HP Pavilion 7867 Upgrade and Service Guide

upgrading and servicing

hp pavilion home pc

the pc

The information in this document is subject to change without notice.

Hewlett-Packard® Company makes no warranty of any kind with regard to this material, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose.

HP shall not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance, or use of this material.

HP assumes no responsibility for the use or reliability of its software on equipment that is not furnished by HP.

This document contains proprietary information that is protected by copyright. All rights are reserved. No part of this document may be photocopied, reproduced, or translated to another language without the prior written consent of HP.

Hewlett-Packard Company Home Products Division P.O. Box 4010 Cupertino, CA 95015-4010 USA

Company in the United States of America and other countries.

Other brand or product names are trademarks of their respective holders.

Warning: The HP Pavilion PC may come with software that allows you to copy audio files in the MP3 format. Unauthorized reproduction and distribution of audio MP3 files, or any portion of them, can result in civil and criminal penalties.

Features of the HP Pavilion

On the top of the chassis is a CD holder (A). Store the CDs that came with the HP Pavilion inside this compartment, so you can quickly locate them if you ever need to reinstall any of the system applications.

To connect components to the front of the PC, flip up the port cover (B) and plug the cables into the corresponding connectors. For more information about these ports, see “Connecting External Components” in the User’s Guide.

Note: The power supply is pre-set for the country in

which you purchased the HP Pavilion. If you move to another location, please make sure you check the voltage requirements in the country you reside before turning on the PC.

components. If an ESD station is not available,

Opening the Computer

Warning: The HP Pavilion is heavy; be sure

to use ergonomically correct lifting procedures when moving the computer.

Avertissement : L’ordinateur HP Pavilion

est lourd ; suivez des procédures ergonomiques lorsque vous le déplacez.

Warning: Electrostatic discharge (ESD) can

damage disk drives, add-in cards, and other

wear a wrist strap attached to a metal part of the computer. Place cards on a conductive foam pad or inside the conductive wrapper they came in; do not place the cards on top of the wrapper.

Avertissement : Des décharges

électrostatiques peuvent endommager les unités de disque, cartes d'extension et autres composants. Si vous ne disposez pas d'une

station de protection contre les décharges électrostatiques, portez un bracelet antistatique relié à une partie métallique de l'ordinateur. Placez les cartes sur un tapis en mousse conducteur ou dans leur emballage, mais ne les posez jamais sur leur emballage.

Warning: Do not operate the system with

the cover removed. Always replace the cover before turning on the system.

Avertissement : N’utilisez pas le système

lorsque son capot est ouvert. Remettez toujours le capot en place avant de mettre le système sous tension.

Before You Begin

Read the following items before attempting to upgrade or service the computer:

These procedures assume familiarity with the general terminology associated with personal computers and with the safety

practices and regulatory compliance required for using and modifying electronic equipment.

Set up an equipment log to record the system model and serial numbers, all installed options, and other information about the system. If you need this information, it will be easier to consult the log than to open up and examine the system.

HP recommends that you use an antistatic wrist strap and a conductive foam pad when working on the system.

Disconnect the system from any telecommunications links, networks, or modems, and then disconnect the system power source before performing any of the procedures described in this guide. Failure to do so before you open the system or do any procedures can result in personal injury or equipment damage.

Note: Disconnect the modem/phone cable before

disconnecting the power cord from the system.

To gain access to the inside of the computer, remove the side panel.

Removing the Side Panel

You must remove the side panel to add memory, insert add-in cards, install or remove drives, or change the battery.

1 Turn off the computer and all peripherals. 2 Disconnect the modem/phone cable. 3 Disconnect the power cord and all other

attached cables (such as the keyboard, mouse, and monitor).

4 Loosen the two thumb screws on the right

side of the back panel. The first time you loosen these screws you’ll need a flathead screwdriver. (These screws do not detach; they’ll stay on the side panel loosely until you tighten them again.)

5 Stand behind the computer, and place one

hand on top of the chassis.

6 Grasp the handle (A) with your other hand

and pull the panel towards you until it stops.

7 Lift the panel up and out. Set the panel

aside.

Removing the Fan Duct

To access some components on the motherboard, you may need to remove the fan duct.

Note: Make sure the computer is turned off and the

modem/phone cable and power cord are disconnected from the computer.

1 Remove the side panel (see “Removing the

Side Panel” on page 3).

2 Gently lay the computer on its side. 3 To disengage the fan duct (B), push down

on the two tabs (C). You can push with your fingers or a pen.

4 Rotate the fan duct down and out to

remove it from the chassis.

Removing the Drive Cage

The HP Pavilion has two drive cages. The top cage that holds the CD drive(s) is stationary. The bottom cage holds the diskette and hard drive and is removable. You may need to remove this bottom drive cage to access

internal components or to add or replace a hard drive.

Note: Make sure the computer is turned off and the

modem/phone cable and power cord are disconnected from the computer.

1 Remove the side panel (see “Removing the

Side Panel” on page 3).

2 Gently lay the computer on its side. 3 Remove the fan duct (see “Removing the

Fan Duct” on page 5).

4 Remove the power and IDE cables from the

back of the diskette and hard drives. Make note of each connection before disconnecting the cables.

5 Push down on the drive cage release tab

(D).

6 Hold the release tab down as you rotate

the cage up and lift it out.

