address.

The Device Address appears, which is read only.

6. Make a note of the device address. You might need it later.

For information on printing to the HP Photosmart from Bluetooth devices using a Bluetooth connection, see:

Connect the HP Photosmart to a computer using a Bluetooth® wireless

•“ connection” on page 11

Connect the HP Photosmart to other Bluetooth devices using a Bluetooth® wireless

•“ connection” on page 13

Connect the HP Photosmart to a computer using a Bluetooth® wireless connection

A Bluetooth connection provides a quick and easy way to print images from a Bluetoothenabled computer without using a cable. With a Bluetooth connection you can access many of the same printing features as with a USB connection. For example, you can check the printer status, as well as the estimated amount of ink remaining in your ink cartridges.

NOTE: The only software functionality available with a Bluetooth connection is

printing. Scanning and software-based copying cannot be done over a Bluetooth connection. However, stand-alone copy functions are still available.

Before you print, you must connect an HP Bluetooth Adapter to the HP Photosmart.

You must have Windows Vista or Windows XP and either the Microsoft Bluetooth Protocol Stack or the Widcomm Bluetooth® Protocol Stack installed in order to connect the HP Photosmart. It is possible to have both the Microsoft Stack and the Widcomm Stack on your computer, but you use only one of them to connect the HP Photosmart.

Set up a Bluetooth connection 11

Finish setting up the HP Photosmart

Chapter 2

• Microsoft stack: If you have Windows Vista or Windows XP with Service Pack 2

installed on your computer, then your computer has the Microsoft Bluetooth Stack. The Microsoft stack allows you to install an external Bluetooth automatically. If your Bluetooth install automatically, then you do not have the Microsoft stack on your computer. Check the documentation that came with the Bluetooth

adapter supports the Microsoft stack but it does not

adapter to see if it supports

adapter

Protocol

the Microsoft stack.

• Widcomm stack: If you have an HP computer with Bluetooth

built in then your computer has the Widcomm stack. If you have an HP computer and plug in an HP Bluetooth Adapter, it will install automatically using the Widcomm stack.

To install and print using the Microsoft stack

1. Make sure that you have installed the product software on the computer.

NOTE: The purpose of installing the software is to make sure the printer driver

is available for the Bluetooth the software, you do not need to reinstall it. If you want both a USB and a Bluetooth

connection to the product, install the USB connection first. For more

connection. Therefore, if you have already installed

information, see the setup instructions. However, if you do not want a USB connection, select Directly to the computer on the Connection Type screen. Also, on the Connect Your Device Now screen, select the check box next to If

you are unable to connect your device now... at the bottom of the screen.

2. Attach an HP Bluetooth Adapter to the front USB port of the product.

3. If you are using an external Bluetooth

Finish setting up the HP Photosmart

computer is started and then attach the Bluetooth computer. If you have Windows Vista or Windows XP with Service Pack 2, the Bluetooth Bluetooth

If your computer has Bluetooth

drivers are installed automatically. If you are prompted to select a

profile, select HCRP.

adapter for your computer, make sure your

adapter to a USB port on the

built in, just make sure the computer is started.

4. On the Windows taskbar, click Start, and then click Printers and Faxes (or click

Control Panel, and then Printers).

5. Double-click the Add Printer icon (or click Add a printer).

6. Click Next, and then select A Bluetooth Printer.

7. Follow the onscreen instructions to finish the installation.

8. Print as you would to any printer.

12 Finish setting up the HP Photosmart

To install and print using the Widcomm stack

1. Make sure that you have installed the product software on the computer.

NOTE: The purpose of installing the software is to make sure the printer driver

is available for the Bluetooth the software, you do not need to reinstall it. If you want both a USB and a Bluetooth

connection to the product, install the USB connection first. For more

connection. Therefore, if you have already installed

you are unable to connect your device now... at the bottom of the screen.

2. Attach an HP Bluetooth Adapter to the front USB port.

3. Click the My Bluetooth Places icon on the desktop or in the taskbar.

4. Click View devices in range.

5. Once the available devices are discovered, double-click the name of the product to

finish the installation.

6. Print as you would to any printer.

Connect the HP Photosmart to other Bluetooth devices using a Bluetooth® wireless connection

You can print photos from any device with Bluetooth wireless technology. If you have a PDA or a mobile phone with Bluetooth wireless technology, you can connect an HP Bluetooth Adapter to the HP Photosmart and send photos to the product wirelessly. You can also print from other devices with Bluetooth wireless technology such as digital cameras and laptops.

To connect to and print from other Bluetooth devices

1. Make sure that you have installed the necessary software on the Bluetooth device.

2. Attach an HP Bluetooth Adapter to the front USB port.

3. Have the device search for available Bluetooth devices.

4. Once the available devices are discovered, select the name of the product.

NOTE: Some mobile phones need to be paired with the HP Photosmart before

you can print. The default passkey for pairing with the HP Photosmart is 0000.

5. Send the print job from the Bluetooth device to the product. See the documentation

for your Bluetooth device for specific instructions on starting a print job.

Set up a Bluetooth connection 13

Finish setting up the HP Photosmart

Chapter 2

Finish setting up the HP Photosmart

14 Finish setting up the HP Photosmart

3 Get to know the HP Photosmart

• Printer parts Control panel features

•

Printer parts

• Front view of the HP Photosmart

Get to know the HP Photosmart 15

Get to know the HP Photosmart

Chapter 3

1 Lid

2 Color graphics display (also referred to as the display)

3 Photo tray

4 Memory Card slots LED

5 Memory Card slot for Secure Digital and XD cards

6 Memory Card slot for Memory Stick cards

7 Front USB port for your PictBridge-compatible digital camera, other storage devices, and

external Bluetooth adapter.

8 Output tray

9 Paper tray extender (also referred to as the tray extender)

10 Paper-width guide for the photo tray

11 Cartridge door access handle

12 Lid backing

13 Glass

14 On button: Turns the product on or off. When the product is off, a minimal amount of

power is still used. To completely remove power, turn off the product, and then unplug the power cord.

15 Wireless LED

16 Paper-width guide for the main tray

17 Main tray (also referred to as the input tray)

18 Cartridge door

• Top and rear views of the HP Photosmart

16 Get to know the HP Photosmart

19 Cartridge access area

20 Printhead assembly

21 Model number location

22 Rear USB port

23 Power connection (Use only with the power adapter supplied by HP.)

Printer parts 17

Get to know the HP Photosmart

Chapter 3

Control panel features

Figure 3-1 Control panel features

1 Scan: Opens the Scan To menu where you can select a destination for your scan.

2 Copy: Opens the Copy menu where you can select a copy type or change the copy settings.

3 Directional keys: Allow you to navigate through photos and menu options. Touch the right

arrow button to access the secondary Home screen.

4 Photo: Opens the Photo Menu.

5 Help: Opens the Help Menu on the display where you can select a topic to learn more about

it. From the Home screen, touching Help lists the topics for which help is available. Depending on the topic you select, the topic will appear on the display or on your computer screen. When viewing screens other than the Home screen, the Help button provides help applicable to the current screen.

6 Home: Returns to the Homescreen (the default screen when you turn on the product).

7 Quick Forms: Prints a variety of blank forms, such as school paper, music paper, mazes,

and checklists.

Get to know the HP Photosmart

8 Setup: Opens the Setup menu where you can change product settings and perform

maintenance functions.

9 Back: Returns to the previous screen on the display.

10 Ink: Opens the Estimated Ink Levels screen.

11 Wireless: Opens the Wireless Summary screen where you can find the host name, IP

address, and the SSID for the product.

12 Cancel: Stops the current operation.

18 Get to know the HP Photosmart

4 How do I?

This section contains links to commonly performed tasks, such as printing photos, scanning, and making copies.

“Print photos from a memory card or USB

•

storage device” on page 31 “Print a creative project” on page 35

•

“Save photos” on page 59

•

“Load media” on page 23

•

“Replace the cartridges” on page 62

•

“Scan to a computer” on page 45

•

“Scan to a memory card or USB storage

•

device” on page 46

How do I?

How do I? 19

Chapter 4

How do I?

20 How do I?

5 Paper basics

You can load many different types and sizes of paper in the HP Photosmart, including letter or A4 paper, photo paper, transparencies, and envelopes.

By default, the HP Photosmart is set to detect the size and type of paper you load in the input tray automatically and then adjust its settings to generate the highest quality output for that paper. If you are using special papers, such as photo paper, transparency film, envelopes, or labels, or if you experience poor print quality using the automatic setting, you can manually set the paper size and type for print and copy jobs.

This section contains the following topics:

•“

Recommended papers for photo printing” on page 21 Recommended papers for printing” on page 22

•“

Load media” on page 23

•“

Information on paper” on page 27

•“

Related topics

Information on paper” on page 27

“

Information on paper

The HP Photosmart is designed to work well with most paper types. Test a variety of paper types before buying a large quantity. Find a paper type that works well and is easy to purchase. HP papers are designed for the best quality results. In addition, follow these tips:

• Do not use paper that is too thin, that has a slick texture, or that stretches easily. It

can feed incorrectly through the paper path, causing paper jams.

• Store photo media in its original packaging inside a resealable plastic bag on a flat

surface in a cool, dry place. When you are ready to print, remove only the paper you plan to use immediately. When you have finished printing, return any unused photo paper to the plastic bag.

• Do not leave unused photo paper in the input tray. The paper might start to curl, which

might reduce the quality of your printouts. Curled paper can also cause paper jams.

• Always hold photo paper by the edges. Fingerprints on photo paper can reduce print

quality.

• Do not use paper that is heavily textured. It can cause graphics or text to print

improperly.

• Do not combine different paper types and paper sizes in the input tray; the entire stack

of paper in the input tray must be the same size and type.

• For best results, do not allow printed photos to stack up in the output tray.

• Store printed photos under glass or in a storage book to prevent bleeding over time

from high humidity.

Paper basics

Information on paper 27

Paper basics

Chapter 5

28 Paper basics

6Print

“Print documents” on page 29

“Print photos” on page 30

“Print a creative project” on page 35

“Print a Web page” on page 39

“Print forms and templates (Quick Forms)” on page 39

Related topics

Load media” on page 23

•“

Recommended papers for photo printing” on page 21

•“

Recommended papers for printing” on page 22

•“

Print documents

Most print settings are automatically handled by the software application. You need to change the settings manually only when you change print quality, print on specific types of paper or transparency film, or use special features.

To print from a software application

1. Make sure you have paper loaded in the input tray.

2. On the File menu in your software application, click Print.

3. Make sure the product is the selected printer.

4. If you need to change settings, click the button that opens the Properties dialog box.

Depending on your software application, this button might be called Properties, Options, Printer Setup, Printer, or Preferences.

NOTE: When printing a photo, you must select options for the specific photo

paper and photo enhancement.

Print

Print 29

Chapter 6

5. Select the appropriate options for your print job by using the features available in the

Advanced, Printing Shortcuts, Features, and Color tabs.

TIP: You can easily select the appropriate options for your print job by choosing

one of the predefined print tasks on the Printing Shortcuts tab. Click a type of print task in the Printing Shortcuts list. The default settings for that type of print task are set and summarized on the Printing Shortcuts tab. If necessary, you can adjust the settings here and save your custom settings as a new printing shortcut. To save a custom printing shortcut, select the shortcut and click Save

As. To delete a shortcut, select the shortcut and click Delete.

6. Click OK to close the Properties dialog box.

7. Click Print or OK to begin printing.

Related topics

Recommended papers for printing” on page 22

•“

Load media” on page 23

•“

View the print resolution” on page 41

•“

Use printing shortcuts” on page 41

•“

Set the default print settings” on page 42

•“

Stop the current job” on page 115

•“

Print photos

•“Print photos saved on your computer” on page 30

Print photos from a memory card or USB storage device” on page 31

•“

Print photos saved on your computer

To print a photo on photo paper

1. Load up to 13 x 18 cm (5 x 7 inch) paper in the photo tray or full-size photo paper in

the main input tray.

2. Slide the paper-width guide inward until it stops at the edge of the paper.

3. On the File menu in your software application, click Print.

4. Make sure the product is the selected printer.

5. Click the button that opens the Properties dialog box.

Depending on your software application, this button might be called Properties, Options, Printer Setup, Printer, or Preferences.

6. Click the Features tab.

7. In the Basic Options area, from the Paper Type drop-down list, select More. Then,

select the appropriate photo paper type.

8. In the Resizing Options area, from the Size drop-down list, select More. Then, select

the appropriate paper size. If the paper size and paper type are not compatible, the printer software displays an

alert and allows you to select a different type or size.

30 Print

9. (Optional) Select the Borderless printing check box if it is not already checked.

If the borderless paper size and paper type are not compatible, the product software displays an alert and allows you to select a different type or size.

10. In the Basic Options area, select a high print quality, such as Best, from the Print

Quality drop-down list.

NOTE: To achieve the highest dpi resolution, you can use the Maximum dpi

setting with supported types of photo paper. If Maximum dpi is not listed in the Print quality drop-down list, you can enable it from the Advanced tab. For more information, see “

Print using the maximum dpi” on page 40.

11. In the HP Real Life Technologies area, click the Photo fix drop-down list and select

from the following options:

• Off: applies no HP Real Life Technologies to the image.

• Basic: enhances low-resolution images; moderately adjusts image sharpness.

12. Click OK to return to the Properties dialog box.

13. Click OK, and then click Print or OK in the Print dialog box.

NOTE: Do not leave unused photo paper in the input tray. The paper might start to

curl, which could reduce the quality of your printout. For best results, do not allow printed photos to stack up in the output tray.

Related topics

Recommended papers for photo printing” on page 21

•“

Load media” on page 23

•“

Print using the maximum dpi” on page 40

•“

View the print resolution” on page 41

•“

Use printing shortcuts” on page 41

•“

Set the default print settings” on page 42

•“

Stop the current job” on page 115

•“

Print photos from a memory card or USB storage device

1. Do one of the following:

Print photo on small-size paper a. Load paper.

 Load up to 13 x 18 cm (5 x 7 inch) photo paper in photo tray.

b. Insert memory device.

Print photos 31

Chapter 6

1 Memory Stick, Memory Stick Pro, Memory Stick Select, Memory Stick Magic Gate,

Memory Stick Duo or Pro Duo (adapter optional), Memory Stick Pro-HG Duo (adapter optional), or Memory Stick Micro (adapter required)

2 MultiMediaCard (MMC), MMC Plus, Secure MultiMedia Card, MMC Mobile (RS-MMC;

adapter required), Secure Digital (SD), Secure Digital Mini (adapter required), Secure Digital High Capacity (SDHC), TransFlash MicroSD Card (adapter required), or xDPicture card and FAT-12,FAT-16,FAT-32,HFS+

3 Front USB port/Pictbridge: For digital cameras and removable drives

c. Select photo.

Touch View & Print.  Touch left or right arrow to scroll through photos.  Touch photo you want to print.  Touch up arrow to increase number of copies.

d. Print photo.

Touch Print to preview print job. Touch Print.

Print photo on full-size paper a. Load paper.

 Load full-size paper in the main input tray.

b. Insert memory device.

32 Print

1 Memory Stick, Memory Stick Pro, Memory Stick Select, Memory Stick Magic Gate,

Memory Stick Duo or Pro Duo (adapter optional), Memory Stick Pro-HG Duo (adapter optional), or Memory Stick Micro (adapter required)

2 MultiMediaCard (MMC), MMC Plus, Secure MultiMedia Card, MMC Mobile (RS-MMC;

3 Front USB port/Pictbridge: For digital cameras and removable drives

c. Select photo.

 Touch View & Print.  Touch left or right arrow to scroll through photos.  Touch photo you want to print.  Touch up arrow to increase number of copies.

d. Change page layout.

 Touch Print to preview print job.  Touch Options to change print settings.  Touch Print Layout.  Touch 8.5 x 11.  Touch Back.

e. Print photo.

 Touch Print.

Print multiple photos on full-size paper a. Load paper.

 Load full-size paper in the main input tray.

Print photos 33

Chapter 6

b. Insert memory device.

1 Memory Stick, Memory Stick Pro, Memory Stick Select, Memory Stick Magic Gate,

Memory Stick Duo or Pro Duo (adapter optional), Memory Stick Pro-HG Duo (adapter optional), or Memory Stick Micro (adapter required)

2 MultiMediaCard (MMC), MMC Plus, Secure MultiMedia Card, MMC Mobile (RS-MMC;

3 Front USB port/Pictbridge: For digital cameras and removable drives

c. Select photo.

Touch View & Print.  Touch left or right arrow to scroll through photos.  Touch photo you want to print.  Touch up arrow to increase number of copies.

d. Change page layout.

Touch Print to preview print job. Touch Options to change print settings. Touch Print Layout.

34 Print

 Touch 3.5 x 5 on 8.5 x 11.  Touch Back.

e. Print photo.

 Touch Print.

2. View the animation for this topic.

Related topics

Recommended papers for photo printing” on page 21

•“

Edit photos before printing” on page 43

•“

Stop the current job” on page 115

•“

Print a creative project

1. Do one of the following:

Print album pages a. Load paper.

 Load up to 13 x 18 cm (5 x 7 inch) photo paper in photo tray or full-size photo

paper in main input tray.

b. Insert memory device.

1 Memory Stick, Memory Stick Pro, Memory Stick Select, Memory Stick Magic Gate,

Memory Stick Duo or Pro Duo (adapter optional), Memory Stick Pro-HG Duo (adapter optional), or Memory Stick Micro (adapter required)

2 MultiMediaCard (MMC), MMC Plus, Secure MultiMedia Card, MMC Mobile (RS-MMC;

3 Front USB port/Pictbridge: For digital cameras and removable drives

Print a creative project 35

Chapter 6

c. Select project type.

Touch Create. Touch Album Pages.

d. Select photo.

 Touch right arrow to scroll through photos.  Touch up arrow to increase number of copies. Touch Done.

e. Print photo.

Touch Print.

Print panoramic photos a. Load paper.

 Load 10 x 30 cm (4 x 12 inch) panorama paper in the main input tray.

b. Insert memory device.

36 Print

1 Memory Stick, Memory Stick Pro, Memory Stick Select, Memory Stick Magic Gate,

Memory Stick Duo or Pro Duo (adapter optional), Memory Stick Pro-HG Duo (adapter optional), or Memory Stick Micro (adapter required)

2 MultiMediaCard (MMC), MMC Plus, Secure MultiMedia Card, MMC Mobile (RS-MMC;

3 Front USB port/Pictbridge: For digital cameras and removable drives

c. Select project type.

 Touch Create.  Touch Panorama Prints.

d. Select photo.

 Touch arrow to scroll through the photos and then select photo.  Touch up arrow to increase number of copies.  Touch Done to preview print job.

e. Print photo.

 Touch Print.

Print wallet photos a. Load paper.

 Load up to 13 x 18 cm (5 x 7 inch) photo paper in photo tray or full-size photo

paper in main input tray.

b. Insert memory device.

1 Memory Stick, Memory Stick Pro, Memory Stick Select, Memory Stick Magic Gate,

Memory Stick Duo or Pro Duo (adapter optional), Memory Stick Pro-HG Duo (adapter optional), or Memory Stick Micro (adapter required)

2 MultiMediaCard (MMC), MMC Plus, Secure MultiMedia Card, MMC Mobile (RS-MMC;

3 Front USB port/Pictbridge: For digital cameras and removable drives

c. Select project type.

 Touch Create.  Touch Wallet Photos.

Print a creative project 37

Chapter 6

d. Select photo.

 Touch arrow to scroll through the photos and then select photo.  Touch up arrow to increase number of copies. Touch Done to preview print job.

e. Print photo.

Touch Print.

Print passport photos a. Load paper.

 Load up to 13 x 18 cm (5 x 7 inch) photo paper in photo tray or full-size photo

paper in main input tray.

b. Insert memory device.

38 Print

1 Memory Stick, Memory Stick Pro, Memory Stick Select, Memory Stick Magic Gate,

Memory Stick Duo or Pro Duo (adapter optional), Memory Stick Pro-HG Duo (adapter optional), or Memory Stick Micro (adapter required)

2 MultiMediaCard (MMC), MMC Plus, Secure MultiMedia Card, MMC Mobile (RS-MMC;

3 Front USB port/Pictbridge: For digital cameras and removable drives

c. Select project type.

Touch Create. Touch Passport Photos.

d. Select photo.

 Touch arrow to scroll through the photos and then select photo.  Touch up arrow to increase number of copies.  Touch Done to preview print job.

e. Print photo.

 Touch Print.

2. View the animation for this topic.

Related topics

Recommended papers for photo printing” on page 21

•“

Edit photos before printing” on page 43

•“

Stop the current job” on page 115

•“

Print a Web page

You can print a Web page from your Web browser on the HP Photosmart.

If you use Internet Explorer 6.0 or higher for Web browsing, you can use HP Smart Web Printing to ensure simple, predictable web printing with control over what you want and how you want it printed. You can access HP Smart Web Printing from the toolbar in Internet Explorer. For more information about HP Smart Web Printing, see the help file provided with it.