Adding Memory

The motherboard contains 168-pin DIMM (dual-inline memory module) sockets; the exact number of sockets depends on which model you have. You can install these types of DIMMs in the system:

64 MB SDRAM

128 MB SDRAM

256 MB SDRAM

All installed memory modules must be 168pin unbuffered SDRAM (synchronous dynamic random access memory) DIMMs and compliant with the Intel® PC SDRAM Unbuffered DIMM Specification.

The HP Pavilion ships with one or more DIMMs, but you can replace the existing DIMM(s) with higher capacity ones.

Installing a DIMM

To install a DIMM:

1 Turn off the computer and all peripherals. 2 Disconnect the modem/phone cable. 3 Disconnect the power cord and all other

attached cables (such as the keyboard, mouse, and monitor).

4 Remove the side panel (see “Removing the

Side Panel” on page 3).

5 Gently lay the computer on its side.

6 Locate the DIMM sockets on the

motherboard.

Note: If all of the DIMM sockets are filled, you need to

remove one of the DIMMs (see “Removing a DIMM” on page 9).

7 If necessary to reach the DIMM socket,

remove the fan duct (see “Removing the Fan Duct” on page 5).

8 If necessary to reach the DIMM socket,

remove the drive cage (see “Removing the Drive Cage” on page 5).

9 Move any cabling out of the way,

if necessary.

10 Push down on the two retaining clips on

the ends of the DIMM socket.

11 Holding the new DIMM by its edges only,

remove it from the antistatic packaging. (Avoid touching the memory chips or the gold contacts on the DIMM.) The DIMM has two small notches on the lower edge that fit into raised bumps in the DIMM socket.

12 Hold the DIMM in alignment with the

socket, aligning the notches with the bumps.

13 Push straight down on top of the DIMM

until it is fully seated in the socket. The retaining clips on the ends of the socket

automatically lock it into position when the DIMM is fully seated.

To reassemble the computer:

1 If you moved any cabling, put them back

into place.

2 Replace the drive cage, fan duct, and side

panel (see “Closing the Computer” on page 20).

3 Reconnect the power cord and all other

cables.

4 Reconnect the modem/phone cable. 5 Turn on the computer and all peripherals.

Removing a DIMM

1 Turn off the computer and all peripherals. 2 Disconnect the modem/phone cable. 3 Disconnect the power cord and all other

attached cables (such as the keyboard, mouse, and monitor).

4 Remove the side panel (see “Removing the

Side Panel” on page 3).

5 Gently lay the computer on its side. 6 Locate the DIMM sockets on the

motherboard.

7 If necessary to reach the DIMM socket,

remove the fan duct (see “Removing the Fan Duct” on page 5).

8 If necessary to reach the DIMM socket,

remove the drive cage (see “Removing the Drive Cage” on page 5).

9 Move any cabling out of the way,

if necessary.

10 Push down on the two retaining clips on

the ends of the DIMM socket until the DIMM pops out of the socket.

exceed the total number of slots multiplied by

volts, à chaque carte installée sur l'ordinateur.

Warning: Do not pull the DIMM out of the

socket. Use the retaining clips to eject the DIMM.

11 Holding the DIMM by its edges only, lift it

away from the socket. Store it in its antistatic packaging.

To install a new DIMM in this socket, see “Installing a DIMM.”

Installing Add-In Cards

At some point, you may want to add a card to the computer to accommodate a new component, such as a scanner, or to upgrade an existing card.

Warning: Do not overload the system by

installing add-in cards that draw excessive current. The system is designed to provide 2 amps (average) of +5 V power for each board/card in the computer. The total +5 V current draw in a fully loaded system (one with all add-in card slots filled) must not

2 amps.

Avertissement : Ne surchargez pas

l'ordinateur en installant des cartes d'extension qui consomment beaucoup de courant. L'ordinateur est conçu pour fournir un courant de 2 ampères (en moyenne), +5

La consommation totale de courant de +5 V sur un ordinateur entièrement chargé (dont tous les logements de cartes sont occupés) ne doit pas excéder le nombre total de supports multiplié par 2 ampères.

To add or replace an add-in card:

1 Turn off the computer and all peripherals.

2 Disconnect the modem/phone cable. 3 Disconnect the power cord and all other

attached cables (such as the keyboard, mouse, and monitor).

4 Remove the side panel (see “Removing the

Side Panel” on page 3).

5 Gently lay the computer on its side.

6 To release the add-in card bracket (A),

push down on the release mechanism (B) as you pull the bracket.

7 Pull the add-in card bracket up and out. 8 If you’re adding a new card to a previously

unused slot, remove the expansion slot cover.

Warning: Be careful of the sharp edges on

the expansion slot cover.

If you’re replacing a card, first disconnect any external and/or internal cables attached to the card. Hold the metal bracket and the far top corner of the card. Carefully remove the card by pulling the card straight out of the expansion slot.

9 Insert the new card into the slot and push

straight down. Make sure the card is properly seated.

10 To replace the add-in card bracket, slide

the bracket into the hole (C) and then push down until the bracket clicks into place.

To reassemble the computer:

1 Replace the side panel (see “Replacing the

Side Panel” on page 23).

2 Reconnect the power cord and all other

cables.

3 Reconnect the modem/phone cable.