To print a Web page

1. Make sure you have paper loaded in the main input tray.

2. On the File menu in your Web browser, click Print.

The Print dialog box appears.

3. Make sure the product is the selected printer.

4. If your Web browser supports it, select the items on the Web page that you want to

include in the printout. For example, in Internet Explorer, click the Options tab to select options such as As

laid out on screen, Only the selected frame, and Print all linked documents.

5. Click Print or OK to print the Web page.

TIP: To print Web pages correctly, you might need to set your print orientation to

Landscape.

Print forms and templates (Quick Forms)

The HP Photosmart contains built-in templates that enable you to print common forms, such as narrow or wide ruled notebook paper, graph paper, task checklists, calendars (not supported on all models), and music sheets on plain letter- or A4-size paper. You can also print games such as dots and fun mazes, which have a different pattern each time you print them.

Print forms and templates (Quick Forms)39

Chapter 6

To print forms from the control panel

1. Make sure you have paper loaded in the input tray.

2. On the Home Screen, touch the right arrow to view more options.

3. Touch Quick Forms.

4. Touch the up or down arrow to scroll through the forms and templates.

5. Touch the form you want to print.

6. If prompted, select the type of form to print.

7. Touch the up arrow to increase the number of copies, and then touch Done.

Print using the maximum dpi

Use maximum dpi mode to print high-quality, sharp images.

To get the most benefit from maximum dpi mode, use it to print high-quality images such as digital photographs. When you select the maximum dpi setting, the printer software displays the optimized dots per inch (dpi) that the HP Photosmart printer will print. Printing in maximum dpi is supported on the following paper-types only:

• HP Premium Plus Photo Paper

• HP Premium Photo Paper

• HP Advanced Photo Paper

• Photo Hagaki cards

Printing in maximum dpi takes longer than printing with other settings and requires a large amount of disk space.

40 Print

To print in Maximum dpi mode

1. Make sure you have paper loaded in the input tray.

2. On the File menu in your software application, click Print.

3. Make sure the product is the selected printer.

4. Click the button that opens the Properties dialog box.

Depending on your software application, this button might be called Properties, Options, Printer Setup, Printer, or Preferences.

5. Click the Advanced tab.

6. In the Features area, select the Enable maximum dpi setting check box.

7. Click the Features tab.

8. In the Paper Type drop-down list, click More, and then select the appropriate paper

type.

9. In the Print Quality drop-down list, click Maximum dpi.

NOTE: To find out what dpi the product will print based on the paper type and

print quality settings you selected, click Resolution.

10. Select any other print settings that you want, and then click OK.

Related topics

View the print resolution” on page 41

“

View the print resolution

The printer software displays the print resolution in dots per inch (dpi). The dpi varies according to the paper type and print quality that you select in the printer software.

To view the print resolution

1. Make sure you have paper loaded in the input tray.

2. On the File menu in your software application, click Print.

3. Make sure the product is the selected printer.

4. Click the button that opens the Properties dialog box.

Depending on your software application, this button might be called Properties, Options, Printer Setup, Printer, or Preferences.

5. Click the Features tab.

6. In the Paper Type drop-down list, select the type of paper that you have loaded.

7. In the Print Quality drop-down list, select the appropriate print quality setting for your

project.

8. Click the Resolution button to view the print resolution dpi for the paper type and

print quality combination you selected.

Use printing shortcuts

Use printing shortcuts to print with print settings that you use often. The printer software has several specially designed printing shortcuts that are available in the Printing Shortcuts list.

NOTE: When you select a printing shortcut the appropriate printing options are

automatically displayed. You can leave them as is, change them, or create your own shortcuts for commonly used tasks.

Use the Printing Shortcuts tab for the following print tasks:

• General Everyday Printing: Print documents quickly.

• Photo Printing–Borderless: Print to the top, bottom, and side edges of 10 x 15 cm

(4 x 6 inch) and 13 x 18 cm (5 x 7 inch) HP Photo Papers.

• Paper-saving Printing: Print two-sided documents with mutliple pages on same

sheet to reduce paper usage.

• Photo Printing–With White Borders: Print a photo with a white border around the

edges.

• Fast/Economical Printing: Produce draft-quality printouts quickly.

• Presentation Printing: Print high-quality documents, including letters and

transparencies.

To create a printing shortcut

1. On the File menu in your software application, click Print.

2. Make sure the product is the selected printer.

Use printing shortcuts 41

Chapter 6

3. Click the button that opens the Properties dialog box.

Depending on your software application, this button might be called Properties,

Options, Printer Setup, Printer, or Preferences.

4. Click the Printing Shortcuts tab.

5. In the Printing Shortcuts list, click a printing shortcut.

The print settings for the selected printing shortcut are displayed.

6. Change the print settings to those you want in the new printing shortcut.

7. Click Save as and type a name for the new printing shortcut, and then click Save.

The printing shortcut is added to the list.

To delete a printing shortcut

1. On the File menu in your software application, click Print.

2. Make sure the product is the selected printer.

3. Click the button that opens the Properties dialog box.

Depending on your software application, this button might be called Properties, Options, Printer Setup, Printer, or Preferences.

4. Click the Printing Shortcuts tab.

5. In the Printing Shortcuts list, click the printing shortcut that you want to delete.

6. Click Delete.

The printing shortcut is removed from the list.

NOTE: Only the shortcuts that you have created can be deleted. The original HP

shortcuts cannot be deleted.

Set the default print settings

If there are settings that you frequently use for printing, you might want to make them the default print settings so they are already set when you open the Print dialog box from within your software application.

To change the default print settings

1. In the HP Solution Center, click Settings, point to Print Settings, and then click

Printer Settings.

42 Print

2. Make changes to the print settings, and click OK.

Edit photos before printing

1. Do one of the following:

Rotate photo a. Select photo.

 Touch View & Print.  Touch left or right arrow to scroll through photos.  Touch photo you want to rotate.

b. Edit photo.

 Touch Edit.  Touch Rotate.  Touch Done.

Crop photo a. Select photo.

 Touch View & Print.  Touch left or right arrow to scroll through photos.  Touch photo you want to crop.

b. Edit photo.

 Touch Edit.  Touch Crop.

Photo fix a. Select photo.

 Touch View & Print.  Touch left or right arrow to scroll through photos.  Touch photo you want to photo fix.

b. Edit photo.

 Touch Edit.  Touch Photo Fix.  Select desired option.

Add frame a. Select photo.

 Touch View & Print.  Touch left or right arrow to scroll through photos.  Touch photo you want to add frame.

b. Edit photo.

 Touch Edit.  Touch Add Frame.  Select desired option.

Edit photos before printing 43

Chapter 6

Adjust brightness a. Select photo.

Touch View & Print.  Touch left or right arrow to scroll through photos.  Touch photo you want to adjust brightness.

b. Edit photo.

Touch Edit. Touch Brightness.  Set brightness and touch Done.

Color effect a. Select photo.

Touch View & Print.  Touch left or right arrow to scroll through photos.  Touch photo you want to add color effect.

b. Edit photo.

Touch Edit. Touch Color Effect.  Select desired option.

2. View the animation for this topic.

44 Print

7 Scan

•“Scan to a computer” on page 45 Scan to a memory card or USB storage device” on page 46

•“ Scan and reprint photos” on page 57

•“

Scan to a computer

To scan to a computer

1. Load original.

a. Lift lid on product.

b. Load original print side down on right front corner of glass.

Scan

Scan 45

Chapter 7

c.Close lid.

2. Start scan.

a.Touch Scan on Home screen.

The Scan To menu appears.

b.Touch Computer.

If product is network-connected, a list of available computers appears. Select computer to which you want to transfer to start the scan.

3. Touch job shortcut you want to use.

4. View the animation for this topic.

Related topics

Stop the current job” on page 115

“

Scan to a memory card or USB storage device

NOTE: You can send the scanned image as a JPEG image to the memory card or

storage device that is currently inserted. This enables you to use the photo print options to print borderless prints and album pages from the scanned image.

1. Do one of the following:

Save a scan to memory card a. Load original.

 Lift lid on product.

Scan

46 Scan

 Load original print side down on right front corner of glass.

Close lid.

b. Insert memory device.

1 Memory Stick, Memory Stick Pro, Memory Stick Select, Memory Stick Magic Gate,

Memory Stick Duo or Pro Duo (adapter optional), Memory Stick Pro-HG Duo (adapter optional), or Memory Stick Micro (adapter required)

2 MultiMediaCard (MMC), MMC Plus, Secure MultiMedia Card, MMC Mobile (RS-MMC;

adapter required), Secure Digital (SD), Secure Digital Mini (adapter required), Secure Digital High Capacity (SDHC), TransFlash MicroSD Card (adapter required), or xDPicture card

3 Front USB port/Pictbridge: For digital cameras and removable drives

c. Start scan.

 Touch Scan on Home screen.

The Scan To menu appears.

 Touch Memory Card.

Scan

Scan to a memory card or USB storage device 47

Chapter 7

Save a scan to USB drive a. Load original.

 Lift lid on product.

 Load original print side down on right front corner of glass.

Scan

48 Scan

Close lid.

b. Insert memory device.

1 Memory Stick, Memory Stick Pro, Memory Stick Select, Memory Stick Magic Gate,

Memory Stick Duo or Pro Duo (adapter optional), Memory Stick Pro-HG Duo (adapter optional), or Memory Stick Micro (adapter required)

2 MultiMediaCard (MMC), MMC Plus, Secure MultiMedia Card, MMC Mobile (RS-MMC;

adapter required), Secure Digital (SD), Secure Digital Mini (adapter required), Secure Digital High Capacity (SDHC), TransFlash MicroSD Card (adapter required), or xDPicture card

3 Front USB port/Pictbridge: For digital cameras and removable drives

c. Start scan.

 Touch Scan on Home screen.

The Scan To menu appears.

 Touch USB Drive.

2. View the animation for this topic.

Related topics

Stop the current job” on page 115

“

Scan to a memory card or USB storage device 49

Scan

Chapter 7

Scan

50 Scan

8Copy

•“Copy text or mixed documents” on page 51 Copy photos (reprint)” on page 57

•“

Copy text or mixed documents

1. Do one of the following:

Make a black and white copy a. Load paper.

 Load full-size paper in main input tray.

b. Load original.

 Lift lid on product.

Copy

TIP: To make copies of thick originals, such as books, you can remove

the lid.

 Load original print side down on right front corner of glass.

Copy 51

Copy

Chapter 8

Close lid.

c. Select Copy.

Touch Copy on Home screen.

The Copy menu appears.

 Touch up arrow to increase number of copies. Touch Settings.

The Copy Settings menu appears. Touch Size. Touch Fit to Page.

d. Start copy.

Touch Black Copy.

52 Copy

Make a color copy a. Load paper.

 Load full-size paper in main input tray.

b. Load original.

 Lift lid on product.

TIP: To make copies of thick originals, such as books, you can remove

the lid.

 Load original print side down on right front corner of glass.

Close lid.

c. Select Copy.

 Touch Copy on Home screen.

The Copy menu appears.

 Touch up arrow to increase number of copies.  Touch Settings.

The Copy Settings menu appears.  Touch Size.  Touch Fit to Page.

d.Start copy.

 Touch Color Copy.

2. View the animation for this topic.

Copy

Copy text or mixed documents 53

Chapter 8

Related topics

Change the copy settings” on page 54

•“ Preview a copy before printing” on page 55

•“ Stop the current job” on page 115

•“

Change the copy settings

To set the number of copies from the control panel

Copy

1. Touch Copy on the Home screen.

The Copy menu appears.

2. Touch up arrow button to increase number of copies.

To set the paper size from the control panel

1. Touch Copy on the Home screen.

The Copy menu appears.

2. Touch Settings.

3. Touch Paper Size.

4. Select the desired copy size.

To set the paper type for copies

1. Touch Copy on the Home screen.

The Copy menu appears.

2. Touch Settings.

3. Touch Paper Type.

4. Select the desired paper type.

Refer to the following table to determine which paper type setting to choose based on the paper loaded in the input tray.

54 Copy

Paper type Control panel setting

Copier paper or letterhead Plain Paper

HP Bright White Paper Plain Paper

HP Premium Plus Photo Paper, Glossy Premium Photo

HP Premium Plus Photo Paper, Matte Premium Photo

HP Premium Plus 10 x 15 cm (4 x 6 inch) Photo Paper

HP Photo Paper Photo Paper

HP Everyday Photo Paper Everyday Photo

HP Everyday Photo Paper, Semi Gloss Everyday Matte

HP Premium Paper Premium Inkjet

Other inkjet paper Premium Inkjet

Premium Photo

Paper type Control panel setting

HP Professional Brochure & Flyer Paper (Glossy)

HP Professional Brochure & Flyer Paper (Matte)

HP Premium or Premium Plus Inkjet Transparency Film

Other transparency film Transparency

Plain Hagaki Plain Paper

Glossy Hagaki Premium Photo

L (Japan only) Premium Photo

Advanced Photo Paper Advanced Photo

Brochure Glossy

Brochure Matte

Transparency

To change the copy quality from the control panel

1. Touch Copy on the Home screen.

The Copy menu appears.

2. Touch Settings.

3. Touch Quality.

4. Select the desired copy quality.

To adjust the copy contrast from the control panel

1. Touch Copy on the Home screen.

The Copy menu appears.

2. Touch Settings.

3. Touch Lighter/Darker.

4. Set the contrast as desired, and then touch Done.

Copy

Preview a copy before printing

After changing settings on the HP Photosmart for making a copy, you can preview an image of the expected output on the display before starting the copy.

NOTE: To ensure an accurate preview, change the paper size and type to reflect

the actual paper you have loaded in the input tray. If you use the Automatic settings, the onscreen preview might not accurately represent the output. Instead, the preview will reflect what the output would be if the default paper type and size were loaded in the input tray.

Previews appear when you select Preview on the Copy menu, or when you use the crop feature to specify a specific area of the original to copy.

Preview a copy before printing 55

Copy

Chapter 8

To preview your copy from the control panel

1. Touch Copy on the Home screen.

The Copy menu appears.

2. Touch Settings.

3. Change copy settings on the product to accurately reflect the copy you want to make.

4. Touch Preview.

An image on the display shows how your copy will print.

Related topics

Change the copy settings” on page 54

“

56 Copy

9 Reprint photos

To reprint an original photo

1. Load original.

a. Lift lid on product.

b. Load original print side down on right front corner of glass.

Reprint photos

c.Close lid.

2. Load paper.

▲ Load up to 13 x 18 cm (5 x 7 inch) paper in photo tray or full-size photo paper in

main input tray.

3. Reprint photo.

a. Touch Scan on Home screen.

The Scan To menu appears. b. Touch Reprint Photo. c. Touch OK. d. Touch desired paper size.

Reprint photos 57

Reprint photos

Chapter 9

e. Touch up arrow to increase number of copies. f.Touch Print.

4. View the animation for this topic.

Related topics

Stop the current job” on page 115

“

58 Reprint photos

10 Save photos

• Save photos to your computer Back up photos to a USB storage device

•

Save photos to your computer

To save photos

1. Insert memory device.

1 Memory Stick, Memory Stick Pro, Memory Stick Select, Memory Stick Magic Gate,

Memory Stick Duo or Pro Duo (adapter optional), Memory Stick Pro-HG Duo (adapter optional), or Memory Stick Micro (adapter required)

2 MultiMediaCard (MMC), MMC Plus, Secure MultiMedia Card, MMC Mobile (RS-MMC;

adapter required), Secure Digital (SD), Secure Digital Mini (adapter required), Secure Digital High Capacity (SDHC), TransFlash MicroSD Card (adapter required), or xD-Picture card and FAT-12,FAT-16,FAT-32,HFS+

3 Front USB port/Pictbridge: For digital cameras and removable drives

2. Connect to computer.

3. Save photos.

a. Touch Save. b. Follow onscreen prompts on computer to save photos to computer.

4. View the animation for this topic.

Related topics

Stop the current job” on page 115

“

Save photos 59

Save photos

Chapter 10

Back up photos to a USB storage device

To back up photos

1. Insert memory device.

a. Insert a memory card into appropriate slot on product.

1 Memory Stick, Memory Stick Pro, Memory Stick Select, Memory Stick Magic Gate,

Memory Stick Duo or Pro Duo (adapter optional), Memory Stick Pro-HG Duo (adapter optional), or Memory Stick Micro (adapter required)

2 MultiMediaCard (MMC), MMC Plus, Secure MultiMedia Card, MMC Mobile (RS-MMC;

3 Front USB port/Pictbridge: For digital cameras and removable drives

Save photos

60 Save photos

b. When photo light stops flashing, connect a storage device to the front USB port.

2. Save photos.

▲ Touch OK when prompted to back up card.

3. Remove memory device.

4. View the animation for this topic.

Related topics

Stop the current job” on page 115

“

11 Maintain the HP Photosmart

• Check the estimated ink levels Order ink supplies

• Replace the cartridges

• Cartridge warranty information

• Print and evaluate a print quality report

•

Check the estimated ink levels

You can easily check the ink supply level to determine how soon you might need to replace a cartridge. The ink supply level shows an estimate of the amount of ink remaining in the cartridges.

NOTE: If you have installed a refilled or remanufactured cartridge, or a cartridge that

has been used in another printer, the ink level indicator might be inaccurate or unavailable.

NOTE: Ink level warnings and indicators provide estimates for planning purposes

only. When you receive a low-ink warning message, consider having a replacement cartridge available to avoid possible printing delays. You do not have to replace the cartridges until the print quality is unacceptable.

NOTE: Ink from the cartridges is used in the printing process in a number of different

ways, including in the initialization process, which prepares the product and cartridges for printing, and in printhead servicing, which keeps print nozzles clear and ink flowing smoothly. In addition, some residual ink is left in the cartridge after it is used. For more information, see

www.hp.com/go/inkusage.

To check the ink levels from the control panel

1. On the Home screen, touch the right arrow to view more options.

2. Touch Ink.

The HP Photosmart displays a gauge that shows the estimated ink levels of all cartridges installed.

Maintain the HP Photosmart 61

Maintain the HP Photosmart

Chapter 11

To check the ink levels from the HP Photosmart Software

1. In the HP Solution Center, click Settings, point to Print Settings, and then click

Printer Toolbox.

NOTE: You can also open the Printer Toolbox from the Print Properties dialog

box. In the Print Properties dialog box, click the Features tab, and then click the Printer Services button.

The Printer Toolbox appears.

2. Click the Estimated Ink Level tab.

The estimated ink levels for the ink cartridges appear.

Related topics

“

Order ink supplies” on page 62

Order ink supplies

To learn which HP supplies work with your product, order supplies online, or create a printable shopping list, open HP Solution Center, and select the online shopping feature.

Cartridge information and links to online shopping also appear on ink alert messages. In addition, you can find cartridge information and order online by visiting

supplies.

NOTE: Ordering cartridges online is not supported in all countries/regions. If it is not

supported in your country/region, contact a local HP reseller for information about purchasing cartridges.

www.hp.com/buy/

Replace the cartridges

To replace the cartridges

1. Check that power is on.

2. Remove cartridge.

a. Open cartridge access door.

Maintain the HP Photosmart

62 Maintain the HP Photosmart

Wait for print carriage to move to center of product.

b. Press tab on cartridge, then remove it from slot.

3. Insert new cartridge.

a. Remove cartridge from packaging.

b. Twist orange cap to snap it off. A forceful twist may be required to remove cap.

Replace the cartridges 63

Maintain the HP Photosmart

Chapter 11

c. Match color icons, then slide cartridge into slot until it clicks into place.

d. Close cartridge door.

4. Align cartridges.

a. When prompted, touch OK to print cartridge alignment page. b. Load page print side down on right front corner of glass, and then touch OK to

scan page.

c. Remove alignment page and recycle or discard it.

5. View the animation for this topic.

Related topics

Order ink supplies” on page 62

“

Cartridge warranty information

Maintain the HP Photosmart

The HP cartridge warranty is applicable when the product is used in its designated HP printing device. This warranty does not cover HP ink products that have been refilled, remanufactured, refurbished, misused, or tampered with.

During the warranty period the product is covered as long as the HP ink is not depleted and the end of warranty date has not been reached. The end of warranty date, in YYYY/ MM/DD format, may be found on the product as indicated:

64 Maintain the HP Photosmart

For a copy of the HP Limited Warranty Statement, see the printed documentation that came with the product.

Print and evaluate a print quality report

Print quality issues can occur for a variety of reasons. You might be using the wrong software settings or printing a poor quality source file, or there might be a problem with the printing system in the HP Photosmart. If you are unhappy with the quality of your prints, you can print a print quality report to help you determine if the printing system is working properly.

To print a print quality report

1. Load letter or A4 unused plain white paper into the input tray.

2. On the Home screen, touch the right arrow to view more options.

3. Touch Setup.

4. Touch Tools.

5. Touch Print Quality Report.

The product prints a print quality report that you can use to diagnose print quality issues.

To evaluate the print quality report

1. Check the ink levels shown on the page. If a cartridge shows very low ink levels and

you find the print quality unacceptable, consider replacing that ink cartridge. Print quality typically deteriorates as cartridges run out of ink.

NOTE: If the print quality report is not legible, you can check the estimated ink

levels from the control panel or HP Photosmart Software.

Print and evaluate a print quality report 65

Maintain the HP Photosmart

Chapter 11

NOTE: Ink level warnings and indicators provide estimates for planning

purposes only. When you receive a low-ink warning message, consider having a replacement cartridge available to avoid possible printing delays. You do not need to replace the ink cartridges until print quality becomes unacceptable.

2. Look at the color bars in the middle of the page. The bars should be solid, have sharp

edges, and extend with uniform color all the way across the page.

Figure 11-1 Color bars - expected result

• If any of the color bars are irregularly streaked, lighter on one side, or contain one

or more streaks of a different color, refer to the following steps.

Figure 11-2 Color bars - irregularly streaked or faded bar (top bar)

Figure 11-3 Color bars - color mixing (yellow bar contains magenta streaks)

◦ Check the estimated ink levels in the cartridges. ◦ Check if the cartridge corresponding to the streaked bar has the orange tab

removed.

Maintain the HP Photosmart

◦ Reinstall the cartridge and make sure all of the cartridges are properly

installed.

66 Maintain the HP Photosmart

◦ Clean the printhead, and then print this diagnostic page again. ◦ If cleaning the printhead does not solve this print quality issue, replace the

cartridge corresponding to the streaked bar.

NOTE: If replacing the cartridge does not solve this print quality issue,

contact HP support for service.

• If any of the color bars show regular white streaks, refer to the following steps.

◦ If line 11 on the diagnostic page reads PHA TTOE = 0, align the printer. ◦ If line 11 on the diagnostic page shows a different value or aligning does not

help, clean the printhead.

NOTE: If cleaning the printhead does not solve this print quality issue,

contact HP support for service.

3. Look at the large text above the alignment pattern. The type should be sharp and

clear.

Figure 11-4 Sample text area - expected result

• If the type is jagged, align the printer, and then print this diagnostic page again.

Figure 11-5 Sample text area - jagged text

• If the text is uneven and ragged at one end, clean the printhead, and then print this diagnostic page again. If this occurs right after a new cartridge is installed, the automatic device servicing routines may solve the problem in a day or so.

Figure 11-6 Sample text area - uneven ink distribution

• If the text is smeared, check if the paper is curled, clean the printhead, and then print this diagnostic page again.

Figure 11-7 Sample text area - streaks or smears

4. Look at the alignment pattern above the color bars. The lines should be straight and

sharp.

Figure 11-8 Alignment pattern - expected result

Print and evaluate a print quality report 67

Maintain the HP Photosmart

Chapter 11

If the lines are jagged, align the printer, and then print this diagnostic page again.

Figure 11-9 Alignment pattern - jagged lines

NOTE: If aligning the printer does not solve this print quality issue, contact HP

support for service.

If you do not see any defects on the print quality report, then the printing system is working correctly. There is no reason to replace supplies or have the product serviced, because they are functioning properly. If you still have a print quality problem, here are some other things you can check:

• Check the paper.

• Check the print settings.

• Make sure your image has sufficient resolution.

• If the problem seems confined to a band near the edge of your printout, use the

software you installed with the product or another software application to rotate the image 180 degrees. The problem might not appear on the other end of the print.

Maintain the HP Photosmart

68 Maintain the HP Photosmart

12 Solve a problem

This section contains the following topics:

HP support

• Setup troubleshooting

• Print troubleshooting

• Print quality troubleshooting

• Memory card troubleshooting

• Scan troubleshooting

• Copy troubleshooting

• Errors

•

HP support

• HP support by phone Additional warranty options

•

HP support by phone

Phone support options and availability vary by product, country/region, and language.

This section contains the following topics:

•

Phone support period Placing a call

• After the phone support period

•

Solve a problem

Phone support period

One year of phone support is available in North America, Asia Pacific, and Latin America (including Mexico). To determine the duration of phone support in Europe, the Middle East, and Africa, go to

Placing a call

Call HP support while you are in front of the computer and the product. Be prepared to provide the following information:

• Product name (HP Photosmart Plus B209 series)

• Model number (located near the cartridge access area)

www.hp.com/support. Standard phone company charges apply.

Solve a problem 69

[[[[[

Chapter 12

Solve a problem

• Serial number (located on the back or bottom of the product)

• Messages that appear when the situation occurs

• Answers to these questions:

◦ Has this situation happened before? ◦ Can you re-create it? ◦ Did you add any new hardware or software to your computer at about the time

that this situation began?

◦ Did anything else occur prior to this situation (such as a thunderstorm, product

was moved, etc.)?

For the list of support phone numbers, visit

www.hp.com/support.

After the phone support period

After the phone support period, help is available from HP at an additional cost. Help may also be available at the HP online support Web site: HP dealer or call the support phone number for your country/region to learn more about support options.

Additional warranty options

Extended service plans are available for the HP Photosmart at additional costs. Go to

www.hp.com/support, select your country/region and language, then explore the services

and warranty area for information about the extended service plans.

Setup troubleshooting

This section contains setup troubleshooting information for the product.

Many issues are caused when the product is connected to the computer using a USB cable before the product software is installed on the computer. If you connected the

70 Solve a problem

www.hp.com/support. Contact your

product to your computer before the software installation screen prompted you to do so, you must follow these steps:

Troubleshooting common setup issues

1. Disconnect the USB cable from the computer.

2. Uninstall the software (if you have already installed it).

For more information, see “

Uninstall and reinstall the software” on page 75.

3. Restart your computer.

4. Turn off the product, wait one minute, then restart it.

5. Reinstall the HP Photosmart software.

CAUTION: Do not connect the USB cable to the computer until prompted by the

software installation screen.

This section contains the following topics:

•

The product will not turn on After setting up the product, it does not print

• The wrong measurements are showing in menus on the display

• The registration screen does not appear

• Uninstall and reinstall the software

•

The product will not turn on

Try the following solutions if there are no light indications, no noise, and no movement from the product when you turn it on.

•

Solution 1: Check the power cord Solution 2: Reset the product

• Solution 3: Press the On button more slowly

• Solution 4: Contact HP to replace the power supply

• Solution 5: Contact HP support for service

•

Solution 1: Check the power cord

Solution:

• Make sure you are using the power cord that came with the product.

• Make sure the power cord is firmly connected to both the product and the power

adapter. Plug the power cord into a power outlet, surge protector, or power strip.

Solve a problem

Setup troubleshooting 71

Chapter 12

Solve a problem

1 Power connection

2 Power cord and adapter

3 Power outlet

• If you are using a power strip, make sure the power strip is turned on. Or, try

plugging the product directly into a power outlet.

• Test the power outlet to make sure it is working. Plug in an appliance that you

know works, and see if the appliance has power. If not, then there might be a problem with the power outlet.

• If you plugged the product into a switched outlet, make sure the outlet is switched

on. If it is switched on but still does not work, then there might be a problem with the power outlet.

Cause: There was a problem with the power cord or the power supply.

If this did not solve the issue, try the next solution.

Solution 2: Reset the product

Solution: Turn off the product, and then unplug the power cord. Plug the power cord back in, and then press the On button to turn on the product.

Cause: The product experienced an error.

If this did not solve the issue, try the next solution.

Solution 3: Press the On button more slowly

Solution: The product might not respond if you press the On button too quickly.

Press the On button once. It might take a few minutes for the product to turn on. If you press the On button again during this time, you might turn the product off.

72 Solve a problem

CAUTION: If the product still does not turn on, it might have a mechanical failure.

Unplug the product from the power outlet.

Contact HP support for service.

Go to:

www.hp.com/support. If prompted, choose your country/region, and then

click Contact HP for information on calling for technical support.

Cause: You pressed the On button too quickly.

If this did not solve the issue, try the next solution.

Solution 4: Contact HP to replace the power supply

Solution: Contact HP support to request a power supply for the product.

Go to:

www.hp.com/support.

If prompted, choose your country/region, and then click Contact HP for information on calling for technical support.

Cause: The power supply was not intended for use with this product.

If this did not solve the issue, try the next solution.

Solution 5: Contact HP support for service

Solution: If you have completed all of the steps provided in the previous solutions

and are still having a problem, contact HP support for service.

Go to:

www.hp.com/support.

If prompted, choose your country/region, and then click Contact HP for technical support.

Cause: You might need assistance to enable the product or software to function properly.

After setting up the product, it does not print

Try the following solutions to resolve the issue. Solutions are listed in order, with the most likely solution first. If the first solution does not solve the problem, continue trying the remaining solutions until the issue is resolved.

•

Step 1: Press the On button to turn on the product Step 2: Set your product as the default printer

• Step 3: Check the connection between the product and computer

•

Solve a problem

Step 1: Press the On button to turn on the product

Solution: Look at the display on the product. If the display is blank and the On

button is not lit, the product is turned off. Make sure the power cord is firmly connected to the product and plugged into a power outlet. Press the On button to turn on the product.

Setup troubleshooting 73

Chapter 12

Solve a problem

Cause: The product might not have been turned on.

If this did not solve the issue, try the next solution.

Step 2: Set your product as the default printer

Solution: Check your computer documentation to change your product to be the

default printer.

Cause: You sent the print job to the default printer, but this product was not the default printer.

If this did not solve the issue, try the next solution.

Step 3: Check the connection between the product and computer

Solution: Check the connection from the product to your computer. Verify that the

USB cable is securely plugged into the USB port on the back of the product. Make sure the other end of the USB cable is plugged into a USB port on your computer. After the cable is connected properly, turn off the product and then on again. If the product is connected to the computer through a wired, wireless, or Bluetooth connection, make sure that the respective connections are active and the product is turned on.

For more information on setting up the product and connecting it to your computer, see the setup instructions guide that came with the product.

Cause: The product and computer were not communicating with each other.

If this did not solve the issue, try the next solution.

The wrong measurements are showing in menus on the display

Solution: Change the country/region setting.

74 Solve a problem

NOTE: You will be prompted to set both the language and the country/region

settings, by using the following procedure.

To set your language and country/region

1. On the Home Screen, touch the right arrow to view more options.

2. Touch Setup.

3. Touch Preferences.

4. Touch Set Language.

5. Touch the down arrow to scroll through the languages. When the language you

want to use appears, touch that language.

6. When prompted, touch Yes to confirm your selection.

The Preferences menu reappears.

7. Touch Set Country/Region.

8. Touch the down arrow to scroll through the countries/regions. When the country/

region you want to use appears, touch that country/region.

9. When prompted, touch Yes to confirm your selection.

Cause: You might have selected the incorrect country/region when setting up the

product. The country/region you select determines the paper sizes shown on the display.

Solve a problem

The registration screen does not appear

Solution: You can access the registration (Sign up now) screen from the Windows taskbar by clicking Start, pointing to Programs or All Programs, HP, Photosmart Plus B209a series, and then clicking Product Registration.

Cause: The registration screen did not launch automatically.

Uninstall and reinstall the software

If your installation is incomplete, or if you connected the USB cable to the computer before prompted by the software installation screen, you might need to uninstall and then reinstall the software. Do not simply delete the HP Photosmart application files from your computer. Make sure to remove them properly using the uninstall utility provided when you installed the software that came with the HP Photosmart.

To uninstall and reinstall the software

1. Disconnect the product from your computer.

2. On the Windows taskbar, click Start, Settings, Control Panel (or just Control

Panel).

Setup troubleshooting 75

Chapter 12

3. Double-click Add/Remove Programs (or click Uninstall a program).

4. Select HP Photosmart All-in-One Driver Software, and then click Change/

Remove.

Follow the onscreen instructions.

5. Restart your computer.

Solve a problem

NOTE: It is important that you disconnect the product before restarting your

computer. Do not connect the product to your computer until after you have reinstalled the software.

6. Insert the product CD-ROM into your computer’s CD-ROM drive and then start the

Setup program.

NOTE: If the Setup program does not appear, locate the setup.exe file on the

CD-ROM drive and double-click it.

NOTE: If you no longer have the installation CD, you can download the software

from

www.hp.com/support.

7. Follow the onscreen instructions and the setup instructions that came with the

product.

When the software installation is complete, the HP Digital Imaging Monitor icon appears in the Windows system tray.

Print troubleshooting

•

Check cartridges Check paper

• Check product

• Check the print settings

• Reset the product

• Contact HP support for service

•

76 Solve a problem

Check cartridges

Follow these steps.

•

Step 1: Make sure you are using genuine HP ink cartridges Step 2: Check the ink levels

•

Step 1: Make sure you are using genuine HP ink cartridges

Solution: Check to see if your ink cartridges are genuine HP ink cartridges.

HP recommends that you use genuine HP ink cartridges. Genuine HP ink cartridges are designed and tested with HP printers to help you easily produce great results, time after time.

NOTE: HP cannot guarantee the quality or reliability of non-HP supplies. Product

service or repairs required as a result of using a non-HP supply will not be covered under warranty.

If you believe you purchased genuine HP ink cartridges, go to:

www.hp.com/go/anticounterfeit

Cause: Non-HP ink cartridges were being used.

Step 2: Check the ink levels

Solution: Check the estimated ink levels in the cartridges.

NOTE: Ink level warnings and indicators provide estimates for planning

purposes only. When you receive a low-ink warning message, consider having a replacement cartridge available to avoid possible printing delays. You do not need to replace the cartridges until print quality becomes unacceptable.

Solve a problem

Check paper

Follow these steps.

•

Step 1: Use the correct paper type

For more information, see:

Check the estimated ink levels” on page 61

“

Cause: The ink cartridges might have insufficient ink.

Step 1: Use the correct paper type Step 2: Load the stack of paper correctly

Solution: HP recommends that you use HP papers or any other paper type that is appropriate for the product. Make sure only one type of paper is loaded at a time.

Always make sure the paper you are printing on is flat. For best results when printing images, use HP Advanced Photo Paper.

Cause: The paper type was incorrect or more than one type of paper was loaded.

Print troubleshooting 77

Chapter 12

Solve a problem

Check product

Step 2: Load the stack of paper correctly

Solution: Remove the stack of paper from the input tray, reload the paper, and then

slide the paper width guide inward until it stops at the edge of the paper.

NOTE: Do not leave unused photo paper in the input tray. The paper might start

to curl, which could reduce the quality of your printout. For best results, do not allow printed photos to stack up in the output tray.

For more information, see:

“

Load media” on page 23

Cause: The paper was loaded incorrectly.

Follow these steps.

•

Step 1: Align the printer Step 2: Clean the printhead

•

Step 1: Align the printer

Solution: Aligning the printer can help ensure excellent print quality.

To align the printer from the HP Photosmart Software

1. Load letter or A4 unused plain white paper into the input tray.

2. In the HP Solution Center, click Settings.

3. In the Print Settings area, click Printer Toolbox.

The Printer Toolbox appears.

4. Click the Device Services tab.

5. Click Align the Printer.

6. When prompted, ensure plain white letter or A4 paper is loaded in the paper tray,

then touch OK.

The product prints an alignment sheet.

7. Load the page print side down on the right front corner of the glass, and then

touch OK to scan the page. When the On button stops flashing, the alignment is complete and the page can be removed. Recycle or discard the page.

Cause: The printer needed to be aligned.

78 Solve a problem

NOTE: You can also open the Printer Toolbox from the Print Properties

dialog box. In the Print Properties dialog box, click the Features tab, and then click Printer Services.

NOTE: If you have colored paper loaded in the paper tray when you align

the print cartridges, the alignment will fail. Load unused plain white paper into the paper tray, and then try the alignment again.

Step 2: Clean the printhead

Solution: If the previous solutions did not resolve the issue, try cleaning the

printhead.

To clean the printhead from the HP Photosmart Software

1. Load letter, A4, or legal unused plain white paper into the main input tray.

2. In the HP Solution Center, click Settings.

3. In the Print Settings area, click Printer Toolbox.

NOTE: You can also open the Printer Toolbox from the Print Properties

dialog box. In the Print Properties dialog box, click the Features tab, and then click Printer Services.

The Printer Toolbox appears.

4. Click the Device Services tab.

5. Click Clean the printhead.

6. Follow the prompts until you are satisfied with the quality of the output, and then

click Done. There are two stages of cleaning. Each stage lasts about two minutes, uses one

sheet of paper, and uses an increasing amount of ink. After each stage, review the quality of the printed page. You should only initiate the next phase of cleaning if the print quality is poor. If print quality still seems poor after you complete both stages of cleaning, try aligning the printer. If print quality problems persist after cleaning and aligning, contact HP support.

After cleaning the printhead, print a print quality report. Evaluate the print quality report to see if the print quality problem still exists.

For more information, see:

“

Print and evaluate a print quality report” on page 65

Cause: The printhead needed to be cleaned.

Solve a problem

Print troubleshooting 79

Chapter 12

Solve a problem

Check the print settings

Solution: Try the following:

• Check the print settings to see if the color settings are incorrect.

For example, check to see if the document is set to print in grayscale. Or, check to see if advanced color settings such as saturation, brightness, or color tone, are set to modify the appearance of colors.

• Check the print quality setting and make sure it matches the type of paper loaded

in the product. You might need to choose a lower print quality setting if colors are running into

each other. Or, choose a higher setting if you are printing a high-quality photo, and then make sure photo paper such as HP Advanced Photo Paper is loaded in the paper tray. For information on using the maximum dpi mode, see “

Print using

the maximum dpi” on page 40.

• Make sure the margin settings for the document do not exceed the printable area

of the product.

To select a print speed or quality

1. Make sure you have paper loaded in the input tray.

2. On the File menu in your software application, click Print.

3. Make sure the product is the selected printer.

4. Click the button that opens the Properties dialog box.

Depending on your software application, this button might be called Properties, Options, Printer Setup, Printer, or Preferences.

5. Click the Features tab.

6. In the Paper Type drop-down list, select the type of paper that you have loaded.

7. In the Print Quality drop-down list, select the appropriate quality setting for your

project.

To check your margin settings

1. Preview your print job before sending it to the product.

In most software applications, click the File menu, and then click Print Preview.

2. Check the margins.

The product uses the margins you have set in your software application, as long as they are greater than the minimum margins the product supports. For more information about setting margins in your software application, see the documentation that came with the software.

3. Cancel the print job if the margins are not satisfactory, and then adjust the margins

in your software application.

Cause: The settings were not set correctly.

Reset the product

Solution: Turn off the product, and then unplug the power cord. Plug the power

cord back in, and then press the On button to turn on the product.

80 Solve a problem

NOTE: To find out what dpi the product will print based on the paper type

and print quality settings you selected, click Resolution.

Cause: The product experienced an error.

Contact HP support for service

Solution: If you have completed all of the steps provided in the previous solutions

and are still having a problem, contact HP support for service.

Go to:

www.hp.com/support.

If prompted, choose your country/region, and then click Contact HP for technical support.

Cause: You might need assistance to enable the product or software to function properly.

Print quality troubleshooting

Use this section to solve these print quality problems:

•

Photo printouts are hazy, blurry, or have inaccurate color

Solution: For best photo color quality, do not allow printouts to stack on top of

photos in the output tray.

Cause: When printouts are stacked on top of a photo before the ink is completely dry, some color distortion may occur in the photo.

Solve a problem

Memory card troubleshooting

Use this section to solve these memory card problems:

•

The product does not read the memory card The photos on the memory card do not transfer to my computer

• Photos in a connected digital camera with PictBridge do not print

•

The product does not read the memory card

•

Step 1: Insert the memory card properly Step 2: Remove the additional memory card

• Step 3: Reformat the memory card in your digital camera

•

Step 1: Insert the memory card properly

Solution: Turn the memory card so that the label faces up and the contacts are

facing the product, and then push the card forward into the appropriate slot until the Photo light turns on.

Memory card troubleshooting 81

Chapter 12

Solve a problem

After the memory card has been inserted properly, the Photo light will blink for a few seconds, and then remain lit.

Cause: The memory card was inserted backwards or upside down.

If this did not solve the issue, try the next solution.

Step 2: Remove the additional memory card

Solution: You can insert only one memory card at a time.

If more than one memory card is inserted, an error message will appear on the display. Remove the additional memory card to resolve the problem.

Cause: You had inserted more than one memory card.

If this did not solve the issue, try the next solution.

Step 3: Reformat the memory card in your digital camera

Solution: Check the computer screen for an error message telling you that the

images on the memory card are corrupted.

If the file system on the card is corrupt, reformat the memory card in your digital camera. For more information, see the documentation that came with your digital camera.

CAUTION: Reformatting the memory card will delete any photos stored on the

card. If you have previously transferred the photos from your memory card to a computer, try printing the photos from the computer. Otherwise, you will need to retake any photos you might have lost.

Cause: The memory card file system was corrupted.

The photos on the memory card do not transfer to my computer

Try the following solutions.

•

Solution 1: Install the product software

•

Solution 2: Check the connection from the product to your computer

Solution 1: Install the product software

Solution: Install the product software that came with the product. If it is installed,

restart your computer.

To install the product software

1. Insert the product CD-ROM into your computer’s CD-ROM drive and then start

the Setup program.

2. When prompted, click Install More Software to install the product software.

3. Follow the onscreen instructions and the setup instructions that came with the

product.

Cause: The product software was not installed.

82 Solve a problem

If this did not solve the issue, try the next solution.

Solution 2: Check the connection from the product to your computer

Solution: Check the connection from the product to your computer. Verify that the

Solve a problem

For more information on setting up the product and connecting it to your computer, see the setup instructions guide that came with the product.

Cause: The product was not properly connected to the computer.

Photos in a connected digital camera with PictBridge do not print

•

Solution 1: Set the camera to PictBridge mode Solution 2: Save the photos in a supported file format

•

Solution 3: Select photos on the camera for printing

Solution 1: Set the camera to PictBridge mode

Solution: If the camera supports PictBridge, make sure the camera is set to

PictBridge mode. See the user guide that came with the camera for instructions on how to do this.

Cause: The digital camera was not in PictBridge mode.

If this did not solve the issue, try the next solution.

Memory card troubleshooting 83

Chapter 12

Solution 2: Save the photos in a supported file format

Solution: Make sure the digital camera is saving photos in a file format that the

PictBridge transfer feature supports (Exif/JPEG, JPEG, and DPOF).

Cause: The images were not in a supported format.

If this did not solve the issue, try the next solution.

Solve a problem

Solution 3: Select photos on the camera for printing

Solution: Before you connect the digital camera to the front USB port on the

product, select some photos on the camera for printing.

NOTE: Some digital cameras do not allow you to select photos until after you

have established a PictBridge connection. If this is the case, connect your digital camera to the front USB port, turn on the camera and change it to PictBridge mode, and then use the camera to select the photos you want to print.

Cause: You did not select any photos on the camera for printing.

Scan troubleshooting

Use this section to solve these scan problems:

•

Scanned image is incorrectly cropped Scanned image shows dotted lines instead of text

• Text format is incorrect

• Text is incorrect or missing

•

Scanned image is incorrectly cropped

Solution: The autocropping feature in the software crops anything that is not part

of the main image. Sometimes this might not be what you want. In that case, turn off autocropping in the software and crop the scanned image manually, or not at all.

Cause: The software was set to automatically crop scanned pictures.

Scanned image shows dotted lines instead of text

Solution: Make a black-and-white copy of the original and then scan the copy.

Cause: If you used the Text image type to scan text that you planned to edit, the

scanner might not have recognized color text. The Text image type scans at 300 x 300 dpi, in black and white.

If you scanned an original that has graphics or artwork surrounding the text, the scanner might not have recognized the text.

84 Solve a problem

Text format is incorrect

Solution: Some applications cannot handle framed text formatting. Framed text is

one of the scan document settings in the software. It maintains complex layouts, such as multiple columns from a newsletter, by putting the text in different frames (boxes) in the destination application. In the software, select the correct format so that the scanned text layout and formatting are retained.

Cause: The scan document settings were incorrect.

Text is incorrect or missing

•

Solution 1: Adjust the brightness in the software Solution 2: Clean the glass and lid

•

Solution 1: Adjust the brightness in the software

Solution: Adjust the brightness in the software, and then rescan the original.

Cause: The brightness was not set correctly.

If this did not solve the issue, try the next solution.

Solution 2: Clean the glass and lid

Solution: Turn off the product, unplug the power cord, and use a soft cloth to wipe

the glass and the back of the document lid.

Cause: Debris might have been stuck on the glass or on the back of the document lid. This can cause poor-quality scans.

Solve a problem

Copy troubleshooting

Use this section to solve these copy problems:

•

Fit to Page is not working as expected

Try the following solutions.

•

Solution 1: Scan, enlarge, and then print a copy Solution 2: Wipe the glass and the back of the document lid

•

Solution 1: Scan, enlarge, and then print a copy

Solution: Fit to Page can only enlarge the original up to the maximum percentage

allowed by your model. For example, 200% might be the maximum enlargement

Copy troubleshooting 85

Chapter 12

percentage allowed by your model. Enlarging a passport photo by 200% might not enlarge it enough for it to fit a full-size page.

If you want to make a large copy of a small original, scan the original into the computer, resize the image in the HP scanning software, and then print a copy of the enlarged image.

Solve a problem

Errors

NOTE: Do not use the product to copy onto envelopes or other papers it does

not support. For more information on recommended media, see “

papers for printing” on page 22.

Cause: You were trying to increase the size of an original that was too small.

If this did not solve the issue, try the next solution.

Solution 2: Wipe the glass and the back of the document lid

Solution: Turn off the product, unplug the power cord, and then use a soft cloth to

wipe the glass and the back of the document lid.

Cause: Debris might have been stuck on the glass or on the back of the document lid. The product interprets anything it detects on the glass as part of the image.

This section contains the following categories of messages about your product:

•

Product messages File messages

• General user messages

• Paper messages

• Ink cartridge and printhead messages

•

Recommended

Product messages

The following is a list of product-related error messages:

•

Firmware revision mismatch Memory is full

• Photo tray problem

• Scanner failure

• Improper shutdown

• Missing HP Photosmart Software

•

Firmware revision mismatch

Solution: Contact HP support for service.

Go to:

If prompted, choose your country/region, and then click Contact HP for information on calling for technical support.

86 Solve a problem

www.hp.com/support.

Cause: The revision number of the product firmware did not match the revision number of the software.

Memory is full

Solution: Try making fewer copies at a time.

Cause: The document you were copying exceeded the memory of the product.

Photo tray problem

Try the following solutions.

•

Solution 1: Make sure paper is loaded correctly in the photo tray Solution 2: Make sure the sheets of paper are not stuck together

•

Solution 1: Make sure paper is loaded correctly in the photo tray

Solution: If the photo tray is empty or there are only a few sheets remaining, load

more paper in the photo tray. If there is paper in the photo tray, remove the paper, tap the stack of paper against a flat surface, and reload the paper into the photo tray. Follow the prompts on the display or the computer screen to continue your print job.

Do not overload the photo tray; make sure the stack of photo paper fits within the photo tray and is no higher than the top of the paper-width guide.

Cause: The paper was not feeding properly because it was loaded incorrectly.

If this did not solve the issue, try the next solution.

Solve a problem

Solution 2: Make sure the sheets of paper are not stuck together

Solution: Remove the paper from the photo tray and shuffle the paper so it does

not stick together. Reload the paper into the photo tray and try printing again.

Cause: Two or more pieces of paper were stuck together.

Scanner failure

Solution: Turn off the product and then turn it on again. Restart your computer and

then try to scan again.

If the problem persists, try plugging the power cord directly into a power outlet rather than a surge protector or power strip. If the problem continues, contact HP support. Go to

www.hp.com/support. If prompted, choose your country/region, and then click

Contact HP for information on calling for technical support.

Cause: The product was busy or an unknown cause interrupted your scan.

Improper shutdown

Solution: Press the On button to turn the product on and off.

Errors 87

Chapter 12

Solve a problem

Cause: The last time the product was used, it was not turned off properly. If the

product is turned off by turning off the switch on a power strip or by using a wall switch, the product can be damaged.

Missing HP Photosmart Software

Try the following solutions.

•

Solution 1: Install the HP Photosmart Software

•

Solution 2: Check the connection from the product to your computer

Solution 1: Install the HP Photosmart Software

Solution: Install the product software that came with the product. If it is installed,

restart your computer.

To install the product software

1. Insert the product CD-ROM into your computer’s CD-ROM drive and then start

the Setup program.

2. When prompted, click Install More Software to install the product software.

3. Follow the onscreen instructions and the setup instructions that came with the

product.

Cause: The HP Photosmart Software was not installed.

If this did not solve the issue, try the next solution.

Solution 2: Check the connection from the product to your computer

Solution: Check the connection from the product to your computer. Verify that the

88 Solve a problem

For more information on setting up the product and connecting it to your computer, see the setup instructions guide that came with the product.

Cause: The product was not properly connected to the computer.

File messages

The following is a list of file-related error messages:

•

Error reading or writing the file Unreadable files. NN files could not be read

• Photos not found

• File not found

• Invalid file name

• Supported file types for the product

• File corrupted

•

Error reading or writing the file

Solution: Check to see if you have the right folder and file name.

Cause: The product software could not open or save the file.

Unreadable files. NN files could not be read

Solution: Reinsert the memory card in the product. If this does not work, retake the

photos with your digital camera. If you already transferred the files to your computer, try printing those files by using the product software. The copies might not be damaged.

Cause: Some of the files on the inserted memory card or attached storage device were damaged.

Solve a problem

Photos not found

Try the following solutions.

•

Solution 1: Reinsert the memory card Solution 2: Print photos from the computer

•

Solution 1: Reinsert the memory card

Solution: Reinsert the memory card. If this does not work, retake the photos with

your digital camera. If you already transferred the files to your computer, try printing those files by using the product software. The copies might not be damaged.

Cause: Some of the files on the inserted memory card or attached storage device were damaged.

If this did not solve the issue, try the next solution.

Errors 89

Chapter 12

Solution 2: Print photos from the computer

Solution: Take some photos with your digital camera, or if you previously saved

photos on your computer, you can print them using the product software.

Cause: No photos were found on the memory card.

Solve a problem

File not found

Solution: Close some applications and try the task again.

Cause: There was not enough available memory on your computer to create a print

preview file.

Invalid file name

Solution: Make sure that you are not using any invalid symbols in the file name.

Cause: The file name you entered was invalid.

Supported file types for the product

The product software only recognizes JPG and TIF images.

File corrupted

Try the following solutions.

•

Solution 1: Reinsert the memory card in the product Solution 2: Reformat the memory card in your digital camera.

•

Solution 1: Reinsert the memory card in the product

Solution: Reinsert the memory card. If this does not work, retake the photos with

your digital camera. If you already transferred the files to your computer, try printing those files by using the product software. The copies might not be damaged.

Cause: Some of the files on the inserted memory card or attached storage device were damaged.

If this did not solve the issue, try the next solution.

Solution 2: Reformat the memory card in your digital camera.

Solution: Check the computer screen for an error message telling you that the

images on the memory card are corrupted.

If the file system on the card is corrupt, reformat the memory card in your digital camera.

90 Solve a problem

CAUTION: Reformatting the memory card will delete any photos stored on the

card. If you have previously transferred the photos from your memory card to a computer, try printing the photos from the computer. Otherwise, you will need to retake any photos you might have lost.

Cause: The memory card file system was corrupted.

General user messages

The following is a list of messages related to common user errors:

•

Memory card error Cannot crop

• Out of disk space

• Card access error

• Use only one card at a time

• Card is inserted incorrectly

• Card is damaged

• Card is not fully inserted

•

Memory card error

•

Solution 1: Remove all but one memory card Solution 2: Remove the memory card and reinsert it correctly

• Solution 3: Push the memory card all the way forward

•

Solve a problem

Solution 1: Remove all but one memory card

Solution: Remove all but one memory card. The product reads the remaining

memory card and displays the first photo stored on the memory card.

Cause: There were two or more memory cards inserted into the product at the same time.

If this did not solve the issue, try the next solution.

Solution 2: Remove the memory card and reinsert it correctly

Solution: Remove the memory card and reinsert it correctly. The label of the

memory card faces up and should be readable as you insert it into the slot.

Cause: You had inserted the memory card backwards or upside down.

If this did not solve the issue, try the next solution.

Errors 91

Chapter 12

Solution 3: Push the memory card all the way forward

Solution: Remove the memory card and reinsert it in the memory card slot until it

stops.

Cause: You had not fully inserted the memory card.

Solve a problem

Cannot crop

Try the following solutions.

•

Solution 1: Close some applications or restart your computer Solution 2: Empty the Recycle Bin on your desktop

•

Solution 1: Close some applications or restart your computer

Solution: Close all unnecessary applications. This includes applications that run in

the background, such as screensavers and virus checkers. (If you turn off your virus checker, remember to turn it back on after you finish.) Try restarting your computer to clear the memory. You might need to purchase more RAM. Refer to the documentation that came with your computer.

Cause: The computer did not have enough memory.

If this did not solve the issue, try the next solution.

Solution 2: Empty the Recycle Bin on your desktop

Solution: Empty the Recycle Bin on your desktop. You might also need to remove

files from the hard disk; for example, delete temporary files.

Cause: For scanning, there must be at least 50 MB of space available on your computer's hard disk.

Out of disk space

Solution: Empty the Recycle Bin on your desktop. You might also need to remove

files from the hard disk; for example, delete temporary files.

Cause: The computer did not have enough memory.

Card access error

Solution: Remove the memory card and reinsert it in the memory card slot until it

stops.

Cause: You had not fully inserted the memory card.

Use only one card at a time

Solution: You can insert only one memory card at a time.

92 Solve a problem

If more than one memory card is inserted, an error message will appear on the display. Remove the additional memory card to resolve the problem.

Cause: There were two or more memory cards inserted into the product at the same time.

Card is inserted incorrectly

Solution: Turn the memory card so that the label faces up and the contacts are

facing the product, and then push the card forward into the appropriate slot until the Photo light turns on.

After the memory card has been inserted properly, the Photo light will blink for a few seconds, and then remain lit.

Cause: You had inserted the memory card backwards or upside down.

Card is damaged

Solution: Reformat your memory card in your camera or format your memory card

in a computer by selecting the FAT format. For more information, see the documentation that came with your digital camera.

CAUTION: Reformatting the memory card will delete any photos stored on the

card. If you have previously transferred the photos from your memory card to a computer, try printing the photos from the computer. Otherwise, you will need to retake any photos you might have lost.

Solve a problem

Cause: You may have formatted the card on a Windows XP computer. By default,

Windows XP will format a memory card of 8 MB or less and 64 MB or more with the FAT32 format. Digital cameras and other devices use the FAT (FAT16 or FAT12) format and cannot recognize a FAT32 formatted card.

Card is not fully inserted

Solution: Turn the memory card so that the label faces up and the contacts are

facing the product, and then push the card forward into the appropriate slot until the Photo light turns on.

After the memory card has been inserted properly, the Photo light will blink for a few seconds, and then remain lit.

Cause: You had not fully inserted the memory card.

Paper messages

The following is a list of paper-related error messages:

•

Paper upside down Paper orientation error

• Ink is drying

•

Errors 93

Chapter 12

Paper upside down

Solution: Load paper in the input tray print side down.

Cause: Paper in the input tray was upside down.

Solve a problem

Paper orientation error

Solution: Insert paper into the input tray with the short edge forward and the print

side down. Slide the paper forward until it stops.

Cause: Paper in the input tray was in landscape orientation.

Ink is drying

Solution: Leave the sheet in the output tray until the message disappears. If it is

necessary to remove the printed sheet before the message disappears, carefully hold the printed sheet on the underside or the edges, and place it on a flat surface to dry.

Cause: Transparencies and some other media require a drying time that is longer than normal.

Ink cartridge and printhead messages

The following is a list of printhead and ink cartridge error messages:

•

Cartridges in wrong slot General printer error

• Incompatible ink cartridges

• Incompatible printhead

• Ink alert

• Ink cartridge problem

• Ink service capacity warning

• Ink system failure

• Check ink cartridges

• Install cartridges

• Non-HP cartridge

• Original HP ink depleted

• Previously used genuine HP cartridge

• Printhead problem

• Problem with printer preparation

•

Cartridges in wrong slot

Solution: Remove and reinsert the indicated ink cartridges into the correct slots by

matching color of cartridges to color and icon for each slot.

94 Solve a problem

Printing cannot occur without one of each type of ink cartridge inserted into the correct slot.

For more information, see:

“

Replace the cartridges” on page 62

Cause: The indicated ink cartridges were inserted into the wrong slots.

General printer error

Try the following solutions.

•

Solution 1: Reset the product Solution 2: Contact HP support

•

Solution 1: Reset the product

Solution: Turn off the product, and then unplug the power cord. Plug the power cord back in, and then press the On button to turn on the product.

Cause: The product experienced an error.

If this did not solve the issue, try the next solution.

Solution 2: Contact HP support

Solution: Write down the error code provided in the message, and then contact HP

support. Go to:

www.hp.com/support

If prompted, choose your country/region, and then click Contact HP for information on calling for technical support.

Cause: There was a problem with the product.

Solve a problem

Incompatible ink cartridges

Try the following solutions.

Errors 95

Chapter 12

Solve a problem

• Solution 1: Check to see if the ink cartridges are compatible Solution 2: Contact HP support

•

Solution 1: Check to see if the ink cartridges are compatible

Solution: Check to make sure you are using the correct ink cartridges for your

product. For a list of compatible ink cartridges, see the printed documentation that came with the product.

If you are using ink cartridges that are not compatible with the product, replace the indicated ink cartridges with ink cartridges that are compatible.

CAUTION: HP recommends that you do not remove an ink cartridge until a

replacement is ready to install.

If it appears that you are using the correct ink cartridges, proceed to the next solution.

For more information, see:

•“

Order ink supplies” on page 62 Replace the cartridges” on page 62

•“

Cause: The indicated ink cartridges were not intended for use in this product as it was currently configured.

If this did not solve the issue, try the next solution.

Solution 2: Contact HP support

Solution: Contact HP support for service.

Go to:

www.hp.com/support.

If prompted, choose your country/region, and then click Contact HP for information on calling for technical support.

Cause: The ink cartridges were not intended for use in this product.

Incompatible printhead

Solution: Contact HP support for service.

Go to:

www.hp.com/support.

If prompted, choose your country/region, and then click Contact HP for information on calling for technical support.

Cause: The printhead was not intended for use in this product, or it was damaged.

Ink alert

Solution: When you receive an Ink Alert message, you do not need to replace the

indicated ink cartridge. However, the amount of ink might be low enough to cause poor print quality. Follow any prompts on the display to continue.

96 Solve a problem

CAUTION: HP recommends that you do not remove an ink cartridge until a

replacement is ready to install.

If you have installed a refilled or remanufactured cartridge, or a cartridge that has been used in another product, the ink level indicator might be inaccurate or unavailable.

Ink level warnings and indicators provide estimates for planning purposes only. When you receive an ink alert message, consider having replacement ink cartridges available to avoid possible printing delays. You do not need to replace the ink cartridges until print quality becomes unacceptable.

For more information, see:

“

Replace the cartridges” on page 62

Cause: The indicated ink cartridges did not have enough ink to print properly.

Ink cartridge problem

•

Solution 1: Install the ink cartridges correctly

•

Solution 2: Close the print carriage latch Solution 3: Clean the electrical contacts

• Solution 4: Replace the ink cartridge

• Solution 5: Contact HP support

•

Solve a problem

Solution 1: Install the ink cartridges correctly

Solution: Make sure all of the ink cartridges are properly installed. Refer to the

following steps to resolve this error.

To make sure the ink cartridges are properly installed

1. Make sure the product is turned on.

2. Open the ink cartridge access door by lifting from the front right of the product,

until the door locks into place.

Errors 97

HP PHOTOSMART PLUS B209 User Manual 2

Specifications and Main Features

Frequently Asked Questions

User Manual

Contents

HP Photosmart Plus B209 series Help 3

Add the HP Photosmart to a network

Finish setting up the HP Photosmart

Install the software for a network connection

Set up a Bluetooth connection

Printer parts

Get to know the HP Photosmart

Control panel features

How do I?

Print documents

Print

Print photos

Print a creative project

Print a Web page

Print forms and templates (Quick Forms)

Scan to a computer

Scan

Scan to a memory card or USB storage device

Copy text or mixed documents

Copy

Reprint photos

Save photos to your computer

Save photos

Back up photos to a USB storage device

Check the estimated ink levels

Maintain the HP Photosmart

Order ink supplies

Replace the cartridges

Cartridge warranty information

Print and evaluate a print quality report

HP support

HP support by phone

Solve a problem

Phone support period

Placing a call

After the phone support period

Additional warranty options

Setup troubleshooting

The product will not turn on

After setting up the product, it does not print

Uninstall and reinstall the software

Print troubleshooting

Check cartridges

Check paper

Check product

Print quality troubleshooting

Memory card troubleshooting

The product does not read the memory card

The photos on the memory card do not transfer to my computer

Photos in a connected digital camera with PictBridge do not print

Scan troubleshooting

Text is incorrect or missing

Copy troubleshooting

Fit to Page is not working as expected

Errors

Product messages

Photo tray problem

Missing HP Photosmart Software

File messages

Photos not found

Supported file types for the product

File corrupted

General user messages

Memory card error

Cannot crop

Paper messages

Ink cartridge and printhead messages

General printer error

Incompatible ink cartridges

Ink cartridge problem
